Exhibit 8 Users Manual
APPLICANT: MOTOROLA, INC. FCC ID: IHDT56FG1
EXHIBIT 8
INSTRUCTION MANUAL
A preliminary draft copy of the Users Manual follows:
V235
GSM
1
HELLOMOTO
Introducing your new Motorola V235 GSM wireless phone.
Here’s a quick anatomy lesson.
Left Soft Key
Navigate menus.
Select menu items.
Open menus.
Volume Keys
Charge up,
go handsfree.
Voice dial.
Right Soft Key
Turn on & off,
hang up, exit menus.
Make & answer calls.
Smart Key
2
Motorola, Inc.
Consumer Advocacy Office
1307 East Algonquin Road
Schaumburg, IL 60196
www.hellomoto.com
MOTOROLA and the Stylized M Logo are registered in the US Patent &
Trademark Office. Java and all other Java-based marks are trademarks or
registered trademarks of Sun Microsystems, Inc. in the U.S. and other
countries. All other product or service names are the property of their
respective owners.
© Motorola, Inc., 2005.
Caution:
Changes or modifications made in the radio phone, not expressly
approved by Motorola, will void the user’s authority to operate the
equipment.
Software Copyright Notice
The Motorola products described in this manual may include copyrighted
Motorola and third-party software stored in semiconductor memories or
other media. Laws in the United States and other countries preserve for
Motorola and third-party software providers certain exclusive rights for
copyrighted software, such as the exclusive rights to distribute or
reproduce the copyrighted software. Accordingly, any copyrighted software
contained in the Motorola products may not be modified,
reverse-engineered, distributed, or reproduced in any manner to the extent
allowed by law. Furthermore, the purchase of the Motorola products shall
not be deemed to grant either directly or by implication, estoppel, or
otherwise, any license under the copyrights, patents, or patent applications
of Motorola or any third-party software provider, except for the normal,
non-exclusive, royalty-free license to use that arises by operation of law in
the sale of a product.
Manual Number: 68XXXXX102-O
3
feature locator
feature locator
main menu
n
Phonebook
s
Recent Calls
• Received Calls
• Dialed Calls
• Notepad
•Call Times*
• Data Times *
• Data Volumes *
e
Messages
• Create Message
• Message Inbox
•Outbox
•Drafts
• Info Services *
•Voicemail
•Quick Notes
•Drafts
•MMS Templates
• Browser Msgs
• Info Services
É
Tools
•Calculator
• Datebook
• Shortcuts
•Alarm Clock
• Dialing Services
Q
Games & Apps
á
Web Access
•Browser
• Web Shortcuts
• Stored Pages
•History
•Go To URL
•Browser Setup
• Web Sessions
h
Multimedia
• Pictures
• Sounds
•Camera
• Video Camera
• Videos
Ü
Voi ce Records
w
Settings
• (see next page)
* optional features
This is the standard main
menu layout. Your phone’s
menu may be a little
different.
4
feature locator
settings menu
l
Personalize
• Home Screen
•Main Menu
• Color Style
• Greeting
• Wallpaper
• Screen Saver
•Quick Dial
t
Ring Styles
•Style
• style Detail
L
Connection
•Sync
H
Call Forward *
•Voice Calls
• Fax Calls
• Data Calls
• Cancel All
• Forward Status
U
In-Call Setup
• In-Call Timer
• My Caller ID
• Talk and Fax
• Answer Options
• Call Waiting
Z
Initial Setup
• Time and Date
• 1-Touch Dial
• Display Timeout
• Backlight
•Scroll
• Language
• Contrast
•DTMF
• Master Reset
•Master Clear
m
Phone Status
• My Tel. Numbers
• Active Line *
•Battery Meter
• Software Update
• Other Information
S
Headset
• Auto Answer
• Voice Dial
J
Car Settings
• Auto Answer
• Auto Handsfree
•Power-off Delay
• Charger Time
j
Network
•New Network
•Network Setup
•Available Networks
• My Network List *
• Service Tone *
• Network Jingle *
• Call Drop Tone
u
Security
• Phone Lock
• Lock Application
• Fixed Dial
• Restrict Calls *
• Call Barring *
• SIM PIN
•New Passwords
• Certificate Mgmt *
c
Java Settings
• Java System
• Delete All Apps
• App Vibration
• App Volume
• App Backlight
* optional features
5
contents
contents
feature locator. . . . . . . . . 3
Safety Information . . . . . 7
EU Conformance. . . . . . 14
Recycling Information . 15
essentials . . . . . . . . . . . 16
about this guide . . . . . 16
SIM card . . . . . . . . . . . 16
battery. . . . . . . . . . . . . 17
turn it on & off. . . . . . . 19
make a call . . . . . . . . . 20
answer a call . . . . . . . . 20
your phone number . . 20
main attractions . . . . . . 21
take & send a photo . . 21
record video . . . . . . . . 23
cable connections . . . . 24
basics. . . . . . . . . . . . . . . 25
display. . . . . . . . . . . . . 25
menus. . . . . . . . . . . . . 28
text entry . . . . . . . . . . 30
volume . . . . . . . . . . . . 35
navigation key . . . . . . . 35
external display . . . . . . 35
handsfree speaker . . . 36
codes & passwords . . 36
lock & unlock phone . . 37
customize . . . . . . . . . . . 38
ring style. . . . . . . . . . . 38
time & date. . . . . . . . . 39
wallpaper . . . . . . . . . . 39
screen saver . . . . . . . . 39
display appearance . . . 40
answer options . . . . . . 41
calls . . . . . . . . . . . . . . . . 42
turn off a call alert . . . . 42
recent calls . . . . . . . . . 42
redial . . . . . . . . . . . . . . 43
return a call . . . . . . . . . 44
notepad. . . . . . . . . . . . 44
hold or mute a call . . . 44
call waiting . . . . . . . . . 45
caller ID. . . . . . . . . . . . 45
emergency calls . . . . . 45
international calls . . . . 46
1-touch dial . . . . . . . . . 46
voicemail. . . . . . . . . . . 47
6
contents
other features . . . . . . . 48
advanced calling . . . . 48
phonebook . . . . . . . . 50
messages . . . . . . . . . 54
personalizing . . . . . . . 57
call times & costs . . . 63
handsfree . . . . . . . . . 64
data & fax calls . . . . . 65
network . . . . . . . . . . . 66
personal organizer . . . 66
security . . . . . . . . . . . 68
fun & games . . . . . . . 69
troubleshooting . . . . . 72
SAR Data . . . . . . . . . . . 73
Warranty . . . . . . . . . . . 75
index . . . . . . . . . . . . . . 81
7
Safety Information
Safety and General Information
Safe ty In formati on
IMPORTANT INFORMATION ON SAFE AND EFFICIENT OPERATION. READ
THIS INFORMATION BEFORE USING YOUR PHONE.
1
Exposure To Radio Frequency (RF) Energy
Your phone contains a transmitter and a receiver. When it is ON, it receives
and transmits RF energy. When you communicate with your phone, the
system handling your call controls the power level at which your phone
transmits.
Your Motorola phone is designed to comply with local regulatory
requirements in your country concerning exposure of human beings to RF
energy.
Operational Precautions
To assure optimal phone performance and make sure human exposure to
RF energy is within the guidelines set forth in the relevant standards,
always adhere to the following instructions.
External Antenna Care
If your phone has an external antenna, use only the supplied or
Motorola-approved replacement antenna. Unauthorized antennas,
modifications, or attachments could damage the phone and/or may result
in non-compliance with local regulatory requirements in your country.
Do NOT hold the external antenna when the phone is IN USE. Holding the
external antenna affects call quality and may cause the phone to operate
at a higher power level than needed.
Phone Operation
When placing or receiving a phone call, hold your phone as you would a
wireline phone.
8
Safety Information
Body-Worn Operation: Voice Communication
To maintain compliance with RF energy exposure guidelines, if you wear a
phone on your body when transmitting voice communications, always
place the phone in a Motorola-supplied or approved clip, holder, holster,
case, or body harness for this phone, if available. Use of accessories not
approved by Motorola may exceed RF energy exposure guidelines.
If you do not use one of the body-worn accessories approved or supplied by
Motorola, and are not using the phone held in the normal use position,
ensure the phone and its antenna are at least 2.5 centimeters (1 inch) from
your body when transmitting.
Data Operation
When using any data feature of the phone, with or without an accessory
cable, position the phone and its antenna at least 2.5 centimeters (1 inch)
from your body.
Approved Accessories
Use of accessories not approved by Motorola, including but not limited to
batteries, antennas, and convertible covers, may cause your phone to
exceed RF energy exposure guidelines. For a list of approved Motorola
accessories, visit our website at
www.motorola.com
.
RF Energy Interference/Compatibility
Note:
Nearly every electronic device is susceptible to RF energy
interference from external sources if inadequately shielded, designed, or
otherwise configured for RF energy compatibility. In some circumstances
your phone may cause interference.
Note:
This device complies with Part 15 of the FCC Rules. Operation is
subject to the following two conditions: (1) this device may not cause
harmful interference, and (2) this device must accept any interference
received, including interference that may cause undesired operation.
9
Safety Information
Facilities
Turn off your phone in any facility where posted notices instruct you to do
so. These facilities may include hospitals or health care facilities that may
be using equipment that is sensitive to external RF energy.
Aircraft
Turn off your wireless device whenever instructed to do so by airline staff.
If your device offers a flight mode or similar feature, consult airline staff
about use in flight. If your device offers a feature that automatically turns
on the phone, then turn off this feature before boarding an airplane or
entering an area where the use of wireless devices is restricted.
Medical Devices
Pacemakers
Pacemaker manufacturers recommend that a minimum separation of
15 centimeters (6 inches) be maintained between a handheld wireless
phone and a pacemaker.
Persons with pacemakers should:
•
ALWAYS keep the phone more than 15 centimeters (6 inches) from
your pacemaker when the phone is turned ON.
•
NOT carry the phone in the breast pocket.
•
Use the ear opposite the pacemaker to minimize the potential for
interference.
•
Turn OFF the phone immediately if you have any reason to suspect
that interference is taking place.
Hearing Aids
Some digital wireless phones may interfere with some hearing aids. In the
event of such interference, you may want to consult your hearing aid
manufacturer to discuss alternatives.
10
Safety Information
Other Medical Devices
If you use any other personal medical device, consult the manufacturer of
your device to determine if it is adequately shielded from RF energy. Your
physician may be able to assist you in obtaining this information.
Use While Driving
Check the laws and regulations on the use of phones in the area where you
drive. Always obey them.
When using your phone while driving, please:
•
Give full attention to driving and to the road. Using a phone may be
distracting in certain circumstances. Discontinue a call if you can’t
concentrate on driving.
•
Use handsfree operation, if available.
•
Pull off the road and park before making or answering a call if
driving conditions so require.
Responsible driving best practices can be found in the “Wireless Phone
Safety Tips” at the end of this guide and/or at the Motorola website:
www.motorola.com/callsmart
.
Operational Warnings
For Vehicles With an Air Bag
Do not place a phone in the area over an air bag or in the air bag
deployment area. Air bags inflate with great force. If a phone is placed in
the air bag deployment area and the air bag inflates, the phone may be
propelled with great force and cause serious injury to occupants of the
vehicle.
Gas or Petrol Stations
Obey all posted signs with respect to the use of radio equipment in gas or
petrol stations. Turn off your wireless device if instructed by authorized
staff.
11
Safety Information
Potentially Explosive Atmospheres
Turn off your phone prior to entering any area with a potentially explosive
atmosphere. Do not remove, install, or charge batteries in such areas.
Sparks in a potentially explosive atmosphere can cause an explosion or fire
resulting in bodily injury or even death.
Note:
The areas with potentially explosive atmospheres referred to above
include fueling areas such as below decks on boats, fuel or chemical
transfer or storage facilities, areas where the air contains chemicals or
particles, such as grain, dust, or metal powders. Areas with potentially
explosive atmospheres are often but not always posted.
Blasting Caps and Areas
To avoid possible interference with blasting operations, turn OFF your
phone when you are near electrical blasting caps, in a blasting area, or in
areas posted “Turn off electronic devices.” Obey all signs and instructions.
Damaged Products
If your phone or battery has been submerged in water, punctured, or
subjected to a severe fall, do not use it until you take it to a Motorola
Authorized Service Center to determine if it has been damaged. Do not
attempt to dry it with an external heat source, such as a microwave oven.
Batteries and Chargers
Batteries can cause property damage and/or bodily injury such as burns if a
conductive material such as jewelry, keys, or beaded chains touch exposed
terminals. The conductive material may complete an electrical circuit (short
circuit) and become hot. Take care when handling a charged battery,
particularly when placing it inside a pocket, purse, or other container with
metal objects.
Use only Motorola Original™ batteries and chargers.
Caution:
To avoid risk of personal injury, do not dispose of your battery in a
fire.
Your battery, charger, or phone may contain symbols, defined as follows:
12
Safety Information
Choking Hazards
Your phone or its accessories may include detachable parts, which may
present a choking hazard to small children. Keep your phone and its
accessories away from small children.
Seizures/Blackouts
Some people may be susceptible to epileptic seizures or blackouts when
exposed to flashing lights, such as when watching television or playing
video games. These seizures or blackouts may occur even if a person never
had a previous seizure or blackout.
If you have experienced seizures or blackouts, or if you have a family
history of such occurrences, please consult with your doctor before playing
video games on your phone or enabling a flashing-lights feature on your
phone. (The flashing-light feature is not available on all products.)
Parents should monitor their children's use of video game or other features
that incorporate flashing lights on the phones. All persons should
discontinue use and consult a doctor if any of the following symptoms
Symbol Definition
Important safety information will follow.
Your battery or phone should not be disposed of in a
fire.
Your battery or phone may require recycling in
accordance with local laws. Contact your local
regulatory authorities for more information.
Your battery or phone should not be thrown in the trash.
Your phone contains an internal lithium ion battery.
032374o
032376o
032375o
032377o
032378o
Li Ion BATT
13
Safety Information
occur: convulsion, eye or muscle twitching, loss of awareness, involuntary
movements, or disorientation.
To limit the likelihood of such symptoms, please take the following safety
precautions:
•
Do not play or use a flashing-lights feature if you are tired or need
sleep.
•
Take a minimum of a 15-minute break hourly.
•
Play in a room in which all lights are on.
•
Play at the farthest distance possible from the screen.
Repetitive Motion Injuries
When you repetitively perform actions such as pressing keys or entering
finger-written characters, you may experience occasional discomfort in
your hands, arms, shoulders, neck, or other parts of your body. Follow these
instructions to avoid problems such as tendonitis, carpal tunnel syndrome,
or other musculoskeletal disorders:
•
Take a minimum 15-minute break every hour of game playing.
•
If your hands, wrists, or arms become tired or sore while playing,
stop and rest for several hours before playing again.
•
If you continue to have sore hands, wrists, or arms during or after
play, stop playing and see a doctor.
1. The information provided in this document supersedes the general safety
information in user’s guides published prior to January 28, 2005.
14
EU Conformance
European Union Directives
Conformance Statement
EU Conformance
Hereby, Motorola declares that this product is in compliance
with:
•
The essential requirements and other relevant provisions of
Directive 1999/5/EC
•
All other relevant EU Directives
The above gives an example of a typical Product Approval Number.
You can view your product’s Declaration of Conformity (DoC) to Directive
1999/5/EC (to R&TTE Directive) at www.motorola.com/rtte. To find your
DoC, enter the product Approval Number from your product’s label in the
“Search” bar on the Web site.
0168
Product
Approval
Number
15
Recycling Information
Recycl ing Information
Caring for the Environment by
Recycling
When you see this symbol on a Motorola product, do not dispose
the product with household waste.
Recycling Mobile Phones and
Accessories
Do not dispose of mobile phones or electrical accessories, such as chargers
or headsets, with your household waste. In some countries or regions,
collection systems are set up to handle electrical and electronic waste
items. Contact your regional authorities for more details. If collection
systems aren’t available, return unwanted mobile phones or electrical
accessories to any Motorola Approved Service Centre in your region.
16
essentials
essentials
about this guide
This guide shows how to locate a menu feature as follows:
Find it:
Press
M
>
Recent Calls
>
Dialed Calls
This example shows that, from the home screen, you press
M
to open the menu, highlight and select
sRecent Calls
, then
highlight and select
Dialed Calls
.
Press
S
to scroll to and highlight a menu feature. Press the
SELECT
key to select the highlighted menu feature.
SIM card
Yo u r Subscriber Identity Module (SIM) card contains personal
information like your phone number and phonebook entries.
Caution:
Don’t bend or scratch your SIM card. Keep it away
from static electricity, water, and dirt.
To install a SIM card:
symbols
This means a feature is network/subscription
dependent and may not be available in all areas.
Contact your service provider for more information.
This means a feature requires an optional accessory.
17
essentials
To remove a SIM card:
battery
battery installation
12
12
18
essentials
battery charging
New batteries are not fully
charged. Plug the travel charger
into your phone and an electrical
outlet. Your phone displays
Charge Complete when
finished.
Tip:
Relax, you can’t overcharge your battery. It will perform
best after you fully charge and discharge it a few times.
If your battery is completely drained, a PC USB charger will
not charge it. Use the travel charger.
battery tips
Battery life depends on the network, signal strength,
temperature, features, and accessories you use.
•
Always use Motorola Original batteries and
chargers. The warranty does not cover
damage caused by non-Motorola batteries
and/or chargers.
•
New batteries or batteries stored for a long time may
take more time to charge.
3
19
essentials
•
When charging your battery, keep it near room
temperature.
•
When storing your battery, keep it uncharged in a cool,
dark, dry place, such as a refrigerator.
•
Never expose batteries to temperatures below -10°C
(14°F) or above 45°C (113°F). Always take your phone
with you when you leave your vehicle.
•
It is normal for batteries to gradually wear down and
require longer charging times. If you notice a change in
your battery life, it is probably time to purchase a new
battery.
Contact your local recycling center for proper battery
disposal.
Warning:
Never dispose of batteries in a fire because they
may explode.
Before using your phone, read the battery safety information
in the “Safety and General Information” section included in
this guide.
turn it on & off
To turn on your phone, press and hold o
for a few seconds or until the display
turns on. If prompted, enter your 6-digit
SIM card PIN code and/or 4-digit unlock
code.
032375o
20
essentials
Caution:
If you enter an incorrect PIN code 3 times in a row,
your SIM card is disabled and your phone displays
SIM Blocked
.
Contact your service provider.
To turn off your phone, press and hold
o
for 2 seconds.
make a call
Enter a phone number and press
n
to make a call.
To “hang up,” close the flip or press
o
.
answer a call
Note:
Your phone cannot receive data over an EDGE network
while it is playing videos or some sound files. The EDGE
È
status indicator appears at the top of your display when you
can receive data over an EDGE network.
When your phone rings and/or vibrates, just open the flip or
press
n
to answer.
To “hang up,” close the flip or press
o
.
your phone number
From the home screen, press
M#
to see your number.
Tip:
Want to see your phone number while you’re on a call?
Press
M
>
My Tel. Numbers
.
To store or edit your name and phone number on your
SIM card, press the
EDIT
key while displaying it. If you
don’t know your phone number, contact your service
provider.
21
main attractions
main attractions
You can do much more with your phone than make and
receive calls!
take & send a photo
Press the camera key on the side of the phone to see the
camera viewfinder:
1
Point the camera lens at the photo subject.
You can press
M
to open the
Pictures Menu
. See the table
after this procedure.
Press
S
up or down to
zoom in or
out.
Remaining
photos you
can capture.
Return to previous
screen.
Press
S
left or right to
change
brightness.
Take a photo.
Press
M
to open
Pictures menu.
CAPTUREBACK
Photo Viewfinder
100 Remaining
AREA
22
main attractions
2
Press the
CAPTURE
key to take a photo.
3
Press the
DISCARD
key to delete the photo and return to the
active viewfinder.
or
Press the
STORE
key to store the photo, send it in a
message, or apply it as a screensaver or wallpaper.
When the viewfinder is active, press
M
to open the
Pictures Menu
:
option
Go To Pictures
View stored pictures and photos.
Auto-Timed Capture
Set a timer for the camera to take a
photo.
Pictures Setup
Open the setup menu to adjust photo
settings.
View Free Space
See how much memory remains.
23
main attractions
record video
Press
M
>
Multimedia
>
Video Camera
to see the video viewfinder.
Note:
You can zoom only before you start recording. The
number of video clips remaining is an estimate.
Point the camera lens at the video subject, then:
1
Press the
CAPTURE
key to start the video.
2
Press the
STOP
key to stop the video.
3
Press the
STORE
key, then select
Store Only
to store the video.
or
Press the
STORE
key, then select
Send in Message
to send the
video in a multimedia message.
or
Press
S
up or down to
zoom in or out.
Remaining
clips you can
capture
Start video
capture.
Return to previous
screen.
Press
M
to
open Videos
Menu.
VIDEO
CLIP
AREA
Video Viewfinder
104 Remaining
BACK CAPTURE
Press
S
left or right to
change
brightness.
24
main attractions
Press the
DISCARD
key to delete the video and return to the
active viewfinder.
If you want to send your video in an MMS message, the
video length must be set to MMS. To set length, from the
video viewfinder press
M
>
Videos Setup
>
Video Length
.
cable connections
Your phone has a mini-USB port
so you can connect it to a
computer to transfer data. You can:
•
Synchronize phonebook and
datebook information between
your phone and a computer or hand-held device.
•
Use your phone as a modem to connect to the
Internet.
•
Use your phone to send and receive data calls from
your computer or handheld device.
Note:
Motorola Original USB data cables and
supporting software are sold separately. Check
your computer or hand-held device to determine
the type of cable you need.
To
transfer data
between your phone and computer, you
must install the software included with the Motorola Original
data kit. See the data kit user’s guide for more information.
To make
data and fax calls
through a connected computer,
see page 65.
25
basics
basics
See page 1 for a basic phone diagram.
display
The home screen displays when you turn on the phone. To
dial a number from the home screen, press number keys and
then
n
.
Note:
Your home screen may look different from the one
below, depending on your service provider.
The Menu Indicator
À
shows that you can press
M
to open
the menu. Soft Key Labels show the current soft key
functions. For soft key locations, see page 1.
Ç
Clock
Right Soft
Key Label
Menu Indicator
Left Soft
Key Label
Service Provider
3:56pm
SETTING PH.BOOK
25-APR-05
Date
26
basics
Status indicators can display at the top of the home screen:
1 Signal Strength Indicator –
Vertical bars show the
strength of the network connection. You can’t make or
receive calls when
!
or
)
displays.
2 EDGE/GPRS Indicator –
Shows when your phone
is using a high-speed Enhanced Data for GSM
Evolution (EDGE) or General Packet Radio Service (GPRS)
network connection. Indicators can include:
3 Data Indicator –
Indicators can include:
*
= GPRS PDP context active
È
= EDGE
+
= GPRS packet data available
4
= secure packet data
transfer
7
= unsecure packet data
transfer
3
= secure application
connection
6
= unsecure application
connection
2
= secure Circuit Switch
Data (CSD) call
5
= unsecure CSD call
040079b
5. Active Line
6. Message
7. Ring Style
8. Battery
Level
4. Roam
3. Data
2. EDGE /
GPRS
1. Signal
Strength
Service Provider
3:56pm
SETTING PH.BOOK
25-APR-05
27
basics
4 Roam Indicator –
Shows when your phone is
seeking or using a network outside your home
network. Indicators can include:
5 Active Line Indicator –
Shows
?
to indicate an
active call, or
>
to indicate when call forwarding is
on. Indicators for dual-line-enabled SIM cards can include:
6 Message Indicator –
Shows when you receive a
new message. Indicators can include:
7 Ring Style Indicator –
Shows the ring style setting.
8 Battery Level Indicator –
Vertical bars show the battery
charge level. Recharge the battery when your phone
shows
Low Battery
.
:
= 2G home
;
= 2G roam
8
= 2.5G home
9
= 2.5G roam
@
= line 1 active
A
= line 1 active, call forward on
B
= line 2 active
C
= line 2 active, call forward on
r
= text message
t
= voice message
y
= loud ring
Ó
= vibrate & ring
z
= soft ring
}
= vibrate then ring
|
= vibrate
Ò
= silent
28
basics
menus
From the home screen, press
M
to enter the main menu.
The following menu icons may be available, depending on
your service provider and service subscription options.
menu features
eMessages nPhonebook
sRecent Calls ÉTools
QGames & Apps áWeb Access
hMultimedia ÜVoice Records
wSettings
EXIT SELECT
Games & Apps
ens
ÉQ
á
hÜw
Scroll up, down,
left, or right.
Press center to
select
highlighted
menu feature.
Exit the main
menu.
Name of
Highlighted
Menu Feature
Icon
Select
highlighted menu
feature.
Exit menu without
making changes.
29
basics
Some features require you to select an option from a list:
•
Scroll up or down to highlight the option you want.
•
In a numbered list, press a number key to highlight an
option.
•
In an alphabetized list, press a key repeatedly to cycle
through its letters and highlight the closest matching
list option.
•
When an option has a list of possible settings, scroll
left or right to select the setting.
•
When an option has a list of possible numeric values,
press a number key to set the value.
Highlighted
Option
Press BACK key
to go back to
previous
screen.
Press
S
to scroll down
to other
options.
Dialed Calls
✓10) John Smith
✓9) Lisa Owens
✓8) Adda Thomas
7) Jack Bradshaw
✓6) Mary Smith
5) Carlos Emrys
✓4) Dave Thompson
✓3) Lisa Owens
BACK VIEW
G
Press VIEW key
to view details
of highlighted
option.
Press
M
to
open sub-menu
30
basics
text entry
Some features let you enter text.
Press
#
in a text entry screen to select an entry mode:
entry mode
j
or
g
Yo ur
Primary
text entry mode can be set to any
iTAP®
j
or tap
g
mode.
p
or
m
Yo ur
Secondary
text entry mode can be set to any
iTAP
p
or tap
m
mode, or set to
None
if you don’t
want a secondary entry mode.
WNumeric
mode enters numbers only.
[Symbol
mode enters symbols only.
M
Msg 450
Vh
For indicator
descriptions,
see following
section.
Flashing
cursor
indicates
insertion point.
After you enter
text, press the
SEND TO key to
enter
recipients.
Press M to
open sub-
menu.
Press the CANCEL
key to
exit
without making changes.
CANCEL SEND TO
31
basics
To set your primary and secondary text entry modes, press
M
>
Entry Setup
in a text entry screen and select
Primary Setup
or
Secondary Setup
.
Tip:
WANT TO SHOUT YOUR MESSAGE? Press
0
in a text
entry screen to change text case to no capital letters (
U
),
next letter capital (
V
with
k
,
n
,
h
, or
q
), or all capitals
(
T
with
i
,
o
,
f
, or
l
).
iTAP® mode
Press
#
in a text entry screen to switch to iTAP mode. If
you don’t see
j
or
p
, press
M
>
Entry Setup
to set iTAP mode
as your primary or secondary text entry mode.
iTAP mode lets you enter words using one keypress per
letter. The iTAP software combines your keypresses into
common words, and predicts each word as you enter it.
32
basics
For example, if you press
7764
, your phone
displays:
•
If you want a different word (such as
Progress
), continue
pressing keypad keys to enter the remaining letters.
•
To enter numbers quickly, press and hold a number key
to temporarily switch to numeric mode. Press the
number keys to enter the numbers you want. Enter a
space to change back to iTAP mode.
•
Press
1
to enter punctuation or other characters.
tap mode
Press
#
in a text entry screen to switch to tap mode. If you
don’t see
Vg
or
Vm
, press
M
>
Entry Setup
to set tap mode
as your primary or secondary text entry mode.
Msg 443
Vj
SELECT
Prog ram
ProgProhSpoiProi
DELETE
Press DELETE
key to delete
last letter.
Press
S
up to accept
Program.
Press
S
right
to highlight
another
combination.
Press * to
enter Prog and
a space.
Press SELECT key to lock
highlighted combination.
33
basics
To enter text in tap mode, press a keypad key repeatedly to
cycle through the letters and number on the key. Repeat this
step to enter each letter.
For example, if you press
8
one time, your phone displays:
M
Msg 449
Ug
Character
displays at
insertion point.
After you enter
text, press the
SEND TO key to
enter
recipients.
Press the DELETE
key to
delete
character to left of insertion
point.
After
2 seconds,
character is
accepted and
cursor moves
to next
position.
DELETE SEND TO
T
34
basics
When you enter three or more characters in a row, your
phone may guess the rest of the word. For example, if you
enter
prog
your phone might display:
•
The first character of every sentence is capitalized. If
necessary, press
S
down to change the character to
lowercase before the cursor moves to the next
position.
•
Press
S
to move the flashing cursor to enter or edit
message text.
•
If you don’t want to save your text or text edits, press
o
to exit without saving.
•
Tap extended mode cycles through additional special
characters and symbols as you repeatedly press a
keypad key.
numeric mode
Press
#
in a text entry screen until you see
W
. Press the
number keys to enter the numbers you want.
Msg 443
U1
M
Character
displays at
insertion point.
Press
S
right to accept
Program, or
press *
to reject it and
enter a space
after Prog.
SEND TO
Prog ram
DELETE
35
basics
symbol mode
Press
#
in a text entry screen until you see
[
. Press a
keypad key to show its symbols at the bottom of the display.
Highlight the symbol you want, then press the
SELECT
key.
volume
Press the volume keys to:
•
turn off an incoming call alert
•
change the earpiece volume
during calls
•
change the ringer volume from the home screen
Tip:
Sometimes silence really is golden. That’s why
you can quickly set your ringer to
Vibrate
or
Silent
by
holding the down volume key in the home screen.
navigation key
Press the navigation key S up, down, left, or
right to scroll and highlight items in the
display. When you highlight something, press
the center key s to select it. The center key
usually does the same thing as the right soft key.
external display
When your phone is closed, the external display shows the
time, date, status indicators, and notifications for incoming
36
basics
calls and other events. For a list of phone status indicators,
see page 26.
To set the phone ring style in the external display:
1
Press a volume key to display
Style:
style name.
2
Press the smart key repeatedly, until the style you want
appears.
3
Press a volume key to return to the home screen.
handsfree speaker
You can use your phone’s handsfree speaker to make calls
without holding the phone to your ear.
During a call, press the
SPEAKER
key to turn the handsfree
speaker on. Your phone displays
Spkrphone On
until you turn it off
or end the call.
Note:
The handsfree speaker won’t work when your phone is
connected to a handsfree car kit or headset.
codes & passwords
Your phone’s 4-digit
unlock code
is originally set to
1234
.
The 6-digit
security code
is originally set to
000000
. If your
service provider didn’t change these codes, you should
change them:
Find it:
Press
M
>
Settings
>
Security
>
New Passwords
You can also change your
SIM PIN2
or call barring
passwords.
37
basics
If you forget your unlock code:
At the
Enter Unlock Code
prompt,
try entering 1234 or the last 4 digits of your phone number. If
that doesn’t work, press
M
and enter your 6-digit security
code instead.
If you forget other codes:
If you forget your security code,
SIM PIN code, PIN2 code, or call barring password, contact
your service provider.
lock & unlock phone
You can lock your phone to keep others from using it. To lock
or unlock your phone, you need the 4-digit unlock code.
To
manually lock
your phone: Press
M
>
Settings
>
Security
>
Phone Lock
>
Lock Now
> unlock code.
To
automatically lock
your phone whenever you turn it off:
Press
M
>
Settings
>
Security
>
Phone Lock
>
Automatic Lock
>
On
>
unlock code.
Note:
You can make emergency calls on a locked phone (see
page 45). A locked phone still rings or vibrates for incoming
calls or messages,
but you need to unlock it to answer
.
battery meter
View a meter that shows your battery’s charge level:
Find it:
Press
M
>
Settings
>
Phone Status
>
Battery Meter
38
customize
customize
ring style
Each ring style profile uses a different set of sounds or
vibrations for incoming calls and other events. Here are the
profiles you can choose:
The ring style profile’s indicator displays at the top of your
home screen. To choose your profile:
Find it:
Press
M
>
Settings
>
Ring Styles
>
Style:
style name
change alerts in a ring style
You can change the alerts for incoming calls and other
events. Your changes are saved in the current ring style
profile.
Find it:
Press
M
>
Settings
>
Ring Styles
> Style
Detail
Note:
Style represents the current ring style. You can’t set an
alert for the
Silent
ring style setting.
1
Highlight
Line 1
or
Line 2
, then press the
CHANGE
key to
change it.
2
Highlight the alert you want, then press the
SELECT
key.
3
Press the
BACK
key to save the alert setting.
yLoud |Vibrate }Vibe Then Ring
zSoft ÓVibe & Ring ÒSilent
39
customize
time & date
You need to set your phone’s time and date to use the
datebook.
To set the time and date: Press
M
>
Settings
>
Initial Setup
>
Time and Date
> time or date.
To choose an
analog or digital
clock for your home screen,
press
M
>
Settings
>
Personalize
>
Home Screen
>
Clock
.
wallpaper
Set a photo, picture, or animation as a wallpaper (background)
image in your home screen.
Find it:
Press
M
>
Settings
>
Personalize
>
Wallpaper
screen saver
Set a photo, picture, or animation as a screen saver. The
screen saver displays when the flip is open and no activity is
detected for a specified time.
Tip:
This feature helps save your screen, but not your battery.
To extend battery life, turn off the screen saver.
option
Select an image for your wallpaper, or
None
for no
wallpaper.
Layout
Select
Center
to center the image in the display,
Tile
to repeat the image across the display, or
Fit-to-screen
to stretch the image across the display.
40
customize
Find it:
Press
M
>
Settings
>
Personalize
>
Screen Saver
display appearance
To choose a
color style
that sets the look of your phone’s
display:
Press
M
>
Settings
>
Personalize
>
Color Style
.
To adjust the
contrast
of your phone’s display:
Press
M
>
Settings
>
Initial Setup
>
Contrast
To save battery life, your
backlight
turns off when you’re not
using your phone. The backlight turns back on when you
open the flip or press any key. To set how long your phone
waits before the backlight turns off:
Press
M
>
Settings
>
Initial Setup
>
Backlight
.
Note:
To turn the backlight on or off for Java™ applications,
press
M
>
Settings
>
Java Settings
>
App Backlight
.
To save battery life, the
display
can turn off when you’re not
using your phone. The display turns back on when you open
the flip or press any key. To set how long your phone waits
before the display turns off:
Press
M
>
Settings
>
Initial Setup
>
Display Timeout
.
option
Select an image for your screen saver, or
None
for
no screen saver.
Delay
Select the length of inactivity before the screen
saver displays.
41
customize
answer options
You can use different ways to answer an incoming call. To
turn on or turn off an answer option:
Find it:
Press
M
>
Settings
>
In-Call Setup
>
Answer Options
option
Multi-Key
Answer by pressing any key.
Open To Answer
Answer by opening the flip.
42
calls
calls
To make and answer calls, see page 20.
turn off a call alert
You can press the volume keys to turn off a call alert before
answering the call.
recent calls
Your phone keeps lists of incoming and outgoing calls, even
for calls that didn’t connect. The most recent calls are listed
first. The oldest calls are deleted as new calls are added.
Shortcut:
Press
n
from the home screen to see the dialed
calls list.
Find it:
Press
M
>
Recent Calls
1
Highlight
Received Calls
or
Dialed Calls
, then press the
SELECT
key.
2
Highlight a call. A
Á
next to a call means the call
connected.
•
To call the number, press
n
.
•
To see call details (like time and date), press the
VIEW
key.
•
To see the
Last Calls Menu
, press
M
. This menu can
include:
43
calls
redial
1
Press
n
from the home screen to see the dialed calls
list.
2
Highlight the entry you want to call, then press
n
.
If you hear a
busy signal
and see
Call Failed, Number Busy
,
press
n
or the
RETRY
key to redial the number. When
option
Store
Create a phonebook entry with the
number in the
No.
field.
Store
does not
appear if the number is already stored.
Delete
Delete the entry.
Delete All
Delete all entries in the list.
Hide ID/Show ID
Hide or show your caller ID for the next
call.
Send Message
Open a new text message with the
number in the
To
field.
Add Digits
Add digits after the number.
Attach Number
Attach a number from the phonebook or
recent calls lists.
Send Tones
Send the number to the network as
DTMF tones.
Note:
This option displays only during a
call.
Talk then Fax
Talk and then send a fax in the
same call (see page 65).
44
calls
the call goes through, your phone rings or vibrates one time,
displays
Redial Successful
, and connects the call.
return a call
Your phone keeps a record of your unanswered calls, and
displays X
Missed Calls
, where X is the number of missed calls.
1
Press the
VIEW
key to see the received calls list.
2
Highlight the call you want to return, then press
n
.
notepad
Your phone saves the last set of digits entered on the keypad
in notepad memory. This can be the last phone number you
called, or a number that you “jot down” during a call for later
use. To see the number stored in the notepad:
Find it:
Press
M
>
Recent Calls
>
Notepad
•
To call the number, press
n
.
•
To create a phonebook entry with the number in the
No.
field, press the
STORE
key.
•
To open the
Dialing Menu
to attach a number or insert a
special character, press
M
.
hold or mute a call
Press
M
>
HOLD
to put all active calls on hold.
Press
MUTE
key (if available) or
M
>
Mute
to put all active calls
on mute.
45
calls
call waiting
When you’re on a call, you’ll hear an alert if you receive
a second call.
Press
n
to answer the new call.
•
To switch between calls, press the
SWITCH
key.
•
To connect the two calls, press the
LINK
key.
•
To end the call on hold, press
M
>
EndCallOnHold
.
To turn the call waiting feature on or off:
Find it:
Press
M
>
Settings
>
In-Call Setup
>
Call Waiting
caller ID
Calling line identification (caller ID) shows the phone
number for an incoming call in your external and internal
displays.
Your phone shows the caller’s name and picture when
they’re stored in your phonebook, or
Incoming Call
when caller ID
information isn’t available.
You can set your phone to play a different ringer ID for an
entry stored in your phonebook (see page 51).
To show or hide
your phone number
from the next person
you call, enter the phone number and press
M
>
Hide ID
.
emergency calls
Your service provider programs one or more emergency
phone numbers, such as 911 or 112, that you can call under
46
calls
any circumstances, even when your phone is locked or the
SIM card is not inserted.
Note:
Emergency numbers vary by country. Your phone’s
preprogrammed emergency number(s) may not work in all
locations, and sometimes an emergency call cannot be
placed due to network, environmental, or interference
issues.
1
Press the keypad keys to dial the emergency number.
2
Press
n
to call the emergency number.
international calls
If your phone service includes international dialing,
press and hold
0
to insert your local international
access code (indicated by
+
). Then, press the keypad keys to
dial the country code and phone number.
1-touch dial
To call phonebook entries 1 through 9, press and hold the
single-digit speed dial number for one second.
You can set 1-touch dial to call the entries in your phone’s
memory phonebook, your SIM card’s phonebook, or your
Fixed Dial list:
Find it:
Press
M
>
Settings
>
Initial Setup
>
1TouchDial
>
Phone
,
SIM
,or
Fixed Dial
47
calls
To add a new phonebook entry, see page 50. To edit the
Speed No.
for a phonebook entry, press
M
>
Phonebook
, highlight
the entry, and press
M
>
Edit
.
voicemail
Your network stores the voicemail messages you
receive. To listen to your messages, call your voicemail
number.
Note:
Your service provider may include additional
information about using this feature.
When you
receive
a voicemail message, your phone displays
the voicemail message indicator
t
and
New Voicemail
. Press
the
CALL
key to listen to the message.
To
check
voicemail messages:
Find it:
Press
M
>
Messages
>
Voicemail
Your phone may prompt you to store your voicemail phone
number. If you don’t know your voicemail number, contact
your service provider.
Note:
You can’t store a
p
(pause),
w
(wait), or
n
(number)
character in this number. If you want to store a voicemail
number with these characters, create a phonebook entry for
it. Then, you can use the entry to call your voicemail.
48
other features
other features
advanced calling
feature
conference call
During a call:
Dial next number, press
n
, press
the
LINK
key.
transfer a call
During a call:
M
>
Transfer
, dial transfer number,
press
n
attach a phone
number
Dial an area code or prefix for a
phonebook number, then:
M
>
Attach Number
speed dial
Speed dial a phonebook entry:
Enter speed dial number, press
#
,
press
n
.
To add a phonebook entry, see page 50.
Tip:
If you forget Aunt Mildred’s speed
dial number, press
M
>
Phonebook
,
highlight her entry, and press the
VIEW
key.
set up quick
dial
Set up preprogrammed phone
numbers:
M
>
Settings
>
Personalize
>
Quick Dial
49
other features
quick dial
Dial preprogrammed phone
numbers:
M
>
Tools
>
Dialing Services
>
Quick Dial
call forwarding
Set up or cancel call forwarding:
M
>
Settings
>
Call Forward
call barring
Restrict outgoing or incoming calls:
M
>
Settings
>
Security
>
Call Barring
change phone
line
If you have a dual-line-enabled SIM
card, you can change your line to
make and receive calls from your other
phone number.
M
>
Settings
>
Phone Status
>
Active Line
The active line indicator shows the active
phone line (see page 27).
fixed dial
When you turn on fixed dialing, you
can call only numbers stored in the
fixed dial list.
Turn fixed dialing on or off:
M
>
Settings
>
Security
>
Fixed Dial
Use the fixed dial list:
M
>
Tools
>
Dialing Services
>
Fixed Dial
feature
50
other features
phonebook
DTMF tones
Activate DTMF tones:
M
>
Settings
>
Initial Setup
>
DTMF
To send DTMF tones during a call, just
press number keys or highlight a number
in the phonebook or recent calls lists and
press
M
>
Send Tones
.
feature
add new entry
M
>
Phonebook
M
>
New
>
Phone Number
or
Email Address
Shortcut:
Enter a phone number in the
home screen, then press the
STORE
key to
create an entry for that number.
Tip:
One phone isn’t enough for some
people. When creating a phonebook
entry, select
MORE
to store another
number for the same
Name
.
dial number
Call a number stored in the phonebook:
M
>
Phonebook
, highlight the phonebook
entry, press
n
Shortcut:
In the phonebook, press a
keypad key 1 or more times to jump to
entries that begin with the key’s letters.
feature
51
other features
record a
voice name
When creating a phonebook entry,
highlight
Voice Name
and press the
RECORD
key. Press and release the voice
key and say the entry’s name (within
2 seconds). When prompted, press and
release the voice key and repeat the
name.
Note:
The
Voice Name
option isn’t available
for entries stored on the SIM card.
voice dial
number
Voice dial a number stored in the
phonebook:
Press and release the voice key, then say
the entry’s name (within 2 seconds).
set ringer ID
for entry
Assign a ring alert (ringer ID) to an entry:
M
>
Phonebook
> entry
M
>
Edit
>
Ringer ID
>ringer name
Note:
The
Ringer ID
option isn’t available for
entries stored on the SIM card.
Activate ringer IDs:
M
>
Settings
>
Ring Styles
> style
Detail
>
Ringer IDs
feature
52
other features
set picture ID
for entry
Assign a photo or picture to display
when you receive a call from an entry:
M
>
Phonebook
> entry
M
>
Edit
>
>picture name
Note:
The
option isn’t available in
entries stored on the SIM card.
set primary or
all numbers
view
Display primary numbers or all numbers
for entries when listed:
M
>
Phonebook
M
>
Setup
>
View
>
All
Contacts
or
Primary Contacts
set category
for entry
M
>
Phonebook
> entry
M
>
Edit
>
Category
>category name
Note:
The
Category
option isn’t available in
entries stored on the SIM card.
set category
view
M
>
Phonebook
M
>
Categories
>category view
You can display
All
entries, entries in a
predefined category (
Business
,
Personal
,
General
,
VIPs
), or entries in a category you
create.
define new
category
M
>
Phonebook
M
>
Categories
M
>
New
feature
53
other features
set primary
number or
address
Set the primary number for an entry with
multiple numbers:
M
>
Phonebook
, highlight the entry, press
M
>
Set Primary
> number or address
Tip:
In
Primary
number view mode, you
can still peek at other numbers stored for
the same name. Highlight the name and
press
S
left or right to see the other
numbers.
create group
mailing list
M
>
Phonebook
M
>
New
>
Mailing List
sort
phonebook list
Set the order in which entries are listed:
M
>
Phonebook
M
>
Setup
>
Sort by
>sort order
You can sort the phonebook list by
Name
,
Speed No.
,
Voice Name
, or
Email
. When sorting
by name, you can display
All
numbers or
just the
Primary
number for each name.
copy
phonebook
entry
Copy an entry from the phone to the
SIM card, or from the SIM card to the
phone:
M
>
Phonebook
, highlight the entry, press
M
>
Copy
>
Entries
>
To
delete
phonebook
entry
M
>
Phonebook
, highlight the entry, press
M
>
Delete
feature
54
other features
messages
check
phonebook
memory
Display space available for phonebook
entries in phone or SIM memory:
M
>
Phonebook M > Phone Capacity
or
SIM
Capacity
send message
to phonebook
entry
Send a phonebook entry a text,
multimedia, or voice message:
M
>
Phonebook
, highlight the entry, press
M
>
Send Message
send
phonebook
entry over
data
connection
Send a phonebook entry to another
phone, computer, or device:
M
>
Phonebook
, highlight the entry, press
M
>
Share Phonebook Entry
feature
send text
message
M
>
Messages
>
Create Message
>
New Short Message
send
multimedia
message
M
>
Messages
>
Create Message
>
New Multimedia Msg
feature
55
other features
send voice
message
M
>
Messages
>
Create Message
>
New Voice Msg
To record the voice message, press the
RECORD
key, speak, then press the
STOP
key. Your phone inserts the voice
recording into a message and lets you
enter email addresses or phone
numbers to receive the message.
use a
multimedia
template
Open a multimedia template with
preloaded media:
M
>
Messages
>
Create Message
>
MMS Templates
read new
message
When your phone displays
New Message
, press the
READ
key to
read the message you received.
read old
messages
M
>
Messages
>
Message Inbox
Icons next to each message
indicate if it is locked
9
, has an
attachment
=
, or is urgent
!
. Press
M
to
perform various operations on a
message.
store message
objects
Go to a multimedia message page,
or highlight an object in a letter,
then:
M
>
Store
feature
56
other features
browser
messages
Read messages received by your
micro-browser:
M
>
Messages
>
Browser Msgs
info services
Read subscription-based
information services messages:
M
>
Messages
>
Info Services
quick notes
Send or create a prewritten
message:
M
>
Messages
>
Quick Notes
cleanup
messages
M
>
Messages
M
>
Cleanup Messages
message setup
Specify settings for incoming and
outgoing text and multimedia messages:
M
>
Messages
M
>
Message Setup
fax message
setup
Set notification on or off for received fax
message:
M
>
Messages
M
>
Fax Msg Setup
voicemail
setup
Enter voicemail number, set notification
on or off for received voicemail message:
M
>
Messages
M
>
Voicemail Setup
feature
57
other features
personalizing
speech commands
You can place calls and perform other tasks by speaking
commands to your phone.
1
Press and release the voice button on the right side of the
phone.
Your phone displays and speaks
Say a command
, followed by a
list of speech commands.
2
Say 1 of the commands listed in the table below.
Your phone performs the corresponding action.
info services
setup
Specify settings for subscription-based
information services messages:
M
>
Messages
M
>
Info Srvc Setup
outbox
auto-cleanup
Set automatic removal of outbox
messages:
M
>
Messages
M
>
Outbox Cleanup
check
message
memory
Display space available for stored
messages:
M
>
Messages M > Memory Meter
feature
58
other features
The following are speech commands and the actions they
perform:
command
Call
place a call (see page 20)
Send Picture
name
send a Pix message to the
Phonebook
entry
whose name you speak
(See page 21for instructions on sending
a picture in a message.)
Send Text
name
send a text message
Phonebook
entry
whose name you speak
Lookup
name look up a
Phonebook
entry by speaking the
entry’s name
Go To
app use a speech shortcut to access the
phone app (application) you specify:
Voicemail
,
Camera
,
Redial
,
Received
Calls
Check
item check the item you specify:
•Status
—network coverage, signal
strength, and battery life
•Signal
—network signal strength
•Network
—network your phone is
currently using
• Battery
—battery charge level
• My Phone Number
—view your
phone number
59
other features
Use the
Call
command to place a call in 2 different ways:
•
Dial a
Phonebook
entry by speaking the name of the entry.
•
Dial any number by speaking the digits in the number.
1
Press and release the voice button on the right side of the
phone.
You phone displays
Say a command
, followed by a list of
speech commands.
2
Say “Call,” then say the name of the
Phonebook
entry, or
speak the digits of the phone number.
For example, to call the mobile number for a
Phonebook
entry named Bill Smith, you would say “Call Bill Smith
mobile.” (If the entry included only 1 number for Bill
Smith, you would simply state “Call Bill Smith.”)
Similarly, to call the phone number 312-555-1212, you
would say “Call 312-555-1212.”
If the phone recognizes the name or number, it places the
call.
If the phone asks you to repeat a name or number, say it
again. If the name or number is not valid or is not
recognized, the phone does not place the call.
If the phone does not recognize the name or number, it
displays a list of up to 3 names or numbers, asks, “Did
you say ...,” and highlights that first item in the list.
If the name or number is correct, say “Yes” to place the
call.
60
other features
If the name or number is not correct, say “No” to go to
the next item on the list.
To select the name or number manually, scroll to the
name or number on the list and press the
SELECT
key.
To exit the list, say “Cancel.”
If you reach the end of the list without confirming a
number, the phone says, “Sorry, no match found.” To try
to place the call again, press the
Repeat
key, say “Call,” and
clearly speak the name or number.
Tip:
Speak numbers at a normal speed and volume,
pronouncing each digit distinctly. Avoid pausing between
digits.
additional personalizing features
feature
language
Set menu language:
M
>
Settings
>
Initial Setup
>
Language
greeting
Enter a greeting to display when you turn
on your phone:
M
>
Settings
>
Personalize
>
Greeting
scroll
Set the highlight bar to stop or wrap
around in menu lists:
M
>
Settings
>
Initial Setup
>
Scroll
61
other features
activate ringer
IDs
Activate ringer IDs assigned to
phonebook entries and categories:
M
>
Settings
>
Ring Styles
> style
Detail
>
Ringer IDs
ring volume
M
>
Settings
>
Ring Styles
> style
Detail
>
Ring Volume
keypad
volume
M
>
Settings
>
Ring Styles
> style
Detail
>
Key Volume
reminders
Set reminder alerts for messages that
you receive:
M
>
Settings
>
Ring Styles
> style
Detail
>
Reminders
home screen
layout
M
>
Settings
>
Personalize
>
Home Screen
>
Layout
>
Centered
or
Left Justified
menu view
Display the main menu as graphic icons
or as a text-based list:
M
>
Settings
>
Personalize
>
Main Menu
>
View
main menu
Reorder your phone’s main menu:
M
>
Settings
>
Personalize
>
Main Menu
>
Reorder
show/hide
menu icons
Show or hide menu feature icons in the
home screen:
M
>
Settings
>
Personalize
>
Home Screen
>
Home Keys
>
Icons
feature
62
other features
change home
keys
Change the features for the soft keys and
navigation key in the home screen:
M
>
Settings
>
Personalize
>
Home Screen
>
Home Keys
Note:
In the
Home Screen
menu, select
SetupwithNews
or
Setup without News
if
your service provider has a news display.
shortcuts
Create a shortcut to a menu item:
Highlight the menu item, press and hold
M
, then press the
YES
key.
Use a shortcut:
Press
M
, then press the shortcut
number.
master reset
Reset all options
except
unlock code,
security code, and lifetime timer:
M
>
Settings
>
Initial Setup
>
Master Reset
feature
63
other features
call times & costs
Network connection time
is the elapsed time from the
moment you connect to your service provider's network to
the moment you end the call by pressing
o
. This time
includes busy signals and ringing.
The amount of network connection time you track on
your resettable timer may not equal the amount of time
for which you are billed by your service provider. For
billing information, contact your service provider.
master clear
Clear all settings and entries you made
except
SIM card information,
downloaded pictures and sound files,
and reset all options
except
unlock code,
security code, and lifetime timer:
M
>
Settings
>
Initial Setup
>
Master Clear
Caution:
Master clear
erases all
information you have entered
(including phonebook and datebook
entries)
and content you have
downloaded
(including photos and
sounds) stored in your phone’s memory.
After you erase the information, you
can’t recover it.
feature
64
other features
handsfree
Note:
The use of wireless devices and their accessories may
be prohibited or restricted in certain areas. Always obey the
laws and regulations on the use of these products.
feature
call times
Display call timers:
M
>
Recent Calls
>
Call Times
in-call timer
Display time or cost information
during a call:
M
>
Settings
>
In-Call Setup
>
In-Call Timer
call cost
Display call cost trackers:
M
>
Recent Calls
>
Call Cost
feature
speakerphone
Activate a connected external
speakerphone during a call:
Press the
SPEAKER
key (if available, or
M
>
Spkrphone On
).
auto answer
(car kit or
headset)
Automatically answer calls when
connected to a car kit or headset:
M
>
Settings
>
Car Settings
or
Headset
>
Auto Answer
voice dial
(headset)
Enable voice dial with headset
send/end key:
M
>
Settings
>
Headset
>
Voice Dial
65
other features
data & fax calls
To connect your phone with a USB cable, see page 24.
auto handsfree
(car kit)
Automatically route calls to a car kit
when connected:
M
>
Settings
>
Car Settings
>
Auto Handsfree
power-off
delay
(car kit)
Set the phone to stay on for a
specified time after the ignition is
switched off:
M
>
Settings
>
Car Settings
>
Power-Off Delay
charger time
(car kit)
Charge the phone for a specified
time after the ignition is switched
off:
M
>
Settings
>
Car Settings
>
Charger Time
feature
send data or
fax
Connect your phone to the device,
then place the call through the
device application.
receive data or
fax
Connect your phone to the device,
then answer the call through the
device application.
talk and fax
Connect your phone to the device,
enter fax number, press
M
>
Talk and Fax
, then press
n
to make
the call.
feature
66
other features
network
personal organizer
using sync
You can call an Internet server and
synchronize your phonebook and
datebook entries with the server.
To
set up
an Internet sync partner, press
M
>
Settings
>
Connection
>
Sync
>
[New Entry]
.
Enter the server details, including
Server
URL
(you can omit
http://
) and
Data Path
(the
folder below the URL where your data is
stored).
To
synchronize files
with a partner you
set up, select the partner from the list in
M
>
Settings
>
Connection
>
Sync
.
feature
network
settings
Display network information and
adjust network settings:
M
>
Settings
>
Network
feature
set alarm
M
>
Tools
>
Alarm Clock
feature
67
other features
turn off alarm
When an alarm displays:
To turn off the alarm, press the
DISABLE
key or
o
.
To set an 8 minute delay, press the
SNOOZE
key.
add new
datebook
event
M
>
Tools
>
Datebook
, highlight the day,
press
s
, press
M
>
New
view datebook
event
Display or edit event details:
M
>
Tools
>
Datebook
, highlight the day,
press
s
, press the
VIEW
key
event
reminder
When an event reminder displays:
To see reminder details, press the
VIEW
key. To close the reminder, press
the
EXIT
key.
send datebook
event to
another device
Send a datebook event to another
phone, computer, or device:
M
>
Tools
>
Datebook
, highlight the day,
press
s
, highlight the event, press
M
>
Send
feature
68
other features
security
create voice
record
Create a voice record (for example, to
make a note to yourself):
Press and hold the voice key, speak into
the phone, release the voice key.
Note:
Recording phone calls is subject to
varying state and federal laws regarding
privacy and recording of conversations.
Always obey the laws and regulations on
the use of this feature.
play voice
record
Play back a voice record:
M
>
Voice Records
> voice record
calculator
M
>
Tools
>
Calculator
currency
converter
M
>
Tools
>
Calculator
M
>
Exchange Rate
Enter exchange rate, press the
OK
key,
enter amount, and press
M
>
Convert Currency
.
feature
SIM PIN
Lock or unlock the SIM card:
M
>
Settings
>
Security
>
SIM PIN
Caution:
If you enter an incorrect PIN
code 3 times in a row, your SIM card is
disabled and your phone displays
SIM Blocked
.
feature
69
other features
fun & games
For basic information on the camera, see page 21.
lock feature
M
>
Settings
>
Security
>
Lock Application
manage
certificates
Enable or disable Internet access
certificates stored on your phone:
M
>
Settings
>
Security
>
Certificate Mgmt
Certificates are used to verify the
identity and security of Web sites when
you download files or share information.
feature
manage
pictures
Manage photos, pictures, and
animations:
M
>
Multimedia
>
Pictures
manage video
clips
M
>
Multimedia
>
Videos
manage
sounds
Manage ring tones and music that you
have downloaded or composed:
M
>
Multimedia
>
Sounds
create ring
tones
Create ring tones that you can use with
your phone:
M
>
Multimedia
>
Sounds
>
[New iMelody]
start
micro-browser
M
>
Web Access
>
Browser
feature
70
other features
download
objects from
Web page
Download a picture, sound, or
other object from a Web page:
Go to the page that links to the file,
highlight the file, press the
SELECT
key, and
press the
STORE
key.
Note:
Normal airtime and/or carrier
usage charges apply.
web sessions
Select or create a Web session:
M
>
Web Access
>
Web Sessions
download
game or
application
Download a Java™ game or
application with the micro-browser:
M
>
Web Access
>
Browser
, go to the page
that links to the application, highlight the
application, press the
SELECT
key, and
press the
DWNLOAD
key
Note:
Normal airtime and/or carrier
usage charges apply.
start game or
application
Start a Java™ game or application:
M
>
Games & Apps
, highlight the
game or application, press the
SELECT
key
Note:
To install and run games stored on
your memory card, press
M
>
Games & Apps
>
[Install New]
.
feature
71
other features
set game or
application
effects
Set volume, turn on vibration effect for
Java™ games or applications
M
>
Settings
>
Java Settings
>
App Vibration
or
App Volume
delete all
games and
applications
M
>
Settings
>
Java Settings
>
Delete All Apps
feature
87
Specific Absorption Rate Data
T
The model wireless phone meets the government’s requirements
for exposure to radio waves.
Your wireless phone is a radio transmitter and receiver. It is designed and
manufactured not to exceed limits for exposure to radio frequency (RF)
energy set by the Federal Communications Commission (FCC) of the U.S.
Government and by the Canadian regulatory authorities. These limits are
part of comprehensive guidelines and establish permitted levels of RF
energy for the general population. The guidelines are based on standards
that were developed by independent scientific organizations through
periodic and thorough evaluation of scientific studies. The standards
include a substantial safety margin designed to assure the safety of all
persons, regardless of age or health.
The exposure standard for wireless mobile phones employs a unit of
measurement known as the Specific Absorption Rate, or SAR. The SAR
limit set by the FCC and by the Canadian regulatory authorities is 1.6 W/
kg
1
Tests for SAR are conducted using standard operating positions
accepted by the FCC and by Industry Canada with the phone transmitting
at its highest certified power level in all tested frequency bands. Although
the SAR is determined at the highest certified power level, the actual SAR
level of the phone while operating can be well below the maximum value.
This is because the phone is designed to operate at multiple power levels
so as to use only the power required to reach the network. In general, the
closer you are to a wireless base station, the lower the power output.
Before a phone model is available for sale to the public in the U.S. and
Canada, it must be tested and certified to the FCC and Industry Canada
that it does not exceed the limit established by each government for safe
exposure. The tests are performed in positions and locations (e.g., at the
ear and worn on the body) reported to the FCC and available for review by
Industry Canada. The highest SAR value for this model phone when
tested for use at the ear is 1.28 W/kg, and when worn on the body, as
88
described in this user guide, is 0.67 W/kg. (Body-worn measurements
differ among phone models, depending upon available accessories and
regulatory requirements).
2
While there may be differences between the SAR levels of various phones
and at various positions, they all meet the governmental requirements for
safe exposure. Please note that improvements to this product model
could cause differences in the SAR value for later products; in all cases,
products are designed to be within the guidelines.
Additional information on Specific Absorption Rates (SAR) can be found
on the Cellular Telecommunications & Internet Association (CTIA) Web
site:
http://www.phonefacts.net
or the Canadian Wireless Telecommunications Association (CWTA) Web
site:
http://www.cwta.ca
1.
In the United States and Canada, the SAR limit for mobile phones used by
the public is 1.6 watts/kg (W/kg) averaged over one gram of tissue. The
standard incorporates a substantial margin of safety to give additional
protection for the public and to account for any variations in measurements.
2. A
The SAR information includes the Motorola testing protocol, assessment
procedure, and measurement uncertainty range for this product.
72
troubleshooting
troubleshooting
If you have questions or need assistance, we're here to help.
Go to
www.motorola.com/consumer/support
, where you
can select from a number of customer care options. You can
also contact the Motorola Customer Support Center at
1-800-331-6456 (United States), 1-888-390-6456 (TTY/TDD
United States for hearing impaired), or 1-800-461-4575
(Canada).
75
Warranty
Motorola Limited Warranty for the
United States and Canada
Warranty
What Does this Warranty Cover?
Subject to the exclusions contained below, Motorola, Inc. warrants its
telephones, pagers, messaging devices, and consumer and professional
two-way radios (excluding commercial, government or industrial radios)
that operate via Family Radio Service or General Mobile Radio Service,
Motorola-branded or certified accessories sold for use with these Products
(“Accessories”) and Motorola software contained on CD-ROMs or other
tangible media and sold for use with these Products (“Software”) to be free
from defects in materials and workmanship under normal consumer usage
for the period(s) outlined below. This limited warranty is a consumer's
exclusive remedy, and applies as follows to new Motorola Products,
Accessories and Software purchased by consumers in the United States or
Canada, which are accompanied by this written warranty:
Products and Accessories
Products Covered Length of Coverage
Products and
Accessories
as defined
above, unless otherwise
provided for below.
One (1) year
from the date of purchase
by the first consumer purchaser of the
product unless otherwise provided for
below.
Decorative Accessories
and Cases.
Decorative
covers, bezels,
PhoneWrap™ covers and
cases.
Limited lifetime warranty
for the
lifetime of ownership by the first
consumer purchaser of the product.
76
Warranty
Exclusions
Normal Wear and Tear.
Periodic maintenance, repair and replacement of
parts due to normal wear and tear are excluded from coverage.
Batteries.
Only batteries whose fully charged capacity falls below 80% of
their rated capacity and batteries that leak are covered by this limited
warranty.
Abuse & Misuse.
Defects or damage that result from: (a) improper
operation, storage, misuse or abuse, accident or neglect, such as physical
damage (cracks, scratches, etc.) to the surface of the product resulting from
misuse; (b) contact with liquid, water, rain, extreme humidity or heavy
perspiration, sand, dirt or the like, extreme heat, or food; (c) use of the
Products or Accessories for commercial purposes or subjecting the Product
or Accessory to abnormal usage or conditions; or (d) other acts which are
not the fault of Motorola, are excluded from coverage.
Use of Non-Motorola Products and Accessories.
Defects or damage
that result from the use of Non-Motorola branded or certified Products,
Accessories, Software or other peripheral equipment are excluded from
coverage.
Monaural Headsets.
Ear
buds and boom headsets
that transmit mono sound
through a wired connection.
Limited lifetime warranty
for the
lifetime of ownership by the first
consumer purchaser of the product.
Consumer and
Professional Two-Way
Radio Accessories.
Ninety (90) days
from the date of
purchase by the first consumer purchaser
of the product.
Products and
Accessories that are
Repaired or Replaced.
The balance of the original warranty
or for ninety (90) days
from the date
returned to the consumer, whichever is
longer.
Products Covered Length of Coverage
77
Warranty
Unauthorized Service or Modification.
Defects or damages resulting
from service, testing, adjustment, installation, maintenance, alteration, or
modification in any way by someone other than Motorola, or its authorized
service centers, are excluded from coverage.
Altered Products.
Products or Accessories with (a) serial numbers or date
tags that have been removed, altered or obliterated; (b) broken seals or
that show evidence of tampering; (c) mismatched board serial numbers; or
(d) nonconforming or non-Motorola housings, or parts, are excluded from
coverage.
Communication Services.
Defects, damages, or the failure of Products,
Accessories or Software due to any communication service or signal you
may subscribe to or use with the Products Accessories or Software is
excluded from coverage.
Software
Exclusions
Software Embodied in Physical Media.
No warranty is made that the
software will meet your requirements or will work in combination with any
hardware or software applications provided by third parties, that the
operation of the software products will be uninterrupted or error free, or
that all defects in the software products will be corrected.
Software NOT Embodied in Physical Media.
Software that is not
embodied in physical media (e.g. software that is downloaded from the
internet), is provided “as is” and without warranty.
Products Covered Length of Coverage
Software.
Applies only to physical
defects in the media that embodies the
copy of the software (e.g. CD-ROM, or
floppy disk).
Ninety (90) days
from the
date of purchase.
78
Warranty
Who Is Covered?
This warranty extends only to the first consumer purchaser, and is not
transferable.
What Will Motorola Do?
Motorola, at its option, will at no charge repair, replace or refund the
purchase price of any Products, Accessories or Software that does not
conform to this warranty. We may use functionally equivalent
reconditioned/refurbished/pre-owned or new Products, Accessories or
parts. No data, software or applications added to your Product, Accessory
or Software, including but not limited to personal contacts, games and
ringer tones, will be reinstalled. To avoid losing such data, software and
applications please create a back up prior to requesting service.
How to Obtain Warranty Service or Other
Information
USA Phones
1-800-331-6456
Pagers
1-800-548-9954
Two-Way Radios and Messaging Devices
1-800-353-2729
Canada All Products
1-800-461-4575
TTY
1-888-390-6456
For
Accessories
and
Software
, please call the telephone number
designated above for the product with which they are used.
79
Warranty
You will receive instructions on how to ship the Products, Accessories or
Software, at your expense, to a Motorola Authorized Repair Center. To
obtain service, you must include: (a) a copy of your receipt, bill of sale or
other comparable proof of purchase; (b) a written description of the
problem; (c) the name of your service provider, if applicable; (d) the name
and location of the installation facility (if applicable) and, most importantly;
(e) your address and telephone number.
What Other Limitations Are There?
ANY IMPLIED WARRANTIES, INCLUDING WITHOUT LIMITATION THE
IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A
PARTICULAR PURPOSE, SHALL BE LIMITED TO THE DURATION OF THIS
LIMITED WARRANTY, OTHERWISE THE REPAIR, REPLACEMENT, OR
REFUND AS PROVIDED UNDER THIS EXPRESS LIMITED WARRANTY IS
THE EXCLUSIVE REMEDY OF THE CONSUMER, AND IS PROVIDED IN LIEU
OF ALL OTHER WARRANTIES, EXPRESS OR IMPLIED. IN NO EVENT SHALL
MOTOROLA BE LIABLE, WHETHER IN CONTRACT OR TORT (INCLUDING
NEGLIGENCE) FOR DAMAGES IN EXCESS OF THE PURCHASE PRICE OF
THE PRODUCT, ACCESSORY OR SOFTWARE, OR FOR ANY INDIRECT,
INCIDENTAL, SPECIAL OR CONSEQUENTIAL DAMAGES OF ANY KIND, OR
LOSS OF REVENUE OR PROFITS, LOSS OF BUSINESS, LOSS OF
INFORMATION OR DATA, SOFTWARE OR APPLICATIONS OR OTHER
FINANCIAL LOSS ARISING OUT OF OR IN CONNECTION WITH THE ABILITY
OR INABILITY TO USE THE PRODUCTS, ACCESSORIES OR SOFTWARE TO
THE FULL EXTENT THESE DAMAGES MAY BE DISCLAIMED BY LAW.
Some states and jurisdictions do not allow the limitation or
exclusion of incidental or consequential damages, or limitation on
the length of an implied warranty, so the above limitations or
exclusions may not apply to you. This warranty gives you specific
legal rights, and you may also have other rights that vary from state
to state or from one jurisdiction to another.
Laws in the United States and other countries preserve for Motorola
certain exclusive rights for copyrighted Motorola software such as the
80
Warranty
exclusive rights to reproduce and distribute copies of the Motorola
software. Motorola software may only be copied into, used in, and
redistributed with, the Products associated with such Motorola software.
No other use, including without limitation disassembly of such Motorola
software or exercise of the exclusive rights reserved for Motorola, is
permitted.
81
index
index
A
accessories 16, 64
accessory connector port 1
active line indicator 27
active line, changing 49
alarm clock 66, 67
alert
set 35, 38
turn off 35, 42
animation 69
answer a call 20, 41
attach a number 43, 48
B
backlight 40
battery 17, 18
battery indicator 27
battery life, extending 18,
39, 40
browser messages 56
browser. See micro-browser
C
cables 24
calculator 68
call
answer 20, 41
end 20
make 20, 50
call barring 36, 49
call forward indicator 27
call forwarding 49
call timers 64
call waiting 45
caller ID 43, 45, 52
camera 21
car kit 64
center key 1, 35
certificate management 69
clock 39
codes 36, 37
color style 40
conference call 48
contrast 40
costs, tracking 64
D
data call 65
data connection 54
data indicator 26
date, setting 39
datebook 67
dial a phone number 20, 49,
50
82
index
dialed calls 42
display 25, 40
download media objects
55, 70
DTMF tones 43, 50
E
earpiece volume 35
EDGE indicator 26
email 55
email address 50
emergency number 45
end a call 20
end key 1, 20
Enter Unlock Code
message 37
external display 35
F
fax call 43, 65
fixed dial 49
flip 20, 41
forward calls 49
G
games 70
GPRS indicator 26
greeting 60
group mailing list 53
H
handsfree speaker 36
headset 64
headset jack 1
hold a call 44
home screen 25, 61, 62
I
in-call indicator 27
Incoming Call message 45
information services 56
setup 57
international access code
46
iTAP text entry mode 31
J
Java applications 70
K
keypad 41, 61
L
language 60
layout 61
lock
application 69
phone 37
SIM card 68
Low Battery message 27
83
index
M
make a call 20, 50
master clear 63
master reset 62
menu 28, 60, 61
menu icons 28, 61
menu indicator 25
menu key 1, 16
message 54, 55
cleanup 56
setup 56
message indicator 27
message reminders 61
micro-browser 56, 69, 70
Missed Calls message 44
multimedia message 54, 55
music 69
mute a call 44
N
navigation key 1, 16, 35
network settings 66
notepad 44
number. See phone number
numeric entry mode 34
O
1-touch dial 46
open to answer 41
optional accessory 16
optional feature 16
P
passwords. See codes
personalize 57
phone number 20, 49, 50
phonebook 43, 46, 48, 50
photo 21, 69
picture 69
picture ID 45, 52
PIN code 19, 36, 68
PIN2 code 36
power key 1, 19, 20
Q
quick dial 49
setup 48
quick notes 56
R
received calls 42
recent calls 42
redial 43
reminders 61
return a call 44
ring style indicator 27
ring style, setting 35, 38
ring tone 69
ringer ID 45, 51, 61
ringer volume 35, 61
roam indicator 27
84
index
S
screen saver 39
security code 36
send key 1, 20
shortcuts 62
signal strength indicator 26
SIM Blocked message 20,
68
SIM card 16, 19, 36, 68
smart key 36
soft keys 1, 25, 62
speakerphone 64
speed dial 48
store your number 20
symbol entry mode 35
synchronizing 66
T
tap text entry mode 32
telephone number. See
phone number
text entry 30
text message 54, 55
time, setting 39
timers 64
transfer a call 48
turn on/off 19
U
unlock
application 69
phone 19, 37
SIM card 68
unlock code 36, 37
USB cables 24
V
video clip 69
videos 23
voice dial 51, 64
voice message 55
voice name, recording 51
voice record 68
voicemail 47
setup 56
voicemail message indicator
27, 47
volume 35, 61
W
wallpaper 39
warranty 75
Web pages 69
Web sessions 70
Y
your phone number 20
U.S. patent Re. 34,976
motorola.com
