Motorola Mobility T56ES1 Portable Dual Band GSM Transceiver with Bluetooth User Manual E790 NA

Motorola Mobility LLC Portable Dual Band GSM Transceiver with Bluetooth E790 NA

Exhibit 8 Users Manual

APPLICANT: MOTOROLA, INC. FCC ID: IHDT56ES1
EXHIBIT 8
INSTRUCTION MANUAL
A preliminary draft copy of the Users Manual follows:
E790
GSM
1
HELLOMOTO
Introducing your new Motorola E790 GSM wireless phone.
Here’s a quick anatomy lesson.
Left Soft Key
Perform function
in lower left
display.
Headset Jack
Stereo Speakers
(both sides)
Camera Key
Activate camera
& take photos.
Volume Key
Smart Key
5-Way Navigation
Joystick with
Center Select
Scroll through
menus, press in
to select items.
Menu Key
Accessory
Connector Port
Insert charger
& phone
accessories.
Right Soft Key
Perform function
in lower right
display.
Power & End Key
Turn phone
on/off, end calls,
exit menu
system.
Send Key
Make & answer
calls.
2
check it out!
check it out!
feature
download
music files
Use the memory card as the default USB
connection:
M
>
Settings
>
Connection > USB Settings
> Memory Card
On your computer, open iTunes, connect
your phone to your computer, and drag
and drop music files to your phone.
play music
Play a song on your phone:
iTunes
>
Songs
> song name >
Play
Tip:
Your phone must be disconnected
from your computer to play songs.
032385o.eps
Camera Key
Activate camera
& take photos.
Mirror
Aim camera lens
for self portraits.
Camera Lens
Integrated Short-
Range Light
Stereo Speakers
(both sides)
3
check it out!
create playlist
Create a playlist of songs on your phone:
On your computer, open iTunes, click the
Add
(
+
) button, and type a name for the
playlist. Then drag songs from your
music library to your playlist.
Connect your phone to your computer
and drag and drop the playlist onto your
phone.
rhythm lights
Activate lights to flash in sync with the
sounds around you:
M
>
Settings
>
Personalize > Rhythm Lights
ring lights
Choose ring lights for incoming calls:
M
>
Settings
> Ring Styles>
Ring Lights
>
> light pattern
take photo &
send
Press
j
to activate the camera. Point
lens and press
CAPTURE
to take a photo.
To send, press the
STORE
key and
select
Send In Message
.
phone skin
Apply different skins to the display:
M
>
Settings
> Personalize>
Skin
> skin
send
multimedia
message
Send a message with pictures,
animations, sounds, and videos:
M
>
Messages
>
Create Message
>
New
Multimedia Message
feature
4
Motorola, Inc.
Consumer Advocacy Office
1307 East Algonquin Road
Schaumburg, IL 60196
www.hellomoto.com
1-800-331-6456 (United States)
1-888-390-6456 (TTY/TDD United States for hearing impaired)
1-800-461-4575 (Canada)
MOTOROLA and the Stylized M Logo are registered in the US Patent &
Trademark Office. All other product or service names are the property of
their respective owners.
The Bluetooth trademarks are owned by their proprietor and used by
Motorola, Inc. under license.
Microsoft, Windows, ActiveSync and Windows Media are registered
trademarks of Microsoft Corporation; and Windows XP and Windows
Mobile are trademarks of Microsoft Corporation.
© Motorola, Inc., 2005.
Caution:
Changes or modifications made in the radio phone, not expressly
approved by Motorola, will void the user’s authority to operate the
equipment.
The information contained in Motorola's user's guides is believed to be
correct at the time of printing. Motorola reserves the right to change or
modify any information or specifications without notice. The contents of
Motorola’s user's guides are provided “as is.” Except as required by
applicable law, no warranties of any kind, either express or implied,
including, but not limited to, the implied warranties of merchantability and
fitness for a particular purpose, are made in relation to the accuracy,
reliability, or contents of this guide.
Manual Number: 68XXXXXX92-O
5
HELLOMOTO
contents
check it out! . . . . . . . . . . 2
contents . . . . . . . . . . . . . 5
Safety Information . . . . . 7
EU Conformance. . . . . . 14
Recycling Information . 15
essentials . . . . . . . . . . . 16
about this guide . . . . . 16
SIM card . . . . . . . . . . . 17
battery. . . . . . . . . . . . . 17
turn it on & off. . . . . . . 20
make a call . . . . . . . . . 20
answer a call . . . . . . . . 20
your phone number . . 21
main attractions . . . . . . 22
use iTunes. . . . . . . . . . 22
take & send a photo . . 26
record & play video clip. .
28
multimedia messages. 31
lights . . . . . . . . . . . . . . 33
memory card . . . . . . . 35
Bluetooth® connections .
38
basics. . . . . . . . . . . . . . . 42
display. . . . . . . . . . . . . 42
menus. . . . . . . . . . . . . 46
text entry . . . . . . . . . . 48
volume . . . . . . . . . . . . 52
navigation key . . . . . . . 52
smart key . . . . . . . . . . 53
handsfree speaker . . . 53
codes & passwords . . 53
lock & unlock phone . . 54
customize . . . . . . . . . . . 55
ring style. . . . . . . . . . . 55
time & date. . . . . . . . . 56
wallpaper . . . . . . . . . . 56
screen saver . . . . . . . . 57
themes . . . . . . . . . . . . 57
display appearance . . . 58
answer options . . . . . . 58
vibrations . . . . . . . . . . 59
6
HELLOMOTO
calls . . . . . . . . . . . . . . . 60
turn off a call alert . . . 60
recent calls . . . . . . . . 60
redial . . . . . . . . . . . . . 61
return a call . . . . . . . . 62
notepad . . . . . . . . . . . 62
hold or mute a call. . . 62
call waiting . . . . . . . . 63
caller ID . . . . . . . . . . . 63
emergency calls . . . . 64
international calls. . . . 64
1-touch dial . . . . . . . . 64
voicemail . . . . . . . . . . 65
other features . . . . . . . 66
advanced calling . . . . 66
phonebook . . . . . . . . 68
messages . . . . . . . . . . 74
email . . . . . . . . . . . . . . 76
instant messaging . . . 78
chat . . . . . . . . . . . . . . 79
personalizing . . . . . . . 79
call times & costs . . . 82
handsfree . . . . . . . . . 83
data & fax calls . . . . . 84
network . . . . . . . . . . . 85
personal organizer . . . 85
security . . . . . . . . . . . 87
fun & games . . . . . . . 87
troubleshooting . . . . . 89
SAR Data . . . . . . . . . . . 90
SAR Data . . . . . . . . . . . 92
Index . . . . . . . . . . . . . . 94
7
Safety Information
Safety and General Information
Safety I nformation
IMPORTANT INFORMATION ON SAFE AND EFFICIENT OPERATION. READ
THIS INFORMATION BEFORE USING YOUR PHONE.
1
Exposure To Radio Frequency (RF) Energy
Your phone contains a transmitter and a receiver. When it is ON, it receives
and transmits RF energy. When you communicate with your phone, the
system handling your call controls the power level at which your phone
transmits.
Your Motorola phone is designed to comply with local regulatory
requirements in your country concerning exposure of human beings to RF
energy.
Operational Precautions
To assure optimal phone performance and make sure human exposure to
RF energy is within the guidelines set forth in the relevant standards,
always adhere to the following instructions.
External Antenna Care
If your phone has an external antenna, use only the supplied or
Motorola-approved replacement antenna. Unauthorized antennas,
modifications, or attachments could damage the phone and/or may result
in non-compliance with local regulatory requirements in your country.
Do NOT hold the external antenna when the phone is IN USE. Holding the
external antenna affects call quality and may cause the phone to operate
at a higher power level than needed.
Phone Operation
When placing or receiving a phone call, hold your phone as you would a
wireline phone.
8
Safety Information
Body-Worn Operation: Voice Communication
To maintain compliance with RF energy exposure guidelines, if you wear a
phone on your body when transmitting voice communications, always
place the phone in a Motorola-supplied or approved clip, holder, holster,
case, or body harness for this phone, if available. Use of accessories not
approved by Motorola may exceed RF energy exposure guidelines.
If you do not use one of the body-worn accessories approved or supplied by
Motorola, and are not using the phone held in the normal use position,
ensure the phone and its antenna are at least 2.5 centimeters (1 inch) from
your body when transmitting.
Data Operation
When using any data feature of the phone, with or without an accessory
cable, position the phone and its antenna at least 2.5 centimeters (1 inch)
from your body.
Approved Accessories
Use of accessories not approved by Motorola, including but not limited to
batteries, antennas, and convertible covers, may cause your phone to
exceed RF energy exposure guidelines. For a list of approved Motorola
accessories, visit our website at
www.motorola.com
.
RF Energy Interference/Compatibility
Note:
Nearly every electronic device is susceptible to RF energy
interference from external sources if inadequately shielded, designed, or
otherwise configured for RF energy compatibility. In some circumstances
your phone may cause interference.
Note:
This device complies with Part 15 of the FCC Rules. Operation is
subject to the following two conditions: (1) this device may not cause
harmful interference, and (2) this device must accept any interference
received, including interference that may cause undesired operation.
9
Safety Information
Facilities
Turn off your phone in any facility where posted notices instruct you to do
so. These facilities may include hospitals or health care facilities that may
be using equipment that is sensitive to external RF energy.
Aircraft
Turn off your wireless device whenever instructed to do so by airline staff.
If your device offers a flight mode or similar feature, consult airline staff
about use in flight. If your device offers a feature that automatically turns
on the phone, then turn off this feature before boarding an airplane or
entering an area where the use of wireless devices is restricted.
Medical Devices
Pacemakers
Pacemaker manufacturers recommend that a minimum separation of
15 centimeters (6 inches) be maintained between a handheld wireless
phone and a pacemaker.
Persons with pacemakers should:
•
ALWAYS keep the phone more than 15 centimeters (6 inches) from
your pacemaker when the phone is turned ON.
•
NOT carry the phone in the breast pocket.
•
Use the ear opposite the pacemaker to minimize the potential for
interference.
•
Turn OFF the phone immediately if you have any reason to suspect
that interference is taking place.
Hearing Aids
Some digital wireless phones may interfere with some hearing aids. In the
event of such interference, you may want to consult your hearing aid
manufacturer to discuss alternatives.
10
Safety Information
Other Medical Devices
If you use any other personal medical device, consult the manufacturer of
your device to determine if it is adequately shielded from RF energy. Your
physician may be able to assist you in obtaining this information.
Use While Driving
Check the laws and regulations on the use of phones in the area where you
drive. Always obey them.
When using your phone while driving, please:
•
Give full attention to driving and to the road. Using a phone may be
distracting in certain circumstances. Discontinue a call if you can’t
concentrate on driving.
•
Use handsfree operation, if available.
•
Pull off the road and park before making or answering a call if
driving conditions so require.
Responsible driving best practices can be found in the “Wireless Phone
Safety Tips” at the end of this guide and/or at the Motorola website:
www.motorola.com/callsmart
.
Operational Warnings
For Vehicles With an Air Bag
Do not place a phone in the area over an air bag or in the air bag
deployment area. Air bags inflate with great force. If a phone is placed in
the air bag deployment area and the air bag inflates, the phone may be
propelled with great force and cause serious injury to occupants of the
vehicle.
Gas or Petrol Stations
Obey all posted signs with respect to the use of radio equipment in gas or
petrol stations. Turn off your wireless device if instructed by authorized
staff.
11
Safety Information
Potentially Explosive Atmospheres
Turn off your phone prior to entering any area with a potentially explosive
atmosphere. Do not remove, install, or charge batteries in such areas.
Sparks in a potentially explosive atmosphere can cause an explosion or fire
resulting in bodily injury or even death.
Note:
The areas with potentially explosive atmospheres referred to above
include fueling areas such as below decks on boats, fuel or chemical
transfer or storage facilities, areas where the air contains chemicals or
particles, such as grain, dust, or metal powders. Areas with potentially
explosive atmospheres are often but not always posted.
Blasting Caps and Areas
To avoid possible interference with blasting operations, turn OFF your
phone when you are near electrical blasting caps, in a blasting area, or in
areas posted “Turn off electronic devices.” Obey all signs and instructions.
Damaged Products
If your phone or battery has been submerged in water, punctured, or
subjected to a severe fall, do not use it until you take it to a Motorola
Authorized Service Center to determine if it has been damaged. Do not
attempt to dry it with an external heat source, such as a microwave oven.
Batteries and Chargers
Batteries can cause property damage and/or bodily injury such as burns if a
conductive material such as jewelry, keys, or beaded chains touch exposed
terminals. The conductive material may complete an electrical circuit (short
circuit) and become hot. Take care when handling a charged battery,
particularly when placing it inside a pocket, purse, or other container with
metal objects.
Use only Motorola Original™ batteries and chargers.
Caution:
To avoid risk of personal injury, do not dispose of your battery in a
fire.
Your battery, charger, or phone may contain symbols, defined as follows:
12
Safety Information
Choking Hazards
Your phone or its accessories may include detachable parts, which may
present a choking hazard to small children. Keep your phone and its
accessories away from small children.
Seizures/Blackouts
Some people may be susceptible to epileptic seizures or blackouts when
exposed to flashing lights, such as when watching television or playing
video games. These seizures or blackouts may occur even if a person never
had a previous seizure or blackout.
If you have experienced seizures or blackouts, or if you have a family
history of such occurrences, please consult with your doctor before playing
video games on your phone or enabling a flashing-lights feature on your
phone. (The flashing-light feature is not available on all products.)
Parents should monitor their children's use of video game or other features
that incorporate flashing lights on the phones. All persons should
discontinue use and consult a doctor if any of the following symptoms
Symbol Definition
Important safety information will follow.
Your battery or phone should not be disposed of in a
fire.
Your battery or phone may require recycling in
accordance with local laws. Contact your local
regulatory authorities for more information.
Your battery or phone should not be thrown in the trash.
Your phone contains an internal lithium ion battery.
032374o
032376o
032375o
032377o
032378o
Li Ion BATT
13
Safety Information
occur: convulsion, eye or muscle twitching, loss of awareness, involuntary
movements, or disorientation.
To limit the likelihood of such symptoms, please take the following safety
precautions:
•
Do not play or use a flashing-lights feature if you are tired or need
sleep.
•
Take a minimum of a 15-minute break hourly.
•
Play in a room in which all lights are on.
•
Play at the farthest distance possible from the screen.
Repetitive Motion Injuries
When you repetitively perform actions such as pressing keys or entering
finger-written characters, you may experience occasional discomfort in
your hands, arms, shoulders, neck, or other parts of your body. Follow these
instructions to avoid problems such as tendonitis, carpal tunnel syndrome,
or other musculoskeletal disorders:
•
Take a minimum 15-minute break every hour of game playing.
•
If your hands, wrists, or arms become tired or sore while playing,
stop and rest for several hours before playing again.
•
If you continue to have sore hands, wrists, or arms during or after
play, stop playing and see a doctor.
1. The information provided in this document supersedes the general safety
information in user’s guides published prior to January 28, 2005.
14
EU Conformance
European Union Directives
Conformance Statement
EU Confor mance
Hereby, Motorola declares that this product is in compliance
with:
•
The essential requirements and other relevant provisions of
Directive 1999/5/EC
•
All other relevant EU Directives
The above gives an example of a typical Product Approval Number.
You can view your product’s Declaration of Conformity (DoC) to Directive
1999/5/EC (to R&TTE Directive) at www.motorola.com/rtte. To find your
DoC, enter the product Approval Number from your product’s label in the
“Search” bar on the Web site.
0168
Product
Approval
Number
15
Recycling Information
Recycling Information
Caring for the Environment by
Recycling
When you see this symbol on a Motorola product, do not dispose
the product with household waste.
Recycling Mobile Phones and
Accessories
Do not dispose of mobile phones or electrical accessories, such as chargers
or headsets, with your household waste. In some countries or regions,
collection systems are set up to handle electrical and electronic waste
items. Contact your regional authorities for more details. If collection
systems aren’t available, return unwanted mobile phones or electrical
accessories to any Motorola Approved Service Centre in your region.
16
essentials
essentials
about this guide
This guide shows how to locate a menu feature as follows:
Find it:
Press
M
>
Recent Calls
>
Dialed Calls
This example shows that, from the home screen, you press
M
to open the menu, highlight and select
sRecent Calls
, then
highlight and select
Dialed Calls
.
Press
S
to scroll to and highlight a menu feature. Press the
SELECT
key to select the highlighted menu feature.
symbols
This means a feature is network/subscription
dependent and may not be available in all areas.
Contact your service provider for more information.
This means a feature requires an optional accessory.
CAUTION: Before using the phone for the
first time, read the
Important Safety and
Legal Information
included in the
gray-edged pages at the back of this guide.
032257o
17
essentials
SIM card
Yo u r Subscriber Identity Module (SIM) card contains personal
information like your phone number and phonebook entries.
Caution:
Don’t bend or scratch your SIM card. Keep it away
from static electricity, water, and dirt.
battery
battery tips
Battery life depends on the network, signal strength,
temperature, features, and accessories you use.
032386o
1.
032387o
2.
032388o
3.
032389o
4.
18
essentials
•
Always use Motorola Original batteries and
chargers. The warranty does not cover
damage caused by non-Motorola batteries
and/or chargers.
•
New batteries or batteries stored for a long time may
take more time to charge.
•
When charging your battery, keep it near room
temperature.
•
When storing your battery, keep it uncharged in a cool,
dark, dry place, such as a refrigerator.
•
Never expose batteries to temperatures below -10°C
(14°F) or above 45°C (113°F). Always take your phone
with you when you leave your vehicle.
•
It is normal for batteries to gradually wear down and
require longer charging times. If you notice a change in
your battery life, it is probably time to purchase a new
battery.
Contact your local recycling center for proper battery
disposal.
Warning:
Never dispose of batteries in a fire because they
may explode.
Before using your phone, read the battery safety information
in the “Safety and General Information” section included in
the gray-edged pages at the back of this guide.
19
essentials
battery installation
battery charging
New batteries are not fully
charged. Plug the travel
charger into your phone and
an electrical outlet. Your
phone displays
Charge Complete
when finished.
Tip:
Relax, you can’t overcharge your battery. It will perform
best after you fully charge and discharge it a few times.
032386o
1.
032390o
2.
032391o
3.
032392o
20
essentials
turn it on & off
Caution:
On power up, the phone may prompt you to enter
your SIM card PIN code to unlock the SIM card. If you enter
an incorrect PIN code 3 times in a row, your SIM card is
disabled and your phone displays
SIM Blocked
. Contact your
service provider.
To turn on your phone, press and hold
O
for a few seconds or until the
display turns on. If prompted, enter
your 6-digit SIM card PIN code and/or
4-digit unlock code.
Note:
You might be prompted to
personalize your phone. Select
Yes
to set them, or
No
to go to
the idle display. You can set your personal options later, see
page 70.
To turn off your phone, press and hold
O
for 2 seconds.
make a call
Enter a phone number and press
N
to make a call.
answer a call
When your phone rings and/or vibrates, press
N
to answer.
To “hang up,” press
O
.
032393o.eps
21
essentials
your phone number
From the home screen, press
M#
to see your number.
Tip:
Want to see your phone number while you’re on a call?
Press
M
>
My Tel. Numbers
.
To store or edit your name and number on your SIM
card, press the
EDIT
key while displaying it. If you don’t
know your phone number, contact your service provider.
22
main attractions
main attractions
You can do much more with your phone than make and
receive calls!
use iTunes
iTunes is a software application you use to manage the music
on your computer and transfer music to your phone. You can
use iTunes to purchase and download music for your phone,
listen to CDs and digital music, and create playlists of your
favorite songs on your phone.
on the phone
From the home screen, press the
iTunes
key to see the iTunes
dsiplay.
c
i
ìë
Song Title
0:00 / 1:44
STYLES CAMERA
Song Running
Time
Menu Indicator
Left Soft Key
Label
Right Soft Key
Label
Previous/Rewind
Play
Next/Fast Forward
iTunes
23
main attractions
opening iTunes
Press the navigation key
S
down to select
i
. The iTunes
menu displays.
playing songs
To play an individual song, use
S
to scroll to
Songs
> song
name and press the
PLAY
key.To play all the songs in a list, use
S
to scroll to
Albums
,
Artists
, or
Playlist
. Then use
S
to scroll
right, select
All
and press the
PLAY
key.
Tip:
Your phone must be disconnected from your computer
to play songs. Don’t disconnect your phone while music is
being transferred.
EXIT PLAY
iTunes
Playlist
Artists
Albums
Songs
Shuffle Songs
>
>
>
>
>
24
main attractions
iTunes controls
with your computer
using the iTunes Music Store
Using iTunes, you can preview, purchase, and download your
favorite songs from the iTunes Music Store (available in some
feature
turn iTunes off
& on
Press the
iTunes
key.
select a menu
item
Use
S
to scroll to menu items, and
select by pressing right.
To return to a previous item, press
S
left.
Tip:
You can use the left and right soft
keys to
PLAY
songs or
EXIT
menus.
pause a song
From the home screen iTunes display,
press
S
up to toggle between
Play (
c
)/Pause(
T
). Or from iTunes press
the
PAUSE
key.
start a song
over
Press
Previous/Rewind
.
play the
previous song
Press
Previous/Rewind
twice.
fast forward
Press
Next/Fast Forward
.
rewind
Press
Previous/Rewind
.
shuffle songs
Press
i
for the iTunes menu. Use
S
to
scroll to
Shuffle Songs
and press
PLAY
.
25
main attractions
countries only). There are hundreds of thousands of songs
available for purchase. You can use an Apple Account to
purchase songs from the music store, or if you have an
American Online (AOL) Account, you can use that.
To browse for and purchase music:
1
Open iTunes and click Music Store in the Source List.
2
Click the Account button and follow the on screen
instructions to set up an account or enter your existing
Apple Account or AOL account information.
3
Once logged into your account, browse and purchase
music.
Tip:
When you purchase a song it appears in the
Purchased Music playlist. You can drag and drop these
songs into playlists you create or directly onto your
phone.
For more information about the iTunes Music Store open
iTunes and choose Help > iTunes and Music Store Help.
downloading music
First, set up the phone to use the memory card as the default
USB connection. On your phone:
M
>
Settings
>
Connection > USB
Settings > Memory Card
On your computer, open iTunes, connect your phone to your
computer, and when the phone appears as a source, drag
and drop music files to your phone.
Note:
When the music is done being downloaded to your
phone, your phone screen displays
OK to Disconnect
. Remove the
26
main attractions
USB cable. Press the large button and pull the USB cable
from the phone.
create a playlist
In iTunes, click the
Add
(
+
), and type a name for the playlist.
Then drag songs from your music library to your
playlist.Connect your phone to your computer and drag and
drop the playlist onto your phone.
Tip:
Your phone must be disconnected from your computer
to play songs. Don’t disconnect your phone while music is
being transferred.
take & send a photo
From the home screen, press the
CAMERA
key to see the
camera viewfinder:
AREA
BACK CAPTURE
Press
BACK
(
-
) to return
to previous screen.
Press
S
up or
down to zoom
in or out.
Press
S
left
or right to
decrease or
increase image
brightness.
Press
M
to open
Pictures Menu
.
Photo Storage
Space Used
(Phone or
Memory Card)
Press
CAPTURE
(
+
)
to take a photo.
Photo Viewfinder
Memory Used:72%
27
main attractions
Tip:
To adjust lighting conditions press
M
>
Pictures Set-up
>
Lighting Conditions
>
CHANGE
1
Point the camera lens at the photo subject.
2
Press the
CAPTURE
key to take a photo.
•
To delete the photo and return to the active viewfinder,
press the
DISCARD
key.
•
To store or send the photo, press the
STORE
key.
Your storage options are
Send in Message
,
Print and Store
,
Store Only
,
Apply as Wallpaper
,
Apply as Screen Saver
, or
Apply as Phone Entry
.
You can use the
Print and Store
option to print the picture
over a Bluetooth.® connection (see page 29).
self portrait
1
Press the
CAMERA
key to activate the camera.
2
Press
M
>
Auto-Timed Capture
.
3
Press
S
left or right to set a 5 or 10 second timer delay,
then press the
START
key.
4
Aim the camera lens.
5
When you hear the camera click your photo is displayed.
camera settings
Press
M
in the viewfinder to open the
Pictures Menu
. This
menu can include:
28
main attractions
record & play video clip
record video clip
Find it:
Press
M
>
Multimedia
>
Videos
>
[New Video]
option
Go To Pictures
View stored pictures and photos.
Switch Storage Device
Save the photo on the phone or memory
card.
Auto-Timed Capture
Set a timer for the camera to take a
photo.
Pictures Setup
Adjusts picture settings.
Switch Storage Device
Save the photo on the phone or memory
card.
View Free Space
See how much memory remains for
storing pictures.
29
main attractions
The active viewfinder image displays.
Note:
You can zoom only before you start recording.
1
Point the camera lens at the video subject.
2
Press the
CAPTURE
key to begin video recording.
3
Press the
STOP
key to stop video recording.
•
To delete the video clip and return to the active
viewfinder, press the
DISCARD
key.
•
To store the video clip, press the
STORE
key.
Your storage options are
Send in Message
or
Store Only
.
VIDEO
CLIP
AREA
BACK CAPTURE
Press
S
up or
down to pause
or play video
clip.
Press
S
left
or right to skip
to previous or
next video clip.
Press
BACK
(
-
) to
return to previous
screen.
Press
M
to
open
Videos
Menu
.
Timer indicates
% played.
Press
CAPTURE
(
-
)
to start
recording
video.
Video Clip Name
 Playing
30
main attractions
play video clip
Find it:
Press
M
>
Multimedia
>
Videos
> video clip
The video clip displays in the playback screen.
video settings
Press
M
in the viewfinder to open the
Videos Menu
. This menu
can include:
option
Go To Videos
View video clips stored on your phone.
Switch Storage Device
Save the video on the phone or memory
card.
VIDEO
CLIP
AREA
BACK DETAILS
Press
S
up or
down to pause
or play video
clip.
Press
S
left
or right to skip
to previous or
next video clip.
Press
BACK
(
-
) to
return to previous
screen.
Press
M
to
open
Videos
Menu
.
Timer indicates
% played.
Press
DETAILS
(
-
) to
view video clip
information.
Video Clip Name
 Playing
31
main attractions
multimedia messages
For more message features, see page 65.
send a multimedia message
A Multimedia Messaging Service (MMS) message
contains pages with text and media objects (including
photos, pictures, animations, or sounds). You can send the
multimedia message to other MMS-capable phones, and to
email addresses.
Find it:
Press
M
>
Messages
>
Create Message
>
New Multimedia Msg
1
Press keypad keys to enter text on the page (for details
about text entry, see page 39).
To in s e r t a
picture, sound, or other object
on the page,
press
M
>
Insert
. Select the file type and the file.
Videos Setup
Open the setup menu to adjust video
settings.
Note:
If you set
Video Length
to
Maximum
,
your network might not let you send the
video clip in a multimedia message. If
necessary, ask your service provider
about limitations.
View Free Space
See how much memory remains for
storing video clips.
option
32
main attractions
To insert
another page
in the message, enter text or
objects on the current page and press
M
>
Insert
>
New Page
. You can enter more text and objects
on the new page.
2
When you finish the message, press the
OK
key.
3
Choose one or more people for
Send To
:
To select a
phonebook entry
, highlight the entry and
press the
ADD
key. Repeat to add other phonebook
entries.
To
enter
a new number, highlight
[One Time Entry]
and press
the
SELECT
key.
To
enter and store
a new number, highlight
[New Phonebook Entry]
and press the
SELECT
key.
4
When you finish entering numbers/addresses, press the
DONE
key. Your phone displays the message fields.
To enter a
subject
for the message, highlight
Subject
and
press the
CHANGE
key.
To
attach a file
to the message, highlight
Attachments
and
press the
CHANGE
key. Select the file type and the file.
To request a
delivery receipt
for the message, highlight
Receipt
and press the
CHANGE
key. Press the
ADD
key.
5
To
send
the message, press the
SEND
key.
To
cancel or save
the message as a
Draft
, press
M
.
33
main attractions
receive a multimedia message
When you receive a multimedia message or letter, your
phone plays an alert and displays
New Message
with a
message indicator such as
r
.
Press the
READ
key to open the message.
•
Photos, pictures, and animations display as you read
the message.
•
A sound file plays when its page displays. Use the
volume keys to adjust the sound volume.
Note:
In a multimedia letter, you may have to highlight
an indicator in the text to play a sound file.
•
Attached files are added to the end of the message. To
open an attachment, highlight the file
indicator/filename and press the
VIEW
key (image),
PLAY
key (sound), or
OPEN
key (phonebook vCard,
datebook vCalendar entry, or unknown file type).
lights
club lights
You can set your phone’s display and keypad to flash rhythm
lights in sync with the music and sounds around you.
Find it:
Press
M
>
Settings
>
Personalize
>
Club Lights
option
Pattern
Choose a the light pattern to activate the
club lights, or turn the lights
Off
.
34
main attractions
Note:
Don’t expect the club lights to work when your battery
is low or when you are on a phone call. The lights pause
when you receive a call or message or if you press a key.
If you want your phone keypad and display to flash for
incoming calls and messages, you need to set ring lights (see
the following section).
ring lights
Use ring lights to set up your phone to flash a light pattern
when receiving a call or message.
Find it:
M
>
Settings
>
Ring Styles
>
Ring Lights
>
light pattern
Tip:
The same light pattern displays for all calls. If you want
specific light patterns for calls from a specific phonebook
category, use the light ID feature (see page 62).
event lights
You can set up event lights for your phone to display a light
pattern when there are: incoming calls from phonebook
categories, incoming text and voicemail messages, alarms,
Timer
Set how long the club lights stay active
(up to 10 minutes).
Sensitivity
Set how loud the surrounding music or
sounds must be for the club lights to
respond. Values range from 1 (least
sensitive) to 7 (most sensitive).
option
35
main attractions
power up, power down, battery charging, Bluetooth
®
connect, Bluetooth activity, and Bluetooth disconnect.
To turn even lights on or off:
Find it:
M
>
Settings
>
Ring Styles
>
Event Lights
>
On or Off
memory card
You can use a removable memory card with your phone
to store and retrieve multimedia objects (such as
photos and sounds).
install a memory card
Note:
If you install the memory card when your phone is
turned on, you might have to turn the phone off and on again
before you try to use the card. Do not remove your memory
card while your phone is using or writing files on it.
1. 2.
36
main attractions
Caution:
Don’t bend or scratch your memory card. Keep it
away from static electricity, water, and dirt.
see and change memory card information
Find it:
Press
M
>
Settings
>
Phone Status
>
Storage Devices
1
Press
S
to highlight the memory card.
2
Press the
DETAILS
key to see memory card information
or
Press
M
to see the
Storage Device
menu, which lets you
Format
or
Rename
the memory card.
To see memory card files
, open a file list (such as
Pictures
or
Sounds
) and press
M
>
Switch Storage Device
>
TRANS
. To see files
stored on your phone again, press
M
>
Switch Storage Device
>
Phone
.
connect the memory card to a computer
You can access your phone’s memory card with a PC.
3.
37
main attractions
Note:
When your phone is connected to a computer, you can
only access the memory card through the computer.
On your phone:
Press
M
>
Settings
>
Connection
>
USB Settings
>
Memory Card
.
This directs the USB connection to your memory
card. Attach the Motorola Original USB cable to the
accessory port on your phone and to an available
USB port on your computer. Then follow these
steps:
On your computer:
1
Find where your phone’s memory card displays as a
“Removable Disk” icon. On a PC this is the “My
Computer” window. On a Mac the icon appears on the
desktop.
2
Double-click on the “Removable Disk” icon to access the
files on your phone’s memory card.
3
To store the desired files onto the memory card, drag and
drop them as follows:
MP3 files:
> mobile > audio
screen savers:
> mobile > picture
wallpapers:
> mobile > picture
video clips:
> mobile > video
4
When you finish, you need to remove the device safely
from your computer:
If you are using a PC
, right-click the “Safely Remove
Hardware” icon in the system tray at the bottom of your
computer screen. Then select “USB Mass Storage
Devices” and “Stop”.
38
main attractions
If you are using a Mac
, select and drag the “Removable
Disk” icon to the “Trash.”
5
Select “USB Mass Storage Device” then “OK”.
On your phone:
To return to
Data Fax
as your USB default connection, press
M
>
Settings
>
Connection
>
USB Settings
>
Data/Fax Connection
.
store and use protected content
If you try to play a copyrighted file, it might ask you to
download a license. Some licenses only let you play a file for
a certain number of times or days. You cannot send, copy, or
change copyrighted files.
For example, a license may allow you to play the content of
your download 5 times or use the content for 3 days before it
expires.
To activate downloaded copyrighted files:
Find it:
Press
M
> >
Activation List
> file type > file
You can see file’s
Status
,
Type
,
Activation
, and
Counts Remaining
.
Bluetooth® connections
Your phone supports Bluetooth wireless connections. You
can set up a wireless link with a Bluetooth headset or car kit,
or connect to another device to exchange and synchronize
files.
39
main attractions
turn Bluetooth power on or off
Find it:
Press
M
>
Settings
>
Connection
>
Bluetooth Link
>
Setup
>
Power
>
On
When Bluetooth power is on, a handsfree accessory can
automatically reconnect to your phone when you turn on the
accessory or move it within range of the phone.
To extend battery life, use the above procedure and set
Bluetooth power to
Off
when not in use.
connect a headset or handsfree device
Find it:
Press
M
>
Settings
>
Connection
>
Bluetooth Link
>
Handsfree
>
[Look For Devices]
Note:
If Bluetooth power is turned off, your phone prompts
you to turn it on.
Your phone scans for devices, and displays the ones it finds
within range. Highlight a device name and press the
SELECT
key to connect. When your phone is connected, the
Bluetooth indicator
à
displays in the home screen.
•
You can only connect your phone to one device at a
time.
•
The device may request permission to bond with your
phone. Press the
YES
key and enter the correct PIN
code to create a secure connection with the device.
40
main attractions
send objects to another device
You can use a Bluetooth wireless connection to send a
media object, phonebook entry, datebook event, or
bookmark from your phone to another device.
1
Highlight the object on your phone that you want to send
to the other device, then press
M
>
Copy
or
Send
.
2
Select a recognized device name listed in the
Object Exchange
menu, or
[Look For Devices]
to search for the device to which
you want to send the object.
advanced Bluetooth® features
feature
make phone
visible to other
device
Allow a Bluetooth device to
discover your phone:
M
>
Settings
>
Connection
>
Bluetooth Link
>
Setup
>
Find Me
connect to
recognized
device
Connect to a recognized handsfree
device:
M
>
Settings
>
Connection
>
Bluetooth Link
>
Handsfree
> device name
disconnect
from device
Highlight the device name and
press the
DROP
key.
switch to
device during
call
Switch to a headset or car kit
during a call:
M
>
Use Bluetooth
41
main attractions
move
multimedia
object to
device
Move a multimedia object to
another device:
Highlight the object, press
M
>
Move
,
select the device name.
Caution:
Moving an object
deletes
the
original object from your phone.
edit device
properties
Edit the properties of a recognized
device:
Highlight the device name, press
M
>
Edit
.
set Bluetooth
options
Highlight the device name, press
M
>
Settings
>
Connection
>
Bluetooth Link
>
Setup
feature
42
basics
basics
See page 1 for a basic phone diagram.
display
The home screen displays when you turn on the phone. To
dial a number from the home screen, press number keys and
N
.
Note:
Your home screen may look different than the one
below, depending on your service provider.
The menu indicator
À
shows that you can press
M
to open
the menu. Soft key labels show the current soft key
functions. For soft key locations, see page 1.
Press
S
up, down, left, or right to open basic menu features
identified by the menu feature icons in the home screen. (You
Menu Indicator
Service Provider
10/15/04
STYLES CAMERA
Left Soft Key
Label
Right Soft Key
Label
Date
Recent Calls
Messages
Clock
Browser
Phonebook
43
basics
can select these menu features even when the icons are
hidden from view.) Press
O
to return to the home screen.
Status indicators can display at the top of the home screen:
1Data Indicator –
Shows connection status. The
Bluetooth® wireless connection indicator
à
shows when
a Bluetooth connection is active. Other indicators can
include:
2 EDGE/GPRS Indicator –
Shows when your phone
is using a high-speed Enhanced Data for GSM
4
= secure packet data
transfer
7
= unsecure packet
data transfer
3
= secure application
connection
6
= unsecure
application connection
2
= secure Circuit
Switch Data (CSD) call
5
= unsecure CSD call
Service Provider
10/15/04
STYLES CAMERA
3.
Signal
Strength
8.
Battery
Level
2.
GPRS
9.
Ring Style
1.
Data
Transmission
10.
Location
6.
Messaging
Presence
7.
Message
4.
Roam
5.
Active
Line
44
basics
Evolution (EDGE) or General Packet Radio Service (GPRS)
network connection. Indicators can include:
3 Signal Strength Indicator –
Vertical bars show the
strength of the network connection. You can’t make or
receive calls when
!
or
)
displays.
4 Roam Indicator –
The roam indicator
ã
shows
when your phone is seeking or using a network
outside your home network. Other indicators can include:
5 Active Line Indicator –
Shows
?
to indicate an
active call, or
>
to indicate when call forwarding is
on. Indicators for dual-line-enabled SIM cards can include:
*
= GPRS PDP context
active
È
= EDGE
+
= GPRS packet data
available
:
= 2G home
;
= 2G roam
8
= 2.5G home
9
= 2.5G roam
@
= line 1 active
B
= line 2 active
A
= line 1 active, call
forward on
C
= line 2 active, call
forward on
45
basics
6 Messaging Presence Indicator –
Shows when
Instant Messaging (IM) is active. Indicators can
include:
7 Message Indicator –
Shows when you receive a
new message. Indicators can include:
8 Battery Level Indicator –
Vertical bars show the battery
charge level. Recharge the battery when your phone
shows
Low Battery
.
9 Ring Style Indicator –
Shows the ring style setting.
10 Location Indicator –
Shows when your phone can
send location information
Ö
or not
Ñ
.
P
= IM active
I
= available for IM
_
= busy
Q
= invisible to IM
J
= available for phone
calls
X
= offline
r
= text message
t
= voicemail message
s
= voicemail & text
message
d
= IM message
Ã
= IM message
a
= active chat session
y
= loud ring
z
= soft ring
|
= vibrate
}
= vibrate then ring
{
= silent
46
basics
menus
From the home screen, press
M
to open the main menu.
The following menu icons may be available, depending on
your service provider and service subscription options.
menu features
nPhonebook eMessages sRecent Calls
ÉTools QGames & Apps áWebAccess
hMultimedia ãIM wSettings
Menu Key
Enter menu
system, or open
a sub-menu.
Right Soft Key
Perform right
function.
5-Way Navigation
Joystick With
Center Select
Scroll up, down,
left, or right.
Press in to select
menu item.
Left Soft Key
Perform left
function.
Highlighted
Menu Feature
Icon
End Key
Exit menu without
making changes.
Phonebook
EXIT SELECT
47
basics
Some features require you to select an option from a list:
•
Scroll up or down to highlight the option you want.
•
In a numbered list, press a number key to highlight an
option.
•
In an alphabetized list, press a key repeatedly to cycle
through its letters and highlight the closest matching
list option.
•
When an option has a list of possible settings, scroll
left or right to select the setting.
•
When an option has a list of possible numeric values,
press a number key to set the value.
Dialed Calls
BACK VIEW
Press
M
to open sub-menu.
Press
VIEW
(
+
) to
view details of
highlighted
option.
Press
BACK
(
-
) to
go back to
previous
screen.
Highlighted
Option
10) John Smith
9)
Lisa Owens
8)
Adda Thomas
7)
Jack Bradshaw
6)
Dave Thompson
5)
John Smith
4)
John Smith
3)
John Smith
48
basics
text entry
Some features let you enter text.
Press
#
in a text entry screen to select an entry mode:
To set your primary and secondary text entry modes, press
M
>
Entry Setup
in a text entry screen and select
Primary Setup
or
Secondary Setup
.
entry mode
j
or
g
Yo u r
Primary
text entry mode can be set to any
iTAP®
j
or tap
g
mode.
p
or
m
Yo u r
Secondary
text entry mode can be set to
any iTAP
p
or tap
m
mode, or set to
None
if
you don’t want a secondary entry mode.
WNumeric
mode enters numbers only.
[Symbol
mode enters symbols only.
450
Msg
CANCEL
Press
CANCEL
(
-
) to exit without
making changes.
For indicator
descriptions,
see following
section.
Flashing cursor
indicates
insertion point.
Press
M
to
open
sub-menu.
49
basics
Tip:
WANT TO SHOUT YOUR MESSAGE? Press
0
in a text
entry screen to change text case to no capital letters (
U
),
next letter capital (
V
with
k
,
n
,
h
, or
q
), or all capitals
(
T
with
i
,
o
,
f
, or
l
).
iTAP® mode
Press
#
in a text entry screen to switch to iTAP mode. If
you don’t see
j
or
p
, press
M
>
Entry Setup
to set iTAP mode
as your primary or secondary text entry mode.
iTAP mode lets you enter words using one keypress per
letter. The iTAP software combines your keypresses into
common words, and predicts each word as you enter it.
For example, if you press
7764
, your phone
displays:
•
If you want a different word (such as
Progress
), continue
pressing keypad keys to enter the remaining
characters.
DELETE SEND TO
Press the
SEND TO
key to send this
message to another phone number or
e-mail.
Press the
DELETE
key to
delete last letter.
Press
*
to enter
Prog
and a space.
Press
S
up to
accept
Program
.
Press
S
right to
highlight another
combination.
Prog ram
Prog Proh Spoi Proi
Msg 442
50
basics
•
To enter numbers quickly, press and hold a number key
to temporarily switch to numeric mode. Press the
number keys to enter the numbers you want. Enter a
space to change back to iTAP mode.
•
Press
1
to enter punctuation or other characters.
tap mode
Press
#
in a text entry screen to switch to tap mode. If you
don’t see
g
or
m
, press
M
>
Entry Setup
to set tap mode as your
primary or secondary text entry mode.
To enter text in tap mode, press a keypad key repeatedly to
cycle through the letters and number on the key. Repeat this
step to enter each letter.
For example, if you press
8
one time, your phone displays:
449
Msg
DELETE SEND TO
Press
DELETE
(
-
) to
delete
character to left
of insertion
point.
Character
displays at
insertion point.
After
2 seconds,
character is
accepted and
cursor moves
to next
position.
T
51
basics
When you enter three or more characters in a row, your
phone may guess the rest of the word. For example, if you
enter
prog
your phone might display:
•
The first character of every sentence is capitalized. If
necessary, press
S
down to change the character to
lowercase before the cursor moves to the next
position.
•
Press
S
to move the flashing cursor to enter or edit
message text.
•
If you don’t want to save your text or text edits,
press
O
to exit without saving.
•
Tap extended mode cycles through additional special
characters and symbols as you repeatedly press a
keypad key.
numeric mode
Press
#
in a text entry screen until you see
W
. Press the
number keys to enter the numbers you want.
432
Msg
DELETE SEND TO
Press
S
right
to accept
program
, or
press
*
to
reject it and
enter a space
after
prog
.
This is a prog ram
52
basics
symbol mode
Press
#
in a text entry screen until you see
[
. Press a
keypad key to show its symbols at the bottom of the display.
Highlight the symbol you want, then press the
SELECT
key.
volume
Press the volume keys to:
•
turn off an incoming call alert
•
change the earpiece volume
during a call
•
change the ringer volume
from the home screen
Tip:
Sometimes silence really is golden. That’s why
you can quickly set your ringer to
Vibrate
or
Silent
by
pressing the down volume key repeatedly in the home
screen.
navigation key
Press the navigation key
S
up, down,
left, or right to scroll and highlight menu
items. When you highlight something,
press the center key
s
to select it.
The center key usually does the same
thing as the right soft key.
032394o.eps
032393o.eps
53
basics
smart key
The smart key gives you another
way to do things. For example,
when you highlight a menu item,
you can press the smart key to
select it (instead of pressing the
SELECT
key). The smart key usually
does the same thing as the right soft key. To change what the
smart key does in the home screen, see page 71.
handsfree speaker
You can use your phone’s handsfree speaker to make calls
without holding the phone to your ear.
During a call, press the
SPEAKER
key to turn the handsfree
speaker on or off. Your phone displays
Spkrphone On
until you
turn it off or end the call.
Note:
The handsfree speaker won’t work when your phone is
connected to a handsfree car kit or headset.
codes & passwords
Your phone’s four-digit
unlock code
is originally set to
1234
.
The six-digit
security code
is originally set to
000000
. If your
service provider didn’t change these codes, you should
change them:
Find it:
Press
M
>
Settings
>
Security
>
New Passwords
You can also change your
SIM PIN
or call barring passwords.
54
basics
If you forget your unlock code:
At the
Enter Unlock Code
prompt,
try entering 1234 or the last four digits of your phone
number. If that doesn’t work, press
M
and enter your
six-digit security code instead.
If you forget other codes:
If you forget your security code,
SIM PIN code, PIN2 code, or call barring password, contact
your service provider.
lock & unlock phone
You can lock your phone to keep others from using it. To lock
or unlock your phone, you need the four-digit unlock code.
To
manually lock
your phone: Press
M
>
Settings
>
Security
>
Phone Lock
>
Lock Now
.
To
automatically lock
your phone whenever you turn it off:
Press
M
>
Settings
>
Security
>
Phone Lock
>
Automatic Lock
>
On
.
Note:
You can make emergency calls on a locked phone (see
page 55). A locked phone still rings or vibrates for incoming
calls or messages,
but you need to unlock it to answer
.
55
customize
customize
ring style
Each ring style profile uses a different set of sounds or
vibrations for incoming calls and other events. Here are the
profiles you can choose:
The ring style profile’s indicator displays at the top of your
home screen. To choose your profile:
Find it:
Press
M
>
Settings
>
Ring Styles
>
Style
> style name
change alerts in a ring style
You can change the alerts for incoming calls and other
events. Your changes are saved in the current ring style
profile.
Find it:
Press
M
>
Settings
>
Ring Styles
> Style
Detail
Note:
Style represents the current ring style. You can’t set an
alert for the
Silent
ring style setting.
1
Highlight
Calls
(or
Line 1
or
Line 2
for dual line phones), then
press the
CHANGE
key to change it.
2
Highlight the alert you want, then press the
SELECT
key.
3
Press the
BACK
key to save the alert setting.
yLoud zSoft |Vibrate
}Vibe then Ring †Vibe & Ring {Silent
56
customize
time & date
You need to set your phone’s time and date to use the
datebook.
Find it:
Press
M
>
Settings
>
Initial Setup
>
Time and Date
To
synchronize
the time and date with the network: Press
M
>
Settings
>
Initial Setup
>
Time and Date
>
Autoupdate
>
On
.
To
manually
set the time and date, turn off
Autoupdate
, then:
Press
M
>
Settings
>
Initial Setup
>
Time and Date
>
Time
and
Date
.
Note:
To choose an analog or digital clock for your home
screen, press
M
>
Settings
>
Personalize
>
Home Screen
>
Clock
.
wallpaper
Set a photo, picture, or animation as a wallpaper (background)
image in your home screen.
Find it:
Press
M
>
Settings
>
Personalize
>
Wallpaper
option
Select a picture for your wallpaper image, or
None
for no wallpaper.
Layout
Select
Center
to center the image in the display,
Tile
to repeat the image across the display, or
Fit-to-screen
to stretch the image across the display.
57
customize
screen saver
Set a photo, picture, or animation as a screen saver image.
The screen saver displays when there is no activity detected
for a specified time.
Set a photo, picture, or animation as a screen saver image.
The screen saver displays when no activity is detected for a
specified time.
Tip:
This feature helps save your screen, but not your battery.
To extend battery life, turn off the screen saver.
Find it:
Press
M
>
Settings
>
Personalize
>
Screen Saver
themes
A phone theme is a group of image and sound files that
you can apply to your phone. Most themes include a
wallpaper image, screen saver image, and ring tone. Your
phone may come with some themes, and you can download
more.
To
apply
a theme: Press
M
>
Multimedia
>
Themes
> theme.
To
download
a theme, see page 79.
To
delete
a theme: Press
M
>
Multimedia
>
Themes
, scroll to the
theme, and press
M
>
Delete
or
Delete All
.
option
Select an image for your screen saver, or
None
for
no screen saver.
Delay
Select the length of inactivity before the screen
saver displays.
58
customize
Note:
You can delete only downloaded themes.
display appearance
To choose a phone
skin
that sets the look and feel of your
phone’s display: Press
M
>
Settings
>
Personalize
>
Skin
.
To set your display
contrast
: Press
M
>
Settings
>
Initial Setup
>
Contrast
.
To save battery life, your
backlight
turns off when you’re not
using your phone. The backlight turns back on when you
press a key. To set how long your phone waits before the
backlight turns off:
Press
M
>
Settings
>
Initial Setup
>
Backlight
.
Note:
To turn the backlight on or off for Java™ applications,
press
M
>
Settings
>
Java Settings
>
App Backlight
.
To save battery life, the
display
can turn off when you’re not
using your phone. The display turns back on when press a
key. To set how long your phone waits before the display
turns off:
Press
M
>
Settings
>
Initial Setup
>
Display Timeout
.
answer options
You can use additional, alternative methods to answer an
incoming call. To activate or deactivate an answer option:
Find it:
Press
M
>
Settings
>
In-Call Setup
>
Answer Options
>
Multi-key
>
On
or
Off
59
customize
vibrations
Some ring tones include vibrations. To activate or deactivate
the vibration option:
Find it:
Press
M
>
Settings
>
Initial Setup
>
Haptics
>
On
or
Off
60
calls
calls
To make and answer calls, see page 11.
turn off a call alert
You can press the volume keys to turn off a call alert before
answering the call.
recent calls
Your phone keeps lists of incoming and outgoing calls, even
for calls that didn’t connect. The most recent calls are listed
first. The oldest calls are deleted as new calls are added.
Shortcut:
Press
N
from the home screen to see the dialed
calls list.
Find it:
Press
M
>
Recent Calls
1
Highlight
Received Calls
or
Dialed Calls
, then press the
SELECT
key.
2
Highlight a call. A
Á
next to a call means the call
connected.
•
To call the number, press
N
.
•
To see call details (like time and date), press the
VIEW
key.
•
To see the
Last Calls Menu
, press
M
. This menu can
include:
61
calls
redial
1
Press
N
from the home screen to see the dialed calls
list.
2
Highlight the entry you want to call, then press
n
.
If you hear a
busy signal
and you see
Call Failed,
Number Busy
, press
N
or the
RETRY
key to redial the
number. When the call goes through, your phone rings or
option
Store
Create a phonebook entry with the
number in the
No.
field.
Delete
Delete the entry.
Delete All
Delete all entries in the list.
Hide ID/Show ID
Hide or show your caller ID for the next
call.
Send Message
Open a new text message with the
number in the
To
field.
Add Digits
Add digits after the number.
Attach Number
Attach a number from the phonebook or
recent calls lists.
Send Tones
Send the number to the network as
DTMF tones.
This option displays only during a call.
Talk then Fax
Talk and then send a fax in the
same call (see page 75).
62
calls
vibrates one time, displays
Redial Successful
, and connects the
call.
return a call
Your phone keeps a record of your unanswered calls, and
displays
X Missed Calls
, where
X
is the number of missed calls.
1
Press the
VIEW
key to see the received calls list.
2
Highlight the call you want to return, then press
N
.
notepad
The last set of digits entered on the keypad are stored in
notepad memory. This can be the last phone number you
called, or a number that you “jot down” during a call for later
use. To see the number stored in the notepad:
Find it:
Press
M
>
Recent Calls
>
Notepad
•
To call the number, press
N
.
•
To create a phonebook entry with the number in the
No.
field, press the
STORE
key.
•
To open the
Dialing Menu
to attach a number or insert a
special character, press
M
.
hold or mute a call
To put all active calls on hold, press
M
>
Hold
.
To put all active calls on mute, press
M
>
Mute
.
63
calls
call waiting
When you’re on a call, you’ll hear an alert if you receive
a second call.
Press
N
to answer the new call.
•
To switch between calls, press the
SWITCH
key.
•
To connect the two calls, press the
LINK
key.
•
To end the call on hold, press
M
>
EndCallOnHold
.
To turn the call waiting feature on or off:
Find it:
Press
M
>
Settings
>
In-Call Setup
>
Call Waiting
caller ID
Calling line identification (caller ID) shows the phone
number for an incoming call in your external and
internal displays.
Your phone shows the caller’s name and picture when
they’re stored in your phonebook, or
Incoming Call
when caller ID
information isn’t available.
You can set your phone to play a distinctive ringer ID for
specific entries stored in your phonebook (see page 61).
You can set your phone to display a distinctive light ID for
specific entries stored in your phonebook (see page 62).
To show or hide
your phone number
for the next outgoing
call, enter digits in the display, then:
Find it:
Press
M
>
Hide ID/Show ID
64
calls
emergency calls
Your service provider programs one or more emergency
phone numbers, such as 911 or 112, that you can call under
any circumstances, even when your phone is locked or the
SIM card is not inserted.
Note:
Emergency numbers vary by country. Your phone’s
preprogrammed emergency number(s) may not work in all
locations, and sometimes an emergency call cannot be
placed due to network, environmental, or interference
issues.
1
Press the keypad keys to dial the emergency number.
2
Press
N
to call the emergency number.
international calls
If your phone service includes international dialing,
press and hold
0
to insert your local international
access code (indicated by
+
). Then, press the keypad keys to
dial the country code and phone number.
1-touch dial
To call phonebook entries 1 through 9, press and hold the
single-digit speed dial number for one second. (To store
phonebook entries on your phone, see page 59.)
You can set 1-touch dial to call the entries in your phone’s
memory phonebook or the SIM card’s phonebook:
Find it:
Press
M
>
Settings
>
Initial Setup
>
1TouchDial
>
Phone
or
SIM
65
calls
You can set 1-touch dial to call the entries in your phone’s
memory phonebook, your SIM card’s phonebook, or your
Fixed Dial list:
Find it:
Press
M
>
Settings
>
Initial Setup
>
1TouchDial
>
Phone
,
SIM
,or
Fixed Dial
voicemail
Your network stores the voicemail messages you
receive. To listen to your messages, call your voicemail
number.
Note:
Your service provider may include additional
information about using this feature.
When you
receive
a voicemail message, your phone displays
the voicemail message indicator
t
and
New Voicemail
. Press
the
CALL
key to listen to the message.
To
check
voicemail messages:
Find it:
Press
M
>
Messages
>
Voicemail
Your phone may prompt you to store your voicemail phone
number. If you don’t know your voicemail number, contact
your service provider
Note:
You can’t store a
p
(pause),
w
(wait), or
n
(number)
character in this number. If you want to store a voicemail
number with these characters, create a phonebook entry for
it. Then, you can use the entry to call your voicemail.
66
other features
other features
advanced calling
feature
conference call
During a call:
Dial next number, press
N
, press
the
LINK
key.
transfer a call
During a call:
M
>
Transfer
, dial transfer number,
press
N
attach a phone
number
Dial an area code or prefix for a
phonebook number, then:
M
>
Attach Number
speed dial
Speed dial a phonebook entry:
Enter speed dial number, press
#
, press
N
.
Tip:
If you forget Aunt Mildred’s speed
dial number, press
M
>
Phonebook
,
highlight her entry, and press the
VIEW
key.
call forwarding
Set up or cancel call forwarding:
M
>
Settings
>
Call Forward
call barring
Restrict outgoing or incoming calls:
M
>
Settings
>
Security
>
Call Barring
67
other features
TTY calls
Set up your phone for use with an
optional TTY device:
M
>
Settings
>
Initial Setup
>
TTY Setup
change phone
line
If you have a dual-line-enabled SIM
card, you can change your line to
make and receive calls from your other
phone number.
M
>
Settings
>
Phone Status
>
Active Line
The active line indicator shows the active
phone line (see page 35).
fixed dial
When you turn on fixed dialing, you
can call only numbers stored in the
fixed dial list.
Turn fixed dialing on or off:
M
>
Settings
>
Security
>
Fixed Dial
Use the fixed dial list:
M
>
Tools
>
Dialing Services
>
Fixed Dial
service dial
Dial service phone numbers:
M
>
Tools
>
Dialing Services
>
Service Dial
quick dial
Dial preprogrammed phone
numbers:
M
>
Tools
>
Dialing Services
>
Quick Dial
feature
68
other features
phonebook
DTMF tones
Activate DTMF tones:
M
>
Settings
>
Initial Setup
>
DTMF
Send DTMF tones during a call:
Press number keys.
Send stored numbers as DTMF tones
during a call:
Highlight a number in the phonebook or
recent calls lists, then press
M
>
Send Tones
.
feature
add new entry
M
>
PhonebookM
>
New
>
Phone Number
or
Email Address
Shortcut:
Enter a phone number in the
home screen, then press the
STORE
key to
create an entry for that number.
Tip:
One phone isn’t enough for some
people. When creating a phonebook
entry, select
MORE
to store another
number for the same
Name
.
feature
69
other features
dial number
Call a number stored in the phonebook:
M
>
Phonebook
, highlight the phonebook
entry, press
n
Shortcut:
In the phonebook, press a
keypad key to jump to entries that begin
with the key’s letters, or to search for the
entry by name (see below).
search for
entry
To set the phonebook search method:
M
>
Phonebook
M
>
Search Method
>
Find
or
Jump To
To search for a phonebook entry, press
the keypad key that contains the first
letter of the entry.
Jump To
mode
immediately jumps to entries that begin
with the key’s letters.
Find
mode prompts
you to enter the name or speed number
for the entry, depending on how the
phonebook list is sorted.
record a
voice name
When creating a phonebook entry,
highlight
Voice Name
and press the
RECORD
key. Press and release the voice
key and say the entry’s name (within
2 seconds). When prompted, press and
release the voice key and repeat the
name.
Note:
The
Voice Name
option isn’t available
for entries stored on the SIM card.
feature
70
other features
voice dial
number
Voice dial a number stored in the
phonebook:
Press and release the voice key, and say
the entry’s name (within 2 seconds).
set ringer ID
for entry
Assign a distinctive ring alert (ringer ID)
to an entry:
M
>
Phonebook
> entry
M
>
Edit
>
Ringer ID
>ringer name
Note:
The
Ringer ID
option isn’t available for
entries stored on the SIM card.
To activate ringer IDs:
M
>
Settings
>
Ring Styles
> style
Detail
>
Ringer IDs
set picture ID
for entry
Assign a photo or picture to display
when you receive a call from an entry:
M
>
Phonebook
> entry
M
>
Edit
>
>picture name
Note:
The
option isn’t available for
entries stored on the SIM card.
set category
for entry
M
>
Phonebook
> entry
M
>
Edit
>
Category
>category name
Note:
The
Category
option isn’t available for
entries stored on the SIM card.
feature
71
other features
set category
view
M
>
Phonebook
M
>
Categories
>category view
You can display
All
entries, entries in a
predefined category (
Business
,
Personal
,
General
,
VIPs
), or entries in a category you
create.
set category
ringer ID
Set a distinctive ring alert (ringer ID) to
sound when you receive calls from
entries in a specific category:
Press
M
>
Phonebook
, press
M
>
Categories
,
highlight the category, press
M
>
Edit
>
Ringer ID
Note:
The
Category
option isn’t available for
entries stored on the SIM card.
To activate ringer IDs:
M
>
Settings
>
Ring Styles
> style
Detail
>
Ringer IDs
set category
light ID
Set a distinctive light pattern to display
when you receive calls from entries in a
specific category:
Press
M
>
Phonebook
, press
M
>
Categories
,
highlight the category, press
M
>
Edit
>
Light ID
Note:
The
Category
option isn’t available for
entries stored on the SIM card.
feature
72
other features
set primary
number or
address
Set the primary number for an entry with
multiple numbers:
M
>
Phonebook
, highlight the entry, press
M
>
Set Primary
> number or address
Tip:
In
Primary
number view mode, you
can still peek at other numbers stored for
the same name. Highlight the name and
press
S
left or right to see the other
numbers.
create group
mailing list
M
>
PhonebookM
>
New
>
Mailing List
sort
phonebook list
Set the order in which entries are listed:
M
>
Phonebook
M
>
Setup
>
Sort by
>sort order
You can sort the phonebook list by
Name
,
Speed No.
,
Voice Name
, or
Email
. When sorting
by name, you can display
All
numbers or
just the
Primary
number for each name.
copy
phonebook
entry
Copy an entry from the phone to the
SIM card, or from the SIM card to the
phone:
M
>
Phonebook
, highlight the entry, press
M
>
Copy
>
Entries
>
To
feature
73
other features
copy multiple
entries
Copy multiple phonebook entries
between the phone and SIM card:
M
>
Phonebook
, highlight one entry, press
M
>
Copy
>
Entries
, press the
CHANGE
key,
highlight another entry, press the
ADD
key, repeat as necessary, press the
DONE
key, >
To
send
phonebook
entry to
another device
Use a Bluetooth® connection to send a
phonebook entry to another phone,
computer, or device:
M
>
Phonebook
, highlight the entry, press
M
>
Send
For more about Bluetooth connections,
see page 29.
print
phonebook
entry
Use a Bluetooth® connection to
send a phonebook entry from your
phone to a printer.
M
>
Phonebook
, highlight the entry, press
M
>
Print
.
You cannot print a
Mailing List
. For more
about Bluetooth connections, see
page 29.
feature
74
other features
messages
For basic multimedia message features, see page 22.
feature
send text
message
M
>
Messages
>
Create Message
>
New Short Msg
send
multimedia
message
M
>
Messages
>
Create Message
>
New Multimedia Msg
send letter
M
>
Messages
>
Create Message
>
New Letter
send email
M
>
Messages
>
Create Message
>
New Email
use a
multimedia
template
Open a multimedia template with
preloaded media:
M
>
Messages
>
MMS Templates
read new
message
Read a new text message or
multimedia message that you have
received:
Press the
READ
key when the
New Message
notification displays.
read new
message or
email
Read a new text message,
multimedia message, or email that
you have received:
Press the
READ
key when the
New Message
notification displays.
75
other features
read old
messages
M
>
Messages
>
Message Inbox
Icons next to each message show
if it is
unread
J
,
read
H
,
urgent
K
,
locked
V
, or has an
attachment
R
.
Press
M
to perform various operations
on a message.
read old email
M
>
Messages
>
Email Msgs
Press
M
to perform various
operations on a message.
store message
objects
Go to a multimedia message page,
or highlight an object in a letter,
then:
M
>
Store
browser
messages
Read messages received by your
micro-browser:
M
>
Messages
>
Browser Msgs
info services
Read subscription-based
information services messages:
M
>
Messages
>
Info Services
feature
76
other features
email
Note:
Make sure you have an email provider and the
following account information ISP settings, protocols,
user id, password, and send and receiving host information.
Otherwise, you might not get these features to work.
feature
set up the
email inbox
M
>
Messages
M
>
Email Setup
composing an
email
M
>
Messages
>
Create Messages > New Email
insert a media
object in an
email
In the message window, press
M
>
Insert
. Select the file type and the
file.
sending an
email
Press
Send To
key. Select who you want to
send the message to either through a
phonebook entry or
[New Entry]
. Enter a
Subject
for the email, and press the
Send
key.
Tip:
You can also add email recipients to
the
Cc
and
Bcc
fields, and choose a
message priority of Normal or Urgent.
77
other features
view status of
sent email
M
>
Message
>
Outbox
Messages are sorted from newest to
oldest. If you see a
e
your message
was successfully sent. If a
>
is
displayed, your message could not be
sent. Try again, the email provider
network could be busy.
receive email
If your phone is set up to
automatically check for new
messages, your phone will display the
message waiting (
e
) indicator when a
new message arrives.
Press the
READ
key to open the message.
delete email
Open the email:
M
>
Delete
manually send
and receive
email
M
>
Messages
>
Email MessageM
>
Send/Receive Mail
call a phone
number in
emai
l
Highlight a phone number in a
message and press P.
create
personal
folders
M
>
Messages
>
Email Message
M
>
Folder
>
Create
move email to
personal folder
After you are done reading the email:
M
>
Move to
>
[Personal Folder]
feature
78
other features
instant messaging
feature
sign on
M
>
IM
>
Sign On
log in
M
>
IM
>
Log In
find others
online
After you log in:
Select
Contact List
to see a list of
other users.
start
conversation
From your
Contact List
, highlight a
name in
Online Contacts
, press the
SEND IM
key.
open active
conversation
From your
Contact List
, highlight a
name in
Conversations
, press the
VIEW
key.
end
conversation
From the conversation display:
M
>
End Conversation
log out
Select
Log Out
from the
IM Online
menu.
create or
change IM
accounts
M
>
IM
>
IM Account
Select an IM account, or select
New
to create a new IM account.
79
other features
chat
personalizing
feature
start chat
M
>
Tools
>
ChatM
>
New Chat
receive chat
request
Press the
ACCEPT
key or the
IGNORE
key.
end chat
During a chat session:
M
>
End Chat
feature
language
Set menu language:
M
>
Settings
>
Initial Setup
>
Language
scroll
Set the highlight bar to stop or wrap
around in menu lists:
M
>
Settings
>
Initial Setup
>
Scroll
ringer IDs
Activate ringer IDs assigned to
phonebook entries and categories:
M
>
Settings
>
Ring Styles
> style
Detail
>
Ringer IDs
ring volume
M
>
Settings
>
Ring Styles
> style
Detail
>
Ring Volume
keypad
volume
M
>
Settings
>
Ring Styles
> style
Detail
>
Key Volume
80
other features
reminders
Set reminder alerts for messages that
you receive:
M
>
Settings
>
Ring Styles
> style
Detail
>
Reminders
clock view
Display an analog or digital clock in the
home screen:
M
>
Settings
>
Personalize
>
Home Screen
>
Setup without News
>
Clock
Note:
To use an analog clock, you must
set your news display to
Without News
.
menu view
Display the main menu as graphic icons
or as a text-based list:
M
>
Settings
>
Personalize
>
Main Menu
>
View
main menu
Reorder your phone’s main menu:
M
>
Settings
>
Personalize
>
Main Menu
>
Reorder
show/hide
menu icons
Show or hide menu feature icons in the
home screen:
change menu
icons & home
keys
Change menu feature icons, soft key
labels, and smart key function in the
home screen:
feature
81
other features
shortcuts
Create a shortcut to a menu item:
Highlight the menu item, then press and
hold
M
.
Use a shortcut:
Press
M
, then press the shortcut
number.
master reset
Reset all options
except
unlock code,
security code, and lifetime timer:
M
>
Settings
>
Initial Setup
>
Master Reset
master clear
Clear all settings and entries you made
except
SIM card information,
downloaded pictures and sound files,
and reset all options
except
unlock code,
security code, and lifetime timer:
M
>
Settings
>
Initial Setup
>
Master Clear
Caution:
Master clear
erases all
information you have entered
(including phonebook and datebook
entries)
and content you have
downloaded
(including photos and
sounds) stored in your phone’s memory.
After you erase the information, you
can’t recover it.
feature
82
other features
call times & costs
Network connection time
is the elapsed time from the
moment you connect to your service provider's network to
the moment you end the call by pressing
o
. This time
includes busy signals and ringing.
The amount of network connection time you track on
your resettable timer may not equal the amount of time
for which you are billed by your service provider. For
billing information, contact your service provider.
feature
call times
Display call timers:
M
>
Recent Calls
>
Call Times
in-call timer
Display time or cost information
during a call:
M
>
Settings
>
In-Call Setup
>
In-Call Timer
call cost
Display call cost trackers:
M
>
Recent Calls
>
Call Cost
credit info
(prepay option)
Display credit information:
M
>
Settings
>
Phone Status
>
Credit Info
credit available
(advice of
charge option)
Display credit available:
M
>
Settings
>
Phone Status
>
Credit Available
call cost setup
Set a credit limit:
M
>
Settings
>
In-Call Setup
>
Call Cost Setup
83
other features
handsfree
Note:
The use of wireless devices and their accessories may
be prohibited or restricted in certain areas. Always obey the
laws and regulations on the use of these products.
data times
Display data call timers:
M
>
Recent Calls
>
Data Times
data volumes
Display data volume meters:
M
>
Recent Calls
>
Data Volumes
feature
speakerphone
Activate a connected external
speakerphone during a call:
Press the
SPEAKER
key (if available), or
M
>
Spkrphone On
.
auto answer
(car kit or
headset)
Automatically answer calls when
connected to a car kit or headset:
M
>
Settings
>
Car Settings
or
Headset
>
Auto Answer
voice dial
(headset)
Enable voice dial with headset
send/end key:
M
>
Settings
>
Headset
>
Voice Dial
auto handsfree
(car kit)
Automatically route calls to a car
kit when connected:
M
>
Settings
>
Car Settings
>
Auto Handsfree
feature
84
other features
data & fax calls
power-off
delay
(car kit)
Set the phone to stay on for a
specified time after the ignition is
switched off:
M
>
Settings
>
Car Settings
>
Power-Off Delay
charger time
(car kit)
Charge the phone for a specified
time after the ignition is switched
off:
M
>
Settings
>
Car Settings
>
Charger Time
feature
send data or
fax
Connect your phone to the device,
then place the call through the
device application.
receive data or
fax
Connect your phone to the device,
then answer the call through the
device application.
talk then fax
Connect your phone to the device,
enter fax number, press
M
>
Talk then Fax
, then press
n
to make
the call.
feature
85
other features
network
personal organizer
feature
network
settings
Display network information and
adjust network settings:
M
>
Settings
>
Network
feature
add new
datebook
event
M
>
Tools
>
Datebook
, highlight the day,
press
s
, press
M
>
New
view datebook
event
Display or edit event details:
M
>
Tools
>
Datebook
, highlight the day,
press
s
, press the
VIEW
key
datebook
event
reminder
When an event reminder displays:
To see reminder details, the
VIEW
key.
To close the reminder, press the
EXIT
key.
send datebook
event to
another device
Use a Bluetooth® connection to send a
datebook event to another phone,
computer, or device:
M
>
Tools
>
Datebook
, highlight the day,
press
s
, highlight the event, press
M
>
Send
For more about Bluetooth connections,
see page 29.
86
other features
security
create voice
record
Create a voice record:
Press and hold the voice key, speak into
the phone, release voice key.
Note:
Recording phone calls is subject to
varying state and federal laws regarding
privacy and recording of conversations.
play voice
record
Play back a voice record:
M
>
Tools
>
Voice Records
> voice record
calculator
M
>
Tools
>
Calculator
currency
converter
M
>
Tools
>
Calculator
M
>
Exchange Rate
Enter exchange rate, press the
OK
key,
enter amount, and select
$
at the bottom
of the display.
feature
SIM PIN Caution:
If you enter an incorrect PIN
code 3 times in a row, your SIM card is
disabled and your phone displays
SIM Blocked
.
Lock or unlock the SIM card:
M
>
Settings
>
Security
>
SIM PIN
lock feature
M
>
Settings
>
Security
>
Lock Application
feature
87
other features
fun & games
manage
certificates
Enable or disable Internet access
certificates stored on your phone:
M
>
Settings
>
Security
>
Certificate Mgmt
Certificates are used to verify the
identity and security of Web sites when
you download files or share information.
feature
manage
pictures
Manage photos, pictures, and
animations:
M
>
Multimedia
>
Pictures
manage video
clips
M
>
Multimedia
>
Videos
manage
sounds
Manage ring tones and music that you
have downloaded or composed:
M
>
Multimedia
>
Sounds
edit sounds
with
motomixer
Edit MIDI-based sound files that you can
use with your phone:
M
>
Multimedia
>
MotoMixer
start
micro-browser
M
>
Web Access
>
Browser
feature
88
other features
download
objects from
web page
Download a picture, sound, or
phone theme from a Web page:
Highlight the file, press the
SELECT
key,
press the
STORE
key.
Note:
Normal airtime and/or carrier
usage charges apply.
web sessions
Select or create a Web session:
M
>
Web Access
>
Web Sessions
play music
Play a song on your phone:
M
>
Multimedia
>
Sounds
>song name
create playlist
Create a playlist of songs to play
on your phone:
M
>
Multimedia
>
Sounds
>
[New Playlist]
create ring
tones
Create ring tones that you can use with
your phone:
M
>
Multimedia
>
Sounds
>
[New iMelody]
feature
89
troubleshooting
troubleshooting
If you have questions or need assistance, we're here to help.
Go to
www.motorola.com/consumer/support
, where you
can select from a number of customer care options. You can
also contact the Motorola Customer Support Center at
1-800-331-6456 (United States), 1-888-390-6456 (TTY/TDD
United States for hearing impaired), or 1-800-461-4575
(Canada).
90
SAR Data
Specific Absorption Rate Data
SAR Data
This model wireless phone meets the government’s
requirements for exposure to radio waves.
Your wireless phone is a radio transmitter and receiver. It is designed and
manufactured not to exceed limits for exposure to radio frequency (RF)
energy set by the Federal Communications Commission (FCC) of the U.S.
Government and by the Canadian regulatory authorities. These limits are
part of comprehensive guidelines and establish permitted levels of RF
energy for the general population. The guidelines are based on standards
that were developed by independent scientific organizations through
periodic and thorough evaluation of scientific studies. The standards
include a substantial safety margin designed to assure the safety of all
persons, regardless of age or health.
The exposure standard for wireless mobile phones employs a unit of
measurement known as the Specific Absorption Rate, or SAR. The SAR
limit set by the FCC and by the Canadian regulatory authorities is
1.6 W/kg.
1
Tests for SAR are conducted using standard operating positions
accepted by the FCC and by Industry Canada with the phone transmitting at
its highest certified power level in all tested frequency bands. Although the
SAR is determined at the highest certified power level, the actual SAR
level of the phone while operating can be well below the maximum value.
This is because the phone is designed to operate at multiple power levels
so as to use only the power required to reach the network. In general, the
closer you are to a wireless base station, the lower the power output.
Before a phone model is available for sale to the public in the U.S. and
Canada, it must be tested and certified to the FCC and Industry Canada that
it does not exceed the limit established by each government for safe
exposure. The tests are performed in positions and locations (e.g., at the
ear and worn on the body) reported to the FCC and available for review by
Industry Canada. The highest SAR value for this model phone when tested
91
SAR Data
for use at the ear is 1.01 W/kg, and when worn on the body, as described in
this user guide, is 0.91 W/kg. (Body-worn measurements differ among
phone models, depending upon available accessories and regulatory
requirements).
2
While there may be differences between the SAR levels of various phones
and at various positions, they all meet the governmental requirements for
safe exposure. Please note that improvements to this product model could
cause differences in the SAR value for later products; in all cases, products
are designed to be within the guidelines.
Additional information on Specific Absorption Rates (SAR) can be found on
the Cellular Telecommunications & Internet Association (CTIA) Web site:
http://www.phonefacts.net
or the Canadian Wireless Telecommunications Association (CWTA) Web
site:
http://www.cwta.ca
1. In the United States and Canada, the SAR limit for mobile phones used by the
public is 1.6 watts/kg (W/kg) averaged over one gram of tissue. The standard
incorporates a substantial margin of safety to give additional protection for the
public and to account for any variations in measurements.
2. The SAR information includes the Motorola testing protocol, assessment
procedure, and measurement uncertainty range for this product.
92
Index
index
AA
accessories 16, 40, 83
accessory connector port 1
active line indicator 44
active line, changing 67
alert
set 52, 55
turn off 52, 60
animation 87
answer a call 20, 58, 59
attach a number 61, 66
B
backlight 58
battery 19
battery indicator 45
battery life, extending 17, 39,
57, 58
Bluetooth connection 38,
40, 73, 86
Bluetooth indicator 2
browser messages 75
browser. See micro-browser
C
calculator 86
call
answer 20, 58, 59
end 20
make 20, 69
call barring 53, 66
call forward indicator 44
call forwarding 66
call timers 82, 83
call waiting 63
caller ID 2, 3, 61, 63, 70
camera 2, 3, 26, 28
camera key 1
car kit 83
center key 1, 52
certificate management 87
chat 79
clock 56, 80
codes 53, 54
conference call 66
contrast 58
copyrighted files 38
costs, tracking 82
credit information 82
D
data call 83, 84
data indicator 43
date, setting 56
93
Index
datebook 85
dial a phone number 20, 67,
69
dialed calls 60
display 42, 58, 80
download media objects 75,
88
drafts folder 32
DTMF tones 61, 68
E
earpiece volume 52
EDGE indicator 43
email 74, 75
email address 68
emergency number 64
end a call 20
end key 1, 20
Enter Unlock Code message
54
external display 2
F
fax call 61, 84
fixed dial 67
forward calls 66
G
GPRS indicator 43
group mailing list 72
H
handsfree speaker 53
headset 83
headset jack 1
hold a call 62
home screen 42, 80
I
IM 76, 78
IM indicators 45
in-call indicator 44
Incoming Call message 63
information services 75
instant messaging. See IM
international access code 64
iTAP text entry mode 49
K
keypad 79
L
language 79
licenses 38
light ID 71
location indicator 45
lock
application 87
phone 54
SIM card 87
Low Battery message 45
94
Index
M
make a call 20, 69
master clear 81
master reset 81
memory card 35
menu 46, 79, 80
menu icons 42, 46, 80
menu indicator 42
menu key 1, 16
message 74, 75
message indicator 33, 45
message reminders 80
micro-browser 75, 88
Missed Calls message 62
MMS, defined 31
MotoMixer 88
multimedia letter 74
multimedia message 31, 74,
75
music 88
mute a call 62
N
navigation key 1, 16, 52
network settings 85
notepad 62
number. See phone number
numeric entry mode 51
O
object exchange 40
1-touch dial 64
optional accessory 16
optional feature 16
P
passwords. See codes
personalize 79
phone number 21, 67, 68
phonebook 61, 64, 66, 68
photo 2, 3, 26, 87
picture 87
picture ID 2, 3, 63, 70
PIN code 20, 53, 87
PIN2 code 53
playlist 88
power key 1, 20
printing 73
Q
quick dial 67
R
received calls 60
recent calls 60
redial 61
reminders 80
return a call 62
ring style indicator 45
95
Index
ring style, setting 52, 55
ring tone 88
ringer ID 63, 70, 71, 79
ringer volume 52, 79
roam indicator 44
S
screen saver 57
security code 53
send key 1, 20
service dial 67
shortcuts 81
signal strength indicator 44
SIM Blocked message 20,
87
SIM card 17, 20, 53, 67, 87
skin 58
smart key 1, 2, 53, 80
soft keys 1, 42, 80
speakerphone 83
speed dial 66
store your number 21
symbol entry mode 52
T
tap text entry mode 50
telephone number. See
phone number
text entry 48
text message 74, 75
theme 57
time, setting 56
timers 82, 83
transfer a call 66
TTY device 67
turn on/off 20
U
unlock
application 87
phone 20, 54
SIM card 87
unlock code 53, 54
V
video clip 28, 87
voice dial 70, 83
voice key 1
voice name, recording 69
voice record 86
voicemail 65
voicemail message indicator
45, 65
volume 52, 79
volume keys 1
W
wallpaper 56
Web pages 88
Web sessions 88
wireless connection. See
Bluetooth connection
96
Index
Y
your phone number 21
U.S. patent Re. 34,976
motorola.com

Navigation menu
