Motorola Mobility LLC CDMA TRANSCEIVER WITH BT & WLAN User Guide
USERS MANUAL
EN
U.S. Cellular Customer Care
1-888-944-9400
06/13/2012
FCC
06/13/2012
FCC
1Congratulations
Congratulations
MOTOROLA Electrify™ 2
Introducing your new MOTOROLA ELECTRIFY 2, the
ultra thin, yet incredibly strong and intelligent phone. It
has tons of advanced features for everything you want
to do—web browsing, multimedia, and more.
•A blistering fast dual-core 1.2 GHz processor lets your
phone download web pages in under a second, and
makes multi-tasking a snap.
•Capture life's moments in full 1080p HD video with
your 8MP camera. Your phone’s 4.3" qHD
ColorBoost™ display makes video playback crisper
and more vivid than ever before.
Note: Certain apps and features may not be available in
all countries.
This product meets the applicable limit for
exposure to radio waves (known as SAR) of
1.6 W/kg (FCC & IC). The limits and guidelines
include a substantial safety margin designed to assure
Caution: Before assembling, charging, or using your
phone for the first time, please read the important
safety, regulatory and legal information provided with
your product.
the safety of all persons, regardless of age and health.
The highest SAR values measured for this device are
listed in the regulatory information packaged with your
product.
More
•Answers: Touch Apps >
Help Center.
• Updates: Phone updates, computer software, user
guides, and more at www.motorola.com/support.
• Accessories: Find accessories for your phone at
www.motorola.com/products.
•Social: The latest news, tips & tricks, videos, and so
much more—join us on:
YouTube™ www.youtube.com/motorola
Facebook™ www.facebook.com/motorola
Tw i t t e r www.twitter.com/motomobile.
06/13/2012
FCC
2Your phone
Your phone
the important keys & connectors
Note: Your phone might look a little different.
4:00
Camera
Text
Phone People
Play Store
Browser
Email
U.S. Cellular
Google
Calendar
Micro USB
Connector
SIM Slot
microSD Slot
3.5mm
Headset Jack
Volume Keys
Power Key
Press = sleep
Hold = power
8MP Camera
(on back)
Recent AppsHomeBack
Front
Camera
Notification
Light
Contents
Let’s go . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Controls. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Home screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Apps & updates . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Calls. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Contacts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Messaging. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Text entry . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Social networking. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Photos & videos . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Music . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Web . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Personalize. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
Location . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
Connect. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
Tips & tricks. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
Tools . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
Management . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
Security . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49
Safety, Regulatory & Legal. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50
06/13/2012
FCC
3Let’s go
Let’s go
let’s get you up and running
Assemble & charge
Note: To avoid SIM card damage, turn off your phone
before you insert or remove the SIM card.
Note: This product uses a non-removable battery. The
battery should only be replaced by a Motorola-approved
service facility. Any attempt to remove or replace your
battery may damage the product and void your warranty.
4:00
Camera
Text
Phone People
Play Store
Browser
Email
U.S. Cellular
Google
Calendar
Note: Pull
down the cover
to insert the
SIM and
microSD cards.
microSD in.
m
2
Br
Charge up.
3H
C
3
micro SIM micro SIM
+ Adapter
SIM in.
S
1
SIM
Tip: In the unlikely event that your device becomes
unresponsive, try a forced reboot—press and hold
both the Power key and the down volume key for up to
10 seconds.
Tip: To save battery life, see “Battery tips” on page 39.
Set up & go
4:00
Camera
Text
Phone People
Play Store
Browser
Email
U.S. Cellular
Google
Calendar
r
r
Select a language.
S
2
Welcome
English
n
d
d
d
a
a
a
ar
r
Complete initial
setup steps.
C
3
Setup
Connection failed
x
t
Finish.
er
S
US
US
C
. C
. C
ll
ell
ell
l
ula
ula
r
r
Fi
4
G
Goo
Goo
Goo
Goo
l
l
gle
gle
gle
gle
Turn on.
T
1
Start
Setup
Congratulations!
Your setup is now complete!
Done
If you have setup any accounts, we will
now import your content, such as
contacts and email. This may take up to
30 minutes but you can start using your
phone right away.
We recommend setting a Security Lock for
this phone by going into Settings >
Location & security.
Sign in
Email
Password
by signing in you agree to the Google and
Additional Privacy Policies.
Back Sign in
06/13/2012
FCC
4Controls
Note: This phone supports apps and services that use a
lot of data, so make sure your data plan meets your
needs. Contact your service provider for details.
Wi-Fi connect
To use a Wi-Fi network for even faster Internet access,
touch the status bar at the top of the home screen and
drag it down. Touch the Wi-Fi networks available
notification to select a network.
You can also touch Apps > Settings > Wi-Fi
>SCAN to search for and connect to wireless networks.
There’s more in “Wi-Fi networks” on page 35.
Cool content & more
Browse and download thousands of the coolest apps on
the planet from Google Play™ Store.
Download new apps with “Browse & install apps” on
page 10. You can install a microSD memory card in your
phone, and load it up with photos, videos, and music
from your computer (see “Memory card & file
management” on page 44).
Controls
a few essentials
Touch
It’s all in the touch:
•Touch: Choose an icon or option.
• Touch & Hold: Move items in the home screen.
• Drag or flick: Scroll slowly (drag) or quickly (flick).
• Pinch or double-touch: Zoom in and out on
websites, photos, and maps.
lark St
Wacker Dr
M
born St
N Micigan
W Lake St W Lake St
E Wacker Pl
State/Lake
Lake Randolph/
Wabash
M
M
M
E Randolph St
Slide two fingers
apart or together
to zoom in or out.
Drag or flick to scroll.
06/13/2012
FCC
5Controls
Lock, UNLOCK, on, & off
To lock the screen, press the Power key, or let the
screen time out (don’t press anything).
To unlock the screen, press the Power key, then
touch and flick to .
Your touchscreen is on when you need it and off when
you don’t.
•When you hold the phone to your ear during calls,
your touchscreen sleeps to prevent accidental
touches.
Charged
Text
Phone
Camera Unlock
4:00
Wed, May 23
Touch and flick to:
Touch and flick to
turn sound on/off.
unlock.
send a text.
open the camera.
make a call.
Unlock.
Phone
Camera.
Messaging.
•To make your touchscreen sleep or wake up, just
press the Power key.
•To change how long your phone waits before the
screen goes to sleep automatically, touch
Apps > Settings > Display > Sleep.
•To make the screen lock when it goes to sleep, see
“Screen lock” on page 47.
Note: You r
touchscreen might
stay dark if the sensor
just above it is
covered. Don't use
covers or screen protectors (even clear ones) that cover
this sensor.
Rotate the screen
When you turn your phone, the touchscreen can rotate
to stay right-side up:
Find it: Apps > Settings > Display > Auto-rotate
screen
06/13/2012
FCC
6Controls
Press
Back, home, & Recent apps
Tou ch H o m e to
close any menu or app
and return to the home
screen. In the home
screen, touch Recent
Apps to show the
most recent apps used,
then touch an app to
open it.
Touch Back to go back.
In some apps you can touch Menu to open menu
options, and touch to start a search.
Phone options menu
Press and hold the Power key to turn off your phone
(
Power off), turn off all wireless connections and put the
phone into low-power Sleep mode, turn Airplane mode on
and off, or change the sound setting.
Recent
Apps
Home
Back
Adjust volume
Press the volume keys to change
ring volume (in the home screen) or
earpiece volume (during a call).
When playing music or video files,
press the volume keys to adjust
media volume.
Screen capture
Share a screen capture of your
favorite playlist, or your new high score. If you can see it
on your phone, you can share it with your friends.
To capture the screen, press the Power key and down
volume key. Follow the instructions to name and store
the file.
06/13/2012
FCC
7Home screen
Home screen
quick access to the things you need most
Quick start: Home screen
The home screen gives you all your latest information in
one place. It’s what you see when you turn on the phone
or touch Home from a menu. It’s basically like this:
Note: Your home screen might look a little different.
4:00
Camera
Text
Phone People
Play Store
Browser
Email
U.S. Cellular
Google
Calendar
Status Bar
Flick left or right to see
more panels of widgets
& shortcuts.
Shortcuts
Touch to open.
Notifications
Drag this bar down to
see details. Flick notifications
left or right to dismiss them.
Favorites Tray
Touch Apps to see all
your apps & widgets.
Navigate
Back , Home &
Recent Apps .
Use & change your home screen
On your home screen, shortcuts are icons that open
your favorite apps, web bookmarks, contacts, mail
labels, playlists, and more. Widgets are live apps or tools
that provide news, weather, messages, and other
updates.
To see other panels of shortcuts and widgets, flick the
home screen left or right.
•To open something, touch it. Touch Home or
Back to return to the home screen.
Tip: When you open a widget, touch Menu to see
any options or settings. You can choose accounts for
Calendar, Email, and widgets.
•To resize widgets, touch
and hold a side until you
feel a vibration, then drag.
•To add shortcuts to the
home screen, touch
Apps , touch and hold an
app, then drag it to a spot
on the home screen.
To create a shortcut folder, drag one shortcut on top
of another to put them both in a folder. To add other
shortcuts, drag them onto the folder icon. To name
the folder, touch it and enter a name at the bottom.
Kristine Kelley
Not even ready to
go back to school
8
3pm
Budget Meeting
THU
JUL
3p
m
Bud
g
et Meetin
g
THU
JU
L
06/13/2012
FCC
8Home screen
•To add widgets, touch Apps , touch Widgets, then
touch and hold a widget (or flick left to see more
widgets).
•To move widgets or shortcuts, touch and hold them,
then drag to a new location.
•To remove shortcuts or widgets from the home
screen, touch and hold them, then drag to Remove at
the top.
•To change wallpaper, touch and hold a blank spot on
the home screen.
Shortcuts in the Favorites Tray at the bottom of the
home screen appear in all panel views. To change a
shortcut in your Favorites Tray (except Apps ), touch
and hold a shortcut, then drag it out of or into the
Favorites Tray.
phone status & notifications
Icons at the top of the screen notify you about
messages and phone status. To see your notifications,
touch the status bar and drag it down. Touch
a notification to select it.
To remove a notification from the list, flick it left or right.
To remove all notifications, touch .
network (full signal) 3G (fast data)
network (roaming) GPS active
network
(no connection)
Wi-Fi connected
Wi-Fi in range Bluetooth
connected
Bluetooth™ on background
data sync
USB connected warning
downloading missed call
active call microSD card
airplane mode
alarm set
new text message
Bluetooth share: Sent fill
2 successful, 0 unseccessful.
Current Battery Level: 93
batt temp: 26/26/26, cpu temp 26
11:23 AM
10:49 AM
wap.
vodafo
April 3, 2012
Status & notification icons.
Toggle icons.
Notification details.
06/13/2012
FCC
9Apps & updates
Note: Applications you download from Google Play™
Store may show other icons in the status bar to alert you
to specific events.
new email calendar event
reminder
new voicemail music player active
vibrate speakerphone on
sound off call muted
battery (charging) battery (full charge)
Apps & updates
get the app you want
Quick start: Apps & updates
Touch Apps in any home screen panel, then flick left
or right to see all your apps.
In the app list, touch All apps to view or create app
groups.
To add an app group, touch Menu > Add group to
home.
To close the app list, touch Home or Back .
Recent apps
Your phone remembers the apps that you used most
recently. From the home screen, touch Recent
New group
Frequent
All apps
Downloaded
WIDGETSALL APPS
Select your view.
Choose the app group
you want to see.
See more options.
Create a new app group.
06/13/2012
FCC
10 Apps & updates
Apps . To remove an app from the list, flick it left or
right.
Browse & install apps
Get all the fun games and cool apps you want! Google
Play™ Store provides direct access to apps, games,
books, and movies that you can download and install on
your phone.
Find it: Apps > Play Store
Scroll to and touch the app you want to install. Then,
touch Install (if app is free) or Buy.
New apps that you install are added to the app list.
Tip: Choose your apps and updates carefully, from
trusted sites, like Play Store, as some may impact
your phone’s performance—see “Choose carefully” on
page 10.
Note: When installing an app, make sure you read the
alerts that tell you what information the app will access.
If you don’t want the app to have access to this
information, cancel the installation.
Manage & restore apps
From the home screen, touch Apps > Settings
>Apps.
Touch an app in the list, then touch Uninstall (for apps
you downloaded), Clear cache, or other options.
Choose carefully
Apps are great. There's something for everyone. Play,
communicate, work, or have fun. But remember, choose
your apps carefully. Here are a few tips:
•To help prevent spyware, phishing, or viruses from
affecting your phone or privacy, use apps from trusted
sites, like Play Store.
•In Play Store, check the apps’ ratings and
comments before installing.
•If you doubt the safety of an app, don't install it.
•Like all apps, downloaded apps will use up memory,
data, battery, and processing power—some more
than others. For example, a simple battery level
widget will use less than a streaming music player
app. After installing an app, if you're not happy with
how much memory, data, battery or processing
power it's using, uninstall it. You can always install it
again later.
•Just like web browsing, you may want to monitor
children’s access to apps to help prevent exposure to
inappropriate content.
•Certain apps may not provide completely accurate
information. Take care, especially when it comes to
personal health.
06/13/2012
FCC
11Calls
Update my phone
You can check, download, and install phone software
updates using your phone, or using your computer:
•Using your phone:
You may get an automatic notification of an available
update on your phone. Simply follow the instructions
to download and install.
To manually check for updates, touch
Apps >
Settings > About phone > System
updates.
Your phone downloads any updates over your mobile
network. Remember, these updates can be quite
large (25MB or more) and may not be available in all
countries. If you don’t have an unlimited data plan, or
mobile network updates are not available in your
country, you can update using a computer.
•Using your computer:
On your computer, go to www.motorola.com/support
and check the “Software” links. If an update is
available, follow the installation instructions.
Calls
it’s good to talk
Quick start: Calls
Dialing options
Find it: Apps > Phone
Tip: If the screen is locked, touch and flick to .
DIALER PHONEBOOKRECENT
1 2ABC 3DEF
4GHI 5JKL 6MNO
7PQRS 8TUV 9WXYZ
0
Victor Harp
0 mins ago
10 mins ago
Mobile 555-555-4570
Mobile 555-555-0754
Cheyenne Medina
Recent Calls List
Touch an entry to call.
Delete
Delete digits you entered.
Open options, like Settings.
Most Recent Calls
Close dialpad.
Call
Enter a phone number
& touch here to call it.
Select phone numbers
from your People list.
06/13/2012
FCC
12 Calls
Tip: Search for contacts right from the dialpad. For
example, to find Jeff in your contacts list, touch 5-3-3-3.
Matching contacts appear above the number field.
In-call options
To use a Bluetooth™ device, touch Bluetooth. (The
device needs to be turned on and previously
paired—see “Connect new devices” on page 37.)
Victor Harp
Mobile (555) 555-4570 00:05
Add call End call Dialpad
Bluetooth Mute Speaker
Start recording
Open options, like
Hold call or Voice quality.
End Call
Speakerphone On/Off
Dialpad
Enter numbers during a call.
Mute/Unmute
Add Call
Add another person
to the call.
Record Call
Open Quick Notepad.
Tip: You can touch Home or Back to leave the
active call display. To reopen it, touch Home
>Phone.
Note: Using a mobile device or accessory while driving
may cause distraction and may be illegal. Always obey
the laws and drive safely.
Note: Recording of calls is subject to varying State and
Federal laws regarding privacy and recording of
conversations. Always obey the laws and regulations on
the use of this feature.
Make & answer calls
To make a call, touch Phone, enter a number, then
touch .
Tip: If the screen is locked, touch and flick to .
To answer a call, touch and flick to .
06/13/2012
FCC
13Calls
To ignore a call, touch
and flick to . If you
want to ignore an
incoming call, but send a
text message to the
caller, touch and flick
to . Select a message
and touch Send to send it.
Tip: To silence an
incoming call alert, press
the Power key or the
volume keys.
Note: When you hold the
phone to your ear, the
display goes dark to prevent accidental touches. When
you move the phone away from your ear, the display
lights up again.
Recent calls
Find it: Phone > Recent
•To call a number, touch next to the entry.
•To see call details, touch the entry.
•To send a text message, create a contact, view a
contact, or other options, touch and hold the entry.
•To search the recent calls list, touch .
•To clear the list, touch Menu > Clear list.
Quick responces
Can’t talk now. What’s up?
I’ll call you right back.
I’ll call you later.
Can’t talk now. Call me later?
Custom message... Send
Frequent calls
Find it: Apps >
People > Favorites
•To call, text, email, or view contact information, touch
the contact.
•To edit, share, delete, or set a ringtone for a contact,
touch the contact, then touch Menu .
Conference calls
To start a conference call, call the first number. After the
call connects, touch . Dial the next number, or select
it from contacts or favorites. When the next number
answers, touch
Merge.
Your phone number
Find it: Apps >
Settings > About phone > Status
>My phone number
Speed dial
Your phone can store nine phone numbers that you can
call with a single keypress. To store a speed dial
number, touch
Phone > Menu > Speed dial setup,
and insert a number in an empty speed dial slot.
To call a speed dial number, touch and hold the
single-digit speed dial number.
06/13/2012
FCC
14Calls
Voicemail
When you have a new voicemail, appears at the top
of the screen. Drag down the status bar and touch the
New voicemail notification to listen to your voicemail
message.
If you need to change your voicemail number, in the
home screen touch Phone >Menu >Settings
>Voicemail settings.
Emergency calls
Note: Your service provider programs one or more
emergency phone numbers that you can call under any
circumstances, even when your phone is locked.
Emergency numbers vary by country. Your
pre-programmed emergency number(s) may not work in
all locations, and sometimes an emergency call cannot
be placed due to network, environmental, or
interference issues.
1Touch Phone (if your phone is locked, touch and
flick to ).
2Enter the emergency number.
3Touch to call the emergency number.
Note: Your phone can use location based services (GPS
and AGPS) to help emergency services find you. See
“Location Services” on page 54.
Cool down
In very limited circumstances, such as where your
phone has been exposed to extreme heat, you may see
“Cool Down” messages. To avoid possible damage to
your battery and phone, you should follow these
instructions until the phone is within its recommended
temperature range. When your phone is in “Cool Down”
mode, only emergency calls can be made.
06/13/2012
FCC
15Contacts
Contacts
contacts like you’ve never had before
Quick start: Contacts
Find it: Apps > People
Tip: To search the list, touch to open a touchscreen
keypad, then type a name.
ICE
MEME
A
In case of emergency
Set up my profile
297 contacts
Abe Baudo
Astrid Fanning
Anna Medina
Avery Durning
Allie Smyth
A
B
C
D
E
F
G
H
I
J
K
L
M
N
O
P
Q
R
S
T
U
V
W
X
Y
Z
GROUPS FAVORITESPEOPLE
Create & view groups
of contacts.
Contacts List
Touch to view contact
information, then you can
call, send a text message, &
more.
Add contacts.
Touch a letter to jump to
contact names that start
with that letter.
View your favorites.
Transfer & sync contacts
Get all your contacts, all in one place:
•Use Gmail™
All your Gmail contacts will automatically get synced
to your phone. Various computer applications for
mobile phones and email accounts allow you to
export your contacts as a “.CSV” file. You can then use
Gmail to import the file. For more details, go to
www.motorola.com/transfercontacts or log in to your
Gmail account on your computer and select “Help”.
•More
There are other methods and tools to help you at
www.motorola.com/transfercontacts.
When you change one of your contacts, your phone
automatically updates your other social networking
accounts. When you change a social networking friend,
your phone updates your contacts.
06/13/2012
FCC
16 Contacts
Create contacts
Find it: Apps >
People >
Touch any entry area to open the touchscreen keypad.
When you’re finished, touch Done.
Where are contacts saved? Your phone gives you the
option to save new contacts in its memory, on your SIM
card, or your Google account. It also updates your social
networking account.
your.account@gmail.com
Set a picture.
Set the number type.
Remove a number.
Set where contact is saved
(Google, Local, or SIM).
Add another number.
Edit or delete contacts
Keep your contacts up to date and add a photo.
Find it: Apps >
People > contact > Menu
>Edit or Delete
Add a photo: Tou ch contact > Menu > Edit >.
Set a ringtone: Touch contact >Menu >Set ringtone.
View CONTACTS
When you set up a social networking account (see
“Social networking” on page 22), you’ll know what
everybody’s up to and when. Every time you pick up a
call, check a message, or look up a friend’s contact info,
you’ll see their name and number, but you can see their
social network status and smiling face, too.
Find it: Apps >
People
•To find a contact, touch and type a contact name.
Touch a contact to open its details. While viewing
details, you can start a call or message by touching
the phone number, messaging icon , email
address, or social network.
•To change which group of contacts is shown (like All
contacts or contacts from your Gmail account) touch
Menu > Contacts to display.
•To change how you view the list of contacts, touch
Menu > Settings > Display options.
06/13/2012
FCC
17Contacts
Groups
Find it: Apps >
People > GROUPS > group name
You can put your contacts into groups (like “Friends” or
“Family”). Then, you can find contacts faster by showing
one group at a time.
To create a new group, touch Apps > People
>GROUPS >.
Favorites
To add a contact to your favorites list, touch the contact
to open it, then touch .
To see your favorites list:
Find it: Apps >
People > FAVORITES
Combine contacts
You might have two or more contacts for the same
person, maybe a Gmail contact who is also stored on
your phone, or one friend with two email addresses. To
combine these contacts:
Find it: Apps >
People
Touch a contact to open it, touch Menu > Edit >
Menu > Join, then touch the second contact.
Call, TEXT, or email contacts
Find it: Apps >
People
Touch a contact to open it, then:
•To call touch, the contact’s number.
•To text message, touch next to the number.
•To email touch the contact’s email address.
06/13/2012
FCC
18 Messaging
Messaging
sometimes it’s best to text, or IM, or email . . .
Quick start: Messaging
Find it: Apps > Text Messaging
Tip: If the screen is locked, touch and flick to .
Tip: To see more messages, flick or drag up.
Y
our
l
ast messa
ge
I
’m fin
e
wi
t
h
t
h
at.
J
on An
d
erso
n
Free
l
ancers
We’re go
i
ng to nee
d
h
e
l
p w
i
t
h
t
h
e new..
.
Mary Morga
n
Meet
m
e
outs
i
de
t
h
e
t
h
eate
r
at
8
a
n
d
do
n’
t
don’t
f
or
g
et
y
our ID. Would
y
ou ma
y
be like
Ji
m Somer
s
M
eetin
g
invitatio
n
M
eeting is set
f
or next Thursday at 10:00
Arther Band
o
Mar 14
Mar
8
Feb 2
3
Feb 22
Feb 4
Cop
y
Revisions
Pl
ease ta
k
e a
l
oo
k
at t
h
e new rev
i
s
i
ons..
.
Anna Medin
a
Messaging
Create message.
Message List
Touch to open a message.
Open options.
Messaging search.
Read & reply to messages
Find it: Apps >
Text Messaging
•To open a text message and all of its replies, touch it.
•To respond to a text message, open it and enter your
response in the text box at the bottom.
•To delete a message, touch and hold to select it, then
drag it to the trash can .
•To adjust messaging options, touch Menu
>Settings in your message list.
Create messages
Find it: >
Text Messaging >
Enter the recipient and message. Touch Menu to
Insert smiley or Add subject, then touch Send.
Tip: To add an attachment, touch .
Send & receive attachments
To send a file in a message, touch .
When you receive a message with an attachment, open
the message and touch the file name to download it.
Then, touch the name again to open it. Some file
formats can be converted to HTML for faster viewing,
and your phone will show
Get HTML version.
While viewing the attachment, touch it to save it, share
it, and more.
06/13/2012
FCC
19Messaging
Tip: To send and receive large attachments faster, use a
Wi-Fi connection (see “Wi-Fi networks” on page 35).
Email
You can set up and use multiple email accounts on your
phone.
To add email accounts, touch Apps > Settings
>Accounts & sync > ADD ACCOUNT.
•Corporate is for Exchange server work email accounts.
Enter details from your IT administrator.
Tip: You might need to enter your domain name with
your user name (like domain/username).
•Email is for most personal email accounts. For
account details, contact the account provider.
To read and reply to messages on your email accounts,
touch Apps > Email.
Wireless Emergency Alerts
Wireless Emergency Alerts, also
known as CMAS or PLAN, is a U.S.
national emergency alert system.
Emergency alerts can pop up to tell
you about a national or local crisis.
After you close an alert, you can reopen it by touching
Apps > Emergency Alerts.
A
LERTS
WIRELESS
CAPABLE
EMERGENCY
TM
Tip: Emergency alerts have a special sound and
vibration that is two seconds long, followed by one
second, then another one second.
To choose which types of alerts you receive, touch
Apps > Emergency Alerts >Menu >Settings.
The U.S. and local governments send these alerts
through your service provider. So you will always receive
alerts for the area where you are, and you won’t receive
alerts if you’re outside of the U.S.
For more, visit www.ctia.org/consumer_info/safety/.
06/13/2012
FCC
20 Text entry
Text entry
keys when you need them
Touchscreen keypad
You can open a keypad on your screen by touching a text
box.
Tip: To close the keypad without saving any text (for
example, to select a different text box), touch Back .
Input methods
To select a text input method, touch and hold Space
to open the Select input method menu, then touch the
method you want.
asdfghj kl
zxcvbnm
.
ertyuiopqw
21 09876543
!?, :;
?123
Dinner at Bistro Fanta
Done
, :-)
Touch for numbers &
symbols.
Delete
Shift
Space
Text Box
Touch to open
keypad.
Shift
Motorola English input
Enter text a letter at a time. As you type, your phone
suggests words from your dictionary and chosen
language.
To add a word to your dictionary, touch the word, then
select
+ add to dictionary.
Swype
TM
Enter words with one continuous motion. Just drag your
finger over the letters in the word.
Tips:
•To enter apostrophes in common words (like “I’ll”),
drag through the n as though it was an apostrophe.
•To enter other punctuation, numbers, or symbols,
touch Symbols .
•To correct a word, double-touch it (tap twice, quickly).
Swype shows a small menu of other word options.
Anne Annex AbbeyAbbrAbbe
asd f gh j k l
zxcvbnm
ertyuiopqw
21 09876543
@$& _():;”
EN !# = /+ ?
+ ! =
Anne
Done
123
To enter a word,
just trace a path
through the
letters. To
capitalize, go
above the keypad.
For double letters,
circle the letter.
+
3
@
+
aa
nn
ee
aa
ee
06/13/2012
FCC
21Text entry
Swype might also show a menu if it can’t guess your
word.
•If Swype doesn’t know a word, you can still touch the
letter keys to enter it. Swype remembers, so next
time you can just drag over the letters.
Typing tips
To . . .
Enter one capital
letter
Tou ch S h i ft .
Enter only capital
letters
Touch and hold Shift .
Touch again to revert to
lowercase.
Move the text entry
cursor
Touch the text where you
want the cursor to go.
Select text Touch and hold text to
select it. If necessary, drag
the text boundary markers
to select the text you want.
Cut or Copy selected
text
Touch icons at the top of the
screen to Cut or Copy
selected text. In a landscape
display, touch Edit > Cut or
Copy.
Text input settings
Find it: Apps > Settings > Language & input
•To change the language for your phone and
touchscreen keypad, touch Locale.
•To change the default text input method, touch Default
under KEYBOARD & INPUT METHODS.
•To change text input settings, touch next to
Motorola English Input or Swype.
Paste cut or copied
text at cursor location
Touch the Paste icon at the
top of the screen. In a
landscape display, touch Edit
>Paste.
Delete character to left
of cursor
Touch Delete (hold to
delete more).
To...
06/13/2012
FCC
22 Social networking
Social networking
my life, your life
Quick start: social networking
You can add your Facebook, Twitter, or other social
networking accounts. If you don’t have accounts on
these sites, visit their websites to set them up.
Find it: Apps > Settings > Accounts & sync > ADD
ACCOUNT
Add an account by touching it. Then enter your user
name and password for that account.
When you sign into social networking accounts, you’ll
see your friends and contacts in your Contacts list.
Tip: To download updates faster, see “Wi-Fi networks”
on page 35.
Edit & delete accounts
Find it: Apps > Settings > Accounts & sync
To sync an account, touch account name > Menu >
>Sync now.
To delete an account, touch account name >Menu
>Remove account.
Photos & videos
see it, capture it, share it!
Photos
Take & share photos
Find it: Apps > Camera
Tip: If the screen is locked, touch and flick to .
756 Honolulu, HI756 Honolulu, HI
Switch between front
& back cameras.
Drag to
Zoom in/out. Tak e
photo.
Shots
Remaining
See your
last photo.
Adjust camera
settings.
Autofocus Box
Touch screen to
change focus location.
Drag to
switch to
camcorder.
06/13/2012
FCC
23Photos & videos
Note: Photos are stored in your phone’s internal
memory, unless you switch it to a microSD memory
card. Photo resolution can be set to 8MP or
Widescreen (6MP).
Tip: Press the volume keys to zoom in and out on the
viewfinder image.
To take the photo, touch in the viewfinder screen.
Your phone stores the photo, and shows a thumbnail
image in the corner of the screen. To see the photo you
just took, touch the thumbnail. Then:
•To set the photo as a wallpaper, contact photo, or
social network photo, touch Menu > Set picture as.
•To share the photo in a message or post it online,
touch . For more info on sharing your photos, see
“Share photos & videos” on page 26.
•To upload the photo to an online photo album,
touch Menu > Quick upload.
•To print the photo, touch Menu > Print (follow the
on screen instructions to set up a printer).
•To delete the photo, touch Menu > Delete.
Panoramic photos
In the viewfinder, drag the tab in the lower left corner,
then touch Modes > Panorama to take a wide panoramic
photo. The camera auto-captures up to six multiple
shots as you move the camera, and joins them together
to make one large image.
Camera settings
Drag the tab in the lower left corner of the viewfinder to
adjust camera settings:
Options
Settings •Widescreen (6MP or 8MP photo
resolution)
•Video Resolution (1080p, 720p, DVD,
VGA, or QVGA)
•Volume Key Function (use volume
keys to zoom)
•Geo-tag (add location information
to pictures taken)
•Video stabilization (reduces hand
shaking during video capture)
•Storage Location (phone or
microSD memory card)
•Shutter Tone
Effects Set a photo effect: Normal, Black and
White, Negative, and more.
Scenes Set the type of photo you want to
take: Auto, Portrait, Landscape, Sport,
and more.
06/13/2012
FCC
24Photos & videos
Modes Set to Single shot, Panorama,
Multi-shot, or Timer.
Exposure Select an exposure setting.
Flash Set Flash On, Flash Off, or Auto Flash.
Options
Videos
Record & share videos
Find it: Apps >
Camera, then drag the camera
switch to the right.
To record a video, touch in the viewfinder screen. To
stop the video recording, touch again.
Your phone stores the video, and shows a thumbnail
image of the video in the corner of the screen. To see
the video you just took, touch the thumbnail. Then:
HD
HD
01:13:12 Los Angeles, CA
01:13:12 Los Angeles, CA
Switch between front
& back cameras.
Record
video.
Watch your
last video.
Adjust camcorder
settings.
Time
Remaining
Zoom
in/out.
Switch to
camera.
06/13/2012
FCC
25Photos & videos
•To play the video, touch .
•To share the video in a message or post it online,
touch . For more info on sharing your video, see
“Share photos & videos” on page 26.
•To delete the video, touch Menu > Delete.
HD videos
You can capture HD-quality videos to watch on an HDTV
or monitor.
To record an HD-quality video, be sure to select the
correct Video resolution. From the active camcorder
viewfinder screen, drag the tab in the lower left corner
of the viewfinder screen, then touch Settings > Video
Resolution > HD+ (1080p) or High Definition (720p).
Camcorder settings
Drag the tab in the lower left corner of the viewfinder to
adjust camcorder settings:
Options
Settings •Widescreen (6MP or 8MP photo
resolution)
•Video Resolution (1080p, 720p, DVD,
VGA, or QVGA)
•Volume Key Function (use volume
keys to zoom)
•Geo-tag (add location information
to pictures taken)
•Video Stabilization (reduce
shakiness during video capture)
•Storage Location (phone or
microSD memory card)
Effects Set a video effect: Normal, Black and
White, Negative, and more.
Audio Scenes Set sound recording options: Stereo,
Wind Reduction, or Concert.
Modes Set to Normal video, Video Message, or
Time Lapse.
Exposure Select an exposure setting.
Light Turn the camcorder light on or off.
06/13/2012
FCC
26 Photos & videos
View photos & videos
Find it: Apps >
Gallery
View all of your photos and videos.
Note: To see the controls when a video is playing, touch
the display.
Share photos & videos
Find it: Apps >
Gallery > photo or video
SCREEN NOT YET AVAILABLE
Touch , then choose how you want to share—like
Bluetooth, Email, Messaging, or an online album.
Manage photos & videos
Find it: Apps > Gallery > photo or video
Touch Menu , then select an option from Edit, Delete,
Set Picture as, Add to album, and more.
Tip: To copy photos to/from a computer, go to “USB
cables” on page 38.
Edit photos & videos
Find it: Apps > Gallery > photo or video
Tou ch M e n u > Edit. You can choose advanced editing
features to resize, crop, or change the color. To undo a
change, touch . When you’re finished, touch SAVE.
06/13/2012
FCC
27Music
Music
when life needs a soundtrack
Quick start: Music
Listen and create playlists anytime, with music on your
phone.
Find it: Apps > Play Music
SONGS GENRESPLAYLISTS
Last added
Allie live shows
Portland
road trip
summer songs
workout 1
Allie’s mix
Song Title
Artist
Flick left or right for songs,
playlists & more.
Shop
Search
Playlist
Settings
During a song:
Open details & settings.
Touch to skip or hold to scan.
Touch for options
• Go back: When you open a song or artist list,
touch in the top left to go back.
• Shuffle or repeat: During a song, touch to show
shuffle and repeat at the bottom. Touch
once to repeat the current song list, or twice to repeat
only the current song.
• Volume: Press the volume keys.
Get music
Transfer
Transfer music from your computer to your phone using
a USB cable connection. See “USB cables” on page 38 to
learn how.
Tips & tricks
• Hide the music player: To use another app while
your music plays, touch Home . To return to the
music player, flick down the status bar and touch the
song title.
Tip: Control music playback from the home screen by
adding the Google Play Music widget.
•Playlists: Touch and hold a song in your library to add
it to a playlist or show other options. To edit, delete
and rename a playlist, touch and hold its name in the
music library.
•Help: To get help or access your Google Play™ Music
with a computer, visit www.google.com/music.
06/13/2012
FCC
28 Music
• During a flight: Press and hold Power > Airplane
mode to turn off all your network and wireless
connections and listen to music during a flight.
FM Radio
Find it: Apps > FM Radio
Note: You need to connect a wired headset to your
phone to use the FM radio. The wires in your headset
Favorites
1
.5
103.5
KCZU
K
0
Favorites
Favorites
Favorites
Favorites
1.5
K
C
Z
U
K
0
103.5 1
08
.0
103.5
KCZU
K
0
Touch start to add
station to favorites.
Drag finger across
dial to tune station.
Play/Stop Radio
Seek Previous/Next
act as the antenna. For best performance, use a
Motorola Original headset. Indoor reception may vary.
Find a station
To tune into a station, drag your finger across the dial.
Station Presets
The first time you use the FM radio, your phone will
prompt you to scan for radio stations. All stations found
are added to your presets.
To add a station to your presets, touch the star in the
upper right corner of the station listing.
set FM radio region
To set your phone’s FM tuner to your region, touch
Apps > FM Radio > Menu > Settings > FM radio
region.
06/13/2012
FCC
29Web
Web
surf the web with your phone
Quick start: Browser
Find it: Apps > Browser
Tip: To zoom in, touch the display with two fingers, then
move them apart.
www.google.com/
Web Images Places News more
Restaurants
Chicago, IL - update
Bars More
History Sign out
Coffee
your.account@gmail.com
SettingsiGoogle Help
View Google in: Mobile Classic
Touch a link to select it.
Touch & hold for more
options.
Touch for
browser options.
View open browser tabs,
or open a new tab.
update
Connect
Your phone uses the mobile phone network (over the air)
or a Wi-Fi connection to automatically access the web.
Note: Surfing the web or downloading data over the
mobile phone network uses your monthly data
subscription allowance.
To use a Wi-Fi network for faster Internet access, touch
the status bar at the top of the home screen and drag it
down. Touch the
Wi-Fi networks available notification to
select a preferred network. For more info, see “Wi-Fi
networks” on page 35.
Note: If you can’t connect, contact your service provider.
Downloads
To download files in your browser, touch a file link or
touch and hold a picture to choose
Save image.
To see the files you downloaded, touch Apps
>Downloads. Touch and hold an item to open it,
see details, or remove it from the list.
You can download “Apps & updates” on page 9.
06/13/2012
FCC
30 Web
Browser options
Touch Menu to see browser options:
Options
Refresh Reload the current page.
Save to
bookmarks
Bookmark the current web page.
Request
desktop site
Open the standard desktop website
instead of the mobile device version.
Bookmarks See your bookmarks.
Save to
bookmarks
Bookmark the current web page.
Share page Share current page via text message
email, and more.
Find on page Find a word or phrase on the current
page.
Request
desktop site
Switch from mobile site to standard
desktop site.
Save for offline
reading
Save current page for offline reading
Settings Adjust browser settings.
Print Print page.
Exit Close the browser app.
YouTube™
Share videos with YouTube users everywhere. You don’t
need a YouTube account to browse and view videos.
Find it: Apps >
YouTube
Note: If you want a YouTube account, go to
www.youtube.com. To create an account or sign in,
touch ACCOUNT.
06/13/2012
FCC
31Personalize
Personalize
add your personal touch
Widgets
Add widgets
Fill your home screen with widgets—make it yours.
Touch Apps > Widgets, touch and hold a widget, then
drag it to a spot on the home screen.
Tip: Flick left to see more widgets.
Personalize widgets
You can customize some widgets. Touch a widget to
open it, then touch Menu .
Your home screen may already have these widgets:
•Favorite People: Quickly call, text, or email your
favorite contacts. To add people to your Favorites list,
see “Favorites” on page 17.
•Calendar: Sync your calendars and review upcoming
events at a glance with the scrollable calendar widget.
To add calendar events, see “Calendar” on page 39.
•News & Weather: Hand pick the news topics that
interest you, then customize downloads and refresh
rates for access to the latest info. See weather
reports for your current location, and for any other
locations you specify.
Shortcuts
To add app shortcuts to the home screen, touch
Apps , touch and hold an app, then drag it to a spot on
the home screen.
Tip: To change a shortcut in your Favorites Tray (except
Apps ), touch and hold a shortcut, then drag it out of
or into the Favorites Tray.
Ringtones
•To personalize your ringtones, touch Apps
>Settings >Sound > Phone ringtone or Default
notification.
•To make your phone ring and vibrate, touch Apps
>Settings > Sound > Vibrate and ring.
•To silence your phone and make it vibrate for
incoming calls, touch Apps > Settings > Sound
>Silent mode > Vibrate.
•To set a ringtone for a contact, touch Apps
>People > contact > Menu > Set ringtone.
Wallpaper
To apply a new wallpaper, touch and hold an empty spot
on your home screen, then choose a wallpaper image
from Live wallpapers, Gallery, or Wallpapers.
06/13/2012
FCC
32 Personalize
Sounds
•To set volume for ringtones, media, and alarms, touch
Apps >
Settings > Sound > Volumes.
•To play dial pad tones, touch Apps > Settings
>Sound > Dial pad touch tones.
•To play sounds for screen selections, touch Apps
>Settings > Sound > Touch sounds.
•To customize the sound settings for media and
videos, touch Apps > Settings > Sound >
Speaker (internal) or Wired stereo devices (connected
external speakers).
Display
•To set display brightness, touch Apps >
Settings > Display > Brightness.
•To set orientation, touch Apps > Settings
>Display >Auto-rotate screen.
•To set the font size for menus and settings, touch
Apps > Settings > Display > Font size.
Date & time
Set date, time, time zone, and formats:
Find it: Apps >
Settings > Date & time
Language & region
Set your menu language and region:
Find it: Apps >
Settings > Language & input
>Locale
Smart actions
Tired of doing the same tasks over and over again? Let
Smart Actions do them for you. You can create rules to
do things, like automatically dim the touch screen when
the battery is low, set your ringer to vibrate at work, and
set a different wallpaper at home.
Find it: Apps >
Smart Actions
To learn how to use Smart Actions, open the Smart
Actions app and touch Menu > Help.
06/13/2012
FCC
33Location
Location
where you are, where you’re going
Google Maps™
Find it: Apps > Maps
Note: The map image you see may be a little different.
g
hts
Arlington Heights
Schaumburg
Elmhurst
Elmhurst
Oak Park
Addison
Addison
Cicero
Cicero
Oak Lawn
Oak Lawn
East
East
Chicag
oChicago
Chicago
Evanston
Evanston
Des Plaines
Des Plaines
Elmwood
Elmwood
Park
La Grange
La Grange
Harvey
Harvey
Calumet
Calumet
City
City
Hammond
Orland Park
Orland Park
GGary
Tinley Park
Blue Island
Blue Island
Northbrook
Northbrook
Chicago
Hei
g
hts
Highland
Highland Park
Highland Park
Grove
Buffalo Grove
e
lein
g
hts
Elmhurst Oak Park
Addison
Cicero
Oak Lawn
East
Chicag
o
Chicago
Evanston
Des Plaines
Elmwood
Park
La Grange
Harvey
Calumet
City
Hammond
Orland Park
G
Tinley Park
Blue Island
Northbrook
Chicago
Hei
g
hts
Highland
Highland Park
Grove
e
lein
294
3
55
290
94
94
90
80
k
k
k
Chicago, IL
C
C
C
A
A
A
A
A
A
A
A
A
ein
ein
e
ele
e
ein
ein
e
e
e
e
e
e
ee
ee
ee
ee
leinlein
ee
ee
ee
elein
k
k
k
k
k
Chicago
Ch
h
h
h
H
and
h
H
d
ao
o
dd
ammoammo
oo
n
n
mm
m
m
m
aa
H
dd
aa
Hammond
y
Tinley
Tinley Parkinley Pa
aa
Tinley Parkey Park
arkark
arka
yy
aa
aa
aa
aa
ee
ee
kk
kk
kk
kk
rr
rr
rr
Tinley ParkTinley P
kk
kk
aa
ee
ee
k
k
k
k
P
Tinley Park
o
g
Chicago
Chicago
Chicago
go
a
a
a
a
gg
gg
Chica
Chica
aa
aa
cagocago
oo
hihi
aa
gogo
Chi
i
Chicago
Heights
Heights
ss
ghgh
ghh
gg
gg
gg
ss
ss
eighteight
hh
hh
HeigHeig
gg
s
s
ss
Heiei
Heights
g
g
g
Highland
Highland
ghlan
ghla
gg
gg
andand
aa
nn
nn
HighlandHighland
gg
Hi
i
Highland
3
5
5
80
Maps
Select a map or
navigation view.
Add Layers of information
to map view.
Find nearby Places.
Get Directions.
Center the map on my
location.
Search maps.
Touch for options like,
My Places & Help.
Google Maps offers powerful, user-friendly mapping
technology and local business information—including
business locations, contact information, and driving
directions.
For help, touch Menu > Help.
Tip: Want to know what’s in your immediate area? Try
Google Places™. Touch Apps > Maps, touch the
Maps view control in the upper-left, then touch Places to
see listings for restaurants, cafes, bars, and more, based
on your current location.
Navigation
Google Maps Navigation Beta™ is a complete GPS
navigation system with voice guidance that shows you
the way.
Find it: Apps > Navigation
Follow the prompts to speak or type your destination.
For more information, go to
www.google.com/mobile/navigation.
Google Latitude™
See where your friends and family are on Google Maps.
Plan to meet up, check that your parents got home
safely, or just stay in touch.
Don’t worry, your location is not shared unless you agree
to it. You need to join Google Latitude, and then invite
06/13/2012
FCC
34Location
your friends to view your location or accept their
invitations.
To get started, touch Apps > Latitude >Join
Latitude. Then:
•To start Google Latitude, touch Apps
>Latitude.
•To add friends, touch FRIENDS LIST >.
•To remove friends, touch FRIENDS LIST, touch a friend
in your list, then touch Remove this friend.
•To turn off Google Latitude, touch your Latitude
name tag in map view, then touch Edit privacy settings
>Sign out of Latitude.
Your navigator deluxe
With Your Navigator Deluxe, get all of the features of an
advanced car navigation system or your mobile phone
with voice turn-by-turn navigation enabled by GPS.
Search for any destination including gas stations, ATMs,
restaurants, and more. Get detailed maps of any
location.
Find it: Apps > Your Navigator
1In order to use Your Navigator Deluxe, you must first
turn on your phone’s location and GPS settings.
2From the applications menu select the Your Navigator
Deluxe application.
From the You Navigator Deluxe Home screen you can
select:
•“Drive To” for turn by turn direction to an address,
airport, contacts addresses and more
•“Places” to search for nearby businesses, the
cheapest gas prices and more
•“Maps & traffic” to see where you currently are
located on a map and what traffic is in the area
06/13/2012
FCC
35Connect
Connect
wired or wireless
Quick start: Wireless
Connect your phone to fast Wi-Fi networks or
Bluetooth™ devices.
To connect, touch Apps > Settings > Wi-Fi or
Bluetooth.
ON
WLAN
Network 1 Name
Connected
Network 2 Name
Network security type
Network 3 Name
Network security type
SCAN ADD NETWORK
ON
Bluetooth
SEARCH FOR DEVICES
AVAILABLE DEVICES
XT885
Not visible to other Bluetooth devices
TOUCH TO PAIR
Motorola Headset
Connect to this network.
Turn Wi-Fi power on & off.
Connect to this device.
Turn Bluetooth
power on & off.
Wi-Fi networks
Turn Wi-Fi power on or off
Tu rn o n : Touch Apps >
Settings, then drag the
Wi-Fi power switch to the right.
Tu rn o f f : Drag the Wi-Fi power switch to the left.
Note: To extend battery life, turn off Wi-Fi power when
not in use.
Wi-Fi search & connect
When Wi-Fi is on, the Wi-Fi in range indicator
appears in the status bar when a network is available.
Drag down the status bar and touch the
Wi-Fi networks
available notification to select and connect to a network,
that you have used before.
To search for a network when Wi-Fi is off:
1Touch Apps > Settings > Wi-Fi.
2Drag the Wi-Fi power switch to the right to
turn on and scan. If Wi-Fi power is already on,
touch SCAN. Your phone lists the networks it finds
within range.
Tip: To see your phone’s MAC address or other Wi-Fi
details, touch Menu > Advanced.
3Touch a network to connect. If necessary,
enter Network SSID, Security, and Password, and touch
Connect.
OFF
ON
OFF
06/13/2012
FCC
36 Connect
When your phone is connected to the network, the
Wi-Fi connected indicator appears in the status bar.
Tip: When you are in range and Wi-Fi power is on, you
will automatically reconnect to available networks you’ve
connected to before.
Wi-Fi hotspot
You can make your phone a Wi-Fi hotspot to provide
portable, convenient internet access to other Wi-Fi
enabled devices.
Caution: This application significantly impacts battery
life. You may want to run this application with the
charger connected.
Note: You need to subscribe to Wi-Fi hotspot service to
use this feature. Contact your service provider.
To set up your phone as a Wi-Fi hotspot:
1Touch Apps > Settings > Tethering &
Mobile Hotspot > Mobile Hotspot to turn on the
hotspot.
2Touch Mobile Hotspot settings > Configure Mobile
Hotspot to change hotspot security and configuration
settings:
•Network SSID: Enter a unique name for your
hotspot and touch Next.
•Security: Select WPA2 PSK. Enter a unique
password. Other users can access your Wi-Fi
hotspot only if they enter the correct password.
Note: Keep it secure. To protect your phone and
hotspot from unauthorized access, it is strongly
recommended that you set up hotspot Security
(WPA2 is the most secure), including password.
•Broadcast Channel: Select a channel that
minimizes potential interference. You may need
to try different channels after your hotspot is
active for a time.
3Tou ch Save when the settings are complete.
When your Wi-Fi hotspot is active, other Wi-Fi enabled
devices can connect by entering your hotspot’s SSID,
selecting a Security type, and entering the correct
Password.
Wi-Fi modes
For those who like to get a bit more technical, your
phone supports the following Wi-Fi modes:
802.11 b, g, n.
Bluetooth wireless
Turn Bluetooth power on or off
Tu rn o n : Touch Apps > Settings, then drag the
Bluetooth power switch to the right.
OFF
06/13/2012
FCC
37Connect
Tu rn o f f : Drag the Bluetooth power switch to the
left.
Note: To extend battery life, turn off Bluetooth power
when not in use.
Connect new devices
Note: This feature requires an optional accessory.
To connect with a new device, you need to pair with it.
You only need to do this once for each device—to
connect again, just turn on the device.
1Make sure the device you are pairing with is in
discoverable mode.
Note: Refer to the guide that came with the device
for details.
2Touch Apps > Settings > Bluetooth.
3Drag the Bluetooth power switch to the right to
turn on and scan. If Bluetooth power is already on,
touch SEARCH FOR DEVICES.
4Touch a device to connect.
5If necessary, touch OK, or enter the device passkey
(like 0000) to connect to the device. When the device
is connected, the Bluetooth connected indicator
appears in the status bar.
Note: Using a mobile device or accessory while driving
may cause distraction and may be illegal. Always obey
the laws and drive safely.
ON
OFF
Reconnect devices
To automatically reconnect your phone with a paired
device, simply turn on the device.
To manually reconnect your phone with a paired device,
touch the device name in the
AVAILABLE DEVICES list.
Disconnect devices
To automatically disconnect your phone from a paired
device, simply turn off the device.
To manually disconnect your phone from a paired device,
touch the device name in the devices list, then touch
OK.
Change device name
Touch Apps >
Settings > Bluetooth, turn Bluetooth
power on, then touch Menu > Rename phone. Enter a
name and touch OK.
PRINTERS
Print email, documents, pictures, and contacts directly
to shared printers on a Wi-Fi network—no printer drivers
necessary. You can even save your favorite printers and
geo-tag their location for future use.
Print a document or file
To print something from the
Email, Quickoffice, or Gallery
apps, open it and touch Menu > Print.
06/13/2012
FCC
38 Tips & tricks
Add a printer
Open the document or file you want to print, then touch
Menu >
Print > Add printers.
USB cables
You can connect your phone to a computer with a USB
cable.
Note: The first time you use a USB connection, your
computer may indicate that drivers are being installed.
Follow any prompts you see to complete the installation.
This may take a few minutes.
1With your phone showing the home screen, connect
a Motorola micro USB data cable from your phone’s
micro USB port to a USB port on your computer. Your
phone should show in the status bar.
Note: Make sure to connect the phone to a high
power USB port. Typically, these are located directly
on your computer.
2Drag and drop files between your computer and
phone folders. When you’re done, use “Safely
Remove Hardware” before disconnecting the USB
cable.
Note: You can’t use files on an installed
microSD memory card while your phone is connected to
the computer.
Tips & tricks
a few handy hints
General tips
•Screen brightness changes as your phone senses the
current lighting conditions.
•To return to the home screen, touch Home .
•To see recently dialed numbers, touch Phone
>Recent.
•To sleep/wake your phone, press the Power key.
•To set screen timeout, touch > Settings
>Display > Sleep.
•To search, touch Apps > Search.
•To automate everyday tasks, touch Apps
>Smart Actions (touch Menu > Help, in the app
to learn more).
•To show the most recent apps you’ve used, touch
Recent Apps .
•To change a shortcut in your Favorites Tray (except
Apps ), touch and hold a shortcut, then drag it out
of or into the Favorites Tray.
•To turn sound on/off, press and hold the Power key,
then touch or .
•To turn airplane mode on/off, press and hold the
Power key > Airplane mode.
06/13/2012
FCC
39Tools
Battery tips
Want to extend your battery life? Try these:
•To help minimize battery use, touch Apps
>
Smart Actions. Check out the sample rules that
enable battery savings: Nighttime Battery Saver, and
Battery Extender.
•To turn off background data transfers, touch Apps
> Settings > Data usage >Menu >Restrict
background data.
•To turn off Bluetooth power, touch Apps >
Settings, then drag the Bluetooth power
switch to the left to turn it off.
•To turn off Wi-Fi power, touch Apps > Settings,
then drag the Wi-Fi power switch to the left to
turn it off.
ON
ON
Tools
stay on top of things
Calendar
Find it: Apps > Calendar
Your calendar events can be
viewed in different ways:
Touch the date, then touch
Day, Week, Month, or Agenda.
When you highlight an event,
more details appear.
Tip: To add a calendar widget
to your home screen, touch
Apps > Widgets, touch
and hold Calendar, then drag
it to a spot on the home
screen.
Add calendar events
From any view, touch
Menu > New event. Enter
the event start time and other details. You can even set a
reminder so you don’t forget about the event. (When
you set the reminder time to 0minutes, it plays at the
event start time).
Tip: Reminders will play only if you’ve selected a
notification ringtone (see “Ringtones” on page 31).
06/13/2012
FCC
40Tools
When you finish entering event details, touch DONE.
Manage calendar events
To edit an event, touch it, then touch Edit event. When
you’re done, touch DONE.
To delete an event, touch it, then touch .
Tasks
Find it: Apps > Tasks
To add a task, touch .
From the tasks main screen, touch All tasks to view your
tasks by due date, priority, and more.
Tip: To add a tasks widget to your home screen, touch
Apps > Widgets, touch and hold Task, then drag it to
a spot on the home screen.
Calculator
Find it: Apps > Calculator
To switch between basic and advanced functions, touch
Menu > Advanced panel or Basic panel. To clear
history, touch Menu > Clear history.
Alarm clock
Find it: Apps > Alarm & Timer
To turn on an alarm, touch the check box.
12345
12345
When an alarm sounds, select Dismiss to turn it off or
touch the screen to snooze for five minutes.
To add an alarm, touch , then enter alarm details.
To enable or disable an alarm, touch the check box.
Accessibility
See, hear, speak, feel, and use. Accessibility features are
there for everyone, helping to make things easier.
Note: For general information, accessories, and more,
visit www.motorola.com/accessibility
Voice recognition
Use your voice—just touch and speak.
• Dialing and commands: Touch Apps > Voice
Commands. To dial, say “Call” and then a contact
name or phone number. Or, say a command from the
list shown, like “Send Text” or “Go To”.
•Search: Touch in the search widget, then say what
you want to search for, like “Motorola accessories”.
• Text entry: Touch a text entry field to open the
touchscreen keypad. Touch , then say what you
want to type.
Tip: Speak naturally, but clearly. Use the microphone in a
similar way to a speakerphone, so no need to shout or
hold the phone close to your mouth.
06/13/2012
FCC
41Tools
To change your voice settings, see “Voice settings” on
page 41.
Voice readouts (TalkBack)
Your navigation and selections, read out loud.
To turn on TalkBack, touch Apps > Settings
>Accessibility > TalkBack.
Note: You may be asked to download additional
“text-to-speech” software (data charges may apply).
To use voice readouts:
• Menus and screens: In menus and screens, touch an
item to highlight it (the item will be read out loud), and
double-touch to open it.
Note: Touch a home screen widget or shortcut to
open it.
• Dialer & text entry: As you type, each number or
letter is read out loud.
• Notification: When you flick the notifications bar
down, all notifications are read out loud.
Tip: Navigate through your apps and menus to hear how
voice readouts work on your phone.
To change your voice settings, see “Voice settings” on
page 41.
Caller ID
When you want to hear who’s calling:
• Read out loud: Have your caller announced—touch
Apps > Settings > Accessibility > Caller ID
Readout.
Tip: To set Caller ID Readout, you can also touch
Phone >Menu > Caller ID Readout.
• Ringtones: Assign a unique ringtone to a
contact—touch People, touch a contact, then
touch Menu > Set ringtone.
To change your voice settings, see “Voice settings” on
page 41.
Voice settings
Personalize your voice settings:
• Voice recognition: Touch Apps > Settings
>Language & input > Voice Search. From here, you
can set options like language and censorship.
• Voice commands: Touch Apps > Voice
Commands > . From here, you can refine
recognition of your voice (Adaptation) and set options
like prompts and shortcuts.
• Text-to-speech: Touch Apps > Settings
>Language & input > Text-to-speech output. From
here, you can set options like speed and language.
Volume & vibrate
Choose volume and vibrate settings that work for you.
Touch Apps > Settings > Sound:
06/13/2012
FCC
42Tools
• Volume: Tou ch Volumes and use the sliders.
Tip: To set separate ring and notification volumes,
uncheck Use incoming call volume for notifications.
• Vibrate: Select Vibrate and ring to feel your phone
ring.
Zoom
Get a closer look. To zoom in, touch the screen with two
fingers and then slide them apart. To zoom out, slide
your fingers together.
Display brightness
Set a brightness level that works for you. Touch Apps
> Settings > Display > Brightness. Make sure that
Automatic brightness is unchecked so you can set your
own level.
Touchscreen & keys
All these touch features are great, and sometimes it’s
nice to hear or feel your touches too. Touch Apps
>Settings > Sound:
• Touchscreen: To hear screen touches (clicks), select
Touch sounds.
•Keys: To feel key touches (vibrate), select Vibrate on
touch.
•Screen lock: To hear when you lock/unlock the screen
(click), select Screen lock sound.
Messages
From a simple text message to IM, email, and more.
Create, send, and receive messages.
Find it: Apps > Text Messaging
And to make text entry even easier, you can use
features like auto-correct, auto-punctuate, and
auto-capitalization—touch Apps > Settings
>Language & input, then touch next to Motorola
English Input.
Hearing aids
To help get a clear sound when using a hearing aid or
cochlear implant, your phone may have been rated for
use with hearing aids. If your phone’s box has “Rated for
Hearing Aids” printed on it, then please read the
following guidance.
Note: Ratings are not a guarantee of compatibility, see
”Hearing Aid Compatibility with Mobile Phones” in your
legal and safety information. You may also want to
consult your hearing health professional, who should be
able to help you get the best results.
•Settings: Touch Phone >Menu > Settings
>HAC mode settings.
• Call volume: During a call, press the side volume
keys to set a call volume that works for you.
06/13/2012
FCC
43Tools
•Position: During a call, hold the phone to your ear as
normal, and then rotate/move it to get the best
position for speaking and listening.
TTY
You can use your phone in TTY mode with standard
teletype machines. Touch Phone >Menu > TTY
mode and select the mode you need:
•TTY Full: Type and read text on your TTY device.
•TTY HCO: Hearing-Carry-Over—type text on your TTY
device and listen to voice replies on your phone’s
speaker.
•TTY VCO: Voice-Carry-Over—speak into your phone
and read text replies on your TTY device.
Note: You’ll need a cable/adapter to connect your TTY
device to the headset jack on your phone.
Refer to your TTY device guide for mode and usage
information.
Apps
Want more? No problem. Google Play™ Store provides
access to thousands of apps, and many provide useful
accessibility features.
Find it: Apps > Play Store
Select a category or touch Search to find the app
you want.
Tip: Choose your apps carefully, from trusted sites like,
Play Store, as some may impact your phone’s
performance.
06/13/2012
FCC
44 Management
Management
stay in control
Memory card & file management
Your photos, videos, and other files are automatically
stored in your phone’s internal memory. You can set
individual applications (camera, camcorder, etc.) to store
files on a microSD card. To install a microSD card, go to
“Assemble & charge” on page 3.
Tip: To move media from internal memory to a
microSD card, touch Apps > Settings > Storage
>Manage internal storage.
Delete or share files on your phone
Find it: Apps > Files > Internal phone storage or
SD card
Touch a file or folder to open, then touch and hold a file
to Delete or Share.
Remove a microSD card
Note: Do not remove a microSD card while your phone
is using it or writing files on it.
Before you remove a microSD card you need to stop
your phone using it. Touch Apps > Settings >
Storage > Unmount SD card.
Data usage
You can track the amount of data uploaded and
downloaded by your phone, and set a limit on your
monthly data usage.
Note: Usage information is provided to help you manage
your phone. This may not match the amounts charged by
your service provider, as they’re not measured in the
same way.
06/13/2012
FCC
45Management
Find it: Apps > Settings > Data usage
The data usage screen shows information and settings
for data transferred over your service provider's mobile
network.
Tip: You can also track Wi-Fi usage, by touching Apps
> Settings > Data usage >Menu > Show Wi-Fi
usage or Restrict background data.
Data usage
ON
Mobile data
Set mobile data limit
Apr 26
-
May 26
Data usage cycle
May 19
-
26: about 38.65MB used
Apr 26 May 26
Measured by your phone. Your carrier’s data
usage accounting may differ.
Browser
Email
14.46MB
7.28MB
limit
4.0GB
warning
1.5GB
Activate data limit.
Mobile data on/off.
Touch an app to see details
& restrict background data.
Drag up/down to set
data usage limit.
Drag up/down to set
data usage warning.
Drag left/right to see data
usage for time period.
Timeframe.
Options.
Set a data usage warning
Touch Apps >
Settings > Data usage, then drag
the right side of the orange bar up/down to set the data
warning level. You'll receive a notification when your
data usage reaches the specified level.
Set a data usage limit
Touch Apps >
Settings > Data usage > Set mobile
data limit, then drag the right side of the red bar
up/down to set the data usage limit.
When you reach your data usage limit, mobile data is
turned off automatically and many of your phone’s
features won't work correctly. You'll receive a
notification when mobile data is turned off.
Restrict background data usage by app
Some apps transfer data in the background, when you're
not using them. You can restrict background data usage
for individual apps to help reduce your overall data
usage.
Touch Apps >
Settings > Data usage, and scroll
down to see which apps are transferring data over the
mobile network. Touch an app, then touch > Restrict
background data.
Restrict all background data
You can restrict background data for all apps across all
available networks (mobile, Wi-Fi, and/or Ethernet).
06/13/2012
FCC
46Management
Find it: Apps > Settings > Data usage >Menu
>Restrict background data.
Caution: Restricting all background data can cause
some features to stop working altogether.
Wireless manager
Find it: Apps > Settings, then go to the WIRELESS
& NETWORKS section
Manage all your wireless connections: Wi-Fi,
Bluetooth™, mobile data, airplane mode, & mobile
hotspot.
Airplane mode
Use airplane mode to turn all your wireless connections
off—useful when flying. Press and hold the Power key
>Airplane mode.
Note: When you select airplane mode, all wireless
services are disabled. You can then turn Wi-Fi and/or
Bluetooth back on, if permitted by your airline. Other
wireless voice and data services (such as calls and text
messages) remain off in airplane mode. Emergency calls
to your region's emergency number can still be made.
Network
You should not need to change any network settings.
Contact your service provider for help.
Touch Apps > Settings > More... > Mobile
networks to see network settings options.
06/13/2012
FCC
47Security
Security
help keep your phone safe
Quick start: Security
Find it: Apps > Settings > Security & Screen Lock
Screen lock
To prevent accidental touches, you can make the screen
lock when it goes to sleep. Touch > Settings
>Security & Screen Lock > Screen lock, then select the
lock type:
Security
Screen lock
Slide
Data encryption
Protect the data on your phone or memory card
SCREEN SECURITY
ENCRYPTION
SIM CARD LOCK
PASSWORDS
Owner info
Set up SIM card lock
Make passwords visible
Enter text to appear
on the lock screen.
Select & set up a
screen lock method.
See the passwords
you enter.
•None: Turn off the screen lock.
•Slide: Flick to the right to unlock.
•Face Unlock: Look at your phone to unlock it.
•Pattern: Draw a pattern to unlock.
•PIN: Enter a numeric PIN to unlock.
•Password: Enter a password to unlock.
Note: You can make emergency calls on a locked phone
(see “Emergency calls” on page 14). A locked phone still
rings, but you need to unlock it to answer.
Face Unlock
Use face recognition software to unlock your phone.
Note: This feature is less secure than a pattern, PIN, or
password.
To get started, touch Apps > Settings > Security &
Screen Lock > Screen lock > Face Unlock.
Follow the instructions and look toward the front camera
lens. When the face capture is complete, you’ll be
prompted to choose a pattern or PIN as a backup
security measure you can use when the phone can’t see
your face clearly.
To unlock the phone, flick to the right and look toward
the front camera lens.
06/13/2012
FCC
48Security
Lock pattern
To set the lock pattern, touch Apps >
Settings
>Security & Screen Lock > Screen lock > Pattern.
Follow the instructions to draw your lock pattern.
When prompted, draw the pattern to unlock the phone.
PIN lock
To set a PIN, touch Apps >
Settings > Security &
Screen Lock > Screen lock > PIN.
Enter a numeric PIN, then confirm it.
When prompted, enter the PIN to unlock the phone.
Password lock
To set the password, touch Apps >
Settings
>Security & Screen Lock > Screen lock > Password.
Enter a password (up to eight characters), then
confirm it.
When prompted, enter the password to unlock the
phone.
Personalize your lock screen
To change your timeout, touch Apps >
Settings
>Display > Sleep. If you don’t touch the screen or press
any keys for the amount of time you select, the screen
locks automatically.
Lock & unlock
To lock your phone screen, do any one of these:
•Press the Power key.
•Let the screen time out (don’t press anything).
•Switch off the power.
To unlock the phone screen, press the Power key to
wake the touchscreen display, then perform the unlock
procedure required by the lock screen (slide, face
unlock, pattern, PIN, or password).
Forgot your pattern, PIN, or password?
Face unlock: If your phone doesn’t recognize your face,
you’ll be prompted to enter your backup pattern or PIN
code to unlock it.
Pattern, PIN, or password: If you make five
unsuccessful attempts to enter your lock pattern, you
can touch
Forgot pattern and enter the Gmail user name
and password you set up as your main Gmail account
when you registered your device. You will then be able
to create a new pattern and unlock your device.
If you forget your PIN or password, contact your service
provider to have your device factory reset.
Warning: A factory reset will delete all data on your
phone.
06/13/2012
FCC
49Troubleshooting
Reset
To reset your phone to factory settings and erase all the
data on your phone, touch Apps >
Settings
>Privacy > Factory data reset > Reset phone.
Warning: All data on your phone will be deleted.
(Nothing on the microSD memory card is deleted.)
Troubleshooting
we’re here to help
Crash recovery
In the unlikely event that your phone stops responding
to touches and key presses, try a forced reboot—press
and hold both the Power key and the down volume key
for up to 10 seconds.
Service & Repairs
If you have questions or need assistance, we’re here to
help.
Go to www.motorola.com/support, where you can
select from a number of customer care options. You can
also contact the Motorola Customer Support Center at
1-800-331-6456 (United States), 1-888-390-6456
(TTY/TDD United States for hearing impaired), or
1-800-461-4575 (Canada).
06/13/2012
FCC
50 Troubleshooting
Safety, Regulatory & Legal
Battery Use & Safety
Battery Use & Safety
The following battery use and safety information applies to all Motorola mobile devices. If
your mobile device uses a non-removable main battery (as stated in your product
information), details related to handling and replacing your battery should be
disregarded—the battery should only be replaced by a Motorola-approved service facility,
and any attempt to remove or replace your battery may damage the product.
Important: Handle and store batteries properly to avoid injury or damage.
Most
battery safety issues arise from improper handling of batteries, and particularly from the
continued use of damaged batteries.
DON’Ts
• Don’t disassemble, crush, puncture, shred, or otherwise attempt to change the
form of your battery.
• Don’t use tools, sharp objects, or excessive force to insert or remove the battery
as this can damage the battery.
• Don’t let the mobile device or battery come in contact with liquids.*
Liquids can
get into the mobile device’s circuits, leading to corrosion.
• Don’t allow the battery to touch metal objects.
If metal objects, such as jewelry, stay
in prolonged contact with the battery contact points, the battery could become very hot.
• Don’t place your mobile device or battery near a heat source.*
High temperatures
can cause the battery to swell, leak, or malfunction.
• Don’t dry a wet or damp battery with an appliance or heat source
, such as a hair
dryer or microwave oven.
DOs
• Do avoid leaving your mobile device in your car in high temperatures.*
• Do avoid dropping the mobile device or battery.*
Dropping these items, especially
on a hard surface, can potentially cause damage.*
• Do contact your service provider or Motorola if your mobile device or battery
has been damaged in any of the ways listed here.
*Note:
Always make sure that any battery, connector and compartment covers are closed
and secure to avoid direct exposure of the battery to any of these conditions, even if your
product information states that your
mobile device
can resist damage from these
conditions.
Important: Motorola recommends you always use Motorola-branded batteries and
chargers for quality assurance and safeguards.
Motorola’s warranty does not cover
damage to the mobile device caused by non-Motorola batteries and/or chargers. To help you
identify authentic Motorola batteries from non-original or counterfeit batteries (that may not
have adequate safety protection), Motorola provides holograms on its batteries. You should
confirm that any battery you purchase has a “Motorola Original” hologram.
If you see a message on your display such as
Invalid Battery
or
Unable to Charge
, take the following steps:
•
Remove the battery and inspect it to confirm that it has a “Motorola Original” hologram;
•
If there is no hologram, the battery is not a Motorola battery;
•
If there is a hologram, replace the battery and try charging it again;
•
If the message remains, contact a Motorola authorized service center.
Warning:
Use of a non-Motorola battery or charger may present a risk of fire, explosion,
leakage, or other hazard.
Proper and safe battery disposal and recycling:
Proper battery disposal is not only
important for safety, it benefits the environment. You can recycle your used batteries in many
retail or service provider locations. Additional information on proper disposal and recycling
can be found at
www.motorola.com/recycling
Disposal:
Promptly dispose of used batteries in accordance with local
regulations. Contact your local recycling center or national recycling organizations
for more information on how to dispose of batteries.
Warning:
Never dispose of batteries in a fire because they may explode.
Battery Charging
Battery Chargi ng
Notes for charging your product’s battery:
•
During charging, keep your battery and charger near room temperature for efficient
battery charging.
•
New batteries are not fully charged.
•
New batteries or batteries stored for a long time may take more time to charge.
•
Motorola batteries and charging systems have circuitry that protects the battery from
damage from overcharging.
Third Party Accessories
Use of third party accessories, including but not limited to batteries, chargers, headsets,
covers, cases, screen protectors and memory cards, may impact your mobile device’s
performance. In some circumstances, third party accessories can be dangerous and may void
032375o
06/13/2012
FCC
51Troubleshooting
your mobile device’s warranty. For a list of Motorola accessories, visit
www.motorola.com/products
Driving Precautions
Responsible and safe driving is your primary responsibility when behind the wheel of a
vehicle. Using a mobile device or accessory for a call or other application while driving may
cause distraction, and may be prohibited or restricted in certain areas—always obey the
laws and regulations on the use of these products.
While driving, NEVER:
•
Type, read, enter or review texts, emails, or any other written data.
•
Surf the web.
•
Input navigation information.
•
Perform any other functions that divert your attention from driving.
While driving, ALWAYS:
•
Keep your eyes on the road.
•
Use a handsfree device if available or required by law in your area.
•
Enter destination information into a navigation device
before
driving.
•
Use voice activated features (such as voice dial) and speaking features (such as audible
directions), if available.
•
Obey all local laws and regulations for the use of mobile devices and accessories in the
vehicle.
•
End your call or other task if you cannot concentrate on driving.
Remember to follow the “Smart Practices While Driving” at
www.motorola.com/callsmart
(in English only).
Seizures, Blackouts & Eyestrain
To reduce eyestrain and avoid headaches, it is always a good idea to hold the screen a
comfortable distance from your eyes, use in a well-lit area, and take frequent breaks.
Some people may be susceptible to seizures or blackouts (even if they have never had one
before) when exposed to flashing lights or light patterns, such as when playing video games,
or watching videos with flashing-light effects.
Discontinue use and consult a physician if any of the following symptoms occur: seizures,
blackout, convulsion, eye or muscle twitching, loss of awareness, or disorientation.
If you or someone in your family has experienced seizures or blackouts, please consult with
your physician before using an application that produces flashing-light effects on your mobile
device.
Caution About High Volume Usage
Warning:
Exposure to loud noise from any source for extended periods of time may affect
your hearing. The louder the volume sound level, the less time is required before your hearing
could be affected. To protect your hearing:
•
Limit the amount of time you use headsets or headphones at high volume.
•
Avoid turning up the volume to block out noisy surroundings.
•
Turn the volume down if you can’t hear people speaking near you.
If you experience hearing discomfort, including the sensation of pressure or fullness in your
ears, ringing in your ears, or muffled speech, you should stop listening to the device through
your headset or headphones and have your hearing checked.
For more information about hearing, see our website at
direct.motorola.com/hellomoto/nss/AcousticSafety.asp
(in English only).
Repetitive Motion
When you repetitively perform actions such as pressing keys or entering finger-written
characters, you may experience occasional discomfort in your hands, arms, shoulders, neck,
or other parts of your body. If you continue to have discomfort during or after such use, stop
use and see a physician.
Children
Keep your mobile device and its accessories away from small children.
These
products are not toys and may be hazardous to small children. For example:
•
A choking hazard may exist for small, detachable parts.
•
Improper use could result in loud sounds, possibly causing hearing injury.
•
Improperly handled batteries could overheat and cause a burn.
Supervise access for older children.
Similar to a computer, if an older child does use
your mobile device, you may want to monitor their access to help prevent:
•
Exposure to inappropriate apps or content.
•
Improper use of apps or content.
•
Loss of data.
Glass Parts
Some parts of your mobile device may be made of glass. This glass could break if the product
receives a substantial impact. If glass breaks, do not touch or attempt to remove. Stop using
your mobile device until the glass is replaced by a qualified service center.
06/13/2012
FCC
52 Safety, Regulatory & Legal
Operational Warnings
Obey all posted signs when using mobile devices in public areas.
Potentially Explosive Areas
Potentially explosive areas are often, but not always, posted and can include blasting areas,
fueling stations, fueling areas (such as below decks on boats), fuel or chemical transfer or
storage facilities, or areas where the air contains chemicals or particles, such as grain dust,
or metal powders.
When you are in such an area, turn off your mobile device, and do not remove, install, or
charge batteries, unless it is a radio product type especially qualified for use in such areas
and certified as “Intrinsically Safe” (for example, Factory Mutual, CSA, or UL approved). In
such areas, sparks can occur and cause an explosion or fire.
Symbol Key
Your battery, charger, or mobile device may contain symbols, defined as follows:
Symbol Definition
Important safety information follows.
Do not dispose of your battery or mobile device in a fire.
Your battery or mobile device may require recycling in accordance with
local laws. Contact your local regulatory authorities for more
information.
Do not dispose of your battery or mobile device with your household
waste. See “Recycling” for more information.
Do not use tools.
032374o
032376o
032375o
Radio Frequency (RF) Energy
Exposure to RF Energy
Your mobile device contains a transmitter and receiver. When it is ON, it receives and
transmits RF energy. When you communicate with your mobile device, the system handling
your call controls the power level at which your mobile device transmits.
Your mobile device is designed to comply with local regulatory requirements in your country
concerning exposure of human beings to RF energy.
RF Energy Operational Precautions
For optimal mobile device performance, and to be sure that human exposure to RF energy
does not exceed the guidelines set forth in the relevant standards, always follow these
instructions and precautions:
•
When placing or receiving a phone call, hold your mobile device just like you would a
landline phone.
•
If you wear the mobile device on your body, always place the mobile device in a
Motorola-supplied or approved accessory (e.g. clip, holder, holster, case or arm band). If
you do not use a body-worn accessory supplied or approved by Motorola, ensure that
whatever product is used is free of any metal and that it positions the mobile device at
least 2.5 cm (1 inch) away from the body.
•
Using accessories not supplied or approved by Motorola may cause your mobile device to
exceed RF energy exposure guidelines. For a list of Motorola-supplied or approved
accessories, visit our website at:
www.motorola.com
.
RF Energy Interference/Compatibility
Nearly every electronic device is subject to RF energy interference from external sources if
inadequately shielded, designed, or otherwise configured for RF energy compatibility. In
some circumstances, your mobile device may cause interference with other devices.
For indoor use only.
Symbol Definition
06/13/2012
FCC
53Safety, Regulatory & Legal
Follow Instructions to Avoid Interference Problems
Turn off your mobile device in any location where posted notices instruct you to do so, such
as hospitals or health care facilities.
In an aircraft, turn off your mobile device whenever instructed to do so by airline staff. If your
mobile device offers an airplane mode or similar feature, consult airline staff about using it in
flight.
Medical Devices
If you have a medical device, including an implantable medical device such as a pacemaker
or defibrillator, consult your healthcare provider and the device manufacturer’s directions
before using this mobile device.
Persons with implantable medical devices should observe the following precautions:
•
ALWAYS keep the mobile device more than 20 centimeters (8 inches) from the
implantable medical device when the mobile device is turned ON.
•
DO NOT carry the mobile device in the breast pocket.
•
Use the ear opposite the implantable medical device to minimize the potential for
interference.
•
Turn OFF the mobile device immediately if you have any reason to suspect that
interference is taking place.
Regulatory Information
Your Motorola mobile device is designed to comply with national and international regulatory
requirements. For full compliance statements and details, please refer to the regulatory
information in your printed product guide.
Specific Absorption Rate (FCC & IC)
SAR (IEEE)
YOUR MOBILE DEVICE MEETS FCC AND IC LIMITS FOR
EXPOSURE TO RADIO WAVES.
Your mobile device is a radio transmitter and receiver. It is designed not to exceed the limits
for exposure to radio waves (radio frequency electromagnetic fields) adopted by the Federal
Communications Commission (FCC) and Industry Canada (IC). These limits include a
substantial safety margin designed to assure the safety of all persons, regardless of age and
health.
The radio wave exposure guidelines use a unit of measurement known as the Specific
Absorption Rate, or SAR. The SAR limit for mobile devices is 1.6 W/kg.
Tests for SAR are conducted using standard operating positions with the device transmitting
at its highest certified power level in all tested frequency bands. The highest SAR values
under the FCC and IC guidelines for your device model are listed below:
During use, the actual SAR values for your device are usually well below the values stated.
This is because, for purposes of system efficiency and to minimize interference on the
network, the operating power of your mobile device is automatically decreased when full
power is not needed for the call. The lower the power output of the device, the lower its SAR
value.
If you are interested in further reducing your RF exposure then you can easily do so by limiting
your usage or simply using a hands-free kit to keep the device away from the head and body.
Additional information can be found at
www.motorola.com/rfhealth
.
European Union Directives Conformance
Statement
EU Conformance
The following CE compliance information is applicable to Motorola mobile devices that carry
one of the following CE marks:
Hereby, Motorola declares that this product is in compliance with:
•
The essential requirements and other relevant provisions of Directive 1999/5/EC
•
All other relevant EU Directives
For products that support Wi-Fi 802.11a (as defined in your product information): This device
is restricted to indoor use when operating in the 5.15 to 5.25 GHz (802.11a) Wi-Fi frequency
band.
Head SAR CDMA 1900, Wi-Fi, Bluetooth 0.83 W/kg
Body-worn SAR CDMA 800, Wi-Fi, Bluetooth 0.65 W/kg
0168
[Only Indoor Use Allowed In France
for Bluetooth and/or Wi-Fi]
0168
06/13/2012
FCC
54Safety, Regulatory & Legal
The following gives an example of a typical Product Approval Number:
You can view your product’s Declaration of Conformity (DoC) to Directive 1999/5/EC (to
R&TTE Directive) at
www.motorola.com/rtte
(in English only). To find your DoC, enter
the Product Approval Number from your product’s label in the “Search” bar on the website.
FCC Notice to Users
FCC Notice
The following statement applies to all products that bear the FCC logo and/or
FCC ID on the product label.
This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to part 15 of the FCC Rules. See 47 CFR Sec. 15.105(b). These limits are
designed to provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses and can radiate radio frequency energy and, if
not installed and used in accordance with the instructions, may cause harmful interference to
radio communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on, the user
is encouraged to try to correct the interference by one or more of the following measures:
•
Reorient or relocate the receiving antenna.
•
Increase the separation between the equipment and the receiver.
•
Connect the equipment to an outlet on a circuit different from that to which the receiver is
connected.
•
Consult the dealer or an experienced radio/TV technician for help.
This device complies with part 15 of the FCC Rules. Operation is subject to the following two
conditions: (1) This device may not cause harmful interference, and (2) this device must
accept any interference received, including interference that may cause undesired operation.
See 47 CFR Sec. 15.19(a)(3).
Motorola has not approved any changes or modifications to this device by the user. Any
changes or modifications could void the user’s authority to operate the equipment. See 47
CFR Sec. 15.21.
0168
Product
Approval
Number
For products that support Wi-Fi 802.11a (as defined in product information): In the United
States, do not use your device outdoors while connected to an 802.11a Wi-Fi network. The
FCC prohibits such outdoor use since frequencies 5.15-5.25 GHz can cause interference with
Mobile Satellite Services (MSS). Public Wi-Fi access points in this range are optimized for
indoor use.
Industry Canada Notice to Users
Industry Canada Notic e
This device complies with Industry Canada license-exempt RSS standard(s). Operation is
subject to the following two conditions: (1) This device may not cause interference and (2)
This device must accept any interference, including interference that may cause undesired
operation of the device. See RSS-GEN 7.1.5. This Class B digital apparatus complies with
Canadian ICES-003.
Software Notices
Software Copyright Noti ce
Warning against unlocking the bootloader or altering a product's operating system
software:
Motorola strongly recommends against altering a product's operating system,
which includes unlocking the bootloader, rooting a device or running any operating software
other than the approved versions issued by Motorola and its partners. Such alterations may
permanently damage your product, cause your product to be unsafe and/or cause your
product to malfunction. In such cases, neither the product nor any damage resulting
therefrom will be covered by warranty.
Important FCC information:
You must not make or enable any changes to the product that
will impact its FCC grant of equipment authorization. The FCC grant is based on the product's
emission, modulation, and transmission characteristics, including: power levels, operating
frequencies and bandwidths, SAR levels, duty-cycle, transmission modes (e.g., CDMA, GSM),
and intended method of using the product (e.g., how the product is held or used in proximity
to the body). A change to any of these factors will invalidate the FCC grant. It is illegal to
operate a transmitting product without a valid grant.
Location Services
GPS & AGPS
The following information is applicable to Motorola mobile devices that provide location
based functionality. Location sources can include GPS, AGPS and Wi-Fi.
Your mobile device can use Global Positioning System (GPS) signals for location-based
applications. GPS uses satellites controlled by the U.S. government that are subject to
changes implemented in accordance with the Department of Defense policy and the Federal
Radio Navigation Plan. These changes may affect the performance of location technology on
your mobile device.
06/13/2012
FCC
55Safety, Regulatory & Legal
Your mobile device can also use Assisted Global Positioning System (AGPS), which obtains
information from the cellular network to improve GPS performance. AGPS uses your wireless
service provider's network and therefore airtime, data charges, and/or additional charges
may apply in accordance with your service plan. Contact your wireless service provider for
details.
Your mobile device can also use Wi-Fi signals to determine your approximate location, using
information from known and available Wi-Fi networks.
Your Location
Location-based information includes information that can be used to determine the
approximate location of a mobile device. Mobile devices which are connected to a wireless
network transmit location-based information. Devices enabled with location technology also
transmit location-based information. Additionally, if you use applications that require
location-based information (e.g. driving directions), such applications transmit location-based
information. This location-based information may be shared with third parties, including your
wireless service provider, applications providers, Motorola, and other third parties providing
services.
Emergency Calls
When you make an emergency call, the cellular network may activate the AGPS technology
in your mobile device to tell the emergency responders your approximate location.
AGPS has limitations and
might not work in your area
. Therefore:
•
Always tell the emergency responder your location to the best of your ability; and
•
Remain on the phone for as long as the emergency responder instructs you.
Navigation
Navigation
The following information is applicable to Motorola mobile devices that provide navigation
features.
When using navigation features, note that mapping information, directions and other
navigational data may contain inaccurate or incomplete data. In some countries, complete
information may not be available. Therefore, you should visually confirm that the navigational
instructions are consistent with what you see. All drivers should pay attention to road
conditions, closures, traffic, and all other factors that may impact driving. Always obey
posted road signs.
Privacy & Data Security
Privacy & Data Security
Motorola understands that privacy and data security are important to everyone. Because
some features of your mobile device may affect your privacy or data security, please follow
these recommendations to enhance protection of your information:
• Monitor access
—Keep your mobile device with you and do not leave it where others
may have unmonitored access. Use your device’s security and lock features, where
available.
• Keep software up to date
—If Motorola or a software/application vendor releases a
patch or software fix for your mobile device that updates the device’s security, install it as
soon as possible.
• Secure Personal Information
—Your mobile device can store personal information in
various locations including your SIM card, memory card, and phone memory. Be sure to
remove or clear all personal information before you recycle, return, or give away your
device. You can also backup your personal data to transfer to a new device.
Note:
For information on how to backup or wipe data from your mobile device, go to
www.motorola.com/support
• Online accounts
—Some mobile devices provide a Motorola online account (such as
MOTOBLUR). Go to your account for information on how to manage the account, and how
to use security features such as remote wipe and device location (where available).
• Applications and updates
—Choose your apps and updates carefully, and install from
trusted sources only. Some apps can impact your phone’s performance and/or have
access to private information including account details, call data, location details and
network resources.
•Wireless
—For mobile devices with Wi-Fi features, only connect to trusted Wi-Fi
networks. Also, when using your device as a hotspot (where available) use network
security. These precautions will help prevent unauthorized access to your device.
• Location-based information
—Mobile devices enabled with location based
technologies such as GPS, AGPS or Wi-Fi, can transmit location-based information. See
“Location Services” for more details.
• Other information your device may transmit
—Your device may also transmit testing
and other diagnostic (including location-based) information, and other non-personal
information to Motorola or other third-party servers. This information is used to help
improve products and services offered by Motorola.
If you have further questions regarding how the use of your mobile device may impact your
privacy or data security, please contact Motorola at
privacy@motorola.com
, or contact
your service provider.
06/13/2012
FCC
56 Safety, Regulatory & Legal
Use & Care
Use & Care
To care for your Motorola mobile device, please observe the following:
liquids
Don’t expose your mobile device to water, rain, extreme humidity, sweat, or
other liquids.
drying
Don’t try to dry your mobile device using a microwave oven, conventional oven,
or dryer, as this may damage the mobile device.
extreme heat or cold
Don’t store or use your mobile device in temperatures below -10°C (14°F) or
above 60°C (140°F). Don’t recharge your mobile device in temperatures below
0°C (32°F) or above 45°C (113°F).
dust and dirt
Don’t expose your mobile device to dust, dirt, sand, food, or other inappropriate
materials.
cleaning
To clean your mobile device, use only a dry soft cloth. Don’t use alcohol or other
cleaning solutions.
shock and vibration
Don’t drop your mobile device.
protection
To help protect your mobile device, always make sure that any battery,
connector and compartment covers are closed and secure.
Recycling
Recycling
Mobile Devices & Accessories
Please do not dispose of mobile devices or electrical accessories (such as
chargers, headsets, or batteries) with your household waste, or in a fire. These
items should be disposed of in accordance with the national collection and
recycling schemes operated by your local or regional authority. Alternatively, you
may return unwanted mobile devices and electrical accessories to any Motorola Approved
Service Center in your region. Details of Motorola approved national recycling schemes, and
further information on Motorola recycling activities can be found at:
www.motorola.com/recycling
Packaging & Product Guides
Product packaging and product guides should only be disposed of in accordance with national
collection and recycling requirements. Please contact your regional authorities for more
details.
California Perchlorate Label
Perchlorate Label
Some mobile phones use an internal, permanent backup battery on the printed circuit board
that may contain very small amounts of perchlorate. In such cases, California law requires
the following label:
Perchlorate Material – special handling may apply when the battery is recycled or disposed
of. See
www.dtsc.ca.gov/hazardouswaste/perchlorate
(in English only).
There is no special handling required by consumers.
Hearing Aid Compatibility with Mobile
Phones
Hearing Aid Compatibility
Some Motorola phones are measured for compatibility with hearing aids. If the box for your
particular model has “Rated for Hearing Aids” printed on it, the following explanation
applies.
When some mobile phones are used near some hearing devices (hearing aids and cochlear
implants), users may detect a buzzing, humming, or whining noise. Some hearing devices are
more immune than others to this interference noise, and phones also vary in the amount of
interference they generate.
The wireless telephone industry has developed ratings for some of their mobile phones, to
assist hearing device users in finding phones that may be compatible with their hearing
06/13/2012
FCC
57Safety, Regulatory & Legal
devices. Not all phones have been rated. Phones that are rated have the rating on their box or
a label on the box. To maintain the published Hearing Aid Compatibility (HAC) rating for this
mobile phone, use only the original equipment battery model.
This phone has been tested and rated for use with hearing aids for some of the wireless
technologies that it uses. However, there may be some newer wireless technologies used in
this phone that have not been tested yet for use with hearing aids. It is important to try the
different features of this phone thoroughly and in different locations, using your hearing aid
or cochlear implant, to determine if you hear any interfering noise. Contact your service
provider or Motorola for information on hearing aid compatibility. If you have questions about
return or exchange policies, contact your service provider or phone retailer.
The ratings are not guarantees. Results will vary depending on the user’s hearing device and
hearing loss. If your hearing device happens to be vulnerable to interference, you may not be
able to use a rated phone successfully. Trying out the phone with your hearing device is the
best way to evaluate it for your personal needs.
M-Ratings:
Phones rated M3 or M4 meet FCC requirements and are likely to generate less
interference to hearing devices than phones that are not labeled. M4 is the better/higher of
the two ratings.
T-Ratings:
Phones rated T3 or T4 meet FCC requirements and are likely to be more usable
with a hearing device’s telecoil (“T Switch” or “Telephone Switch”) than unrated phones. T4
is the better/higher of the two ratings. (Note that not all hearing devices have telecoils in
them.)
Hearing devices may also be measured for immunity to this type of interference. Your hearing
device manufacturer or hearing health professional may help you find results for your hearing
device. The more immune your hearing aid is, the less likely you are to experience
interference noise from mobile phones.
Software Copyright
Software Copyright N otice
Motorola products may include copyrighted Motorola and third-party software stored in
semiconductor memories or other media. Laws in the United States and other countries
preserve for Motorola and third-party software providers certain exclusive rights for
copyrighted software, such as the exclusive rights to distribute or reproduce the copyrighted
software. Accordingly, any copyrighted software contained in Motorola products may not be
modified, reverse-engineered, distributed, or reproduced in any manner to the extent allowed
by law. Furthermore, the purchase of Motorola products shall not be deemed to grant either
directly or by implication, estoppel, or otherwise, any license under the copyrights, patents,
or patent applications of Motorola or any third-party software provider, except for the normal,
non-exclusive, royalty-free license to use that arises by operation of law in the sale of a
product.
Content Copyright
Content Copyright
The unauthorized copying of copyrighted materials is contrary to the provisions of the
Copyright Laws of the United States and other countries. This device is intended solely for
copying non-copyrighted materials, materials in which you own the copyright, or materials
which you are authorized or legally permitted to copy. If you are uncertain about your right to
copy any material, please contact your legal advisor.
Open Source Software Information
OSS Information
For instructions on how to obtain a copy of any source code being made publicly available by
Motorola related to software used in this Motorola mobile device, you may send your request
in writing to the address below. Please make sure that the request includes the model
number and the software version number.
MOTOROLA MOBILITY, INC.
OSS Management
600 North US Hwy 45
Libertyville, IL 60048
USA
The Motorola website
opensource.motorola.com
(in English only) also contains
information regarding Motorola's use of open source.
Motorola has created the
opensource.motorola.com
website to serve as a portal for
interaction with the software community-at-large.
To view additional information regarding licenses, acknowledgments and required copyright
notices for open source packages used in this Motorola mobile device, please
press Menu Key >
Settings
>
About phone
>
Legal information
>
Open source licenses
. In addition, this Motorola device may include
self-contained applications that present supplemental notices for open source packages used
in those applications.
Export Law Assurances
Export Law
This product is controlled under the export regulations of the United States of America and
Canada. The Governments of the United States of America and Canada may restrict the
exportation or re-exportation of this product to certain destinations. For further information
contact the U.S. Department of Commerce or the Canadian Department of Foreign Affairs and
International Trade.
06/13/2012
FCC
58 Safety, Regulatory & Legal
Product Registration
Registratio n
Online Product Registration:
www.motorola.com/us/productregistration
(in English only)
Product registration is an important step toward enjoying your new Motorola product.
Registering permits us to contact you for product or software updates and allows you to
subscribe to updates on new products or special promotions. Registration is not required for
warranty coverage.
Please retain your original dated sales receipt for your records. For warranty service of your
Motorola product you will need to provide a copy of your dated sales receipt to confirm
warranty status.
Thank you for choosing a Motorola product.
Service & Repairs
If you have questions or need assistance, we're here to help.
Go to
www.motorola.com/repair
(United States) or
www.motorola.com/support
(Canada), where you can select from a number of
customer care options. You can also contact the Motorola Customer Support Center at
1-800-734-5870 (United States), 1-888-390-6456 (TTY/TDD United States for hearing
impaired), or 1-800-461-4575 (Canada).
How to Obtain Service or Other Information
1. Please access and review the online Customer Support section of Motorola's consumer
website prior to requesting warranty service.
2. If the Product is still not functioning properly after making use of this resource, please
contact the Warrantor listed at the Motorola website or the contact information for the
corresponding location.
3. A representative of Motorola, or of a Motorola Authorized Repair Center, will help
determine whether your Product requires service. You may be required to download, or
otherwise obtain and accept software updates from Motorola or a Motorola Authorized
Repair Center. You are responsible for any applicable carrier service fees incurred while
obtaining the required downloads. Complying with the warranty process, repair
instructions and accepting such software updates is required in order to receive additional
warranty support.
4. If the software update does not fix the problem, you will receive instructions on how to
ship the Product to a Motorola Authorized Repair Center or other entity.
5. To obtain warranty service, as permitted by applicable law, you are required to include: (a)
a copy of your receipt, bill of sale or other comparable proof of purchase; (b) a written
description of the problem; (c) the name of your service provider, if applicable; (d) your
address and telephone number. In the event the Product is not covered by the Motorola
Limited Warranty, Motorola will inform the consumer of the availability, price and other
conditions applicable to the repair of the Product.
To obtain service or other information, please access and review the online
Customer Support section of Motorola's consumer website at www.motorola.com.
Motorola Mobility Inc. Limited Global
Warranty Mobile Phones
Warr an ty
Note: This Limited Warranty is not applicable in Quebec, Canada.
FOR CONSUMERS WHO ARE COVERED BY CONSUMER PROTECTION LAWS OR
REGULATIONS IN THEIR COUNTRY OF PURCHASE OR, IF DIFFERENT, THEIR
COUNTRY OF RESIDENCE, THE BENEFITS CONFERRED BY THIS LIMITED
WARRANTY ARE IN ADDITION TO ALL RIGHTS AND REMEDIES CONVEYED BY
SUCH CONSUMER PROTECTION LAWS AND REGULATIONS.
Who is Covered?
This Limited Warranty extends only to the first consumer purchaser of the Product, and is not
transferable.
What Does this Limited Warranty Cover?
Motorola Mobility Inc. or its subsidiaries' warranty obligations are limited to the terms and
conditions set forth herein. Subject to the exclusions contained below, Motorola Mobility Inc
or its subsidiaries ("Motorola") warrant this Mobile Phone, and any in-box accessories which
accompany such Mobile Phone ("Product") against defects in materials and workmanship,
under normal consumer use, for a period of ONE (1) YEAR from the date of retail purchase by
the original end-user purchaser, or the period of time required by the laws of the country
where the Product is purchased, whichever is longer ("Warranty Period").
Repairs made under this Limited Warranty are covered for the balance of the original
Warranty Period, or 90 days from the date of service, whichever is longer. Any upgrade to the
original product will be covered only for the duration of the original Warranty Period.
This Limited Warranty is only available in the country where the Product was purchased.
Motorola may provide service outside the country of purchase, to the extent that it is possible
and under the terms and conditions of the country of purchase.
This Limited Warranty applies only to new Products which are a) manufactured by or for
Motorola as identified by the "Motorola" trademark, trade name, or logo legally affixed to
06/13/2012
FCC
59Safety, Regulatory & Legal
them; b) purchased by consumers from an authorized reseller or distributor of Motorola
Products; and c) accompanied by this written Limited Warranty.
What Will Motorola Do?
If a covered defect or damage arises and a valid warranty claim is received within the
applicable Warranty Period, Motorola, at its sole option, unless otherwise required by
applicable law, will either (1) repair, at no charge, the defect or damage using new, used or
reconditioned/refurbished functionally equivalent replacement parts; or (2) exchange the
Product with a replacement Product that is new or which has been reconditioned/refurbished
or otherwise remanufactured from new or used parts and is functionally equivalent to the
original Product; or (3) refund the purchase price of any Products covered by the terms and
conditions of this Limited Warranty.
Products, parts and supporting documentation provided to Motorola as part of the warranty
process, shall become the property of Motorola, and may not be returned. When a
replacement or refund is given, the Product for which the replacement or refund is provided
must be returned to Motorola and shall become the property of Motorola.
Exclusions (Products and Accessories)
This warranty does not apply to:
(a)
Consumable parts
, such as batteries or protective coatings designed to diminish over
time unless failure has occurred due to a defect in materials or workmanship. As with all
batteries, the maximum capacity of the battery will decrease with time and use; this is not a
defect. Only defective batteries and batteries that leak are covered by this warranty.
(b)
Cosmetic damage
, including but not limited to scratches, dents, cracks or other
cosmetic damage.
(c)
Damage caused by use with non-Motorola products.
Defects or damage that result
from the use of non-Motorola branded or certified Products, accessories or other peripheral
equipment, including without limitation housings, parts, or software, are excluded from
coverage.
(d)
Damage caused by accident, abuse, misuse, liquid contact, fire, earthquake or
other external causes
; including but not limited to: (i) improper usage or operation (e.g.
operating the Product outside their permitted or intended uses as defined by Motorola,
including but not limited to as set forth by Motorola in the Products' User Manual, Quick Start
Guide, Online Tutorials, and other documentation), improper storage (e.g. subjecting the
Product to extreme temperatures), abuse or neglect (e.g. broken/bent/missing
clips/fasteners/connectors); impact damage (e.g. dropping the Product) (ii) contact with
liquids, water, rain, extreme humidity, heavy perspiration or other moisture; sand, food, dirt or
similar substances (except for Products sold as resistant to such substances, but only to the
extent the damage was not caused by incorrectly securing the phone's protective elements or
subjecting the Product to conditions beyond its stated specifications or limits); (iii) use of the
Products for commercial rental purposes; or (iv) external causes or acts which are not the
fault of Motorola, including but not limited to flood, fire, earthquake, tornado or other acts of
God, are excluded from coverage.
(e)
Unauthorized Service or Modification.
Defects or damage resulting from service,
testing, adjustment, installation, maintenance, alteration, or modification in any way,
including but not limited to tampering with or altering the software, by someone other than
Motorola, or its authorized service centers, are excluded from coverage. Notwithstanding the
foregoing, any Product which has had its bootloader unlocked, or whose operating system
has been altered, including any failed attempts to unlock the bootloader or alter such
operating system, is not covered by this warranty, regardless of whether such modifications
are authorized, approved, or otherwise sanctioned by Motorola.
(f)
A product or part that has been modified in any manner without the written
permission of Motorola.
Products that have been altered in any manner so as to prevent
Motorola from determining whether such Products are covered under the terms of this
Limited Warranty are excluded from coverage. The forgoing shall include but not be limited to
(i) serial numbers, date tags or other manufacturer coding that has been removed, altered or
obliterated; (ii) mismatched or duplicated serial numbers; or (iii) broken seals or other
evidence of tampering. Do not open the Product or attempt to repair the Product yourself;
such conduct may cause damage that is not covered by this warranty.
(g)
Normal wear and tear or otherwise due to the normal aging of the Product.
(h)
Defects, damages, or the failure of the Product due to any communication
service or network you subscribe to or use with the Products.
(i)
All software, including operating system software, third-party software,
applications, and all other software of any kind.
Software distributed by Motorola is
provided "AS-IS" and "AS AVAILABLE," "WITH ALL FAULTS" and without a warranty of any
kind. The Limited Warranty does not apply to any non-Motorola product or any software,
even if packaged or sold with the Motorola hardware, unless otherwise required by
applicable local law.
(j)
Products that have been refurbished, reconditioned, or remanufactured
, except for
Products repaired or replaced pursuant to the terms of this Limited Warranty.
If damage is outside the scope of warranty coverage, repair services may be available, but all
costs associated with such out of warranty repair will be your responsibility.
06/13/2012
FCC
60 Safety, Regulatory & Legal
What Other Limitations are There?
•
TO THE EXTENT PERMITTED BY APPLICABLE LAW, THIS LIMITED WARRANTY AND THE
REMEDIES SET FORTH HEREIN ARE EXCLUSIVE AND IN LIEU OF ALL OTHER
WARRANTIES AND REMEDIES, WHETHER ORAL OR WRITTEN, STATUTORY, EXPRESS OR
IMPLIED. NO ORAL OR WRITTEN REPRESENTATIONS MADE BY MOTOROLA OR ANY
SELLER, RESELLER OR DISTRIBUTOR OF THE PRODUCTS, INCLUDING EMPLOYEES AND
AGENTS THEREOF, SHALL CREATE ANY ADDITIONAL WARRANTY OBLIGATIONS,
INCREASE THE SCOPE, OR OTHERWISE MODIFY IN ANY MANNER THE TERMS OF THIS
LIMITED WARRANTY.
•
TO THE EXTENT PERMITTED BY APPLICABLE LAW, MOTOROLA SPECIFICALLY
DISCLAIMS ANY AND ALL STATUTORY OR IMPLIED WARRANTIES, INCLUDING,
WITHOUT LIMITATION, WARRANTIES OF MERCHANTABILITY, FITNESS FOR A
PARTICULAR PURPOSE, NONINFRINGEMENT AND ALL WARRANTIES AGAINST HIDDEN
OR LATENT DEFECTS. WHERE SUCH STATUTORY OR IMPLIED WARRANTIES CANNOT
LAWFULLY BE DISCLAIMED, THEN TO THE EXTENT PERMITTED BY LAW, ALL SUCH
WARRANTIES SHALL BE LIMITED IN DURATION TO THE DURATION OF THE EXPRESS
LIMITED WARRANTY CONTAINED HEREIN AND THE REMEDIES OF REPAIR,
REPLACEMENT, OR REFUND AS DETERMINED BY MOTOROLA IN ITS SOLE DISCRETION
SHALL BE THE EXCLUSIVE REMEDY OF THE CONSUMER.
•
TO THE EXTENT PERMITTED BY APPLICABLE LAW, MOTOROLA DOES NOT WARRANT
THAT THE OPERATION OF ANY PRODUCTS OR SOFTWARE COVERED UNDER THIS
LIMITED WARRANTY WILL MEET YOUR REQUIREMENTS, WORK IN COMBINATION
WITH ANY HARDWARE OR SOFTWARE APPLICATIONS OR THIRD PARTY SERVICES, BE
UNINTERRUPTED, ERROR-FREE, OR WITHOUT RISK TO, OR LOSS OF, ANY
INFORMATION, DATA, SOFTWARE OR APPLICATIONS CONTAINED THEREIN, OR THAT
DEFECTS IN THE PRODUCTS OR SOFTWARE WILL BE CORRECTED.
•
TO THE EXTENT PERMITTED BY APPLICABLE LAW, IN NO EVENT SHALL MOTOROLA BE
LIABLE, WHETHER IN CONTRACT, TORT OR UNDER OTHER LEGAL THEORY (INCLUDING
NEGLIGENCE), FOR DAMAGES IN EXCESS OF THE PURCHASE PRICE OF THE PRODUCTS,
OR FOR ANY INDIRECT, INCIDENTAL, SPECIAL OR CONSEQUENTIAL DAMAGES OF ANY
KIND, OR LOSS OF REVENUE OR PROFITS; LOSS OF BUSINESS; BUSINESS
INTERRUPTION; LOSS OF OPPORTUNITY; LOSS OF GOODWILL; LOSS OF REPUTATION;
LOSS OF, DAMAGE TO, OR CORRUPTION OF INFORMATION, DATA, SOFTWARE OR
APPLICATIONS (INCLUDING ANY COSTS ASSOCIATED WITH RECOVERING,
PROGRAMMING, OR REPRODUCING ANY INFORMATION, DATA, SOFTWARE OR
APPLICATIONS STORED ON OR USED WITH MOTOROLA PRODUCTS, OR ANY FAILURE
TO MAINTAIN THE CONFIDENTIALITY OF ANY INFORMATION OR DATA STORED ON THE
PRODUCTS); OR OTHER FINANCIAL LOSS ARISING OUT OF OR IN CONNECTION WITH
THE ABILITY OR INABILITY TO USE THE PRODUCTS.
•
SOME STATES OR JURISDICTIONS DO NOT ALLOW THE LIMITATION OR EXCLUSION OF
INCIDENTAL OR CONSEQUENTIAL DAMAGES, OR THE EXCLUSION OR LIMITATION ON
THE LENGTH OF AN IMPLIED WARRANTY, OR THE LIMITATION OR EXCLUSION OF
DAMAGES FOR PERSONAL INJURIES CAUSED BY NEGLIGENCE, SO THE ABOVE
LIMITATIONS OR EXCLUSIONS MAY NOT APPLY TO YOU. THIS WARRANTY GIVES YOU
SPECIFIC LEGAL RIGHTS, AND YOU MAY ALSO HAVE OTHER RIGHTS THAT VARY FROM
STATE OR JURISDICTION.
• DATA BACKUP:
ALL INFORMATION, DATA, SOFTWARE OR OTHER APPLICATIONS,
INCLUDING BUT NOT LIMITED TO PERSONAL CONTACTS, ADDRESS BOOKS, PICTURES,
MUSIC AND GAMES WILL BE ERASED DURING THE REPAIR PROCESS, AND CAN NOT BE
REINSTALLED BY MOTOROLA. TO AVOID LOSING SUCH INFORMATION, DATA,
SOFTWARE OR OTHER APPLICATIONS PLEASE CREATE A BACK UP BEFORE YOU DELIVER
YOUR PRODUCT FOR WARRANTY SERVICE, REMOVE ANY CONFIDENTIAL, PROPRIETARY
OR PERSONAL INFORMATION AND DISABLE ANY SECURITY PASSWORDS. YOU WILL BE
RESPONSIBLE FOR REINSTALLING ALL SUCH INFORMATION, DATA, SOFTWARE, OTHER
APPLICATIONS AND PASSWORDS. MOTOROLA AND/OR ITS AUTHORIZED SERVICE
CENTERS ARE NOT RESPONSIBLE FOR THE LOSS OR MISUSE OF ANY DATA, FILES,
CONTENT, APPLICATIONS AND PROGRAMS WHEN THE PRODUCT IS DELIVERED FOR
WARRANTY SERVICE. YOUR PRODUCT OR A REPLACEMENT PRODUCT WILL BE
RETURNED TO YOU AS YOUR PRODUCT WAS CONFIGURED WHEN ORIGINALLY
PURCHASED, SUBJECT TO APPLICABLE SOFTWARE UPDATES. MOTOROLA MAY
INSTALL OPERATING SYSTEM SOFTWARE UPDATES AS PART OF WARRANTY SERVICE
THAT MAY PREVENT THE PRODUCT FROM REVERTING TO AN EARLIER VERSION OF THE
OPERATING SYSTEM SOFTWARE. THIRD PARTY APPLICATIONS INSTALLED ON THE
PRODUCT MAY NOT BE COMPATIBLE OR WORK WITH THE PRODUCT AS A RESULT OF
THE OPERATING SYSTEM SOFTWARE UPDATE. MOTOROLA AND ITS AUTHORIZED
SERVICE CENTERS ARE NOT RESPONSIBLE FOR THE LOSS OF, OR INABILITY TO USE,
SUCH INFORMATION, DATA, SOFTWARE OR OTHER APPLICATIONS.
• WARNING AGAINST UNLOCKING THE BOOTLOADER OR ALTERING A
PRODUCT'S OPERATING SYSTEM SOFTWARE:
MOTOROLA STRONGLY
RECOMMENDS AGAINST ALTERING A PRODUCT'S OPERATING SYSTEM, WHICH
INCLUDES UNLOCKING THE BOOTLOADER, ROOTING A DEVICE OR RUNNING ANY
OPERATING SOFTWARE OTHER THAN THE APPROVED VERSIONS ISSUED BY
MOTOROLA AND ITS PARTNERS. SUCH ALTERATIONS MAY PERMANENTLY DAMAGE
YOUR PRODUCT, CAUSE YOUR PRODUCT TO BE UNSAFE AND/OR CAUSE YOUR
06/13/2012
FCC
61Safety, Regulatory & Legal
PRODUCT TO MALFUNCTION. IN SUCH CASES, NEITHER THE PRODUCT NOR ANY
DAMAGE RESULTING THEREFROM WILL BE COVERED BY THIS WARRANTY.
• IMPORTANT FCC INFORMATION:
YOU MUST NOT MAKE OR ENABLE ANY CHANGES
TO THE PRODUCT THAT WILL IMPACT ITS FCC GRANT OF EQUIPMENT AUTHORIZATION.
THE FCC GRANT IS BASED ON THE PRODUCT'S EMISSION, MODULATION, AND
TRANSMISSION CHARACTERISTICS, INCLUDING: POWER LEVELS, OPERATING
FREQUENCIES AND BANDWIDTHS, SAR LEVELS, DUTY-CYCLE, TRANSMISSION MODES
(E.G., CDMA, GSM), AND INTENDED METHOD OF USING THE PRODUCT (E.G., HOW THE
PRODUCT IS HELD OR USED IN PROXIMITY TO THE BODY). A CHANGE TO ANY OF THESE
FACTORS WILL INVALIDATE THE FCC GRANT. IT IS ILLEGAL TO OPERATE A
TRANSMITTING PRODUCT WITHOUT A VALID GRANT.
Copyright & Trademarks
Motorola Mobility, Inc.
Consumer Advocacy Office
600 N US Hwy 45
Libertyville, IL 60048
www.motorola.com
Note:
Do not ship your product to the above address. If you need to return your product for
repairs, replacement, or warranty service, please contact the Motorola Customer Support
Center at:
1-800-734-5870 (United States)
1-888-390-6456 (TTY/TDD United States for hearing impaired)
1-800-461-4575 (Canada)
Certain features, services and applications are network dependent and may not be available
in all areas; additional terms, conditions and/or charges may apply. Contact your service
provider for details.
All features, functionality, and other product specifications, as well as the information
contained in this guide, are based upon the latest available information and believed to be
accurate at the time of printing. Motorola reserves the right to change or modify any
information or specifications without notice or obligation.
Note:
The images in this guide are examples only.
MOTOROLA and the Stylized M Logo are trademarks or registered trademarks of Motorola
Trademark Holdings, LLC. Google, the Google logo, Google Maps, Google Talk, Google
Latitude, Gmail, YouTube, Picasa, Google Play Books, Google Docs, Google Goggles, Google
Finance, Google Places, Google Maps Navigation Beta, Google Calendar, Android and Google
Play Store are trademarks of Google, Inc. All other product or service names are the property
of their respective owners.
© 2012 Motorola Mobility, Inc. All rights reserved.
Caution:
Motorola does not take responsibility for changes/modification to the transceiver.
Product ID: MOTOROLA ELECTRIFY™ 2 (Model XT881)
Manual Number: 68016765001-A
06/13/2012
FCC
06/13/2012
FCC
06/13/2012
FCC
