39Photos & videos

View & Share Photos & videos

From the home screen, touch > My Gallery.

Flick left and right to show folders. Touch a folder to

show its photos or videos, then touch a thumbnail

image to open, share, or delete it.

Tip: From the viewfinder, you can touch the thumbnail

in the top right to open your last photo or video.

•To zoom in, touch

the screen with

two fingers and

then drag them

apart. To zoom out,

drag your fingers

together.

•To send or post

the photo or video, touch Menu > Share.

•To delete the photo or video, touch Menu > Delete.

•To set a photo as your wallpaper or a contact photo,

touch More > Set as.

•To crop or rotate a photo, touch More.

•To play a video, touch .

Tip: Turn the phone sideways for a widescreen view.

40 Music

Music

when music is what you need...

Quick start: Music

From the home screen, touch > Music, then

choose a song to play it:

•To adjust volume, use the phone’s volume keys.

11:04

Music Artist

Album Title

Song Title

0:26 3:27

Open Playlist

Shuffle On/Off

Repeat Off/All/Current

Music Controls

Total Song Time

Progress Bar

41Music

•When a song is playing, you touch Menu to add

it to a playlist or use it as a Use it as a ringtone.

To edit, delete, or rename playlists, touch

>Music touch the Playlists tab, then touch and

hold the playlist name.

•To hide the player and use other apps,

touch Home . Your music keeps playing. To

return to the player, flick down the status bar and

touch .

Tip: For quick music player controls, touch and hold

an empty spot in your home screen, then choose

Widget > Music.

•To stop the player, touch .

•Before a flight, turn off network and wireless

connections so that you can keep listening to music:

Press and hold Power > Flight Mode.

Note: When you select flight Mode, all wireless

services are disabled. You can then turn Wi-Fi and/or

Bluetooth back on, if permitted by your airline. Other

wireless voice and data services (such as calls and

text messages) remain off in flight Mode.

Emergency calls to your region's emergency

number (e.g., 911) can still be made.

You can use your phone’s 3.5mm OMTP headset jack

to connect wired headphones, or go wireless with

“Bluetooth™ Devices” on page 47.

42 Music

To listen to FM radio stations, plug in a 3.5mm OMTP

headset and touch > FM Radio. Your phone uses

the headset wire as the radio antenna.

Music Files

Note: Copyright—do you have the right? Always follow

the rules. See “Content Copyright” in your legal and

safety information.

To get songs for your music player, you can download

them from online services or copy them from your

computer. Your music player can play these file

formats: MP3, M4A, AAC, ACC+, MIDI, WAV, or OGG

Vorbis.

Note: Your phone does not support any DRM

protected files.

To copy files from your computer to your phone, you

can use “Cable Connection” on page 50 or

“Bluetooth™ Devices” on page 47.

To save a CD as files on your computer (“rip” the CD),

you can use a program like Microsoft™ Windows™

Media Player. First, make sure you change the format

to MP3 (under Rip > Format in Windows Media

Player).

43personalize

personalize

add your personal touch

Quick Start: personalize

From the home screen, touch Menu > Settings

>Sound or Display.

Display settings

Brightness

Screen timeout

All window animations are shown

Animation

Auto-rotate screen

Adjust the delay before the screen

automatically turns off

Sound settings

General

Incoming calls

Only in Silent mode

Vibrate

Volume

Silent mode

Silence all sounds except media &

alarms

Phone ringtone

Notifications

Notification ringtone

Choose separate volume

settings for incoming calls,

media, alarms, and notifications.

Call & Message Notifications

Turn on or off menu animations.

44 personalize

•To choose a ring tone or vibration for incoming

calls and messages, touch Menu > Settings

>Sound, then choose Phone ringtone,

Notification ringtone, or Vibrate.

•To set the volume for your ringtone, media, and

alarm, touch Menu > Settings > Sound

>Volume.

Tip: Press the volume keys to

change the ringer volume (in the

home screen), or the earpiece

volume (during a call).

•To hear dialpad sounds, touch

Menu > Settings > Sound >

Audible touch tones.

•To hear menu selection sounds, touch Menu

>Settings > Sound > Audible selection

•To set a new wallpaper, touch and hold an empty

spot on the home screen, then touch Wallpapers.

•To set display brightness, touch Menu

>Settings > Display > Brightness

•Many apps can rotate the screen when you rotate

your phone. To turn this on or off, touch Menu

>Settings > Display > Auto-rotate screen.

•Screen animations make your menus look

smoother. To turn animations on or off, touch

Menu > Settings > Display > Animation

Volume

Keys

45personalize

wallpaper

To set a new wallpaper, touch and hold an empty spot

on the home screen, then touch Wallpapers.

Language & region

Set your menu language and region:

Find it: Menu > Settings > Language &

keyboard > Select language

Date & time

Set date, time, time zone, and formats:

Find it: Menu > Settings > Date & time

46 Connections

Connections

home, office, or hotspot

Quick Start: Connections

From the home screen, touch Menu > Settings

>Wireless & networks, then Bluetooth settings or

Wi-Fi settings.

Wi-Fi networks

Wi-Fi settings

Notify me when an open network is

available

Network notification

(Your network)

Add Wi-Fi network

Wi-Fi

Bluetooth devices

Bluetooth settings

(Your Phone)

Device name

Scan for devices

Make device discoverable

Discoverable

Bluetooth

Pair with this device

(Nearby Bluetooth Device)

Turn Bluetooth power on & scan,

or turn off.

Change your phone’s Bluetooth

device name.

Turn Wi-Fi power on & scan, or

turn off.

Re-scan.

Connect a device found by the

scan.

Connect a device found by the

scan.

47Connections

•To connect Bluetooth devices, touch Menu

>Settings > Wireless & networks > Bluetooth

settings > Scan for devices (or Bluetooth, if it is

off). Touch a device that your phone found, to

connect it.

•To connect Wi-Fi networks, touch Menu

>Settings > Wireless & networks > Wi-Fi

settings (then touch Wi-Fi, if it is off). Touch a

network that your phone found, to connect it.

•To use a cable connection, connect your phone’s

micro USB port to a standard USB port on your

computer, then use a computer program to transfer

files to and from your phone’s memory card. Your

phone supports microSD cards up to 32GB.

On your phone, flick down the status bar and touch

to enable your phone’s memory card (optional

accessory).

You can download your phone’s driver files from

www.motorola.com/support.

Bluetooth™ Devices

Note: This feature requires an optional accessory.

You can connect your phone to other Bluetooth

devices for handsfree calls, file transfers, and more:

1Make sure the device you are pairing with is in

discoverable mode.

48 Connections

2Touch Menu > Settings > Wireless &

networks > Bluetooth settings.

3Tou ch Scan for devices (Bluetooth if it is turned

off). Your phone scans, and lists nearby devices.

4Touch a device to connect.

5If necessary, touch Pair or enter the device passkey

(like 0000) to connect to the device. When the

device is connected, the Bluetooth connected

indicator appears in the status bar.

To reconnect a device you’ve connected before, just

turn it on.

To disconnect a device, just turn it off.

Note: Using a mobile device or accessory while

driving may cause distraction and may be illegal.

Always obey the laws and drive safely.

Tip: Touch and hold an empty spot on your home

screen, then choose Widgets > Power Control for a

widget that lets you turn on or off Wi-Fi, Bluetooth,

Use GPS satellites, and more.

Note: Your phone's Bluetooth features and Bluetooth

power levels are not allowed for outdoor operation in

France. To avoid unlawful interference with radio

signals, do not use the Bluetooth features in France

unless you are indoors.

49Connections

Wi-Fi Networks

You can connect to Wi-Fi networks for even faster

Internet access and to download data:

1Touch Menu > Settings > Wireless &

networks > Wi-Fi settings.

2Touch Menu > Scan (or touch Wi-Fi, if it is off.

Your phone scans for nearby networks.

To see your phone’s MAC address or other Wi-Fi

details, touch Menu > Advanced.

3Touch a network to connect.

4If necessary, enter details from from the network

administrator. When your phone is connected, the

Wi-Fi indicator appears in the status bar.

When power is on and your phone finds a network

you’ve used, it automatically reconnects and shows

in the status bar.

Tip: Touch and hold an empty spot on your home

screen, then choose Widgets > Power Control for a

widget that lets you turn on or off Wi-Fi, Bluetooth,

Use GPS satellites, and more.

Note: Your phone's Wi-Fi features and power levels

are not allowed for outdoor operation in France. To

avoid unlawful interference with radio signals, do not

use the Wi-Fi features in France unless you are

indoors.

50 Connections

Cable Connection

You can use a cable connection to transfer songs,

pictures, or other files between your phone and

computer. You will need a:

•Microsoft™ Windows™ PC or Apple™

Macintosh™.

•data cable with a standard USB connector on one

end and a micro USB connector on the other end.

•microSD memory card (up to 32GB) inserted in your

phone, as shown in “Assemble & charge” on page 5.

Tip: To see the available memory on your memory

card, from the home screen touch Menu >

Settings > Storage.

To connect your phone and computer with a cable:

1Insert a memory card in

your phone, then connect

your phone’s micro USB

port to a USB port on your

computer.

Note: If your computer asks

for your phone’s driver files, you can download them

from www.motorola.com/support.

2Your phone should show in the status bar. Flick

down the status bar, touch the to enable your

phone’s memory card.

51Connections

3On your computer, open a program (like Windows™

Media Player for music files, or

Microsoft™ Windows™ Explorer to drag and drop

other files) and use it to transfer your files.

52 Security

Security

help keep your phone safe

Quick start: Security

From the home screen, touch Menu > Settings

>Location & security.

•To set a lock Pattern, PIN, or Password that you

must enter whenever you wake up the screen,

touch Menu > Settings > Location & security

>Set up screen lock. Follow the prompts to enter

and confirm the pattern, PIN, or password.

Device administration

Lock screen with a pattern, PIN, or password

Set up screen lock

Show password as you type

Turn off ephemeris auto download

Visible passwords

Credential storage

Screen unlock

Passwords

Add or remove device administrators

Select device administrators

Location & security settings

Set up SIM card lock

SIM card lock

Show password letters and

numbers when you enter them

(rather than ***).

Choose a number code that you

must enter when you turn on

your phone.

Set a lock pattern, PIN, or

password that you must enter

whenever you wake up the

screen.

53Security

Note: You can make emergency calls on a locked

phone (“Contacts” on page 22). A locked phone still

rings, but you need to unlock it to answer.

•To se t a SIM card PIN that you must enter when

you turn on your phone, touch Menu > Settings

> Location & security > Set up SIM card lock >

Lock SIM card. Enter your SIM PIN code. To change

your code, choose Change SIM PIN.

Caution: If you enter an incorrect PIN code three

times, your phone locks your SIM card. To unlock it,

you need a PUK code from your service provider.

Reset

To reset your phone to factory settings and erase all

the data on your phone, touch Menu > Settings >

Privacy > Factory data reset > Reset phone.

Warning: All downloaded apps and user data on your

phone will be deleted. Data on your memory card will

not be deleted.

54 Troubleshooting

Troubleshooting

we’re here to help

Crash recovery

In the unlikely event that your phone stops responding

to touchs and key presses, try a quick reset. Remove

the back cover and battery (“Assemble & charge” on

page 5), then replace and turn on your phone as usual.

Service & Repairs

If you have questions or need assistance, we're here

to help.

Go to www.motorola.com/support, where you can

select from a number of customer care options. You

can also contact the Motorola Customer Support

Center at 1-800-331-6456 (United States),

1-888-390-6456 (TTY/TDD United States for hearing

impaired), or 1-800-461-4575 (Canada).

Safety, Regulatory & Legal

Battery Use & Safety

Important: Handle and store batteries properly to avoid injury or damage.

Most

battery issues arise from improper handling of batteries, and particularly from the

continued use of damaged batteries.

DON’Ts

• Don’t disassemble, crush, puncture, shred, or otherwise attempt to change

the form of your battery.

• Don’t let the mobile device or battery come in contact with liquids.*

Liquids

can get into the mobile device’s circuits, leading to corrosion.

• Don’t allow the battery to touch metal objects.

If metal objects, such as jewelry,

stay in prolonged contact with the battery contact points, the battery could become

very hot.

• Don’t place your mobile device or battery near a heat source.*

High

temperatures can cause the battery to swell, leak, or malfunction.

• Don’t dry a wet or damp battery with an appliance or heat source

, such as a

hair dryer or microwave oven.

DOs

• Do avoid leaving your mobile device in your car in high temperatures.*

• Do avoid dropping the mobile device or battery.*

Dropping these items,

especially on a hard surface, can potentially cause damage.*

• Do contact your service provider or Motorola if your mobile device or battery

has been damaged by dropping, liquids or high temperatures.

* Note:

Always make sure that the battery compartment and any connector covers are

closed and secure to avoid direct exposure of the battery to any of these conditions, even

if your product information states that your

mobile device

can resist damage from these

conditions.

Important: Motorola recommends you always use Motorola-branded batteries

and chargers for quality assurance and safeguards.

Motorola’s warranty does not

cover damage to the mobile device caused by non-Motorola batteries and/or chargers. To

help you identify authentic Motorola batteries from non-original or counterfeit batteries

(that may not have adequate safety protection), Motorola provides holograms on its

batteries. You should confirm that any battery you purchase has a “Motorola Original”

hologram.

If you see a message on your display such as

Invalid Battery

Unable to Charge

, take the following steps:

•

Remove the battery and inspect it to confirm that it has a “Motorola Original”

hologram;

•

If there is no hologram, the battery is not a Motorola battery;

•

If there is a hologram, replace the battery and try charging it again;

•

If the message remains, contact a Motorola authorized service center.

Warning:

Use of a non-Motorola battery or charger may present a risk of fire, explosion,

leakage, or other hazard.

Proper and safe battery disposal and recycling:

Proper battery disposal is not only

important for safety, it benefits the environment. You can recycle your used batteries in

many retail or service provider locations. Additional information on proper disposal and

recycling can be found at

www.motorola.com/recycling

Disposal:

Promptly dispose of used batteries in accordance with local

regulations. Contact your local recycling center or national recycling

organizations for more information on how to dispose of batteries.

Warning:

Never dispose of batteries in a fire because they may explode.

Battery Charging

Notes for charging your product’s battery:

•

During charging, keep your battery and charger near room temperature for efficient

battery charging.

•

New batteries are not fully charged.

•

New batteries or batteries stored for a long time may take more time to charge.

•

Motorola batteries and charging systems have circuitry that protects the battery from

damage from overcharging.

Third Party Accessories

Use of third party accessories, including but not limited to batteries, chargers, headsets,

covers, cases, screen protectors and memory cards, may impact your mobile device’s

performance. In some circumstances, third party accessories can be dangerous and may

void your mobile device’s warranty. For a list of Motorola accessories, visit

www.motorola.com/products

032375o

Driving Precautions

Responsible and safe driving is your primary responsibility when behind the wheel of a

vehicle. Using a mobile device or accessory for a call or other application while driving

may cause distraction. Using a mobile device or accessory may be prohibited or restricted

in certain areas, always obey the laws and regulations on the use of these products.

While driving, NEVER:

•

Type or read texts.

•

Enter or review written data.

•

Surf the web.

•

Input navigation information.

•

Perform any other functions that divert your attention from driving.

While driving, ALWAYS:

•

Keep your eyes on the road.

•

Use a handsfree device if available or required by law in your area.

•

Enter destination information into a navigation device

before

driving.

•

Use voice activated features (such as voice dial) and speaking features (such as

audible directions), if available.

•

Obey all local laws and regulations for the use of mobile devices and accessories in

the vehicle.

•

End your call or other task if you cannot concentrate on driving.

Remember to follow the “Smart Practices While Driving” in this guide and at

www.motorola.com/callsmart

(in English only).

Seizures/Blackouts

Some people may be susceptible to epileptic seizures or blackouts when exposed to

flashing lights, such as when playing videos or games. These may occur even if a person

has never had a previous seizure or blackout.

If you have experienced seizures or blackouts, or if you have a family history of such

occurrences, please consult with your physician before playing videos or games or

enabling a flashing-lights feature (if available) on your mobile device.

Discontinue use and consult a physician if any of the following symptoms occur:

convulsion, eye or muscle twitching, loss of awareness, involuntary movements, or

disorientation. It is always a good idea to hold the screen away from your eyes, leave the

lights on in the room, take a 15-minute break every hour, and stop use if you are tired.

Caution About High Volume Usage

Warning:

Exposure to loud noise from any source for extended periods of

time may affect your hearing. The louder the volume sound level, the less

time is required before your hearing could be affected. To protect your

hearing:

•

Limit the amount of time you use headsets or headphones at high

volume.

•

Avoid turning up the volume to block out noisy surroundings.

•

Turn the volume down if you can’t hear people speaking near you.

If you experience hearing discomfort, including the sensation of pressure or fullness in

your ears, ringing in your ears, or muffled speech, you should stop listening to the device

through your headset or headphones and have your hearing checked.

For more information about hearing, see our website at

direct.motorola.com/hellomoto/nss/AcousticSafety.asp

(in English only).

Repetitive Motion

When you repetitively perform actions such as pressing keys or entering finger-written

characters, you may experience occasional discomfort in your hands, arms, shoulders,

neck, or other parts of your body. If you continue to have discomfort during or after such

use, stop use and see a physician.

Children

Keep your mobile device and its accessories away from small children.

These

products are not toys and may be hazardous to small children. For example:

•

A choking hazard may exist for small, detachable parts.

•

Improper use could result in loud sounds, possibly causing hearing injury.

•

Improperly handled batteries could overheat and cause a burn.

Similar to a computer, if a child does use your mobile device, you may want to monitor

their access to help prevent exposure to inappropriate apps or content.

Glass Parts

Some parts of your mobile device may be made of glass. This glass could break if the

product receives a substantial impact. If glass breaks, do not touch or attempt to remove.

Stop using your mobile device until the glass is replaced by a qualified service center.

Operational Warnings

Obey all posted signs when using mobile devices in public areas.

Potentially Explosive Atmospheres

Areas with potentially explosive atmospheres are often, but not always, posted and can

include fueling areas, such as below decks on boats, fuel or chemical transfer or storage

facilities, or areas where the air contains chemicals or particles, such as grain dust, or

metal powders.

When you are in such an area, turn off your mobile device, and do not remove, install, or

charge batteries unless it is a radio product type especially qualified for use in such areas

as “Intrinsically Safe” (for example, Factory Mutual, CSA, or UL approved). In such areas,

sparks can occur and cause an explosion or fire.

Symbol Key

Your battery, charger, or mobile device may contain symbols, defined as follows:

Symbol Definition

Important safety information follows.

Do not dispose of your battery or mobile device in a fire.

Your battery or mobile device may require recycling in accordance

with local laws. Contact your local regulatory authorities for more

information.

Do not dispose of your battery or mobile device with your household

waste. See “Recycling” for more information.

032374o

032376o

032375o

Radio Frequency (RF) Energy

Exposure to RF Energy

Your mobile device contains a transmitter and receiver. When it is ON, it receives and

transmits RF energy. When you communicate with your mobile device, the system

handling your call controls the power level at which your mobile device transmits.

Your mobile device is designed to comply with local regulatory requirements in your

country concerning exposure of human beings to RF energy.

RF Energy Operational Precautions

For optimal mobile device performance, and to be sure that human exposure to RF energy

does not exceed the guidelines set forth in the relevant standards, always follow these

instructions and precautions:

•

When placing or receiving a phone call, hold your mobile device just like you would a

landline phone.

•

If you wear the mobile device on your body, always place the mobile device in a

Motorola-supplied or approved clip, holder, holster, case, or body harness. If you do not

use a body-worn accessory supplied or approved by Motorola, keep the mobile device

and its antenna at least 2.5 cm (1 inch) from your body when transmitting.

•

Using accessories not supplied or approved by Motorola may cause your mobile device

to exceed RF energy exposure guidelines. For a list of Motorola-supplied or approved

accessories, visit our website at:

www.motorola.com

Do not use tools.

For indoor use only.

Listening at full volume to music or voice through a headset may

damage your hearing.

Symbol Definition

RF Energy Interference/Compatibility

Nearly every electronic device is subject to RF energy interference from external sources if

inadequately shielded, designed, or otherwise configured for RF energy compatibility. In

some circumstances, your mobile device may cause interference with other devices.

Follow Instructions to Avoid Interference Problems

Turn off your mobile device in any location where posted notices instruct you to do so.

In an aircraft, turn off your mobile device whenever instructed to do so by airline staff. If

your mobile device offers an flight Mode or similar feature, consult airline staff about

using it in flight.

Implantable Medical Devices

If you have an implantable medical device, such as a pacemaker or defibrillator, consult

your physician before using this mobile device.

Persons with implantable medical devices should observe the following precautions:

•

ALWAYS keep the mobile device more than 20 centimeters (8 inches) from the

implantable medical device when the mobile device is turned ON.

•

DO NOT carry the mobile device in the breast pocket.

•

Use the ear opposite the implantable medical device to minimize the potential for

interference.

•

Turn OFF the mobile device immediately if you have any reason to suspect that

interference is taking place.

Read and follow the directions from the manufacturer of your implantable medical device.

If you have any questions about using your mobile device with your implantable medical

device, consult your healthcare provider.

Specific Absorption Rate (I%%%)

SAR (ICNIRP)

YOUR MOBILE DEVICE MEETS &##,)-)43&/2

EXPOSURE TO RADIO WAVES.

Your mobile device is a radio transmitter and receiver. It is designed not to exceed the

limits for exposure to radio waves (radio frequency electromagnetic fields) adopted by

Federal Communications Commission (FCC). These limits include a substantial safety

margin designed to assure the safety of all persons, regardless of age and health.

The radio wave exposure guidelines use a unit of measurement known as the Specific

Absorption Rate, or SAR. The SAR limit for mobile devices is 1.6 W/kg.

Tests for SAR are conducted using standard operating positions with the device

transmitting at its highest certified power level in all tested frequency bands. The highest

SAR values under the FCC guidelines for your device model are listed below:

During use, the actual SAR values for your device are usually well below the values

stated. This is because, for purposes of system efficiency and to minimise interference on

the network, the operating power of your mobile device is automatically decreased when

full power is not needed for the call. The lower the power output of the device, the lower

its SAR value.

Body-worn SAR testing has been carried out using an approved accessory or at a

separation distance of 1 cm (0.4 inch). To meet RF exposure guidelines during body-worn

operation, the device should be in an approved accessory or positioned at least 1cm

(0.4 inch) away from the body. If you are not using an approved accessory, ensure that

whatever product is used is free of any metal and that it positions the phone at least 1

cm (0.4 inch) away from the body.

The World Health Organization has stated that present scientific information does not

indicate the need for any special precautions for the use of mobile devices. They

recommend that if you are interested in further reducing your exposure then you can easily

do so by limiting your usage or simply using a hands-free kit to keep the device away from

the head and body.

Additional information can be found at

www.who.int/emf

(World Health

Organization) or

www.motorola.com/rfhealth

(Motorola Mobility, Inc.).

Information from the World Health

Organization

WHO Information

“A large number of studies have been performed over the last two decades to assess

whether mobile phones pose a potential health risk. To date, no adverse health effects

have been established for mobile phone use.”

Head SAR UMTS 900/2100 + Bluetooth

GSM 850/1900 + Bluetooth

CDMA 800/1900 + Bluetooth

___ W/kg

0.555 W/kg

___ W/kg

Body-worn SAR UMTS 900/2100 + Bluetooth

GSM 850/1900 + Bluetooth

CDMA 800/1900 + Bluetooth

___ W/kg

0.921 W/kg

___ W/kg

Source: WHO Fact Sheet 193

Further information:

http://www.who.int/emf

European Union Directives Conformance

Statement

EU Conformance

The following CE compliance information is applicable to Motorola mobile devices that

carry one of the following CE marks:

Hereby, Motorola declares that this product is in compliance with:

•

The essential requirements and other relevant provisions of Directive 1999/5/EC

•

All other relevant EU Directives

The above gives an example of a typical Product Approval Number.

You can view your product’s Declaration of Conformity (DoC) to Directive 1999/5/EC (to

R&TTE Directive) at

www.motorola.com/rtte

. To find your DoC, enter the Product

Approval Number from your product’s label in the “Search” bar on the website.

FCC Notice to Users

FCC Notice

The following statement applies to all products that bear the FCC logo on the

product label.

This equipment has been tested and found to comply with the limits for a Class B digital

device, pursuant to part 15 of the FCC Rules. See 47 CFR Sec. 15.105(b). These limits are

0168

[Only Indoor Use Allowed In France

for Bluetooth and/or Wi-Fi]

0168

Product

Approval

Number

designed to provide reasonable protection against harmful interference in a residential

installation. This equipment generates, uses and can radiate radio frequency energy and,

if not installed and used in accordance with the instructions, may cause harmful

interference to radio communications. However, there is no guarantee that interference

will not occur in a particular installation. If this equipment does cause harmful

interference to radio or television reception, which can be determined by turning the

equipment off and on, the user is encouraged to try to correct the interference by one or

more of the following measures:

•

Reorient or relocate the receiving antenna.

•

Increase the separation between the equipment and the receiver.

•

Connect the equipment to an outlet on a circuit different from that to which the

receiver is connected.

•

Consult the dealer or an experienced radio/TV technician for help.

This device complies with part 15 of the FCC Rules. Operation is subject to the following

two conditions: (1) This device may not cause harmful interference, and (2) this device

must accept any interference received, including interference that may cause undesired

operation. See 47 CFR Sec. 15.19(a)(3).

Motorola has not approved any changes or modifications to this device by the user. Any

changes or modifications could void the user’s authority to operate the equipment. See 47

CFR Sec. 15.21.

For products that support Wi-Fi 802.11a (as defined in the product specifications available

www.motorola.com

), the following information applies. This equipment has the

capability to operate Wi-Fi in the 5 GHz Unlicensed National Information Infrastructure

(U-NII) band. Because this band is shared with MSS (Mobile Satellite Service), the FCC

has restricted such devices to indoor use only (see 47 CFR 15.407(e)). Since wireless hot

spots operating in this band have the same restriction, outdoor services are not offered.

Nevertheless, please do not operate this device in Wi-Fi mode when outdoors.

Location Services (GPS & AGPS)

GPS & AGPS

The following information is applicable to Motorola mobile devices that provide location-

based (GPS and/or AGPS) functionality.

Your mobile device can use Global Positioning System (GPS) signals for location-based

applications. GPS uses satellites controlled by the U.S. government that are subject to

changes implemented in accordance with the Department of Defense policy and the

Federal Radio Navigation Plan. These changes may affect the performance of location

technology on your mobile device.

Your mobile device can also use Assisted Global Positioning System (AGPS), which

obtains information from the cellular network to improve GPS performance. AGPS uses

your wireless service provider's network and therefore airtime, data charges, and/or

additional charges may apply in accordance with your service plan. Contact your wireless

service provider for details.

Your Location

Location-based information includes information that can be used to determine the

approximate location of a mobile device. Mobile devices which are connected to a

wireless network transmit location-based information. Devices enabled with GPS or AGPS

technology also transmit location-based information. Additionally, if you use applications

that require location-based information (e.g. driving directions), such applications transmit

location-based information. This location-based information may be shared with third

parties, including your wireless service provider, applications providers, Motorola, and

other third parties providing services.

Emergency Calls

When you make an emergency call, the cellular network may activate the AGPS

technology in your mobile device to tell the emergency responders your approximate

location.

AGPS has limitations and

might not work in your area

. Therefore:

•

Always tell the emergency responder your location to the best of your ability; and

•

Remain on the phone for as long as the emergency responder instructs you.

Navigation

The following information is applicable to Motorola mobile devices that provide

navigation features.

When using navigation features, note that mapping information, directions and other

navigational data may contain inaccurate or incomplete data. In some countries, complete

information may not be available. Therefore, you should visually confirm that the

navigational instructions are consistent with what you see. All drivers should pay

attention to road conditions, closures, traffic, and all other factors that may impact driving.

Always obey posted road signs.

Smart Practices While Driving

Driving Safety

Check the laws and regulations on the use of mobile devices and their

accessories in the areas where you drive. Always obey them. The use of these

devices may be prohibited or restricted in certain areas—for example,

handsfree use only may be required. Go to

www.motorola.com/callsmart

(in English only) for more information.

Your mobile device lets you communicate by voice and data—almost anywhere, anytime,

wherever wireless service is available and safe conditions allow. When driving a car,

driving is your first responsibility. If you choose to use your mobile device while driving,

remember the following tips:

• Get to know your Motorola mobile device and its features such as speed dial,

redial and voice dial.

If available, these features help you to place your call without

taking your attention off the road.

• When available, use a handsfree device.

If possible, add an additional layer of

convenience to your mobile device with one of the many Motorola Original handsfree

accessories available today.

• Position your mobile device within easy reach.

Be able to access your mobile

device without removing your eyes from the road. If you receive an incoming call at an

inconvenient time, if possible, let your voicemail answer it for you.

• Let the person you are speaking with know you are driving; if necessary,

suspend the call in heavy traffic or hazardous weather conditions.

Rain, sleet,

snow, ice, and even heavy traffic can be hazardous.

• Do not take notes or look up phone numbers while driving.

Jotting down a “to

do” list or going through your address book takes attention away from your primary

responsibility—driving safely.

• Dial sensibly and assess the traffic; if possible, place calls when your car is

not moving or before pulling into traffic.

If you must make a call while moving, dial

only a few numbers, check the road and your mirrors, then continue.

• Do not engage in stressful or emotional conversations that may be

distracting.

Make people you are talking with aware you are driving and suspend

conversations that can divert your attention away from the road.

• Use your mobile device to call for help.

Dial 911 or other local emergency number

in the case of fire, traffic accident, or medical emergencies (wherever wireless phone

service is available).

• Use your mobile device to help others in emergencies.

If you see an auto

accident, crime in progress, or other serious emergency where lives are in danger, call

911 or other local emergency number (wherever wireless phone service is available),

as you would want others to do for you.

• Call roadside assistance or a special non-emergency wireless assistance

number when necessary.

If you see a broken-down vehicle posing no serious

hazard, a broken traffic signal, a minor traffic accident where no one appears injured,

or a vehicle you know to be stolen, call roadside assistance or other special

non-emergency wireless number (wherever wireless phone service is available).

Privacy & Data Security

Motorola understands that privacy and data security are important to everyone. Because

some features of your mobile device may affect your privacy or data security, please

follow these recommendations to enhance protection of your information:

• Monitor access

—Keep your mobile device with you and do not leave it where others

may have unmonitored access. Use your device’s security and lock features, where

available.

• Keep software up to date

—If Motorola or a software/application vendor releases a

patch or software fix for your mobile device that updates the device’s security, install it

as soon as possible.

• Secure Personal Information

—Your mobile device can store personal information

in various locations including your SIM card, memory card, and phone memory. Be sure

to remove or clear all personal information before you recycle, return, or give away

your device. You can also backup your personal data to transfer to a new device.

Note:

For information on how to backup or wipe data from your mobile device, go to

www.motorola.com/support

• Online accounts

—Some mobile devices provide a Motorola online account (such as

MOTOBLUR). Go to your account for information on how to manage the account, and

how to use security features such as remote wipe and device location (where

available).

• Applications and updates

—Choose your apps and updates carefully, and install

from trusted sources only. Some apps can impact your phone’s performance and/or

have access to private information including account details, call data, location details

and network resources.

•Wireless

—For mobile devices with Wi-Fi features, only connect to trusted Wi-Fi

networks. Also, when using your device as a hotspot (where available) use network

security. These precautions will help prevent unauthorised access to your device.

• Location-based information

—Location-based information includes information that

can be used to determine the approximate location of a mobile device. Mobile phones

which are connected to a wireless network transmit location-based information.

Devices enabled with GPS or AGPS technology also transmit location-based

information. Additionally, if you use applications that require location-based

information (e.g. driving directions), such applications transmit location-based

information. This location-based information may be shared with third parties,

including your wireless service provider, applications providers, Motorola, and other

third parties providing services.

• Other information your device may transmit

—Your device may also transmit

testing and other diagnostic (including location-based) information, and other

non-personal information to Motorola or other third-party servers. This information is

used to help improve products and services offered by Motorola.

If you have further questions regarding how the use of your mobile device may impact your

privacy or data security, please contact Motorola at

privacy@motorola.com

, or

contact your service provider.

Use & Care

To care for your Motorola mobile device, please observe the following:

liquids

Don’t expose your mobile device to water, rain, extreme humidity, sweat, or

other liquids. If it does get wet, don’t try to accelerate drying with the use of

an oven or dryer, as this may damage the mobile device.

extreme heat or cold

Don’t store or use your mobile device in temperatures below -10°C (14°F) or

above 60°C (140°F). Don’t recharge your mobile device in temperatures

below 0°C (32°F) or above 45°C (113°F).

microwaves

Don’t try to dry your mobile device in a microwave oven.

dust and dirt

Don’t expose your mobile device to dust, dirt, sand, food, or other

inappropriate materials.

cleaning solutions

To clean your mobile device, use only a dry soft cloth. Don’t use alcohol or

Motorola Mobility T56ML3 Mobile Phone User Manual 3 of 3

Motorola Mobility LLC Mobile Phone 3 of 3

Contents

user manual 3 of 3

Navigation menu

Namespaces

Views

Navigation
