Exhibit 8 Users Manual

APPLICANT: MOTOROLA, INC. FCC ID: IHDT56GT1

INSTRUCTION MANUAL

• A preliminary draft copy of the User’s Manual follows this cover page.

• The User’s Manual will have the following text added to it:

"NOTE: This equipment has been tested and found to comply with the limits for a Class B

digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide

reasonable protection against harmful interference in a residential installation. This equipment

generates, uses and can radiate radio frequency energy and, if not installed and used in

accordance with the instructions, may cause harmful interference to radio communications.

However, there is no guarantee that interference will not occur in a particular installation. If

this equipment does cause harmful interference to radio or television reception, which can be

determined by turning the equipment off and on, the user is encouraged to try to correct the

interference by one or more of the following measures:

. Reorient or relocate the receiving antenna.

. Increase the separation between the equipment and receiver.

. Connect the equipment into an outlet on a circuit different from that to which the receiver is

connected.

. Consult the dealer or an experienced radio/TV technician for help."

EXHIBIT 8

motorola.com

K1 GSM

Cover.Print.Front.UG.landscape-K1.fm Page 1 Friday, March 24, 2006 5:56 PM

HELLOMOTO

Introducing your new Motorola K1 GSM wireless phone. Here’s a quick anatomy lesson.

For Push to Talk (PTT) details, see page 53.

Left Soft Key

Volume Keys

Charge up or

go handsfree.

Make &

answer calls.

Smart Key

Go online.

Scroll up,

down, left, or

right.

Select.

Right Soft Key

Clear Key

Voice Dial Key

Turn on & off,

hang up, exit

menus.

Home Screen Main Menu

Press and hold the

Power

Key

for a few

seconds or until the

display lights up to turn

on your phone.

Press the Navigation Key

up, down, left, or right

(

) to highlight a menu

feature.

Press the Center Key

(

) to select it.

Press the Center Key

key to open the

Main Menu

Styles Camera

Service Provider

12/31/09

12:00

Exit Select

Games & Apps

Motorola, Inc.

Consumer Advocacy Office

1307 East Algonquin Road

Schaumburg, IL 60196

www.hellomoto.com

Certain mobile phone features are dependent on the capabilities

and settings of your service provider’s network. Additionally,

certain features may not be activated by your service provider,

and/or the provider's network settings may limit the feature’s

functionality. Always contact your service provider about feature

availability and functionality. All features, functionality, and other

product specifications, as well as the information contained in this

user's guide are based upon the latest available information and

are believed to be accurate at the time of printing. Motorola

reserves the right to change or modify any information or

specifications without notice or obligation.

MOTOROLA and the Stylized M Logo are registered in the US

Patent & Trademark Office. All other product or service names are

the property of their respective owners. The Bluetooth trademarks

are owned by their proprietor and used by Motorola, Inc. under

license. Java and all other Java-based marks are trademarks or

registered trademarks of Sun Microsystems, Inc. in the U.S. and

other countries.

Caution:

Changes or modifications made in the radio phone, not

expressly approved by Motorola, will void the user’s authority to

operate the equipment.

Software Copyright Notice

The Motorola products described in this manual may include

copyrighted Motorola and third-party software stored in

semiconductor memories or other media. Laws in the United

States and other countries preserve for Motorola and third-party

software providers certain exclusive rights for copyrighted

software, such as the exclusive rights to distribute or reproduce

the copyrighted software. Accordingly, any copyrighted software

contained in the Motorola products may not be modified,

reverse-engineered, distributed, or reproduced in any manner to

the extent allowed by law. Furthermore, the purchase of the

Motorola products shall not be deemed to grant either directly or

by implication, estoppel, or otherwise, any license under the

copyrights, patents, or patent applications of Motorola or any

third-party software provider, except for the normal, non-exclusive,

royalty-free license to use that arises by operation of law in the

sale of a product.

Manual Number: 68XXXXX141-O

contents

menu map . . . . . . . . . . . . 6

Safety Information . . . . . 8

Use and Care . . . . . . . . . 13

EU Conformance . . . . . . 14

Recycling Information. . 15

essentials . . . . . . . . . . . . 16

about this guide. . . . . . 16

SIM card . . . . . . . . . . . 16

battery . . . . . . . . . . . . . 17

turn it on & off . . . . . . . 19

make a call. . . . . . . . . . 20

answer a call . . . . . . . . 20

store a phone number . 20

call a stored phone

number . . . . . . . . . . . . 21

your phone number . . . 21

main attractions . . . . . . 22

phone updates. . . . . . . 22

headlines . . . . . . . . . . . 22

Bluetooth™ wireless . . 24

audio player . . . . . . . . . 25

take & send a photo . . 26

record & send a video . 29

text messages. . . . . . . 30

memory card . . . . . . . . 32

cable connections . . . . 34

basics . . . . . . . . . . . . . . . 36

display . . . . . . . . . . . . . 36

text entry . . . . . . . . . . . 39

volume. . . . . . . . . . . . . 42

navigation key . . . . . . . 43

smart key. . . . . . . . . . . 43

external display . . . . . . 43

handsfree speaker . . . . 43

codes & passwords . . . 44

lock & unlock phone . . 44

customize. . . . . . . . . . . . 45

ring style . . . . . . . . . . . 45

time & date . . . . . . . . . 46

wallpaper . . . . . . . . . . . 47

screen saver . . . . . . . . 47

themes . . . . . . . . . . . . 47

display appearance . . . 48

answer options . . . . . . 49

calls. . . . . . . . . . . . . . . . . 50

turn off a call alert . . . . 50

recent calls . . . . . . . . . 50

redial . . . . . . . . . . . . . . 51

return a call . . . . . . . . . 52

caller ID . . . . . . . . . . . . 52

contents

emergency calls . . . . . 52

voicemail . . . . . . . . . . 53

push to talk (PTT) . . . . 53

other features . . . . . . . . 60

advanced calling . . . . . 60

phonebook . . . . . . . . . 65

messages. . . . . . . . . . 70

instant messaging . . . 73

personalizing. . . . . . . . . 74

call times & costs . . . . 76

handsfree . . . . . . . . . . 77

data & fax calls . . . . . . 78

network . . . . . . . . . . . 80

personal organizer . . . 81

security. . . . . . . . . . . . 83

fun & games. . . . . . . . 83

service and repairs . . . . 87

SAR Data. . . . . . . . . . . . 88

Warranty . . . . . . . . . . . . 89

WHO Information . . . . . 93

index . . . . . . . . . . . . . . . 94

menu map

main menu

Phonebook

Recent Calls

• (press

to scroll through the

call lists)

Messages

• Create Message

•EmailMsgs

• Message Inbox

• Hot Messages

•Voicemail

• Browser Msgs

• Info Services *

• Outbox

•Drafts

• Templates

To o l s

• SIM Tool Kit Apps *

•Calculator

• Datebook

• Shortcuts

•Alarm Clock

• Dialing Services

• Fixed Dial *

• Voice Dial

• Mobile QQ *

• Activation List *

• World Clock

Games & Apps

Web Access *

•Browser

• Web Shortcuts

• Stored Pages

•History

•Go To URL

•Browser Setup

• Web Sessions *

Multimedia

• Themes

•Voice Records

•Camera

• Video Camera

•Pictures

• Sounds

• Videos

IM *

Settings

• (see next page)

* optional features

This is the standard main

menu layout.

Your phone’s

menu may be different.

menu map

settings menu

Personalize

• Home Screen

• Main Menu

•Skin

• Greeting

• Wallpaper

• Screen Saver

Ring Styles

•Style

• style Detail

Connection

• Bluetooth™ Link

• USB Settings

•MOTOSYNC™

Call Forward *

• Voice Calls

• Fax Calls

• Data Calls

•Cancel All

• Forward Status

In-Call Setup

• In-Call Timer

• Call Cost Setup *

• My Caller ID

• Talk and Fax

• Answer Options

• Call Waiting

Initial Setup

• Time and Date

• Speed Dial

• Display Timeout

• Backlight

• TTY Setup *

•Scroll

• Text Marquee

• Language

• Brightness

•DTMF

• Master Reset

• Master Clear

Phone Status

• My Tel. Numbers

• Credit Info/Available *

• Active Line *

• Battery Meter

• Storage Devices

• Software Update *

• Other Information

Headset

• Auto Answer

•Voice Dial

Car Settings

• Auto Answer

• Auto Handsfree

•Power-Off Delay

• Charger Time

* optional features

Airplane Mode

• Airplane Mode

• Prompt at Power Up

Network

•New Network

•Network Setup

• Available Networks

• My Network List *

• Service Tone *

• Network Jingle *

• Call Drop Tone

Security

• Phone Lock

•Lock PTT Key*

• Lock Application

• Fixed Dial *

• Restrict Calls *

• Call Barring *

• SIM PIN

•New Passwords

• Certificate Mgmt *

PTT Settings *

• PTT Service

Java™ Settings

• Java System

• Delete All Apps

• App Vibration

• App Volume

• App Backlight

Safety Information

Safety and General Information

Safe ty Infor mation

This section contains important information on the safe and

efficient operation of your mobile device. Read this

information before using your mobile device.

Exposure To Radio Frequency (RF)

Energy

Your mobile device contains a transmitter and receiver. When it is

ON, it receives and transmits RF energy. When you communicate

with your mobile device, the system handling your call controls the

power level at which your mobile device transmits.

Your Motorola mobile device is designed to comply with local

regulatory requirements in your country concerning exposure of

human beings to RF energy.

Operational Precautions

For optimal mobile device performance and to be sure that human

exposure to RF energy does not exceed the guidelines set forth in

the relevant standards, always follow these instructions and

precautions.

External Antenna Care

If your mobile device has an external antenna, use only a

Motorola-supplied or approved replacement antenna. Use of

unauthorized antennas, modifications, or attachments could

damage the mobile device and/or may result in your device not

complying with local regulatory requirements in your country.

DO NOT hold the external antenna when the mobile device is IN

USE. Holding the external antenna affects call quality and may

cause the mobile device to operate at a higher power level than

needed.

Product Operation

When placing or receiving a phone call, hold your mobile device

just like you would a landline phone.

If you wear the mobile device on your body, always place the

mobile device in a Motorola-supplied or approved clip, holder,

holster, case, or body harness. If you do not use a body-worn

accessory supplied or approved by Motorola, keep the mobile

device and its antenna at least 2.5 centimeters (1 inch) from your

body when transmitting.

* The information provided in this document supersedes the general

safety information in user’s guides published prior to May 1, 2006.

Safety Information

When using any data feature of the mobile device, with or without

an accessory cable, position the mobile device and its antenna at

least 2.5 centimeters (1 inch) from your body.

Using accessories not supplied or approved by Motorola may

cause your mobile device to exceed RF energy exposure

guidelines. For a list of Motorola-supplied or approved

accessories, visit our website at

www.motorola.com

RF Energy Interference/Compatibility

Nearly every electronic device is subject to RF energy interference

from external sources if inadequately shielded, designed, or

otherwise configured for RF energy compatibility. In some

circumstances your mobile device may cause interference with

other devices.

This device complies with Part 15 of the FCC Rules. Operation is

subject to the following two conditions: (1) this device may not

cause harmful interference, and (2) this device must accept any

interference received, including interference that may cause

undesired operation.

Follow Instructions to Avoid Interference

Problems

Turn off your mobile device in any location where posted notices

instruct you to do so. These locations include hospitals or health

care facilities that may be using equipment that is sensitive to

external RF energy.

In an aircraft, turn off your mobile device whenever instructed to

do so by airline staff. If your mobile device offers an airplane mode

or similar feature, consult airline staff about using it in flight.

Pacemakers

If you have a pacemaker, consult your physician before using this

device.

Persons with pacemakers should observe the following

precautions:

•

ALWAYS keep the mobile device more than

20 centimeters (8 inches) from your pacemaker when the

mobile device is turned ON.

•

DO NOT carry the mobile device in the breast pocket.

•

Use the ear opposite the pacemaker to minimize the

potential for interference.

•

Turn OFF the mobile device immediately if you have any

reason to suspect that interference is taking place.

Hearing Aids

Some digital mobile devices may interfere with some hearing aids.

In the event of such interference, you may want to consult your

hearing aid manufacturer or physician to discuss alternatives.

Safety Information

Other Medical Devices

If you use any other personal medical device, consult your

physician or the manufacturer of your device to determine if it is

adequately shielded from RF energy.

Driving Precautions

Check the laws and regulations on the use of mobile devices in the

area where you drive. Always obey them.

When using your mobile device while driving, please:

•

Give full attention to driving and to the road. Using a

mobile device may be distracting. Discontinue a call if you

can’t concentrate on driving.

•

Use handsfree operation, if available.

•

Pull off the road and park before making or answering a

call if driving conditions so require.

Responsible driving practices can be found in the “Smart Practices

While Driving” section at the end of this guide and/or at the

Motorola website:

www.motorola.com/callsmart

Operational Warnings

Obey all posted signs when using mobile devices in public areas,

such as health care facilities or blasting areas.

Automobile Air Bags

Do not place a mobile device in the air bag deployment area.

Potentially Explosive Atmospheres

Areas with potentially explosive atmospheres are often but not

always posted, and can include fueling areas such as below decks

on boats, fuel or chemical transfer or storage facilities, or areas

where the air contains chemicals or particles, such as grain, dust,

or metal powders.

When you are in such an area, turn off your mobile device, and do

not remove, install, or charge batteries. In such areas, sparks can

occur and cause an explosion or fire.

Damaged Products

If your mobile device or battery has been submerged in water,

punctured, or subjected to a severe fall, do not use it until you take

it to a Motorola Authorized Service Center. Do not attempt to dry it

with an external heat source, such as a microwave oven.

Batteries and Chargers

If jewelry, keys, beaded chains, or other conductive

materials touch exposed battery terminals, this

could complete an electrical circuit (short circuit),

become very hot, and could cause damage or

injury. Be careful when handling a charged battery,

Safety Information

particularly when placing it inside a pocket, purse, or other

container with metal objects.

Use only Motorola Original

batteries and chargers.

Caution:

To avoid risk of personal injury, do not dispose of your

battery in a fire.

Your battery, charger, or mobile device may contain symbols,

defined as follows:

Choking Hazards

Your mobile device or its accessories may include detachable

parts, which may present a choking hazard to small children. Keep

your mobile device and its accessories away from small children.

Glass Parts

Some parts of your mobile device may be made of glass. This glass

could break if the product is dropped on a hard surface or receives

a substantial impact. If glass breaks, do not touch or attempt to

remove. Stop using your mobile device until the glass is replaced

by a qualified service center.

Seizures/Blackouts

Some people may be susceptible to epileptic seizures or blackouts

when exposed to flashing lights, such as when playing video

games. These may occur even if a person has never had a previous

seizure or blackout.

If you have experienced seizures or blackouts, or if you have a

family history of such occurrences, please consult with your

Symbol Definition

Important safety information follows.

Do not dispose of your battery or mobile

device in a fire.

Your battery or mobile device may require

recycling in accordance with local laws.

Contact your local regulatory authorities

for more information.

Do not throw your battery or mobile device

in the trash.

Your mobile device contains an internal

lithium ion battery.

Do not let your battery, charger, or mobile

device get wet.

032374o

032376o

032375o

032378o

Li Ion BATT

Listening at full volume to music or voice

through a headset may damage your

hearing.

Symbol Definition

Safety Information

physician before playing video games or enabling a flashing-lights

feature (if available) on your mobile device.

Discontinue use and consult a physician if any of the following

symptoms occur: convulsion, eye or muscle twitching, loss of

awareness, involuntary movements, or disorientation. It is always

a good idea to hold the screen away from your eyes, leave the

lights on in the room, take a 15-minute break every hour, and stop

use if you are very tired.

Caution About High Volume Usage

Listening at full volume to music or voice through a

headset may damage your hearing.

Repetitive Motion

When you repetitively perform actions such as pressing keys or

entering finger-written characters, you may experience occasional

discomfort in your hands, arms, shoulders, neck, or other parts of

your body. If you continue to have discomfort during or after such

use, stop use and see a physician.

Use and Care

To care for your Motorola phone, please keep it away from:

liquids of any kind dust and dirt

Don’t expose your phone to water, rain,

extreme humidity, sweat, or other moisture.

Don’t expose your phone to dust, dirt, sand,

food, or other inappropriate materials.

extreme heat or cold cleaning solutions

Avoid temperatures below -10°C/14°F or

above 45°C/113°F.

To clean your phone, use only a dry soft cloth.

Don’t use alcohol or other cleaning solutions.

microwaves the ground

Don’t try to dry your phone in a microwave

oven.

Don’t drop your phone.

EU Conformance

European Union Directives Conformance Statement

EU Conformance

Hereby, Motorola declares that this product is in compliance with

•

The essential requirements and other relevant provisions

of Directive 1999/5/EC

•

All other relevant EU Directives

The above gives an example of a typical Product Approval Number.

You can view your product’s Declaration of Conformity (DoC) to

Directive 1999/5/EC (to R&TTE Directive) at

www.motorola.com/rtte

. To find your DoC, enter the

product Approval Number from your product’s label in the “Search”

bar on the web site.

Recycling Information

Caring for the Environment by Recycling

When you see this symbol on a Motorola product, do

not dispose the product with household waste.

Recycling Mobile Phones and Accessories

Do not dispose of mobile phones or electrical accessories, such as

chargers or headsets, with your household waste. In some

countries or regions, collection systems are set up to handle

electrical and electronic waste items. Contact your regional

authorities for more details. If collection systems aren’t available,

return unwanted mobile phones or electrical accessories to any

Motorola Approved Service Centre in your region.

essentials

about this guide

This guide shows how to open a menu

feature as follows:

Find it:

eMessages

Create Message

This means that, from the home screen:

Press the center key

to open the

Press the navigation key

to scroll to

eMessages

, and press the center key

to select it.

Press the navigation key

to scroll to

Create Message

, and press the center key

to select it.

SIM card

Caution:

Don’t bend or scratch your SIM card.

Keep it away from static electricity, water, and

dirt.

symbols

This means a feature is

network/subscription dependent

and may not be available in all areas.

Contact your service provider for

more information.

This means a feature requires an

optional accessory.

essentials

Yo u r Subscriber Identity Module (SIM) card

contains personal information like your phone

number and phonebook entries.

To insert and use a

memory card

, see

page 32.

battery

battery installation

essentials

battery charging

New batteries

are not fully

charged. Plug

the battery

charger into

your phone

and an

electrical outlet. Your phone might take

several seconds to start charging the battery.

Your display shows

Charge Complete

when

finished.

Tip:

Relax, you can’t overcharge your battery.

It will perform best after you fully charge and

discharge it a few times.

You can charge your battery by

connecting a cable from your

phone's mini-USB port to a USB

port on a computer. Both your

phone and the computer must be turned on,

and your computer must have the correct

software drivers installed. Cables and

software drivers are available in

Motorola Original data kits, sold separately.

battery tips

Battery life depends on the network, signal

strength, temperature, features, and

accessories you use.

•

Always use Motorola

Original batteries and

chargers. The warranty does

not cover damage caused by

non-Motorola batteries and/or chargers.

•

New batteries or batteries stored for a

long time may take more time to

charge.

essentials

•

When charging your battery, keep it

near room temperature.

When storing your battery, keep it

uncharged in a cool, dark, dry place.

•

Never expose batteries to

temperatures below -10°C (14°F) or

above 45°C (113°F). Always take your

phone with you when you leave your

vehicle.

•

It is normal for batteries to gradually

wear down and require longer charging

times. If you notice a change in your

battery life, it is probably time to

purchase a new battery.

Contact your local recycling center for

proper battery disposal.

Warning:

Never dispose of batteries in a fire

because they may explode.

Before using your phone, read the battery

safety information in the “Safety and General

Information” section included in this guide.

turn it on & off

Caution:

Some phones ask for your SIM card

PIN code when you turn them on. If you enter

an incorrect PIN code three times before the

correct code, your SIM card is disabled, and

your display shows

SIM Blocked

. Contact your

service provider.

To turn on your phone,

press and hold

for

a few seconds or until

the keypad or display

lights up. If prompted,

enter your eight-digit SIM card PIN code

and/or four-digit unlock code.

032375o

essentials

To turn off your phone, press and hold

for

a few seconds.

make a call

Enter a phone number and press

to make

a call.

To “hang up,” close the flip or press

answer a call

Note:

Your phone cannot receive data over an

EDGE network while it is playing videos or

some sound files. The EDGE

status

indicator appears at the top of your display

when you can receive data over an EDGE

network.

When your phone rings and/or vibrates, just

open the flip or press

to answer.

To “hang up,” close the flip or press

store a phone number

You can store a phone number in your

Phonebook

Find it:

nPhonebook

, then press

Options

Create New

Contact

Enter a name and other details for the

phone number. To select a highlighted

item, press the center key

Note:

Phonebook entries stored on the

SIM card only have a

Name

and

Number

. To

make your phone store entries in your

phone memory instead, to the home

screen and press

nPhonebook

, then

press

Options

Setup

Default Storage

Phone

Press the

Done

key to store the number.

To edit or delete a

Phonebook

entry, see

page 65.

essentials

To store an email address from the home

screen, press

nPhonebook

New Entry

Enter the new contact’s name and

information.

Note:

Your phonebook can show you the

entries stored in your phone’s memory or on

your SIM card. To choose which entries you

see, press

nPhonebook

, then press

Options

View

. You can select

Phone &SIM Card

SIM Card

, or

Phone Contacts

call a stored phone

number

Find it:

nPhonebook

Scroll to the phonebook entry.

Shortcut:

In the phonebook, press

keypad keys to enter the first letters of an

entry you want. If necessary, press the

key. To change the way your

phonebook search works, see page 69.

Press

to call the entry.

your phone number

From the home screen, press

to see

your number.

Tip:

Want to see your phone number while

you’re on a call? Press

Options

My Tel. Numbers

You can edit the name and phone

number stored on your SIM card. From

the home screen, press

, select an

entry, press the

View

key, press the

Options

key,

and select

Edit

. If you don’t know your phone

number, contact your service provider.

main attractions

You can do much more with your phone than

make and receive calls!

phone updates

Sometimes, we think of ways to make

your phone’s software faster or more

efficient after you’ve purchased your phone.

You can find out if your phone can be updated,

and register for free update notifications at:

http://www.hellomoto.com/support/

update

Note:

Software updates do not affect your

phonebook entries or other personal entries

or files. If you receive a software update but

choose to install it later, see page 80.

headlines

A few minutes after you turn on your

phone, headlines begin scrolling at the

bottom of your home screen. These headlines

give you news, sports, weather, and other

information.

read headlines

To go to the next or previous headlines:

press

right or left.

To go to the next or previous headline

channels: hold

right or left.

To see the current headline’s details: press

the center key

. While viewing details:

main attractions

•

To go to the next or previous headline’s

details, press

right or left.

•

If a full article is available, you can

press the

key to see it.

change headline settings

In the home screen, press the

Options

key and

select

Headlines

to open your headline options:

options

Headlines

Turn headlines on or off.

Add New

Channels

Open a list of channel

categories. To subscribe to a

channel, select it from a

category or select

Search Channels

to search for it.

Manage My

Channels

Open a list of the channels

to which you subscribe.

Select a channel to see its

details, see its license

information, cancel its

subscription, or remove it

from the list.

Note:

If you cancel a

subscription, the channel

stays in this list until you

remove it or the subscription

period ends.

What Are

Headlines?

Show a description of the

headline service.

Home Keys

Show or hide feature icons

in your home screen, or

change the features for the

soft keys and navigation key

in the home screen.

options

main attractions

Bluetooth™ wireless

Your phone supports Bluetooth wireless

connections. You can connect your phone

with a Bluetooth headset or car kit to make

handsfree calls. You can connect your phone

with a phone or computer that supports

Bluetooth connections to exchange files.

Note:

The use of wireless phones while

driving may cause distraction. Discontinue a

call if you can’t concentrate on driving.

Additionally, the use of wireless devices and

their accessories may be prohibited or

restricted in certain areas. Always obey the

laws and regulations on the use of these

products.

For maximum Bluetooth security

, you

should always connect Bluetooth devices in a

safe, private environment.

turn Bluetooth power on or off

Find it:

wSettings

Connection

Bluetooth Link

Setup

Power

Note:

To extend battery life, use this

procedure to set Bluetooth power to

Off

when

not in use. Your phone will not connect to

Display

Change the headline

animation speed and home

screen text layout.

Connections

Change your settings for

downloading headlines and

see details of your last

connection.

Note:

To manually update

your headline contents,

select

Connection Details

, then

Refresh

options

main attractions

devices until you set Bluetooth power back to

and connect your phone with the device

again.

use a headset or handsfree car

kit

Before you try to connect your phone with

a handsfree device

, make sure the device is

and

ready

in pairing or bonding mode

(see the user’s guide for the device). You can

connect your phone with only one device at a

time.

Find it:

wSettings

Connection

Bluetooth Link

Handsfree

[Look For Devices]

Your phone lists the devices it finds within

range.

Scroll to a device in the list and press the

center key

Press the

Yes

key to connect to the

device.

If necessary, enter the device passkey

(such as

0000

) and press the

key.

When your phone is connected, the Bluetooth

indicator

shows in the home screen.

Shortcut:

When Bluetooth power is on, your

phone can automatically connect to a

handsfree device you have used before. Just

turn on the device or move it near the phone.

Tip:

Want to know more about your headset

or car kit? For specific information about a

device, refer to the instructions that came

with it.

audio player

Note:

You cannot use the audio player with a

USB cable connected to your phone.

main attractions

Your phone can play song files:

Find it:

hMultimedia

Sounds

and select

the file you want to play.

Press

up to play or

pause. Press

down to

stop. Press

right or

left to go forward or back.

To download songs to

your phone, see page 85. To copy files

between your phone and a computer, see

page 33.

Note:

Your phone may not play MP3 files that

have a bit rate higher than 128 kbps. If you try

to download or play one of these files, your

phone might show you an error or ask you to

delete the file.

Tip:

You can listen to tunes on your way. Use

airplane mode to make your phone safe to

use even while you’re on a plane. See

page 86.

take & send a photo

To view, edit, or delete photos you’ve taken,

see page 84.

Your camera lens is on the back of your

phone.

main attractions

Press

hMultimedia

Camera

to see

the camera viewfinder.

Note:

Adjusting the exposure affects the

brightness of both the viewfinder display

and the captured photo.

Press the center key

to take the photo

in the viewfinder. You can:

•

Press the

Store

key to store or send the

photo.

To send the photo in a message, press

Store

Send in Message

, enter message

text, press

Send To

, select a recipient,

press the center key

, then press

Send

•

Press the

Discard

key to delete the photo

and return to the active viewfinder.

Before you capture the photo, you can press

Options

to open the camera menu:

232

Press

up or down to

view camera

settings.

Press left or

right to

change.

Open the

camera menu.

Focus point

OptionsBack

Zoom

Exit the camera.

Camera

Mode (photo

or video)

Camera Light

(on or off)

Resolution

Remaining

photos

Storage

(phone or

memory card)

Timer

options

Go To Pictures

See stored pictures and

photos.

main attractions

self portrait

If you close your phone while the viewfinder

is active, the external display shows the

image. Press the volume keys to zoom, or

press the smart key to capture the image.

Phone Memory /

Memory Card

Choose to see

pictures stored on

your phone or memory

card.

Note:

Your phone stores

pictures on your memory

card unless you select

Phone Memory

Auto-Timed Capture

Set a timer for the camera

to take a photo.

Pictures Setup

Open the setup menu to

adjust photo settings.

options

View Free Space

See how much memory

remains.

Note:

Your service

provider may store some

content in user memory

before you receive the

phone.

options

main attractions

send a stored photo in a

message

Find it:

eMessages

Create Message

Message

, then press

Options

Insert


Scroll to the picture you want and press

Insert

Enter the message text and press

Send To

Scroll to a recipient address and press the

center key

Press the

Send

key to send the message.

record & send a video

To view, edit, or delete videos you’ve

recorded, see page 84.

Your camera lens is on the back of your

phone.

Press

hMultimedia

Video Camera

to see

the video viewfinder.

Note:

You can zoom only before you start

recording. The number of clips remaining is

an estimate.

Zoom

Press

or down to

view camera

settings.

Press left or

right to

change.

Exit the camera.

Open the

video menu.

Focus point

Back Options

Camera

Mode (photo

or video)

Camera Light

(on or off)

Minutes

remaining

Storage

(phone or

memory card)

main attractions

If you want to send your video in a message,

the video length must be set to

MMS

. To set

length, press

Options

Videos Setup

Video Length

Press the center key

to start recording

the video in the viewfinder.

Press the

Stop

key to stop recording the

video. You can:

•

Press the

Options

key to preview, store,

or discard the video.

•

Press the

Send

key to send the

video in a message.

text messages

To create a group mailing list, see page 69.

For more message features, see page 70.

send a text message

A text message can contain text and

pictures, sounds, or other media

objects. You can add multiple pages to a

message, and you can put text and media

objects on each page. You can send a

message to other compatible phones, or to

email addresses.

Find it:

eMessages

Create Message

Message

Press keypad keys to enter text on the

page (for details about text entry, see

page 39).

To i ns e r t a

picture, sound, or other

object

on the page, press

Options

Insert

Select the file type and the file.

To i ns e r t

another page

in the message,

enter text or objects on the current page

main attractions

and press

Options

Insert

New Page

. You can

enter more text and objects on the new

page.

When you finish the message, press the

Send To

key.

Choose one or more people for

Send To

To select a

phonebook entry

, scroll to

the entry and press the center key

Repeat to add other phonebook entries.

enter

a new number or email address,

scroll to

[New Number]

[New Email Address]

and press the center key

send

the message, press the

Send

key.

Before you send a message, press

Options

to choose

Save to Drafts

Abort Message

, or open

Message Options

(such as message

Subject

addresses).

receive a text message

When you receive a message, your

phone plays an alert and the display

shows

New Message

with a message indicator

such as

Press the

Read

key to open the message.

If a multimedia message contains media

objects:

•

Photos, pictures, and animations show

as you read the message.

•

A sound file plays when its slide

shows. Use the volume keys to adjust

the sound volume.

Note:

In a multimedia letter, you may

have to scroll to an indicator in the text

to play a sound file.

•

Attached files are added to the end of

the message. To open an attachment,

main attractions

scroll to the file indicator/filename and

press the

View

key (image),

Play

key

(sound), or

Open

key (phonebook vCard,

datebook vCalendar entry, or unknown

file type).

memory card

You can use a removable memory card

with your phone to store and retrieve

multimedia objects (such as photos and

sounds).

Note:

If you download a copyrighted file and

store it on your memory card, you can use the

file only while your memory card is inserted in

your phone. You cannot send, copy, or change

copyrighted files.

install a memory card

Remove the

battery door.

Slide the top of

the memory

card under the

metal band.

Replace the

battery door.

Do not remove your memory card while your

phone is using it or writing files on it.

see and change memory card

information

To see the

files stored on your memory

card

, open any file list (such as

Pictures

) and

select

Memory Card

. To see files stored on your

phone, select

Phone Memory

instead.

main attractions

To see yo u r

memory card name

and other

information about the card:

Find it:

wSettings

Phone Status

Storage Devices

Press

to scroll to the memory card

that is installed.

Press the

Details

key to see the memory

card information.

Press

Options

to see the

Storage Device

menu,

which lets you

Format

Rename

the memory

card.

connect the memory card to a

computer

You can access your phone’s memory card

with a PC.

Note:

When your phone is connected to a

computer, you can only access the memory

card through the computer.

On your phone:

Press

wSettings

Connection

USB Settings

Default Connection

Memory Card

This directs the USB connection to

your memory card. Attach the

Motorola Original USB cable to the

accessory port on your phone and

to an available USB port on your computer.

Then follow these steps:

On your computer:

Open your “My Computer” window,

where your phone’s memory card shows

as a “Removable Disk” icon.

main attractions

Click on the “Removable Disk” icon to

access the files on your phone’s memory

card.

To store the desired files onto the

memory card, drag and drop them as

follows:

MP3 or AAC files:

> mobile > audio

screen savers:

> mobile > picture

wallpapers:

> mobile > picture

video clips:

> mobile > video

When you finish, remove the device by

selecting the “Safely Remove Hardware”

icon in the system tray at the bottom of

your computer screen. Then select “USB

Mass Storage Devices” and “Stop”.

Select “USB Mass Storage Device” then

“OK”.

On your phone:

To return to

Data

as your USB default

connection, press

wSettings

Connection

USB Settings

Default Connection

DataConnection

cable connections

Yo u r

phone

has a mini-USB

port so you can

connect it to a

computer to

transfer data.

Note:

Motorola Original USB data

cables and supporting software are

sold separately. Check your

computer or hand-held device to

determine the type of cable you need. To

transfer data

between your phone and

main attractions

computer, you must install the software

included with the Motorola Original data kit.

See the data kit user’s guide for more

information. To make

data calls

through a

connected computer, see page 78.

basics

See page 1 for a basic phone diagram.

display

The home screen shows when you turn on

the phone.

Note:

Depending on your service

provider, your home screen might look

different from the one shown. It might show

headlines from your service provider at the

bottom. To change this headline view, press

the

Options

key in your home screen and select

Headlines

To dial a number from the home screen, press

number keys and

Press the center key

to open the menu.

Soft Key Labels show the current soft key

functions. For soft key locations, see page 1.

Clock

Press

right to see

headlines, if

available.

Right Soft

Key Label

Menu Indicator

Left Soft

Key Label

Service Provider

12:00

Text and graphics from your

Service Provider

Setup Home Camera

basics

Status indicators can show at the top of the

home screen:

1 Signal Strength Indicator –

Vertical bars

show the strength of the network

connection. You can’t make or receive

calls when

)

shows.

2 EDGE/GPRS Indicator –

Shows

when your phone is using a

high-speed Enhanced Data for GSM

Evolution (EDGE) or General Packet Radio

Service (GPRS) network connection.

Indicators can include:

3 Data Indicator –

Shows connection

status.

Active

Line

Message

Ring

Style

Battery

Level

Roam

Data

EDGE /

GPRS

Signal

Strength

Service Provider

12:00

Setup Home Camera

Text and graphics from your

Service Provider

= GPRS PDP context

active

= EDGE

= GPRS packet data

available

= secure

packet data

transfer

= unsecure

packet data

transfer

= secure

application

connection

= unsecure

application

connection

= secure

Circuit Switch Data

(CSD) call

= unsecure

CSD call

basics

4Roam Indicator –

Shows

when

your phone is seeking or using a

network outside your home network.

5 PTT / Active Line Indicator –

Shows when you can make and

receive PTT calls (

) or both PTT calls

and Instant Messages (

). When

PTT is not active, this can show

indicate an active phone call, or

indicate when call forwarding is on.

Indicators for dual-line-enabled SIM cards

can include:

6 Message Indicator –

Shows when

you receive a new message.

Indicators can include:

7 Ring Style Indicator –

Shows the ring

style setting.

8 Battery Level Indicator –

Vertical bars

show the battery charge level. Recharge

the battery when your phone shows

Low Battery

= Bluetooth™ connection is active

= line 1

active

= line 1 active, call

forward on

= line 2

active

= line 2 active, call

forward on

= text message

= voice

message

= voice & text message

= IM message

= loud ring

†

= vibrate & ring

= soft ring

}

vibrate then ring

= vibrate

{

= silent

basics

text entry

Some features let you enter text.

Press

in a text entry view to select an

entry mode:

To set your primary and secondary text entry

modes, press

Options

Text Setup

in a text entry

view and select

Primary Setup

Secondary Setup

Tip:

WANT TO SHOUT YOUR MESSAGE?

Press

in a text entry view to change text

case to all capital letters (

), no capitals

(

), or next letter capital (

For indicator

descriptions

see following

section.

Flashing

cursor

indicates

insertion

point.

Press the

Options

key to

open the

submenu.

Press the

Cancel

key to exit

without making changes.

Msg

SMS:3000

Cancel Options

entry modes

Your

Primary

text entry mode can

be set to any iTAP™

or tap

mode.

Your

Secondary

text entry mode can

be set to any iTAP

or tap

mode, or set to

None

if you don’t

want a secondary entry mode.

WNumeric

mode enters numbers only.

[Symbol

mode enters symbols only.

basics

iTAP™ mode

Press

in a text entry view to switch to

iTAP mode. If you don’t see

, press

Options

Text Setup

to set iTAP mode as your

primary or secondary text entry mode.

iTAP mode lets you enter words using one

keypress per letter. The iTAP software

combines your keypresses into common

words, and predicts each word as you enter it.

For example, if you press

7764

your display shows:

•

If you want a different word (such as

Progress

), continue pressing keypad keys

to enter the remaining letters.

•

To enter numbers quickly, press and

hold a number key to temporarily

switch to numeric mode. Press the

Options

Prog ram

Cancel

MsgSMS:2993

Press the

Cancel

key to

cancel the

suggested

word.

Press

right to accept

Program

Press

enter a space

at the cursor.

Hold

up or

down to see a

list of word

options.

Press the

Options

key to open

message options.

basics

number keys to enter the numbers you

want. Enter a space to change back to

iTAP mode.

•

Press

to enter punctuation or other

characters.

tap and tap extended modes

Press

in a text entry view to switch to tap

mode. If you don’t see

, press

Options

Text Setup

to set tap mode as your

primary or secondary text entry mode.

To enter text in

Tap

mode, press a keypad key

repeatedly to cycle through the letters and

number on the key. Repeat this step to enter

each letter. The

Tap Extended

mode works the

same way, but includes more special

characters and symbols.

For example, if you press

one time, your

display shows:

•

The first character of every sentence is

capitalized. If necessary, press

down to change the character to

lowercase before the cursor moves to

the next position.

Options

P age

Send To

Msg

SMS:2995

After you

enter text,

press the

Send To

key to

enter

recipients.

Character

displays at

insertion

point.

After

2 seconds,

your phone

suggests a

word. Press

right to

accept it, or

press

enter a space

at the cursor.

Press the

Options

key to open

message options.

basics

•

Press

to move the flashing cursor

to enter or edit message text.

•

To cancel your message, press

numeric mode

Press

in a text entry view until you see

. Press the number keys to enter the

numbers you want.

symbol mode

Press

in a text entry view until you see

[

Press a keypad key to show its symbols at the

bottom of the display. Scroll to the symbol you

want, then press the center key

volume

Press the volume keys

to:

•

turn off an

incoming call

alert

•

change the

earpiece volume during calls

•

change the ringer volume from the

home screen

Tip:

Sometimes silence really is

golden. That’s why you can quickly set

your ringer to

Vibrate

Silent

by holding

the down volume key while you are in

the home screen.

basics

navigation key

Press the

navigation key

up,

down, left, or right to scroll

to items in the display.

When you scroll to

something, press the center key

to select

it.

smart key

The smart key gives you another way to do

things. For example, when you scroll to a

menu item, you can press the smart key to

select it (instead of pressing the

center key

). The smart key usually does

the same thing as pressing the

center key

. To find the smart key, see

page 1. To change what the smart key does in

the home screen, see page 76.

external display

When your phone is closed, the external

display shows the time, date, status

indicators, and notifications for incoming calls

and other events. For a list of phone status

indicators, see page 37.

handsfree speaker

You can use your phone’s handsfree speaker

to make calls without holding the phone to

your ear.

During a call, press the

Options

key and select

Spkrphone On

to turn the handsfree speaker on.

Your display shows

Spkrphone On

until you turn it

off or end the call.

Note:

The handsfree speaker won’t work

when your phone is connected to a handsfree

car kit or headset.

basics

codes & passwords

Your phone’s four-digit

unlock code

originally set to

1234

. The six-digit

security

code

is originally set to

000000

. If your

service provider didn’t change these codes,

you should change them:

Find it:

wSettings

Security

New Passwords

You can also change your

SIM PIN

or call

barring passwords.

If you forget your unlock code:

At the

Enter Unlock Code

prompt, try entering 1234 or the

last four digits of your phone number. If that

doesn’t work, press

and enter your

six-digit security code instead.

If you forget other codes:

If you forget your

security code, SIM PIN code, PIN2 code, or

call barring password, contact your service

provider.

lock & unlock phone

You can lock your phone to keep others from

using it. To lock or unlock your phone, you

need the four-digit unlock code.

manually lock

your phone:

Press

wSettings

Security

Phone Lock

Lock Now

automatically lock

your phone whenever

you turn it off: Press

wSettings

Security

Phone Lock

Automatic Lock

Note:

You can make emergency calls on a

locked phone (see page 52). A locked phone

still rings or vibrates for incoming calls or

messages,

but you need to unlock it to

answer

customize

ring style

Each ring style profile uses a different set of

sounds or vibrations for incoming calls and

other events. Here are the profiles you can

choose:

The ring style profile’s indicator shows at the

top of your home screen. To choose your

profile:

Find it:

wSettings

Ring Styles

Style:

style name

Shortcut:

In the

home screen

, press the

volume keys up or down to quickly change

your ring style profile. With your

phone

closed

, press a volume key to see your ring

style profile, press the smart key to change it,

then press a volume key to store the change.

change alerts in a ring style

You can change the alerts for incoming calls

and other events. Your changes are saved in

the current ring style profile.

Find it:

wSettings

Ring Styles

>style

Detail

Note:

Style represents the current ring style.

You can’t set an alert for the

Silent

ring style

setting.

yLoud |Vibrate }Vibe Then Ring

zSoft †Vibe &Ring {Silent

customize

Scroll to

Calls

(or

Line 1

Line 2

for dual-line

phones), then press the

Change

key to

change it.

Scroll to the alert you want, then press

the center key

Press the

Back

key to save the alert setting.

time & date

Your phone can automatically update your

time zone, time and date. It uses the time and

date for the datebook.

synchronize

the time zone, time,

and date with the network: Press

wSettings

Initial Setup

Time and Date

Autoupdate

Time &Time Zone

. If you don’t want

your phone to automatically update your time

zone and date, choose

Time Only

instead.

manually

set the time zone, time, and

date, turn off

Autoupdate

, then: Press

wSettings

Initial Setup

Time and Date

Time Zone

,time or date. To jump to a city in

the time zone list, enter the first letter of its

name by pressing keypad keys.

Tip:

To choose three time zones for easier

access, press

ÉTools

World Clock

When you open

World Clock

, you can press the

Options

key to see time zones on a map.

To ch o o s e a n

analog or digital

clock for your

home screen, press

wSettings

Personalize

Home Screen

Clock

Note:

If your home screen shows

headlines from your service provider, it

uses a digital clock. To choose an analog

clock, you must turn off the headlines. Press

the

Options

key in your home screen and select

Headlines

customize

wallpaper

Set a photo, picture, or animation as a

wallpaper (background) image in your home

screen.

Find it:

wSettings

Personalize

Wallpaper

screen saver

Set a photo, picture, or animation as a screen

saver. The screen saver shows when the flip

is open and no activity is detected for a

specified time.

Tip:

This feature helps save your screen, but

not your battery. To extend battery life, turn off

the screen saver.

Find it:

wSettings

Personalize

Screen Saver

themes

A phone theme is a group of image and

sound files that you can apply to your

phone. Most themes include a wallpaper

options


Press

up or down to select a

picture, or select

None

for no

wallpaper.

Layout

Select

Center

to center the image in

the display,

Tile

to repeat the

image across the display, or

Fit-to-screen

to stretch the image

across the display.

options


Press

up or down to select a

picture or animation, or select

None

for no screen saver.

Delay

Select the length of inactivity

before the screen saver shows.

customize

image, screen saver image, and ring tone.

Your phone may come with some themes,

and you can download more.

apply

a theme, press

hMultimedia

Themes

> theme.

download

a theme, see page 85.

delete

a theme, press

hMultimedia

Themes

, scroll to the theme, and

press

Options

Delete

Delete All

Note:

You can delete only downloaded

themes.

display appearance

To choose a phone

skin

that sets the look and

feel of your phone’s display: Press

wSettings

Personalize

Skin

To set your display

brightness

: Press

wSettings

Initial Setup

Brightness

To save battery life, your keypad

backlight

turns off when you’re not using your phone.

The backlight turns back on when you open

the flip or press any key. To set how long your

phone waits before the backlight turns off:

Press

wSettings

Initial Setup

Backlight

Note:

To turn the backlight on or off for Java™

applications, press

wSettings

JavaSettings

App Backlight

To save battery life, the

display

can turn off

when you’re not using your phone. The

display turns back on when you open the flip

or press any key. To set how long your phone

waits before the display turns off:

Press

wSettings

Initial Setup

Display Timeout

customize

answer options

You can use different ways to answer an

incoming call. To turn on or turn off an answer

option:

Find it:

wSettings

In-Call Setup

Answer Options

options

Multi-Key

Answer by pressing any key.

Open to Answer

Answer by opening the flip.

calls

To make and answer calls, see page 20.

turn off a call alert

You can press the volume keys to turn off a

call alert before answering the call.

recent calls

Your phone keeps lists of incoming and

outgoing calls, even for calls that didn’t

connect. The most recent calls are listed first.

The oldest calls are deleted as new calls are

added.

Shortcut:

Press

from the home screen to

see a list of dialed calls.

Find it:

sRecent Calls

, press

select >

Received Calls

Dialed Calls

Scroll to a call. A

next to a call means the

call connected.

•

To call the number, press

•

To see call details (like time and date),

press the center key

•

To see the

Last Calls Menu

, press

Options

This menu can include:

options

Store

Create a phonebook entry

with the number in the

No.

field.

Store

does not appear if

the number is already

stored.

calls

redial

Press

from the home screen to see a

list of recent calls.

Scroll to the entry you want to call, then

press

If you hear a

busy signal

and you see

Call Failed

, you can press

or the

Retry

key to redial the number. When the call goes

through, your phone rings or vibrates one

time, shows

Redial Successful

, and connects the

call.

Delete

Delete the entry.

Delete All

Delete all entries in the list.

Hide ID /

Show ID

Hide or show your caller ID

for the next call.

Send Message

Open a new text message

with the number in the

field.

Add Digits

Add digits after the number.

Attach Number

Attach a number from the

phonebook or recent calls

lists.

Send Tones

Send the number to the

network as DTMF tones.

This option shows only

during a call.

options

Talk then Fax

Talk and then send a

fax in the same call

(see page 79).

options

calls

return a call

Your phone keeps a record of your

unanswered calls, and shows

X Missed Calls

where

is the number of missed calls.

Press the

View

key to see the received

calls list.

Scroll to the call you want to return, then

press

caller ID

Calling line identification (caller ID)

shows the phone number for an

incoming call in your external and internal

displays.

Your phone shows the caller’s name and

picture when they’re stored in your

phonebook, or

Incoming Call

when caller ID

information isn’t available.

You can set your phone to play a different

ringer ID for an entry stored in your

phonebook (see page 66).

To show or hide

your phone number

from

the next person you call, enter the phone

number and press

Options

Hide ID/Show ID

emergency calls

Your service provider programs one or more

emergency phone numbers, such as 911 or

112, that you can call under any

circumstances, even when your phone is

locked or the SIM card is not inserted.

Note:

Emergency numbers vary by country.

Your phone’s preprogrammed emergency

number(s) may not work in all locations, and

sometimes an emergency call cannot be

calls

placed due to network, environmental, or

interference issues.

Press the keypad keys to dial the

emergency number.

Press

to call the emergency number.

voicemail

Your network stores the voicemail

messages you receive. To listen to your

messages, call your voicemail number.

Note:

Your service provider may include

additional information about using this

feature.

When you

receive

a voicemail message, your

phone shows the voicemail message

indicator

and

New Voicemail

. Press the

Call

key

to listen to the message.

check

voicemail messages:

Find it:

eMessages

Voicemail

Your phone may prompt you to store your

voicemail phone number. If you don’t know

your voicemail number, contact your service

provider.

Note:

You can’t store a

(pause),

(wait), or

(number) character in this number. If you want

to store a voicemail number with these

characters, create a phonebook entry for it.

Then, you can use the entry to call your

voicemail.

push to talk (PTT)

Push to Talk (PTT) lets you talk walkie-talkie

style with other PTT subscribers. You can talk

to one person or a group.

PTT and the other related features

indicated are network and subscription

dependent features, and are not available in all

calls

areas. PTT connectivity requires

PTT-compatible phones.

Note:

To lock your PTT key or turn PTT on or

off, see page 58.

make a PTT call

When

shows at the top of your home

screen, you can make and receive PTT calls.

To make a PTT call:

Enter a PTT subscriber’s phone number in

your home screen, or select a contact or

group from a list:

•

PTT Contacts

(press the PTT key to open

the list)

Note:

If you change your

Open To

setting,

your PTT key does not open the

contacts list (see page 58).

•

PTT Quick Group

(press the PTT key and

Options

Quick Group

) This lets you select

more than one contact for the call.

•

PTT Groups

(press the PTT key and

Options

Go To Groups

)

Hold the PTT key and speak after you hear

the tone. Release the PTT key to let

others speak.

To speak during a PTT call

, hold your

PTT key and speak after the tone. Only

one person can speak at a time.

To end the call

, press

. If nobody

speaks for 20 seconds, the call ends

(actual timing varies between

PTT servers).

To send a PTT alert

instead of a standard PTT

call, scroll to a PTT contact in

PTT Contacts

and

press the

Alert

key. The contact’s phone rings

or vibrates, and the contact can speak first. If

calls

the contact does not respond, the call ends.

You cannot send alerts to groups.

answer a PTT call

Note:

Your phone cannot receive PTT calls

while it is recording videos, and may not

receive PTT calls while it is playing videos or

some sound files. The PTT indicator

appears at the top of your display when you

can receive PTT calls.

When you receive a PTT call

, you hear a

tone or alert followed by conversation from

the caller.

• To speak

when the caller stops

speaking, hold your PTT key and speak

after the tone. Only one person can

speak at a time.

• To end the call

, press

If you change your

My Answer Mode

setting to

Manual

, your phone does not automatically

answer as described (see page 58).

When you receive a PTT alert

, press the

PTT key and speak after the tone. You can

also press the

Ignore

key to cancel the call.

Your phone shows

Missed Call

if you miss a PTT

alert. It does not show

Missed Call

when you

miss a standard PTT call unless you set

My Answer Mode

Manual

(see page 58).

send a picture with push to

view (PTV)

You can send a picture with PTT. You can

either send a picture in a PTT call, or you can

open the picture and start a call.

Note:

You cannot send pictures in group calls

or while someone is speaking. You can send

calls

pictures only to phones with push to view

(PTV) capability.

To send a picture during a PTT call

, press

Options

, then select

Camera

to capture a new

picture or

Pictures

to send a stored picture.

To send a stored picture

, press

hMultimedia

Pictures

, scroll to the

picture, and press the PTT key.

To take a photo and send it

, press

hMultimedia

Camera

Capture

the photo,

and press the PTT key.

Your phone plays a tone when the picture

transfer completes. To speak after the picture

transfers, hold the PTT key and speak after

the tone.

PTT contacts and groups

You can store PTT

Contacts

to make one-to-one

calls, or you can store PTT

Groups

to make

group calls.

To store a contact

, press

PTT key

, then

Options

Add New Contact

. Enter the contact’s

Name

and phone number (

No.

), then press the

Done

key. Your network stores the contact and your

phone returns to the

PTT Contacts

list with the

new contact shown.

To create a group of contacts

that you can

call at the same time, press

PTT key

, then

Options

Go To Groups

, then

Options

Add New Group

Enter the group’s

Name

and select the

Members

then press the

Done

key. Your network stores

the group and your phone returns to the

PTT Groups

list with the new group shown.

calls

To see PTT contacts

, press the PTT key.

Scroll to a contact and press

Options

View

Edit

Delete

it.

To see PTT groups

, press the PTT key and

Options

Go To Groups

. Scroll to a group and press

Options

View

Delete

it. You cannot edit a

group, but you can delete it and create a new

one with the members you want.

Icons in the PTT contact and group lists

indicate if someone is online (

) or offline

(

). They also tell you if a contact is

blocked (

block

a contact, scroll to the contact and

press

Options

Edit

Block Mode

. To unblock

the contact, scroll to it and press the

Unblock

key.

To set an

online alert

to tell you when a

contact comes online, scroll to the contact

and press

Options

Enable Online Alert

. You can turn

online alert tones on or off in your

PTT Setup

menu (see page 58).

To refresh the contact or group list from your

network, press

Options

Refresh List

To see only your frequently used contacts or

groups, press

Options

Frequently Used

Highlighted

Contact

View PTT Menu

options.

Press

scroll down to

other options.

PTT Contacts

John Smith

Lisa Owens

Adda Thomas

Jack Bradshaw

Mary Smith

Carlos Emrys

Dave Thompson

Lisa Owens

PTT Menu Alert

Send a PTT alert

to the

highlighted

contact.

calls

PTT settings

turn PTT on or off

from your home screen,

press

wSettings

PTT Settings

PTT Service

Off

To prevent accidental PTT calls, you can set

your phone to

lock the PTT key

automatically

when you haven’t pressed it for a few minutes

and your phone is closed. Press

wSettings

Security

Lock PTT Key

and

select how long your phone should wait

before it locks the key. To unlock the key, hold

it for two seconds or open the phone. The

PTT key unlocks when you receive a PTT call.

You can change your PTT menu and call

preferences.

Find it:

Press

PTT key

. In the

PTT Menu

, select

PTT Setup

Personalize

options

Open To

From the home screen, the

PTT key can open the PTT

menu (

PTT Menu

), or your

contacts list sorted by name

(

Contacts

), or most recent call

(

Last Contact Call

Sort by

Sort your contacts and

groups by

Name

, online

Status

or call

Frequency

My Answer Mode

Set the mode for incoming

PTT calls to

Manual

(press the

PTT key to answer),

Auto-Accept

(standard mode

that accepts all calls), or

Do Not Disturb

(accepts no

calls).

Tone Volume

Set the volume for the tone

you hear when it is your turn

to speak.

calls

PTT Speaker

Turn the speakerphone

Off

for PTT calls.

Set Online Alert

Tone

You can set an online alert to

tell you when a contact or

group comes online (scroll

to the entry in your

PTT Contacts

PTT Groups

and

press

Options

Enable Online Alert

This setting tells your phone

whether to play these alert

tones (

) or not (

Off

options

other features—advanced calling

other features

advanced calling

features

1-touch dial

To call phonebook entries with

Speed No.

1 through 9, hold the key for the entry (

through

Note:

To speed dial phonebook entries 10

and above, see “speed dial” on page 61.

To add a new phonebook entry, see

page 20. To edit the

Speed No.

for a

phonebook entry, see page 68.

set 1-touch dial list

You can set 1-touch dial to call the

entries in your phone’s phonebook or

Fixed Dial list: Press

wSettings

InitialSetup

Speed Dial

Phone

Fixed Dial

features

other features—advanced calling

speed dial

Speed dial a phonebook entry:

Enter the speed dial number, press

then press

Note:

To 1-touch dial phonebook entries 1

through 9, see “1-touch dial” on page 60.

To add a new phonebook entry, see

page 20. To edit the

Speed No.

for a

phonebook entry, see page 68.

You can set speed dial to call the

entries in your phone memory

phonebook or your Fixed Dial list: Press

wSettings

InitialSetup

Speed Dial

Phone Memory

Fixed Dial

Tip:

If you forget Aunt Mildred’s speed dial

number, press

nPhonebook

, scroll to

her entry, and press the center key

features

set speed dial list

You can set speed dial to call the

entries in your phone memory

phonebook or your Fixed Dial list: Press

wSettings

InitialSetup

Speed Dial

Phone Memory

Fixed Dial

attach a phone number

Dial an area code or prefix for a

phonebook number, then press

Options

Attach Number

features

other features—advanced calling

notepad

The last number you entered is stored in

the notepad. You can use the notepad to

“jot down” a number during a call for later

use. To see the notepad:

Press

sRecent Calls

, press the

Options

key, then >

Notepad

•

To call the number, press

•

To create a phonebook entry with the

number in the

No.

field, press the

Store

key.

•

To open the

Dialing Menu

to attach a

number or insert a special character,

press

Options

features

international calls

If your phone service includes

international dialing, press and hold

insert your local international access code

(indicated by

). Then, press the keypad

keys to dial the country code and phone

number.

hold a call

Press

Options

Hold

to put all active calls on

hold.

mute a call

Press the

Mute

key (if available) or

Options

Mute

to put all active calls on mute.

features

other features—advanced calling

call waiting

When you’re on a call, you’ll hear an

alert if you receive a second call.

Press

to answer the new call.

•

To switch between calls, press the

Switch

key.

•

To connect the two calls, press the

Link

key.

•

To end the call on hold, press

Options

End Call On Hold

To turn the call waiting feature on or off,

press

wSettings

In-Call Setup

Call Waiting

Off

features

conference call

During a call:

Dial next number, press

, press the

Link

key.

transfer a call

During a call:

Options

Transfer

, dial transfer number, press

call forwarding

Set up or cancel call forwarding:

wSettings

Call Forward

restrict calls

Restrict outgoing or incoming calls:

wSettings

Security

Restrict Calls

features

other features—advanced calling

call barring

Restrict outgoing or incoming calls:

wSettings

Security

Call Barring

TTY calls

Set up your phone for use with an

optional TTY device:

wSettings

Initial Setup

TTY Setup

change phone line

If you have a dual-line-enabled SIM

card, you can change your line to make and

receive calls from your other phone

number.

wSettings

Phone Status

Active Line

features

fixed dial

When you turn on fixed dialing, you

can call only numbers stored in the fixed

dial list.

Turn fixed dialing on or off:

wSettings

Security

Fixed Dial

Use the fixed dial list:

ÉTools

Dialing Services

Fixed Dial

quick dial

Dial preprogrammed phone numbers:

ÉTools

Dialing Services

Quick Dial

features

other features—phonebook

phonebook

DTMF tones

Activate DTMF tones:

wSettings

InitialSetup

DTMF

To send DTMF tones during a call, just

press number keys or scroll to a number in

the phonebook or recent calls lists and

press

Options

Send Tones

features

edit or delete a phonebook entry

Edit a number stored in the phonebook:

nPhonebook

, scroll to the phonebook

entry, and press

Options

. You can select

Edit Contact

Delete

, or other options.

Shortcut:

In the phonebook, press keypad

keys to enter the first letters of an entry you

want. If necessary, press the

key. To

change the way your phonebook search

works, see page 69.

other features—phonebook

record voice name for a phonebook

entry

When creating a phonebook entry, scroll to

Voice Name

and press the

Record

key. Press the

Record

key again and say the entry’s name

(within two seconds). When prompted,

press the

Record

key and repeat the name.

Note:

The

Voice Name

option isn’t available for

entries stored on the SIM card.

voice dial a phonebook entry

Voice dial a number stored in the

phonebook:

ÉTools

Dialing Services

Voice Dial

When prompted, say the entry’s voice

name (within two seconds).

features

set ringer ID for a phonebook entry

Assign a ring alert (ringer ID) to an entry:

nPhonebook

> entry, then press

Options

Edit Contact

Ringer ID

> ringer name

Note:

The

Ringer ID

option isn’t available for

entries stored on the SIM card.

Activate ringer IDs:

wSettings

Ring Styles

> style

Detail

Ringer IDs

set picture ID for a phonebook entry

Assign a photo or picture to show when you

receive a call from an entry:

nPhonebook

> entry, then press

Options

Edit Contact


> picture name

Note:

The


option isn’t available for

entries stored on the SIM card.

features

other features—phonebook

set picture ID view for phonebook

Show entries as a text list, or with picture

caller ID photos:

nPhonebook

, then press

Options

Setup

View by

> view name

set category for a phonebook entry

nPhonebook

> entry, then press

Options

Edit Contact

Category

>category name

You can show

All

entries, entries in a

predefined category (

Business

Personal

General

VIPs

), or entries in a category you create.

features

create a new category

nPhonebook

, then press

Options

Manage Contacts

Edit Categories

[New Category]

Enter the category name, and select its

members from your phonebook entries.

edit a category

nPhonebook

, then press

Options

Manage Contacts

Edit Categories

Scroll to the category name and press

Options

Edit Category

You can edit the category name, members,

ringer ID, or picture. Your phone uses the

ringer ID and picture whenever you receive

calls from numbers in the category.

features

other features—phonebook

set speed number for a phonebook entry

Set the

Speed No.

for an entry:

nPhonebook

, scroll to the entry, and

press

Options

Edit Contact

Speed No.

To speed dial an entry, enter the speed dial

number, press

, then press

. To use

1-touch dial, see page 60.

features

set primary number or address for a

phonebook entry

Set the primary number for an entry with

multiple numbers:

nPhonebook

, scroll to the entry, press

Options

Set Primary

> number or address

Note:

The

Set Primary

option isn’t available for

entries stored on the SIM card.

Tip:

Primary

number view mode, you can

still peek at other numbers stored for the

same name. Scroll to the name and press

left or right to see the other numbers.

features

other features—phonebook

create group mailing list

You can put several phonebook entries in a

group mailing list, then send a message to

the list. To create a list:

nPhonebook

, then press

Options

New

Message List

You can select the list name as an address

for multimedia messages.

Note:

Message List

cannot include entries

stored on the SIM card.

sort phonebook list

Set the order in which entries are listed:

nPhonebook

, then press

Options

Setup

Sort by

>sort order

You can sort the phonebook list by

First Name

Last Name

features

change phonebook search

In the phonebook, press keypad keys to

enter the first letters of an entry you want.

If necessary, press the

key.

To change how this search works:

nPhonebook

, then press

Options

Setup

Search Method

Jump To

Find

Jump To

jumps directly to the entry, and

Find

waits for you to press the

key.

copy one phonebook entry

Copy an entry from the phone to the SIM

card, or from the SIM card to the phone:

nPhonebook

, scroll to the entry, press

Options

Copy

Entries

features

other features—messages

messages

send phonebook entry in a text message

Send a phonebook entry in a text or email

message:

nPhonebook

, scroll to the entry, press

Options

Send Contact

send phonebook entry in a multimedia

message

Send a phonebook entry in a multimedia

message:

nPhonebook

, scroll to the entry, press

Options

Share Phonebook Entry

MultimediaMsg

send phonebook entry to another device

Send a phonebook entry to another phone,

computer, or device:

nPhonebook

, scroll to the entry, press

Options

Share Phonebook Entry

features

print phonebook entry over

Bluetooth™ connection

You can use a Bluetooth wireless

connection to send a phonebook entry from

your phone to a printer.

nPhonebook

Scroll to the entry you want to print, and

press

Options

You cannot print a

Mailing List

. For more about

Bluetooth connections, see page 24.

features

send email

eMessages

Create Message

New Email

features

other features—messages

send voice message

eMessages

Create Message

New Voice Msg

To record the voice message, press the

Record

key, speak, then press the

Stop

key.

Your phone inserts the voice recording into

a message and lets you enter email

addresses or phone numbers to receive the

message.

use a multimedia template

Open a multimedia message with

preloaded animations:

eMessages

Create Message

MMS Templates

features

read and manage messages

eMessages

Message Inbox

Icons next to each message indicate if it is

read

or unread

. Icons can also

indicate if the message is locked

urgent

, or low priority

↓

, or if it has an

attachment

Forward

Lock

, or

Delete

a message,

scroll to it and press

Options

read and manage email

eMessages

Email Msgs

Forward

Lock

, or

Delete

a message,

scroll to it and press

Options

features

other features—messages

store message objects

Go to a multimedia message page, or

scroll to an object in a message, then:

Options

Store

print message over Bluetooth™

connection

You can use a Bluetooth wireless

connection to send a message from your

phone to a printer.

eMessages

Message Inbox

Email Msgs

Outbox

, or

Drafts

Scroll to the message you want to print and

press

Options

You cannot print message

Templates

. For

more about Bluetooth connections, see

page 24.

features

store text messages on your SIM

card

To store incoming text messages on your

SIM card, press:

eMessages

, then press

Options

Message Setup

Text Msg Setup

Store To

SIM

features

other features—instant messaging

instant messaging

edit email settings

You can edit the settings for your

Email connections. To use email, you need

to store your email

User ID

and

Password

eMessages

, then press

Options

Email Msg Setup

Account Settings

If you have more than one email account,

select an account to edit.

Your phone shows a list of email settings.

Here is where you store your email

User ID

and

Password

Note:

To create a new account, select

New Entry

in the

Account Settings

list. Your display

shows a folder for each email account under

eMessages

Email Msgs

features

browser messages

Read messages received by your

micro-browser:

eMessages

Browser Msgs

info services

Read subscription-based information

services messages:

eMessages

Info Services

features

ãIM

Select an IM account, or select

[New Account]

to set up an IM account.

features

other features—personalizing

personalizing

ãIM

, press the

Options

key, then

Offline Settings

Tur n o n

Auto-Login

to start the IM login

whenever you select

. Turn on

Power-On Login

to start the IM login whenever

you turn on your phone.

set IM ring style

Select a ring or vibration for new IM

messages and contact alerts.

wSettings

Ring Styles

> style

Detail

features

language

Set menu language:

wSettings

InitialSetup

Language

scroll

Set the scroll bar to

Up/Down

Wrap Around

menu lists:

wSettings

InitialSetup

Scroll

text marquee

Set the speed for scrolling text in your

display:

wSettings

InitialSetup

Text Marquee

other features—personalizing

activate ringer IDs

Activate ringer IDs assigned to phonebook

entries and categories:

wSettings

Ring Styles

> style

Detail

Ringer IDs

ring volume

wSettings

Ring Styles

> style

Detail

Ring Volume

keypad volume

wSettings

Ring Styles

> style

Detail

Key Volume

reminders

Set reminder alerts for messages that you

receive:

wSettings

Ring Styles

> style

Detail

Reminders

features

headline view

If your home screen shows scrolling

headlines from your service provider, you

can turn them on or off:

the

Options

key in your home screen and

select

Headlines

menu view

Show the main menu as graphic icons or as

a text-based list:

wSettings

Personalize

Main Menu

View

main menu

Reorder your phone’s main menu:

wSettings

Personalize

Main Menu

Reorder

features

other features—call times & costs

call times & costs

Network connection time

is the elapsed

time from the moment you connect to your

show/hide menu icons

Show or hide menu feature icons in

the home screen:

wSettings

Personalize

Home Screen

Home Keys

Icons

Note:

This option is not available if your

home screen shows scrolling headlines

from your service provider.

change home keys

Change features for the soft keys,

navigation key, and smart key in the home

screen:

wSettings

Personalize

Home Screen

Home Keys

Note:

This option is not available if your

home screen shows scrolling headlines

from your service provider.

features

master reset

Reset all options

except

unlock code,

security code, and lifetime timer:

wSettings

InitialSetup

Master Reset

master clear

Caution:

Master clear

erases all

information you have entered

(including

phonebook and datebook entries)

and

content you have downloaded

(including

photos and sounds) stored in your phone’s

memory. After you erase the information,

you can’t recover it.

wSettings

InitialSetup

Master Clear

features

other features—handsfree

service provider's network to the moment

you end the call by pressing

. This time

includes busy signals and ringing.

The amount of network connection time

you track on your resettable timer may not

equal the amount of time for which you

are billed by your service provider. For

billing information, contact your service

provider.

handsfree

Note:

The use of wireless phones while

driving may cause distraction. Discontinue a

call if you can’t concentrate on driving.

Additionally, the use of wireless devices and

their accessories may be prohibited or

restricted in certain areas. Always obey the

laws and regulations on the use of these

products.

features

call times

Show call timers:

sRecent Calls

, press the

Options

key,

then >

Call Times

in-call timer

Show time or cost information during

a call:

wSettings

In-Call Setup

In-Call Timer

call cost

Show call cost trackers:

sRecent Calls

, press the

Options

key,

then >

Call Cost

features

other features—data & fax calls

data & fax calls

To connect your phone with a USB cable, see

page 34.

features

speakerphone

Activate the speakerphone during a

call:

Press the

Speaker

key (if available, or

Options

Spkrphone On

auto answer

(car kit or headset)

Automatically answer calls when

connected to a car kit or headset:

wSettings

Car Settings

Headset

Auto Answer

voice dial

(headset)

Enable voice dial with headset

send/end key:

wSettings

Headset

Voice Dial

auto handsfree

(car kit)

Automatically route calls to a car kit

when connected:

wSettings

Car Settings

Auto Handsfree

features

send data or fax

Connect your phone to the device,

then place the call through the device

application.

features

other features—data & fax calls

receive data or fax

Connect your phone to the device,

then answer the call through the device

application.

talk then fax

Connect your phone to the device,

enter fax number, press

Options

Talk then Fax

then press

to make the call.

features

using sync

You can call an Internet server and

synchronize your phonebook and datebook

entries with the server.

set up

an Internet sync partner, press

wSettings

Connection

MOTOSYNC

Sync

[New Entry]

. Enter the server details,

including

Server URL

(you can omit

http://

) and

DataPath

(the folder below the URL where

your data is stored).

synchronize files

with a partner you set

up, select the partner from the list in

wSettings

Connection

MOTOSYNC

Sync

features

other features—network

network

using Exchange ActiveSync

You make your phone automatically

synchronize its datebook entries with an

Internet server.

set up

an ActiveSync partner, press

wSettings

Connection

MOTOSYNC

Exchange

, press the

Options

key, then >

Setup

Enter the server details, including

Server Name

Domain

, and the

Web Session

to use.

To set up a

Web Session

, see page 85.

schedule

synchronization, press

wSettings

Connection

MOTOSYNC

Exchange

, press the

Options

key, then

Auto Sync Setup

. Enter the time and days you

want your phone to synchronize.

features

network settings

See network information and adjust

network settings:

wSettings

Network

software update

Your service provider can send

updated phone software over the air to your

phone. When your phone receives a

software update, you can choose to install it

later. To install the software update later:

wSettings

Phone Status

Software Update

Install Now

other features—personal organizer

personal organizer

features

set alarm

ÉTools

Alarm Clock

turn off alarm

When an alarm happens:

To turn off the alarm, press the

Disable

key or

. To set an eight-minute delay, press the

Snooze

key.

Note:

The

Snooze

key is available only if the

phone is already powered on when the

alarm sounds.

add new datebook event

ÉTools

Datebook

, scroll to the day,

press

, press

Options

New

see datebook event

See or edit event details:

ÉTools

Datebook

, scroll to the day,

press

, press the

View

key

event reminder

When an event reminder happens:

To see reminder details, press the

View

key.

To close the reminder, press the

Exit

key.

send datebook event to another device

Send a datebook event to another phone,

computer, or device:

ÉTools

Datebook

, scroll to the day,

press

, scroll to the event, press

Options

Send

features

other features—personal organizer

print datebook month, week, or

day over Bluetooth™ connection

You can use a Bluetooth wireless

connection to send a datebook month,

week, or day from your phone to a printer.

ÉTools

Datebook

Go to the month, week, or day view and

press

Options

For more about Bluetooth connections, see

page 24.

features

create voice record

Create a voice record:

ÉTools

Voice Record

When prompted, speak into the phone.

Note:

Recording phone calls is subject to

varying state and federal laws regarding

privacy and recording of conversations.

Always obey the laws and regulations on

the use of this feature.

play voice record

Play back a voice record:

ÉTools

Voice Record

> voice record

calculator

ÉTools

Calculator

features

other features—security

security

fun & games

For basic information on the camera, see

page 26.

currency converter

ÉTools

Calculator

, then press

Options

Exchange Rate

Enter exchange rate, press the

key, enter

amount, and press

Options

Convert Currency

features

SIM PIN

Caution:

If you enter an incorrect PIN code

three times before the correct code, your

SIM card is disabled and your display shows

SIM Blocked

Lock or unlock the SIM card:

wSettings

Security

SIM PIN

features

lock feature

wSettings

Security

Lock Application

manage certificates

Enable or disable Internet access

certificates stored on your phone:

wSettings

Security

Certificate Mgmt

Certificates are used to verify the identity

and security of Web sites when you

download files or share information.

features

other features—fun & games

features

view, delete, or manage pictures

Manage photos, pictures, and

animations:

hMultimedia

Pictures

view, delete, or manage video clips

hMultimedia

Videos

hear, delete, or manage sounds

Manage ring tones and music that you have

downloaded or composed:

hMultimedia

Sounds

Note:

Your phone cannot receive PTT calls

or data over an EDGE network while it is

playing some sound files. Indicators appear

at the top of your display when you can

receive PTT

or EDGE

data.

create ring tones

Create ring tones that you can use with

your phone:

hMultimedia

Sounds

[New iMelody]

start micro-browser

Just press

features

other features—fun & games

download objects from Web page

Download a picture, sound, or other

object from a Web page:

Press

, go to the page that links to the

file, scroll to the link, and select it.

Note:

Normal airtime and/or carrier usage

charges apply.

To activate downloaded copyrighted files,

press

ÉTools

Activation List

>file type > file. You can see file’s

Status

Type

Activation

, and

Counts Remaining

Web sessions

A Web Session stores settings that

your phone uses to access the Internet. To

select or create a Web session:

áWeb Access

Web Sessions

features

download game or application

You can download a Java™ game or

application the same way you download

pictures or other objects:

Press

, go to the page that links to the

file, scroll to the link, and select it.

Note:

Normal airtime and/or carrier usage

charges apply.

start game or application

Start a Java™ game or application:

QGames &Apps

, scroll to the game or

application, press the center key

Note:

To install and run games stored on

your memory card, press

QGames &Apps

[Install New]

features

other features—fun & games

airplane mode

You can switch your phone to airplane mode

to prevent it from communicating with the

network. This lets you use games or other

applications while you are on an airplane,

without interfering with airplane

communications.

wSettings

Airplane Mode

You can make the airplane mode option

appear whenever you turn on your phone:

wSettings

Airplane Mode

Prompt At Power Up

features

service and repairs

If you have questions or need assistance,

we're here to help.

Go to

www.motorola.com/consumer/support

where you can select from a number of

customer care options. You can also contact

the Motorola Customer Support Center at

1-800-331-6456 (United States),

1-888-390-6456 (TTY/TDD United States for

hearing impaired), or 1-800-461-4575

(Canada).

88a

SAR Data

Specific Absorption Rate Data

SAR Da ta

This model meets international guidelines for

exposure to radio waves.

Your mobile device is a radio transmitter and receiver. It is

designed not to exceed the limits for exposure to radio waves

recommended by international guidelines. These guidelines were

developed by the independent scientific organization ICNIRP and

include safety margins designed to assure the protection of all

persons, regardless of age and health.

The guidelines use a unit of measurement known as the Specific

Absorption Rate, or SAR. The ICNIRP SAR limit for mobiles devices

used by the general public is 2 W/kg and the highest SAR value for

this device when tested at the ear was ___ W/kg.

As mobile

devices offer a range of functions, they can be used in other

positions, such as on the body as described in this user guide.

this case, the highest tested SAR value is ___ W/kg.

As SAR is measured utilizing the device’s highest transmitting

power, the actual SAR of this device while operating is typically

below that indicated above. This is due to automatic changes to

the power level of the device to ensure it only uses the minimum

level required to reach the network.

While there may be differences between the SAR levels of various

phones and at various positions, they all meet the governmental

requirements for safe exposure. Please note that improvements to

this product model could cause differences in the SAR value for

later products; in all cases, products are designed to be within the

guidelines.

The World Health Organization has stated that present scientific

information does not indicate the need for any special precautions

for the use of mobile devices. They note that if you want to reduce

your exposure then you can do so by limiting the length of calls or

using a “hands-free” device to keep the mobile phone away from

the head and body.

Additional Information can be found on the websites of the World

Health Organization (

http://www.who.int/emf

) or

Motorola, Inc.

(

http://www.motorola.com/rfhealth

1. The tests are carried out in accordance with international guidelines for

testing. The limit incorporates a substantial margin for safety to give

additional protection for the public and to account for any variations in

measurements. Additional related information includes the Motorola

testing protocol, assessment procedure, and measurement uncertainty

range for this product.

2. Please see the Safety and General Information section about body worn

operation.

88b

Specific Absorption Rate Data

The model wireless phone meets the government’s requirements

for exposure to radio waves.

Your wireless phone is a radio transmitter and receiver. It is designed and

manufactured not to exceed limits for exposure to radio frequency (RF)

energy set by the Federal Communications Commission (FCC) of the U.S.

Government and by the Canadian regulatory authorities. These limits are

part of comprehensive guidelines and establish permitted levels of RF

energy for the general population. The guidelines are based on standards

that were developed by independent scientific organizations through

periodic and thorough evaluation of scientific studies. The standards

include a substantial safety margin designed to assure the safety of all

persons, regardless of age or health.

The exposure standard for wireless mobile phones employs a unit of

measurement known as the Specific Absorption Rate, or SAR. The SAR

limit set by the FCC and by the Canadian regulatory authorities is 1.6 W/

Tests for SAR are conducted using standard operating positions

accepted by the FCC and by Industry Canada with the phone transmitting

at its highest certified power level in all tested frequency bands. Although

the SAR is determined at the highest certified power level, the actual SAR

level of the phone while operating can be well below the maximum value.

This is because the phone is designed to operate at multiple power levels

so as to use only the power required to reach the network. In general, the

closer you are to a wireless base station, the lower the power output.

Before a phone model is available for sale to the public in the U.S. and

Canada, it must be tested and certified to the FCC and Industry Canada

that it does not exceed the limit established by each government for safe

exposure. The tests are performed in positions and locations (e.g., at the

ear and worn on the body) reported to the FCC and available for review by

Industry Canada. The highest SAR value for this model phone when

tested for use at the ear is 1.39 W/kg, and when worn on the body, as

88c

described in this user guide, is 0.39 W/kg. (Body-worn measurements

differ among phone models, depending upon available accessories and

regulatory requirements).

While there may be differences between the SAR levels of various phones

and at various positions, they all meet the governmental requirements for

safe exposure. Please note that improvements to this product model

could cause differences in the SAR value for later products; in all cases,

products are designed to be within the guidelines.

Additional information on Specific Absorption Rates (SAR) can be found

on the Cellular Telecommunications & Internet Association (CTIA) Web

site:

http://www.phonefacts.net

or the Canadian Wireless Telecommunications Association (CWTA) Web

site:

http://www.cwta.ca

In the United States and Canada, the SAR limit for mobile phones used by

the public is 1.6 watts/kg (W/kg) averaged over one gram of tissue. The

standard incorporates a substantial margin of safety to give additional

protection for the public and to account for any variations in measurements.

2. A

The SAR information includes the Motorola testing protocol, assessment

procedure, and measurement uncertainty range for this product.

Warranty

Motorola Limited Warranty for the United States and

Canada

War r an t y

What Does this Warranty Cover?

Subject to the exclusions contained below, Motorola, Inc. warrants

its telephones, pagers, messaging devices, and consumer and

professional two-way radios (excluding commercial, government

or industrial radios) that operate via Family Radio Service or

General Mobile Radio Service, Motorola-branded or certified

accessories sold for use with these Products (“Accessories”) and

Motorola software contained on CD-ROMs or other tangible media

and sold for use with these Products (“Software”) to be free from

defects in materials and workmanship under normal consumer

usage for the period(s) outlined below. This limited warranty is a

consumer's exclusive remedy, and applies as follows to new

Motorola Products, Accessories and Software purchased by

consumers in the United States or Canada, which are accompanied

by this written warranty:

Products and Accessories

Products Covered Length of Coverage

Products and

Accessories

defined above, unless

otherwise provided for

below.

One (1) year

from the date of

purchase by the first consumer

purchaser of the product unless

otherwise provided for below.

Decorative

Accessories and

Cases.

Decorative

covers, bezels,

PhoneWrap™ covers

and cases.

Limited lifetime warranty

for the

lifetime of ownership by the first

consumer purchaser of the product.

Monaural Headsets.

Ear buds and boom

headsets that transmit

mono sound through a

wired connection.

Limited lifetime warranty

for the

lifetime of ownership by the first

consumer purchaser of the product.

Warranty

Exclusions

Normal Wear and Tear.

Periodic maintenance, repair and

replacement of parts due to normal wear and tear are excluded

from coverage.

Batteries.

Only batteries whose fully charged capacity falls below

80% of their rated capacity and batteries that leak are covered by

this limited warranty.

Abuse & Misuse.

Defects or damage that result from:

(a) improper operation, storage, misuse or abuse, accident or

neglect, such as physical damage (cracks, scratches, etc.) to the

surface of the product resulting from misuse; (b) contact with

liquid, water, rain, extreme humidity or heavy perspiration, sand,

dirt or the like, extreme heat, or food; (c) use of the Products or

Accessories for commercial purposes or subjecting the Product or

Accessory to abnormal usage or conditions; or (d) other acts which

are not the fault of Motorola, are excluded from coverage.

Use of Non-Motorola Products and Accessories.

Defects or

damage that result from the use of Non-Motorola branded or

certified Products, Accessories, Software or other peripheral

equipment are excluded from coverage.

Unauthorized Service or Modification.

Defects or damages

resulting from service, testing, adjustment, installation,

maintenance, alteration, or modification in any way by someone

other than Motorola, or its authorized service centers, are

excluded from coverage.

Altered Products.

Products or Accessories with (a) serial

numbers or date tags that have been removed, altered or

obliterated; (b) broken seals or that show evidence of tampering;

non-Motorola housings, or parts, are excluded from coverage.

Communication Services.

Defects, damages, or the failure of

Products, Accessories or Software due to any communication

service or signal you may subscribe to or use with the Products

Accessories or Software is excluded from coverage.

Software

Consumer and

Professional

Two-Way Radio

Accessories.

Ninety (90) days

from the date of

purchase by the first consumer

purchaser of the product.

Products and

Accessories that are

Repaired or

Replaced.

The balance of the original

warranty or for ninety (90) days

from the date returned to the

consumer, whichever is longer.

Products Covered Length of Coverage

Software.

Applies only to physical

defects in the media that embodies

the copy of the software (e.g.

CD-ROM, or floppy disk).

Ninety (90) days

from

the date of purchase.

Warranty

Exclusions

Software Embodied in Physical Media.

No warranty is made

that the software will meet your requirements or will work in

combination with any hardware or software applications provided

by third parties, that the operation of the software products will be

uninterrupted or error free, or that all defects in the software

products will be corrected.

Software NOT Embodied in Physical Media.

Software that is

not embodied in physical media (e.g. software that is downloaded

from the internet), is provided “as is” and without warranty.

Who Is Covered?

This warranty extends only to the first consumer purchaser, and is

not transferable.

What Will Motorola Do?

Motorola, at its option, will at no charge repair, replace or refund

the purchase price of any Products, Accessories or Software that

does not conform to this warranty. We may use functionally

equivalent reconditioned/refurbished/pre-owned or new Products,

Accessories or parts. No data, software or applications added to

your Product, Accessory or Software, including but not limited to

personal contacts, games and ringer tones, will be reinstalled. To

avoid losing such data, software and applications please create a

back up prior to requesting service.

How to Obtain Warranty Service or

Other Information

You will receive instructions on how to ship the Products,

Accessories or Software, at your expense, to a Motorola

Authorized Repair Center. To obtain service, you must include: (a) a

copy of your receipt, bill of sale or other comparable proof of

purchase; (b) a written description of the problem; (c) the name of

your service provider, if applicable; (d) the name and location of the

installation facility (if applicable) and, most importantly; (e) your

address and telephone number.

USA Phones

1-800-331-6456

Pagers

1-800-548-9954

Two-Way Radios and Messaging Devices

1-800-353-2729

Canada All Products

1-800-461-4575

TTY

1-888-390-6456

For

Accessories

and

Software

, please call the telephone

number designated above for the product with which they are

used.

Warranty

What Other Limitations Are There?

ANY IMPLIED WARRANTIES, INCLUDING WITHOUT LIMITATION

THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS

FOR A PARTICULAR PURPOSE, SHALL BE LIMITED TO THE

DURATION OF THIS LIMITED WARRANTY, OTHERWISE THE

REPAIR, REPLACEMENT, OR REFUND AS PROVIDED UNDER THIS

EXPRESS LIMITED WARRANTY IS THE EXCLUSIVE REMEDY OF

THE CONSUMER, AND IS PROVIDED IN LIEU OF ALL OTHER

WARRANTIES, EXPRESS OR IMPLIED. IN NO EVENT SHALL

MOTOROLA BE LIABLE, WHETHER IN CONTRACT OR TORT

(INCLUDING NEGLIGENCE) FOR DAMAGES IN EXCESS OF THE

PURCHASE PRICE OF THE PRODUCT, ACCESSORY OR SOFTWARE,

OR FOR ANY INDIRECT, INCIDENTAL, SPECIAL OR

CONSEQUENTIAL DAMAGES OF ANY KIND, OR LOSS OF

REVENUE OR PROFITS, LOSS OF BUSINESS, LOSS OF

INFORMATION OR DATA, SOFTWARE OR APPLICATIONS OR

OTHER FINANCIAL LOSS ARISING OUT OF OR IN CONNECTION

WITH THE ABILITY OR INABILITY TO USE THE PRODUCTS,

ACCESSORIES OR SOFTWARE TO THE FULL EXTENT THESE

DAMAGES MAY BE DISCLAIMED BY LAW.

Some states and jurisdictions do not allow the limitation or

exclusion of incidental or consequential damages, or

limitation on the length of an implied warranty, so the

above limitations or exclusions may not apply to you. This

warranty gives you specific legal rights, and you may also

have other rights that vary from state to state or from one

jurisdiction to another.

Laws in the United States and other countries preserve for

Motorola certain exclusive rights for copyrighted Motorola

software such as the exclusive rights to reproduce and distribute

copies of the Motorola software. Motorola software may only be

copied into, used in, and redistributed with, the Products

associated with such Motorola software. No other use, including

without limitation disassembly of such Motorola software or

exercise of the exclusive rights reserved for Motorola, is

permitted.

WHO Information

Information from the World Health Organization

WHO Inf ormati on

Present scientific information does not indicate the need for any

special precautions for the use of mobile phones. If you are

concerned, you may want to limit your own or your children’s RF

exposure by limiting the length of calls or by using handsfree

devices to keep mobile phones away from your head and body.

Source: WHO Fact Sheet 193

Further information:

http://www.who.int./peh-emf

index

accessories 16, 77

accessory connector port 1

activation list 85

active line indicator 38

active line, changing 64

airplane mode 86

alarm clock 81

alert

set 42, 45

turn off 42, 50

animation 84

answer a call 20, 49

attach a number 51, 61

audio player 25

backlight 48

battery 17, 18

extending battery life 18

battery indicator 38

battery life, extending 24, 47,

Bluetooth connection

datebook entry, printing

datebook entry, sending

description 24

messages, printing 72

phonebook entries,

printing 70

phonebook entries,

sending 70

brightness 48

browser messages 73

browser. See micro-browser

cables 34

calculator 82

call

answer 20, 49

end 20

make 20

call barring 44, 64

call forward indicator 38

call forwarding 63

call timers 77

index

call waiting 63

caller ID 51, 52, 66

camera 26

car kit 77

categories 67

center key 1, 43

center select key 16

certificate management 83

channels for headlines 23

clock 46

codes 44

conference call 63

copyrighted files, activating

costs, tracking 77

data call 78, 79

data indicator 37

date, setting 46

datebook 81

dial a phone number 20, 64

dialed calls 50

digital audio 25

display 2, 24, 36, 48, 75

download media objects 72,

downloaded files, activating

drafts folder 31

DTMF tones 51, 65

earpiece volume 42

EDGE indicator 37

reading and managing 71

sending 70

settings 73

emergency number 52

end a call 20

end key 1, 20

Enter Unlock Code message

external display 28, 43

fax call 51, 78, 79

fixed dial 64

flip 20, 49

forward calls 63

games 85

GPRS indicator 37

group mailing list 69

handsfree speaker 43

headlines 22, 36, 75

headset 77

headset jack 1

index

hold a call 62

home screen 2, 36, 75, 76

IM 73

in-call indicator 38

Incoming Call message 52

information services 73

instant messaging. See IM

international access code 62

iTAP text entry mode 40

Java applications 85

keypad 49, 75

language 74

linking. See Bluetooth

connection

lock

application 83

phone 44

SIM card 83

Low Battery message 38

make a call 20

master clear 76

master reset 76

memory card 32

menu 2, 16, 36, 74, 75

menu icons 75, 76

message 71, 72

message indicator 31, 38

message reminders 75

micro-browser 73, 84, 85

Missed Calls message 52

MMS, defined 30

MP3 sound files 25, 26

multimedia message 30, 71,

music 84

mute a call 62

navigation key 1, 16, 43

network settings 80

notepad 62

number. See phone number

numeric entry mode 42

1-touch dial 60, 68

open to answer 49

optional accessory 16

optional feature 16

index

pairing. See Bluetooth

connection

passwords. See codes

personalize 74

phone number 21, 64

phonebook 51, 60, 61, 65,

photo 26, 84

picture 84

picture ID 52, 66

PIN code 19, 44, 83

PIN2 code 44

power key 1, 19, 20

PTT 53

calls, answering 55

calls, making 54

contacts and groups 56

icons 57

indicator 38

locking key 58

Quick Groups 54

sending pictures 55

settings 58

turning on or off 58

PTV 55

Push to Talk. See PTT

quick dial 64

received calls 50

recent calls 50

redial 51

reminders 75

restrict calls 63

return a call 52

ring style indicator 38

ring style, setting 42, 45

ring tone 84

ringer ID 52, 66, 75

ringer volume 42, 75

roam indicator 38

safety information 8

screen saver 47

SCREEN3. See headlines

scrolling 74

security code 44

send key 1, 20

signal strength indicator 37

SIM 72

SIM Blocked message 19,

SIM card 16, 19, 44, 83

skin 48

smart key 43, 76

soft keys 1, 36, 76

software update 80

speakerphone 77

speed dial 61

index

store your number 21

symbol entry mode 42

synchronizing 79, 80

tap text entry mode 41

telephone number. See

phone number

text entry 39

text marquee 74

text message 71, 72

theme 47

time zone 46

time, setting 46

timers 77

transfer a call 63

TTY device 64

turn on/off 19

unlock

application 83

phone 19, 44

SIM card 83

unlock code 44

USB cables 34

video clip 84

videos 29

voice dial 66, 78

voice message 71

voice name, recording 66

voice record 82

voicemail 53

voicemail message indicator

38, 53

volume 42, 75

wallpaper 47

warranty 89

Web pages 84

Web sessions 85

your phone number 21

U.S. patent Re. 34,976

Motorola Mobility T56GT1 Dual-Band GSM/ EDGE Transceiver with Bluetooth User Manual

Motorola Mobility LLC Dual-Band GSM/ EDGE Transceiver with Bluetooth

Exhibit 8 Users Manual

Navigation menu

Namespaces

Views

Navigation
