Exhibit 8 Users Manual

APPLICANT MOTOROLA INC. FCC ID: IHDP56KW1

INSTRUCTION MANUAL

A representative version of the user's manual follows:

Exhibit 8

1Congratulations

Congratulations

MOTOROLA Calgary with MOTOBLUR

MOTOROLA Calgary with MOTOBLUR syncs

contacts, posts, feeds, messages, e-mails, photos and

much more—from sources like Facebook, Twitter,

MySpace, Gmail, Yahoo, your work e-mail, Picassa,

Photobucket, LastFM—and automatically serves it up

just the way you want it.

•Only MOTOBLUR syncs your favorite social

networking sites – all your contacts, all your

messages, all the latest updates – straight to your

MOTOROLA Calgary.

•Download thousands of cool apps from Android

Market™ and the Motorola app store, to play and

surf to your heart’s content.

•MOTOBLUR backs it all up too. So relax, already.

Caution: Before assembling, charging or using your

phone for the first time, please read “Safety,

Regulatory & Legal” on page 54. Once your phone

is up and running, touch Menu > Settings

>About phone > Safety & regulatory to read the full

information.

More information

On your phone—Touch Home > Help Center.

You can also flick your home screen left or right to see

two widgets called Getting Started and Tips & Tricks.

Touch them for helpful advice.

On your computer—Go to

www.motorola.com/mycalgary.

After you create a MOTOBLUR account, you can also

www.motorola.com/mymotoblur

So, whether you want to read, watch, or play, we can

help.

2Your phone

Your phone

Tip: To change the Notification LED, touch Menu

>Settings > Display & security > Notification LED.

Power Key

Press to put the dis-

play to sleep, or hold

to turn off.

Volume Keys

Camera Key

Voice Command

Key

Activate speech

dialing & voice

commands.

Menu Key

Touch to open menu

options.

Battery & microSD

Card compartment

Micro USB

Connector

Charge or connect to

PC.

Optical Navigation

Key.

Scroll to & select

options.

Home Key

Touch to return to

home screen.

Back Key

Touch for text

search.

3.5mm Headset Jack

Note: Your phone might look a little different.

Delete

Return

Space

Shift

When you open or turn your phone,

the screen adjusts for you.

3Your phone

TOC to be developed Let’s go

let’s get you up and running

Assemble & charge

Caution: Please read the battery use and safety text in

the important legal and safety information packaged

with your phone.

1cover off 2battery in

3microSD in (may

already be done)

4cover on

5charge up

4Your phone

Tip: To save battery life, see “Battery tips” on page 26.

Set up & go

Create or log into a MOTOBLUR account to get your

contacts, email, messages, and status information, for

all your accounts, all in one place, all the time. There’s

more in “Your MOTOBLUR account” on page 10.

Registration is secure, and should only take a few

minutes:

1Turn on.

2Select a language.

3Touch Setup to create a

MOTOBLUR account, or

touch Home to skip setup

and go to the home

screen.

To create a MOTOBLUR

account, enter your name,

your current email address

(where MOTOBLUR can

send account information),

and a MOTOBLUR account

password.

Tip: Open your phone to

type.

If you choose

Home, go to step 5.

You can add

MOTOBLUR and

other accounts later

in “Add account”

on page 11.

MOTOBLUR ID:

Enter email address

Your name:

e.g. John Smith

Password:

Password

NextBack

Creating your

MOTOBLUR account...

5Your phone

Turn it on & off

To turn on your phone,

press Power (on the right side).

To turn off your phone, press and hold

Power , then touch Power off in the

menu that opens.

Wi-Fi connect

If you want to use a Wi-Fi network for even faster

Internet access, touch Menu > Settings

>Wireless controls > Wi-Fi settings. Touch Wi-Fi to

search for and connect to wireless networks. There’s

more in “Wi-Fi” on page 44.

4Add your accounts to

MOTOBLUR.

After you finish or skip

signing in, your home

screen appears.

Touch an account

type, then enter the

user name or email

and password that

you set up on that

account.

acebook

ast

cas

Photobucke

ace

Cool content & more

Note: You might not have some features. For details,

ask your service provider.

Browse and download thousands of the coolest apps

on the planet from Android. On top of that, you get a

full HTML browser, so you can surf in style.

Download new apps with “Android Market™” on

page 42. Your phone comes with a microSD memory

card installed—you can load it up with photos, videos,

and music from your computer using “Manage files

with a USB connection” on page 45.

Note: Do not remove your memory card while your

phone is using it or writing files on it.

Security

Your contacts are backed-up on MOTOBLUR, so don’t

worry. Even if you lose your phone, MOTOBLUR can

help you find it or wipe it. And when you get your next

MOTOBLUR product, your stored info makes it a snap

to set up with just a username and password.

Of course it doesn't stop there. There are plenty of

ways to protect your phone and your information,

in “Security” on page 50.

6Touchscreen & keys

Touchscreen & keys

a few essentials

Touch tips

Here are some tips on how to navigate around your

phone.

Touch

To choose an icon or option,

Touch it. Try it: In the home

screen, touch

Contacts.

Touch & hold

To open special options, touch

and hold an icon or other item.

Try it: In the home screen,

touch Contacts, then

touch and hold a contact to

open options.

Contacts

Alex Pico

Delete contact

Alex Pico

View contact

Call

Send Text Message

Drag

To scroll through a list or

move slowly, drag across

the touchscreen. Try it: In

the home screen, touch

Contacts, then drag

your Contacts list up or

down.

Tip: When you drag or flick

a list, a scroll bar appears

on the right. Drag the scroll

bar to move the list to a

letter A - Z.

Flick

To scroll through a list or move quickly, flick across the

touchscreen (drag quickly and release).

Tip: When you flick a long list, touch the screen to stop

it from scrolling.

Optical navigation key

Move your finger lightly

over the Optical Navigation

Key to navigate your

phone’s display and to

highlight options.

Contacts

StatusHistory A-Z

Alex Pico

Mariana Bukvic

Luke Carmody

Dan Smith

Keith Zang

Kate Shunney

Optical

Navigation

Key

7Touchscreen & keys

Key tips

Menu, home, & back

Touch Home to

close any menu or app

and return to the home

screen. Touch and hold

Home to show the

last few apps you used,

then touch an app to

open it. In the home screen, touch Home to open

or close the main menu.

Touch Menu to open menu options, or Back to

go back.

Sleep & wake up

To save your battery, prevent accidental

touches, or when you want to wipe

smudges off your touchscreen, put the

touchscreen to sleep by pressing

Power . To wake up the

touchscreen, just press Power

touch Menu , Home , or

Back , or open the phone.

To change how long your phone waits before the

screen goes to sleep automatically, touch Menu

>Settings > Display & security > Screen timeout.

Tip: To make the screen lock when it goes to sleep,

use “Screen lock” on page 50.

Power key menu

Press and hold Power to open the power key

menu, where you can turn off the phone (Power off),

or turn off features (Airplane mode, Bluetooth, Wi-Fi,

or GPS).

Adjust volume

Press the volume keys to

change the ring volume (in

the home screen), or the

earpiece volume (during a

call).

Spin the screen

In many apps, the touchscreen can spin to stay

right-side up when you rotate your phone:

Find it: Menu > Settings > Display & security

>Orientation

Volume

Keys

8Home screen

Home screen

quick access to the things you need most

Quick start: Home screen

The home screen gives you all your latest information

in one place. It’s what you see when you turn on the

phone or touch Home from a menu. It’s basically

like this:

Trevor Gilley

Black turtleneck

and a beret, and

he thought I was

serious?

5 min ago

298 minutes away from cake.

15 min ago

Browser

Vanessa Eskridge

Ultra secret

double-agent

party agenda

11:35

London

Partly Sunny

20˚

Messaging

Status Indicators

Your Online Status

Touch to change your status.

Widgets

Touch to open, or touch &

hold to move or delete.

Flick left or right to open

more panels of widgets.

Shortcuts

Touch to open.

Open the main menu.

Notifications

Flick this bar down to see

details.

Use & change your home screen

On your home screen, shortcuts are icons that you

open your favorite apps, Web bookmarks, contacts,

mail labels, or music playlists. Widgets show you

news, weather, messages, and other updates.

Flick the home screen left or right to open other panels

of shortcuts and widgets.

•To open something, touch it. Touch Home to

return to the home screen.

To change a widget’s settings, open it and then

touch Menu > Setup.

You can find details about the settings for

Happenings (“Add account” on page 11), Messages

(“Set up messaging” on page 20), Music (“Music”

on page 32), Social Status (“Update your status” on

page 11), or News or Weather (“Set up widgets” on

page 27).

•To add something or change your wallpaper, touch

and hold an empty spot until you see the Add to

Home screen menu.

You can add a folder to organize your shortcuts.

•To move or delete something, touch and hold it

until you feel a vibration, then drag it to another

spot, another panel, or the trash at the bottom of

the screen.

9Home screen

To search, use a Search widget (if you have one on

your home screen), or touch Menu > Search .

Tip: In your main menu or Contacts, you can open your

phone (or touch and hold Menu to open a display

keypad), then type contact details to search.

Phone status & notifications

At the top of the screen, icons

on the left notify you about new

messages or events (flick the bar

down for details). Icons on the

right tell you about phone status:

Bluetooth® active network (full signal)

GPS active network (roaming)

Wi-Fi active GPRS (fast data)

downloading EDGE (faster data)

Google Search

Search by voice.

For a text search, touch

the text box & type

using the touch keypad

or the QWERTY keypad.

Then, touch the icon for

a text search.

11:35

Tip: To see today’s date, touch and hold the status

indicators.

vibrate 3G (fastest data)

silent flight mode

mute call battery (charging)

speakerphone active battery (full charge)

Google™ sync

active

alarm set

10 Main menu

Main menu

Quick start: Main menu

The main menu shows you all of

your applications. To open it from

the home screen, touch

Home . To close it, touch

Home again.

Note: Your main menu will vary.

Tip: To find an app in the main menu, open your phone

(or touch and hold Menu to open a display keypad),

then type the app name.

Recent apps

Touch and hold Home to see the last few apps you

used, then touch the app you want. Touch Home

to return to the home screen.

Social networking

my life, your life

Your MOTOBLUR account

The first time you turned on your phone, you

registered for a MOTOBLUR account that manages

your messages, contacts, and more (“Set up & go” on

page 4). You can log into this account from a computer

to upload contacts, reset your password, get help, or

even locate your phone:

www.motorola.com/mymotoblur

What is MOTOBLUR?

MOTOROLA Calgary with MOTOBLUR is the first

phone with social skills.

Only MOTOBLUR synchs contacts, posts, feeds,

messages, e-mails, photos and much more—from

sources like Facebook, Twitter, MySpace, your work

e-mail, Picasa, Photobucket—and automatically serves

it up just the way you want it. No opening and closing

apps and menus, it’s all front and center on your home

screen and integrated throughout the entire phone so

you can communicate anyway you like.

11Social networking

Update your status

After you add a social networking account, you can

update and see your current status in a Social Status

widget on your home screen.

To update your status, just touch your Social Status

widget and enter text. If you have more than one

account, you can use the pull-down menu to limit

which accounts are updated. If you don’t see a Social

Status widget, flick your home screen left or right to

check all panels.

To add a Social Status widget:

1Touch and hold an empty spot on your home screen

to open the Add to Home screen menu.

2Touch Widgets > Social Status. The widget appears

in the empty spot, and will show your status the

next time your phone updates from the network.

Add account

If you skipped setting up a MOTOBLUR account

when you first turned on your phone, you’ll need to set

up a MOTOBLUR account before you can add other

accounts. In your home screen, touch Setup your

Blur account and follow the steps in “Set up & go” on

page 4.

Note: You can add your Facebook, MySpace, Twitter,

or other accounts to your phone. If you don’t have

accounts, you can visit their Web sites to set them up.

Find it: Menu > Settings > Accounts > Add

account...

To sign into your account, use the user name or email

and password that you set up on that account (the

same as on your computer).

When you sign into social networking accounts, you’ll

see your friends and contacts in your Contacts list, and

your status and updates can appear in Social Status

and Happenings widgets.

Twitter and MySpace messages will always appear

as “read” on your phone, but your phone notifies you

when you receive a new message. MySpace marks

your messages as “read” online.

For email accounts, see “Set up messaging” on

page 20.

Tip: To download updates faster, use “Wi-Fi” on

page 44.

View account updates & features

After you add a social networking account, you can see

and respond to friends’ updates with the Happenings

widget on your home screen. If you don’t see one, set

one up in “Widgets” on page 27.

12 Calls

When you touch the Happenings widget to open an

update, you can touch the social network’s icon to

open its Web site.

Note: Your network or other factors might affect the

speed of widget updates.

Edit & delete accounts

Find it: Menu > Settings > Accounts

Touch and hold an account, then touch Open account

to edit it, or touch Delete account to remove it (along

with its contacts and messages).

Calls

it’s good to talk

Quick start: Calls

Dialing options

Find it: Dialer

Recent FrequentDialer Spd Dial

GHI

ABC DEF

MNO

TUVPQRS WXY

123

JKL

Call

Speed Dial List

Touch to

, the

touch

to add or edit.

Frequent Call List

Touch to open, then touch an

entry to call.

Delete

Touch to delete a digit you

entered.

Recent Calls

Touch to open, then touch an

entry to call.

Open Your Contacts

Call

Enter a phone number &

touch here to call it.

13Calls

In-call options

During a call, touch Menu to choose Hold, New

call, or Use Bluetooth, or to wake up the touchscreen

if it’s dark.

Tip: You can touch Home or Back to hide the

active call display. To reopen it, touch Dialer.

Make & answer calls

To make a call, touch Dialer, enter a number,

then touch Call.

Alex Pico

Mobile (555) 555-2505

Just found $100 on the street! Drinks on

me tonight!

End call

SpeakerMute

Active call ( 00:12 )

Call Timer

Mute

Tap to mute or unmute the

call.

End Call

Tap to hang up.

Speakerphone

Tap to turn the speakerphone

on or off.

Dial Pad

Tap to open a dial pad, to

enter numbers during a call.

Tip: To enter the international dialing code, touch and

hold . To add a pause or wait after numbers, touch

Menu .

To answer a call, drag Answer to

the right (when your phone is

unlocked, Answer is just a touch

button).

End calls

Touch End call.

Note: When you hold your phone

to your ear, the display goes dark

to avoid accidental touches.

When you move your phone away from your ear, the

display lights up again.

Tip: You can touch Home or Back to hide the

active call display. To reopen it, touch Dialer.

Speed dial

Find it: Dialer > Spd Dial

•To call a number, touch it.

•To add, edit, or clear entries, touch Menu .

Voice dial

Find it: Dialer >

Slide to Answer

Press Power/Lock button to ignore

End call

SpeakerMute

Call

14 Calls

Say a number, or a name from your Contacts.

Handsfree

Note: Using a mobile device or accessory while

driving may cause distraction and may be illegal.

Always obey the laws and drive safely.

During a call:

•To use the speakerphone, touch Speaker.

•To use a Bluetooth® device, touch Menu > Use

Bluetooth.

Mute & hold

During a call:

•To mute the current call, touch Mute.

•To put a call on hold, touch Menu > Hold.

Enter numbers during a call

To enter numbers during a call,

touch and then touch the dial

pad.

Recent calls

Find it: Dialer > Recent

•To call a number, touch it.

End call

SpeakerMute

•To send a text message, create a contact, view a

contact, add the call to speed dial, or other options,

touch and hold an entry.

•To filter the list, touch the view name (like All calls)

at the top.

•To clear the list, touch Menu .

Frequent calls

Find it: Dialer > Frequent

•To call a number, touch it.

•To send a text message, view a contact, add the call

to speed dial, or other options, touch and hold an

entry.

Conference calls

To start a conference call, call the first number. After

they answer, touch Menu > New call and call the

next number. When the next number answers, touch

Menu > Join.

Your phone number

Find it: Menu > Settings > About phone > Status

>Phone number

15Calls

Your caller ID

To hide your number from the people you call,

touch Menu > Settings > Call settings

>Additional call settings > Caller ID.

Emergency calls

Note: Your service provider programs one or more

emergency phone numbers (such as 911 or 112) that

you can call under any circumstances, even when your

phone is locked. Emergency numbers vary by country.

Your pre-programmed emergency number(s) may not

work in all locations, and sometimes an emergency

call cannot be placed due to network, environmental,

or interference issues.

1Touch Dialer (if your phone is locked, touch

Emergency Call or touch Menu > Emergency

call).

2Enter the emergency number.

3Touch Call to call the emergency number.

Note: Your mobile device can use AGPS satellite

signals to help emergency services find you (see the

important legal and safety information packaged with

your phone).

Call forwarding & waiting

You can forward calls all the time, or only when your

phone is busy, unanswered, or unreachable (not on the

network):

Find it: Menu > Settings > Call settings > Call

forwarding

When you’re on a call and a second call comes in, Call

waiting lets you answer it by touching Answer. You can

turn off Call waiting, to send second calls straight to

your voicemail:

Find it: Menu > Settings > Call settings

>Additional call settings > Call waiting

Restrict outgoing calls

To restrict your phone so that it can only dial a few

numbers:

Find it: Menu > Settings > Call settings > Fixed

dialing number

•To turn fixed dialing on, touch FDN disabled.

•To add or delete the allowed numbers, touch

Manage FDN list.

16 Contacts

Contacts

contacts like you’ve never had before

Quick start: Contacts

Find it: Contacts

Tip: To search the list, open your phone (or touch and

hold Menu to open a display keypad), then type a

name. When you flick or drag this list, a scroll bar

appears on the right. Drag the scroll bar to move the

list faster.

Contacts

StatusHistory A-Z

Alex Pico

Mariana Bukvic

Luke Carmody

Dan Smith

Keith Zang

Kate Shunney

Group

Touch Menu to

choose which group to

show (like All, Favorites, or

Facebook).

Create Contacts

Views

Touch a list view, or flick

the display right or left to

show:

History - recently used

A-Z - list without status

Status - list with status

Contacts List

Touch to view contact

information. Touch & hold

to edit, delete, & more.

Call, text, or email contacts

Find it: Contacts

For Call, Send Text Message, Email, View contact, or

other options, touch and hold the contact.

View & use contacts

With a MOTOROLA Calgary with MOTOBLUR, you’ll

know what everybody’s up to and when. Every time

you pick up a call, check a message, or look up a

friend’s contact info, sure, you’ll see their name and

number, but you’ll see their social network status and

smiling face, too.

Find it: Contacts

•To filter the contacts by group (All, Facebook, and so

on) touch the filter name at the top.

Tip: To change which account provides the pictures

for your Contacts, from the home screen touch

Menu > Settings > Accounts > Menu

>Picture source.

•To change the list view, touch History (recently

used), A-Z (list without status), or Status (list with

status) at the bottom.

•To find a contact, just type the name.

Touch a contact to open its details. To start a call or

message, just touch a phone number or other info.

17Contacts

You can touch History, Info, or Happenings at the

bottom of the screen to see more.

Edit or delete contacts

Find it: Contacts

Touch the contact, then touch Menu > Edit or

Delete. You can set a ringer, address, and other details

that will be saved on your phone and your MOTOBLUR

account.

Where are contacts edited or deleted? Your phone

edits the contacts in its memory, and also updates

your MOTOBLUR account.

Link contacts

You might have two Contacts for the same person,

maybe a friend with two email addresses. To combine

these two contacts:

Find it: Contacts

Touch a contact to open it, then touch Menu

>Link contact and touch the second entry. Your

MOTOBLUR account remembers this connection.

Create contacts

Find it: Contacts >Menu >Add contact

Open your phone to type the name and details.

When you’re finished, touch Menu > Save.

Where are contacts saved? Your phone saves new

contacts in its memory, and also updates your

MOTOBLUR account. So, if you get another

MOTOBLUR phone, you can just log into MOTOBLUR

to download your contacts and update your accounts:

In Contacts, touch Menu > Settings to choose

which accounts are updated with new contacts.

Adam Aaronson

Phone

First Last

Phone

Add contact

Home

Mobile

Touch Mobile to choose a

different type for this

entry.

Touch + to add another

entry.

Touch - to remove this

entry.

To see more details, flick up.

18 Contacts

Synchronize contacts

Note: You might not have this feature. For details, ask

your service provider.

When you change one of your Contacts, your phone

automatically updates your MOTOBLUR account

online. Also, your phone updates your Contacts and

MOTOBLUR account whenever you change a friend in

your social networking accounts.

Note: To synchronize contacts in your service provider

account, ask your service provider.

So, you don’t have to do anything to synchronize your

Contacts with your other accounts! MOTOBLUR takes

care of it for you.

My details

Find it: Contacts >Menu >View my

details

To edit details, touch them.

Groups

You can put your Contacts into groups that you create

(like “friends,” “family,” or “work”). Then, you can find

contacts faster by showing one group at a time.

To create a group in your Contacts, touch Menu

>Add group. Enter a group name, then touch Add to

add members.

To show only one group in your Contacts, touch

Contacts at the top of your screen and choose the

group name.

19Messaging

Messaging

sometimes it’s best to text, or IM, or email . . .

Quick start: Messaging

Find it: Home > Messaging > Universal Inbox

Tip: To see more messages, flick or drag up.

Read & reply to messages

Every text, email, friend-feed, wall post, and bulletin is

automatically delivered to you, ready for your

immediate reply with the slide-out keypad. The best

8:34 PM

Alex Pico

Some guys have all the luck - me...

Right now, you’re busy flexing...

Sep 25

Keith Zang

Job

It’s only a freelance gig, but it pays...

Sep 25

Kate Shunney

I have so much energy today, I have

no IDEA why.

Universal Inbox (4)

Sep 25

Seth Rementer

The cinnamon bun place is right

next to the store. It’s like 8 hours...

Create Message

Touch to create a new

message, & see a list of your

drafts (indicated by the

number).

Message List

Touch to open a message.

Touch & hold to move,

delete, & more.

Check for Messages Now

Message Type

Message Status

Icons indicate a message:

unread

urgent

has attachments

part is you don’t have to dig through any apps, screens

or menus—every message streams right to the phone,

viewable exactly the way you want.

Every text, email, friend-feed, wall post, and bulletin is

automatically delivered to you, ready for your

immediate reply with the flip-open keypad. The best

part is you don’t have to dig through any apps, screens

or menus—every message streams right to the phone,

viewable exactly the way you want.

Find it: Home > Messaging > Universal Inbox

Note: Universal Inbox shows all of your messages

together—text, email, and social networking

messages. To show only one type of message, touch a

message account type instead of Universal Inbox.

•To open a message and all of its replies, touch it.

•To respond to a message, just open it and enter

your response in the text box at the bottom.

To forward a text message, touch and hold a

message in the conversation, then touch Forward

message.

For email, touch to choose

a reply or forward option.

•To open options, touch and

hold a message.

20 Messaging

Tip: Try the Messages widget in “Widgets” on

page 27.

Create messages

Find it: Home

>Messaging >

Choose a message type. Then,

enter the recipient and message. In text messages

and emails, touch Menu for options like Insert... or

Attach Files.

Send & receive attachments

To send a file in a message, open a new message and

touch Menu > Insert... or Attach Files.

When you receive a message with an attachment,

open the message and touch the file name to

download it. Then, touch the name again to open it.

Some file formats can be converted to HTML for faster

viewing, and your phone will show a button that says

Get HTML version.

Tip: To send and receive large attachments faster, use

a Wi-Fi connection, in “Wi-Fi” on page 44.

Set up messaging

To add email accounts, touch Menu > Settings

>Accounts > Add account....

Messaging

•Corporate Sync is for Exchange server work email

accounts. Enter details from your IT administrator.

Tip: You might need to enter your domain name

with your user name (like domain/username)

Note: Some work accounts might require you to

add a password lock to your phone, for security. To

stop an account from showing the contacts you

create on your phone, touch Contacts, touch

Menu > Settings, then uncheck the account

under New contacts.

•Email is for most personal email accounts. For

account details, contact the account provider.

Note: While you are using a Wi-Fi network, you

cannot access Yahoo Mail accounts. You can still

use your browser to see these accounts at

mail.yahoo.com.

To change your settings, touch Home

>Messaging > Menu , then touch:

•Manage accounts to change your user name or

password (or server settings, for email).

•Edit Universal Inbox to choose which accounts

show messages in the Universal Inbox.

•Messaging Settings to set the notification for each

account type (along with other preferences, for

email).

21Messaging

To g e t Gmail™ in your Messages widget and

Universal Inbox, you’ll need to add it as an Email

account: Touch Home > Messaging

> Menu , then touch Manage accounts > Add

account... > Email and enter your Gmail™ details. If

you added your Google account too, turn off its email

sync to avoid duplicate email notices: Touch

Home > Accounts, touch your Google™ account,

and touch the checkmark to turn off Gmail.

Tip: For social network accounts, see “Add account”

on page 11.

Instant messages

Note: You might not have this feature. For details, ask

your service provider.

To send and receive instant messages, you can use an

instant messaging app or your browser.

•To download and use an instant messaging app,

touch Home > Market > Applications

>Communication, then choose an app for your

provider. Once you download the app, you’ll see it in

“Main menu” on page 10.

•If you don’t see an app for your IM provider, you can

use your Web browser. Touch

Home > Browser >Menu >Go, then

enter your provider’s Web site. Once you’re there,

follow the link to sign in.

Note: Your IM options will depend on your IM provider.

To browse instant messaging apps from your

computer, go to www.android.com/market.

Voicemail

When you have a new voicemail, shows at the top

of your screen. To hear the voicemail,

touch Dialer, then touch and hold .

If you need to change your voicemail number, in the

home screen touch Menu > Settings > Call

settings > Voicemail.

22 Text entry

Text entry

think keyboard, now think smaller

Typing tips

To use the full keypad, slide open your phone (“Your

phone” has a keypad diagram):

To use the full keypad, slide open your phone:

To . ..

Enter symbols chosen from

a list

Press Symbols

Enter special function

characters in the corners of

keys

Press Function

Enter several special

function characters, until

you touch Alternate

again

Press Function

twice

Enter one capital letter Press Shift

Enter only capital letters,

until you press Shift

again

Press Shift twice

Select text Hold Shift +

touch Optical

Navigation Key

Cut, Copy, or Paste text

you selected

Touch and hold the

text box to open the

Edit text menu

Select text Hold Shift +

touch Optical

Navigation Key

Cut, Copy, or Paste text

you selected

Touch and hold the

text box to open the

Edit text menu

Delete a character (hold to

delete more)

Press Delete

Delete the current line Press Function +

Delete

Jump to the beginning/end

of a line

Press Function +

Optical Navigation

Key

Start a new line (email or

social networking) or send

the message (text

messages)

Press Return

To...

23Text entry

To change your text entry settings and see the

dictionary of terms you’ve used, from the home

screen, touch Menu > Settings > Locale & text.

Touchscreen keypad

When your phone is closed, you can open a display

keypad by touching a text field, or touching and holding

Menu . To close the keypad, touch Back .

To change your settings for this keypad, from the home

screen, touch Menu > Settings > Locale & text

>Android keyboard.

zxcvbnm

df ghj kl

DEL

we r t y u i op

?123

Delete

Return

Space

Symbols/Numbers

Touch to open a keypad for symbols and numbers.

Shift

Text Entry

Touch to open

the touchscreen

keypad.

Format text in emails

When you create an email, you can format your

message. To select text for formatting, press and hold

Shift , then touch the Optical Navigation Key.

Text entry settings

When you use the touchscreen keypad, your phone

suggests words from your dictionary and chosen

language. Your phone also automatically enters

apostrophes in some words, like “dont.”

Find it: Menu > Settings > Locale & text

•To edit your dictionary, touch User dictionary.

New message

To:

Subject:

Send Discard

Font

Bold, Italic,

or Underline

Bullet FontSmiley

24 Tips & tricks

•To change the language and the style for your

touchscreen keypad, touch Select locale.

•To change the sounds, corrections, and other

settings for your touchscreen keypad, touch Android

keyboard.

•To change the automatic correction settings for your

full keypad, touch Device keyboard.

Tips & tricks

a few handy hints

Shortcuts

To...

Return to the home

screen

Touch H om e .

See recently dialed

numbers

Touch Dialer

>Recent.

Sleep/wake your

phone

To sleep, press Power . To

wake, touch Menu .

Set lock screen Touch Menu > Settings

>Display & security

>Screen lock.

Google™ search Touch Menu > Search.

Show last few apps

used

Touch and hold Home .

Turn airplane mode

on/off

Press and hold Power

>Airplane mode.

Turn Bluetooth®

on/off

Press and hold Power

>Bluetooth.

Turn Wi-Fi on/off Press and hold Power

>Wi-Fi.

25Tips & tricks

Tur n GPS on/off Press and hold Power

>GPS.

Zoom in to select a

link on a web page

Tou ch > link.

Go to the top of a

list

Press Function > Optical

Navigation Key up.

Go to the bottom of

a list

Press Function > Optical

Navigation Key down.

Scroll list up one

screen

Press Shift > Optical

Navigation Key up.

Scroll list down

one screen

Press Shift > Optical

Navigation Key down.

Sync media to your

desktop / laptop

Sync your pictures, videos,

music, and iTunes™ playlists

between your phone and

laptop or desktop

Sync contacts from

your desktop /

laptop to your phone

Use the MOTOBLUR portal:

www.motorola.com/mymoto

blur.

To . ..

Show email or

updates from a

group of friends

Touch Contacts

>Menu >Add Group.

Create a group, then open

the group (touch Contacts at

the top of your Contacts list).

Touch History to see this

group’s messages, or Status

to see their updates.

Change which

messages appear in

the Universal Inbox

Open the Universal Inbox

then touch Menu > Edit

Universal Inbox to choose

your accounts.

Add a shortcut on

your home screen

for an app or contact

Touch and hold an open area

on your home screen to open

the Add to Home screen

menu, then choose

Shortcuts. Then, you can

choose from the

Applications or Contact lists.

Move a widget or

shortcut

Touch and hold the widget or

shortcut until you feel a

vibration, then drag it to

where you want.

To...

26 Tips & tricks

Battery tips

Your phone is like a small computer, giving you a lot of

information and apps, at 3G speed, with a touch

display! Depending on what you use, that can take a

lot of power. So, if you want to save battery life

between charges, you could reduce:

•recording or watching videos, listening to music, or

taking pictures.

•widgets that stream information to your home

screen, like news or weather (“Use & change your

home screen” on page 8).

•unused online accounts that you registered with

MOTOBLUR (“Edit & delete accounts” on page 12).

•GPS, Wi-Fi, and Bluetooth® use: Press and hold

Power to open the Power key menu, then touch

items to turn them off or on.

Delete a widget or

shortcut

Touch and hold a widget or

shortcut until you feel a

vibration, then drag it to the

trash can at the bottom of

your screen.

To . .. •Email updates: Touch Messaging >Menu

>Messaging settings > Email > Get new email

>Every hour.

•Google™ app updates: Touch Menu > Settings

>Google Synchronization > Background data.

•network speed: Touch Menu > Settings

>Wireless controls > Mobile networks > Select

network > 2G Only.

•network searching: If you are out of coverage, to

keep your phone from looking for networks, press

and hold Power to open the Power key menu,

then touch Airplane mode.

•display brightness: Touch Menu > Settings

>Display & security > Brightness > (dimmer

setting).

•display timeout delay: Touch Menu > Settings

>Display & security > Screen timeout > (shorter

setting).

27Personalize

Personalize

add your personal touch

Widgets

Create widgets

1Find an empty spot on your home screen where you

want to add a widget. You can flick left or right to

open other panels on your home screen.

2Touch and hold the empty spot until you see the

Add to Home screen menu.

3Touch Widgets.

4Touch the type of widget. If necessary, enter the

widget settings.

Set up widgets

You can customize some widgets. Touch a widget to

open it, then touch Menu :

•Happenings: Update your status, choose which

accounts appear in this widget, or manage your

accounts (the same as “Add account” on page 11).

•Messages: Change the widget name or choose how

long it shows new messages. To add email

accounts, “Set up messaging” on page 20.

•Music: Set this widget to an artist, album, song,

playlist, or just touch Menu > Party shuffle.

There’s more about “Music” on page 32.

•News: Change the widget name, choose how long it

shows new stories, or choose a news source. To

choose a source, touch , then choose preset

Bundles or Channels, or choose Custom to enter a

URL for a Webpage or an RSS feed.

•Weather: Change temperature units or add

locations. To add locations, touch , enter a city,

and touch Search. When you open the weather

widget, flick left to see other locations you added.

Note: Some apps have custom widget types that you

can add and set up after you install the app.

Ringtones

To personalize your ringtones:

Find it: Menu > Settings >Sound & ringtones

>Phone ringtone or Notification ringtone

To set your ringer and vibrate options:

Find it: Menu > Settings > Sound & ringtones

>Ringer & vibrate modes

To change your ringtone to silent, slide the ringer off

switch down.

28 Personalize

Tip: To use a song as a ringtone, touch

Home > Music > Songs, touch and hold the

song name, then touch Use as phone ringtone.

Sounds

Display settings

features

set volume for media and videos

Menu > Settings > Sound & ringtones > Media

volume

play tones when using dial pad

Menu > Settings > Sound & ringtones > Audible

touch tones

play sound on screen selection

Menu > Settings > Sound & ringtones > Audible

selection

features

notification LED

Blinks to tell you that a notification has been

received. Menu > Settings > Display & security

>Notification LED

Date & time

Set date, time, time zone, and formats:

Find it: Menu > Settings > Date & time

Language & region

Set your menu language and region:

Find it: Menu > Settings > Locale & text > Select

locale

set display brightness

Menu > Settings > Display & security

>Brightness

set orientation

Menu > Settings > Display & security

>Orientation

set animation

Menu > Settings > Display & security

>Animation

features

29Photos & videos

Photos & videos

see it, capture it, share it!

Photos

Take & share photos

Take that family photo, and post it online for everyone

to see.

Find it: Press Camera

Note: Photos are stored on your microSD memory

card. Picture Resolution is 3MP, unless you change it.

245

5MP

New York, New York 10006

United States

Autofocus Box Tap the screen to show a

thumbnail of your last photo.

To take the photo, lightly press Camera halfway

until the autofocus box turns green, then press all the

way to take the photo.

Touch the viewfinder to see a thumbnail of the photo

you’ve just taken (on the right). Touch the thumbnail,

then:

•To see all your photos, touch Gallery.

•To set the photo as a wallpaper, contact photo, or

social network profile photo, touch Set as.

•To send the photo in a message or post it online,

touch Share. For more info on sharing your photos,

see “Share your photo gallery” on page 30.

•To delete the photo and return to the viewfinder,

touch Delete.

Photo options

In the viewfinder, touch Menu > Settings to open

the camera menu:

options

Store

location in

pictures

Save the details of where the photo

was taken.


Resolution

Set the resolution of your photo.

30 Photos & videos

View your photos

Find it: Home > Picture Gallery

Color Effects Choose your color settings, like

None, Negative, or B/W.

Reset

Settings

Undo all of your camera setting

changes.

Advanced

settings

Set the Picture Quality of your

photo, or choose your White

Balance light settings, like Auto,

Daylight, or Cloudy.

options

All Pictures (10/43) 2010-07-12 12.00.00

ctures

(

10/43

)

7-12 12.

ll P

My Pictures All Pictures

Picture Dates

Tap on the left to open the

date list, then drag the dates

to find pictures.

we’re here to help

Crash recovery

In the unlikely event that your phone stops responding

to touches and key presses, try a quick reset. Remove

the back cover and battery (“Assemble & charge” on

page 3), then replace and turn on your phone as usual.

Service & repairs

If you have questions or need assistance, go to

www.motorola.com/support, where you can select

from a number of customer care options. You can also

contact the Motorola Customer Support Center at

1-800-331-6456 (United States), 1-888-390-6456

(TTY/TDD United States for hearing impaired), or

1-800-461-4575 (Canada).

54 Troubleshooting

Safety, Regulatory & Legal

Battery Use & Safety

Batter y Use & Safety

Important: Handle and store batteries properly to avoid injury or damage.

Most battery issues arise from improper handling of batteries, and particularly from

the continued use of damaged batteries.

DON’Ts

• Don’t disassemble, crush, puncture, shred, or otherwise attempt to

change the form of your battery.

• Don’t let the phone or battery come in contact with water.

Water can get

into the phone’s circuits, leading to corrosion. If the phone and/or battery get

wet, have them checked by your carrier or contact Motorola, even if they appear

to be working properly.

• Don’t allow the battery to touch metal objects.

If metal objects, such as

jewelry, stay in prolonged contact with the battery contact points, the battery

could become very hot.

• Don’t place your battery near a heat source.

Excessive heat can damage the

phone or the battery. High temperatures can cause the battery to swell, leak, or

malfunction. Therefore:

•

not

dry a wet or damp battery with an appliance or heat source, such as a

hair dryer or microwave oven.

•

Avoid leaving your phone in your car in high temperatures.

DOs

• Do avoid dropping the battery or phone.

Dropping these items, especially on

a hard surface, can potentially cause damage.

• Do contact your service provider or Motorola if your phone or battery

has been damaged from dropping or high temperatures.

Important: Use Motorola Original products for quality assurance and

safeguards.

To aid consumers in identifying authentic Motorola batteries from

non-original or counterfeit batteries (that may not have adequate safety protection),

Motorola provides holograms on its batteries. Consumers should confirm that any

battery they purchase has a “Motorola Original” hologram.

Motorola recommends you always use Motorola-branded batteries and

chargers.

Motorola mobile devices are designed to work with Motorola batteries.

If you see a message on your display such as

Invalid Battery

Unable to Charge

, take the following steps:

•

Remove the battery and inspect it to confirm that it has a “Motorola Original”

hologram;

•

If there is no hologram, the battery is not a Motorola battery;

•

If there is a hologram, replace the battery and retry charging it;

•

If the message remains, contact a Motorola authorized service center.

Important:

Motorola’s warranty does not cover damage to the phone caused by

non-Motorola batteries and/or chargers.

Warning:

Use of a non-Motorola battery or charger may present a risk of fire,

explosion, leakage, or other hazard.

Proper and safe battery disposal and recycling:

Proper battery disposal is not

only important for safety, it benefits the environment. Consumers may recycle their

used batteries in many retail or service provider locations. Additional information on

proper disposal and recycling may be found on the Web:

•

www.motorola.com/recycling

•

www.rbrc.org/call2recycle/

(in English only)

Disposal:

Promptly dispose of used batteries in accordance with local

regulations. Contact your local recycling center or national recycling

organizations for more information on how to dispose of batteries.

Warning:

Never dispose of batteries in a fire because they may explode.

Battery Charging

Batter y Chargi ng

Notes for charging your phone’s battery:

•

When charging your battery, keep it near room temperature. Never expose

batteries to temperatures below 0°C (32°F) or above 45°C (113°F) when

charging.

•

New batteries are not fully charged.

•

New batteries or batteries stored for a long time may take more time to charge.

•

Motorola batteries and charging systems have circuitry that protects the battery

from damage from overcharging.

032375o

55Troubleshooting

Specific Absorption Rate

SAR (IEEE)

Your model wireless phone meets the governmental

requirements for exposure to radio waves.

Your mobile device is a radio transmitter and receiver. It is designed and

manufactured to not exceed limits for exposure to radio frequency (RF) energy set by

the Federal Communications Commission (FCC) of the U.S. Government and by the

Canadian regulatory authorities. These limits are part of comprehensive guidelines

and establish permitted levels of RF energy for the general population. The

guidelines are based on standards that were developed by independent scientific

organizations through periodic and thorough evaluation of scientific studies. The

standards include a substantial safety margin designed for the safety of all persons,

regardless of age or health, and to account for any variations in measurements.

The exposure standard for mobile devices employs a unit of measurement known as

the Specific Absorption Rate (SAR). The SAR limit set by the FCC and by the

Canadian regulatory authorities is 1.6 watts per kilogram (W/kg), averaged over one

gram of tissue. Tests for SAR are conducted using procedures accepted by the FCC

and by Industry Canada with the mobile device transmitting at its highest certified

power level in all tested frequencies. Although the SAR is determined at the highest

certified power level, the actual SAR level of the mobile device while operating can

be below the maximum value. This is because the mobile device is designed to

operate at multiple power levels so as to use only the power required to reach the

network. In general, the closer you are to a wireless base station, the lower the

power output.

Before a mobile device is available for sale to the public in the U.S. and Canada, it

must be tested and certified to the FCC and Industry Canada that it does not exceed

the limit established by each government for safe exposure. The tests are performed

in positions and locations (e.g., at the ear and worn on the body) submitted to the

FCC and available for review by Industry Canada. The highest SAR value for this

mobile device when tested for use at the ear is 0.40 W/kg, and when worn on the

body, as described in this guide, is 0.69 W/kg. Body-worn measurements can differ,

depending upon available accessories and regulatory requirements. The SAR

information includes the Motorola testing protocol, assessment procedure, and

measurement uncertainty range for this product.

While there may be differences between the SAR levels of various mobile devices

and at various positions, they meet the governmental requirements for safe

exposure. Please note that improvements to this product model could cause

differences in the SAR value for later products; in all cases, products are designed to

be within the guidelines.

Additional information on SAR can be found on the Cellular Telecommunications

& Internet Association (CTIA) Web site:

http://www.phonefacts.net

or the Canadian Wireless Telecommunications Association (CWTA) Web site:

http://www.cwta.ca

Software Copyright Notice

Motorola products may include copyrighted Motorola and third-party software

stored in semiconductor memories or other media. Laws in the United States and

other countries preserve for Motorola and third-party software providers certain

exclusive rights for copyrighted software, such as the exclusive rights to distribute

or reproduce the copyrighted software. Accordingly, any copyrighted software

contained in Motorola products may not be modified, reverse-engineered,

distributed, or reproduced in any manner to the extent allowed by law. Furthermore,

the purchase of Motorola products shall not be deemed to grant either directly or by

implication, estoppel, or otherwise, any license under the copyrights, patents, or

patent applications of Motorola or any third-party software provider, except for the

normal, non-exclusive, royalty-free license to use that arises by operation of law in

the sale of a product.

Content Copyright

The unauthorized copying of copyrighted materials is contrary to the provisions of

the Copyright Laws of the United States and other countries. This device is intended

solely for copying non-copyrighted materials, materials in which you own the

are uncertain about your right to copy any material, please contact your legal

advisor.

56 Troubleshooting

Open Source Software Information

OSS Information

For instructions on how to obtain a copy of any source code being made publicly

available by Motorola related to software used in this Motorola mobile device, you

may send your request in writing to the address below. Please make sure that the

request includes the model number and the software version number.

MOTOROLA, INC.

OSS Management

600 North US Hwy 45

Libertyville, IL 60048

USA

The Motorola website

opensource.motorola.com

also contains information

regarding Motorola's use of open source.

Motorola has created the

opensource.motorola.com

website to serve as a

portal for interaction with the software community-at-large.

To view additional information regarding licenses, acknowledgments and required

please press Menu Key >

Settings

About Phone

Legal information

Open source licenses

. In addition, this

Motorola device may include self-contained applications that present supplemental

notices for open source packages used in those applications.

GPS & AGPS

Your mobile device can use Global Positioning System (GPS) signals for

location-based applications. GPS uses satellites controlled by the U.S. government

that are subject to changes implemented in accordance with the Department of

Defense policy and the Federal Radio Navigation Plan. These changes may affect

the performance of location technology on your mobile device.

Your mobile device can also use Assisted Global Positioning System (AGPS), which

obtains information from the cellular network to improve GPS performance. AGPS

uses your wireless service provider's network and therefore airtime, data charges,

and/or additional charges may apply in accordance with your service plan. Contact

your wireless service provider for details.

Your Location

Location-based information includes information that can be used to determine the

approximate location of a mobile device. Mobile phones which are connected to a

wireless network transmit location-based information. Devices enabled with GPS or

AGPS technology also transmit location-based information. Additionally, if you use

applications that require location-based information (e.g. driving directions), such

applications transmit location-based information. This location-based information

may be shared with third parties, including your wireless service provider,

applications providers, Motorola, and other third parties providing services.

Emergency Calls

When you make an emergency call, the cellular network may activate the AGPS

technology in your mobile device to tell the emergency responders your approximate

location.

AGPS has limitations and

might not work in your area

. Therefore:

•

Always tell the emergency responder your location to the best of your ability; and

•

Remain on the phone for as long as the emergency responder instructs you.

Performance Tips

•

Go outside and away from underground locations, covered vehicles, structures

with metal or concrete roofs, tall buildings, and foliage. Indoor performance

might improve if you move closer to windows, but some window sun shielding

films can block satellite signals.

•

Move away from radios, entertainment equipment, and other electronic devices.

Navigation

Navigation information provided by your mobile device does not replace the need for

you to pay attention to road conditions and closures, traffic, weather conditions, and

other factors that may affect your safety while driving. Always make sure the

information on your mobile device agrees with what you see outside your window,

and with other navigation sources such as street signs, visual sightings, and maps.

Always obey posted road signs.

Motorola strives to provide complete and accurate mapping information, directions,

and other navigational data, using a combination of governmental and private

57Troubleshooting

location information sources. These sources may contain some inaccurate or

incomplete data. Also, in some countries, complete map information may not be

available.

Safety & General Information

Safety Information

This section contains important information on the safe and efficient

operation of your mobile device. Read this information before using your

mobile device.

Exposure to Radio Frequency (RF) Energy

Your mobile device contains a transmitter and receiver. When it is ON, it receives

and transmits RF energy. When you communicate with your mobile device, the

system handling your call controls the power level at which your mobile device

transmits.

Your mobile device is designed to comply with local regulatory requirements in your

country concerning exposure of human beings to RF energy.

Operational Precautions

For optimal mobile device performance, and to be sure that human exposure to RF

energy does not exceed the guidelines set forth in the relevant standards, always

follow these instructions and precautions.

Product Operation

When placing or receiving a phone call, hold your mobile device just like you would

a landline phone.

If you wear the mobile device on your body, always place the mobile device in a

Motorola-supplied or approved clip, holder, holster, case, or body harness. If you do

not use a body-worn accessory supplied or approved by Motorola, keep the mobile

device and its antenna at least 2.5 centimeters (1 inch) from your body when

transmitting.

Using accessories not supplied or approved by Motorola may cause your mobile

device to exceed RF energy exposure guidelines. For a list of Motorola-supplied or

approved accessories, visit our Web site at:

www.motorola.com

RF Energy Interference/Compatibility

Nearly every electronic device is subject to RF energy interference from external

sources if inadequately shielded, designed, or otherwise configured for RF energy

compatibility. In some circumstances, your mobile device may cause interference

with other devices.

Follow Instructions to Avoid Interference Problems

Turn off your mobile device in any location where posted notices instruct you to do

so.

In an aircraft, turn off your mobile device whenever instructed to do so by airline

staff. If your mobile device offers an airplane mode or similar feature, consult airline

staff about using it in flight.

Implantable Medical Devices

If you have an implantable medical device, such as a pacemaker or defibrillator,

consult your physician before using this mobile device.

Persons with implantable medical devices should observe the following precautions:

•

ALWAYS keep the mobile device more than 20 centimeters (8 inches) from the

implantable medical device when the mobile device is turned ON.

•

DO NOT carry the mobile device in the breast pocket.

•

Use the ear opposite the implantable medical device to minimize the potential

for interference.

•

Turn OFF the mobile device immediately if you have any reason to suspect that

interference is taking place.

Read and follow the directions from the manufacturer of your implantable medical

device. If you have any questions about using your mobile device with your

implantable medical device, consult your healthcare provider.

Driving Precautions

Using a mobile device while driving may cause distraction. End a call if you can’t

concentrate on driving. Input information about your destination and route prior to

your drive. Do not input data or engage in text messaging while driving. Keep your

eyes on the road while driving. Listen to the audible turn-by-turn directions, if

available.

58 Troubleshooting

Also, using a mobile device or accessory may be prohibited or restricted in certain

areas. Always obey the laws and regulations on the use of these products.

Responsible driving practices can be found at www.motorola.com/callsmart (in

English only).

Operational Warnings

Obey all posted signs when using mobile devices in public areas.

Potentially Explosive Atmospheres

Areas with potentially explosive atmospheres are often, but not always, posted and

can include fueling areas, such as below decks on boats, fuel or chemical transfer or

storage facilities, or areas where the air contains chemicals or particles, such as

grain dust, or metal powders.

When you are in such an area, turn off your mobile device, and do not remove,

install, or charge batteries. In such areas, sparks can occur and cause an explosion

or fire.

Symbol Key

Your battery, charger, or mobile device may contain symbols, defined as follows:

Symbol Definition

Important safety information follows.

Do not dispose of your battery or mobile device in a fire.

Your battery or mobile device may require recycling in

accordance with local laws. Contact your local regulatory

authorities for more information.

Do not throw your battery or mobile device in the trash.

032374o

032376o

032375o

Batteries & Chargers

Caution:

Improper treatment or use of batteries may present a danger of fire,

explosion, leakage, or other hazard. For more information, see “Battery Use &

Safety.”

Keep Your Mobile Device & Its Accessories Away

From Small Children

These products are not toys and may be hazardous to small children. For example:

•

A choking hazard may exist for small, detachable parts.

•

Improper use could result in loud sounds, possibly causing hearing injury.

•

Improperly handled batteries could overheat and cause a burn.

Glass Parts

Some parts of your mobile device may be made of glass. This glass could break if

the product is dropped on a hard surface or receives a substantial impact. If glass

breaks, do not touch or attempt to remove. Stop using your mobile device until the

glass is replaced by a qualified service center.

Seizures/Blackouts

Some people may be susceptible to epileptic seizures or blackouts when exposed to

flashing lights, such as when playing video games. These may occur even if a person

has never had a previous seizure or blackout.

If you have experienced seizures or blackouts, or if you have a family history of such

occurrences, please consult with your physician before playing video games or

enabling a flashing-lights feature (if available) on your mobile device.

Do not let your battery, charger, or mobile device get wet.

Listening at full volume to music or voice through a headset may

damage your hearing.

Symbol Definition

59Troubleshooting

Discontinue use and consult a physician if any of the following symptoms occur:

convulsion, eye or muscle twitching, loss of awareness, involuntary movements, or

disorientation. It is always a good idea to hold the screen away from your eyes,

leave the lights on in the room, take a 15-minute break every hour, and stop use if

you are tired.

Caution About High Volume Usage

Warning:

Exposure to loud noise from any source for extended

periods of time may affect your hearing. The louder the volume sound

level, the less time is required before your hearing could be affected.

To protect your hearing:

•

Limit the amount of time you use headsets or headphones at high volume.

•

Avoid turning up the volume to block out noisy surroundings.

•

Turn the volume down if you can’t hear people speaking near you.

If you experience hearing discomfort, including the sensation of pressure or fullness

in your ears, ringing in your ears, or muffled speech, you should stop listening to the

device through your headset or headphones and have your hearing checked.

For more information about hearing, see our Web site at

direct.motorola.com/hellomoto/nss/AcousticSafety.asp (in English only).

Repetitive Motion

When you repetitively perform actions such as pressing keys or entering

finger-written characters, you may experience occasional discomfort in your hands,

arms, shoulders, neck, or other parts of your body. If you continue to have discomfort

during or after such use, stop use and see a physician.

[Apr0109]

Industry Canada Notice to Users

Industry Canada Notice

Operation is subject to the following two conditions: (1) This device may not cause

interference and (2) This device must accept any interference, including interference

that may cause undesired operation of the device. See RSS-GEN 7.1.5.

FCC Notice to Users

FCC Notice

The following statement applies to all products that have received FCC

approval. Applicable products bear the FCC logo, and/or an FCC ID in the

format FCC-ID:xxxxxx on the product label.

Motorola has not approved any changes or modifications to this device by the user.

Any changes or modifications could void the user’s authority to operate the

equipment. See 47 CFR Sec. 15.21.

This device complies with part 15 of the FCC Rules. Operation is subject to the

following two conditions: (1) This device may not cause harmful interference, and (2)

this device must accept any interference received, including interference that may

cause undesired operation. See 47 CFR Sec. 15.19(3).

This equipment has been tested and found to comply with the limits for a Class B

digital device, pursuant to part 15 of the FCC Rules. These limits are designed to

provide reasonable protection against harmful interference in a residential

installation. This equipment generates, uses and can radiate radio frequency energy

and, if not installed and used in accordance with the instructions, may cause

harmful interference to radio communications. However, there is no guarantee that

interference will not occur in a particular installation. If this equipment does cause

harmful interference to radio or television reception, which can be determined by

turning the equipment off and on, the user is encouraged to try to correct the

interference by one or more of the following measures:

•

Reorient or relocate the receiving antenna.

•

Increase the separation between the equipment and the receiver.

•

Connect the equipment to an outlet on a circuit different from that to which the

receiver is connected.

•

Consult the dealer or an experienced radio/TV technician for help.

Use & Care

To care for your Motorola phone, please keep it away from:

liquids of any kind

Don’t expose your phone to water, rain, extreme humidity, sweat, or

other moisture. If it does get wet, don’t try to accelerate drying with the

use of an oven or dryer, as this may damage the phone.

60 Troubleshooting

extreme heat or cold

Avoid temperatures below 0°C/32°F or above 45°C/113°F.

microwaves

Don’t try to dry your phone in a microwave oven.

dust and dirt

Don’t expose your phone to dust, dirt, sand, food, or other inappropriate

materials.

cleaning solutions

To clean your phone, use only a dry soft cloth. Don’t use alcohol or other

cleaning solutions.

the ground

Don’t drop your phone.

Motorola Limited Warranty for the

United States and Canada

Warranty

What Does this Warranty Cover?

Subject to the exclusions contained below, Motorola, Inc. warrants its mobile

telephones (“Products”), Motorola-branded or certified accessories sold for use with

these Products (“Accessories”), and Motorola software contained on CD-ROMs or

other tangible media and sold for use with these Products (“Software”) to be free

from defects in materials and workmanship under normal consumer usage for the

period(s) outlined below. This limited warranty is a consumer's exclusive remedy,

and applies as follows to new Motorola Products, Accessories, and Software

purchased by consumers in the United States or Canada, which are accompanied by

this written warranty:

Products and Accessories

Exclusions (Products and Accessories)

Normal Wear and Tear.

Periodic maintenance, repair and replacement of parts

due to normal wear and tear are excluded from coverage.

Batteries.

Only batteries whose fully charged capacity falls below 80% of their

rated capacity and batteries that leak are covered by this limited warranty.

Abuse & Misuse.

Defects or damage that result from: (a) improper operation,

storage, misuse or abuse, accident or neglect, such as physical damage (cracks,

scratches, etc.) to the surface of the product resulting from misuse; (b) contact with

liquid, water, rain, extreme humidity or heavy perspiration, sand, dirt or the like,

extreme heat, or food; (c) use of the Products or Accessories for commercial

purposes or subjecting the Product or Accessory to abnormal usage or conditions; or

(d) other acts which are not the fault of Motorola, are excluded from coverage.

Products Covered Length of Coverage

Products and Accessories

defined above, unless otherwise

provided for below.

One (1) year

from the date of purchase by

the first consumer purchaser of the product

unless otherwise provided for below.

Decorative Accessories and

Cases.

Decorative covers,

bezels, PhoneWrap™ covers and

cases.

Limited lifetime warranty

for the

lifetime of ownership by the first consumer

purchaser of the product.

Monaural Headsets.

Ear buds

and boom headsets that transmit

mono sound through a wired

connection.

Limited lifetime warranty

for the

lifetime of ownership by the first consumer

purchaser of the product.

Products and Accessories

that are Repaired or

Replaced.

The balance of the original warranty or

for ninety (90) days

from the date

returned to the consumer, whichever is

longer.

61Troubleshooting

Use of Non-Motorola Products and Accessories.

Defects or damage that result

from the use of non-Motorola branded or certified Products, Accessories, Software

or other peripheral equipment are excluded from coverage.

Unauthorized Service or Modification.

Defects or damages resulting from

service, testing, adjustment, installation, maintenance, alteration, or modification in

any way by someone other than Motorola, or its authorized service centers, are

excluded from coverage.

Altered Products.

Products or Accessories with (a) serial numbers or date tags

that have been removed, altered or obliterated; (b) broken seals or that show

evidence of tampering; (c) mismatched board serial numbers; or (d) nonconforming

or non-Motorola housings, or parts, are excluded from coverage.

Communication Services.

Defects, damages, or the failure of Products,

Accessories or Software due to any communication service or signal you may

subscribe to or use with the Products Accessories or Software is excluded from

coverage.

Software

Exclusions (Software)

Software Embodied in Physical Media.

No warranty is made that the software

will meet your requirements or will work in combination with any hardware or

software applications provided by third parties, that the operation of the software

products will be uninterrupted or error free, or that all defects in the software

products will be corrected.

Software NOT Embodied in Physical Media.

Software that is not embodied in

physical media (e.g. software that is downloaded from the Internet), is provided “as

is” and without warranty.

Products Covered Length of Coverage

Software.

Applies only to physical defects in the

media that embodies the copy of the software (e.g.

CD-ROM, or floppy disk).

Ninety (90) days

from

the date of purchase.

Who is Covered?

This warranty extends only to the first consumer purchaser, and is not transferable.

What Will Motorola Do?

Motorola, at its option, will at no charge repair, replace or refund the purchase price

of any Products, Accessories or Software that does not conform to this warranty. We

may use functionally equivalent reconditioned/refurbished/pre-owned or new

Products, Accessories or parts. No data, software or applications added to your

Product, Accessory or Software, including but not limited to personal contacts,

games and ringer tones, will be reinstalled. To avoid losing such data, software, and

applications, please create a back up prior to requesting service.

How to Obtain Warranty Service or Other

Information

You will receive instructions on how to ship the Products, Accessories or Software,

at your expense, to a Motorola Authorized Repair Center. To obtain service, you must

include: (a) a copy of your receipt, bill of sale or other comparable proof of purchase;

(b) a written description of the problem; (c) the name of your service provider, if

applicable; (d) the name and location of the installation facility (if applicable) and,

most importantly; (e) your address and telephone number.

What Other Limitations are There?

ANY IMPLIED WARRANTIES, INCLUDING WITHOUT LIMITATION THE IMPLIED

WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE,

SHALL BE LIMITED TO THE DURATION OF THIS LIMITED WARRANTY, OTHERWISE

THE REPAIR, REPLACEMENT, OR REFUND AS PROVIDED UNDER THIS EXPRESS

LIMITED WARRANTY IS THE EXCLUSIVE REMEDY OF THE CONSUMER, AND IS

PROVIDED IN LIEU OF ALL OTHER WARRANTIES, EXPRESS OR IMPLIED. IN NO

USA All Products, Accessories, and Software:

1-800-331-6456

Canada All Products:

1-800-461-4575

TTY

1-888-390-6456

62 Troubleshooting

EVENT SHALL MOTOROLA BE LIABLE, WHETHER IN CONTRACT OR TORT

(INCLUDING NEGLIGENCE) FOR DAMAGES IN EXCESS OF THE PURCHASE PRICE OF

THE PRODUCT, ACCESSORY OR SOFTWARE, OR FOR ANY INDIRECT, INCIDENTAL,

SPECIAL OR CONSEQUENTIAL DAMAGES OF ANY KIND, OR LOSS OF REVENUE OR

PROFITS, LOSS OF BUSINESS, LOSS OF INFORMATION OR DATA, SOFTWARE OR

APPLICATIONS OR OTHER FINANCIAL LOSS ARISING OUT OF OR IN CONNECTION

WITH THE ABILITY OR INABILITY TO USE THE PRODUCTS, ACCESSORIES OR

SOFTWARE TO THE FULL EXTENT THESE DAMAGES MAY BE DISCLAIMED BY LAW.

Some states and jurisdictions do not allow the limitation or exclusion of

incidental or consequential damages, or limitation on the length of an

implied warranty, so the above limitations or exclusions may not apply to

you. This warranty gives you specific legal rights, and you may also have

other rights that vary from state to state or from one jurisdiction to another.

Hearing Aid Compatibility with Mobile

Phones

Heari ng Aids

Some Motorola phones are measured for compatibility with hearing aids. If the box

for your particular model has “Rated for Hearing Aids” printed on it, the following

explanation applies.

When some mobile phones are used near some hearing devices (hearing aids and

cochlear implants), users may detect a buzzing, humming, or whining noise. Some

hearing devices are more immune than others to this interference noise, and phones

also vary in the amount of interference they generate.

The wireless telephone industry has developed ratings for some of their mobile

phones, to assist hearing device users in finding phones that may be compatible

with their hearing devices. Not all phones have been rated. Phones that are rated

have the rating on their box or a label on the box. To maintain the published Hearing

Aid Compatibility (HAC) rating for this mobile phone, use only the original equipment

battery model.

The ratings are not guarantees. Results will vary depending on the user’s hearing

device and hearing loss. If your hearing device happens to be vulnerable to

interference, you may not be able to use a rated phone successfully. Trying out the

phone with your hearing device is the best way to evaluate it for your personal

needs.

M-Ratings:

Phones rated M3 or M4 meet FCC requirements and are likely to

generate less interference to hearing devices than phones that are not labeled. M4

is the better/higher of the two ratings.

T-Ratings:

Phones rated T3 or T4 meet FCC requirements and are likely to be more

usable with a hearing device’s telecoil (“T Switch” or “Telephone Switch”) than

unrated phones. T4 is the better/higher of the two ratings. (Note that not all hearing

devices have telecoils in them.)

Hearing devices may also be measured for immunity to this type of interference.

Your hearing device manufacturer or hearing health professional may help you find

results for your hearing device. The more immune your hearing aid is, the less likely

you are to experience interference noise from mobile phones.

Information from the World Health

Organization

WHO Information

Present scientific information does not indicate the need for any special precautions

for the use of mobile phones. If you are concerned, you may want to limit your own

or your children’s RF exposure by limiting the length of calls or by using handsfree

devices to keep mobile phones away from your head and body.

Source: WHO Fact Sheet 193

Further information:

http://www.who.int/peh-emf

Product Registration

Registration

Online Product Registration:

www.motorola.com/us/productregistration

Product registration is an important step toward enjoying your new Motorola

product. Registering permits us to contact you for product or software updates and

allows you to subscribe to updates on new products or special promotions.

Registration is not required for warranty coverage.

Please retain your original dated sales receipt for your records. For warranty service

of your Motorola Personal Communications Product you will need to provide a copy

of your dated sales receipt to confirm warranty status.

Thank you for choosing a Motorola product.

Export Law Assurances

Export Law

This product is controlled under the export regulations of the United States of

America and Canada. The Governments of the United States of America and Canada

may restrict the exportation or re-exportation of this product to certain destinations.

For further information contact the U.S. Department of Commerce or the Canadian

Department of Foreign Affairs and International Trade.

Caring for the Environment by

Recycling

Recycli ng Inform ation

This symbol on a Motorola product means the product should not be

disposed of with household waste.

Disposal of your Mobile Device &

Accessories

Please do not dispose of mobile devices or electrical accessories (such

as chargers, headsets, or batteries) with your household waste. Do not

dispose of your battery or mobile device in a fire. These items should be

disposed of in accordance with the national collection and recycling

schemes operated by your local or regional authority. Alternatively, you may return

unwanted mobile devices and electrical accessories to any Motorola Approved

Service Center in your region. Details of Motorola approved national recycling

032376o

schemes, and further information on Motorola recycling activities can be found at:

www.motorola.com/recycling

Disposal of your Mobile Device Packaging &

Product Guide

Product packaging and product guides should only be disposed of in accordance with

national collection and recycling requirements. Please contact your regional

authorities for more details.

California Perchlorate Label

Perchlorat e Label

Some mobile phones use an internal, permanent backup battery on the printed

circuit board that may contain very small amounts of perchlorate. In such cases,

California law requires the following label:

Perchlorate Material – special handling may apply. See

www.dtsc.ca.gov/hazardouswaste/perchlorate

There is no special handling required by consumers.

Privacy & Data Security

Priva cy & Data Secur ity

Motorola understands that privacy and data security are important to everyone.

Because some features of your mobile device may affect your privacy or data

security, please follow these recommendations to enhance protection of your

information:

• Monitor access

—Keep your mobile device with you and do not leave it where

others may have unmonitored access. Lock your device’s keypad where this

feature is available.

• Keep software up to date

—If Motorola or a software/application vendor

releases a patch or software fix for your mobile device that updates the device’s

security, install it as soon as possible.

•Erase before recycling

—Delete personal information or data from your

mobile device prior to disposing of it or turning it in for recycling. For instructions

on how to delete all personal information from your device, see your product

guide.

Note:

For information on backing up your mobile device data before erasing it, go

www.motorola.com

and navigate to the “downloads” section of the

consumer Web page for “Motorola Backup” or “Motorola Phone Tools.”

• Location-based information

—Location-based information includes

information that can be used to determine the approximate location of a mobile

device. Mobile phones which are connected to a wireless network transmit

location-based information. Devices enabled with GPS or AGPS technology also

transmit location-based information. Additionally, if you use applications that

require location-based information (e.g. driving directions), such applications

transmit location-based information. This location-based information may be

shared with third parties, including your wireless service provider, applications

providers, Motorola, and other third parties providing services.

•Other information your device may transmit

—Your device may also transmit

testing and other diagnostic (including location-based) information, and other

non-personal information to Motorola or other third-party servers. This

information is used to help improve products and services offered by Motorola.

If you have further questions regarding how the use of your mobile device may

impact your privacy or data security, please contact Motorola at

privacy@motorola.com

, or contact your service provider.

Smart Practices While Driving

Drivi ng Safety

Drive Safe, Call Smart

Check the laws and regulations on the use of mobile devices and their

accessories in the areas where you drive. Always obey them. The use of

these devices may be prohibited or restricted in certain areas—for

example, handsfree use only. Go to

www.motorola.com/callsmart

(in English only) for more information.

Your mobile device lets you communicate by voice and data—almost anywhere,

anytime, wherever wireless service is available and safe conditions allow. When

driving a car, driving is your first responsibility. If you choose to use your mobile

device while driving, remember the following tips:

• Get to know your Motorola mobile device and its features such as speed

dial and redial.

If available, these features help you to place your call without

taking your attention off the road.

• When available, use a handsfree device.

If possible, add

an additional layer of convenience to your mobile device with

one of the many Motorola Original handsfree accessories

available today.

• Position your mobile device within easy reach.

Be able to

access your mobile device without removing your eyes from the road. If you

receive an incoming call at an inconvenient time, if possible, let your voicemail

answer it for you.

• Let the person you are speaking with know you are driving; if necessary,

suspend the call in heavy traffic or hazardous weather conditions.

Rain,

sleet, snow, ice, and even heavy traffic can be hazardous.

• Do not take notes or look up phone numbers while driving.

Jotting down a

“to do” list or going through your address book takes attention away from your

primary responsibility—driving safely.

• Dial sensibly and assess the traffic; if possible, place calls when your

car is not moving or before pulling into traffic.

If you must make a call while

moving, dial only a few numbers, check the road and your mirrors, then continue.

• Do not engage in stressful or emotional conversations that may be

distracting.

Make people you are talking with aware you are driving and

suspend conversations that can divert your attention away from the road.

•Use your mobile device to call for help.

Dial 911 or other local emergency

number in the case of fire, traffic accident, or medical emergencies (wherever

wireless phone service is available).

•Use your mobile device to help others in emergencies.

If you see an auto

accident, crime in progress, or other serious emergency where lives are in

danger, call 911 or other local emergency number (wherever wireless phone

service is available), as you would want others to do for you.

•Call roadside assistance or a special non-emergency wireless

assistance number when necessary.

If you see a broken-down vehicle

posing no serious hazard, a broken traffic signal, a minor traffic accident where

no one appears injured, or a vehicle you know to be stolen, call roadside

assistance or other special non-emergency wireless number (wherever wireless

phone service is available).

Motorola, Inc.

Consumer Advocacy Office

600 N US Hwy 45

Libertyville, IL 60048

http://www.hellomoto.com

Note:

Do not ship your phone to the above address. If you need to return your phone

for repairs, replacement, or warranty service, please contact the Motorola Customer

Support Center at:

1-800-331-6456 (United States)

1-888-390-6456 (TTY/TDD United States for hearing impaired)

1-800-461-4575 (Canada)

Certain mobile phone features are dependent on the capabilities and settings of

your service provider’s network. Additionally, certain features may not be activated

by your service provider, and/or the provider’s network settings may limit the

feature’s functionality. Always contact your service provider about feature

availability and functionality. All features, functionality, and other product

specifications, as well as the information contained in this guide, are based upon

the latest available information and believed to be accurate at the time of printing.

Motorola reserves the right to change or modify any information or specifications

without notice or obligation.

MOTOROLA and the Stylized M Logo are registered in the US Patent & Trademark

Office. The Bluetooth trademarks are owned by their proprietor and used by

Motorola, Inc. under license. Java and all other Java-based marks are trademarks or

registered trademarks of Sun Microsystems, Inc. in the U.S. and other countries.

Microsoft, Windows, Windows Me, and Windows Vista are registered trademarks

of Microsoft Corporation in the United States and other countries. Google, YouTube,

Picasa, Gmail, and the Google logo are trademarks of Google, Inc. is a

Certification Mark of the Wireless Fidelity Alliance, Inc. All other product or service

names are the property of their respective owners.

Caution:

Changes or modifications made in the radio phone, not expressly approved

by Motorola, will void the user’s authority to operate the equipment.

Bluetooth ID: ____

Manual Number: ___

U.S. patent Re. 34,976

Motorola Mobility P56KW1 Portable Cellular/ PCS CDMA Transceiver with WLAN and Bluetooth User Manual APPLICANT MOTOROLA INC

Motorola Mobility LLC Portable Cellular/ PCS CDMA Transceiver with WLAN and Bluetooth APPLICANT MOTOROLA INC

Exhibit 8 Users Manual

Navigation menu

Namespaces

Views

Navigation
