Welcome

Welcome to the world of Motorola digital wireless

communications! We are pleased that you have chosen the

Motorola V500 GSM wireless phone.

Headset Jack

Insert headset

accessory for

handsfree use.

Volume Keys

Adjust earpiece &

ringer volume.

Voice Key

Create voice

records, phonebook

& shortcut names.

Accessory

Connector Port

Insert charger &

phone accessories.

Power & End Key

Turn phone on/off,

end calls, exit menu

system.

Right Soft Key

Perform functions

identified by right

display prompt.

Menu Key

Left Soft Key

Perform functions

identified by left

display prompt.

Send Key

Make & answer

calls, view recently

dialed calls list.

5-Way

Navigation Key

Scroll through

menus & lists, set

feature values.

Smart Key

Select menu items,

make & end calls.

DRAFT

Check It Out!

Feature Description

Take Photo

Press

CAMERA

(

) to activate the camera,

point lens at subject, press

CAPTURE

(

) to

take a photo.

Send Photo

Send the photo to a phone number or

email address:

Press

STORE

(

) >

Send In Message

Camera Lens

Take photos to send

to others & use on

your phone.

Smart Key

Set ring style & call

forwarding with flip

closed, answer

calls with headset

accessory.

Mirror

Aim camera lens for

self portraits.

External Display

View incoming call

information.

Handsree Speaker

(on back of phone)

DRAFT

Set Photo as

Picture Caller

Assign a photo to a phonebook entry to

enable picture caller ID:

Multimedia

Pictures

> photo

Apply As Phonebook Entry

Send

Multimedia

Message

Send a multimedia message

with pictures, animations, and

sounds:

Messages

Create Message

New Multimedia Msg

Send Letter

Send a multimedia letter:

Messages

Create Message

New Letter

Wireless

Connection

Set up a Bluetooth™ wireless connection

to a headset accessory, car kit, or

external device:

Settings

Connection

Bluetooth Link

Handsfree

[Look For Devices]

Phone Theme

Apply a phone theme:

Multimedia

Themes

> theme

Feature Description

DRAFT

Motorola, Inc.

Consumer Advocacy Office

1307 East Algonquin Road

Schaumburg, IL 60196

1-800-331-6456 (United States)

1-888-390-6456 (TTY/TDD United States)

1-800-461-4575 (Canada)

www.motorola.com

(United States)

www.motorola.ca

(Canada)

MOTOROLA and the Stylized M Logo are registered in the US Patent &

Trademark Office. The Bluetooth trademarks are owned by their

proprietor and used by Motorola, Inc. under license. Java and all other

Java-based marks are trademarks or registered trademarks of Sun

Microsystems, Inc. in the U.S. and other countries. All other product or

service names are the property of their respective owners.

Software Copyright Notice

The Motorola products described in this manual may include copyrighted

Motorola and third-party software stored in semiconductor memories or

other media. Laws in the United States and other countries preserve for

Motorola and third-party software providers certain exclusive rights for

copyrighted software, such as the exclusive rights to distribute or

reproduce the copyrighted software. Accordingly, any copyrighted

software contained in the Motorola products may not be modified,

reverse-engineered, distributed, or reproduced in any manner to the

extent allowed by law. Furthermore, the purchase of the Motorola

products shall not be deemed to grant either directly or by implication,

estoppel, or otherwise, any license under the copyrights, patents, or

patent applications of Motorola or any third-party software provider,

except for the normal, non-exclusive, royalty-free license to use that

arises by operation of law in the sale of a product.

Manual number: 68XXXXXX21-O

Cover number: 8988485L61-O

DRAFT
