Motorola Mobility P56MJ2 CDMA/LTE TRANSCEIVER WITH BT & WLAN User Manual APPLICANT MOTOROLA INC
Motorola Mobility LLC CDMA/LTE TRANSCEIVER WITH BT & WLAN APPLICANT MOTOROLA INC
Contents
USERS MANUAL 3
APPLICANT: MOTOROLA MOBILITY, INC. FCC ID: IHDP56MJ2
INSTRUCTION MANUAL
A representative version of the user's manual follows:
Exhibit 8
LIFE. POWERED.
Back Next
More Support
+
MOTOROLA
Your tablet
Start
Want More?
Troubleshooting
Safety, Regulatory & Legal
Your tablet
Your tablet
MOTOROLA [Fleming] has the latest tablet innovations,
with access to Android Market™ to get even more.
At a glance—When you’re up and running, be sure to
explore what your tablet can do:
•Customize: “Personalize” your tablet, then “Surf” and
bookmark your favorite websites.
•Create: Check and send your “Email”, and even create
and edit documents and calendar events for “Work”.
•Enjoy: “Load up” your tablet’s apps and games, or “Play
& record” video, music, and more.
Tips & tricks
•Power/Sleep: To turn your tablet on or off, press and
hold Power/Sleep on the back. To make the screen
sleep or wake up, press but don’t hold.
Note: Certain apps and features may not be available in all
countries.
This product meets the applicable limit for
exposure to radio waves (known as SAR) of
1.6 W/kg (FCC). The limits and guidelines include a
substantial safety margin designed to assure the safety of
all persons, regardless of age and health. The highest SAR
values measured for this device are listed in the regulatory
information packaged with your product.
LIFE. POWERED.
Back Next
More Support
+
MOTOROLA
Your tablet
Start
Want More?
Troubleshooting
Safety, Regulatory & Legal
Start
Start
Set up
Let’s get you up and running.
Note: This product uses a non-removable battery. The
battery should only be replaced by a Motorola-approved
service facility. Any attempt to remove or replace your
battery may damage the product.
Note: This device supports apps and services that use a lot
of data, so make sure your data plan meets your needs.
Contact your service provider for details.
1Insert the charger into the MicroUSB port on the bottom
of your tablet, then wait for the battery charging
indicator to show a steady white light (fully charged).
2Press and hold Power/Sleep on the back of your
tablet to turn it on.
3Choose a language and touch Start.
In the WiFi setup screen, touch the network you want to
connect, then enter a password if you need to.
Choose location settings and touch Next (for the most
accurate location features, check both services).
Follow the setup wizard to set your time zone, and
confirm the time and date.
Note: To change your Wi-Fi settings or time zone later,
touch Apps > Settings > Wireless & networks, or
Date & Time.
4Follow the setup wizard to create or log into your Google
Account and go to the home screen. Record your
Google Account information for future reference.
Check the Motorola Mobile Services approval and touch
Next.
Note: You can use your Google account to back up your
contacts, bookmarks, user dictionary, Wi-Fi passwords,
some app information, and other settings, in case you
lose your tablet or reinstall an app. To set up sync later,
touch Apps > Settings > Accounts & sync.
Tip: In the unlikely event that your tablet becomes
unresponsive, try a forced reboot—press and hold both
Power/Sleep and the up volume key for three seconds.
LIFE. POWERED.
Back Next
More Support
+
MOTOROLA
Your tablet
Start
Want More?
Troubleshooting
Safety, Regulatory & Legal
Want More?
Want More?
More information
You can get more information, more help, more free stuff.
We’re here to help.
•Answers: Check out the help center on your
tablet—touch Apps > Help Center. If your device
does not have Help Center, you can download it from
www.motorola.com/[Fleming]help.
•Support: Tablet software updates, PC software, user
guides, online help, and more at
www.motorola.com/my[Fleming] or
www.motorola.com/my[Fleming]wifi. You can call us
with warranty and support questions at 1-800-734-5870
(United States), 1-888-390-6456 (TTY/TDD United States
for hearing impaired), or 1-800-461-4575 (Canada).
•Updates: To keep your tablet current, software updates
may be available. Touch Apps > Settings > About
tablet > System updates to see if your tablet is up to
date. If it isn’t, touch Update.
•Join us: Get the latest news, apps, tips & tricks, videos
and so much more—join us on:
YouTube™ www.youtube.com/motorola
Facebook™ www.facebook.com/motorola
Twitter www.twitter.com/motomobile
Accessories
You can find accessories for your phone at
www.motorola.com/products.
LIFE. POWERED.
Back Next
More Support
+
MOTOROLA
Your tablet
Start
Want More?
Troubleshooting
Safety, Regulatory & Legal
Troubleshooting
Troubleshooting
Force a reboot
In the unlikely event that your tablet becomes
unresponsive, try a forced reboot: Press and hold both
Power/Sleep and the volume up key for three seconds.
Reset your tablet
If you forget your unlock pattern or password, your tablet
should prompt you to reset it after five tries. If it doesn't,
you can do a factory data reset to restore your tablet to its
factory settings:
Warning: This deletes all of your data on the tablet. This
includes pictures, videos, documents, and other files that
you have not backed up online or on a PC.
1Turn on your tablet and, when the Motorola logo
appears, press and hold the volume down key. Keep
holding the volume down key until Android recovery text
appears in top left corner.
2Press the volume up key to put device in Android
recovery mode.
3When the Android recovery screen appears, press and
hold Power/Sleep . While holding Power/Sleep ,
press and release the volume up key.
4Your tablet should show a wipe data/factory reset
option. Press Power/Sleep to select the reset option.
5Use the volume keys to select Yes, then press
Power/Sleep to confirm the reset.
6After your tablet resets, press Power/Sleep to select
reboot system now.
Service & repairs
If you have questions or need assistance, go to
http://www.motorola.com/support, where you can select
from a number of customer care options. You can also
contact the Motorola Customer Support Center at
1-800-734-5870 (United States), 1-888-390-6456 (TTY/TDD
United States for hearing impaired), or 1-800-461-4575
(Canada).
LIFE. POWERED.
Back Next
More Support
+
MOTOROLA
Your tablet
Start
Want More?
Troubleshooting
Safety, Regulatory & Legal
Safety, Regulatory & Legal
Safety, Regulatory & Legal
Battery Use & Safety
Battery Use & Safety
The following battery use and safety information applies to all Motorola mobile devices. If
your mobile device uses a non-removable main battery (as stated in your product
information), details related to handling and replacing your battery should be
disregarded—the battery should only be replaced by a Motorola-approved service facility,
and any attempt to remove or replace your battery may damage the product.
Important: Handle and store batteries properly to avoid injury or damage.
Most
battery issues arise from improper handling of batteries, and particularly from the
continued use of damaged batteries.
DON’Ts
• Don’t disassemble, crush, puncture, shred, or otherwise attempt to change the
form of your battery.
• Don’t let the mobile device or battery come in contact with liquids.*
Liquids can
get into the mobile device’s circuits, leading to corrosion.
• Don’t allow the battery to touch metal objects.
If metal objects, such as jewelry,
stay in prolonged contact with the battery contact points, the battery could become very
hot.
• Don’t place your mobile device or battery near a heat source.*
High
temperatures can cause the battery to swell, leak, or malfunction.
• Don’t dry a wet or damp battery with an appliance or heat source
, such as a hair
dryer or microwave oven.
DOs
• Do avoid leaving your mobile device in your car in high temperatures.*
• Do avoid dropping the mobile device or battery.*
Dropping these items, especially
on a hard surface, can potentially cause damage.*
• Do contact your service provider or Motorola if your mobile device or battery
has been damaged by dropping, liquids or high temperatures.
*Note:
Always make sure that the battery compartment and any connector covers are
closed and secure to avoid direct exposure of the battery to any of these conditions, even if
your product information states that your
mobile device
can resist damage from these
conditions.
Important: Motorola recommends you always use Motorola-branded batteries
and chargers for quality assurance and safeguards.
Motorola’s warranty does not
cover damage to the mobile device caused by non-Motorola batteries and/or chargers. To
help you identify authentic Motorola batteries from non-original or counterfeit batteries
(that may not have adequate safety protection), Motorola provides holograms on its
batteries. You should confirm that any battery you purchase has a “Motorola Original”
hologram.
If you see a message on your display such as
Invalid Battery
or
Unable to Charge
, take the following steps:
•
Remove the battery and inspect it to confirm that it has a “Motorola Original”
hologram;
•
If there is no hologram, the battery is not a Motorola battery;
•
If there is a hologram, replace the battery and try charging it again;
•
If the message remains, contact a Motorola authorized service center.
Warning:
Use of a non-Motorola battery or charger may present a risk of fire, explosion,
leakage, or other hazard.
Proper and safe battery disposal and recycling:
Proper battery disposal is not only
important for safety, it benefits the environment. You can recycle your used batteries in
many retail or service provider locations. Additional information on proper disposal and
recycling can be found at
www.motorola.com/recycling
Disposal:
Promptly dispose of used batteries in accordance with local
regulations. Contact your local recycling center or national recycling
organizations for more information on how to dispose of batteries.
Warning:
Never dispose of batteries in a fire because they may explode.
Battery Charging
Battery Charging
Notes for charging your product’s battery:
•
During charging, keep your battery and charger near room temperature for efficient
battery charging.
•
New batteries are not fully charged.
•
New batteries or batteries stored for a long time may take more time to charge.
•
Motorola batteries and charging systems have circuitry that protects the battery from
damage from overcharging.
Third Party Accessories
Use of third party accessories, including but not limited to batteries, chargers, headsets,
covers, cases, screen protectors and memory cards, may impact your mobile device’s
performance. In some circumstances, third party accessories can be dangerous and may
void your mobile device’s warranty. For a list of Motorola accessories, visit
www.motorola.com/products
Driving Precautions
Responsible and safe driving is your primary responsibility when behind the wheel of a
vehicle. Using a mobile device or accessory while driving may cause distraction and may
be prohibited or restricted in certain areas. Always obey the laws and regulations on the
use of these products.
While driving, NEVER:
•
Type or read messages.
•
Enter or review written data.
•
Surf the web.
032375o
LIFE. POWERED.
Back Next
More Support
+
MOTOROLA
Your tablet
Start
Want More?
Troubleshooting
Safety, Regulatory & Legal
Safety, Regulatory & Legal
•
Input navigation information.
•
Perform any other functions that divert your attention from driving.
While driving, ALWAYS:
•
Keep your eyes on the road.
•
Enter destination information into a navigation device
before
driving.
•
Use voice activated features (such as voice commands) and speaking features (such as
audible directions), if available.
•
Obey all local laws and regulations for the use of mobile devices and accessories in the
vehicle.
•
End any task if you cannot concentrate on driving.
Remember to follow the “Smart Practices While Driving” in this guide.
Seizures/Blackouts
Some people may be susceptible to epileptic seizures or blackouts when exposed to
flashing lights, such as when playing videos or games. These may occur even if a person
has never had a previous seizure or blackout.
If you have experienced seizures or blackouts, or if you have a family history of such
occurrences, please consult with your physician before playing videos or games or
enabling a flashing-lights feature (if available) on your mobile device.
Discontinue use and consult a physician if any of the following symptoms occur:
convulsion, eye or muscle twitching, loss of awareness, involuntary movements, or
disorientation. It is always a good idea to hold the screen away from your eyes, leave the
lights on in the room, take a 15-minute break every hour, and stop use if you are tired.
Caution About High Volume Usage
Warning:
Exposure to loud noise from any source for extended periods of time may affect
your hearing. The louder the volume sound level, the less time is required before your
hearing could be affected. To protect your hearing:
•
Limit the amount of time you use headsets or headphones at high volume.
•
Avoid turning up the volume to block out noisy surroundings.
•
Turn the volume down if you can’t hear people speaking near you.
If you experience hearing discomfort, including the sensation of pressure or fullness in your
ears, ringing in your ears, or muffled speech, you should stop listening to the device
through your headset or headphones and have your hearing checked.
For more information about hearing, see our website at
direct.motorola.com/hellomoto/nss/AcousticSafety.asp
(in English only).
Repetitive Motion
When you repetitively perform actions such as pressing keys or entering finger-written
characters, you may experience occasional discomfort in your hands, arms, shoulders,
neck, or other parts of your body. If you continue to have discomfort during or after such
use, stop use and see a physician.
Children
Keep your mobile device and its accessories away from small children.
These
products are not toys and may be hazardous to small children. For example:
•
A choking hazard may exist for small, detachable parts.
•
Improper use could result in loud sounds, possibly causing hearing injury.
•
Improperly handled batteries could overheat and cause a burn.
Similar to a computer, if a child does use your mobile device, you may want to monitor their
access to help prevent exposure to inappropriate apps or content.
Glass Parts
Some parts of your mobile device may be made of glass. This glass could break if the
product receives a substantial impact. If glass breaks, do not touch or attempt to remove.
Stop using your mobile device until the glass is replaced by a qualified service center.
Operational Warnings
Obey all posted signs when using mobile devices in public areas.
Potentially Explosive Atmospheres
Areas with potentially explosive atmospheres are often, but not always, posted and can
include fueling areas, such as below decks on boats, fuel or chemical transfer or storage
facilities, or areas where the air contains chemicals or particles, such as grain dust, or
metal powders.
When you are in such an area, turn off your mobile device, and do not remove, install, or
charge batteries unless it is a radio product type especially qualified for use in such areas
as “Intrinsically Safe” (for example, Factory Mutual, CSA, or UL approved). In such areas,
sparks can occur and cause an explosion or fire.
Symbol Key
Your battery, charger, or mobile device may contain symbols, defined as follows:
Symbol Definition
Important safety information follows.
Do not dispose of your battery or mobile device in a fire.
Your battery or mobile device may require recycling in
accordance with local laws. Contact your local regulatory
authorities for more information.
032374o
032376o
032375o
LIFE. POWERED.
Back Next
More Support
+
MOTOROLA
Your tablet
Start
Want More?
Troubleshooting
Safety, Regulatory & Legal
Safety, Regulatory & Legal
Radio Frequency (RF) Energy
Exposure to RF Energy
Your mobile device contains a transmitter and receiver. When it is ON, it receives and
transmits RF energy. When you communicate with your mobile device, the system handling
your network access controls the power level at which your mobile device transmits.
Your mobile device is designed to comply with local regulatory requirements in your
country concerning exposure of human beings to RF energy.
RF Energy Interference/Compatibility
Nearly every electronic device is subject to RF energy interference from external sources if
inadequately shielded, designed, or otherwise configured for RF energy compatibility. In
some circumstances, your mobile device may cause interference with other devices.
Follow Instructions to Avoid Interference Problems
Turn off your mobile device in any location where posted notices instruct you to do so.
In an aircraft, turn off your mobile device whenever instructed to do so by airline staff. If
your mobile device offers an airplane mode or similar feature, consult airline staff about
using it in flight.
Implantable Medical Devices
If you have an implantable medical device, such as a pacemaker or defibrillator, consult
your physician before using this mobile device.
Persons with implantable medical devices should observe the following precautions:
•
ALWAYS keep the mobile device more than 20 centimeters (8 inches) from the
implantable medical device when the mobile device is turned ON.
•
Turn OFF the mobile device immediately if you have any reason to suspect that
interference is taking place.
Read and follow the directions from the manufacturer of your implantable medical device.
If you have any questions about using your mobile device with your implantable medical
device, consult your healthcare provider.
Do not dispose of your battery or mobile device with your
household waste. See “Recycling” for more information.
Do not use tools.
For indoor use only.
Symbol Definition
Specific Absorption Rate (FCC)
SAR (IEEE)
YOUR MOBILE DEVICE MEETS FCC LIMITS FOR EXPOSURE
TO RADIO WAVES.
Your mobile device is a radio transmitter and receiver. It is designed not to exceed the
limits for exposure to radio waves (radio frequency electromagnetic fields) adopted by the
Federal Communications Commission (FCC). These limits include a substantial safety
margin designed to assure the safety of all persons, regardless of age and health.
The radio wave exposure guidelines use a unit of measurement known as the Specific
Absorption Rate, or SAR. The SAR limit for mobile devices is 1.6 W/kg.
Tests for SAR are conducted using standard operating positions with the device
transmitting at its highest certified power level in all tested frequency bands. The highest
SAR value under the FCC guidelines for your device model is listed below:
During use, the actual SAR values for your device are usually well below the values stated.
This is because, for purposes of system efficiency and to minimize interference on the
network, the operating power of your mobile device is automatically decreased when full
power is not needed for the wireless connection. The lower the power output of the
device, the lower its SAR value.
If you are interested in further reducing your RF exposure then you can easily do so by
limiting your usage or simply using a hands-free kit to keep the device away from the head
and body.
Additional information can be found at
www.motorola.com/rfhealth
.
European Union Directives Conformance
Statement
EU Conformance
The following CE compliance information is applicable to Motorola mobile devices that
carry one of the following CE marks:
Hereby, Motorola declares that this product is in compliance with:
•
The essential requirements and other relevant provisions of Directive 1999/5/EC
•
All other relevant EU Directives
Body SAR CDMA 800/1900, Wi-Fi, Bluetooth
Wi-Fi, Bluetooth
1.46 W/kg
0168
[Only Indoor Use Allowed In France
for Bluetooth and/or Wi-Fi]
0168
LIFE. POWERED.
Back Next
More Support
+
MOTOROLA
Your tablet
Start
Want More?
Troubleshooting
Safety, Regulatory & Legal
Safety, Regulatory & Legal
The above gives an example of a typical Product Approval Number.
You can view your product’s Declaration of Conformity (DoC) to Directive 1999/5/EC (to
R&TTE Directive) at
www.motorola.com/rtte
(in English only). To find your DoC, enter
the Product Approval Number from your product’s label in the “Search” bar on the website.
FCC Notice to Users
FCC Notice
The following statement applies to all products that bear the FCC logo on the
product label.
This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to part 15 of the FCC Rules. See 47 CFR Sec. 15.105(b). These limits are
designed to provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses and can radiate radio frequency energy and, if
not installed and used in accordance with the instructions, may cause harmful interference
to radio communications. However, there is no guarantee that interference will not occur in
a particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on, the
user is encouraged to try to correct the interference by one or more of the following
measures:
•
Reorient or relocate the receiving antenna.
•
Increase the separation between the equipment and the receiver.
•
Connect the equipment to an outlet on a circuit different from that to which the receiver
is connected.
•
Consult the dealer or an experienced radio/TV technician for help.
This device complies with part 15 of the FCC Rules. Operation is subject to the following
two conditions: (1) This device may not cause harmful interference, and (2) this device must
accept any interference received, including interference that may cause undesired
operation. See 47 CFR Sec. 15.19(a)(3).
Motorola has not approved any changes or modifications to this device by the user. Any
changes or modifications could void the user’s authority to operate the equipment. See 47
CFR Sec. 15.21.
For products that support Wi-Fi 802.11a (as defined in the product specifications available
at
www.motorola.com
), the following information applies. This equipment has the
capability to operate Wi-Fi in the 5 GHz Unlicensed National Information Infrastructure
(U-NII) band. Because this band is shared with MSS (Mobile Satellite Service), the FCC has
restricted such devices to indoor use only (see 47 CFR 15.407(e)). Since wireless hot spots
0168
Product
Approval
Number
operating in this band have the same restriction, outdoor services are not offered.
Nevertheless, please do not operate this device in Wi-Fi mode when outdoors.
Industry Canada Notice to Users
Industry Canada Notice
Operation is subject to the following two conditions: (1) This device may not cause
interference and (2) This device must accept any interference, including interference that
may cause undesired operation of the device. See RSS-GEN 7.1.5. This Class B digital
apparatus complies with Canadian ICES-003.
Location Services (GPS & AGPS)
GPS & AGPS
The following information is applicable to Motorola mobile devices that provide location
based (GPS and/or AGPS) functionality.
Your mobile device may use Global Positioning System (GPS) signals for location-based
applications. GPS uses satellites controlled by the U.S. government that are subject to
changes implemented in accordance with the Department of Defense policy and the
Federal Radio Navigation Plan. These changes may affect the performance of location
technology on your mobile device.
Your mobile device may also use Assisted Global Positioning System (AGPS), which
obtains information from the cellular network to improve GPS performance. AGPS uses
your wireless service provider's network and therefore airtime, data charges, and/or
additional charges may apply in accordance with your service plan. Contact your wireless
service provider for details.
Your Location
Location-based information includes information that can be used to determine the
approximate location of a mobile device. Mobile devices which are connected to a wireless
network transmit location-based information. Devices enabled with GPS or AGPS
technology also transmit location-based information. Additionally, if you use applications
that require location-based information (e.g. driving directions), such applications transmit
location-based information. This location-based information may be shared with third
parties, including your wireless service provider, applications providers, Motorola, and
other third parties providing services.
Navigation
Navigation
The following information is applicable to Motorola mobile devices that provide navigation
features.
When using navigation features, note that mapping information, directions and other
navigational data may contain inaccurate or incomplete data. In some countries, complete
information may not be available. Therefore, you should visually confirm that the
navigational instructions are consistent with what you see. All drivers should pay attention
to road conditions, closures, traffic, and all other factors that may impact driving. Always
obey posted road signs.
LIFE. POWERED.
Back Next
More Support
+
MOTOROLA
Your tablet
Start
Want More?
Troubleshooting
Safety, Regulatory & Legal
Safety, Regulatory & Legal
Smart Practices While Driving
Driving Safety
Check the laws and regulations on the use of mobile devices and their
accessories in the areas where you drive. Always obey them. The use of these
devices may be prohibited or restricted in certain areas—for example, handsfree
use only may be required. Go to
www.motorola.com/callsmart
(in English only) for more information.
Note:
Voice call features may not be available on all products.
Your mobile device lets you communicate by voice and data—almost anywhere, anytime,
wherever wireless connection is available and safe conditions allow. When driving a car,
driving is your first responsibility. If you choose to use your mobile device while driving,
remember the following tips:
• Get to know your Motorola mobile device and its features such as voice
commands and “read out loud” features.
If available, these features help you to
use your device without taking your attention off the road.
• When available, use a handsfree device.
If possible, add an additional layer of
convenience to your mobile device with one of the many Motorola Original handsfree
accessories available today.
• Position your mobile device within easy reach.
Be able to access your mobile
device without removing your eyes from the road. If you receive a call at an
inconvenient time, if possible, let your voicemail answer it for you.
• Let the person you are speaking with know you are driving; if necessary,
suspend the call in heavy traffic or hazardous weather conditions.
Rain, sleet,
snow, ice, and even heavy traffic can be hazardous.
• Do not take notes or look up information while driving.
Jotting down a “to do”
list or going through your address book takes attention away from your primary
responsibility—driving safely.
• Assess the traffic; if possible, place calls when your car is not moving or
before pulling into traffic.
If you must make a call while moving, use features such as
voice commands, check the road and your mirrors, then continue.
• Do not engage in stressful or emotional conversations that may be distracting.
Make people you are talking with aware you are driving and suspend conversations
that can divert your attention away from the road.
Privacy & Data Security
Privacy & Data Security
Motorola understands that privacy and data security are important to everyone. Because
some features of your mobile device may affect your privacy or data security, please follow
these recommendations to enhance protection of your information:
• Monitor access
—Keep your mobile device with you and do not leave it where others
may have unmonitored access. Use your device’s security and lock features, where
available.
• Keep software up to date
—If Motorola or a software/application vendor releases a
patch or software fix for your mobile device that updates the device’s security, install it
as soon as possible.
• Secure Personal Information
—Your mobile device can store personal information in
various locations including your SIM card, memory card, and internal memory. Be sure
to remove or clear all personal information before you recycle, return, or give away your
device. You can also backup your personal data to transfer to a new device.
Note:
For information on how to backup or wipe data from your mobile device, go to
www.motorola.com/support
• Online accounts
—Some mobile devices provide a Motorola online account (such as
MOTOBLUR). Go to your account for information on how to manage the account, and
how to use security features such as remote wipe and device location (where
available).
• Applications and updates
—Choose your apps and updates carefully, and install
from trusted sources only. Some apps can impact your product’s performance and/or
have access to private information including account details, useage data, location
details and network resources.
• Wireless
—For mobile devices with Wi-Fi features, only connect to trusted Wi-Fi
networks. Also, when using your device as a hotspot (where available) use network
security. These precautions will help prevent unauthorized access to your device.
• Location-based information
—Location-based information includes information that
can be used to determine the approximate location of a mobile device. Products which
are connected to a wireless network transmit location-based information. Devices
enabled with GPS or AGPS technology also transmit location-based information.
Additionally, if you use applications that require location-based information (e.g. driving
directions), such applications transmit location-based information. This location-based
information may be shared with third parties, including your wireless service provider,
applications providers, Motorola, and other third parties providing services.
• Other information your device may transmit
—Your device may also transmit
testing and other diagnostic (including location-based) information, and other
non-personal information to Motorola or other third-party servers. This information is
used to help improve products and services offered by Motorola.
If you have further questions regarding how the use of your mobile device may impact your
privacy or data security, please contact Motorola at
privacy@motorola.com
, or
contact your service provider.
Use & Care
Use & Care
To care for your Motorola mobile device, please observe the following:
liquids
Don’t expose your mobile device to water, rain, extreme humidity, sweat, or
other liquids. If it does get wet, don’t try to accelerate drying with the use of
an oven or dryer, as this may damage the mobile device.
LIFE. POWERED.
Back Next
More Support
+
MOTOROLA
Your tablet
Start
Want More?
Troubleshooting
Safety, Regulatory & Legal
Safety, Regulatory & Legal
extreme heat or cold
Don’t use, recharge or store your mobile device in temperatures below 0°C
(32°F) or above 35°C (95°F).
microwaves
Don’t try to dry your mobile device in a microwave oven.
dust and dirt
Don’t expose your mobile device to dust, dirt, sand, food, or other
inappropriate materials.
cleaning solutions
To clean your mobile device, use only a dry soft cloth. Don’t use alcohol or
other cleaning solutions.
shock and vibration
Don’t drop your mobile device.
protection
To help protect your mobile device, always make sure that any battery,
connector and compartment covers are closed and secure.
Recycling
Recycling
Mobile Devices & Accessories
Please do not dispose of mobile devices or electrical accessories (such as
chargers, headsets, or batteries) with your household waste, or in a fire. These
items should be disposed of in accordance with the national collection and
recycling schemes operated by your local or regional authority. Alternatively,
you may return unwanted mobile devices and electrical accessories to any Motorola
Approved Service Center in your region. Details of Motorola approved national recycling
schemes, and further information on Motorola recycling activities can be found at:
www.motorola.com/recycling
Packaging & Product Guides
Product packaging and product guides should only be disposed of in accordance with
national collection and recycling requirements. Please contact your regional authorities for
more details.
California Perchlorate Label
Perchlorat e Label
Some mobile devices use an internal, permanent backup battery on the printed circuit
board that may contain very small amounts of perchlorate. In such cases, California law
requires the following label:
Perchlorate Material – special handling may apply when the battery is recycled or disposed
of. See
www.dtsc.ca.gov/hazardouswaste/perchlorate
(in English only).
There is no special handling required by consumers.
Hearing Aid Compatibility with Mobile
Devices
Hearing Aid Compatibility
Some Motorola products are measured for compatibility with hearing aids. If the box for
your particular model has “Rated for Hearing Aids” printed on it, the following explanation
applies.
When some mobile devices are used near some hearing devices (hearing aids and cochlear
implants), users may detect a buzzing, humming, or whining noise. Some hearing devices
are more immune than others to this interference noise, and mobile devices also vary in
the amount of interference they generate.
The mobile devices industry has developed ratings for some of their products, to assist
hearing device users in finding products that may be compatible with their hearing devices.
Not all mobile devices have been rated. Products that are rated have the rating on their box
or a label on the box. To maintain the published Hearing Aid Compatibility (HAC) rating for
this mobile device, use only the original equipment battery model.
This mobile device has been tested and rated for use with hearing aids for some of the
wireless technologies that it uses. However, there may be some newer wireless
technologies used in this device that have not been tested yet for use with hearing aids. It
is important to try the different features of this product thoroughly and in different
locations, using your hearing aid or cochlear implant, to determine if you hear any
interfering noise. Contact your service provider or Motorola for information on hearing aid
compatibility. If you have questions about return or exchange policies, contact your service
provider or retailer.
The ratings are not guarantees. Results will vary depending on the user’s hearing device
and hearing loss. If your hearing device happens to be vulnerable to interference, you may
not be able to use a rated mobile device successfully. Trying out the product with your
hearing device is the best way to evaluate it for your personal needs.
M-Ratings:
Products rated M3 or M4 meet FCC requirements and are likely to generate
less interference to hearing devices than products that are not labeled. M4 is the
better/higher of the two ratings.
T-Ratings:
Products rated T3 or T4 meet FCC requirements and are likely to be more
usable with a hearing device’s telecoil (“T Switch” or “Telephone Switch”) than unrated
products. T4 is the better/higher of the two ratings. (Note that not all hearing devices have
telecoils in them.)
LIFE. POWERED.
Back Next
More Support
+
MOTOROLA
Your tablet
Start
Want More?
Troubleshooting
Safety, Regulatory & Legal
Safety, Regulatory & Legal
Hearing devices may also be measured for immunity to this type of interference. Your
hearing device manufacturer or hearing health professional may help you find results for
your hearing device. The more immune your hearing aid is, the less likely you are to
experience interference noise from mobile devices.
Software Copyright Notice
Software Copyright Notice
Motorola products may include copyrighted Motorola and third-party software stored in
semiconductor memories or other media. Laws in the United States and other countries
preserve for Motorola and third-party software providers certain exclusive rights for
copyrighted software, such as the exclusive rights to distribute or reproduce the
copyrighted software. Accordingly, any copyrighted software contained in Motorola
products may not be modified, reverse-engineered, distributed, or reproduced in any
manner to the extent allowed by law. Furthermore, the purchase of Motorola products shall
not be deemed to grant either directly or by implication, estoppel, or otherwise, any license
under the copyrights, patents, or patent applications of Motorola or any third-party
software provider, except for the normal, non-exclusive, royalty-free license to use that
arises by operation of law in the sale of a product.
Content Copyright
Content Copyright
The unauthorized copying of copyrighted materials is contrary to the provisions of the
Copyright Laws of the United States and other countries. This device is intended solely for
copying non-copyrighted materials, materials in which you own the copyright, or materials
which you are authorized or legally permitted to copy. If you are uncertain about your right
to copy any material, please contact your legal advisor.
Open Source Software Information
OSS Info rmation
For instructions on how to obtain a copy of any source code being made publicly available
by Motorola related to software used in this Motorola mobile device, you may send your
request in writing to the address below. Please make sure that the request includes the
model number and the software version number.
MOTOROLA MOBILITY, INC.
OSS Management
600 North US Hwy 45
Libertyville, IL 60048
USA
The Motorola website
opensource.motorola.com
(in English only) also contains
information regarding Motorola's use of open source.
Motorola has created the
opensource.motorola.com
website to serve as a portal for
interaction with the software community-at-large.
To view additional information regarding licenses, acknowledgments and required
copyright notices for open source packages used in this Motorola mobile device, please
touch
Apps
>
Settings
>
About tablet
>
Legal information
>
Open source licenses
. In addition, this Motorola device may include
self-contained applications that present supplemental notices for open source packages
used in those applications.
Export Law Assurances
Export Law
This product is controlled under the export regulations of the United States of America and
Canada. The Governments of the United States of America and Canada may restrict the
exportation or re-exportation of this product to certain destinations. For further information
contact the U.S. Department of Commerce or the Canadian Department of Foreign Affairs
and International Trade.
Product Registration
Registration
Online Product Registration:
www.motorola.com/us/productregistration
(in English only)
Product registration is an important step toward enjoying your new Motorola product.
Registering permits us to contact you for product or software updates and allows you to
subscribe to updates on new products or special promotions. Registration is not required
for warranty coverage.
Please retain your original dated sales receipt for your records. For warranty service of your
Motorola Personal Communications Product you will need to provide a copy of your dated
sales receipt to confirm warranty status.
Thank you for choosing a Motorola product.
Service & Repairs
If you have questions or need assistance, we’re here to help.
Go to
www.motorola.com/repair
(United States) or
www.motorola.com/support
(Canada), where you can select from a number of
customer care options. You can also contact the Motorola Customer Support Center at:
1-800-734-5870 (United States), 1-888-390-6456 (TTY/TDD United States for hearing
impaired), or 1-800-461-4575 (Canada).
How to Obtain Service or Other Information
1. Please access and review the online Customer Support section of Motorola's consumer
website prior to requesting warranty service.
2. If the Product is still not functioning properly after making use of this resource, please
contact the Warrantor listed at the Motorola website or the contact information for the
corresponding location.
3. A representative of Motorola, or of a Motorola Authorized Repair Center, will help de-
termine whether your Product requires service. You may be required to download, or oth-
erwise obtain and accept software updates from Motorola or a Motorola Authorized
Repair Center. You are responsible for any applicable carrier service fees incurred while
obtaining the required downloads. Complying with the warranty process, repair instruc-
tions and accepting such software updates is required in order to receive additional war-
ranty support.
4. If the software update does not fix the problem, you will receive instructions on how to
LIFE. POWERED.
Back Next
More Support
+
MOTOROLA
Your tablet
Start
Want More?
Troubleshooting
Safety, Regulatory & Legal
Safety, Regulatory & Legal
ship the Product to a Motorola Authorized Repair Center or other entity.
5. To obtain warranty service, as permitted by applicable law, you are required to include:
(a) a copy of your receipt, bill of sale or other comparable proof of purchase; (b) a written
description of the problem; (c) the name of your service provider, if applicable; (d) your
address and telephone number. In the event the Product is not covered by the Motorola
Limited Warranty, Motorola will inform the consumer of the availability, price and other
conditions applicable to the repair of the Product.
ALL INFORMATION, DATA, SOFTWARE OR OTHER APPLICATIONS, INCLUDING
BUT NOT LIMITED TO PERSONAL CONTACTS, ADDRESS BOOKS, PICTURES,
MUSIC AND GAMES WILL BE ERASED DURING THE REPAIR PROCESS, AND CAN
NOT BE REINSTALLED BY MOTOROLA.
To avoid losing such information, data,
software or other applications please create a back up before you deliver your Product for
warranty service, and disable any security passwords. You will be responsible for
reinstalling all such information, data, software, other applications and passwords. Your
Product or a replacement Product will be returned to you as your Product was configured
when originally purchased, subject to applicable software updates. Motorola may install
operating system software updates as part of warranty service that may prevent the
Product from reverting to an earlier version of the operating system software. Third party
applications installed on the Product may not be compatible or work with the Product as a
result of the operating system software update. Motorola and its Authorized Service
Centers are not responsible for the loss of, or inability to use, such information, data,
software or other applications.
To obtain service or other information, please access and review the online
Customer Support section of Motorola's consumer website at
www.motorola.com
.
Limited Global Warranty Motorola Tablet
Computer
Warr ant y
Note: This Limited Warranty is not applicable in Quebec, Canada.
FOR CONSUMERS WHO ARE COVERED BY CONSUMER PROTECTION LAWS OR
REGULATIONS IN THEIR COUNTRY OF PURCHASE OR, IF DIFFERENT, THEIR
COUNTRY OF RESIDENCE, THE BENEFITS CONFERRED BY THIS LIMITED
WARRANTY ARE IN ADDITION TO ALL RIGHTS AND REMEDIES CONVEYED BY
SUCH CONSUMER PROTECTION LAWS AND REGULATIONS.
Who is Covered?
This Limited Warranty extends only to the first consumer purchaser of the Product, and is
not transferable.
What Does this Limited Warranty Cover?
Motorola's warranty obligations are limited to the terms and conditions set forth herein
and are only available in the country where the Product was purchased. Subject to the
exclusions contained below, Motorola warrants this Tablet Computer (“Product”) against
defects in materials and workmanship, under normal consumer use, for a period of ONE (1)
YEAR from the date of retail purchase by the original end-user purchaser (“Warranty
Period”).
Products repaired or replaced under this Limited Warranty are covered for the balance of
the original warranty period, or 90 days from the date of service, whichever is longer. Any
upgrade to the original product will be covered only for the duration of the Warranty
Period.
This Limited Warranty applies only to new Products which are a) manufactured by or for
Motorola as identified by the “Motorola” trademark, trade name, or logo legally affixed to
them; b) purchased by consumers from an authorized reseller or distributor of Motorola
Products; and c) accompanied by this written Limited Warranty.
What Will Motorola Do?
If a covered defect or damage arises and a valid warranty claim is received within the
applicable Warranty Period, Motorola, at its sole option, unless otherwise required by
applicable law, will either (1) repair, at no charge, the defect or damage using new, used or
reconditioned/refurbished functionally equivalent replacement parts; or (2) exchange the
Product with a replacement Product that is new or which has been
reconditioned/refurbished or otherwise remanufactured from new or used parts and is
functionally equivalent to the original Product; or (3) refund the purchase price of any
Products covered by the terms and conditions of this Limited Warranty.
Products, parts and supporting documentation provided to Motorola as part of the warranty
process, shall become the property of Motorola, and may not be returned. When a
replacement or refund is given, the Product for which the replacement or refund is provided
must be returned to Motorola and shall become the property of Motorola.
Exclusions (Products and Accessories)
This warranty does not apply to:
(a)
Consumable parts
, such as batteries, unless its fully charged capacity falls below
50% of their rated capacity within the first year from the date of purchase; or protective
coatings designed to diminish over time unless failure has occurred due to a defect in
materials or workmanship.
(b)
Cosmetic damage
, including but not limited to scratches, dents, cracks or other
cosmetic damage.
(c)
Damage caused by use with non-Motorola products.
Defects or damage that
result from the use of non-Motorola branded or certified Products, accessories or other
peripheral equipment, including without limitation housings, parts, or software, are
excluded from coverage.
(d)
Damage caused by accident, abuse, misuse, liquid contact, fire, earthquake or
other external causes
; including but not limited to: (i) improper usage or operation (e.g.
operating the Product outside their permitted or intended uses as defined by Motorola,
including but not limited to as set forth by Motorola in the Products' User Manual, Quick
Start Guide, Online Tutorials, and other documentation), improper storage (e.g. subjecting
the Product to extreme temperatures), abuse or neglect (e.g. broken/bent/missing
clips/fasteners/connectors); impact damage (e.g. dropping the Product) (ii) contact with
LIFE. POWERED.
Back Next
More Support
+
MOTOROLA
Your tablet
Start
Want More?
Troubleshooting
Safety, Regulatory & Legal
Safety, Regulatory & Legal
liquids, water, rain, extreme humidity, heavy perspiration or other moisture; sand, food, dirt
or similar substances; (iii) use of the Products for commercial rental purposes; or (iv)
external causes or acts which are not the fault of Motorola, including but not limited to
flood, fire, earthquake, tornado or other acts of God, are excluded from coverage.
(e)
Damage caused by unauthorized Service or Modification.
Defects or damage
resulting from service, testing, adjustment, installation, maintenance, alteration, or
modification in any way, including but not limited to tampering with or altering the
software, by someone other than Motorola, or its authorized service centers, are excluded
from coverage.
(f)
A product or part that has been modified in any manner without the written
permission of Motorola.
Products that have been altered in any manner so as to prevent
Motorola from determining whether such Products are covered under the terms of this
Limited Warranty are excluded from coverage. The forgoing shall include but not be limited
to (i) serial numbers, date tags or other manufacturer coding that has been removed,
altered or obliterated; (ii) mismatched or duplicated serial numbers; or (iii) broken seals or
other evidence of tampering. Do not open the Product or attempt to repair the Product
yourself; such conduct may cause damage that is not covered by this warranty.
(g)
Normal wear and tear or otherwise due to the normal aging of the Product.
(h)
Defects, damages, or the failure of the Product due to any communication
service or network you subscribe to or use with the Products.
(i)
All software, including operating system software, third-party software,
applications, and all other software of any kind.
Software distributed by Motorola is
provided “AS-IS” and “AS AVAILABLE,” “WITH ALL FAULTS” and without a warranty of any
kind. The Limited Warranty does not apply to any non-Motorola product or any software,
even if packaged or sold with the Motorola Product hardware, unless otherwise required
by applicable local law.
(j)
Products that have been refurbished, reconditioned, or remanufactured.
The
foregoing does not apply to Products repaired or replaced pursuant to the terms of this
Limited Warranty.
What Other Limitations are There?
TO THE EXTENT PERMITTED BY APPLICABLE LAW:
•
THIS LIMITED WARRANTY AND THE REMEDIES SET FORTH HEREIN ARE EXCLUSIVE
AND IN LIEU OF ALL OTHER WARRANTIES AND REMEDIES, WHETHER ORAL OR
WRITTEN, STATUTORY, EXPRESS OR IMPLIED. NO ORAL OR WRITTEN
REPRESENTATIONS MADE BY MOTOROLA OR ANY SELLER, RESELLER OR
DISTRIBUTOR OF THE PRODUCTS, INCLUDING EMPLOYEES AND AGENTS THEREOF,
SHALL CREATE ANY ADDITIONAL WARRANTY OBLIGATIONS, INCREASE THE SCOPE,
OR OTHERWISE MODIFY IN ANY MANNER THE TERMS OF THIS LIMITED WARRANTY.
•
MOTOROLA SPECIFICALLY DISCLAIMS ANY AND ALL STATUTORY OR IMPLIED
WARRANTIES, INCLUDING, WITHOUT LIMITATION, WARRANTIES OF
MERCHANTABILITY, FITNESS FOR A PARTICULAR PURPOSE, NONINFRINGEMENT AND
ALL WARRANTIES AGAINST HIDDEN OR LATENT DEFECTS. WHERE SUCH STATUTORY
OR IMPLIED WARRANTIES CANNOT LAWFULLY BE DISCLAIMED, THEN TO THE
EXTENT PERMITTED BY LAW, ALL SUCH WARRANTIES SHALL BE LIMITED IN
DURATION TO THE DURATION OF THE EXPRESS LIMITED WARRANTY CONTAINED
HEREIN AND THE REMEDIES OF REPAIR, REPLACEMENT, OR REFUND AS DETERMINED
BY MOTOROLA IN ITS SOLE DISCRETION SHALL BE THE EXCLUSIVE REMEDY OF THE
CONSUMER.
•
MOTOROLA DOES NOT WARRANT THAT THE OPERATION OF ANY PRODUCTS OR
SOFTWARE COVERED UNDER THIS LIMITED WARRANTY WILL MEET YOUR
REQUIREMENTS, WORK IN COMBINATION WITH ANY HARDWARE OR SOFTWARE
APPLICATIONS OR THIRD PARTY SERVICES, BE UNINTERRUPTED, ERROR-FREE, OR
WITHOUT RISK TO, OR LOSS OF, ANY INFORMATION, DATA, SOFTWARE OR
APPLICATIONS CONTAINED THEREIN, OR THAT DEFECTS IN THE PRODUCTS OR
SOFTWARE WILL BE CORRECTED.
•
IN NO EVENT SHALL MOTOROLA BE LIABLE, WHETHER IN CONTRACT, TORT OR
UNDER OTHER LEGAL THEORY (INCLUDING NEGLIGENCE), FOR DAMAGES IN EXCESS
OF THE PURCHASE PRICE OF THE PRODUCTS, OR FOR ANY INDIRECT, INCIDENTAL,
SPECIAL OR CONSEQUENTIAL DAMAGES OF ANY KIND, OR LOSS OF REVENUE OR
PROFITS; LOSS OF BUSINESS; BUSINESS INTERRUPTION; LOSS OF OPPORTUNITY;
LOSS OF GOODWILL; LOSS OF REPUTATION; LOSS OF, DAMAGE TO, OR CORRUPTION
OF INFORMATION, DATA, SOFTWARE OR APPLICATIONS (INCLUDING ANY COSTS
ASSOCIATED WITH RECOVERING, PROGRAMMING, OR REPRODUCING ANY
INFORMATION, DATA, SOFTWARE OR APPLICATIONS STORED ON OR USED WITH
MOTOROLA PRODUCTS, OR ANY FAILURE TO MAINTAIN THE CONFIDENTIALITY OF
ANY INFORMATION OR DATA STORED ON THE PRODUCTS); OR OTHER FINANCIAL
LOSS ARISING OUT OF OR IN CONNECTION WITH THE ABILITY OR INABILITY TO USE
THE PRODUCTS.
SOME STATES OR JURISDICTIONS DO NOT ALLOW THE LIMITATION OR
EXCLUSION OF INCIDENTAL OR CONSEQUENTIAL DAMAGES, OR THE
EXCLUSION OR LIMITATION ON THE LENGTH OF AN IMPLIED WARRANTY, OR
THE LIMITATION OR EXCLUSION OF DAMAGES FOR PERSONAL INJURIES
CAUSED BY NEGLIGENCE, SO THE ABOVE LIMITATIONS OR EXCLUSIONS MAY
NOT APPLY TO YOU. THIS WARRANTY GIVES YOU SPECIFIC LEGAL RIGHTS, AND
YOU MAY ALSO HAVE OTHER RIGHTS THAT VARY FROM STATE OR
JURISDICTION.
In the event that any term or provision contained in this Limited Warranty is found to be
invalid, illegal or unenforceable by a court of competent jurisdiction, then such provision
shall be deemed modified to the extent necessary to make such provision enforceable by
such court, taking into account the intent of the parties. The invalidity in whole or in part of
any portion of this Limited Warranty shall not impair or affect the validity or enforceability
of the remaining provisions of this Limited Warranty.
LIFE. POWERED.
Back Next
More Support
+
MOTOROLA
Your tablet
Start
Want More?
Troubleshooting
Safety, Regulatory & Legal
Safety, Regulatory & Legal
Copyright & Trademarks
Motorola Mobility, Inc.
Consumer Advocacy Office
600 N US Hwy 45
Libertyville, IL 60048
www.motorola.com
Note:
Do not ship your product to the above address. If you need to return your product for
repairs, replacement, or warranty service, please contact the Motorola Customer Support
Center at:
1-800-734-5870 (United States)
1-888-390-6456 (TTY/TDD United States for hearing impaired)
1-800-461-4575 (Canada)
Certain features, services and applications are network dependent and may not be
available in all areas; additional terms, conditions and/or charges may apply. Contact your
service provider for details.
All features, functionality, and other product specifications, as well as the information
contained in this guide, are based upon the latest available information and believed to be
accurate at the time of printing. Motorola reserves the right to change or modify any
information or specifications without notice or obligation.
Note:
The images in this guide are examples only.
MOTOROLA and the Stylized M Logo are trademarks or registered trademarks of Motorola
Trademark Holdings, LLC. Google, the Google logo, Google Maps, Google Talk, Google
Latitude, Gmail, YouTube, Picasa, Android and Android Market are trademarks of Google,
Inc. All other product or service names are the property of their respective owners.
© 2011 Motorola Mobility, Inc. All rights reserved.
Caution:
Motorola does not take responsibility for changes/modification to the
transceiver.
Bluetooth ID: XXXXXXX
Product ID: MOTOROLA [Fleming]™ (Model XT862)
Manual Number: 68XXXXXXXX-X
