APPLICANT: MOTOROLA, INC. FCC ID: IHDT56BJ3

EXHIBIT 8

INSTRUCTION MANUAL

A revised preliminary draft copy of the Users Manual follows:

PRELIMINARY

Motorola

Series 120x

Wireless Telephone

User Guide

FCC Type Approval Draft

September 24, 2001

PRELIMINARY

Welcome

Welcome to the world of Motorola digital wireless

communications! We are pleased that you have chosen the

Motorola

Series 120x wireless phone to keep you

connected with ease.

Power Key

Turn the phone

on and off.

Display

Headset Jack

Insert headset

accessory for

hands-free use.

Volume Keys

Adjust earpiece

and ringer volume.

End Key

End phone calls,

exit menu system.

Left Soft Key

Perform functions

identiﬁed by left

display prompt.

Earpiece

Menu Key

Voice Key

Record and activate

voice notes,

phonebook and

shortcut names.

Right Soft Key

Perform functions

identiﬁed by right

display prompt.

Scroll Keys

Move through

menus and lists.

Send Key

Send and answer

calls, view recent

dialed calls list.

Accessory Connector Port

Insert charger, FM Stereo Radio

Headset, and phone accessories.

Microphone

PRELIMINARY

Personal Communications Sector

600 North U.S. Highway 45

Libertyville, Illinois 60048

1-800-331-6456 (United States)

1-888-390-6456 (TTY/TDD United States)

1-800-461-4575 (Canada)

www.motorola.com

(United States)

www.motorola.ca

(Canada)

MOTOROLA, the Stylized M Logo and all other trademarks indicated as

such herein are trademarks of Motorola, Inc. ® Reg. U.S. Pat. & Tm. Off.

TrueSync, Sidekick, Starﬁsh, and the Stylized Starﬁsh Logo are registered

trademarks of Starﬁsh Software, Inc., a wholly owned independent

subsidiary of Motorola, Inc. All other product or service names are the

property of their respective owners.

Software Copyright Notice

The Motorola products described in this manual may include

copyrighted Motorola and third party software stored in semiconductor

memories or other media. Laws in the United States and other countries

preserve for Motorola and third party software providers certain

exclusive rights for copyrighted software, such as the exclusive rights to

distribute or reproduce the copyrighted software. Accordingly, any

copyrighted software contained in the Motorola products may not be

modiﬁed, reverse-engineered, distributed, or reproduced in any manner

to the extent allowed by law. Furthermore, the purchase of the

Motorola products shall not be deemed to grant either directly or by

implication, estoppel, or otherwise, any license under the copyrights,

patents, or patent applications of Motorola or any third party software

provider, except for the normal, non-exclusive, royalty-free license to use

that arises by operation of law in the sale of a product.

Manual number:

XXXXXXXXXX-O

Cover number:

8988485L07-O

✂

PRELIMINARY

Menu Map

Main Menu

• Recent Calls

• Received Calls

• Dialed Calls

• Notepad

• Call Times

• Phonebook

• Quick Dial

• Radio

• Messages

• Voicemail

• Text Msgs

• Browser Alerts

• Quick Notes

• Outbox

• Drafts

• Shortcuts

• Voice Notes

• Browser

• Settings

(see next page)

Note: This is the standard phone menu

layout. You or your service provider may

have changed the menu layout or

changed some feature names. Not all

features may be available for all users.

For example, the Radio feature on the

main menu (left) is displayed only when

the optional FM Stereo Radio Headset

accessory is plugged into the accessory

connector port on your phone (see

phone illustration, page 1).

For a description of the standard menu

features, see pages 49 to 60.

Shortcuts

Change display zoom:

Press

, then

press and hold

Lock/unlock keypad:

Press

Display my phone number:

Press

Dial voicemail number:

Press and hold

Go to dialed calls list:

Press

Exit menu system:

Press

✂

PRELIMINARY

Settings Menu

• Ring Styles

• Style

•

Style

Detail

• My Tones

• Phone Status

• My Tel. Number

• Battery Meter

• Other Information

• Connection

• Incoming Call

• In-Call Setup

• In-Call Timer

• Answer Options

• Security

• Phone Lock

• Lock Keypad

• Lock Application

• Restrict Calls

• New Passwords

• Other Settings

• Personalize

• Main Menu

• Keys

• Greeting

• Banner

• Quick Dial

• Initial Setup

• Time and Date

• Auto PIN Dial

• Auto Redial

• Backlight

• Zoom

• Scroll

• Animation

• Language

• Contrast

• DTMF

• Master Reset

• Master Clear

• Network

• Car Settings

• Headset

PRELIMINARY

Contents

Menu Map

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

About This Guide

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

Safety and General Information

. . . . . . . . . . . . . . . . . . . 10

Getting Started

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

What’s in the Box? . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

Installing the Battery . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

Charging the Battery . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

Turning Your Phone On . . . . . . . . . . . . . . . . . . . . . . . . . . 19

Sending a Call . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

Ending a Call . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

Receiving a Call . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

Displaying Your Phone Number . . . . . . . . . . . . . . . . . . . . 21

About Your Phone

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22

Display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22

Changing the Zoom Setting . . . . . . . . . . . . . . . . . . . . . . . 25

Volume Keys . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25

Battery Use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26

Sending and Receiving Calls

. . . . . . . . . . . . . . . . . . . . . . 28

Redialing a Number . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28

Using Automatic Redial . . . . . . . . . . . . . . . . . . . . . . . . . . 28

Caller ID . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29

Voice Privacy . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29

Dialing an Emergency Number . . . . . . . . . . . . . . . . . . . . . 30

Dialing With Speed Dial . . . . . . . . . . . . . . . . . . . . . . . . . . 31

Dialing With One-Touch Dial . . . . . . . . . . . . . . . . . . . . . . 32

Additional Dialing Features . . . . . . . . . . . . . . . . . . . . . . . 32

Using Features While On a Call

. . . . . . . . . . . . . . . . . . . . 35

Using Call Waiting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35

Contents

PRELIMINARY

Making a Three-Way Call . . . . . . . . . . . . . . . . . . . . . . . . . 35

Additional On-Call Features . . . . . . . . . . . . . . . . . . . . . . . 36

Using the Menu

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38

Navigating to a Feature . . . . . . . . . . . . . . . . . . . . . . . . . . 38

Selecting a Feature Option . . . . . . . . . . . . . . . . . . . . . . . . 39

Entering Feature Information . . . . . . . . . . . . . . . . . . . . . . 40

Entering Text

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42

Choosing a Text Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . 42

Tap Method . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43

Symbol Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45

Predictive Text Entry with iTAP™ Software . . . . . . . . . . . . 46

Menu Feature Descriptions

. . . . . . . . . . . . . . . . . . . . . . . 49

Phonebook

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61

Fields in a Phonebook Entry . . . . . . . . . . . . . . . . . . . . . . . 61

Storing a Phonebook Entry . . . . . . . . . . . . . . . . . . . . . . . 62

Recording a Voice Name For a Phonebook Entry . . . . . . . . 64

Dialing a Phonebook Entry . . . . . . . . . . . . . . . . . . . . . . . . 65

Radio

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67

Turning the Radio On and Off . . . . . . . . . . . . . . . . . . . . . 67

Tuning a Station . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67

Storing a Preset . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 68

Selecting a Preset . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 68

Sending and Receiving Calls With the Radio On . . . . . . . . 68

Messages—Voicemail

. . . . . . . . . . . . . . . . . . . . . . . . . . . 70

Storing Your Voicemail Number . . . . . . . . . . . . . . . . . . . . 70

Receiving a New Voicemail Message . . . . . . . . . . . . . . . . 70

Listening to a Voicemail Message . . . . . . . . . . . . . . . . . . . 71

Turning Off the Voice Message Waiting Indicator . . . . . . . 71

Contents

PRELIMINARY

Messages—Text

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 72

Setting Up the Text Message Inbox . . . . . . . . . . . . . . . . . . 72

Receiving a Text Message . . . . . . . . . . . . . . . . . . . . . . . . 73

Reading, Locking, or Deleting a Text Message . . . . . . . . . . 74

Sending a Text Message . . . . . . . . . . . . . . . . . . . . . . . . . . 75

Sending a Quick Note Text Message . . . . . . . . . . . . . . . . . 77

Voice Notes

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 80

Recording a Voice Note . . . . . . . . . . . . . . . . . . . . . . . . . . 80

Playing a Voice Note . . . . . . . . . . . . . . . . . . . . . . . . . . . . 81

Micro-Browser

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 82

Starting a Micro-Browser Session . . . . . . . . . . . . . . . . . . . 82

Interacting With Web Pages . . . . . . . . . . . . . . . . . . . . . . . 83

Adjusting Your Settings

. . . . . . . . . . . . . . . . . . . . . . . . . . 84

Ring Styles . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 84

Reordering Menu Items . . . . . . . . . . . . . . . . . . . . . . . . . . 90

Customizing a Soft Key Function . . . . . . . . . . . . . . . . . . . 91

Security

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 92

Assigning a New Code or Password . . . . . . . . . . . . . . . . . 92

Locking and Unlocking Your Phone . . . . . . . . . . . . . . . . . 92

Locking and Unlocking Your Keypad . . . . . . . . . . . . . . . . . 94

Troubleshooting

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 95

Programming Instructions

. . . . . . . . . . . . . . . . . . . . . . . 99

Speciﬁc Absorption Rate Data

. . . . . . . . . . . . . . . . . . . 100

Additional Health and Safety Information

. . . . . . . . . 103

Warranty

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 112

Export Law Assurances

. . . . . . . . . . . . . . . . . . . . . . . . . 120

Index

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 121

Wireless Phone Safety Tips . . . . . . . . . . . . . . . . . . . . . . 131

PRELIMINARY

About This Guide

Using Your Phone’s Features

This user guide introduces you to the many features in your

Motorola V phone. A reference guide for your phone is also

available that explains the phone’s features in more detail. To

obtain a copy of the reference guide or another copy of this user

guide, see the Motorola Web site at:

http://motorola.com/consumer/manuals

(United States)

http://www.motorola.ca/manuals

(Canada)

or contact the Motorola Customer Call Center at

1-800-331-6456 in the United States or 1-800-461-4575 in

Canada.

Navigating To a Menu Feature

You can access many of your phone’s features through the menu

system. This guide shows you how to navigate to a speciﬁc menu

feature as follows:

The > symbol means that you should scroll to and select the

feature. This example shows that you must press M, scroll to

and select Recent Calls, then scroll to and select Dialed Calls

to view the dialed calls list.

Find the Feature

M> Recent Calls

> Dialed Calls

About This Guide

PRELIMINARY

Optional Features

Features marked with this label are optional network

and/or subscription-dependent features. These

features may not be offered by all service providers in

all geographical areas. Contact your service provider

for information about availability.

Optional Accessories

Features marked with this label require the use of an

optional Motorola Original™ accessory.

PRELIMINARY

Safety and General

Information

IMPORTANT INFORMATION ON SAFE AND EFFICIENT

OPERATION. READ THIS INFORMATION BEFORE USING YOUR

PHONE.

RF Operational Characteristics

Your phone contains a transmitter and a receiver. When it is ON,

it receives and transmits radio frequency (RF) energy. The phone

operates in the frequency range of 824 MHz to 849 MHz in

analog and digital mode and 1851.25 MHz to 1908.75 MHz in

digital mode.

When you communicate with your phone, the system handling

your call controls the power levels at which your phone

transmits. The output power level typically may vary over a range

from 0.05 watts to 0.56 watts in analog mode and 0.0 watts to

0.32 watts in digital mode.

Exposure To Radio Frequency Energy

Your Motorola phone is designed to comply with the following

national and international standards and guidelines regarding

exposure of human beings to radio frequency electromagnetic

energy (EME):

•United States Federal Communications Commission, Code

of Regulations; 47 CFR part 2 sub-part J

•American National Standards Institute (ANSI) / Institute of

Electrical and Electronic Engineers (IEEE) C95. 1-1992

Safety and General Information

PRELIMINARY

• Institute of Electrical and Electronic Engineers (IEEE)

C95.1-1999 Edition

• National Council on Radiation Protection and

Measurements (NCRP) of the United States, Report 86,

1986

• International Commission on Non-Ionizing Radiation

Protection (ICNIRP) 1998

• Ministry of Health (Canada) Safety Code 6. Limits of Human

Exposure to Radiofrequency Electromagnetic Fields in the

Frequency Range from 3 kHz to 300 GHz, 1999

• Australian Communications Authority

Radiocommunications (Electromagnetic Radiation-Human

Exposure) Standard 1999

To assure optimal phone performance and make sure human

exposure to radio frequency electromagnetic energy is within the

guidelines set forth in the above standards, always adhere to the

following procedures:

Portable Phone Operation and EME

Exposure

Antenna Care

Use only the supplied or an approved replacement

antenna. Unauthorized antennas, modiﬁcations, or

attachments could damage the phone and may violate FCC

regulations.

Safety and General Information

PRELIMINARY

Do NOT hold the antenna when the phone is in use.

Holding the antenna affects call quality and may cause the

phone to operate at a higher power level than needed.

Phone Operation

When placing or receiving a phone call, hold your phone as you

would a wireline telephone. Speak directly into the

microphone.

Body-Worn Operation

To maintain compliance with FCC/Health Canada RF exposure

guidelines, if you wear a phone on your body when transmitting,

always place the phone in a Motorola-supplied or approved

clip, holder, holster, case, or body harness for this

product. Use of non-Motorola-approved accessories may

exceed FCC/Health Canada RF exposure guidelines. If you do

not use a body-worn accessory, and are not holding the

phone in the normal use position at the ear, ensure the

phone and its antenna are at least one inch

(2.5 centimeters) from your body when transmitting.

Data Operation

When using any data feature of the phone, with or without an

accessory cable, position the phone and its antenna at

least one inch (2.5 centimeters) from your body.

Approved Accessories

For a list of approved Motorola accessories, visit our website at

www.motorola.com

Safety and General Information

PRELIMINARY

Electromagnetic Interference/

Compatibility

Note: Nearly every electronic device is susceptible to

electromagnetic interference (EMI) if inadequately shielded,

designed, or otherwise conﬁgured for electromagnetic

compatibility.

Facilities

To avoid electromagnetic interference and/or compatibility

conﬂicts, turn off your phone in any facility where posted notices

instruct you to do so. Hospitals or health care facilities may be

using equipment that is sensitive to external RF energy.

Aircraft

When instructed to do so, turn off your phone when on board an

aircraft. Any use of a phone must be in accordance with

applicable regulations per airline crew instructions.

Medical Devices

Pacemakers

The Advanced Medical Technology Association recommends that

a minimum separation of 6 inches (15 centimeters) be

maintained between a handheld wireless phone and a

pacemaker. These recommendations are consistent with the

independent research by, and recommendations of, the United

States Food and Drug Administration.

Safety and General Information

PRELIMINARY

Persons with pacemakers should:

• ALWAYS keep the phone more than six inches

(15 centimeters) from your pacemaker when the phone is

turned ON.

• NOT carry the phone in the breast pocket.

• use the ear opposite the pacemaker to minimize the

potential for interference.

• turn OFF the phone immediately if you have any reason to

suspect that interference is taking place.

Hearing Aids

Some digital wireless phones may interfere with some hearing

aids. In the event of such interference, you may want to consult

your hearing aid manufacturer to discuss alternatives.

Other Medical Devices

If you use any other personal medical device, consult the

manufacturer of your device to determine if it is adequately

shielded from RF energy. Your physician may be able to assist

you in obtaining this information.

Safety and General

Use While Driving

Check the laws and regulations on the use of phones in the area

where you drive. Always obey them.

When using your phone while driving, please:

Safety and General Information

PRELIMINARY

• give full attention to driving and to the road.

• use hands-free operation, if available.

• pull off the road and park before making or answering a

call if driving conditions so require.

Operational Warnings

For Vehicles With an Air Bag

Do not place a portable phone in the area over an air bag or in

the air bag deployment area. Air bags inﬂate with great force. If

a portable phone is placed in the air bag deployment area and

the air bag inﬂates, the phone may be propelled with great force

and cause serious injury to occupants of the vehicle.

Potentially Explosive Atmospheres

Turn off your phone prior to entering any area with a potentially

explosive atmosphere, unless the phone is a model speciﬁcally

identiﬁed as being “Intrinsically Safe.” Do not remove, install, or

charge batteries in such areas. Sparks in a potentially explosive

atmosphere can cause an explosion or ﬁre resulting in bodily

injury or even death.

Note: The areas with potentially explosive atmospheres referred

to above include fueling areas such as below decks on boats,

fuel or chemical transfer or storage facilities, areas where the air

contains chemicals or particles, such as grain, dust, or metal

powders, and any other area where you would normally be

advised to turn off your vehicle engine. Areas with potentially

explosive atmospheres are often but not always posted.

Safety and General Information

PRELIMINARY

Blasting Caps and Areas

To avoid possible interference with blasting operations, turn OFF

your phone when you are near electrical blasting caps, in a

blasting area, or in areas posted: “Turn off two-way radio.” Obey

all signs and instructions.

Operational Cautions

Antennas

Do not use any portable phone that has a damaged

antenna. If a damaged antenna comes into contact with your

skin, a minor burn can result.

Batteries

All batteries can cause property damage and/or bodily injury

such as burns if a conductive material such as jewelry, keys, or

beaded chains touches exposed terminals. The conductive

material may complete an electrical circuit (short circuit) and

become quite hot. Exercise care in handling any charged battery,

particularly when placing it inside a pocket, purse, or other

container with metal objects.

ITC01-065

PRELIMINARY

Getting Started

What’s in the Box?

Your digital wireless phone typically comes equipped with a

battery and a charger. Other accessory options can customize

your phone for maximum performance and portability.

To purchase Motorola Original™ accessories, please contact the

Motorola Customer Call Center at 1-800-331-6456 in the

United States or 1-800-461-4575 in Canada.

Installing the Battery

Before you can use your phone, you need to install and charge

the battery.

Your phone is designed to be used only with Motorola

Original batteries and accessories. We recommend that

you store batteries in their protective cases when not

in use.

Do This

Remove the battery from its protective clear plastic case.

If the phone’s battery door

is already in place, lightly

slide down the battery

door release latch and lift

the battery door off of the

phone.

Release

latch

Getting Started

PRELIMINARY

Charging the Battery

Before you can use your phone, you need to install and charge

the battery.

Insert the battery, printed

arrows ﬁrst, into the

battery compartment and

push down.

Replace the battery door.

Do This

Plug the travel charger

into your phone with the

release tab facing up.

Plug the other end of the travel charger into the

appropriate electrical outlet.

When your phone indicates that the battery is fully

charged, press the release tab and remove the travel

charger.

Do This

Getting Started

PRELIMINARY

Turning Your Phone On

Do This To

Press and hold P

(the power key)

turn on your phone

Enter your four-digit unlock

code and press OK (+)

unlock your phone, if

necessary

The unlock code is

originally set to 1234, but

in some instances your

service provider may

program a new code.

Power

key

Getting Started

PRELIMINARY

Sending a Call

To call a number, your phone must be turned on, be unlocked,

and have a network connection with adequate signal strength.

Note: You can make an emergency call even when the phone is

locked. See “Dialing an Emergency Number” on page 30.

Ending a Call

Do This To

Extend the

antenna.

optimize signal reception

Tip: Your phone uses a two-stage

antenna that must be fully extended

for proper operation. You may have

to pull on the antenna a second time

to extend the antenna to its

maximum length.

Press the keypad

keys

dial the phone number (up to 32

digits)

Tip: If you make a mistake, press

DELETE (-) to delete the last digit,

or press and hold DELETE (-) to

clear all digits.

Press N

(send key)

send the call

Press To

O (end key) end the call

Getting Started

PRELIMINARY

Receiving a Call

To receive a call, your phone must be turned on and have a

network connection with adequate signal strength. If your phone

is locked, you must unlock the phone to answer the call.

When you receive a call, your phone rings and/or vibrates and

displays an incoming call message.

Displaying Your Phone Number

From the idle display:

Press To

N or ANSWER (+)answer the call

Press To

M #see your phone number

PRELIMINARY

About Your Phone

See page 1 for a diagram of your phone that describes basic

phone components.

Display

The top section of the display shows phone status indicators. The

following illustration shows some of the common indicators that

you may see at the top of the display when using your phone.

Messages, phone numbers, and menu options appear in the

middle of the display. Text labels at the bottom corners of the

display show the current soft key functions. A M (menu) indicator

in the bottom center of the display indicates that you can open

the main menu or a feature sub-menu to see more options. For

more information about the soft key and menu key labels, see

“Using the Menu” on page 38.

Some of the phone functions described in this guide must be

performed from the idle display. The term

idle display

refers to

the standard display that you see when your phone is on and

ready to use, when you are

not

on a call or using the menu

system.

About Your Phone

PRELIMINARY

➊ Signal Strength Indicator Shows the strength of your

phone’s connection with the network.

You cannot send or receive calls when the “no signal” indicator

is displayed.

➋ Digital (F) or Analog (I) Signal

Indicators Your service provider may use one or

both of these indicators to indicate whether you are

receiving a digital or analog signal.

➌ In Use Indicator Appears when a call is in progress.

➍ Roam Indicator Appears when your phone uses another

network system outside your home network. When you leave

your home network area, your phone

roams

or seeks another

network.

Strong 5 4 3 2 1 j No signal

12:00am

➐

➏

➒

➋➌➍➎

➑

➓

➊

➋

About Your Phone

PRELIMINARY

➎ Message Waiting Indicator Appears when

your phone receives a text message.

➏ Voice Message Waiting Indicator Appears

when you receive a voicemail message.

➐ Battery Level Indicator Shows the amount of

charge left in your battery. The more segments visible, the

greater the charge.

Recharge your battery as soon as possible when you see the

Low Battery warning message.

➑ Clock Shows the current time. The clock is

available only when your phone is operating in digital

mode. In some instances, your phone may prompt

you to enter the correct time when you turn it on.

➒ Menu Indicator Indicates that you can press M to open

a menu. See “Using the Menu” on page 38.

➓ Alert Setting Indicator Shows the current selected alert.

The default alert setting is a ringer.

High E D C B Empty

w Loud ring x Soft ring

y Vibrate u Ring and vibrate

t Silent

About Your Phone

PRELIMINARY

Changing the Zoom Setting

You can set your phone’s display to show either three lines or

two lines of text plus soft key labels. Three lines of text display

more information, while two lines increase text size.

To change the display view, press M once, then press and

hold M again within two seconds of the ﬁrst press.

You can also adjust the zoom setting from the menu. See the

“Zoom” item on page 58.

Volume Keys

Use the upper and lower volume keys to adjust your phone’s

earpiece and ringer volume. The volume keys are located on the

left side of the phone.

You can also use the volume keys to scroll up or down through

menus and lists.

To change keypad volume, see “Customize an Alert Style” on

page 85.

When Press To

During a call volume keys increase or decrease

earpiece speaker volume

From the idle

display

volume keys increase or decrease ringer

volume

About Your Phone

PRELIMINARY

Battery Use

Caution: To prevent injuries or burns, do not allow metal

objects to contact or short-circuit the battery terminals.

To maximize your battery’s performance:

• Always use Motorola approved batteries and battery

chargers. The phone warranty does not cover damage

caused from using non-Motorola batteries and/or battery

chargers.

• New batteries or batteries that have been stored for long

periods of time may require a longer charge time.

• Maintain the battery at or near room temperature when

charging.

• Do not expose batteries to temperatures below -10°C

(14°F) or above 45°C (113°F). Always take your phone with

you when you leave your vehicle.

• When you do not intend to use a battery for a while, store it

uncharged in a cool, dark, dry place, such as a refrigerator.

• Over extended periods of time, batteries gradually wear

down and require longer charging times. This is normal. If

you charge your battery regularly and notice a decrease in

talk time or an increase in charging time, then it is probably

time to purchase a new battery.

• The more you talk on the phone or use phone features (like

sending text messages), the less standby time your battery

has.

About Your Phone

PRELIMINARY

The rechargeable batteries that power this product

must be disposed of properly and may need to be

recycled. Refer to your battery’s label for battery type.

Contact your local recycling center for proper disposal methods.

Never dispose of batteries in a ﬁre because they may explode.

PRELIMINARY

Sending and Receiving Calls

For basic instructions on how to send a call, end a call, and

receive a call, see page 20 of the “Getting Started” section.

Redialing a Number

If you hear an ordinary busy signal, the phone number you dialed

is busy.

Using Automatic Redial

If the network is busy, you hear a fast busy signal, and your

phone displays the message Call Failed.

When automatic redial is turned on, your phone automatically

repeats the call attempt over the next four minutes. When the

call goes through, your phone rings or vibrates one time, displays

the message Redial Successful, and then connects the call.

You must turn on automatic redial to use this feature. See the

“Auto Redial” option on page 58 to turn on automatic redial.

When automatic redial is turned off, you can manually activate

the feature to redial a phone number. When you hear a busy

signal and see the Call Failed message:

Press To

O hang up

N redial the busy number

Press To

N or RETRY (+)activate automatic redial

Sending and Receiving Calls

PRELIMINARY

Caller ID

The

calling line identification

(caller ID) feature lets

you see who is calling before you answer.

• If the caller’s name is stored in your phonebook, the phone

automatically displays the name. Otherwise, the phone

displays the caller’s phone number.

• If caller ID information is not available, your phone displays

the message Incoming Call.

Voice Privacy

Your phone always tries to use a high-security

connection to prevent others from intercepting your

calls.

• If a high-security connection is available, your phone uses it

and displays the message Voice Private. This message

does not appear when caller ID or other information ﬁlls the

display.

• If a high-security connection is not available, your phone

uses a standard connection.

Sending and Receiving Calls

PRELIMINARY

Dialing an Emergency Number

Your service provider programs one or more emergency phone

numbers (such as 911) that you can call under any

circumstances. You can dial and call the emergency number even

when your phone or keypad is locked, or when you are prompted

to enter a code or password.

Note: Emergency numbers vary by country. Your phone’s

emergency number(s) may not work in all locations.

To call the emergency number at any time:

When you call an emergency number, your phone displays

Emergency Mode. During the next ten minutes, the emergency

operator may place a call back to your phone, unless you make

another call or turn the phone off.

Press To

keypad keys dial the emergency number (such as

911)

N call the emergency number

Sending and Receiving Calls

PRELIMINARY

Dialing With Speed Dial

The

speed dial

feature lets you dial any phonebook entry with a

minimal number of keypresses.

Whenever you store an entry in your phonebook, the entry is

assigned a unique speed dial number. The speed dial number

identiﬁes the location where the entry is stored in phonebook

memory. If you know the speed dial number for the phonebook

entry you want to call, you can use the speed dial feature.

To make an entry in the phonebook or view an existing entry’s

speed dial number, see “Storing a Phonebook Entry” on

page 62.

Press To

keypad keys enter the one-, two-, or three-digit

speed dial number for the entry you

want to dial

# submit the number

Note: On some networks,

you can skip this step for

phonebook entries stored

in speed dial locations 1

through 99.

N call the entry

Sending and Receiving Calls

PRELIMINARY

Dialing With One-Touch Dial

You can call phonebook entries 2 through 9 with the push of a

single key. Just press and hold the one-digit speed dial number

for one second.

You

cannot

use one-touch dial to call phonebook entry number

1, since the 1 key is reserved for dialing your voicemail

number. See “Listening to a Voicemail Message” on page 71.

To store entries in locations 2 through 9 in the phonebook, see

“Storing a Phonebook Entry” on page 62.

Additional Dialing Features

In addition to pressing numbers on your keypad, you can insert

numbers or characters and send calls in a variety of ways.

While dialing (with digits visible in the display):

Do This To

Press M

> Attach Number

attach a number from the phonebook

or recent calls list to the end of the

digits you entered

Press M

> Send Message

create a text message addressed to

the number entered

Sending and Receiving Calls

PRELIMINARY

Press M and then

scroll to and select

one of the following:

•Insert Pause

(to insert a p)

•Insert Wait

(to insert a w)

•Insert 'n'

(to insert an n)

insert a special character when

making a call that requires you to dial

and send additional digits (for

example, to make a calling card call,

or to retrieve messages from an

answering machine):

•Pause tells your phone to wait

until the call connects before it

automatically sends the next

digit(s) in a series.

•Wait tells your phone to wait

until the call connects, and then

to prompt you for conﬁrmation

before it sends the next digit(s).

•'n' tells your phone to prompt you

for a number before dialing the

call. The number you enter is

inserted into the dialing sequence

in place of the n character

Do This To

Sending and Receiving Calls

PRELIMINARY

You can also call numbers using these features:

Do This To Call

Press and release the voice key

on the right side of your phone

and say the entry’s name (in

two seconds).

a phone number using the

voice dial feature

See “Recording a Voice

Name For a Phonebook

Entry” on page 64.

Press M > Recent Calls

> Received Calls or

Dialed Calls >

entry to call

a missed call or a number

from a call you recently

dialed or received

PRELIMINARY

Using Features While On a

Call

Using Call Waiting

If you subscribe to call waiting, an alert tone sounds

while you are on a call to indicate that you have

received a second call.

To put the ﬁrst call on hold and answer the second call:

Making a Three-Way Call

During a call, you can call and connect a third party

so that the three of you can talk together. You cannot

do this if you already have a call on hold.

While you are on a call:

Press To

N answer the new call

N switch back to the ﬁrst call

Press To

keypad keys enter the third person’s number

Note: On some networks, you must

press N before entering the third

person’s number.

N call the number and connect the new

person

Using Features While On a Call

PRELIMINARY

Additional On-Call Features

While you are on a call, you can perform the following tasks:

N connect the two calls

O end the entire call

Do This To

Press MUTE (+)mute a call

Press M

> My Tel. Number

view your phone number

Press M > Send Tones send a number to the network

as DTMF tones, for credit card

calling or password entry

Note: This option appears only

when you enter digits or select

stored digits during an active

call.

To activate DTMF tones, see the

“DTMF” item on page 59.

Press M

>Received Calls

Dialed Calls

view the telephone numbers

from calls you have recently

received or dialed

Press M > Messages view or send messages from the

message center

Press To

Using Features While On a Call

PRELIMINARY

Press M > Datebook view your schedule of events

stored in the datebook

Press M

> Other Information

view a list of feature

speciﬁcations for your phone

Do This To

PRELIMINARY

Using the Menu

Navigating to a Feature

You can access many of your phone’s features by using these

keys to move through the menu system:

Main Menu

)Recent Calls

)Phonebook

)EXIT)SELECT

Scroll Keys

Move up or down

through menus

and lists.

Menu Key

Enter the menu

system, or open

a sub-menu, when

appears in the

bottom center of

the display.

Right Soft Key

Perform the

function shown

in the lower

right corner of

the display

(usually

SELECT

the highlighted

menu item).

Left Soft Key

Perform the

function shown

in the lower left

corner of the

display (usually

EXIT

BACK

* and #

Cycle through

and set the

value of the

highlighted

menu item.

End Key

Exit the menu

system without

making changes,

return to the

idle display.

Volume Keys

Move up or down

through menus

and lists.

Using the Menu

PRELIMINARY

This guide shows you how to navigate to a speciﬁc menu feature

as follows:

The > symbol means that you should scroll to and select the

feature. This example shows that you must press M, scroll to

and select Recent Calls, then scroll to and select Dialed Calls

to see the dialed calls list.

Selecting a Feature Option

Some features require you to select an item from a list:

Select an item by highlighting it. Use one of the following

approaches:

• Press S to scroll up or down to the item you want.

• In a numbered list, press a number key to highlight the

item.

Find the Feature

M> Recent Calls

> Dialed Calls

Dialed Calls

10) John Smith

9) Mary Smith

BACK VIEW

Press

BACK

(

)

to go back to the

previous screen.

A sub-menu is

available. Press

to open

the sub-menu.

Highlighted

item

Press

VIEW

(

) to view

details of the highlighted item.

STORE

(

) appears if you can

store the item in your phonebook.

Using the Menu

PRELIMINARY

• In an alphabetized list, press a key multiple times to cycle

through the letters on the key and highlight the closest

matching list item.

Entering Feature Information

Features such as the phonebook require you to enter information

to ﬁll in an entry’s details:

• Enter numbers or text with the keypad. (See “Entering Text”

on page 42.)

• When an item has a list of possible values, press

* or # to scroll through and select a value.

• When an item has a list of possible numeric values, press a

number key to set the value.

Entry Details

Name:John Smith

No.:2125551212

CANCEL CHANGE

Press

scroll down

to additional

items.

Press

CANCEL

(

) to exit

without making changes.

DONE

(

) appears when you

enter or edit information. Press

DONE

(

) to save your changes.

Press

CHANGE

(

)

to edit the selected

information.

Highlighted

item

Using the Menu

PRELIMINARY

• If you enter or edit information and then decide that you do

not want to save your changes, press O to exit without

saving.

The message center lets you compose and send text messages.

(See “Entering Text” on page 42.) A

flashing cursor

shows you

where the text will appear:

When you enter text, the ﬂashing cursor changes to a

block

cursor

, and the soft key functions change:

Msg:

CANCEL BROWSE

Press

BROWSE

(

)

to view and

insert a name,

number, or

message from

previously

stored

information.

Press

CANCEL

(

)

to exit without

making changes.

Flashing

cursor

indicates

insertion

point.

Press

to open the

sub-menu.

Msg:

DELETE OK

Press

(

)

to accept and

store the text.

Press

DELETE

(

) to

delete the character to the

left of the insertion point.

Block

cursor

indicates

current

highlighted

character.

After two seconds, the block

cursor reverts to a ﬂashing cursor

and moves to the next position.

PRELIMINARY

Entering Text

Various text entry methods make it easy for you to enter names,

numbers, email addresses, and text messages on your phone.

You can enter all characters (letters, numbers, and symbols)

using the standard tap method. Other text modes let you easily

enter numbers and symbols, or insert text already stored on your

phone. Finally, a predictive text mode lets you enter text

messages with a minimum of keypresses.

Choosing a Text Mode

To activate a text mode, press M from any text entry screen

and select the text mode from the Entry Method menu:

Note: The text mode you select remains active until you change

it by selecting another mode.

iTAP Let the phone predict each word as you enter it,

then choose the word from a list (see “Predictive

Text Entry with iTAP™ Software” on page 46).

Tap Method Enter characters one at a time by pressing the

key for the letter, number, or symbol (see “Tap

Method” on page 43). This is the standard

mode for entering text on your phone.

Numeric Enter only the number that appears on each key.

Symbol Enter symbols only (see “Symbol Mode” on

page 45).

Browse Browse through your phonebook and recent

calls lists to select a name or number to enter.

Entering Text

PRELIMINARY

Tap Method

Tap method is the default standard mode for entering text on

your phone.

To activate tap method from any text entry screen, press M

and select the Tap Method menu option.

To enter text using the tap method:

General Text Entry Rules

Use the keypad to enter letters, numbers, symbols, and other

characters with the tap method. Press the same key repeatedly

to cycle through available characters (see the “Character Chart”

on page 44):

• To enter text at a ﬂashing cursor, press a number key.

• To enter the desired character, press the number key as

many times as necessary. For example, press 2 three

times to enter the “c” character.

Do This To

Press a number

key one or more

times

cycle through the characters

associated with the key and select

the character you want (see the

“Character Chart” on page 44).

Continue to press

number keys

enter the rest of the characters in the

text message

Press OK (+)accept and store the text when you

are ﬁnished

Entering Text

PRELIMINARY

• Press and hold a number key to switch between tap method

and numeric text entry mode.

• To move the ﬂashing cursor up or down one line in a text

message, or to change a character in block cursor to

uppercase or lowercase, press S.

• To move the ﬂashing cursor to the left or right in a text

message, press * or #.

• If you do not press a key for two seconds, the character in

the block cursor is accepted, and the cursor moves to the

next position.

• The ﬁrst character of every sentence is capitalized unless

you manually change it. (Press S down to force the

character to lowercase while it is highlighted by the block

cursor.)

Character Chart

Use this chart as a guide for entering spaces, numbers, letters,

symbols, and other characters with the tap method.

space

. 1 ? ! , @ _ & ~ : ; " - ( )

' ¿ ¡ % £ $ ¥

0 + - 0 x * / \ [ ] = > < # §

Entering Text

PRELIMINARY

Symbol Mode

Your phone provides an alternate way to ﬁnd and enter symbol

characters in a text message. You can view and select from a

variety of available symbols.

To activate symbol mode from any text entry screen, press M

and select the Symbol menu option.

To enter a symbol in symbol mode:

Do This To

Press a number

key one time

display its symbol options (see the

“Symbol Chart” on page 46)

The symbols associated with the key

you pressed are shown at the bottom

of the display. If necessary, press

other keypad keys to ﬁnd the symbol

you want.

Press * or #

the number key

multiple times

highlight the symbol you want

Press SELECT (+)add the highlighted symbol to the

text area at the top of the display

Entering Text

PRELIMINARY

Symbol Chart

Use this chart as a guide for entering symbols in symbol mode.

Predictive Text Entry with iTAP™

Software

iTAP™ software provides a predictive text entry method that lets

you enter the letters of a word using only one keypress per letter.

You must activate iTAP software prior to entering letters. You can

do this from any text entry screen by pressing M to open the

Entry Method menu and selecting the iTAP menu option.

space

. ? ! , @ _ &

~ : ; " - ( ) ' ¿ ¡

% £ $ ¥

2 @ _ \

3 / : ;

4 " & '

5 ( ) [ ] { }

6 ¿ ¡ ~

7 < > =

8 $ £ ¥

9 # % *

0 + - x * / = > <

# §

Entering Text

PRELIMINARY

Enter Words

To enter a word with iTAP software:

Do This To

Press a number

key one time

enter the ﬁrst letter of the word

The letters associated with the key

you pressed are shown at the bottom

of the display.

Press number keys

(one per letter)

enter the rest of the word

Alternative words and letter

combinations are shown at the

bottom of the display based on the

keys you press. These word choices

are updated with each keypress.

When you have

entered all the

letters of the

word, press

* or #

locate and highlight the word you

want

Press SELECT (+)add the highlighted word to the text

area at the top of the display

A space is automatically inserted

after the word.

Entering Text

PRELIMINARY

Enter Novel Words

You may enter a word that is not in the iTAP software dictionary.

If you enter all the letters of a word but the word is not

displayed:

Do This To

Press DELETE (-) one

or more times

delete one or more letters until

you see a letter combination

that matches the start of the

word

Press * or #highlight the letter or letter

combination

Press SELECT (+),

then press *

shift the text entry cursor to the

left and “lock” the selected

portion of the word

Continue entering

letters and highlighting

letter combinations

spell the word

PRELIMINARY

Menu Feature Descriptions

This chapter describes all of your phone’s features in order of the

menu map shown on page 3. Some descriptions also include

page numbers where you can ﬁnd more detailed information. If

you would like to learn more about a speciﬁc feature, a reference

guide for your phone is also available. To obtain a copy of the

reference guide or another copy of this user guide, see the

Motorola Web site at:

http://motorola.com/consumer/manuals

(United States)

http://www.motorola.ca/manuals

(Canada)

or contact the Motorola Customer Call Center at

1-800-331-6456 (United States) or 1-800-461-4575 (Canada).

Main Menu

ECENT

ALLS

View the numbers of your recent dialed calls and received

calls. Press N to go directly to the dialed calls list from the

idle display.

Received Calls

M> Recent Calls

> Received Calls

View a list of recently received calls.

Your phone keeps a list of the numbers from calls you

recently received, even if you did not answer. You can scroll

through the list until you ﬁnd an entry you want to call,

store, or delete.

Menu Feature Descriptions

PRELIMINARY

Dialed Calls

M> Recent Calls

> Dialed Calls

View a list of recently dialed calls. Your phone keeps a list of

recently dialed phone numbers, even if the calls did not

connect. A < means the call connected. You can scroll

through the list until you ﬁnd an entry you want to call,

store, or delete.

Notepad

M> Recent Calls

> Notepad

Stores the last phone number entered on the keypad. The

number may be the last number you called or a number you

entered during a phone call.

You can call the number on the notepad or you can store it

as part of a phonebook entry.

Call Times

M> Recent Calls

> Call Times

View call timers, which record

network connection time,

the

elapsed time from the moment you connect to your service

provider’s network to the moment you end the call by

pressing O.

The amount of network connection time you track

on your timer may not equal the amount of time for

which you are billed by your service provider. For

billing information, please contact your service

provider directly.

You can scroll through a list of ﬁve timers: Last Call, Dialed

Calls, Received Calls, All Calls, and Lifetime.

Menu Feature Descriptions

PRELIMINARY

HONEBOOK

M> Phonebook

M> Phonebook Menu

Create and manage a personalized phonebook. You can call

phone numbers stored in the phonebook or, for entries with

email addresses, you can send a text message directly from

your phone.

UICK

IAL

M> Quick Dial

Dial pre-programmed customer service numbers.

Create a

phonebook entry

Enter a name, phone number or email

address, and type indicator, such as

home or work. The phone will assign a

speed dial number. See page 62.

Set up voice dial Record a voice name you can use to

dial a phone number by saying the

person’s name. See page 64.

Edit a phonebook

entry

View and then update details of a

phonebook entry.

Dial a phonebook

entry

Use the phonebook list, voice dial,

speed dial, or one-touch dial to call a

number or send a text message to an

email address. See pages 28 and 66.

Delete a

phonebook entry

Use the Phonebook Menu to remove

outdated entries.

Sort phonebook

entries

Accept the standard sort by speed dial

number or sort entries by name or

voice dial.

Menu Feature Descriptions

PRELIMINARY

Your service provider may program one or more quick dial

numbers, such as the customer service number, into your

phone. You can call them by selecting them from the quick

dial list.

Note: Your service provider may use a different name for

this feature.

ADIO

M> Radio

Listen to FM radio stations. This menu feature is

displayed only when the optional Motorola

Original™ FM Stereo Radio headset is plugged

into the accessory connector port on your phone. See

“Radio” on page 67.

ESSAGES

M> Messages

Adjust message settings, view and manage the

various types of messages your phone can receive

and/or send:

Voicemail Store and call the voicemail number

provided by your service provider. See

“Messages—Voicemail” on page 70.

Text Msgs Send and receive text messages. See

“Messages—Text” on page 72.

Browser Alerts Read alert messages received by your

micro-browser.

Quick Notes Select and send pre-written messages

from the quick notes list.

Outbox View all outgoing text messages,

delivered and undelivered.

Menu Feature Descriptions

PRELIMINARY

HORTCUTS

M> Shortcuts

Create keypad or voice shortcuts to menu features.

OICE

OTES

M> Voice Notes

Use the voice key to record and playback messages and

phone calls. See “Voice Notes” on page 80.

ROWSER

M> Browser

Access Web pages and run Web-based

applications.

The micro-browser delivers WAP (Wireless Application

Protocol) pages from your service provider directly to your

phone. See “Micro-Browser” on page 82.

Settings Menu

ING

TYLES

Style

M> Settings

> Ring Styles

> Style

Select a type of ring or vibration alert style for incoming

calls and messages. See “Ring Styles” on page 84.

Style Detail

M> Settings

> Ring Styles

Style

Detail

Change details about the ring or vibration alert style.

Style

represents the name of the current alert setting style. See

“Ring Styles” on page 84.

Drafts Store and edit text messages that you

have written but not sent.

Menu Feature Descriptions

PRELIMINARY

My Tones

M> Settings

> Ring Styles

> My Tones

Create custom alert tones for your phone. See “Use the My

Tones Feature” on page 86.

HONE

TATUS

My Tel. Number

M> Settings

> Phone Status

> My Tel. Number

View, enter, and edit your name and phone number.

Battery Meter

M> Settings

> Phone Status

> Battery Meter

View a detailed battery charge meter.

Other Information

M> Settings

> Phone Status

> Other Information

View the phone’s feature speciﬁcations (if available from

the service provider).

ONNECTION

Connect your phone to a computer or hand-held

device to send and receive data and fax calls on

the connected device. Connect your phone using a

serial cable or USB cable.

Menu Feature Descriptions

PRELIMINARY

Incoming Call

M> Settings

> Connection

> Incoming Call

Specify the format for the next incoming call. You can select

Fax In Only, Data In Only, or Normal.

N-

ALL

ETUP

Use the in-call setup menu to set the features that are

active during a call, such as the in-call timer and call

answering options.

In-Call Timer

M> Settings

> In-Call Setup

> In-Call Timer

Adjust call timer display and beep settings. You can set your

timer to beep at a selected interval during your calls. (60

seconds is the default.) You can also turn on or off a display

timer during calls as follows:

Answer Options

M> Settings

> In-Call Setup

> Answer Options

Turn call answering options on or off:

Time Display the elapsed time for the

current call.

Off Hide the in-call timer.

Multi-Key Answer by pressing any key.

Menu Feature Descriptions

PRELIMINARY

ECURITY

Lets you change the four-digit unlock code and a six-digit

security code that will prevent other users from accessing your

personal information or modifying your phone settings.

Phone Lock

M> Settings > Security

> Phone Lock

Lock and unlock your phone. See “Locking and Unlocking

Your Phone” on page 92.

Lock Keypad

M> Settings > Security

> Lock Keypad

Lock and unlock your keypad to prevent accidental

keypresses that might inadvertently dial an emergency

number or one-touch dial number.

Lock Application

M> Settings > Security

> Lock Application

Lock and unlock speciﬁc phone applications (such as

phonebook) so that users must enter the unlock code

before they can use the applications.

Restrict Calls

M> Settings > Security

> Restrict Calls

Stop all incoming and/or outgoing calls, or restrict outgoing

calls to the numbers stored in your phonebook.

You can still place calls to emergency numbers when

outgoing calls are restricted. Your phone still receives

incoming text messages when incoming calls are restricted.

Menu Feature Descriptions

PRELIMINARY

New Passwords

M> Settings > Security

> New Passwords

Change your unlock code or your security code (originally

set to 000000). See “Assigning a New Code or Password”

on page 92.

THER

ETTINGS

Use the other settings menu to view or adjust personal

options, the initial setup of your phone, the way your phone

connects to your service provider’s network, and the setup

of optional equipment needed for hands-free use.

Personalize

M> Settings

> Other Settings

> Personalize

Set several personal phone options:

Main Menu Change the order of the main menu.

See “Reordering Menu Items” on

page 90.

Keys Change the functions of the soft keys

in the idle display. See “Customizing a

Soft Key Function” on page 91.

Greeting Change the text displayed when you

turn on your phone.

Banner Change the text that appears in the

idle display.

Quick Dial Change quick dial number(s).

Menu Feature Descriptions

PRELIMINARY

Initial Setup

M> Settings

> Other Settings

> Initial Setup

Set many basic phone options:

Time and Date Set the phone’s time and date.

Auto PIN Dial Some networks require an

authenticating PIN to allow

outgoing calls. Use this

feature to automatically dial

your PIN.

Auto Redial Automatically redial calls that fail due

to busy network conditions.

Backlight Set the amount of time that the

display backlight remains on, or turn

off the backlight to conserve battery

power.

Zoom Switch between three lines

(Zoom Out) and two lines (Zoom In) of

display text.

Scroll Force the cursor to stop or wrap

around when it reaches the top or

bottom of a list in the display.

Animation Turn animation off (to conserve the

battery) or on. Animation makes your

phone’s menus move smoothly as you

scroll up and down.

Language Set the language for phone menus.

Menu Feature Descriptions

PRELIMINARY

Network

M> Settings

> Other Settings

> Network

View and adjust your phone’s network settings.

Your service provider registers your phone to a network. You

can view information about the current network, change

how your phone searches for a network, and turn on/off

alerts that indicate when a call is dropped or network

registration changes.

Contrast Adjust the contrast setting for your

display.

DTMF Switch DTMF tones to be long, short,

or off.

Master Reset Reset all options back to their original

factory settings

except

for the unlock

code, security code, and lifetime timer.

Master Clear Reset all options back to their original

factory settings

except

for the unlock

code, security code, and lifetime timer,

and

clear all user settings and entries.

Note: This option

erases all

user-entered information

stored in

your phone’s memory, including

phonebook entries. Once you erase

the information, it cannot be

recovered.

Menu Feature Descriptions

PRELIMINARY

Car Settings

M> Settings

> Other Settings

> Car Settings

Adjust hands-free settings for an optional

Motorola Original™ car kit you have purchased.

Note: The use of wireless devices and their accessories may

be prohibited or restricted in certain areas. Always obey the

laws and regulations on the use of these products.

Headset

M> Settings

> Other Settings

> Headset

Set your phone to automatically answer calls after

two rings when connected to a headset.

Auto Answer Set the car kit to automatically answer

calls after two rings.

Auto Handsfree Set your phone to detect and

automatically route calls to the car kit.

Power-Off Delay Specify the amount of time the car kit

delivers power to the phone after you

switch off the ignition.

Charger Time Specify the amount of time the car kit

uses your car battery to charge your

phone after you switch off the ignition.

PRELIMINARY

Phonebook

You can store a list of names and phone numbers or email

addresses in your phone’s electronic phonebook. You can view

these entries and call them directly from your phone.

For email addresses, you can send a text message

directly from your phone.

To see the list of names stored in your phonebook,

press M > Phonebook from the idle display. Scroll to a name

and press VIEW (+) to view details of the phonebook entry as

shown in the following display.

Fields in a Phonebook Entry

$*Carlo Emrys

215-433-7215

Speed No.15

BACK EDIT

Entry’s phone

number or

email address

Type

indicator

identiﬁes number

type:

Work

Home

Main

Mobile

Fax

Pager

[

Voice Name

indicator

indicates a recorded voice name Entry’s

Name

Edit entryPress

to open

the

Phonebook Menu

Return to list

Entry’s speed

dial number

Phonebook

PRELIMINARY

Storing a Phonebook Entry

A phone number is required for a phonebook entry. All other

information is optional.

Shortcut: Enter a phone number in the idle display, then press

STORE (+) to create a phonebook entry with the number in the

No. ﬁeld. Go directly to step 3 in the following procedure to

enter additional information and store the entry.

Enter Information

Find the Feature

M> Phonebook

M> New

Press To

S scroll to Phone Number or

Email Address

SELECT (+)select the type of entry

CHANGE (+)select Name

keypad keys enter a name for the phonebook

entry (see “Entering Text” on

page 42)

OK (+)store the name

CHANGE (+)select No. or Email

keypad keys enter the phone number or email

address

OK (+)store the phone number or email

address

Phonebook

PRELIMINARY

CHANGE (+)select Type

Note: This option is not available for

email entries. Your phone

automatically applies an [ (email)

type indicator when you enter an

email address.

S scroll to the type of phone number

SELECT (+)select the number type

RECORD (+)

Go to step 13 if

you do not want

to record a voice

name for the entry

record a voice name for the entry, if

desired

See “Recording a Voice Name For a

Phonebook Entry” on page 64.

S scroll to Speed No., the number to

speed dial

the entry

The next available speed dial number

is assigned to a new phonebook

number by default.

CHANGE (+)select Speed No. if you want to

change it

keypad keys enter a different speed number, if

desired

Press To

Phonebook

PRELIMINARY

Complete Phonebook Entry

When you are ﬁnished entering information for a phonebook

entry:

Recording a Voice Name For a

Phonebook Entry

You can record a voice name when you create a new phonebook

entry, or when you edit a previously stored phonebook entry. This

lets you use voice dial to call the number without dialing (see

“Voice Dial” on page 66).

Tip: Make your voice recording in a quiet location. Hold the

phone about four inches (10 centimeters) from your mouth, and

OK (+)save the modiﬁed speed number

If your chosen speed number is

already assigned to another entry,

you are asked if you want to replace

that entry.

SELECT (+)select MORE if you want to create

another entry with the same Name

Note: You must enter a name and

number to use this option.

Press To

DONE (-)store the entry and return to the

phonebook list

Press To

Phonebook

PRELIMINARY

speak directly into the phone’s microphone in a normal tone of

voice.

Dialing a Phonebook Entry

You can use the phonebook list, voice dial, speed dial, or

one-touch dial to call a number (or send a text message to an

Find the Feature

M> Phonebook

Do This To

Press S scroll to the entry that needs a

voice name

Press VIEW (+)display the entry’s detailed view

Press EDIT (+)edit the phonebook entry

Press S scroll to Voice Name

Press RECORD (+)begin the recording process

The phone displays Press Voice

key then say name.

Press and release the

voice key on the right

side of your phone and

say the entry’s name (in

two seconds)

record the voice name

The phone displays Press Voice

Key then REPEAT name.

Press the voice key and

repeat the name

conﬁrm the voice name

The phone displays Trained:

Voice Name.

Press DONE (-) store the voice name

Phonebook

PRELIMINARY

email address) stored in your phonebook. To use speed dial, see

“Dialing With Speed Dial” on page 31. To use one-touch dial,

see “Dialing With One-Touch Dial” on page 32.

Phonebook List

To call a number or send email to an entry in the phonebook list:

Voice Dial

To call a number or send an email using voice dial:

Find the Feature

M> Phonebook

Press To

S scroll to the entry you want to call

N send the call (for a phone number)

open a new message form with the

entry’s address in the To ﬁeld (for

email entries)

Do This Result

Press and release the

voice key on the right

side of your phone and

say the entry’s name (in

two seconds).

Your phone goes to the entry in

the phonebook list, repeats the

voice name, waits two seconds,

then automatically dials the call

(for a phone number) or opens a

new message form (for an email

address).

PRELIMINARY

Radio

You can use your phone to tune, store presets, and

listen to FM radio stations when the optional Motorola

Original™ FM Stereo Radio Headset accessory is

plugged into the phone’s accessory connector port.

Turning the Radio On and Off

Alternatively, you can use the following procedure:

Note: The Radio (+) soft key option and Radio menu feature

are displayed only when the FM Stereo Radio Headset is plugged

into the accessory connector port.

Tuning a Station

Press To

Radio (+)turn the radio on and off

Press To

M open the menu

S scroll to Radio

On (+) or Off (+)turn the radio on or off

Do This To

Press S

Press and hold S

scroll up or down to the next frequency

scroll up or down to the next available

stereo station

Radio

PRELIMINARY

Storing a Preset

To store a station to a preset that you can recall later:

Selecting a Preset

To select a preset radio station:

Sending and Receiving Calls With the

Radio On

Your phone interrupts the radio signal and rings or vibrates as

usual to notify you of an incoming call, message, or other event.

When you receive a call:

Do This To

Press and hold a number

key (1 to 9)

assign its preset number to the

tuned station

Press To

a number key (1 to 9) tune the station stored at that

preset location

Do This To

Press IGNORE (-)ignore the call

Press ANSWER (+)

Press the button on the

FM Stereo Radio Headset

microphone

answer the call

Note: You can use the FM

Stereo Radio Headset

microphone to converse with

the other party during a call.

Radio

PRELIMINARY

To end the call and resume the FM broadcast:

Turn the radio off before dialing outgoing calls from the phone

keypad. You do not have to turn off the FM radio feature to dial

emergency numbers, or numbers selected from your phonebook

or other lists.

Tip: To dial a recently called number, press N or the button on

the FM Stereo Radio Headset microphone to go to the dialed

calls list. For more information, see “Recent Calls” on page 49.

Do This To

Press O

Press and hold the button

on the FM Stereo Radio

Headset microphone

end the call

PRELIMINARY

Messages—Voicemail

You can listen to your voicemail messages by calling

your network voicemail phone number. Voicemail

messages are stored on the network—not on your

phone. Contact your service provider for more details.

Storing Your Voicemail Number

Store your voicemail number in your phone to make it faster and

easier to use voicemail. Your voicemail number is provided by

your service provider.

Receiving a New Voicemail Message

When you receive a voicemail message, your phone displays the

& (voice message waiting) indicator and a New VoiceMail

notiﬁcation. (Some networks only indicate when you have

messages, whether they are new or not.) If reminders are turned

on, your phone sends a reminder every ﬁve minutes until you

close the new message notiﬁcation, listen to the message, or

turn off your phone.

Find the Feature

M> Messages

M> VoiceMail Setup

Press To

keypad keys enter the phone number for your

voicemail

OK (+)store the number

Messages—Voicemail

PRELIMINARY

From the new message notiﬁcation:

Listening to a Voicemail Message

To listen to your voicemail messages at any time:

Your phone calls the voicemail phone number you stored. If you

do not have a voicemail number stored, the phone guides you

through storing a number.

Shortcut: You can also press and hold 1 to listen to your

voicemail message(s). A = (voicemail) indicator is printed on

the 1 key as a function reminder.

Turning Off the Voice Message Waiting

Indicator

When you receive a voicemail message, your phone displays the

& (voice message waiting) indicator until you listen to the

message. To clear the voice message waiting indicator manually,

you can reset the voicemail counter to zero.

Do This To

Press CALL (+)

Press and hold 1

call your voicemail phone number

and listen to the message

Find the Feature

M> Messages > VoiceMail

Find the Feature

M> Messages

M> Clear Count

PRELIMINARY

Messages—Text

Text messages are brief messages that you can send

and receive (such as Where are we meeting?).

Received messages appear on your phone display or

in your text message inbox.

Quick notes are pre-written text messages that you can

customize and send quickly.

Your text message inbox must be set up

before

you can send and

receive these messages. The total number of messages the inbox

can hold depends on the length of the messages, and the

number of other messages and drafts stored in your phone.

Setting Up the Text Message Inbox

Note: Your service provider may have already programmed the

text message inbox settings for you.

Find the Feature

M> Messages

M> Text Msg Setup

Press To

CHANGE (+)change the Cleanup setting

S scroll to the number of days that

messages should stay in the text

message inbox, or the number of

messages that should be kept in the

inbox

Messages—Text

PRELIMINARY

Receiving a Text Message

Note: Your text message inbox must be set up before you can

receive text messages.

When you receive a new message, your phone displays the X

(message waiting) indicator and a New message notiﬁcation,

and gives an alert. If reminders are turned on, your phone sends

a reminder every ﬁve minutes until you close the new message

notiﬁcation, read the message, or turn off your phone.

From the new message notiﬁcation:

SELECT (+) select the cleanup setting

If you select Custom, continue.

Otherwise, go directly to step 8 to

complete the procedure.

S scroll to the number of days or

messages

} (+) move to the type identiﬁer

S scroll to days or msgs

DONE (-) store the custom cleanup period

DONE (-)save the text message inbox settings

Press To

READ (+)open the message (or your text

message inbox if there are multiple

messages)

Press To

Messages—Text

PRELIMINARY

As memory space for storing messages gets close to full, the X

(message waiting) indicator ﬂashes and your phone displays

Memory is Low! when you receive a new message. When no

more messages can be stored, your phone displays Memory is

Full! and the network temporarily holds your new messages. To

receive these new messages, you must delete some existing

messages from your inbox, outbox, or drafts folder.

Reading, Locking, or Deleting a Text

Message

You can open your text message inbox to read, lock, or delete

messages at any time.

Messages in the text message inbox are sorted from newest to

oldest. The oldest messages are deleted automatically as

speciﬁed by the inbox cleanup setting (see “Setting Up the Text

Message Inbox” on page 72). If you want to save a message,

you should lock it to prevent it from being deleted during

cleanup.

Find the Feature

M> Messages > Text Msgs

Press To

S scroll to the message you want

(d = unread and urgent, n = read,

f = read and locked)

READ (+)open the message

Messages—Text

PRELIMINARY

Sending a Text Message

You can create and send a text message to one or more

recipients. The text message feature lets you manually enter each

recipient’s phone number or email address, or select one or more

numbers/addresses from the phonebook or recent calls lists.

Note: When you manually enter phone numbers or email

addresses in the To ﬁeld, you must insert a space between each

phone number/address. Press 1 one time, wait for the space

to appear, then enter the next phone number or email address.

SAVE (-)

DELETE (+)

close the message without changes

delete the message

open the Text Msg Menu and scroll

to other operations, such as Lock/

Unlock

Find the Feature

M> Messages

M> Create Message

Press To

CHANGE (+)select To

Press To

Messages—Text

PRELIMINARY

keypad keys enter one or more phone numbers or

email addresses where you want to

send the message

Tip: Remember to press 1 one

time to insert a space between each

phone number/address that you enter

manually.

BROWSE (+) select one or more phone numbers or

email addresses from the phonebook

or recent calls lists

OK (+)store the number(s) and/or email

address(es)

CHANGE (+)select Msg

keypad keys enter the text message (see “Entering

Text” on page 42)

Note: Message length is limited. A

two-digit counter at the top of the

display shows how many characters

are left.

OK (+)store the text message

CHANGE (+)select Priority

S scroll to the priority you want

SELECT (+)set the priority

CHANGE (+)select Call

Press To

Messages—Text

PRELIMINARY

Sending a Quick Note Text Message

Quick notes are short, pre-written text messages that you

can create, select, edit, and send quickly (for example,

Meet me at ...). You can also create new quick note messages

and store them for later use.

To send a quick note message:

keypad keys enter the number you want your

recipient to call back (the message’s

From ﬁeld)

OK (+)store the number

DONE (-)ﬁnish the message

Your phone displays

Send Message Now?

YES (-)

NO (+)

send the message

cancel the message or save it as a

draft

A saved message is stored in the

drafts folder, where you can edit it

and send it at a later time.

Find the Feature

M> Messages > Quick Notes

Press To

S scroll to the quick note

Press To

Messages—Text

PRELIMINARY

The Quick Note Menu includes the following options:

READ (+)read the quick note

M open the Quick Note Menu to

perform other procedures as

described in the following list

Option Description

New Open an editor where you can create a

new quick note.

Enter text and press OK (+) to save it as a

quick note.

Edit Open an editor where you can edit the

selected quick note.

Edit the quick note text and press OK (+)

to save your changes.

Delete Delete the selected quick note.

Press To

Messages—Text

PRELIMINARY

Send Open a new message, with the selected

quick note text in the Msg ﬁeld.

Complete the other ﬁelds in the message

(for details, see “Sending a Text Message”

on page 75).

To send the quick note to multiple

recipients, enter multiple phone numbers

and/or email addresses in the To ﬁeld as

described in step 2 of the procedure for

“Sending a Text Message” on page 75.

Option Description

PRELIMINARY

Voice Notes

The voice note feature lets you record personal messages or

phone calls. You can play back a voice note at any time. There

are no pre-recorded voice notes on your phone.

Recording a Voice Note

Use this procedure to record a voice note when the idle display is

visible, or use it during a phone call to record the call. Your

phone plays an alert tone to notify the other party that the call is

being recorded.

Note: Recording phone calls is subject to varying state and

federal laws regarding privacy and recording of conversations.

Tip: Make your voice recording in a quiet location. Hold the

phone about four inches (10 centimeters) from your mouth, and

speak directly into the phone’s microphone in a normal tone of

voice.

Do This Result

Press and hold the voice

key on the right side of

your phone for the duration

of the recording.

A tone sounds in the

earpiece and the phone

displays the Recording

Voice Note message.

Speak your voice note into

the phone while continuing

to hold the voice key.

The phone records the

message and displays a

recording timer.

Release the voice key to

stop recording.

The phone displays the voice

notes list number and the

total recording time.

Voice Notes

PRELIMINARY

Playing a Voice Note

To play a recorded voice note:

When an optional Motorola Original™ headset accessory or FM

Stereo Radio Headset accessory is connected to your phone,

voice note playback is automatically routed to the headset.

Tip: You can play a voice note while taking a call. It won’t be

transmitted to the other party.

Find the Feature

M> Voice Notes

Press To

S scroll to the voice note

PLAY (+)play the voice note

PRELIMINARY

Micro-Browser

The micro-browser lets you access Web pages on

your phone. Contact your service provider to set up

access, if necessary.

Starting a Micro-Browser Session

To open the micro-browser:

The micro-browser displays the home page set up by your service

provider.

Shortcut: If you open a text message with a Web address (URL)

embedded in it, you can press M > Go To to launch the

micro-browser and go directly to the URL. If more than one URL

is embedded, you can select one from a list.

If you are unable to establish a network connection with the

micro-browser, contact your service provider.

Find the Feature

M> Browser

Press To

S scroll to a bookmark or service

SELECT (+)select the service

Micro-Browser

PRELIMINARY

Interacting With Web Pages

You can perform the following operations on a Web page:

Do This To

Press Sscroll through a text message

Press S and then

SELECT (+)

scroll through and select items in a

list

Press keypad keys

and then OK (+)

enter requested information

Tip: Press * to delete one letter

at a time if you make a mistake.

Press S to scroll to a

phone number on a Web

page, then press N

call the number from the

micro-browser

Press *go back to the previous Web page

Press M open the Browser Menu

PRELIMINARY

Adjusting Your Settings

You can adjust a wide variety of phone settings to suit your

needs.

Ring Styles

Your phone rings or vibrates to notify you of an incoming call,

message, or other event. This ring or vibration is called an

alert

You can select one of ﬁve different alert styles:

The alert setting indicator in your display shows the current alert

style (see illustration on page 23).

Each alert style contains settings for ringer and keypad volume. It

also includes alert tone settings for different events: incoming

calls, text messages, voicemail messages, data calls, fax calls,

alarms, and reminders. You can modify the settings in each style.

Select an Alert Style

w Loud ring x Soft ring

y Vibrate u Ring and vibrate

t Silent

Find the Feature

M> Settings > Ring Styles

> Style

Press To

S scroll to the alert style you want to

use

Adjusting Your Settings

PRELIMINARY

Customize an Alert Style

You can customize an alert style by changing the alerts used for

speciﬁc events (such as incoming calls, text messages, etc.). Your

phone includes multiple preset alert tones and vibrations. Any

changes you make are saved to the current alert style.

Tip: This feature also lets you set the alert style’s ringer volume

and keypad volume.

Note:

Style

represents the name of the current alert style.

SELECT (+)select the alert style

The phone displays the

Changed: Style message.

Find the Feature

M> Settings > Ring Styles

Style

Detail

Press To

S scroll to the event for which you want

to set a new alert

CHANGE (+)select the event

The phone displays the list of

available alerts.

S scroll to the alert you want for the

event

Press To

Adjusting Your Settings

PRELIMINARY

Use the My Tones Feature

You can create custom alert tones for your phone. The tones you

create appear in the list of available alerts (see “Customize an

Alert Style” on page 85).

Creating a Tone

SELECT (+)select the alert

The phone displays the

Changed:

Event Alert

message.

Find the Feature

M> Settings > Ring Styles

> My Tones > [New Tone]

Press To

CHANGE (+)select Notes

keypad keys enter notes for the tone

OK (+)store the notes

CHANGE (+)select Name

keypad keys enter the name for the tone

OK (+)store the name

DONE (-)store the tone

Press To

Adjusting Your Settings

PRELIMINARY

Entering Notes

To create a new tone, use the keypad keys to enter each note in

turn. You can modify a note’s pitch, octave, or length by entering

an octave/note/length combination as described below:

Key Note or Option Description

1 1 set octave one

2 set octave two

3 set octave three

2 A note A

B note B

C note C

3 D note D

E note E

F note F

4 G note G

R rest

7 # sharp

b ﬂat

0 q quarter note or quarter rest

h half note or half rest

w whole note or whole rest

Adjusting Your Settings

PRELIMINARY

Enter a note as follows:

Task Action

Change the

octave

Set the new octave (1, 2, or 3)

before

selecting the note. The new octave applies

to the note and all following notes until

you change it again.

Select the note

(required)

Press a keypad key to enter a note.

Change a note to

a sharp or ﬂat

Enter a sharp or ﬂat (# or b)

after

selecting

the note.

Some sharps and ﬂats are played as

standard notes. For example, B# is the

same as C. Press S to scroll to valid

notes when entering a new note.

Change a note’s

length

Set the new length (q, h, or w)

after

selecting the note. The new length applies

to the note and all following notes until

you change it again.

Add a rest Enter one or more rests (R characters) as

needed in the tone sequence. You can set

the length of the rest by entering a q, h, or

w character

after

the rest, just as you can

for a note.

Listen to a new

tone as you

compose it

Press M to enter the Compose Menu,

and select Play All to play the notes you

have entered.

Adjusting Your Settings

PRELIMINARY

Playing a Tone

Editing a Tone

You cannot edit the standard tones included with your phone. To

edit a custom tone that you created:

Find the Feature

M> Settings > Ring Styles

> My Tones

Press To

S scroll to the tone you want

M open the My Tones Menu

S scroll to Play

SELECT (+) select Play

The phone displays the playback

meter and plays the tone.

PLAY (+)

CANCEL (-)

play the tone again

return to the my tones list

Find the Feature

M> Settings > Ring Styles

> My Tones

Press To

S scroll to the tone you want to edit

EDIT (+)open the tone details

S scroll to the details you want to edit

(Name or Notes)

Adjusting Your Settings

PRELIMINARY

Deleting a Tone

You cannot delete the standard tones included with your phone.

To delete a custom tone that you created:

Reordering Menu Items

You can customize the order of the items in your phone’s main

menu, depending upon your usage.

CHANGE (+)select the details you want to edit

keypad keys enter new text or notes

OK (+)store the details

Find the Feature

M> Settings > Ring Styles

> My Tones

Press To

S scroll to the tone you want

M open the My Tones Menu

S scroll to Delete

SELECT (+)select Delete

YES (-)conﬁrm the deletion

Find the Feature

M> Settings

> Other Settings

> Personalize > Main Menu

Press To

Adjusting Your Settings

PRELIMINARY

Customizing a Soft Key Function

You can relabel the soft keys (- and +) to access different

main menu items from the idle display.

Press To

S scroll to the menu item you want to

move

GRAB (+)grab the menu item you want to

move

S move the item up or down the menu

INSERT (+)insert the item in the new location

Find the Feature

M> Settings

> Other Settings

> Personalize > Keys

Press To

S scroll to Left or Right

CHANGE (+)open the key editor

S scroll to the new key function

CHANGE (+)conﬁrm the new function

The key will have the new function

whenever the phone is idle.

PRELIMINARY

Security

Assigning a New Code or Password

Your phone’s four-digit unlock code and the six-digit security

code (originally set to 000000) are set at the factory. Your service

provider may reset these numbers before you receive your

phone.

If your service provider has

not

reset these numbers, we

recommend that you change them to prevent other users from

accessing your personal information or modifying your phone

settings. The unlock code must contain four digits, and the

security code must contain six digits. Be sure to make a note of

the new numbers.

Locking and Unlocking Your Phone

You can lock your phone manually or set your phone to lock

automatically whenever you turn it off.

When you try to use a locked phone, it asks you to enter the

unlock code. A locked phone still rings or vibrates for incoming

calls or messages,

but you must unlock it to answer

You may be able to make emergency calls on your phone even

when it is locked. See “Dialing an Emergency Number” on

page 30.

Security

PRELIMINARY

Lock Your Phone Manually

Set Your Phone to Lock Automatically

You can set your phone to lock every time you turn it off:

Unlock Your Phone

At the Enter Unlock Code prompt:

Find the Feature

M> Settings > Security

> Phone Lock > Lock Now

Press To

keypad keys enter your four-digit unlock code

OK (+)lock the phone

Find the Feature

M> Settings > Security

> Phone Lock

> Automatic Lock > On

Press To

keypad keys enter your four-digit unlock code

OK (+)set the phone to lock automatically

Press To

keypad keys enter your four-digit unlock code

OK (+)unlock your phone

Security

PRELIMINARY

Locking and Unlocking Your Keypad

You can lock your phone keypad to prevent accidental use. This

feature is useful in situations where an accidental keypress might

inadvertently dial an emergency number or one-touch dial

number (for example, when carrying your phone in a purse or

pocket).

Note: Incoming calls and messages unlock the keypad.

Press To

M *lock or unlock your keypad

PRELIMINARY

Troubleshooting

Check these questions ﬁrst if you have problems with your

phone:

Question Answer

Is your phone set

up correctly?

Press M #. If you do not see your

phone number, contact your service

provider.

Is your battery

charged? Do you

see B in the

display?

The battery level indicator should have

at least one segment showing (C). If

it does not, recharge your battery. (See

“Charging the Battery” on page 18 and

“Battery Use” on page 26.)

Does the handset

have a signal?

Do you see j in

the display?

Make sure that your antenna is fully

extended (if applicable). The signal

strength indicator should have at least

one segment showing (1). If it does

not, move to an area with a stronger

signal to use your phone.

Is the earpiece

volume too low

or does the

phone not ring?

Press the upper volume key on the side

of the phone.

Troubleshooting

PRELIMINARY

The following refer to speciﬁc problems:

Has the phone

been damaged,

dropped, or

gotten wet?

Dropping your phone, getting it wet, or

using a non-Motorola battery or battery

charger can damage the phone. The

phone’s limited warranty does not cover

liquid damage or damage caused from

using non-Motorola accessories.

Was a

non-Motorola

battery or

battery charger

used?

Problem Solution

I pressed the

power key, but

nothing

happened.

Be sure to press and hold Pthe power

key until the display appears and you

hear an audible alert (this could take a

couple of seconds). If nothing happens,

check that a charged battery is

installed. (See “Installing the Battery”

on page 17.)

The display says:

Enter Unlock

Code. How do I

unlock my

phone?

Enter the factory-preset unlock code, or

the last four digits of your phone

number. (See “Locking and Unlocking

Your Phone” on page 92.) If this fails,

call your service provider (the company

that sends you your monthly wireless

service bill).

Question Answer

Troubleshooting

PRELIMINARY

I cannot send/

receive calls.

Make sure that your antenna is fully

extended (if applicable) and that you

have a phone signal (see the “Signal

Strength Indicator” item on page 23).

Avoid electrical or radio interference,

and obstructions such as bridges,

parking garages, or tall buildings.

Your phone also may have the

Restrict Calls feature turned on. If

you know the unlock code, you can

change this setting in the security menu

(M > Settings > Security).

I cannot open my

inbox.

Before you can use text or information

services messages, you must set up the

appropriate inbox. See “Setting Up the

Text Message Inbox” on page 72.

My phone’s

display is too

dark.

You can use the Contrast feature (see

page 59) to change the level of contrast

in your phone display.

You can also use the Backlight feature

(see page 58) to change the length of

time that your phone’s backlight display

stays on.

Problem Solution

Troubleshooting

PRELIMINARY

I am unable to

record a voice

note or voice

name.

Try moving to a quieter location to make

your voice recording. Hold the phone

about four inches (10 centimeters) away

from your mouth, and speak directly

into your phone’s microphone in a

normal tone of voice.

I launched the

micro-browser

but the display

says: Service Not

Available.

You may be in an area without service.

If you have wireless service, look in the

display for the digital signal indicator

(F). If you do not see the indicator, you

may be in an area that has only analog

service or no service at all. If you see the

digital signal indicator, you may be

connected to a digital network that

does not support Internet access.

I launched the

micro-browser

but the display

says: Data Server

Unavailable.

Try again in a few minutes. The servers

may be temporarily busy.

Problem Solution

PRELIMINARY

Programming Instructions

Follow this procedure if you need to program your phone’s

phone number or system ID.

Note: Programming is normally done by a trained technician at

the site of purchase. Users should not make changes other than

ones in the following procedure.

Before programming, ask your service provider for your:

• 10-digit MIN (Mobile Identiﬁcation Number)

• 8- to 15-digit IMSI (International Mobile Service Identiﬁer)

• 8- to 15-digit MDN (Mobile Directory Number)

• 5-digit AMPS SysID number

• 5-digit CDMA SysID number

Do This To

Press 7 4 6 6 3

# M M

(These keys spell P-H-O-N-E

+ # M M).

open the user activation

Press SELECT (+)select NAM1

Press the keypad keys for the

10-digit MIN

open the MIN display and

enter the new MIN

Press OK (+)store the new MIN

Similarly, enter appropriate numbers for the IMSI, MDN,

AMPS SysID, and CDMA SysID

Press DONE (-)close the NAM1 list

Press BACK (-)close the user activation

100

PRELIMINARY

Speciﬁc Absorption Rate

Data

This model phone meets the government’s

requirements for exposure to radio waves.

Your wireless phone is a radio transmitter and receiver. It is

designed and manufactured not to exceed limits for exposure to

radio frequency (RF) energy set by the U.S. Federal

Communications Commission for the United States and by

Health Canada for Canada. These limits are part of

comprehensive guidelines and establish permitted levels of RF

energy for the general population. The guidelines are based on

standards that were developed by independent scientiﬁc

organizations through periodic and thorough evaluation of

scientiﬁc studies. The standards include a substantial safety

margin designed to assure the safety of all persons, regardless of

age or health.

The exposure standard for wireless mobile phones employs a

unit of measurement known as the Speciﬁc Absorption Rate, or

SAR. The SAR limit set by the FCC and by Health Canada is 1.6

W/kg.1 Tests for SAR are conducted using standard operating

positions accepted by the FCC and by Industry Canada with the

phone transmitting at its highest certiﬁed power level in all

tested frequency bands. Although the SAR is determined at the

highest certiﬁed power level, the actual SAR level of the phone

while operating can be well below the maximum value. This is

because the phone is designed to operate at multiple power

levels so as to use only the power required to reach the network.

101

PRELIMINARY

In general, the closer you are to a wireless base station antenna,

the lower the power output.

Before a phone model is available for sale to the public in the

U.S. and Canada, it must be tested and certiﬁed to the FCC and

Industry Canada that it does not exceed the limit established by

each government for safe exposure. The tests are performed in

positions and locations (e.g., at the ear and worn on the body)

reported to the FCC and available for review by Industry Canada.

The highest SAR value for this model phone when tested for use

at the ear is TBD W/kg

2, and when worn on the body, as

described in this user guide, is TBD W/kg.

2 (Body-worn

measurements differ among phone models, depending upon

available accessories and regulatory requirements). While there

may be differences between the SAR levels of various phones

and at various positions, they all meet the governmental

requirements for safe exposure.

The FCC and Industry Canada have granted an Equipment

Authorization for this model phone with all reported SAR levels

evaluated as being in compliance with the FCC and Health

Canada RF exposure guidelines. SAR information on this model

phone is on ﬁle with the FCC and can be found under the Display

Grant section of:

http://www.fcc.gov/oet/fccid

after searching on FCC ID IHDT56BJ3. You may also refer to

Motorola’s Web site:

http://www.motorola.com/rfhealth

102

PRELIMINARY

Additional information on Speciﬁc Absorption Rates (SAR) can

be found on the Cellular Telecommunications & Internet

Association (CTIA) Web site:

http://phonefacts.net

or the Canadian Wireless Telecommunications Association

(CWTA) Web site:

http://www.cwta.ca

1. In the United States and Canada, the SAR limit for mobile phones

used by the public is 1.6 watts/kg (W/kg) averaged over one gram of

tissue. The standard incorporates a substantial margin of safety to

give additional protection for the public and to account for any

variations in measurements.

2. Additional related information includes the Motorola testing

protocol, assessment procedure, and measurement uncertainty

range for this product.

ITC01-064

103

PRELIMINARY

The U.S. Food and Drug

Administration's Center for Devices

and Radiological Health Consumer

Update on Mobile Phones

FDA has been receiving inquiries about the safety of mobile

phones, including cellular phones and PCS phones. The following

summarizes what is known—and what remains unknown—

about whether these products can pose a hazard to health, and

what can be done to minimize any potential risk. This

information may be used to respond to questions.

Why the concern?

Mobile phones emit low levels of radio frequency energy (i.e.,

radio frequency radiation) in the microwave range while being

used. They also emit very low levels of radio frequency energy

(RF), considered non-signiﬁcant, when in the stand-by mode. It

is well known that high levels of RF can produce biological

damage through heating effects (this is how your microwave

oven is able to cook food). However, it is not known whether, to

what extent, or through what mechanism, lower levels of RF

might cause adverse health effects as well. Although some

research has been done to address these questions, no clear

picture of the biological effects of this type of radiation has

emerged to date. Thus, the available science does not allow us to

conclude that mobile phones are absolutely safe, or that they are

unsafe. However, the available scientiﬁc evidence does not

demonstrate any adverse health effects associated with the use

of mobile phones.

104

PRELIMINARY

What kinds of phones are in question?

Questions have been raised about hand-held mobile phones, the

kind that have a built-in antenna that is positioned close to the

user's head during normal telephone conversation. These types

of mobile phones are of concern because of the short distance

between the phone's antenna—the primary source of the RF—

and the person's head. The exposure to RF from mobile phones

in which the antenna is located at greater distances from the

user (on the outside of a car, for example) is drastically lower

than that from hand-held phones, because a person's RF

exposure decreases rapidly with distance from the source. The

safety of so-called “cordless phones,” which have a base unit

connected to the telephone wiring in a house and which operate

at far lower power levels and frequencies, has not been

questioned.

How much evidence is there that hand-held mobile

phones might be harmful?

Brieﬂy, there is not enough evidence to know for sure, either

way; however, research efforts are on-going. The existing

scientiﬁc evidence is conﬂicting and many of the studies that

have been done to date have suffered from ﬂaws in their

research methods. Animal experiments investigating the effects

of RF exposures characteristic of mobile phones have yielded

conﬂicting results. A few animal studies, however, have

suggested that low levels of RF could accelerate the

development of cancer in laboratory animals. In one study, mice

genetically altered to be predisposed to developing one type of

cancer developed more than twice as many such cancers when

they were exposed to RF energy compared to controls. There is

much uncertainty among scientists about whether results

obtained from animal studies apply to the use of mobile phones.

105

PRELIMINARY

First, it is uncertain how to apply the results obtained in rats and

mice to humans. Second, many of the studies that showed

increased tumor development used animals that had already

been treated with cancer-causing chemicals, and other studies

exposed the animals to the RF virtually continuously—up to 22

hours per day.

For the past ﬁve years in the United States, the mobile phone

industry has supported research into the safety of mobile

phones. This research has resulted in two ﬁndings in particular

that merit additional study:

In a hospital-based, case-control study, researchers looked

for an association between mobile phone use and either

glioma (a type of brain cancer) or acoustic neuroma (a

benign tumor of the nerve sheath). No statistically

signiﬁcant association was found between mobile phone

use and acoustic neuroma. There was also no association

between mobile phone use and gliomas when all types of

types of gliomas were considered together. It should be

noted that the average length of mobile phone exposure in

this study was less than three years.

When 20 types of glioma were considered separately,

however, an association was found between mobile phone

use and one rare type of glioma, neuroepithelliomatous

tumors. It is possible with multiple comparisons of the same

sample that this association occurred by chance. Moreover,

the risk did not increase with how often the mobile phone

was used, or the length of the calls. In fact, the risk actually

decreased with cumulative hours of mobile phone use.

Most cancer causing agents increase risk with increased

exposure. An ongoing study of brain cancers by the

106

PRELIMINARY

National Cancer Institute is expected to bear on the

accuracy and repeatability of these results.1

Researchers conducted a large battery of laboratory tests to

assess the effects of exposure to mobile phone RF on

genetic material. These included tests for several kinds of

abnormalities, including mutations, chromosomal

aberrations, DNA strand breaks, and structural changes in

the genetic material of blood cells called lymphocytes. None

of the tests showed any effect of the RF except for the

micronucleus assay, which detects structural effects on the

genetic material. The cells in this assay showed changes

after exposure to simulated cell phone radiation, but only

after 24 hours of exposure. It is possible that exposing the

test cells to radiation for this long resulted in heating. Since

this assay is known to be sensitive to heating, heat alone

could have caused the abnormalities to occur. The data

already in the literature on the response of the

micronucleus assay to RF are conﬂicting. Thus, follow-up

research is necessary.2

FDA is currently working with government, industry, and

academic groups to ensure the proper follow-up to these

industry-funded research ﬁndings. Collaboration with the

Cellular Telecommunications Industry Association (CTIA) in

particular is expected to lead to FDA providing research

recommendations and scientiﬁc oversight of new CTIA-funded

research based on such recommendations.

Two other studies of interest have been reported recently in the

literature:

Two groups of 18 people were exposed to simulated mobile

phone signals under laboratory conditions while they

107

PRELIMINARY

performed cognitive function tests. There were no changes

in the subjects' ability to recall words, numbers, or pictures,

or in their spatial memory, but they were able to make

choices more quickly in one visual test when they were

exposed to simulated mobile phone signals. This was the

only change noted among more than 20 variables

compared.3

In a study of 209 brain tumor cases and 425 matched

controls, there was no increased risk of brain tumors

associated with mobile phone use. When tumors did exist in

certain locations, however, they were more likely to be on

the side of the head where the mobile phone was used.

Because this occurred in only a small number of cases, the

increased likelihood was too small to be statistically

signiﬁcant.4

In summary, we do not have enough information at this point to

assure the public that there are, or are not, any low incident

health problems associated with use of mobile phones. FDA

continues to work with all parties, including other federal

agencies and industry, to assure that research is undertaken to

provide the necessary answers to the outstanding questions

about the safety of mobile phones.

What is known about cases of human cancer that

have been reported in users of hand-held mobile

phones?

Some people who have used mobile phones have been

diagnosed with brain cancer. But it is important to understand

that this type of cancer also occurs among people who have not

used mobile phones. In fact, brain cancer occurs in the U.S.

population at a rate of about 6 new cases per 100,000 people

108

PRELIMINARY

each year. At that rate, assuming 80 million users of mobile

phones (a number increasing at a rate of about 1 million per

month), about 4800 cases of brain cancer would be expected

each year among those 80 million people, whether or not they

used their phones. Thus it is not possible to tell whether any

individual's cancer arose because of the phone, or whether it

would have happened anyway. A key question is whether the

risk of getting a particular form of cancer is greater among

people who use mobile phones than among the rest of the

population. One way to answer that question is to compare the

usage of mobile phones among people with brain cancer with

the use of mobile phones among appropriately matched people

without brain cancer. This is called a case-control study. The

current case-control study of brain cancers by the National

Cancer Institute, as well as the follow-up research to be

sponsored by industry, will begin to generate this type of

information.

What is FDA's role concerning the safety of mobile

phones?

Under the law, FDA does not review the safety of radiation-

emitting consumer products such as mobile phones before

marketing, as it does with new drugs or medical devices.

However, the agency has authority to take action if mobile

phones are shown to emit radiation at a level that is hazardous

to the user. In such a case, FDA could require the manufacturers

of mobile phones to notify users of the health hazard and to

repair, replace or recall the phones so that the hazard no longer

exists.

Although the existing scientiﬁc data do not justify FDA

regulatory actions at this time, FDA has urged the mobile phone

109

PRELIMINARY

industry to take a number of steps to assure public safety. The

agency has recommended that the industry:

• support needed research into possible biological effects of

RF of the type emitted by mobile phones

• design mobile phones in a way that minimizes any RF

exposure to the user that is not necessary for device

function

• cooperate in providing mobile phone users with the best

possible information on what is known about possible

effects of mobile phone use on human health

At the same time, FDA belongs to an interagency working group

of the federal agencies that have responsibility for different

aspects of mobile phone safety to ensure a coordinated effort at

the federal level. These agencies are:

• National Institute for Occupational Safety and Health

• Environmental Protection Agency

• Federal Communications Commission

• Occupational Health and Safety Administration

• National Telecommunications and Information

Administration

The National Institutes of Health also participates in this group.

In the absence of conclusive information about any

possible risk, what can concerned individuals do?

If there is a risk from these products—and at this point we do

not know that there is—it is probably very small. But if people

are concerned about avoiding even potential risks, there are

simple steps they can take to do so. For example, time is a key

110

PRELIMINARY

factor in how much exposure a person receives. Those persons

who spend long periods of time on their hand-held mobile

phones could consider holding lengthy conversations on

conventional phones and reserving the hand-held models for

shorter conversations or for situations when other types of

phones are not available.

People who must conduct extended conversations in their cars

every day could switch to a type of mobile phone that places

more distance between their bodies and the source of the RF,

since the exposure level drops off dramatically with distance. For

example, they could switch to:

• a mobile phone in which the antenna is located outside the

vehicle

• a hand-held phone with a built-in antenna connected to a

different antenna mounted on the outside of the car or built

into a separate package

• a headset with a remote antenna to a mobile phone carried

at the waist

Again, the scientiﬁc data do not demonstrate that mobile

phones are harmful. But if people are concerned about the radio

frequency energy from these products, taking the simple

precautions outlined above can reduce any possible risk.

Where can I ﬁnd additional information?

For additional information, see the following Web sites:

Federal Communications Commission (FCC) RF Safety

Program (select “Information on Human Exposure to RF Fields

from Cellular and PCS Radio Transmitters”):

http://www.fcc.gov/oet/rfsafety

111

PRELIMINARY

World Health Organization (WHO) International Commission

on Non-Ionizing Radiation Protection (select Qs & As):

http://www.who.int/emf

United Kingdom, National Radiological Protection

Board:

http://www.nrpb.org.uk

Cellular Telecommunications Industry Association (CTIA):

http://www.wow-com.com

U.S. Food and Drug Administration (FDA) Center for Devices

and Radiological Health:

http://www.fda.gov/cdrh/consumer/

1. Muscat et al. Epidemiological Study of Cellular Telephone Use and

Malignant Brain Tumors. In: State of the Science Symposium;1999

June 20; Long Beach, California.

2. Tice et al. Tests of mobile phone signals for activity in genotoxicity

and other laboratory assays. In: Annual Meeting of the

Environmental Mutagen Society; March 29, 1999, Washington,

D.C.; and personal communication, unpublished results.

3. Preece, AW, Iwi, G, Davies-Smith, A, Wesnes, K, Butler, S, Lim, E, and

Varey, A. Effect of a 915-MHz simulated mobile phone signal on

cognitive function in man. Int. J. Radiat. Biol., April 8, 1999.

4. Hardell, L, Nasman, A, Pahlson, A, Hallquist, A and Mild, KH. Use of

cellular telephones and the risk for brain tumors: a case-control

study. Int. J. Oncol., 15: 113-116, 1999.

FDA020400

PRELIMINARY

112

Warranty

Limited Warranty for Motorola Personal

Communications Products and Accessories

Purchased in the United States and Canada

I. What This Warranty Covers

Defects in materials and workmanship in the following new

“Products” manufactured, sold or certiﬁed by Motorola, with

which this limited warranty is included in/on the package:

(a) wireless cellular telephones, pagers and two-way radios that

operate via “Personal Radio Service” (such as Family Radio

Service and General Mobile Radio Service), together with

software imbedded in any of these products, and (b) subject to

the following exceptions, accessories or software sold for use

with these products.

• Battery Exception. This limited warranty extends only to

batteries in which the fully-charged capacity falls below

80% of rated capacity and batteries that leak;

• Software Exceptions. This limited warranty extends only to

physical defects in the media (such as CD-ROM) that

tangibly embodies each copy of any software sold and/or

certiﬁed by Motorola for use with Products. Software that is

not tangibly embodied in media and that is purchased

separately from Products (such as software that is

downloaded from the internet) comes “as is” and

without warranty.

PRELIMINARY

113

Warranty

II. What the Period of Coverage Is

Subject to the following exceptions, one year from the date the

Products are purchased by the ﬁrst end-user:

• 90-Day Warranty Exception. The warranty is for 90 days for:

(a) any software tangibly embodied in media or (b) any

accessories for two-way radios that are covered by this

warranty, as described in Section I, above.

• Limited Lifetime Warranty Exception. The warranty is a

limited lifetime warranty for the lifetime of ownership by

the ﬁrst end-user of the following products, only:

(a) decorative covers, including bezel, PhoneWrap™ or

case (any model); and (b) ear buds and boom headsets that

transmit mono sound through a wire connection (this does

not include ear buds or boom headsets that either transmit

stereo sound or that are wireless, or both).

• Repair/Replacement Exception. The warranty is for the

balance of the original warranty or for 90 days from the

date returned and delivered to the ﬁrst end-user, whichever

is longer.

III. Who is Covered

This warranty extends to you only if you are the ﬁrst end-user

purchaser.

IV. What We Will Do to Correct Warranty Problems

At no charge to you, we have the option to repair or replace the

Products that do not conform to the warranty, or to refund the

Products’ purchase price. We may use functionally equivalent

PRELIMINARY

Warranty

114

reconditioned/refurbished/pre-owned or new Products or parts.

No software updates are provided.

V. How to Get Warranty Service

PLEASE CALL US — DO NOT SHIP:

Accessories and software—call the number designated for the

product with which they are used.

You will receive instructions on how to ship the Products to

Motorola or our designated resource. If instructed to ship the

Products, you must ship them with freight, duties and insurance

prepaid. Regardless of where you are instructed to return the

Products, you must include: (a) a copy of your receipt, bill of sale

or other comparable proof of purchase; (b) a written description

of the problem; (c) the name of your service provider (if this

Product requires subscription service); (d) the name and location

of the installation facility (if applicable) and, most importantly;

(e) your address and telephone number. If requested, you must

also return all detachable parts such as antennas, batteries and

chargers. RETAIN YOUR ORIGINAL PROOF OF PURCHASE.

For Products we ask you ship to us, we will ship repaired or

replacement Products at our expense for the freight and

insurance, but at your expense for any duties. If additional

USA Canada

Cellular 1-800-331-6456 All Products

1-800-461-4575

Paging 1-800-548-9954

FRS Radios 1-800-353-2729 TTY (Text Telephone)

1-888-390-6456

TTY (Text Telephone)

1-888-390-6456

PRELIMINARY

115

Warranty

information is needed, please contact us at the telephone

number listed above.

VI. What This Warranty Does Not Cover

•Products that are operated in combination with

ancillary or peripheral equipment or software not

furnished or otherwise certiﬁed by Motorola for

use with the Products (“ancillary equipment”), or

any damage to the Products or ancillary equipment

as a result of such use. Among other things,

“ancillary equipment” includes batteries, chargers,

adaptors, and power supplies not manufactured or

supplied by Motorola. Any of these voids the

warranty.

• Someone other than Motorola (or its authorized service

centers) tests, adjusts, installs, maintains, alters, modiﬁes or

services the Products in any way. Any of these voids the

warranty.

• Rechargeable batteries that: (a) are charged by other than

the Motorola-approved battery charger speciﬁed for

charging such batteries; (b) have any broken seals or show

evidence of tampering; (c) are used in equipment other

than the Product for which they are speciﬁed; or (d) are

charged and stored at temperatures greater than 60

degrees centigrade. Any of these voids the warranty.

• Products that have: (a) serial numbers or date tags that

have been removed, altered or obliterated; (b) board serial

numbers that do not match each other, or board serial

numbers that do not match the housing; or

PRELIMINARY

Warranty

116

of these voids the warranty.

• Defects or damage that result from: (a) use of the Products

in a manner that is not normal or customary; (b) improper

operation or misuse; (c) accident or neglect such as

dropping the Products onto hard surfaces; (d) contact with

water, rain, extreme humidity or heavy perspiration;

(e) contact with sand, dirt or the like; or (f) contact with

extreme heat, or spills of food or liquid.

• Physical damage to the surface of the Products, including

scratches, cracks or other damage to a display screen, lens

or other externally exposed parts.

• Failure of Products that is due primarily to any

communication service or signal you may subscribe to or

use with the Products.

• Coil cords that are stretched or that have any broken

modular tabs.

• Leased Products.

Flat-rate repair rates may apply to Products not covered by this

warranty. To obtain information about Products needing repairs

that are not covered by this warranty, please call the telephone

number previously listed. We will provide information on repair

availability, rates, methods of payment, where to send the

Products, etc.

VII. Some Other Limitations

This is Motorola’s complete warranty for the Products,

and states your exclusive remedies. This warranty is

PRELIMINARY

117

Warranty

given in lieu of all other express warranties. Implied

warranties, including without limitation, the implied

warranties of merchantability and ﬁtness for a

particular purpose, are given only if speciﬁcally

required by applicable law. Otherwise, they are

speciﬁcally excluded.

No warranty is made as to coverage, availability, or

grade of service provided by the Products, whether

through a service provider or otherwise.

No warranty is made that the software will meet your

requirements or will work in combination with any

hardware or applications software products provided

by third parties, that the operation of the software

products will be uninterrupted or error free, or that all

defects in the software products will be corrected.

In no event shall Motorola be liable, whether in

contract or tort (including negligence) for damages in

excess of the purchase price of the Product, or for any

indirect, incidental, special or consequential damages

of any kind, or loss of revenue or proﬁts, loss of

business, loss of information or data, or other ﬁnancial

loss arising out of or in connection with the ability or

inability to use the Products, to the full extent these

damages may be disclaimed by law.

VIII. Patent and Software Provisions

At Motorola’s expense, we will defend you, and pay costs and

damages that may be ﬁnally awarded against you, to the extent

that a lawsuit is based on a claim that the Products directly

PRELIMINARY

Warranty

118

infringe a United States patent. Our obligation is conditioned on:

(a) you notifying us promptly in writing when you receive notice

of the claim; (b) you giving us sole control of the defense of the

suit and all negotiations for its settlement or compromise; and

likely to become, the subject of a claim of infringement of a

United States patent, you permit us, at our option and expense,

either to: procure for you the right to continue using the

Products; replace or modify them so that they become

non-infringing; or grant you a credit for such Products, as

depreciated, and accept their return. The depreciation will be an

equal amount per year over the lifetime of the Products, as

established by Motorola.

Motorola will have no liability to you with respect to any claim of

patent infringement that is based upon the combination of the

Products or parts furnished under this limited warranty with

ancillary equipment, as deﬁned in VI., above.

This is Motorola’s entire liability with respect to

infringement of patents by the Products.

IX. State Law and Other Jurisdiction Rights

Some states and other jurisdictions do not allow the exclusion or

limitation of incidental or consequential damages, or limitation

on the length of an implied warranty, so the above limitations or

exclusions may not apply to you.

This warranty gives you speciﬁc legal rights, and you may also

have other rights, which vary from jurisdiction to jurisdiction.

PRELIMINARY

119

Warranty

To obtain information on Motorola Personal Communications

Products, including warranty service, accessories and optional

Extended Warranties on selected Products, please call:

Accessories and software—call the telephone number

designated above for the product with which they are used.

DO NOT SHIP PRODUCTS TO THESE ADDRESSES —

INSTEAD PLEASE CALL.

To correspond with Motorola about Products, please write us at

http://www.motorola.com

or at:

ITC01-078

USA Canada

Cellular 1-800-331-6456 All Products

1-800-461-4575

Paging 1-800-548-9954

FRS Radios 1-800-353-2729 TTY (Text Telephone)

1-888-390-6456

TTY (Text Telephone)

1-888-390-6456

In the USA: In Canada:

Motorola, Inc. Motorola Canada Limited

600 North U.S. Highway 45 5875 Whittle Road

Libertyville, IL 60048 Mississauga, ON L4Z 2H4

120

PRELIMINARY

Export Law Assurances

This product is controlled under the export regulations of the

United States of America and Canada. The Governments of the

United States of America and Canada may restrict the

exportation or re-exportation of this product to certain

destinations. For further information contact the U.S.

Department of Commerce or the Canadian Department of

Foreign Affairs and International Trade.

121

PRELIMINARY

Index

accessories

standard 17

accessories, optional 9, 67, 81

accessory connector port 1

alert

creating 86–90

deﬁned 84

indicators 24, 84

type, selecting 85–86

alert setting indicator 24

deﬁned 84

alert style

customizing 85–86

deﬁned 84

setting 84–85

animation 58

antenna 20

application, locking 56

Attach Number feature 32

auto PIN dial 58

automatic redial

activating 58

using 28

backlight 58

banner text 57

battery

charging for ﬁrst time 18

charging with car kit 60

extending battery life

26–27, 58

installing 17–18

level indicator 24

meter 54

block cursor, deﬁned 41

browse text mode 42

browser alerts 52

browser.

See

micro-browser 53

call

alert style, setting 84–85

alert type, selecting 85–86

alert, creating 86–90

answer options 55

answering 21

attaching phone number to

preﬁx digits 32

call waiting 35

calling card 33

data call, setting 55

datebook, accessing 37

dialed calls list 34, 36, 50

emergency number 30

Index

122

PRELIMINARY

call (continued)

ending 20

fax call, setting 55

in-call timer 55

incoming call type, setting

message center, accessing

muting 36

placing 20

privacy 29

received calls list 34, 36, 49

receiving 21

restricting 56

secure connection 29

sending 20

three-way call 35

voice dial 34

Call Failed message 28

call timers 50

call waiting 35

caller ID 29

calling card call 33

calling line identiﬁcation.

See

caller ID

car kit 60

charging with car kit 60

clock 24

contrast 59

cursor 41

customer service, calling

51–52

customizing the menu 90

data call

connecting to external device

incoming call format, setting

date, setting 58

default passwords 92

dialed calls list 34, 36, 50

digital/analog signal indicator

display

animation 58

backlight 58

banner text 57

contrast 59

described 22–24

greeting 57

idle display 22

language 58

zoom 25, 58

drafts folder 53

DTMF tones 36, 59

123

Index

PRELIMINARY

earpiece

illustration 1

volume, adjusting 25

sending 75–77

storing address 61

emergency number 30

end key

functions 1, 20

menu functions 38

ending a call 20

Enter Unlock Code message

event alert 85–86

fax call

connecting to external device

incoming call format, setting

ﬂashing cursor, deﬁned 41

FM radio headset 52, 67

FM Stereo Radio Headset 81

for hands-free use 60

greeting, display 57

hands-free use 60

headset

FM radio 52, 67

FM Stereo Radio Headset 81

for hands-free use 60

jack 1

high-security connection 29

idle display, deﬁned 22

in use indicator 23

inbox, text message 72

in-call timer 55

Incoming Call message 29

incoming call type 55

indicators

alert setting 24, 84

battery level 24

digital/analog signal 23

in use 23

menu 22

message waiting 24, 74

ring alert 24, 84

roam 23

signal strength 23

Index

124

PRELIMINARY

indicators (continued)

silent alert 24, 84

vibrate alert 24, 84

voice message waiting 24,

70, 71

voice name 61

iTAP software

activating 46

entering words 47–48

jack for hands-free headset 1

key

end 1, 20, 38

left soft key 1, 38, 91

lock 94

menu 1, 21, 38

power 1, 19

right soft key 1, 38, 91

scroll 1, 38

send 1, 20, 21

voice 1, 65, 80

volume control 1, 38

keypad

volume, setting 85

keypad, answering calls with

language 58

left soft key

customizing 91

functions 1, 38

lock

applications 56

keypad 94

phone 92–93

lock application feature 56

loud ring alert 24, 84

making a call 20

master clear 59

master reset 59

Memory is Full! message 74

Memory is Low! message 74

customizing 90–91

entering text 42–48

features 49–53

language, setting 58

locking applications 56

My Tones Menu 89, 90

navigating 8, 38–39

Phonebook Menu 51, 61

Quick Note Menu 78–79

rearranging features 90–91

125

Index

PRELIMINARY

menu (continued)

scroll feature 58

Text Msg Menu 75

using features 8, 39–41

menu indicator 22, 24

menu key 1, 21, 38

message

deleting 74–75

drafts folder 53

inbox setup 72–73

locking 74–75

outbox 52

quick note 52, 77–79

reading 74–75

receiving, text 73–74

reminders 70, 73

sending 75–77

text 52, 72–77

voicemail 52, 70–71

message waiting indicator 24

ﬂashing 74

micro-browser

browser alerts 52

call a number from 83

deﬁned 53, 82

functions 83

go to previous page 83

starting 82

microphone 1

muting a call 36

my telephone number 36, 54

my tones 86–90

My Tones Menu 89, 90

’n’ character 33

network settings 59

notepad 50

numeric text mode 42

one-touch dialing 32

optional accessory, deﬁned 9

optional feature, deﬁned 9

outbox 52

passwords

changing 57, 92

default 92

pause character 33

phone

accessories, optional 9

accessories, standard 17

answer options 55

connecting to external device

date, setting 58

feature speciﬁcations 37, 54

Index

126

PRELIMINARY

phone (continued)

keypad, locking and

unlocking 94

language, setting 58

locking 92–93

muting a call 36

network settings 59

one-touch dialing 32

passwords 57, 92

secure connection 29

speciﬁcations 37, 54

speed dial, using 31

time, setting 58

turning on/off 19

unlocking 19, 92–93

voice dial 34

phone number

attaching to preﬁx digits 32

redialing 28

viewing your own 21, 36

voice dial 34

phonebook

attaching phone number to

preﬁx digits 32

dialing an entry number 65

email address 61

entry name 61

ﬁelds 61

number type indicator 61

one-touch dialing 32

phonebook (continued)

phone number 61

speed dial number 31, 61,

63–64

speed dial, using 31

storing an entry 62–64

voice name entry 64–65

voice name indicator 61

Phonebook Menu 51, 61

PIN code, dialing automatically

power key 1, 19

predictive text entry

activating 46

entering words 47–48

privacy, voice 29

quick dial

setting number 57

using 51–52

quick note 52, 77–79

deﬁned 72

Quick Note Menu 78–79

radio 52, 67–69

received calls list 34, 36, 49

receiving a call 21

127

Index

PRELIMINARY

recent calls

attaching phone number to

preﬁx digits 32

menu description 49

redial

automatic redial 28

busy number 28

reminders

text message 73

voicemail message 70

restricting calls 56

right soft key

customizing 91

functions 1, 38

ring alert

creating 86–90

indicators 24, 84

setting 84–85

type, selecting 85–86

ring and vibrate alert

indicator 84

ringer

setting 84–85

volume, adjusting 85

ringer volume 25

roam indicator 23

scroll feature 58

scroll keys 1, 38

secure connection 29

send key 1, 20, 21

sending a call 20

short message service.

See

message

signal strength indicator 23

silent alert indicator 24, 84

SMS.

See

message

soft keys

customizing 57, 91

functions 38

illustration 1

soft ring alert 24, 84

speed dial

changing number 63–64

number, deﬁned 31

using 31

standby time, increasing 26

style, alert

deﬁned 84

setting 84–85

symbol text mode 45–46

symbols, entering 45–46

tap method text entry 43–44

text

block cursor 41

browse mode 42

changing text mode 42

Index

128

PRELIMINARY

text (continued)

character chart 44

entering from keypad

42–48

ﬂashing cursor 41

iTAP software predictive text

entry 46–48

numeric mode 42

symbol chart 46

symbol mode 45–46

tap method 43–44

text message.

See

message

text mode, changing 42

Text Msg Menu 75

three-way call 35

time, setting 58

timers 50

travel charger 18

unlock

keypad 94

phone 92–93

vibrate alert

indicator 24, 84

setting 84–85

type, selecting 85–86

voice dial

dialing a number 34, 66

recording voice name

64–65

voice key

dialing a number 34

functions 1

recording a voice name 65

recording a voice note 80

voice message waiting indicator

24, 70, 71

voice name

deﬁned 64

phonebook indicator 61

recording 64–65

voice note

deﬁned 80

playing 81

recording 80

voice privacy 29

Voice Private message 29

voicemail 52, 70–71

volume

earpiece 25

keypad 85

ringer 25, 85

volume keys 1, 25, 38

129

Index

PRELIMINARY

wait character 33

warranty 112–119

Web pages

functions 83

viewing 82

zoom setting 25, 58

U.S. patent Re. 34,976

Index

130

PRELIMINARY

✂

PRELIMINARY

131

Wireless Phone Safety Tips

“Safety is your most important call!”

Your Motorola wireless telephone gives you

the powerful ability to communicate by voice—

almost anywhere, anytime, wherever wireless

phone service is available and safe conditions allow.

But an important responsibility accompanies the

beneﬁts of wireless phones, one that every user

must uphold.

When driving a car, driving is your ﬁrst

responsibility. If you ﬁnd it necessary to use your

wireless phone while behind the wheel of a car,

practice good common sense and remember the

following tips:

Get to know your Motorola wireless phone and its

features such as speed dial and redial. If available,

these features help you to place your call without taking your

attention off the road.

When available, use a hands-free device. If possible,

add an additional layer of convenience to your wireless

phone with one of the many Motorola Original™ hands-free

accessories available today.

✂

132

PRELIMINARY

Position your wireless phone within easy reach. Be

able to access your wireless phone without removing your

eyes from the road. If you receive an incoming call at an

inconvenient time, if possible, let your voice mail answer it

for you.

Let the person you are speaking with know you are

driving; if necessary, suspend the call in heavy trafﬁc

or hazardous weather conditions. Rain, sleet, snow, ice,

and even heavy trafﬁc can be hazardous.

If you receive an incoming call at an inconvenient

time do not take notes or look up phone numbers

while driving. Jotting down a “to do” list or going through

your address book takes attention away from your primary

responsibility—driving safely.

Dial sensibly and assess the trafﬁc; if possible, place

calls when you are not moving or before pulling into

trafﬁc. Try to plan calls when your car will be stationary. If

you need to make a call while moving, dial only a few

numbers, check the road and your mirrors, then continue.

Do not engage in stressful or emotional

conversations that may be distracting. Make people

you are talking with aware you are driving and suspend

conversations which have the potential to divert your

attention away from the road.

Use your wireless phone to call for help. Dial 9-1-1 or

other local emergency number in the case of ﬁre, trafﬁc

accident or medical emergencies.*

✂

133

PRELIMINARY

Use your wireless phone to help others in

emergencies. If you see an auto accident, crime in progress

or other serious emergency where lives are in danger, call

9-1-1 or other local emergency number, as you would want

others to do for you.*

Call roadside assistance or a special non-emergency

wireless assistance number when necessary. If you see

a broken-down vehicle posing no serious hazard, a broken

trafﬁc signal, a minor trafﬁc accident where no one appears

injured, or a vehicle you know to be stolen, call roadside

assistance or other special non-emergency wireless number.*

* Wherever wireless phone service is available.

✂

134

PRELIMINARY

Check the laws and regulations on the use of

wireless telephones and their accessories in the

areas where you drive. Always obey them. The

use of these devices may be prohibited or

restricted in certain areas.

For more information,

please call

1-888-901-SAFE

or visit the

CTIA Web site at

www.wow-com.com™

ITC00-011

Motorola Mobility T56BJ3 Portable Cellular/PCS Transceiver User Manual BJ EX08

Motorola Mobility LLC Portable Cellular/PCS Transceiver BJ EX08

ex08 Users Manual

Navigation menu

Namespaces

Views

Navigation
