Welcome
Congratulations! You are now the proud owner of a Motorola
V102c Personal Communicator. Your Personal Communicator
combines advanced calling and messaging capabilities in a
stylish, compact unit.
! .
Volume Keys
Adjust earpiece
and ringer volume.
Left Soft Key
Perform functions of
left display prompt.
Menu Key
Right Soft Key
Perform functions of
right display prompt
.
Send Key
Send & answer calls,
view recent dialed
calls list.
Smart Button
Access Phone
Book, make calls
using Voice Tags.
Power/End Key
Long press—
power on and off.
Short press—end
calls.
Voice Note Key
Record & activate
voice notes,
phonebook &
shortcut names.
Display
User.Guide.Tarpon.book Page 1 Saturday, June 23, 2001 5:03 PM
2
PRELIMINARY
Personal Communications Sector
600 North U.S. Highway 45
Libertyville, Illinois 60048
1-800-331-6456 (United States)
1-888-390-6456 (TTY/TDD United States)
1-800-461-4575 (Canada)
www.motorola.com
MOTOROLA, the Stylized M Logo and all other trademarks
indicated as such herein are trademarks of Motorola, Inc. ® Reg.
U.S. Pat. & Tm. Off. All other product or service names are the
property of their respective owners.
© 2001 Motorola, Inc. All rights reserved. Printed in the U.S.A.
Computer Program Copyrights
The Motorola products described in this manual may include Motorola
computer programs stored in semiconductor memories or other media
that are copyrighted with all rights reserved worldwide to Motorola.
Laws in the United States and other countries preserve for Motorola,
Inc. certain exclusive rights to the copyrighted computer programs,
including the exclusive right to copy, reproduce, modify, decompile,
disassemble, and reverse-engineer the Motorola computer programs in
any manner or form without Motorola's prior written consent.
Furthermore, the purchase of Motorola products shall not be deemed to
grant either directly or by implication, estoppel, or otherwise, any
license or rights under the copyrights, patents, or patent applications of
Motorola, except for a nonexclusive license to use the Motorola product
and the Motorola computer programs with the Motorola product.
Manual number:
Cover number:
User.Guide.Tarpon.book Page 2 Saturday, June 23, 2001 5:03 PM
3
Preliminary
✂
Menu Map
Main Menu
• Phonebook
• Radio
• Messages
• Voicemail
• Text Msgs
• Browser Alerts
• Quick Notes
• Outbox
• Drafts
• Shortcuts
• Voice Notes
• Browser
• Settings
(see next page)
Note:
This is the standard phone
menu layout. You or your service
provider may have changed the
menu layout or changed some
feature names. Not all features
may be available for all users.
For example, the
Radio
feature
on the main menu (left) is
displayed only when the FM
Stereo Radio Headset accessory
is plugged into the accessory
connector port on your phone
(see phone illustration, page 1).
For a description of the standard
menu features, see pages 53 to
64.
Shortcuts
Change display zoom:
Press
M
, then
press and hold
M
Lock/unlock keypad:
Press
M
*
Display my phone number:
Press
M
#
Go to dialed calls list:
Press
N
User.Guide.Tarpon.book Page 3 Saturday, June 23, 2001 5:03 PM
4
Preliminary
✂
Settings Menu
• Ring/Vibrate
• Alert
•
Alert
Detail
• Phone Status
• My Tel. Number
• Battery Meter
• Other Information
• Connection
• Incoming Call
• In-Call Setup
• In-Call Timer
• Answer Options
• Security
• Phone Lock
• Lock Keypad
• Lock Application
• Restrict Calls
• New Passwords
• Other Settings
• Personalize
• Main Menu
• Keys
• Greeting
• Banner
• Quick Dial
• Initial Setup
• Time and Date
• Auto PIN Dial
• Auto Redial
• Backlight
• Zoom
• Scroll
• Animation
• Language
• Contrast Setting
• DTMF
• Master Reset
• Master Clear
• Network
• Car Settings
• Headset
User.Guide.Tarpon.book Page 4 Saturday, June 23, 2001 5:03 PM
5
PRELIMINARY
Contents
Menu Map
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
About This Guide
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Safety and General Information
. . . . . . . . . . . . . . . . . . . 10
Getting Started
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
What’s in the Box? . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Installing the Battery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Charging the Battery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Turning On Your Personal Communicator . . . . . . . . . . . . . . . . 19
Sending a Call . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Ending a Call . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Receiving a Call . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Displaying Your Phone Number . . . . . . . . . . . . . . . . . . . . . . . 21
Basic Features
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Changing the Zoom Setting . . . . . . . . . . . . . . . . . . . . . . . . . 24
Volume Keys . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Battery Use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Messages—Text
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Setting Up the Text Message Inbox . . . . . . . . . . . . . . . . . . . . 27
Receiving a New Text Message . . . . . . . . . . . . . . . . . . . . . . . 28
Reading, Locking, or Deleting a Text Message . . . . . . . . . . . . 29
Sending a New Text Message . . . . . . . . . . . . . . . . . . . . . . . . 30
Sending a New Text Message to More Than One Person . . . . 32
Sending a Quick Note Text Message . . . . . . . . . . . . . . . . . . . 33
Sending a Quick Note to More than One Person . . . . . . . . . . 34
Sending and Receiving Calls
. . . . . . . . . . . . . . . . . . . . . . 37
Redialing a Number . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
Using Automatic Redial . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
User.Guide.Tarpon.book Page 5 Saturday, June 23, 2001 5:03 PM
Contents
6
PRELIMINARY
Caller ID . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
Dialing an Emergency Number When the
Personal Communicator Is Locked . . . . . . . . . . . . . . . . . . . . . 38
Dialing With Speed Dial . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
Dialing With One-Touch Dial . . . . . . . . . . . . . . . . . . . . . . . . . 39
Additional Dialing Features . . . . . . . . . . . . . . . . . . . . . . . . . . 40
Using Features While On a Call
. . . . . . . . . . . . . . . . . . . 42
Using Call Waiting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
Making a Three-Way Call . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
Additional On-Call Features . . . . . . . . . . . . . . . . . . . . . . . . . 43
Using the Menu
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
Navigating to a Feature . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
Selecting a Feature Option . . . . . . . . . . . . . . . . . . . . . . . . . . 45
Entering Feature Information . . . . . . . . . . . . . . . . . . . . . . . . 46
Entering Text
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48
Choosing a Text Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48
Tap Method . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49
Predictive Text Entry with iTAP™ Software . . . . . . . . . . . . . . 50
Menu Feature Descriptions
. . . . . . . . . . . . . . . . . . . . . . . 53
Main Menu Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53
Settings Menu Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57
Phonebook
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 65
Fields in a Phonebook Entry Form . . . . . . . . . . . . . . . . . . . . . 65
Storing a Phonebook Entry . . . . . . . . . . . . . . . . . . . . . . . . . . 66
Recording a Voice Name For a Phonebook Entry . . . . . . . . . . 68
Dialing a Phonebook Entry . . . . . . . . . . . . . . . . . . . . . . . . . . 69
Radio
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 71
Turning the Radio On and Off . . . . . . . . . . . . . . . . . . . . . . . . 71
Tuning a Station . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 72
User.Guide.Tarpon.book Page 6 Saturday, June 23, 2001 5:03 PM
7
Contents
PRELIMINARY
Storing a Preset . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 72
Selecting a Preset . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 72
Sending and Receiving Calls With the Radio On . . . . . . . . . . . 73
Messages—Voicemail
. . . . . . . . . . . . . . . . . . . . . . . . . . . 74
Storing Your Voicemail Number . . . . . . . . . . . . . . . . . . . . . . . 74
Receiving a New Voicemail Message . . . . . . . . . . . . . . . . . . . 74
Listening to a Voicemail Message . . . . . . . . . . . . . . . . . . . . . 75
Voice Notes
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 76
Recording a Voice Note . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 76
Playing a Voice Note . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 77
Micro-Browser
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 78
Starting a Micro-Browser Session . . . . . . . . . . . . . . . . . . . . . 78
Interacting With Web Pages . . . . . . . . . . . . . . . . . . . . . . . . . 79
Adjusting Your Settings
. . . . . . . . . . . . . . . . . . . . . . . . . . 80
Ring/Vibrate . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 80
Reordering Menu Items . . . . . . . . . . . . . . . . . . . . . . . . . . . . 81
Customizing a Soft Key Function . . . . . . . . . . . . . . . . . . . . . . 82
Security
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 83
Assigning a New Code or Password . . . . . . . . . . . . . . . . . . . 83
Locking and Unlocking Your Personal Communicator . . . . . . . 83
Locking and Unlocking Your Keypad . . . . . . . . . . . . . . . . . . . 85
Troubleshooting
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 87
Specific Absorption Rate Data
. . . . . . . . . . . . . . . . . . . . 91
FDA Update
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 94
Warranty
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 103
Export Law Assurances
. . . . . . . . . . . . . . . . . . . . . . . . . 110
Index
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 111
Wireless Phone Safety Tips
. . . . . . . . . . . . . . . . . . . . . 119
User.Guide.Tarpon.book Page 7 Saturday, June 23, 2001 5:03 PM
8
Preliminary
About This Guide
Using Your Personal Communicator’s
Features
This guide introduces you to the many features in your Motorola
Personal Communicator. A reference guide for your Personal
Communicator is also available that explains its features in more
detail. To obtain a copy of the reference guide or another copy of
this user guide, see the Motorola Web site at:
http://motorola.com/consumer/manuals
or contact the Motorola Customer Call Center at
1-800-331-6456 in the United States or 1-800-461-4575 in
Canada.
Navigating To a Menu Feature
You can access many of your Personal Communicator’s features
through the menu system. This guide shows you how to navigate
to a specific menu feature as follows:
The > symbol means that you should scroll to and select the
feature. This example shows that you must press
M
, scroll to
and select
Recent Calls
, then scroll to and select
Dialed Calls
to view the dialed calls list.
Find the Feature
M> Recent Calls
> Dialed Calls
User.Guide.Tarpon.book Page 8 Saturday, June 23, 2001 5:03 PM
9
About This Guide
Preliminary
Optional Features
Features marked with this icon are optional network
and/or subscription-dependent features that may not
be offered by all service providers in all geographical
areas. Contact your service provider for information
about availability.
Optional Accessories
Features marked with this icon require the use of an
optional Motorola Original™ accessory.
User.Guide.Tarpon.book Page 9 Saturday, June 23, 2001 5:03 PM
PRELIMINARY
10
Safety and General
Information
IMPORTANT INFORMATION ON SAFE AND EFFICIENT
OPERATION. READ THIS INFORMATION BEFORE USING YOUR
PHONE.
RF Operational Characteristics
Your phone contains a transmitter and a receiver. When it is ON,
it receives and transmits radio frequency (RF) energy. The phone
operates in the frequency range of 824 MHz to 849 MHz in
analog and digital mode and 1850 MHz to 1910 MHz in digital
mode.
When you communicate with your phone, the system handling
your call controls the power levels at which your phone
transmits. The output power level typically may vary over a range
from 0.04 watts to 0.49 watts in analog mode and 0.0 watts to
0.57 watts in digital mode.
Exposure To Radio Frequency Energy
Your Motorola phone is designed to comply with the following
national and international standards and guidelines regarding
exposure of human beings to radio frequency electromagnetic
energy (EME):
• United States Federal Communications Commission, Code
of Regulations; 47 CFR part 2 sub-part J
• American National Standards Institute (ANSI) / Institute of
Electrical and Electronic Engineers (IEEE) C95. 1-1992
User.Guide.Tarpon.book Page 10 Saturday, June 23, 2001 5:03 PM
PRELIMINARY
11
Safety and General Information
• Institute of Electrical and Electronic Engineers (IEEE)
C95.1-1999 Edition
• National Council on Radiation Protection and
Measurements (NCRP) of the United States, Report 86,
1986
• International Commission on Non-Ionizing Radiation
Protection (ICNIRP) 1998
• Ministry of Health (Canada) Safety Code 6. Limits of Human
Exposure to Radiofrequency Electromagnetic Fields in the
Frequency Range from 3 kHz to 300 GHz, 1999
• Australian Communications Authority
Radiocommunications (Electromagnetic Radiation-Human
Exposure) Standard 1999
To assure optimal phone performance and make sure human
exposure to radio frequency electromagnetic energy is within the
guidelines set forth in the above standards, always adhere to the
following procedures:
Portable Phone Operation and EME
Exposure
Antenna Care
Use only the supplied or an approved replacement
antenna. Unauthorized antennas, modifications, or
attachments could damage the phone and may violate FCC
regulations.
User.Guide.Tarpon.book Page 11 Saturday, June 23, 2001 5:03 PM
PRELIMINARY
Safety and General Information
12
Do NOT hold the antenna when the phone is in use.
Holding the antenna affects call quality and may cause the
phone to operate at a higher power level than needed.
Phone Operation
When placing or receiving a phone call, hold your phone as you
would a wireline telephone. Speak directly into the
microphone.
Body-Worn Operation
To maintain compliance with FCC/Health Canada RF exposure
guidelines, if you wear a phone on your body when transmitting,
always place the phone in a Motorola-supplied or approved
clip, holder, holster, case, or body harness for this
product. Use of non-Motorola-approved accessories may
exceed FCC/Health Canada RF exposure guidelines. If you do
not use a body-worn accessory, and are not holding the
phone in the normal use position at the ear, ensure the
phone and its antenna are at least one inch
(2.5 centimeters) from your body when transmitting.
Data Operation
When using any data feature of the phone, with or without an
accessory cable, position the phone and its antenna at
least one inch (2.5 centimeters) from your body.
Approved Accessories
For a list of approved Motorola accessories, visit our website at
www.motorola.com
.
User.Guide.Tarpon.book Page 12 Saturday, June 23, 2001 5:03 PM
PRELIMINARY
13
Safety and General Information
Electromagnetic Interference/
Compatibility
Note: Nearly every electronic device is susceptible to
electromagnetic interference (EMI) if inadequately shielded,
designed, or otherwise configured for electromagnetic
compatibility.
Facilities
To avoid electromagnetic interference and/or compatibility
conflicts, turn off your phone in any facility where posted notices
instruct you to do so. Hospitals or health care facilities may be
using equipment that is sensitive to external RF energy.
Aircraft
When instructed to do so, turn off your phone when on board an
aircraft. Any use of a phone must be in accordance with
applicable regulations per airline crew instructions.
Medical Devices
Pacemakers
The Advanced Medical Technology Association recommends that
a minimum separation of 6 inches (15 centimeters) be
maintained between a handheld wireless phone and a
pacemaker. These recommendations are consistent with the
independent research by, and recommendations of, the United
States Food and Drug Administration.
User.Guide.Tarpon.book Page 13 Saturday, June 23, 2001 5:03 PM
PRELIMINARY
Safety and General Information
14
Persons with pacemakers should:
• ALWAYS keep the phone more than six inches
(15 centimeters) from your pacemaker when the phone is
turned ON.
• NOT carry the phone in the breast pocket.
• use the ear opposite the pacemaker to minimize the
potential for interference.
• turn OFF the phone immediately if you have any reason to
suspect that interference is taking place.
Hearing Aids
Some digital wireless phones may interfere with some hearing
aids. In the event of such interference, you may want to consult
your hearing aid manufacturer to discuss alternatives.
Other Medical Devices
If you use any other personal medical device, consult the
manufacturer of your device to determine if it is adequately
shielded from RF energy. Your physician may be able to assist
you in obtaining this information.
Safety and General
Use While Driving
Check the laws and regulations on the use of phones in the area
where you drive. Always obey them.
When using your phone while driving, please:
User.Guide.Tarpon.book Page 14 Saturday, June 23, 2001 5:03 PM
PRELIMINARY
15
Safety and General Information
• give full attention to driving and to the road.
• use hands-free operation, if available.
• pull off the road and park before making or answering a
call if driving conditions so require.
Operational Warnings
For Vehicles With an Air Bag
Do not place a portable phone in the area over an air bag or in
the air bag deployment area. Air bags inflate with great force. If
a portable phone is placed in the air bag deployment area and
the air bag inflates, the phone may be propelled with great force
and cause serious injury to occupants of the vehicle.
Potentially Explosive Atmospheres
Turn off your phone prior to entering any area with a potentially
explosive atmosphere, unless the phone is a model specifically
identified as being “Intrinsically Safe.” Do not remove, install, or
charge batteries in such areas. Sparks in a potentially explosive
atmosphere can cause an explosion or fire resulting in bodily
injury or even death.
Note: The areas with potentially explosive atmospheres referred
to above include fueling areas such as below decks on boats,
fuel or chemical transfer or storage facilities, areas where the air
contains chemicals or particles, such as grain, dust, or metal
powders, and any other area where you would normally be
advised to turn off your vehicle engine. Areas with potentially
explosive atmospheres are often but not always posted.
User.Guide.Tarpon.book Page 15 Saturday, June 23, 2001 5:03 PM
PRELIMINARY
Safety and General Information
16
Blasting Caps and Areas
To avoid possible interference with blasting operations, turn OFF
your phone when you are near electrical blasting caps, in a
blasting area, or in areas posted: “Turn off two-way radio.” Obey
all signs and instructions.
Operational Cautions
Antennas
Do not use any portable phone that has a damaged
antenna. If a damaged antenna comes into contact with your
skin, a minor burn can result.
Batteries
All batteries can cause property damage and/or bodily injury
such as burns if a conductive material such as jewelry, keys, or
beaded chains touches exposed terminals. The conductive
material may complete an electrical circuit (short circuit) and
become quite hot. Exercise care in handling any charged battery,
particularly when placing it inside a pocket, purse, or other
container with metal objects.
ITC01-065
User.Guide.Tarpon.book Page 16 Saturday, June 23, 2001 5:03 PM
17
Preliminary
Getting Started
What’s in the Box?
Your Personal Communicator typically comes equipped with a
battery and a charger. Other accessory options can customize
your Personal Communicator for maximum performance and
portability.
To purchase Motorola Original™ accessories, contact the
Motorola Customer Call Center at 1-800-331-6456 in the
United States or 1-800-461-4575 in Canada.
Installing the Battery
Before you can use your Personal Communicator, you need to
install and charge the battery.
Your Personal Communicator is designed to be used
only with Motorola Original batteries and accessories.
We recommend that you store batteries in their
protective cases when not in use.
Do This
1
Remove the battery from its protective clear plastic case.
2
Unlock the battery door by
pushing the release latch
away from the battery
door..
Release
latch
User.Guide.Tarpon.book Page 17 Saturday, June 23, 2001 5:03 PM
Getting Started
18
Preliminary
Charging the Battery
Before you can use your Personal Communicator, you need to
install and charge the battery.
3
Press the battery door at
the arrow, push it away
from the Personal
Communicator, and
remove it.
4
Insert the battery, printed
arrows first, into the
battery compartment, and
push down.
5
Replace the battery door.
6
Push the release latch
toward the battery door to
lock it into place.
Do This
1
Plug the travel charger
into your Personal
Communicator with the
release tab facing up.
Do This
User.Guide.Tarpon.book Page 18 Saturday, June 23, 2001 5:03 PM
19
Getting Started
Preliminary
Turning On Your Personal
Communicator
2
Plug the other end of the travel charger into the
appropriate electrical outlet.
3
When your Personal Communicator indicates that the
battery is fully charged, press the release tab and remove
the travel charger.
Do This To
1
Press and hold P
(the power key)
turn on your Personal
Communicator
2
Enter your four-digit unlock
code and press OK (+)
unlock your Personal
Communicator, if
necessary
The unlock code is
originally set to 1234.
Do This (Continued)
Power
key
User.Guide.Tarpon.book Page 19 Saturday, June 23, 2001 5:03 PM
Getting Started
20
Preliminary
Sending a Call
To call a number:
• your headset must be connected to your Personal
Communicator
• your Personal Communicator must be opened, turned on,
unlocked, and have a network connection with adequate
signal strength
Ending a Call
Do This To
1
Press the keypad
keys
dial the phone number (up to 32
digits)
If you make a mistake, press
DELETE ([) to delete the last
digit, or press and hold
DELETE ([) to clear all digits.
2
Press Ssend the call
Press To
Eend the call
User.Guide.Tarpon.book Page 20 Saturday, June 23, 2001 5:03 PM
21
Getting Started
Preliminary
Receiving a Call
To receive a call:
• your headset must be connected to your Personal
Communicator
• your Personal Communicator must be turned on, unlocked,
and have a network connection with adequate signal
strength
When you receive a call, your Personal Communicator rings and/
or vibrates and displays an incoming call message.
When your Personal Communicator is closed or in its holster, you
can answer the call by pressing I (Smart Key), located on the
front of your Personal Communicator.
Displaying Your Phone Number
From the idle display:
Press To
N or ANSWER ([) answer the call
Press To
M #see your phone number
User.Guide.Tarpon.book Page 21 Saturday, June 23, 2001 5:03 PM
22
Preliminary
Basic Features
See page 1 for a diagram of your Personal Communicator that
describes its basic features.
Display
The top section of the display shows Personal Communicator
status indicators. The following illustration shows some of the
common indicators that you may see at the top of the display
when using your Personal Communicator.
• Messages, phone numbers, and menu options appear in the
middle of the display.
• The current soft key functions appear at the bottom corners
of the display show the current soft key functions.
•A M (menu) indicator in the bottom center of the display
indicates that you can open the main menu or a feature
sub-menu to see more options.
For more information about the soft key and menu key labels,
see “Using the Menu” on page 44.
Some functions described in this guide must be performed from
the idle display.
Idle display
is the standard display that you see
when your Personal Communicator is on and ready to use, and
you are
not
on a call or using the menu system.
User.Guide.Tarpon.book Page 22 Saturday, June 23, 2001 5:03 PM
23
Basic Features
Preliminary
➊ Signal Strength Indicator Shows the strength of your
Personal Communicator’s connection with the network.
You cannot send or receive calls when the “no signal” indicator
is displayed.
➋ In Use Indicator Appears when a call is in progress.
➌ Roam Indicator Appears when your Personal
Communicator uses another network system outside your home
network. When you leave your home network area, your
Personal Communicator
roams
or seeks another network.
➍ Message Waiting Indicator Appears when
your Personal Communicator receives a text message.
➎ Voice Message Waiting Indicator Appears
when you receive a voicemail message.
Strong 5 4 3 2 1 j No signal
12:00am ➐
➏
➒
➋➌➍➎
➑
➓
➊
User.Guide.Tarpon.book Page 23 Saturday, June 23, 2001 5:03 PM
Basic Features
24
Preliminary
➏ Battery Level Indicator Shows the amount of charge left
in your battery. The more segments visible, the greater the
charge.
Recharge your battery as soon as possible when you see the
Low Battery warning message.
➐ Clock Shows the current time. The clock is
available only when your Personal Communicator is
operating in digital mode.
➑ Menu Indicator Indicates that you can press M to open
a menu. See “Using the Menu” on page 44.
➒ Digital (F) or Analog (I) Signal Indicator Shows
whether you are receiving a digital or analog signal.
➓ Alert Setting Indicator Shows the current selected alert.
The default alert setting is a ringer.
Changing the Zoom Setting
You can set your Personal Communicator’s display to show three
lines or two lines of text plus soft key labels. Three lines of text
display more information, while two lines increase text size.
To change the display view, press M once, then press and hold
M again within two seconds.
High E D C B Empty
w Loud ring x Soft ring
y Vibrate u Ring and vibrate
t Silent
User.Guide.Tarpon.book Page 24 Saturday, June 23, 2001 5:03 PM
25
Basic Features
Preliminary
You can also adjust the zoom setting from the menu. See
“Zoom” on page 62.
Volume Keys
Use the upper and lower volume keys (on the front of your
Personal Communicator) to adjust earpiece and ringer volume.
You can also use the volume keys to scroll up or down through
menus and lists.
To change keypad volume, see “Select a Ring/Vibration for a
Specific Event” on page 81.
Battery Use
Caution: To prevent injuries or burns, do not allow metal
objects to contact or short-circuit the battery terminals.
To maximize battery performance:
• Always use Motorola approved batteries and battery
chargers. The Personal Communicator warranty does not
cover damage caused from using non-Motorola batteries
and/or battery chargers.
When Press To
During a call volume keys increase or decrease
earpiece speaker volume
From the idle
display
volume keys increase or decrease ringer
volume
User.Guide.Tarpon.book Page 25 Saturday, June 23, 2001 5:03 PM
Basic Features
26
Preliminary
• New batteries or batteries that have been stored for long
periods of time may require a longer charge time.
• Maintain the battery at or near room temperature when
charging.
• Do not expose batteries to temperatures below -10°C
(14°F) or above 45°C (113°F). Always take your Personal
Communicator with you when you leave your vehicle.
• When you do not intend to use a battery for a while, store it
uncharged in a cool, dark, dry place, such as a refrigerator.
• Over extended periods of time, batteries gradually wear
down and require longer charging times. This is normal. If
you charge your battery regularly and notice a decrease in
talk time or an increase in charging time, then it is probably
time to purchase a new battery.
• The more you talk on the Personal Communicator or use its
features (like sending text messages), the less standby time
your battery has.
The rechargeable batteries that power this product
must be disposed of properly and may need to be
recycled. Refer to your battery’s label for battery type.
Contact your local recycling center for proper disposal methods.
Never dispose of batteries in a fire because they may explode.
User.Guide.Tarpon.book Page 26 Saturday, June 23, 2001 5:03 PM
27
PRELIMINARY
Messages—Text
Text messages are brief messages that you can send
and receive (such as Where are we meeting?).
Received messages appear on your Personal
Communicator display or in your text message inbox.
You must set up the text message inbox
before
you can send and
receive messages. The total number of messages the inbox can
store depends on the length of the messages and on how many
other messages and drafts are stored.
Note: Your service provider may have already programmed the
text message inbox setting for you.
Setting Up the Text Message Inbox
Find the Feature
M> Messages
M > Text Msg Setup
Press To
1
O scroll to Srvce Center No.
2
CHANGE ([) change the Srvce Center No.
provided by your service provider
3
keypad keys enter the phone number for the
service center that handles your
outgoing messages
4
OK ([) store your service center number
5
CHANGE ([) change the Expire After period
User.Guide.Tarpon.book Page 27 Saturday, June 23, 2001 5:03 PM
Messages—Text
28
PRELIMINARY
Receiving a New Text Message
Note: You must set up the text message inbox before you can
receive text messages.
When you receive a new message, your Personal Communicator
displays New Message X and sounds an alert. If reminders are
turned on, a reminder is sent every five minutes until you close
the new message notification, read the message, or turn off your
Personal Communicator.
6
keypad keys enter the expiration period—the
number of days your network tries to
send unreceived messages
7
OK ([) store the expiration period
8
CHANGE ([) change the Cleanup setting
9
O scroll to the period of time that
messages stay in your inbox
10
SELECT ([) select the cleanup period
If you select Custom, continue.
Otherwise, the procedure is
complete.
11
O change the entry for the number or
label
12
Oswitch between the number and the
label
13
DONE ([) store the custom cleanup period after
you finish entering all information
Press To
User.Guide.Tarpon.book Page 28 Saturday, June 23, 2001 5:03 PM
29
Messages—Text
PRELIMINARY
When your inbox is full, each new message replaces the oldest
unlocked message.
From the new message notification:
Reading, Locking, or Deleting a Text
Message
You can open your text message inbox to read, lock, or delete
messages at any time.
Messages in the text message inbox are sorted from newest to
oldest. Oldest messages are deleted as new ones are added. To
save a message, lock it to prevent it from being overwritten by a
new message.
Press To
READ ([) open the message (or your text
message inbox if there are multiple
messages)
Find the Feature
M> Messages > Text Msgs
Press To
1
O scroll to the message you want
(d = unread and urgent,
o = read, f = read and locked)
2
READ ([) open the message
User.Guide.Tarpon.book Page 29 Saturday, June 23, 2001 5:03 PM
Messages—Text
30
PRELIMINARY
Sending a New Text Message
To create and send a new text message:
3
SAVE ([)
or
DELETE ([)
or
M
close the message without changes
delete the message
open the Text Msg Menu and scroll
to other options such as Lock/
Unlock
Find the Feature
M> Messages > Text Msgs
M> Create Message
Press To
1
CHANGE ([) select To
2
keypad keys enter the phone number or email
address where you want to send the
message
Note: To send the message to
multiple recipients, see “Sending a
New Text Message to More Than One
Person” on page 32.
3
OK ([) store the number or email address
4
CHANGE ([) select Msg
5
keypad keys enter the text message (see “Entering
Text” on page 48)
Press To
User.Guide.Tarpon.book Page 30 Saturday, June 23, 2001 5:03 PM
31
Messages—Text
PRELIMINARY
6
OK ([) store the text message
Note: Message length is limited.
When 40 or fewer characters remain,
a two-digit counter at the top of the
display shows how many are left.
7
CHANGE ([) select Priority
8
O scroll to the priority you want
9
SELECT ([) set the priority
10
CHANGE ([) select Call
11
keypad keys enter the number you want your
recipient to call back (the message’s
From field)
12
OK ([) store the number
13
DONE ([) finish the message
Your Personal Communicator displays
Send Message Now?
14
YES ([)
or
NO ([)
send the message
cancel the message or save it as a
draft
Press To
User.Guide.Tarpon.book Page 31 Saturday, June 23, 2001 5:03 PM
Messages—Text
32
PRELIMINARY
Sending a New Text Message to More
Than One Person
You can create and send a single text message to multiple
recipients. To create the message:
Find the Feature
M> Messages > Text Msgs
M> Create Message
Press To
1
CHANGE ([) select To
2
BROWSE ([) open the Browse Menu
3
O scroll to Phonebook
4
SELECT ([) select Phonebook
5
O scroll to a phone number or email
address where you want to send the
message
6
ADD ([) add the number or address to the
group of message recipients
Note: To add more recipients, scroll
to and select other phone numbers
and/or email addresses from the
phonebook list.
7
DONE ([) close the phonebook list and return
to the To field in the text message
window
User.Guide.Tarpon.book Page 32 Saturday, June 23, 2001 5:03 PM
33
Messages—Text
PRELIMINARY
Sending a Quick Note Text Message
Quick notes are short, pre-written text messages that you
can create, select, edit, and send quickly (for example,
Meet me at ...).
To send or save a quick note message:
8
OK ([)
or
M
store the numbers/addresses and
complete the other message fields
(for details, see “Sending a New Text
Message” on page 30)
open the To Menu to browse for
more phone numbers or email
addresses
• Press O to scroll to Browse
• Press SELECT ([) to open the
Browse Menu and repeat this
procedure for the additional
numbers/addresses
Find the Feature
M> Messages > Quick Notes
Press To
1
O scroll to the quick note
2
M open the Quick Note Menu to
perform other procedures as
described in the following list
Press To
User.Guide.Tarpon.book Page 33 Saturday, June 23, 2001 5:03 PM
Messages—Text
34
PRELIMINARY
The Quick Note Menu includes the following options:
Sending a Quick Note to More than
One Person
To send a quick note text message to multiple recipients:
Option Description
New Open an editor where you can create a
new quick note.
Enter text and press OK ([) to save it as
a quick note.
Edit Open an editor where you can edit the
selected quick note.
Edit the quick note text and press
OK ([) to save your changes.
Delete Delete the selected quick note.
Send Open a new message, with the selected
quick note text in the Msg field.
Complete the other fields in the message.
(For details, see “Sending a New Text
Message” on page 30.)
To send the quick note to multiple
recipients, see “Sending a Quick Note to
More than One Person” on page 34.
Find the Feature
M> Messages > Quick Notes
User.Guide.Tarpon.book Page 34 Saturday, June 23, 2001 5:03 PM
35
Messages—Text
PRELIMINARY
Press To
1
O scroll to the quick note
2
M open the Quick Note Menu.
3
O scroll to Send
4
SELECT ([) select Send
5
CHANGE ([) select To
6
BROWSE ([) open the Browse Menu
7
O scroll to Phonebook
8
SELECT ([) select Phonebook
9
Oscroll to a phone number or email
address where you want to send the
message
10
ADD ([) add the number or address to the
group of message recipients
To add more recipients, scroll to and
select other phone numbers and/or
email addresses from the phonebook
list.
11
DONE ([) close the phonebook list and return
to the To field in the quick note text
message window
User.Guide.Tarpon.book Page 35 Saturday, June 23, 2001 5:03 PM
Messages—Text
36
PRELIMINARY
12
OK ([)
or
M
store the numbers/addresses and
complete the other message fields
(for details, see “Sending a New Text
Message” on page 30)
open the To Menu to browse for
more phone numbers or email
addresses
• Press O to scroll to Browse
• Press SELECT ([) to open the
Browse Menu and repeat this
procedure for the additional
numbers/addresses
Press To
User.Guide.Tarpon.book Page 36 Saturday, June 23, 2001 5:03 PM
37
Preliminary
Sending and Receiving
Calls
For basic instructions on how to send a call, end a call, and
receive a call, see page 20 of the “Getting Started” section.
Redialing a Number
If you hear an ordinary busy signal, the phone number you dialed
is busy. From the idle display:
Using Automatic Redial
If the network is busy, you hear a fast busy signal, and your
Personal Communicator displays the message Call Failed.
When you activate automatic redial, your Personal
Communicator repeats the call attempt over the next four
minutes.
When the call goes through, your Personal Communicator rings
or vibrates once, displays Redial Successful, and then
connects the call automatically.
Press To
1
S go directly to the dialed calls list
2
Oscroll the entry you want to call
3
Sredial the busy number
Press To
N or RETRY ([) activate automatic redial
User.Guide.Tarpon.book Page 37 Saturday, June 23, 2001 5:03 PM
Sending and Receiving Calls
38
Preliminary
You must activate automatic redial in order to use the feature.
See the “Auto Redial” item on page 62.
Caller ID
The
calling line identification
(caller ID) feature lets you
see who is calling before you answer.
• If the caller’s name is stored in your phonebook, the
Personal Communicator automatically displays the name.
Otherwise, the Personal Communicator displays the caller’s
phone number.
• If caller ID information is not available, your Personal
Communicator displays the message Incoming Call.
Dialing an Emergency Number When
the Personal Communicator Is Locked
Your service provider may program one or more emergency
phone numbers that you can call even if your Personal
Communicator is locked or restricted.
When you see Enter Unlock Code in the display:
Press To
1
keypad keys dial the emergency number (such as
911 or 112)
2
S call the emergency number
User.Guide.Tarpon.book Page 38 Saturday, June 23, 2001 5:03 PM
39
Sending and Receiving Calls
Preliminary
Dialing With Speed Dial
The
speed dial
feature lets you dial any phonebook entry with a
minimal number of keypresses.
Whenever you store an entry in your phonebook, the entry is
assigned a unique speed dial number. If you know the speed dial
number for the phonebook entry you want to call, you can use
the speed dial feature.
To make an entry in the phonebook or view an existing entry’s
speed dial number, see “Storing a Phonebook Entry” on
page 66.
Dialing With One-Touch Dial
You can call phonebook entries 2 through 9 with the push of a
single key. Just press and hold the one-digit speed dial number
for one second.
It is recommended that you reserve location 1 in the phonebook
for storing your voicemail number. In many cases, your service
provider has already stored your voicemail number in location 1.
Press To
1
keypad keys enter the one-, two-, or three-digit
speed dial number for the entry you
want to dial
2
Osubmit the number
3
Scall the entry
User.Guide.Tarpon.book Page 39 Saturday, June 23, 2001 5:03 PM
Sending and Receiving Calls
40
Preliminary
If your voicemail number is not accessible by pressing and
holding the 1 key, complete the following steps:
To store entries in locations 2 through 9 in the phonebook, see
“Storing a Phonebook Entry” on page 66.
Additional Dialing Features
In addition to pressing numbers on your keypad, you can insert
numbers or characters and send calls in a variety of ways.
While dialing (with digits visible in the display):
Do This To
1
Store your voicemail number in
phonebook location number 1
(see “Storing a Phonebook
Entry” on page 66)
enable the 1 key
voicemail shortcut
2
Complete the instructions for
“Storing Your Voicemail Number”
on page 74
enable voicemail soft
key and menu
shortcuts
Do This To
Press M
> Attach Number
attach a number from the phonebook
or recent calls list to the end of the
digits you entered
Press M
> Send Message
create a text message addressed to
the number entered
User.Guide.Tarpon.book Page 40 Saturday, June 23, 2001 5:03 PM
41
Sending and Receiving Calls
Preliminary
You can also call numbers using these features:
Press M and then
scroll to and select
one of the following:
•Insert Pause
(to insert a p)
•Insert Wait
(to insert a w)
•Insert 'n'
(to insert an n)
insert a special character when
making a calling card call:
•Pause tells your Personal
Communicator to wait until the
call connects before it sends the
next digit.
•Wait tells your Personal
Communicator to wait until the
call connects, and then to prompt
you before it sends the next digit.
•'n' tells your Personal
Communicator to stop and to
prompt you for a number before it
sends the next digit.
Do This To Call
Press and release the voice key
on the right side of your phone
and say the entry’s name (in
two seconds).
a phone number using the
voice dial feature
See “Recording a Voice
Name For a Phonebook
Entry” on page 68.
Press M > Recent Calls
> Received Calls or
Dialed Calls >
entry to call
a missed call or a number
from a call you recently
dialed or received
Do This To
User.Guide.Tarpon.book Page 41 Saturday, June 23, 2001 5:03 PM
42
Preliminary
Using Features While On a
Call
Using Call Waiting
If you subscribe to call waiting, an alert tone sounds
while you are on a call to indicate that you have
received a second call.
To put the first call on hold and answer the second call:
To end the first call and answer the second call:
Making a Three-Way Call
During a call, you can call and connect a third party so
that the three of you can talk together. You cannot do
this if you already have a call on hold.
Press To
1
S answer the new call
2
S switch back to the first call
Press To
1
Eend the current call
Your Personal Communicator rings to
signal the new call.
2
Sanswer the new call
User.Guide.Tarpon.book Page 42 Saturday, June 23, 2001 5:03 PM
43
Using Features While On a Call
Preliminary
During a call:
Additional On-Call Features
While you are on a call, you can perform the following tasks:
Press To
1
keypad keys enter the third person’s number
2
NS call the number and connect the new
person
3
Sconnect the two calls
4
Eend the entire call
Do This To
Press MUTE ([) mute a call
Press M
> My Tel. Number
see your phone number
Press M > Send Tones send a number to the network
as DTMF tones, for credit card
calling or password entry
To activate DTMF tones, see the
“DTMF” item on page 63.
User.Guide.Tarpon.book Page 43 Saturday, June 23, 2001 5:03 PM
44
Preliminary
Using the Menu
Navigating to a Feature
You can access many of your Personal Communicator’s features
by using these keys to move through the menu system:
! .
Volume Keys
Move up or down
through menus
and lists.
Left Soft Key
Perform function
shown in the lower
left corner of the
display (usually
EXIT
or
BACK
).
Menu Key
Enter the menu
system, or open
a sub-menu, when
M
appears in the
bottom center of
the display.
Right Soft Key
Perform function
shown in lower
right corner of the
display (usually
SELECT
the
highlighted menu
item).
End Key
Exit the menu
system without
making changes,
return to the idle
display
Smart Button
Access Phone book,
make calls using
Voice Tags.
Scroll Keys
Move up or down
through menus
and lists.
User.Guide.Tarpon.book Page 44 Saturday, June 23, 2001 5:03 PM
45
Using the Menu
Preliminary
This guide shows how to navigate to a menu feature as follows:
The > symbol means that you should scroll to and select the
feature. In this example, you should press M, scroll to and
select Recent Calls, then scroll to and select Dialed Calls.
Selecting a Feature Option
Some features require you to select an item from a list:
Select an item by highlighting it with any of these methods:
• Press S to scroll up or down to the item you want.
• In a numbered list, press a number key to highlight the
item.
• In an alphabetized list, press a key multiple times to cycle
through the letters on the key and highlight the closest
matching list item.
Find the Feature
M> Recent Calls
> Dialed Calls
Dialed Calls
10) John Smith
9) Mary Smith
BACK VIEW
Press
BACK
(
[
)
to go back to the
previous screen.
A sub-menu
is available.
Press
M
to
open it.
Highlighted
item
Press
VIEW
(
[
) to view
details of the highlighted item.
STORE
(
[
) appears if you can
store the item in your phonebook.
M
User.Guide.Tarpon.book Page 45 Saturday, June 23, 2001 5:03 PM
Using the Menu
46
Preliminary
Entering Feature Information
Features such as the phonebook require you to enter information
to fill in one or more items:
• Enter numbers or text with the keypad. (See “Entering Text”
on page 48.)
• When an item has a list of possible values, press * or #
to scroll through and select a value.
• When an item has a list of possible numeric values, press a
number key to set the value.
• If you enter or edit information and then decide that you do
not want to save your changes, press E to exit without
saving.
Entry Details
Name:John Smith
No.:2125551212
CANCEL CHANGE
Press
S
to
scroll down
to additional
items.
Press
CANCEL
(
[
) to exit
without making changes.
DONE
(
[
) appears when you
enter or edit information. Press
DONE
(
[
) to save your changes.
Press
CHANGE
(
[
)
to edit the selected
information.
Highlighted
item
User.Guide.Tarpon.book Page 46 Saturday, June 23, 2001 5:03 PM
47
Using the Menu
Preliminary
The message center lets you compose and send text messages.
(See “Entering Text” on page 48.) A
flashing cursor
shows you
where the text will appear:
When you enter text, the flashing cursor changes to a
block
cursor
, and the soft key functions change:
Msg:
CANCEL BROWSE
Press
BROWSE
(
[
)
to view and
insert a name,
number, or
message from
previously
stored
information.
Press
CANCEL
(
[
)
to exit without making
changes.
Flashing
cursor
indicates
insertion
point.
Press
M
to open
the sub-menu.
M
Msg:
T
DELETE OK
Press
OK
(
[
)
to accept and
store the text.
Press
DELETE
(
[
) to
delete the character to the
left of the insertion point.
Block
cursor
indicates
current
highlighted
character.
M
After two seconds, the block
cursor reverts to a flashing cursor
and moves to the next position.
User.Guide.Tarpon.book Page 47 Saturday, June 23, 2001 5:03 PM
48
Preliminary
Entering Text
Various text entry methods make it easy for you to enter names,
numbers, email addresses, and text messages on your Personal
Communicator.
You can enter all characters (letters, numbers, and symbols)
using the standard tap method. Other text modes let you easily
enter numbers or insert text already stored on your Personal
Communicator. Finally, a predictive text mode lets you enter text
messages with a minimum of keypresses.
Choosing a Text Mode
To activate a text mode, press M from any text entry screen
and select the text mode from the Entry Method menu:
Note: The text mode you select remains active until you change
it by selecting another mode.
iTAP Let the Personal Communicator predict each
word as you enter it, then choose the word from
a list (see “Predictive Text Entry with iTAP™
Software” on page 50).
Tap Method Enter characters one at a time by pressing the
key for the letter, number, or symbol (see “Tap
Method” on page 49). This is the standard
mode for entering text on your Personal
Communicator.
Numeric Enter only the number that appears on each key.
Browse Browse through your phonebook and recent
calls lists to select a name or number to enter.
User.Guide.Tarpon.book Page 48 Saturday, June 23, 2001 5:03 PM
49
Entering Text
Preliminary
Tap Method
Tap method is the default standard mode for entering text on
your Personal Communicator.
To enter text using the tap method:
General Text Entry Rules
Use the keypad to enter letters, numbers, symbols, and other
characters with the tap method. Press the same key repeatedly
to cycle through available characters (see the “Character Chart”
on page 50):
• To enter text at a flashing cursor, press a number key.
• To enter the desired character, press the number key as
many times as necessary. For example, press 2 three times
to enter the “c” character.
• To cycle between uppercase and lowercase characters,
press and hold a key.
Do This To
1
Press a number
key one or more
times
cycle through the characters
associated with the key and select
the character you want (see the
“Character Chart” on page 50).
2
Continue to press
number keys
enter the rest of the characters in the
text message
3
Press OK ([) accept and store the text when you
are finished
User.Guide.Tarpon.book Page 49 Saturday, June 23, 2001 5:03 PM
Entering Text
50
Preliminary
• To move the flashing cursor up or down one line in a text
message, or to change a character in block cursor to
uppercase or lowercase, press the up or down arrow on the
O key.
• To move the flashing cursor to the left or right in a text
message, press the left or right arrow on the O key.
• If you do not press a key for two seconds, the character in
the block cursor is accepted, and the cursor moves to the
next position.
• The first character of every sentence is capitalized unless
you manually change it. (Hold the number key or press O
down to force the character to lowercase while it is
highlighted by the block cursor.)
Character Chart
Use this chart as a guide for entering spaces, numbers, letters,
symbols, and other characters with the tap method. Press and
hold a key to cycle between uppercase and lowercase characters.
Predictive Text Entry with iTAP™
Software
iTAP™ software provides a predictive text entry method that lets
you enter the letters of a word using only one keypress per letter.
1
space
. 1 ? ! , @ _ & : ; " - ( ) '
¿ ¡ % £ $ ¥
0 + - 0 x * / = > < # §
User.Guide.Tarpon.book Page 50 Saturday, June 23, 2001 5:03 PM
51
Entering Text
Preliminary
You must activate iTAP software prior to entering letters. You can
do this from any text entry screen by pressing M and selecting
the iTAP menu option.
Enter Words
To enter a word:
Do This To
1
Press a number
key one time
enter the first letter of the word
The letters associated with the key
you pressed are shown at the bottom
of the display.
2
Press number keys
(one per letter)
enter the rest of the word
Alternative words and letter
combinations are shown at the
bottom of the display based on the
keys you press. These word choices
are updated with each keypress.
3
When you have
entered all the
letters of the
word, press O
locate and highlight the word you
want
4
Press
SELECT ([)
add the highlighted word to the text
area at the top of the display
A space is automatically inserted
after the word.
User.Guide.Tarpon.book Page 51 Saturday, June 23, 2001 5:03 PM
Entering Text
52
Preliminary
Enter Novel Words
You may enter a word that is not in the iTAP software dictionary.
If you enter all the letters of a word but the word is not
displayed:
Do This To
1
Press DELETE ([)
one or more times
delete one or more letters until
you see a letter combination
that matches the start of the
word
2
Press Ohighlight the letter or letter
combination
3
Press SELECT ([),
then press O
shift the text entry cursor to the
left and “lock” the selected
portion of the word
4
Continue entering
letters and highlighting
letter combinations
spell the word
User.Guide.Tarpon.book Page 52 Saturday, June 23, 2001 5:03 PM
53
Preliminary
Menu Feature Descriptions
This chapter describes all of your Personal Communicator’s
features in order of the menu map shown on page 3. Some
descriptions also include page numbers where you can find more
detailed information. If you would like to learn more about a
specific feature, a reference guide for your Personal
Communicator is also available. To obtain a copy of the reference
guide or another copy of this user guide, see the Motorola Web
site at:
http://motorola.com/consumer/manuals
or contact the Motorola Customer Call Center at
1-800-331-6456 in the United States or 1-800-461-4575 in
Canada.
Main Menu Features
R
ECENT
C
ALLS
View the numbers of your recent dialed calls and received
calls. Press S to go directly to the dialed calls list from
the idle display.
Received Calls
M> Recent Calls
> Received Calls
View a list of recently received calls.
Your Personal Communicator keeps a list of the numbers
from calls you recently received, even if you did not answer.
You can scroll through the list until you find an entry you
want to call, store, or delete.
User.Guide.Tarpon.book Page 53 Saturday, June 23, 2001 5:03 PM
Menu Feature Descriptions
54
Preliminary
Dialed Calls
M> Recent Calls
> Dialed Calls
View a list of recently dialed calls. Your Personal
Communicator keeps a list of recently dialed phone
numbers, even if the calls did not connect. A < means the
call connected. You can scroll through the list until you find
an entry you want to call, store, or delete.
Notepad
M> Recent Calls
> Notepad
Stores the last phone number entered on the keypad. The
number may be the last number you called or a number you
entered during a phone call.
You can call the number on the notepad or you can store it
as part of a phonebook entry.
Call Times
M> Recent Calls
> Call Times
View call timers, which record
network connection time,
the
elapsed time from the moment you connect to your service
provider’s network to the moment you end the call by
pressing E.
The amount of network connection time you track
on your timer may not equal the amount of time for
which you are billed by your service provider. For
billing information, please contact your service
provider directly.
You can scroll through a list of five timers: Last Call, Dialed
Calls, Received Calls, All Calls, and Lifetime.
User.Guide.Tarpon.book Page 54 Saturday, June 23, 2001 5:03 PM
55
Menu Feature Descriptions
Preliminary
P
HONEBOOK
M> Phonebook
M> Phonebook Menu
Create and manage a personalized phonebook. You can call
numbers stored in the phonebook, and send text messages
to entries with email addresses.
Create a
phonebook
entry
Enter a name, phone number or email
address, and type indicator (such as
home
or
work
). The Personal
Communicator will assign a speed dial
number. See page 66.
Set up voice
dial
Record a voice name you can use to
dial a phone number by saying the
person’s name. See page 68.
Edit a
phonebook
entry
View and then update details of a
phonebook entry.
Dial a
phonebook
entry
Use the phonebook list, voice dial,
speed dial, or one-touch dial to call a
number or send a text message to an
email address. See pages 39 and 70.
Delete a
phonebook
entry
Use the Phonebook Menu to remove
outdated entries.
Check
phonebook
capacity
See how many of the phonebook’s
entries have been used (up to 400).
Sort phonebook
entries
Sort entries by speed dial number or
by name or voice dial.
User.Guide.Tarpon.book Page 55 Saturday, June 23, 2001 5:03 PM
Menu Feature Descriptions
56
Preliminary
Q
UICK
D
IAL
M> Quick Dial
Dial pre-programmed customer service numbers.
Your service provider may program one or more
quick dial numbers, such as the customer service number,
into your Personal Communicator. You can call them by
selecting them from the quick dial list.
Note: Your service provider may use a different name for
this feature.
R
ADIO
M> Radio
Listen to FM radio stations. This menu feature is
displayed only when the optional Motorola
Original™ FM Stereo Radio headset is plugged
into the accessory connector port on your Personal
Communicator. See “Radio” on page 71.
M
ESSAGES
M> Messages
Adjust message settings, view and manage the
various types of messages your Personal
Communicator can receive and/or send:
Voicemail Store and call the voicemail number
provided by your service provider. See
“Messages—Voicemail” on page 74.
Text Msgs Send and receive text messages. See
“Messages—Text” on page 27.
Browser Alerts Read alert messages received by your
micro-browser.
Quick Notes Select and send pre-written messages
from the quick notes list.
User.Guide.Tarpon.book Page 56 Saturday, June 23, 2001 5:03 PM
57
Menu Feature Descriptions
Preliminary
S
HORTCUTS
M> Shortcuts
Create keypad or voice shortcuts to menu features.
V
OICE
N
OTES
M> Voice Notes
Use the voice key to record and playback messages and
phone calls. See “Voice Notes” on page 76.
B
ROWSER
M> Browser
Access Web pages and run Web-based
applications.
The micro-browser delivers WAP (Wireless Application
Protocol) pages from your service provider directly to your
Personal Communicator. See “Micro-Browser” on page 78.
Settings Menu Features
R
ING
/V
IBRATE
Alert
M> Settings
> Ring/Vibrate
> Alert
Select a type of ring or vibration alert for incoming calls and
messages. See “Ring/Vibrate” on page 80.
Outbox View all outgoing text messages,
delivered and undelivered.
Drafts Store and edit text messages that you
have written but not sent.
User.Guide.Tarpon.book Page 57 Saturday, June 23, 2001 5:03 PM
Menu Feature Descriptions
58
Preliminary
Alert Detail
M> Settings
> Ring/Vibrate
>
Alert
Detail
Change details about the ring or vibration alert.
Alert
represents the name of the current alert setting. See “Ring/
Vibrate” on page 80.
P
HONE
S
TATUS
My Tel. Number
M> Settings
> Phone Status
> My Tel. Number
View, enter, and edit your name and phone number.
Battery Meter
M> Settings
> Phone Status
> Battery Meter
View a detailed battery charge meter.
Other Information
M> Settings
> Phone Status
> Other Information
View the Personal Communicator’s feature specifications (if
available from the service provider).
C
ONNECTION
Connect your Personal Communicator to a
computer or hand-held device to send and receive
data and fax calls on the connected device.
Connect your Personal Communicator using a serial cable
or USB cable. See:
http://www.motorola.com/
User.Guide.Tarpon.book Page 58 Saturday, June 23, 2001 5:03 PM
59
Menu Feature Descriptions
Preliminary
Incoming Call
M> Settings
> Connection
> Incoming Call
Specify the format for the next incoming call. You can select
Fax In Only, Data In Only, or Normal.
I
N-
C
ALL
S
ETUP
Use the in-call setup menu to set the features that are
active during a call, such as the in-call timer and call
answering options.
In-Call Timer
M> Settings
> In-Call Setup
> In-Call Timer
Adjust call timer display and beep settings. You can set your
timer to beep at a selected interval during your calls. (60
seconds is the default.) You can also turn on or off a display
timer during calls as follows:
Answer Options
M> Settings
> In-Call Setup
> Answer Options
Turn call answering options on or off:
Time Display the elapsed time for the
current call.
Off Hide the in-call timer.
Multi-Key Answer by pressing any key.
User.Guide.Tarpon.book Page 59 Saturday, June 23, 2001 5:03 PM
Menu Feature Descriptions
60
Preliminary
S
ECURITY
Change the four-digit unlock code and a six-digit security
code to prevent other users from accessing your personal
information or modifying your Personal Communicator
settings.
Phone Lock
M> Settings > Security
> Phone Lock
Lock and unlock your Personal Communicator. See “Locking
and Unlocking Your Personal Communicator” on page 83.
Lock Keypad
M> Settings > Security
> Lock Keypad
Lock and unlock your keypad to prevent accidental
keypresses that might inadvertently dial an emergency
number or one-touch dial number.
Lock Application
M> Settings > Security
> Lock Application
Lock and unlock specific Personal Communicator
applications (such as phonebook) so that users must enter
the unlock code before they can use the applications.
Restrict Calls
M> Settings > Security
> Restrict Calls
Restrict all incoming and outgoing calls, or restrict them to
numbers stored in your phonebook. A restricted incoming
call is treated as unanswered. Your Personal Communicator
displays Missed Calls and adds it to the received list.
You can still call emergency numbers when outgoing calls
are restricted. Your Personal Communicator still receives
incoming text messages when incoming calls are restricted.
User.Guide.Tarpon.book Page 60 Saturday, June 23, 2001 5:03 PM
61
Menu Feature Descriptions
Preliminary
New Passwords
M> Settings > Security
> New Passwords
Change your unlock code (originally set to 1234) or your
security code (originally set to 000000). See “Assigning a
New Code or Password” on page 83.
O
THER
S
ETTINGS
Use the other settings menu to view or adjust personal
options, the initial setup of your Personal Communicator,
how it connects to your service provider’s network, and the
setup of optional equipment needed for hands-free use.
Personalize
M> Settings
> Other Settings
> Personalize
Set several personal Personal Communicator options:
Main Menu Change the order of the main menu.
See “Reordering Menu Items” on
page 81.
Keys Change the functions of the soft keys
in the idle display. See “Customizing a
Soft Key Function” on page 82.
Greeting Change the text displayed when you
turn on your Personal Communicator.
Banner Change the text that appears in the
idle display.
Quick Dial Change quick dial number(s).
User.Guide.Tarpon.book Page 61 Saturday, June 23, 2001 5:03 PM
Menu Feature Descriptions
62
Preliminary
Initial Setup
M> Settings
> Other Settings
> Initial Setup
Set many basic Personal Communicator options:
Time and Date Set the Personal Communicator’s time
and date.
Auto PIN Dial Some networks require an
authenticating PIN to allow
outgoing calls. Use this
feature to automatically dial
your PIN.
Auto Redial Automatically redial calls that fail due
to busy network conditions.
Backlight Set the amount of time that the
display backlight remains on, or turn
off the backlight to conserve battery
power.
Zoom Switch between three lines
(Zoom Out) and two lines (Zoom In) of
display text.
Scroll Force the cursor to stop or wrap
around when it reaches the top or
bottom of a list in the display.
Animation Turn animation off (to conserve the
battery) or on. Animation makes your
Personal Communicator’s menus move
smoothly as you scroll up and down.
Language Set the language for menus.
User.Guide.Tarpon.book Page 62 Saturday, June 23, 2001 5:03 PM
63
Menu Feature Descriptions
Preliminary
Network
M> Settings
> Other Settings
> Network
View and adjust your Personal Communicator’s network
settings.
Your service provider registers your Personal Communicator
to a network. You can view information about the current
network, change how your Personal Communicator
searches for a network, and turn on/off alerts that indicate
when a call is dropped or network registration changes.
Contrast
Setting
Adjust your display contrast setting.
DTMF Switch DTMF tones or off.
Master Reset Reset all options to their original
factory settings
except
for the unlock
code, security code, and lifetime timer.
Master Clear Reset all options back to their original
factory settings
except
for the unlock
code, security code, and lifetime timer,
and
clear all user settings and entries.
Note: This option
erases all
user-entered information
stored in
your Personal Communicator’s
memory, including phonebook entries.
Once you erase the information, it
cannot be recovered.
User.Guide.Tarpon.book Page 63 Saturday, June 23, 2001 5:03 PM
Menu Feature Descriptions
64
Preliminary
Car Settings
M> Settings
> Other Settings
> Car Settings
Adjust hands-free settings for an optional
Motorola Original™ car kit (purchased separately).
Note: The use of wireless devices and their accessories may
be prohibited or restricted in certain areas. Always obey the
laws and regulations on the use of these products.
Headset
M> Settings
> Other Settings
> Headset
Set your Personal Communicator to automatically
answer calls after two rings when connected to a headset.
Auto Answer Set the car kit to automatically answer
calls after two rings.
Auto Handsfree Set your Personal Communicator to
detect and automatically route calls to
the car kit.
Power-Off Delay Specify the amount of time the car kit
delivers power to the Personal
Communicator after you switch off the
ignition.
Charger Time Specify the amount of time the car kit
uses your car battery to charge your
Personal Communicator after you
switch off the ignition.
User.Guide.Tarpon.book Page 64 Saturday, June 23, 2001 5:03 PM
65
Preliminary
Phonebook
You can store a list of names and phone numbers or email
addresses in your Personal Communicator’s electronic
phonebook. Your Personal Communicator can store up to 400
entries. You can view these entries and call them directly from
your Personal Communicator. For email addresses, you can send
a text message directly from your Personal Communicator.
To see the list of names stored in your phonebook, press
M > Phonebook from the idle display. Scroll to a name and
press VIEW ([) to view details of the phonebook entry as
shown in the following display.
Fields in a Phonebook Entry Form
$*Carlo Emrys
2154337215
Speed No.15
BACK EDIT
Entry’s phone
number or
email address
Type
indicator
identifies
number type:
$
Work
U
Home
S
Main
h
Mobile
Z
Fax
p
Pager
X
Email
Voice Name
indicator
indicates a recorded voice name Entry’s
Name
Edit
entry
Press
M
to open the
Phonebook
Menu
Return
to list
M
Entry’s speed
dial number
User.Guide.Tarpon.book Page 65 Saturday, June 23, 2001 5:03 PM
Phonebook
66
Preliminary
Storing a Phonebook Entry
A phone number is required for a phonebook entry. All other
information is optional.
Shortcut: Enter a phone number in the idle display, then press
STORE ([) to create a phonebook entry with the number in
the No. field.
Enter Information
Find the Feature
M> Phonebook
M> New
Press To
1
O scroll to Phone Number or
Email Address
2
SELECT ([)select the type of entry
3
CHANGE ([)select Name
4
keypad keys enter a name for the entry (see
“Entering Text” on page 48)
5
OK ([) store the name
6
CHANGE ([) select No. or Email
7
keypad keys enter phone number or email address
8
OK ([) store the number or address
9
CHANGE ([) select Type
Note: This option is not available for
email entries. When you enter an
email address, an [ (email) type
indicator is applied automatically .
User.Guide.Tarpon.book Page 66 Saturday, June 23, 2001 5:03 PM
67
Phonebook
Preliminary
10
O scroll to the type of phone number
11
SELECT ([) select the number type
12
RECORD ([)
or
Go to step 13 if
you don’t want to
record a voice
name.
record a voice name for the entry, if
desired
See “Recording a Voice Name For a
Phonebook Entry” on page 68.
13
Oscroll to Speed No., the number to
speed dial
the entry
The next available speed dial number
is assigned to a new phonebook
number by default.
14
CHANGE ([) select Speed No. if you want to
change it
15
keypad keys enter a different speed number, if
desired
16
OK ([) save the modified speed number
If your chosen speed number is
already assigned to another entry,
you are asked if you want to replace
that entry.
17
SELECT ([) select MORE if you want to create
another entry with the same Name
Note: You must enter a name and
number to use this option.
Press To
User.Guide.Tarpon.book Page 67 Saturday, June 23, 2001 5:03 PM
Phonebook
68
Preliminary
Complete Phonebook Entry
When you are finished entering information for a phonebook
entry:
Recording a Voice Name For a
Phonebook Entry
You can record a voice name when you create a new phonebook
entry or when you edit a previously stored phonebook entry. This
lets you use voice dial to call the number without dialing. (See
“Voice Dial” on page 70.)
Your Personal Communicator can store a total of 20 voice
names.
Tip: Record your voice name in a quiet location. Hold the
Personal Communicator about four inches (10 centimeters) from
your mouth, and speak directly into the microphone in a normal
tone of voice.
Press To
DONE ([) store the entry and return to the
phonebook list
Find the Feature
M> Phonebook
Do This To
1
Press O scroll to the desired entry
2
Press VIEW ([) display the entry’s detailed view
3
Press EDIT ([) edit the phonebook entry
4
Press O scroll to Voice Name
User.Guide.Tarpon.book Page 68 Saturday, June 23, 2001 5:03 PM
69
Phonebook
Preliminary
Dialing a Phonebook Entry
You can use the phonebook list, voice dial, speed dial, or
one-touch dial to call a number (or send a text message to an
email address) stored in your phonebook. To use speed dial, see
“Dialing With Speed Dial” on page 39. To use one-touch dial,
see “Dialing With One-Touch Dial” on page 39.
5
Press RECORD ([) begin the recording process
The Personal Communicator
displays Press Voice key then
say name.
6
Press and release the
voice key on the front
of your Personal
Communicator, and
speak the entry’s name
within two seconds
record the voice name
The Personal Communicator
displays Press Voice Key then
REPEAT name.
7
Press the voice key and
repeat the name
confirm the voice name
The Personal Communicator
displays Trained: Voice Name.
Do This To
User.Guide.Tarpon.book Page 69 Saturday, June 23, 2001 5:03 PM
Phonebook
70
Preliminary
Phonebook List
To call a number or send email to an entry in the phonebook list:
Voice Dial
To call a number or send an email using voice dial:
Find the Feature
M> Phonebook
Press To
1
Oscroll to the entry you want to call
2
Ssend the call (for a phone number)
or
open a new message form with the
entry’s address in the To field (for
email entries)
Do This Result
Press and release the
voice key, and speak the
entry’s name (within two
seconds).
Your Personal Communicator finds
the entry, repeats the voice name,
pauses two seconds, then places
the call (for a phone number) or
opens a new message form (for an
email address).
User.Guide.Tarpon.book Page 70 Saturday, June 23, 2001 5:03 PM
71
Preliminary
Radio
You can use your Personal Communicator to tune, store
presets, and listen to FM radio stations when the
optional Motorola Original™ FM Stereo Radio Headset
accessory is plugged into the Personal Communicator’s
accessory connector port.
Turning the Radio On and Off
Alternatively, you can use the following procedure:
Note: The Radio ([) soft key option and Radio menu feature
are displayed only when the FM Stereo Radio Headset is plugged
into the accessory connector port.
Press To
Radio ([) turn the radio on and off
Press To
1
M open the menu
2
O scroll to Radio
3
On ([) or Off ([) turn the radio on or off
User.Guide.Tarpon.book Page 71 Saturday, June 23, 2001 5:03 PM
Radio
72
Preliminary
Tuning a Station
Storing a Preset
To store a station to a preset that you can recall later:
Selecting a Preset
To select a preset radio station:
Do This To
Press O
or
Press and hold O
scroll up or down to the next frequency
scroll up or down to the next available
stereo station
Do This To
Press and hold a number
key (1 to 9)
assign its preset number to the
tuned station
Press To
a number key (1 to 9) tune the station stored at that
preset location
User.Guide.Tarpon.book Page 72 Saturday, June 23, 2001 5:03 PM
73
Radio
Preliminary
Sending and Receiving Calls With the
Radio On
Your Personal Communicator interrupts the radio signal and
rings or vibrates as usual to notify you of an incoming call,
message, or other event. When you receive a call:
To end the call and resume the FM broadcast:
Turn the radio off before dialing outgoing calls. You do not have
to turn off the FM radio feature to dial emergency numbers or
numbers selected from your phonebook or other lists.
Tip: To dial a recently called number, press S or the button
on the FM Stereo Radio Headset microphone to go to the dialed
calls list.
Do This To
Press IGNORE ([) ignore the call
Press ANSWER ([)
or
Press the button on the
FM Stereo Radio Headset
microphone
answer the call
Note: You can use the FM
Stereo Radio Headset
microphone to converse with
the other party during a call.
Do This To
Press E
or
Press and hold the button
on the headset microphone
end the call
User.Guide.Tarpon.book Page 73 Saturday, June 23, 2001 5:03 PM
74
PRELIMINARY
Messages—Voicemail
You can listen to your voicemail messages by calling
your network voicemail phone number. Voicemail
messages are stored on the network—not on your
Personal Communicator. Contact your service provider
for more details.
Storing Your Voicemail Number
Store your voicemail number in your Personal Communicator to
make it faster and easier to use voicemail. Your voicemail
number is provided by your service provider.
Receiving a New Voicemail Message
When you receive a voicemail message, your Personal
Communicator displays New VoiceMail &. (Some networks
only indicate when you have messages, whether they are new or
not.) If reminders are turned on, your Personal Communicator
sends a reminder every five minutes until you close the new
message notification, listen to the message, or turn off your
Personal Communicator.
Find the Feature
M> Messages
M> VoiceMail Setup
Press To
1
keypad keys enter the phone number for your
voicemail
2
OK ([) store the number
User.Guide.Tarpon.book Page 74 Saturday, June 23, 2001 5:03 PM
75
Messages—Voicemail
PRELIMINARY
From the new message notification:
Listening to a Voicemail Message
To listen to your voicemail messages at any time:
Your Personal Communicator calls the voicemail phone number
you stored. If you do not have a voicemail number stored, the
Personal Communicator guides you through storing a number.
Do This To
Press CALL ([) call your voicemail phone number
and listen to the message
Find the Feature
M> Messages > VoiceMail
User.Guide.Tarpon.book Page 75 Saturday, June 23, 2001 5:03 PM
76
PRELIMINARY
Voice Notes
The voice note feature lets you record personal messages. You
can play back a voice note at any time.
There are no pre-recorded voice notes on your Personal
Communicator.
Recording a Voice Note
Your Personal Communicator can store a total of two minutes of
voice note recordings. (That is, the combined recording time of
all voice notes cannot exceed two minutes.)
Use this procedure to record a voice note when the idle display is
visible, or use it during a Personal Communicator call to record
the call. Your Personal Communicator plays an alert tone to
notify the other party that the call is being recorded.
Note: Recording phone calls is subject to varying state and
federal laws regarding privacy and recording of conversations.
Tip: Record your voice note in a quiet location. Hold the
Personal Communicator about four inches (10 centimeters) from
your mouth and speak directly into its microphone in a normal
tone of voice.
Do This Result
1
Press and hold the voice
key on the front of your
Personal Communicator for
the duration of the
recording.
A tone sounds in the
earpiece and the Personal
Communicator displays the
Recording Voice Note
message.
User.Guide.Tarpon.book Page 76 Saturday, June 23, 2001 5:03 PM
77
Voice Notes
PRELIMINARY
Playing a Voice Note
To play a recorded voice note:
When a Motorola Original™ headset accessory or FM radio
headset accessory is attached to your Personal Communicator,
voice note playback is automatically routed to the headset.
Tip: You can play a voice note while taking a call. It won’t be
transmitted to the other party.
2
Speak your voice message
into the Personal
Communicator.
The Personal Communicator
records the message and
displays a recording timer.
3
Release the voice key to
stop recording.
The Personal Communicator
displays the voice notes list
number and the total
recording time.
Find the Feature
M> Voice Notes
Press To
1
O scroll to the voice note
2
PLAY ([) play the voice note
Do This Result
User.Guide.Tarpon.book Page 77 Saturday, June 23, 2001 5:03 PM
78
PRELIMINARY
Micro-Browser
The micro-browser enables you to access Web pages
on your Personal Communicator. Contact your service
provider to set up access, if necessary.
Starting a Micro-Browser Session
To open the micro-browser:
The micro-browser displays the home page set up by your service
provider.
Shortcut: If you open a text message with a Web address (URL)
in it, you can go directly to the URL by selecting M > Go To.
If you are unable to establish a network connection with the
micro-browser, contact your service provider.
Find the Feature
M> Browser
Press To
1
O scroll to a bookmark or service
2
SELECT ([) select the service
User.Guide.Tarpon.book Page 78 Saturday, June 23, 2001 5:03 PM
79
Micro-Browser
PRELIMINARY
Interacting With Web Pages
You can perform the following operations on a Web page:
Do This To
Press Oscroll through a text message
Press O and then
SELECT ([)
scroll through and select items in a
list
Press keypad keys
and then OK ([)
enter requested information
Press O to scroll to a
phone number on a Web
page, then press N
call the number from the
micro-browser
Press Ogo back to the previous Web page
User.Guide.Tarpon.book Page 79 Saturday, June 23, 2001 5:03 PM
80
Preliminary
Adjusting Your Settings
You can adjust a wide variety of Personal Communicator settings
to suit your needs.
Ring/Vibrate
Your Personal Communicator rings or vibrates to notify you of an
incoming call, message, or other event. This ring or vibration is
called an
alert
. You can use a standard alert for all events, or set
different alert types for different events. The alert setting
indicator in your display shows the current standard alert setting:
Select a Ring/Vibration for All Events
w Loud ring x Soft ring
y Vibrate u Ring and vibrate
t Silent
Find the Feature
M> Settings > Ring/Vibrate
> Alert
Press To
1
O scroll to the alert you want to use
2
SELECT ([) select the alert
The Personal Communicator displays
the Changed: Alert message.
User.Guide.Tarpon.book Page 80 Saturday, June 23, 2001 5:03 PM
81
Adjusting Your Settings
Preliminary
Select a Ring/Vibration for a Specific Event
You can select the alert that your Personal Communicator uses
for a specific event (such as an incoming call) from 32 different
preset tones and vibrations. When you select a ring or vibration
alert for a
specific
event, it overrides the default alert set for
all
events.
Tip: This feature also lets you set the ringer volume and keypad
volume.
Reordering Menu Items
You can customize the order of the items in your Personal
Communicator’s main menu, depending upon your usage.
Find the Feature
M> Settings > Ring/Vibrate
>
Alert
Detail
Press To
1
O scroll to the event for which you want
to set a new alert
2
CHANGE ([) select the event
The Personal Communicator displays
the list of available alerts.
3
O scroll to the alert you want for the
event
4
SELECT ([) select the alert
The Personal Communicator displays
the Changed:
Event Alert
message.
User.Guide.Tarpon.book Page 81 Saturday, June 23, 2001 5:03 PM
Adjusting Your Settings
82
Preliminary
Customizing a Soft Key Function
You can relabel the soft keys to access different main menu items
from the idle display.
Find the Feature
M> Settings
> Other Settings
> Personalize > Main Menu
Press To
1
O scroll to the menu item you want to
move
2
GRAB ([) grab the menu item you want to
move
3
O move the item up or down the menu
4
INSERT ([) insert the item in the new location
Find the Feature
M> Settings > Other Settings
> Personalize > Keys
Press To
1
O scroll to Left or Right
2
CHANGE ([) open the key editor
3
O scroll to the new key function
4
CHANGE ([) confirm the new function
The key will have the new function
whenever the Personal
Communicator is idle.
User.Guide.Tarpon.book Page 82 Saturday, June 23, 2001 5:03 PM
83
PRELIMINARY
Security
Assigning a New Code or Password
Your Personal Communicator’s four-digit unlock code is
originally set to 1234, and the six-digit security code to 000000,
at the factory. Your service provider may reset these numbers
before you receive your Personal Communicator.
If your service provider has
not
reset these numbers, you should
change them to prevent other users from accessing your
personal information or modifying your Personal Communicator
settings. The unlock code must contain four digits, and the
security code must contain six digits. Be sure to make a note of
the new numbers.
Locking and Unlocking Your Personal
Communicator
You can lock your Personal Communicator manually or set your
Personal Communicator to lock automatically whenever you turn
it off.
When you try to use a locked Personal Communicator, it asks you
to enter the unlock code. A locked Personal Communicator still
rings or vibrates for incoming calls or messages,
but you must
unlock it to answer
.
You can make emergency calls on your Personal Communicator
even when it is locked. See “Dialing an Emergency Number
When the Personal Communicator Is Locked” on page 38.
User.Guide.Tarpon.book Page 83 Saturday, June 23, 2001 5:03 PM
Security
84
PRELIMINARY
Locking Manually
Locking Automatically
You can set your Personal Communicator to lock every time you
turn it off:
Find the Feature
M> Settings > Security
> Phone Lock > Lock Now
Press To
1
keypad keys enter your four-digit unlock code
2
OK ([) lock the Personal Communicator
Find the Feature
M> Settings > Security
> Phone Lock
> Automatic Lock > On
Press To
1
keypad keys enter your four-digit unlock code
2
OK ([) set the Personal Communicator to
lock automatically
User.Guide.Tarpon.book Page 84 Saturday, June 23, 2001 5:03 PM
85
Security
PRELIMINARY
Unlock Your Personal Communicator
At the Enter Unlock Code prompt:
Locking and Unlocking Your Keypad
You can lock your Personal Communicator keypad to prevent
accidental use. This feature is useful in situations where an
accidental keypress might inadvertently dial an emergency
number or one-touch dial number (for example, when carrying
your Personal Communicator in a purse or pocket).
Note: Incoming calls and messages unlock the keypad.
Press To
1
keypad keys enter your four-digit unlock code
The unlock code is originally set to
1234.
2
OK ([) unlock your Personal Communicator
Press To
M *lock or unlock your keypad
User.Guide.Tarpon.book Page 85 Saturday, June 23, 2001 5:03 PM
Security
86
PRELIMINARY
User.Guide.Tarpon.book Page 86 Saturday, June 23, 2001 5:03 PM
87
PRELIMINARY
Troubleshooting
Check these questions first if you have problems with your
Personal Communicator:
Question Answer
Is your Personal
Communicator
set up correctly?
Press M #. If you do not see your
phone number, contact your service
provider.
Is your battery
charged? Do you
see B in the
display?
The battery level indicator should have
at least one segment showing (C). If
it does not, recharge your battery. (See
“Charging the Battery” on page 18 and
“Battery Use” on page 25.)
Does the handset
have a signal?
Do you see j in
the display?
Make sure that your antenna is fully
extended (if applicable). The signal
strength indicator should have at least
one segment showing (1). If it does
not, move to an area with a stronger
signal to use your Personal
Communicator.
Is the earpiece
volume too low
or does the
Personal
Communicator
not ring?
Press the upper volume key on the front
of the Personal Communicator.
User.Guide.Tarpon.book Page 87 Saturday, June 23, 2001 5:03 PM
Troubleshooting
88
PRELIMINARY
The following refer to specific problems:
Has the Personal
Communicator
been damaged,
dropped, or
gotten wet?
Dropping your Personal Communicator,
getting it wet, or using a non-Motorola
battery or battery charger can damage
the Personal Communicator. The
Personal Communicator’s limited
warranty does not cover liquid damage
or damage caused from using
non-Motorola accessories.
Was a
non-Motorola
battery or
battery charger
used?
Problem Solution
I pressed the
power key, but
nothing
happened.
Be sure to press and hold P the power
key until the display appears and you
hear an audible alert (this could take a
couple of seconds). If nothing happens,
check that a charged battery is
installed. (See “Installing the Battery”
on page 17.)
The display says:
Enter Unlock
Code. How do I
unlock my
Personal
Communicator?
Enter the factory-preset unlock code
(1234), or the last four digits of your
phone number. (See “Locking and
Unlocking Your Personal
Communicator” on page 83.) If this
fails, call your service provider (the
company that sends you your monthly
wireless service bill).
Question Answer
User.Guide.Tarpon.book Page 88 Saturday, June 23, 2001 5:03 PM
89
Troubleshooting
PRELIMINARY
I cannot send/
receive calls.
Make sure that you have a phone signal
(see the “Signal Strength Indicator”
item on page 23). Avoid electrical or
radio interference, and obstructions
such as bridges, parking garages, or tall
buildings.
Your Personal Communicator also may
have the Restrict Calls feature
turned on. If you know the unlock code,
you can change this setting in the
security menu (M > Settings >
Security).
I cannot open my
inbox.
Before you can use text or information
services messages, you must set up the
appropriate inbox. See “Setting Up the
Text Message Inbox” on page 27.
My Personal
Communicator’s
display is too
dark.
You can use the Contrast Setting
feature (see page 63) to change the
level of contrast in your Personal
Communicator display.
You can also use the Backlight feature
(see page 62) to change the length of
time that your Personal Communicator’s
backlight display stays on.
Problem Solution
User.Guide.Tarpon.book Page 89 Saturday, June 23, 2001 5:03 PM
Troubleshooting
90
PRELIMINARY
I am unable to
record a voice
note or voice
name.
Try moving to a quieter location to make
your voice recording. Hold the Personal
Communicator about four inches (10
centimeters) away from your mouth,
and speak directly into your Personal
Communicator’s microphone in a
normal tone of voice.
I launched the
micro-browser
but the display
says: Service Not
Available.
You may be in an area without service.
If you have wireless service, look in the
display for the digital signal indicator
(F). If you do not see the indicator, you
may be in an area that has only analog
service or no service at all. If you see the
digital signal indicator, you may be
connected to a digital network that
does not support Internet access.
I launched the
micro-browser
but the display
says: Data Server
Unavailable.
Try again in a few minutes. The servers
may be temporarily busy.
Problem Solution
User.Guide.Tarpon.book Page 90 Saturday, June 23, 2001 5:03 PM
PRELIMINARY
91
Specific Absorption Rate
Data
This model phone meets the government’s
requirements for exposure to radio waves.
Your wireless phone is a radio transmitter and receiver. It is
designed and manufactured not to exceed limits for exposure to
radio frequency (RF) energy set by the U.S. Federal
Communications Commission for the United States and by
Health Canada for Canada. These limits are part of
comprehensive guidelines and establish permitted levels of RF
energy for the general population. The guidelines are based on
standards that were developed by independent scientific
organizations through periodic and thorough evaluation of
scientific studies. The standards include a substantial safety
margin designed to assure the safety of all persons, regardless of
age or health.
The exposure standard for wireless mobile phones employs a
unit of measurement known as the Specific Absorption Rate, or
SAR. The SAR limit set by the FCC and by Health Canada is 1.6
W/kg.1 Tests for SAR are conducted using standard operating
positions accepted by the FCC and by Industry Canada with the
phone transmitting at its highest certified power level in all
tested frequency bands. Although the SAR is determined at the
highest certified power level, the actual SAR level of the phone
while operating can be well below the maximum value. This is
because the phone is designed to operate at multiple power
levels so as to use only the power required to reach the network.
User.Guide.Tarpon.book Page 91 Saturday, June 23, 2001 5:03 PM
PRELIMINARY
92
In general, the closer you are to a wireless base station antenna,
the lower the power output.
Before a phone model is available for sale to the public in the
U.S. and Canada, it must be tested and certified to the FCC and
Industry Canada that it does not exceed the limit established by
each government for safe exposure. The tests are performed in
positions and locations (e.g., at the ear and worn on the body)
reported to the FCC and available for review by Industry Canada.
The highest SAR value for this model phone when tested for use
at the ear is 1.27 W/kg2, and when worn on the body, as
described in this user guide, is 1.24 W/kg.2 (Body-worn
measurements differ among phone models, depending upon
available accessories and regulatory requirements). While there
may be differences between the SAR levels of various phones
and at various positions, they all meet the governmental
requirements for safe exposure.
The FCC and Industry Canada have granted an Equipment
Authorization for this model phone with all reported SAR levels
evaluated as being in compliance with the FCC and Health
Canada RF exposure guidelines. SAR information on this model
phone is on file with the FCC and can be found under the Display
Grant section of:
http://www.fcc.gov/oet/fccid
after searching on FCC ID IHDT56AS1. You may also refer to
Motorola’s Web site:
http://www.motorola.com/rfhealth
User.Guide.Tarpon.book Page 92 Saturday, June 23, 2001 5:03 PM
PRELIMINARY
93
Additional information on Specific Absorption Rates (SAR) can
be found on the Cellular Telecommunications & Internet
Association (CTIA) Web site:
http://phonefacts.net
or the Canadian Wireless Telecommunications Association
(CWTA) Web site:
http://www.cwta.ca
1. In the United States and Canada, the SAR limit for mobile phones used by
the public is 1.6 watts/kg (W/kg) averaged over one gram of tissue. The
standard incorporates a substantial margin of safety to give additional
protection for the public and to account for any variations in measurements.
2. Additional related information includes the Motorola testing protocol,
assessment procedure, and measurement uncertainty range for this
product.
ITC01-064
User.Guide.Tarpon.book Page 93 Saturday, June 23, 2001 5:03 PM
94
PRELIMINARY
The U.S. Food and Drug
Administration's Center for Devices
and Radiological Health Consumer
Update on Mobile Phones
FDA Update
FDA has been receiving inquiries about the safety of mobile
phones, including cellular phones and PCS phones. The following
summarizes what is known—and what remains unknown—
about whether these products can pose a hazard to health, and
what can be done to minimize any potential risk. This
information may be used to respond to questions.
Why the concern?
Mobile phones emit low levels of radio frequency energy (i.e.,
radio frequency radiation) in the microwave range while being
used. They also emit very low levels of radio frequency energy
(RF), considered non-significant, when in the stand-by mode. It
is well known that high levels of RF can produce biological
damage through heating effects (this is how your microwave
oven is able to cook food). However, it is not known whether, to
what extent, or through what mechanism, lower levels of RF
might cause adverse health effects as well. Although some
research has been done to address these questions, no clear
picture of the biological effects of this type of radiation has
emerged to date. Thus, the available science does not allow us to
conclude that mobile phones are absolutely safe, or that they are
unsafe. However, the available scientific evidence does not
demonstrate any adverse health effects associated with the use
of mobile phones.
User.Guide.Tarpon.book Page 94 Saturday, June 23, 2001 5:03 PM
95
PRELIMINARY
What kinds of phones are in question?
Questions have been raised about hand-held mobile phones, the
kind that have a built-in antenna that is positioned close to the
user's head during normal telephone conversation. These types
of mobile phones are of concern because of the short distance
between the phone's antenna—the primary source of the RF—
and the person's head. The exposure to RF from mobile phones
in which the antenna is located at greater distances from the
user (on the outside of a car, for example) is drastically lower
than that from hand-held phones, because a person's RF
exposure decreases rapidly with distance from the source. The
safety of so-called “cordless phones,” which have a base unit
connected to the telephone wiring in a house and which operate
at far lower power levels and frequencies, has not been
questioned.
How much evidence is there that hand-held mobile
phones might be harmful?
Briefly, there is not enough evidence to know for sure, either
way; however, research efforts are on-going. The existing
scientific evidence is conflicting and many of the studies that
have been done to date have suffered from flaws in their
research methods. Animal experiments investigating the effects
of RF exposures characteristic of mobile phones have yielded
conflicting results. A few animal studies, however, have
suggested that low levels of RF could accelerate the
development of cancer in laboratory animals. In one study, mice
genetically altered to be predisposed to developing one type of
cancer developed more than twice as many such cancers when
they were exposed to RF energy compared to controls. There is
much uncertainty among scientists about whether results
obtained from animal studies apply to the use of mobile phones.
User.Guide.Tarpon.book Page 95 Saturday, June 23, 2001 5:03 PM
96
PRELIMINARY
First, it is uncertain how to apply the results obtained in rats and
mice to humans. Second, many of the studies that showed
increased tumor development used animals that had already
been treated with cancer-causing chemicals, and other studies
exposed the animals to the RF virtually continuously—up to 22
hours per day.
For the past five years in the United States, the mobile phone
industry has supported research into the safety of mobile
phones. This research has resulted in two findings in particular
that merit additional study:
1
In a hospital-based, case-control study, researchers looked
for an association between mobile phone use and either
glioma (a type of brain cancer) or acoustic neuroma (a
benign tumor of the nerve sheath). No statistically
significant association was found between mobile phone
use and acoustic neuroma. There was also no association
between mobile phone use and gliomas when all types of
types of gliomas were considered together. It should be
noted that the average length of mobile phone exposure in
this study was less than three years.
When 20 types of glioma were considered separately,
however, an association was found between mobile phone
use and one rare type of glioma, neuroepithelliomatous
tumors. It is possible with multiple comparisons of the same
sample that this association occurred by chance. Moreover,
the risk did not increase with how often the mobile phone
was used, or the length of the calls. In fact, the risk actually
decreased with cumulative hours of mobile phone use.
Most cancer causing agents increase risk with increased
exposure. An ongoing study of brain cancers by the
User.Guide.Tarpon.book Page 96 Saturday, June 23, 2001 5:03 PM
97
PRELIMINARY
National Cancer Institute is expected to bear on the
accuracy and repeatability of these results.1
2
Researchers conducted a large battery of laboratory tests to
assess the effects of exposure to mobile phone RF on
genetic material. These included tests for several kinds of
abnormalities, including mutations, chromosomal
aberrations, DNA strand breaks, and structural changes in
the genetic material of blood cells called lymphocytes. None
of the tests showed any effect of the RF except for the
micronucleus assay, which detects structural effects on the
genetic material. The cells in this assay showed changes
after exposure to simulated cell phone radiation, but only
after 24 hours of exposure. It is possible that exposing the
test cells to radiation for this long resulted in heating. Since
this assay is known to be sensitive to heating, heat alone
could have caused the abnormalities to occur. The data
already in the literature on the response of the
micronucleus assay to RF are conflicting. Thus, follow-up
research is necessary.2
FDA is currently working with government, industry, and
academic groups to ensure the proper follow-up to these
industry-funded research findings. Collaboration with the
Cellular Telecommunications Industry Association (CTIA) in
particular is expected to lead to FDA providing research
recommendations and scientific oversight of new CTIA-funded
research based on such recommendations.
Two other studies of interest have been reported recently in the
literature:
1
Two groups of 18 people were exposed to simulated mobile
phone signals under laboratory conditions while they
User.Guide.Tarpon.book Page 97 Saturday, June 23, 2001 5:03 PM
98
PRELIMINARY
performed cognitive function tests. There were no changes
in the subjects' ability to recall words, numbers, or pictures,
or in their spatial memory, but they were able to make
choices more quickly in one visual test when they were
exposed to simulated mobile phone signals. This was the
only change noted among more than 20 variables
compared.3
2
In a study of 209 brain tumor cases and 425 matched
controls, there was no increased risk of brain tumors
associated with mobile phone use. When tumors did exist in
certain locations, however, they were more likely to be on
the side of the head where the mobile phone was used.
Because this occurred in only a small number of cases, the
increased likelihood was too small to be statistically
significant.4
In summary, we do not have enough information at this point to
assure the public that there are, or are not, any low incident
health problems associated with use of mobile phones. FDA
continues to work with all parties, including other federal
agencies and industry, to assure that research is undertaken to
provide the necessary answers to the outstanding questions
about the safety of mobile phones.
What is known about cases of human cancer that
have been reported in users of hand-held mobile
phones?
Some people who have used mobile phones have been
diagnosed with brain cancer. But it is important to understand
that this type of cancer also occurs among people who have not
used mobile phones. In fact, brain cancer occurs in the U.S.
population at a rate of about 6 new cases per 100,000 people
User.Guide.Tarpon.book Page 98 Saturday, June 23, 2001 5:03 PM
99
PRELIMINARY
each year. At that rate, assuming 80 million users of mobile
phones (a number increasing at a rate of about 1 million per
month), about 4800 cases of brain cancer would be expected
each year among those 80 million people, whether or not they
used their phones. Thus it is not possible to tell whether any
individual's cancer arose because of the phone, or whether it
would have happened anyway. A key question is whether the
risk of getting a particular form of cancer is greater among
people who use mobile phones than among the rest of the
population. One way to answer that question is to compare the
usage of mobile phones among people with brain cancer with
the use of mobile phones among appropriately matched people
without brain cancer. This is called a case-control study. The
current case-control study of brain cancers by the National
Cancer Institute, as well as the follow-up research to be
sponsored by industry, will begin to generate this type of
information.
What is FDA's role concerning the safety of mobile
phones?
Under the law, FDA does not review the safety of radiation-
emitting consumer products such as mobile phones before
marketing, as it does with new drugs or medical devices.
However, the agency has authority to take action if mobile
phones are shown to emit radiation at a level that is hazardous
to the user. In such a case, FDA could require the manufacturers
of mobile phones to notify users of the health hazard and to
repair, replace or recall the phones so that the hazard no longer
exists.
Although the existing scientific data do not justify FDA
regulatory actions at this time, FDA has urged the mobile phone
User.Guide.Tarpon.book Page 99 Saturday, June 23, 2001 5:03 PM
100
PRELIMINARY
industry to take a number of steps to assure public safety. The
agency has recommended that the industry:
• support needed research into possible biological effects of
RF of the type emitted by mobile phones
• design mobile phones in a way that minimizes any RF
exposure to the user that is not necessary for device
function
• cooperate in providing mobile phone users with the best
possible information on what is known about possible
effects of mobile phone use on human health
At the same time, FDA belongs to an interagency working group
of the federal agencies that have responsibility for different
aspects of mobile phone safety to ensure a coordinated effort at
the federal level. These agencies are:
• National Institute for Occupational Safety and Health
• Environmental Protection Agency
• Federal Communications Commission
• Occupational Health and Safety Administration
• National Telecommunications and Information
Administration
The National Institutes of Health also participates in this group.
In the absence of conclusive information about any
possible risk, what can concerned individuals do?
If there is a risk from these products—and at this point we do
not know that there is—it is probably very small. But if people
are concerned about avoiding even potential risks, there are
simple steps they can take to do so. For example, time is a key
User.Guide.Tarpon.book Page 100 Saturday, June 23, 2001 5:03 PM
101
PRELIMINARY
factor in how much exposure a person receives. Those persons
who spend long periods of time on their hand-held mobile
phones could consider holding lengthy conversations on
conventional phones and reserving the hand-held models for
shorter conversations or for situations when other types of
phones are not available.
People who must conduct extended conversations in their cars
every day could switch to a type of mobile phone that places
more distance between their bodies and the source of the RF,
since the exposure level drops off dramatically with distance. For
example, they could switch to:
• a mobile phone in which the antenna is located outside the
vehicle
• a hand-held phone with a built-in antenna connected to a
different antenna mounted on the outside of the car or built
into a separate package
• a headset with a remote antenna to a mobile phone carried
at the waist
Again, the scientific data do not demonstrate that mobile
phones are harmful. But if people are concerned about the radio
frequency energy from these products, taking the simple
precautions outlined above can reduce any possible risk.
Where can I find additional information?
For additional information, see the following Web sites:
User.Guide.Tarpon.book Page 101 Saturday, June 23, 2001 5:03 PM
102
PRELIMINARY
Federal Communications Commission (FCC) RF Safety
Program (select “Information on Human Exposure to RF Fields
from Cellular and PCS Radio Transmitters”):
http://www.fcc.gov/oet/rfsafety
World Health Organization (WHO) International Commission
on Non-Ionizing Radiation Protection (select Qs & As):
http://www.who.int/emf
United Kingdom, National Radiological Protection
Board:
http://www.nrpb.org.uk
Cellular Telecommunications Industry Association (CTIA):
http://www.wow-com.com
U.S. Food and Drug Administration (FDA) Center for Devices
and Radiological Health:
http://www.fda.gov/cdrh/consumer/
1. Muscat et al. Epidemiological Study of Cellular Telephone Use and
Malignant Brain Tumors. In: State of the Science Symposium;1999 June 20;
Long Beach, California.
2. Tice et al. Tests of mobile phone signals for activity in genotoxicity and other
laboratory assays. In: Annual Meeting of the Environmental Mutagen
Society; March 29, 1999, Washington, D.C.; and personal communication,
unpublished results.
3. Preece, AW, Iwi, G, Davies-Smith, A, Wesnes, K, Butler, S, Lim, E, and Varey,
A. Effect of a 915-MHz simulated mobile phone signal on cognitive function
in man. Int. J. Radiat. Biol., April 8, 1999.
4. Hardell, L, Nasman, A, Pahlson, A, Hallquist, A and Mild, KH. Use of cellular
telephones and the risk for brain tumors: a case-control study. Int. J. Oncol.,
15: 113-116, 1999.
FDA020400
User.Guide.Tarpon.book Page 102 Saturday, June 23, 2001 5:03 PM
103
PRELIMINARY
Warranty
Limited Warranty for Motorola Personal
Communications Products Purchased in the United
States and Canada
I. What This Warranty Covers
• Products. Defects in materials and workmanship in wireless
cellular telephones, pagers, and/or two-way radios, and
certain accessories that are sold with them, such as the
battery, battery charger and holster manufactured and/or
sold by Motorola (Products).
• Batteries. Defects in materials and workmanship in
batteries that are manufactured by Motorola and/or sold
with Products are covered by this warranty only if the fully-
charged capacity falls below 80% of rated capacity or they
leak.
• Software. Physical defects in the media that tangibly
embodies each copy of any software supplied with the
Products.
II. What the Period of Coverage Is
From the date the Products are purchased by the first end-user:
• Products. The warranty is for one year. Exception: The
warranty for Spirit GT series and Talkabout series two-way
radio accessories is for 90 days.
• Software. The warranty is for 90 days.
• Repairs/Replacements. The warranty is for the balance of
the original warranty or for 90 days from the date you
receive it, whichever is longer.
User.Guide.Tarpon.book Page 103 Saturday, June 23, 2001 5:03 PM
Warranty
104
PRELIMINARY
III. Who is Covered
This warranty extends to the first end-user purchaser, only.
IV. What We Will Do to Correct Warranty Problems
At no charge to you, we have the option to repair or replace the
Products or software that do not conform to the warranty, or to
refund the Products’ purchase price. We may use functionally
equivalent reconditioned/refurbished/pre-owned or new
Products or parts. No software updates are provided.
V. How to Get Warranty Service
Please call:
You will receive instructions on how to ship the Products to
Motorola. You must ship the Products to us with freight, duties
and insurance prepaid. Along with the Products you must
include: (a) a copy of your receipt, bill of sale or other
comparable proof of purchase; (b) a written description of the
problem; (c) the name of your service provider (if this Product
requires subscription service); (d) the name and location of the
installation facility (if applicable) and, most importantly; (e) your
address and telephone number. If requested, you must also
USA
Cellular 1-800-331-6456
Paging 1-800-548-9954
Two-Way 1-800-353-2729
TTY (Text Telephone) 1-888-390-6456
Canada
All Products 1-800-461-4575
TTY (Text Telephone) 1-888-390-6456
User.Guide.Tarpon.book Page 104 Saturday, June 23, 2001 5:03 PM
105
Warranty
PRELIMINARY
return all detachable parts such as antennas, batteries and
chargers. RETAIN YOUR ORIGINAL PROOF OF PURCHASE.
We will ship repaired or replacement Products at our expense for
the freight and insurance, but at your expense for any duties. If
additional information is needed, please contact us at the
telephone number listed above.
VI. What This Warranty Does Not Cover
• Products that are operated in combination with ancillary or
peripheral equipment or software not furnished by
Motorola for use with the Products (“ancillary equipment”),
or any damage to the Products or ancillary equipment as a
result of such use. Among other things, “ancillary
equipment” includes batteries, chargers, adaptors, and
power supplies not manufactured or supplied by Motorola.
Any of these voids the warranty.
• Someone other than Motorola (or its authorized service
centers) tests, adjusts, installs, maintains, alters, modifies or
services the Products in any way. Any of these voids the
warranty.
• Rechargeable batteries that: (a) are charged by other than
the Motorola-approved battery charger specified for
charging such batteries; (b) have any broken seals or show
evidence of tampering; (c) are used in equipment other
than the Product for which they are specified; or (d) are
charged and stored at temperatures greater than 60
degrees centigrade. Any of these voids the warranty.
• Products that have: (a) serial numbers or date tags that
have been removed, altered or obliterated; (b) board serial
numbers that do not match each other, or board serial
numbers that do not match the housing; or (c)
User.Guide.Tarpon.book Page 105 Saturday, June 23, 2001 5:03 PM
Warranty
106
PRELIMINARY
nonconforming or non-Motorola housings or parts. Any of
these voids the warranty.
• Defects or damage that result from: (a) use of the Products
in a manner that is not normal or customary; (b) improper
operation or misuse; (c) accident or neglect such as
dropping the Products onto hard surfaces; (d) contact with
water, rain, extreme humidity or heavy perspiration; (e)
contact with sand, dirt or the like; or (f) contact with
extreme heat, or spills of food or liquid.
• Physical damage to the surface of the Products, including
scratches, cracks or other damage to a display screen, lens
or other externally exposed parts.
• Failure of Products that is due primarily to any
communication service or signal you may subscribe to or
use with the Products.
• Coil cords that are stretched or that have any broken
modular tabs.
• Products that are leased.
Flat-rate repair rates may apply to Products not covered by this
warranty. To obtain information about Products needing repairs
that are not covered by this warranty, please call the telephone
number previously listed. We will provide information on repair
availability, rates, methods of payment, where to send the
Products, etc.
VII. Some Other Limitations
This is Motorola’s complete warranty for the Products,
and states your exclusive remedies. This warranty is
given in lieu of all other express warranties. Implied
warranties, including without limitation, the implied
warranties of merchantability and fitness for a
User.Guide.Tarpon.book Page 106 Saturday, June 23, 2001 5:03 PM
107
Warranty
PRELIMINARY
particular purpose, are given only if specifically
required by applicable law. Otherwise, they are
specifically excluded.
No warranty is made as to coverage, availability, or
grade of service provided by the Products, whether
through a service provider or otherwise.
No warranty is made that the software will meet your
requirements or will work in combination with any
hardware or applications software products provided
by third parties, that the operation of the software
products will be uninterrupted or error free, or that all
defects in the software products will be corrected.
In no event shall Motorola be liable, whether in
contract or tort (including negligence) for damages in
excess of the purchase price of the Product, or for any
indirect, incidental, special or consequential damages
of any kind, or loss of revenue or profits, loss of
business, loss of information or data, or other financial
loss arising out of or in connection with the ability or
inability to use the Products, to the full extent these
damages may be disclaimed by law.
VIII. Patent and Software Provisions
At Motorola’s expense, we will defend you, and pay costs and
damages that may be finally awarded against you, to the extent
that a lawsuit is based on a claim that the Products directly
infringe a United States patent. Our obligation is conditioned on:
(a) you notifying us promptly in writing when you receive notice
of the claim; (b) you giving us sole control of the defense of the
suit and all negotiations for its settlement or compromise; and
(c) should the Products become, or in Motorola's opinion be
likely to become, the subject of a claim of infringement of a
User.Guide.Tarpon.book Page 107 Saturday, June 23, 2001 5:03 PM
Warranty
108
PRELIMINARY
United States patent, you permit us, at our option and expense,
either to: procure for you the right to continue using the
Products; replace or modify them so that they become non-
infringing; or grant you a credit for such Products, as
depreciated, and accept their return. The depreciation will be an
equal amount per year over the lifetime of the Products, as
established by Motorola.
Motorola will have no liability to you with respect to any claim of
patent infringement that is based upon the combination of the
Products or parts furnished under this limited warranty with
ancillary equipment, as defined in VI., above.
This is Motorola’s entire liability with respect to
infringement of patents by the Products.
Laws in the United States and other countries preserve for
Motorola and other third party software providers certain
exclusive rights for copyrighted software, such as the exclusive
rights to reproduce in copies and distribute copies of such
software. The software may be copied into, used in and
redistributed with only those Products that are associated with
such software. No other use, including without limitation,
disassembly or reverse engineering of such software or exercise
of exclusive rights in such software is permitted.
IX. State Law and Other Jurisdiction Rights
Some states and other jurisdictions do not allow the exclusion or
limitation of incidental or consequential damages, or limitation
on the length of an implied warranty, so the above limitations or
exclusions may not apply to you.
This warranty gives you specific legal rights, and you may also
have other rights, which vary from jurisdiction to jurisdiction.
User.Guide.Tarpon.book Page 108 Saturday, June 23, 2001 5:03 PM
109
Warranty
PRELIMINARY
To obtain information on Motorola Personal Communications
Products, including warranty service, accessories and optional
Extended Warranties on selected Products, please call:
To correspond with Motorola about the Products, please write us
at
http://www.motorola.com
or at:
USA
Cellular 1-800-331-6456
Paging 1-800-548-9954
Two-Way 1-800-353-2729
TTY (Text Telephone) 1-888-390-6456
Canada
All Products 1-800-461-4575
TTY (Text Telephone) 1-888-390-6456
In the USA:
Motorola, Inc.
600 North U.S. Highway 45
Libertyville, IL 60048
In Canada:
Motorola Canada Limited
5875 Whittle Road
Mississauga, ON L4Z 2H4
User.Guide.Tarpon.book Page 109 Saturday, June 23, 2001 5:03 PM
110
PRELIMINARY
Export Law Assurances
This product is controlled under the export regulations of the
United States of America and Canada. The Governments of the
United States of America and Canada may restrict the
exportation or re-exportation of this product to certain
destinations. For further information contact the U.S.
Department of Commerce or the Canadian Department of
Foreign Affairs and International Trade.
User.Guide.Tarpon.book Page 110 Saturday, June 23, 2001 5:03 PM
111
PRELIMINARY
Index
A
accessories
optional 9, 71
standard 17
alert
defined 80
indicators 24, 80
setting 80
type, selecting 81
alert setting indicator 24, 80
animation 62
application, locking 60
Attach Number feature 40
auto PIN dial 62
automatic redial
activating 62
using 37
B
backlight 62
banner text 61
battery
charging for first time
18–19
charging with car kit 64
extending battery life
25–26, 62
installing 17–18
level indicator 24
meter 58
block cursor, defined 47
browse text mode 48
browser alerts 56
browser.
See
micro-browser 57
C
call
alert type, selecting 81
alert, setting 80
answer options 59
answering 21
attaching phone number to
prefix digits 40
call waiting 42
calling card 41
data call, setting 59
dialed calls list 41, 54
emergency number 38
ending 20
fax call, setting 59
in-call timer 59
incoming call type, setting
59
muting 43
placing 20
received calls list 41, 53
receiving 21
restricting 60
User.Guide.Tarpon.book Page 111 Saturday, June 23, 2001 5:03 PM
Index
112
PRELIMINARY
sending 20
three-way call 42–43
voice dial 41
call timers 54
call waiting 42
caller ID 38
calling card call 41
calling line identification.
See
caller ID
car kit 64
charging with car kit 64
clock 24
contrast 63
cursor 47
customer service, calling 56
customizing the menu 81
D
data call
connecting to external device
58
incoming call format, setting
59
date, setting 62
default passwords 83
dialed calls list 41, 54
digital/analog signal indicator
24
display
animation 62
backlight 62
banner text 61
contrast 63
described 22–24
greeting 61
idle display 22
language 62
zoom 24–25, 62
drafts folder 57
DTMF tones 43, 63
E
earpiece
volume, adjusting 25
emergency number 38
end key
functions 20
menu functions 44
ending a call 20
Enter Unlock Code message
85
event alert 81
F
fax call
connecting to external device
58
incoming call format, setting
59
flashing cursor, defined 47
FM radio headset 56, 71
for hands-free use 64
User.Guide.Tarpon.book Page 112 Saturday, June 23, 2001 5:03 PM
113
Index
PRELIMINARY
G
greeting, display 61
H
hands-free use 64
headset
FM radio 56, 71
for hands-free use 64
I
idle display, defined 22
in use indicator 23
inbox, text message 27
in-call timer 59
Incoming Call message 38
incoming call type 59
indicators
alert setting 24, 80
battery level 24
digital/analog signal 24
in use 23
menu 22
message waiting 23
ring alert 24, 80
roam 23
signal strength 23
silent alert 24, 80
vibrate alert 24, 80
voice message waiting 23
voice name 65
iTAP software
activating 51
entering words 51–52
K
key
end 20, 44
left soft key 82
lock 85
menu 1, 21, 44
power 19
right soft key 1, 44, 82
scroll 44
send 1, 20, 21
voice 1, 69, 76–77
volume control 1, 44
keypad volume 81
keypad, answering calls with
59
L
language 62
left soft key
customizing 82
lock
applications 60
keypad 85
phone 83–85
lock application feature 60
loud ring alert 24, 80
User.Guide.Tarpon.book Page 113 Saturday, June 23, 2001 5:03 PM
Index
114
PRELIMINARY
M
making a call 20
master clear 63
master reset 63
menu
customizing 81–82
entering text 48–52
features 53–57
language, setting 62
locking applications 60
navigating 8, 44–45
Phonebook Menu 55, 65
Quick Note Menu 33–34
rearranging features 81–82
scroll feature 62
Text Msg Menu 30
using features 8, 45–47
menu indicator 22, 24
menu key 1, 21, 44
message
deleting 29–30
drafts folder 57
inbox setup 27–28
locking 29–30
outbox 57
quick note 33–36, 56
reading 29–30
reminders 28, 74
text 27–31, 56
voicemail 56, 74–75
message waiting indicator 23
micro-browser
browser alerts 56
call a number from 79
defined 57, 78
functions 79
go to previous page 79
starting 78
muting a call 43
my telephone number 43, 58
N
’n’ character 41
network settings 63
notepad 54
numeric text mode 48
O
one-touch dialing 39–40
optional accessory, defined 9
optional feature, defined 9
outbox 57
P
passwords
changing 61, 83
default 83
pause character 41
phone
accessories, optional 9
accessories, standard 17
User.Guide.Tarpon.book Page 114 Saturday, June 23, 2001 5:03 PM
115
Index
PRELIMINARY
answer options 59
connecting to external device
58
date, setting 62
feature specifications 58
keypad, locking and
unlocking 85
language, setting 62
locking 83–85
muting a call 43
network settings 63
one-touch dialing 39–40
passwords 61, 83
specifications 58
speed dial, using 39
time, setting 62
turning on/off 19
unlocking 19, 83–85
voice dial 41
phone number
attaching to prefix digits 40
redialing 37
viewing your own 21, 43
voice dial 41
phonebook
attaching phone number to
prefix digits 40
dialing an entry number 69
entry name 65
fields 65
number type indicator 65
one-touch dialing 39–40
phone number 65
speed dial number 39, 65,
67
speed dial, using 39
storing an entry 66–68
voice name entry 68–69
voice name indicator 65
Phonebook Menu 55, 65
PIN code, dialing automatically
62
power key 19
predictive text entry
activating 51
entering words 51–52
Q
quick dial
setting number 61
using 56
quick note 33–36, 56
Quick Note Menu 33–34
R
radio 56, 71–73
received calls list 41, 53
receiving a call 21
recent calls
attaching phone number to
prefix digits 40
User.Guide.Tarpon.book Page 115 Saturday, June 23, 2001 5:03 PM
Index
116
PRELIMINARY
menu description 53
redial
automatic redial 37
busy number 37
reminders
text message 28
voicemail message 74
restricting calls 60
right soft key
customizing 82
functions 1, 44
ring alert
indicators 24, 80
setting 80
type, selecting 81
ringer volume 25, 81
roam indicator 23
S
scroll feature 62
scroll keys 44
send key 1, 20, 21
sending a call 20
short message service.
See
text
message
signal strength indicator 23
silent alert indicator 24, 80
SMS.
See
text message
soft keys
customizing 61, 82
soft ring alert 24, 80
speed dial
changing number 67
number, defined 39
using 39
standby time, increasing 26
T
tap method text entry 49–50
text
block cursor 47
browse mode 48
changing text mode 48
character chart 50
entering from keypad
48–52
flashing cursor 47
iTAP software predictive text
entry 50–52
numeric mode 48
tap method 49–50
text message 27–31, 56
text mode, changing 48
Text Msg Menu 30
three-way call 42–43
time, setting 62
timers 54
travel charger 18
U
unlock
keypad 85
User.Guide.Tarpon.book Page 116 Saturday, June 23, 2001 5:03 PM
117
Index
PRELIMINARY
phone 83–85
V
vibrate alert
indicator 24, 80
setting 80
type, selecting 81
voice dial
dialing a number 41, 70
recording voice name
68–69
voice key
dialing a number 41
functions 1
recording a voice name 69
recording a voice note
76–77
voice message waiting indicator
23
voice name
defined 68
phonebook indicator 65
recording 68–69
voice note
defined 76
playing 77
recording 76–77
total recording time 76
voicemail 56, 74–75
volume
earpiece 25
keypad 81
ringer 25, 81
volume keys 1, 25, 44
W
wait character 41
warranty 103–109
Web pages
functions 79
viewing 78
Z
zoom setting 24–25, 62
U.S. patent Re. 34,976
User.Guide.Tarpon.book Page 117 Saturday, June 23, 2001 5:03 PM
Index
118
PRELIMINARY
User.Guide.Tarpon.book Page 118 Saturday, June 23, 2001 5:03 PM
119
✂
PRELIMINARY
Wireless Phone Safety Tips
“Safety is your most important call!”
Your Motorola wireless telephone gives you
the powerful ability to communicate by voice—
almost anywhere, anytime, wherever wireless
phone service is available and safe conditions allow.
But an important responsibility accompanies the
benefits of wireless phones, one that every user
must uphold.
When driving a car, driving is your first
responsibility. If you find it necessary to use your
wireless phone while behind the wheel of a car,
practice good common sense and remember the
following tips:
1
Get to know your Motorola wireless phone and its
features such as speed dial and redial. If available,
these features help you to place your call without taking your
attention off the road.
2
When available, use a hands-free device. If possible,
add an additional layer of convenience to your wireless
phone with one of the many Motorola Original™ hands-free
accessories available today.
User.Guide.Tarpon.book Page 119 Saturday, June 23, 2001 5:03 PM
120
✂
PRELIMINARY
3
Position your wireless phone within easy reach. Be
able to access your wireless phone without removing your
eyes from the road. If you receive an incoming call at an
inconvenient time, if possible, let your voice mail answer it
for you.
4
Let the person you are speaking with know you are
driving; if necessary, suspend the call in heavy traffic
or hazardous weather conditions. Rain, sleet, snow, ice,
and even heavy traffic can be hazardous.
5
If you receive an incoming call at an inconvenient
time do not take notes or look up phone numbers
while driving. Jotting down a “to do” list or going through
your address book takes attention away from your primary
responsibility—driving safely.
6
Dial sensibly and assess the traffic; if possible, place
calls when you are not moving or before pulling into
traffic. Try to plan calls when your car will be stationary. If
you need to make a call while moving, dial only a few
numbers, check the road and your mirrors, then continue.
7
Do not engage in stressful or emotional
conversations that may be distracting. Make people
you are talking with aware you are driving and suspend
conversations which have the potential to divert your
attention away from the road.
8
Use your wireless phone to call for help. Dial 9-1-1 or
other local emergency number in the case of fire, traffic
accident or medical emergencies.*
User.Guide.Tarpon.book Page 120 Saturday, June 23, 2001 5:03 PM
121
✂
PRELIMINARY
9
Use your wireless phone to help others in
emergencies. If you see an auto accident, crime in progress
or other serious emergency where lives are in danger, call
9-1-1 or other local emergency number, as you would want
others to do for you.*
10
Call roadside assistance or a special non-emergency
wireless assistance number when necessary. If you see
a broken-down vehicle posing no serious hazard, a broken
traffic signal, a minor traffic accident where no one appears
injured, or a vehicle you know to be stolen, call roadside
assistance or other special non-emergency wireless number.*
* Wherever wireless phone service is available.
User.Guide.Tarpon.book Page 121 Saturday, June 23, 2001 5:03 PM
122
✂
PRELIMINARY
Check the laws and regulations on the use of
wireless telephones and their accessories in the
areas where you drive. Always obey them. The
use of these devices may be prohibited or
restricted in certain areas.
For more information,
please call
1-888-901-SAFE
or visit the
CTIA Web site at
www.wow-com.com™
User.Guide.Tarpon.book Page 122 Saturday, June 23, 2001 5:03 PM
