APPLICANT: MOTOROLA, INC. FCC ID: IHDT56CA2

EXHIBIT 8

INSTRUCTION MANUAL

A preliminary draft copy of the Users Manual follows:

DIGITAL WIRELESS

TELEPHONE

User's Guide >

Welcome

Welcome to the world of Motorola digital wireless

communications! We are pleased that you have chosen the

Motorola 120t wireless phone.

Antenna

Display

Headset Jack

Insert headset

accessory.

End Key

End phone calls,

exit menu system.

Left Soft Key

Perform functions

identiﬁed by left

display prompt.

Earpiece

Menu Key

Voice Key

Record voice notes,

phonebook and

shortcut names.

Right Soft Key

Perform functions

identiﬁed by right

display prompt.

Send Key

Send and answer

calls, view recent

dialed calls list.

Accessory

Connector Port

Insert charger and

phone accessories.

Microphone

Power Key

Volume Keys

Adjust earpiece

and ringer volume.

Scroll Keys

Move through

menus and lists.

Personal Communications Sector

600 North U.S. Highway 45

Libertyville, Illinois 60048

1-800-331-6456 (United States)

1-888-390-6456 (TTY/TDD United States)

1-800-461-4575 (Canada)

www.motorola.com

(United States)

www.motorola.ca

(Canada)

MOTOROLA, the Stylized M Logo and all other trademarks indicated as

such herein are trademarks of Motorola, Inc. ® Reg. U.S. Pat. & Tm. Off.

TrueSync, Sidekick, Starﬁsh, and the Stylized Starﬁsh Logo are registered

trademarks of Starﬁsh Software, Inc., a wholly owned independent

subsidiary of Motorola, Inc. All other product or service names are the

property of their respective owners.

Software Copyright Notice

The Motorola products described in this manual may include copyrighted

Motorola and third party software stored in semiconductor memories or

other media. Laws in the United States and other countries preserve for

Motorola and third party software providers certain exclusive rights for

copyrighted software, such as the exclusive rights to distribute or

reproduce the copyrighted software. Accordingly, any copyrighted

software contained in the Motorola products may not be modiﬁed,

reverse-engineered, distributed, or reproduced in any manner to the

extent allowed by law. Furthermore, the purchase of the Motorola

products shall not be deemed to grant either directly or by implication,

estoppel, or otherwise, any license under the copyrights, patents, or

patent applications of Motorola or any third party software provider,

except for the normal, non-exclusive, royalty-free license to use that

arises by operation of law in the sale of a product.

Manual number: 6809438A79-O

Cover number: 8988485L49-O

✂

Menu Map

Main Menu

• Recent Calls

• Received Calls

• Dialed Calls

• Notepad

• Call Times

• Phonebook

• Datebook

• Quick Dial

• Radio

• Messages

• Create Msg

• Voicemail

• Text Msgs

• Quick Notes

• Outbox

• Drafts

• Ring Styles

• Style

•

Style

Detail

• My Tones

• Shortcuts

• Voice Notes

• Browser

• Calculator

• Games

• Settings

(see next page)

Shortcuts

Change display zoom:

Press

, then

press and hold

Lock/unlock keypad:

Press

Display my phone number:

Press

Go to dialed calls list:

Press

Exit menu system:

Press

Note: This is the standard phone

menu layout. You or your service

provider may have changed the

menu layout or changed some

feature names. Not all features

may be available for all users.

For example, the Radio feature on

the main menu (left) is displayed

only when the optional FM Stereo

Radio Headset accessory is

plugged into the accessory

connector port on your phone

(see phone illustration, page 1).

✂

Settings Menu

• Phone Status

• My Tel. Number

• Active Line

• Battery Meter

• Other Information

• Connection

• Incoming Call

• In-Call Setup

• In-Call Timer

• Answer Options

• Security

• Phone Lock

• Lock Keypad

• Lock Application

• Talk Secure

• Restrict Calls

• New Passwords

• Other Settings

• Personalize

• Main Menu

•Keys

• Greeting

• Quick Dial

• Initial Setup

• Time and Date

• Backlight

• Zoom

• TTY Setup

• Scroll

• Animation

• Language

• Battery Save

• Contrast

• DTMF

• Master Reset

• Master Clear

• Network

• Car Settings

• Headset

Contents

Menu Map

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3

About This Guide

. . . . . . . . . . . . . . . . . . . . . . . . . . . . .10

Safety and General Information

. . . . . . . . . . . . . . . . . .11

Getting Started

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18

What’s in the Box? . . . . . . . . . . . . . . . . . . . . . . . . . . .18

Installing the Battery . . . . . . . . . . . . . . . . . . . . . . . . . .18

Charging the Battery . . . . . . . . . . . . . . . . . . . . . . . . .19

Turning Your Phone On . . . . . . . . . . . . . . . . . . . . . . .21

Making a Call . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .21

Ending a Call . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .22

Answering a Call . . . . . . . . . . . . . . . . . . . . . . . . . . . .22

Seeing Your Phone Number . . . . . . . . . . . . . . . . . . . .22

About Your Phone

. . . . . . . . . . . . . . . . . . . . . . . . . . . . .23

Using the Display . . . . . . . . . . . . . . . . . . . . . . . . . . . .23

Zooming In and Out . . . . . . . . . . . . . . . . . . . . . . . . . .25

Adjusting Volume . . . . . . . . . . . . . . . . . . . . . . . . . . . .25

Battery Use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .25

Making and Answering Calls

. . . . . . . . . . . . . . . . . . . .28

Redialing a Number . . . . . . . . . . . . . . . . . . . . . . . . . .28

Using Caller ID . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .28

Using Talk Secure . . . . . . . . . . . . . . . . . . . . . . . . . . . .28

Returning an Unanswered Call . . . . . . . . . . . . . . . . .29

Calling an Emergency Number . . . . . . . . . . . . . . . . .29

Turning Off a Call Alert . . . . . . . . . . . . . . . . . . . . . . . .30

Canceling an Incoming Call . . . . . . . . . . . . . . . . . . . .30

Calling With Speed Dial . . . . . . . . . . . . . . . . . . . . . . .31

Calling With One-Touch Dial . . . . . . . . . . . . . . . . . . . .31

Contents

Calling a Number In a Text Message . . . . . . . . . . . . . 31

Additional Calling Features . . . . . . . . . . . . . . . . . . . . 32

Using Features While On a Call

. . . . . . . . . . . . . . . . . 33

Using Call Waiting . . . . . . . . . . . . . . . . . . . . . . . . . . . 33

Making a Three-Way Call . . . . . . . . . . . . . . . . . . . . . 33

Additional On-Call Features . . . . . . . . . . . . . . . . . . . 34

Using the Menu

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35

Navigating to a Feature . . . . . . . . . . . . . . . . . . . . . . . 35

Selecting a Feature Option . . . . . . . . . . . . . . . . . . . . 36

Entering Feature Information . . . . . . . . . . . . . . . . . . . 37

Entering Text

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39

Choosing a Text Mode . . . . . . . . . . . . . . . . . . . . . . . . 39

Using Tap Method . . . . . . . . . . . . . . . . . . . . . . . . . . . 40

Using Symbol Mode . . . . . . . . . . . . . . . . . . . . . . . . . 43

Using iTAP™ Software Predictive Text Entry Method 44

Menu Feature Descriptions

. . . . . . . . . . . . . . . . . . . . . 48

Recent Calls

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59

Viewing Received Calls or Dialed Calls . . . . . . . . . . . 59

Using the Notepad . . . . . . . . . . . . . . . . . . . . . . . . . . . 61

Viewing and Resetting Call Timers . . . . . . . . . . . . . . 61

Phonebook

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 64

Viewing Entry Details . . . . . . . . . . . . . . . . . . . . . . . . . 64

Storing a Phonebook Entry . . . . . . . . . . . . . . . . . . . . 65

Storing a PIN Code With the Phone Number . . . . . . 67

Recording a Voice Name For a Phonebook Entry . . . 69

Dialing a Phonebook Entry . . . . . . . . . . . . . . . . . . . . 70

Editing a Phonebook Entry . . . . . . . . . . . . . . . . . . . . 71

Deleting a Phonebook Entry . . . . . . . . . . . . . . . . . . . 71

Setting the Primary Number for a Phonebook Entry . 71

Checking Phonebook Capacity . . . . . . . . . . . . . . . . . 72

Sorting the Phonebook List . . . . . . . . . . . . . . . . . . . . 73

Contents

Datebook

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .75

Week View . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .75

Day View . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .76

Event View . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .76

Adding a Datebook Event . . . . . . . . . . . . . . . . . . . . . .77

Changing Event Information . . . . . . . . . . . . . . . . . . . .77

Copying an Event . . . . . . . . . . . . . . . . . . . . . . . . . . . .78

Deleting an Event . . . . . . . . . . . . . . . . . . . . . . . . . . . .79

Radio

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .80

Turning the Radio On and Off . . . . . . . . . . . . . . . . . .80

Tuning a Station . . . . . . . . . . . . . . . . . . . . . . . . . . . . .81

Storing a Preset . . . . . . . . . . . . . . . . . . . . . . . . . . . . .81

Selecting a Preset . . . . . . . . . . . . . . . . . . . . . . . . . . .81

Sending and Receiving Calls With the Radio On . . . .81

Messages—Voicemail

. . . . . . . . . . . . . . . . . . . . . . . . . .83

Storing Your Voicemail Number . . . . . . . . . . . . . . . . .83

Receiving a Voicemail Message . . . . . . . . . . . . . . . . .84

Listening to a Voicemail Message . . . . . . . . . . . . . . .84

Messages—Text

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .85

Setting Up the Text Message Inbox . . . . . . . . . . . . . .85

Receiving a Text Message . . . . . . . . . . . . . . . . . . . . .86

Reading, Locking, or Deleting a Text Message . . . . .87

Storing Sounds . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .90

Sending a Text Message . . . . . . . . . . . . . . . . . . . . . .91

Sending a Quick Note Text Message . . . . . . . . . . . . .93

Viewing the Status of Sent Text Messages . . . . . . . . .94

Ring Styles

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .95

Selecting a Ring Style . . . . . . . . . . . . . . . . . . . . . . . .95

Customizing a Ring Style . . . . . . . . . . . . . . . . . . . . . .95

Creating Alert Tones . . . . . . . . . . . . . . . . . . . . . . . . . .97

Setting Reminders . . . . . . . . . . . . . . . . . . . . . . . . . .104

Contents

Shortcuts

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 105

Standard Shortcuts . . . . . . . . . . . . . . . . . . . . . . . . . 105

Creating a Shortcut . . . . . . . . . . . . . . . . . . . . . . . . . 105

Using Shortcuts . . . . . . . . . . . . . . . . . . . . . . . . . . . . 107

Voice Notes

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 108

Recording a Voice Note . . . . . . . . . . . . . . . . . . . . . . 108

Viewing the Voice Notes List . . . . . . . . . . . . . . . . . . 109

Playing a Voice Note . . . . . . . . . . . . . . . . . . . . . . . . 110

Locking and Unlocking a Voice Note . . . . . . . . . . . . 112

Deleting a Voice Note . . . . . . . . . . . . . . . . . . . . . . . 113

Micro-Browser

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 114

Starting a Micro-Browser Session . . . . . . . . . . . . . . 114

Interacting With Web Pages . . . . . . . . . . . . . . . . . . . 115

Calculator

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 116

Calculating Numbers . . . . . . . . . . . . . . . . . . . . . . . . 116

Converting Currency . . . . . . . . . . . . . . . . . . . . . . . . 118

Games

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 119

Playing a Game . . . . . . . . . . . . . . . . . . . . . . . . . . . . 119

Game Options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 120

Blackjack . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 120

Falling Numbers . . . . . . . . . . . . . . . . . . . . . . . . . . . . 121

Video Poker . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 122

Adjusting Your Settings

. . . . . . . . . . . . . . . . . . . . . . . 124

Reordering Menu Items . . . . . . . . . . . . . . . . . . . . . . 124

Customizing a Soft Key Function . . . . . . . . . . . . . . . 124

TTY Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 125

Hands-Free Use . . . . . . . . . . . . . . . . . . . . . . . . . . . 127

Data Calls

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 131

Connecting Your Phone to an External Device . . . . 131

Sending a Data Call . . . . . . . . . . . . . . . . . . . . . . . . . 134

Receiving a Data Call . . . . . . . . . . . . . . . . . . . . . . . 135

Contents

Security

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .137

Assigning a New Code or Password . . . . . . . . . . . .137

If You Forget a Code or Password . . . . . . . . . . . . . .138

Locking and Unlocking Your Phone . . . . . . . . . . . . .139

Locking and Unlocking Your Keypad . . . . . . . . . . . .140

Restricting Calls . . . . . . . . . . . . . . . . . . . . . . . . . . . .140

Activating Talk Secure . . . . . . . . . . . . . . . . . . . . . . .142

Troubleshooting

. . . . . . . . . . . . . . . . . . . . . . . . . . . . .143

Programming Instructions

. . . . . . . . . . . . . . . . . . . . .152

Speciﬁc Absorption Rate Data

. . . . . . . . . . . . . . . . .154

Additional Health and Safety Information

. . . . . . . .157

Warranty

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .166

Product Registration

. . . . . . . . . . . . . . . . . . . . . . . . .173

Export Law Assurances

. . . . . . . . . . . . . . . . . . . . . . .173

Index

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .174

Wireless Phone Safety Tips

. . . . . . . . . . . . . . . . . . . .187

About This Guide

This user guide introduces you to the many features in

your Motorola wireless phone.

Navigating To a Menu Feature

Use the menu system to access your phone’s features.

This guide shows you how to select a menu feature as

follows:

This example shows that you must press

, scroll to

and select

Messages

, then scroll to and select

Text Msgs

Optional Features

This label identiﬁes an optional network or

subscription-dependent feature that may not be

offered by all service providers in all

geographical areas. Contact your service

provider for more information.

Optional Accessories

This label identiﬁes a feature that requires an

optional Motorola Original™ accessory.

Find the Feature

Messages

Text Msgs

Safety and General Information

Safety and General

Information

IMPORTANT INFORMATION ON SAFE AND EFFICIENT

OPERATION. READ THIS INFORMATION BEFORE USING

YOUR PHONE.

The information provided in this document supersedes the

general safety information contained in user guides published

prior to July 2000. For information regarding radio use in a

hazardous atmosphere please refer to the Factory Mutual

(FM) Approval Manual Supplement or Instruction Card, which

is included with radio models that offer this capability.

This device complies with Part 15 of the FCC Rules.

Operation is subject to the following two conditions:

(1) this device may not cause harmful interference, and

(2) this device must accept any interference received,

including interference that may cause undesired operation.

RF Operational Characteristics

Your phone contains a transmitter and a receiver. When it is

ON, it receives and transmits radio frequency (RF) energy.

The phone operates in the frequency range of 824 MHz to

849 MHz in analog and digital mode and 1850 MHz to 1910

MHz in digital mode.

When you communicate with your phone, the system handling

your call controls the power levels at which your phone

transmits. The output power level typically may vary over a

Safety and General Information

range from 0.00 watts to 0.35 watts in analog mode and 0.00

watts to 0.56 watts in digital mode.

Exposure To Radio Frequency Energy

Your Motorola phone is designed to comply with the following

national and international standards and guidelines regarding

exposure of human beings to radio frequency electromagnetic

energy:

•United States Federal Communications Commission,

Code of Regulations; 47 CFR part 2 sub-part J

•American National Standards Institute (ANSI) / Institute

of Electrical and Electronic Engineers (IEEE) C95.

1-1992

•Institute of Electrical and Electronic Engineers (IEEE)

C95.1-1999 Edition

•National Council on Radiation Protection and

Measurements (NCRP) of the United States, Report

86, 1986

•International Commission on Non-Ionizing Radiation

Protection (ICNIRP) 1998

•Ministry of Health (Canada) Safety Code 6. Limits of

Human Exposure to Radiofrequency Electromagnetic

Fields in the Frequency Range from 3 kHz to 300 GHz,

1999

•Australian Communications Authority

Radiocommunications (Electromagnetic

Radiation-Human Exposure) Standard 1999

To assure optimal phone performance and make sure human

exposure to radio frequency electromagnetic energy is within

Safety and General Information

the guidelines set forth in the above standards, always adhere

to the following procedures:

Portable Phone Operation and EME Exposure

Antenna Care

Use only the supplied or an approved replacement

antenna. Unauthorized antennas, modiﬁcations, or

attachments could damage the phone and may violate FCC

regulations.

Do NOT hold the antenna when the phone is in use.

Holding the antenna affects call quality and may cause the

phone to operate at a higher power level than needed.

Phone Operation

When placing or receiving a phone call, hold your phone

as you would a wireline telephone. Speak directly into

the microphone.

Body-Worn Operation

To maintain compliance with FCC/Health Canada RF

exposure guidelines, if you wear a phone on your body when

transmitting, always place the phone in a Motorola-supplied or

approved clip, holder, holster, case, or body harness for this

product. Use of non-Motorola-approved accessories may

exceed FCC/Health Canada RF exposure guidelines. If you

do not use one of the Motorola-supplied or approved

body-worn accessories, and are not using the phone held in

the normal use position, ensure the phone and its antenna

are at least one inch (2.5 centimeters) from your body

when transmitting.

Safety and General Information

Data Operation

When using any data feature of the phone, with or without an

accessory cable, position the phone and its antenna at

least one inch (2.5 centimeters) from your body.

Approved Accessories

For a list of approved Motorola accessories, visit our website

www.mot.com

Electromagnetic Interference/Compatibility

Note: Nearly every electronic device is susceptible to

electromagnetic interference (EMI) if inadequately shielded,

designed, or otherwise conﬁgured for electromagnetic

compatibility.

Facilities

To avoid electromagnetic interference and/or compatibility

conﬂicts, turn off your phone in any facility where posted

notices instruct you to do so. Hospitals or health care facilities

may be using equipment that is sensitive to external RF

energy.

Aircraft

When instructed to do so, turn off your phone when on board

an aircraft. Any use of a phone must be in accordance with

applicable regulations per airline crew instructions.

Medical Devices

Pacemakers

The Advanced Medical Technology Association recommends

that a minimum separation of 6 inches (15 centimeters) be

Safety and General Information

maintained between a handheld wireless phone and a

pacemaker. These recommendations are consistent with the

independent research by, and recommendations of, the

United States Food and Drug Administration.

Persons with pacemakers should:

•ALWAYS keep the phone more than six inches

(15 centimeters) from your pacemaker when the phone is

turned ON.

•NOT carry the phone in the breast pocket.

•use the ear opposite the pacemaker to minimize the

potential for interference.

•turn OFF the phone immediately if you have any reason

to suspect that interference is taking place.

Hearing Aids

Some digital wireless phones may interfere with some

hearing aids. In the event of such interference, you may

want to consult your hearing aid manufacturer to discuss

alternatives.

Other Medical Devices

If you use any other personal medical device, consult the

manufacturer of your device to determine if it is adequately

shielded from RF energy. Your physician may be able to assist

you in obtaining this information.

Safety and General Use While Driving

Check the laws and regulations on the use of phones in the

area where you drive. Always obey them.

Safety and General Information

When using your phone while driving, please:

•give full attention to driving and to the road.

•use hands-free operation, if available.

•pull off the road and park before making or answering a

call if driving conditions so require.

Operational Warnings

For Vehicles With an Air Bag

Do not place a portable phone in the area over an air bag or in

the air bag deployment area. Air bags inﬂate with great force.

If a portable phone is placed in the air bag deployment area

and the air bag inﬂates, the phone may be propelled with

great force and cause serious injury to occupants of the

vehicle.

Potentially Explosive Atmospheres

Turn off your phone prior to entering any area with a

potentially explosive atmosphere, unless the phone is a model

speciﬁcally identiﬁed as being “Intrinsically Safe.” Do not

remove, install, or charge batteries in such areas. Sparks in a

potentially explosive atmosphere can cause an explosion or

ﬁre resulting in bodily injury or even death.

Note: The areas with potentially explosive atmospheres

referred to above include fueling areas such as below decks

on boats, fuel or chemical transfer or storage facilities, areas

where the air contains chemicals or particles, such as grain,

dust, or metal powders, and any other area where you would

normally be advised to turn off your vehicle engine. Areas with

potentially explosive atmospheres are often but not always

posted.

Safety and General Information

Blasting Caps and Areas

To avoid possible interference with blasting operations, turn

OFF your phone when you are near electrical blasting caps, in

a blasting area, or in areas posted: “Turn off two-way radio.”

Obey all signs and instructions.

Operational Cautions

Antennas

Do not use any portable phone that has a damaged

antenna. If a damaged antenna comes into contact with your

skin, a minor burn can result.

Batteries

All batteries can cause property damage and/or bodily

injury such as burns if a conductive material such as

jewelry, keys, or beaded chains touches exposed

terminals. The conductive material may complete an

electrical circuit (short circuit) and become quite hot. Exercise

care in handling any charged battery, particularly when

placing it inside a pocket, purse, or other container with metal

objects.

ITC01-101

Getting Started

What’s in the Box?

Your wireless phone typically comes equipped with a

battery and a charger. Other accessory options can

customize your phone for maximum performance and

portability.

To purchase Motorola Original™ accessories, contact the

Motorola Customer Call Center at 1-800-331-6456 in the

United States or 1-800-461-4575 in Canada.

Installing the Battery

You must install and charge the battery to use your phone.

Your phone is designed to be used only with

Motorola Original batteries and accessories. We

recommend that you store batteries in their

protective cases when not in use.

Do This

1Remove the battery from its protective clear

plastic case.

Getting Started

Charging the Battery

New batteries are shipped partially charged. Before

you can use your phone, you need to install and charge

the battery, as indicated by the following instructions.

2If necessary, slide

down the battery

door release latch

and lift the door off

of the phone.

3Insert the battery,

printed arrows

ﬁrst, into the top of

the battery

compartment and

push down.

4Replace the battery door.

Do This

Release

latch

Getting Started

Some batteries perform best after several full charge/

discharge cycles.

Notes:

•When you charge the battery, the battery level

indicator in the upper right corner of the display

shows how much of the charging process is

complete.

•If the battery charge drops too low, your phone

may power off during a call, even when the charger is

connected. To avoid this possibility, do not make calls

while charging the battery.

Do This

1Plug the

travel

charger into

your phone

with the

release tab

facing up.

2Plug the other end of the travel charger into the

appropriate electrical outlet.

3When your phone indicates that the battery is

fully charged (

Charge Complete

), press the

release tab and remove the travel charger.

Release

tab

Getting Started

Turning Your Phone On

Making a Call

Do This To

1Press and hold

turn on your phone

2If necessary, enter

your four-digit

unlock code and

press

(

)

unlock your phone

The unlock code is

originally set to 1234. Your

service provider may

change this number

before you receive your

phone.

Press To

1keypad keys dial the phone number

Tip: If you make a mistake,

press

DELETE

(

) to delete

the last digit, or press and

hold

DELETE

(

) to clear all

digits.

make the call

Power

key

Getting Started

Ending a Call

Answering a Call

When you receive a call, your phone rings and/or vibrates

and displays an incoming call message.

Tip: If your phone is locked, you must unlock it to answer

the call.

Seeing Your Phone Number

Press To

end the call

Press To

ANSWER

(

)answer the call

Press To

see your phone number

About Your Phone

See page 1 for a basic phone diagram.

Using the Display

The

idle display

is the standard display that you see when

you are

not

on a call or using the menu.

Labels at the bottom corners of the display show the

current soft key functions. A

(menu) indicator at the

bottom center of the display indicates that you can

press

to enter the main menu.

12:00am

PH.BOOK MESSAGE

O,X&5E

Clock

➐

Battery

Level

Indicator

➌

In Use

Indicator

➍

Roam

Indicator

➎

Message

Waiting

Indicator

➏

Voice

Message

Waiting

Indicator

➓

Ring Style

Indicator

➊

Signal

Strength

Indicator

➋

Digital/

Analog

Signal

Indicator

➑

Active

line

Indicator

➒

Indicator

Soft Key Labels

About Your Phone

➊

Signal Strength Indicator Vertical bars show the

strength of the network connection. You cannot make or

receive calls when the

(no signal) indicator is displayed.

➋

Digital (

) or Analog (

) Signal

Indicator Shows whether you are receiving a

digital or analog signal.

➌

In Use Indicator Shows that a call is in progress.

➍

Roam Indicator Shows that your phone is

seeking or using another network system

outside your home network.

➎

Message Waiting Indicator Appears when

you receive a text message.

➏

Voice Message Waiting Indicator Appears

when you receive a voicemail message.

➐

Battery Level Indicator Vertical bars show the battery

charge level. Recharge the battery when you see

Low Battery

and hear the low battery alert.

➑

Active Line Indicator Shows the current

active phone line.

➒

Menu Indicator Indicates that you can press

to enter the main menu or open a feature sub-menu.

About Your Phone

➓

Ring Style Indicator Shows the ring style setting.

Zooming In and Out

Press and release

, then press and hold

to zoom

in and out on the display. Zoom in to increase text size,

zoom out to display more information.

You can also zoom in and out from the menu. See

page 55.

Adjusting

Volume

Press the up and down

volume keys to:

•increase and

decrease earpiece

volume during a call

•increase and decrease the ringer volume setting

when the idle display is visible

Battery Use

Battery performance depends on many factors,

including your wireless carrier’s network conﬁguration;

signal strength; the temperature at which you operate your

= loud ring

= soft ring

= vibrate

= vibrate and ring

= silent

Volume

keys

About Your Phone

phone; the features and/or settings you select and use;

and your voice, data, and other application usage patterns.

Battery Care

Caution: To prevent injuries or burns, do not allow metal

objects to contact or short-circuit the battery terminals.

To maximize your battery’s performance:

•Always use Motorola Original™ batteries and battery

chargers. The phone warranty does not cover damage

caused from using non-Motorola batteries and/or

battery chargers.

•New batteries or batteries that have been stored for

long periods of time may require a longer charge time.

•Maintain the battery at or near room temperature

when charging.

•Do not expose batteries to temperatures below

-10°C (14°F) or above 45°C (113°F). Always take your

phone with you when you leave your vehicle.

•When you do not intend to use a battery for a while,

store it uncharged in a cool, dark, dry place, such as a

refrigerator.

•Over extended periods of time, batteries gradually

wear down and require longer charging times. This is

normal. If you charge your battery regularly and

notice a decrease in talk time or an increase in

charging time, then it is probably time to purchase

a new battery.

About Your Phone

The rechargeable batteries that power this

product must be disposed of properly and may

need to be recycled. Refer to your battery’s label

for battery type. Contact your local recycling center for

proper disposal methods. Never dispose of batteries in a

ﬁre because they may explode.

Extending Battery Life

• Turn off your display backlight

The backlight uses power. To turn it off, see page 55.

• Minimize keypad-intense functions

Activities that require intensive keystroke use (such as

playing a game or using messaging) reduce your

phone’s talk and standby time. Lock the keypad when

storing the phone in your purse or pocket to avoid

unnecessary keypad and backlight activations. See

page 140.

Making and Answering Calls

Making and

Answering Calls

For basic instructions on how to make a call, end a call,

and answer a call, see pages 21–22.

Redialing a Number

If you hear an ordinary busy signal:

Using Caller ID

Calling line identiﬁcation

(caller ID) displays the

phone number for incoming calls.

The phone displays the caller’s name when the

name is stored in your phonebook, or

Incoming Call

when caller ID information is not available.

Using Talk Secure

When

talk secure

is activated, your phone always tries to

use a high-security connection to prevent others from

intercepting your calls. To activate talk secure, see

page 142.

Press To

hang up

redial the busy number

Making and Answering Calls

If a high-security connection is not available, your phone

uses a standard connection and displays

Line Not Secure

This message does not appear when caller ID or other

information is displayed.

Returning an Unanswered

Call

Your phone keeps a record of your unanswered calls, and

displays:

•the

(missed call) indicator

•

X Missed Calls

Y Unknown

, where

is the total

number of missed calls and

is the number of missed

calls with no caller ID information

Calling an Emergency Number

Your service provider programs one or more emergency

phone numbers, such as 911, that you can call under any

circumstances, even when your phone is locked.

Note: Emergency numbers vary by country. Your phone’s

preprogrammed emergency number(s) may not work in all

locations, and sometimes an emergency call cannot be

Press To

VIEW

(

)see the received calls list

select a call to return

make the call

Making and Answering Calls

placed due to network, environmental, or interference

issues.

Turning Off a Call Alert

You can turn off your phone’s incoming call alert before

answering the call.

Canceling an Incoming Call

While the phone is ringing or vibrating:

Depending on your phone settings and/or

service subscription, the call may be forwarded

to another number, or the caller may hear a

busy signal.

Press To

1keypad keys dial the emergency number

call the emergency number

Press To

either volume key turn off the alert

Press To

IGNORE

(

)cancel the incoming call

Making and Answering Calls

Calling With Speed Dial

Each entry you store in your phonebook is assigned a

unique

speed dial

number. To speed dial a phonebook

entry:

Calling With One-Touch Dial

To call phonebook entries 1 through 9, just press and hold

the one-digit speed dial number for one second.

We recommend that you reserve phonebook entry 1

(speed dial number 1) for storing and dialing your

voicemail number. In many cases, your service provider

has already done this for you. If necessary, see page 65 to

store your voicemail number for one-touch dial access.

Calling a Number In a Text

Message

To call a phone number embedded in a text

message that you receive:

Press To

1keypad keys enter the speed dial number

for the entry you want to call

submit the number

call the entry

Making and Answering Calls

Additional Calling Features

While dialing (with digits visible in the display), open the

Dialing Menu

to perform the following tasks:

You can also call a number using these features:

Press To

open the

Text Msg Menu

scroll to

Call Back

SELECT

(

)call the number

Press To

Attach Number

attach a number from the

phonebook or recent call lists

Send Message

open a new text message

with the number in the

ﬁeld

Do This To Call

Press and release the voice

key, then say a voice name a phonebook entry

using voice dial

To record a voice

name, see page 69.

Press

Recent Calls

Received Calls

Dialed Calls

entry to call

a missed call, or a

recent received or

dialed call

Voice

key

Using Features While On a Call

Using Features While

On a Call

Using Call Waiting

When you are on a call, an alert tone sounds to

indicate that you have received a second

call.

Making a Three-Way Call

During a call, you can call and connect a third

party for a three-way call. You cannot do this if

you already have a call on hold.

Press To

answer the new call

switch back to the ﬁrst call

Press To

1keypad keys dial the third party’s number

call the number

connect the two calls

end the entire call

Using Features While On a Call

Additional On-Call Features

Press To

MUTE

(

) (if available) or

Mute

mute the call

SPEAKER

(

) (if available)

Spkrphone On

activate an attached

speakerphone during an

active call

My Tel. Number

see your phone number

Send Tones

send a number to the

network as DTMF tones,

for credit card or

password calls

To activate DTMF tones,

see the “DTMF” option

on page 56.

Received Calls

Dialed Calls

view recent received or

dialed call numbers

Messages

view or send messages

Datebook

view datebook entries

Other Information

view phone

speciﬁcations

Using the Menu

Navigating to a Feature

Use these keys to move through the menu system:

Main Menu

)Recent Calls

)Phonebook

)EXIT)SELECT

Menu Key

Enter the menu

system, or open

a sub-menu,

when

appears in the

bottom center

of the display.

Right Soft Key

Perform the

function shown

in the lower

right corner of

the display

(usually

SELECT

the highlighted

menu item).

Left Soft Key

Perform the

function shown

in the lower left

corner of the

display (usually

EXIT

BACK

Scroll Keys

Scroll up or

down through

menus and lists.

and

Cycle through

and set the

value of the

highlighted

menu item.

End Key

Exit the menu

system without

making changes,

return to the

idle display.

Using the Menu

Selecting a Feature Option

Some features require you to select an item from a list:

•Press

to scroll up or down to highlight the item

you want.

•In a numbered list, press a number key to highlight the

item.

•In an alphabetized list, press a key multiple times to

cycle through the letters on the key and highlight the

closest matching list item.

Dialed Calls

10) John Smith

9) Mary Smith

BACK VIEW

Press

BACK

(

)

to go back to

the previous

screen.

Highlighted

item

Press

open the sub-menu. Press

VIEW

(

) to view

details of the highlighted item.

Using the Menu

Entering Feature Information

Some features require you to enter information:

•Enter numbers or text with the keypad.

•When an item has a list of possible values, press

to scroll through and select a value.

•When an item has a list of possible numeric values,

press a number key to set the value.

•If you enter or edit information and do not want to save

your changes, press

to exit without saving.

Entry Details

Name:John Smith

No.:2125551212

CANCEL CHANGE

Press

scroll down

to additional

items.

Highlighted

item

Press

CANCEL

(

) to exit

without making changes.

DONE

(

) appears when

you enter or edit information.

Press

CHANGE

(

)

to edit the

information.

Using the Menu

The message center lets you compose and send text

messages. A

ﬂashing cursor

shows where text will appear:

When you enter text using the standard tap method, the

ﬂashing cursor changes to a

block cursor

, and the soft

key functions change:

Msg:

CANCEL BROWSE

Press

BROWSE

(

)

to view and

insert a

quick note.

Press

CANCEL

(

) to exit

without making changes.

Flashing

cursor

indicates

insertion

point.

Press

to open

the sub-menu.

Msg:

DELETE OK

Press

(

)

to accept

and store

the text.

Press

DELETE

(

)

to delete the character

to the left of the insertion

point.

Block

cursor

indicates

current

highlighted

character.

After two seconds, the

block cursor reverts to a

ﬂashing cursor and moves

to the next position.

Entering Text

Multiple text entry methods make it easy for you to enter

names, numbers, and messages on your phone.

Choosing a Text Mode

Press

from any text entry screen to select a text

mode:

Note: The text mode you select remains active until

you change it by selecting another mode.

iTAP

Let the phone predict each word as you

enter it. See page 44.

Tap Method

Enter letters, numbers, and symbols by

pressing a key one or more times. See

page 40.

Numeric

Enter numbers only.

Symbol

Enter symbols only. See page 43.

Browse

Browse your phonebook or recent call

lists to select a name or number.

Entering Text

Using Tap Method

This is the standard mode for entering text on your phone.

Press

from any text entry screen and select the

Tap Method

menu option.

Do This To

1Press a number

key one or more

times

select a letter, number, or

symbol shown in the

“Character Chart” on page 42

2Continue

pressing number

keys

enter the remaining

characters

3Press

(

)store the text when you are

ﬁnished

Entering Text

General Text Entry Rules

Press a number key repeatedly to cycle through its

characters. See “Character Chart” on page 42.

•If you do not press a key for two seconds, the

character in the block cursor is accepted, and the

cursor moves to the next position.

Press a number

key as many

times as

necessary

to enter the

desired

character at

ﬂashing cursor

location.

)Msg

)

)CANCEL)BROWSE

Change

letter in

block cursor

to uppercase

or lowercase.

Press and hold

a number key

to cycle

between text

entry modes.

Move ﬂashing

cursor to the

left or right in

text message.

Entering Text

•The ﬁrst character of every sentence is capitalized.

(Press

down to force the character to lowercase

while it is highlighted by the block cursor).

•Your phone may support multiple languages. The

current language setting determines whether a new

message begins on the left or right side of the display.

You can switch languages within a message. Press

to select the text mode and language you want to

use.

Character Chart

Use this chart as a guide for entering spaces, letters,

numbers, and symbols with the tap method.

Note: This chart may not reﬂect the exact character set

available on your phone.

space

. 1 ? ! , @ _ & ~ : ; " -

( ) ' ¿ ¡ % £ $ ¥

a b c 2 á à â ã ç

d e f 3 é è ê ë

g h i 4 í î ï

j k l 5

m n o 6 ñ ó ô õ

p q r s 7

t u v 8

ü ú ù û

w x y z 9

+ - 0 x * / \ [ ] = > < # §

Entering Text

Using Symbol Mode

Your phone provides an alternate way to enter symbol

characters in a message. Press

from any text entry

screen and select the

Symbol

menu option.

Symbol Chart

Use this chart as a guide for entering characters in

symbol mode.

Do This To

1Press a number

key one time display its symbol options at

the bottom of the display

See “Symbol Chart” on

page 43.

2Press

Press the

number key

multiple times

highlight the symbol you want

3Press

SELECT

(

)

enter the symbol at the

ﬂashing cursor location

space

. ? ! , @ _ &

~ : ; " - ( ) ' ¿ ¡ %

£ $ ¥

@ _ \

/ : ;

" & '

Entering Text

Using iTAP™ Software

Predictive Text Entry Method

iTAP™ software provides a predictive text entry method

that lets you enter a word using one keypress per letter.

Press

from any text entry screen and select the

iTAP

menu option.

Enter Words

( ) [ ] { }

¿ ¡ ~

< > =

$ £ ¥

# % *

+ - x * / = > < # §

Do This To

1Press a number

key one time enter the ﬁrst letter of the

word

The letters associated with

the key are shown at the

bottom of the display.

2Press number

keys (one per

letter)

enter the rest of the word

Alternative words and letter

combinations are shown at

the bottom of the display. The

word choices are updated

with each keypress.

Entering Text

For example, to spell the word “act,” press

The display shows:

Enter Novel Words

You may enter a word that the iTAP software does not

recognize. If the word you want is not displayed:

3Press

highlight the word you want

4Press

SELECT

(

)

enter the word at the ﬂashing

cursor location

A space is automatically

inserted after the word.

Do This To

1Press

DELETE

(

)

one or more times

delete letters until you

see a letter combination

that matches the start of

the word

Do This To

Act Cat Bat Abu }

DELETE SELECT

Press

SELECT

(

) to

insert the highlighted word.

Press

DELETE

(

)

to clear the last letter.

Flashing

cursor

indicates

insertion

point.

Press

scroll and see

additional word

choices.

Entering Text

Punctuation

Capitalization

The ﬁrst word of a sentence is automatically

capitalized, with following words in lowercase.

2Press

highlight the letter or

letter combination

3Press

SELECT

(

then press

shift the text entry cursor

to the left and “lock” the

selected word portion

4Continue to enter

letters and highlight

letter combinations

spell the word

Press To

enter punctuation or other

characters as shown in the

“Character Chart” on page 42

Press To

change the words to initial

character capitalized, all

uppercase characters, or all

lowercase characters

Do This To

Entering Text

Enter Numbers

Delete Letters and Words

Place the cursor to the right of the text you want to delete,

and then do the following:

Do This To

1Enter the ﬁrst

digit and then

highlight it

put the iTAP software in

number entry mode

2Press number

keys add digits to the number

3Press

SELECT

(

)

enter the number at the

ﬂashing cursor location

Do This To

Press

DELETE

(

)delete one letter at a time

Hold

DELETE

(

)delete the entire message

Menu Feature Descriptions

Menu Feature

Descriptions

This chapter describes all of your phone’s features in order

of the menu map shown on pages 3–4.

Main Menu

ECENT

ALLS

Received Calls

Recent Calls

Received Calls

View a list of recently received calls. See page 59.

Dialed Calls

Recent Calls

Dialed Calls

View a list of recently dialed calls. See page 59.

Notepad

Recent Calls

Notepad

Call or store the last number entered on the keypad.

See page 61.

Call Times

Recent Calls

Call Times

View call timers that track time spent on

your last call, dialed calls, received calls,

all calls since reset, and all calls total. See page 61.

HONEBOOK

Phonebook

Store names and numbers as entries in your

phonebook, then call numbers by selecting them

from the phonebook list. See page 64.

Menu Feature Descriptions

ATEBOOK

Datebook

Use the datebook calendar to schedule and review

your appointments. See page 75.

UICK

IAL

Quick Dial

Dial pre-programmed numbers. Your

service provider may program your phone

with one or more quick dial numbers, such

as the customer service number. You can call them

by selecting them from the quick dial list.

Note: Your service provider may use a different

name for this feature.

ADIO

Radio

Listen to FM radio stations with the optional

Motorola Original™ FM Stereo Radio

Headset accessory. This menu feature is

displayed only when the FM Stereo Radio Headset

is plugged into the accessory connector port on

your phone. See page 80.

ESSAGES

Messages

Adjust message settings, view and

manage the various types of messages

your phone can receive and/or send:

Create Msg

Create new text messages.

See page 91.

Voicemail

Listen to your recorded

voice messages. See

page 83.

Menu Feature Descriptions

ING

TYLES

Style

Ring Styles

Style

Select the ring style your phone uses to notify you

of incoming calls, messages, or other events. See

page 95.

Style Detail

Ring Styles

Style

Detail

Change details about the current ring style.

Style

represents the name of the ring style. See page 95.

My Tones

Ring Styles

My Tones

Create custom alert tones for your phone. See

page 97.

HORTCUTS

Shortcuts

Create keypad or voice shortcuts to menu features.

See page 105.

Text Msgs

Read and manage text

messages. See page 85.

Quick Notes

Select and send pre-written

messages from the quick

notes list. See page 93.

Outbox

View all outgoing text

messages, delivered and

undelivered.

Drafts

Store and edit text

messages that you have

written but not sent.

Menu Feature Descriptions

OICE

OTES

Voice Notes

Use the voice key to record messages and phone

calls. See page 108.

Note: Recording phone calls is subject to varying

state and federal laws regarding privacy and

recording of conversations.

ROWSER

Browser

Access Web pages and run Web-based

applications. The micro-browser delivers

WAP (Wireless Application Protocol)

pages from your service provider directly to your

phone. See page 114.

ALCULATOR

Calculator

Use your phone as a calculator or currency

converter. See page 116.

AMES

Games

Play games on your phone. See page 119.

Settings Menu

HONE

TATUS

My Tel. Number

Settings

Phone Status

My Tel. Number

View, enter, and edit information about your

name and phone number.

Menu Feature Descriptions

Active Line

Settings

Phone Status

Active Line

Change the active phone line to send and receive

calls from either of the available numbers.

Battery Meter

Settings

Phone Status

Battery Meter

View a detailed battery charge meter.

Other Information

Settings

Phone Status

Other Information

View your phone’s feature speciﬁcations

(if available from the service provider).

ONNECTION

Connect your phone to a computer or

hand-held device to send and receive data

calls on the connected device. See

page 131.

Incoming Call

Settings

Connection

Incoming Call

Specify the format for the next incoming call. You

can select

Data In Only

Normal

. See page 135.

N-

ALL

ETUP

Set the features that are active during a call, such

as the in-call timer and call answering options.

Menu Feature Descriptions

In-Call Timer

Settings

In-Call Setup

In-Call Timer

Adjust call timer

Display

and

Beep

settings. You can

set your timer to beep at a selected interval during

your calls. (60 seconds is the default.) You can also

turn on or off a display timer during calls as follows:

Answer Options

Settings

In-Call Setup

Answer Options

Turn call answering options on or off:

ECURITY

Phone Lock

Settings

Security

Phone Lock

Lock and unlock your phone. See page 139.

Lock Keypad

Settings

Security

Lock Keypad

View instructions on how to lock and unlock your

keypad. See page 140.

Lock Application

Settings

Security

Lock Application

Lock and unlock speciﬁc phone applications

(such as phonebook or datebook). When an

application is locked, users must enter the unlock

code to use the application.

Time

Display the elapsed time for

the current call.

Off

No in-call timer display.

Multi-Key

Answer by pressing any key.

Menu Feature Descriptions

Talk Secure

Settings

Security

Talk Secure

Activate a secure connection to prevent others from

intercepting your calls. See pages 28 and 142.

Restrict Calls

Settings

Security

Restrict Calls

Restrict incoming and outgoing calls. See

page 140.

New Passwords

Settings

Security

New Passwords

Change your unlock code (originally set to 1234) or

your security code (originally set to 000000). See

page 137.

THER

ETTINGS

Personalize

Settings

Other Settings

Personalize

Set several personal phone options:

Main Menu

Change the order of the

main menu. See page 124.

Keys

Change the functions of the

soft keys in the idle display.

See page 124.

Greeting

Change the text

displayed when

you turn on your

phone.

Menu Feature Descriptions

Initial Setup

Settings

Other Settings

Initial Setup

Set many basic phone options:

Quick Dial

Change quick dial

number(s).

Time and Date

Set the phone’s time and

date.

Backlight

Set the amount of time that

the display backlight

remains on, or turn off the

backlight to conserve

battery power.

Zoom

Switch between three lines

(

Zoom Out

) and two lines

(

Zoom In

) of display text.

TTY Setup

Set your phone to

operate in one of

three TTY modes,

or return to normal

Voice

mode. See page 125.

Scroll

Force the cursor to stop or

wrap around when it

reaches the top or bottom of

a list in the display.

Menu Feature Descriptions

Animation

Turn animation off (to

conserve battery power) or

on. Animation makes your

phone’s menus move

smoothly as you scroll up

and down.

Language

Set the language for phone

menus.

Battery Save

Adjust the phone’s power

usage characteristics to

conserve power.

Contrast

Adjust the contrast setting

for your display.

DTMF

Your phone can send a

number to the network as

dual tone multi-frequency

(DTMF) tones. DTMF tones

are used to communicate

with automated systems

that require you to enter a

number such as a code,

password, or credit card

number. Use this option to

set DTMF tones on or off.

Master Reset

Reset all options back to

their original factory settings

except

for the unlock code,

security code, and lifetime

timer.

Menu Feature Descriptions

Network

Settings

Other Settings

Network

View and adjust your phone’s network

settings.

Your service provider registers your phone to a

network. You can view information about the current

network, change how your phone searches for a

network, and activate alerts that indicate when a

call is dropped or network registration changes.

Car Settings

Settings

Other Settings

Car Settings

Adjust hands-free car kit settings.

You can set your phone to route calls directly to the

car kit when it detects a connection, and

Master Clear

Reset all options back to

their original factory settings

except

for the unlock code,

security code, and lifetime

timer,

and

clear all user

settings and entries.

Note: This option

erases all

user-entered information

stored in your phone’s

memory, including

phonebook and datebook

entries. Once you erase the

information, it cannot be

recovered.

Menu Feature Descriptions

automatically answer calls after two rings. See

page 127.

Note: The use of wireless devices and their

accessories may be prohibited or restricted in

certain areas. Always obey the laws and regulations

on the use of these products.

Headset

Settings

Other Settings

Headset

Set your phone to automatically answer

calls after two rings when connected to a headset.

See page 127.

Recent Calls

Viewing Received Calls or

Dialed Calls

Your phone keeps a list of the calls you recently received

and dialed, even if the calls did not connect. The lists are

sorted from newest to oldest entries. The oldest entries are

deleted as new ones are added.

Shortcut: Press

to go directly to the dialed calls list

from the idle display.

Find the Feature

Recent Calls

Press To

scroll to

Received Calls

Dialed Calls

SELECT

(

)select the list

scroll to an entry

Note:

means the call

connected.

Recent Calls

The

Last Calls Menu

includes the following options:

VIEW

(

)

call the entry’s number

view entry details

open the

Last Calls Menu

perform other procedures as

described in the following list

Option Description

Store

Create a phonebook entry with

the number in the

No.

ﬁeld.

Delete

Delete the entry.

Delete All

Delete all entries in the list.

Send Message

Open a new text message with

the number in the

ﬁeld.

Add Digits

Add digits after the number.

Attach Number

Attach a number from the

phonebook or recent call lists,

after the highlighted number.

Send Tones

Send the number to the network

as DTMF tones, for credit card or

password calls.

Press To

Recent Calls

Using the Notepad

Your phone stores the most recent string of digits

entered on the keypad in a temporary memory location

called the

notepad

. This can be a phone number that

you called, or a number that you entered but did not

call. To retrieve the number stored in the notepad:

Viewing and Resetting Call

Timers

Network connection time

is the elapsed time from the

moment you connect to your service provider's network to

the moment you end the call by pressing

. This time

includes busy signals and ringing.

Find the Feature

Recent Calls

Notepad

Press To

STORE

(

)

call the number

open the

Dialing Menu

attach a number or insert a

special character

create a phonebook entry

with the number in the

No.

ﬁeld

Recent Calls

The amount of network connection time you track on

your resettable timer may not equal the amount of

time for which you are billed by your service

provider. For billing information, please contact

your service provider directly.

You can view the following network

connection times:

Timer Description

Last Call

Time spent on last dialed or

received call. You cannot reset this

timer.

Dialed Calls

Time spent on dialed calls since

the last time you reset this timer.

Received Calls

Time spent on received calls

since the last time you reset this

timer.

All Calls

Time spent on dialed and

received calls since the last time

you reset this timer.

Lifetime

Time spent on all calls on this

phone. You cannot reset this timer.

Recent Calls

To view a call timer:

To reset the call timer:

Find the Feature

Recent Calls

Call Times

Press To

scroll to the timer you want\

SELECT

(

)view the recorded time

Press To

RESET

(

)reset the time (if available)

YES

(

)conﬁrm the reset

Phonebook

You can store a list of names and phone numbers or email

addresses in your phone’s electronic phonebook.

To see the names in your phonebook, press

Phonebook

from the idle display. Scroll to a name

and press

VIEW

(

) to view details of the phonebook

entry as shown below.

Viewing Entry Details

Note: When you set a distinctive ringer alert for an entry,

the

Ringer ID

setting appears below the speed dial number.

$*Carlo Emrys

2154337215

Speed No.15

BACK EDIT

Entry’s

phone

number

email address

Type

indicator

identiﬁes

number type:

Work

Home

Main

Mobile

Fax

Pager

[

Voice Name

indicator

indicates a recorded

voice name Entry’s

Name

Edit

entry

Press

to open the

Phonebook

Return

to list

Entry’s speed

dial number

Phonebook

Storing a Phonebook Entry

A phone number or email address is required for a

phonebook entry. All other information is optional.

Shortcut: Enter a phone number in the idle display, then

press

STORE

(

) to create a phonebook entry with the

number in the

No.

ﬁeld. Go directly to step 3 to continue.

Enter Information

Find the Feature

Phonebook

New

Press To

scroll to

Phone Number

Email Address

SELECT

(

)select the entry type

CHANGE

(

)select

Name

4keypad keys enter a name for the entry

(

)store the name

CHANGE

(

)select

No.

7keypad keys enter the phone number or

email address

Tip: You can store a PIN code

with the phone number. See

page 67.

(

)store the phone number or

email address

Phonebook

CHANGE

(

)select

Type

Note: This option is not

available for email entries.

scroll to the number type

SELECT

(

)select the number type

RECORD

(

)

Go to step 13 if

you do not want

a voice name

record a voice name for the

entry, if desired (see page 69)

scroll to

Speed No.

The next available speed dial

number is assigned to a new

phonebook entry.

CHANGE

(

)select

Speed No.

if you want

to change it

15 keypad keys enter a different speed dial

number, if desired

(

)store the speed dial number

CHANGE

(

)select

Ringer ID

if you want to

assign a distinctive ringer

alert for the phone number

Your phone uses the alert to

notify you when you receive a

call from this phone number.

See page 96.

Press To

Phonebook

Complete Phonebook Entry

When you are ﬁnished entering information for a

phonebook entry:

Storing a PIN Code With the

Phone Number

You can store a PIN code with the phone number for calls

that require additional digits (for example, to make a calling

card call, or to retrieve voicemail or answering machine

messages). Insert one or more of the following characters

scroll to the alert you want

SELECT

(

)store the ringer ID alert

SELECT

(

)select

if you want to

create another entry under

the same

Name

You must use a different

Type

identiﬁer for each number.

Press To

DONE

(

)store the entry

Press To

Phonebook

in the dialing sequence to ensure that the number dials

and connects properly:

Note: You can store a maximum of 32 digits per number.

Each character counts as one digit.

Press To

Insert Pause

insert a

(pause) character

Your phone dials the

preceding digits, waits for the

call to connect, then sends

the remaining digit(s).

Insert Wait

insert a

(wait) character

Your phone dials the

preceding digits, waits for the

call to connect, then prompts

you for conﬁrmation before it

sends the remaining digit(s).

Insert 'n'

insert an

(number)

character

Your phone prompts you for a

number before dialing the

call. The number you enter is

inserted into the dialing

sequence in place of the

character

Phonebook

Recording a Voice Name For a

Phonebook Entry

You can record a voice name for a new or existing

phonebook entry. A voice name lets you call the

phonebook entry using voice dial (see page 70).

Tip: Make your recording in a quiet location. Hold the

phone about four inches (10 centimeters) from your

mouth, and speak directly into the phone in a normal

tone of voice.

Find the Feature

Phonebook

Do This To

1Press

scroll to the entry

2Press

VIEW

(

) view entry details

3Press

EDIT

(

) edit the entry

4Press

scroll to

Voice Name

5Press

RECORD

(

)begin recording

6Press and release

the voice key and say

the entry’s name (in

two seconds)

record the voice name

7Press and release

the voice key and

repeat the name

conﬁrm the voice name

8Press

DONE

(

)store the voice name

Phonebook

Dialing a Phonebook Entry

Use one of the following procedures to call a number (or

send a text message to an email address) stored in your

phonebook.

Phonebook List

Voice Dial

To speed dial a phonebook entry, see page 31. To call an

entry with one-touch dial, see page 31.

Find the Feature

Phonebook

Press To

1keypad key letter jump to entries that begin

with that letter (optional)

scroll to the entry

make the call

Do This To

Press and release

the voice key and

say the entry’s name

(in two seconds).

make the call

Phonebook

Editing a Phonebook Entry

Edit the entry as described on pages 65-67.

Deleting a Phonebook Entry

Setting the Primary Number for

a Phonebook Entry

When you enter multiple phone numbers for the same

name, you can set one as the primary number.

Find the Feature

Phonebook

Press To

scroll to the entry

VIEW

(

)view entry details

EDIT

(

) edit the entry

Find the Feature

Phonebook

Press To

scroll to the entry

open the

Phonebook Menu

scroll to

Delete

SELECT

(

)select

Delete

YES

(

)conﬁrm the deletion

Find the Feature

Phonebook

Depending on how the phonebook list is sorted, the

primary number is listed ﬁrst, or is the only number that

appears for a phonebook entry. See page 73.

Checking Phonebook Capacity

You can see how much memory space remains for storing

phonebook and datebook entries on your phone.

Press To

scroll to the entry

open the

Phonebook Menu

scroll to

Set Primary

SELECT

(

)select

Set Primary

scroll to the number you want

to set as the primary number

SELECT

(

)set the primary number

Find the Feature

Phonebook

Press To

open the

Phonebook Menu

scroll to

Ph Book Capacity

SELECT

(

)select

Ph Book Capacity

Your phone displays the

phone memory meter.

Phonebook

Sorting the Phonebook List

You can sort your phonebook list by speed dial number

(the standard), name, email address, or voice name.

Note: The voice name sort is identical to the name sort,

except that entries with voice name tags appear ﬁrst.

If you select

Speed No.

Voice Name

, or

, the

procedure is complete.

If you select

Name

, you must specify whether you want to

view all numbers or just the primary number for each

name:

Find the Feature

Phonebook

Press To

open the

Phonebook Menu

scroll to

Setup

SELECT

(

)select

Setup

scroll to

Sort by

CHANGE

(

)select

Sort by

scroll to

Name

Speed No.

Voice Name

, or

SELECT

(

)select the sort order

Press To

CHANGE

(

)change view preference

scroll to

Primary Contacts

All Contacts

Phonebook

To set an entry’s primary phone number, see page 71.

Tip: When the phonebook list displays primary numbers

only, you can scroll to a name and press

to view

other numbers associated with the name.

SELECT

(

)select the view preference

DONE

(

)set the view preference

Press To

Datebook

The datebook is a calendar that lets you schedule and

organize events such as appointments and meetings. You

can set the datebook to send a reminder alarm for speciﬁc

events.

Note: You must set the correct time and date on your

phone to use the datebook.

To schedule or review datebook events:

Week View

The datebook initially displays a calendar for the week.

Lines or ﬁlled boxes indicate scheduled events.

Find the Feature

Datebook

EXIT VIEW

{15 NOV-21 NOV }

Go to

selected day

Exit the

datebook

Untimed

event

12 hour

window One-hour event

Days of week

(press

to select)

Full day (12-hour)

event scheduled

S M T W T F S

Press

to open

the

Datebook Menu

Datebook

Day View

Select a day and press

VIEW

(

) to see the day’s events.

Event View

Select an event and press

VIEW

(

) to see event

details.

{THU 19-NOV }

¥ Joe's B-day

9:00 A Marie,...

BACK VIEW

Day of week

Show event

details

Return to

previous screen

Untimed

event

Event

Reminder

alarm

Down scroll

arrow

Press

to open

the

Datebook Menu

A THU 9:00am

Marie, mtg about

new product

BACK EDIT

Day and time

Edit event

Return to

previous screen

Event details

Reminder

alarm

Down scroll

arrow

Press

to open

the

Datebook Menu

Datebook

Adding a Datebook Event

A title is required for a datebook event. All other

information is optional.

Note: You must create an event to use the reminder alarm.

Changing Event Information

Find the Feature

Datebook

day

New

Press To

CHANGE

(

)select

Title

2keypad keys enter a title for the event

(

)store the event title

scroll to other ﬁelds and enter

information as necessary

You can set start time,

duration, date, repeat

interval, and reminder alarm.

DONE

(

)store the event

Find the Feature

Datebook

Press To

scroll to the day

VIEW

(

)display the day view

scroll to the event

VIEW

(

)display the event view

EDIT

(

)edit the event

Datebook

Copying an Event

scroll to the information you

want to change

CHANGE

(

)edit the information

8keypad keys enter new information

DONE

(

)store the information

Find the Feature

Datebook

Press To

scroll to the day

VIEW

(

)display the day view

scroll to the event

open the

Datebook Menu

scroll to

Copy

SELECT

(

)copy the event

YES

(

)conﬁrm the copy

Your phone assumes you

want to change the date, and

displays the

Date

ﬁeld.

8keypad keys enter date information

}

(

)move to month, day, and year

DONE

(

)save the copy of the event

scroll to and edit event

information, if necessary

Press To

Datebook

Deleting an Event

DONE

(

)store the information

Find the Feature

Datebook

Press To

scroll to the day

VIEW

(

)display the day view

scroll to the event

open the

Datebook Menu

scroll to

Delete

SELECT

(

)select

Delete

YES

(

)conﬁrm the deletion

Press To

Radio

You can use your phone to listen to FM radio

stations when the optional Motorola Original™ FM

Stereo Radio Headset accessory is plugged into

the phone’s accessory connector port.

Turning the Radio On and Off

Alternatively, you can use the following procedure:

Note: The

Radio

menu feature and soft key options

appear only when the FM Stereo Radio Headset is

plugged into the accessory connector port.

Press To

Radio

(

)turn the radio on and off

Press To

open the menu

scroll to

Radio

(

) or

Off

(

)

turn the radio on or off

Radio

Tuning a Station

Storing a Preset

Selecting a Preset

Sending and Receiving Calls

With the Radio On

Your phone rings or vibrates as usual to notify you of an

incoming call, message, or other event.

Do This To

Press

Press and hold

scroll to the next frequency

scroll to the next available

stereo station

Do This To

Press and hold a

number key

(

)

assign its preset number to

the tuned station

Press To

a number key

(

)tune the station stored at the

preset location

Radio

To end the call and resume the FM broadcast:

Turn the radio off before dialing outgoing calls from the

phone keypad. You do not have to turn off the radio to

dial emergency numbers, or numbers selected from your

phonebook or recent call lists.

Tip: To dial a recently called number, press

or the

button on the FM Stereo Radio Headset microphone to go

to the dialed calls list. For more information, see page 59.

Do This To

Press

IGNORE

(

)ignore the call

Press

ANSWER

(

)

Press the button on the

FM Stereo Radio

Headset microphone

answer the call

Note: You can use the

FM Stereo Radio

Headset microphone to

converse with the other

party during a call

Do This To

Press

Press and hold the

button on the FM Stereo

Radio Headset

microphone

end the call

Messages—Voicemail

You can listen to your voicemail messages by

calling your network voicemail phone number.

Voicemail messages are stored on the

network—not on your phone.

Storing Your Voicemail Number

Storing your voicemail number on your phone makes it

easy for you to listen to new voicemail messages. In many

cases, your service provider has already done this for you.

Your service provider additionally may store your voicemail

number as phonebook entry number 1, so you can use

one-touch dial to listen to your voicemail messages. If

necessary, see page 65 to store your voicemail number

for one-touch dial access.

Find the Feature

Messages

VoiceMail Setup

Press To

1keypad keys enter your voicemail number

Tip: You can store your PIN

code with the voicemail

number. See page 67.

(

)store the number

Messages—Voicemail

Receiving a Voicemail Message

When you receive a voicemail message, your phone

displays the

(voice message waiting) indicator and a

New VoiceMail

notiﬁcation.

If reminders are turned on, your phone sends a reminder

at regular intervals until you close the new message

notiﬁcation, listen to the message, or turn off your phone.

Listening to a Voicemail

Message

The phone calls your voicemail number. If no voicemail

number is stored, your phone prompts you to store one.

Shortcut: If your voicemail number is also stored as

phonebook entry number 1, you can press and hold

listen to your voicemail message(s).

Press To

CALL

(

)listen to the message

Find the Feature

Messages

VoiceMail

Messages—Text

Text messages are brief messages that you

can send and receive.

Quick notes are pre-written text messages that

you can incorporate into a message and send

quickly.

Your text message inbox must be set up

before

you can

send and receive messages. The number of messages the

inbox can hold depends on the length of the messages,

and the number of other messages and drafts stored on

your phone.

Setting Up the Text Message

Inbox

Note: In many cases, your service provider has already

set up the text message inbox for you.

Find the Feature

Messages

Text Msg Setup

Press To

CHANGE

(

)change the

Srvce Center No.

2keypad keys enter the phone number for

the service that handles your

outgoing messages

(

)store the number

Messages—Text

Receiving a Text Message

Note: Your text message inbox must be set up before you

can receive text messages. See page 85.

CHANGE

(

)change the

Expire After

period

5keypad keys enter the expiration period—

the number of days your

network tries to send

unreceived messages

(

)store the expiration period

CHANGE

(

)change the

Cleanup

setting

scroll to the number of days

you want to keep messages

in the inbox, or the number of

messages you want to keep

SELECT

(

)select the cleanup setting

CHANGE

(

)change the

SMS Alert

setting

select whether you want

incoming message alerts

turned

Off

while you are

on a voice call

SELECT

(

)select the

SMS Alert

setting

DONE

(

)save the inbox settings

Press To

Messages—Text

When you receive a text message, your phone displays the

(message waiting) indicator and a

New Message

notiﬁcation, and gives an alert.

If reminders are turned on, your phone sends a reminder

at regular intervals until you close the new message

notiﬁcation, read the message, or turn off your phone.

When your phone displays

Memory is Full!

, you must

delete some existing messages to receive new messages.

Reading, Locking, or Deleting a

Text Message

Messages in the text message inbox are sorted from

newest to oldest. The oldest messages are deleted

automatically as speciﬁed by the inbox cleanup setting

(see page 85). If you want to save a message, you should

lock it to prevent it from being deleted during cleanup.

Press To

READ

(

)open the message

Find the Feature

Messages

Text Msgs

Messages—Text

Press To

scroll to the message

The following indicators show

message status:

= unread

=unread (with attachment)

= unread and urgent

(with attachment)

= read

= read (with attachment)

= read and urgent

= read and locked

(with attachment)

READ

(

)open the message

BACK

(

)

DELETE

(

)

close the message

delete the message

open the

Text Msg Menu

perform other procedures as

described in the following list

Messages—Text

The

Text Msg Menu

includes the following options:

SAVE

(

)

(

)

close the message

compose and send a reply

open the

Text Msg Menu

perform other procedures as

described in the following list

Option Description

Delete

Delete the message.

Call Back

Call the number in the message

header or embedded in the

message.

Go To

Launch the micro-browser and go

to a Web address (URL)

embedded in the message.

Forward

Open a copy of the text message,

with an empty

ﬁeld.

Note: You cannot forward sound

ﬁles embedded in a text message.

Only the text is forwarded.

Store Tone

Store the selected sound ﬁle.

Play

Play a sound ﬁle in the message.

Lock/Unlock

Lock or unlock the message.

Press To

Messages—Text

Storing Sounds

Text messages that you receive can contain sounds. A

sound begins playing when you scroll to or select the

(sound ﬁle) indicator in the message.

You can store these embedded sound ﬁles on your phone,

and use them as alert tones.

For more information about using sound ﬁles, see

pages 95 and 97.

Store Number

Create a phonebook entry, with

the embedded number in the

No.

ﬁeld.

Delete All

Delete all inbox messages.

Create Message

Open a new text message.

Store Address

Create a phonebook entry, with

the embedded email address in

the

ﬁeld.

Setup

Open the text message inbox

setup menu.

Press To

open the

Text Msg Menu

scroll to

Store Tone

SELECT

(

)select the option

Your phone adds the sound

to the

My Tones

list.

Option Description

Messages—Text

Sending a Text Message

You can send a text message to one or more

recipients. You can manually enter each recipient’s

phone number or email address, or select numbers/

addresses from the phonebook or recent call lists.

Note: When you manually enter numbers and/or email

addresses, you must insert a space between each entry.

Press and hold

until the space appears, then enter the

next number or email address.

Find the Feature

Messages

Create Message

Press To

CHANGE

(

)select

2keypad keys

BROWSE

(

)

enter one or more phone

numbers and/or email

addresses

Tip: Press

to insert a

space between each

number/address that you

enter manually.

select numbers/addresses

from the phonebook or recent

call lists

(

)store the numbers/addresses

CHANGE

(

)select

Msg

Messages—Text

5keypad keys

BROWSE

(

)

enter the message

Note: Message length is

limited.As you near the limit,

a display counter shows how

many characters are left.

select and insert a quick note

message (see page 93)

(

)store the message

CHANGE

(

)select

Priority

scroll to the priority you want

SELECT

(

)set the priority

CHANGE

(

)select

Call

11 keypad keys enter a number for the

recipient to call back

(

)store the number

CHANGE

(

)select

Receipt

select whether you want the

message status to be

updated when the recipient

opens the message

Note: Sent messages are

stored in your outbox. See

page 94.

(

)store your receipt preference

DONE

(

)ﬁnish the message

Press To

Messages—Text

Sending a Quick Note Text

Message

Quick notes are pre-written text messages that you can

incorporate into a message and send quickly (for example,

Meet me at ...

). You can also create new quick notes.

The

Quick Note Menu

includes the following options:

YES

(

)

(

)

send the message

cancel the message or save it

in the drafts folder

Find the Feature

Messages

Quick Notes

Press To

scroll to the quick note

READ

(

)

read the quick note

open the

Quick Note Menu

perform other procedures as

described in the following list

Option Description

New

Create a new quick note.

Edit

Edit the quick note.

Press To

Messages—Text

Viewing the Status of Sent

Text Messages

Messages that you send are stored in the outbox.

Messages in the outbox are sorted from newest to oldest.

The following indicators show message status:

Delete

Delete the quick note.

Send

Open a new message with the

quick note in the

Msg

ﬁeld.

Find the Feature

Messages

Outbox

= sending in progress

= sent

= sending failed

= read by recipient

Option Description

Ring Styles

Your phone rings or vibrates to notify you of an incoming

call or other event. This ring or vibration is called an

alert

You can select one of ﬁve different ring styles:

The ring style indicator in the display shows the current

ring style (see page 23).

Each ring style contains settings for speciﬁc event alerts,

ringer ID, and ringer and keypad volume.

Selecting a Ring Style

Customizing a Ring Style

Change Style Settings

You can change the alerts that notify you of the following

events: incoming calls, text messages, voicemail

= loud ring

= soft ring

= vibrate

= vibrate and ring

= silent

Find the Feature

Ring Styles

Style

Press To

scroll to the ring style

SELECT

(

)select the ring style

Ring Styles

messages, data calls, fax calls, alarms, and reminders.

Any changes you make are saved to the current ring style.

Note:

Style

represents the current ring style.

Activate and Deactivate Ringer IDs

When ringer IDs are turned on, your phone uses

distinctive ringer alerts to notify you of incoming calls or

messages from speciﬁc entries stored in your phonebook.

To assign a ringer ID to a phonebook entry, see page 65.

Note:

Style

represents the current ring style.

Find the Feature

Ring Styles

Style

Detail

Press To

scroll to the event

CHANGE

(

)select the event

scroll to the alert you want

SELECT

(

)select the alert

Find the Feature

Ring Styles

Style

Detail

Press To

scroll to

Ringer IDs

CHANGE

(

)change the ringer IDs setting

scroll to

Off

SELECT

(

)select the option

Ring Styles

Set Ringer or Keypad Volume

Note:

Style

represents the current ring style.

Creating Alert Tones

You can create and store up to 32 custom alert tones on

your phone. The tones appear in the list of available alerts.

Create a Tone

Find the Feature

Ring Styles

Style

Detail

Press To

scroll to

Ring Volume

Key Volume

scroll to the desired volume

(

)conﬁrm the new volume

Find the Feature

Ring Styles

My Tones

Press To

scroll to

[New Tone]

SELECT

(

)select

[New Tone]

CHANGE

(

)select

Notes

4keypad keys enter notes (see)

(

)store the notes

CHANGE

(

)select

Name

7keypad keys enter a name for the tone

Ring Styles

Enter Notes

To create a new tone, use the keypad keys to enter notes.

For each note, you must specify the octave (optional),

pitch, length, and a length modiﬁer (optional). Press a

key multiple times to cycle through its available options

and enter the necessary character as described in the

following lists.

Octave

The default setting for a new tone is octave four.

Notes and Rests

(

)store the name

DONE

(

)store the tone

Key Display Description

enter

followed by a number

(

) to set the octave

Key Display Description

sharp

ﬂat

note A

note B

note C

Press To

Ring Styles

Lengths and Modiﬁers

Volume Control Characters

note D

note E

note F

note G

rest

Key Display Description

whole note

half note

quarter note

eighth note

sixteenth note

1/32 note

dotted note

double dotted note

;

2/3 length note

Key Display Description

, and

Set volume level from

V15

. Enter

V+

V-

increase or decrease

volume one level from

current setting.

Key Display Description

100

Ring Styles

Repeat Characters

Note Entry Sequence

Key Display Description

(

)

, and

Use parentheses to enclose

sequence of notes to be

repeated. After the

sequence, enter

followed

by digit(s) to set number of

repetitions.

Do This Action

1Set the octave

(optional) Set the octave (

)

before

selecting the note. The

octave applies to the note

and all following notes until

you change it again.

2Set the note to a

sharp or ﬂat, if

necessary

Enter a sharp or ﬂat (

)

before

selecting the note.

3Select the note

(required) Press a keypad key.

4Set length

(required) Set the length (

)

after

selecting the note. If you you

do not specify a length, a

(quarter note) length is

appended to the note.

5Modify length

(optional) Enter a length modiﬁer (

;

)

after

you set the length.

101

Ring Styles

You can perform the following tasks when creating a tone:

Example

Press the following keys to create this sequence of notes

and rests in octave three: C (quarter note), E ﬂat (quarter

note), half rest, and G (whole note):

Task Action

Insert a rest Enter one or more rests

(

characters) as needed in the

tone sequence. Set the length of

the rest (

)

after

the rest, just

as you would for a note.

Repeat a note

sequence Use

(

and

)

to group a sequence

of notes. After the sequence,

enter

followed by a number to

set the number of repetitions.

Adjust volume Enter

V+

V-

to increase or

decrease volume one level at the

current location in the note

sequence.

Listen to a new

tone as you

compose it

Press

to enter the

Compose Menu

, and select

Play All

to play the notes you

have entered.

Press To Display

set octave

three

enter note C

102

Ring Styles

Play a Tone

set length to

quarter note

enter ﬂat

symbol

enter note

E ﬂat

set length to

quarter note

enter rest

set length to

half rest

enter note G

set length to

whole note

Find the Feature

Ring Styles

My Tones

Press To

scroll to the tone

open the

My Tones Menu

scroll to

Play

SELECT

(

) select

Play

Press To Display

103

Ring Styles

Edit a Tone

You cannot edit the predeﬁned alert tones included

with your phone. To edit a custom alert tone:

Delete a Tone

You cannot delete the predeﬁned alert tones included with

your phone. To delete a custom alert tone:

PLAY

(

)

CANCEL

(

)

play the tone again

return to my tones list

Find the Feature

Ring Styles

My Tones

Press To

scroll to the tone

EDIT

(

)open the tone details

scroll to the item you want to

edit (

Name

Notes

)

CHANGE

(

)select the item

5keypad keys enter new text or notes

(

)store the new text or notes

DONE

(

)save your changes

Find the Feature

Ring Styles

My Tones

Press To

104

Ring Styles

Download a Tone

You can download custom alert tones from a text

message. See page 90.

Setting Reminders

A reminder is an alert that rings or vibrates at regular

intervals to notify you about a voicemail or text message

that you have received.

Note:

Style

represents the current ring style.

Press To

scroll to the tone

open the

My Tones Menu

scroll to

Delete

SELECT

(

)select

Delete

YES

(

)conﬁrm the deletion

Find the Feature

Ring Styles

Style

Detail

Reminders

Press To

scroll to

Beep

Vibrate

to set

the reminder alert type, or

Off

to turn off all reminders

SELECT

(

)select the reminder alert

105

Shortcuts

Your phone includes several standard shortcuts. You can

create additional shortcuts to frequently used menu items.

Standard Shortcuts

The following shortcuts are pre-programmed in your

phone. You cannot edit or delete these shortcuts.

Creating a Shortcut

You can create a keypad shortcut

plus

an optional voice

shortcut to a menu item. A voice shortcut takes you

directly to the menu item when you say the shortcut name.

Tip: Make your recording in a quiet location. Hold the

phone about four inches (10 centimeters) from your mouth,

and speak directly into the phone in a normal tone of voice.

Do This To

Press

, then

press and hold

(within two seconds)

zoom in/out on your phone

display

Press

lock/unlock your keypad

Press

see your phone number

Press

go to the dialed calls list

Press

exit the menu system

Do This To

1Press

enter the menu system

106

Shortcuts

2Press

scroll to the menu item

3Press and hold

open the shortcut editor

4Press

YES

(

)view shortcut options

5Press

CHANGE

(

)

Press

DONE

(

)

Press

change the keypad

shortcut number

select the default keypad

shortcut number

scroll to

Voice

to assign a

voice shortcut

6Press

RECORD

(

)begin recording

7Press and release

the voice key and say

the shortcut’s name

(in two seconds)

record the shortcut name

8Press and release

the voice key and

repeat the name

conﬁrm the shortcut

name

9Press

DONE

(

)store the shortcut name

Do This To

107

Shortcuts

Using Shortcuts

Use a Keypad Shortcut

Select a Shortcut From the List

Use a Voice Shortcut

Press To

open the menu

the keypad shortcut

number

go to the menu item or

perform the menu action

Find the Feature

Shortcuts

the shortcut you want

Do This To

1Press

open the menu

2Press and release

the voice key and say

the shortcut’s name

(in two seconds)

go to the menu item or

perform the menu action

108

Voice Notes

You can use the voice note feature to record personal

messages and phone calls on your phone.

Recording a Voice Note

Use this procedure to record a voice note from the idle

display, or to record a phone call in progress. Your phone

plays an alert tone to notify the other party that the call is

being recorded.

Note: Recording phone calls is subject to varying state

and federal laws regarding privacy and recording of

conversations.

Tip: Make your recording in a quiet location. Hold the

phone about four inches (10 centimeters) from your mouth,

and speak directly into the phone in a normal tone of voice.

Do This Result

1Press and hold the

voice key for the

duration of the

recording.

The phone sounds an

alert tone and begins

recording.

2Speak your voice note. The phone records the

voice note.

3Release the voice key

to stop recording. The phone displays the

voice note number and

total recording time.

109

Voice Notes

Viewing the Voice Notes List

Find the Feature

Voice Notes

2)2:20pm 6/1/00

1)4:05am 4/1/00

EXIT PLAY

Press

to open the

Voice Notes Menu

Play the

highlighted

voice note

Return to

previous screen

Time/date

recorded

Down scroll

arrow

Locked

voice note

110

Voice Notes

Playing a Voice Note

When you connect an optional Motorola Original™

headset or FM Stereo Radio Headset accessory to your

phone, playback is automatically routed to the headset.

Tip: You can play a voice note while taking a call. It will not

be transmitted to the other party.

Playback Screen

The playback screen is displayed as the voice note plays.

Find the Feature

Voice Notes

Press To

scroll to the voice note

PLAY

(

)play the voice note

Erase

voice note

Return to

screen

Voice note

number

Press

fast forward

Press

to rewind

Voice Note 3

{}

SAVE DELETE

Indicates

% played

Press

to open the

Voice Notes Menu

111

Voice Notes

Voice Note Controls

Stop

playback and

return to voice

notes list.

Stop

playback and

go to

Voice

Notes Menu

Stop

playback and

scroll up/down

to next voice

note.

Rewind three

seconds,

resume

playing.

Press and hold

to rewind to the

beginning.

When playback is

complete, press to

restart.

Fast forward

three

seconds,

resume

playing.

Press any

number to

alternately

stop and

start

playback.

If voice note is

locked, stop

playback and

unlock voice

note.

Press and

hold to fast

forward to

end.

If voice note is

unlocked, stop

playback and

display

Delete

Voice Note?

Raise or lower

playback

volume of

voice note.

112

Voice Notes

Locking and Unlocking a Voice

Note

Lock a voice note to prevent it from being deleted. You

must unlock a voice note to delete it.

To lock or unlock a voice note during playback:

Playback stops when you lock or unlock a voice note.

Press any number key to resume playback.

Find the Feature

Voice Notes

Press To

scroll to the voice note

open the

Voice Notes Menu

scroll to

Lock

Unlock

SELECT

(

)lock or unlock the voice note

Press To

open the

Voice Notes Menu

scroll to

Lock

Unlock

SELECT

(

)lock or unlock the voice note

113

Voice Notes

Deleting a Voice Note

Notes:

•You cannot delete a locked voice note.

•You cannot recover a delete voice note.

Find the Feature

Voice Notes

Press To

scroll to the voice note you

want to delete

open the

Voice Notes Menu

scroll to

Delete

Delete All

SELECT

(

)select the highlighted option

YES

(

)

(

)

conﬁrm the deletion

cancel deletion

114

Micro-Browser

The micro-browser lets you access

Web pages and Web-based

applications on your phone. Contact

your service provider to set up access,

if necessary.

Starting a Micro-Browser

Session

If you are unable to establish a network connection with

the micro-browser, contact your service provider.

Find the Feature

Browser

Press To

scroll to a bookmark, service,

or application

SELECT

(

)select the item

115

Micro-Browser

Interacting With Web Pages

Press To

scroll through text, or

highlight a selectable item

SELECT

(

)select the highlighted item

call the highlighted phone

number from the

micro-browser

keypad keys,

followed by

(

)

enter information

Press

to delete one letter

at a time if you make a

mistake.

go back to the previous page

open the

Browser Menu

116

Calculator

You can use your phone as a calculator and currency

converter.

Calculating Numbers

Press To

1number keys enter a number

highlight a calculator function

SELECT

(

)perform the function

Calculator

EXIT SELECT

Selected

function

appears

here

Perform the

highlighted

function

Press

to open

the

Calculator Menu

Exit the

calculator

Entered

number

Press

to scroll

to other

functions

Press

to highlight

a function

.Ö

C=+-x}

117

Calculator

The calculator can perform the following functions:

Function Description

Insert a decimal point

Clear the calculation

Clear entry (replaces

when you enter

subsequent values in a calculation)

Calculate the result

Add

Subtract

Multiply

Divide

Divide the displayed value by 100

Change the entry’s sign

(positive/negative)

Calculate the exchange rate

Store the value in memory (overwrites

current stored value)

Clear the value stored in memory

Replace the displayed value with the

value stored in memory

118

Calculator

Converting Currency

The currency converter works just like the calculator,

but uses the

(currency) function:

Find the Feature

Calculator

Exchange Rate

Press To

1number keys enter the exchange rate

(

)store the exchange rate

3number keys enter the amount to convert

(amount to multiply by the

exchange rate)

highlight the

function

SELECT

(

)perform the conversion

119

Games

You can play games on your phone between phone calls.

An incoming call, message, alarm, or alert automatically

ends the game.

Playing a Game

When the game is over:

Find the Feature

Games

Press To

scroll to a game

SELECT

(

)start the game

Press To

NEW

(

) or

YES

(

)

start another session of the

same game

BACK

(

) or

(

)

end the game session

120

Games

Game Options

Press

to select the following options during a game.

Note: Some options may not be available for all games.

Blackjack

In this classic card game, you play against the dealer to

see who can get closer to 21 points without going over.

Rules of the Game

•The ﬁrst card is dealt to the dealer. The dealer’s cards

are shown at the top of the display, and your cards are

shown at the bottom.

•Face cards count as 10 points. Number cards count

as the points shown on their face.

•An ace counts as 11 points, unless that would put you

over 21 points. Otherwise, an ace is counted as 1

point. An ace that is originally counted as 11 may later

be counted as 1 if it will bring your total under or equal

to 21 points.

•An initial deal of an ace and a card with a face value of

10 points counts as exactly 21 points or Blackjack.

Option Description

Game Sounds

Switch game sounds on/off.

New Game

Start a new game session.

Help

Review the goal of the game.

121

Games

•Blackjack automatically wins against any other hand

that totals 21 points.

•If you score more than 21 points, you go “bust” or

lose.

•If you get ﬁve cards without going bust, you win.

•If you and the dealer have the same score, the dealer

wins.

•You can ask for a “hit” or another card as long as

you do not go bust.

•As long as the dealer’s total is less than 17 points,

the dealer must continue to take a hit.

How to Play

When the game begins, you are dealt two cards.

Falling Numbers

Score points by pressing the corresponding number key

for numbers as they “fall” down the display.

Rules of the Game

•If a number reaches the bottom of the display or if you

press an incorrect number key, you score one miss.

•The game is over when you score three misses.

Press To

STAY

(

)see the results of the hand

HIT ME

(

)request another card

122

Games

•The game has ﬁve levels. When you complete a level,

play continues automatically at the next level.

•You earn a bonus if you ﬁnish a level without a miss.

How to Play

When the game begins, numbers start falling from the

upper portion of the display. Press the corresponding

number key to eliminate a falling number before it

reaches the bottom of the display.

Press

to select the following options:

Video Poker

Turn 100 credits into 9,999-plus credits by making the best

possible poker hands.

Rules of the Game

•You start a new game with 100 credits. You must bet

from 1-10 credits for each hand you play.

•You are dealt ﬁve cards face up, and have one

opportunity to trade in cards (zero to ﬁve) for new

ones.

•A winning hand earns credits as listed in the

Awards Table

Option Description

Level

Choose the starting level of play.

Top Scores

View the top ﬁve scores.

123

Games

•Your credit total is saved when you exit the game. The

next time you play, you start with the number of credits

that remain from the previous session.

•The game is over when you lose all of your credits.

How to Play

Place your initial bet or change your bet (from 1-10 credits)

and then:

Press

to select the following options:

Press To

DEAL

(

)start a new hand

select the card to the left

select the card to the right

or discard selected card

or undo discard (replaces

previous option after discard)

DONE

(

)remove discarded cards and

deal replacements

Option Description

Change Bet

Change bet amount (not

available while hand is in play).

Choose Deck

Choose the deck image.

Awards Table

View the list of odds/payouts for

each winning hand.

124

Adjusting Your Settings

Adjusting Your

Settings

Reordering Menu Items

You can reorder the items in your phone’s main menu.

Customizing a Soft Key

Function

You can relabel the soft keys (

and

) to access

different menu items from the idle display.

Find the Feature

Settings

Other Settings

Personalize

Main Menu

Press To

scroll to a menu item

GRAB

(

)grab the menu item

move the item to a new

location in the menu

INSERT

(

)insert the menu item

Find the Feature

Settings

Other Settings

Personalize

Keys

125

Adjusting Your Settings

TTY Operation

You can use an optional TTY device with your

phone to send and receive calls. You must plug the

TTY device into the phone’s headset jack and set

the phone to operate in one of three TTY modes.

Notes:

•Use a TSB-121 compliant cable (provided by the

TTY manufacturer) to connect the TTY device to

your phone.

•Set the phone volume to level 4 (middle setting) for

proper operation. If you experience a high number of

incorrect characters, adjust the volume as necessary

to minimize the error rate.

•For optimal performance, your phone should be at

least 12 inches (30 centimeters) away from the TTY

device. Placing the phone too close to the TTY device

may cause high error rates.

Press To

scroll to

Left

Right

CHANGE

(

)select the key

scroll to the new key function

CHANGE

(

)conﬁrm the new function

126

Adjusting Your Settings

Set TTY Mode

When you set your phone to a TTY mode, it operates in

that mode whenever the TTY device is connected.

The

TTY Setup

menu includes the following options:

When your phone is in a TTY mode, the international

TTY symbol and the mode setting are shown in the

display. You can press

TTYMODE

(

) to change the mode

setting.

Find the Feature

Settings

Other Settings

Initial Setup

TTY Setup

Press To

scroll to

TTY Setup

CHANGE

(

)change the TTY mode

scroll to the TTY mode

SELECT

(

)select the TTY mode

Option Description

TTY

Transmit and receive TTY characters

VCO

Receive TTY characters but transmit

by speaking into the microphone

HCO

Transmit TTY characters but receive by

listening to the earpiece

Voice

Return to normal voice mode

127

Adjusting Your Settings

Switch to TTY Mode During a Voice Call

Return to Voice Mode

To return to normal voice mode, select

Voice

from the

TTY Setup

menu as described on page 126.

Hands-Free Use

You can purchase an optional Motorola

Original™ hands-free car kit or headset for your

phone. These accessories provide alternative

ways for you to use your phone without using your

hands.

Note: The use of wireless devices and their accessories

may be prohibited or restricted in certain areas. Always

obey the laws and regulations on the use of these

products.

Press To

open the

Call

scroll to

TTY Setup

SELECT

(

)display the

TTY Setup

scroll to the TTY mode

SELECT

(

)select the TTY mode

128

Adjusting Your Settings

Automatic Answer

You can set your phone to automatically answer calls after

two rings (four seconds) when connected to a car kit or

headset.

Automatic Hands-Free

You can set your phone to automatically route calls to a car

kit when it detects a connection.

Find the Feature

Settings

Other Settings

Press To

scroll to

Car Settings

Headset

SELECT

(

)select the feature

scroll to

Auto Answer

CHANGE

(

)select

Auto Answer

scroll to

Off

SELECT

(

)conﬁrm the setting

Find the Feature

Settings

Other Settings

Car Settings

Auto Handsfree

Press To

scroll to

Off

SELECT

(

)conﬁrm the setting

129

Adjusting Your Settings

Power-Off Delay

When your phone is connected to a car kit, you can set it

to stay on for a period of time after you switch off the

ignition. This prevents the phone from draining your vehicle

battery, but leaves the phone on long enough that you do

not have to re-enter your unlock code when making short

stops.

Note: This feature may not work with all car ignition

switches.

Caution: If you select

Continuous

, the phone does not

power off when you turn off the ignition. Be careful not to

drain your vehicle battery if you select this option.

Charger Time

When your phone is connected to a car kit, you can set it

to charge itself for a speciﬁed time period after you switch

off the ignition. This helps ensure that the phone battery

gets fully charged while the vehicle is parked.

Find the Feature

Settings

Other Settings

Car Settings

Power-Off Delay

Press To

scroll to the time delay

SELECT

(

)conﬁrm your selection

130

Adjusting Your Settings

Note: This feature may not work with all car ignition

switches.

Find the Feature

Settings

Other Settings

Car Settings

Charger Time

Press To

scroll to the charge time

SELECT

(

)conﬁrm your selection

131

Data Calls

A Motorola Original™ data kit lets you transfer

data between your phone and a computer or other

external device. You can:

•use your phone as a modem to connect to the

Internet.

•use your phone to send and receive data calls on your

computer or hand-held device.

Connecting Your Phone to an

External Device

Connect your phone to a computer or hand-held device

using a serial cable or a USB cable.

Note: Not all devices are compatible with serial cable or

USB cable connections. Check your external device for

speciﬁcations.

Set Up a Cable Connection

Attach a serial cable or Motorola Original USB cable to

the phone and external device as follows.

Note: Check your computer or hand-held device to

determine the type of cable you need.

132

Data Calls

Attaching a Serial Cable

Use the interchangeable head on the Motorola

Multi-Connect Serial Cable to connect a computer, Palm III

device, or Palm V device to your phone.

Do This

1Plug the serial

cable into the

detachable head.

Make sure that the

Motorola logo on

the detachable

head and the

metal shielding on

the serial cable

plug are both

facing you.

2With the Motorola

logo and the

phone both facing

you, plug the

detachable head

into the phone’s

accessory

connector port.

3Plug the other end of the cable into the serial

interface connection on the external device and

tighten the screws.

133

Data Calls

Attaching a USB Cable

Install the Software

Install the software from the CD-ROM that comes with

your Motorola Original data kit. See the data kit’s user

guide for more information.

Do This

4Plug the end of the

cable with the

Motorola logo into the

phone’s accessory

connector port. Make

sure that the logo and

the phone are both

facing you.

5Plug the other end—the USB connection—into

the USB port on the external device.

134

Data Calls

Sending a Data Call

Use this procedure to send data from a connected device,

and to synchronize phonebook and datebook information

between your phone, computer, and/or hand-held device.

Connect your phone to the device as described on

page 131 and do the following:

Do This To

1Check the phone make sure that the phone is

connected and powered on

2Open the

application on

your computer

place the call through the

application (such as

dial-up-networking)

Note: You cannot dial data

numbers through your

phone’s keypad. You must

dial them through your

computer.

3End the call from

the connected

device

close the call and connection

when the transfer is complete

135

Data Calls

Receiving a Data Call

Use this procedure to transfer data to your computer or

hand-held device.

Set Up Your Phone

Transfer the Data

Your phone notiﬁes you when the data call arrives, and

transfers the call to the connected device. Use the

application running on the device to answer the call.

Find the Feature

Settings

Connection

Incoming Call

Do This To

1Press

CHANGE

(

)select

Next Call

2Press

scroll to

Data In Only

3Press

SELECT

(

)set the call format

4Connect your phone

to the device enable the data transfer

Note: You cannot answer incoming voice calls when

your phone is in data mode. Any voice calls you

receive are treated as unanswered calls. To return a

voice call, reset your phone to voice mode as

described on page 136.

136

Data Calls

End the Data Connection

When the data transfer is complete:

Reset Normal Voice Operation

After making a data call, you must reset your phone to

resume normal voice operations. You cannot receive voice

calls when your phone is in data mode.

Your phone also reverts to normal voice operations

when you turn it off and then turn it back on.

Do This To

End the call from the

connected device close the connection

Find the Feature

Settings

Connection

Incoming Call

Do This To

1Press

CHANGE

(

)select

Next Call

2Press

scroll to

Normal

3Press

SELECT

(

)reset your phone

137

Security

Assigning a New Code or

Password

Your phone’s unlock code is originally set to 1234, and the

security code is originally set to 000000. Your service

provider may reset these numbers before you receive your

phone.

If your service provider has

not

reset these numbers, we

recommend that you change them to prevent other users

from accessing your personal information. The unlock

code must contain four digits, and the security code must

contain six digits.

Notes:

•Your service provider may retain your phone’s security

code for customer service purposes. In this case, you

will not be able to use phone features that require you

to enter the security code.

•If the unlock code is the only code you can change,

the

New Passwords

menu is not available. In this case,

change the unlock code by selecting:

Settings

Security

Phone Lock

Unlock Code

To change a code or password:

Find the Feature

Settings

Security

New Passwords

138

Security

If You Forget a Code or

Password

If you forget your security code, contact your service

provider.

If you forget your unlock code, try entering 1234 or the last

four digits of your phone number. If that does not work, do

the following at the

Enter Unlock Code

prompt:

Press To

scroll to the code or password

CHANGE

(

)select the code or password

3keypad keys enter your old code

(

)submit your old code

5keypad keys enter the new code

(

)assign the new code

7keypad keys re-enter the new code

(

)conﬁrm the new code

Press To

go to the unlock code bypass

screen

2keypad keys enter your security code

(

)submit your security code

139

Security

Locking and Unlocking Your

Phone

You can lock your phone manually or set the phone to lock

automatically whenever you turn it off.

To use a locked phone, you must enter the unlock code. A

locked phone still rings or vibrates for incoming calls or

messages,

but you must unlock it to answer

You can make emergency calls on your phone even when

it is locked. For more information, see page 29.

Lock Your Phone Manually

Set Your Phone to Lock Automatically

You can set your phone to lock every time you turn it off.

Find the Feature

Settings

Security

Phone Lock

Lock Now

Press To

1keypad keys enter your unlock code

(

)lock the phone

Find the Feature

Settings

Security

Phone Lock

Automatic Lock

Press To

1keypad keys enter your unlock code

(

)activate automatic lock

140

Security

Unlock Your Phone

At the

Enter Unlock Code

prompt:

Locking and Unlocking Your

Keypad

You can lock your phone keypad to prevent accidental

keypresses (for example, when carrying your phone in a

purse or pocket).

Note: Incoming calls and messages unlock the keypad.

Restricting Calls

You can stop all incoming and/or outgoing calls, or you can

restrict them to the numbers stored in your phonebook.

Notes:

•You can make emergency calls when outgoing

calls are restricted.

•Your phone still receives incoming text messages

when incoming calls are restricted.

Press To

1keypad keys enter your unlock code

(

)unlock your phone

Press To

lock or unlock your keypad

141

Security

•When you restrict incoming calls to numbers stored in

the phonebook, a valid incoming call may be restricted

if caller ID information for the call is not available from

the network.

Tip: The phonebook is not locked when you restrict

outgoing calls to numbers stored in the phonebook. To

prevent a user from adding (and then calling) a new

phonebook entry, you may want to lock the phonebook.

See the “Lock Application” item on page 53.

Find the Feature

Settings

Security

Restrict Calls

Press To

1keypad keys enter your unlock code

(

)open the restrict calls menu

scroll to

Outgoing Calls

Incoming Calls

CHANGE

(

)select the option

CHANGE

(

)change the

Allow

setting

scroll to

All

None

, or

Phonebook

SELECT

(

)select the allowed calls

142

Security

Activating Talk Secure

Your phone can attempt to send your calls using a high-

security connection, to prevent others from intercepting

them. For more information, see page 28.

Find the Feature

Settings

Security

Talk Secure

Press To

scroll to

Preferred

Off

SELECT

(

)switch talk secure on or off

143

Troubleshooting

Check these questions ﬁrst if you have problems with

your phone. If you need additional help, contact the

Motorola Customer Call Center at 1-800-331-6456

(United States) or 1-800-461-4575 (Canada).

Question Answer

Is your phone

set up

correctly?

Press

. If you do not see

your phone number, contact your

service provider.

Is your battery

charged? Do

you see

the display?

The battery level indicator should

have at least one segment

showing (

). If it does not,

recharge your battery. See

page 19.

Does the

handset have

a signal? Do

you see

the display?

The signal strength indicator

should have at least one segment

showing (

). If it does not, move

to an area with a stronger signal

to use your phone.

Is the earpiece

volume too

low?

While on a call, press the upper

volume key on the side of your

phone.

144

Troubleshooting

The following refer to speciﬁc problems:

Is the other

party unable

to hear you?

Your phone may be muted. Press

UNMUTE

(

) if necessary to

unmute the phone.

Also, make sure that your phone’s

microphone is not blocked by its

carrying case or a sticker.

Has the phone

been

damaged,

dropped, or

gotten wet?

Dropping your phone, getting it

wet, or using a non-Motorola

battery or battery charger can

damage the phone. The phone’s

limited warranty does not cover

liquid damage or damage caused

from using non-Motorola

accessories.

Was a

non-Motorola

battery or

battery

charger used?

Problem Solution

My phone was

stolen. To

whom should I

report this?

Report a stolen phone to the

police and to your service provider

(the company that sends you your

monthly wireless service bill).

I forgot my

password. See page 138.

Question Answer

145

Troubleshooting

I pressed the

power key, but

nothing

happened.

Be sure to press and hold

(the power key) until the display

appears and you hear an alert.

This could take several seconds. If

nothing happens, check that a

charged battery is installed. See

page 18.

The display

says:

Enter

Unlock Code

How do I

unlock my

phone?

Enter the factory-preset unlock

code (1234), or the last four digits

of your phone number. If this fails,

call your service provider (the

company that sends you your

monthly wireless service bill).

My phone

asks for an

unlock code

when I try to

open a feature.

The application you want is

locked. If you do not know the

unlock code, see page 138.

My phone

does not ring. If you see

in the

display, then the ringer is turned

off. See page 95.

Also, the ringer may be set to

Silent

even though your phone is

set to an audible ring style. See

page 95.

Problem Solution

146

Troubleshooting

My phone

rings even

though I

selected the

Silent

(or

Vibrate

) ring

style.

The ringer may be set to play a

tone even though your phone is

set to a silent ring style. See

page 95.

I tried to place

a call and

heard an

alternating

high/low tone.

Your call did not reach the

wireless system. You may have

dialed the number too soon after

turning the phone on. Wait until

you see the idle display before

making a call.

I cannot send/

receive calls. Make sure that you have a phone

signal (see the “Signal Strength

Indicator” item on page 24). Avoid

electrical or radio interference,

and obstructions such as bridges,

parking garages, or tall buildings.

Your phone also may have the

Restrict Calls

feature turned on.

If you know the unlock code, you

can change this setting in the

security menu (

Settings

Security

Problem Solution

147

Troubleshooting

My phone has

poor reception

and drops

calls.

Make sure that your antenna is

not bent or damaged.

Also, make sure you have a phone

signal (see the “Signal Strength

Indicator” item on page 24). Stay

clear of any obstructions such as

bridges, parking garages, or tall

buildings.

I cannot hear

others on my

phone.

While on a call, press the upper

volume key. The display should

show the volume increasing.

Also, make sure that your phone’s

earpiece is not blocked by its

carrying case.

I cannot open

my message

inbox.

Before you can use text

messages, you must set up the

message inbox. See page 85.

How do I see

the calls I sent

or received?

To see the most recent calls you

dialed or received:

Recent Calls

Received Calls

Dialed Calls

Problem Solution

148

Troubleshooting

My phone will

not send

voicemail

commands,

passwords, or

other codes.

Your phone sends commands and

passwords as DTMF tones. You

can set your phone’s DTMF tones

to be

Off

. If you have trouble

sending numbers, check your

DTMF setting.

1From the idle display, press:

Settings

Other Settings

Initial Setup

DTMF

2Press

to scroll to

3Press

SELECT

(

) to select it.

My phone’s

display is too

dark.

Use the

Contrast

feature to

change the level of contrast in

your display. See page 56.

You can also use the

Backlight

feature to change the length of

time that the display backlight

stays on. See page 55.

My battery

didn’t last as

long as I

expected.

What can I do

to extend

battery life

Your battery’s performance is

affected by charge time, feature

use, temperature changes,

backlight use, and other factors.

For tips on extending your battery

life, see page 25.

Problem Solution

149

Troubleshooting

I am unable to

record a voice

note, voice

name, or voice

shortcut.

Try moving to a quieter location to

make your voice recording. Hold

the phone about four inches (10

centimeters) from your mouth,

and speak directly into the phone

in a normal tone of voice.

My TTY device

doesn’t work

with my

phone.

Your phone must be set to a TTY

mode for the phone to detect your

TTY device. See page 125.

I plugged the

data cable into

my phone but

my phone did

not beep. How

do I know if

the data cable

is ready to go?

The beep indicates that you are

set up correctly. If you did not hear

a beep, make sure that both ends

of the data cable are connected—

the smaller end to your phone and

the larger end to your computer.

Also, your computer may have

deactivated the port to save

power. Try opening an application

that uses the port, like a fax or

dial-up application, to

automatically activate the port.

Problem Solution

150

Troubleshooting

My phone

beeped when I

attached the

data cable, but

my data

applications

don’t work.

You must be in an area with digital

coverage. Check your phone’s

display for the digital signal

indicator (

Some wireless networks may not

support data transmission. If you

see the digital indicator, but you

are roaming on an unfamiliar

network, this may be the case.

Also, remember that data

transmission usually requires a

subscription. Call your service

provider for more information.

When sending

data with the

data cable,

why does the

computer

show a

connection

rate of 19200

Kbps?

19200 Kbps is the data transfer

rate of the connection between

your computer and the phone.

The rate of the connection

between your phone and the

network is displayed on your

phone, and will be either 14400 or

9600 Kbps.

I can’t end my

data call by

closing the

application on

my computer.

What can I do?

Try pressing

on your phone.

Or try disconnecting the cable or

turning off the phone. If possible,

always close the connection

through your computer, as these

alternative methods may disrupt

the application on your computer.

Problem Solution

151

Troubleshooting

I launched the

micro-browser

but the display

says:

Service Not

Available

You may be in an area without

service. If you have wireless

service, look in the display for the

digital signal indicator (

). If you

do not see the indicator, you may

be in an area that has only analog

service or no service at all. If you

see the digital signal indicator, you

may be connected to a digital

network that does not support

Internet access.

I launched the

micro-browser

but the display

says:

Data Server

Unavailable

Try again in a few minutes. The

servers may be temporarily busy.

Problem Solution

152

Programming Instructions

Programming

Instructions

Follow this procedure if you need to program your phone’s

phone number(s).

Note: Programming is normally done by a trained

technician at the site of purchase. Users should not make

changes other than ones in the following procedure.

Before programming, ask your service provider for your:

•Carrier System ID (a one- to ﬁve-digit number)

•10-digit MIN (Mobile Identiﬁcation Number)

Press To

, the Carrier System

ID number,

enter programming

mode

(This is the security code

that is in the phone when

it is shipped from the

factory.)

enter the security

code

(

)submit the security

code

scroll to

MIN

CHANGE

(

)open the MIN

display

153

Programming Instructions

6keypad keys for the

10-digit MIN enter the new MIN

(

)store the new MIN

DONE

(

)exit programming

mode

Press To

154

Specific Absorption Rate Data

Speciﬁc Absorption

Rate Data

This model phone meets the government’s requirements

for exposure to radio waves.

Your wireless phone is a radio transmitter and receiver. It is

designed and manufactured not to exceed limits for exposure

to radio frequency (RF) energy set by the U.S. Federal

Communications Commission for the United States and by

Health Canada for Canada. These limits are part of

comprehensive guidelines and establish permitted levels of

RF energy for the general population. The guidelines are

based on standards that were developed by independent

scientiﬁc organizations through periodic and thorough

evaluation of scientiﬁc studies. The standards include a

substantial safety margin designed to assure the safety of all

persons, regardless of age or health.

The exposure standard for wireless mobile phones employs a

unit of measurement known as the Speciﬁc Absorption Rate,

or SAR. The SAR limit set by the FCC and by Health Canada

is 1.6 W/kg.

Tests for SAR are conducted using standard

operating positions accepted by the FCC and by Industry

Canada with the phone transmitting at its highest certiﬁed

power level in all tested frequency bands. Although the SAR is

determined at the highest certiﬁed power level, the actual

SAR level of the phone while operating can be well below the

maximum value. This is because the phone is designed to

operate at multiple power levels so as to use only the power

required to reach the network. In general, the closer you are

155

Specific Absorption Rate Data

to a wireless base station antenna, the lower the power

output.

Before a phone model is available for sale to the public in the

U.S. and Canada, it must be tested and certiﬁed to the FCC

and Industry Canada that it does not exceed the limit

established by each government for safe exposure. The tests

are performed in positions and locations (e.g., at the ear and

worn on the body) reported to the FCC and available for

review by Industry Canada. The highest SAR value for this

model phone when tested for use at the ear is 1.46 W/kg

and when worn on the body, as described in this user guide, is

0.69 W/kg.

(Body-worn measurements differ among phone

models, depending upon available accessories and regulatory

requirements). While there may be differences between the

SAR levels of various phones and at various positions, they all

meet the governmental requirements for safe exposure.

The FCC and Industry Canada have granted an Equipment

Authorization for this model phone with all reported SAR

levels evaluated as being in compliance with the FCC and

Health Canada RF exposure guidelines. SAR information on

this model phone is on ﬁle with the FCC and can be found

under the Display Grant section of:

http://www.fcc.gov/oet/fccid

after searching on FCC ID IHDT56CA2. You may also refer to

Motorola’s Web site:

http://www.motorola.com/rfhealth

156

Specific Absorption Rate Data

Additional information on Speciﬁc Absorption Rates (SAR)

can be found on the Cellular Telecommunications & Internet

Association (CTIA) Web site:

http://phonefacts.net

or the Canadian Wireless Telecommunications Association

(CWTA) Web site:

http://www.cwta.ca

1. In the United States and Canada, the SAR limit for mobile

phones used by the public is 1.6 watts/kg (W/kg) averaged over

one gram of tissue. The standard incorporates a substantial

margin of safety to give additional protection for the public and

to account for any variations in measurements.

2. Additional related information includes the Motorola testing

protocol, assessment procedure, and measurement uncertainty

range for this product.

ITC01-064

157

Additional Health and Safety Information

The U.S. Food and Drug

Administration's Center for

Devices and Radiological Health

Consumer Update on Mobile Phones

Additional Health and Safety Information

FDA has been receiving inquiries about the safety of mobile

phones, including cellular phones and PCS phones. The

following summarizes what is known—and what remains

unknown—about whether these products can pose a hazard

to health, and what can be done to minimize any potential

risk. This information may be used to respond to questions.

Why the concern?

Mobile phones emit low levels of radio frequency energy (i.e.,

radio frequency radiation) in the microwave range while being

used. They also emit very low levels of radio frequency energy

(RF), considered non-signiﬁcant, when in the stand-by mode.

It is well known that high levels of RF can produce biological

damage through heating effects (this is how your microwave

oven is able to cook food). However, it is not known whether,

to what extent, or through what mechanism, lower levels of RF

might cause adverse health effects as well. Although some

research has been done to address these questions, no clear

picture of the biological effects of this type of radiation has

emerged to date. Thus, the available science does not allow

us to conclude that mobile phones are absolutely safe, or that

they are unsafe. However, the available scientiﬁc evidence

does not demonstrate any adverse health effects associated

with the use of mobile phones.

158

Additional Health and Safety Information

What kinds of phones are in question?

Questions have been raised about hand-held mobile phones,

the kind that have a built-in antenna that is positioned close to

the user's head during normal telephone conversation. These

types of mobile phones are of concern because of the short

distance between the phone's antenna—the primary source

of the RF—and the person's head. The exposure to RF from

mobile phones in which the antenna is located at greater

distances from the user (on the outside of a car, for example)

is drastically lower than that from hand-held phones, because

a person's RF exposure decreases rapidly with distance from

the source. The safety of so-called “cordless phones,” which

have a base unit connected to the telephone wiring in a house

and which operate at far lower power levels and frequencies,

has not been questioned.

How much evidence is there that hand-held

mobile phones might be harmful?

Brieﬂy, there is not enough evidence to know for sure, either

way; however, research efforts are on-going. The existing

scientiﬁc evidence is conﬂicting and many of the studies that

have been done to date have suffered from ﬂaws in their

research methods. Animal experiments investigating the

effects of RF exposures characteristic of mobile phones have

yielded conﬂicting results. A few animal studies, however,

have suggested that low levels of RF could accelerate the

development of cancer in laboratory animals. In one study,

mice genetically altered to be predisposed to developing one

type of cancer developed more than twice as many such

cancers when they were exposed to RF energy compared to

controls. There is much uncertainty among scientists about

whether results obtained from animal studies apply to the use

159

Additional Health and Safety Information

of mobile phones. First, it is uncertain how to apply the results

obtained in rats and mice to humans. Second, many of the

studies that showed increased tumor development used

animals that had already been treated with cancer-causing

chemicals, and other studies exposed the animals to the RF

virtually continuously—up to 22 hours per day.

For the past ﬁve years in the United States, the mobile phone

industry has supported research into the safety of mobile

phones. This research has resulted in two ﬁndings in

particular that merit additional study:

In a hospital-based, case-control study, researchers

looked for an association between mobile phone use and

either glioma (a type of brain cancer) or acoustic neuroma

(a benign tumor of the nerve sheath). No statistically

signiﬁcant association was found between mobile phone

use and acoustic neuroma. There was also no association

between mobile phone use and gliomas when all types of

types of gliomas were considered together. It should be

noted that the average length of mobile phone exposure in

this study was less than three years.

When 20 types of glioma were considered separately,

however, an association was found between mobile phone

use and one rare type of glioma, neuroepithelliomatous

tumors. It is possible with multiple comparisons of the

same sample that this association occurred by chance.

Moreover, the risk did not increase with how often the

mobile phone was used, or the length of the calls. In fact,

the risk actually decreased with cumulative hours of

mobile phone use. Most cancer causing agents increase

risk with increased exposure. An ongoing study of brain

160

Additional Health and Safety Information

cancers by the National Cancer Institute is expected to

bear on the accuracy and repeatability of these results.

Researchers conducted a large battery of laboratory tests

to assess the effects of exposure to mobile phone RF on

genetic material. These included tests for several kinds of

abnormalities, including mutations, chromosomal

aberrations, DNA strand breaks, and structural changes in

the genetic material of blood cells called lymphocytes.

None of the tests showed any effect of the RF except for

the micronucleus assay, which detects structural effects

on the genetic material. The cells in this assay showed

changes after exposure to simulated cell phone radiation,

but only after 24 hours of exposure. It is possible that

exposing the test cells to radiation for this long resulted in

heating. Since this assay is known to be sensitive to

heating, heat alone could have caused the abnormalities

to occur. The data already in the literature on the response

of the micronucleus assay to RF are conﬂicting. Thus,

follow-up research is necessary.

FDA is currently working with government, industry, and

academic groups to ensure the proper follow-up to these

industry-funded research ﬁndings. Collaboration with the

Cellular Telecommunications Industry Association (CTIA) in

particular is expected to lead to FDA providing research

recommendations and scientiﬁc oversight of new CTIA-

funded research based on such recommendations.

Two other studies of interest have been reported recently in

the literature:

Two groups of 18 people were exposed to simulated

mobile phone signals under laboratory conditions while

161

Additional Health and Safety Information

they performed cognitive function tests. There were no

changes in the subjects' ability to recall words, numbers,

or pictures, or in their spatial memory, but they were able

to make choices more quickly in one visual test when they

were exposed to simulated mobile phone signals. This

was the only change noted among more than 20 variables

compared.

In a study of 209 brain tumor cases and 425 matched

controls, there was no increased risk of brain tumors

associated with mobile phone use. When tumors did exist

in certain locations, however, they were more likely to be

on the side of the head where the mobile phone was

used.

Because this occurred in only a small number of cases,

the increased likelihood was too small to be statistically

signiﬁcant.

In summary, we do not have enough information at this point

to assure the public that there are, or are not, any low incident

health problems associated with use of mobile phones. FDA

continues to work with all parties, including other federal

agencies and industry, to assure that research is undertaken

to provide the necessary answers to the outstanding

questions about the safety of mobile phones.

What is known about cases of human cancer that

have been reported in users of hand-held mobile

phones?

Some people who have used mobile phones have been

diagnosed with brain cancer. But it is important to understand

that this type of cancer also occurs among people who have

not used mobile phones. In fact, brain cancer occurs in the

162

Additional Health and Safety Information

U.S. population at a rate of about 6 new cases per 100,000

people each year. At that rate, assuming 80 million users of

mobile phones (a number increasing at a rate of about 1

million per month), about 4800 cases of brain cancer would be

expected each year among those 80 million people, whether

or not they used their phones. Thus it is not possible to tell

whether any individual's cancer arose because of the phone,

or whether it would have happened anyway. A key question is

whether the risk of getting a particular form of cancer is

greater among people who use mobile phones than among

the rest of the population. One way to answer that question is

to compare the usage of mobile phones among people with

brain cancer with the use of mobile phones among

appropriately matched people without brain cancer. This is

called a case-control study. The current case-control study of

brain cancers by the National Cancer Institute, as well as the

follow-up research to be sponsored by industry, will begin to

generate this type of information.

What is FDA's role concerning the safety of

mobile phones?

Under the law, FDA does not review the safety of radiation-

emitting consumer products such as mobile phones before

marketing, as it does with new drugs or medical devices.

However, the agency has authority to take action if mobile

phones are shown to emit radiation at a level that is

hazardous to the user. In such a case, FDA could require the

manufacturers of mobile phones to notify users of the health

hazard and to repair, replace or recall the phones so that the

hazard no longer exists.

Although the existing scientiﬁc data do not justify FDA

regulatory actions at this time, FDA has urged the mobile

163

Additional Health and Safety Information

phone industry to take a number of steps to assure public

safety. The agency has recommended that the industry:

•support needed research into possible biological effects

of RF of the type emitted by mobile phones

•design mobile phones in a way that minimizes any RF

exposure to the user that is not necessary for device

function

•cooperate in providing mobile phone users with the best

possible information on what is known about possible

effects of mobile phone use on human health

At the same time, FDA belongs to an interagency working

group of the federal agencies that have responsibility for

different aspects of mobile phone safety to ensure a

coordinated effort at the federal level. These agencies are:

•National Institute for Occupational Safety and Health

•Environmental Protection Agency

•Federal Communications Commission

•Occupational Health and Safety Administration

•National Telecommunications and Information

Administration

The National Institutes of Health also participates in this

group.

In the absence of conclusive information about

any possible risk, what can concerned

individuals do?

If there is a risk from these products—and at this point we do

not know that there is—it is probably very small. But if people

164

Additional Health and Safety Information

are concerned about avoiding even potential risks, there are

simple steps they can take to do so. For example, time is a

key factor in how much exposure a person receives. Those

persons who spend long periods of time on their hand-held

mobile phones could consider holding lengthy conversations

on conventional phones and reserving the hand-held models

for shorter conversations or for situations when other types of

phones are not available.

People who must conduct extended conversations in their

cars every day could switch to a type of mobile phone that

places more distance between their bodies and the source of

the RF, since the exposure level drops off dramatically with

distance. For example, they could switch to:

•a mobile phone in which the antenna is located outside

the vehicle

•a hand-held phone with a built-in antenna connected to a

different antenna mounted on the outside of the car or

built into a separate package

•a headset with a remote antenna to a mobile phone

carried at the waist

Again, the scientiﬁc data do not demonstrate that mobile

phones are harmful. But if people are concerned about the

radio frequency energy from these products, taking the simple

precautions outlined above can reduce any possible risk.

Where can I ﬁnd additional information?

For additional information, see the following Web sites:

Federal Communications Commission (FCC) RF Safety

Program (select “Information on Human Exposure to RF

165

Additional Health and Safety Information

Fields from Cellular and PCS Radio Transmitters”):

http://www.fcc.gov/oet/rfsafety

World Health Organization (WHO) International

Commission on Non-Ionizing Radiation Protection (select Qs

& As):

http://www.who.int/emf

United Kingdom, National Radiological Protection Board:

http://www.nrpb.org.uk

Cellular Telecommunications Industry Association

(CTIA):

http://www.wow-com.com

U.S. Food and Drug Administration (FDA) Center for

Devices and Radiological Health:

http://www.fda.gov/cdrh/consumer/

1. Muscat et al. Epidemiological Study of Cellular Telephone Use

and Malignant Brain Tumors. In: State of the Science

Symposium;1999 June 20; Long Beach, California.

2. Tice et al. Tests of mobile phone signals for activity in

genotoxicity and other laboratory assays. In: Annual Meeting of

the Environmental Mutagen Society; March 29, 1999,

Washington, D.C.; and personal communication, unpublished

results.

3. Preece, AW, Iwi, G, Davies-Smith, A, Wesnes, K, Butler, S, Lim,

E, and Varey, A. Effect of a 915-MHz simulated mobile phone

signal on cognitive function in man. Int. J. Radiat. Biol., April 8,

1999.

4. Hardell, L, Nasman, A, Pahlson, A, Hallquist, A and Mild, KH.

Use of cellular telephones and the risk for brain tumors: a case-

control study. Int. J. Oncol., 15: 113-116, 1999.

ITC00-010

166

Warranty

MOTOROLA LIMITED WARRANTY FOR

PERSONAL COMMUNICATION PRODUCTS,

ACCESSORIES AND SOFTWARE PURCHASED IN

THE UNITED STATES OR CANADA

What Does this Warranty Cover?

Subject to the exclusions contained below, Motorola, Inc.

warrants its wireless telephones, pagers and consumer

two-way radios that operate via Family Radio Service or

General Mobile Radio Service (“Products”), Motorola-branded

or certiﬁed accessories sold for use with these Products

(“Accessories”) and Motorola software contained on

CD-ROMs or other tangible media and sold for use with these

Products (“Software”) to be free from defects in materials and

workmanship under normal consumer usage for the period(s)

outlined below. This limited warranty is a consumer's exclusive

remedy, and applies as follows to new Motorola Products,

Accessories and Software purchased by consumers in the

United States or Canada, which are accompanied by this

written warranty:

167

Warranty

Products and Accessories

Products Covered Length of Coverage

Products and

Accessories as deﬁned

above, unless otherwise

provided for below.

One (1) year from the date of

purchase by the ﬁrst consumer

purchaser of the product

unless otherwise provided for

below.

Decorative Accessories

and Cases. Decorative

covers, bezels,

PhoneWrap™ covers and

cases.

Limited lifetime warranty for

the lifetime of ownership by the

ﬁrst consumer purchaser of

the product.

Monaural Headsets. Ear

buds and boom headsets

that transmit mono sound

through a wired

connection.

Limited lifetime warranty for

the lifetime of ownership by the

ﬁrst consumer purchaser of

the product.

Consumer Two-Way

Radio Accessories. Ninety (90) days from the

date of purchase by the ﬁrst

consumer purchaser of the

product.

Products and

Accessories that are

Repaired or Replaced.

The balance of the original

warranty or for ninety (90)

days from the date returned to

the consumer, whichever is

longer.

168

Warranty

Exclusions

Normal Wear and Tear. Periodic maintenance, repair and

replacement of parts due to normal wear and tear are

excluded from coverage.

Batteries. Only batteries whose fully charged capacity falls

below 80% of their rated capacity and batteries that leak are

covered by this limited warranty.

Abuse & Misuse. Defects or damage that result from:

(a) improper operation, storage, misuse or abuse, accident or

neglect, such as physical damage (cracks, scratches, etc.) to

the surface of the product resulting from misuse; (b) contact

with liquid, water, rain, extreme humidity or heavy

perspiration, sand, dirt or the like, extreme heat, or food;

purposes or subjecting the Product or Accessory to abnormal

usage or conditions; or (d) other acts which are not the fault of

Motorola, are excluded from coverage.

Use of Non-Motorola Products and Accessories. Defects

or damage that result from the use of Non-Motorola branded

or certiﬁed Products, Accessories, Software or other

peripheral equipment are excluded from coverage.

Unauthorized Service or Modiﬁcation. Defects or damages

resulting from service, testing, adjustment, installation,

maintenance, alteration, or modiﬁcation in any way by

someone other than Motorola, or its authorized service

centers, are excluded from coverage.

Altered Products. Products or Accessories with (a) serial

numbers or date tags that have been removed, altered or

obliterated; (b) broken seals or that show evidence of

tampering; (c) mismatched board serial numbers; or

169

Warranty

(d) nonconforming or non-Motorola housings, or parts, are

excluded form coverage.

Communication Services. Defects, damages, or the failure

of Products, Accessories or Software due to any

communication service or signal you may subscribe to or use

with the Products Accessories or Software is excluded from

coverage.

Software

Exclusions

Software Embodied in Physical Media. No warranty is

made that the software will meet your requirements or will

work in combination with any hardware or software

applications provided by third parties, that the operation of the

software products will be uninterrupted or error free, or that all

defects in the software products will be corrected.

Software NOT Embodied in Physical Media. Software that

is not embodied in physical media (e.g. software that is

downloaded from the internet), is provided “as is” and without

warranty.

Products Covered Length of Coverage

Software. Applies only to

physical defects in the media

that embodies the copy of the

software (e.g. CD-ROM, or

ﬂoppy disk).

Ninety (90) days from the

date of purchase.

170

Warranty

Who is Covered?

This warranty extends only to the ﬁrst consumer purchaser,

and is not transferable.

What Will Motorola Do?

Motorola, at its option, will at no charge repair, replace or

refund the purchase price of any Products, Accessories or

Software that does not conform to this warranty. We may use

functionally equivalent reconditioned/refurbished/pre-owned

or new Products, Accessories or parts. No data, software or

applications added to your Product, Accessory or Software,

including but not limited to personal contacts, games and

ringer tones, will be reinstalled. To avoid losing such data,

software and applications please create a back up prior to

requesting service.

How to Obtain Warranty Service or Other

Information?

To obtain service or information, please call:

USA Canada

Phones 1-800-331-6456 All Products

1-800-461-4575

Pagers 1-800-548-9954

Two-Way Radios 1-800-353-2729 TTY 1-888-390-6456

TTY 1-888-390-6456

For Accessories and Software, please call the telephone

number designated above for the product with which they

are used.

171

Warranty

You will receive instructions on how to ship the Products,

Accessories or Software, at your expense, to a Motorola

Authorized Repair Center. To obtain service, you must

include: (a) a copy of your receipt, bill of sale or other

comparable proof of purchase; (b) a written description of the

problem; (c) the name of your service provider, if applicable;

(d) the name and location of the installation facility (if

applicable) and, most importantly; (e) your address and

telephone number.

What Other Limitations Are There?

ANY IMPLIED WARRANTIES, INCLUDING WITHOUT

LIMITATION THE IMPLIED WARRANTIES OF

MERCHANTABILITY AND FITNESS FOR A PARTICULAR

PURPOSE, SHALL BE LIMITED TO THE DURATION OF

THIS LIMITED WARRANTY, OTHERWISE THE REPAIR,

REPLACEMENT, OR REFUND AS PROVIDED UNDER THIS

EXPRESS LIMITED WARRANTY IS THE EXCLUSIVE

REMEDY OF THE CONSUMER, AND IS PROVIDED IN LIEU

OF ALL OTHER WARRANTIES, EXPRESS OF IMPLIED. IN

NO EVENT SHALL MOTOROLA BE LIABLE, WHETHER IN

CONTRACT OR TORT (INCLUDING NEGLIGENCE) FOR

DAMAGES IN EXCESS OF THE PURCHASE PRICE OF

THE PRODUCT, ACCESSORY OR SOFTWARE, OR FOR

ANY INDIRECT, INCIDENTAL, SPECIAL OR

CONSEQUENTIAL DAMAGES OF ANY KIND, OR LOSS OF

REVENUE OR PROFITS, LOSS OF BUSINESS, LOSS OF

INFORMATION OR DATA, SOFTWARE OR APPLICATIONS

OR OTHER FINANCIAL LOSS ARISING OUT OF OR IN

CONNECTION WITH THE ABILITY OR INABILITY TO USE

THE PRODUCTS, ACCESSORIES OR SOFTWARE TO THE

172

Warranty

FULL EXTENT THESE DAMAGES MAY BE DISCLAIMED BY

LAW.

Some states and jurisdictions do not allow the limitation

or exclusion of incidental or consequential damages, or

limitation on the length of an implied warranty, so the

above limitations or exclusions may not apply to you.

This warranty gives you speciﬁc legal rights, and you

may also have other rights that vary from state to state or

from one jurisdiction to another.

Laws in the United States and other countries preserve for

Motorola certain exclusive rights for copyrighted Motorola

software such as the exclusive rights to reproduce and

distribute copies of the Motorola software. Motorola software

may only be copied into, used in, and redistributed with, the

Products associated with such Motorola software. No other

use, including without limitation disassembly of such Motorola

software or exercise of the exclusive rights reserved for

Motorola, is permitted.

ITC02-154

173

Product Registration

Online Product Registration:

http://www.motorola.com/warranty

Product registration is an important step toward enjoying your

new Motorola product. Registering helps us facilitate warranty

service, and permits us to contact you should your product

require an update or other service. Registration is for U.S.

residents only and is not required for warranty coverage.

Please retain your original dated sales receipt for your

records. For warranty service of your Motorola Personal

Communications Product you will need to provide a copy of

your dated sales receipt to conﬁrm warranty status.

Thank you for choosing a Motorola product.

Export Law

Assurances

This product is controlled under the export regulations of the

United States of America and Canada. The Governments of

the United States of America and Canada may restrict the

exportation or re-exportation of this product to certain

destinations. For further information contact the U.S.

Department of Commerce or the Canadian Department of

Foreign Affairs and International Trade.

174

Index

accessories

optional 10, 80, 110,

125, 127, 131

standard 18

accessory connector port

active line indicator

deﬁned 24

illustration 23

Add Digits

feature 60

alarm 75, 77

alert

creating 97–104

deﬁned 95

reminders, turning on/off

104

selecting 95–96

turning off 30

analog signal indicator

deﬁned 24

illustration 23

animation 56

answering a call 22

antenna 1

application, locking 53

appointments.

See

datebook

Attach Number

feature 32,

backlight 55

battery

car kit charger time 129

charging 19–20

extending battery life

25–27, 55, 56

installing 18–19

level indicator 20, 23,

meter 52

battery save 56

blackjack 120–121

block cursor, deﬁned 38

browse text mode 39

browser.

See

micro-browser

calculator 116–118

calendar.

See

datebook

175

Index

call

adding digits after phone

number 60

alert, creating 97–104

alert, selecting 95–96

alert, turning off 30

answer options 53

answering 22

call waiting 33

calling card 67

canceling 30

data call 134–136

datebook, opening 34

deleting 59–60

dialed calls list 32, 34,

59–60

dialing 21

dialing a recent call

59–60

emergency number 29

ending 22

in-call timer 53

incoming call type,

setting 135–136

making 21

message center,

accessing 34

muting 34

preﬁx digits, inserting

privacy 28, 142

call (continued)

received calls list 32,

34, 59–60

receiving 22

recent calls 59–60

restricting 140–141

ring style, setting 95

secure connection 28,

142

speakerphone,

activating 34

storing 59–60

three-way call 33

timing 61–63

unanswered call 29

voice dial 32

call timers 61–63

resetting 63

viewing 63

call waiting 33

caller ID 28, 29

calling card call 67

calling line identiﬁcation.

See

caller ID

car kit

automatic answer 128

automatic hands-free

128

charger time 129

power-off delay 129

clock 23

176

Index

codes

changing 137–138

default 21

if you forget a

code/password

138

original 137

computer

connecting to phone

131–133

contrast, display 56

currency converter 118

cursor 38

customer service, calling

customizing the menu 124

data call

connecting to external

device 131–133

incoming call format,

setting 135–136

receiving 135–136

sending 134

date, setting 55

datebook

adding an event 77

alarm 77

calendar 75

changing event

information 77

datebook (continued)

copying an event 78

day view 76

deleting an event 79

event reminders, turning

on/off 104

event view 76

reminders 77

week view 75

deleting a call 59–60

dialed calls list 32, 34,

59–60

dialing a number 21

Dialing Menu

digital signal indicator

deﬁned 24

illustration 23

display

animation 56

backlight 55

contrast 56

described 23–25

greeting 54

idle display 23

illustration 23

language 56

zoom setting 55

zooming in/out 25

drafts folder 50

DTMF tones 34, 56, 60,

148

177

Index

earpiece

illustration 1

volume, adjusting 25

address, storing in

phonebook

65–67

email, sending 70, 91–93

emergency number 29

end key

functions 1, 22

menu functions 35

ending a call 22

Enter Unlock Code

message 138, 140

event alert 95–96

exchange rate, calculating

118

external device

connecting to phone

131–133

factory settings, resetting

56–57

falling numbers 121–122

ﬂashing cursor, deﬁned 38

FM Stereo Radio Headset

49, 80–82

games 119–123

greeting, display 54

hands-free mode

automatic answer 128

automatic call routing

128

charger time 129

deﬁned 127

power-off delay 129

speakerphone,

activating 34

headset

automatic answer 128

FM Stereo Radio

Headset 49,

80–82

headset jack 1

high-security connection

28, 142

idle display, deﬁned 23

in use indicator

deﬁned 24

illustration 23

inbox, text message

85–86

in-call timer 53

178

Index

incoming call

canceling 30

type, setting 135–136

Incoming Call

message

indicators

active line 23, 24

battery level 20, 23, 24

digital/analog signal 23,

in use 23, 24

loud ring style 25, 95

menu 23, 24

message waiting 23,

24, 87

missed call 29

ring style 23, 25, 95

roam 23, 24

signal strength 23, 24

silent alert 25

silent ring style 25, 95

soft ring style 25, 95

vibrate and ring style

25, 95

vibrate style 25, 95

voice message waiting

23, 24, 84

voice name 64

iTAP software 44–47

key

end 1, 22, 35

left soft key 1, 23, 35,

124

lock 53, 140

menu 1, 10, 24, 35

power 1, 21

right soft key 1, 23, 35,

124

scroll 1, 35

send 1, 21, 22, 59

voice 1, 69, 108

volume control 1, 25

keypad

answering calls 53

locking and unlocking

53, 140

volume, setting 97

language, setting 56

left soft key

customizing 124

functions 1, 23, 35

Line Not Secure

message

lock

applications 53

keypad 53, 140

179

Index

lock (continued)

phone 139–140

voice notes 112

lock application feature 53

loud ring style indicator

25, 95

Low Battery

message 24

making a call 21

master clear 57

master reset 56

Memory is Full!

message

Browser Menu

115

Calculator Menu

116

customizing 124

Datebook Menu

75, 76

Dialing Menu

32, 61

entering text 37–38,

39–47

features 48–58

language, setting 56

Last Calls Menu

lists 36

locking applications 53

My Tones Menu

102, 104

navigating 10, 35

Phonebook Menu

Quick Note Menu

93–94

menu (continued)

rearranging features

124

scroll feature 55

Text Msg Menu

89–90

using features 10,

36–38

Voice Notes Menu

109,

110, 111

menu indicator

deﬁned 24

illustration 23

menu key 1, 10, 24, 35

message

deleting, text 87–90

dialing number from 31

drafts folder 50

inbox setup, text

message 85–86

locking, text 87–90

outbox 50, 94

quick note 93–94

reading, text 87–90

receiving, text 86–87

reminders, receiving 84,

reminders, turning on/off

104

sending 32, 91–93

sound 90

status 94

180

Index

message (continued)

text 85–94

voicemail 83–84

message waiting indicator

deﬁned 24

displayed 87

illustration 23

micro-browser

using 114–115

microphone 1

missed call indicator 29

Missed Call

message 29

missed call, dialing 32

muting a call 34

my telephone number 22,

34, 51

my tones 97–104

My Tones Menu

102, 104

network settings 57

notepad

deﬁned 61

entering digits 61

retrieving digits 61

number, viewing your own

numeric text mode 39

one-touch dial

deﬁned 31

using 31

voicemail number 31

optional accessory,

deﬁned 10

optional feature, deﬁned

outbox 50, 94

passwords.

See

codes

pause character 68

phone

active line indicator 24

alert, turning off 30

answer options 53

codes 137–138

connecting to external

device 131–133

erase user-entered

information 57

feature speciﬁcations

34, 52

information 34

keypad, locking and

unlocking 53,

140

locking 139–140

muting a call 34

181

Index

phone (continued)

reset all options 56

secure connection 28,

142

security code 137

speciﬁcations 34, 52

turning on/off 21

unlock code 21, 137,

138

unlocking 21, 139–140

voice dial 32

phone number

active line indicator 24

active phone line,

changing 52

adding digits after 60

attaching to preﬁx digits

attaching two numbers

redialing 28

seeing your own 22, 34

sending text message to

storing in phonebook

65–67

viewing your own 51

voice dial 32

phonebook

attaching two numbers

capacity, checking 72

phonebook (continued)

deleting an entry 71

dialing a number 70

editing an entry 71

email address 64

entry details 64

entry name 64

number type indicator

one-touch dial 31

phone number 64

preﬁx digits, inserting

primary number, setting

ringer ID,

activating/deactiv

ating 96

ringer ID, deﬁned 66, 96

ringer ID, setting 66

sending an email 70

sorting entries 73

speed dial number 64,

speed dial number,

deﬁned 31

speed dial, using 31

storing an entry 65–67

voice name entry 69

voice name indicator 64

PIN code 67

power key 1, 21

182

Index

predictive text entry 44–47

privacy, call 28, 142

quick dial

changing number(s) 55

using 49

quick note 93–94

deﬁned 85

radio 80–82

received calls list 32, 34,

59–60

recent calls 59–60

redial

busy number 28

reminders

datebook 77

deﬁned 104

text message 87

turning on/off 104

voicemail message 84

restricting calls 140–141

right soft key

customizing 124

functions 1, 23, 35

ring alert

selecting 95–96

turning off 30

ring style

customizing 95–97

deﬁned 95

indicators 25, 95

setting 95

ring style indicator

deﬁned 25, 95

illustration 23

ringer

volume, adjusting 25

volume, setting 97

ringer ID

activating/deactivating

deﬁned 66, 96

listed in phonebook

entry 64

setting for phonebook

entry 66

roam indicator

deﬁned 24

illustration 23

scroll feature 55

scroll keys 1, 35

secure connection 28, 142

security code

changing 137–138

send key 1, 21, 22, 59

short message service.

See

text message

183

Index

shortcuts

creating 105–106

standard 105

using 107

signal strength indicator

deﬁned 24

illustration 23

silent alert indicator 25

silent ring style indicator

25, 95

SMS.

See

text message

soft keys

customizing 124

functions 23, 35

illustration 1

labels 23

soft ring style indicator 25,

sound

storing 90

speakerphone, activating

speed dial

changing number 66

number, deﬁned 31

sorting phonebook

entries by 73

using 31

standby time, increasing

storing a call 59–60

symbol text mode 43–44

symbols, entering 43–44

Talk Secure

feature 28,

142

tap method text entry

40–42

telephone number, viewing

your own 51

text

block cursor 38

browse mode 39

character chart 42

entering from keypad

39–47

entry mode, changing

ﬂashing cursor 38

iTAP software predictive

text entry 44–47

numeric mode 39

symbol chart 43

symbol mode 43–44

tap method 40–42

text message

deﬁned 85

deleting 87–90

dialing number from 31

drafts folder 50

inbox setup 85–86

locking 87–90

184

Index

text message (continued)

outbox 50

quick note 93–94

reading 87–90

receiving 86–87

reminders 87

sending 32, 91–93

sound 90

status 94

text mode, changing 39

three-way call 33

time, setting 55

timers 61–63

resetting 63

viewing 63

travel charger, using 20

TTY device 125–127

unlock

keypad 53, 140

phone 139–140

unlock code 138

bypassing 138

changing 137–138

entering 21, 139, 140

vibrate alert

selecting 95–96

turning off 30

vibrate and ring style

indicator 25, 95

vibrate ring style

setting 95

vibrate style

indicator 25, 95

video poker 122–123

voice dial

dialing a number 32, 70

recording voice name

voice key

dialing a number 32

functions 1

recording a voice name

recording a voice note

108

voice message waiting

indicator 23, 24, 84

voice name

deﬁned 69

phonebook indicator 64

recording 69

voice notes 108–113

185

Index

voice shortcut

creating 105–106

deﬁned 105

using 107

voicemail

dialing with one-touch

dial 31

reminders, turning on/off

104

using 83–84

volume

earpiece 25

keypad 97

ringer 25, 97

volume keys 1, 25

wait character 68

warranty 166–172

Web pages 114–115

zoom setting 55

zooming in/out 25

U.S. patent Re. 34,976

186

Index

✂

187

Wireless Phone Safety

Tips

“Safety is your most important call!”

Your Motorola wireless telephone gives you

the powerful ability to communicate by voice—

almost anywhere, anytime, wherever wireless

phone service is available and safe conditions allow.

But an important responsibility accompanies the

beneﬁts of wireless phones, one that every user

must uphold.

When driving a car, driving is your ﬁrst

responsibility. If you ﬁnd it necessary to use your

wireless phone while behind the wheel of a car,

practice good common sense and remember the

following tips:

1 Get to know your Motorola wireless phone and its

features such as speed dial and redial. If available,

these features help you to place your call without taking

your attention off the road.

✂

188

2 When available, use a hands-free device. If possible,

add an additional layer of convenience to your wireless

phone with one of the many Motorola Original™ hands-

free accessories available today.

3 Position your wireless phone within easy reach. Be

able to access your wireless phone without removing

your eyes from the road. If you receive an incoming call

at an inconvenient time, if possible, let your voice mail

answer it for you.

4 Let the person you are speaking with know you are

driving; if necessary, suspend the call in heavy

trafﬁc or hazardous weather conditions. Rain, sleet,

snow, ice, and even heavy trafﬁc can be hazardous.

5 If you receive an incoming call at an inconvenient

time do not take notes or look up phone numbers

while driving. Jotting down a “to do” list or going

through your address book takes attention away from

your primary responsibility—driving safely.

6 Dial sensibly and assess the trafﬁc; if possible,

place calls when you are not moving or before

pulling into trafﬁc. Try to plan calls when your car will

be stationary. If you need to make a call while moving,

dial only a few numbers, check the road and your

mirrors, then continue.

7 Do not engage in stressful or emotional

conversations that may be distracting. Make people

you are talking with aware you are driving and suspend

conversations which have the potential to divert your

attention away from the road.

✂

189

8 Use your wireless phone to call for help. Dial 9-1-1 or

other local emergency number in the case of ﬁre, trafﬁc

accident or medical emergencies.*

9 Use your wireless phone to help others in

emergencies. If you see an auto accident, crime in

progress or other serious emergency where lives are in

danger, call 9-1-1 or other local emergency number, as

you would want others to do for you.*

10 Call roadside assistance or a special

non-emergency wireless assistance number when

necessary. If you see a broken-down vehicle posing no

serious hazard, a broken trafﬁc signal, a minor trafﬁc

accident where no one appears injured, or a vehicle you

know to be stolen, call roadside assistance or other

special non-emergency wireless number.*

* Wherever wireless phone service is available.

✂

190

Check the laws and regulations on the use of

wireless telephones and their accessories in the

areas where you drive. Always obey them. The

use of these devices may be prohibited or

restricted in certain areas.

For more information,

please call

1-888-901-SAFE

or visit the

CTIA Web site at

www.wow-com.com™

ITC00-011

motorola.com

8988485L49-O

Motorola Mobility T56CA2 Portable Cellular/PCS Transceiver (AMPS/TDMA) User Manual CA EX08A

Motorola Mobility LLC Portable Cellular/PCS Transceiver (AMPS/TDMA) CA EX08A

ex 08 Users Manual

Navigation menu

Namespaces

Views

Navigation
