Motorola Mobility T56CG1 Portable Cellular/PCS Transceiver (AMPS/CDMA) User Manual CG EX08
Motorola Mobility LLC Portable Cellular/PCS Transceiver (AMPS/CDMA) CG EX08
Exhibit 8 Preliminary Users Manual Draft
APPLICANT: MOTOROLA, INC. FCC ID: IHDT56CG1
EXHIBIT 8
INSTRUCTION MANUAL
A preliminary draft copy of the Users Manual follows:
PRELIMINARY
Motorola T720
CDMA R2.1
Mobile Phone User’s Guide
FCC Submission Draft
February 18, 2002
PRELIMINARY
1
PRELIMINARY
Welcome
Welcome to the world of Motorola digital wireless
communications! We are pleased that you have chosen the
Motorola T720 wireless phone.
Earpiece
Headset Jack
Insert headset
accessory for
hands-free use.
Status Light
See incoming call
and service status.
Volume Keys
Adjust earpiece
and ringer volume.
Voice Key
Record voice notes,
phonebook and
shortcut names.
Display
Microphone
Accessory
Connector Port
Insert charger and
phone accessories.
Power Key
& End Key
Turn phone on and
off, end phone
calls, exit menu
system.
Right Soft Key
Perform functions
identified by right
display prompt.
Menu Key
Left Soft Key
Perform functions
identified by left
display prompt.
Send Key
Send and answer
calls, view recent
dialed calls list.
4-Way
Navigation Key
Scroll through
menus and lists,
set feature values.
2
PRELIMINARY
Personal Communications Sector
600 North U.S. Highway 45
Libertyville, Illinois 60048
1-800-331-6456 (United States)
1-888-390-6456 (TTY/TDD United States)
1-800-461-4575 (Canada)
www.motorola.com
(United States)
www.motorola.ca
(Canada)
MOTOROLA, the Stylized M Logo and all other trademarks indicated as
such herein are trademarks of Motorola, Inc. ® Reg. U.S. Pat. & Tm. Off.
All other product or service names are the property of their respective
owners.
© 2002 Motorola, Inc. All rights reserved.
Software Copyright Notice
The Motorola products described in this manual may include copyrighted
Motorola and third party software stored in semiconductor memories or
other media. Laws in the United States and other countries preserve for
Motorola and third party software providers certain exclusive rights for
copyrighted software, such as the exclusive rights to distribute or
reproduce the copyrighted software. Accordingly, any copyrighted
software contained in the Motorola products may not be modified,
reverse-engineered, distributed, or reproduced in any manner to the
extent allowed by law. Furthermore, the purchase of the Motorola
products shall not be deemed to grant either directly or by implication,
estoppel, or otherwise, any license under the copyrights, patents, or
patent applications of Motorola or any third party software provider,
except for the normal, non-exclusive, royalty-free license to use that
arises by operation of law in the sale of a product.
Manual number: 6809441A31-O
Cover number: 8988485L49-O
✂
3
PRELIMINARY
Menu Map
Main Menu
• Recent Calls
• Received Calls
• Dialed Calls
• Notepad
• Call Times
• Phonebook
• Picture Viewer
• Datebook
• Quick Dial
• Radio
• Chat
• Messages
• Inbox
• Create Msg
• Voicemail
• Email Msgs
• Browser Alerts
• Quick Notes
• Outbox
• Drafts
• Ring Styles
• Style
•
Style
Detail
• My Tones
• Shortcuts
• Voice Notes
• Browser
• My Java Apps
• Calculator
• Games
• Settings
(see next page)
Shortcuts
Change display zoom:
Press
M
, then
press and hold
M
Display my phone number:
Press
M
#
Dial voicemail number:
Press and hold
1
Go to dialed calls list:
Press
N
Exit menu system:
Press
O
Note: This is the standard phone
menu layout. You or your service
provider may have changed the
menu layout or changed some
feature names. Not all features
may be available for all users.
For example, the Radio feature on
the main menu (left) is displayed
only when the optional FM Stereo
Radio Headset accessory is
plugged into the accessory
connector port on your phone
(see phone illustration, page 1).
✂
4
PRELIMINARY
Settings Menu
• Phone Status
• My Tel. Number
• Active Line
• Battery Meter
• Other Information
• Connection
• Incoming Call
• In-Call Setup
• In-Call Timer
• Answer Options
• Security
• Phone Lock
• Lock Application
• Restrict Calls
• New Passwords
• Java Tools
• Java App Loader
• Java System
• Network Access
• Other Settings
• Personalize
• Main Menu
•Keys
• Greeting
• Banner
• Wallpaper
• Screen Saver
• Quick Dial
• Initial Setup
• Time and Date
• Auto PIN Dial
• Auto Redial
• Backlight
• Status Light
• Zoom
• TTY Setup
• Scroll
• Animation
• Language
• Contrast
• DTMF
• Master Reset
• Master Clear
• Network
• Car Settings
• Headset
5
PRELIMINARY
Contents
Contents
Menu Map
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
About This Guide
. . . . . . . . . . . . . . . . . . . . . . . . . . . . .11
Safety and General Information
. . . . . . . . . . . . . . . . . .12
Getting Started
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19
What’s in the Box? . . . . . . . . . . . . . . . . . . . . . . . . . . .19
Installing the Battery . . . . . . . . . . . . . . . . . . . . . . . . . .19
Charging the Battery . . . . . . . . . . . . . . . . . . . . . . . . .20
Replacing the Convertible Cover . . . . . . . . . . . . . . . .21
Turning Your Phone On . . . . . . . . . . . . . . . . . . . . . . .22
Sending a Call . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .23
Ending a Call . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .24
Receiving a Call . . . . . . . . . . . . . . . . . . . . . . . . . . . . .24
Displaying Your Phone Number . . . . . . . . . . . . . . . . .24
About Your Phone
. . . . . . . . . . . . . . . . . . . . . . . . . . . . .25
Display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .25
Changing the Zoom Setting . . . . . . . . . . . . . . . . . . . .27
Status Light . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .28
Volume Keys . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .29
External Display . . . . . . . . . . . . . . . . . . . . . . . . . . . . .29
4-Way Navigation Key . . . . . . . . . . . . . . . . . . . . . . . .29
Battery Use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .30
Sending and Receiving Calls
. . . . . . . . . . . . . . . . . . . .32
Redialing a Number . . . . . . . . . . . . . . . . . . . . . . . . . .32
Using Automatic Redial . . . . . . . . . . . . . . . . . . . . . . .32
Caller ID . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .33
Returning an Unanswered Call . . . . . . . . . . . . . . . . .33
Dialing an Emergency Number . . . . . . . . . . . . . . . . .34
Terminating an Incoming Call . . . . . . . . . . . . . . . . . . .34
6
PRELIMINARY
Contents
Dialing With Speed Dial . . . . . . . . . . . . . . . . . . . . . . . 35
Dialing With One-Touch Dial . . . . . . . . . . . . . . . . . . . 35
Dialing a Number In a Text Message . . . . . . . . . . . . . 36
Additional Dialing Features . . . . . . . . . . . . . . . . . . . . 36
Using Features While On a Call
. . . . . . . . . . . . . . . . . 39
Using Call Waiting . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
Making a Three-Way Call . . . . . . . . . . . . . . . . . . . . . 39
Additional On-Call Features . . . . . . . . . . . . . . . . . . . 40
Using the Menu
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
Navigating to a Feature . . . . . . . . . . . . . . . . . . . . . . . 41
Selecting a Feature Option . . . . . . . . . . . . . . . . . . . . 43
Entering Feature Information . . . . . . . . . . . . . . . . . . . 44
Entering Text
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
Choosing a Text Mode . . . . . . . . . . . . . . . . . . . . . . . . 47
Tap Method . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48
Symbol Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51
Predictive Text Entry with iTAP™ Software . . . . . . . . 52
Menu Feature Descriptions
. . . . . . . . . . . . . . . . . . . . . 56
Recent Calls
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 70
Viewing the Received Calls or Dialed Calls List . . . . 70
Using the Notepad . . . . . . . . . . . . . . . . . . . . . . . . . . . 71
Viewing and Resetting Call Timers . . . . . . . . . . . . . . 72
Phonebook
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 74
Fields in a Phonebook Entry . . . . . . . . . . . . . . . . . . . 74
Storing a Phonebook Entry . . . . . . . . . . . . . . . . . . . . 75
Recording a Voice Name For a Phonebook Entry . . . 77
Dialing a Phonebook Entry . . . . . . . . . . . . . . . . . . . . 78
Editing a Phonebook Entry . . . . . . . . . . . . . . . . . . . . 79
Deleting a Phonebook Entry . . . . . . . . . . . . . . . . . . . 79
Synchronizing with TrueSync Software . . . . . . . . . . . 80
Sorting the Phonebook List . . . . . . . . . . . . . . . . . . . . 80
7
PRELIMINARY
Contents
Picture Viewer
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .82
Downloading Pictures . . . . . . . . . . . . . . . . . . . . . . . . .82
Managing Pictures . . . . . . . . . . . . . . . . . . . . . . . . . . .82
Datebook
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .86
Week View . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .86
Day View . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .87
Event View . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .88
Storing a Datebook Event . . . . . . . . . . . . . . . . . . . . .88
Changing Event Information . . . . . . . . . . . . . . . . . . . .89
Copying an Event . . . . . . . . . . . . . . . . . . . . . . . . . . . .89
Deleting an Event . . . . . . . . . . . . . . . . . . . . . . . . . . . .90
Radio
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .92
Turning the Radio On and Off . . . . . . . . . . . . . . . . . .92
Tuning a Station . . . . . . . . . . . . . . . . . . . . . . . . . . . . .93
Storing a Preset . . . . . . . . . . . . . . . . . . . . . . . . . . . . .93
Selecting a Preset . . . . . . . . . . . . . . . . . . . . . . . . . . .93
Sending and Receiving Calls With the Radio On . . . .93
Chat
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .95
Starting a Chat Session . . . . . . . . . . . . . . . . . . . . . . .95
Using the Chat Log . . . . . . . . . . . . . . . . . . . . . . . . . . .97
Responding to Chat . . . . . . . . . . . . . . . . . . . . . . . . . .98
Ending a Chat Session . . . . . . . . . . . . . . . . . . . . . . . .99
Messages—Voicemail
. . . . . . . . . . . . . . . . . . . . . . . . .100
Storing Your Voicemail Number . . . . . . . . . . . . . . . .100
Receiving a Voicemail Message . . . . . . . . . . . . . . . .101
Listening to a Voicemail Message . . . . . . . . . . . . . .101
Turning Off the Voice Message Waiting Indicator . . .101
Messages—Text
. . . . . . . . . . . . . . . . . . . . . . . . . . . . .102
Setting Up the Message Inbox . . . . . . . . . . . . . . . . .102
Receiving a Text Message . . . . . . . . . . . . . . . . . . . .103
Reading, Locking, or Deleting a Text Message . . . .103
8
PRELIMINARY
Contents
Storing Pictures, Animations, and Sounds From a Text
Message . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 105
Sending a Text Message . . . . . . . . . . . . . . . . . . . . . 108
Sending a Quick Note Text Message . . . . . . . . . . . . 110
Inserting Pictures, Animations, and Sounds in a Text
Message . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 111
Viewing the Status of Sent Text Messages . . . . . . . 113
Messages—Email
. . . . . . . . . . . . . . . . . . . . . . . . . . . . 115
Setting Up the Email Inbox . . . . . . . . . . . . . . . . . . . 115
Receiving an Email Message . . . . . . . . . . . . . . . . . 119
Reading, Locking, or Deleting an Email Message . . 120
Sending an Email Message . . . . . . . . . . . . . . . . . . . 123
Inserting a Quick Note Into an Email Message . . . . 127
Manually Sending and Receiving Email . . . . . . . . . 128
Viewing the Status of Sent Email Messages . . . . . . 129
Calling a Phone Number in an Email Message . . . . 129
Sending Email to an Embedded Email Address . . . 130
Go to a URL in an Email Message . . . . . . . . . . . . . 130
Creating Personal Folders . . . . . . . . . . . . . . . . . . . . 130
Moving Email to a Personal Folder . . . . . . . . . . . . . 131
Renaming a Personal Folder . . . . . . . . . . . . . . . . . . 132
Deleting a Personal Folder . . . . . . . . . . . . . . . . . . . 132
Ring Styles
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 133
Selecting a Ring Style . . . . . . . . . . . . . . . . . . . . . . . 133
Customizing a Ring Style . . . . . . . . . . . . . . . . . . . . 134
Using My Tones . . . . . . . . . . . . . . . . . . . . . . . . . . . . 135
Setting Reminders . . . . . . . . . . . . . . . . . . . . . . . . . . 141
Shortcuts
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 142
Standard Shortcuts . . . . . . . . . . . . . . . . . . . . . . . . . 142
Creating a Shortcut . . . . . . . . . . . . . . . . . . . . . . . . . 142
Using Shortcuts . . . . . . . . . . . . . . . . . . . . . . . . . . . . 144
9
PRELIMINARY
Contents
Voice Notes
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .145
Recording a Voice Note . . . . . . . . . . . . . . . . . . . . . .145
Viewing the Voice Notes List . . . . . . . . . . . . . . . . . .146
Playing a Voice Note . . . . . . . . . . . . . . . . . . . . . . . .147
Locking and Unlocking a Voice Note . . . . . . . . . . . .149
Deleting a Voice Note . . . . . . . . . . . . . . . . . . . . . . . .150
Micro-Browser
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .151
Starting a Micro-Browser Session . . . . . . . . . . . . . .151
Interacting With Web Pages . . . . . . . . . . . . . . . . . . .152
Downloading Pictures, Animations, and Sounds . . .152
J2ME Applications
. . . . . . . . . . . . . . . . . . . . . . . . . . .156
Downloading an Application With the Micro-Browser . . .
156
Downloading an Application From a Computer . . . .156
Launching a J2ME Application . . . . . . . . . . . . . . . . .157
J2ME Application Control Keys . . . . . . . . . . . . . . . .158
Analyzing or Deleting a J2ME Application . . . . . . . .158
Viewing J2ME Version and Available Memory . . . . .159
Calculator
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .161
Calculating Numbers . . . . . . . . . . . . . . . . . . . . . . . .161
Converting Currency . . . . . . . . . . . . . . . . . . . . . . . .163
Games
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .164
Playing a Game . . . . . . . . . . . . . . . . . . . . . . . . . . . .164
Game Options . . . . . . . . . . . . . . . . . . . . . . . . . . . . .164
Blackjack . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .165
Falling Numbers . . . . . . . . . . . . . . . . . . . . . . . . . . . .166
Mindblaster . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .167
Paddleball . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .169
Reversal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .170
Video Poker . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .171
10
PRELIMINARY
Contents
Adjusting Your Settings. . . . . . . . . . . . . . . . . . . . . . . 173
Reordering Menu Items . . . . . . . . . . . . . . . . . . . . . . 173
Customizing a Soft Key Function . . . . . . . . . . . . . . . 173
Wallpaper . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 174
Screen Saver . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 175
TTY Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 176
Hands-Free Use . . . . . . . . . . . . . . . . . . . . . . . . . . . 178
Data and Fax Calls . . . . . . . . . . . . . . . . . . . . . . . . . . . 182
Connecting Your Phone to an External Device . . . . 182
Sending a Data or Fax Call . . . . . . . . . . . . . . . . . . . 185
Receiving a Data or Fax Call . . . . . . . . . . . . . . . . . . 186
Security. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 188
Assigning a New Code or Password . . . . . . . . . . . . 188
If You Forget a Code or Password . . . . . . . . . . . . . . 189
Locking and Unlocking Your Phone . . . . . . . . . . . . . 190
Restricting Calls . . . . . . . . . . . . . . . . . . . . . . . . . . . . 191
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 193
Programming Instructions . . . . . . . . . . . . . . . . . . . . 202
Specific Absorption Rate Data . . . . . . . . . . . . . . . . . 204
Additional Health and Safety Information . . . . . . . . 207
Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 216
Product Registration . . . . . . . . . . . . . . . . . . . . . . . . . 224
Export Law Assurances . . . . . . . . . . . . . . . . . . . . . . 224
Index . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 225
Wireless Phone Safety Tips. . . . . . . . . . . . . . . . . . . . 241
11
PRELIMINARY
About This Guide
About This Guide
This user guide introduces you to the many features in
your Motorola wireless phone.
Navigating To a Menu Feature
You can access many of your phone’s features through the
menu system. This guide shows you how to navigate to a
specific menu feature as follows:
The > symbol means that you should scroll to and select
the feature. This example shows that you must press
M
,
scroll to and select
Messages
, then scroll to and select
Text Msgs
.
Optional Features
Features marked with this label are optional
network and/or subscription-dependent
features. These features may not be offered by
all service providers in all geographical areas.
Contact your service provider for more information.
Optional Accessories
Features marked with this label require the use of
an optional Motorola Original™ accessory.
Find the Feature
M
>
Messages
>
Text Msgs
12
PRELIMINARY
Safety and General Information
Safety and General
Information
IMPORTANT INFORMATION ON SAFE AND EFFICIENT
OPERATION. READ THIS INFORMATION BEFORE USING
YOUR PHONE.
The information provided in this document supersedes the
general safety information contained in user guides published
prior to July 2000. For information regarding radio use in a
hazardous atmosphere please refer to the Factory Mutual
(FM) Approval Manual Supplement or Instruction Card, which
is included with radio models that offer this capability.
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions:
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received,
including interference that may cause undesired operation.
RF Operational Characteristics
Your phone contains a transmitter and a receiver. When it is
ON, it receives and transmits radio frequency (RF) energy.
The phone operates in the frequency range of 824 MHz to
849 MHz in analog and digital mode and 1851.25 MHz to
1908.75 MHz in digital mode.
When you communicate with your phone, the system handling
your call controls the power levels at which your phone
transmits. The output power level typically may vary over a
13
PRELIMINARY
Safety and General Information
range from ____ watts to ____ watts in analog mode and
____ watts to ____ watts in digital mode.
Exposure To Radio Frequency Energy
Your Motorola phone is designed to comply with the following
national and international standards and guidelines regarding
exposure of human beings to radio frequency electromagnetic
energy:
•United States Federal Communications Commission,
Code of Regulations; 47 CFR part 2 sub-part J
•American National Standards Institute (ANSI) / Institute
of Electrical and Electronic Engineers (IEEE) C95.
1-1992
•Institute of Electrical and Electronic Engineers (IEEE)
C95.1-1999 Edition
•National Council on Radiation Protection and
Measurements (NCRP) of the United States, Report
86, 1986
•International Commission on Non-Ionizing Radiation
Protection (ICNIRP) 1998
•Ministry of Health (Canada) Safety Code 6. Limits of
Human Exposure to Radiofrequency Electromagnetic
Fields in the Frequency Range from 3 kHz to 300 GHz,
1999
•Australian Communications Authority
Radiocommunications (Electromagnetic
Radiation-Human Exposure) Standard 1999
To assure optimal phone performance and make sure human
exposure to radio frequency electromagnetic energy is within
14
PRELIMINARY
Safety and General Information
the guidelines set forth in the above standards, always adhere
to the following procedures:
Portable Phone Operation and EME Exposure
Antenna Care
Use only the supplied or an approved replacement
antenna. Unauthorized antennas, modifications, or
attachments could damage the phone and may violate FCC
regulations.
Do NOT hold the antenna when the phone is in use.
Holding the antenna affects call quality and may cause the
phone to operate at a higher power level than needed.
Phone Operation
When placing or receiving a phone call, hold your phone
as you would a wireline telephone. Speak directly into
the microphone.
Body-Worn Operation
To maintain compliance with FCC/Health Canada RF
exposure guidelines, if you wear a phone on your body when
transmitting, always place the phone in a Motorola-supplied or
approved clip, holder, holster, case, or body harness for this
product. Use of non-Motorola-approved accessories may
exceed FCC/Health Canada RF exposure guidelines. If you
do not use one of the Motorola-supplied or approved
body-worn accessories, and are not using the phone held in
the normal use position, ensure the phone and its antenna
are at least one inch (2.5 centimeters) from your body
when transmitting.
15
PRELIMINARY
Safety and General Information
Data Operation
When using any data feature of the phone, with or without an
accessory cable, position the phone and its antenna at
least one inch (2.5 centimeters) from your body.
Approved Accessories
For a list of approved Motorola accessories, visit our website
at
www.mot.com
.
Electromagnetic Interference/Compatibility
Note: Nearly every electronic device is susceptible to
electromagnetic interference (EMI) if inadequately shielded,
designed, or otherwise configured for electromagnetic
compatibility.
Facilities
To avoid electromagnetic interference and/or compatibility
conflicts, turn off your phone in any facility where posted
notices instruct you to do so. Hospitals or health care facilities
may be using equipment that is sensitive to external RF
energy.
Aircraft
When instructed to do so, turn off your phone when on board
an aircraft. Any use of a phone must be in accordance with
applicable regulations per airline crew instructions.
Medical Devices
Pacemakers
The Advanced Medical Technology Association recommends
that a minimum separation of 6 inches (15 centimeters) be
16
PRELIMINARY
Safety and General Information
maintained between a handheld wireless phone and a
pacemaker. These recommendations are consistent with the
independent research by, and recommendations of, the
United States Food and Drug Administration.
Persons with pacemakers should:
•ALWAYS keep the phone more than six inches
(15 centimeters) from your pacemaker when the phone is
turned ON.
•NOT carry the phone in the breast pocket.
•use the ear opposite the pacemaker to minimize the
potential for interference.
•turn OFF the phone immediately if you have any reason
to suspect that interference is taking place.
Hearing Aids
Some digital wireless phones may interfere with some
hearing aids. In the event of such interference, you may
want to consult your hearing aid manufacturer to discuss
alternatives.
Other Medical Devices
If you use any other personal medical device, consult the
manufacturer of your device to determine if it is adequately
shielded from RF energy. Your physician may be able to assist
you in obtaining this information.
Safety and General Use While Driving
Check the laws and regulations on the use of phones in the
area where you drive. Always obey them.
17
PRELIMINARY
Safety and General Information
When using your phone while driving, please:
•give full attention to driving and to the road.
•use hands-free operation, if available.
•pull off the road and park before making or answering a
call if driving conditions so require.
Operational Warnings
For Vehicles With an Air Bag
Do not place a portable phone in the area over an air bag or in
the air bag deployment area. Air bags inflate with great force.
If a portable phone is placed in the air bag deployment area
and the air bag inflates, the phone may be propelled with
great force and cause serious injury to occupants of the
vehicle.
Potentially Explosive Atmospheres
Turn off your phone prior to entering any area with a
potentially explosive atmosphere, unless the phone is a model
specifically identified as being “Intrinsically Safe.” Do not
remove, install, or charge batteries in such areas. Sparks in a
potentially explosive atmosphere can cause an explosion or
fire resulting in bodily injury or even death.
Note: The areas with potentially explosive atmospheres
referred to above include fueling areas such as below decks
on boats, fuel or chemical transfer or storage facilities, areas
where the air contains chemicals or particles, such as grain,
dust, or metal powders, and any other area where you would
normally be advised to turn off your vehicle engine. Areas with
potentially explosive atmospheres are often but not always
posted.
18
PRELIMINARY
Safety and General Information
Blasting Caps and Areas
To avoid possible interference with blasting operations, turn
OFF your phone when you are near electrical blasting caps, in
a blasting area, or in areas posted: “Turn off two-way radio.”
Obey all signs and instructions.
Operational Cautions
Antennas
Do not use any portable phone that has a damaged
antenna. If a damaged antenna comes into contact with your
skin, a minor burn can result.
Batteries
All batteries can cause property damage and/or bodily
injury such as burns if a conductive material such as
jewelry, keys, or beaded chains touches exposed
terminals. The conductive material may complete an
electrical circuit (short circuit) and become quite hot. Exercise
care in handling any charged battery, particularly when
placing it inside a pocket, purse, or other container with metal
objects.
ITC01-101
19
PRELIMINARY
Getting Started
Getting Started
What’s in the Box?
Your wireless phone typically comes equipped with a
battery and a charger. Other accessory options can
customize your phone for maximum performance and
portability.
To purchase Motorola Original™ accessories, contact the
Motorola Customer Call Center at 1-800-331-6456 in the
United States or 1-800-461-4575 in Canada.
Installing the Battery
You must install and charge the battery to use your phone.
Your phone is designed to be used only with
Motorola Original batteries and accessories. We
recommend that you store batteries in their
protective cases when not in use.
Do This
1Remove the battery from its protective clear
plastic case.
20
PRELIMINARY
Getting Started
Charging the Battery
New batteries are shipped partially charged. Before you
can use your phone, you need to install and charge the
battery, as indicated by the following instructions. Some
2If the phone’s
battery door is in
place, slide down
the release latch
and lift the door off
of the phone.
3Insert the battery,
printed arrows first,
into the battery
compartment and
push down.
4Insert the teeth at
the bottom of the
battery door into
the slot at the base
of the phone, then
push the door down
and snap it into
place.
Do This
Release
latch
21
PRELIMINARY
Getting Started
batteries perform best after several full charge/discharge
cycles.
Note: When you charge the battery, the battery level
indicator in the upper right corner of the display shows how
much of the charging process is complete.
Replacing the Convertible
Cover
You can replace the top cover on your flip phone to
personalize its appearance.
Do This
1Plug the
travel
charger into
your phone
with the
release tab
facing up.
2Plug the other end of the travel charger into the
appropriate electrical outlet.
3When your phone indicates that the battery is
fully charged (
Charge Complete
), press the
release tab and remove the travel charger.
Release
tab
22
PRELIMINARY
Getting Started
Your phone is designed to be used only with Motorola
Original accessories. See your Motorola retailer for new or
replacement covers.
Turning Your Phone On
Do This
1Insert your
fingernail into the
slot at the base of
the flip cover, then
pull up and lift the
cover off the
phone
2Insert the tabs on
the top edge of the
new cover into the
slots at the top of
the flip, then push
the cover down
and snap it into
place.
Do This To
1Open your phone expose the keypad
2Press and hold
P
turn on your phone
Power
key
23
PRELIMINARY
Getting Started
Sending a Call
To call a number, your phone must be unlocked and have a
network connection with adequate signal strength.
Note: You can make an emergency call even when the
phone is locked. See page 34.
3If necessary, enter
your four-digit
unlock code and
press
OK
(
+
)
unlock your phone
The unlock code is
originally set to 1234. Your
service provider may
change this number
before you receive your
phone.
Do This To
1Extend the
antenna optimize signal reception
2Press the
keypad keys dial the phone number
Tip: If you make a mistake,
press
DELETE
(
-
) to delete the
last digit, or press and hold
DELETE
(
-
) to clear all digits.
3Press
N
send the call
Do This To
24
PRELIMINARY
Getting Started
Ending a Call
Receiving a Call
To receive a call, your phone must have a network
connection with adequate signal strength. If your phone is
locked, you must unlock it to answer the call.
When you receive a call, your phone rings and/or vibrates
and displays an incoming call message.
Displaying Your Phone Number
From the idle display:
Press To
O
end the call
Press To
N
or
ANSWER
(
+
)answer the call
Press To
M
#
see your phone number
25
PRELIMINARY
About Your Phone
About Your Phone
See page 1 for a basic phone diagram.
Display
Some phone functions must be performed from the
idle
display
, the standard display that you see when you are
not
on a call or using the menu.
Phone status indicators appear at the top of the idle
display, along with the name of your service provider, and
the current time.
Use the 4-way navigation key (
S
) to select a feature
represented by the icons in the center of the idle display, or
press
M
to enter the main menu.
Labels at the bottom corners of the display show the
current soft key functions.
26
PRELIMINARY
About Your Phone
➊
Signal Strength Indicator Vertical bars show the
strength of the network connection. You cannot send or
receive calls when the
j
(no signal) indicator is displayed.
➋
Digital (
F
) or Analog (
I
) Signal
Indicators Your service provider may use one
or both indicators to show whether you are
receiving a digital or analog signal.
➌
In Use Indicator Shows that a call is in progress.
➍
Roam Indicator Shows that your phone
is seeking or using another network system
outside your home network.
4:00
pm
SETTING
Service Provider Name
SHORTCUT
➒
Ring
Style
Indicator
Clock
➊
Signal
Strength
Indicator
➐
Battery
Level
Indicator
➌
In Use
Indicator
➍
Roam
Indicator
➎
Message
Waiting
Indicator
➏
Voice
Message
Waiting
Indicator
➑
Active
line
Indicator
➓
Menu
Indicator
Soft Key Labels
Phonebook
Messages
Datebook
Micro-
Browser
➋
Digital/
Analog
Signal
Indicator
27
PRELIMINARY
About Your Phone
➎
Message Waiting Indicator Appears when
you receive a text message.
➏
Voice Message Waiting Indicator Appears
when you receive a voicemail message.
➐
Battery Level Indicator Vertical bars show the amount
of charge left in your battery. Recharge the battery as soon
as possible when your phone displays
Low Battery
and
you hear the low battery alert.
➑
Active Line Indicator Shows the current
active line.
➒
Ring Style Indicator Shows the current selected ring
style. The default setting is a ringer.
➓
Menu Indicator Indicates that you can press
M
to enter
the main menu or open a feature sub-menu.
Changing the Zoom Setting
You can set your phone’s display to show nine lines or
seven lines of text plus soft key labels. Nine lines of text
display more information, while seven lines increase
text size.
w
= loud ring
x
= soft ring
y
= vibrate
u
= ring and vibrate
t
= silent
28
PRELIMINARY
About Your Phone
To change the display view, press
M
once, then press and
hold
M
again within two seconds of the first press.
You can also adjust the zoom setting from the menu. See
page 66.
Status Light
The status light shows when
you have an incoming call or
message, or when your
phone is
roaming
(using a
non-home system). The light
changes color to indicate
different conditions:
Note: You can turn off the status light to increase your
phone’s
standby time
, the length of time that your phone’s
battery retains power when the phone is turned on but is
not in use. To turn off the status light, see page 66.
Indication Status
alternating red/green incoming call
flashing green in service, home system
flashing yellow roaming, non-home system
flashing red no service
Status
light
29
PRELIMINARY
About Your Phone
Volume Keys
Use the upper and lower
volume keys to adjust
your phone’s earpiece
and ringer volume.
External Display
When the flip is closed, the external display shows the time
and date. It also displays messages to notify you of events
(like incoming calls) that need your attention.
4-Way
Navigation
Key
The 4-way navigation
key functions as a
joystick that you can use to navigate the menu system,
change feature settings, and play games.
When Press To
you are in a call volume
keys increase or decrease
earpiece volume
the idle display
is showing (with
flip opened)
volume
keys increase or decrease
ringer volume
Volume
keys
4-way
navigation
key
30
PRELIMINARY
About Your Phone
Tip: Down and up are your primary movements within
menus. Move left and right to change feature settings,
navigate the datebook, and edit text.
Battery Use
Battery performance depends on many factors, including
your wireless carrier’s network configuration; signal
strength; the temperature at which you operate your
phone; the features and/or settings you select and use;
and your voice, data, and other application usage patterns.
Battery Care
Caution: To prevent injuries or burns, do not allow metal
objects to contact or short-circuit the battery terminals.
To maximize your battery’s performance:
•Always use Motorola Original™ batteries and battery
chargers. The phone warranty does not cover damage
caused from using non-Motorola batteries and/or
battery chargers.
•New batteries or batteries that have been stored for
long periods of time may require a longer charge time.
•Maintain the battery at or near room temperature
when charging.
•Do not expose batteries to temperatures below -
10°C (14°F) or above 45°C (113°F). Always take
your phone with you when you leave your vehicle.
•When you do not intend to use a battery for a
while, store it uncharged in a cool, dark, dry place,
such as a refrigerator.
31
PRELIMINARY
About Your Phone
•Over extended periods of time, batteries gradually
wear down and require longer charging times. This is
normal. If you charge your battery regularly and notice
a decrease in talk time or an increase in charging
time, then it is probably time to purchase a new
battery.
The rechargeable batteries that power this
product must be disposed of properly and may
need to be recycled. Refer to your battery’s label
for battery type. Contact your local recycling center for
proper disposal methods. Never dispose of batteries in a
fire because they may explode.
Extending Battery Life
• Talk less or send fewer messages
It’s simple, but the more you talk or send messages,
the more battery power you use.
• Turn off your status light
The status light uses power. To turn it off, see
page 66.
• Turn off your display backlight
The backlight uses power, too. To turn it off, see
page 66.
• Avoid keypad-intense functions
Activities that require intensive keystroke use
(such as playing a game or using messaging)
reduce your phone’s talk and standby time.
• Spend less time on the Internet
Using your phone’s Internet micro-browser reduces
the phone’s talk and standby time.
32
PRELIMINARY
Sending and Receiving Calls
Sending and
Receiving Calls
For basic instructions on how to send a call, end a call,
and receive a call, see pages 23–24.
Redialing a Number
If you hear an ordinary busy signal:
Using Automatic Redial
If the network is busy, you hear a fast busy signal, and your
phone displays
Call Failed
.
With automatic redial, your phone automatically repeats
the call attempt for four minutes. When the call goes
through, your phone rings or vibrates one time, displays
Redial Successful
, and then connects the call.
You must turn on automatic redial to use the feature. See
the “Auto Redial” option on page 66.
Press To
1
O
hang up
2
N
redial the busy number
33
PRELIMINARY
Sending and Receiving Calls
When automatic redial is turned off, you can manually
activate the feature to redial a phone number. When you
hear a fast busy signal and see
Call Failed
:
Caller ID
The
calling line identification
(caller ID) feature
displays the caller’s phone number for incoming
calls.
If the caller’s name is stored in your phonebook,
the phone displays the name. If caller ID information is not
available, the phone displays
Incoming Call
.
Returning an Unanswered Call
Your phone keeps a record of your unanswered calls, and
displays:
•the
T
(missed call) indicator
•
X Missed Calls
Y Unknown
, where
X
is the total
number of missed calls and
Y
is the number of missed
calls with no caller ID information
Press To
N
or
RETRY
(
+
)activate automatic redial
Press To
1
VIEW
(
+
) see the received calls list
2
S
select a call to return
3
N
send the call
34
PRELIMINARY
Sending and Receiving Calls
Dialing an Emergency Number
Your service provider programs one or more
emergency phone numbers, such as 911, that you can
call under any circumstances, even when your phone is
locked.
Note: Emergency numbers vary by country. Your phone’s
emergency number(s) may not work in all locations.
Terminating an Incoming Call
While the phone is ringing or vibrating:
Depending on your phone settings and the type
of subscription you have with your service
provider, the call may be forwarded to another
number, or the caller may hear a busy signal.
Press To
1keypad keys dial the emergency number
2
N
call the emergency number
Press To
O
or
IGNORE
(
-
)cancel the incoming call
35
PRELIMINARY
Sending and Receiving Calls
Dialing With Speed Dial
Each entry you store in your phonebook is assigned a
unique
speed dial
number. To speed dial a phonebook
entry:
Dialing With One-Touch Dial
To call phonebook entries 1 through 9, just press and hold
the one-digit speed dial number for one second.
It is recommended that you reserve phonebook entry 1
(speed dial number 1) for storing and dialing your
voicemail number. In many cases, your service provider
has already done this for you. For more information, see
page 100.
Press To
1keypad keys enter the speed dial number
for the entry you want to call
2
#
submit the number
Note: Some
networks let you
skip this step for
speed dial
numbers 1 through 99.
3
N
call the entry
36
PRELIMINARY
Sending and Receiving Calls
Dialing a Number In a Text
Message
To dial a phone number embedded in a text
message that you receive:
Additional Dialing Features
While dialing (with digits visible in the display), you can
open the
Dialing Menu
to perform the following tasks:
Press To
1
M
open the
Text Msg Menu
2
S
scroll to
Call Back
3
SELECT
(
+
) dial the number
Press To
M
>
Attach Number
attach a number from the
phonebook or recent call lists
M
>
Send Message
open a new text message
with the number in the
To
field
37
PRELIMINARY
Sending and Receiving Calls
To insert a special character for calls that require additional
digits (for example, to make a calling card call, or to
retrieve messages from an answering machine):
Press To
M
>
Insert Pause
insert a
p
(pause) character
Your phone dials the
preceding digits, waits for the
call to connect, then sends
the remaining digit(s).
M
>
Insert Wait
insert a
w
(wait) character
Your phone dials the
preceding digits, waits for the
call to connect, then prompts
you for confirmation before it
sends the remaining digit(s).
M
>
Insert 'n'
insert an
n
(number)
character
Your phone prompts you for a
number before dialing the
call. The number you enter is
inserted into the dialing
sequence in place of the
n
character
38
PRELIMINARY
Sending and Receiving Calls
You can also call a number using these features:
Do This To Call
Press and release the voice
key, then speak a voice
name (in two seconds).
a phonebook entry
using voice dial
See “Recording a
Voice Name For a
Phonebook Entry” on
page 77.
Press
M
>
Recent Calls
>
Received Calls
or
Dialed Calls
>
entry to call
a missed call, or a
recent received or
dialed call
Voice
key
39
PRELIMINARY
Using Features While On a Call
Using Features While
On a Call
Using Call Waiting
When you are on a call, an alert tone sounds to
indicate that you have received a second
call. To answer the second call:
Making a Three-Way Call
During a call, you can call and connect a third
party for a three-way call. You cannot do this if
you already have a call on hold.
Press To
1
N
answer the new call
2
N
switch back to the first call
Press To
1keypad keys enter the third party’s number
Note: Some networks may
require you to press
N
first.
2
N
call the new person
3
N
connect the two calls
4
O
end the entire call
40
PRELIMINARY
Using Features While On a Call
Additional On-Call Features
Press To
MUTE
(
+
) (if available) or
M
>
Mute
mute the call
SPEAKER
(
+
) (if available)
or
M
>
Spkrphone On
activate an attached
speakerphone
M
>
My Tel. Number
view your phone number
M
>
Send Tones
send a number to the
network as DTMF tones
(for credit card or
password calls)
To activate DTMF tones,
see the “DTMF” option
on page 67.
M
>
Received Calls
or
Dialed Calls
view recent received or
dialed call numbers
M
>
Messages
view or send messages
M
>
Datebook
view datebook entries
M
>
Other Information
view phone
specifications
41
PRELIMINARY
Using the Menu
Using the Menu
Navigating to a Feature
Use these keys to move through the menu system:
EXIT SELECT
Main Menu
phonebook
Current
selection.
4-Way
Navigation Key
Scroll
up
or
down
through menus
and lists. Scroll
left
or
right
to
cycle through
and set the value
of the highlighted
menu item.
Menu Key
Open a sub-menu
when
e
appears
in the bottom
center of
the display.
Right Soft Key
Perform the
function shown
in the lower
right corner of
the display
(usually
SELECT
the highlighted
menu item).
End Key
Exit the menu
system without
making
changes,
return to the
idle display.
Left Soft Key
Perform the
function shown
in the lower left
corner of the
display (usually
EXIT
or
BACK
).
42
PRELIMINARY
Using the Menu
Highlight an icon in the main menu by using S to scroll up,
down, left, or right. Icons are animated as you select them.
Selecting
(
More
) displays additional main menu
features
. The following icons represent features that may be
shown in the main menu, depending on your service provider and
the services to which you subscribe.
Main Menu Icon Feature
Phonebook
Message Center
Datebook
Micro-Browser
Calculator
Shortcuts
Recent Calls
Settings
More
Games
Media Center
J2ME
Quick Dial List
43
PRELIMINARY
Using the Menu
Selecting a Feature Option
Some features require you to select an item from a list:
•Press
S
to scroll up or down to highlight the item you
want.
•In a numbered list, press a number key to highlight the
item.
•In an alphabetized list, press a key multiple times to
cycle through the letters on the key and highlight the
closest matching list item.
Radio
SMS Interactive
Voice Notes
Main Menu Icon Feature
Dialed Calls
10) John Smith
9) Lisa Owens
8) Adda Thomas
7) Jack Bradsh..
6) Mary Smith
5) Dave Thomp...
VIEWBACK e
5E
Press
BACK
(
-
)
to go back to the
previous screen.
Highlighted
item
Press
M
to open
the sub-menu.
Press
VIEW
(
+
) to view
details of the highlighted item.
44
PRELIMINARY
Using the Menu
Entering Feature Information
Some features require you to enter information :
•Enter numbers or text with the keypad.
•When an item has a list of possible values, press
S
to the left or right to scroll through and select a value.
•When an item has a list of possible numeric values,
press a number key to set the value.
•If you enter or edit information and do not want to save
your changes, press
O
to exit without saving.
Entry Details
Name:John Smith
No.:2125551212
Type:Work
Voice Name:
Speed No.:2
Ringer ID:Contin...
CHANGECANCEL
5E
Press
CANCEL
(
-
) to exit
without making changes.
DONE
(
-
) appears when you
enter or edit information.
Press
CHANGE
(
+
)
to edit the
information.
Press
S
to scroll
down to
additional
items.
Highlighted
item
$
45
PRELIMINARY
Using the Menu
The message center lets you compose and send text
messages. A
flashing cursor
shows where text will appear:
Msg:
5E
BROWSECANCEL e
Press
CANCEL
(
-
)
to exit without
making changes.
Press
M
to open the
sub-menu.
Press
BROWSE
(
+
)
to view and
insert a name,
number, or
message from
previously
stored
information.
Flashing
cursor
indicates
insertion
point.
46
PRELIMINARY
Using the Menu
When you enter text, the flashing cursor changes to a
block cursor
, and the soft key functions change:
5E
OKDELETE e
Msg:
T
After two seconds, the block
cursor reverts to a flashing
cursor and moves to the
next position.
Press
DELETE
(
-
) to
delete the character to
the left of the insertion
point.
Block
cursor
indicates
current
highlighted
character.
Press
OK
(
+
)
to accept
and store
the text.
47
PRELIMINARY
Entering Text
Entering Text
Multiple text entry methods make it easy for you to enter
names, numbers, email addresses, and text messages on
your phone.
Choosing a Text Mode
Press
M
from any text entry screen to select the text mode
from the
Entry Method
menu:
Note: The text mode you select remains active until
you change it by selecting another mode.
iTAP
Let the phone predict each word as you
enter it (see page 52).
Tap Method
Enter letters, numbers, and symbols by
pressing a key one or more times (see
page 48).
Numeric
Enter numbers only.
Symbol
Enter symbols only (see page 51).
Browse
Browse your phonebook or recent call
lists to select a name or number.
48
PRELIMINARY
Entering Text
Tap Method
This is the standard mode for entering text on your phone.
Press
M
from any text entry screen and select the
Tap Method
menu option.
Do This To
1Press a number
key one or more
times
select a letter, number, or
symbol shown in the
“Character Chart” on page 50
2Continue
pressing number
keys
enter the remaining
characters
3Press
OK
(
+
) store the text when you are
finished
49
PRELIMINARY
Entering Text
General Text Entry Rules
Press a number key repeatedly to cycle through its
characters (see “Character Chart” on page 50):
•If you do not press a key for two seconds, the
character in the block cursor is accepted, and the
cursor moves to the next position.
CANCEL BROWSE
MSG:.
Press navigation
key
left
or
right
to move flashing
cursor to the
left or right in
text message.
Press navigation
key
up
or
down
to change
character in
block cursor to
uppercase or
lowercase.
Press a
number key to
enter text at
flashing cursor
location.
Press a
number key
as many times
as necessary
to enter the
desired
character.
Press and hold
a number key
to cycle
between tap
method and
numeric text
entry mode.
50
PRELIMINARY
Entering Text
•The first character of every sentence is capitalized.
(Press
S
down to force the character to lowercase
while it is highlighted by the block cursor).
•Your phone may support multiple languages. The
current language setting determines whether a new
message begins on the left or right side of the display.
You can switch languages within a message. Press
M
to select the text mode and language you want to use.
Character Chart
Use this chart as a guide for entering spaces, letters,
numbers, and symbols with the tap method.
Note: This chart may not reflect the exact character set
available on your phone.
1
space
. 1 ? ! , @ _ & ~ : ; "
- ( ) ' ¿ ¡ % £ $ ¥
2
a b c 2 ä å á à â ã
α
β
ç
3
d e f 3
δ
ë é è ê
φ
4
g h i 4 ï í î
γ
5
j k l 5
λ
6
m n o 6 ñ ö ø ó ò ô õ
ω
7
p q r s 7
π
ß σ
8
t u v 8
θ
ü ú ù û
9
w x y z 9
ξ ψ
0
+ - 0 x * / \ [ ] = > < # §
51
PRELIMINARY
Entering Text
Symbol Mode
Your phone provides an alternate way to enter symbol
characters in a message. Press
M
from any text entry
screen and select the
Symbol
menu option.
Symbol Chart
Use this chart as a guide for entering characters in
symbol mode.
Do This To
1Press a number
key one time display its symbol options at
the bottom of the display (see
“Symbol Chart” on page 51)
2Press
S
or
Press the
number key
multiple times
highlight the symbol you want
3Press
SELECT
(
+
) enter the symbol at the
flashing cursor location
1
space
. ? ! , @ _
& ~ : ; " - ( ) ' ¿
¡ % £ $ ¥
2
@ _ \
3
/ : ;
4
" & '
5
( ) [ ] { }
52
PRELIMINARY
Entering Text
Predictive Text Entry with
iTAP™ Software
iTAP™ software provides a predictive text entry method
that lets you enter the letters of a word using only one
keypress per letter.
Press
M
from any text entry screen and select the
iTAP
menu option.
Enter Words
6
¿ ¡ ~
7
< > =
8
$ £ ¥
9
# % *
0
+ - x * / = > <
# §
Do This To
1Press a number
key one time enter the first letter of the
word
The letters associated with
the key are shown at the
bottom of the display.
53
PRELIMINARY
Entering Text
For example, to spell the word “act,” press
2
2
8
.
The display shows:
2Press number
keys (one per
letter)
enter the rest of the word
Alternative words and letter
combinations are shown at
the bottom of the display. The
word choices are updated
with each keypress.
3Press
S
highlight the word you want
4Press
SELECT
(
+
) enter the word at the flashing
cursor location
A space is automatically
inserted after the word.
Do This To
5E
SELECTDELETE
Msg:
Act Cat Bat Abu }
Press
DELETE
(
-
)
to clear the
last letter.
Flashing
cursor
indicates
insertion
point.
Press
S
to
scroll and see
additional word
choices.
Press
SELECT
(
+
)
to insert the
highlighted
word.
54
PRELIMINARY
Entering Text
Enter Novel Words
You may enter a word that is not in the iTAP software
dictionary. If the word you want is not displayed:
Punctuation
Do This To
1Press
DELETE
(
-
) one
or more times delete letters until you
see a letter combination
that matches the start of
the word
2Press
S
highlight the letter or
letter combination
3Press
SELECT
(
+
),
then press
S
to the
left
shift the text entry cursor
to the left and “lock” the
selected word portion
4Continue to enter
letters and highlight
letter combinations
spell the word
Press To
0
or
1
enter punctuation or other
characters as shown in the
“Character Chart” on page 50
55
PRELIMINARY
Entering Text
Capitalization
The first word of a sentence is automatically capitalized,
with following words in lowercase.
Enter Numbers
Delete Letters and Words
Place the cursor to the right of the text you want to delete,
and then do the following:
Press To
S
up or down change the words to initial
character capitalized, all
uppercase characters, or all
lowercase characters
Do This To
1Enter the first
digit and then
highlight it
put the iTAP software in
number entry mode
2Press number
keys add digits to the number
3Press
SELECT
(
+
) enter the number at the
flashing cursor location
Do This To
Press
DELETE
(
-
) delete one letter at a time
Hold
DELETE
(
-
) delete the entire message
56
PRELIMINARY
Menu Feature Descriptions
Menu Feature
Descriptions
This chapter describes all of your phone’s features in order
of the menu map shown on pages 3–4.
Main Menu
R
ECENT
C
ALLS
Received Calls
M
>
Recent Calls
>
Received Calls
View a list of recently received calls. See “Viewing
the Received Calls or Dialed Calls List” on page 70.
Dialed Calls
M
>
Recent Calls
>
Dialed Calls
View a list of recently dialed calls. See “Viewing the
Received Calls or Dialed Calls List” on page 70.
Notepad
M
>
Recent Calls
>
Notepad
Call or store the last number entered on the keypad.
See “Using the Notepad” on page 71.
Call Times
M
>
Recent Calls
>
Call Times
View call timers that track time spent on your last
call, dialed calls, received calls, all calls since reset,
and all calls total. See “Viewing and Resetting Call
Timers” on page 72.
57
PRELIMINARY
Menu Feature Descriptions
P
HONEBOOK
M
>
Phonebook
Store names and numbers as entries in your
phonebook, then call numbers by selecting them
from the phonebook list. See “Phonebook” on
page 74.
P
ICTURE
V
IEWER
M
>
Picture Viewer
View and manage the pictures and animations
stored on your phone. See “Picture Viewer” on
page 82.
D
ATEBOOK
M
>
Datebook
Use the datebook calendar to schedule and review
your appointments. See “Datebook” on page 86.
Q
UICK
D
IAL
M
>
Quick Dial
Dial pre-programmed numbers. Your
service provider may program your phone
with one or more quick dial numbers, such
as the customer service number. You can call them
by selecting them from the quick dial list.
Note: Your service provider may use a different
name for this feature.
R
ADIO
M
>
Radio
Listen to FM radio stations with the optional
Motorola Original™ FM Stereo Radio
Headset accessory. This menu feature is
displayed only when the FM Stereo Radio
Headset is plugged into the accessory
connector port on your phone. See “Radio” on
page 92.
58
PRELIMINARY
Menu Feature Descriptions
C
HAT
M
>
Chat
Exchange text messages in real time with
another wireless phone user. See “Chat”
on page 95.
M
ESSAGES
M
>
Messages
Adjust message settings, view and
manage the various types of messages
your phone can receive and/or send:
Inbox
Send and manage text
messages. See
“Messages—Text” on
page 102.
Create Msg
Create new text messages.
See “Sending a Text
Message” on page 108.
Voicemail
Listen to your recorded
voice messages. See
“Messages—Voicemail” on
page 100.
Email Msgs
Send and receive email
messages. See
“Messages—Email” on
page 115.
Browser Alerts
Read alert messages
received by your
micro-browser.
59
PRELIMINARY
Menu Feature Descriptions
R
ING
S
TYLES
Style
M
>
Ring Styles
>
Style
Select the ring style your phone uses to notify you
of incoming calls, messages, or other events. See
“Ring Styles” on page 133.
Style Detail
M
>
Ring Styles
>
Style
Detail
Change details about the current ring style.
Style
represents the name of the ring style. See “Ring
Styles” on page 133.
My Tones
M
>
Ring Styles
>
My Tones
Create custom alert tones for your phone. See
“Using My Tones” on page 135.
S
HORTCUTS
M
>
Shortcuts
Create keypad or voice shortcuts to menu features.
See “Shortcuts” on page 142.
Quick Notes
Select and send pre-written
messages from the quick
notes list. See “Sending a
Quick Note Text Message”
on page 110.
Outbox
View all outgoing text
messages, delivered and
undelivered.
Drafts
Store and edit text
messages that you have
written but not sent.
60
PRELIMINARY
Menu Feature Descriptions
V
OICE
N
OTES
M
>
Voice Notes
Use the voice key to record messages and phone
calls. See “Voice Notes” on page 145.
Note: Recording phone calls is subject to varying
state and federal laws regarding privacy and
recording of conversations.
B
ROWSER
M
>
Browser
Access Web pages and run Web-based
applications. The micro-browser delivers
WAP (Wireless Application Protocol)
pages from your service provider directly to your
phone. See “Micro-Browser” on page 151.
M
Y
J
AVA
A
PPS
M
>
My Java Apps
Run J2ME applications, including games,
that are installed on your phone. See
“J2ME Applications” on page 156.
C
ALCULATOR
M
>
Calculator
Use your phone as a calculator or currency
converter. See “Calculator” on page 161.
G
AMES
M
>
Games
Play games on your phone. See “Games” on
page 164.
61
PRELIMINARY
Menu Feature Descriptions
Settings Menu
P
HONE
S
TATUS
My Tel. Number
M
>
Settings
>
Phone Status
>
My Tel. Number
View, enter, and edit information about your name
and phone number.
Active Line
M
>
Settings
>
Phone Status
>
Active Line
Change the active phone line to send and receive
calls from either of the available numbers.
Battery Meter
M
>
Settings
>
Phone Status
>
Battery Meter
View a detailed battery charge meter.
Other Information
M
>
Settings
>
Phone Status
>
Other Information
View your phone’s feature specifications
(if available from the service provider).
C
ONNECTION
Connect your phone to a computer or
hand-held device to send and receive
data and fax calls on the connected
device. See “Data and Fax Calls” on page 182.
62
PRELIMINARY
Menu Feature Descriptions
Incoming Call
M
>
Settings
>
Connection
>
Incoming Call
Specify the format for the next incoming call. You
can select
Fax In Only
,
Data In Only
, or
Normal
. See
“Receiving a Data or Fax Call” on page 186.
I
N-
C
ALL
S
ETUP
Set the features that are active during a call, such
as the in-call timer and call answering options.
In-Call Timer
M
>
Settings
>
In-Call Setup
>
In-Call Timer
Adjust call timer
Display
and
Beep
settings. You can
set your timer to beep at a selected interval during
your calls. (60 seconds is the default.) You can also
turn on or off a display timer during calls as follows:
Answer Options
M
>
Settings
>
In-Call Setup
>
Answer Options
Turn call answering options on or off:
Time
Display the elapsed time for
the current call.
Off
No in-call timer display.
Multi-Key
Answer by pressing any key.
Open to Answer
Answer by opening the flip.
63
PRELIMINARY
Menu Feature Descriptions
S
ECURITY
Phone Lock
M
>
Settings
>
Security
>
Phone Lock
Lock and unlock your phone. See “Locking and
Unlocking Your Phone” on page 190.
Lock Application
M
>
Settings
>
Security
>
Lock Application
Lock and unlock specific phone applications (such
as phonebook or datebook). When an application is
locked, users must enter the unlock code to use the
application.
Restrict Calls
M
>
Settings
>
Security
>
Restrict Calls
Restrict incoming and outgoing calls. See
“Restricting Calls” on page 191.
New Passwords
M
>
Settings
>
Security
>
New Passwords
Change your unlock code (originally set to 1234) or
your security code (originally set to 000000). See
“Assigning a New Code or Password” on page 188.
J
AVA
T
OOLS
Java App Loader
M
>
Settings
>
Java Tools
>
Java App Loader
Download a J2ME application to your phone
from a computer. See “Downloading an
Application From a Computer” on page 156.
64
PRELIMINARY
Menu Feature Descriptions
Java System
M
>
Settings
>
Java Tools
>
Java System
View the J2ME software version in your phone, and
view information about the phone memory available
for J2ME applications. See “Viewing J2ME Version
and Available Memory” on page 159.
Network Access
M
>
Settings
>
Java Tools
>
Network Access
Approve Internet connections for J2ME
applications. See “Launching a J2ME Application”
on page 157.
O
THER
S
ETTINGS
Personalize
M
>
Settings
>
Other Settings
>
Personalize
Set several personal phone options:
Main Menu
Change the order of the
main menu. See
“Reordering Menu Items” on
page 173.
Keys
Change the functions of the
soft keys in the idle display.
See “Customizing a Soft
Key Function” on page 173.
Greeting
Change the text
displayed when
you turn on your
phone.
65
PRELIMINARY
Menu Feature Descriptions
Initial Setup
M
>
Settings
>
Other Settings
>
Initial Setup
Set many basic phone options:
Banner
Change the text that
appears in the idle display.
Note: Banner text does not
appear in your phone’s
external display.
Wallpaper
Change the background
image used in the idle
display. See “Wallpaper” on
page 174.
Screen Saver
Change your phone’s
screen saver image. See
“Screen Saver” on
page 175.
Quick Dial
Change quick dial
number(s).
Time and Date
Set the phone’s time and
date.
Auto PIN Dial
Some networks
require an
authenticating PIN
to allow outgoing
calls. Use this feature to
automatically dial your PIN.
66
PRELIMINARY
Menu Feature Descriptions
Auto Redial
Use this option to turn on or
turn off the automatic redial
feature. When you turn on
automatic redial, your phone
automatically redials calls
that fail due to busy network
conditions. See “Using
Automatic Redial” on
page 32.
Backlight
Set the amount of time that
the display backlight
remains on, or turn off the
backlight to conserve
battery power.
Status Light
Turn the status light off (to
conserve battery power)
and on.
Zoom
Switch between six lines
(
Zoom Out
) and four lines
(
Zoom In
) of display text.
TTY Setup
Set your phone to
operate in one of
three TTY modes,
or return to normal
Voice
mode. See “TTY
Operation” on page 176.
Scroll
Force the cursor to stop or
wrap around when it
reaches the top or bottom of
a list in the display.
67
PRELIMINARY
Menu Feature Descriptions
Animation
Turn animation off (to
conserve battery power) or
on. Animation makes your
phone’s menus move
smoothly as you scroll up
and down.
Language
Set the language for phone
menus.
Contrast
Adjust the contrast setting
for your display.
DTMF
Your phone can send a
number to the network as
dual tone multi-frequency
(DTMF) tones. DTMF tones
are used to communicate
with automated systems
that require you to enter a
number such as a code,
password, or credit card
number. User this option to
set DTMF tones to be long,
short, or off.
Master Reset
Reset all options back to
their original factory settings
except
for the unlock code,
security code, and lifetime
timer.
68
PRELIMINARY
Menu Feature Descriptions
Network
M
>
Settings
>
Other Settings
>
Network
View and adjust your phone’s network
settings.
Your service provider registers your phone to a
network. You can view information about the current
network, change how your phone searches for a
network, and activate alerts that indicate when a
call is dropped or network registration changes.
Car Settings
M
>
Settings
>
Other Settings
>
Car Settings
Adjust hands-free car kit settings.
You can set your phone to route calls directly to the
car kit when it detects a connection, and
Master Clear
Reset all options back to
their original factory settings
except
for the unlock code,
security code, and lifetime
timer,
and
clear all user
settings and entries.
Note: This option
erases all
user-entered information
stored in your phone’s
memory, including
phonebook and datebook
entries. Once you erase the
information, it cannot be
recovered.
69
PRELIMINARY
Menu Feature Descriptions
automatically answer calls after two rings. See
“Hands-Free Use” on page 178.
Note: The use of wireless devices and their
accessories may be prohibited or restricted in
certain areas. Always obey the laws and regulations
on the use of these products.
Headset
M
>
Settings
>
Other Settings
>
Headset
Set your phone to automatically answer
calls after two rings when connected to a headset.
See “Hands-Free Use” on page 178.
70
PRELIMINARY
Recent Calls
Recent Calls
Viewing the Received Calls
or Dialed Calls List
Your phone keeps a list of the calls you recently received
and dialed, even if the calls did not connect. The lists are
sorted from newest to oldest entries. The oldest entries are
deleted as new ones are added.
Shortcut: Press
N
to go directly to the dialed calls list
from the idle display.
Find the Feature
M
>
Recent Calls
Press To
1
S
scroll to
Received Calls
or
Dialed Calls
2
SELECT
(
+
) select the list
3
S
scroll to an entry
Note:
<
means the call
connected.
4
N
call the entry’s number
or
VIEW
(
+
) view entry details
or
M
open the
Last Calls Menu
to
perform other procedures as
described in the following list
71
PRELIMINARY
Recent Calls
The
Last Calls Menu
includes the following options:
Using the Notepad
Your phone stores the most recent string of digits entered
on the keypad in a temporary memory location called the
notepad
. This can be a phone number that you called, or a
number that you entered but did not call. To retrieve the
number stored in the notepad:
Option Description
Store
Create a phonebook entry with
the number in the
No.
field.
Delete
Delete the entry.
Delete All
Delete all entries in the list.
Send Message
Open a new text message with
the number in the
To
field.
Add Digits
Add digits after the number.
Attach Number
Attach a number from the
phonebook or recent call lists,
after the highlighted number.
Send Tones
Send the number to the network
as DTMF tones (for credit card or
password calls).
Find the Feature
M
>
Recent Calls
>
Notepad
72
PRELIMINARY
Recent Calls
Viewing and Resetting Call
Timers
Network connection time
is the elapsed time from the
moment you connect to your service provider's network to
the moment you end the call by pressing
O
. This time
includes busy signals and ringing.
The amount of network connection time you track on
your resettable timer may not equal the amount of
time for which you are billed by your service provider.
For billing information, please contact your service
provider directly.
You can view the following network connection times:
Press To
N
or
M
or
STORE
(
+
)
call the number
open the
Dialing Menu
to
attach a number or insert a
special character
create a phonebook entry
with the number in the
No.
field
Timer Description
Last Call
Time spent on the last call dialed
or received. You cannot reset this
timer.
73
PRELIMINARY
Recent Calls
To view a call timer:
To reset the call timer:
Dialed Calls
Total time spent on dialed calls
since the last time you reset this
timer.
Received Calls
Total time spent on calls received
since the last time you reset this
timer.
All Calls
Total time spent on dialed and
received calls since the last time
you reset this timer.
Lifetime
Total time spent on all calls on this
phone. You cannot reset this timer.
Find the Feature
M
>
Recent Calls
>
Call Times
Press To
1
S
scroll to the timer you want
2
SELECT
(
+
) view the recorded time
Press To
1
RESET
(
+
) reset the time (if available)
2
YES
(
-
) confirm the reset
Timer Description
74
PRELIMINARY
Phonebook
Phonebook
You can store a list of names and phone numbers or email
addresses in your phone’s electronic phonebook.
To see the names stored in your phonebook, press
M
>
Phonebook
from the idle display. Scroll to a name and
press
VIEW
(
+
) to view details of the phonebook entry
as shown in the following display.
Fields in a Phonebook Entry
Note: When you set a distinctive ringer alert for a
phonebook entry, the
Ringer ID
setting appears below the
speed dial number.
*Carlo Emrys
01543372151410
Speed No. 15
Ringer ID:Contin...
EDITBACK e
5E
$
Type
indicator
identifies
number
type:
$
Work
U
Home
S
Main
h
Mobile
Z
Fax
p
Pager
[
Email
Entry’s
Name
Edit
entry
Return
to list
Entry’s speed
dial number
Voice Name
indicator
indicates a recorded
voice name
Press
M
to open the
Phonebook Menu
Entry’s
phone number
or
email address
Entry’s ringer
ID setting
75
PRELIMINARY
Phonebook
Storing a Phonebook Entry
A phone number or email address is required for a
phonebook entry. All other information is optional.
Shortcut: Enter a phone number in the idle display, then
press
STORE
(
+
) to create a phonebook entry with the
number in the
No.
field. Go directly to step 3 in the
following procedure to continue.
Enter Information
Find the Feature
M
>
Phonebook
M
>
New
Press To
1
S
scroll to
Phone Number
or
Email Address
2
SELECT
(
+
) select the entry type
3
CHANGE
(
+
) select
Name
4keypad keys enter a name for the entry
5
OK
(
+
) store the name
6
CHANGE
(
+
) select
No.
or
Email
7keypad keys enter the phone number or
email address
8
OK
(
+
) store the phone number or
email address
9
CHANGE
(
+
) select
Type
Note: This option is not
available for email entries.
10
S
scroll to the number type
76
PRELIMINARY
Phonebook
11
SELECT
(
+
) select the number type
12
RECORD
(
+
)
or
Go to step 13 if
you do not want
a voice name
record a voice name for the
entry, if desired (see page 77)
13
S
scroll to
Speed No.
The next available speed dial
number is assigned to a new
phonebook entry.
14
CHANGE
(
+
) select
Speed No.
if you want
to change it
15 keypad keys enter a different speed dial
number, if desired
16
OK
(
+
) store the speed dial number
17
CHANGE
(
+
) select
Ringer ID
if you want to
assign a distinctive ringer
alert for the phone number
Your phone uses the alert to
notify you when you receive a
call from this phone number
(see page 134).
18
S
scroll to the alert you want
19
SELECT
(
+
) store the ringer ID alert
20
SELECT
(
+
) select
MORE
if you want to
create another entry with the
same
Name
Press To
77
PRELIMINARY
Phonebook
Complete Phonebook Entry
When you are finished entering information for a
phonebook entry:
Recording a Voice Name For
a Phonebook Entry
You can record a voice name for a new or existing
phonebook entry. This lets you call the phonebook entry
using the voice dial feature (see page 79).
Tip: Make your recording in a quiet location. Hold the
phone about four inches (10 centimeters) from your mouth,
and speak directly into the phone in a normal tone of voice.
Press To
DONE
(
-
) store the entry
Find the Feature
M
>
Phonebook
Do This To
1Press
S
scroll to the entry
2Press
VIEW
(
+
) view entry details
3Press
EDIT
(
+
) edit the entry
4Press
S
scroll to
Voice Name
5Press
RECORD
(
+
) begin recording
6Press and release
the voice key and say
the entry’s name (in
two seconds)
record the voice name
78
PRELIMINARY
Phonebook
Dialing a Phonebook Entry
You can use the phonebook list, voice dial, speed dial,
or one-touch dial to call a number (or send a text
message to an email address) stored in your
phonebook. To use speed dial, see page 35. To use
one-touch dial, see page 35.
Phonebook List
To call or send email to a phonebook entry:
7Press and release
the voice key and
repeat the name
confirm the voice name
8Press
DONE
(
-
) store the voice name
Find the Feature
M
>
Phonebook
Press To
1
S
scroll to the entry
2
N
send the call (phone number)
or open a new text message
with the address in the
To
field (email address)
Do This To
79
PRELIMINARY
Phonebook
Voice Dial
To call a number or send an email using voice dial:
Editing a Phonebook Entry
Edit the entry by following the procedures described on
page 75.
Deleting a Phonebook Entry
Do This To
Press and release the
voice key and say the
entry’s name (in two
seconds).
send the call (phone
number) or open a new
text message (email
address)
Find the Feature
M
>
Phonebook
Press To
1
S
scroll to the entry
2
VIEW
(
+
) view entry details
3
EDIT
(
+
) edit the entry
Find the Feature
M
>
Phonebook
Press To
1
S
scroll to the entry
2
M
open the
Phonebook Menu
3
S
scroll to
Delete
4
SELECT
(
+
) select
Delete
80
PRELIMINARY
Phonebook
Synchronizing with TrueSync
Software
You can synchronize phonebook entries
between your phone and computer or
hand-held device with Starfish TrueSync
®
software, a Motorola accessory product. See
the TrueSync user guide for more information.
Note: TrueSync software is designed to synchronize with
basic features of many popular Personal Information
Management (PIM) software and hardware products.
Sorting the Phonebook List
You can sort your phonebook list by speed dial number
(the standard), name, email address, or voice dial.
Tip: The voice dial sort is identical to the name sort,
except that entries with voice name tags appear first.
5
YES
(
-
) confirm the deletion
Find the Feature
M
>
Phonebook
Press To
1
M
open the
Phonebook Menu
2
S
scroll to
Setup
3
SELECT
(
+
) select
Setup
4
S
scroll to
Sort by
5
CHANGE
(
+
) select
Sort by
Press To
81
PRELIMINARY
Phonebook
6
S
scroll to the sort order you
want
7
SELECT
(
+
) select the sort order
Press To
82
PRELIMINARY
Picture Viewer
Picture Viewer
Use the picture viewer to manage the pictures and
animations stored on your phone.
Downloading Pictures
You can download pictures and animations
onto your phone from the micro-browser
application, or from a text message.
To download a picture or animation from the
micro-browser, see “Downloading Pictures, Animations,
and Sounds” on page 152.
To download a picture or animation from a text message,
see “Storing Pictures, Animations, and Sounds From a
Text Message” on page 105.
Managing Pictures
You can view information about the pictures and
animations stored on your phone, rename or delete
pictures, and change the wallpaper and/or screen saver
images that your phone displays.
Find the Feature
M
>
Picture Viewer
83
PRELIMINARY
Picture Viewer
Press To
1
S
scroll to the picture you want
Pictures in the picture
selection list are listed in
alphabetical order.
2
SELECT
(
+
) view the picture in the picture
viewer
3
S
left or right
or
DETAILS
(
+
)
or
M
scroll to and view the
previous/next picture in the
list
view information about the
selected picture
open the
Picture Viewer
menu to perform other
procedures as described in
the following list
84
PRELIMINARY
Picture Viewer
The
Picture Viewer
menu includes the following options:
Option Description
Details
View information about the
selected picture, including
picture name, file type, and
file size.
Note: This option is
available only when a name
is highlighted in the picture
selection list. To view
information about a picture
as it is displayed, press
DETAILS
(
+
).
Set as Wallpaper
Set the selected picture as
the phone’s wallpaper
image.
Set as Screen Saver
Set the selected picture as
the phone’s screen saver
image.
Rename
Rename the selected
picture.
Delete
Delete the selected picture.
Press
Yes
(
-
) to confirm the
deletion.
85
PRELIMINARY
Picture Viewer
Note: When you set an animation as a wallpaper image,
only the first frame of the animation is displayed.
You can adjust the way that wallpaper and screen saver
images are displayed by pressing
M
>
Settings
>
Other Settings
>
Personalize
and then selecting the
desired option. For more information, see “Wallpaper” on
page 174 and “Screen Saver” on page 175.
86
PRELIMINARY
Datebook
Datebook
The datebook is a calendar that lets you schedule and
organize events such as appointments and meetings. The
datebook can also send a reminder alarm for specific
events.
Note: You must set the correct time and date in order to
use the datebook.
To schedule or review datebook events:
Week View
The datebook initially displays a calendar for the week.
Lines or filled boxes indicate scheduled events.
Find the Feature
M
>
Datebook
Go to
selected
day
One-hour
event
Days of
week
(press
S
left or right
to select)
Full day (12-hour)
event scheduled
Press
M
to open
the
Datebook Menu
Exit the
datebook
Untimed
event
12 hour
window
87
PRELIMINARY
Datebook
Day View
Select a day and press
VIEW
(
+
) to see the day’s events. .
{THU 19-NOV }
¥ Joe's Birthday
8:00A Marie,..
9:00A conf c..
9:30A status
1:00A presen..
3:00A weekly..
VIEWBACK e
5E
Show
event
details
Down scroll
arrow
Alarm Events
Day of
week
Untimed
event
Return to
previous
screen Press
M
to open
the
Datebook Menu
88
PRELIMINARY
Datebook
Event View
Select an event and press
VIEW
(
+
) to see event details.
Storing a Datebook Event
A title is required for a datebook event. All other
information is optional.
Find the Feature
M
>
Datebook
>
day
M
>
New
Press To
1
CHANGE
(
+
) select
Title
2keypad keys enter a title for the event
3
OK
(
+
) store the event title
ATHU 8:00am
Marie, mtg for
status
(1 hrs)
A10 min before
None
EDITBACK e
5E
Edit
event
Alarm
Duration
Event
details
Return to
previous
screen
Repeat
Day and time
Alarm time
Press
M
to open
the
Datebook Menu
89
PRELIMINARY
Datebook
Changing Event Information
Copying an Event
4
S
scroll to other fields and enter
information as necessary
You can set start time,
duration, date, repeat
interval, and reminder alarm.
5
DONE
(
-
) store the event
Find the Feature
M
>
Datebook
Press To
1
S
left or right scroll to the day
2
VIEW
(
+
) display the day view
3
S
scroll to the event
4
VIEW
(
+
) display the event view
5
EDIT
(
+
) edit the event
6
S
scroll to the information you
want to change
7
CHANGE
(
+
) edit the information
8keypad keys enter new information
9
DONE
(
-
) store the information
Find the Feature
M
>
Datebook
Press To
90
PRELIMINARY
Datebook
Deleting an Event
Press To
1
S
left or right scroll to the day
2
VIEW
(
+
) display the day view
3
S
scroll to the event
4
M
open the
Datebook Menu
5
S
scroll to
Copy
6
SELECT
(
+
) copy the event
7
YES
(
-
) confirm the copy
Your phone assumes you
want to change the date, and
displays the
Date
field.
8keypad keys enter date information
9
}
(
+
)
or
S
to the right
move to month, day, and year
10
DONE
(
-
) save the copy of the event
11
DONE
(
-
) return to the day view
Find the Feature
M
>
Datebook
Press To
1
S
left or right scroll to the day
2
VIEW
(
+
) display the day view
3
S
scroll to the event
4
M
open the
Datebook Menu
91
PRELIMINARY
Datebook
5
S
scroll to
Delete
6
SELECT
(
+
) select
Delete
7
YES
(
-
) confirm the deletion
Press To
92
PRELIMINARY
Radio
Radio
You can use your phone to listen to FM radio
stations when the optional Motorola Original™ FM
Stereo Radio Headset accessory is plugged into
the phone’s accessory connector port.
Turning the Radio On and Off
Alternatively, you can use the following procedure:
Note: The
Radio
menu feature and soft key options
appear only when the FM Stereo Radio Headset is
plugged into the accessory connector port.
Press To
Radio
(
+
) turn the radio on and off
Press To
1
M
open the menu
2
S
scroll to
Radio
3
On
(
+
) or
Off
(
+
) turn the radio on or off
93
PRELIMINARY
Radio
Tuning a Station
Storing a Preset
Selecting a Preset
Sending and Receiving Calls
With the Radio On
Your phone rings or vibrates as usual to notify you of an
incoming call, message, or other event.
Do This To
Press
S
or
Press and hold
S
scroll to the next frequency
scroll to the next available
stereo station
Do This To
Press and hold a
number key
(
1
to
9
)
assign its preset number to
the tuned station
Press To
a number key
(
1
to
9
)tune the station stored at the
preset location
Do This To
Press
IGNORE
(
-
) ignore the call
94
PRELIMINARY
Radio
To end the call and resume the FM broadcast:
Turn the radio off before dialing outgoing calls from the
phone keypad. You do not have to turn off the radio to
dial emergency numbers, or numbers selected from
your phonebook or recent call lists.
Tip: To dial a recently called number, press
N
or the button
on the FM Stereo Radio Headset microphone to go to the
dialed calls list (see page 70).
Press
ANSWER
(
+
)
or
Press the button on the
FM Stereo Radio
Headset microphone
answer the call
Note: You can use the
FM Stereo Radio
Headset microphone to
converse with the other
party during a call
Do This To
Press
O
or
Press and hold the
button on the FM Stereo
Radio Headset
microphone
end the call
Do This To
95
PRELIMINARY
Chat
Chat
You can exchange text messages in real time
with another wireless phone user by opening a
chat session. The text messages you send
appear immediately on your chat partner’s
phone. Only one chat session can be active at a time.
Starting a Chat Session
To start a chat session with another wireless phone user:
Find the Feature
M
>
Chat
M
>
New Chat
Press To
1keypad keys enter your
Chat Name
for the
session (up to 10 characters)
2
OK
(
+
) save your
Chat Name
3keypad keys
or
BROWSE
(
+
)
enter the phone number for
your chat partner
select a phone number from
the phonebook or recent call
lists
4
OK
(
+
) save the phone number
5keypad keys enter your first chat message
for the session
96
PRELIMINARY
Chat
Notes:
•If you send a chat message to a phone that only has
text messaging, the chat text appears as a text
message on the other phone. The reply appears as
chat text on your phone.
•You can also start a chat session while reading a text
message. Open the
Text Msg Menu
and select
Chat
.
The
Chat
option takes you to the chat name editor,
and inserts the message’s
Reply To
number in the
To
field. This option is not available for email messages.
•When no more chat messages can be stored, your
phone displays
Memory is Full!
and the network
temporarily holds your new messages. To receive
these new messages, you must delete some existing
messages from your inbox, outbox, or drafts folder.
6
OK
(
+
) send the chat message
Your phone displays your new
chat log, with
>>
next to the
text. When your chat partner
replies, the reply appears
below your text.
7
CHAT
(
+
) enter a reply to your partner
8
OK
(
+
) send your reply and return to
the chat log
Press To
97
PRELIMINARY
Chat
Using the Chat Log
The chat log displays the text exchanged in a chat session.
During a session, your phone displays the current log.
When you open chat, the phone displays the log from the
previous session (unless you cleared it).
The
Chat Menu
includes the following options:
Option Description
New Chat
Opens a new chat session.
Call Partner
Send a voice call to your chat
partner.
Call Number
Send a voice call to the
number listed in the chat log.
Store Number
Create a phonebook entry for
the number listed in the chat
log.
wanted to know if
you will be there
today
Carlo>What time
does it start?
>>10 AM
CHATEXIT e
5E
Enter
reply
Exit
chat
Press
M
to open the
Chat Menu
Chat
text
Chat
name
Message
Status:
>>
sending
m
failed
Press
S
to scroll
and see
more text.
Newest
messages
appear at
bottom of
log.
98
PRELIMINARY
Chat
Responding to Chat
When you receive a chat message, your phone displays
Chat from
chat name
(where
chat came
is the person
requesting the session), and gives an alert. If reminders
are turned on, your phone sends a reminder at regular
intervals until you respond to the chat notification, or until
you turn off your phone. (See “Setting Reminders” on
page 141.)
End Chat
End the current chat session.
Go to Top
Scroll to the top of the chat
log.
Go to Bottom
Scroll to the bottom of the
Chat log.
Clear Log
Clear all text from the chat
log.
Re-send
Resend the most recent chat
text, if it failed.
Send Message
Open the chat editor to send
chat text to your partner.
Press To
ACCEPT
(
+
) accept the chat session
IGNORE
(
-
) refuse the chat session
If you ignore the chat request,
the other person receives no
response.
Option Description
99
PRELIMINARY
Chat
If a chat session is in progress and you receive another
chat request, the new request appears as an incoming text
message, with the
chat name
at the beginning of the text.
Ending a Chat Session
To end a chat session:
Your chat partner is not notified when you end a chat
session. If your partner sends more chat text, your phone
treats it like an incoming text message, with your chat
partner’s
chat name
at the beginning of the text.
You can also end a chat session by turning off your phone,
answering an incoming call, or starting a new chat session
with someone else.
If you exit chat without selecting
End Chat
, and if your chat
partner sends more text, your phone notifies you and adds
it to the chat log. You can re-enter the session by opening
chat again.
Press To
1
M
open the
Chat Menu
2
S
scroll to
End Chat
3
SELECT
(
+
) select
End Chat
4
YES
(
-
) confirm that you want to end
the chat session
100
PRELIMINARY
Messages—Voicemail
Messages—Voicemail
You can listen to your voicemail messages by
calling your network voicemail phone number.
Voicemail messages are stored on the
network—not on your phone.
Storing Your Voicemail Number
Storing your voicemail number on your phone makes it
easy for you to listen to new voicemail messages. In many
cases, your service provider has already done this for you.
Your service provider additionally may store your voicemail
number as phonebook entry number 1, so you can use
one-touch dial to listen to your voicemail messages. If
necessary, see “Storing a Phonebook Entry” on page 75 to
store your voicemail number for one-touch dial access.
Find the Feature
M
>
Messages
M
>
VoiceMail Setup
Press To
1keypad keys enter your voicemail number
2
OK
(
+
) store the number
101
PRELIMINARY
Messages—Voicemail
Receiving a Voicemail Message
When you receive a voicemail message, your phone
displays the
&
(voice message waiting) indicator and a
New VoiceMail
notification.
If reminders are turned on, your phone sends a reminder
at regular intervals until you close the new message
notification, listen to the message, or turn off your phone.
Listening to a Voicemail
Message
The phone calls your voicemail number. If no voicemail
number is stored, your phone prompts you to store one.
Shortcut: If your voicemail number is also stored as
phonebook entry number 1, you can press and hold
1
to
listen to your voicemail message(s).
Turning Off the Voice Message
Waiting Indicator
To clear the
&
(voice message waiting) indicator:
Do This To
Press
CALL
(
+
) listen to the message
Find the Feature
M
>
Messages
>
VoiceMail
Find the Feature
M
>
Messages
M
>
Clear Count
102
PRELIMINARY
Messages—Text
Messages—Text
Text messages are brief messages that you
can send and receive.
Quick notes are pre-written text messages
that you can customize and send quickly.
Your message inbox must be set up
before
you can send
and receive messages. The number of messages the
inbox can hold depends on the length of the messages,
and the number of other messages and drafts stored on
your phone.
Setting Up the Message Inbox
Note: In many cases, your service provider has already
set up the inbox for you.
Find the Feature
M
>
Messages
M
>
Inbox Setup
Press To
1
CHANGE
(
+
) change the
Cleanup
setting
2
S
scroll to the number of days
you want to keep messages
in the inbox, or the number of
messages you want to keep
3
SELECT
(
+
) select the cleanup setting
4
DONE
(
-
) save the inbox settings
103
PRELIMINARY
Messages—Text
Receiving a Text Message
Note: Your message inbox must be set up before you
can receive text messages. See page 102.
When you receive a text message, your phone displays
the
X
(message waiting) indicator and a
New Inbox Message
notification.
If reminders are turned on, your phone sends a reminder
at regular intervals until you close the new message
notification, read the message, or turn off your phone.
When your phone displays
Memory is Full!
, you must
delete some existing messages to receive new messages.
Reading, Locking, or Deleting a
Text Message
Messages in the message inbox are sorted from newest to
oldest. The oldest messages are deleted automatically as
specified by the inbox cleanup setting (see page 102). If
you want to save a message, you should lock it to prevent
it from being deleted during cleanup.
Press To
READ
(
+
) open the message
Find the Feature
M
>
Messages
>
Inbox
104
PRELIMINARY
Messages—Text
The
Text Msg Menu
includes the following options:
Press To
1
S
scroll to the message
The following indicators show
message status:
Y
= unread
d
= unread and urgent
n
= read
ò
= read and urgent
f
= read and locked
2
READ
(
+
) open the message
3
SAVE
(
-
)
or
DELETE
(
+
)
or
M
close the message
delete the message
open the
Text Msg Menu
to
perform other procedures as
described in the following list
Option Description
Create Message
Open a new text message.
Call Back
Call the number in the message
header or embedded in the
message.
Go To
Launch the micro-browser and go
to a Web address (URL)
embedded in the message.
105
PRELIMINARY
Messages—Text
Storing Pictures, Animations,
and Sounds From a Text
Message
You can receive a text message with pictures, animations,
and/or sounds (such as music or alert tones) inserted in
the message. Pictures and animations are displayed
automatically as you scroll through the message. A sound
begins playing when you scroll to the sound file in the
message.
You can store these pictures and animations on your
phone, and use them for screen saver or wallpaper
Reply
Open a new text message with
the sender’s
Reply To
number or
email address in the
To
field.
Forward
Open a copy of the text message
with an empty
To
field.
Lock/Unlock
Lock or unlock the message.
Store Number
Create a phonebook entry with
the embedded number in the
No.
field.
Delete
Delete the message.
Delete All
Delete all inbox messages.
Store Address
Create a phonebook entry with
the embedded email address in
the
Email
field.
Inbox Setup
Open the inbox setup menu.
Option Description
106
PRELIMINARY
Messages—Text
images. Sounds can be stored and used as alert tones for
incoming calls or other events.
Select an Image or Sound File
To store an image or sound file from a text message,
you must first select the file you want to store. While
reading the message:
Store a Picture or Animation File
To store the current displayed picture or animation:
Press To
1
S
up or down scroll to and highlight the
inserted picture, animation, or
sound file
2
M
open the
Text Msg Menu
3
S
scroll to
Store
4
SELECT
(
+
) display a list of message
items that can be stored
5
S
scroll to
File Attachment
6
SELECT
(
+
) display the highlighted image
or sound file
Press To
1
STORE
(
+
) view a list of picture storage
options
2
S
scroll to
Store Only
3
SELECT
(
+
) store the picture or animation
107
PRELIMINARY
Messages—Text
To set the picture or animation as your new screen saver
or wallpaper image:
Note: When you set an animation as a wallpaper image,
only the first frame of the animation is displayed.
For more information about using pictures and animations,
see “Picture Viewer” on page 82, “Wallpaper” on
page 174, and “Screen Saver” on page 175.
Store a Sound File
To store the current displayed sound file:
Press To
1
STORE
(
+
) view a list of picture storage
options
2
S
scroll to
Set as Screen Saver
or
Set as Wallpaper
3
SELECT
(
+
) store the picture and set it as
the screen saver or wallpaper
Press To
1
STORE
(
+
) view a list of sound storage
options
2
S
scroll to
Store Only
3
SELECT
(
+
) store the sound
Your phone adds the sound
to the
My Tones
list along with
the other custom tones you
have created.
108
PRELIMINARY
Messages—Text
To set the sound as an alert tone for a specific event:
For more information about using sound files, see
page 135.
Sending a Text Message
You can send a text message to one or more recipients.
You can manually enter each recipient’s phone number or
email address, or select numbers/addresses from the
phonebook or recent call lists.
Press To
1
STORE
(
+
) view a list of sound storage
options
2
S
scroll to
Set As Ring Tone
3
SELECT
(
+
) set the sound as an alert
Your phone displays the
message
Set As Which?
, and
lists the events (incoming
calls, text messages, etc.) for
which an alert may be set
4
S
scroll to the event for which
you want to set the new alert
5
SELECT
(
+
) store the sound and set it as
the new alert for the selected
event
The new alert tone setting is
saved to the current alert
profile
109
PRELIMINARY
Messages—Text
Note: When you manually enter numbers and/or email
addresses, you must insert a space between each entry.
Press
1
one time, wait for the space to appear, then
enter the next number or email address.
Find the Feature
M
>
Messages
>
Create Message
Press To
1
CHANGE
(
+
) select
To
2keypad keys
or
BROWSE
(
+
)
enter one or more phone
numbers and/or email
addresses
Tip: Press
1
to insert a
space between each
number/address that you
enter manually.
select numbers/addresses
from the phonebook or recent
call lists
3
OK
(
+
) store the numbers/addresses
4
CHANGE
(
+
) select
Msg
5keypad keys enter the message
Note: Message length is
limited.A counter at the top of
the display shows how many
characters are left.
6
OK
(
+
) store the message
7
CHANGE
(
+
) select
Priority
110
PRELIMINARY
Messages—Text
Sending a Quick Note Text
Message
Quick notes are pre-written messages that you can edit
and send quickly (for example,
Meet me at ...
). You can
also create and store new quick notes.
8
S
scroll to the priority you want
9
SELECT
(
+
) set the priority
10
CHANGE
(
+
) select
Call
11 keypad keys enter a number for the
recipient to call back
12
OK
(
+
) store the number
13
DONE
(
-
) finish the message
14
YES
(
-
)
or
NO
(
+
)
send the message
cancel the message or save it
in the drafts folder
Find the Feature
M
>
Messages
>
Quick Notes
Press To
1
S
scroll to the quick note
Press To
111
PRELIMINARY
Messages—Text
The
Quick Note Menu
includes the following options:
Inserting Pictures, Animations,
and Sounds in a Text Message
You can insert pictures, animations, and/or sounds (such
as music or alert tones) into the body of a text message as
you compose it.
2
READ
(
+
)
or
M
read the quick note
open the
Quick Note Menu
to
perform other procedures as
described in the following list
Option Description
New
Create a new quick note.
Edit
Edit the quick note.
Delete
Delete the quick note.
Send
Open a new message with the
quick note in the
Msg
field.
Press To
112
PRELIMINARY
Messages—Text
Insert a Picture or Sound File
Use the keypad keys to enter your message as usual.
When you come to a spot in the message where you
want to insert a picture or sound file:
A generic file type indicator identifies the type and location
of the inserted file in the text message.
Press To
1
M
open the
Message Menu
2
S
scroll to
Insert
3
SELECT
(
+
) display a list of the different
file types you can insert in the
message
4
S
scroll to
,
Animation
, or
Sound
5
SELECT
(
+
) select the type of file you
want to insert
6
S
scroll to the image or sound
file you want
7
VIEW
(
+
) (for an
image file)
or
PLAY
(
+
) (for a
sound file)
preview the highlighted file
8
INSERT
(
+
) insert the highlighted image
or sound file in the text
message at the current
cursor location
113
PRELIMINARY
Messages—Text
Notes:
•Your phone may be configured to allow only
predefined images and sounds in a text message.
The predefined image and sound files on your
phone are identified by an indicator.
•You can attach up to five pictures, at a maximum
size of 255x255 pixels (8 Kb) per picture.
View or Delete an Inserted File
To view or delete an inserted image or sound file in a text
message that you are composing:
Viewing the Status of Sent Text
Messages
Messages that you send are stored in the outbox.
Press To
1
S
place the cursor to the right of
the file type indicator in the
message that you are
composing
2
S
to the left highlight the file type indicator
3
SELECT
(
+
)
or
4
DELETE
(
-
)
display/play the inserted file
delete the inserted file from
the text message
Find the Feature
M
>
Messages
>
Outbox
114
PRELIMINARY
Messages—Text
Messages in the outbox are sorted from newest to oldest.
The following indicators show message status:
á
= sending in progress
Y
= delivered
m
= sending failed
115
PRELIMINARY
Messages—Email
Messages—Email
You can send and receive email messages
from your phone. New email messages that
you receive are stored on your service
provider’s email server until you download them
to your phone.
You must set up the email message inbox
before
you can
send and receive email messages.
Setting Up the Email Inbox
Note: Your service provider may have already
programmed the email inbox settings for you.
Find the Feature
M
>
Messages
>
Email Msgs
M
>
Email Msg Setup
Press To
1
CHANGE
(
+
) change the
Protocol
for your
service provider’s email
server type
2
S
up or down scroll to the protocol
3
OK
(
+
) store the protocol
4
CHANGE
(
+
) enter or change your
User ID
5keypad keys enter your user ID
6
OK
(
+
) store your user ID
7
CHANGE
(
+
) enter or change your
Password
116
PRELIMINARY
Messages—Email
8keypad keys enter your password, which
will be displayed as asterisks
9
OK
(
+
) store your password
You are prompted to enter the
password a second time for
confirmation.
10
CHANGE
(
+
) change the
Receiving host
11 keypad keys enter the IP address or host
name that handles your
incoming email
12
OK
(
+
) store the receiving host
13
CHANGE
(
+
) change the
SMTP host
14 keypad keys enter the IP address or host
name that handles your
outgoing email
15
OK
(
+
) store the SMPT host
16
CHANGE
(
+
) enter or change the
Return
address
17 keypad keys enter your email address
18
OK
(
+
) store the return address
19
CHANGE
(
+
) change the
Cleanup
setting
20
S
up or down scroll to the number of days
or number of messages that
should be kept in your inbox
Press To
117
PRELIMINARY
Messages—Email
21
SELECT
(
+
) select the cleanup setting
If you select
Custom
,
continue. Otherwise, go
directly to step 26.
22
S
up or down scroll to the number of days
or messages
23
}
(
+
)
or
S
to the right
move to the type identifier
24
S
up or down scroll to
days
or
msgs
25
DONE
(
-
) store the custom cleanup
setting
26
CHANGE
(
+
) change the
Save on server
setting
27
S
up or down scroll to
Yes
(to save copies of
your email messages on your
service provider’s email
server)
or
No
28
OK
(
+
) store the save on server
setting
29
CHANGE
(
+
) change the
Check new msgs
setting
Press To
118
PRELIMINARY
Messages—Email
30
S
up or down scroll to the interval at which
your phone will receive new
email and send outgoing
email (every
5
mins
,
10
mins
,
or
15
mins
).
If you select
No
, you must
manually
Send/Receive Mail
(see page 128).
If you select
Custom
,
continue. Otherwise, go
directly to step 35.
31
S
up or down scroll to the number of
minutes or days
32
}
(
+
)
or
S
to the right
move to the type identifier
33
S
up or down scroll to
mins
or
days
34
DONE
(
-
) store the custom send/
receive interval
35
CHANGE
(
+
) change
Hide fields
36
S
up or down scroll to
No
or
Hide
fields
37
SELECT
(
+
) select the
Hide Fields
setting
If you selected
Hide
Fields
,
continue. Otherwise, go
directly to step 40.
Press To
119
PRELIMINARY
Messages—Email
Receiving an Email Message
Note: You must set up the email message inbox before you
can receive text messages. See “Setting Up the Email
Inbox” on page 115.
If you set up your phone to check for new email messages
(
Check new msgs
in the
Email Msg Setup
), your phone
displays the
X
(message waiting) indicator and a
New Message
notification, and gives an alert when you
receive a new email message. If reminders are turned on,
your phone sends a reminder at regular intervals until you
close the new message notification, read the message, or
turn off your phone. (See “Setting Reminders” on
page 141.)
38
PICK
(
+
) select the fields to hide when
composing new email (
cc
and/or
bcc
)
39
Done
(
+
) store the hide fields setting
40
CHANGE
(
+
) enter your email auto
signature
41 keypad keys enter the text that will be
appended to your outgoing
email messages
42
OK
(
+
) store your auto signature
43
DONE
(
-
) save the email message
inbox settings
Press To
120
PRELIMINARY
Messages—Email
From the new message notification:
As memory space for storing email messages gets close
to full, the
X
(message waiting) indicator flashes and your
phone displays
Memory is Low!
when you receive a new
email message. When no more messages can be stored,
your phone displays
Memory is Full!
and the network
temporarily holds your new email messages. To receive
these new messages, you must delete some existing
messages from your email inbox and manually check for
new messages. (See page 128).
Reading, Locking, or Deleting
an Email Message
You can open your email message inbox to read, lock, or
delete messages at any time.
Messages in the email inbox are sorted from newest to
oldest. The oldest messages are deleted automatically as
specified by the inbox cleanup setting (see page 115). If
you want to save a message, you should lock it to prevent
it from being deleted during cleanup.
Press To
READ
(
+
) open the message (or your
email message inbox if there
are multiple messages)
121
PRELIMINARY
Messages—Email
Note: If you create personal folders, the email inbox will list
folders instead of messages. See page 130.
Find the Feature
M
>
Messages
>
Email Msgs
Press To
1
S
scroll to the message you want
The following indicators show
message status:
Y
= unread
d
= unread and urgent
n
= read
ò
= read and urgent
f
= read and locked
2
READ
(
+
) open the message
3
MORE
(
+
) scroll to the next page or
message
4
SAVE
(
-
)
DELETE
(
+
)
or
M
close the message without
changes
delete the message
open the
Email Msg Menu
to
perform other procedures as
described in the following list
122
PRELIMINARY
Messages—Email
The
Email Msg Menu
includes the following options:
Option Description
Reply
Open a new email message, with
the originator’s email address in
the
To
field.
Reply All
Open a new email message, with
all of the original recipients’ email
addresses in the appropriate
fields (
To
,
cc
, and
bcc
).
Forward
Open a copy of the email
message, with an empty
To
field.
Lock/Unlock
Lock or unlock the message.
Move to
Move the message to a personal
folder (see page 131).
Store Address
Store an email address
embedded in the message in your
phonebook.
Store Number
Store a phone number embedded
in the message in your
phonebook.
Delete
or
Delete All
Delete a message or all email
inbox messages.
Press
Yes
(
-
) to confirm the
deletion.
Create Email
Open a new email message.
Send/Receive
Mail
Connect to your email service
provider to receive new email and
send outgoing email.
123
PRELIMINARY
Messages—Email
Sending an Email Message
You can send an email message to one or more recipients.
The email message feature lets you enter each recipient’s
email address, or select addresses from the phonebook.
When you enter email addresses in the
To
,
cc
, or
bcc
field,
you must insert a space between each address.
Press
1
, wait for the space to appear, then enter the
next address. (Comma, semicolon, or colon can also be
used.)
Email Msg
Setup
Open the email message inbox
setup menu.
Find the Feature
M
>
Messages
>
Email Msgs
M
>
Create Email
Press To
1
CHANGE
(
+
) select
To
Option Description
124
PRELIMINARY
Messages—Email
2keypad keys
or
BROWSE
(
+
)
enter one or more email
addresses
Tip: Remember to press
1
to insert a space between
each address.
select addresses from the
phonebook. Press
ADD
(
+
) to
select from the phonebook
list. Press
DONE
(
+
) when
finished selecting from the
list.
3
OK
(
+
) store the email address(es) in
the
To
field
4
CHANGE
(
+
) select
cc
Note:
cc
may be hidden as
specified by the inbox
Hide
fields
setting (see
page 115).
5keypad keys
or
BROWSE
(
+
)
enter email addresses or
select them from the
phonebook. See step 2 for
entering email addresses.
6
OK
(
+
) store the email address(es) in
the
cc
field
Press To
125
PRELIMINARY
Messages—Email
7
CHANGE
(
+
) select
bcc
Note:
bcc
may be hidden as
specified by the inbox
Hide
fields
setting (see
page 115).
8keypad keys
or
BROWSE
(
+
)
enter email addresses or
select them from the
phonebook. See step 2 for
entering email addresses.
9
OK
(
+
) store the email address(es) in
the
bcc
field
10
CHANGE
(
+
) select
Subject
11 keypad keys enter the subject (see
“Entering Text” on page 47)
Note: The subject can be up
to 128 characters.
12
OK
(
+
) store the subject
13
CHANGE
(
+
) select
Msg
Press To
126
PRELIMINARY
Messages—Email
14 keypad keys
or
BROWSE
(
-
)
enter the email message (see
“Entering Text” on page 47)
insert a quick note (see
page 127)
Note: Message length is
limited. When 40 or fewer
characters remain, a two-digit
counter at the top of the
display shows how many are
left. Auto signature is
included in the count.
15
OK
(
+
) store the email message
16
CHANGE
(
+
) select
Priority
17
S
scroll to
Normal
or
Urgent
18
SELECT
(
+
) store the priority
19
CHANGE
(
+
) select
Priority
20
S
scroll to the priority you want
21
SELECT
(
+
) set the priority
22
CHANGE
(
+
) select
Call
23 keypad keys enter the number you want
your recipient to call back (the
message’s
From
field)
24
OK
(
+
) store the number
25
DONE
(
-
) finish the message
Your phone displays
Send Message Now?
Press To
127
PRELIMINARY
Messages—Email
Inserting a Quick Note Into an
Email Message
Quick notes are short, pre-written messages that you can
select, edit, and send in a text or email message (for
example,
Meet me at ...
). You can also create new quick
notes and store them for later use.
For information on editing and creating quick notes, and
sending quick notes in a text message, see “Sending a
Quick Note Text Message” on page 110.
To insert a quick note into an email message, while in the
message body (
Msg
field):
26
YES
(
-
)
or
NO
(
+
)
send the message
cancel the message or save it
as a draft
A saved message is stored in
the drafts folder, where you
can edit it and send it at a
later time.
Press To
1
BROWSE
(
+
) list the quick notes
2
S
scroll to a quick note
3
SELECT
(
+
) insert the quick note
Press To
128
PRELIMINARY
Messages—Email
Manually Sending and
Receiving Email
You can set up your phone to connect to your service
provider at regular intervals, download new email to
your inbox, and send outgoing email from your outbox
(see page 115).
If you do not set up your phone to periodically check for
new messages, you must manually connect to your email
service provider to send and receive email.
Find the Feature
M
>
Messages
>
Email Msgs
M
>
Send/Receive Mail
Press To
1
YES
(
+
) connect to your email service
provider in response to
Connect Now?
2
READ
(
+
) open the new message (or
your email message inbox if
there are multiple new
messages)
129
PRELIMINARY
Messages—Email
Viewing the Status of Sent
Email Messages
Email messages that you send are stored in the
outbox. To view the contents of your outbox:
Messages are sorted from newest to oldest. The following
indicators identify message status:
Calling a Phone Number in an
Email Message
To store the number in the phonebook, press
M
and select
Store Number
.
Find the Feature
M
>
Messages
>
Email Msgs
>
Outbox
>
Message Status
á
= sending in progress
Y
= delivered
m
= sending failed
Press To
1
S
scroll to and highlight the
phone number in the
message
Note: Periods, commas,
slashes, hyphens, and
parentheses are ignored.
2
CALL
(
+
) call the number
130
PRELIMINARY
Messages—Email
Sending Email to an Embedded
Email Address
To store the address in the phonebook, press
M
and select
Store Address
.
Go to a URL in an Email
Message
Creating Personal Folders
Your phone has an email inbox, outbox, drafts folder, and
sent folder. You can create up to 5 personal folders to help
you organize your mail.
Press To
1
S
scroll to and highlight the
address in the message
2
MAIL TO
(
+
) open a new email, with the
selected email address in the
To
field
Press To
1
S
scroll to and highlight the
URL (the URL must be
underlined in the message)
2
GO TO
(
+
) start a browser session and
go to the selected URL
131
PRELIMINARY
Messages—Email
If you create personal folders, the email msg inbox will list
the inbox folder first, followed by personal folders in
alphabetical order.
Moving Email to a Personal
Folder
Find the Feature
M
>
Messages
>
Email Msgs
M
>
Folder
Press To
1
S
scroll to
Create
2
SELECT
(
+
) open a New Folder screen
3keypad keys enter the folder name
4
OK
(
+
) save the folder
Find the Feature
M
>
Messages
>
Email Msgs
Press To
1
S
scroll to the message
2
M
open the
Email Msg Menu
3
S
scroll to
Move to
4
SELECT
(
-
) list personal folders
5
S
scroll to the personal folder
6
SELECT
(
-
) move the message
132
PRELIMINARY
Messages—Email
Renaming a Personal Folder
Deleting a Personal Folder
Find the Feature
M
>
Messages
>
Email Msgs
M
>
Folder
Press To
1
S
scroll to
Rename
2
SELECT
(
+
) list personal folders
3
S
scroll to the folder to rename
4
SELECT
(
+
) select the folder
5
YES
(
+
) open the New Folder Name
screen
6keypad keys enter the new folder name
7
OK
(
+
) save the folder
Find the Feature
M
>
Messages
>
Email Msgs
M
>
Folder
Press To
1
S
scroll to
Delete
2
SELECT
(
+
) list personal folders
1
S
scroll to the folder to delete
2
SELECT
(
+
) select the folder
3
YES
(
+
) delete the folder
133
PRELIMINARY
Ring Styles
Ring Styles
Your phone rings or vibrates to notify you of an incoming
call or other event. This ring or vibration is called an
alert
.
You can select one of five different ring styles:
The ring style indicator in the display shows the current
ring style (see page 26).
Each ring style contains settings for specific event alerts,
and ringer and keypad volume.
Selecting a Ring Style
w
= loud ring
x
= soft ring
y
= vibrate
u
= ring and vibrate
t
= silent
Find the Feature
M
>
Ring Styles
>
Style
Press To
1
S
scroll to the ring style
2
SELECT
(
+
) select the ring style
134
PRELIMINARY
Ring Styles
Customizing a Ring Style
Change Style Settings
You can change the alerts that notify you of the following
events: incoming calls, text messages, voicemail
messages, data calls, fax calls, alarms, and reminders.
Any changes you make are saved to the current ring style.
Note:
Style
represents the current ring style.
Activate and Deactivate Ringer IDs
When ringer IDs are turned on, your phone uses
distinctive ringer alerts to notify you of incoming calls or
messages from specific entries stored in your phonebook.
To assign a ringer ID to a phonebook entry, see page 75.
Note:
Style
represents the current ring style.
Find the Feature
M
>
Ring Styles
>
Style
Detail
Press To
1
S
scroll to the event
2
CHANGE
(
+
) select the event
3
S
scroll to the alert you want
4
SELECT
(
+
) select the alert
Find the Feature
M
>
Ring Styles
>
Style
Detail
Press To
1
S
scroll to
Ringer IDs
135
PRELIMINARY
Ring Styles
Set Ringer or Keypad Volume
Note:
Style
represents the current ring style.
Using My Tones
You can create and store up to 32 custom alert tones on
your phone. The tones appear in the list of available alerts.
Create a Tone
2
CHANGE
(
+
) change the ringer IDs setting
3
S
scroll to
On
or
Off
4
SELECT
(
+
) select the option
Find the Feature
M
>
Ring Styles
>
Style
Detail
Press To
1
S
scroll to
Ring Volume
or
Key Volume
2
S
left or right scroll to the desired volume
3
OK
(
+
) confirm the new volume
Find the Feature
M
>
Ring Styles
>
My Tones
Press To
1
S
scroll to
[New Tone]
2
SELECT
(
+
) select
[New Tone]
3
CHANGE
(
+
) select
Notes
Press To
136
PRELIMINARY
Ring Styles
Enter Notes
Use the keypad keys to enter each note. Press a key
multiple times to cycle through its notes or options (pitch,
octave, or length). The default setting for a new tone is a
quarter note in octave two.
4keypad keys enter notes (see page 136)
5
OK
(
+
) store the notes
6
CHANGE
(
+
) select
Name
7keypad keys enter a name for the tone
8
OK
(
+
) store the name
9
DONE
(
-
) store the tone
Key Phone Display Description
1
1
set octave one
2
set octave two
3
set octave three
2
A
note A
B
note B
C
note C
3
D
note D
E
note E
F
note F
4
G
note G
R
rest
Press To
137
PRELIMINARY
Ring Styles
Enter a note as follows:
7
#
sharp
b
flat
0
q
quarter note or rest
h
half note or rest
w
whole note or rest
Task Action
Change the
octave Set the new octave (
1
,
2
, or
3
)
before
selecting the note. The
octave applies to all following
notes until you change it again.
Select the note
(required) Press a keypad key.
Change a note
to a sharp or
flat
Enter a sharp or flat (
#
or
b
)
after
selecting the note.
Some sharps and flats are played
as standard notes. For example,
B#
is the same as
C
. Press
S
to
scroll to valid notes when entering
a new note.
Change a
note’s length Set the new length (
q
,
h
, or
w
)
after
selecting the note. The
length applies to all following
notes until you change it again.
Key Phone Display Description
138
PRELIMINARY
Ring Styles
Example
Press the following keys to play this sequence of notes and
rests in octave three: C (quarter note), E flat (quarter
note), half rest, and G (whole note):
Add a rest Enter one or more rests (
R
characters) as needed in the tone
sequence. Set the length of the
rest by entering a
q
,
h
, or
w
character
after
the rest, just as
you would for a note.
Listen to a new
tone as you
compose it
Press
M
to enter the
Compose Menu
, and select
Play All
to play the notes you
have entered.
Press To Phone
Display
1
1
1
1
set octave
three
3
2
2
2
2
enter a
quarter note
C
C
3
3
3
7
7
enter a
quarter note
E flat
Eb
4
4
4
0
0
enter a half
rest
Rh
Task Action
139
PRELIMINARY
Ring Styles
Play a Tone
Edit a Tone
You cannot edit the predefined alert tones included with
your phone. To edit a custom alert tone:
5
4
0
0
0
enter a whole
note G
Gw
Find the Feature
M
>
Ring Styles
>
My Tones
Press To
1
S
scroll to the tone
2
M
open the
My Tones Menu
3
S
scroll to
Play
4
SELECT
(
+
) select
Play
5
PLAY
(
+
)
or
CANCEL
(
-
)
play the tone again
return to my tones list
Find the Feature
M
>
Ring Styles
>
My Tones
Press To
1
S
scroll to the tone
2
EDIT
(
+
) open the tone details
Press To Phone
Display
140
PRELIMINARY
Ring Styles
Delete a Tone
You cannot delete the predefined alert tones included
with your phone. To delete a custom alert tone:
Download a Tone
You can download custom alert tones from the
micro-browser application, or from a text message. To
download tones from the micro-browser, see page 152. To
download tones from a text message, see page 105.
3
S
scroll to the item you want to
edit (
Name
or
Notes
)
4
CHANGE
(
+
) select the item
5keypad keys enter new text or notes
6
OK
(
+
) store the tone
Find the Feature
M
>
Ring Styles
>
My Tones
Press To
1
S
scroll to the tone
2
M
open the
My Tones Menu
3
S
scroll to
Delete
4
SELECT
(
+
) select
Delete
5
YES
(
-
) confirm the deletion
Press To
141
PRELIMINARY
Ring Styles
Send Tones
You can send alert tones to other wireless phone users. To
insert a tone in a text message, see page 111.
Setting Reminders
A reminder is an alert that rings or vibrates at regular
intervals to notify you about a voicemail or text message
that you have received, or a datebook event that you
have scheduled.
Note:
Style
represents the current ring style.
Find the Feature
M
>
Ring Styles
>
Style
Detail
>
Reminders
Press To
1
S
scroll to
Beep
or
Vibrate
to set
the reminder alert type, or
Off
to turn off all reminders
2
SELECT
(
+
) select the reminder alert
142
PRELIMINARY
Shortcuts
Shortcuts
Your phone includes several standard shortcuts. You can
create additional shortcuts to frequently used menu items.
Standard Shortcuts
The following shortcuts are pre-programmed in your
phone. You cannot edit or delete these shortcuts.
Creating a Shortcut
You can create a keypad shortcut
plus
an optional voice
shortcut to a menu item. A voice shortcut takes you
directly to the menu item when you say the shortcut name.
Tip: Make your recording in a quiet location. Hold the
phone about four inches (10 centimeters) from your mouth,
and speak directly into the phone in a normal tone of voice.
Do This To
Press
M
, then press
and hold
M
(within
two seconds)
zoom in/out on your phone
display
Press
M
#
display your phone number
Press
N
go to the dialed calls list
Press
O
exit the menu system
Do This To
1Press
M
enter the menu system
143
PRELIMINARY
Shortcuts
2Press
S
scroll to the menu item
3Press and hold
M
open the shortcut editor
4Press
YES
(
-
view shortcut options
5Press
CHANGE
(
+
)
or
Press
DONE
(
-
)
or
Press
S
change the keypad
shortcut number
select the default keypad
shortcut number
scroll to
Voice
to assign a
voice shortcut
6Press
RECORD
(
+
) begin recording
The phone displays
Press Voice Key then
say voice shortcut
.
7Press and release
the voice key and say
the shortcut’s name
(in two seconds)
record the shortcut name
8Press and release
the voice key and
repeat the name
confirm the shortcut
name
9Press
DONE
(
-
) store the shortcut name
Do This To
144
PRELIMINARY
Shortcuts
Using Shortcuts
Use a Keypad Shortcut
Select a Shortcut From the List
Use a Voice Shortcut
Press To
1
M
open the menu
2
the keypad shortcut
number
go to the menu item or
perform the menu action
Find the Feature
M
>
Shortcuts
>
the shortcut you
want
Do This To
1Press
M
open the menu
2Press and release
the voice key and say
the shortcut’s name
(in two seconds)
go to the menu item or
perform the menu action
145
PRELIMINARY
Voice Notes
Voice Notes
You can use the voice note feature to record personal
messages and phone calls on your phone.
Recording a Voice Note
Use this procedure to record a voice note from the idle
display, or to record a phone call in progress. Your phone
plays an alert tone to notify the other party that the call is
being recorded.
Note: Recording phone calls is subject to varying state
and federal laws regarding privacy and recording of
conversations.
Tip: Make your recording in a quiet location. Hold the
phone about four inches (10 centimeters) from your mouth,
and speak directly into the phone in a normal tone of voice.
Do This Result
1Press and hold the
voice key for the
duration of the
recording.
The phone sounds an
alert tone and begins
recording.
2Speak your voice note. The phone records the
voice note.
3Release the voice key
to stop recording. The phone displays the
voice note number and
total recording time.
146
PRELIMINARY
Voice Notes
Viewing the Voice Notes List
Find the Feature
M
>
Voice Notes
Voice Notes
6)2:20pm 4/01..
5)4:05pm 3/31..
4)4:00pm 3/31..
3)11:05am 3/31.
2)9:00am 3/31..
1)7:15pm 3/30..
PLAYEXIT e
5E
f
Down
scroll
arrow
Locked
voice
note
Return to
previous
screen Press
M
to open the
Voice Notes Menu
Play the
highlighted
voice note
Time/date
recorded
147
PRELIMINARY
Voice Notes
Playing a Voice Note
When you connect an optional Motorola Original™
headset or FM Stereo Radio Headset accessory to your
phone, playback is automatically routed to the headset.
Tip: You can play a voice note while taking a call. It will not
be transmitted to the other party.
Playback Screen
The playback screen is displayed as the voice note plays.
Find the Feature
M
>
Voice Notes
Press To
1
S
scroll to the voice note
2
PLAY
(
+
) play the voice note
Voice Note 3
{}
DELETESAVE e
5E
Indicates
% played
Return to
previous
screen
Voice
note
number
Press
S
right to
fast
forward
Erase
voice note
Press
M
to open the
Voice Notes Menu
Press
S
left to
rewind
148
PRELIMINARY
Voice Notes
Voice Note Controls
Raise or lower
playback
volume of
voice note.
Press
up/down
to stop
playback and
scroll to next
voice note.
Press
left
to
rewind three
seconds,
resume playing.
Press
left and
hold
to rewind
to the beginning.
Press
right
to fast forward
three seconds,
resume playing.
Press
right and
hold
to fast
forward to end.
When playback
is complete,
press
right
to restart.
Press any number
key to alternately
stop and start
playback.
Stop
playback and
go to
Voice
Notes Menu
.
Stop
playback and
return to voice
notes list.
If voice note is
locked, stop
playback and
unlock voice
note.
If voice note is
unlocked, stop
playback and
display
Delete
Voice Note?
149
PRELIMINARY
Voice Notes
Locking and Unlocking a Voice
Note
Lock a voice note to prevent it from being deleted. You
must unlock a voice note to delete it.
To lock or unlock a voice note during playback:
Playback stops when you lock or unlock a voice note.
Press any number key to resume playback.
Find the Feature
M
>
Voice Notes
Press To
1
S
scroll to the voice note
2
M
open the
Voice Notes Menu
3
S
scroll to
Lock
or
Unlock
4
SELECT
(
+
) lock or unlock the voice note
Press To
1
M
open the
Voice Notes Menu
2
S
scroll to
Lock
or
Unlock
3
SELECT
(
+
) lock or unlock the voice note
150
PRELIMINARY
Voice Notes
Deleting a Voice Note
Notes:
•Press
NO
(
+
) to cancel deletion.
•You cannot delete a locked voice note.
•You cannot recover a deleted voice note.
Find the Feature
M
>
Voice Notes
Press To
1
S
scroll to the voice note
2
M
open the
Voice Notes Menu
3
S
scroll to
Delete
or
Delete All
4
SELECT
(
+
) select the highlighted option
5
YES
(
-
) confirm the deletion
151
PRELIMINARY
Micro-Browser
Micro-Browser
The micro-browser lets you access Web pages
and Web-based applications on your phone.
Contact your service provider to set up access,
if necessary.
Starting a Micro-Browser
Session
Shortcut: If you open a text message with a Web address
(URL) embedded in it, you can press
M
>
Go To
to launch
the micro-browser and go directly to the URL.
If you are unable to establish a network connection with
the micro-browser, contact your service provider.
Find the Feature
M
>
Browser
Press To
1
S
scroll to a bookmark, service,
or application
2
SELECT
(
+
) select the item
152
PRELIMINARY
Micro-Browser
Interacting With Web Pages
Downloading Pictures,
Animations, and Sounds
You can use the micro-browser to download pictures,
animations, and sounds onto your phone for use as screen
saver images, wallpaper images, or alert tones.
To download an image or sound file from a Web page,
simply select its link. A picture or animation is displayed
when downloading is complete. A sound file begins to
play when downloading is complete.
Press To
S
scroll through text, or
highlight a selectable item
SELECT
(
+
) select the highlighted item
N
call the highlighted phone
number from the
micro-browser
keypad keys,
followed by
OK
(
+
)enter information
Press
*
to delete one letter
at a time if you make a
mistake.
*
go back to the previous page
M
open the
Browser Menu
153
PRELIMINARY
Micro-Browser
Store a Picture or Animation File
To store the current displayed picture or animation:
To set the picture or animation as your new screen saver
or wallpaper image:
Note: When you set an animation as a wallpaper image,
only the first frame of the animation is displayed.
For more information about using pictures and animations,
see “Picture Viewer” on page 82, “Wallpaper” on
page 174, and “Screen Saver” on page 175.
Press To
1
STORE
(
+
) view the list of picture storage
options
2
S
scroll to
Store Only
3
SELECT
(
+
) store the picture or animation
Press To
1
STORE
(
+
) view the list of picture storage
options
2
S
scroll to
Set as Screen Saver
or
Set as Wallpaper
3
SELECT
(
+
) store the picture and set it as the
screen saver or wallpaper image
154
PRELIMINARY
Micro-Browser
Store a Sound File
To store the current displayed sound file:
To set the sound as an alert tone for a specific event:
Press To
1
STORE
(
+
) view the list of sound storage
options
2
S
scroll to
Store Only
3
SELECT
(
+
) store the sound
Your phone adds the sound
to the
My Tones
list along with
the custom tones you have
created.
Press To
1
STORE
(
+
) view the list of sound storage
options
2
S
scroll to
Set As Ring Tone
3
SELECT
(
+
) set the sound as an alert
Your phone displays the
message
Set As Which?
, and
lists the events (incoming
calls, text messages, etc.) for
which an alert may be set
4
S
scroll to the event for which
you want to set the new alert
155
PRELIMINARY
Micro-Browser
For more information about using sound files, see
page 135.
5
SELECT
(
+
) store the sound and set it as
the new alert for the selected
event
The new alert tone setting is
saved to the current alert
profile
Press To
156
PRELIMINARY
J2ME Applications
J2ME Applications
You can install and run J2ME (Java 2
Micro Edition) applications on your phone.
These applications add new features and
services to your phone.
Downloading an Application
With the Micro-Browser
Go to the page that contains the J2ME application you
want, then:
Downloading an Application
From a Computer
See page 182 for instructions on how to connect your
phone to a computer.
Find the Feature
M
>
Browser
Press To
1
S
scroll to the application
2
SELECT
(
+
) view the application details
3
DWNLOAD
(
+
) download the application
157
PRELIMINARY
J2ME Applications
On the computer, locate and prepare the file you want to
download, then select the following phone menu option:
Launching a J2ME Application
If the application requires an Internet connection, your
phone prompts you to approve the connection. To
automatically approve Internet connections for J2ME
applications:
Find the Feature
M
>
Settings
>
Java Tools
>
Java App Loader
Find the Feature
M
>
My Java Apps
Press To
1
S
scroll to the application
2
SELECT
(
+
) launch the application, or
open the list of applications in
a suite
3
S
scroll to the application you
want, if necessary
4
SELECT
(
+
) launch the application
Find the Feature
M
>
Settings
>
Java Tools
>
Network Access
Press To
1
S
scroll to
Always Ask
,
Ask Once Per App
, or
Never Ask
158
PRELIMINARY
J2ME Applications
J2ME Application Control Keys
Your phone’s keys perform the following functions in a
J2ME application.
Analyzing or Deleting a J2ME
Application
Use the application manager to view details or delete a
J2ME application.
2
SELECT
(
+
) select the highlighted setting
Key Function
S
Move up, down, left, or right in a game.
5
“Fire” your weapon in a game.
O
End the application.
N
Call a number displayed in the
application.
M
Open the J2ME applications menu.
Find the Feature
M
>
My Java Apps
Press To
1
S
scroll to the application
2
M
open the application manager
menu
3
S
scroll to a menu option
Press To
159
PRELIMINARY
J2ME Applications
The application manager menu includes the following
options:
Viewing J2ME Version and
Available Memory
To view J2ME version information, or the amount of phone
memory available for J2ME applications:
4
SELECT
(
+
) select the option to perform
procedures as described in
the following list
Option Description
View Details
Display the suite name, vendor,
version, number of apps, flash
usage, and memory
requirements.
Delete
Delete the suite.
Show Memory
or
Hide Memory
Show or hide the application’s
memory size in the application list
view.
Find the Feature
M
>
Settings
>
Java Tools
>
Java System
Press To
160
PRELIMINARY
J2ME Applications
To automatically show an application’s memory size in the
application list view, see “Analyzing or Deleting a J2ME
Application” on page 158.
Press To
1
S
scroll through version and
memory information as
described in the following
table
2
OK
(
+
) close the display
Option Displays
CLDC Version
The connected limited device
configuration version on your
phone.
MIDP Version
The mobile information device
profile version on your phone.
Data Space
Memory available for application
data (such as phone book entries
or game scores).
Program Space
Amount of free memory available
for J2ME applications.
Heap Size
Amount of runtime memory
available for J2ME applications.
Flash Space
Available space for J2ME
applications, including free
memory and used memory.
161
PRELIMINARY
Calculator
Calculator
You can use your phone as a calculator and currency
converter.
Calculating Numbers
Press To
1number keys enter a number
2
S
highlight a calculator function
3
SELECT
(
+
) perform the function
Calculator
+0
SELECTEXIT e
5E
MS
Ö
.C+ -x
$
=
% ±
MC MR
Selected
function
appears
here
Perform the
highlighted
function
Press
M
to open
the
Calculator Menu
Exit the
calculator
Entered
number
Press
S
to highlight
a function
162
PRELIMINARY
Calculator
The calculator can perform the following functions:
Function Description
.
Insert a decimal point
C
Clear the calculation
CE
Clear entry (replaces
C
when you enter
subsequent values in a calculation)
+
Add
-
Subtract
x
Multiply
Ö
Divide
MS
Store the value in memory (overwrites
current stored value)
MC
Clear the value stored in memory
MR
Replace the displayed value with the
value stored in memory
=
Calculate the result
%
Divide the displayed value by 100
±
Change the entry’s sign
(positive/negative)
$
Calculate the exchange rate
163
PRELIMINARY
Calculator
Converting Currency
The currency converter works just like the calculator, but
uses the
$
(currency) function:
Find the Feature
M
>
Calculator
M
>
Exchange Rate
Press To
1number keys enter the exchange rate
2
OK
(
+
) store the exchange rate
3number keys enter the amount to convert
(amount to multiply by the
exchange rate)
4
S
highlight the
$
function
5
SELECT
(
+
) perform the conversion
164
PRELIMINARY
Games
A
7
A
Games
You can play games with your phone between phone calls.
An incoming call, message, alarm, or alert automatically
ends the game.
Playing a Game
When the game is over:
Game Options
Press
M
to select the following options during a game:
Find the Feature
M
>
Games
Press To
1
S
scroll to a game
2
SELECT
(
+
) start the game
Press To
NEW
(
+
) or
YES
(
+
)start another session of the
same game
BACK
(
-
) or
NO
(
-
)end the game session
Option Description
Game Sounds
Switch game sounds on/off.
New Game
Start a new game session.
Key Configuration
Assign game functions to
different keypad keys.
165
PRELIMINARY
Games
A
7
A
Blackjack
In this classic card game, you play against the dealer to
see who can get closer to 21 points without going over.
Rules of the Game
•You start a new game with 100 credits. You must
bet from 1-10 credits for each hand you play.
•Press
DEAL
(
+
) to start a new hand.
•The first card is dealt to the dealer. The dealer’s cards
are shown at the top of the display, and your cards are
shown at the bottom.
•Face cards count as 10 points. Number cards count
as the points shown on their face.
•An ace counts as 11 points, unless that would put you
over 21 points. Otherwise, an ace is counted as 1
point. An ace that is originally counted as 11 may later
be counted as 1 if it will bring your total under or equal
to 21 points.
•An initial deal of an ace and a card with a face value of
10 points counts as exactly 21 points or Blackjack.
•Blackjack automatically wins against any other hand
that totals 21 points.
•If you score more than 21 points, you go “bust” or
lose.
Help
Review the goal of the game.
Option Description
166
PRELIMINARY
Games
A
7
A
•If you get five cards without going bust, you win.
•If you and the dealer have the same score, the dealer
wins.
•You can ask for a “hit” or another card as long as you
do not go bust.
•As long as the dealer’s total is less than 17 points, the
dealer must continue to take a hit.
How to Play
When the game begins, you are dealt two cards.
Press
M
to select the following options:
Falling Numbers
Score points by pressing the corresponding number key
for numbers as they “fall” down the display.
Press To
STAY
(
-
) see the results of the hand
HIT ME
(
+
) request another card
Option Description
Insurance
If the dealer’s first card is an
ace, pay half of your wager to
insure against the dealer
winning with Blackjack.
Double Down
Double your initial wager after
receiving your first two cards.
Choose Deck
Choose the deck image.
167
PRELIMINARY
Games
A
7
A
Rules of the Game
•If a number reaches the bottom of the display or if you
press an incorrect number key, you score one miss.
•The game is over when you score three misses.
•The game has five levels. When you complete a level,
play continues automatically at the next level.
•You earn a bonus if you finish a level without a
miss.
How to Play
When the game begins, numbers start falling from the
upper portion of the display. Press the corresponding
number key to eliminate a falling number before it reaches
the bottom of the display.
Press
M
to set the following options:
Mindblaster
Guess a secret four-symbol code. You play by entering
symbols into four spaces and then submitting a guess.
Rules of the Game
•Your score is the number of guesses it takes to reveal
the secret code.
Option Description
Level
Choose the starting level of play.
Top Scores
View the top five scores.
168
PRELIMINARY
Games
A
7
A
•When you submit a guess, you receive clues that
indicate how many symbols you have identified
correctly and how many are in the correct position.
The position of the clues does
not
correspond to the
location of the symbols.
•You can see a history of your last 10 guesses.
•Once you enter a symbol into a blank space, you
can change the symbol but you cannot make the
space blank again.
•When you correctly guess the four-symbol code, the
display shows your score and the level of your next
game.
•After you win one game, you progress from level 1 to
level 2. After you win two more games, you progress
from level 2 to level 3.
•When you exit the game or turn off the phone, you
begin again at level 1.
How to Play
When the game begins, you see four blank spaces.
= correct symbol in correct position
= correct symbol in wrong position
Do This To
Press
S
left or
right
move from space to space
Press
S
up or
down
place a symbol in a space
169
PRELIMINARY
Games
A
7
A
Press
M
to select the following options:
Paddleball
Move your paddle to strike a bouncing ball. The paddle
gets smaller as your score increases.
Rules of the Game
•Your score is the number of times your paddle hits the
ball.
•The game is over when the paddle misses the ball.
How to Play
Press
GUESS
(
+
) submit a guess (when all four
spaces contain symbols)
Select
>
and then
press
S
up or
down
scroll through a history of
your last 10 guesses
Option Description
Level
Choose the starting level of play.
Top Scores
View the top score for each
level.
Press To
S
up or down move your paddle to hit the
bouncing ball
Do This To
170
PRELIMINARY
Games
A
7
A
Reversal
Compete against the phone to place more disks of your
color (black or white) on the 64-square playing area.
Rules of the Game
•Black plays first, and players alternate turns.
•Place a disk of your color on an empty square
adjacent to an opponent’s disk so that at least one
of the opponent’s disks is between two of your
disks. The opponent’s disk(s) flip to become your
color.
•If you cannot make a legal move, the game displays
No move
and you lose your turn.
•Then game ends when neither player can make a
valid move.
How to Play
1Select a square as follows:
Press To move the highlight
4
or
S
to the left left
6
or
S
to the
right
right
2
or
S
up above
8
or
S
down below
1
upper-left
3
upper-right
7
lower-left
171
PRELIMINARY
Games
A
7
A
2Press
PLACE
(
+
) to place one of your colored disks in
the selected square.
Press
M
to select the following options:
Video Poker
Turn 100 credits into 9,999+ credits by making the best
possible poker hands.
Rules of the Game
•You start a new game with 100 credits. You must bet
from 1-10 credits for each hand you play.
•You are dealt five cards face up, and have one
opportunity to trade in cards (zero to five) for new
ones.
•A winning hand earns credits as listed in the
Awards Table
.
•Your credit total is saved when you exit the game. The
next time you play, you start with the number of credits
that remain from the previous session.
9
lower-right
Option Description
Undo
Take back your last move.
Auto-Assign
Color
Select
Yes
to assign colors
automatically at the start of each
game.
Press To move the highlight
172
PRELIMINARY
Games
A
7
A
•The game is over when you lose all of your credits.
How to Play
Place your initial bet or change your bet (from 1-10 credits)
and then:
Press
M
to select the following options:
Press To
DEAL
(
+
) start a new hand
4
or
S
to the left select the card to the left
6
or
S
to the
right
select the card to the right
5
or
DISCARD
(
-
) discard (cannot be undone)
DONE
(
+
) remove discarded cards and
deal replacements
Option Description
Change Bet
Change the amount of your bet.
Choose Deck
Choose the deck image.
Awards Table
View the list of odds/payouts for
each winning hand.
173
PRELIMINARY
Adjusting Your Settings
Adjusting Your
Settings
Reordering Menu Items
You can reorder the items in your phone’s main menu.
Customizing a Soft Key
Function
You can relabel the soft keys (
-
and
+
) to access different
menu items from the idle display.
Find the Feature
M
>
Settings
>
Other Settings
>
Personalize
>
Main Menu
Press To
1
S
scroll to a menu item
2
GRAB
(
+
) grab the menu item
3
S
move the item to a new
location in the menu
4
INSERT
(
+
) insert the menu item
Find the Feature
M
>
Settings
>
Other Settings
>
Personalize
>
Keys
174
PRELIMINARY
Adjusting Your Settings
Wallpaper
You can set the wallpaper (background) picture that is
displayed in your phone’s idle display. You can use a still
picture or an animation as a wallpaper image. When you
set an animation as a wallpaper image, only the first frame
of the animation is displayed.
To set and adjust the wallpaper picture on your phone:
Press To
1
S
scroll to
Left
or
Right
2
CHANGE
(
+
) open the key editor
3
S
scroll to the new key function
4
CHANGE
(
+
) confirm the new function
Find the Feature
M
>
Settings
>
Other Settings
>
Personalize
>
Wallpaper
Press To
1
S
scroll to
2
CHANGE
(
+
) open the picture viewer
3
S
left or right scroll to the picture or
animation you want to use
To turn off the wallpaper
picture, scroll to
(None)
.
4
SELECT
(
+
) select the picture
5
S
scroll to
Layout
175
PRELIMINARY
Adjusting Your Settings
Screen Saver
You can set the screen saver picture that is displayed in
your phone’s idle display when no activity is detected for a
specified period of time. You can use a still picture or an
animation as a screen saver image.
6
CHANGE
(
+
) adjust the layout of the
wallpaper
7
S
scroll to
Center
or
Tile
The
Center
option places the
image in the center of the
display and, if necessary,
shrinks the image to fill the
display area.
The
Tile
option fills the
display area with adjacent
copies of the image
8
SELECT
(
+
) confirm the wallpaper layout
setting
Find the Feature
M
>
Settings
>
Other Settings
>
Personalize
>
Screen Saver
Press To
1
S
scroll to
2
CHANGE
(
+
) open the picture viewer
Press To
176
PRELIMINARY
Adjusting Your Settings
The selected screen saver picture or animation is activated
and displayed after the period of inactivity you specify. If
necessary, the image is shrunk to fill the display area. An
animation repeats for one minute. After one minute, the
first frame of the animation is displayed.
TTY Operation
You can use an optional TTY device with your
phone to send and receive calls. You must plug the
TTY device into the phone’s headset jack and set
the phone to operate in one of three TTY modes.
3
S
left or right scroll to the picture or
animation that you want to
use
To turn off the screen saver
picture, scroll to
(None)
.
4
SELECT
(
+
) select the picture
5
S
scroll to
Delay
6
CHANGE
(
+
) set the delay interval for
screen saver activation
7
S
scroll to the inactivity time
interval that will activate the
screen saver image
8
SELECT
(
+
) confirm the screen saver
delay setting
Press To
177
PRELIMINARY
Adjusting Your Settings
Set TTY Mode
When you set your phone to a TTY mode, it operates in
that mode whenever the TTY device is connected.
The
TTY Setup
menu includes the following options:
When your phone is in a TTY mode, the international TTY
symbol and the mode setting are shown in the idle display.
You can press
TTYMODE
(
-
) to change the mode setting.
Find the Feature
M
>
Settings
>
Other Settings
>
Initial Setup
>
TTY Setup
Press To
1
S
scroll to
TTY Setup
2
CHANGE
(
+
) change the TTY mode
3
S
scroll to the TTY mode
4
SELECT
(
+
) select the TTY mode
Option Description
TTY
Transmit and receive TTY characters
VCO
Receive TTY characters but transmit
by speaking into the microphone
HCO
Transmit TTY characters but receive by
listening to the earpiece
Voice
Return to normal voice mode
178
PRELIMINARY
Adjusting Your Settings
Switch to TTY Mode During a Voice Call
Return to Voice Mode
To return to normal voice mode, select
Voice
from the
TTY Setup
menu as described on page 177.
Hands-Free Use
You can purchase an optional Motorola
Original™ hands-free car kit or headset for
your phone. These accessories provide
alternative ways for you to use your phone
without using your hands.
Note: The use of wireless devices and their accessories
may be prohibited or restricted in certain areas. Always
obey the laws and regulations on the use of these
products.
Press To
1
M
open the
Call
menu
2
S
scroll to
TTY Setup
3
SELECT
(
+
) display the
TTY Setup
menu
4
S
scroll to the TTY mode
5
SELECT
(
+
) select the TTY mode
179
PRELIMINARY
Adjusting Your Settings
Automatic Answer
You can set your phone to automatically answer calls after
two rings when connected to a car kit or headset.
Automatic Hands-Free
You can set your phone to automatically route calls to a car
kit when it detects a connection.
Find the Feature
M
>
Settings
>
Other Settings
Press To
1
S
scroll to
Car Settings
or
Headset
2
SELECT
(
+
) select the feature
3
S
scroll to
Auto Answer
4
CHANGE
(
+
) select
Auto Answer
5
S
scroll to
On
or
Off
6
SELECT
(
+
) confirm the setting
Find the Feature
M
>
Settings
>
Other Settings
>
Car Settings
>
Auto Handsfree
Press To
1
S
scroll to
On
or
Off
2
SELECT
(
+
) confirm the setting
180
PRELIMINARY
Adjusting Your Settings
Power-Off Delay
When your phone is connected to a car kit, you can set it
to stay on for a specified time period after you switch off
the ignition. This prevents the phone from draining your
vehicle battery, but leaves the phone on long enough that
you do not have to re-enter your unlock code when making
short stops.
Caution: If you select
Continuous
, the phone does not
power off when you turn off the ignition. Be careful not to
drain your vehicle battery if you select this option.
Charger Time
When your phone is connected to a car kit, you can set it
to charge itself for a specified time period after you switch
off the ignition. This helps ensure that the phone battery
gets fully charged while the vehicle is parked.
Find the Feature
M
>
Settings
>
Other Settings
>
Car Settings
>
Power-Off Delay
Press To
1
S
scroll to the time delay
2
SELECT
(
+
) confirm your selection
Find the Feature
M
>
Settings
>
Other Settings
>
Car Settings
>
Charger Time
181
PRELIMINARY
Adjusting Your Settings
Press To
1
S
scroll to the charge time
2
SELECT
(
+
) confirm your selection
182
PRELIMINARY
Data and Fax Calls
Data and Fax Calls
A Motorola Original™ data kit lets you transfer
data between your phone and a computer or other
external device. You can:
•synchronize data between your phone and an
external device with Starfish TrueSync
®
software, a
Motorola accessory product. See the TrueSync user
guide for more information.
Note: TrueSync software is designed to synchronize
with basic features of many popular Personal
Information Management (PIM) software and
hardware products.
•use your phone as a modem to connect to the
Internet.
•use your phone to send and receive data and fax calls
on your computer or hand-held device.
Connecting Your Phone to an
External Device
Connect your phone to a computer or hand-held device
using a serial cable or a USB cable.
Note: Not all devices are compatible with serial cable or
USB cable connections. Check your external device for
specifications.
183
PRELIMINARY
Data and Fax Calls
Set Up a Cable Connection
Attach a serial cable or Motorola Original USB cable to the
phone and external device as follows. Your phone plays a
short tone when the cable connects.
Note: Check your computer or hand-held device to
determine the type of cable you need.
Attaching a Serial Cable
Use the interchangeable head on the Motorola
Multi-Connect Serial Cable to connect a computer, Palm III
device, or Palm V device to your phone.
Do This
1Plug the serial
cable into the
detachable head.
Make sure that the
Motorola logo on
the detachable
head and the
metal shielding on
the serial cable
plug are both
facing you.
184
PRELIMINARY
Data and Fax Calls
Attaching a USB Cable
2With the Motorola
logo and the
phone both facing
you, plug the
detachable head
into the phone’s
accessory
connector port.
3Plug the other end of the cable into the serial
interface connection on the external device and
tighten the screws.
Do This
1Plug the end of the
cable with the
Motorola logo into the
phone’s accessory
connector port. Make
sure that the logo and
the phone are both
facing you.
2Plug the other end—the USB connection—into
the USB port on the external device.
Do This
185
PRELIMINARY
Data and Fax Calls
Install the Software
Install the software from the CD-ROM that comes with
your Motorola Original data kit. See the data kit’s user
guide for more information.
Sending a Data or Fax Call
You can connect your phone to a computer or hand-held
device to send data or a fax from the connected device.
Use this feature to transfer data from your computer onto
another device, and to synchronize phonebook and
datebook information between your phone, computer, and/
or hand-held device.
Connect your phone as described on page 182 and do the
following:
Do This To
1Check the phone make sure that the phone is
connected and powered on
2Open the
application on
your computer
place the call through the
application (such as
dial-up-networking or fax)
Note: You cannot dial data or
fax numbers through your
phone’s keypad. You must
dial them through your
computer.
3End the call from
the connected
device
close the call and connection
when the transfer is complete
186
PRELIMINARY
Data and Fax Calls
Receiving a Data or Fax Call
You can connect your phone to a computer or hand-held
device to receive data or a fax.
Use this feature to transfer data to your computer from
another device.
Set Up Your Phone
Transfer the Data or Fax
Your phone notifies you when the data or fax call arrives,
and transfers the call to the connected device. You must
Find the Feature
M
>
Settings
>
Connection
>
Incoming Call
Do This To
1Press
CHANGE
(
+
) select
Next Call
2Press
S
scroll to
Data In Only
or
Fax In Only
3Press
SELECT
(
+
) set the call format
4Connect your phone
to the device enable the data or fax
transfer
Note: You cannot answer incoming voice calls when
your phone is in data or fax mode. Any voice calls you
receive are treated as unanswered calls. To return a
voice call, reset your phone to voice mode as
described on page 187.
187
PRELIMINARY
Data and Fax Calls
use the application running on the connected device to
answer the call.
End the Data/Fax Connection
When the data or fax transfer is complete:
Reset Normal Voice Operation
After making a data or fax call, you must reset your phone
to resume normal voice operations.
Your phone also reverts to normal voice operations when
you turn it off and then turn it back on.
Do This To
End the call from the
connected device close the connection
Find the Feature
M
>
Settings
>
Connection
>
Incoming Call
Do This To
1Press
CHANGE
(
+
) select
Next Call
2Press
S
scroll to
Normal
3Press
SELECT
(
+
) reset your phone
188
PRELIMINARY
Security
Security
Assigning a New Code or
Password
Your phone’s unlock code is originally set to 1234, and the
security code is originally set to 000000. Your service
provider may reset these numbers before you receive your
phone.
If your service provider has
not
reset these numbers, we
recommend that you change them to prevent other users
from accessing your personal information. The unlock
code must contain four digits, and the security code must
contain six digits.
Notes:
•Your service provider may retain your phone’s security
code for customer service purposes. In this case, you
will not be able to use phone features that require you
to enter the security code.
•If the unlock code is the only code you can change,
the
New Passwords
menu is not available. In this case,
change the unlock code by selecting:
M
>
Settings
>
Security
>
Phone Lock
>
Unlock Code
.
To change a code or password:
Find the Feature
M
>
Settings
>
Security
>
New Passwords
189
PRELIMINARY
Security
If You Forget a Code or
Password
If you forget your security code, contact your service
provider.
If you forget your unlock code, try entering 1234 or the last
four digits of your phone number. If that does not work, do
the following at the
Enter Unlock Code
prompt:
Press To
1
S
scroll to the code or password
2
CHANGE
(
+
) select the code or password
3keypad keys enter your old code
4
OK
(
+
) submit your old code
5keypad keys enter the new code
6
OK
(
+
) assign the new code
7keypad keys re-enter the new code
8
OK
(
+
) confirm the new code
Press To
1
M
go to the unlock code bypass
screen
2keypad keys enter your security code
3
OK
(
+
) submit your security code
190
PRELIMINARY
Security
Locking and Unlocking Your
Phone
You can lock your phone manually or set the phone to lock
automatically whenever you turn it off.
To use a locked phone, you must enter the unlock code. A
locked phone still rings or vibrates for incoming calls or
messages,
but you must unlock it to answer
.
You can make emergency calls on your phone even when
it is locked. For more information, see page 34.
Lock Your Phone Manually
Set Your Phone to Lock Automatically
You can set your phone to lock every time you turn it off.
Find the Feature
M
>
Settings
>
Security
>
Phone Lock
>
Lock Now
Press To
1keypad keys enter your unlock code
2
OK
(
+
) lock the phone
Find the Feature
M
>
Settings
>
Security
>
Phone Lock
>
Automatic Lock
>
On
Press To
1keypad keys enter your unlock code
2
OK
(
+
) activate automatic lock
191
PRELIMINARY
Security
Unlock Your Phone
At the
Enter Unlock Code
prompt:
Restricting Calls
You can stop all incoming and/or outgoing calls, or you can
restrict outgoing calls to the numbers stored in your
phonebook.
Notes:
•You can make emergency calls when outgoing calls
are restricted.
•Your phone still receives incoming text messages
when incoming calls are restricted.
Press To
1keypad keys enter your unlock code
2
OK
(
+
) unlock your phone
Find the Feature
M
>
Settings
>
Security
>
Restrict Calls
Press To
1keypad keys enter your unlock code
2
OK
(
+
) open the restrict calls menu
3
S
scroll to
Outgoing Calls
or
Incoming Calls
4
CHANGE
(
+
) select the option
5
CHANGE
(
+
) change the
Allow
setting
6
S
scroll to
All
,
None
, or
Phonebook
(for outgoing calls)
192
PRELIMINARY
Security
Tip: The phonebook is not locked when you restrict
outgoing calls to numbers stored in the phonebook. To
prevent a user from adding (and then calling) a new
phonebook entry, you may want to lock the phonebook.
See the “Lock Application” item on page 63.
7
SELECT
(
+
) select the allowed calls
Press To
193
PRELIMINARY
Troubleshooting
Troubleshooting
Check these questions first if you have problems with
your phone. If you need additional help, contact the
Motorola Customer Call Center at 1-800-331-6456
(United States) or 1-800-461-4575 (Canada).
Question Answer
Is your phone
set up
correctly?
Press
M
#
. If you do not see
your phone number, contact your
service provider.
Is your battery
charged? Do
you see
B
in
the display?
The battery level indicator should
have at least one segment
showing (
C
). If it does not,
recharge your battery. See
page 20.
Does the
handset have
a signal? Do
you see
j
in
the display?
Make sure that your antenna is
fully extended. The signal strength
indicator should have at least one
segment showing (
1
). If it does
not, move to an area with a
stronger signal to use your phone.
Is the earpiece
volume too
low?
While on a call, press the upper
volume key on the side of your
phone.
194
PRELIMINARY
Troubleshooting
The following refer to specific problems:
Is the other
party unable
to hear you?
Make sure that your antenna is
fully extended and that your
phone is not muted. Press
UNMUTE
(
+
) if necessary to
unmute the phone.
Also, make sure that your phone’s
microphone is not blocked by its
carrying case or a sticker.
Has the phone
been
damaged,
dropped, or
gotten wet?
Dropping your phone, getting it
wet, or using a non-Motorola
battery or battery charger can
damage the phone. The phone’s
limited warranty does not cover
liquid damage or damage caused
from using non-Motorola
accessories.
Was a
non-Motorola
battery or
battery
charger used?
Problem Solution
My phone was
stolen. To
whom should I
report this?
Report a stolen phone to the
police and to your service provider
(the company that sends you your
monthly wireless service bill).
I forgot my
password. See page 189.
Question Answer
195
PRELIMINARY
Troubleshooting
I pressed the
power key, but
nothing
happened.
Be sure to press and hold
P
(the
power key) until the display
appears and you hear an audible
alert. (This could take several
seconds.) If nothing happens,
check that a charged battery is
installed. See page 19.
The display
says:
Enter
Unlock Code
.
How do I
unlock my
phone?
Enter the factory-preset unlock
code (1234), or the last four digits
of your phone number. If this fails,
call your service provider (the
company that sends you your
monthly wireless service bill).
My phone
asks for an
unlock code
when I try to
open a feature.
The application you want is
locked. If you do not know the
unlock code, see page 189.
My phone
does not ring. If you see
t
or
y
in the
display, then the ringer is turned
off. See page 133.
Also, the ringer may be set to
Silent
even though your phone is
set to an audible ring style. See
page 134.
Problem Solution
196
PRELIMINARY
Troubleshooting
My phone
rings even
though I
selected the
Silent
(or
Vibrate
) ring
style.
The ringer may be set to play a
tone even though your phone is
set to a silent ring style. See
page 134.
I tried to place
a call and
heard an
alternating
high/low tone.
Your call did not reach the
wireless system. You may have
dialed the number too soon after
turning the phone on. Wait until
the display says
Ready
before
making a call.
I cannot send/
receive calls. Make sure that your antenna is
fully extended and that you have a
phone signal (see the “Signal
Strength Indicator” item on
page 26). Avoid electrical or radio
interference, and obstructions
such as bridges, parking garages,
or tall buildings.
Your phone also may have the
Restrict Calls
feature turned on.
If you know the unlock code, you
can change this setting in the
security menu (
M
>
Settings
>
Security
).
Problem Solution
197
PRELIMINARY
Troubleshooting
My phone has
poor reception
and drops
calls.
Make sure that your antenna is
fully extended and is not bent or
damaged.
Also, make sure you have a phone
signal (see the “Signal Strength
Indicator” item on page 26). Stay
clear of any obstructions such as
bridges, parking garages, or tall
buildings.
I cannot hear
others on my
phone.
While on a call, press the upper
volume key. The display should
show the volume increasing.
Also, make sure that your phone’s
earpiece is not blocked by its
carrying case.
I cannot open
my inbox. Before you can use text
messages, you must set up the
message inbox. See page 102.
How do I see
the calls I sent
or received?
To see the most recent calls you
dialed or received:
M
>
Recent Calls
>
Received Calls
or
Dialed Calls
Problem Solution
198
PRELIMINARY
Troubleshooting
My phone will
not send
voicemail
commands,
passwords, or
other codes.
Your phone sends commands and
passwords as DTMF tones. You
can set your phone’s DTMF tones
to be
Long
,
Short
, or
Off
. If you
have trouble sending numbers, try
changing your DTMF setting.
1From the idle display, press:
M
>
Settings
>
Other Settings
>
Initial Setup
>
DTMF
2Press
S
to scroll to
Long
or
Short
(some analog networks
may not recognize short
tones).
3Press
SELECT
(
+
) to select it.
My phone’s
display is too
dark.
Use the
Contrast
feature to
change the level of contrast in
your phone display. See page 67.
You can also use the
Backlight
feature to change the length of
time that the display backlight
stays on. See page 66.
Problem Solution
199
PRELIMINARY
Troubleshooting
My battery
didn’t last as
long as I
expected.
What can I do
to extend
battery life?
Your battery’s performance is
affected by charge time, feature
use, temperature changes,
backlight use, and other factors.
For tips on extending your battery
life, see page 30.
I am unable to
record a voice
note, voice
name, or voice
shortcut.
Try moving to a quieter location to
make your voice recording. Hold
the phone about four inches (10
centimeters) from your mouth,
and speak directly into the phone
in a normal tone of voice.
My TTY device
doesn’t work
with my
phone.
Your phone must be set to a TTY
mode for the phone to detect your
TTY device. See “TTY Operation”
on page 176.
I plugged the
data cable into
my phone but
my phone did
not beep. How
do I know if
the data cable
is ready to go?
The beep indicates that you are
set up correctly. If you did not hear
a beep, make sure that both ends
of the data cable are connected—
the smaller end to your phone and
the larger end to your computer.
Also, your computer may have
deactivated the port to save
power. Try opening an application
that uses the port, like a fax or
dial-up application, to
automatically activate the port.
Problem Solution
200
PRELIMINARY
Troubleshooting
My phone
beeped when I
attached the
data cable, but
my data and
fax
applications
don’t work.
You must be in an area with digital
coverage. Check your phone’s
display for the digital signal
indicator (
F
).
Some wireless networks may not
support data or fax transmission.
If you see the digital indicator, but
you are roaming on an unfamiliar
network, this may be the case.
Also, remember that data and fax
transmission usually requires a
subscription. Call your service
provider for more information.
When sending
data with the
data cable,
why does the
computer
show a
connection
rate of 19200
Kbps?
19200 Kbps is the data transfer
rate of the connection between
your computer and the phone.
The rate of the connection
between your phone and the
network is displayed on your
phone, and will be either 14400 or
9600 Kbps.
I can’t end my
data call by
closing the
application on
my computer.
What can I do?
Try pressing on your phone. Or try
disconnecting the cable or turning
off the phone. If possible, always
close the connection through your
computer, as these alternative
methods may disrupt the
application on your computer.
Problem Solution
201
PRELIMINARY
Troubleshooting
I launched the
micro-browser
but the display
says:
Service Not
Available
.
You may be in an area without
service. If you have wireless
service, look in the display for the
digital signal indicator (
F
). If you
do not see the indicator, you may
be in an area that has only analog
service or no service at all. If you
see the digital signal indicator, you
may be connected to a digital
network that does not support
Internet access.
I launched the
micro-browser
but the display
says:
Data Server
Unavailable
.
Try again in a few minutes. The
servers may be temporarily busy.
Problem Solution
202
PRELIMINARY
Programming Instructions
Programming
Instructions
Follow this procedure if you need to program your phone’s
phone number(s) or system ID.
Note: Programming is normally done by a trained
technician at the site of purchase. Users should not make
changes other than ones in the following procedure.
Before programming, ask your service provider for your:
•10-digit MIN (Mobile Identification Number)
•8- to 15-digit IMSI (International Mobile Service
Identifier)
•8- to 15-digit MDN (Mobile Directory Number)
•5-digit AMPS Sys ID number
•5-digit CDMA Sys ID number
Do This To
1Press
7
,
4
,
6
,
6
,
3
,
#
,
M
,
M
(These keys spell
P-H-O-N-E +
#
,
M
,
M
.)
open the user
activation menu
2Press
S
scroll to
NAM1
(phone number 1)
or
NAM2
(phone
number 2)
203
PRELIMINARY
Programming Instructions
3Press
SELECT
(
+
) open the NAM
programming menu
4Press the keypad keys for
the 10-digit MIN open the MIN editor
and enter the new
MIN
5Press
OK
(
+
) store the new MIN
6Similarly, enter appropriate numbers for the
IMSI, MDN, AMPS Sys ID, and CDMA Sys ID
7Press
DONE
(
-
) close the NAM
programming menu
8Press
EXIT
(
-
) close the user
activation menu
Do This To
204
PRELIMINARY
Specific Absorption Rate Data
Specific Absorption
Rate Data
This model phone meets the government’s requirements
for exposure to radio waves.
Your wireless phone is a radio transmitter and receiver. It is
designed and manufactured not to exceed limits for exposure
to radio frequency (RF) energy set by the U.S. Federal
Communications Commission for the United States and by
Health Canada for Canada. These limits are part of
comprehensive guidelines and establish permitted levels of
RF energy for the general population. The guidelines are
based on standards that were developed by independent
scientific organizations through periodic and thorough
evaluation of scientific studies. The standards include a
substantial safety margin designed to assure the safety of all
persons, regardless of age or health.
The exposure standard for wireless mobile phones employs a
unit of measurement known as the Specific Absorption Rate,
or SAR. The SAR limit set by the FCC and by Health Canada
is 1.6 W/kg.
1
Tests for SAR are conducted using standard
operating positions accepted by the FCC and by Industry
Canada with the phone transmitting at its highest certified
power level in all tested frequency bands. Although the SAR is
determined at the highest certified power level, the actual
SAR level of the phone while operating can be well below the
maximum value. This is because the phone is designed to
operate at multiple power levels so as to use only the power
required to reach the network. In general, the closer you are
205
PRELIMINARY
Specific Absorption Rate Data
to a wireless base station antenna, the lower the power
output.
Before a phone model is available for sale to the public in the
U.S. and Canada, it must be tested and certified to the FCC
and Industry Canada that it does not exceed the limit
established by each government for safe exposure. The tests
are performed in positions and locations (e.g., at the ear and
worn on the body) reported to the FCC and available for
review by Industry Canada. The highest SAR value for this
model phone when tested for use at the ear is ____ W/kg
2
,
and when worn on the body, as described in this user guide, is
____ W/kg.
2
(Body-worn measurements differ among phone
models, depending upon available accessories and regulatory
requirements). While there may be differences between the
SAR levels of various phones and at various positions, they all
meet the governmental requirements for safe exposure.
The FCC and Industry Canada have granted an Equipment
Authorization for this model phone with all reported SAR
levels evaluated as being in compliance with the FCC and
Health Canada RF exposure guidelines. SAR information on
this model phone is on file with the FCC and can be found
under the Display Grant section of:
http://www.fcc.gov/oet/fccid
after searching on FCC ID ________. You may also refer to
Motorola’s Web site:
http://www.motorola.com/rfhealth
206
PRELIMINARY
Specific Absorption Rate Data
Additional information on Specific Absorption Rates (SAR)
can be found on the Cellular Telecommunications & Internet
Association (CTIA) Web site:
http://phonefacts.net
or the Canadian Wireless Telecommunications Association
(CWTA) Web site:
http://www.cwta.ca
1. In the United States and Canada, the SAR limit for mobile
phones used by the public is 1.6 watts/kg (W/kg) averaged over
one gram of tissue. The standard incorporates a substantial
margin of safety to give additional protection for the public and
to account for any variations in measurements.
2. Additional related information includes the Motorola testing
protocol, assessment procedure, and measurement uncertainty
range for this product.
ITC01-064
207
PRELIMINARY
Additional Health and Safety Information
The U.S. Food and Drug
Administration's Center for
Devices and Radiological Health
Consumer Update on Mobile Phones
Additional Health and Safety Information
FDA has been receiving inquiries about the safety of mobile
phones, including cellular phones and PCS phones. The
following summarizes what is known—and what remains
unknown—about whether these products can pose a hazard
to health, and what can be done to minimize any potential
risk. This information may be used to respond to questions.
Why the concern?
Mobile phones emit low levels of radio frequency energy (i.e.,
radio frequency radiation) in the microwave range while being
used. They also emit very low levels of radio frequency energy
(RF), considered non-significant, when in the stand-by mode.
It is well known that high levels of RF can produce biological
damage through heating effects (this is how your microwave
oven is able to cook food). However, it is not known whether,
to what extent, or through what mechanism, lower levels of RF
might cause adverse health effects as well. Although some
research has been done to address these questions, no clear
picture of the biological effects of this type of radiation has
emerged to date. Thus, the available science does not allow
us to conclude that mobile phones are absolutely safe, or that
they are unsafe. However, the available scientific evidence
does not demonstrate any adverse health effects associated
with the use of mobile phones.
208
PRELIMINARY
Additional Health and Safety Information
What kinds of phones are in question?
Questions have been raised about hand-held mobile phones,
the kind that have a built-in antenna that is positioned close to
the user's head during normal telephone conversation. These
types of mobile phones are of concern because of the short
distance between the phone's antenna—the primary source
of the RF—and the person's head. The exposure to RF from
mobile phones in which the antenna is located at greater
distances from the user (on the outside of a car, for example)
is drastically lower than that from hand-held phones, because
a person's RF exposure decreases rapidly with distance from
the source. The safety of so-called “cordless phones,” which
have a base unit connected to the telephone wiring in a house
and which operate at far lower power levels and frequencies,
has not been questioned.
How much evidence is there that hand-held
mobile phones might be harmful?
Briefly, there is not enough evidence to know for sure, either
way; however, research efforts are on-going. The existing
scientific evidence is conflicting and many of the studies that
have been done to date have suffered from flaws in their
research methods. Animal experiments investigating the
effects of RF exposures characteristic of mobile phones have
yielded conflicting results. A few animal studies, however,
have suggested that low levels of RF could accelerate the
development of cancer in laboratory animals. In one study,
mice genetically altered to be predisposed to developing one
type of cancer developed more than twice as many such
cancers when they were exposed to RF energy compared to
controls. There is much uncertainty among scientists about
whether results obtained from animal studies apply to the use
209
PRELIMINARY
Additional Health and Safety Information
of mobile phones. First, it is uncertain how to apply the results
obtained in rats and mice to humans. Second, many of the
studies that showed increased tumor development used
animals that had already been treated with cancer-causing
chemicals, and other studies exposed the animals to the RF
virtually continuously—up to 22 hours per day.
For the past five years in the United States, the mobile phone
industry has supported research into the safety of mobile
phones. This research has resulted in two findings in
particular that merit additional study:
1
In a hospital-based, case-control study, researchers
looked for an association between mobile phone use and
either glioma (a type of brain cancer) or acoustic neuroma
(a benign tumor of the nerve sheath). No statistically
significant association was found between mobile phone
use and acoustic neuroma. There was also no association
between mobile phone use and gliomas when all types of
types of gliomas were considered together. It should be
noted that the average length of mobile phone exposure in
this study was less than three years.
When 20 types of glioma were considered separately,
however, an association was found between mobile phone
use and one rare type of glioma, neuroepithelliomatous
tumors. It is possible with multiple comparisons of the
same sample that this association occurred by chance.
Moreover, the risk did not increase with how often the
mobile phone was used, or the length of the calls. In fact,
the risk actually decreased with cumulative hours of
mobile phone use. Most cancer causing agents increase
risk with increased exposure. An ongoing study of brain
210
PRELIMINARY
Additional Health and Safety Information
cancers by the National Cancer Institute is expected to
bear on the accuracy and repeatability of these results.
1
2
Researchers conducted a large battery of laboratory tests
to assess the effects of exposure to mobile phone RF on
genetic material. These included tests for several kinds of
abnormalities, including mutations, chromosomal
aberrations, DNA strand breaks, and structural changes in
the genetic material of blood cells called lymphocytes.
None of the tests showed any effect of the RF except for
the micronucleus assay, which detects structural effects
on the genetic material. The cells in this assay showed
changes after exposure to simulated cell phone radiation,
but only after 24 hours of exposure. It is possible that
exposing the test cells to radiation for this long resulted in
heating. Since this assay is known to be sensitive to
heating, heat alone could have caused the abnormalities
to occur. The data already in the literature on the response
of the micronucleus assay to RF are conflicting. Thus,
follow-up research is necessary.
2
FDA is currently working with government, industry, and
academic groups to ensure the proper follow-up to these
industry-funded research findings. Collaboration with the
Cellular Telecommunications Industry Association (CTIA) in
particular is expected to lead to FDA providing research
recommendations and scientific oversight of new CTIA-
funded research based on such recommendations.
Two other studies of interest have been reported recently in
the literature:
1
Two groups of 18 people were exposed to simulated
mobile phone signals under laboratory conditions while
211
PRELIMINARY
Additional Health and Safety Information
they performed cognitive function tests. There were no
changes in the subjects' ability to recall words, numbers,
or pictures, or in their spatial memory, but they were able
to make choices more quickly in one visual test when they
were exposed to simulated mobile phone signals. This
was the only change noted among more than 20 variables
compared.
3
2
In a study of 209 brain tumor cases and 425 matched
controls, there was no increased risk of brain tumors
associated with mobile phone use. When tumors did exist
in certain locations, however, they were more likely to be
on the side of the head where the mobile phone was
used.
Because this occurred in only a small number of cases,
the increased likelihood was too small to be statistically
significant.
4
In summary, we do not have enough information at this point
to assure the public that there are, or are not, any low incident
health problems associated with use of mobile phones. FDA
continues to work with all parties, including other federal
agencies and industry, to assure that research is undertaken
to provide the necessary answers to the outstanding
questions about the safety of mobile phones.
What is known about cases of human cancer that
have been reported in users of hand-held mobile
phones?
Some people who have used mobile phones have been
diagnosed with brain cancer. But it is important to understand
that this type of cancer also occurs among people who have
not used mobile phones. In fact, brain cancer occurs in the
212
PRELIMINARY
Additional Health and Safety Information
U.S. population at a rate of about 6 new cases per 100,000
people each year. At that rate, assuming 80 million users of
mobile phones (a number increasing at a rate of about 1
million per month), about 4800 cases of brain cancer would be
expected each year among those 80 million people, whether
or not they used their phones. Thus it is not possible to tell
whether any individual's cancer arose because of the phone,
or whether it would have happened anyway. A key question is
whether the risk of getting a particular form of cancer is
greater among people who use mobile phones than among
the rest of the population. One way to answer that question is
to compare the usage of mobile phones among people with
brain cancer with the use of mobile phones among
appropriately matched people without brain cancer. This is
called a case-control study. The current case-control study of
brain cancers by the National Cancer Institute, as well as the
follow-up research to be sponsored by industry, will begin to
generate this type of information.
What is FDA's role concerning the safety of
mobile phones?
Under the law, FDA does not review the safety of radiation-
emitting consumer products such as mobile phones before
marketing, as it does with new drugs or medical devices.
However, the agency has authority to take action if mobile
phones are shown to emit radiation at a level that is
hazardous to the user. In such a case, FDA could require the
manufacturers of mobile phones to notify users of the health
hazard and to repair, replace or recall the phones so that the
hazard no longer exists.
Although the existing scientific data do not justify FDA
regulatory actions at this time, FDA has urged the mobile
213
PRELIMINARY
Additional Health and Safety Information
phone industry to take a number of steps to assure public
safety. The agency has recommended that the industry:
•support needed research into possible biological effects
of RF of the type emitted by mobile phones
•design mobile phones in a way that minimizes any RF
exposure to the user that is not necessary for device
function
•cooperate in providing mobile phone users with the best
possible information on what is known about possible
effects of mobile phone use on human health
At the same time, FDA belongs to an interagency working
group of the federal agencies that have responsibility for
different aspects of mobile phone safety to ensure a
coordinated effort at the federal level. These agencies are:
•National Institute for Occupational Safety and Health
•Environmental Protection Agency
•Federal Communications Commission
•Occupational Health and Safety Administration
•National Telecommunications and Information
Administration
The National Institutes of Health also participates in this
group.
In the absence of conclusive information about
any possible risk, what can concerned
individuals do?
If there is a risk from these products—and at this point we do
not know that there is—it is probably very small. But if people
214
PRELIMINARY
Additional Health and Safety Information
are concerned about avoiding even potential risks, there are
simple steps they can take to do so. For example, time is a
key factor in how much exposure a person receives. Those
persons who spend long periods of time on their hand-held
mobile phones could consider holding lengthy conversations
on conventional phones and reserving the hand-held models
for shorter conversations or for situations when other types of
phones are not available.
People who must conduct extended conversations in their
cars every day could switch to a type of mobile phone that
places more distance between their bodies and the source of
the RF, since the exposure level drops off dramatically with
distance. For example, they could switch to:
•a mobile phone in which the antenna is located outside
the vehicle
•a hand-held phone with a built-in antenna connected to a
different antenna mounted on the outside of the car or
built into a separate package
•a headset with a remote antenna to a mobile phone
carried at the waist
Again, the scientific data do not demonstrate that mobile
phones are harmful. But if people are concerned about the
radio frequency energy from these products, taking the simple
precautions outlined above can reduce any possible risk.
Where can I find additional information?
For additional information, see the following Web sites:
Federal Communications Commission (FCC) RF Safety
Program (select “Information on Human Exposure to RF
215
PRELIMINARY
Additional Health and Safety Information
Fields from Cellular and PCS Radio Transmitters”):
http://www.fcc.gov/oet/rfsafety
World Health Organization (WHO) International
Commission on Non-Ionizing Radiation Protection (select Qs
& As):
http://www.who.int/emf
United Kingdom, National Radiological Protection Board:
http://www.nrpb.org.uk
Cellular Telecommunications Industry Association
(CTIA):
http://www.wow-com.com
U.S. Food and Drug Administration (FDA) Center for
Devices and Radiological Health:
http://www.fda.gov/cdrh/consumer/
1. Muscat et al. Epidemiological Study of Cellular Telephone Use
and Malignant Brain Tumors. In: State of the Science
Symposium;1999 June 20; Long Beach, California.
2. Tice et al. Tests of mobile phone signals for activity in
genotoxicity and other laboratory assays. In: Annual Meeting of
the Environmental Mutagen Society; March 29, 1999,
Washington, D.C.; and personal communication, unpublished
results.
3. Preece, AW, Iwi, G, Davies-Smith, A, Wesnes, K, Butler, S, Lim,
E, and Varey, A. Effect of a 915-MHz simulated mobile phone
signal on cognitive function in man. Int. J. Radiat. Biol., April 8,
1999.
4. Hardell, L, Nasman, A, Pahlson, A, Hallquist, A and Mild, KH.
Use of cellular telephones and the risk for brain tumors: a case-
control study. Int. J. Oncol., 15: 113-116, 1999.
ITC00-010
216
PRELIMINARY
Warranty
Warranty
Limited Warranty for Motorola Personal
Communications Products and Accessories
Purchased in the United States and Canada
I. What This Warranty Covers
Defects in materials and workmanship in the following new
“
Products
”
manufactured, sold or certified by Motorola, with
which this limited warranty is included in/on the package:
(a) wireless cellular telephones, pagers and two-way radios
that operate via “Personal Radio Service” (such as Family
Radio Service and General Mobile Radio Service), together
with software imbedded in any of these products, and
(b) subject to the following exceptions, accessories or
software sold for use with these products.
•Battery Exception. This limited warranty extends only to
batteries in which the fully-charged capacity falls below
80% of rated capacity and batteries that leak;
•Software Exceptions. This limited warranty extends only
to physical defects in the media (such as CD-ROM) that
tangibly embodies each copy of any software sold and/or
certified by Motorola for use with Products. Software that
is not tangibly embodied in media and that is purchased
separately from Products (such as software that is
downloaded from the internet) comes “as is” and
without warranty.
217
PRELIMINARY
Warranty
II. What the Period of Coverage Is
Subject to the following exceptions, one year from the date the
Products are purchased by the first end-user:
•90-Day Warranty Exception. The warranty is for 90 days
for: (a) any software tangibly embodied in media or
(b) any accessories for two-way radios that are covered
by this warranty, as described in Section I, above.
•Limited Lifetime Warranty Exception. The warranty is a
limited lifetime warranty for the lifetime of ownership by
the first end-user of the following products, only:
(a) decorative covers, including bezel, PhoneWrap™ or
case (any model); and (b) ear buds and boom headsets
that transmit mono sound through a wire connection (this
does not include ear buds or boom headsets that either
transmit stereo sound or that are wireless, or both).
•Repair/Replacement Exception. The warranty is for the
balance of the original warranty or for 90 days from the
date returned and delivered to the first end-user,
whichever is longer.
III. Who is Covered
This warranty extends to you only if you are the first end-user
purchaser.
IV. What We Will Do to Correct Warranty Problems
At no charge to you, we have the option to repair or replace
the Products that do not conform to the warranty, or to refund
the Products’ purchase price. We may use functionally
equivalent reconditioned/refurbished/pre-owned or new
Products or parts. No software updates are provided.
218
PRELIMINARY
Warranty
V. How to Get Warranty Service
PLEASE CALL US — DO NOT SHIP:
Accessories and software—call the number designated for
the product with which they are used.
You will receive instructions on how to ship the Products to
Motorola or our designated resource. If instructed to ship the
Products, you must ship them with freight, duties and
insurance prepaid. Regardless of where you are instructed to
return the Products, you must include: (a) a copy of your
receipt, bill of sale or other comparable proof of purchase;
(b) a written description of the problem; (c) the name of your
service provider (if this Product requires subscription service);
(d) the name and location of the installation facility (if
applicable) and, most importantly; (e) your address and
telephone number. If requested, you must also return all
detachable parts such as antennas, batteries and chargers.
RETAIN YOUR ORIGINAL PROOF OF PURCHASE.
For Products we ask you ship to us, we will ship repaired or
replacement Products at our expense for the freight and
insurance, but at your expense for any duties. If additional
information is needed, please contact us at the telephone
number listed above.
USA Canada
Cellular 1-800-331-6456 All Products
1-800-461-4575 Paging 1-800-548-9954
FRS Radios 1-800-353-2729 TTY (Text Telephone)
1-888-390-6456 TTY (Text Telephone)
1-888-390-6456
219
PRELIMINARY
Warranty
VI. What This Warranty Does Not Cover
• Products that are operated in combination with
ancillary or peripheral equipment or software not
furnished or otherwise certified by Motorola for use
with the Products (“ancillary equipment”), or any
damage to the Products or ancillary equipment as a
result of such use. Among other things, “ancillary
equipment” includes batteries, chargers, adaptors,
and power supplies not manufactured or supplied by
Motorola. Any of these voids the warranty.
•Someone other than Motorola (or its authorized service
centers) tests, adjusts, installs, maintains, alters,
modifies or services the Products in any way. Any of
these voids the warranty.
•Rechargeable batteries that: (a) are charged by other
than the Motorola-approved battery charger specified for
charging such batteries; (b) have any broken seals or
show evidence of tampering; (c) are used in equipment
other than the Product for which they are specified; or
(d) are charged and stored at temperatures greater than
60 degrees centigrade. Any of these voids the warranty.
•Products that have: (a) serial numbers or date tags that
have been removed, altered or obliterated; (b) board
serial numbers that do not match each other, or board
serial numbers that do not match the housing; or
(c) nonconforming or non-Motorola housings or parts.
Any of these voids the warranty.
220
PRELIMINARY
Warranty
•Defects or damage that result from: (a) use of the
Products in a manner that is not normal or customary;
(b) improper operation or misuse; (c) accident or neglect
such as dropping the Products onto hard surfaces;
(d) contact with water, rain, extreme humidity or heavy
perspiration; (e) contact with sand, dirt or the like; or
(f) contact with extreme heat, or spills of food or liquid.
•Physical damage to the surface of the Products,
including scratches, cracks or other damage to a display
screen, lens or other externally exposed parts.
•Failure of Products that is due primarily to any
communication service or signal you may subscribe to or
use with the Products.
•Coil cords that are stretched or that have any broken
modular tabs.
•Leased Products.
Flat-rate repair rates may apply to Products not covered by
this warranty. To obtain information about Products needing
repairs that are not covered by this warranty, please call the
telephone number previously listed. We will provide
information on repair availability, rates, methods of payment,
where to send the Products, etc.
221
PRELIMINARY
Warranty
VII. Some Other Limitations
This is Motorola’s complete warranty for the Products,
and states your exclusive remedies. This warranty is
given in lieu of all other express warranties. Implied
warranties, including without limitation, the implied
warranties of merchantability and fitness for a particular
purpose, are given only if specifically required by
applicable law. Otherwise, they are specifically excluded.
No warranty is made as to coverage, availability, or grade
of service provided by the Products, whether through a
service provider or otherwise.
No warranty is made that the software will meet your
requirements or will work in combination with any
hardware or applications software products provided by
third parties, that the operation of the software products
will be uninterrupted or error free, or that all defects in
the software products will be corrected.
In no event shall Motorola be liable, whether in contract
or tort (including negligence) for damages in excess of
the purchase price of the Product, or for any indirect,
incidental, special or consequential damages of any kind,
or loss of revenue or profits, loss of business, loss of
information or data, or other financial loss arising out of
or in connection with the ability or inability to use the
Products, to the full extent these damages may be
disclaimed by law.
222
PRELIMINARY
Warranty
VIII. Patent and Software Provisions
At Motorola’s expense, we will defend you, and pay costs and
damages that may be finally awarded against you, to the
extent that a lawsuit is based on a claim that the Products
directly infringe a United States patent. Our obligation is
conditioned on: (a) you notifying us promptly in writing when
you receive notice of the claim; (b) you giving us sole control
of the defense of the suit and all negotiations for its settlement
or compromise; and (c) should the Products become, or in
Motorola's opinion be likely to become, the subject of a claim
of infringement of a United States patent, you permit us, at our
option and expense, either to: procure for you the right to
continue using the Products; replace or modify them so that
they become non-infringing; or grant you a credit for such
Products, as depreciated, and accept their return. The
depreciation will be an equal amount per year over the lifetime
of the Products, as established by Motorola.
Motorola will have no liability to you with respect to any claim
of patent infringement that is based upon the combination of
the Products or parts furnished under this limited warranty
with ancillary equipment, as defined in VI., above.
This is Motorola’s entire liability with respect to
infringement of patents by the Products.
IX. State Law and Other Jurisdiction Rights
Some states and other jurisdictions do not allow the exclusion
or limitation of incidental or consequential damages, or
limitation on the length of an implied warranty, so the above
limitations or exclusions may not apply to you.
223
PRELIMINARY
Warranty
This warranty gives you specific legal rights, and you may also
have other rights, which vary from jurisdiction to jurisdiction.
To obtain information on Motorola Personal Communications
Products, including warranty service, accessories and
optional Extended Warranties on selected Products, please
call:
Accessories and software—call the telephone number
designated above for the product with which they are used.
DO NOT SHIP PRODUCTS TO THESE ADDRESSES —
INSTEAD PLEASE CALL.
To correspond with Motorola about Products, please write us
at:
http://www.motorola.com
or at:
ITC01-078
USA Canada
Cellular 1-800-331-6456 All Products
1-800-461-4575 Paging 1-800-548-9954
FRS Radios 1-800-353-2729 TTY (Text Telephone)
1-888-390-6456 TTY (Text Telephone)
1-888-390-6456
In the USA: In Canada:
Motorola, Inc. Motorola Canada Limited
600 North U.S. Highway 45 5875 Whittle Road
Libertyville, IL 60048 Mississauga, ON L4Z 2H4
224
PRELIMINARY
Product Registration
Online Product Registration:
http://www.motorola.com/warranty
Product registration is an important step toward enjoying your
new Motorola product. Registering helps us facilitate warranty
service, and permits us to contact you should your product
require an update or other service. Registration is for U.S.
residents only and is not required for warranty coverage.
Please retain your original dated sales receipt for your
records. For warranty service of your Motorola Personal
Communications Product you will need to provide a copy of
your dated sales receipt to confirm warranty status.
Thank you for choosing a Motorola product.
Export Law
Assurances
This product is controlled under the export regulations of the
United States of America and Canada. The Governments of
the United States of America and Canada may restrict the
exportation or re-exportation of this product to certain
destinations. For further information contact the U.S.
Department of Commerce or the Canadian Department of
Foreign Affairs and International Trade.
225
PRELIMINARY
Index
Index
A
accessories
optional 11, 92, 147,
176, 178, 182
standard 19
accessory connector port
1
active line indicator
defined 27
illustration 26
Add Digits
feature 71
alert
creating 135–140
defined 133
downloading a sound
file 152–155
reminders, turning on/off
141
selecting 134
setting sound file as ring
tone 108,
154–155
storing a sound file
107–108,
154–155
alert tone
deleting from text
message 113
inserting in text
message 112
analog signal indicator
defined 26
illustration 26
animation 67
deleting 82–85
downloading 152–155
renaming 82–85
screen saver, setting
84, 107, 153,
175–176
screensaver, adjusting
175–176
storing 106–107, 153
viewing 82–85
wallpaper, adjusting
174–175
wallpaper, setting 84,
107, 153,
174–175
antenna 23
application, locking 63
appointments.
See
datebook
226
PRELIMINARY
Index
Attach Number
feature 36,
71
auto PIN dial 65
automatic redial
turning on/off 66
using 32–33
B
backlight 66
banner text 65
battery
car kit charger time 180
charging 20–21
extending battery life
28, 30–31, 66,
67, 199
installing 19–20
level indicator 21, 26,
27
meter 61
blackjack 165–166
block cursor, defined 46
browse text mode 47
browser alerts 58
browser.
See
micro-browser
C
calculator 161–163
calendar.
See
datebook
call
adding digits after phone
number 71
alert, creating 135–140
alert, selecting 134
answer options 62
answering 24
call waiting 39
calling card 37
canceling 34
data call 185–187
datebook, opening 40
deleting 70–71
dialed calls list 38, 40,
70–71
dialing 23
dialing a recent call
70–71
emergency number 34
ending 24
fax call 185–187
ignoring 34
in-call timer 62
incoming call type,
setting 186–187
message center,
accessing 40
muting 40
placing 23
prefix digits, inserting
36
227
PRELIMINARY
Index
call (continued)
received calls list 38,
40, 70–71
receiving 24
recent calls 70–71
restricting 191–192
ring style, setting 133
sending 23
speakerphone,
activating 40
storing 70–71
terminating 34
three-way call 39
timing 72–73
unanswered call 33
voice dial 38
Call Failed
message 32
call timers
described 72–73
resetting 73
viewing 73
call waiting 39
caller ID 33
calling card call 37
calling line identification.
See
caller ID
car kit
automatic answer 179
automatic hands-free
179
charger time 180
power-off delay 180
chat 95–99
clock 26
codes
changing 188–189
default 23, 188
if you forget a
code/password
189
computer
connecting to phone
182–185
synchronizing data 80,
182
contrast, display 67
convertible cover 21–22
currency converter 163
cursor 45–46
customer service, calling
57
customizing the menu 173
D
data call
connecting to external
device 182–185
incoming call format,
setting 186–187
receiving 186–187
sending 185
date, setting 65
228
PRELIMINARY
Index
datebook
adding an event 88
alarm 89
calendar 86
changing event
information 89
copying an event 89
day view 87
deleting an event 90
event reminders, turning
on/off 141
event view 88
icon 26
reminders 89
week view 86
Datebook Menu
86, 87, 88
deleting a call 70–71
dialed calls list 38, 40,
70–71
dialing a number 23
Dialing Menu
36, 72
digital signal indicator
defined 26
illustration 26
display
animation 67
backlight 66
banner text 65
contrast 67
described 25–27
greeting 64
idle display 25
display (continued)
illustration 26
language 67
zoom setting 27, 66
drafts folder 59
DTMF tones 40, 67, 71,
198
E
earpiece
illustration 1
volume, adjusting 29
email 115–132
deleting 120–123
inbox setup 115–119
locking 120–123
personal folders
130–132
quick note, inserting
127
reading 120–123
receiving 119–120
sending 123–127
status 129
email address, storing in
phonebook 75–77
email, sending 78–79,
108–110
emergency number 34
end key
functions 1, 24
menu functions 41
229
PRELIMINARY
Index
ending a call 24
Enter Unlock Code
message 189, 191
Entry Method
menu 52
event alert 134
exchange rate, calculating
163
external device
connecting to phone
182–185
synchronizing data 80,
182
external display 29
F
factory settings, resetting
67–68
falling numbers 166–167
fax call
connecting to external
device 182–185
incoming call format,
setting 186–187
receiving 186–187
sending 185
flashing cursor, defined 45
flip
external display and 29
open to answer call 62
turning the phone on 22
FM Stereo Radio Headset
57, 92–94
4-way navigation key 1,
29, 41
G
games 164–172
greeting, display 64
H
hands-free mode
automatic answer 179
automatic call routing
179
charger time 180
defined 178
power-off delay 180
speakerphone,
activating 40
headset
automatic answer 179
FM Stereo Radio
Headset 57,
92–94
headset jack 1
I
idle display, defined 25
ignoring a call 34
230
PRELIMINARY
Index
in use indicator
defined 26
illustration 26
inbox, email 115–119
inbox, text message 102
in-call timer 62
incoming call
canceling 34
ignoring 34
terminating 34
type, setting 186–187
Incoming Call
message
33
indicators
active line 26, 27
battery level 21, 26, 27
digital/analog signal 26
in use 26
loud ring style 27, 133
menu 26, 27
message waiting 26,
27, 103, 119, 120
missed call 33
ring and vibrate ring
style 27, 133
ring style 26, 27, 133
roam 26
signal strength 26
silent alert 27
silent ring style 27, 133
soft ring style 27, 133
indicators (continued)
vibrate ring style 27,
133
voice message waiting
26, 27, 101
voice name 74
iTAP software 52–55
J
J2ME applications
156–160
joystick 1, 29, 41
K
key
end 1, 24, 41
4-way navigation 1, 29,
41
left soft key 1, 25, 41,
173
menu 1, 11, 27, 41
power 1, 22
right soft key 1, 25, 41,
173
send 1, 23, 24, 70
voice 1, 77, 145
volume control 1, 29
keypad
answering calls 62
volume, setting 135
231
PRELIMINARY
Index
L
language, setting 67
Last Calls Menu
71
left soft key
customizing 173
functions 1, 25, 41
lock
applications 63
phone 190–191
voice notes 149
lock application feature 63
loud ring style indicator
27, 133
Low Battery
message 27
M
making a call 23
master clear 68
master reset 67
Memory is Full!
message
96, 103, 120
Memory is Low!
message
120
menu
Browser Menu
152
customizing 173
Datebook Menu
86, 87,
88
Dialing Menu
36, 72
Email Msg Menu
121–123
menu (continued)
entering text 44–46,
47–55
Entry Method
menu 52
features 56–69
icons, described 25
language, setting 67
Last Calls Menu
71
lists 43
locking applications 63
My Tones Menu
139, 140
navigating 11, 29, 41
Phonebook Menu
74
Quick Note Menu
111
rearranging features
173
scroll feature 66
Text Msg Menu
104–105
using features 11,
43–46
Voice Notes Menu
146,
147, 148
menu indicator
defined 27
illustration 26
menu key 1, 11, 27, 41
message
alert tone, deleting 113
alert tone, inserting 112
animation, deleting 113
animation, inserting 112
232
PRELIMINARY
Index
message (continued)
animation, storing
105–107
browser alert 58
chat 95–99
chat name in message
99
deleting, email 120–123
deleting, text 103–105
dialing number from 36
drafts folder 59
email 115–132
icon 26
image, deleting 113
image, inserting
111–112
image, storing 105–108
inbox setup, email
115–119
inbox setup, text
message 102
locking, email 120–123
locking, text 103–105
outbox 59, 113, 129
picture, deleting 113
picture, inserting 112
picture, storing
105–107
quick note 110–111
reading, email 120–123
reading, text 103–105
message (continued)
receiving, email
119–120
receiving, text 103
reminders, receiving
101, 103, 119
reminders, turning on/off
141
sending 36, 108–110
sending email 123–127
sound, deleting 113
sound, inserting
111–112
sound, storing 105–108
status 113, 129
text 102–114
voicemail 100–101
message waiting indicator
defined 27
displayed 103, 119
flashing 120
illustration 26
micro-browser
browser alerts 58
icon 26
image, downloading
152–155
J2ME applications
156–160
sound, downloading
152–155
using 151–152
233
PRELIMINARY
Index
microphone 1
mindblaster 167–169
missed call indicator 33
Missed Call
message 33
missed call, dialing 38
muting a call 40
my telephone number 24,
40, 61
my tones 135–140
My Tones Menu
139, 140
N
network settings 68
notepad
defined 71
entering digits 71
retrieving digits 71
number, viewing your own
24, 61
numeric text mode 47
O
one-touch dial
defined 35
using 35
voicemail number 35
optional accessory,
defined 11
optional feature, defined
11
outbox 59, 113, 129
P
paddleball 169
passwords.
See
codes
pause character 37
phone
active line indicator 27
answer options 62
codes 188–189
connecting to external
device 182–185
erase user-entered
information 68
feature specifications
40, 61
flip 22
information 40
locking 190–191
reset all options 67
security code 188
specifications 40, 61
turning on/off 22
unlock code 23, 188,
189
unlocking 23, 190–191
voice dial 38
phone number
active line indicator 27
active phone line,
changing 61
adding digits after 71
attaching to prefix digits
36
234
PRELIMINARY
Index
phone number (continued)
attaching two numbers
71
redialing 32
sending text message to
36
storing in phonebook
75–77
viewing your own 24,
40, 61
voice dial 38
phonebook
attaching two numbers
71
deleting an entry 79
dialing a number 78–79
editing an entry 79
email address 74
entry name 74
fields 74
icon 26
number type indicator
74
one-touch dial 35
phone number 74
prefix digits, inserting
36
ringer ID,
activating/deactiv
ating 134–135
ringer ID, defined 76,
134
phonebook (continued)
ringer ID, setting 76
sending an email 78–79
sorting entries 80
speed dial number 74,
76
speed dial number,
defined 35
speed dial, using 35
storing an entry 75–77
synchronizing entries
80, 182
voice name entry 77–78
voice name indicator 74
Phonebook Menu
74
deleting 82–85
downloading 152–155
renaming 82–85
screen saver, adjusting
175–176
screen saver, setting
84, 107, 153,
175–176
storing 106–107, 153
viewing 82–85
wallpaper, adjusting
174–175
wallpaper, setting 84,
107, 153,
174–175
235
PRELIMINARY
Index
PIN code, dialing
automatically 65
power key 1, 22
predictive text entry 52–55
Q
quick dial
changing number(s) 65
using 57
quick note 110–111
defined 102
sending 127
R
radio 92–94
received calls list 38, 40,
70–71
receiving a call 24
recent calls 70–71
redial
automatic redial 32–33
busy number 32
reminders
datebook 89
defined 141
text message 103, 119
turning on/off 141
voicemail message 101
restricting calls 191–192
reversal 170–171
right soft key
customizing 173
functions 1, 25, 41
ring alert
selecting 134
ring and vibrate ring style
indicator 27, 133
ring style
customizing 134–135
defined 133
indicators 27, 133
setting 133
ring style indicator
defined 27, 133
illustration 26
ring tone, setting sound file
as 108, 154–155
ringer
volume, adjusting 29
volume, setting 135
ringer ID
activating/deactivating
134–135
defined 76, 134
listed in phonebook
entry 74
setting for phonebook
entry 76
roam indicator
defined 26
illustration 26
236
PRELIMINARY
Index
S
screen saver
adjusting 175–176
setting 84, 107, 153,
175–176
scroll feature 66
security code
changing 188–189
send key 1, 23, 24, 70
sending a call 23
short message service.
See
text message
shortcuts
creating 142–143
standard 142
using 144
signal strength indicator
defined 26
illustration 26
silent alert indicator 27
silent ring style indicator
27, 133
SMS.
See
text message
soft keys
customizing 173
functions 25, 41
illustration 1
labels 26
soft ring style indicator 27,
133
sound
deleting from text
message 113
downloading 152–155
inserting in text
message 112
setting as ring tone 108,
154–155
storing a sound file
107–108,
154–155
speakerphone, activating
40
speed dial
changing number 76
number, defined 35
sorting phonebook
entries by 80
using 35
standby time
defined 28
increasing 31
status light 1, 28, 66
storing a call 70–71
symbol text mode 51–52
symbols, entering 51–52
synchronizing data 80,
182
237
PRELIMINARY
Index
T
tap method text entry
48–50
telephone number, viewing
your own 24, 61
text
block cursor 46
browse mode 47
character chart 50
entering from keypad
47–55
entry mode, changing
47
flashing cursor 45
iTAP software predictive
text entry 52–55
numeric mode 47
symbol chart 51
symbol mode 51–52
tap method 48–50
text message
alert tone, deleting 113
alert tone, inserting 112
animation, deleting 113
animation, inserting 112
animation, storing
105–107
chat 95–99
chat name in message
99
defined 102
deleting 103–105
dialing number from 36
drafts folder 59
image, deleting 113
image, inserting
111–112
image, storing 105–108
inbox setup 102
locking 103–105
outbox 59
picture, deleting 113
picture, inserting 112
picture, storing
105–107
quick note 110–111
reading 103–105
receiving 103
reminders 103, 119
sending 36, 108–110
sound, deleting 113
sound, inserting
111–112
sound, storing 105–108
status 113
text mode, changing 47
three-way call 39
time, setting 65
timers
described 72–73
resetting 73
viewing 73
travel charger, using 21
238
PRELIMINARY
Index
TrueSync 80, 182
TTY device 176–178
U
unlock
phone 190–191
unlock code 189
bypassing 189
changing 188–189
entering 23, 190, 191
V
vibrate alert
selecting 134
vibrate ring style
indicator 27, 133
setting 133
video poker 171–172
voice dial
dialing a number 38, 79
recording voice name
77–78
sending an email 79
voice key
dialing a number 38
functions 1
recording a voice name
77
recording a voice note
145
voice message waiting
indicator 26, 27,
101
voice name
defined 77
phonebook indicator 74
recording 77–78
voice notes 145–150
Voice Notes Menu
146,
147
voice shortcut
creating 142–143
defined 142
using 144
voicemail
dialing with one-touch
dial 35
listening to message(s)
101
number, storing 100
receiving 101
reminders, turning on/off
141
voice message waiting
indicator, turning
off 101
volume
earpiece 29
keypad 135
ringer 29, 135
volume keys 1, 29
239
PRELIMINARY
Index
W
wait character 37
wallpaper
adjusting 174–175
setting 84, 107, 153,
174–175
warranty 216–223
Web pages 151–152
Z
zoom setting 27, 66
U.S. patent Re. 34,976
240
PRELIMINARY
Index
✂
PRELIMINARY
241
Wireless Phone Safety
Tips
“Safety is your most important call!”
Your Motorola wireless telephone gives you
the powerful ability to communicate by voice—
almost anywhere, anytime, wherever wireless
phone service is available and safe conditions allow.
But an important responsibility accompanies the
benefits of wireless phones, one that every user
must uphold.
When driving a car, driving is your first
responsibility. If you find it necessary to use your
wireless phone while behind the wheel of a car,
practice good common sense and remember the
following tips:
1 Get to know your Motorola wireless phone and its
features such as speed dial and redial. If available,
these features help you to place your call without taking
your attention off the road.
✂
PRELIMINARY
242
2 When available, use a hands-free device. If possible,
add an additional layer of convenience to your wireless
phone with one of the many Motorola Original™ hands-
free accessories available today.
3 Position your wireless phone within easy reach. Be
able to access your wireless phone without removing
your eyes from the road. If you receive an incoming call
at an inconvenient time, if possible, let your voice mail
answer it for you.
4 Let the person you are speaking with know you are
driving; if necessary, suspend the call in heavy
traffic or hazardous weather conditions. Rain, sleet,
snow, ice, and even heavy traffic can be hazardous.
5 If you receive an incoming call at an inconvenient
time do not take notes or look up phone numbers
while driving. Jotting down a “to do” list or going
through your address book takes attention away from
your primary responsibility—driving safely.
6 Dial sensibly and assess the traffic; if possible,
place calls when you are not moving or before
pulling into traffic. Try to plan calls when your car will
be stationary. If you need to make a call while moving,
dial only a few numbers, check the road and your
mirrors, then continue.
7 Do not engage in stressful or emotional
conversations that may be distracting. Make people
you are talking with aware you are driving and suspend
conversations which have the potential to divert your
attention away from the road.
✂
PRELIMINARY
243
8 Use your wireless phone to call for help. Dial 9-1-1 or
other local emergency number in the case of fire, traffic
accident or medical emergencies.*
9 Use your wireless phone to help others in
emergencies. If you see an auto accident, crime in
progress or other serious emergency where lives are in
danger, call 9-1-1 or other local emergency number, as
you would want others to do for you.*
10 Call roadside assistance or a special
non-emergency wireless assistance number when
necessary. If you see a broken-down vehicle posing no
serious hazard, a broken traffic signal, a minor traffic
accident where no one appears injured, or a vehicle you
know to be stolen, call roadside assistance or other
special non-emergency wireless number.*
* Wherever wireless phone service is available.
✂
PRELIMINARY
244
Check the laws and regulations on the use of
wireless telephones and their accessories in the
areas where you drive. Always obey them. The
use of these devices may be prohibited or
restricted in certain areas.
For more information,
please call
1-888-901-SAFE
or visit the
CTIA Web site at
www.wow-com.com™
ITC00-011
