Motorola Mobility P56KR1 i410 iDEN/MOTOTALK PORTABLE WITH BLUETOOTH User Manual Exhibit 12
Motorola Mobility LLC i410 iDEN/MOTOTALK PORTABLE WITH BLUETOOTH Exhibit 12
Users Manual
FCC Filing Package for Motorola i410 Transceiver FCC ID: IHDP56KR1
Temporary Confidentiality Requested
iDEN, Motorola Inc., 600 North US Hwy 45, Libertyville, IL 60048, USA WWW.MOT.COM/iDEN
Exhibit 8: Draft User’s Manual -- 47 CFR 2.1033(b)(3)
The attached User’s Manual is the final production-intended version of the generic Motorola
International English User Manual. This guide will be adapted to carrier-specific versions, but the key
information herein will be retained. Translations into other languages will also be done to support the
needs of other markets. Minor revisions may be made to these manuals, prior to and subsequent to,
placing this product onto the market. Selected portions of the User Guide can be found as indicated
below:
8.1 Part 15B Declaration of Conformity: Page 4
8.2 Safety Section: Page 77
8.3 Specific Absorption Rate (SAR) Data: Page 85
8.4 Guidance for use with Hearing Aids: Page 59, 90
User’s Guide
i410
DECLARATION OF CONFORMITY
Per FCC CFR 47 Part 2 Section 2.1077(a)
Responsible Party Name: Motorola, Inc.
Address: 8000 West Sunrise Boulevard
Plantation, FL 33322 USA
Phone Number: 1 (800) 453-0920
Hereby declares that the product:
Product Name: i410
Model Number: H76XAH6JR7AN
FCC-ID: IHDP56KR1
Conforms to the following regulations:
FCC Part 15, subpart B, section 15.107(a), 15.107(d) and section 15.109(a)
FCC Notice to Users
The following statement applies to all products that have
received FCC approval. Applicable products bear the FCC logo,
and/or an FCC ID in the format FCC-ID: IHDP56KR1 on the product
label.
Motorola has not approved any changes or modifications to this device by
the user. Any changes or modifications could void the user’s authority to
operate the equipment. See 47 CFR Sec. 15.21.
Class B Digital Device
As a personal computer peripheral, this device complies with part 15 of
the FCC Rules. Operation is subject to the following two conditions: (1)
This device may not cause harmful interference, and (2) this device must
accept any interference received, including interference that may cause
undesired operation. See 47 CFR Sec. 15.19(3).
Note:
This equipment has been tested and found to comply with the limits for
a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular
installation.
If this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and on,
the user is encouraged to try to correct the interference by one or more of
the following measures:
•
Reorient or relocate the receiving antenna.
•
Increase the separation between the equipment and receiver.
•
Connect the equipment into an outlet on a circuit different from
that to which the receiver is connected.
•
Consult the dealer or an experienced radio/TV technician for
help.
Industry Canada Notice to Users
Operation is subject to the following two conditions: (1) This device may
not cause interference and (2) This device must accept any interference,
including interference that may cause undesired operation of the device.
See RSS-GEN 7.1.5.
Motorola, Inc.
Consumer Advocacy Office
600 North US Highway 45
Libertyville, IL 60048
www.hellomoto.com
Note:
Do not ship your phone to the above address. If you need to
return your phone for repairs, replacement, or warranty service,
please contact the Motorola Customer Support Center at:
1-800-453-0920 (United States)
1-877-483-2840 (TTY/TDD United States for hearing impaired)
Certain mobile phone features are dependent on the capabilities
and settings of your service provider’s network. Additionally,
certain features may not be activated by your service provider,
and/or the provider's network settings may limit the feature’s
functionality. Always contact your service provider about feature
availability and functionality. All features, functionality, and other
product specifications, as well as the information contained in this
user's guide are based upon the latest available information and
are believed to be accurate at the time of printing. Motorola
reserves the right to change or modify any information or
specifications without notice or obligation.
MOTOROLA and the Stylized M Logo are registered in the US
Patent & Trademark Office. All other product or service names are
the property of their respective owners. Java and all other
Java-based marks are trademarks or registered trademarks of Sun
Microsystems, Inc. in the U.S. and other countries.
© Motorola, Inc., 2009.
Manual Number: NNTN7813A
1
HELLOMOTO
Introducing your new Motorola i410 phone. Here’s a quick anatomy lesson.
Left Soft Key
Perform function
in lower left
display.
Right Soft Key
Perform function
in lower right
display.
End/Power Key
End calls, exit
menu system,
turns phone
on/off.
Web Key
Talk Key
Make &
answer calls.
4-Way Navigation
Key
Volume Keys
PTT Button
Micro USB
Connector
Connects charger
and accessories.
Audio Jack
Menu Key
From home screen,
open main menu.
OK Key
Ready
10:05 am 4/17
Contcs Msgs
Ready
10:05 am 4/17
Contcs Msgs
2
check it out
up, down, left or right ( )
2
Customizable
r
key
to open the
Settings
screen
1
Press and hold the
Power Key
for a
few seconds, or until
the screen lights up,
to turn on your phone.
3
4
Press the
r
key
to select.
Press the Navigation Key
to highlight a menu feature.
that can be used
@
Ready
10:05 am 4/17
Contcs Msgs
Ready
10:05 am 4/17
Contcs Msgs
3
contents
contents
check it out . . . . . . . . . . . . 2
menu map . . . . . . . . . . . . . 5
use and care . . . . . . . . . . . 7
essentials . . . . . . . . . . . . . 8
about this guide . . . . . . 8
SIM card . . . . . . . . . . . . 9
battery . . . . . . . . . . . . . . 9
turn it on & off . . . . . . 12
enable security . . . . . 12
make a phone call. . . 12
answer a phone call . 12
make a private call . . 13
answer a private call 13
store a phone
number or private ID. 14
call a stored phone
number or private ID. 14
your phone number
and Private ID . . . . . . 15
text messages . . . . . . 15
main attractions . . . . . . 21
media center . . . . . . . 21
PTV features . . . . . . . 22
one touch PTT. . . . . . 29
PT manager . . . . . . . . 30
MMS. . . . . . . . . . . . . . 30
bluetooth
®
. . . . . . . . . 45
basics . . . . . . . . . . . . . . . 49
display . . . . . . . . . . . . 49
text entry . . . . . . . . . . 50
volume . . . . . . . . . . . . 52
navigation key. . . . . . 53
handsfree speaker . . 53
transmitters . . . . . . . . 53
features for the
hearing impaired. . . . 54
calls. . . . . . . . . . . . . . . . . 56
recent calls . . . . . . . . 56
redial. . . . . . . . . . . . . . 57
voice names . . . . . . . 57
caller ID . . . . . . . . . . . 58
call forward . . . . . . . . 58
emergency calls . . . . 59
international calls . . . 59
speed dial . . . . . . . . . . 60
turbo dial . . . . . . . . . . . 60
voice mail . . . . . . . . . . 61
customize. . . . . . . . . . . . . 62
ring tones . . . . . . . . . . 62
wallpaper . . . . . . . . . . 63
backlight . . . . . . . . . . . 64
datebook . . . . . . . . . . . 64
hide or show
location information . 65
other features . . . . . . . . . 66
advanced calling . . . . 66
contacts . . . . . . . . . . . 67
datebook . . . . . . . . . . . 67
GPS . . . . . . . . . . . . . . . 68
handsfree . . . . . . . . . . 69
personalize . . . . . . . . . 70
pc applications. . . . . . 70
4
contents
TTY . . . . . . . . . . . . . . . . 70
security . . . . . . . . . . . . 71
Legal and Safety. . . . . . . 72
Safety and General
Information . . . . . . . . . 72
Operational
Precautions . . . . . . . . 73
RF Energy
Interference/
Compatibility. . . . . . . . 73
Bluetooth . . . . . . . . . . 74
Caring for the
Environment by
Recycling . . . . . . . . . . 75
Driving Precautions . 75
Operational
Warnings. . . . . . . . . . . 75
Service and Repairs . 77
Export Law
Assurances . . . . . . . . 78
Battery Use and
Safety . . . . . . . . . . . . . 78
Battery Charging . . . . 80
Specific Absorption
Rate . . . . . . . . . . . . . . . 80
AGPS and Emergency
Calls . . . . . . . . . . . . . . 81
Motorola Limited
Warranty for the
United States
and Canada . . . . . . . . 82
Hearing Aid
Compatibility With
Mobile Phones . . . . . 85
Information From
the World Health
Organization . . . . . . . 86
Product Registration 86
Wireless: The New
Recyclable. . . . . . . . . 87
California
Perchlorate Label. . . 87
Patent and
Trademark
Information . . . . . . . . 87
Software Copyright
Notice. . . . . . . . . . . . . 87
Privacy and Data
Security . . . . . . . . . . . 88
Smart Practices
While Driving . . . . . . . 88
index. . . . . . . . . . . . . . . . . 90
5
menu map
menu map
main menu
p
Call Alert
L
Java Apps.
• Java System
u
Settings
• (see next page)
t
Ring To n e s
• Vibrate All: On/Off
• Ringer
• Vibrate
• Silent
c
GPS
• Position
• Privacy
• Interface
P
Call Forward
D
Datebook
l
Memo
1
Net
J
My Info
•My Name
• Line 1
• Private ID
• Group ID
• Carrier IP
• IP1 Address
• IP2 Address
• Circuit Data
0
VoiceRecord
• [New VoiceRec]
B
Recent Calls
j
Media Center
K
Shortcuts
•[New Entry]
• 1)Shortcuts
• 2)Cntcs[New Contact]
• 3)Recent Calls
• 4)Contacts
• 5)Datebook
• 6)Messages
•7)VoiceRecord
•8)Net
• 9)Call Forward
A
Contacts
• [New Contact]
o
Profiles
M
Call Timers
•Last Call
• Phone Reset
• Phone Lifetime
•Prvt/Grp Reset
• Prvt/Grp Life
• Circuit Reset
• Circuit Lifetime
•Kbytes Reset
N
PT Manager
•Quick PTT
• Send Message
• Send Picture
• Send Event
• Send My Info
• Send Contact
• Configure
E
Messages
• [Create Message]
• [Create Txt Msg]
• [Create MMS Msg]
•Voice Mail
• Inbox
•Drafts
• Outbox
•Net Alert
C
Bluetooth
• Hands Free
• Link to Devices
• Device History
•Setup
• Find Me
This is the standard Main Menu layout.
Your phone’s menu may be a little
different.
6
menu map
settings menu
Display/Info
• Wallpaper
•Text Size
• Theme
• Home Icons
• Backlight
•Clock
• Menu View
• Large Dialing
• Language
Phone Calls
• Set Line
•Any Key Ans
• Auto Redial
• Call Waiting
• Auto Ans
• Flip Activation
• Minute Beep
• Call Duration
• TTY
• Hearing Aid
• Notifications
• DTMF Dialing
• Prepend
2-Way Radio
• Tkgrp Silent
•Tkgrp Area
• One Touch PTT
• Alert Type
•PTT Quick Notes
•On/Off PTT
• Store Rcvd Info
• PTT Backlight
Personalize
• Menu Options
•Up Key
•Down Key
•Left Key
• Right Key
• Center Key
• Left Sftkey
• Right Sftkey
•Power Up
Vol u me
• Line 1
• Messages
• Earpiece
• Speaker
•Keypad
• Java Earpiece
• Java Spkr
•Data
Security
• Phone Lock
• Keypad Lock
•SIM PIN
• GPS PIN
• Change Passwds
Advanced
• Alert Timeout
• Headset/Spkr
• Connectivity
• Reset Defaults
• Return to Home
• Transmitters
• Phone Only
• Baud Rate
7
use and care
Use and Care
To care for your Motorola phone, please keep it away from:
liquids of any kind dust and dirt
Don’t expose your phone to water, rain,
extreme humidity, sweat, or other
moisture. If it does get wet, don’t try to
accelerate drying with the use of an
oven or dryer, as this may damage the
phone.
Don’t expose your phone to dust, dirt,
sand, food, or other inappropriate
materials.
extreme heat or cold cleaning solutions
Avoid temperatures below 0°C/32°F or
above 45°C/113°F
.
To clean your phone, use only a dry soft
cloth. Don’t use alcohol or other
cleaning solutions.
microwaves the ground
Don’t try to dry your phone in a
microwave oven.
Don’t drop your phone.
8
essentials
essentials
Caution:
Before using the phone for the first
time, read the Important Safety and Legal
information included in the gray edged pages
at the back of this guide.
about this guide
This guide shows how to locate a menu
feature as follows:
Find it:
/
>
Settings
This means that, from the home screen:
1
Press the menu button
/
to open the
Main Menu
.
2
Press the navigation key to scroll to
Settings
.
3
Press the center key
r
to select it.
symbols
This means a feature is network/
subscription dependent and may
not be available in all areas. Contact
your service provider for more
information.
This means a feature requires an
optional accessory.
9
essentials
SIM card
insert the SIM card
Turn off your phone and remove your battery
before you install or remove a SIM card.
Carefully slide the SIM chip into your phone,
until it lies flat in the SIM chip holder.
Warning:
To avoid loss or damage, do not
remove your SIM chip from your phone unless
absolutely necessary.
battery
battery installation
1
Slide the battery door up until it is
released.
10
essentials
battery charging
New batteries are not fully charged.
charge using the charger
1
Pull out the connector cover, and insert
the charger into the accessory connector
on your phone as shown.
2
Plug the other end of the charger into the
appropriate electrical outlet.
When you charge the battery, the battery level
indicator at the upper right of the screen
shows charging progress. At least one
segment of the indicator must be visible to
ensure full phone functionality while charging.
2
Remove battery door.
3
Insert battery as shown below. Push the
battery down until it snaps in place.
4
Replace the battery door.
11
essentials
charge from your computer
You can partially charge your phone’s
battery by connecting a Motorola-approved
USB cable from your phone’s micro-USB port
to a high power USB connector on a
computer (not a low-power one, such as the
USB connector on your keyboard or
bus-powered USB hub). Typically, USB
high-power connectors are located directly on
your computer.
Note:
The phone will be charged at a slower
rate than it is charged with the rapid charger.
Your computer must be turned on, and you
must have correct software drivers installed
on your computer. If the Phone is off when
the USB cable is connected between the
computer and the phone, the phone will
power up in charging mode. This mode allows
the phone to charge fastest and quickest.
Note:
If the battery is very low, the phone will
not turn On, but it will continue to charge at a
low rate. The phone will power up in charging
mode when the battery has been charged to
approximately 5% of its capacity. For faster
charging under a very low battery condition, it
is recommended to use the rapid charger
supplied with the handset.
If the phone is turned on while charging from
a computer, it will not fully charge the battery.
In this case, the battery charge will be
maintained approximately between 80% and
95% of the battery's capacity. Cables and
software drivers are available in Motorola
Original
TM
data kits, sold separately.
Tip:
Motorola batteries have circuitry that
protects the battery from damage from
overcharging. Of course, unplugging the
charger from the wall will prevent the battery
from overcharging.
12
essentials
turn it on & off
To turn on you r
phone, press and
hold
@
for a few
seconds or until the
display turns on.
To turn off your phone, press and hold
@
for
two seconds.
Note:
If you press
@
for more than four
seconds, the handset will power “On” on
“Transmitter Off” mode. See “transmitters”
on page 53.
enable security
You must enable security the first time you
power on you phone or within 10 days of first
activation.
1
Press
-
under
Ok
.
2
Your are prompted to enable security.
Press
-
under
Yes
. A series of screens
followed by the default home page
displays.
3
Press
@
to return to the home screen.
make a phone call
Enter a phone number and press
`
to make
a call or use a voice name. See “voice
names” on page 57.
Note:
For best call quality avoid covering the
antenna with your hand.
To hang up press
@
.
answer a phone call
When your phone rings and/or vibrates, you
have the following options to answer:
13
essentials
1
If you want to answer the call on the
handsfree speaker phone, press the
speaker key
s
with the flip closed. To
hang up press the smart key
(
.
2
If you want to answer the call using the
handset, just open the flip and press
`
.
To hang up press
@
or close the flip.
Note:
You must have the
Flip Activation
feature
On. See “advanced calling” on page 66.
make a private call
With Private calls service, you use your phone
as a long-range, digital 2-way radio using one-
to-one Private calls.
Your Private ID is the number at which you
receive one-to-one Private calls.
Note:
PTT means Push to Talk / Walkie-Talkie.
To make a private call
1
Enter the Private ID you want to call.
2
Press and hold the PTT button. Begin
talking after your phone emits a chirping
sound.
3
Release the PTT button to listen.
To end the call press
@
.
Note:
A Private call ends automatically if there
is no activity on the call for a few seconds.
Tip:
To let someone know you want to talk to
them on a Private call, press
-
under
Alert
.
answer a private call
1
When your phone emits a chirping sound
or vibrates to indicate you are receiving a
Private call, wait for the caller to finish
speaking.
14
essentials
2
Press and hold the PTT button and begin
talking after your phone emits a chirping
sound.
3
Release the PTT button to listen.
To end the call press
-
under
Exit
.
store a phone number
or private ID
You can store a phone number or Private ID in
Contacts
:
1
Press
/
>
Contacts
>
[New Contact]
.
2
Enter a name for the new entry. Each
entry’s name can contain up to 20
characters.
3
Select
Ringer
if you wish to assign a
specific ring tone to that phone number.
4
Select a type for the entry (
Mobile
,
Private
,
Work1
,
Work2
,
Home
,
Email
,
Fax
,
Pager
,
IP
or
Other
).
To store a Private ID, choose
Private
.
5
Enter the number for the entry and press
-
under
Done
to save the entry.
Tip:
Before saving the entry, you can save
more information. You can store E-mail
addresses, or IP addresses. You can assign
each number a speed dial number and voice
name.
After you have saved the number, the new
Contacts entry is displayed.
call a stored phone
number or private ID
Shortcut:
From the home screen press
-
under
Contcs
or
15
essentials
Find it:
/
>
Contacts
1
Scroll to the
Contacts
entry.
Tip:
By pressing the first letter of the
name of the
Contacts
you want, you will be
taken to all the contact names starting
with the letter you pressed.
2
If the Contacts entry contains more than
one number, scroll left or right until the
type of the number you want to call is
displayed (
Mobile
,
Private
,
Work1
,
Work2
,
Home
,
etc.).
3
If you choose a phone number, press
`
to call the entry.
or
If you choose a Private ID press and hold
the PTT button to call the number.
Tip:
If the Contacts entry you scrolled to
contains a Private ID, you can make an instant
Private call to that Private ID by pressing and
holding the PTT button, even if the Private ID
is not the type of number displayed.
your phone number and
Private ID
Find it:
/
>
My Info
Tip:
Want to see your phone number or
Private ID while you’re on a call? Press
/
>
My Info
.
text messages
If your service provider offers text messaging,
your phone sends text messages using
Mobile Originated Short Messaging Services
(MOSMS) and receives text messages from
other phones that are using MOSMS.
16
essentials
Note:
The messaging menus may look
slightly different, depending on the
messaging setup of your phone.
set it up
Before you begin using text messaging, you
may need to set up your signature, service
center number, and expiration information.
Shortcut:
From the home screen press
-
under
Msgs
>
/
>
Text Msg Setup
.
or
Find it:
/
>
Messages
>
/
>
Text Msg Setup
The following options become available:
option
Signature:
Enter your signature (up to 11
characters long).
Delivery Rpt:
Set this option to
On
if you want
your phone to show you when the
message has been delivered.
Srvc Cntr No:
Enter the phone number of your
service center. If you do not know this
number, contact your service provider.
Expire After:
This is the amount of time
messages you send are saved at the
service center if they cannot be delivered.
After this period, they are discarded.
Scroll to select the number of days you
want your messages to be saved.
Cleanup:
Controls how long messages remain
in the
Inbox
and
Outbox
before they are
deleted. See “cleanup” on page 43.
Quick Notes
: Quick notes are short, pre-written
text messages that you can create, edit,
and send in your text messages. You can
store up to 20 quick notes. A quick note
may be up to 30 characters long.
You can create a
[New Note]
or press
-
under
Edit
to change the pre-written quick notes.
option
17
essentials
Press
-
under
Done
to save the information
you entered.
receive a text message
1
To view the message press
-
under
Read
.
2
To dismiss the message notification press
-
under
Exit
.
Note:
If your phone is powered off when you
receive a text message, your phone notifies
you the next time you power it on. If you are
out of your coverage area, your phone alerts
you when you return to your coverage area.
Tip:
While reading a text and numeric
message that contains a phone number, you
can press
`
to call that number.
read from the message center
1
From the home screen press
-
under
Msgs
>
Inbox
>
Text Inbox.
2
Select the message you want to read or
press the number of the message you
want to read. If the message fills more
than one screen, scroll to read it.
Tip:
Scrolling through one message lets
you view the next message.
3
To reply to the message, press
-
under
Reply
or to see all other choices, including
forwarding and deleting the message,
calling the sender, or storing the sender’s
number in
Contacts
, press
/
.
create and send text messages
1
From the home screen press
-
under
Msgs
>
[Create Message]
>
[Create Txt Msg]
.
or
Select
Inbox
>
Text Inbox
, or
Outbox
>
Text Outbox
,
or
Drafts
>
Text Draft
.
2
To address the message use the keypad
to enter the phone number of the person
18
essentials
you want to send the message to and
press
r
.
or
Press
-
under
Browse
, and select
Recent
Calls
,
Contacts
or
Memo
to find the number you
want.
3
Select
Msg
and enter the text of the
message or to use a quick note press
-
under
Browse
and scroll to the quick note
you want.
4
Press
/
>
Set Send Method
and select
Text
,
Fax
,
x400
,
Paging
,
Email
,
ERMES
, or
Voice
.
5
If you want to send the message, press
-
under
Send
or to delete the message
without sending it, press
-
under
Cancel
.
Note:
If you want to request confirmation
of delivery press
/
>
Delivery Report
>
On
.
use drafts
When you save a message as a draft, it is
saved in the drafts folder.
Shortcut:
From the home screen press
-
under
Msgs
>
Drafts
>
Text Draft
.
1
Select the draft you want to edit. You also
have the choice to create new text
messages from this menu.
2
To edit the fields you want to change,
follow step 2 through step 5 in “create
and send text messages” above.
resend text messages
Shortcut:
From the home screen press
-
under
Msgs
>
Outbox
>
Text Outbox
.
1
Scroll to the message you want to resend
or press the number of the message you
want to resend.
2
Press
-
under
Resend
.
19
essentials
delete sent text messages
Shortcut:
From the home screen press
-
under
Msgs
>
Outbox
>
Text Outbox
.
1
Scroll to the message you want to delete.
2
Press
-
under
Delete
.
3
Press
-
under
Yes
to confirm.
delete all unlocked sent messages
Shortcut:
From the home screen press
-
under
Msgs
>
Outbox
>
Text Outbox
.
1
Press
/
>
Delete All
.
2
Press
-
under
Yes
to confirm.
go to a website
If a message contains one or more website
URLs, you can go to that website. See “go to
a website” on page 39.
manage memory
Your text inbox, outbox, and drafts folder have
a set amount of memory available for storing
messages.
The text inbox holds 20 messages. If the text
inbox is full, you cannot receive messages
until you delete some.
The outbox and drafts folder share memory
space. Togheter they can hold 30 messages.
If the outbox and drafts folder memory is full,
you cannot send messages or save drafts
until you delete some.
To view the amount of memory available in
your text inbox:
Shortcut:
From the home screen press
-
under
Msgs
>
/
>
Text Msg Setup
>
Mem Mtr-Inbox
.
To view the amount of memory available in
your outbox and drafts folder:
20
essentials
Shortcut:
From the home screen press
-
under
Msgs
>
/
>
Text Msg Setup
>
Mem Mtr-Other
.
21
main attractions
main attractions
media center
The media center lets you access pictures and
audio recordings stored in your phone’s
memory.
The following audio recordings can be
accessed through the media center:
•
Voice records
•
Musical ring tones in the list of ring
tones
•
Audio recordings saved from MMS
messages received
•
Audio recordings downloaded to your
phone
Items in the media center can be sent in
MMS messages. See “MMS” on page 30.
Pictures in the media center can be sent in
Private calls using Send via PTT.
Audio files supported by the Media Center
include:
Format Sampling Rates/Bit Rates
.au 8 KHz/8 kbps
.midi 8 KHz
.mp3 8 KHz/8 kbps
.wav 8 KHz/64 kbps
22
main attractions
Image files supported by the Media Center
include:
PTV features
With Push To View features, your phone
can send and receive the following
items through Private calls with other phones
that have this capability:
•
Short text messages
1
•
Pictures
1
•
Datebook events
•
My Info
•
Contact information
You can choose to send My Info and contact
information to any Private ID.
You can choose to send pictures, messages,
events to the Private ID you are engaged in a
a Private call with, Private IDs on the
Recent Calls
list, and Private IDs stored in
Contacts
.
When you make or receive a Private call, your
phone automatically determines whether the
phone you are engaged in a Private call with is
able to receive each of these items. Your
phone saves this information for as long as
the Private ID is on your
Recent Calls
list or is
saved in your
Contacts
. Your phone updates the
saved information each time you make or
receive a call to or from that Private ID.
Format Max. Image Size (in pixels)
.png 640 x 480
.gif 640 x 480
.jpg 640 x 480
.wbmp 127 x 127
1. Additional charges may apply.
23
main attractions
You can turn your phone’s ability to send and
receive messages, pictures, events on and
off.
send messages
The Push to Send Messages feature
lets you send short text messages
through Private calls.
When you send a message, it appears on the
display of the phone you are engaged in the
Private call with. The message won’t be
stored in the recent calls list.
begin a message and choose a
recipient
You can begin a message during a Private call,
from the
Contacts
list, the
Recent Calls
list, or from
the
PT Manager
.
begin a message during a Private call:
While in a Private call, press
/
>
Use PTT Feature
>
Send Message
.
begin a message from the Contact or
the Recent Calls list
1
From the
Contacts
or the
Recent Calls
list,
select the entry containing the Private ID
you want to send the message to.
2
Press
/
>
Use PTT Feature
>
Send Message
.
begin a message from the PT Manager
The
PT Manager
lets you select the Private ID
you want to send the message to from
Contacts
or the
Recent Calls
list.
Find it:
/
>
PT Manager
>
Send Message
Then select
A Contact
or
A Recent Call
to see a list
of entries from the
Contacts
or the
Recent Calls
list
that can receive messages.
24
main attractions
create messages
After you have begun a message and chosen
a recipient, a screen appears that lets you
create the text of the message you want to
send. Your message may be up to 400
characters long.
You can choose from a list of ready-made
words or short phrases called Quick Notes.
You can use a Quick Note as it is or edit it
before you send it. Editing a Quick Note
changes the Quick Note for this message only
and will not change the Quick Note on the list.
send a completed message
After you have completed your message,
press the PTT button to send it.
receive messages
When you receive a message, a message
notification appears on the display. To view
the message press
r
.
To dismiss the message press
-
under
Dismiss
.
reply to a message
1
View the message.
2
Press
-
under
Reply
.
3
Create the message and press the PTT
button to send it.
send pictures
You can send pictures stored in
Media
Center
through Private calls. The picture you
send appears on the Private call recipient’s
display.
25
main attractions
If the recipient accepts the picture, their
phone saves the picture.
The first time you send a stored picture after
turning the phone on,
Picture Fees May Apply.
Continue?
appears and you are prompted to
respond.
Note:
You cannot make or receive Private
calls while transmitting or receiving a picture.
send a picture during a call
1
While in a Private call, press
-
under
or press
/
>
Use PTT Feature
>
Send Picture
.
A list of pictures that can be included in a
Private call appears.
2
Select the picture you want to send.
3
Press the PTT button to send the picture.
4
Wait while the picture is transmitted. The
Private call is temporarily interrupted
while a picture is transmitted.
5
When prompted, press the PTT button to
resume the Private call.
start a call by sending a picture
from Media Center
Find it:
/
>
Media Center
1
Select the picture you want to send.
2
Press
/
>
Send Via...
>
Send via PTT
.
A list of contacts that have Private IDs and
are able to receive pictures appears.
3
Select the name of the person you want
to send the picture to.
4
Press the PTT button to send the picture.
5
When prompted, press the PTT button to
resume the Private call.
26
main attractions
from the PT Manager:
Find it:
/
>
PT Manager
>
Send Picture
1
Select
A Contact
, or
A Recent Call
to see a list of
entries that can receive pictures.
2
Select the entry containing the Private ID
you want to send the message to.
3
Select the picture you want to send.
4
Press the PTT button to send the picture.
5
Once picture has been sent, when
prompted press the PTT button to resume
the call.
receive a picture
When someone sends you a picture, your
phone emits a tone or vibrates and a message
appears asking if you want to accept the
picture.
Pictures you receive are saved to your phone’s
memory. They are accessible through
Media
Center
.
When you see a message asking if you want
to accept the picture, press
Yes
to accept or
No
to decline.
Tip:
If you want to stop the transmission
before it is finished, press
@
.
Note:
The first time you accept a stored
picture after turning the phone on,
Picture Fees
May Apply. Continue?
appears and you are
prompted to respond. Press
-
under
Yes
to
accept the picture.
clear a picture from the display
If you want to clear a picture from your
phone’s display while still on a call, press
/
>
Clear Screen
.
The picture will not appear on the display
again the next time you receive a call from
27
main attractions
person who sent it. This does not delete the
picture from
Media Center
.
send My Info
1
While in a Private Call press
/
>
Send via PTT
, and push the PTT button to
send.
or
2
From the home screen press
/
>
My Info
>
/
>
Send via PTT
and
push the PTT
button to send.
set my info sending option
You can control what portion of the
information in
My Info
is sent and
whether it is sent automatically in every call or
only when you choose to send it.
Find it:
/
>
PT Manager
>
Configure
>
PTT My Info
>
Info to Send
1
Select or remove the fields you want to
send.
2
Press
-
under
Done
.
The information your phone sends always
includes
My Name
and
Private
. You may also send
Line 1
,
Carrier IP
, and
Circuit Data
depending on your
sending options.
automatic sending
To control whether you send your information
automatically:
Find it:
/
>
PT Manager
>
Configure
>
PTT My Info
>
Auto Send
1
Select
On
or
Off
.
When you make a call in which your
information is sent automatically, the name
you entered in the
My Name
field of
My Info
appears on the display of the recipient’s
phone, even if your name and Private ID are
not stored in the recipient’s Contacts.
28
main attractions
send contact information
1
While in a Private Call press
/
>
Use PTT Feature
.
2
Select
Send Contact
and select the contact
information you want to send.
3
Push the PTT button to send.
or
1
From the home screen press
/
>
PT Manager
>
Send Contact
.
2
Enter the Private ID number of the person
you want to send the Contact information
to or press
-
under
Browse
.
3
Select from
Recent Calls
,
Contacts
, or
Memo
.
4
Select the contact information you want
to send and push the PTT button.
turn PTT features on and off
You can turn your phone’s ability to send and
receive messages, pictures, and Datebook
events on and off.
You cannot turn your phone’s ability to send
and receive My Info and contact information
on and off.
Find it:
/
>
PT Manager
>
Configure
1
Select
On/Off PTT
.
2
Check or uncheck
Messages
,
Pictures
and/or
Events
.
29
main attractions
one touch PTT
Find it:
/
>
PT Manager
>
Configure
>
One Touch PTT
One Touch PTT
sets your phone to do any of the
following each time you press the PTT button
from the home screen:
quick PTT
Quick PTT lets you quickly make a call.
To view a list of Contacts with Private IDs in
Contacts
:
Find it:
/
>
PT Manager
>
Quick PTT
or
option
Off
: Nothing happens when you press the
PTT button from the home screen.
Quick PTT
: Go to Quick PTT. See “quick PTT”
on page 29.
Last Call
: Call the most recent Private ID or
Group on the recent calls list.
Assigned No.
: Call a Private ID you assign.
Enter the number using your keypad, or
press
-
under
Search
. Select
Contacts
,
Recent
Calls
, or
Memo
.
PT Manager
: Go to PT Manager. See “PT
manager” on page 30.
Send Message
: Go to the first screen to send a
message.
Send Picture
: Go to the first screen to send
pictures. See “send pictures” on page 24.
Send Event
: Go the the first screen to send a
Datebook event.
Send My Info
: Go to the first screen to send My
Info. See “send My Info” on page 27.
Send Contact
: Go to the first screen to send a
contact. See “send contact information” on
page 28.
option
30
main attractions
Find it:
/
>
Quick PTT
To move between
Contacts
,
Recent Calls
, or
Memo
,
use the left or right, or press
*
or
#
.
To make a Private call:
1
Select the entries you want.
2
Press
Done
.
3
Push the PTT button.
PT manager
The
PT Manager
lets you quickly access PTT
features, and other Private call features, from
the main menu.
You can also access the Quick PTT feature and
set the One Touch PTT feature.
Find it:
/
>
PT Manager
1
Select
Quick PTT
to quickly find a contact
that has a Private ID.
or
2
Select
Send Message
,
Send Picture
,
Send Event
,
Send
My Info
, or
Send Contact
. After choosing what
PTT item you are sending, select a
contact and press the PTT button to send.
or
3
Select
Configure
to configure your
PTT Quick
Notes
,
PTT My Info
,
One Touch PTT
, or
On/Off PTT
.
MMS
Multi-Media Messaging Service (MMS) lets
you send and receive messages that may
include text, pictures and audio recordings.
create a message
Shortcut:
From the home screen press
-
under
Msgs
>
[Create Message]
>
[Creat MMS Msg]
.
or
31
main attractions
Find it:
/
>
Messages
>
[Create Message]
>
[Creat MMS Msg]
1
Select
To
and add the phone number or
email address or select from
Contacts
or
Recent Calls
and press
-
under
Back
.
Tip:
To remove a phone number or email
address from the list of message recipients,
scroll to the phone number or email address
and press
-
under
Remove
.
When you are finished addressing the
message, press
-
under
Back
.
To enter or edit the body of the message:
2
Select
Mesg
and enter text or press
-
under
QNotes
to select a pre-written quick
note.
3
Press
-
under
Back
and
-
under
Send
.
more message options
To view more message fields in a message
you are creating, select
.....MORE.....
or press
-
under
More
.
option
Subject
: Create or edit the subject line.
Attach
: Attach a picture, audio file or voice
record.
Cc
: Send a copy of this message to
someone else.
Auto Replies
: Allows you to create a list of
possible short answers for the recipient to
choose when replying to your message.
Priority
: Set priority
Normal
or
High
.
Report
: Set receipt confirmation
On Delivery
.
Valid Until:
Set a date after which attempts to
deliver the message end, or press
-
under
No Date
.
32
main attractions
reply to a message
You can reply to a message while you are
viewing it, or while a previously viewed
message is highlighted in the message
center. You cannot reply to unread messages.
To reply to a message:
1
View the message you want to reply to.
2
To reply to the sender only, press
-
under
Reply
or if you wish to include all the
people copied in the message, press
-
under
Reply All
.
A list of short phrases appears. Select any
of these phrases to add it to your
messages or select
[Create Reply]
.
3
Edit any message fields you want to
change.
4
Press
-
under
Send
.
quick notes
When you are filling in the
Message
and
Subject
message fields, you can add ready-made
words or short phrases called Quick Notes.
After you add these words or phrases, you
can edit them as you would any other text.
1
While you are creating a message, scroll
to or select
Message
or
Subject
.
2
Press
-
under
QNotes
.
Select the Quick Note you want to insert
into the message.
3
Press
-
under
Send
.
attach a picture, audio and
voice recording
You can attach one or more pictures, audio or
voice recordings from your phone into the
body of the message. You can include text in
33
main attractions
the body of your message in addition to these
items.
While you are filling in the
Attach
field, press
[New]
>
Browse Pictures
or
Browse Audio
.
A list of available pictures, audio and voice
recordings appears.
Select the picture, audio or voice record you
want to attach.
Tip:
To view or listen to the item before
attaching it, highlight it and press
Preview
.
Note:
You can only attach audio files and
pictures if they are not forward locked and if
their DRM settings do not prevent you from
sending.
Forward locked items are usually copyright
protected, and you cannot share them with
anyone, such as in Private calls or by
uploading them from your phone.
create a new voice record
You can create a new voice record to send
with a message:
1
Press
/
or press
-
under
Attach
>
[New]
.
2
Select
Record Voice
.
3
Say the message you want to record into
the microphone.
4
When you are finished recording,
press
r
.
5
When you are finished, press
-
under
Done
.
The voice record is attached to the message
and saved to the list of voice records.
remove an attachment
To remove an attachment in a message you
are creating:
1
Select
Attach
.
34
main attractions
2
Scroll to the attachment you want to
remove.
3
Press
/
>
Unattach
.
drafts
While you are creating a message, you can
save it in the MMS drafts folder before you
send it.
You can view, edit, send, or delete saved
drafts.
save a message in the MMS
drafts folder
From the Message center press
/
>
Save
.
You can continue to create the message. The
version you saved in the MMS drafts folder
will not change.
send a draft
Shortcut:
From the home screen press
-
under
Msgs
>
Drafts
>
MMS Drafts
.
1
Select the draft you want to send.
2
Press
-
under
Send
.
edit a draft
Shortcut:
From the home screen press
-
under
Msgs
>
Drafts
>
MMS Drafts
.
Select the draft you want to edit and press
O
.
delete a draft
When you send a draft, it is removed from the
MMS drafts folder.
To delete a message in the MMS drafts folder
without sending it, scroll to the message you
want to delete and press
-
under
Delete
and
-
under
Yes
.
35
main attractions
MMS outbox
MMS messages you have sent or tried to
send are stored in the MMS Outbox.
forward items from the outbox
Shortcut:
From the home screen press
-
under
Msgs
>
Outbox
>
MMS Outbox
.
1
Scroll to the message you want to
forward.
2
Press
/
>
Forward
.
3
Edit and send your message.
resend
If a message was not sent from your handset,
you can resend it.
Shortcut:
From the home screen press
-
under
Msgs
>
Outbox
>
MMS Outbox
.
1
Scroll to the message you want to resend.
2
Press
Resend
.
Note:
If your message was sent successfully,
Resend
will not appear as an option.
check delivery status
If a message was successfully sent and you
set the message to give a report confirming
delivery, you can check the delivery status:
Shortcut:
From the home screen press
-
under
Msgs
>
Outbox
>
MMS Outbox
.
1
Scroll to the message you want to view.
2
Press
/
>
Delivery Status
.
delete a message
1
Scroll to the message you want to delete.
2
Press
-
under
Delete
.
or
3
Press
/
>
Delete Multiple
.
36
main attractions
4
Select the message or messages you
want to delete.
5
Press
-
under
Delete
to confirm.
receive a message
When you receive an MMS message, a
message notification appears on the display.
1
To view the message press
r
.
2
If the message fills more than one screen,
use the navigation key to scroll down
and read the remaining text.
message notifications
When you receive a message, your phone
notifies you with text on the display, a
notification tone or vibration.
You can access the message or dismiss the
notification.
If you dismiss the notification, the message is
not deleted. It can be accessed through the
message center.
If you are not on a phone call when you
receive a message, your phone sounds a
notification tone every 30 seconds until you
access the message or dismiss the alert.
If you are on a call when you receive a
message, your phone may sound a
notification tone during the call or after you
end the call, depending on how you set your
notification options.
set notification options
To control whether your phone sounds
message notification tones while you are on a
phone call:
Find it:
/
>
Settings
>
Phone Calls
>
Notifications
.
37
main attractions
Select from the following options:
Tip:
To set notification options during a call
press
/
>
Call Setup
>
Notifications
.
embedded objects and
attachments
Messages may contain pictures or audio
recordings as part of the body of the message
or as attachments.
If a message contains pictures or audio
recordings in the body of the message,
highlight each picture or audio recording to
view or play it.
If a message contains a picture or audio
recording as an attachment, open the
attachment to view the picture or play the
audio recording.
open attachments
1
View the message.
2
Highlight the attachment you want to
open and press
r
. Attachments appear
at the end of a message.
Note:
Attachments that are of an unknown
type cannot be opened, but they can be
deleted.
option
Receive All
: Tones sound during calls for all
types of messages.
Msg Mail Only
: Tones sound during calls for
mail messages; tones for all other types of
messages are held until you end calls.
Delay All
: Tones for all types of messages are
held until you end calls.
Note:
Delay All
is the default setting.
38
main attractions
view received messages from
the message center
Shortcut:
From the home screen press
-
under
Msgs
>
Inbox
>
MMS Inbox
.
use auto replies
If the message you are replying to was sent
with auto replies, it contains a numbered list
of possible replies for you to send. Press the
number of the reply you want to send. The
reply is sent immediately without further
action.
delete unread messages
1
Scroll to the message you want to delete.
2
Press
-
under
Delete
.
3
Press
-
under
Yes
to confirm.
forward a message
1
Press
/
>
Forward
.
2
Create and send your message.
Embedded objects and attachments are
included when you forward a message.
lock and unlock messages
Locked messages cannot be deleted until you
unlock them.
1
View the message you want to lock or
unlock.
2
Press
/
>
Lock Message
or
/
>
Unlock Message
.
call a number in a message
If a message you receive contains a phone
number or Private number in the From field,
the To field, the Cc field, the subject line, or
the body of the message, you can call or send
a call alert to that number.
39
main attractions
send a call alert
1
View the message.
2
Highlight the Private number you want to
alert.
3
Press
/
>
Alert
.
4
Push the PTT button.
store message information to
contacts
If a message you receive contains a phone
number, Private number, or an email address
in the From field, the To field, the Cc field, the
subject line, or the body of the message, you
can store this information to Contacts.
1
View the message.
2
Highlight the number or email address
you want to save.
3
Press
/
>
Save Number
or
/
>
Save Email
.
4
To store the number or email address as a
new entry, select
[New Contact]
.
To store the number or email address to
an existing entry, select the entry.
5
With the Contacts type field highlighted,
scroll left or right to display the Contacts
type you want to assign the number or
email address.
6
Press
-
under
Done
.
go to a website
If a message contains one or more website
URLs, you can go to that website.
1
View the message.
2
Highlight the website URL you want to go
to.
3
Press
/
>
Go To Website
.
Note:
The entire URL must appear in the
message to allow you to open the website.
40
main attractions
save an embedded picture or
audio recording
To save a picture or audio recording that is
part of the body of a message you receive:
1
View the message.
2
Highlight the picture or audio recording
you want to save.
3
Press
/
>
Save Picture
or
/
>
Save Audio
.
The item will save in the default storage
location.
Note:
Some types of pictures and audio
recordings can be viewed or played, but not
saved.
delete an embedded picture or
audio recording
To delete a picture or audio recording that is
part of the body of a message you receive:
1
View the message.
2
Highlight the picture or audio recording
you want to delete.
3
Press
/
>
Delete Picture
or
/
>
Delete Audio
.
save attachments
1
View the message.
2
Highlight the attachment you want to
save.
3
Press
/
>
Save Attachment
.
Selected items save to the default storage
location.
Note:
Some types of pictures and audio
recordings can be viewed or played, but not
saved. You may save pictures and audio
recordings from slide shows individually as
you view or listen to them.
41
main attractions
save a picture
1
View the slide show.
2
When the picture you want to save
appears, press
/
>
Save Picture
.
save audio
1
View the slide show.
2
Press
/
>
Save Audio
.
3
If the slide show contains more than one
audio recording, a list of the audio
recordings appears. Select the audio
recording you want to save.
message transmission
After you start to send a message you have
created or start to download a message you
have been sent, you can still stop the
message transmission from being completed.
With the flip closed, press the smart key on
the top
(
. Opening or closing the flip does
not interrupt message transmission.
customize MMS
Find it:
/
>
Messages
>
/
>
MMS Setup
This option is available from many context-
sensitive menus when you are using MMS.
The MMS Setup menu lets you customize
MMS for your handset with the following
options:
option
Friendly Name
: Enter text here to create a
friendly name. Your friendly name is the
name displayed in the
From
field on other
iDEN handsets when they receive
messages from you.
42
main attractions
new quick notes and reply
phrases
create quick notes
1
From the MMS Setup menu, select
Quick
Notes
or
Replies
.
Signature
: Enter text here to create a
signature. Your signature is text that is
automatically inserted at the end of all
messages you create. You can edit the text
before sending the message.
Quick Notes
: Lets you create new Quick Notes
and edit or delete Quick Notes you have
created.
Replies
: Lets you create new reply phrases
and edit or delete reply phrases you have
created.
Cleanup
: Controls how long messages remain
in the Inbox and
Outbox
before they are
deleted.
option
Downloads
: Controls whether your phone
automatically downloads new messages
when they arrive, or only after you respond
to a prompt or read the message from the
Inbox. Set this option to
Automatic
if you want
your phone to download new messages
automatically; set the option to
Manual
if you
want your phone to prompt you before
downloading new messages.
Memory Size
: Shows the total amount of
Used
,
Free
, and total
Capacity
of the phone’s
memory.
option
43
main attractions
2
Select
[New Quicknote]
or
[New Reply]
.
3
Enter text from the keypad.
edit quick notes
You can edit only Quick Notes and reply
phrases you have created.
1
From the MMS Setup menu, select
Quick
Notes
or
Replies
.
2
Select the Quick Note or reply phrase you
want to edit.
3
Edit the text.
delete only Quick Notes and reply
phrases you have created
1
From the
MMS Setup
menu, select
Quick Notes
or
Replies
.
2
Scroll to the Quick Note or reply phrase
you want to delete.
3
Press
-
under
Delete
.
4
Press
-
under
Yes
to confirm.
cleanup
The
Cleanup
option controls how long
messages remain in the
MMS Inbox
and
MMS
Outbox
before they are deleted. You set the
cleanup option for the Inbox and Outbox
separately.
The cleanup option only deletes unlocked read
messages from the Inbox, and sent
messages from the Outbox for MMS.
Find it:
/
>
Messages
>
/
>
MMS Setup
>
Cleanup
1
Select
Inbox
or
Outbox
.
2
Choose a cleanup option from the
following list:
option
Off
: Messages are never automatically
deleted.
44
main attractions
3
Press
-
under
Yes
to automatically delete
messages now or press
-
under
No
to
delete messages later.
delete multiple or all messages
To delete multiple messages, all read and
unread unlocked messages from the MMS
Inbox, all messages in the MMS Drafts folder,
or all successfully sent messages in the MMS
Outbox:
Find it:
/
>
Messages
1
Select
Inbox
,
Drafts
, or
Outbox
.
5 Messages
: If you have more than 5
messages, messages are deleted in the
order they were received, starting with the
oldest, until 5 are left.
10 Messages
: If you have more than 10
messages, messages are deleted in the
order they were received, starting with the
oldest, until 10 are left.
With these options, messages are deleted
in the order they were received, starting
with the oldest, until the selected number
are left.
1 Day
: Messages are deleted if they are older
than 1 day.
3 Days
: Messages are deleted if they are
older than 3 days.
With these options, messages are deleted
when you exit the message center after
setting the option.
option
F-In F-Out
: The earliest message added to the
queue will be the first to be deleted (First in/
first out). (MOSMS only)
Custom
: Lets you create a clean-up option of
up to 99 messages or 99 days.
option
45
main attractions
2
Press
/
>
MMS Inbox
,
MMS Drafts
, or
MMS
Outbox
>
/
>
Delete Multiple
, and check the
messages you want to delete.
or
3
Select
Delete All
and press
-
under
Yes
to
confirm.
Note:
Locked messages cannot be deleted
from the Inbox.
bluetooth®
Your phone supports the use of wireless
Bluetooth headsets.
Find it:
/
>
Bluetooth
The Bluetooth connection menu contains an
option to search for audio devices.
turn Bluetooth
On or Off
You can turn your phone’s Bluetooth feature
on or off. While Bluetooth power is on, your
phone can communicate with other devices.
Find it:
/
>
Bluetooth
>
Setup
>
Power
>
On
1
Select
Name
if you wish to assign a name
to your handset.
2
Select
Find Me Time
to determine the
amount of time in which your handset can
be found by other Bluetooth devices.
Tip:
You can turn off Bluetooth if you want to
prolong battery life or if you enter an area
where Bluetooth is prohibited.
Note:
When the Bluetooth connection is
activated, a Bluetooth LED indicator will be lit
above the external display.
46
main attractions
make a Bluetooth connection
connect your phone with a Bluetooth
headset
Find it:
/
>
Bluetooth
>
Hands Free
>
[Find Devices]
1
Follow the instructions on your Bluetooth
headset to set it up to be found.
2
Once your Bluetooth headset is set to be
found press
r
on your handset. Your
phone will scan the Bluetooth headset
until it finds it. Press
r
when you see the
name of the Bluetooth headset on your
screen.
3
Your phone requires that you create a
bond in order to connect with a Bluetooth
headset. Press
-
under
Yes
when you
are prompted to bond with the headset.
4
Enter the Bluetooth pass key.
Some Bluetooth devices ship with
Bluetooth PINs. Please refer to your
Bluetooth device’s user guide to locate
this information.
If a device ships without a Bluetooth PIN,
then refer to its user guide to set the PIN
on that device. To establish a connection
to that device, enter the same PIN for
both your phone and the device. For
example, if you enter 1234 as the device’s
PIN, then enter 1234 as your phone’s PIN.
5
Press
-
under
Ok
.
Note:
This handset offers a Bluetooth auto
pair feature with auto pair compatible
Motorola devices. When bonded via
Bluetooth with a certain device, the pin will
not be required.
connect your phone with another
device
Find it:
/
>
Bluetooth
>
Link To Devices
47
main attractions
1
Select the device you want from the list of
found devices on your screen.
2
Create a bond if you are prompted to do
so.
Tip:
If you have previously connected to a
device, the device will be stored on your
phone so you can connect with it easily.
use Bluetooth during a call
You can connect with available Bluetooth
devices during a call.
Note:
If the
Handsfree Devices
list contains only
one device, then your phone will automatically
try to connect to that device.
1
While in a call, press
/
>
Use Bluetooth
.
2
Press
-
under
Yes
to power On
Bluetooth.
3
Select the audio device you want to
connect to from the list of
Handsfree Devices
.
send information via Bluetooth
You can use your phone to send Contacts
entries, or Datebook events to another
Bluetooth device.
The receiving device must be within 32 feet
(10 meters) of your phone in order to connect
with yours.
Note:
Files sent or received may be up
to 200 kb, depending on your service
provider.
send Contacts
Shortcut:
From the home screen press
-
under
Contcs
.
1
Select the contact you want to send.
2
Press
/
>
Send Via...
>
Bluetooth
.
3
Press
-
under
Yes
to power On
Bluetooth.
48
main attractions
4
Select the device you want to transfer the
contact information to.
or
Search for the device by selecting
[Find
Devices]
.
5
If prompted, bond with the device.
Your phone connects with the device and
transfers the contact.
send a Datebook event
Find it:
/
>
Datebook
1
Select the datebook event you want to
send.
2
Press
/
>
Send Via...
>
Bluetooth
.
If the event you select repeats, then you
will be prompted to choose whether to
send the selected instance of the event or
all instances of the event.
To send only the selected instance of the
event, select
This Event Only
.
or
To send all instances of the event, select
Repeat Events
.
3
Press
-
under
Yes
to power On
Bluetooth.
4
Select the device you want to transfer the
contact information to.
or
Search for the device by selecting
[Find
Devices]
.
5
If prompted, bond with the device.
Your phone connects with the device and
sends the datebook event.
49
basics
basics
See page 1 for a basic phone diagram.
display
The home screen shows when you turn on
the phone. To dial a number from the home
screen, press number keys and
`
.
Note:
Your home screen may look different.
Soft key labels show the current soft key
functions. For soft key
-
locations, see
page 1.
status indicators
Status indicators are shown at the top of the
home screen:
1
Signal Strength Indicator:
Vertical bars show
the strength of the network connection. You
can’t make or receive calls when
1
or
0
shows.
2
Active Phone Line:
1 indicates phone line 1 is
ready to make calls.
Ready
10:05 am 4/17
Contcs Msgs
1. 2. 3. 4. 5. 6. 7.
Ready
10:05 am 4/17
Contcs Msgs
50
basics
3
Speaker Off:
Sounds associated with Private
calls are set to come through the earpiece
rather than through the speaker.
4
Ringer Off:
Your phone is set to not ring.
5
Message Indicator:
Shows when you
receive a text message.
6
Packet Data:
Your handset is ready to transfer
packet data or is transferring packet data.
7
Battery Charge Indicator:
A fuller battery
indicates a greater charge. Recharge the
battery when your phone shows
Low Battery
.
text entry
Some features let you enter text.
Your phone provides convenient ways to enter
words, letters, punctuation, and numbers
whenever you are prompted to enter text (for
example, when adding a Contacts entry or
when text messaging).
change the character input mode:
1
When you see a screen where you can
enter text, press
/
to change the
character input mode.
2
Select one of the following options:
entry modes
Alpha
Press a key several times for
each character.
Word
Enter words using a predictive
text entering system that lets
you enter a word with fewer
keypresses.
Symbols
Enter symbols.
Numeric
Enter numbers by pressing the
numbers on the keypad.
Languages
Lets you select the input
language.
51
basics
Tip:
When entering text, press and hold
#
to
change letter capitalization (
Abc
>
ABC
>
abc
).
word mode
Word English Text Input lets you enter text
into your phone by pressing keys just once
per letter.
Word English Text Input analyzes the letters
you enter using an intuitive word database
and creates a suitable word. (The word may
change as you type.)
enter a word using Word Character
Input:
1
Select the
Word
character input mode.
2
Press the corresponding keys once per
letter to enter a word (for example, to
enter the word
Jeff
, press
5333
). (If
you make a mistake, press
-
under
Delete
or
*
to erase a single character. Press
and hold
-
under
Delete
or
*
to delete an
entire entry.)
3
To accept a word and insert a space,
press
#
.
alpha mode
enter characters by tapping the keypad:
1
Select the
Alpha
mode.
2
Press the corresponding keys repeatedly
until the desired letter appears. (For
example, to enter the word
Jeff
, press
5
once,
3
two times,
3
three times, and
3
three times again. If you make a
mistake, press
-
under
Delete
to erase a
single character. Press and hold
-
under
Delete
to erase an entire entry.)
By default, the first letter of an entry is
capitalized and the following letters are
lowercased. After a character is entered, the
cursor automatically advances to the next
52
basics
space after two seconds or when you enter a
character on a different key.
Characters scroll in the following order:
volume
Press the volume keys up
or down to:
•
turn off an incoming
call alert
•
change the earpiece
volume during calls
•
change the ringer
volume from the
home screen
Tip:
You can quickly set your ringer to
Vibrate All
by holding the down volume
key in the home screen.
characters
1
Space . 1 ? ! , @ & : ; “ - ( ) ‘ ¿
¡ %
£ $ ¥
2
A B C 2 Á Ã Â À Ç
3
D E F 3 É Ê È
4
G H I 4 Í Ì
5
J K L 5
6
M N O 6 Ó Õ Ô Ò
7
P Q R S 7 ß
8
T U V 8 Ú Ü Û Ù
9
W X Y Z 9
0
+ - 0 * / \ [ ] = > < # §
#
Space
*
Back
53
basics
navigation key
Press the navigation key
up, down, left, or right
to scroll to items in the
display. When you scroll
to something, press
r
.
handsfree speaker
You can use your phone’s hands-free speaker
to make calls without holding the phone to
your ear.
During a call press the
speaker key
s
to
turn the hands-free
speaker on.
The hands-free speaker stays on until you
press the speaker key or end the call. The
next phone call will redirect the audio back to
the earpiece.
transmitters
Note:
Consult airline staff about the use of
the Transmitters feature during flight. Turn off
your phone whenever instructed to do so by
airline staff.
Transmitters turns off your phone’s calling
features in situations where wireless phone
use is prohibited, but you can use the phone’s
other non-calling features when Transmitters
turned Off.
Find it:
/
>
u
>
Advanced
>
Transmitters
>
Off
54
basics
features for the hearing
impaired
using your phone with a
hearing aid
For best results use the following optimization
procedures and handset setting. They
generally apply as well for users with cochlear
implants:
optimize your handset position and
orientation
While in a phone call slide your phone up and
down, then left and right until best
microphone coupling is obtained. You also
may need to adjust your hearing aid (HA)
volume setting
.
If your HA has a telecoil, activate its switch,
then also rotate the handset as illustrated to
align the telecoils.
Note:
Some automatically switched hearing
aids may need an auxiliary switching magnet.
If you are unsure whether your HA is telecoil
equipped or needs an auxiliary magnet,
please refer to your HA user guide or contact
a hearing aid professional or supplier.
55
basics
choose your hearing aid setting
Find it:
/
>
Settings
>
Phone Calls
>
Hearing Aid
.
1
Set this option to
Microphone
. Microphone
coupling is now optimized.
or
2
Set this option to
Telecoil
. Handset meets
US federal requirements for telecoil
coupling sound.
or
3
Set this option to
Off
(factory default). This
is the setting for non HA users.
Approximate telecoil location is just
above the battery.
Approximate telecoil location is within
6-13 mm of this location.
Off - Shut off
M - Microphone
T - Telecoil
56
calls
calls
To make and answer calls, see page 12.
recent calls
The
Recent Calls
list contains information
associated with calls you have made and
received and call alerts you have received.
When you send or receive Private calls, the
Recent Call list contains the following PTT
items with those calls:
•
Messages
•
Pictures
•
Events
•
My Info
•
Contacts
The recent calls list displays up to 20 of the
most recent calls and call alerts.
Find it:
/
>
Recent Calls
Tip:
You can also access the Recent Calls list
by pressing the navigation key
down.
1
Scroll through the list.
2
Highlight the item you want to view or
perform some action on.
3
To view more details of the item press
r
.
store an item to contacts from
recent calls
Phone calls, Private calls, My Info received
from other phones, or Contacts entries
received from other phones can be stored to
the Contacts list from the Recent Calls list.
57
calls
Find it:
/
>
Recent Calls
1
Scroll to or select the item you want to
store.
2
Press
-
under
Save
to store the
information as a new entry in the
Contacts list.
or
3
If
Save
is not one or you options, press
/
>
Update Contacts
. And select the contact
you want to update.
4
Press
-
under
Done
to save your changes.
redial
To redial your last outgoing phone call, press
and hold
`
or push the PTT button if it was a
private call.
voice names
You can place calls by speaking comands to
your phone if you have previously assigned a
voice name to your contacts.
assign voice names to contacs
1
Press
-
under
Contcs
and select
[New
Contact]
.
2
Assing a name, phone number and select
[Options]
.
3
Select
Voice Name
and follow the prompt to
record the voice name.
4
Press
-
under
Back
and
-
under
Done
to
save the entry.
place a call using voice command
1
From the home screen press and hold the
speaker key
s
until you are prompted to
say the voice name.
The handset will automatically place the call.
58
calls
caller ID
Caller ID allows people to identify a
caller before answering the phone by
displaying the number of the incoming call. If
you do not want your number displayed when
you make a call, just follow these easy steps.
To block your phone number from being
displayed for a specific outgoing call:
1
Press
*67
..
2
Enter the number you want to call.
3
Press
`
.
To permanently block your number, call your
service provider’s Customer Care.
call forward
Call forwarding sends calls to the phone
numbers you specify. You can forward all calls
to one number or forward missed calls to
different numbers depending on the reason
you missed the call. You can forward phone
lines 1 and 2 independently.
Find it:
/
>
Call Forward
1
To forward all calls select
All Calls
and select
To
to enter the phone number you want all
your calls forwarded to.
or
2
You can specify a forwarding number for
each type of missed call by selecting
Detailed
and choosing the following options:
If Busy
: When your handset is on a call or
transferring data.
If No Answer
: When you do not answer on
the first 4 rings.
If Unreachable
: When your handset is out of
coverage or powered off.
59
calls
emergency calls
Your service provider programs one or more
emergency phone numbers that you can call
under any circumstances, even when your
phone is locked or the SIM card is not
inserted.
Note:
Emergency numbers vary by country.
Your phone’s preprogrammed emergency
number(s) may not work in all locations, and
sometimes an emergency call cannot be
placed due to network, environmental, or
interference issues.
Your phone supports emergency calling.
Emergency phone calls can be made even
when your SIM card is blocked or not in your
phone.
Dial 911 or your local emergency number to
be connected to an emergency response
center. If you are on an active call, you must
end it before making an emergency call.
When you make an emergency call, your
phone’s GPS Enabled feature can help
emergency service personnel find you, if you
are in a location where your phone's GPS
antenna has established a clear view of the
open sky and your local emergency response
center has the equipment to process location
information. Because of the limitations of this
feature, always provide your best knowledge
of your location to the emergency response
center when you make an emergency call.
Note:
Emergency calls cannot be placed
while the keypad is locked.
Note:
If you have not registered on the
network, emergency calls cannot be placed
while your SIM card is in your phone.
international calls
If your phone service includes international
dialing, press and hold 0 to insert your local
60
calls
international access code (indicated by +).
Then, press the keypad keys to dial the
country code and phone number.
You can additionally enable a predefined prefix
to the dialing number by using
Prepend
dialing.
Find it:
/
>
Settings
>
Phone Calls
>
Prepend
1
Select
Prepend
and set it to
On
.
2
Select
Number
and add the prefix number of
your choice.
When the
Prepend
feature is set to
On
, the
predefined prefix is inserted to the front of
the number that you are dialing.
Except that the number is led by "*", "00",
"011" or the number contains "+".
Note:
You can also use
Prepend
temporarily
when the feature is set to
Off
. For example,
enter the phone number from the home
screen and press
/
>
Add Prepend
. The
temporary prepend will be inserted to the
number you are dialing.
speed dial
Each phone number stored in Contacts is
assigned a Speed Dial number, which you can
use to call that number.
1
From the home screen, use the keypad to
enter the Speed Dial number assigned to
the phone number you want to call.
2
Press
#
.
3
Press
`
.
turbo dial
The first nine entries in your contacts are set
for turbo dial. They can be called by pressing
and holding the speed dial number
(1 through 9).
61
calls
voice mail
Note:
To receive voice mail messages, you
must first set up a voice mail account with
your service provider.
receive a message
When you receive a voice mail message,
New
VoiceMail Message
appears on the display.
To check voicemail messages press
-
under
Call
.
To dismiss the message notification:
If the flip is closed, press the smart key
(
on
the top.
If the flip is open, press
r
,
Back
, or close the
flip.
If the caller leaves a message, this icon
y
appears on the display, reminding you that
you have a new message.
62
customize
customize
ring tones
To set the ring tone your phone makes when
you receive phone calls, call alerts, message
notifications, pictures sent using Send via PTT
or Datebook reminders:
Note:
Only ring tones stored in your phone’s
memory are available in the ring tones list.
Not all audio files can be assigned as ring
tones.
Find it: /
> Ring Tones
1
Make sure
Vibrate All
is set to
Off
.
2
Scroll through the list of ring tones and
select the one you want to assign.
Vibrate
sets your phone to vibrate instead of
making a sound;
Silent
sets your phone to
neither vibrate nor make a sound.
Tip:
Highlighting a ring tone lets you hear
it.
3
Select the features you want to assign the
ring tone to.
4
When you are finished, press
Done
.
Note:
This icon
M
appears on the display if
you set your phone to
Silent
. This icon
Q
appears on the display if you set the phone to
Vibrate All
.
set your phone to vibrate
You can set your phone to vibrate instead of
making a sound when you receive all phone
calls, Private calls, call alerts, message
63
customize
notifications, pictures sent using Send via PTT,
and Datebook reminders.
Find it:
/
>
Ring Tones
>
Vibrate All
1
Set this option to
On
or
Locked
.
Setting this option to
On
lets you turn
Vibrate
All
off by pressing the up volume control.
Setting this option to
Locked
requires you to
press and hold the up volume control to
turn
Vibrate All
off. The
Locked
option helps
prevent you from accidentally turning
Vibrate All
off.
To set
Vibrate All
to
On
or
Locked
using the volume
controls: Press the volume controls to turn
down the volume as far as possible to set
Vibrate All
to
On
. Continue to hold the down
volume control to set
Vibrate All
to
Locked
.
To set your phone to vibrate instead of making
a sound for some features but not others:
Find it:
/
>
Ring Tones
1
Make sure
Vibrate All
is set to
Off
.
2
Select
Vibrate
from the list of ring tones.
3
Select the features you want to set to
make no sound.
4
When you are finished, press
-
under
Done
.
wallpaper
Set a photo or picture as a wallpaper
(background) image in your phone’s home
screen or throughout all menu screens.
Find it:
/
>
Settings
>
Display/Info
>
Wallpaper
>
Wallpaper
.
To select a wallpaper image scroll through the
list of pictures and press
r
to select the
picture of your choice.
Note:
You can set the wallpaper to change
automatically after a certain period of time by
64
customize
turning on the
Auto Cycle
feature located in the
Wallpaper menu.
backlight
Set the amount of time that the display and
java apps. backlights remain on, or turn off the
backlight feature to extend battery life.
Find it:
/
>
Settings
>
Display/Info
>
Backlight
datebook
Find it:
/
>
Datebook
>
/
>
Setup
You can view or change these options:
option
Start View
: Sets Datebook to start in day view,
week view, or month view when you
access Datebook.
Daily Begin
: Sets the beginning of your day.
This is the earliest time of day displayed in
week view, if you have a 12-hour day view.
Delete After
: Sets the amount of time
Datebook waits to delete an event after it
occurs.
Time Shift
: Lets you shift the times of all
Datebook events. This is useful if you are
traveling to a different time zone.
Alert Timeout
: Sets the amount of time a tone
continues to sound when you receive a
Datebook reminder.
Clock
: Controls whether the time and date
appear on the home screen; sets time and
date format.
option
65
customize
hide or show
location information
Your phone is equipped with a Location
feature for use in connection with location-
based services that may be available in the
future.
The Location feature allows the network to
detect your position. Turning Location off will
hide your location from everyone except for
your local emergency response center.
Note:
Turning Location on will allow the
network to detect your position using GPS
technology, making some applications and
services easier to use. Turning Location off
will disable the GPS location function for all
purposes except 911, but will not hide your
general location based on the cell site serving
your call. No application or service may use
your location without your request or
permission. GPS-enhanced 911 is not
available in all areas.
set your privacy options
Find it:
/
>
GPS
>
Privacy
Select
Restricted
,
Unrestricted
, or
Ask Access
.
66
other features - advanced calling
other features
advanced calling
feature
call waiting
Find it:
To accept the
second call and put
the active call on hold press
-
under
Yes
.
To accept the second call
and end the active call press
`
.
Your phone rings with the
second call for you to
answer.
flip
activation
To make your handset to
answer and end calls by
opening and closing the flip
press
/
>
u
>
Phone Calls
>
Flip Activation
.
Select
Flip To Ans
>
On
and
Flip
to End
>
On
.
any key
answer
To answer phone calls by
pressing any key on the
keypad press
/
>
u
>
Phone Calls
>
Any Key Ans
>
On
.
feature
67
other features - contacts
contacts datebook
feature
edit/delete
contact entry
Press
-
under
Contacts
.
Select a contact and press
/
>
Edit
. Change the
desired content and press
-
under
Done
.
set ringer ID
Press
-
under
Contacts
.
Select a contact and press
/
>
Edit
>
Ringer
. Select
desired ringer, press
-
under
Back
, and
-
under
Done
.
feature
create
datebook
events
To create a new Datebook
event press
/
>
D
>
[
New Event]
.
see datebook
event
To see a calendar event
press
/
>
D
> left or
right to see the day and
up or down to see the
events.
event
reminder
When an event reminder
occurs press
-
under
View
.
Press
-
under
Back
to close
the reminder.
68
other features - GPS
GPS
To improve GPS performance:
•
Stay in the open,
•
Move away from other electrical or
electronic devices
•
Remain stationary.
•
Avoid covering the antenna with your
hands.
receive
datebook
events via
PTT
To view the information
while still in the Private call
press
r
.
The 5 most recent events
received from a Private ID
are stored with the that
Private ID on the recent
calls list.
To store events to the
Datebook press
-
under
Save
while viewing the event
you want to store.
feature
feature
view
approximate
location
To see your approximate
location press
/
>
GPS
>
Position
. Scroll to view the
entire screen.
To recalculate position press
Rfrsh
. This may take several
minutes.
69
other features - handsfree
handsfree
Note:
The use of wireless phones while
driving may cause distraction. Discontinue a
call if you can't concentrate on driving.
Additionally, the use of wireless devices and
their accessories may be prohibited or
restricted in certain areas. Always obey the
laws and regulations on the use of these
products
set GPS
privacy
options
To set the level of privacy for
your GPS system press
/
>
GPS
>
Privacy
.
If your GPS PIN security
feature is enabled, enter your
GPS PIN and select the
privacy option you want.
change GPS
PIN
Note:
Your default GPS PIN is
0000.
To change your GPS PIN press
/
>
Settings
>
Security
>
Change
Passwds
>
GPS PIN
.
Enter the current GPS PIN and
enter the new 4- to 8-digit
GPS PIN. Re-enter the new
4- to 8-digit GPS PIN to
confirm.
feature
feature
speaker-
phone
To activate the
speakerphone while
driving press and hold
the speakerphone key
s
.
auto answer
To automatically answer
calls when connected to a
car kit or headset press
/
>
Settings
>
Phone Calls
>
Auto Ans
. Select the amount
of rings before answering.
70
other features - personalize
personalize pc applications
TTY
feature
language
To set the language of your
menu press
/
>
Settings
>
Display/Info
>
Language
.
backlight time
length
To select how long the
display screen and keypad
are backlit press
/
>
Settings
>
Display/Info
>
Backlight
.
menu style
To show the Main Menu as
graphic icons or a text-based
list press
/
>
Settings
>
Display/Info
>
Menu View
.
clock display
To display the clock on your
home screen press
/
>
Settings
>
Display/Info
>
Clock
>
Display
>
On
.
feature
other PC
applications
For a list of complete PC
applications visit
www.motorola.com/support
feature
turn On TTY
feature
From the home screen
press
/
>
Settings
>
Phone Calls
>
TTY
>
Use TTY
>
On
.
choose TTY
mode
From the home screen
press
/
>
Settings
>
Phone Calls
>
TTY
>
Type
.
Select from
TTY
,
VCO
or
HCO
.
71
other features - security
security
Note:
You can make emergency calls on a
locked phone (see page 59).
change the
TTY baud
rate
From the home screen
press
/
>
Settings
>
Phone Calls
>
TTY
>
Baud
.
Select
45.45
or
50.00
.
change TTY
mode
during a call
While in the TTY call, press
/
>
In Call Setup
>
TTY
>
Type
.
Select from
TTY
,
VCO
or
HCO
.
feature
phone lock
To lock the phone press
/
>
Settings
>
Security
>
Phone
Lock
>
Lock Now
or
Auto Lock
.
feature
keypad lock
To lock the keypad press
/
>
Settings
>
Security
>
Keypad Lock
>
Lock Now
or
Auto Lock
.
Shortcut:
To lock the
keypad press
/
>
*
.
enable SIM
PIN
To enable SIM PIN, press
/
>
Settings
>
Security
>
SIM PIN
>
On
.
change SIM
PIN
To change the SIM PIN,
press
/
>
Settings
>
Security
>
Change Passwds
>
SIM PIN
.
feature
72
Legal and Safety
Legal and Safety
Safety and General Information
This section contains important information on the safe and
efficient operation of your mobile device. Read this
information before using your integrated multi-service
portable radio.*
Exposure to Radio Frequency (RF) Energy
Your mobile device contains a transmitter and receiver. When it is
ON, it receives and transmits RF energy. When you communicate
with your phone, the system handling your call controls the power
level at which your phone transmits.
Your mobile device is designed to comply with local regulatory
requirements in your country concerning exposure of human beings
to RF energy.
Portable Radio Product Operation and EME
Exposure
Your Motorola radio product is designed to comply with the
following national and international standards and guidelines
regarding exposure of human beings to radio frequency
electromagnetic energy (EME):
•
United States Federal Communications Commission, Code
of Federal Regulations; 47 CFR part 2 sub-part J.
•
American National Standards Institute (ANSI) / Institute of
Electrical and Electronics Engineers (IEEE). C95. 1-1992.
•
Institute of Electrical and Electronics Engineers (IEEE).
C95. 1-2005 Edition.
*
•
International Commission on Non-Ionizing Radiation
Protection (ICNIRP) 1998.
•
Ministry of Health (Canada). Safety Code 6. Limits of
Human Exposure to Radio frequency Electromagnetic
Fields in the Frequency Range from 3 kHz to 300 GHz,
1999.
•
Australian Communications Authority Radio
communications (Electromagnetic Radiation - Human
Exposure) Standard 2003.
•
ANATEL, Brazil Regulatory Authority, Resolution 303 (July
2, 2002) “Regulation of the limitation of exposure to
* The information provided in this document supersedes the general
safety information in user’s guides published prior to May 1, 2006
Legal and Safety
73
electrical, magnetic, and electromagnetic fields in the
radio frequency range between 9 kHz and 300 GHz.”
“Attachment to Resolution 303 from July 2, 2002."
Operational Precautions
For optimal mobile device performance, and to be sure that human
exposure to RF energy does not exceed the guidelines set forth in
the relevant standards, always follow these instructions and
precautions.
Phone Operation
When placing or receiving a phone call, hold your mobile phone as
you would a landline telephone.
Speak directly into the
microphone
.
Two-way radio operation
Your radio product has been designed and tested to comply with
national and international standards and guidelines regarding
human exposure to RF electromagnetic energy, when operated in
the two-way mode (at the face, or at the abdomen when using an
audio accessory) at usage factors of up to 50% talk/50% listen.
Transmit no more than the rated duty factor of 50% of the time. To
transmit (talk), push the PTT button. To receive calls, release the
PTT button. Transmitting 50% of the time or less, is important
because this radio generates measurable RF energy only when
transmitting (in terms of measuring for standards compliance).
When using your radio product as a traditional
two-way radio,
hold the radio product in a
vertical position with the microphone one
to two inches (2.5 to 5 cm) away from the
lips
.
If you wear the mobile device on your body,
always place the mobile device in a Motorola approved clip,
holder, holster, case or body harness. If you do not use a body-worn
accessory supplied or approved by Motorola and are not using the
mobile device in the intended use positions along side the head in
the phone mode or in front of the face in the two-way radio mode,
or if you hang your device from a lanyard around your neck, keep
the device at least 2.5 centimeters (1 inch) from your body when
transmitting.
Approved Accessories
For a list of approved Motorola accessories call 1-800-453-0920, or
visit our website at www.motorola.com/phoneaccessories.
RF Energy Interference/Compatibility
Nearly every electronic device is subject to RF energy interference
from external sources if inadequately shielded, designed or
otherwise configured for RF energy compatibility. In some
circumstances your mobile device may cause interference with
other devices.
74
Legal and Safety
Follow Instructions to Avoid Interference
Problems
Turn OFF your mobile device in any location where posted notices
instruct you to do so.
In an aircraft, turn off your mobile device whenever instructed to
do so by airline staff. If your mobile device offers an airplane mode
or similar feature, consult airline staff about using it in flight.
Implantable Medical Devices
If you have an implantable medical devices, such as a pacemaker
or defibrillator, consult your physician before using this mobile
device.
Persons with implantable medical devices should observe the
following precautions:
•
ALWAYS keep the mobile device more than 20
centimeters (8 inches) from the implantable medical
device when the phone is turned ON.
•
DO NOT carry the mobile device in the breast pocket;
•
Use the ear opposite the implantable medical device to
minimize the potential for interference.
•
Turn OFF the mobile device immediately if you have any
reason to suspect that interference is taking place.
Read and follow the directions from the manufacturer of your
implantable medical device. If you have any questions about using
your mobile device with your implantable medical device, consult
your health care provider.
Hearing Aids
Some phones may interfere with some hearing aids. In the event of
such interference, you may want to consult your hearing aid
manufacturer or physician to discuss alternatives.
Other Medical Devices and Health Care Facilities
If you use any other personal medical devices, consult your
physician or the manufacturer or your device to determine if it is
adequately shielded from RF energy. Turn off your radio product
when instructed to do so in hospitals or health care facilities that
may be using equipment that is sensitive to external RF energy.
Bluetooth
This device supports Bluetooth 1.2 including HSP, HFP, OPP, DUN,
PBAP, and BPP. In order for Bluetooth devices to communicate with
one another, they must utilize the same Bluetooth profile. To
determine the profiles supported by other Motorola devices, visit
www.hellomoto.com/bluetooth. For other devices, contact their
respective manufacturer.
Certain Bluetooth features including those listed may not be
supported by all compatible Bluetooth-enabled devices, and/or the
functionality of such features may be limited in certain devices, or
by certain wireless carriers. Contact your wireless carrier about
feature availability and functionality.
Legal and Safety
75
Caring for the Environment by
Recycling
This symbol on a Motorola product means the
product should not be disposed of with household
waste.
Disposal of your Mobile Device and Accessories
Please do not dispose of mobile devices or electrical accessories
(such as chargers, headsets, or batteries) with your household
waste. These items should be disposed of in accordance with the
national collection and recycling schemes operated by your local or
regional authority. Alternatively, you may return unwanted mobile
devices and electrical accessories to any Motorola Approved
Service Center in your region. Details of Motorola approved
national recycling schemes, and further information on Motorola
recycling activities can be found at:
www.motorola.com/recycling
Disposal of your Mobile Device Packaging and
User’s Guide
Product packaging and user’s guides should only be disposed of in
accordance with national collection and recycling requirements.
Please contact your regional authorities for more details.
Driving Precautions
The use of wireless phones while driving may cause distraction.
Discontinue a call if you can’t concentrate on driving.
Additionally, the use of wireless devices and their accessories may
be prohibited or restricted in certain areas. Always obey the laws
and regulations on the use of these products.
Responsible driving practices can be found in the “Smart Practices
While Driving” section (see page 88).
Operational Warnings
Obey all posted signs when using Mobile devices in public areas.
Potentially Explosive Atmospheres
Areas with potentially explosive atmospheres are often but not
always posted, and can include fueling areas such as below decks
on boats, fuel or chemical transfer or storage facilities, or areas
where the air contains chemicals or particles, such as grain, dust
or metal powders.
When you are in such area, turn off your handset, and do not
remove, install, or charge batteries unless it is a radio product type
especially qualified for use in such areas as “Intrinsically Safe” (for
example, Factory Mutual, CSA, or UL approved). In such areas,
sparks can occur and cause an explosion or fire.
76
Legal and Safety
Symbol Key
Your battery, charger, or portable radio may contain symbols,
defined as follows:
Batteries and Chargers
Caution: Improper treatment or use of batteries may present
a danger of fire, explosion, leakage, or other hazard. For
more information, see the “Battery Use and Battery Safety”
section in this user’s guide.
Keep Your Mobile Device and Its Accessories
Away from Small Children
These products are not toys and may be hazardous to small
children. For example:
•
A choking hazard may exist for small, detachable parts.
•
Improper use could result in loud sounds, possibly causing
hearing injury.
•
Improperly handled batteries could overheat and cause a
burn.
Glass Parts
Some parts of your mobile device may be made of glass. This glass
could break if the product is dropped on a hard surface or receives
Symbol Definition
Important safety information
follows.
Do not dispose of your battery
or phone in a fire.
Your battery or phone may
require recycling in
accordance with local laws.
Contact your local regulatory
authorities for more
information.
Do not throw your battery or
phone in the trash.
Your phone contains an
internal lithium ion battery.
Do not let your battery,
charger, or phone get wet.
032374o032374o
032376o032376o
032375o032375o
032378o
Li Ion BATT
032378o
Li Ion BATT
Listening at full volume to
music or voice through a
headset may damage your
hearing.
Symbol Definition
Legal and Safety
77
a substantial impact. If glass breaks, do not touch or attempt to
remove. Stop using your mobile device until the glass is replaced
by a qualified service center.
Seizures/Blackouts
Some people may be susceptible to epileptic seizures or blackouts
when exposed to flashing lights, such as when playing video
games. These may occur even if a person has never had a previous
seizure or blackout.
If you have experienced seizures or blackouts, or if you have a
family history of such occurrences, please consult with your
physician before playing video games or enabling a flashing-lights
feature (if available) on your mobile device.
Discontinue use and consult a physician if any of the following
symptoms occur: convulsion, eye or muscle twitching, loss of
awareness, involuntary movements, or disorientation. It is always
a good idea to hold the screen away from your eyes, leave the
lights on in the room, take a 15-minute break every hour, and stop
use if you are very tired.
Caution About High Volume Usage
Warning:
Warning: Exposure to loud noise from any
source for extended periods of time may affect your
hearing. The louder the volume sound level, the
less time is required before your hearing could be
affected. To protect your hearing:
•
Limit the amount of time you use headsets or headphones
at high volume.
•
Avoid turning up the volume to block out noisy
surroundings.
•
Turn the volume down if you can’t hear people speaking
near you.
If you experience hearing discomfort, including the sensation of
pressure or fullness in your ears, ringing in your ears, or muffled
speech, you should stop listening to the device through your
headset or headphones and have your hearing checked.
For more information about hearing, see our Web site at
www.motorola.com/hearingsafety
(in English only).
Repetitive Motion
When you repetitively perform actions such as pressing keys or
entering finger-written characters, you may experience occasional
discomfort in your hands, arms, shoulders, neck, or other parts of
your body. If you continue to have discomfort during or after such
use, stop use and see a physician.
Service and Repairs
If you have questions or need assistance, we’re here to help.
Go to
www.motorola.com/support
, where you can select from
a number of customer care options. You can also contact the
Motorola Customer Support Center at 1 (800) 453-0920 (United
78
Legal and Safety
States), 1 (877) 483-2840 (TTY, TDD United States for hearing
impaired).
Export Law Assurances
This product is controlled under the export regulations of the
United States of America and Canada. The Governments of the
United States of America and Canada may restrict the exportation
or re-exportation of this product to certain destinations. For further
information contact the U.S. Department of Commerce or the
Canadian Department of Foreign Affairs and International Trade.
Battery Use and Safety
• Motorola recommends you always use
Motorola-branded batteries and chargers.
The
warranty does not cover damage caused by non-Motorola
batteries and/or chargers.
Caution:
Use of an unqualified battery or charger may
present a risk of fire, explosion, leakage, or other hazard.
Improper battery use, or use of a damaged battery, may
result in a fire, explosion, or other hazard.
•
Battery usage by children should be supervised.
• Important
: Motorola mobile devices are designed to work
best with qualified batteries. If you see a message on your
display such as
Invalid Battery
or
Unable to Charge
, take the
following steps:
•
Remove the battery and inspect it to confirm it bears a
Motorola “Original Equipment” hologram;
•
If there is no hologram, the battery is not a qualified
battery;
•
If there is a hologram, replace the battery and retry
charging it;
•
If the message remains, contact a Motorola Authorized
Service Center.
•
When storing your battery, keep it in a cool, dry place.
•
It is normal over time for battery life to decrease, and for
the battery to exhibit shorter runtime between charges or
require more frequent or longer charging times.
Important: Handle and store batteries properly to avoid
injury or damage.
Most battery issues arise from improper
handling of batteries, and particularly from the continued use of
damaged batteries.
DON’Ts
• Don’t disassemble, crush, puncture, shred, or
otherwise attempt to change the form of your
battery.
• Don’t let the phone or battery come in contact with
water.
Water can get into the phone’s circuits, leading to
corrosion. If the phone and/or battery get wet, have them
checked by your carrier or contact Motorola, even if they
appear to be working properly.
Legal and Safety
79
• Don’t allow the battery to touch metal objects.
If
metal objects, such as jewelry, stay in prolonged contact
with the battery contact points, the battery could become
very hot.
• Don’t place your battery near a heat source.
Excessive heat can damage the phone or the battery. High
temperatures can cause the battery to swell, leak, or
malfunction. Therefore:
•
Do
not
dry a wet or damp battery with an appliance or
heat source, such as a hair dryer or microwave oven.
•
Avoid leaving your phone in your car in high temperatures.
DOs
• Do avoid dropping the battery or phone.
Dropping
these items, especially on a hard surface, can potentially
cause damage.
• Do contact your service provider or Motorola if your
phone or battery has been damaged from dropping
or high temperatures.
Important: Use Motorola Original products for quality
assurance and safeguards.
To aid consumers in identifying
authentic Motorola batteries from non-original or counterfeit
batteries (that may not have adequate safety protection), Motorola
provides holograms on its batteries. Consumers should confirm
that any battery they purchase has a “Motorola Original”
hologram.
Motorola recommends you always use Motorola-branded
batteries and chargers.
Motorola mobile devices are designed
to work with Motorola batteries. If you see a message on your
display such as
Invalid Battery
or
Unable to Charge
, take the following
steps:
•
Remove the battery and inspect it to confirm that it has a
“Motorola Original” hologram;
•
If there is no hologram, the battery is not a Motorola
battery;
•
If there is a hologram, replace the battery and retry
charging it;
•
If the message remains, contact a Motorola authorized
service center.
Important:
Motorola’s warranty does not cover damage to the
phone caused by non-Motorola batteries and/or chargers.
Warning:
Use of a non-Motorola battery or charger may present a
risk of fire, explosion, leakage, or other hazard.
Proper and safe battery disposal and recycling:
Proper
battery disposal is not only important for safety, it benefits the
environment. Consumers may recycle their used batteries in many
retail or service provider locations. Additional information on
proper disposal and recycling may be found on the Web:
• www.motorola.com/recycling
• www.rbrc.org/call2recycle/
(in English only)
80
Legal and Safety
Disposal:
Promptly dispose of used batteries in accordance with
local regulations. Contact your local recycling center or national
recycling organizations for more information on how to dispose of
batteries.
Warning:
Never dispose of batteries in a fire because they may
explode.
Battery Charging
Notes for charging your phone’s battery:
•
When charging your battery, keep it near room
temperature. Never expose batteries to temperatures
below 0°C (32°F) or above 45°C (113°F) when charging.
•
New batteries are not fully charged.
•
New batteries or batteries stored for a long time may take
more time to charge.
•
Motorola batteries and charging systems have circuitry
that protects the battery from damage from overcharging.
Specific Absorption Rate
Your model wireless phone meets the governmental
requirements for exposure to radio waves.
Your mobile device is a radio transmitter and receiver. It is
designed and manufactured to not exceed limits for exposure to
radio frequency (RF) energy set by the Federal Communications
Commission (FCC) of the U.S. Government and by the Canadian
regulatory authorities. These limits are part of comprehensive
guidelines and establish permitted levels of RF energy for the
general population. The guidelines are based on standards that
were developed by independent scientific organizations through
periodic and thorough evaluation of scientific studies. The
standards include a substantial safety margin designed for the
safety of all persons, regardless of age or health, and to account
for any variations in measurements.
The exposure standard for mobile devices employs a unit of
measurement known as the Specific Absorption Rate (SAR). The
SAR limit set by the FCC and by the Canadian regulatory
authorities is 1.6 watts per kilogram (W/kg), averaged over one
gram of tissue. Tests for SAR are conducted using procedures
accepted by the FCC and by Industry Canada with the mobile
device transmitting at its highest certified power level in all tested
frequencies. Although the SAR is determined at the highest
certified power level, the actual SAR level of the mobile device
while operating can be below the maximum value. This is because
the mobile device is designed to operate at multiple power levels
so as to use only the power required to reach the network. In
general, the closer you are to a wireless base station, the lower
the power output.
Before a mobile device is available for sale to the public in the U.S.
and Canada, it must be tested and certified to the FCC and Industry
Canada that it does not exceed the limit established by each
government for safe exposure. The tests are performed in
positions and locations (e.g., at the ear and worn on the body)
Legal and Safety
81
submitted to the FCC and available for review by Industry Canada.
The highest SAR value for this mobile device when tested for use
at the ear is 0.72 W/kg, and when worn on the body, as described
in this guide, is 1.03 W/kg. Body-worn measurements can differ,
depending upon available accessories and regulatory
requirements. The SAR information includes the Motorola testing
protocol, assessment procedure, and measurement uncertainty
range for this product.
While there may be differences between the SAR levels of various
mobile devices and at various positions, they meet the
governmental requirements for safe exposure. Please note that
improvements to this product model could cause differences in the
SAR value for later products; in all cases, products are designed to
be within the guidelines.
Additional information on SAR can be found on the Cellular
Telecommunications & Internet Association (CTIA) Web site:
http://www.phonefacts.net
or the Canadian Wireless Telecommunications Association (CWTA)
Web site:
http://www.cwta.ca
AGPS and Emergency Calls
When you make an emergency call, your mobile device can use
Assisted Global Positioning System (AGPS) satellite signals to tell
the emergency response center your approximate location.
The AGPS feature has limitations, so always tell the emergency
response center your best knowledge of your location. Remain on
the phone for as long as the emergency response center instructs
you.
AGPS
might not work
for emergency calls, if your local
emergency response center does not process AGPS location
information. For details, contact your local authorities.
If your mobile device cannot find strong AGPS satellite signals, the
location of the nearest cell tower in contact with your mobile
device is automatically provided to the emergency response
center.
AGPS Performance Tips
•
Go outside and away from underground locations, covered
vehicles, structures with metal or concrete roofs, tall
buildings, and foliage. Indoor performance might improve
if you move closer to windows, but some window sun
shielding films can block satellite signals.
•
Move away from radios, entertainment equipment, and
other electronic devices that might interfere with or block
AGPS satellite signals.
AGPS uses satellites controlled by the U.S. government and
subject to changes implemented in accordance with the
Department of Defense AGPS user policy and the Federal Radio
Navigation Plan. These changes might affect AGPS performance.
82
Legal and Safety
Motorola Limited Warranty for the
United States and Canada
What Does this Warranty Cover?
Note: FOR IDEN SUBSCRIBER PRODUCTS, ACCESSORIES
AND SOFTWARE PURCHASED IN THE UNITED STATES OR
CANADA
Subject to the exclusions contained below, Motorola, Inc. warrants
its Motorola iDEN Digital Mobile and Portable Handsets
("Products"), Motorola-branded or certified accessories sold for
use with these Products ("Accessories") and Motorola software
contained on CD-Roms or other tangible media and sold for use
with these Products ("Software") to be free from defects in
materials and workmanship under normal consumer usage for the
period(s) outlined below.
This limited warranty is a
consumer's exclusive remedy, and applies as follows to
new Products, Accessories and Software purchased by
consumers in the United States or Canada, which are
accompanied by this written warranty:
What is not covered? (Exclusions)
Normal Wear and Tear
. Periodic maintenance, repair and
replacement of parts due to normal wear and tear are excluded
from coverage.
Ornamental Decorations
. Ornamental decorations such as
emblems, graphics, rhinestones, jewels, gemstones and their
settings, and other decorative elements, are excluded from
coverage.
Products Covered Length of Coverage
Products as defined
above.
Ninety (90) days
from the date of
purchase by the first consumer
purchaser of the product.
Accessories as
defined above.
Ninety (90) days
from the date of
purchase by the first consumer
purchaser of the product.
Products or
Accessories that are
Repaired or
Replaced.
The balance of the original
warranty or for ninety (90) days
from the date returned to the
consumer, whichever is longer.
Software
as defined
above. Applies only to
physical defects in the
media that embodies
the copy of the software
(e.g. CD-ROM, or floppy
disk).
Ninety (90) days from the date
of purchase
.
Products Covered Length of Coverage
Legal and Safety
83
Batteries
. Only batteries whose fully charged capacity falls below
80% of their rated capacity and batteries that leak are covered by
this limited warranty.
Abuse & Misuse
. Defects or damage that result from: (a)
improper operation, storage, misuse or abuse, accident or neglect,
such as physical damage (cracks, scratches, etc.) to the surface of
the product resulting from misuse; (b) contact with liquid, water,
rain, extreme humidity or heavy perspiration, sand, dirt or the like,
extreme heat, or food; (c) use of the Products or Accessories for
commercial purposes or subjecting the Product or Accessory to
abnormal usage or conditions; or (d) other acts which are not the
fault of Motorola, are excluded from coverage.
Use of Non-Motorola Products and Accessories
. Defects or
damage that result from the use of Non-Motorola branded or
certified Products, Accessories, Software or other peripheral
equipment are excluded from coverage.
Unauthorized Service or Modification
. Defects or damages
resulting from service, testing, adjustment, installation,
maintenance, alteration, including without limitation, software
changes, or modification in any way by someone other than
Motorola, or its authorized service centers, are excluded from
coverage.
Altered Products
. Products or Accessories with (a) serial
numbers or date tags that have been removed, altered or
obliterated; (b) broken seals or that show evidence of tampering;
(c) mismatched board serial numbers; or (d) nonconforming or
non-Motorola housings, antennas, or parts, are excluded from
coverage.
Communication Services
. Defects, damages, or the failure of
Products, Accessories or Software due to any communication
service or signal you may subscribe to or use with the Products,
Accessories or Software is excluded from coverage.
Software Embodied in Physical Media.
No warranty is made
that the software will meet your requirements or will work in
combination with any hardware or software applications provided
by third parties, that the operation of the software products will be
uninterrupted or error free, or that all defects in the software
products will be corrected.
Software NOT Embodied in Physical Media
. Software that is
not embodied in physical media (e.g. software that is downloaded
from the internet), is provided "as is" and without warranty.
Who is covered?
This warranty extends only to the first
consumer purchaser, and is not transferable.
What will Motorola Do?
Motorola, at its option, will at no
charge repair, replace or refund the purchase price of any Products,
Accessories or Software that does not conform to this warranty.
We may use functionally equivalent
reconditioned/refurbished/pre-owned or new Products,
Accessories or parts. No data, software or applications added to
your Product, Accessory or Software, including but not limited to
personal contacts, games and ringer tones, will be reinstalled. To
avoid losing such data, software and applications please create a
back up prior to requesting service.
84
Legal and Safety
How to Obtain Warranty Service or Other Information?
To
obtain service or information, please call:
Motorola iDEN Customer Services 1-800-453-0920 or
954-723-4910
TTY-877-483-2840
Or visit us online at http://www.motorola.com/iden
You will receive instructions on how to ship the Products,
Accessories or Software, at your expense, to a Motorola
Authorized Repair Center. To obtain service, you must include: (a) a
copy of your receipt, bill of sale or other comparable proof of
purchase; (b) a written description of the problem; (c) the name of
your service provider, if applicable; (d) the name and location of the
installation facility (if applicable) and, most importantly; (e) your
address and telephone number.
What Other Limitations Are There?
ANY IMPLIED
WARRANTIES, INCLUDING WITHOUT LIMITATION THE IMPLIED
WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A
PARTICULAR PURPOSE, SHALL BE LIMITED TO THE DURATION OF
THIS LIMITED WARRANTY, OTHERWISE THE REPAIR,
REPLACEMENT, OR REFUND AS PROVIDED UNDER THIS EXPRESS
LIMITED WARRANTY IS THE EXCLUSIVE REMEDY OF THE
CONSUMER, AND IS PROVIDED IN LIEU OF ALL OTHER
WARRANTIES, EXPRESS OF IMPLIED. IN NO EVENT SHALL
MOTOROLA BE LIABLE, WHETHER IN CONTRACT OR TORT
(INCLUDING NEGLIGENCE) FOR DAMAGES IN EXCESS OF THE
PURCHASE PRICE OF THE PRODUCT, ACCESSORY OR SOFTWARE,
OR FOR ANY INDIRECT, INCIDENTAL, SPECIAL OR
CONSEQUENTIAL DAMAGES OF ANY KIND, OR LOSS OF
REVENUE OR PROFITS, LOSS OF BUSINESS, LOSS OF
INFORMATION OR DATA, SOFTWARE OR APPLICATIONS OR
OTHER FINANCIAL LOSS ARISING OUT OF OR IN CONNECTION
WITH THE ABILITY OR INABILITY TO USE THE PRODUCTS,
ACCESSORIES OR SOFTWARE TO THE FULL EXTENT THESE
DAMAGES MAY BE DISCLAIMED BY LAW.
Some states and jurisdictions do not allow the limitation or
exclusion of incidental or consequential damages, or limitation on
the length of an implied warranty, so the above limitations or
exclusions may not apply to you. This warranty gives you specific
legal rights, and you may also have other rights that vary from
state to state or from one jurisdiction to another.
Laws in the United States and other countries preserve for
Motorola certain exclusive rights for copyrighted Motorola
software such as the exclusive rights to reproduce and distribute
copies of the Motorola software. Motorola software may only be
copied into, used in, and redistributed with, the Products
associated with such Motorola software. No other use, including
without limitation disassembly of such Motorola software or
exercise of the exclusive rights reserved for Motorola, is
permitted.
Patent and Software Provisions:
MOTOROLA will defend, at its own expense, any suit brought
against the end user purchaser to the extent that it is based on a
claim that the Product or parts infringe a patent, and Motorola will
pay those costs and damages finally awarded against the end user
Legal and Safety
85
purchaser in any such suit which are attributable to any such
claim, but such defense and payments are conditioned on the
following:
•
That MOTOROLA will be notified promptly in writing by
such purchaser of any notice of such claim;
•
That MOTOROLA will have sole control of the defense of
such suit and all negotiations for its settlement or
compromise; and
•
Should the Product or parts become, or in MOTOROLA’S
opinion be likely to become, the subject of a claim of
infringement of a patent, that such purchaser will permit
MOTOROLA, at its option and expense, either to procure
for such purchaser the right to continue using the Product
or parts or to replace or modify the same so that it
becomes non infringing or to grant such purchaser a credit
for the Product or parts as depreciated and accept its
return. The depreciation will be an equal amount per year
over the lifetime of the Product or parts as established by
MOTOROLA.
MOTOROLA will have no liability with respect to any claim of
patent infringement which is based upon the combination of the
Product or parts furnished hereunder with software, apparatus or
devices not furnished by MOTOROLA, nor will MOTOROLA have
any liability for the use of ancillary equipment or software not
furnished by MOTOROLA which is attached to or sued in
connection with the Product or any parts thereof. In no event shall
MOTOROLA be liable for any incidental, special or consequential
damages arising from any claim of patent infringement or alleged
infringement.
Laws in the United States and other countries preserve for
MOTOROLA certain exclusive rights for copyrighted MOTOROLA
software, such as the exclusive rights to reproduce in copies and
distribute copies of such MOTOROLA software. MOTOROLA
software may be used in only the Product in which the software
was originally embodied and such software in such Product may
not be replaced, copied, distributed, modified in any way, or used
to produce any derivative thereof. No other use including, without
limitation, alteration, modification, reproduction, distribution, or
reverse engineering of such MOTOROLA software or exercise or
rights in such MOTOROLA software is permitted. No license is
granted by implication, estoppel or otherwise under MOTOROLA
patent rights or copyrights.
Hearing Aid Compatibility With Mobile
Phones
Some Motorola phones are measured for compatibility with
hearing aids. If the box for your particular model has “Rated for
Hearing Aids” printed on it, the following explanation applies.
When some mobile phones are used near some hearing devices
(hearing aids and cochlear implants), users may detect a buzzing,
humming, or whining noise. Some hearing devices are more
immune than others to this interference noise, and phones also
vary in the amount of interference they generate.
86
Legal and Safety
The wireless telephone industry has developed ratings for some of
their mobile phones, to assist hearing device users in finding
phones that may be compatible with their hearing devices. Not all
phones have been rated. Phones that are rated have the rating on
their box or a label on the box.
The ratings are not guarantees. Results will vary depending on the
user’s hearing device and hearing loss. If your hearing device
happens to be vulnerable to interference, you may not be able to
use a rated phone successfully. Trying out the phone with your
hearing device is the best way to evaluate it for your personal
needs.
M-Ratings:
Phones rated M3 or M4 meet FCC requirements and
are likely to generate less interference to hearing devices than
phones that are not labeled. M4 is the better/higher of the two
ratings.
T-Ratings:
Phones rated T3 or T4 meet FCC requirements and are
likely to be more usable with a hearing device’s telecoil (“T
Switch” or “Telephone Switch”) than unrated phones. T4 is the
better/higher of the two ratings. (Note that not all hearing devices
have telecoils in them.)
Hearing devices may also be measured for immunity to this type of
interference. Your hearing device manufacturer or hearing health
professional may help you find results for your hearing device. The
more immune your hearing aid is, the less likely you are to
experience interference noise from mobile phones.
Information From the World Health
Organization
Present scientific information does not indicate the need for any
special precautions for the use of mobile phones. If you are
concerned, you may want to limit your own or your children’s RF
exposure by limiting the length of calls or by using hands-free
devices to keep mobile phones away from your head and body.
Source: WHO Fact Sheet 193
Further information:
http://www.who.int./peh-emf
.
Product Registration
Online Product Registration:
www.motorola.com/us/productregistration
Product registration is an important step toward enjoying your new
Motorola product. Registering permits us to contact you for
product or software updates and allows you to subscribe to
updates on new products or special promotions. Registration is not
required for warranty coverage.
Please retain your original dated sales receipt for your records. For
warranty service of your Motorola Personal Communications
Product you will need to provide a copy of your dated sales receipt
to confirm warranty status.
Thank you for choosing a Motorola product.
Legal and Safety
87
Wireless: The New Recyclable
Your wireless phone can be recycled. Recycling your phone
reduces the amount of waste disposed in landfills and allows
recycled materials to be incorporated into new products.
The Cellular Telecommunications Industry Association (CTIA) and
its members encourage consumers to recycle their phones and
have taken steps to promote the collection and environmentally
sound recycling of end-of-life devices.
As a phone user, you have an important role in ensuring that this
device is recycled properly. When it comes time to give this phone
up or trade it in for a new one, please remember that the phone,
the charger, and many of its accessories can be recycled. It's easy.
To learn more about CTIA's Recycling Program for Used Wireless
Devices, please visit us at:
http://recycling.motorola.young-america.com/ index.html
California Perchlorate Label
Some mobile phones use an internal, permanent backup battery on
the printed circuit board that may contain very small amounts of
perchlorate. In such cases, California law requires the following
label:
Perchlorate Material - special handling may apply. See
www.dtsc.ca.gov/hazardouswaste/perchlorate
.
There is no special handling required by consumers.
Patent and Trademark Information
MOTOROLA, the Stylized M Logo and all other trademarks
indicated as such herein are trademarks of Motorola, Inc. ® Reg.
U.S. Pat. & Tm. Off. © 2009 Motorola, Inc. All rights reserved.
Microsoft and Microsoft Internet Explorer are registered
trademarks of Microsoft Corporation.
T9 is a trademark owned by Tegic Communications.
T9
®
Text Input Patent and Trademark Information.
This product is covered by U.S. Pat. 5,818,437, U.S. Pat. 5,953,541,
U.S. Pat. 6,011,554 and other patents pending.
Java and all other Java-based marks are trademarks or registered
trademarks of Sun Microsystems, Inc. in the U.S. and other
countries.
All other product names or services mentioned in this manual are
the property of their respective trademark owners.
Software Copyright Notice
Motorola products may include copyrighted Motorola and third
party software stored in semiconductor memories or other media.
Laws in the United States and other countries preserve for
Motorola and third party software providers certain exclusive
rights for copyrighted software, such as the exclusive rights to
distribute or reproduce the copyrighted software. Accordingly, any
copyrighted software contained in the Motorola products may not
be modified, reverse-engineered, distributed, or reproduced in any
88
Legal and Safety
manner to the extent allowed by law. Furthermore, the purchase of
Motorola products shall not be deemed to grant either directly or
by implication, estoppel, or otherwise, any license under the
copyrights, patents, or patent applications of Motorola or any third
party software provider, except for the normal, non-exclusive,
royalty-free license to use that arises by operation of law in the
sale of a product.
Privacy and Data Security
Motorola understands that privacy and data security are important
to everyone. Because some features of your mobile device may
affect your privacy or data security, please follow these
recommendations to enhance protection of your information:
• Monitor access—
Keep your mobile device with you and
do not leave it where others may have unmonitored
access. Lock your device’s keypad where this feature is
available.
• Keep software up to date—
If Motorola or a
software/application vendor releases a patch or software
fix for your mobile device that updates the device’s
security, install it as soon as possible.
• Erase before recycling—
Delete personal information
or data from your mobile device prior to disposing of it or
turning it in for recycling. For instructions on how to delete
all personal information from your device, please contact
your local service provider.
• Understanding AGPS—
To provide location information
for emergency calls, certain Motorola mobile devices
incorporate Assisted Global Positioning System (AGPS)
technology. AGPS technology also can be used in
non-emergency applications to track and monitor a user’s
location—for example, to provide driving directions. Users
who prefer not to permit such tracking and monitoring
should avoid using such applications.
If you have further questions regarding how the use of your mobile
device may impact your privacy or data security, please contact
Motorola at
privacy@motorola.com
, or contact your service
provider.
Smart Practices While Driving
Drive Safe, Call Smart
SM
Check the laws and regulations on the use of phones and
their accessories in the areas where you drive. Always
obey them. The use of these devices may be prohibited or
restricted in certain areas—for example handsfree use
only. Go to www.motorola.com/callsmart (in English only)
for more information.
Your mobile device lets you communicate by voice and
data—almost anywhere, anytime, wherever wireless service is
available and safe conditions allow. When driving a car, driving is
your first responsibility. If you choose to use your phone while
driving, remember the following tips:
Legal and Safety
89
• Get to know your Motorola mobile device and its
features such as speed dial and redial.
If available,
these features help you to place your call without taking
your attention off the road.
• When available, use a handsfree
device.
If possible, add an additional
layer of convenience to your phone with
one of the many Motorola Original
handsfree accessories available today.
• Position your mobile device within easy reach.
Be
able to access your phone without removing your eyes
from the road. If you receive an incoming call at an
inconvenient time, if possible, let your voice mail answer
it for you.
• Let the person you are speaking with know you are
driving; if necessary, suspend the call in heavy
traffic or hazardous weather conditions.
Rain, sleet,
snow, ice, and even heavy traffic can be hazardous.
• Do not take notes or look up phone numbers while
driving.
Jotting down a “to do” list or going through your
address book takes attention away from your primary
responsibility, driving safely.
• Dial sensibly and assess the traffic; if possible,
place calls when your car is not moving or before
pulling into traffic.
If you must make a call while
moving, dial only a few numbers, check the road and your
mirrors, then continue.
• Do not engage in stressful or emotional
conversations that may be distracting.
Make people
you are talking with aware you are driving and suspend
conversations that can divert your attention away from the
road.
• Use your mobile device to call for help.
Dial 911 or
other local emergency number in the case of fire, traffic
accident, or medical emergencies (wherever wireless
phone service is available).
• Use your mobile device to help others in
emergencies.
If you see an auto accident, crime in
progress, or other serious emergency where lives are in
danger, call 911 or other local emergency number
(wherever wireless phone service is available), as you
would want others to do for you.
• Call roadside assistance or a special
non-emergency wireless assistance number when
necessary.
If you see a broken-down vehicle posing no
serious hazard, a broken traffic signal, a minor traffic
accident where no one appears injured, or a vehicle you
know to be stolen, call roadside assistance or other
special non-emergency wireless number (wherever
wireless phone service is available).
90
index
index
A
accessories 8, 69
active phone line 49
advanced calling 66
alert
set 52, 62
turn off 52
answer a call 12
audio formats 21
auto replies 38
B
backlight 64, 70
battery 9, 10
battery indicator 50
Bluetooth
connect 46
send information 47
setting your phone 45
turning on or off 45
C
call
answer 12
end 12, 13
make 12
call forward 58
caller ID 58
calls 56
center key 53
center select key 8
clock 70
combined power/end/home
key 12, 13
contacts 67
D
datebook 67
receive events via PTT 68
setup 64
dial a phone number 12
dialed calls 56
display 49
drafts 18
E
earpiece volume 52
emergency number 59
end a call 12, 13
F
frequently asked questions
service and repairs 77
91
index
G
GPS 68
GPS enabled
emergency calls 59
GPS, see GPS enabled
H
handsfree 69
handsfree speaker 53
hearing aid 54
Hearing Aid Compatibility 85
home screen 49
I
image formats 22
incoming call message 58
international calls 59
iTAP text entry mode 51
L
language 70
low battery message 50
M
make a call 12
media center 21
memory
text messages 19
message center
text messages 17
message indicator 50
messages 70
MMS 30
N
navigation key 8, 53
O
one touch PTT 29
optional accessory 8, 69
optional feature 8
P
packet data 50
PC applications 70
personalize 70
phone number 15
private calls
answer 13
make 13
PT manager 30
Q
quick notes
create, edit 16, 18
R
radio frequency 72
received calls 56
recent calls 56
recycling 87
redial 57
ring style indicator 50
92
index
ring style, setting 52
ring tones
off 62
setting 62
vibrate 62, 63
ringer volume 52
S
safety
radio frequency 72
RF energy interference 73
safety information 72
safety tips 88
security 71
send key 12
SIM card 9
change SIM PIN 71
enable SIM PIN 71
soft keys 49
speaker 50, 68
speed dial 60
store your number 15
T
tap text entry mode 51
text entry 50
text messages 15
creating 17
deleting 19
drafts 18
memory 19
message center 17
receiving 17
resend messages 18
sending 17
sent messages 19
setting up 16
transmitters 53
TTY calls 70
turn on/off 12
V
voice mail
receiving 61
setting up 61
voice names 57
voicemail 61
volume 52
W
wallpaper 63
WHO information 86
Y
your phone number 15
www.motorola.com
NNTN7813A
@NNTN7813A@
xxxxxxxx xx xx AUG/09
Printed in USA
