Exhibit 8 Users Manual

APPLICANT: MOTOROLA, INC. FCC ID: IHDT56EF1

EXHIBIT 8

INSTRUCTION MANUAL

A preliminary draft copy of the Users Manual follows:

START HERE >

A840

CDMA

DRAFT

Welcome

Welcome to the world of Motorola digital wireless

communications! We are pleased that you have chosen the

Motorola A840 wireless phone.

CLR Key

Volume Keys

Adjust earpiece

& ringer volume.

Smart Key

Select menu

items, make &

end calls, set

ring styles.

Voice

Recognition Key

Press once to

activate speaker-

independent

voice recognition.

Press & hold to

record voice

records, contacts,

& shortcut names.

Accessory Port

Send Key

Make &

answer calls,

view recently

dialed calls list.

Left Soft Key

Perform

functions

identified by left

display prompt.

Right Soft Key

Perform

functions

identified by right

display prompt.

5-Way

Navigation Key

Scroll through menus

& lists, set feature

values. In menus,

press k to select

highlighted item.

Power/End Key

Turn phone

on/off, end

phone calls,

exit menus.

Camera Key

DRAFT

Check It Out!

Feature Description

Take Photo

Press the camera key to activate the

camera, point lens at subject, press

CAPTURE

(

) to take a photo.

Send Photo

Send the photo to a phone number

Press

STORE

(

) >

Send In Message

Headset Jack

Camera Lens

Take photos to send

to others & use

on your phone.

External

Display

Integrated Short-

Range Flash

Projected when

taking flash photos.

Camera Key

DRAFT

Set Photo as

Picture Caller

After you capture a photo, assign it to a

phonebook entry to enable picture caller

ID:

Multimedia

Pictures

> photo

Apply As

Phonebook Entry

Send

Multimedia

Message

Send a multimedia messag with

pictures, animations, and

sounds:

Messages

Create Message

New Multimedia Msg

Send Letter

Send a multimedia letter:

Messages

Create Message

New Short Msg

Read

Multimedia

Message

Read a new multimedia message or

letter you have received:

Press

READ

(

)

Select

Account

(CDMA/GSM)

Select from CDMA and GSM

accounts:

Settings

Phone Mode

> desired account

Feature Description

032380o

DRAFT

Motorola, Inc.

Consumer Advocacy Office

1307 East Algonquin Road

Schaumburg, IL 60196

1-800-331-6456 (United States)

1-888-390-6456 (TTY/TDD United States)

1-800-461-4575 (Canada)

www.motorola.com

(United States)

www.motorola.ca

(Canada)

MOTOROLA and the Stylized M Logo are registered in the US Patent &

Trademark Office. The Bluetooth trademarks are owned by their proprietor and

used by Motorola, Inc. under license. All other product or service names are

the property of their respective owners.

Caution:

Changes or modifications made in the radio phone, not expressly

approved by Motorola, will void the user’s authority to operate the equipment.

Software Copyright Notice

The Motorola products described in this manual may include copyrighted

Motorola and third-party software stored in semiconductor memories or other

media. Laws in the United States and other countries preserve for Motorola

and third-party software providers certain exclusive rights for copyrighted

software, such as the exclusive rights to distribute or reproduce the copyrighted

software. Accordingly, any copyrighted software contained in the Motorola

products may not be modified, reverse-engineered, distributed, or reproduced

in any manner to the extent allowed by law. Furthermore, the purchase of the

Motorola products shall not be deemed to grant either directly or by implication,

estoppel, or otherwise, any license under the copyrights, patents, or patent

applications of Motorola or any third-party software provider, except for the

normal, non-exclusive, royalty-free license to use that arises by operation of

law in the sale of a product.

Manual number: 6809482A51-O

DRAFT

Contents

Getting Started

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

About This Guide . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

Installing the SIM Card . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

Battery Use. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

Installing the Battery . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

Charging the Battery. . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

Turning On Your Phone. . . . . . . . . . . . . . . . . . . . . . . . . . 12

Adjusting Volume . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

Making a Call . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

Answering a Call. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

Changing the Call Alert. . . . . . . . . . . . . . . . . . . . . . . . . . 15

Viewing Your Phone Number . . . . . . . . . . . . . . . . . . . . . 15

Highlight Features

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

Taking and Sending a Photo. . . . . . . . . . . . . . . . . . . . . . 16

TTY Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

Learning to Use Your Phone

. . . . . . . . . . . . . . . . . . . . . . 21

Using the Display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

Using the 5-Way Navigation Key. . . . . . . . . . . . . . . . . . . 24

Using Menus. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25

Entering Text. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28

Using the Smart Key. . . . . . . . . . . . . . . . . . . . . . . . . . . . 38

Using the External Display . . . . . . . . . . . . . . . . . . . . . . . 39

Using the Handsfree Speaker. . . . . . . . . . . . . . . . . . . . . 40

Changing a Code, PIN, or Password . . . . . . . . . . . . . . . 40

Locking and Unlocking Your Phone . . . . . . . . . . . . . . . . 41

If You Forget a Code, PIN, or Password . . . . . . . . . . . . . 42

Using the Phonebook . . . . . . . . . . . . . . . . . . . . . . . . . . . 43

DRAFT

Setting Up Your Phone

. . . . . . . . . . . . . . . . . . . . . . . . . . 51

Setting the Time and Date . . . . . . . . . . . . . . . . . . . . . . 51

Setting an Alert Style . . . . . . . . . . . . . . . . . . . . . . . . . . 51

Setting Answer Options. . . . . . . . . . . . . . . . . . . . . . . . . 52

Setting a Wallpaper Image . . . . . . . . . . . . . . . . . . . . . . 52

Setting a Screen Saver Image . . . . . . . . . . . . . . . . . . . 53

Setting Display Color. . . . . . . . . . . . . . . . . . . . . . . . . . . 54

Setting Phone Greeting. . . . . . . . . . . . . . . . . . . . . . . . . 54

Adjusting the Backlight . . . . . . . . . . . . . . . . . . . . . . . . . 55

Setting Display Contrast . . . . . . . . . . . . . . . . . . . . . . . . 55

Setting Display Brightness . . . . . . . . . . . . . . . . . . . . . . 55

Hiding or Showing Location Information . . . . . . . . . . . . 55

Conserving Battery Power . . . . . . . . . . . . . . . . . . . . . . 56

Calling Features

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57

Changing the Active Line . . . . . . . . . . . . . . . . . . . . . . . 57

Redialing a Number . . . . . . . . . . . . . . . . . . . . . . . . . . . 57

Turning Off a Call Alert . . . . . . . . . . . . . . . . . . . . . . . . . 58

Using Caller ID . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58

Calling an Emergency Number . . . . . . . . . . . . . . . . . . . 59

Viewing Recent Calls . . . . . . . . . . . . . . . . . . . . . . . . . . 59

Returning an Unanswered Call . . . . . . . . . . . . . . . . . . . 61

Using the Notepad . . . . . . . . . . . . . . . . . . . . . . . . . . . . 62

Attaching a Number . . . . . . . . . . . . . . . . . . . . . . . . . . . 62

Calling with Speed Dial . . . . . . . . . . . . . . . . . . . . . . . . . 63

Calling with 1-Touch Dial (CDMA Only) . . . . . . . . . . . . 63

Using Voicemail. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 64

Using Call Waiting (GSM Only). . . . . . . . . . . . . . . . . . . 65

Putting a Call On Hold. . . . . . . . . . . . . . . . . . . . . . . . . . 66

Phone Features

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67

Main Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67

Calling Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 69

DRAFT

Messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 69

Phonebook . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 70

Personalizing Features . . . . . . . . . . . . . . . . . . . . . . . . . . 73

Menu Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 79

Dialing Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 80

Call Monitoring . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 80

Handsfree Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . 81

Data and Fax Calls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 83

Network Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 84

Personal Organizer Features . . . . . . . . . . . . . . . . . . . . . 86

Security. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 88

News and Entertainment . . . . . . . . . . . . . . . . . . . . . . . . 88

Specific Absorption Rate Data

. . . . . . . . . . . . . . . . . . . . 90

Index

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 92

DRAFT

Getting Started

About This Guide

This guide describes the basic features of your Motorola

wireless phone.

Optional Features

This label identifies an optional network or

subscription-dependent feature that may not be

offered by all service providers in all geographical

areas. Contact your service provider for more

information.

Optional Accessories

This label identifies a feature that requires an

optional Motorola Original

accessory.

CAUTION:

Before using the phone for the

first time, read the

Important Safety and

Legal Information

included in the

gray-edged pages at the back of this guide.

032259o

032380o

DRAFT

Getting Started

Installing the SIM Card

Your SIM (Subscriber Identity Module) card contains

your phone number, service details, and phonebook/

message memory.

Caution:

Do not bend or scratch your SIM card. Avoid

exposing your SIM card to static electricity, water, or dirt.

Battery Use

Battery performance depends on many factors, including

your wireless carrier’s network configuration; signal

strength; the temperature at which you operate your

phone; the features and/or settings you select and use;

items attached to the phone’s accessory connector port;

and your voice, data, and other application usage patterns.

Caution:

To prevent injuries or burns, do not allow metal

objects to contact or short-circuit the battery terminals.

1. 2.

DRAFT

Getting Started

To maximize your battery’s performance:

•

Always use Motorola Original batteries and battery

chargers. The phone warranty does not cover

damage caused from using non-Motorola batteries

and/or battery chargers.

•

New batteries or batteries that have been stored

for a long time may require a longer charge time.

•

Maintain the battery at or near room temperature

when charging.

•

Do not expose batteries to temperatures below -10°C

(14°F) or above 45°C (113°F). Always take your

phone with you when you leave your vehicle.

•

When you do not intend to use a battery for a while,

store it uncharged in a cool, dark, dry place, such as a

refrigerator.

•

Batteries gradually wear down and require longer

charging times. This is normal. If you charge your

battery regularly and notice a decrease in talk time or

an increase in charging time, then it is probably time

to purchase a new battery.

The rechargeable batteries that power this phone

must be disposed of properly and may need to

be recycled. Refer to your battery’s label for

battery type. Contact your local recycling center for proper

disposal methods.

Warning:

Never dispose of batteries in a fire because they

may explode.

DRAFT

Getting Started

Installing the Battery

You must install and charge the battery to use your

phone.

Your phone is designed to use only Motorola

Original batteries and accessories. We

recommend that you store batteries in their

protective cases when not in use.

Charging the Battery

New batteries are shipped partially charged. Before you

can use your phone, you need to install and charge the

Release

Latch

032409o

032410o

032409o

DRAFT

Getting Started

battery as described below. Some batteries perform best

after several full charge/discharge cycles.

Tip:

You can safely leave the travel charger connected to

the phone after charging is complete. This will

not

damage

the battery.

Turning On Your Phone

Action

Plug the travel

charger into

your phone

with the release

tab facing up.

Plug the other end of the travel charger into the

appropriate electrical outlet.

When your phone indicates

Charge Complete

, press

the release tab and remove the travel charger.

Action

Press and hold the

power key for 3

seconds.

Note:

The phone

may require several

seconds to power on.

Power

Key

DRAFT

Getting Started

Adjusting

Volume

Press the up or down

volume keys to:

•

increase or decrease earpiece volume during a call

•

increase or decrease the ringer volume setting when

the home screen is visible (flip must be open)

Tip:

At the lowest volume setting, press the down

volume key once to switch to vibrate alert. Press it

again to switch to silent alert. Press the up volume key

to cycle back to vibrate alert, then ring alert.

•

turn off an incoming call alert

Making a Call

If necessary, enter your 4-digit unlock code (the

last 4 digits of your phone number) and press

(

) to unlock the phone.

Action

Dial the number.

Tip:

If you make a mistake, press the clear

key

to delete the last digit. Press and hold

to clear all digits.

Action

Volume

Keys

DRAFT

Getting Started

Note:

You must dial the phone number from the home

screen. See page 21.

Answering a Call

When you receive a call, your phone rings and/or vibrates

and displays an incoming call message.

Tip:

When the phone flip is active, open the phone to

answer the call. (To activate, press

Settings

In-Call Setup

Answer Options

Open to Answer

Note:

If the phone is locked, you must unlock it to answer

the call.

Press

to make

the call.

Press

to end the

call.

Action

Press

answer.

Press

to end the

call.

Action

Press to

send call.

Press to

answer

call.

DRAFT

Getting Started

Changing the Call Alert

Phone Flip Open

Press the down volume

key to switch to lower

call alert volume, then

switch to vibrate and,

finally, silent alert. Press the up volume key to cycle back

from silent alert to vibrate and then to the lowest alert

volume setting.

Phone Flip Closed

Press the smart key, then

press the up and down

volume keys to scroll

through the alert styles:

Loud

Soft

Vibrate

Vibe & Ring

, and

Silent

. The alert styles are shown

on the external display.

After scrolling to the desired alert style, press the smart

key to save the setting and return to the home screen.

Viewing Your Phone Number

To view your phone number from the home screen, press

While you are on a call, press

My Tel. Number

Volume

Keys

Volume

Keys

Smart

Key

DRAFT

Highlight Features

You can do much more with your phone than make and

receive calls! This section describes some of your

phone’s highlight features.

Taking and Sending a Photo

Shortcut:

Press

to activate your phone’s camera:

The active viewfinder image appears on your display.

Find the Feature

Multimedia

Camera

040034o

Press

up or down to

zoom in or out

on image.

Photo storage

memory

space

currently in

use.

Take a photo.

Press

left or right to

decrease or

increase


brightness. Return to previous screen.

Press

to open

Pictures menu.

BACK CAPTURE

Photo Viewfinder

Memory Used: 72%


AREA

DRAFT

Highlight Features

Point the camera lens at the photo subject, then:

Press To

CAPTURE

(

)

take a photo

STORE

(

)

DISCARD

(

)

view storage options

delete the photo and return to

active viewfinder

If you choose to store the

photo, continue to step 3.

scroll to

Send in Message

Store Only

Apply as Wallpaper

Apply as Screen Saver

, or

Apply as Phonebook Entry

SELECT

(

) select a storage option

DRAFT

Highlight Features

Taking a Self Portrait

Pictures Menu Options

When the camera is active, press

to access the

Pictures Menu

. The

Pictures Menu

can include the following

options:

Action

Close the flip.

Hold the camera with the lens aimed at yourself.

Press the camera key on the side of the phone to

capture the photo.

Option Description

Go To Pictures

View pictures and photos

stored on your phone.

Auto-Timed Capture

Set a timer for the camera to

take a photo.

Delete All

Delete all pictures.

Pictures Setup

Open the setup menu to

adjust picture settings.

Switch Storage Device

Save the picture on memory

card, if available, or on phone

memory (

Phone

View Free Space

See how much memory

remains for storing pictures.

Flash

Set a flash for photos taken in

settings with low light.

DRAFT

Highlight Features

TTY Operation

You can use an optional TTY device with your phone to

send and receive calls. You must plug the TTY device into

the phone’s headset jack and set the phone to operate in 1

of 3 TTY modes.

Note:

Use a TSB-121 compliant cable (provided by the

TTY manufacturer) to connect the TTY device to your

phone.

Note:

Set the phone to level 4 (middle setting) for proper

operation. If you experience a high number of incorrect

characters, adjust the volume as needed to minimize the

error rate.

Note:

For optimal performance, your phone should be at

least 12 inches (30 centimeters) from the TTY device.

Placing the phone too close to the TTY device may cause

high error rates.

Adjust Contrast

Increase or decrease

contrast.

Image Style

Scroll right or left to specify

Negative

Antique

Black and White

Color

Capture Title

Specify a title for the photo to

be captured.

Option Description

DRAFT

Highlight Features

Setting TTY Mode

When you set your phone to a TTY mode, it

operates in that mode whenever the TTY device is

connected.

The

TTY Setup

menu can include the following options:

When your phone is in a TTY mode, the international TTY

mode, the international TTY symbol, and the mode setting

display during an active TTY call.

Returning to Voice Mode

To return to normal voice mode, select

Voice

from the

TTY Setup

menu.

Press To

up or down scroll to the TTY mode

SELECT

(

) select the TTY mode

Press To

TTY

transmit and receive TTY

characters

VCO

receive TTY characters but

transmit by speaking into

microphone

HCO

transmit TTY characters but

receive by listening to

earpiece

Voice

return to normal voice mode

DRAFT

Learning to Use Your Phone

Learning to Use Your

Phone

See page 1 for a basic phone diagram.

Using the Display

The home screen is displayed when you are

not

on a

call or using the menu. You must be in the home screen

to dial a phone number.

Note:

Your home screen may look different than the

display shown above.

The

(menu) indicator indicates that you can press the

menu key (

) to enter the main menu.

Labels at the bottom corners of the display show the

current soft key functions. Press the left soft key (

) or

032418o

(O4\rÑuyÉ

Right Soft Key

Label

Date

Left Soft Key

Lable

Clock

RECENT PH.BOOK

6:35am

Service Provider

10/15/04

DRAFT

Learning to Use Your Phone

right soft key (

) to perform the function indicated by the

left or right soft key label.

Your phone can display an analog or digital clock in the

home screen (see page 67).

The following status indicators can display:

1. Data Transmission Indicator

Shows connection and

data transmission status. Indicators can include:

2. Coverage Indicator

CDMA and GSM.

= secure packet

data transfer

= unsecure packet

data transfer

= secure

application

connection

= unsecure

application

connection

= secure Circuit

Switch Data

(CSD) call

= unsecure CSD

call

032419o

(O4\rÑuyÉ

Signal

Strength

Coverage

Data

Transmission

Message

Battery

Level

Ring Alert

Location

Roam

RECENT PH.BOOK

6:35am

Service Provider

10/15/04

AGPS

Service

DRAFT

Learning to Use Your Phone

3. Signal Strength Indicator

Vertical bars show the

strength of the network connection. You cannot make or

receive calls when the

(no signal) indicator or

)

(no

transmit) indicator is displayed.

4. Roam Indicator

Shows when your phone is

seeking or using another network outside your

home network.

5. Message Indicator

Displays when you

receive a new message. Indicators can

include:

When you enter a message, a number here shows the

number of characters left on the current page (text

message), or the message size (multimedia message or

letter).

6. Battery Level Indicator

Vertical bars show the battery

charge level. Recharge the battery when

Low Battery

displays and the battery alert sounds.

7. Ring Alert Indicator

Shows the ring alert setting.

= text message

= loud ring

=soft ring

=vibrate

}

= vibrate and ring

{

= silent

032380o

032380o032380o

DRAFT

Learning to Use Your Phone

8. AGPS Service Indicator

Indicates when AGPS

Service is off (icon is grey), on (icon is white), or on and

finding your location (icon is green).

9. Location Indicator

Your phone may be able

to send location information to the network during

an emergency call. Indicators show when your

phone is sending location information:

Using the 5-Way Navigation

Key

Use the 5-way navigation key (

) to scroll up, down, left,

or right through the menu system. Within menus, press

to select a highlighted menu item.

= location on

= location off

032380o

DRAFT

Learning to Use Your Phone

Using Menus

From the home screen, press

to enter the main menu.

Press

to scroll to and highlight a menu feature icon in

the main menu.The following icons represent features that

may appear in the main menu, depending on your service

provider and service subscription options.

032407o

032420o

]áh

Ém

032420o

Left Soft Key

Perform left

function.

Menu Key 5-Way Navigation

Key

Scroll through

menus & lists.

Press center to

select highlighted

items.

Recent Calls

Right Soft Key

Perform right

function.

EXIT SELECT

DRAFT

Learning to Use Your Phone

Selecting a Menu Feature

This guide shows you how to select a menu feature,

starting from the home screen.

This example shows that from the home screen, you must

press

, scroll to and select

Recent Calls

from the main

menu, then scroll to and select

Dialed Calls

. Press

scroll, and the left/right soft keys to select the functions

listed in the bottom left and right corners of the display.

Icon Feature

Phonebook

Recent Calls

Messages

]

Get It Now

Web Access

Multimedia

Settings

Tools

Phone Status

Find the Feature

Recent Calls

Dialed Calls

DRAFT

Learning to Use Your Phone

Selecting a Feature Option

Some features require you to select an option from a list:

•

Press

to scroll up or down to highlight the option

you want.

•

In a numbered list, press a number key to highlight the

option.

•

In an alphabetized list, press a key repeatedly to cycle

through the letters on the key and highlight the closest

matching list option.

•

When an option has a list of possible values, press

left or right to scroll through and select a value.

•

When an option has a list of possible numeric values,

press a number key to set the value.

032421o

(+49rÑyÉ

Press

VIEW (+)

to view details

of highlighted

option.

Press

BACK (-)

to return to

screen.

Highlight

Option

Press (M) to open sub-menu.

BACK VIEW

Dialed Calls

10) John Smith

9) Lisa Owens

8) Adda Thomas

7) Jack Bradshaw

6) Dave Thompson

5) John Smith

4) John Smith

3) John Smith

DRAFT

Learning to Use Your Phone

Entering Text

Some features require you to enter information.

The message center lets you compose and send text

messages.

(èÏyÉ

Press

scroll down to

other options.

Name: John Smith

Picture: None

......MORE......

Ringer ID: Continental

Speed No: 2

Type: Work

No.: 2125551212

Entry Details

CANCEL CHANGE

Category: General

Press

CANCEL

(

) to exit without

making changes.

DONE

(

) displays when you

enter or edit information.

Highlighted

Option

Press

CHANGE

(

)

to enter or edit

information.

040036o

040037o

449

(yÉ

For indicator

descriptions,

see following

section.

Flashing cursor

indicates

insertion point.

Press

open

sub-menu.

Press

INSERT

(

) to

insert a quick

note, picture, or

sound.

Press

CANCEL

(

) to exit

without making changes.

Msg

CANCEL INSERT

DRAFT

Learning to Use Your Phone

Choosing a Text Entry Method

Multiple text entry methods make it easy for you to enter

names, numbers, and messages.

From any text entry screen, you can specify the entry

method you want to use.

You can select the following entry mode options:

Alternatively, you can select a text entry method in any text

entry screen by pressing

Entry Mode

Assigning Primary and Secondary Text Entry

Methods

From any text entry screen, you can assign

Primary

and

Secondary

text entry method s.

Find the Feature

Entry Mode

Primary

Use the text entry method assigned

to this option (see below to set).

Numeric

Enter numbers only (see page 36).

Symbol

Enter symbols only (see page 37).

Secondary

Use the text entry method assigned

to this option (see below to set).

Find the Feature

Entry Setup

Press To

scroll to

Primary Setup

Secondary Setup

DRAFT

Learning to Use Your Phone

You can select 1 of these text entry methods:

Text Entry Method Indicators

When you select the

Primary

Secondary

text entry method,

the following indicators identify the text entry setting:

CHANGE

(

) view entry methods (see

below)

scroll to an entry method

SELECT

(

) select the highlighted entry

method

iTAP

English

Let the phone predict each English

word as you press keys (see page 34).

iTAP Español

Let the phone predict each Spanish

word as you press keys (see page 34).

TAP Method

Enter letters and numbers by pressing

a key 1 or more times.

Primary

Secondary

Tap, no capital letters

Tap, capitalize next letter

only

Tap, all capital letters

iTAP, no capital letters

iTAP, capitalize next

letter only

Press To

DRAFT

Learning to Use Your Phone

The following indicators identify

Numeric

Symbol

entry

method:

Using Capitalization

Press

in any text entry screen to change text

case. The following indicators show capitalization

status:

Using Tap Method

This is the standard method for entering text on your

phone.

Regular

Tap

method cycles through the letters and number

of the key you press.

Tap Extended

method also cycles

through additional symbols as shown in the “Character

Chart” on page 33.

iTAP, all capital letters

= numeric method

[

= symbol method

= no capital letters

= capitalize next

letter only

= all capital letters

Press To

a keypad key 1

or more times

select a letter, number, or

symbol

DRAFT

Learning to Use Your Phone

In a text entry screen, you can press

to switch

entry methods. An indicator shows which method is

active (see page 30). If

Tap

Tap Extended

is not available

as the

Primary

Secondary

entry method, see page 29.

When you enter text with

Tap

Tap Extended

method, the soft

key functions change.

keypad keys enter remaining characters

Tip:

Press

right to accept

a word completion, or

insert a space.

(

) store the text

Press To

040038o

449

(yÉ

Character

displays at

insertion point.

After

2 seconds,

character is

accepted and

cursor moves to

next position.

Press

(

)

to accept and

store text.

Press

DELETE

(

) to delete

character to left of insertion point.

DELETE OK

Msg

DRAFT

Learning to Use Your Phone

When you enter 3 or more characters in a row, your phone

may guess the rest of the word. For example, if you enter

prog

you might see:

If you want a different word (such as

progress

), continue

pressing keypad keys to enter the remaining characters.

Character Chart

Use this chart as a guide for entering characters with

Tap Extended

method.

. ? ! , @ ' - _ : ; ( ) & “ ~ 1 0 ¿ ¡ % £ $ ¥

+ x * / \ [ ] = > < # §

a b c 2 á

d e f 3 é

g h i 4 í

j k l 5

m n o 6 ñ ó

p q r s 7

t u v 8 ú ü

040039o

449

(yÉ

Press

right

to accept

Program

, or

press

reject it and

enter a space

after

prog

DELETE OK

Msg

This is a program

DRAFT

Learning to Use Your Phone

Note:

This chart may not reflect the exact character set

available on your phone. In a URL editor,

first shows

common characters for that editor.

Tap Method Text Entry Rules

•

Press a keypad key repeatedly to cycle through its

characters.

•

After 2 seconds,

Tap

method accepts the character,

and the cursor moves to the next position.

•

Press

left or right to move the flashing cursor to

the left or right in a text message.

•

The first character of every sentence is capitalized. If

necessary, press

down to force the character to

lowercase before the cursor moves to the next

position.

•

If you enter or edit information and do not want to save

the changes, press

to exit without saving.

Using iTAP™ Method

iTAP™ software provides a predictive text entry method

that lets you enter a word using 1 keypress per letter. This

can be faster than

Tap

method, because your phone

combines the key presses into common words.

w x y z 9

change text case, for capital letters

enter a space (hold to enter a return)

change text entry method (hold for default)

DRAFT

Learning to Use Your Phone

For example, if you press

, letter

combinations that match your key presses display:

If you want a different word (such as

Progress

), continue

pressing keypad keys to enter the remaining characters.

Entering Words

In a text entry screen, you can press

to switch entry

methods. An indicator tells you which method is active

(see page 30). If

iTAP

method is not available as the

Primary

Secondary

entry method, see page 29.

Press To

keypad keys

(1 press per

letter)

show possible letter

combinations at the bottom of

the display

left or right highlight the combination you

want

(yÉ

}

Press

up to

accept Program.

Press

right

to highlight

another

combination.

Press

enter Prog and a

space.

Press SELECT (

) to lock

highlighted combination.

Press

DELETE (

) to

delete last

letter.

040040o

Program

Prog Proh Spoi Proi

DELETE OK

Msg

DRAFT

Learning to Use Your Phone

If you enter a word your phone does not recognize, the

phone stores it to use as 1 of your word options. When you

fill memory space for unrecognized words, your phone

deletes the oldest words to add new words.

Using Numeric Method

In a text entry screen, press

to switch entry methods

until the

(numeric) indicator displays.

Press keypad keys to enter the numbers you want. When

you finish entering numbers, press

to switch to

another entry method.

SELECT

(

)

lock a highlighted

combination

You can press keypad keys to

add more letters to the end of

the combination.

enter the highlighted

combination when it spells a

word

A space is automatically

inserted after the word.

Press To

DRAFT

Learning to Use Your Phone

Using Symbol Method

In a text entry screen, press

to switch entry methods

until the

[

(symbol) indicator displays.

Symbol Chart

Use this chart as a guide for entering characters with

symbol method.

Press To

keypad keys

(1 press per

symbol)

show possible symbol

combinations at the bottom of

the display

left or right highlight the combination you

want

SELECT

(

)

lock a highlighted

combination

You can press keypad keys to

add more symbols to the end

of the combination.

enter the highlighted

combination

. ? ! , @ ' - : ; ( ) & “ ~ 1 0 ¿ ¡ % £ $ ¥

+ x * / \ [ ] = > < # §

@ _ \

/ : ;

" & '

DRAFT

Learning to Use Your Phone

Note:

This chart may not reflect the exact character set

available on your phone. In a URL editor,

first

shows common characters for that editor.

Deleting Letters and Words

Place the cursor to the right of the text you want to delete,

and then:

Using the Smart Key

The smart key gives you another way to perform many

basic phone functions. It anticipates the next action you

are likely to perform. For example, when you highlight a

menu item, you can press the smart key to select it. You

can use the smart key to make and end calls, turn features

on and off, and open your phonebook. The smart key

( ) [ ] { }

¿ ¡ ~

< > =

$ £ ¥

# % *

+ - x * / \ = > < # §

enter a space (hold to enter a return)

change text entry method (hold for default)

Action

Press

to delete 1 letter at a time.

Hold

to delete all text.

DRAFT

Learning to Use Your Phone

usually performs the same function as the right

soft key (

Using the External Display

When the flip is closed, use the external display for the

following:

•

View time, date, and phone status information.

•

Read messages that notify you of incoming calls

and other events.

•

Use the external display as a viewfinder when you

take a self portrait with the phone’s camera.

Setting Phone Alert Style

Return an Unanswered Call

Your phone keeps a record of your unanswered calls and

displays

X Missed Calls

in the external display.

Press To

volume keys scroll to

Style

smart key select an alert style

volume keys return to the home screen

Press To

smart key see the received calls list

volume keys select a call to return

smart key make the call

DRAFT

Learning to Use Your Phone

Note:

Because the microphone and earpiece are

unavailable when the phone is closed, you must use a

headset or other handsfree device with this feature.

Using the Handsfree Speaker

When you activate your phone’s integrated handsfree

speaker, you can use the phone without holding it to your

ear.

Press

SPEAKER

(

) to turn the handsfree speaker on

or off during a call. A soft audio alert confirms

activation/deactivation.

When you turn on the handsfree speaker, your phone

displays

Speaker On

in the home screen. The handsfree

speaker remains on until you press

SPEAKER

(

) again or

turn the phone off.

Note:

The handsfree speaker is disabled when you

connect your phone to a handsfree car kit or headset

accessory.

Changing a Code, PIN, or

Password

Your phone’s 4-digit unlock code is originally set to 1234,

and the 6-digit security code is originally set to 000000.

Your service provider may reset these codes before you

receive your phone.

If your service provider has

not

reset these codes, we

recommend that you change them to prevent others from

accessing your personal information. The unlock code

DRAFT

Learning to Use Your Phone

must contain 4 digits, and the security code must contain 6

digits.

To change a code or password:

Locking and Unlocking Your

Phone

You can lock your phone manually or set the phone to

lock automatically whenever you turn it off.

To use a locked phone, you must enter the unlock code. A

locked phone still rings or vibrates for incoming calls or

messages,

but you must unlock it to answer

You can make emergency calls on your phone even when

it is locked (see page 59).

Locking Your Phone Manually

Find the Feature

Settings

Security

New Passwords

Find the Feature

Settings

Security

Phone Lock

Lock Now

Press To

keypad keys enter your unlock code

(

) lock the phone

DRAFT

Learning to Use Your Phone

Unlocking Your Phone

Tip:

Your phone’s unlock code is originally set to 1234.

Many service providers reset the unlock code to the last 4

digits of your phone number.

At the

Enter Unlock Code

prompt:

Setting Your Phone to Lock

Automatically

You can set your phone to lock every time you turn it off:

If You Forget a Code, PIN, or

Password

Note:

Your phone’s 4-digit unlock code is originally set to

1234, and the 6-digit security code is originally set to

000000. Many service providers reset the unlock code to

Press To

keypad keys enter your unlock code

(

) unlock your phone

Find the Feature

Settings

Security

Phone Lock

Automatic Lock

Press To

keypad keys enter your unlock code

(

) activate automatic lock

DRAFT

Learning to Use Your Phone

the last 4 digits of your phone number before you receive

your phone.

If you forget your unlock code, try entering 1234 or the last

4 digits of your phone number. If that does not work, do the

following at the

Enter Unlock Code

prompt:

If you forget your security code or call barring password,

contact your service provider.

Using the Phonebook

This section briefly describes basic phonebook operation.

Storing a Phonebook Entry

A phone number or email address are required for a

phonebook entry. All other information is optional.

Shortcut:

Enter a phone number in the idle display, then

press

STORE

(

) to create a phonebook entry with the

number in the

No.

field. Go directly to step 3 to continue.

Enter Information

Press To

display the unlock code

bypass screen

keypad keys enter your security code

(

) submit your security code

Find the Feature

Phonebook

[New Entry]

DRAFT

Learning to Use Your Phone

Press To

scroll to

Phone Number

Email Address

SELECT

(

) select the entry type

CHANGE

(

)select

Name

keypad keys

BROWSE

(

)

enter a name

select a name from the

phonebook

(

) store the name

CHANGE

(

)select

Categories

> category name

Feature Description

DRAFT

Phone Features

Sort

Phonebook

List

Set the order in which phonebook

entries are listed:

Phonebook

Setup

Sort by

> sort order

Set Primary

Number

Set the primary number for a

phonebook entry with multiple

numbers:

Phonebook

> entry

Set Primary

> phone number

View All or

Primary

Contacts

Phonebook

Setup

View

Edit Entry

Edit a phonebook entry:

Phonebook

> entry

Edit

Delete Entry

Delete a phonebook entry:

Phonebook

> entry

Delete

Copy

Phonebook

Entry

Copy a phonebook entry to another

location in phonebook:

Phonebook

> entry

Copy

Entry

> location number

Copy

Multiple

Phonebook

Entries

Copy a phonebook entry to another

location in phonebook:

Phonebook

> entry

Copy

Entries

From(start):

> location number >

From(end):

> location number >

To(start):

> location number

Feature Description

DRAFT

Phone Features

Personalizing Features

Using Voice Commands to Place Calls

Advanced Voice Dialing lets you place a call by speaking a

phone number.

Note:

This feature supports the Chinese dial plan as well

as 7-digit, 10-digit, and 11-digit numbers. It does

not

support and will

not

dial 3-digit numbers such as 112. If

you need to make an emergency call, use your phone

keypad to dial and send the number.

Action

Press and release the voice button on the right

side of the phone.

Your phone displays

Say a command

and plays the

same prompt out loud.

Say “Digit Dial.”

DRAFT

Phone Features

When prompted, say the phone number.

If the phone recognizes the number, it dials that

number.

If the phone asks you to repeat a number, say it

again. If the number is not valid or is not

recognized, the phone does not place the call.

If the phone does not recognize the number, it

displays a list of up to 3 numbers and asks, “Did

you say ...” followed by the first number in the

list.

•

If the number is correct, say “Yes” to dial

that number.

•

If the number is not correct, say “No” to go

to the next number.

•

To select the number manually, scroll to the

correct number on the list and press

SELECT

(

•

To exit the list and repeat the number, press

the voice button.

If you reach the end of the list without confirming

a number, the phone asks if you want to try

again. Say “Yes” to say the number again or “No”

to exit without placing a call.

Action

DRAFT

Phone Features

Tip:

Speak numbers at a normal speed and volume,

pronouncing each digit distinctly. Avoid pausing between

digits.

To Adapt Advanced Voice Dialing to Your Voice

For most people, Advanced Voice Dialing works well

without any initial setup. However, if the phone is

frequently unable to recognize numbers correctly when

you use Advanced Voice Dialing, you may be able to

improve your results by adapting it to your voice.

Note:

If the phone is used by several people, reset

Advanced Voice Dialing to its original setting before

proceeding. This ensures that you are not adapting over

someone else’s adaptation.

Adapting Advanced Voice Dialing to Your Voice

Find the Feature

Settings

Personalize

Voice Dial Setup

Action

Scroll to

Adapt Digits

Press

SELECT

(

Press

START

(

When the phone prompts you to say the 1st digit

sequence, wait for the beep and then repeat the

digits in a normal tone of voice.

DRAFT

Phone Features

Tip:

When adapting Advanced Voice Dialing:

•

Choose a quiet place for recording.

•

Wait for the beep before you begin to speak.

•

Speak at a normal speed and volume, pronouncing

each digit distinctly. Avoid pausing between digits.

•

If you make a mistake while recording a sequence of

digits, or if an unexpected noise spoils the recording,

rerecord that sequence.

If the recording sounds acceptable (no mistakes

or background noises), say “Yes” or press

YES

(

If the recording is not acceptable, say “No” or

press

(

). When prompted to say the digits

again, wait for the beep and then record the

digits again. Repeat this step until you are

satisfied with the recording.

Repeat the recording process with each set of

digits (12 in all) until adaptation is complete.

(The phone will say “Adaptation Complete.”)

Action

DRAFT

Phone Features

To Reset Advanced Voice Dialing

Additional Personalizing Features

Find the Feature

Settings

Personalize

Voice Dial Setup

Press To

scroll to

Reset Digits

(

)reset Advanced Voice Dialing

to the factory default

Feature Description

Ring Alert

Change the ring alert for an event:

Settings

Ring Styles

> Style

Detail

> event name

Ringer IDs

Activate distinctive ringer alerts

assigned to phonebook entries:

Settings

Ring Styles

> Style

Detail

Ringer IDs

Ring

Volume

Set ringer volume:

Settings

Ring Styles

> Style

Detail

Ring Volume

Keypad

Volume

Set keypad keypress volume:

Settings

Ring Styles

> Style

Detail

Key Volume

Reminders

Set reminder alerts for picture, text,

or voicemail messages you receive:

Settings

Ring Styles

> Style

Detail

Reminders

DRAFT

Phone Features

Greeting

Change the greeting that

appears when you turn on

your phone:

Settings

Personalize

Greeting

Shortcuts

Create a shortcut to a menu item:

Highlight the menu item, then press

and hold

Select a shortcut:

Tools

Shortcuts

> shortcut name

Message

Alerts

Set whether or not you are alerted to

incoming messages during a call:

Settings

In-Call Setup

MSG Alert

Phone

Spec-

ifications

View your phone’s feature

specifications:

Phone Status

Other Information

View and

Manage

Storage

Devices

Phone Status

Storage Devices

Feature Description

032380o

DRAFT

Phone Features

Menu Features

Feature Description

Hide or

Show

Home

Keys

Settings

Personalize

Home Screen

Home Keys

Set Clock

Type

Set analog or digital time display on

home screen:

Settings

Personalize

> Home Screen

Clock

Language

Set display language:

Settings

Initial Setup

Language

Scroll

Set the highlight bar to stop or wrap

around in menu lists:

Settings

Initial Setup

Scroll

Master

Reset

Reset all options except unlock code,

security code, and lifetime timer:

Settings

Initial Setup

Master Reset

Master

Clear

Reset all options except unlock code,

security code, and lifetime timer, and

clear all user settings and entries:

Settings

Initial Setup

Master Clear

DRAFT

Phone Features

Dialing Features

Call Monitoring

Network connection time

is the elapsed time from the

moment you connect to your service provider's network to

the moment you end the call by pressing

. This time

includes busy signals and ringing.

The amount of network connection time you track on

your resettable timer may not equal the amount of

time for which you are billed by your service

Feature Description

Auto PIN

Dial (GSM

Only)

Automatically dial an authenticating

PIN code for outgoing calls:

Settings

Initial Setup

Auto PIN Dial

DTMF

Tones

Activate DTMF tones:

Settings

Initial Setup

DTMF

Send DTMF tones during a call:

Press number keys.

Send stored numbers as DTMF tones

during a call:

Highlight a number in the phonebook

or recent calls lists, then press

Send Tones

DRAFT

Phone Features

provider. For billing information, please contact your

service provider directly.

Handsfree Features

Note:

The use of wireless devices and their accessories

may be prohibited or restricted in certain areas. Always

Feature Description

Call Times

View call timers:

Recent Calls

(

) >

Call Times

In-Call

Timer

Display time or cost

information during a call:

Settings

In-Call Setup

In-Call Timer

Data

Times

View data call timers:

Recent Calls

(

) >

Data Times

Data

Volumes

View data volume meters:

Recent Calls

(

) >

Data Volumes

Battery

Charge

View a detailed battery charge meter:

Phone Status

Battery Meter

032380o

DRAFT

Phone Features

obey the laws and regulations on the use of these

products.

Feature Description

Accessory

Volume

Settings

(car kit)

Adjust volume levels of car

kit accessory:

During an active call, press

your phone’s up or down

volume keys.

Speaker-

phone

Activate a connected

external speakerphone

during a call:

Press

SPEAKER

(

) (if

available) or

Spkrphone On

Auto

Answer

(car kit or

headset)

Automatically answer calls

when connected to a car kit

or headset:

Settings

Car Settings

Auto Answer

Headset

Auto Answer

Voice Dial

(headset)

Enable voice dial with

headset send/end key:

Settings

Headset

Voice Dial

Auto

Handsfree

(car kit)

Automatically route calls to a

car kit when connected:

Settings

Car Settings

Auto Handsfree

DRAFT

Phone Features

Data and Fax Calls

Power-Off

Delay

(car kit)

Set the phone to stay on for

a period of time after the

ignition is switched off:

Settings

Car Settings

Power-Off Delay

Charger

Time

(car kit)

Charge the phone for a

period of time after the

ignition is switched off:

Settings

Car Settings

Charger Time

Feature Description

Send Data

or Fax

Connect your phone to the

device, then place the call

through the device application.

Receive

Data or

Fax

Connect your phone to the

device, then answer the call

through the device application.

Talk and

Fax (GSM

Only)

Connect your phone to the

device, enter the number,

press

Dialing Menu

Talk and Fax

, then press

make the call.

Feature Description

DRAFT

Phone Features

Network Features

GSM Network Settings

Feature Description

Select

Account

(CDMA/

GSM)

Select from CDMA and GSM

accounts:

Settings

Phone Mode

> desired account

Feature Description

Find New

Network

Settings

GSM

Settings

New

Network

Change

Network

Setup

Values

Set how your phone

searches for a network

connection:

Settings

GSM

Settings

Network Setup

List

Networks

View a list of available

networks, and register your

phone with a network:

Settings

GSM

Settings

Available Networks

View Your

Networks

View a list of all networks that

your phone can use:

Settings

GSM

Settings

My Network List

032380o

DRAFT

Phone Features

CDMA Network Settings

Adjust

Service

Tones

Set your phone to beep each

time the network registration

status changes:

Settings

GSM

Settings

Service Tone

Set Call

Drop Alert

Set your phone to emit an

alert tone whenever the

network drops a call:

Settings

GSM

Settings

Call

Drop

Tone

Feature Description

View

Current

Network

Settings

CDMA

Settings

Current

Network

Configure

System

Mode

Switch to another mode to

improve calling conditions,

network coverage, or

roaming conditions:

Settings

CDMA

Settings

CDMA Set Mode

Select

System

Select phone’s system

according to system channel:

Settings

CDMA Settings

Srvc Status

Feature Description

032380o

DRAFT

Phone Features

Personal Organizer Features

Adjust

Service

Tones

Set your phone to beep each

time the network registration

status changes:

Settings

CDMA

Settings

Service Tone

Set Call

Drop Alert

Set your phone to emit an

alert tone whenever the

network drops a call:

Settings

CDMA

Settings

Call

Drop

Tone

Feature Description

Add

Datebook

Event

Add an event to the datebook:

Tools

Datebook

> day

New

View

Datebook

Event

View or edit event details:

Tools

Datebook

> day

> event name

Event

Reminder

View event reminder:

VIEW

(

)

Dismiss event reminder:

EXIT

(

)

Copy

Datebook

Event

Copy a datebook event to date and/or

time:

Tools

Datebook

> day > event

Copy

Feature Description

032380o

DRAFT

Phone Features

Set Alarm

Set an alarm:

Tools

Alarm Clock

Turn Off

Alarm

Turn off alarm:

Press

DISABLE

(

) or

Set 8-minute delay:

Press

SNOOZE

(

Create

Voice

Record

Create a voice record:

Press and hold voice key, speak into

the phone, release voice key.

Note:

Recording phone calls is subject

to varying state and federal laws

regarding privacy and recording of

conversations.

Play Voice

Record

Play back a voice record:

Tools

Voice Records

Calculator

Calculate numbers:

Tools

Calculator

Currency

Converter

Convert currency:

Tools

Calculator

Exchange Rate

Enter exchange rate, press

(

enter amount, press

Convert Currency

Feature Description

DRAFT

Phone Features

Security

News and Entertainment

Feature Description

SIM PIN

(GSM Only)

Lock or unlock the SIM card:

Settings

Security

SIM PIN

Lock

Application

Lock phone applications:

Settings

Security

Lock Application

Lock

Keypad

Settings

Security

Lock Keypad

Feature Description

Launch

Micro-

Browser

Start a micro-browser

session:

Web Access

Web Browser

Web

Sessions

Select or create a Web

session:

Web Access

Web Sessions

Download

Game or

Application

(Get It Now)

Download a game or

application with

Get It Now

> application

SELECT

(

) >

DWNLOAD

(

)

Manage

Pictures

Manage pictures and

animations:

Multimedia

Pictures

032380o

DRAFT

Phone Features

Manage

Sounds

Manage ring tones, sounds that you

have composed or downloaded:

Multimedia

Sounds

Feature Description

DRAFT

Specific Absorption Rate Data

The model wireless phone meets the government’s requirements for

exposure to radio waves.

Your wireless phone is a radio transmitter and receiver. It is designed and

manufactured not to exceed limits for exposure to radio frequency (RF)

energy set by the Federal Communications Commission (FCC) of the U.S.

Government and by the Canadian regulatory authorities. These limits are

part of comprehensive guidelines and establish permitted levels of RF

energy for the general population. The guidelines are based on standards

that were developed by independent scientific organizations through

periodic and thorough evaluation of scientific studies. The standards

include a substantial safety margin designed to assure the safety of all

persons, regardless of age or health.

The exposure standard for wireless mobile phones employs a unit of

measurement known as the Specific Absorption Rate, or SAR. The SAR

limit set by the FCC and by the Canadian regulatory authorities is 1.6 W/

kg.

Tests for SAR are conducted using standard operating positions

accepted by the FCC and by Industry Canada with the phone transmitting

at its highest certified power level in all tested frequency bands. Although

the SAR is determined at the highest certified power level, the actual SAR

level of the phone while operating can be well below the maximum value.

This is because the phone is designed to operate at multiple power levels

so as to use only the power required to reach the network. In general, the

closer you are to a wireless base station, the lower the power output.

Before a phone model is available for sale to the public in the U.S. and

Canada, it must be tested and certified to the FCC and Industry Canada

that it does not exceed the limit established by each government for safe

exposure. The tests are performed in positions and locations (e.g., at the

ear and worn on the body) reported to the FCC and available for review by

Industry Canada. The highest SAR value for this model phone when

tested for use at the ear is 1.53 W/kg, and when worn on the body, as

DRAFT

described in this user guide, is 1.47 W/kg. (Body-worn measurements

differ among phone models, depending upon available accessories and

regulatory requirements).

While there may be differences between the SAR levels of various phones

and at various positions, they all meet the governmental requirements for

safe exposure. Please note that improvements to this product model

could cause differences in the SAR value for later products; in all cases,

products are designed to be within the guidelines.

Additional information on Specific Absorption Rates (SAR) can be found

on the Cellular Telecommunications & Internet Association (CTIA) Web

site:

http://www.phonefacts.net

or the Canadian Wireless Telecommunications Association (CWTA) Web

site:

http://www.cwta.ca

1. In the United States and Canada, the SAR limit for mobile phones used by

the public is 1.6 watts/kg (W/kg) averaged over one gram of tissue. The

standard incorporates a substantial margin of safety to give additional

protection for the public and to account for any variations in measurements.

2. The SAR information includes the Motorola testing protocol, assessment

procedure, and measurement uncertainty range for this product.

DRAFT

Index

accessories 8, 40

Advanced Voice Dialing 73

AGPS service indicator 24

alarm clock 87

alert

defined 51

setting 13, 39, 51, 77

turning off 13, 15, 58

ALI indicators 55

animation

screen saver 53

viewing 88

wallpaper 52

answering a call 14, 52

application, locking and

unlocking 88

automatic location

information

sending 55

backlight 55

battery

charging 11

extending battery life 9,

54, 55, 56

installing 11

level indicator 23

Bluetooth 82

brightness, setting 55

calculator 87

call

adding digits after phone

number 61

Advanced Voice Dialing

alert, setting 13, 39, 51,

alert, turning off 13, 15,

answer options 52

answering 14

calling card 47

deleting 59

dialed calls list 59

dialing 13

emergency number 59

ending 14

handsfree speaker 40

hold 66

making 13

received calls list 59

DRAFT

receiving 14

recent calls 59

speakerphone 82

storing 59

timers 81

unanswered call 39, 61

caller ID 3, 61

calling card call 47

camera

taking a photo 2, 16

capitalization, changing 31

car kit 81

character chart 33

codes

changing 40

default 13, 40, 42, 43

forgetting 42

contrast, display 55

cursor 28

data call 83

timers 81

volume meters 81

datebook 86

deleting a call 59

dialed calls list 59

dialing a number 13

display

backlight 55

brightness 55

contrast 55

greeting 78

language 79

distinctive ringer alert 77

drafts folder 70

DTMF tones

activating 80

sending 60, 61, 80

earpiece volume 13

emergency number 59

end key 14

ending a call 14

Enter Unlock Code

message 42, 43

event alert 77

external display 39

5-way navigation key 24

flashing cursor 28

flip

external display 39

open to answer 14, 52

screen saver 53

greeting 78

DRAFT

handsfree speaker 40

handsfree use 81

headset

accessory, using 81

using with external

display 40

Hide ID feature 61

hold a call 66

home screen 21

indicators

AGPS service 24

ALI 55

battery level 23

location 24

loud ring alert 23

message 23

missed call 61

ring alert 23

roam 23

signal strength 23

silent alert 23

soft ring alert 23

text case 30, 31

text entry method 23, 30,

transmission 22

vibrate alert 23

vibrate and ring alert 23

voicemail message 64

iTAP software 34

key

end 14

5-way navigation 24

left soft key 22

menu 26

power 12

right soft key 22

send 14, 60

smart 38, 39

volume control 13

keypad

answering calls 52

volume, setting 77

language, setting 79

left soft key

functions 22

location indicator 24

location, sending to network

lock

application 88

phone 41

Low Battery message 23

DRAFT

making a call 13

master clear 79

master reset 79

entering text 28

language, setting 79

lists 27

navigating 25

using features 27

menu key 26

message

cleanup 70

drafts 70

inbox setup 69

outbox 70

quick note 70

reading 69, 70

reminders, turning on/off

status 70

text 69

message indicator 23

missed call indicator 61

Missed Calls message 39,

my telephone number 15

notepad 62

number

viewing your number 15

numbers, entering 36

1-touch dial

using 63

open to answer 52

optional accessory, defined

optional feature, defined 8

outbox 70

passwords. See codes

pause character 47, 48

phone

alert, setting 13, 39, 51,

alert, turning off 13, 15,

answer options 52

automatic location

information 55

clear stored information

codes 40

flip 14

keypad, answering calls

language, setting 79

location 55

DRAFT

locking 41

reset all options 79

security code 40

unlock code 40

unlocking 13, 41, 42, 43

phone number

adding digits after 61

attaching 2 numbers 61,

redialing 57

storing in phonebook 43,

viewing your number 15

phonebook

attaching 2 numbers 61,

category views 50, 71

creating an entry 43

deleting an entry 72

dialing a number 71

editing an entry 72

entry category 71

group mailing list 70

number, storing 43

1-touch dial 63

picture caller ID 3

primary number, setting

ringer ID 71, 77

ringer ID, defined 46

ringer ID, setting 46

sorting entries 50, 72

speed dial number 45, 63

storing an entry 43, 70

voice dialing 71


picture caller ID 3

sending 2, 16

taking 2, 16


screen saver 53

viewing 88

wallpaper 52

picture caller ID 3

PIN code

storing with phonebook

entry 47

power key 12

predictive text entry 34

quick note 70

received calls list 59

recent calls 59

redial

busy number 57

reminders

turning on/off 77

right soft key

functions 22

ring alert

DRAFT

setting 13, 15, 39, 51, 77

turning off 13, 15, 58

ring alert indicators 23

ring tone

managing 89

ringer ID

defined 46

setting 71

setting for phonebook

entry 46

turning on/off 77

ringer volume, setting 13,

roam indicator 23

screen saver 53

security code

changing 40

default 40

forgetting 43

send key 14, 60

shortcuts 78

Show ID feature 61

signal strength indicator 23

silent alert indicator 23

silent alert, setting 13, 39,

silent ring alert, setting 15

SIM card

defined 9

installing 9

precautions 9

smart key 38, 39

soft keys

functions 22

sound

managing 89

Speaker On message 40

speakerphone

activating 82

automatic answer 82

speed dial 63

changing number 45

standby time, increasing

54, 55

storing a call 59

symbol chart 37

symbols, entering 37

tap method text entry 31

telephone number

viewing your number 15

text 31

character chart 33

entering 28

entry method, setup 29

flashing cursor 28

iTAP software predictive

text entry 34

numeric method 36

DRAFT

symbol chart 37

symbol method 37

tap method 31

text case indicator 30, 31

text entry method

setup 29

text entry method indicator

23, 30, 31

timers 81

transmission indicator 22

travel charger 12

unlock

application 88

phone 41

unlock code

bypassing 42

changing 40

default 13, 40, 42, 43

entering 13, 41, 42

forgetting 43

vibrate alert

setting 13, 39, 51, 77

turning off 13, 15, 58

voice dial 71, 82

voice dialing

Advanced Voice Dialing

voice key

dialing a number 71

voicemail 64

voicemail message indicator

volume

earpiece 13

keypad 77

ringer 13, 77

volume keys 13

wait character 48

wallpaper 52

motorola.com

IMPORTANT SAFETY AND LEGAL

INFORMATION>

Software Copyright Notice

The Motorola products described in this manual may include copyrighted

Motorola and third party software stored in semiconductor memories or

other media. Laws in the United States and other countries preserve for

Motorola and third party software providers certain exclusive rights for

copyrighted software, such as the exclusive rights to distribute or

reproduce the copyrighted software. Accordingly, any copyrighted

software contained in the Motorola products may not be modified,

reverse-engineered, distributed, or reproduced in any manner to the

extent allowed by law. Furthermore, the purchase of the Motorola

products shall not be deemed to grant either directly or by implication,

estoppel, or otherwise, any license under the copyrights, patents, or

patent applications of Motorola or any third party software provider,

except for the normal, non-exclusive, royalty-free license to use that

arises by operation of law in the sale of a product.

Part Number: 6809476A21-O

Contents

Safety and General Information

. . . . . . . . . . . . . . . . . . . . 4

FDA Consumer Information on Wireless Phones

. . . . . 10

Product Registration

. . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

RF Energy Interference

. . . . . . . . . . . . . . . . . . . . . . . . . . 20

Export Law Assurances

. . . . . . . . . . . . . . . . . . . . . . . . . . 20

Wireless: The New Recyclable

. . . . . . . . . . . . . . . . . . . . 21

Wireless Phone Safety Tips

. . . . . . . . . . . . . . . . . . . . . . 23

Safety and General Information

IMPORTANT INFORMATION ON SAFE AND EFFICIENT OPERATION.

READ THIS INFORMATION BEFORE USING YOUR PHONE.

The information provided in this document supersedes the general safety

information in user’s guides published prior to December 1, 2002.

Exposure To Radio Frequency (RF) Energy

Your phone contains a transmitter and a receiver. When it is ON, it

receives and transmits RF energy. When you communicate with your

phone, the system handling your call controls the power level at which

your phone transmits.

Your Motorola phone is designed to comply with local regulatory

requirements in your country concerning exposure of human beings to RF

energy.

Operational Precautions

To assure optimal phone performance and make sure human exposure to

RF energy is within the guidelines set forth in the relevant standards,

always adhere to the following procedures.

External Antenna Care

Use only the supplied or Motorola-approved replacement antenna.

Unauthorized antennas, modifications, or attachments could damage the

phone.

Do NOT hold the external antenna when the phone is IN USE. Holding

the external antenna affects call quality and may cause the phone to

operate at a higher power level than needed. In addition, use of

unauthorized antennas may result in non-compliance with the local

regulatory requirements in your country.

Phone Operation

When placing or receiving a phone call, hold your phone as you would a

wireline telephone.

Body-Worn Operation

To maintain compliance with RF energy exposure guidelines, if you wear a

phone on your body when transmitting, always place the phone in a

Motorola-supplied or approved clip, holder, holster, case, or body harness

for this phone, if available. Use of accessories not approved by Motorola

may exceed RF energy exposure guidelines. If you do not use one of the

body-worn accessories approved or supplied by Motorola, and are not

using the phone held in the normal use position, ensure the phone and its

antenna are at least 1 inch (2.5 centimeters) from your body when

transmitting.

Data Operation

When using any data feature of the phone, with or without an accessory

cable, position the phone and its antenna at least 1 inch (2.5 centimeters)

from your body.

Approved Accessories

Use of accessories not approved by Motorola, including but not limited to

batteries and antennas, may cause your phone to exceed RF energy

exposure guidelines. For a list of approved Motorola accessories, visit our

website at

www.Motorola.com

RF Energy Interference/Compatibility

Note:

Nearly every electronic device is susceptible to RF energy

interference from external sources if inadequately shielded, designed, or

otherwise configured for RF energy compatibility. In some circumstances

your phone may cause interference.

Facilities

Turn off your phone in any facility where posted notices instruct you to do

so. These facilities may include hospitals or health care facilities that may

be using equipment that is sensitive to external RF energy.

Aircraft

When instructed to do so, turn off your phone when on board an aircraft.

Any use of a phone must be in accordance with applicable regulations per

airline crew instructions.

Medical Devices

Pacemakers

Pacemaker manufacturers recommend that a minimum separation of

6 inches (15 centimeters) be maintained between a handheld wireless

phone and a pacemaker.

Persons with pacemakers should:

•

ALWAYS keep the phone more than 6 inches (15 centimeters) from

your pacemaker when the phone is turned ON.

•

NOT carry the phone in the breast pocket.

•

Use the ear opposite the pacemaker to minimize the potential for

interference.

•

Turn OFF the phone immediately if you have any reason to suspect

that interference is taking place.

Hearing Aids

Some digital wireless phones may interfere with some hearing aids. In the

event of such interference, you may want to consult your hearing aid

manufacturer to discuss alternatives.

Other Medical Devices

If you use any other personal medical device, consult the manufacturer of

your device to determine if it is adequately shielded from RF energy. Your

physician may be able to assist you in obtaining this information.

Use While Driving

Check the laws and regulations on the use of phones in the area where

you drive. Always obey them.

When using your phone while driving, please:

•

Give full attention to driving and to the road.

•

Use handsfree operation, if available.

•

Pull off the road and park before making or answering a call if driving

conditions so require.

Responsible driving best practices may be found in the “Wireless Phone

Safety Tips” at the end of this manual and at the Motorola website:

www.Motorola.com/callsmart

Operational Warnings

For Vehicles With an Air Bag

Do not place a phone in the area over an air bag or in the air bag

deployment area. Air bags inflate with great force. If a phone is placed in

the air bag deployment area and the air bag inflates, the phone may be

propelled with great force and cause serious injury to occupants of the

vehicle.

Potentially Explosive Atmospheres

Turn off your phone prior to entering any area with a potentially explosive

atmosphere. Do not remove, install, or charge batteries in such areas.

Sparks in a potentially explosive atmosphere can cause an explosion or

fire resulting in bodily injury or even death.

Note:

The areas with potentially explosive atmospheres referred to above

include fueling areas such as below decks on boats, fuel or chemical

transfer or storage facilities, areas where the air contains chemicals or

particles, such as grain, dust, or metal powders. Areas with potentially

explosive atmospheres are often but not always posted.

Blasting Caps and Areas

To avoid possible interference with blasting operations, turn OFF your

phone when you are near electrical blasting caps, in a blasting area, or in

areas posted “Turn off electronic devices.” Obey all signs and instructions.

Batteries

Batteries can cause property damage and/or bodily injury such as burns if

a conductive material such as jewelry, keys, or beaded chains touch

exposed terminals. The conductive material may complete an electrical

circuit (short circuit) and become quite hot. Exercise care in handling any

charged battery, particularly when placing it inside a pocket, purse, or

other container with metal objects.

Use only Motorola original batteries

and chargers.

Your battery or phone may contain symbols, defined as follows:

Seizures/Blackouts

Some people may be susceptible to epileptic seizures or blackouts when

exposed to flashing lights, such as when watching television or playing

Symbol Definition

Important safety information will follow.

Your battery or phone should not be disposed of in a

fire.

Your battery or phone may require recycling in

accordance with local laws. Contact your local

regulatory authorities for more information.

Your battery or phone should not be thrown in the

trash.

Your phone contains an internal lithium ion battery.

LiIon BATT

video games. These seizures or blackouts may occur even if a person

never had a previous seizure or blackout.

If you have experienced seizures or blackouts, or if you have a family

history of such occurrences, please consult with your doctor before

playing video games on your phone or enabling a flashing-lights feature

on your phone. (The flashing-light feature is not available on all products.)

Parents should monitor their children's use of video game or other

features that incorporate flashing lights on the phones. All persons should

discontinue use and consult a doctor if any of the following symptoms

occur: convulsion, eye or muscle twitching, loss of awareness, involuntary

movements, or disorientation.

To limit the likelihood of such symptoms, please take the following safety

precautions:

•

Do not play or use a flashing-lights feature if you are tired or need

sleep.

•

Take a minimum of a 15-minute break hourly.

•

Play in a room in which all lights are on.

•

Play at the farthest distance possible from the screen.

Repetitive Motion Injuries

When you play games on your phone, you may experience occasional

discomfort in your hands, arms, shoulders, neck, or other parts of your

body. Follow these instructions to avoid problems such as tendonitis,

carpal tunnel syndrome, or other musculoskeletal disorders:

•

Take a minimum 15-minute break every hour of game playing.

•

If your hands, wrists, or arms become tired or sore while playing,

stop and rest for several hours before playing again.

•

If you continue to have sore hands, wrists, or arms during or after

play, stop playing and see a doctor.

FDA Consumer

Information on Wireless

Phones

The U.S. Food and Drug Administration (FDA) provides consumer

information on wireless phones at:

http://www.fda.gov/cellphones/qa.html

Following are safety-related questions and answers discussed at this web

site.

Do wireless phones pose a health hazard?

The available scientific evidence does not show that any health problems

are associated with using wireless phones. There is no proof, however,

that wireless phones are absolutely safe. Wireless phones emit low levels

of radio frequency energy (RF) in the microwave range while being used.

They also emit very low levels of RF when in the stand-by mode. Whereas

high levels of RF can produce health effects (by heating tissue), exposure

to low level RF that does not produce heating effects causes no known

adverse health effects. Many studies of low level RF exposures have not

found any biological effects. Some studies have suggested that some

biological effects may occur, but such findings have not been confirmed

by additional research. In some cases, other researchers have had

difficulty in reproducing those studies, or in determining the reasons for

inconsistent results.

What is FDA's role concerning the safety of

wireless phones?

Under the law, FDA does not review the safety of radiation-emitting

consumer products such as wireless phones before they can be sold, as it

does with new drugs or medical devices. However, the agency has

authority to take action if wireless phones are shown to emit radio

frequency energy (RF) at a level that is hazardous to the user. In such a

case, FDA could require the manufacturers of wireless phones to notify

users of the health hazard and to repair, replace or recall the phones so

that the hazard no longer exists.

Although the existing scientific data do not justify FDA regulatory actions,

FDA has urged the wireless phone industry to take a number of steps,

including the following:

•

Support needed research into possible biological effects of RF of the

type emitted by wireless phones;

•

Design wireless phones in a way that minimizes any RF exposure to

the user that is not necessary for device function; and

•

Cooperate in providing users of wireless phones with the best

possible information on possible effects of wireless phone use on

human health.

FDA belongs to an interagency working group of the federal agencies that

have responsibility for different aspects of RF safety to ensure

coordinated efforts at the federal level. The following agencies belong to

this working group:

•

National Institute for Occupational Safety and Health

•

Environmental Protection Agency

•

Federal Communications Commission

•

Occupational Safety and Health Administration

•

National Telecommunications and Information Administration

The National Institutes of Health participates in some interagency working

group activities, as well.

FDA shares regulatory responsibilities for wireless phones with the

Federal Communications Commission (FCC). All phones that are sold in

the United States must comply with FCC safety guidelines that limit RF

exposure. FCC relies on FDA and other health agencies for safety

questions about wireless phones.

FCC also regulates the base stations that the wireless phone networks

rely upon. While these base stations operate at higher power than do the

wireless phones themselves, the RF exposures that people get from

these base stations are typically thousands of times lower than those they

can get from wireless phones. Base stations are thus not the primary

subject of the safety questions discussed in this document.

What is FDA doing to find out more about the

possible health effects of wireless phone RF?

FDA is working with the U.S. National Toxicology Program and with

groups of investigators around the world to ensure that high priority

animal studies are conducted to address important questions about the

effects of exposure to radio frequency energy (RF).

FDA has been a leading participant in the World Health Organization

International Electromagnetic Fields (EMF) Project since its inception in

1996. An influential result of this work has been the development of a

detailed agenda of research needs that has driven the establishment of

new research programs around the world. The Project has also helped

develop a series of public information documents on EMF issues.

FDA and the Cellular Telecommunications & Internet Association (CTIA)

have a formal Cooperative Research and Development Agreement

(CRADA) to do research on wireless phone safety. FDA provides the

scientific oversight, obtaining input from experts in government, industry,

and academic organizations. CTIA-funded research is conducted through

contracts to independent investigators. The initial research will include

both laboratory studies and studies of wireless phone users. The CRADA

will also include a broad assessment of additional research needs in the

context of the latest research developments around the world.

What steps can I take to reduce my exposure to

radio frequency energy from my wireless

phone?

If there is a risk from these products--and at this point we do not know that

there is--it is probably very small. But if you are concerned about avoiding

even potential risks, you can take a few simple steps to minimize your

exposure to radio frequency energy (RF). Since time is a key factor in how

much exposure a person receives, reducing the amount of time spent

using a wireless phone will reduce RF exposure.

If you must conduct extended conversations by wireless phone every day,

you could place more distance between your body and the source of the

RF, since the exposure level drops off dramatically with distance. For

example, you could use a headset and carry the wireless phone away

from your body or use a wireless phone connected to a remote antenna

Again, the scientific data do not demonstrate that wireless phones are

harmful. But if you are concerned about the RF exposure from these

products, you can use measures like those described above to reduce

your RF exposure from wireless phone use.

What about children using wireless phones?

The scientific evidence does not show a danger to users of wireless

phones, including children and teenagers. If you want to take steps to

lower exposure to radio frequency energy (RF), the measures described

above would apply to children and teenagers using wireless phones.

Reducing the time of wireless phone use and increasing the distance

between the user and the RF source will reduce RF exposure.

Some groups sponsored by other national governments have advised that

children be discouraged from using wireless phones at all. For example,

the government in the United Kingdom distributed leaflets containing such

a recommendation in December 2000. They noted that no evidence exists

that using a wireless phone causes brain tumors or other ill effects. Their

recommendation to limit wireless phone use by children was strictly

precautionary; it was not based on scientific evidence that any health

hazard exists.

Do hands-free kits for wireless phones reduce

risks from exposure to RF emissions?

Since there are no known risks from exposure to RF emissions from

wireless phones, there is no reason to believe that hands-free kits reduce

risks. Hands-free kits can be used with wireless phones for convenience

and comfort. These systems reduce the absorption of RF energy in the

head because the phone, which is the source of the RF emissions, will not

be placed against the head. On the other hand, if the phone is mounted

against the waist or other part of the body during use, then that part of the

body will absorb more RF energy. Wireless phones marketed in the U.S.

are required to meet safety requirements regardless of whether they are

used against the head or against the body. Either configuration should

result in compliance with the safety limit.

Do wireless phone accessories that claim to

shield the head from RF radiation work?

Since there are no known risks from exposure to RF emissions from

wireless phones, there is no reason to believe that accessories that claim

to shield the head from those emissions reduce risks. Some products that

claim to shield the user from RF absorption use special phone cases,

while others involve nothing more than a metallic accessory attached to

the phone. Studies have shown that these products generally do not work

as advertised. Unlike “hand-free” kits, these so-called “shields” may

interfere with proper operation of the phone. The phone may be forced to

boost its power to compensate, leading to an increase in RF absorption.

In February 2002, the Federal Trade Commission (FTC) charged two

companies that sold devices that claimed to protect wireless phone users

from radiation with making false and unsubstantiated claims. According to

FTC, these defendants lacked a reasonable basis to substantiate their

claim.

Motorola Limited Warranty for

the United States and Canada

What Does this Warranty Cover?

Subject to the exclusions contained below, Motorola, Inc. warrants its

telephones, pagers, messaging devices, and consumer and professional

two-way radios (excluding commercial, government or industrial radios)

that operate via Family Radio Service or General Mobile Radio Service,

Motorola-branded or certified accessories sold for use with these

Products (“Accessories”) and Motorola software contained on CD-ROMs

or other tangible media and sold for use with these Products (“Software”)

to be free from defects in materials and workmanship under normal

consumer usage for the period(s) outlined below. This limited warranty is

a consumer's exclusive remedy, and applies as follows to new Motorola

Products, Accessories and Software purchased by consumers in the

United States or Canada, which are accompanied by this written

warranty:

Products and Accessories

Products Covered Length of Coverage

Products and Accessories

as defined above, unless

otherwise provided for below.

One (1) year

from the date of

purchase by the first consumer

purchaser of the product unless

otherwise provided for below.

Decorative Accessories and

Cases

. Decorative covers,

bezels, PhoneWrap™ covers

and cases.

Limited lifetime warranty

for the

lifetime of ownership by the first

consumer purchaser of the

product.

Exclusions

Normal Wear and Tear.

Periodic maintenance, repair and replacement of

parts due to normal wear and tear are excluded from coverage.

Batteries.

Only batteries whose fully charged capacity falls below 80% of

their rated capacity and batteries that leak are covered by this limited

warranty.

Abuse & Misuse.

Defects or damage that result from: (a) improper

operation, storage, misuse or abuse, accident or neglect, such as physical

damage (cracks, scratches, etc.) to the surface of the product resulting

from misuse; (b) contact with liquid, water, rain, extreme humidity or

heavy perspiration, sand, dirt or the like, extreme heat, or food; (c) use of

the Products or Accessories for commercial purposes or subjecting the

Product or Accessory to abnormal usage or conditions; or (d) other acts

which are not the fault of Motorola, are excluded from coverage.

Use of Non-Motorola Products and Accessories.

Defects or damage

that result from the use of Non-Motorola branded or certified Products,

Accessories, Software or other peripheral equipment are excluded from

coverage.

Monaural Headsets.

Ear

buds and boom headsets that

transmit mono sound through

a wired connection.

Limited lifetime warranty

for the

lifetime of ownership by the first

consumer purchaser of the

product.

Consumer and Professional

Two-Way Radio

Accessories.

Ninety (90) days

from the date of

purchase by the first consumer

purchaser of the product.

Products and Accessories

that are Repaired or

Replaced.

The balance of the original

warranty or for ninety (90) days

from the date returned to the

consumer, whichever is longer.

Products Covered Length of Coverage

Unauthorized Service or Modification.

Defects or damages resulting

from service, testing, adjustment, installation, maintenance, alteration, or

modification in any way by someone other than Motorola, or its authorized

service centers, are excluded from coverage.

Altered Products.

Products or Accessories with (a) serial numbers or

date tags that have been removed, altered or obliterated; (b) broken seals

or that show evidence of tampering; (c) mismatched board serial

numbers; or (d) nonconforming or non-Motorola housings, or parts, are

excluded from coverage.

Communication Services.

Defects, damages, or the failure of Products,

Accessories or Software due to any communication service or signal you

may subscribe to or use with the Products Accessories or Software is

excluded from coverage.

Software

Exclusions

Software Embodied in Physical Media.

No warranty is made that the

software will meet your requirements or will work in combination with any

hardware or software applications provided by third parties, that the

operation of the software products will be uninterrupted or error free, or

that all defects in the software products will be corrected.

Software NOT Embodied in Physical Media.

Software that is not

embodied in physical media (e.g. software that is downloaded from the

internet), is provided “as is” and without warranty.

Who is Covered?

This warranty extends only to the first consumer purchaser, and is not

transferable.

Products Covered Length of Coverage

Software.

Applies only to physical defects

in the media that embodies the copy of the

software (e.g. CD-ROM, or floppy disk).

Ninety (90) days

from the

date of purchase.

What Will Motorola Do?

Motorola, at its option, will at no charge repair, replace or refund the

purchase price of any Products, Accessories or Software that does not

conform to this warranty. We may use functionally equivalent

reconditioned/refurbished/pre-owned or new Products, Accessories or

parts. No data, software or applications added to your Product, Accessory

or Software, including but not limited to personal contacts, games and

ringer tones, will be reinstalled. To avoid losing such data, software and

applications please create a back up prior to requesting service.

How to Obtain Warranty Service or Other

Information

You will receive instructions on how to ship the Products, Accessories or

Software, at your expense, to a Motorola Authorized Repair Center. To

obtain service, you must include: (a) a copy of your receipt, bill of sale or

other comparable proof of purchase; (b) a written description of the

problem; (c) the name of your service provider, if applicable; (d) the name

and location of the installation facility (if applicable) and, most importantly;

(e) your address and telephone number.

What Other Limitations Are There?

ANY IMPLIED WARRANTIES, INCLUDING WITHOUT LIMITATION THE

IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A

USA

Phones

1-800-331-6456

Pagers 1-800-548-9954

Two-Way Radios and

Messaging Devices

1-800-353-2729

Canada

All Products

1-800-461-4575

TTY

1-888-390-6456

For

Accessories

and

Software

, please call the telephone number

designated above for the product with which they are used.

PARTICULAR PURPOSE, SHALL BE LIMITED TO THE DURATION OF

THIS LIMITED WARRANTY, OTHERWISE THE REPAIR,

REPLACEMENT, OR REFUND AS PROVIDED UNDER THIS EXPRESS

LIMITED WARRANTY IS THE EXCLUSIVE REMEDY OF THE

CONSUMER, AND IS PROVIDED IN LIEU OF ALL OTHER

WARRANTIES, EXPRESS OR IMPLIED. IN NO EVENT SHALL

MOTOROLA BE LIABLE, WHETHER IN CONTRACT OR TORT

(INCLUDING NEGLIGENCE) FOR DAMAGES IN EXCESS OF THE

PURCHASE PRICE OF THE PRODUCT, ACCESSORY OR SOFTWARE,

OR FOR ANY INDIRECT, INCIDENTAL, SPECIAL OR

CONSEQUENTIAL DAMAGES OF ANY KIND, OR LOSS OF REVENUE

OR PROFITS, LOSS OF BUSINESS, LOSS OF INFORMATION OR

DATA, SOFTWARE OR APPLICATIONS OR OTHER FINANCIAL LOSS

ARISING OUT OF OR IN CONNECTION WITH THE ABILITY OR

INABILITY TO USE THE PRODUCTS, ACCESSORIES OR SOFTWARE

TO THE FULL EXTENT THESE DAMAGES MAY BE DISCLAIMED BY

LAW.

Some states and jurisdictions do not allow the limitation or

exclusion of incidental or consequential damages, or limitation on

the length of an implied warranty, so the above limitations or

exclusions may not apply to you. This warranty gives you specific

legal rights, and you may also have other rights that vary from state

to state or from one jurisdiction to another.

Laws in the United States and other countries preserve for Motorola

certain exclusive rights for copyrighted Motorola software such as the

exclusive rights to reproduce and distribute copies of the Motorola

software. Motorola software may only be copied into, used in, and

redistributed with, the Products associated with such Motorola software.

No other use, including without limitation disassembly of such Motorola

software or exercise of the exclusive rights reserved for Motorola, is

permitted.

Product Registration

Online Product Registration:

http://www.motorola.com/warranty

Product registration is an important step toward enjoying your new

Motorola product. Registering helps us facilitate warranty service, and

permits us to contact you should your product require an update or other

service. Registration is for U.S. residents only and is not required for

warranty coverage.

Please retain your original dated sales receipt for your records. For

warranty service of your Motorola Personal Communications Product you

will need to provide a copy of your dated sales receipt to confirm warranty

status.

Thank you for choosing a Motorola product.

RF Energy Interference

This device complies with Part 15 of the FCC Rules. Operation is subject

to the following two conditions: (1) this device may not cause harmful

interference, and (2) this device must accept any interference received,

including interference that may cause undesired operation.

Export Law Assurances

This product is controlled under the export regulations of the United

States of America and Canada. The Governments of the United States of

America and Canada may restrict the exportation or re-exportation of this

product to certain destinations. For further information contact the U.S.

Department of Commerce or the Canadian Department of Foreign Affairs

and International Trade.

Wireless: The New Recyclable

Your wireless phone can be recycled. Recycling your wireless phone

reduces the amount of waste disposed in landfills and allows recycled

materials to be incorporated into new products.

The Cellular Telecommunications Industry Association (CTIA) and its

members encourage consumers to recycle their phones and have taken

steps to promote the collection and environmentally sound recycling of

end-of-life wireless devices.

As a wireless phone user, you have an important role in ensuring that this

phone is recycled properly. When it comes time to give this phone up or

trade it in for a new one, please remember that the phone, the charger,

and many of its accessories can be recycled. It's easy. To learn more

about CTIA's Recycling Program for Used Wireless Devices in the United

States, including information on where to recycle wireless devices near

you, please visit

www.recyclewirelessphones.com

✂

art# 020827-O.eps

Wireless Phone Safety

Tips

“Safety is your most important call!”

Your Motorola wireless telephone gives you

the powerful ability to communicate by voice—

almost anywhere, anytime, wherever wireless

phone service is available and safe conditions allow.

But an important responsibility accompanies the

benefits of wireless phones, one that every user

must uphold.

When driving a car, driving is your first

responsibility. If you find it necessary to use your

wireless phone while behind the wheel of a car,

practice good common sense and remember the

following tips:

1 Get to know your Motorola wireless phone and its

features such as speed dial and redial.

If available,

these features help you to place your call without taking

your attention off the road.

✂

2 When available, use a hands-free device.

If possible,

add an additional layer of convenience to your wireless

phone with one of the many Motorola Original™ hands-

free accessories available today.

3 Position your wireless phone within easy reach.

able to access your wireless phone without removing

your eyes from the road. If you receive an incoming call

at an inconvenient time, if possible, let your voice mail

answer it for you.

4 Let the person you are speaking with know you are

driving; if necessary, suspend the call in heavy traffic

or hazardous weather conditions.

Rain, sleet, snow,

ice, and even heavy traffic can be hazardous.

5 If you receive an incoming call at an inconvenient

time do not take notes or look up phone numbers

while driving.

Jotting down a “to do” list or going through

your address book takes attention away from your

primary responsibility—driving safely.

6 Dial sensibly and assess the traffic; if possible, place

calls when you are not moving or before pulling into

traffic.

Try to plan calls when your car will be stationary.

If you need to make a call while moving, dial only a few

numbers, check the road and your mirrors, then continue.

7 Do not engage in stressful or emotional

conversations that may be distracting.

Make people

you are talking with aware you are driving and suspend

conversations which have the potential to divert your

attention away from the road.

✂

8 Use your wireless phone to call for help.

Dial 9-1-1 or

other local emergency number in the case of fire, traffic

accident or medical emergencies.*

9 Use your wireless phone to help others in

emergencies.

If you see an auto accident, crime in

progress or other serious emergency where lives are in

danger, call 9-1-1 or other local emergency number, as

you would want others to do for you.*

10 Call roadside assistance or a special non-emergency

wireless assistance number when necessary.

If you

see a broken-down vehicle posing no serious hazard, a

broken traffic signal, a minor traffic accident where no

one appears injured, or a vehicle you know to be stolen,

call roadside assistance or other special non-emergency

wireless number.*

* Wherever wireless phone service is available.

✂

Check the laws and regulations on the use of

wireless telephones and their accessories in the

areas where you drive. Always obey them. The

use of these devices may be prohibited or

restricted in certain areas.

For more information,

please call

1-888-901-SAFE

or visit the

CTIA Web site at

www.wow-com.com

™

Motorola Mobility T56EF1 Portable Cellular/PCS Transceiver (CDMA) User Manual UG C330 GSM

Motorola Mobility LLC Portable Cellular/PCS Transceiver (CDMA) UG C330 GSM

Exhibit 8 Users Manual

Navigation menu

Namespaces

Views

Navigation
