Motorola Mobility T56MQ2 Mobile Phone User Manual
Motorola Mobility LLC Mobile Phone
Contents
- 1. User manual
- 2. User Manual
User Manual
web
media
Bluetooth™
Contacts
Tips & tricks Music
Calls
Messages
Menu map
home screen
Basics
Let’s go
Personalize
MOTOROLA
This product meets the applicable SAR limits of 1.6 W/kg
(FCC) and 2.0 W/kg (ICNIRP). The limits and guidelines include
a substantial safety margin designed to assure the safety of
all persons, regardless of age and health. The highest SAR
values measured for this device are listed in the legal and
safety information packaged with your product.
Note: When carrying the product or using it while worn on
your body, either use an approved accessory such as a holster
or otherwise maintain a distance of 2.5 cm (1 inch) from the
body to ensure compliance with RF exposure requirements.
Note that the product may be transmitting even if you are not
making a phone call.
SCREEN MINI
TM
68016088001-A
welcome your phone
social networks
congratulations!
Whether you’re a talker, a texter, or just love listening to
music on the move, MOTOROLA SCREEN MINI (EX132)
does it all.
Your phone is splash and dust resistant, because life
happens fast, be ready for whatever it throws at you.
Note: Always make sure that the battery door cover and
connector cover are closed and secure. Damage caused
by failing to properly secure the phone’s splash resistant
covers is not covered by the warranty.
If you’d like even more information about how to use your
new MOTOROLA SCREEN MINI (EX132) visit
www.motorola.com/support
.
So, let’s go.
Note: Certain apps and features may not be available in
all countries/carriers.
Caution: Before assembling, charging, or using your
phone for the first time, please read the important safety,
regulatory and legal information in this guide.
12:00
Volume
Micro USB Connector/Headset
Charge, connect to
PC and connect the
headset.
Power
Touchscreen
Keys
Key
CameraKey
Home Key
Indicator Display
message s
Send an SMS or MMS
1Touch Message > New message.
2Enter your message.
3Add pictures, videos, and more using options at the
bottom of the screen.
4Touch Add recipient > select a contact.
5Touch Send.
Read messages
When you receive a message, your phone plays an alert
and shows the new message indicator at the top of
the screen.
To read the new message, touch View. To read
messages stored in your inbox, touch Message >
Inbox.
calls
Make calls
From the home screen, touch then enter a number
and touch .
Answer calls
When your phone rings or vibrates, touch Answer.
End a call
Touch End call.
In-call options
During a call, touch Loudspeaker, Keypad, Mute, New
call, Contacts or Hold.
Redial number
1Touch > Call log.
2Touch and hold the contact you want to call, then
touch Call.
Emergency calls
To call an emergency number, enter the emergency
number and touch Call.
Your service provider programs one or more emergency
phone numbers that you can call under any
circumstances, even when your phone is locked.
Emergency numbers vary by country. Your pre-
programmed emergency number(s) may not work in all
locations, and sometimes an emergency call cannot be
placed due to network, environmental, or interference
issues.
music
Recent calls
To see your Missed, Received and Dialled calls, touch
> Call Log.
Voicemail
From the home screen, touch , then touch and
hold 1. If your voicemail number is preset, you will
connect.
Backlight time
To set how long your backlight stays on, touch >
Settings > Display > Backlight time-out.
Battery tips
Want to extend your battery life? Try these:
•Turn off Bluetooth™ power: Touch > Bluetooth >
Off.
•Turn off the screen saver: Touch > Settings
>Display > Screensaver > Off.
To use the music player, insert a microSD memory card
(optional). The music player supports MP3, MIDI, AAC,
AMR and WAV music formats.
Play music
Touch > Music player
controls
Tip: To access music stored on your microSD memory
card, touch > My Files > Memory Card. To
transfer music to/from your memory card, plug your USB
cable into your phone & computer, then drag & drop files
to the ‘Music’ folder.
function
play/pause Touch / .
next/previous
song
Touch / .
volume Press the side volume
keys up or down.
Call log
•All
• Missed
•Received
• Dialled
• Delete All
Active mode
•Music
•Radio
• Camera
•Video
•Stopwatch
Organiser
• Alarm clock
•To-do list
• Calculator
• Countdown timer
•Stopwatch
• Notes
• World clock
• Unit converter
Browser
Email
Contacts
This is a standard main menu
layout. Your phone’s menu may be
a little different. Flick the menu
screen left or right to view more
panels.
* Network/Carrier dependent.
Settings
Music player
Radio
Recorder
Photos
Camera
My Files
Message
Bluetooth
Media
Twitter*
Facebook
MySpace*
YouTube*
Google Search*
Gmail
let’s go
4H
12
34
56
Cover off SIM in
microSD in Battery in
Cover on Charge up
basics
Turn it on & off
Press and hold (on top of the phone) for a few
seconds to turn the phone on/off.
To u ch tips
•Touch: To choose an icon or option.
•Touch & hold: To open special options.
•Drag/Flick: Scroll/move slowly (drag) or quickly
(flick).
Menu navigation
Touch to open the main menu.
Press Home to close any menu or app and return to
the home screen.
Touch Back to go back.
Flick the menu screen left or right to view more panels.
customize
Profiles
Your phone has different profiles. You can customize
ringtones, alerts, and volumes for each profile.
Touch > Settings > Profiles, then select from
these profiles:
•General: Standard profile default setting.
•Silent: Ringtone is off, vibrate is off.
•Meeting: Vibrate is on, ringtone is off.
•Outdoor: Ringtone and key tone volume set to
maximum.
•Flight mode: Turn off all wireless connections.
Display settings
To set display settings such as wallpaper, and screen
saver, touch > Settings > Display.
Date & time
Set date, time, time zone, and formats:
touch > Settings >Date and time.
Google Maps
Use your phone to access your favourite social network
sites.
Note: If you don’t have a social network account, you can
visit the web site to set it up.
Update your status
After you set up an account, you can sign in, update and
see your current status, and see and respond to friends’
updates.
phonebook
Create contacts
Touch Contacts > , enter the contact name and
details, then touch Save.
Tip: Tou ch > More > Memory in use to choose where
to save your contacts (Phone memory, SIM card or
Phone and SIM card).
Call contacts
Touch and hold a contact, then touch Call.
Add Groups Speed dials More
04:35
:
5
3
0
4
:
:
0
4
5
3
3
5
0
3
5
0
4
3
35
:
3
AM
M
A
M
A
A
07970405803
3
5
8
0
0
9
0
0
7
7
0
4
0797
0
97
0
0797
Mike
ike
M
i
Lara
ara
L
05569873490
69873490
6
5
5
5
5
0
0
734
Search for
contact.
View contact.
Add contact.
View memory
status, and more.
Add contact to
speed dial.
Add contact to
a group.
Bluetooth
Turn on or off
Touch > Bluetooth > On or Off
When Bluetooth power is on, the Bluetooth indicator
appears in the home screen.
Connect new devices
To connect with a new device, you need to pair with it.
You only need to do this once for each device.
1Make sure the device you are pairing with is in
discoverable mode (see device instructions).
2Tou ch > Bluetooth > Paired devices > New.
3Your phone lists the devices it finds within range.
Select a device to connect.
4If necessary, enter the device passkey (like 0000) to
connect to the device.
photos & videos
Photos & videos
•Photos: Touch > Camera. To take the photo,
press .
•Videos: Touch > Camera, then drag down.
Press to start/stop.
After you’ve taken the photo, touch , then:
•To send in a message, or via Bluetooth, touch Send.
•To assign to a contact, touch Attach to contact.
To see the photos and videos you’ve taken,
touch > My Files >Images or Video clips.
USB drag & drop
Use your phone’s browser to surf your favorite web sites,
upload videos, and download apps. Log onto your
internet-based email account to check your email.
Touch > Browser
•To go to a Web page, input the URL.
•To bookmark a Web page, touch More
>Bookmarks >Add bookmark.
•To change displays settings like Font size and View
mode, touch More > Setting.
•To go to a link on a Web page, touch it.
Note: If you can’t connect, contact your service provider.
status indicators
The home screen is what you see when you turn on the
phone or touch Home from a menu. It’s basically like
this:
Note: Your home screen might look a little different.
11-01-2011 (Fri)
01:33
Menu Icon
Status Indicators
Touch to open
main menu.
Shortcuts
Touch to open.
Safety, Regulatory & Legal
Safety, Regulatory & Legal
Battery Use & Safety
Battery Use & Safety
Important: Handle and store batteries properly to avoid injury or damage.
Most battery issues arise from improper handling of batteries, and particularly
from the continued use of damaged batteries.
DON’Ts
• Don’t disassemble, crush, puncture, shred, or otherwise attempt to
change the form of your battery.
• Don’t let the mobile device or battery come in contact with liquids.*
Liquids can get into the mobile device’s circuits, leading to corrosion.
• Don’t allow the battery to touch metal objects.
If metal objects, such as
jewelry, stay in prolonged contact with the battery contact points, the
battery could become very hot.
•Don’t place your mobile device or battery near a heat source.*
High
temperatures can cause the battery to swell, leak, or malfunction.
• Don’t dry a wet or damp battery with an appliance or heat source
, such
as a hair dryer or microwave oven.
DOs
• Do avoid leaving your mobile device in your car in high temperatures.*
• Do avoid dropping the mobile device or battery.*
Dropping these items,
especially on a hard surface, can potentially cause damage.*
•Do contact your service provider or Motorola if your mobile device or
battery has been damaged by dropping, liquids or high temperatures.
*Note:
Always make sure that the battery compartment and any connector
covers are closed and secure to avoid direct exposure of the battery to any of
these conditions, even if your product information states that your
mobile
device
can resist damage from these conditions.
Important: Motorola recommends you always use Motorola-branded
batteries and chargers for quality assurance and safeguards.
Motorola’s
warranty does not cover damage to the mobile device caused by non-Motorola
batteries and/or chargers. To help you identify authentic Motorola batteries from
non-original or counterfeit batteries (that may not have adequate safety
protection), Motorola provides holograms on its batteries. You should confirm
that any battery you purchase has a “Motorola Original” hologram.
If you see a message on your display such as
Invalid Battery
or
Unable to Charge
, take the following steps:
•
Remove the battery and inspect it to confirm that it has a
“Motorola Original” hologram;
•
If there is no hologram, the battery is not a Motorola battery;
•
If there is a hologram, replace the battery and try charging it again;
•
If the message remains, contact a Motorola authorized service center.
Warning:
Use of a non-Motorola battery or charger may present a risk of fire,
explosion, leakage, or other hazard.
Proper and safe battery disposal and recycling:
Proper battery disposal is not
only important for safety, it benefits the environment. You can recycle your used
batteries in many retail or service provider locations. Additional information on
proper disposal and recycling can be found at
www.motorola.com/
recycling
Disposal:
Promptly dispose of used batteries in accordance with local
regulations. Contact your local recycling center or national recycling
organizations for more information on how to dispose of batteries.
Warning:
Never dispose of batteries in a fire because they may
explode.
Battery Charging
Battery Charging
Notes for charging your product’s battery:
•
During charging, keep your battery and charger near room temperature for
efficient battery charging.
•
New batteries are not fully charged.
•
New batteries or batteries stored for a long time may take more time to
charge.
•
Motorola batteries and charging systems have circuitry that protects the
battery from damage from overcharging.
Third Party Accessories
Use of third party accessories, including but not limited to batteries, chargers,
headsets, covers, cases, screen protectors and memory cards, may impact your
mobile device’s performance. In some circumstances, third party accessories
can be dangerous and may void your mobile device’s warranty. For a list of
Motorola accessories, visit
www.motorola.com/products
Driving Precautions
Responsible and safe driving is your primary responsibility when behind the
wheel of a vehicle. Using a mobile device or accessory for a call or other
application while driving may cause distraction. Using a mobile device or
accessory may be prohibited or restricted in certain areas, always obey the laws
and regulations on the use of these products.
While driving, NEVER:
•
Type or read texts.
•
Enter or review written data.
032375o
•
Surf the web.
•
Input navigation information.
•
Perform any other functions that divert your attention from driving.
While driving, ALWAYS:
•
Keep your eyes on the road.
•
Use a handsfree device if available or required by law in your area.
•
Enter destination information into a navigation device
before
driving.
•
Use voice activated features (such as voice dial) and speaking features (such
as audible directions), if available.
•
Obey all local laws and regulations for the use of mobile devices and
accessories in the vehicle.
•
End your call or other task if you cannot concentrate on driving.
Remember to follow the “Smart Practices While Driving” in this guide and at
www.motorola.com/callsmart
(in English only).
Seizures/Blackouts
Some people may be susceptible to epileptic seizures or blackouts when exposed
to flashing lights, such as when playing videos or games. These may occur even if
a person has never had a previous seizure or blackout.
If you have experienced seizures or blackouts, or if you have a family history of
such occurrences, please consult with your physician before playing videos or
games or enabling a flashing-lights feature (if available) on your mobile device.
Discontinue use and consult a physician if any of the following symptoms occur:
convulsion, eye or muscle twitching, loss of awareness, involuntary movements,
or disorientation. It is always a good idea to hold the screen away from your eyes,
leave the lights on in the room, take a 15-minute break every hour, and stop use if
you are tired.
Caution About High Volume Usage
Warning:
Exposure to loud noise from any source for extended periods of time
may affect your hearing. The louder the volume sound level, the less time is
required before your hearing could be affected. To protect your hearing:
•
Limit the amount of time you use headsets or headphones at high volume.
•
Avoid turning up the volume to block out noisy surroundings.
•
Turn the volume down if you can’t hear people speaking near you.
If you experience hearing discomfort, including the sensation of pressure or
fullness in your ears, ringing in your ears, or muffled speech, you should stop
listening to the device through your headset or headphones and have your
hearing checked.
For more information about hearing, see our website at
direct.motorola.com/hellomoto/nss/AcousticSafety.asp
(in English
only).
Repetitive Motion
When you repetitively perform actions such as pressing keys or entering finger-
written characters, you may experience occasional discomfort in your hands,
arms, shoulders, neck, or other parts of your body. If you continue to have
discomfort during or after such use, stop use and see a physician.
Children
Keep your mobile device and its accessories away from small children.
These products are not toys and may be hazardous to small children. For example:
•
A choking hazard may exist for small, detachable parts.
•
Improper use could result in loud sounds, possibly causing hearing injury.
•
Improperly handled batteries could overheat and cause a burn.
Similar to a computer, if a child does use your mobile device, you may want to
monitor their access to help prevent exposure to inappropriate apps or content.
Glass Parts
Some parts of your mobile device may be made of glass. This glass could break if
the product receives a substantial impact. If glass breaks, do not touch or attempt
to remove. Stop using your mobile device until the glass is replaced by a qualified
service center.
Operational Warnings
Obey all posted signs when using mobile devices in public areas.
Potentially Explosive Atmospheres
Areas with potentially explosive atmospheres are often, but not always, posted
and can include fueling areas, such as below decks on boats, fuel or chemical
transfer or storage facilities, or areas where the air contains chemicals or
particles, such as grain dust, or metal powders.
When you are in such an area, turn off your mobile device, and do not remove,
install, or charge batteries unless it is a radio product type especially qualified for
use in such areas as “Intrinsically Safe” (for example, Factory Mutual, CSA, or UL
approved). In such areas, sparks can occur and cause an explosion or fire.
Symbol Key
Your battery, charger, or mobile device may contain symbols, defined as follows:
Radio Frequency (RF) Energy
Exposure to RF Energy
Your mobile device contains a transmitter and receiver. When it is ON, it receives
and transmits RF energy. When you communicate with your mobile device, the
system handling your call controls the power level at which your mobile device
transmits.
Your mobile device is designed to comply with local regulatory requirements in
your country concerning exposure of human beings to RF energy.
RF Energy Operational Precautions
For optimal mobile device performance, and to be sure that human exposure to
RF energy does not exceed the guidelines set forth in the relevant standards,
always follow these instructions and precautions:
•
When placing or receiving a phone call, hold your mobile device just like you
would a landline phone.
•
If you wear the mobile device on your body, always place the mobile device in
a Motorola-supplied or approved clip, holder, holster, case, or body harness. If
you do not use a body-worn accessory supplied or approved by Motorola,
keep the mobile device and its antenna at least 2.5 cm (1 inch) from your
body when transmitting.
•
Using accessories not supplied or approved by Motorola may cause your
mobile device to exceed RF energy exposure guidelines. For a list of
Motorola-supplied or approved accessories, visit our website at:
www.motorola.com
.
RF Energy Interference/Compatibility
Nearly every electronic device is subject to RF energy interference from external
sources if inadequately shielded, designed, or otherwise configured for RF
energy compatibility. In some circumstances, your mobile device may cause
interference with other devices.
Follow Instructions to Avoid Interference Problems
Turn off your mobile device in any location where posted notices instruct you to
do so.
In an aircraft, turn off your mobile device whenever instructed to do so by airline
staff. If your mobile device offers an airplane mode or similar feature, consult
airline staff about using it in flight.
Implantable Medical Devices
If you have an implantable medical device, such as a pacemaker or defibrillator,
consult your physician before using this mobile device.
Persons with implantable medical devices should observe the following
precautions:
•
ALWAYS keep the mobile device more than 20 centimeters (8 inches) from
the implantable medical device when the mobile device is turned ON.
•
DO NOT carry the mobile device in the breast pocket.
•
Use the ear opposite the implantable medical device to minimize the potential
for interference.
•
Turn OFF the mobile device immediately if you have any reason to suspect
that interference is taking place.
Symbol Definition
Important safety information follows.
Do not dispose of your battery or mobile device in a fire.
Your battery or mobile device may require recycling in
accordance with local laws. Contact your local regulatory
authorities for more information.
Do not dispose of your battery or mobile device with your
household waste. See “Recycling” for more information.
Do not use tools.
For indoor use only.
032374o
032376o
032375o
Read and follow the directions from the manufacturer of your implantable medical
device. If you have any questions about using your mobile device with your
implantable medical device, consult your healthcare provider.
Specific Absorption Rate (IEEE)
SAR (I EEE)
YOUR MOBILE DEVICE MEETS FCC LIMITS FOR EXPOSURE TO RADIO
WAVES.
Your mobile device is a radio transmitter and receiver. It is designed not to exceed
the limits for exposure to radio waves (radio frequency electromagnetic fields)
adopted by the Federal Communications Commission (FCC). These limits include
a substantial safety margin designed to assure the safety of all persons,
regardless of age and health.
The radio wave exposure guidelines use a unit of measurement known as the
Specific Absorption Rate, or SAR. The SAR limit for mobile devices is 1.6 W/kg.
Tests for SAR are conducted using standard operating positions with the device
transmitting at its highest certified power level in all tested frequency bands. The
highest SAR values under the FCC guidelines for your device model are listed
below:
During use, the actual SAR values for your device are usually well below the
values stated. This is because, for purposes of system efficiency and to minimize
interference on the network, the operating power of your mobile device is
automatically decreased when full power is not needed for the call. The lower the
power output of the device, the lower its SAR value.
Body-worn SAR testing has been carried out using an approved accessory or at a
separation distance of 2.5 cm (1 inch). To meet RF exposure guidelines during
body-worn operation, the device should be in an approved accessory or
positioned at least 2.5 cm (1 inch) away from the body. If you are not using an
approved accessory, ensure that whatever product is used is free of any metal
and that it positions the phone at least 2.5 cm (1 inch) away from the body.
The World Health Organization has stated that present scientific information does
not indicate the need for any special precautions for the use of mobile devices.
They recommend that if you are interested in further reducing your exposure then
you can easily do so by limiting your usage or simply using a hands-free kit to
keep the device away from the head and body.
Additional information can be found at
www.who.int/emf
(World Health
Organization) or
www.motorola.com/rfhealth
(Motorola Mobility, Inc.).
Specific Absorption Rate (ICNIRP)
SAR (I CNIRP)
YOUR MOBILE DEVICE MEETS INTERNATIONAL GUIDELINES FOR
EXPOSURE TO RADIO WAVES.
Your mobile device is a radio transmitter and receiver. It is designed not to exceed
the limits for exposure to radio waves (radio frequency electromagnetic fields)
recommended by international guidelines. The guidelines were developed by an
independent scientific organization (ICNIRP) and include a substantial safety
margin designed to assure the safety of all persons, regardless of age and health.
The radio wave exposure guidelines use a unit of measurement known as the
Specific Absorption Rate, or SAR. The SAR limit for mobile devices is 2 W/kg.
Tests for SAR are conducted using standard operating positions with the device
transmitting at its highest certified power level in all tested frequency bands. The
highest SAR values under the ICNIRP guidelines for your device model are listed
below:
Head SAR UMTS 850/2100 +
GSM
850/900/1800/1900 + Bluetooth
0.992 W/kg
Body-worn SAR UMTS 850/2100 +
GSM
850/900/1800/1900 + Bluetooth
0.78 W/kg
Head SAR UMTS 850/1900 +
GSM
850/900/1800/1900 + Bluetooth
1. 3 4 W / k g
Body-worn SAR UMTS 850/1900 +
GSM
850/900/1800/1900 + Bluetooth
0.625 W/kg
Head SAR UMTS 850/2100 +
GSM
850/900/1800/1900 + Bluetooth
0.753 W/kg
Body-worn SAR UMTS 850/2100 +
GSM
850/900/1800/1900 + Bluetooth
0.522 W/kg
Head SAR UMTS 850/1900 +
GSM
850/900/1800/1900 + Bluetooth
0.77 W/kg
Body-worn SAR UMTS 850/1900 +
GSM
850/900/1800/1900 + Bluetooth
0.512 W/kg
During use, the actual SAR values for your device are usually well below the
values stated. This is because, for purposes of system efficiency and to minimize
interference on the network, the operating power of your mobile device is
automatically decreased when full power is not needed for the call. The lower the
power output of the device, the lower its SAR value.
Body-worn SAR testing has been carried out using an approved accessory or at a
separation distance of 2.5 cm (1 inch). To meet RF exposure guidelines during
body-worn operation, the device should be in an approved accessory or
positioned at least 2.5 cm (1 inch) away from the body. If you are not using an
approved accessory, ensure that whatever product is used is free of any metal
and that it positions the phone at least 2.5 cm (1 inch) away from the body.
The World Health Organization has stated that present scientific information does
not indicate the need for any special precautions for the use of mobile devices.
They recommend that if you are interested in further reducing your exposure then
you can easily do so by limiting your usage or simply using a hands-free kit to
keep the device away from the head and body.
Additional information can be found at
www.who.int/emf
(World Health
Organization) or
www.motorola.com/rfhealth
(Motorola Mobility, Inc.).
Information from the World Health
Organization
WHO Information
“A large number of studies have been performed over the last two decades to
assess whether mobile phones pose a potential health risk. To date, no adverse
health effects have been established for mobile phone use.”
Source: WHO Fact Sheet 193
Further information:
http://www.who.int/emf
European Union Directives Conformance
Statement
EU Conformance
The following CE compliance information is applicable to Motorola mobile devices
that carry one of the following CE marks:
Hereby, Motorola declares that this product is in compliance with:
•
The essential requirements and other relevant provisions of Directive 1999/5/
EC
•
All other relevant EU Directives
The above gives an example of a typical Product Approval Number.
You can view your product’s Declaration of Conformity (DoC) to Directive 1999/5/
EC (to R&TTE Directive) at
www.motorola.com/rtte
. To find your DoC,
enter the Product Approval Number from your product’s label in the “Search” bar
on the website.
FCC Notice to Users
FCC Notice
The following statement applies to all products that bear the FCC logo on
the product label.
This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to part 15 of the FCC Rules. See 47 CFR Sec. 15.105(b).
These limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates, uses and can
radiate radio frequency energy and, if not installed and used in accordance with
the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and
on, the user is encouraged to try to correct the interference by one or more of the
following measures:
•
Reorient or relocate the receiving antenna.
•
Increase the separation between the equipment and the receiver.
•
Connect the equipment to an outlet on a circuit different from that to which
the receiver is connected.
•
Consult the dealer or an experienced radio/TV technician for help.
This device complies with part 15 of the FCC Rules. Operation is subject to the
following two conditions: (1) This device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that
may cause undesired operation. See 47 CFR Sec. 15.19(a)(3).
Motorola has not approved any changes or modifications to this device by the
user. Any changes or modifications could void the user’s authority to operate the
equipment. See 47 CFR Sec. 15.21.
0168
0168
Product
Approval
Number
For products that support W-Fi 802.11a (as defined in the product specifications
available at
www.motorola.com
), the following information applies. This
equipment has the capability to operate Wi-Fi in the 5 GHz Unlicensed National
Information Infrastructure (U-NII) band. Because this band is shared with MSS
(Mobile Satellite Service), the FCC has restricted such devices to indoor use only
(see 47 CFR 15.407(e)). Since wireless hot spots operating in this band have the
same restriction, outdoor services are not offered. Nevertheless, please do not
operate this device in Wi-Fi mode when outdoors.
Smart Practices While Driving
Driving Safety
Check the laws and regulations on the use of mobile devices and their
accessories in the areas where you drive. Always obey them. The use of
these devices may be prohibited or restricted in certain areas—for example,
handsfree use only may be required. Go to
www.motorola.com/
callsmart
(in English only) for more information.
Your mobile device lets you communicate by voice and data—almost anywhere,
anytime, wherever wireless service is available and safe conditions allow. When
driving a car, driving is your first responsibility. If you choose to use your mobile
device while driving, remember the following tips:
• Get to know your Motorola mobile device and its features such as speed
dial, redial and voice dial.
If available, these features help you to place your
call without taking your attention off the road.
• When available, use a handsfree device.
If possible, add an additional layer
of convenience to your mobile device with one of the many Motorola Original
handsfree accessories available today.
• Position your mobile device within easy reach.
Be able to access your
mobile device without removing your eyes from the road. If you receive an
incoming call at an inconvenient time, if possible, let your voicemail answer it
for you.
• Let the person you are speaking with know you are driving; if necessary,
suspend the call in heavy traffic or hazardous weather conditions.
Rain,
sleet, snow, ice, and even heavy traffic can be hazardous.
• Do not take notes or look up phone numbers while driving.
Jotting down
a “to do” list or going through your address book takes attention away from
your primary responsibility—driving safely.
• Dial sensibly and assess the traffic; if possible, place calls when your car
is not moving or before pulling into traffic.
If you must make a call while
moving, dial only a few numbers, check the road and your mirrors, then
continue.
• Do not engage in stressful or emotional conversations that may be
distracting.
Make people you are talking with aware you are driving and
suspend conversations that can divert your attention away from the road.
• Use your mobile device to call for help.
Dial 911 or other local emergency
number in the case of fire, traffic accident, or medical emergencies (wherever
wireless phone service is available).
• Use your mobile device to help others in emergencies.
If you see an auto
accident, crime in progress, or other serious emergency where lives are in
danger, call 911 or other local emergency number (wherever wireless phone
service is available), as you would want others to do for you.
• Call roadside assistance or a special non-emergency wireless assistance
number when necessary.
If you see a broken-down vehicle posing no
serious hazard, a broken traffic signal, a minor traffic accident where no one
appears injured, or a vehicle you know to be stolen, call roadside assistance
or other special non-emergency wireless number (wherever wireless phone
service is available).
Privacy & Data Security
Privacy & Data Security
Motorola understands that privacy and data security are important to everyone.
Because some features of your mobile device may affect your privacy or data
security, please follow these recommendations to enhance protection of your
information:
• Monitor access
—Keep your mobile device with you and do not leave it
where others may have unmonitored access. Use your device’s security and
lock features, where available.
•Keep software up to date
—If Motorola or a software/application vendor
releases a patch or software fix for your mobile device that updates the
device’s security, install it as soon as possible.
•Secure Personal Information
—Your mobile device can store personal
information in various locations including your SIM card, memory card, and
phone memory. Be sure to remove or clear all personal information before
you recycle, return, or give away your device. You can also backup your
personal data to transfer to a new device.
Note:
For information on how to backup or wipe data from your mobile device, go to
www.mo-
torola.com/support
• Online accounts
—Some mobile devices provide a Motorola online account
(such as MOTOBLUR). Go to your account for information on how to manage
the account, and how to use security features such as remote wipe and
device location (where available).
•Applications and updates
—Choose your apps and updates carefully, and
install from trusted sources only. Some apps can impact your phone’s
performance and/or have access to private information including account
details, call data, location details and network resources.
• Wireless
—For mobile devices with Wi-Fi features, only connect to trusted
Wi-Fi networks. Also, when using your device as a hotspot (where available)
use network security. These precautions will help prevent unauthorized
access to your device.
•Location-based information
—Location-based information includes
information that can be used to determine the approximate location of a
mobile device. Mobile phones which are connected to a wireless network
transmit location-based information. Devices enabled with GPS or AGPS
technology also transmit location-based information. Additionally, if you use
applications that require location-based information (e.g. driving directions),
such applications transmit location-based information. This location-based
information may be shared with third parties, including your wireless service
provider, applications providers, Motorola, and other third parties providing
services.
• Other information your device may transmit
—Your device may also
transmit testing and other diagnostic (including location-based) information,
and other non-personal information to Motorola or other third-party servers.
This information is used to help improve products and services offered by
Motorola.
If you have further questions regarding how the use of your mobile device may
impact your privacy or data security, please contact Motorola at
privacy@motorola.com
, or contact your service provider.
Use & Care
Use & Care
To care for your Motorola mobile device, please observe the following:
liquids
Don’t expose your mobile device to water, rain, extreme humidity,
sweat, or other liquids. If it does get wet, don’t try to accelerate drying
with the use of an oven or dryer, as this may damage the mobile
device.
extreme heat or cold
Don’t store or use your mobile device in temperatures below -10°C
(14°F) or above 60°C (140°F). Don’t recharge your mobile device in
temperatures below 0°C (32°F) or above 45°C (113°F).
microwaves
Don’t try to dry your mobile device in a microwave oven.
dust and dirt
Don’t expose your mobile device to dust, dirt, sand, food, or other
inappropriate materials.
cleaning solutions
To clean your mobile device, use only a dry soft cloth. Don’t use
alcohol or other cleaning solutions.
shock and vibration
Don’t drop your mobile device.
protection
To help protect your mobile device, always make sure that the battery
compartment and any connector covers are closed and secure.
Recycling
Recycl ing
Mobile Devices & Accessories
Please do not dispose of mobile devices or electrical accessories (such
as chargers, headsets, or batteries) with your household waste, or in a
fire. These items should be disposed of in accordance with the national
collection and recycling schemes operated by your local or regional
authority. Alternatively, you may return unwanted mobile devices and electrical
accessories to any Motorola Approved Service Center in your region. Details of
Motorola approved national recycling schemes, and further information on
Motorola recycling activities can be found at:
www.motorola.com/
recycling
Packaging & Product Guides
Product packaging and product guides should only be disposed of in accordance
with national collection and recycling requirements. Please contact your regional
authorities for more details.
Software Copyright Notice
Software C opyright Notice
Motorola products may include copyrighted Motorola and third-party software
stored in semiconductor memories or other media. Laws in the United States and
other countries preserve for Motorola and third-party software providers certain
exclusive rights for copyrighted software, such as the exclusive rights to distribute
or reproduce the copyrighted software. Accordingly, any copyrighted software
contained in Motorola products may not be modified, reverse-engineered,
distributed, or reproduced in any manner to the extent allowed by law.
Furthermore, the purchase of Motorola products shall not be deemed to grant
either directly or by implication, estoppel, or otherwise, any license under the
copyrights, patents, or patent applications of Motorola or any third-party software
provider, except for the normal, non-exclusive, royalty-free license to use that
arises by operation of law in the sale of a product.
Content Copyright
Content Copyri ght
The unauthorized copying of copyrighted materials is contrary to the provisions of
the Copyright Laws of the United States and other countries. This device is
intended solely for copying non-copyrighted materials, materials in which you
own the copyright, or materials which you are authorized or legally permitted to
copy. If you are uncertain about your right to copy any material, please contact
your legal advisor.
Service & Repairs
If you have questions or need assistance, we're here to help.
Go to
www.motorola.com/support
, where you can select from a number
of customer care options. You can also contact the Motorola Customer Support
Center at 0800 666 8676 (Argentina), 800-201-442 (Chile), 01-800-700-1504
(Colombia), 01 800 021 0000 (México), 0800-100-4289 (Venezuela), or 0-800-52-
470 (Perú).
Latin America Warranty, Except Mexico
Warranty (Except Mexico)
Latin America Warranty Motorola Mobility Inc. Subscribers/
Cellular Division
Through its own service centers and/or its authorized service centers, Motorola
provides a 1-year warranty that covers the cellular phone, all its parts and labor
against any defect and operation as long as the “Product” has been operated and
handled under normal conditions. The term of 1 year begins when the “Product”
is purchased.
Conditions
1
For warranty service, return the “Product” and this warranty to the place of purchase or to
any Motorola authorized service center.
If additional information is needed, please contact any of our service centers:
If the cellular phone has been installed in a vehicle, take the vehicle to the service center to
analyze the equipment, or the installation on the vehicle. This warranty does not cover the
installation of the cellular phone.
2
Motorola Mobility Inc., through its own service centers and/or their authorized service
centers, will repair or replace the cellular phone at no charge. This warranty covers shipping
expenses, only if it is needed to make the repair.
Motorola Mobility Inc. through its own service centers and/or their authorized service
centers, at its own discretion, will repair, replace, or reimburse the purchase price of the
defective cellular phone only during the warranty period, as long as the “Product,” in
accordance with the conditions established in this warranty, is returned to a Motorola
service center or to a Motorola authorized service center. All the accessories, batteries,
parts, small boards or equipment of the cellular telephone that by virtue of being defective
are replaced in fulfillment of this warranty, will automatically become property of Motorola
Mobility, Inc.
3
To receive warranty service, present your cellular phone or accessory to any Motorola service
center or Motorola authorized service center, along with your receipt of purchase or
Motorola Comercial, S.A. de C.V.
Bosques Alisos No. 125
Bosques de las Lomas
CP 05120 México, D.F.
Telephone: 257-6700
Motorola Industrial Ltda.l
Chedid Jafet
222 - Bloco D - 1º andar
Vila Olimpia 04551-065
Sao Paulo, Brazil
Telephone: 0800-773 1244
Motorola Mobility Colombia S.A.S.
Carrera 7 7152
Torre B Piso 13 Oficina 1301
Torre del Banco Ganadero
Santa Fe de Bogotá, Colombia
Telephone: 01800 700 1504
comparable substitute that indicates the date of purchase, serial number of the transceiver,
and/or electronic serial number.
4
The repair time will not be greater than 30 days, starting from the day the equipment was
received at the service center.
5
To purchase parts, spare parts, accessories and service not covered by this warranty, contact
one of the service centers listed in section 1, or any authorized service center in your locality.
6
This warranty is not valid in the following cases:
•
Defects or damages derived from abnormal use.
•
Defects or damages derived from accident or negligence.
•
Defects or damages derived from tests, unsuitable operation, maintenance,
installation and adjustments, or derived from any alteration or modification of
any type.
•
Damage caused to antennas, unless they are consequences of defects in
material or workmanship.
•
When the cellular phone has been disassembled and/or repaired so that its
operation has been affected or that it can not be tested to verify any claim
that grants this warranty.
•
Any cellular phone with a serial number that has been removed, altered, or
obliterated.
•
Defects or damages caused by food spills or liquids.
•
When the cables of the control unit have been stretched or the module
tongue-piece has broken.
•
When the surface of the “Product” and its pieces have been scratched or
damaged due to normal use.
•
Leather cases.
•
Rented cellular phones.
•
When the “Product” has been altered or repaired by non-Motorola authorized
service centers.
•
When the “Product” has not been operated in agreement with the
instructions that accompany the “Product.”
7
The batteries (Nickel-Cadmium) are warranted only if their capacity is reduced by 80% below
its predicted capacity. This warranty is null for all types of batteries if:
•
The batteries are charged by a charger that has not been approved by
Motorola.
•
Any of the battery seals are broken or tampered with.
•
The batteries were used or installed in non-Motorola equipment.
Limited Warranty (Mexico)
Warranty (Mexico)
For Motorola personal communication products and accessories purchased
in Mexico
I. Concepts Covered by this Warranty
This warranty covers all the parts, components, accessories and labor of the
Motorola “Product” from defects in materials and workmanship under normal
consumer usage.
The Motorola “Products” that are protected under this warranty can be:
(a) cellular telephones, (b) radar sets, (c) two-way radios, and (d) wireless
telephones.
Motorola Comercial, S.A. de C.V., at its option, will at no charge repair, replace, or
refund the purchase price of any “Product” that does not conform to this
warranty. Motorola may use functionally equivalent reconditioned/refurbished/
pre-owned or new products, accessories, or parts. Updates in software are not
covered.
II. Length of Warranty Coverage
The length of coverage is one (1) year from the date the new “Product” was
purchased from an authorized distributor.
“Product”:
Brand: Motorola Model:
Number of Mechanical Series:
Number of Electronic Series:
Name of Distributor:
Street and Number:
To wn :
Municipality:
Postal Code, City, State, or
Country:
Telephone:
Date of Delivery or Installation:
III. Place where consumers can make the warranty
effective, obtain parts, components, and accessories
Motorola Comercial, S.A. de C.V.
Bosques de Alisos 125
Col. Bosques de las Lomas
Del. Cuajimalpa
Te:(55) 5257-6700
IV. Procedure to Make the Warranty Effective
For warranty service, return the “Product” (with its components and
accessories, such as batteries, antennas, and charger) to the place of purchase,
to the address above, or to an authorized service center, or call
01 800 021 0000. To request a refund, you must present this warranty, sealed
by the place of purchase, along with the “Product.”
V. Warranty Limitations or Exceptions
The warranty is not valid when:
•
The “Product” has been used in conditions different from the normal ones.
•
The “Product” has not been operated as described in the operating
instructions.)
•
The “Product” has been altered or repaired by someone other than
Motorola, or its authorized service centers.
If repairs are not covered by this warranty, Motorola, at the request of the
purchaser, will provide information regarding availability, prices, and other
conditions for the repair of the “Product.”
To obtain information on products that need repairs not covered by this
warranty, please call 01 800 021 0000.
Note:
In other countries, consult the laws and local regulations under the
warranty and its local Motorola office.
Copyright & Trademarks
Motorola Mobility Argentina S.A.
Suipacha 1111 - Piso 18
C1008AAW Buenos Aires
ARGENTINA
www.motorola.com
Certain features, services and applications are network dependent and may not
be available in all areas; additional terms, conditions and/or charges may apply.
Contact your service provider for details.
All features, functionality, and other product specifications, as well as the
information contained in this guide, are based upon the latest available
information and believed to be accurate at the time of printing. Motorola
reserves the right to change or modify any information or specifications without
notice or obligation.
Note:
The images in this guide are examples only.
MOTOROLA and the Stylized M Logo are trademarks or registered trademarks
of Motorola Trademark Holdings, LLC. All other product or service names are
the property of their respective owners.
© 2011 Motorola Mobility, Inc. All rights reserved.
Caution:
Motorola does not take responsibility for changes/modification to the
transceiver.
Product ID: MOTOROLA SCREEN MINI (EX132)
Manual Number: 68016088001-A
Product Model: Date of Purchase:
Seal of the authorized or established distributor where the “Product”
was purchased:
