Motorola Mobility T56DD1 Portable Cellular/ PCS GSM Transceiver User Manual UG C330 GSM
Motorola Mobility LLC Portable Cellular/ PCS GSM Transceiver UG C330 GSM
Exhibit 8 Preliminary Users Manual
APPLICANT: MOTOROLA, INC. FCC ID: IHDT56DD1
EXHIBIT 8
INSTRUCTION MANUAL
A preliminary draft copy of the Users Manual follows:
1
PRELIMINARY
Welcome
Bottom of phone:
EarpieceInternal Antenna
USB Connector
Insert data cable.
Right Soft Key
Perform right display
prompt functions.
Menu Key
Open a menu when
you see
G
in the
display.
Power/End Key
Press and hold to
turn phone
on and off.
Press and release to
end phone calls, exit
menu system.
Send/Answer Key
Make and answer
calls; press in idle to
list recently dialed
calls.
Navigation Key
Scroll through lists,
set volume.
Left Soft Key
Perform left display
prompt functions.
Microphone Headset Connector
Power Connector
Insert charger.
Volume Keys
Adjust earpiece and
ringer volume.
Smart Key
Select menu items,
send and end calls.
UG.E380.GSM.book Page 1 Thursday, June 12, 2003 8:42 AM
2
PRELIMINARY
Personal Communications Sector
600 North U.S. Highway 45
Libertyville, Illinois 60048
1-800-331-6456 (United States)
1-888-390-6456 (TTY/TDD United States)
1-800-461-4575 (Canada)
www.motorola.com
(United States)
www.motorola.ca
(Canada)
MOTOROLA and the Stylized M Logo are registered in the US Patent &
Trademark Office. All other product or service names are the property of
their respective owners.
© Motorola, Inc. 2003.
Software Copyright Notice
The Motorola products described in this manual may include copyrighted
Motorola and third party software stored in semiconductor memories or
other media. Laws in the United States and other countries preserve for
Motorola and third party software providers certain exclusive rights for
copyrighted software, such as the exclusive rights to distribute or
reproduce the copyrighted software. Accordingly, any copyrighted
software contained in the Motorola products may not be modified,
reverse-engineered, distributed, or reproduced in any manner to the
extent allowed by law. Furthermore, the purchase of the Motorola
products shall not be deemed to grant either directly or by implication,
estoppel, or otherwise, any license under the copyrights, patents, or
patent applications of Motorola or any third party software provider,
except for the normal, non-exclusive, royalty-free license to use that
arises by operation of law in the sale of a product.
Manual number: 6809461A46-O
Cover number: 8988485L49-O
UG.E380.GSM.book Page 2 Thursday, June 12, 2003 8:42 AM
3
PRELIMINARY
Contents
Getting Started
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
What’s in the Box?. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
About This Guide. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Installing the Battery . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Charging the Battery . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Battery Use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Changing Your SIM Card. . . . . . . . . . . . . . . . . . . . . . . . 16
Changing Your Phone’s Lens . . . . . . . . . . . . . . . . . . . . 18
Turning Your Phone On . . . . . . . . . . . . . . . . . . . . . . . . . 20
Adjusting the Volume. . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Making a Call. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Answering a Call . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Viewing Your Phone Number . . . . . . . . . . . . . . . . . . . . 22
Learning to Use Your Phone
. . . . . . . . . . . . . . . . . . . . . 23
Using the Display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Using the 4-Way Navigation Key . . . . . . . . . . . . . . . . . . 27
Using Menus . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Entering Text . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
Choosing a Text Entry Method . . . . . . . . . . . . . . . . . . . 38
Using Your Phone While it is Closed . . . . . . . . . . . . . . . 39
Using the Smart Key . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
Locking and Unlocking Your Phone. . . . . . . . . . . . . . . . 42
Changing a Code or Password . . . . . . . . . . . . . . . . . . . 43
If You Forget a Code or Password. . . . . . . . . . . . . . . . . 44
Locking and Unlocking the Keypad . . . . . . . . . . . . . . . . 44
Setting Up Your Phone
. . . . . . . . . . . . . . . . . . . . . . . . . . 45
Storing Your Name and Phone Number . . . . . . . . . . . . 45
Setting the Time and Date. . . . . . . . . . . . . . . . . . . . . . . 45
UG.E380.GSM.book Page 3 Thursday, June 12, 2003 8:42 AM
4
PRELIMINARY
Setting an Alert Style . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
Setting Answer Options . . . . . . . . . . . . . . . . . . . . . . . . . 47
Activating Club Lights . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
Setting a Wallpaper Image . . . . . . . . . . . . . . . . . . . . . . . 48
Selecting a Screen Saver . . . . . . . . . . . . . . . . . . . . . . . . 49
Setting Display Color . . . . . . . . . . . . . . . . . . . . . . . . . . . 50
Setting Display Contrast . . . . . . . . . . . . . . . . . . . . . . . . . 50
Adjusting the Backlight . . . . . . . . . . . . . . . . . . . . . . . . . . 50
Zooming In and Out . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50
Conserving Battery Power . . . . . . . . . . . . . . . . . . . . . . . 51
Calling Features
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52
Changing the Active Line . . . . . . . . . . . . . . . . . . . . . . . . 52
Redialing a Number . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52
Using Caller ID . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53
Canceling an Incoming Call . . . . . . . . . . . . . . . . . . . . . . 53
Turning Off a Call Alert . . . . . . . . . . . . . . . . . . . . . . . . . . 54
Calling an Emergency Number. . . . . . . . . . . . . . . . . . . . 54
Dialing International Numbers . . . . . . . . . . . . . . . . . . . . 55
Viewing the Received Calls or Dialed Calls List . . . . . . . 55
Returning an Unanswered Call . . . . . . . . . . . . . . . . . . . . 57
Using the Notepad . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58
Attaching a Number . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58
Calling With Speed Dial . . . . . . . . . . . . . . . . . . . . . . . . . 59
Calling With 1-Touch Dial . . . . . . . . . . . . . . . . . . . . . . . . 59
Using Voicemail . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59
Using Call Waiting. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61
Putting a Call on Hold . . . . . . . . . . . . . . . . . . . . . . . . . . . 62
Transferring a Call. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 62
Phone Features
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 64
Main Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 64
Feature Quick Reference . . . . . . . . . . . . . . . . . . . . . . . . 66
UG.E380.GSM.book Page 4 Thursday, June 12, 2003 8:42 AM
5
PRELIMINARY
Specific Absorption Rate Data
. . . . . . . . . . . . . . . . . . . . 79
Additional Health and Safety Information
. . . . . . . . . . . 81
Warranty
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 89
Product Registration
. . . . . . . . . . . . . . . . . . . . . . . . . . . . 94
Export Law Assurances
. . . . . . . . . . . . . . . . . . . . . . . . . 94
RF Energy Interference
. . . . . . . . . . . . . . . . . . . . . . . . . . 94
Index
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 95
Wireless Phone Safety Tips
. . . . . . . . . . . . . . . . . . . . . 103
UG.E380.GSM.book Page 5 Thursday, June 12, 2003 8:42 AM
6
PRELIMINARY
Safety and General Information
IMPORTANT INFORMATION ON SAFE AND EFFICIENT OPERATION.
READ THIS INFORMATION BEFORE USING YOUR PHONE.
The information provided in this document supersedes the general safety
information in user guides published prior to December 1, 2002.
Exposure To Radio Frequency (RF) Energy
Your phone contains a transmitter and a receiver. When it is ON, it
receives and transmits RF energy. When you communicate with your
phone, the system handling your call controls the power level at which
your phone transmits.
Your Motorola phone is designed to comply with local regulatory
requirements in your country concerning exposure of human beings to RF
energy.
Operational Precautions
To assure optimal phone performance and make sure human exposure to
RF energy is within the guidelines set forth in the relevant standards,
always adhere to the following procedures.
External Antenna Care
Use only the supplied or Motorola-approved replacement antenna.
Unauthorized antennas, modifications, or attachments could damage the
phone.
Do NOT hold the external antenna when the phone is IN USE. Holding
the external antenna affects call quality and may cause the phone to
operate at a higher power level than needed. In addition, use of
unauthorized antennas may result in non-compliance with the local
regulatory requirements in your country.
UG.E380.GSM.book Page 6 Thursday, June 12, 2003 8:42 AM
7
PRELIMINARY
Phone Operation
When placing or receiving a phone call, hold your phone as you would a
wireline telephone.
Body-Worn Operation
To maintain compliance with RF energy exposure guidelines, if you wear
a phone on your body when transmitting, always place the phone in a
Motorola-supplied or approved clip, holder, holster, case, or body harness
for this phone, if available. Use of accessories not approved by Motorola
may exceed RF energy exposure guidelines. If you do not use one of the
body-worn accessories approved or supplied by Motorola, and are not
using the phone held in the normal use position, ensure the phone and its
antenna are at least 1 inch (2.5 centimeters) from your body when
transmitting.
Data Operation
When using any data feature of the phone, with or without an accessory
cable, position the phone and its antenna at least 1 inch (2.5 centimeters)
from your body.
Approved Accessories
Use of accessories not approved by Motorola, including but not limited to
batteries and antenna, may cause your phone to exceed RF energy
exposure guidelines. For a list of approved Motorola accessories, visit our
website at
www.Motorola.com
.
RF Energy Interference/Compatibility
Note:
Nearly every electronic device is susceptible to RF energy
interference from external sources if inadequately shielded, designed, or
otherwise configured for RF energy compatibility. In some circumstances
your phone may cause interference.
Facilities
Turn off your phone in any facility where posted notices instruct you to do
so. These facilities may include hospitals or health care facilities that may
be using equipment that is sensitive to external RF energy.
UG.E380.GSM.book Page 7 Thursday, June 12, 2003 8:42 AM
8
PRELIMINARY
Aircraft
When instructed to do so, turn off your phone when on board an aircraft.
Any use of a phone must be in accordance with applicable regulations per
airline crew instructions.
Medical Devices
Pacemakers
Pacemaker manufacturers recommend that a minimum separation of
6 inches (15 centimeters) be maintained between a handheld wireless
phone and a pacemaker.
Persons with pacemakers should:
•
ALWAYS keep the phone more than 6 inches (15 centimeters) from
your pacemaker when the phone is turned ON.
•
NOT carry the phone in the breast pocket.
•
Use the ear opposite the pacemaker to minimize the potential for
interference.
•
Turn OFF the phone immediately if you have any reason to suspect
that interference is taking place.
Hearing Aids
Some digital wireless phones may interfere with some hearing aids. In the
event of such interference, you may want to consult your hearing aid
manufacturer to discuss alternatives.
Other Medical Devices
If you use any other personal medical device, consult the manufacturer of
your device to determine if it is adequately shielded from RF energy. Your
physician may be able to assist you in obtaining this information.
Use While Driving
Check the laws and regulations on the use of phones in the area where
you drive. Always obey them.
UG.E380.GSM.book Page 8 Thursday, June 12, 2003 8:42 AM
9
PRELIMINARY
When using your phone while driving, please:
•
Give full attention to driving and to the road.
•
Use hands-free operation, if available.
•
Pull off the road and park before making or answering a call if
driving conditions so require.
Responsible driving best practices may be found in the “Wireless Phone
Safety Tips” at the end of this manual and at the Motorola website:
www.Motorola.com/callsmart
.
Operational Warnings
For Vehicles With an Air Bag
Do not place a phone in the area over an air bag or in the air bag
deployment area. Air bags inflate with great force. If a phone is placed in
the air bag deployment area and the air bag inflates, the phone may be
propelled with great force and cause serious injury to occupants of the
vehicle.
Potentially Explosive Atmospheres
Turn off your phone prior to entering any area with a potentially explosive
atmosphere, unless it is a phone type especially qualified for use in such
areas and certified as “Intrinsically Safe.” Do not remove, install, or
charge batteries in such areas. Sparks in a potentially explosive
atmosphere can cause an explosion or fire resulting in bodily injury or
even death.
Note:
The areas with potentially explosive atmospheres referred to above
include fueling areas such as below decks on boats, fuel or chemical
transfer or storage facilities, areas where the air contains chemicals or
particles, such as grain, dust, or metal powders. Areas with potentially
explosive atmospheres are often but not always posted.
Blasting Caps and Areas
To avoid possible interference with blasting operations, turn OFF your
phone when you are near electrical blasting caps, in a blasting area, or in
UG.E380.GSM.book Page 9 Thursday, June 12, 2003 8:42 AM
10
PRELIMINARY
areas posted “Turn off electronic devices.” Obey all signs and
instructions.
Batteries
Batteries can cause property damage and/or bodily injury such as burns if
a conductive material such as jewelry, keys, or beaded chains touch
exposed terminals. The conductive material may complete an electrical
circuit (short circuit) and become quite hot. Exercise care in handling any
charged battery, particularly when placing it inside a pocket, purse, or
other container with metal objects.
Use only Motorola original batteries
and chargers.
Your battery or phone may contain symbols, defined as follows:
Seizures/Blackouts
Some people may be susceptible to epileptic seizures or blackouts when
exposed to blinking lights, such as when watching television or playing
video games. These seizures or blackouts may occur even if a person
never had a previous seizure or blackout.
If you have experienced seizures or blackouts, or if you have a family
history of such occurrences, please consult with your doctor before
Symbol Definition
Important safety information will follow.
Your battery or phone should not be disposed of in a
fire.
Your battery or phone may require recycling in
accordance with local laws. Contact your local
regulatory authorities for more information.
Your battery or phone should not be thrown in the
trash.
Your phone contains an internal lithium ion battery.
LiIon BATT
UG.E380.GSM.book Page 10 Thursday, June 12, 2003 8:42 AM
11
PRELIMINARY
playing video games on your phone or enabling a blinking-lights feature
on your phone. (The blinking-light feature is not available on all products.)
Parents should monitor their children's use of video game or other
features that incorporate blinking lights on the phones. All persons should
discontinue use and consult a doctor if any of the following symptoms
occur: convulsion, eye or muscle twitching, loss of awareness, involuntary
movements, or disorientation.
To limit the likelihood of such symptoms, please take the following safety
precautions:
•
Do not play or use a blinking-lights feature if you are tired or need
sleep.
•
Take a minimum of a 15-minute break hourly.
•
Play in a room in which all lights are on.
•
Play at the farthest distance possible from the screen.
Repetitive Motion Injuries
When you play games on your phone, you may experience occasional
discomfort in your hands, arms, shoulders, neck, or other parts of your
body. Follow these instructions to avoid problems such as tendonitis,
carpal tunnel syndrome, or other musculoskeletal disorders:
•
Take a minimum 15-minute break every hour of game playing.
•
If your hands, wrists, or arms become tired or sore while playing,
stop and rest for several hours before playing again.
•
If you continue to have sore hands, wrists, or arms during or after
play, stop playing and see a doctor.
UG.E380.GSM.book Page 11 Thursday, June 12, 2003 8:42 AM
12
PRELIMINARY
Getting Started
Getting Started
What’s in the Box?
Your digital wireless phone typically comes with a
battery and a charger. Other accessory options can
customize your phone for maximum performance and
portability.
To purchase Motorola Original™ accessories, contact the
Motorola Customer Call Center at 1-800-331-6456 in the
United States or 1-800-461-4575 in Canada.
About This Guide
This user guide describes how to use your Motorola
wireless phone.
To obtain the reference guide for your phone, or another
copy of this user guide, see the Motorola Web site at:
http://motorola.com/consumer/manuals
or contact the Motorola Customer Call Center at 1-800-
331-6456 in the United States or 1-800-461-4575 in
Canada.
Note:
A reference guide for your phone is also
available that describes your phone’s features
in more detail.
UG.E380.GSM.book Page 12 Thursday, June 12, 2003 8:42 AM
13
PRELIMINARY
Getting Started
Optional Features
This label identifies an optional network, SIM
card, or subscription-dependent feature that
may not be offered by all service providers in
all geographical areas. Contact your service
provider for more information.
Optional Accessories
This label identifies a feature that requires an
optional Motorola Original™ accessory.
Installing the Battery
You must install and charge the battery to use your phone.
Your phone is designed to be used only with
Motorola Original batteries and accessories. We
recommend that you store batteries in their
protective cases when not in use.
Action
1
Remove the battery from its protective clear
plastic case, if necessary.
2
Press the cover
release button.
3
Slide the phone’s
back cover down,
then lift it off.
Cover release button
2
3
UG.E380.GSM.book Page 13 Thursday, June 12, 2003 8:42 AM
14
PRELIMINARY
Getting Started
Charging the Battery
New batteries are partially charged. Before you can use
your phone, you need to install and charge the battery.
Some batteries perform best after several full charge/
discharge cycles.
Caution:
If the battery is fully discharged, your phone may
not display
Charging
for up to 1 minute after inserting the
4
Insert the battery
with printed
arrows and two
tabs at the top of
the battery
compartment.
5
Push down until
the battery inserts
at the bottom.
6
Set the back cover
on the phone, then
slide it up to lock it.
Action
45
6
UG.E380.GSM.book Page 14 Thursday, June 12, 2003 8:42 AM
15
PRELIMINARY
Getting Started
charger.
Do not
attempt to force the charger further in if
you do not see an immediate response.
When you charge the battery, the battery level indicator in
the upper right corner of the display shows how much of
the charging process is complete. See “Battery Level
Indicator” on page 24.
Battery Use
Caution:
To prevent injuries or burns, do not allow metal
objects to contact or short-circuit the battery terminals.
To maximize battery performance:
•
Always use Motorola Original™ batteries and battery
chargers. The phone warranty does not cover
damage caused from using non-Motorola batteries
and/or battery chargers.
•
New batteries or batteries that have been stored for a
long time may require a longer initial charge time.
Action
1
Plug the travel
charger into the
middle jack as
shown.
2
Plug the other end of the travel charger into the
appropriate electrical outlet.
3
When your phone indicates
Charge Complete
,
remove the travel charger.
UG.E380.GSM.book Page 15 Thursday, June 12, 2003 8:42 AM
16
PRELIMINARY
Getting Started
•
Maintain the battery at or near room temperature
when charging.
•
Do not expose batteries to temperatures below -
10°C (14°F) or above 45°C (113°F). Always take
your phone with you when you leave your vehicle.
•
When you do not intend to use a battery for a
while, store it uncharged in a cool, dark, dry place,
such as a refrigerator.
•
Over time, batteries gradually wear down and require
longer charging times. This is normal. If you charge
your battery regularly and notice a decrease in talk
time or an increase in charging time, then it is
probably time to purchase a new battery.
The rechargeable batteries that power this
product must be disposed of properly and may
need to be recycled. Refer to your battery’s label
for battery type. Contact your local recycling center for
proper disposal methods. Never dispose of batteries in a
fire because they may explode.
Changing Your SIM Card
Your SIM (Subscriber Identity Module) card contains your
phone number, service details, and phonebook/message
memory. It must be installed in your phone, and must be a
3-volt
SIM card. If you have problems with your SIM card,
contact your service provider.
UG.E380.GSM.book Page 16 Thursday, June 12, 2003 8:42 AM
17
PRELIMINARY
Getting Started
Caution:
Do not bend or scratch your SIM card. Avoid
exposing your SIM card to static electricity, water, or dirt.
Action
1
Press the cover
release button.
2
Slide the phone’s
back cover down,
then lift it off.
3
Lift out the battery
from the base of
the phone.
4
Slide the metal
SIM card cover to
unlock it.
5
Lift out the old SIM
card, if necessary.
Cover release button
1
2
SIM card
UG.E380.GSM.book Page 17 Thursday, June 12, 2003 8:42 AM
18
PRELIMINARY
Getting Started
Changing Your Phone’s Lens
Always use Motorola Original™ lenses. The phone
warranty does not cover damage caused from
using non-Motorola accessories.
6
Slide in the new
SIM card in the
holder with the cut
corner on the
upper right and the
gold plate facing
down.
7
Insert the battery
with printed
arrows and two
tabs at the top of
the battery
compartment.
8
Push down until
the battery inserts
at the bottom.
9
Set the back cover
on the phone, then
slide it up to lock it.
Action
SIM card
78
9
UG.E380.GSM.book Page 18 Thursday, June 12, 2003 8:42 AM
19
PRELIMINARY
Getting Started
Your phone has a removable lens that you can replace to
change its appearance.
Action
1
Open your phone
flip.
2
Press the lens
carefully until it
pops out.
3
Insert the bottom
of the new lens
into the bottom of
the phone flip.
4
Press the top of
the new lens onto
the phone until it
snaps into place.
3
4
UG.E380.GSM.book Page 19 Thursday, June 12, 2003 8:42 AM
20
PRELIMINARY
Getting Started
Turning Your Phone On
Adjusting the Volume
Press up and down on
volume keys or right and left
on the
S
to:
•
increase and decrease
earpiece volume during a
call
Action
1
Press and hold
O
(the End/Power
key).
2
If necessary, enter your SIM card PIN code and
press
OK
(
+
) to unlock your SIM card.
Note:
If you enter an incorrect PIN code 3 times
in a row, your SIM card is disabled and your
phone displays
SIM Blocked
.
3
If necessary, enter your 4-digit unlock code and
press
OK
(
+
) to unlock your phone.
Note:
The unlock code is originally set to 1234.
(For more information, see page 42.)
End/
Power
key
Volume
keys
UG.E380.GSM.book Page 20 Thursday, June 12, 2003 8:42 AM
21
PRELIMINARY
Getting Started
•
increase and decrease the ringer volume setting when
the idle display is visible (flip must be open)
Tip:
At the lowest volume setting, press the down
volume key once to switch to vibrate alert. Press it
again to switch to silent alert. Press the up volume
key to switch back to vibrate alert, then ring alert.
•
turn off an incoming call alert
Making a Call
Note:
Do not block the built-in
antenna in the top of your phone while
you are on a call.
Press To
1
keypad keys dial the phone number
Tip:
If you make a mistake,
press
DELETE
(
-
) to delete
the last digit, or press and
hold
DELETE
(
-
) to delete all
digits.
2
N
make the call
3
O
end the call and “hang up” the
phone
Built-in antenna
UG.E380.GSM.book Page 21 Thursday, June 12, 2003 8:42 AM
22
PRELIMINARY
Getting Started
Answering a Call
When you receive a call, your phone rings and/or
vibrates and displays an incoming call message.
Tip:
You can answer a call by opening the phone if you
turn on the
Open to Answer
option (see page 47).
Note:
If the phone is locked, you must unlock it to answer
the call.
Viewing Your Phone Number
To view your phone number from the idle display, press
M#
.
While you are on a call, press
M
>
My Tel. Numbers
.
Note:
You must store your phone number on your SIM
card to use this feature. To store your phone number on
your SIM card, see page 45. If you do not know your
phone number, contact your service provider.
Press To
1
N
or
ANSWER
(
+
)
answer the call
2
O
(end key) hang up when the call is done
UG.E380.GSM.book Page 22 Thursday, June 12, 2003 8:42 AM
23
PRELIMINARY
Learning to Use Your Phone
Learning to Use Your
Phone
See page 1 for a basic phone diagram.
Using the Display
The idle display (shown below) is the standard display
when you are not on a call or using the menu.
The
G
(menu) indicator at the bottom center of the display
indicates you can press the menu key (
M
) to display the
main menu to see more features.
Labels at the bottom corners of the display show the
current soft key functions. Press the left soft key (
-
) or
right soft key (
+
) to perform the function indicated by the
left or right soft key label.
12:00
MYMENU MESSAGE
Clock
G
59
Y
Soft Key Labels
J
Menu
Indicator
UG.E380.GSM.book Page 23 Thursday, June 12, 2003 8:42 AM
24
PRELIMINARY
Learning to Use Your Phone
The following status indicators can appear:
➊
Alert Style Indicator
Shows the currently selected
alert style. The default alert style is
Loud Ring
.
➋
Signal Strength Indicator
Indicates the strength of
your phone’s connection with the network.
You cannot make or answer calls when the “no signal”
indicator displays.
➌
GPRS Indicator
Indicates that your phone
is using a high-speed GPRS network
connection (
)
). GPRS allows faster data
transfer speeds. The indicator does not mean
that you are in a call; only that you are registered on the
Y
Loud Ring
X
Soft Ring
W
Vibrate
_Vibe&Ring
a
Silent
Strong
5
4
3
2
1
0
No signal
12:00
MYMENU MESSAGE
G
5| U; Üg9
YJ
➋
Signal
Strength
➑
Battery
Level
➌
GPRS
➍
In Use
➏
Text C a s e
(if applies)
➐
Message
or Entry
Method
➎
Roam
➊
Alert Style
➒
Active Line
UG.E380.GSM.book Page 24 Thursday, June 12, 2003 8:42 AM
25
PRELIMINARY
Learning to Use Your Phone
network with a GPRS connection. Other possible
indicators:
➍
In Use Indicator
Indicates when you are on a call, and
when you have a secure (
G
) or insecure (
F
) connection.
➎
Roam Indicator
Indicates when your phone
uses another network outside your home
network (
;
). When you leave your home
network area, your phone roams or seeks
another network.
➏
Text Case Indicator
Indicates the text case when you
are in a text editor.
To change the case, press
0
(see page 38).
➐
Message or Entry Method Indicator
Indicates when you have an active Chat
session, or when you have a new voice (
f
) or
text (
g
) message waiting. When you enter a
text message, a number here indicates how many more
characters can fit in the message.
(
GPRS PDP context
active
*
GPRS packet data
available
Ü
No capital letters
Ö
All capital letters
Ñ
Next letter capital
UG.E380.GSM.book Page 25 Thursday, June 12, 2003 8:42 AM
26
PRELIMINARY
Learning to Use Your Phone
Any time you enter text, an icon here indicates the entry
method:
Symbol
(
å
),
Numeric
(
á
),
Primary
, or
Secondary
:
To change the entry method, press
#
(see
page 38).
➑
Battery Level Indicator
Shows the amount of charge
left in your battery. The more bars visible, the greater the
charge.
Recharge your battery as soon as possible when you see
the
Low Battery
warning message and hear the low
battery alert.
➒
Active Line Indicator
Shows
J
or
K
to indicate the
currently active phone line.
Primary Secondary
ïõ
Tap, no capital letters
óù
Tap, next letter capital
ñú
Tap, all capital letters
ôü
iTAP, no capital letters
†°
iTAP, next letter capital
òû
iTAP, all capital letters
High
9
8
7
6
Low
UG.E380.GSM.book Page 26 Thursday, June 12, 2003 8:42 AM
27
PRELIMINARY
Learning to Use Your Phone
Using the 4-Way Navigation
Key
Use the 4-way
navigation key like a
joystick to navigate the
menu system, change
feature settings, and play
games.
Tip:
Down and up are the primary movements within
menus. Move left and right to change feature settings,
navigate the datebook, and edit text.
Navigation
key
UG.E380.GSM.book Page 27 Thursday, June 12, 2003 8:42 AM
28
PRELIMINARY
Learning to Use Your Phone
Using Menus
From the idle display, press
M
to display the main menu.
Selecting a Menu Feature
From the idle display, select a menu feature as follows:
This example shows that from the idle display, you must
press
M
, scroll to and select
Recent Calls
, then scroll to
and select
Dialed Calls
to display the dialed calls list. Use
S
to scroll, and the left/right soft keys to perform the
functions in the bottom left and right corners of the display.
Find the Feature
M
>
Recent Calls
>
Dialed Calls
Right Soft Key
Perform functions
identified by right
display prompt.
Power/End Key
Press and hold to
power phone
on and off.
Press and release
to end phone
calls, exit menus.
Left Soft Key
Perform functions
identified by left
display prompt.
Menu Key
Enter menu
system or open a
sub-menu.
Navigation Key
Scroll through
menus and lists,
set feature values.
UG.E380.GSM.book Page 28 Thursday, June 12, 2003 8:42 AM
29
PRELIMINARY
Learning to Use Your Phone
Selecting a Feature Option
Some features require you to select an item from a list:
•
Press
S
to scroll up or down to highlight an item.
•
In a numbered list, press a number key to highlight the
item.
•
In an alphabetized list, press a key repeatedly to cycle
through the letters on the key and highlight the closest
matching list item.
•
When an item has a list of possible values, press
S
left or right to scroll and select a value.
•
When an item has a list of possible numeric values,
press a number key to set the value.
Dialed Calls
10)John Smith
9)Mary Smith
BACK VIEW
59
G
Press
BACK
(
-
) to
show the
previous
screen.
Press
M
to
open the
sub-menu.
Highlighted
item
Press
VIEW
(
+
) to show details
for the highlighted item.
UG.E380.GSM.book Page 29 Thursday, June 12, 2003 8:42 AM
30
PRELIMINARY
Learning to Use Your Phone
Entering Text
Some features require you to enter information.
The message center lets you compose and send text
messages. A flashing cursor shows where text will appear:
Entry Details
Name:_____________
No.:_______________
CANCEL CHANGE
59
G
Press
S
to
scroll down to
additional
items.
Press
CANCEL
(
-
) to exit
without making changes.
DONE
(
-
) displays when you
enter or edit information.
Press
CHANGE
(
+
) or
number keys to edit
the information.
Highlighted
item
Msg:
CANCEL INSERT
G
59Ü450
Press
INSERT
(
+
)
to view and
insert stored
text or
objects.
Press
CANCEL
(
-
) to exit
without making changes.
Flashing
cursor
indicates
insertion
point.
Press
M
to open the
sub-menu.
For indicators, see page 24
UG.E380.GSM.book Page 30 Thursday, June 12, 2003 8:42 AM
31
PRELIMINARY
Learning to Use Your Phone
Using the Tap Method
This is the standard method for entering text on your
phone.
In a text entry screen, you can press
#
to switch entry
methods. An indicator tells you which method is active
(see page 24). If
Tap Method
(
ï
or
õ
) is not available, see
page 38.
Press To
1
A number key
(one or more
times)
select a letter, number, or
symbol shown in the chart on
page 32.
2
Number keys enter remaining characters
Tip:
Press
S
right to accept
a word completion, or
*
to insert a space
3
OK
(
+
) store the text
UG.E380.GSM.book Page 31 Thursday, June 12, 2003 8:42 AM
32
PRELIMINARY
Learning to Use Your Phone
When you enter text using the standard tap method, the
flashing cursor changes to a block cursor, and the soft key
functions change:
When you enter 3 or more characters in a row, your phone
may guess the rest of the word. For example, if you enter
prog
you might see:
If you want a different word, such as
progress
, continue
pressing number keys to enter the remaining characters.
Character Chart
Use this chart as a guide for entering characters with the
tap method.
1
. 1 0 ? ! , @ _ & ~ : ; " - ( ) ' ¿ ¡ %
£ $ ¥
¢
£
+ x * / \ [ ] = > < # §
Msg:
T
DELETE OK
Press
OK
(
+
) to
accept
and store
the text.
Press
DELETE
(
-
) to delete
the character to the left of
the insertion point.
Block cursor
indicates
currently
highlighted
character.
G
59
After 2 seconds, the
block cursor reverts to
a flashing cursor and
moves to the next
position.
Ü449
Msg:
Thisisaprogram
DELETE OK
G
59
In
Tap
, press
S
right to accept the
word, or press
*
to reject it
and enter a space
after
prog
.
Ü435
UG.E380.GSM.book Page 32 Thursday, June 12, 2003 8:42 AM
33
PRELIMINARY
Learning to Use Your Phone
Note:
This chart may not reflect the exact character set
available on your phone. In an email address or URL
editor,
1
shows the common characters for that editor
first.
Tap Method Text Entry Rules
•
Press a number key repeatedly to cycle through its
characters. See the chart on page 32.
•
If you do not press a key for 2 seconds, the character
in the block cursor is accepted, and the cursor moves
to the next position.
•
Press
S
left or right to move the flashing cursor to
the left or right in a text message.
•
The first character of every sentence is capitalized.
Press
S
down to force the character to lowercase
while it is highlighted by the block cursor.
2
a b c 2 ä å á à â ã
α
β
ç
3
d e f 3
δ
ë é è ê
φ
4
g h i 4 ï í î
γ
5
j k l 5
λ
6
m n o 6 ñ ö ø ó ò ô õ
ω
7
p q r s 7
π
ß
σ
8
t u v 8
θ
ü ú ù û
9
w x y z 9
ξ ψ
0
change text case, for capital letters
*
enter a space (hold to enter a return)
#
change text entry method (hold for default)
UG.E380.GSM.book Page 33 Thursday, June 12, 2003 8:42 AM
34
PRELIMINARY
Learning to Use Your Phone
•
Your phone may support multiple languages. The
current language setting determines whether a new
message begins on the left or right side of the display.
•
If you enter or edit information and do not want to
save the changes, press
O
to exit without saving.
Using the iTAP™ Method
iTAP™ software provides a predictive text entry method
that lets you enter a word using one key press per
letter. This can be faster than the
Tap Method
, because
your phone combines the key presses into common
words.
For example, if you press
7764
, letter
combinations that match your key presses appear:
If you want a different word, such as
progress
, continue
pressing number keys to enter the remaining characters.
Entering Words
In a text entry screen, you can press
#
to switch entry
methods. An indicator tells you which method is active
Prog ram
Prog Proh Spoi Proi
c
DELETE SELECT
G
59
Ü443
Press
SELECT
(
+
) to insert
the highlighted word.
Press
DELETE
(
-
) to
clear the last letter entered.
Press
S
up to
accept
Program
,
or right to highlight
another option.
Press
*
to
enter
Prog
and a
space.
UG.E380.GSM.book Page 34 Thursday, June 12, 2003 8:42 AM
35
PRELIMINARY
Learning to Use Your Phone
(see page 24). If
iTAP
(
ô
or
ü
) is not available, see
page 38.
If you enter a word your phone does not
recognize, your phone stores it to use as one of
your word options. When you fill memory space
for unrecognized words, your phone deletes
the oldest words as you add new words.
Press To
1
Number keys
(one press per
letter)
show possible letter
combinations at the bottom of
the display
2
S
right or left highlight the combination you
want
3
SELECT
(
+
) lock a highlighted
combination
You can press number keys
to add more letters to the end
of the combination.
or
*
enter the highlighted
combination when it spells a
word
A space appears after the
word.
UG.E380.GSM.book Page 35 Thursday, June 12, 2003 8:42 AM
36
PRELIMINARY
Learning to Use Your Phone
Using the Symbol Method
In a text-entry screen, press
#
to switch entry methods
until you see the Symbol icon (
å
) in the status bar.
Symbol Chart
Use this chart as a guide for entering symbols in symbol
method.
Press To
1
Number keys
(one press per
symbol)
show possible symbol
combinations at the bottom of
the display
2
S
right or left highlight the combination you
want
3
SELECT
(
+
) lock a highlighted
combination
You can press number keys
to add more symbols to the
end of the combination
or
*
enter the highlighted
combination
A space appears after the
combination.
1
. ? ! , @ _ & ~ : ; " - ( ) ' ¿ ¡ % £ $ ¥
¢
£
2
@ _ \
3
/ : ;
4
" & '
UG.E380.GSM.book Page 36 Thursday, June 12, 2003 8:42 AM
37
PRELIMINARY
Learning to Use Your Phone
Note:
In an email address or URL editor,
1
shows
the common characters for that editor first.
Using the Numeric Method
In a text entry screen, press
#
to switch entry methods
until you see the Numeric icon (
á
) in the status bar.
Press keypad keys to enter the numbers you want. When
you finish entering numbers, press
#
to switch to
another entry method.
Deleting Letters and Words
Place the cursor to the right of the text you want to delete,
and then:
5
( ) [ ] { }
6
¿ ¡ ~
7
< > =
8
$ £ ¥
¢
£
9
# % *
0
+ - x * / = > < # §
*
enter a space (hold to enter a return)
#
change text entry method (hold for default)
Do This To
Press
DELETE
(
-
) delete one letter at a time
Hold
DELETE
(
-
) delete the entire message
UG.E380.GSM.book Page 37 Thursday, June 12, 2003 8:42 AM
38
PRELIMINARY
Learning to Use Your Phone
Choosing a Text Entry Method
Multiple text entry methods make it easy for you to enter
names, numbers, and messages. The method you select
remains active until you select another method.
Press
#
in any text entry screen to change to one of
the following entry methods:
Press
0
in any text entry screen to change your entry
case. An icon in the status bar indicates when you select
no capital letters (
Ü
), next letter capital only (
Ñ
), or all
capital letters (
Ö
).
Setting Up a Text Entry Method
To set the primary or secondary text entry methods, press
M
>
Entry Setup
from any text entry screen. Select
Primary Setup
or
Secondary Setup
, and choose:
Primary
The primary text entry method you
set up (see the next section).
Numeric
(
á
) Enter numbers only.
Symbol
(
å
) Enter symbols only (see page 36).
Secondary
The secondary text entry method
you set up (see the next section).
(None)
Hide the
Secondary
setting (only
available for
Secondary Setup
).
iTAP
Let the phone predict each word
as you press keys (see page 34).
UG.E380.GSM.book Page 38 Thursday, June 12, 2003 8:42 AM
39
PRELIMINARY
Learning to Use Your Phone
Using Your
Phone While
it is Closed
When your phone is
closed, you can still see
the display.
You can use the volume
keys and the smart key
to do the following tasks,
even though the keypad
is covered.
Opening the Quick Menu
When your phone is closed and idle, press the smart key
to see these options. Use the volume keys to scroll
through options, and the smart key to select an option:
Tap Method
Enter letters, numbers, and
symbols by pressing a key 1 or
more times (see page 31).
Option Description
Ring Style
lets you choose a style of ring
tones and alerts (see page 46)
Club Lights
lets you activate the flashing
lights (see page 47)
Smart
Key
selects
Volume
Keys
scroll
UG.E380.GSM.book Page 39 Thursday, June 12, 2003 8:42 AM
40
PRELIMINARY
Learning to Use Your Phone
Answering an Incoming Call
When a call arrives while your phone is closed, your
phone rings and/or vibrates and shows an incoming
call message. If you have a headset or other
hands-free device plugged into your phone:
Tip:
You can answer a call by opening the phone if you
turn on the
Open to Answer
option (see page 47).
Note:
If the phone is locked, you must unlock it to answer
the call.
Voice Dial
* opens your voice dial list (see
page 68)
Received Calls
* opens the list of received calls
Dialed Calls
* opens the list of received calls
* Available only if a headset is plugged into the phone
Action To
Press the smart key answer the call
Press either volume
key
silence the call alert
without cancelling the call
Press and hold the
smart key
cancel the call
Option Description
UG.E380.GSM.book Page 40 Thursday, June 12, 2003 8:42 AM
41
PRELIMINARY
Learning to Use Your Phone
Returning an Unanswered Call
Your phone keeps a record of unanswered calls and
displays X
Missed Calls
.
Note:
Because the microphone and earpiece are
unavailable when the phone is closed, you must use a
headset or other hands-free device with this feature.
Using the Smart Key
The smart key provides another way to perform many
basic phone functions. It anticipates the next action you
are likely to perform. For example, when you highlight a
menu item, you can press the smart key to select it. You
can use the smart key to make and end calls, toggle
features on and off, and open your phonebook. The smart
key usually performs the same function as the right soft
key (
+
).
Tip:
The smart key provides an optional way to do some
things faster. It is never the only way to perform a task.
Press To
1
smart key see the received calls list
Note:
Press either volume
key to dismiss the reminder.
2
volume keys select a call in the received
calls list
3
smart key make the call
UG.E380.GSM.book Page 41 Thursday, June 12, 2003 8:42 AM
42
PRELIMINARY
Learning to Use Your Phone
Locking and Unlocking Your
Phone
You can lock your phone manually or set it to lock
automatically whenever you turn it off.
A locked phone still rings or vibrates for incoming calls or
messages, but you must unlock it to answer. To use a
locked phone, enter the unlock code.
You can make emergency calls on your phone even
when it is locked. See page 54.
Locking Your Phone Manually
Unlocking Your Phone
At the
Enter Unlock Code
prompt:
Find the Feature
M
>
Settings
>
Security
>
Phone Lock
>
Lock Now
Press To
1
keypad keys enter your 4-digit unlock code
2
OK
(
+
) lock the phone
Press To
1
keypad keys enter your 4-digit unlock code
The unlock code is originally
set to 1234. If necessary, see
“If You Forget a Code or
Password” on page 44.
UG.E380.GSM.book Page 42 Thursday, June 12, 2003 8:42 AM
43
PRELIMINARY
Learning to Use Your Phone
Setting Your Phone to Lock Automatically
You can set your phone to lock every time you turn it off.
Changing a Code or Password
Your 4-digit unlock code is originally set to 1234, and the
6-digit security code is originally set to 000000. Your
service provider may reset these numbers before you
receive your phone.
If your service provider has not reset these numbers, we
recommend that you change them to prevent others from
accessing your personal information or modifying your
phone settings. The unlock code must contain 4 digits, and
the security code must contain 6 digits.
2
OK
(
+
) unlock your phone
Find the Feature
M
>
Settings
>
Security
>
Phone Lock
>
Automatic Lock
>
On
Press To
1
keypad keys enter your 4-digit unlock code
2
OK
(
+
) set the phone to lock
automatically
Find the Feature
M
>
Settings
>
Security
>
New Passwords
Press To
UG.E380.GSM.book Page 43 Thursday, June 12, 2003 8:42 AM
44
PRELIMINARY
Learning to Use Your Phone
If You Forget a Code or
Password
If you forget your security code (originally set to 000000),
SIM PIN, SIM PIN2, or call barring password, contact your
service provider.
If you forget your unlock code, try entering 1234 or the last
4 digits of your phone number. If that does not work, do
the following when you see the
Enter Unlock Code
message:
Locking and Unlocking the
Keypad
You can lock the keypad to prevent accidental key presses
(for example, when carrying your phone in a purse or
pocket).
Note:
Incoming calls and messages unlock the keypad.
Press To
1
M
go to the unlock code bypass
screen
2
keypad keys enter your security code
3
OK
(
+
) submit your security code
Press To
M*
lock or unlock the keypad
UG.E380.GSM.book Page 44 Thursday, June 12, 2003 8:42 AM
45
PRELIMINARY
Setting Up Your Phone
Setting Up Your
Phone
Storing Your Name and Phone
Number
To store or edit your name and phone number information
on your SIM card:
If you do not know your phone number, contact your
service provider. To view your phone number from the
idle display or during a call, see page 22.
Setting the Time and Date
To use the datebook, you must set the time and date.
Find the Feature
M
>
Settings
>
Phone Status
>
My Tel. Numbers
Find the Feature
M
>
Settings
>
Other Settings
>
Initial Setup
>
Time and Date
UG.E380.GSM.book Page 45 Thursday, June 12, 2003 8:42 AM
46
PRELIMINARY
Setting Up Your Phone
Setting an Alert Style
Your phone can ring or vibrate when you receive a call,
message, or other event. This is called an alert. An
indicator in the display shows the current alert style:
To set an alert style:
Tip:
You can choose a single theme to set your wallpaper,
screen saver, alert style, and other settings. From idle,
press
M
>
Media Center
>
Theme
and select a theme.
Each alert style has settings for specific event alerts and
ringer and keypad volume. To change these settings:
Loud changes to the name of the current Ring Style.
Note:
Some ring tones vibrate automatically. If you use
one of these tones, your phone vibrates even when it is not
set to
Vibrate
or
Vibe&Ring
. To turn off these vibrations, see
page 71.
Y
Loud Ring
X
Soft Ring
W
Vibrate
_Vibe&Ring
a
Silent
Find the Feature
M
>
Alert Styles
>
Ring Style
Press To
1
S
scroll to the style
2
SELECT
(
+
) select the style
Find the Feature
M
>
Alert Styles
>Loud
Detail
UG.E380.GSM.book Page 46 Thursday, June 12, 2003 8:42 AM
47
PRELIMINARY
Setting Up Your Phone
Tip:
You can make your phone flash when you receive a
call or message from someone in your phonebook. See
page 69.
Setting Answer Options
You can use different methods to answer an incoming call.
The
Answer Options
menu includes:
Activating Club Lights
Club Lights make your phone’s display, keys, and side
band flash in beat with music or noise around you. You
can activate Club Lights for up to 10 minutes.
Find the Feature
M
>
Settings
>
In-Call Setup
>
Answer Options
Multi-Key
answer by pressing any key
Open to Answer
answer by opening the flip
Find the Feature
M
>
Settings
>
Other Settings
>
Personalize
>
Club Lights
Setting Description
Pattern
choose a light pattern to activate Club
Lights, or turn the lights
Off
Timer
set how many minutes Club Lights will
stay active (up to 10 minutes)
UG.E380.GSM.book Page 47 Thursday, June 12, 2003 8:42 AM
48
PRELIMINARY
Setting Up Your Phone
Notes:
•
Club Lights only work when your phone is idle and
your battery is not low. Club Lights pause if you press
a key or receive a call or message.
•
Your phone can also flash for incoming calls and
messages (see page 69). Some games might make
your phone flash and vibrate.
Tip:
To create a shortcut to the
Club Lights
feature,
highlight it, then press and hold
M
.
To use a shortcut, press
M
>
Shortcuts
in idle.
Setting a Wallpaper Image
You can set a picture or an animation as a wallpaper
(background) image in your phone’s idle display.
Note:
When you set an animation as a wallpaper image,
only the first frame of the animation displays.
Sensitivity
set how loud the music has to be
before Club Lights respond (1 to 7)
Find the Feature
M
>
Settings
>
Other Settings
>
Personalize
>
Wallpaper
Setting Description
select the picture or animation for the
background image in your idle display
Layout
select
Center
or
Tile
Setting Description
UG.E380.GSM.book Page 48 Thursday, June 12, 2003 8:42 AM
49
PRELIMINARY
Setting Up Your Phone
Tip:
You can choose a single theme to set your wallpaper,
screen saver, alert style, and other settings. From idle,
press
M
>
Media Center
>
Theme
and select a theme.
Selecting a Screen Saver
You can set a picture or an animation as a screen saver
image. The image displays when the phone detects no
activity for a specified time.
The screen saver image shrinks to fit the display, if
necessary. An animation repeats for 1 minute, then the
first frame of the animation displays.
Tip:
You can choose a single theme to set your wallpaper,
screen saver, alert style, and other settings. From idle,
press
M
>
Media Center
>
Theme
and select a theme.
Find the Feature
M
>
Settings
>
Other Settings
>
Personalize
>
Screen Saver
Setting Description
select the picture that appears when
your phone is idle
Delay
select how long your phone must be
idle before the screen saver picture
appears
UG.E380.GSM.book Page 49 Thursday, June 12, 2003 8:42 AM
50
PRELIMINARY
Setting Up Your Phone
Setting Display Color
You can select the color palette that your phone uses to
display indicators, highlights, and soft key labels.
Setting Display Contrast
Adjusting the Backlight
You can set the amount of time that the display backlight
remains on, or turn off the backlight to conserve battery
power.
Zooming In and Out
Press and release
M
, then press and hold
M
to zoom in
and out on the display. Zoom in to increase text size, zoom
out to display more information.
Find the Feature
M
>
Settings
>
Other Settings
>
Personalize
>
Color Style
Find the Feature
M
>
Settings
>
Other Settings
>
Initial Setup
>
Contrast
Find the Feature
M
>
Settings
>
Other Settings
>
Initial Setup
>
Backlight
UG.E380.GSM.book Page 50 Thursday, June 12, 2003 8:42 AM
51
PRELIMINARY
Setting Up Your Phone
You can also zoom in and out from the menu.
Conserving Battery Power
Some networks and phones include a battery
save setting to conserve battery power.
Find the Feature
M
>
Settings
>
Other Settings
>
Initial Setup
>
Zoom
Find the Feature
M
>
Settings
>
Other Settings
>
Initial Setup
>
Battery Save
UG.E380.GSM.book Page 51 Thursday, June 12, 2003 8:42 AM
52
PRELIMINARY
Calling Features
Calling Features
For basic instructions on how to make and answer calls,
see page 21.
Changing the Active Line
Change the active phone line to make and
receive calls from your other phone number.
The active line indicator in the display shows the current
active phone line (see page 24).
Redialing a Number
From the idle display:
Find the Feature
M
>
Settings
>
Phone Status
>
Active Line
Press To
1
N
view the dialed calls list
2
S
scroll to the entry you want
3
N
redial the number
UG.E380.GSM.book Page 52 Thursday, June 12, 2003 8:42 AM
53
PRELIMINARY
Calling Features
Using Caller ID
Calling line identification (caller ID) displays the
phone number for incoming calls.
For
Incoming Calls:
The phone displays the
caller’s name when the name is stored in your
phonebook, or
Incoming Call
when caller ID information is
not available.
For
Outgoing Calls:
Other phones can display your
phone number when you call them or send a message. To
hide your number for the next call or message, press
M
>
Settings
>
In-Call Setup
>
My Caller ID
>
Next Call Only
.
Canceling an Incoming Call
While the phone is ringing or vibrating:
Depending on your phone settings and the
type of subscription you have, the call may be
forwarded to another number, or the caller
may hear a busy signal.
Press To
IGNORE
(
-
) cancel the incoming call
UG.E380.GSM.book Page 53 Thursday, June 12, 2003 8:42 AM
54
PRELIMINARY
Calling Features
Turning Off a Call Alert
You can turn off your phone’s incoming call alert before
answering the call:
Calling an Emergency Number
Your service provider programs one or more emergency
phone numbers (such as 112 or 911) that you can call
under any circumstances, even when your phone is
locked.
Note:
Emergency numbers vary by country. Your phone’s
emergency number(s) may not work in all locations, and
sometimes an emergency call cannot be placed due to
network, environmental, or interference issues.
Press To
S
up or down turn off the alert
Press To
1
keypad keys dial the emergency number
2
N
call the emergency number
UG.E380.GSM.book Page 54 Thursday, June 12, 2003 8:42 AM
55
PRELIMINARY
Calling Features
Dialing International Numbers
To dial the local international access code:
Viewing the Received Calls or
Dialed Calls List
Your phone keeps lists of the calls you recently received
and dialed, even if the calls did not connect. The lists are
sorted from newest to oldest, and contain up to 10 entries.
The oldest entries are deleted as new ones are added.
Shortcut:
From the idle display, press
N
to display the
dialed calls list.
Action To
Press
0
for 2
seconds
insert the international
access code (
+
) for the
country from which you are
dialing
Find the Feature
M
>
Recent Calls
Press To
1
S
scroll to
Received Calls
or
Dialed Calls
2
SELECT
(
+
) select the list
3
S
scroll to an entry
Note:
\
means the call
connected.
UG.E380.GSM.book Page 55 Thursday, June 12, 2003 8:42 AM
56
PRELIMINARY
Calling Features
4
N
call the entry’s number
Note:
Press and hold
N
for 2
seconds to send the number
as DTMF tones during a call.
or
+
if
View
appears above the
+
key—view the entry’s details
if
Store
appears above the
+
key—store the entry’s details
in the phonebook
or
M
open the
Last Calls Menu
to
perform other procedures in
the following list
Option Description
Store
Create a phonebook entry with
the selected number in the
No.
field. (This option does not appear
if
STORE
appears above the
+
key, or if the number is already
stored as a phonebook entry.)
Delete
Delete the entry. (This option
does not appear if
DELETE
appears
above the
+
key.)
Delete All
Delete all entries in the current
list.
Press To
UG.E380.GSM.book Page 56 Thursday, June 12, 2003 8:42 AM
57
PRELIMINARY
Calling Features
Returning an Unanswered Call
Your phone displays the following for unanswered calls:
•
the
N
(missed call) indicator
•
X
Missed Calls
, where X is the total number of
missed calls
Hide ID
/
Show ID
Hide (or show) your caller ID for
the next call.
Send Message
Create a new text message, with
the selected number in the
Tel No.
field. See page 10.
Add Digits
Add digits to the end of the
selected number.
Attach Number
Attach another number from the
phonebook or recent calls list to
the end of the selected number.
Press To
1
VIEW
(
+
) see the received calls list,
beginning with the most
recent call
2
S
scroll through the list and
select a call that you want to
return
3
N
make the call
Option Description
UG.E380.GSM.book Page 57 Thursday, June 12, 2003 8:42 AM
58
PRELIMINARY
Calling Features
Using the Notepad
Your phone stores the most recent string of digits entered
on the keypad in a temporary memory location called the
notepad. This can be a phone number that you called, or a
number that you entered but did not call. To retrieve the
number stored in the notepad:
Attaching a Number
While dialing (with digits visible in the display):
Find the Feature
M
>
Recent Calls
>
Notepad
Press To
N
call the number
or
M
open the
Dialing Menu
to attach a
number or insert a special character.
or
STORE
(
+
) create a new phonebook entry, with
the notepad number copied into the
No.
field.
See “Creating a Phonebook Entry” on
page 29.
Press To
M
>
Attach Number
attach a number from the
phonebook or recent calls list
to the end of the digits you
entered
UG.E380.GSM.book Page 58 Thursday, June 12, 2003 8:42 AM
59
PRELIMINARY
Calling Features
Calling With Speed Dial
Each entry in your phonebook is assigned a unique speed
dial number that identifies where the entry is stored in
phone memory or on the SIM card. To speed dial a
phonebook entry, in the idle display:
Calling With 1-Touch Dial
To call phonebook entries 1 through 9 from the idle
display, press and hold the 1-digit speed dial number for 1
second.
Tip:
You must specify which phone number list you want
to use with this feature: phone memory phonebook, or SIM
card phonebook. See the Reference Guide.
Using Voicemail
You can listen to your voicemail messages by
calling your network voicemail phone number.
Voicemail messages are stored on the
network—not on your phone.
Press To
1
keypad keys enter the speed dial number
for the entry you want to dial
2
#
submit the number
3
N
call the entry
UG.E380.GSM.book Page 59 Thursday, June 12, 2003 8:42 AM
60
PRELIMINARY
Calling Features
Storing Your Voicemail Number
Storing your voicemail number in your phone makes it
easy for you to listen to new voicemail messages. Your
voicemail number is provided by your service provider.
Note:
You cannot store pause, wait, or n characters in this
number. If you want to store a voicemail number with
these characters, create a phonebook entry for it. Then,
you can use the entry to call your voicemail. For more
about these characters, see page 69.
Receiving a New Voicemail Message
When you receive a voicemail message, your phone
displays
f
(voice message waiting) and
New VoiceMail
. Some networks only indicate when you
have messages, whether they are new or not.
Find the Feature
M
>
Messages
M
>
VoiceMail Setup
Press To
1
keypad keys enter the phone number for
your voicemail
2
OK
(
+
) store the number
Press To
CALL
(
+
) call the voicemail phone
number you stored and listen
to the message
UG.E380.GSM.book Page 60 Thursday, June 12, 2003 8:42 AM
61
PRELIMINARY
Calling Features
Listening to a Voicemail Message
Your phone calls your voicemail number. If no voicemail
number is stored, the phone prompts you to store one.
Using Call Waiting
When you are on a call, an alert tone sounds to
indicate that you have received a second call.
You must turn on call waiting to use this feature. To
turn call waiting on or off:
Find the Feature
M
>
Messages
>
VoiceMail
Press To
1
N
answer the new call
2
SWITCH
(
+
)
or
LINK
(
-
)
switch back to the first call
Note:
You can press
SWITCH
(
+
) at any time to
switch between calls.
connect the two calls
Find the Feature
M
>
Settings
>
In-Call Setup
>
Call Waiting
UG.E380.GSM.book Page 61 Thursday, June 12, 2003 8:42 AM
62
PRELIMINARY
Calling Features
Putting a Call on Hold
Transferring a Call
While you are on a call, you can transfer the call to another
phone by first talking to the person who answers the other
phone, or by directly transferring the call.
Announcing the Call Transfer
Press To
HOLD
(
+
) (if
available)
or
M
>
Hold
put a call on hold
Your phone displays a
=
(flashing phone) indicator to
indicate the call is on hold.
Find the Feature
M
>
Hold
Press To
1
keypad keys enter the phone number
where you are transferring
the call
2
N
dial the phone number
Speak to the person who
answers the target phone.
3
M
open the menu
4
S
scroll to
Transfer
5
SELECT
(
+
) select
Transfer
UG.E380.GSM.book Page 62 Thursday, June 12, 2003 8:42 AM
63
PRELIMINARY
Calling Features
Not Announcing the Call Transfer
6
OK
(
+
) confirm the transfer
Your phone displays the
message
Transfer: Complete
when it
transfers. You can hang up
the phone when you see this
message.
Find the Feature
M
>
Transfer
Press To
1
keypad keys enter the phone number
where you are transferring
the call
2
N
dial the phone number
Your phone displays the
message
Transfer: Complete
when it
transfers. You can hang up
the phone when you see this
message.
Press To
UG.E380.GSM.book Page 63 Thursday, June 12, 2003 8:42 AM
64
Phone Features
PRELIMINARY
Phone Features
Main Menu
This is the standard main menu layout.
Menu
organization and feature names may vary on your
phone.
Not all features may be available for all users.
m
Voice Di al
r
Phonebook
z
Recent Calls
• Received Calls
• Dialed Calls
• Notepad
• Call Times
• Call Cost
•Data Times
•Data Volumes
o
Chat *
w
Alert Styles
• Ring Style
•alert Detail
• Ring Lights
• Event Lights
v
Media Center
•Theme
•Pictures
• Sound
• MotoMixer
-
Games & Apps
ê
WebAccess
• Web Browser
• Web Shortcuts
• Stored Pages
•History
• Go to URL
• Web Sessions
•Browser Setup
6
Office Tools
• Datebook
•Calculator
More
>
*
Alarm Clock
ã
Settings
• (see next page)
:
MyMenu
U
Messages *
• Create Message
•Voicemail
• Message Inbox
• Browser Msgs
• Info Services
• Quick Notes
•Outbox
• Drafts
7
SIM Applications *
Q
Fixed Dial
9
Service Dial *
R
Quick Dial
ê
Java Tools
• Java App Loader
•Java System
•Network Access
• DNS IP
Note:
Select
More
when it appears in
the menu to see more menu items.
* optional network, SIM card, or
subscription-dependent features
UG.E380.GSM.book Page 64 Thursday, June 12, 2003 8:42 AM
65
PRELIMINARY
Phone Features
Settings Menu
Call Forward *
•Voice Calls
•Fax Calls
•Data Calls
• Cancel All
• Forward Status
Phone Status
•My Tel. Numbers
*
• Credit Info/Available
*
• Active Line
• Battery Meter
• Other Information
In-Call Setup
• In-Call Timer
• Call Cost Setup
*
• My Caller ID
• Talk and Fax
*
• Answer Options
• Call Waiting
*
Security
• Phone Lock
• Lock Keypad
• Lock Application
•Fixed Dial
• Call Barring
*
• SIM PIN
•New Passwords
Other Settings
• Personalize
• Club Lights
• Main Menu
•Keys
• Color Style
•Greeting
*
• Wallpaper
• Screen Saver
•Quick Dial
*
• Initial Setup
• Time and Date
•1-Touch Dial
• Backlight
• Zoom
• TTY Setup
•Scroll
• Animation
• Haptics
• Language
• Battery Save
• Contrast
•DTMF
•Master Reset
• Master Clear
•Network
• New Network
• Network Setup
• Available Networks
• My Network List
• Service Tone
• Call Drop Tone
• Car Settings
• Headset
Note:
This is the standard
phone menu layout. Menu
organization and feature names
may vary on your phone. Not all
features may be available for all
users.
* optional network, SIM card, or
subscription-dependent
features
Shortcuts
O
pen
Phonebook
:
Press
S
d
or
e
in idle
Set Ring Volume
:
Press
S
b
or
c
in idle
Change Display Zoom:
Press
M
, then hold
M
UG.E380.GSM.book Page 65 Thursday, June 12, 2003 8:42 AM
66
Phone Features
PRELIMINARY
Feature Quick Reference
You can do more with your phone than make and receive
phone calls! For example, you can:
•
store frequently called numbers in the phonebook for
easy dialing
•
organize your meetings and other events in the
datebook
•
browse the Web
•
download applications
•
send messages
This section provides information to help you use features
on your phone that are not described in this user guide.
For more detailed information, see the reference guide.
Calling Features
Feature Description
Conference
Call
During a call:
M
>
Hold
, dial next
number, press
N
, press
LINK
(
-
)
Call
Forwarding
Set up or cancel call
forwarding:
M
>
Settings
>
Call Forward
Call Barring
Restrict outgoing or
incoming calls:
M
>
Settings
>
Security
>
Call Barring
UG.E380.GSM.book Page 66 Thursday, June 12, 2003 8:42 AM
67
PRELIMINARY
Phone Features
Message Features
Chat Features
TTY Calls
Set up your phone for use
with an optional TTY device:
M
>
Settings
>
Other Settings
>
Initial Setup
>
TTY Setup
Feature Description
Send
Message
Send a text message:
M
>
Messages
>
Create Message
To enter text, see page 30.
Insert
Pictures
and Sounds
While composing a message:
M
>
Insert
Received
Messages
Read received messages:
M
>
Messages
>
Message Inbox
Press
M
to perform various
operations on the selected message.
Store
Pictures
and Sounds
Highlight a picture or sound in a
message, then:
M
>
Store
Feature Description
Start Chat
Start a new chat session:
M
>
Chat
M
>
New Chat
Feature Description
UG.E380.GSM.book Page 67 Thursday, June 12, 2003 8:42 AM
68
Phone Features
PRELIMINARY
Phonebook Features
Receive
Chat
Request
When you receive a chat request:
Press
ACCEPT
(
+
) or
IGNORE
(
-
)
End Chat
During a chat session:
M
>
End Chat
Feature Description
Create Entry
Create a new phonebook entry:
M
>
Phonebook
M
>
New
>
Phone Number
or
Email Address
Dial Number
Call a number in the phonebook:
M
>
Phonebook
> entry to call
N
Voice Dial
Number
Voice dial a number in the
phonebook:
Press
M
>
Voice Dial
, and say the
entry’s name (in 2 seconds)
Feature Description
UG.E380.GSM.book Page 68 Thursday, June 12, 2003 8:42 AM
69
PRELIMINARY
Phone Features
Store a PIN
Code in a
Number
While entering the number:
M
>
Insert Pause
,
Wait
, or
‘n’
Pause
: waits for the call to connect,
then sends the remaining digit(s).
If your network does not recognize
the first pause character, try two (
pp
).
Wait
: waits for the call to connect,
then prompts you for confirmation
before it sends the remaining digit(s).
‘n’
: prompts you for a number
before dialing the call. The number
you enter is inserted into the dialing
sequence in place of the
n
character
Phonebook
Categories
You can put phonebook entries into
categories. When you get a call or
message from someone in a
category, your phone uses the
category’s special ring or flashing
lights.
To set up a category, press
M
>
Phonebook
M
>
Categories
.
Scroll to the category, then press
M
>
Edit
To set an entry’s category, press
M
>
Phonebook
> entry to edit, then
press
EDIT
(
+
).
Feature Description
UG.E380.GSM.book Page 69 Thursday, June 12, 2003 8:42 AM
70
Phone Features
PRELIMINARY
Personalizing Features
1-Touch
Dial
Set 1-touch dial to call entries stored
in your phone memory phonebook or
the SIM card phonebook:
M
>
Settings
>
Other Settings
>
Initial Setup
>
1-Touch Dial
Feature Description
Event Alert
Change an event alert:
M
>
Alert Styles
> alert
Detail
>event name
Ring
Volume
Adjust ringer volume:
M
>
Alert Styles
> alert
Detail
>
Ring Volume
Keypad
Volume
Adjust keypad key press volume:
M
>
Alert Styles
> alert
Detail
>
Key Volume
My Tones
Compose your own ring tones,
manage ring tones that you have
composed or downloaded:
M
>
Media Center
>
MotoMixer
Themes
Apply the wallpaper, screen saver,
alert style, and other settings in a
theme:
M
>
Media Center
>
Theme
Feature Description
UG.E380.GSM.book Page 70 Thursday, June 12, 2003 8:42 AM
71
PRELIMINARY
Phone Features
Menu Features
Haptic
Vibrations
Turn on or off the vibrations in
special games and ring tones:
M
>
Settings
>
Other Settings
>
Initial Setup
>
Haptics
Main Menu
Reorder your phone’s main menu:
M
>
Settings
>
Other Settings
>
Personalize
>
Main Menu
Soft Keys
Change soft key labels in the idle
display:
M
>
Settings
>
Other Settings
>
Personalize
>
Keys
Shortcuts
Create a shortcut to a menu item:
Highlight the menu item, then press
and hold
M
.
Select a shortcut:
M
>
MyMenu
> shortcut name
Feature Description
Language
Set menu language:
M
>
Settings
>
Other Settings
>
Initial Setup
>
Language
Master
Reset
Reset all options except unlock
code, security code, lifetime timer:
M
>
Settings
>
Other Settings
>
Initial Setup
>
Master Reset
Feature Description
UG.E380.GSM.book Page 71 Thursday, June 12, 2003 8:42 AM
72
Phone Features
PRELIMINARY
Dialing Features
Master
Clear
Reset all options except unlock
code, security code, lifetime timer,
clear all user settings and entries:
M
>
Settings
>
Other Settings
>
Initial Setup
>
Master Clear
Feature Description
Fixed Dial
Turn fixed dialing on or off:
M
>
Settings
>
Security
>
Fixed Dial
Use the fixed dial list:
M
>
Fixed Dial
Service Dial
Dial service phone
numbers:
M
>
Service Dial
Quick Dial
Dial pre-programmed
phone numbers:
M
>
Quick Dial
Feature Description
UG.E380.GSM.book Page 72 Thursday, June 12, 2003 8:42 AM
73
PRELIMINARY
Phone Features
Call Monitoring Features
Network connection time is the elapsed time from the moment you
connect to your service provider's network to the moment you end the
call by pressing the end key. This time includes busy signals and
ringing.
The amount of network connection time you track on your
resettable timer may not equal the amount of time for which you
are billed by your service provider. For billing information, please
contact your service provider directly.
DTMF
Tones
Activate DTMF tones:
M
>
Settings
>
Other Settings
>
Initial Setup
>
DTMF
Send DTMF tones during a call:
Press number keys
Send stored numbers as DTMF
tones during a call:
Highlight a number in the phonebook
or recent call lists, then press
M
>
Send Tones
Feature Description
Call Times
View call timers:
M
>
Recent Calls
>
Call Times
Feature Description
UG.E380.GSM.book Page 73 Thursday, June 12, 2003 8:42 AM
74
Phone Features
PRELIMINARY
Hands-Free Features
Data and Fax Call Features
In-Call
Timer
Display time or cost
information during a call:
M
>
Settings
>
In-Call Setup
>
In-Call Timer
Call Cost
View call cost trackers:
M
>
Recent Calls
>
Call Cost
Feature Description
Auto
Answer
(car kit or
headset)
Automatically answer calls
when connected to a car kit
or headset:
M
>
Settings
>
Other Settings
>
Car Settings
or
Headset
>
Auto Answer
Feature Description
Send Data
or Fax
Connect your phone to the
device, then place the call
through the device
application
Feature Description
UG.E380.GSM.book Page 74 Thursday, June 12, 2003 8:42 AM
75
PRELIMINARY
Phone Features
Network Features
Personal Organizer Features
Talk Then
Fax
Connect your phone to the
device, enter the number,
press
M
>
Talk Then Fax
,
then press
N
to make the
call
Feature Description
Network
Settings
View network information
and adjust network
settings:
M
>
Settings
>
Other Settings
>
Network
Feature Description
Add
Datebook
Event
Add an event to the datebook:
M
>
Office Tools
>
Datebook
> day
M
>
New
View
Datebook
Event
View or edit event details:
M
>
Office Tools
>
Datebook
> day
>event name
Respond to
Event
Reminder
View event when reminder appears:
VIEW
(
+
)
Dismiss event reminder:
EXIT
(
-
)
Feature Description
UG.E380.GSM.book Page 75 Thursday, June 12, 2003 8:42 AM
76
Phone Features
PRELIMINARY
Set Alarm
Clock
You can set alarms to make your
phone ring.
M
>
Alarm Clock
>
[New Alarm]
Alarms do not appear in the
datebook and do not ring if your
phone is off.
View Alarm
Clock
To see or change an alarm you set:
M
>
Alarm Clock
> the alarm
Scroll (
S
) to the alarm. Press the
right softkey (
+
) to
ENABLE
or
DISABLE
the alarm. Press
M
for more
options.
Respond to
Alarm
Alarms ring for 30 minutes unless
you press
DISABLE
(
-
) to turn off the alarm, or
SNOOZE
(
+
) to snooze for 8 minutes.
Calculator
Calculate numbers:
M
>
Office Tools
>
Calculator
Currency
Converter
Convert currency:
M
>
Office Tools
>
Calculator
M
>
Exchange Rate
Enter exchange rate, press
OK
(
+
),
enter amount, select
$
function
Feature Description
UG.E380.GSM.book Page 76 Thursday, June 12, 2003 8:42 AM
77
PRELIMINARY
Phone Features
Security Features
News and Entertainment Features
Feature Description
SIM PIN
Lock or unlock the SIM card:
M
>
Settings
>
Security
>
SIM PIN
Caution:
If you enter an incorrect
PIN code 3 times in a row, your SIM
card is disabled and your phone
displays
SIM Blocked
.
Lock
Application
Lock phone applications:
M
>
Settings
>
Security
>
Lock Application
Feature Description
Launch
Micro-
Browser
Start a micro-browser session:
M
>
Web Access
>
Browser
Web
Sessions
Select or create a Web session:
M
>
Web Access
>
Web Sessions
Launch
Game or
Application
Launch a game or application:
M
>
Games & Apps
, highlight the
application, press
SELECT
(
+
)
Download
Game or
Application
(not China)
Download a game or application:
M
>
Web Access
>
Browser
, find the
application, press
SELECT
(
+
), press
DWNLOAD
(
+
)
UG.E380.GSM.book Page 77 Thursday, June 12, 2003 8:42 AM
78
Phone Features
PRELIMINARY
Download
Game or
Application
(China only)
Download a game or application:
M
>
Get JavaApps
and select a Web
Session to open a list of applications
you can download.
Network
Access
Edit network connection settings for
Java games and applications:
M
>
Java Tools
Application
Manager
View information about a Java game
or application:
Highlight the application and press
M
Java
System
View Java version and memory
information:
M
>
Java Tools
>
Java System
Feature Description
UG.E380.GSM.book Page 78 Thursday, June 12, 2003 8:42 AM
79
PRELIMINARY
Specific Absorption Rate Data
Specific Absorption Rate Data
This model phone meets the government’s requirements for
exposure to radio waves.
Your mobile phone is a radio transmitter and receiver. It is designed and
manufactured not to exceed limits for exposure to radio frequency (RF)
energy. These limits are part of comprehensive guidelines and establish
permitted levels of RF energy for the general population. The guidelines
are based on standards that were developed by independent scientific
organizations through periodic and thorough evaluation of scientific
studies. The guidelines include a substantial safety margin designed to
assure the safety of all persons, regardless of age and health.
The exposure standard for mobile phones employs a unit of
measurement known as the Specific Absorption Rate, or SAR. Under the
guidelines for your phone model, the SAR limit is 2.0 W/kg.
1
Tests for
SAR are conducted in accordance with CENELEC
2
testing procedures
using standard operating positions with the phone transmitting at its
highest certified power level in all tested frequency bands. Although the
SAR is determined at the highest certified power level, the actual SAR of
the phone while operating can be well below the maximum value. This is
because the phone is designed to operate at multiple power levels so as
to use only the power required to reach the network. In general, the closer
you are to a base station, the lower the power output of the phone.
Before a phone model is available for sale to the public, it is tested to
confirm compliance with the guidelines. The tests are performed in
positions and locations (e.g., at the ear and worn on the body) that
conform to a uniform testing methodology determined by an expert
standards body. The highest SAR value for this model phone when tested
for use at the ear is __ W/kg.
3
While there may be differences between the SAR levels of various
phones and at various positions, they all meet the governmental
requirements for safe exposure. Please note that improvements to this
UG.E380.GSM.book Page 79 Thursday, June 12, 2003 8:42 AM
80
PRELIMINARY
product model could cause differences in the SAR value for later
products; in all cases, products are designed to be within the guidelines.
1. The SAR limit recommended by international guidelines (ICNIRP) for mobile
phones used by the public is 2.0 watts/kilogram (W/kg) averaged over ten
grams of tissue. The limit incorporates a substantial margin for safety to give
additional protection for the public and to account for any variations in
measurements.
2. CENELEC is a European Union standards body.
3.
Additional related information includes the Motorola testing protocol,
assessment procedure, and measurement uncertainty range for this product.
UG.E380.GSM.book Page 80 Thursday, June 12, 2003 8:42 AM
81
PRELIMINARY
Additional Health and Safety Information
The U.S. Food and Drug
Administration's Center
for Devices and Radiological
Health Consumer Update on
Mobile Phones
FDA has been receiving inquiries about the safety of mobile phones,
including cellular phones and PCS phones. The following summarizes
what is known—and what remains unknown—about whether these
products can pose a hazard to health, and what can be done to minimize
any potential risk. This information may be used to respond to questions.
Why the concern?
Mobile phones emit low levels of radio frequency energy (i.e., radio
frequency radiation) in the microwave range while being used. They also
emit very low levels of radio frequency energy (RF), considered non-
significant, when in the stand-by mode. It is well known that high levels of
RF can produce biological damage through heating effects (this is how
your microwave oven is able to cook food). However, it is not known
whether, to what extent, or through what mechanism, lower levels of RF
might cause adverse health effects as well. Although some research has
been done to address these questions, no clear picture of the biological
effects of this type of radiation has emerged to date. Thus, the available
science does not allow us to conclude that mobile phones are absolutely
safe, or that they are unsafe. However, the available scientific evidence
does not demonstrate any adverse health effects associated with the use
of mobile phones.
What kinds of phones are in question?
Questions have been raised about hand-held mobile phones, the kind
that have a built-in antenna that is positioned close to the user's head
during normal telephone conversation. These types of mobile phones are
UG.E380.GSM.book Page 81 Thursday, June 12, 2003 8:42 AM
82
PRELIMINARY
of concern because of the short distance between the phone's antenna—
the primary source of the RF—and the person's head. The exposure to
RF from mobile phones in which the antenna is located at greater
distances from the user (on the outside of a car, for example) is drastically
lower than that from hand-held phones, because a person's RF exposure
decreases rapidly with distance from the source. The safety of so-called
“cordless phones,” which have a base unit connected to the telephone
wiring in a house and which operate at far lower power levels and
frequencies, has not been questioned.
How much evidence is there that hand-held
mobile phones might be harmful?
Briefly, there is not enough evidence to know for sure, either way;
however, research efforts are on-going. The existing scientific evidence is
conflicting and many of the studies that have been done to date have
suffered from flaws in their research methods. Animal experiments
investigating the effects of RF exposures characteristic of mobile phones
have yielded conflicting results. A few animal studies, however, have
suggested that low levels of RF could accelerate the development of
cancer in laboratory animals. In one study, mice genetically altered to be
predisposed to developing one type of cancer developed more than twice
as many such cancers when they were exposed to RF energy compared
to controls. There is much uncertainty among scientists about whether
results obtained from animal studies apply to the use of mobile phones.
First, it is uncertain how to apply the results obtained in rats and mice to
humans. Second, many of the studies that showed increased tumor
development used animals that had already been treated with cancer-
causing chemicals, and other studies exposed the animals to the RF
virtually continuously—up to 22 hours per day.
For the past five years in the United States, the mobile phone industry has
supported research into the safety of mobile phones. This research has
resulted in two findings in particular that merit additional study:
1 In a hospital-based, case-control study, researchers looked for an
association between mobile phone use and either glioma (a type of
UG.E380.GSM.book Page 82 Thursday, June 12, 2003 8:42 AM
83
PRELIMINARY
brain cancer) or acoustic neuroma (a benign tumor of the nerve
sheath). No statistically significant association was found between
mobile phone use and acoustic neuroma. There was also no
association between mobile phone use and gliomas when all types of
types of gliomas were considered together. It should be noted that
the average length of mobile phone exposure in this study was less
than three years.
When 20 types of glioma were considered separately, however, an
association was found between mobile phone use and one rare type
of glioma, neuroepithelliomatous tumors. It is possible with multiple
comparisons of the same sample that this association occurred by
chance. Moreover, the risk did not increase with how often the mobile
phone was used, or the length of the calls. In fact, the risk actually
decreased with cumulative hours of mobile phone use. Most cancer
causing agents increase risk with increased exposure. An ongoing
study of brain cancers by the National Cancer Institute is expected to
bear on the accuracy and repeatability of these results.
1
2 Researchers conducted a large battery of laboratory tests to assess
the effects of exposure to mobile phone RF on genetic material.
These included tests for several kinds of abnormalities, including
mutations, chromosomal aberrations, DNA strand breaks, and
structural changes in the genetic material of blood cells called
lymphocytes. None of the tests showed any effect of the RF except
for the micronucleus assay, which detects structural effects on the
genetic material. The cells in this assay showed changes after
exposure to simulated cell phone radiation, but only after 24 hours of
exposure. It is possible that exposing the test cells to radiation for this
long resulted in heating. Since this assay is known to be sensitive to
heating, heat alone could have caused the abnormalities to occur.
The data already in the literature on the response of the micronucleus
assay to RF are conflicting. Thus, follow-up research is necessary.
2
FDA is currently working with government, industry, and academic groups
to ensure the proper follow-up to these industry-funded research findings.
Collaboration with the Cellular Telecommunications Industry Association
UG.E380.GSM.book Page 83 Thursday, June 12, 2003 8:42 AM
84
PRELIMINARY
(CTIA) in particular is expected to lead to FDA providing research
recommendations and scientific oversight of new CTIA-funded research
based on such recommendations.
Two other studies of interest have been reported recently in the literature:
1 Two groups of 18 people were exposed to simulated mobile phone
signals under laboratory conditions while they performed cognitive
function tests. There were no changes in the subjects' ability to recall
words, numbers, or pictures, or in their spatial memory, but they were
able to make choices more quickly in one visual test when they were
exposed to simulated mobile phone signals. This was the only
change noted among more than 20 variables compared.
3
2 In a study of 209 brain tumor cases and 425 matched controls, there
was no increased risk of brain tumors associated with mobile phone
use. When tumors did exist in certain locations, however, they were
more likely to be on the side of the head where the mobile phone was
used.
Because this occurred in only a small number of cases, the increased
likelihood was too small to be statistically significant.
4
In summary, we do not have enough information at this point to assure
the public that there are, or are not, any low incident health problems
associated with use of mobile phones. FDA continues to work with all
parties, including other federal agencies and industry, to assure that
research is undertaken to provide the necessary answers to the
outstanding questions about the safety of mobile phones.
What is known about cases of human cancer
that have been reported in users of hand-held
mobile phones?
Some people who have used mobile phones have been diagnosed with
brain cancer. But it is important to understand that this type of cancer also
occurs among people who have not used mobile phones. In fact, brain
cancer occurs in the U.S. population at a rate of about 6 new cases per
UG.E380.GSM.book Page 84 Thursday, June 12, 2003 8:42 AM
85
PRELIMINARY
100,000 people each year. At that rate, assuming 80 million users of
mobile phones (a number increasing at a rate of about 1 million per
month), about 4800 cases of brain cancer would be expected each year
among those 80 million people, whether or not they used their phones.
Thus it is not possible to tell whether any individual's cancer arose
because of the phone, or whether it would have happened anyway. A key
question is whether the risk of getting a particular form of cancer is
greater among people who use mobile phones than among the rest of the
population. One way to answer that question is to compare the usage of
mobile phones among people with brain cancer with the use of mobile
phones among appropriately matched people without brain cancer. This
is called a case-control study. The current case-control study of brain
cancers by the National Cancer Institute, as well as the follow-up
research to be sponsored by industry, will begin to generate this type of
information.
What is FDA's role concerning the safety of
mobile phones?
Under the law, FDA does not review the safety of radiation-emitting
consumer products such as mobile phones before marketing, as it does
with new drugs or medical devices. However, the agency has authority to
take action if mobile phones are shown to emit radiation at a level that is
hazardous to the user. In such a case, FDA could require the
manufacturers of mobile phones to notify users of the health hazard and
to repair, replace or recall the phones so that the hazard no longer exists.
Although the existing scientific data do not justify FDA regulatory actions
at this time, FDA has urged the mobile phone industry to take a number of
steps to assure public safety. The agency has recommended that the
industry:
•
support needed research into possible biological effects of RF of the
type emitted by mobile phones
•
design mobile phones in a way that minimizes any RF exposure to
the user that is not necessary for device function
UG.E380.GSM.book Page 85 Thursday, June 12, 2003 8:42 AM
86
PRELIMINARY
•
cooperate in providing mobile phone users with the best possible
information on what is known about possible effects of mobile phone
use on human health
At the same time, FDA belongs to an interagency working group of the
federal agencies that have responsibility for different aspects of mobile
phone safety to ensure a coordinated effort at the federal level. These
agencies are:
•
National Institute for Occupational Safety and Health
•
Environmental Protection Agency
•
Federal Communications Commission
•
Occupational Health and Safety Administration
•
National Telecommunications and Information Administration
The National Institutes of Health also participates in this group.
In the absence of conclusive information about
any possible risk, what can concerned
individuals do?
If there is a risk from these products—and at this point we do not know
that there is—it is probably very small. But if people are concerned about
avoiding even potential risks, there are simple steps they can take to do
so. For example, time is a key factor in how much exposure a person
receives. Those persons who spend long periods of time on their hand-
held mobile phones could consider holding lengthy conversations on
conventional phones and reserving the hand-held models for shorter
conversations or for situations when other types of phones are not
available.
People who must conduct extended conversations in their cars every day
could switch to a type of mobile phone that places more distance between
their bodies and the source of the RF, since the exposure level drops off
dramatically with distance. For example, they could switch to:
•
a mobile phone in which the antenna is located outside the vehicle
UG.E380.GSM.book Page 86 Thursday, June 12, 2003 8:42 AM
87
PRELIMINARY
•
a hand-held phone with a built-in antenna connected to a different
antenna mounted on the outside of the car or built into a separate
package
•
a headset with a remote antenna to a mobile phone carried at the
waist
Again, the scientific data do not demonstrate that mobile phones are
harmful. But if people are concerned about the radio frequency energy
from these products, taking the simple precautions outlined above can
reduce any possible risk.
Where can I find additional information?
For additional information, see the following Web sites:
Federal Communications Commission
(FCC) RF Safety Program
(select “Information on Human Exposure to RF Fields from Cellular and
PCS Radio Transmitters”):
http://www.fcc.gov/oet/rfsafety
World Health Organization
(WHO) International Commission on
Non-Ionizing Radiation Protection (select Qs & As):
http://
www.who.int/emf
United Kingdom, National Radiological Protection Board
:
http://www.nrpb.org.uk
Cellular Telecommunications Industry Association
(CTIA):
http://www.wow-com.com
U.S. Food and Drug Administration
(FDA) Center for Devices and
Radiological Health:
http://www.fda.gov/cdrh/consumer/
1. Muscat et al. Epidemiological Study of Cellular Telephone Use and Malignant
Brain Tumors. In: State of the Science Symposium;1999 June 20; Long
Beach, California.
2. Tice et al. Tests of mobile phone signals for activity in genotoxicity and other
laboratory assays. In: Annual Meeting of the Environmental Mutagen Society;
UG.E380.GSM.book Page 87 Thursday, June 12, 2003 8:42 AM
88
PRELIMINARY
March 29, 1999, Washington, D.C.; and personal communication,
unpublished results.
3. Preece, AW, Iwi, G, Davies-Smith, A, Wesnes, K, Butler, S, Lim, E, and Varey,
A. Effect of a 915-MHz simulated mobile phone signal on cognitive function
in man. Int. J. Radiat. Biol., April 8, 1999.
4. Hardell, L, Nasman, A, Pahlson, A, Hallquist, A and Mild, KH. Use of cellular
telephones and the risk for brain tumors: a case-control study. Int. J. Oncol.,
15: 113-116, 1999.
UG.E380.GSM.book Page 88 Thursday, June 12, 2003 8:42 AM
89
PRELIMINARY
Warranty
Motorola Limited Warranty for
the United States and Canada
What Does this Warranty Cover?
Subject to the exclusions contained below, Motorola, Inc. warrants its
telephones, pagers, messaging devices, and consumer and professional
two-way radios (excluding commercial, government or industrial radios)
that operate via Family Radio Service or General Mobile Radio Service,
Motorola-branded or certified accessories sold for use with these
Products (“Accessories”) and Motorola software contained on CD-ROMs
or other tangible media and sold for use with these Products (“Software”)
to be free from defects in materials and workmanship under normal
consumer usage for the period(s) outlined below. This limited warranty is
a consumer's exclusive remedy, and applies as follows to new Motorola
Products, Accessories and Software purchased by consumers in the
United States or Canada, which are accompanied by this written
warranty:
Products and Accessories
Products Covered Length of Coverage
Products and Accessories
as
defined above, unless otherwise
provided for below.
One (1) year
from the date of
purchase by the first consumer
purchaser of the product unless
otherwise provided for below.
Decorative Accessories and
Cases
. Decorative covers,
bezels, PhoneWrap™ covers
and cases.
Limited lifetime warranty
for the
lifetime of ownership by the first
consumer purchaser of the
product.
UG.E380.GSM.book Page 89 Thursday, June 12, 2003 8:42 AM
90
PRELIMINARY
Exclusions
Normal Wear and Tear.
Periodic maintenance, repair and replacement
of parts due to normal wear and tear are excluded from coverage.
Batteries.
Only batteries whose fully charged capacity falls below 80% of
their rated capacity and batteries that leak are covered by this limited
warranty.
Abuse & Misuse.
Defects or damage that result from: (a) improper
operation, storage, misuse or abuse, accident or neglect, such as
physical damage (cracks, scratches, etc.) to the surface of the product
resulting from misuse; (b) contact with liquid, water, rain, extreme
humidity or heavy perspiration, sand, dirt or the like, extreme heat, or
food; (c) use of the Products or Accessories for commercial purposes or
subjecting the Product or Accessory to abnormal usage or conditions; or
(d) other acts which are not the fault of Motorola, are excluded from
coverage.
Use of Non-Motorola Products and Accessories.
Defects or damage
that result from the use of Non-Motorola branded or certified Products,
Accessories, Software or other peripheral equipment are excluded from
coverage.
Monaural Headsets.
Ear buds
and boom headsets that transmit
mono sound through a wired
connection.
Limited lifetime warranty
for the
lifetime of ownership by the first
consumer purchaser of the
product.
Consumer and Professional
Two-Way Radio Accessories.
Ninety (90) days
from the date of
purchase by the first consumer
purchaser of the product.
Products and Accessories that
are Repaired or Replaced.
The balance of the original
warranty or for ninety (90) days
from the date returned to the
consumer, whichever is longer.
Products Covered Length of Coverage
UG.E380.GSM.book Page 90 Thursday, June 12, 2003 8:42 AM
91
PRELIMINARY
Unauthorized Service or Modification.
Defects or damages resulting
from service, testing, adjustment, installation, maintenance, alteration, or
modification in any way by someone other than Motorola, or its authorized
service centers, are excluded from coverage.
Altered Products.
Products or Accessories with (a) serial numbers or
date tags that have been removed, altered or obliterated; (b) broken seals
or that show evidence of tampering; (c) mismatched board serial
numbers; or (d) nonconforming or non-Motorola housings, or parts, are
excluded from coverage.
Communication Services.
Defects, damages, or the failure of Products,
Accessories or Software due to any communication service or signal you
may subscribe to or use with the Products Accessories or Software is
excluded from coverage.
Software
Exclusions
Software Embodied in Physical Media.
No warranty is made that the
software will meet your requirements or will work in combination with any
hardware or software applications provided by third parties, that the
operation of the software products will be uninterrupted or error free, or
that all defects in the software products will be corrected.
Software NOT Embodied in Physical Media.
Software that is not
embodied in physical media (e.g. software that is downloaded from the
internet), is provided “as is” and without warranty.
Who is Covered?
This warranty extends only to the first consumer purchaser, and is not
transferable.
Products Covered Length of Coverage
Software.
Applies only to physical defects
in the media that embodies the copy of the
software (e.g. CD-ROM, or floppy disk).
Ninety (90) days
from
the date of purchase.
UG.E380.GSM.book Page 91 Thursday, June 12, 2003 8:42 AM
92
PRELIMINARY
What Will Motorola Do?
Motorola, at its option, will at no charge repair, replace or refund the
purchase price of any Products, Accessories or Software that does not
conform to this warranty. We may use functionally equivalent
reconditioned/refurbished/pre-owned or new Products, Accessories or
parts. No data, software or applications added to your Product, Accessory
or Software, including but not limited to personal contacts, games and
ringer tones, will be reinstalled. To avoid losing such data, software and
applications please create a back up prior to requesting service.
How to Obtain Warranty Service or Other
Information
You will receive instructions on how to ship the Products, Accessories or
Software, at your expense, to a Motorola Authorized Repair Center. To
obtain service, you must include: (a) a copy of your receipt, bill of sale or
other comparable proof of purchase; (b) a written description of the
problem; (c) the name of your service provider, if applicable; (d) the name
and location of the installation facility (if applicable) and, most importantly;
(e) your address and telephone number.
What Other Limitations Are There?
ANY IMPLIED WARRANTIES, INCLUDING WITHOUT LIMITATION THE
IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A
USA
Phones
1-800-331-6456
Pagers
1-800-548-9954
Two-Way Radios
and Messaging Devices
1-800-353-2729
Canada
All Products
1-800-461-4575
TTY
1-888-390-6456
For
Accessories
and
Software
, please call the telephone number
designated above for the product with which they are used.
UG.E380.GSM.book Page 92 Thursday, June 12, 2003 8:42 AM
93
PRELIMINARY
PARTICULAR PURPOSE, SHALL BE LIMITED TO THE DURATION OF
THIS LIMITED WARRANTY, OTHERWISE THE REPAIR,
REPLACEMENT, OR REFUND AS PROVIDED UNDER THIS EXPRESS
LIMITED WARRANTY IS THE EXCLUSIVE REMEDY OF THE
CONSUMER, AND IS PROVIDED IN LIEU OF ALL OTHER
WARRANTIES, EXPRESS OR IMPLIED. IN NO EVENT SHALL
MOTOROLA BE LIABLE, WHETHER IN CONTRACT OR TORT
(INCLUDING NEGLIGENCE) FOR DAMAGES IN EXCESS OF THE
PURCHASE PRICE OF THE PRODUCT, ACCESSORY OR
SOFTWARE, OR FOR ANY INDIRECT, INCIDENTAL, SPECIAL OR
CONSEQUENTIAL DAMAGES OF ANY KIND, OR LOSS OF REVENUE
OR PROFITS, LOSS OF BUSINESS, LOSS OF INFORMATION OR
DATA, SOFTWARE OR APPLICATIONS OR OTHER FINANCIAL LOSS
ARISING OUT OF OR IN CONNECTION WITH THE ABILITY OR
INABILITY TO USE THE PRODUCTS, ACCESSORIES OR SOFTWARE
TO THE FULL EXTENT THESE DAMAGES MAY BE DISCLAIMED BY
LAW.
Some states and jurisdictions do not allow the limitation or
exclusion of incidental or consequential damages, or limitation on
the length of an implied warranty, so the above limitations or
exclusions may not apply to you. This warranty gives you specific
legal rights, and you may also have other rights that vary from state
to state or from one jurisdiction to another.
Laws in the United States and other countries preserve for Motorola
certain exclusive rights for copyrighted Motorola software such as the
exclusive rights to reproduce and distribute copies of the Motorola
software. Motorola software may only be copied into, used in, and
redistributed with, the Products associated with such Motorola software.
No other use, including without limitation disassembly of such Motorola
software or exercise of the exclusive rights reserved for Motorola, is
permitted.
UG.E380.GSM.book Page 93 Thursday, June 12, 2003 8:42 AM
94
PRELIMINARY
Product Registration
Product Registration
Online Product Registration:
http://www.motorola.com/warranty
Product registration is an important step toward enjoying your new
Motorola product. Registering helps us facilitate warranty service, and
permits us to contact you should your product require an update or other
service. Registration is for U.S. residents only and is not required for
warranty coverage.
Please retain your original dated sales receipt for your records. For
warranty service of your Motorola Personal Communications Product you
will need to provide a copy of your dated sales receipt to confirm warranty
status.
Thank you for choosing a Motorola product.
Export Law Assurances
Export Law Assurances
This product is controlled under the export regulations of the United
States of America and Canada. The Governments of the United States of
America and Canada may restrict the exportation or re-exportation of this
product to certain destinations. For further information contact the U.S.
Department of Commerce or the Canadian Department of Foreign Affairs
and International Trade.
RF Energy Interference
RF Energy Interference
This device complies with Part 15 of the FCC Rules. Operation is subject
to the following two conditions: (1) this device may not cause harmful
interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation.
UG.E380.GSM.book Page 94 Thursday, June 12, 2003 8:42 AM
95
PRELIMINARY
Index
A
accessories
connector ports 1
optional 13, 67
standard 12
accessory 41
Add Digits
feature 57
alarm clock 76
alert
creating 70
defined 46
indicators 24, 46
personalizing 70
setting 46
turning off 21
volume 70
animation
inserting in message 67
storing 67
wallpaper 48
application, locking and
unlocking 77
Attach Number
feature 57,
58
B
backlight 50
barring calls 66
battery
Battery Save
feature 50
charging 14–15
extending battery life
15–16, 50
installing 13
level indicator 15, 24, 26
block cursor, defined 32
C
calculator 76
call
adding digits after phone
number 57
alert profile, setting 46
alert, turning off 21
answer options 47
answering 22
barring 66
call waiting 61
canceling 53
costs 74
deleting 55
dialed calls list 55
dialing
dialing a recent call 55
emergency number 54
ending 21, 22
UG.E380.GSM.book Page 95 Thursday, June 12, 2003 8:42 AM
96
PRELIMINARY
forwarding 66
hold 62
ignoring 53
making
placing
prefix digits, inserting 58
received calls list 55
receiving 22
recent calls 55
storing 55
terminating 53
timers 73, 74
transferring 62
unanswered call 41, 57
call waiting 61
caller ID
incoming calls 53
outgoing calls 57
calling line identification.
See caller ID
car kit
automatic answer 74
categories, phonebook 69
chat 67
clock 23
club lights 47
codes. See passwords
color, display 50
conference call 66
contrast, display 50
cursor 30
D
data call
receive 75
send 74
date, setting 45
datebook 75
default passwords 43
deleting a call 55
dialed calls list 55
dialing
fixed numbers 72
quick dial numbers 72
service numbers 72
dialing a number
display
backlight 50
color 50
contrast 50
described 23
idle display 23
illustration 23
language 71
with phone closed 39
zoom setting 50
downloading 77, 78
DTMF tones 56
activating 73
sending 73
E
earpiece
UG.E380.GSM.book Page 96 Thursday, June 12, 2003 8:42 AM
97
PRELIMINARY
illustration 1
earpiece volume 20
emergency number 54
end key
functions 1, 21, 22, 28
ending a call 21, 22
Enter Unlock Code
message
42, 44
F
fax call
receive 75
send 74
fixed dial 72
flashing cursor, defined 30
forwarding calls 66
4-way navigation key 27
G
games 77, 78
Get JavaApps 78
H
hands-free mode
external display 41
hands-free use
automatic answer 74
haptics 71
headset
automatic answer 74
use with external display
41
Hide ID
feature 57
hold a call 62
I
idle display, defined 23
ignoring a call 53
incoming call
canceling 53
ignoring 53
terminating 53
Incoming Call
message 53
indicators
alert setting 24, 46
alert type 24, 46
battery level 15, 24, 26
GPRS 24
menu 23
message 25
message waiting 24
missed call 57
roam 24, 25
signal strength 24
silent alert 24, 46
text entry 25
transmit 25
vibrate alert 24, 46
iTAP software
activating 38
entering words 34
UG.E380.GSM.book Page 97 Thursday, June 12, 2003 8:42 AM
98
PRELIMINARY
J
Java applications 77, 78
K
key
end 1, 21, 22, 28
4-way navigation 27
left soft key 1, 28, 71
menu 1, 22, 28
navigation 1, 27
right soft key 1, 28, 71
send 1, 21, 22, 55
smart 1, 41
volume 1
volume control 20
keypad
answering calls 47
volume, adjusting 70
L
language, setting 71
Last Calls Menu
opening 56
options 56
left soft key
functions 1, 28
personalizing 71
lights
club 47
incoming call 69
line, active 52
lock
application 77
phone 42
SIM card 77
loud ring alert 24, 46
M
making a call
master clear 72
master reset 71
menu
entering text 30
language, setting 71
Last Calls Menu
56
lists 29
navigating 28
personalizing 71
quick 39
rearranging features 71
using features 30
menu indicator
defined 23
illustration 23
menu key 1, 22, 28
message
chat 67
deleting 67
locking 67
reading 67
sending 67
voicemail 59
message indicator
UG.E380.GSM.book Page 98 Thursday, June 12, 2003 8:42 AM
99
PRELIMINARY
defined 25
message waiting indicator
illustration 24
micro-browser
browser setup 77
Java applications 77
using 77
Web sessions 77
microphone 1
missed call indicator 57
Missed Calls
message 41,
57
my phone number 22
my telephone number 22
my tones 70
N
n character, storing in a
number 69
navigation key 1, 27
network settings 75
notepad
defined 58
entering digits 58
number, viewing your own
22
numeric text entry method
38
O
1-touch dial
defined 59
setting preference 70
using 59
optional accessory, defined
13
optional feature, defined 13
P
passwords
changing 43
default 43
if you forget a password
44
pause, storing in a number
69
phone
accessories, optional 13
accessories, standard 12
alert, turning off 21
answer options 47
clear stored information
72
date, setting 45
keypad, answering calls
47
language, setting 71
line 52
locking 42
network settings 75
1-touch dial 59
passwords 43, 44
reset all options 71
security code 44
UG.E380.GSM.book Page 99 Thursday, June 12, 2003 8:42 AM
100
PRELIMINARY
speed dial, using 59
text entry indicator 25
time, setting 45
unlock code 44
unlocking 20, 42
phone number
adding digits after 57
attaching to prefix digits
58
attaching two numbers
57
line 52
redialing 52
storing in phonebook 68
viewing your own 22
phonebook
attaching two numbers
57
categories 69
dialing a number 68
1-touch dial 59
prefix digits, inserting 58
speed dial number 59
speed dial, using 59
storing an entry 68
voice dialing 68
inserting in message 67
storing 67
wallpaper 48
PIN code
entering 77
PIN code, storing in number
69
predictive text entry
activating 38
entering words 34
profile
setting 46
prompt, storing in a number
69
Q
quick dial 72
quick menu 39
R
received calls list 55
receiving a call 22
recent calls 55
redial
busy number 52
right soft key
functions 1, 28
personalizing 71
ring alert
turning off 21
ring and vibrate alert 24, 46
ring style
setting 21
ring. See alert
ringer volume, setting 21
roam indicator
defined 25
UG.E380.GSM.book Page 100 Thursday, June 12, 2003 8:42 AM
101
PRELIMINARY
illustration 24
S
security code 44
send key 1, 21, 22, 55
sending a call. See making
a call
service dial 72
shortcuts
creating 71
Show ID
feature 57
signal strength indicator
defined 24
illustration 24
silent alert indicator 24, 46
silent ring style, setting 21
SIM Blocked
message 20,
77
SIM card
defined 16
locking 77
precautions 17
SIM Blocked
message 20,
77
SIM PIN code
entering 77
smart key
functions 41
location 1
soft keys
illustration 1, 28
personalizing 71
soft ring alert 24, 46
sound
inserting in message 67
storing 67
special characters 69
speed dial
number, defined 59
using 59
storing a call 55
symbol text method 36, 37
symbols, entering 36, 37
T
tap method text entry 31
telephone number, viewing
your own 22
text
block cursor 32
character chart 32
entering from keypad 30
entry method, changing
38
entry method, setup 38
flashing cursor 30
iTAP software predictive
text entry 34
numeric entry method 38
symbol chart 36
symbol method 36, 37
tap method 31
text entry indicator
defined 25
UG.E380.GSM.book Page 101 Thursday, June 12, 2003 8:42 AM
102
PRELIMINARY
text method, changing 38
text method, setup 38
time, setting 45
timers 73, 74
transfer a call 62
transmit indicator
defined 25
travel charger, using 15
TTY device 67
U
unlock
application 77
unlock code 42, 44
V
vibrate alert
indicator 24, 46
setting 46, 71
turning off 21, 71
vibrate ring style, setting 21
voice dial
dialing a number 68
voicemail 59
volume
earpiece 20
keypad 70
ringer 21, 70
volume keys 1, 20
W
wait, storing in a number 69
wallpaper 48
warranty 89
Web pages 77
Web sessions 77
Z
zoom setting 50
U.S. patent Re. 34,976
UG.E380.GSM.book Page 102 Thursday, June 12, 2003 8:42 AM
✂
PRELIMINARY
103
art# 020827-O.eps
Wireless Phone Safety
Tips
“Safety is your most important call!”
Your Motorola wireless telephone gives you
the powerful ability to communicate by voice—
almost anywhere, anytime, wherever wireless
phone service is available and safe conditions allow.
But an important responsibility accompanies the
benefits of wireless phones, one that every user
must uphold.
When driving a car, driving is your first
responsibility. If you find it necessary to use your
wireless phone while behind the wheel of a car,
practice good common sense and remember the
following tips:
1 Get to know your Motorola wireless phone and its
features such as speed dial and redial.
If available,
these features help you to place your call without taking
your attention off the road.
2 When available, use a hands-free device.
If possible,
add an additional layer of convenience to your wireless
UG.E380.GSM.book Page 103 Thursday, June 12, 2003 8:42 AM
✂
PRELIMINARY
104
phone with one of the many Motorola Original™ hands-
free accessories available today.
3 Position your wireless phone within easy reach.
Be
able to access your wireless phone without removing
your eyes from the road. If you receive an incoming call
at an inconvenient time, if possible, let your voice mail
answer it for you.
4 Let the person you are speaking with know you are
driving; if necessary, suspend the call in heavy
traffic or hazardous weather conditions.
Rain, sleet,
snow, ice, and even heavy traffic can be hazardous.
5 If you receive an incoming call at an inconvenient
time do not take notes or look up phone numbers
while driving.
Jotting down a “to do” list or going
through your address book takes attention away from
your primary responsibility—driving safely.
6 Dial sensibly and assess the traffic; if possible,
place calls when you are not moving or before
pulling into traffic.
Try to plan calls when your car will
be stationary. If you need to make a call while moving,
dial only a few numbers, check the road and your
mirrors, then continue.
7 Do not engage in stressful or emotional
conversations that may be distracting.
Make people
you are talking with aware you are driving and suspend
conversations which have the potential to divert your
attention away from the road.
8 Use your wireless phone to call for help.
Dial 9-1-1 or
other local emergency number in the case of fire, traffic
accident or medical emergencies.*
UG.E380.GSM.book Page 104 Thursday, June 12, 2003 8:42 AM
✂
PRELIMINARY
105
9 Use your wireless phone to help others in
emergencies.
If you see an auto accident, crime in
progress or other serious emergency where lives are in
danger, call 9-1-1 or other local emergency number, as
you would want others to do for you.*
10 Call roadside assistance or a special
non-emergency wireless assistance number when
necessary.
If you see a broken-down vehicle posing no
serious hazard, a broken traffic signal, a minor traffic
accident where no one appears injured, or a vehicle you
know to be stolen, call roadside assistance or other
special non-emergency wireless number.*
* Wherever wireless phone service is available.
UG.E380.GSM.book Page 105 Thursday, June 12, 2003 8:42 AM
✂
PRELIMINARY
106
Check the laws and regulations on the use of
wireless telephones and their accessories in the
areas where you drive. Always obey them. The
use of these devices may be prohibited or
restricted in certain areas.
For more information,
please call
1-888-901-SAFE
or visit the
CTIA Web site at
www.wow-com.com™
UG.E380.GSM.book Page 106 Thursday, June 12, 2003 8:42 AM
