Motorola Mobility T56PA1 Portable Multi-Band GSM/ EDGE/ WCDMA/ LTE Phone with WLAN, Bluetooth and RFID User Manual User Guide

Motorola Mobility LLC Portable Multi-Band GSM/ EDGE/ WCDMA/ LTE Phone with WLAN, Bluetooth and RFID User Guide

Exhibit 8 Users Manual

Socialize Browse Photos & videos
Calls Contacts
Top topics Search topics
Control & customize
Start Home screen & apps
Safety
Type
qwe r t y
45 612 3
Locate
44 West Street
Messages
Protect
At a glance
Want More?
Work Connect & transfer
Music
Troubleshoot
Books
PLAYLISTS
#1
www.
GMAIL™ GOOGLE+™
Motorola <XFON>
pick a topic, get what you need
16 APR 2013
FCC
BackNext
Menu More
At a glance
a quick look
Yo u r p h o ne
Do you believe in love at first sight? Look at your
<Xfone_temp_name>. Maybe you do.
• Beautiful, but made for real life: The tough body and
Gorilla glass resist drops, scratches, and splashes. Yet, it’s
still big and glossy with an HD screen and crisp sound.
• Won’t run out of juice: The efficient, long-lasting battery
won’t die on you just when you’re updating your status or
finally getting to your to-do list.
Gmail Maps Google + Gallery
Headphone
Jack
Volume Keys
Pressing down
volume + power
takes a screen
capture and
immortalizes
embarrassing
text errors.
Power/Sleep Key
Front Camera
For seles.
Photo/Video
Camera
(on back)
Notication
Light
Flashes when
you have a
message.
nano SIM Card
Tray & Slot
Tiny card, use the
pokey tool.
Micro USB/
Charger
Microphone
Tips & tricks
•Start: SIM in, charge up, and register. See “Start”.
•Top topics: Just want a quick hit of what your phone can
do? See “Top topics”.
•More: All the topics in this guide and so much more, right on
your phone. Touch Apps >
Moto Care
>
HELP
TOPICS
. Want even more? See “Get more”
This product meets the applicable limit for exposure
to radio waves (known as SAR) of 1.6 W/kg (FCC &
IC). The limits and guidelines include a substantial
safety margin designed to assure the safety of all persons,
regardless of age and health. The highest SAR values measured
for this device are listed in the regulatory information packaged
with your product.
At a glance
Your phone
Top topics
16 APR 2013
FCC
BackNext
Menu More
At a glance
Top topics
Check out what your phone can do.
•Personalize your phone: see “Redecorate your home”.
•Make a quick change: “Quick settings”.
•Go online: see “Browse”.
•Explore: see “The best of Google™”.
•Find apps: see “Download apps”.
•Be social: see “Socialize”.
•Find it yourself: see “Locate & navigate”.
•Take a photo: see “Take photos”.
•Connect to Wi-Fi: see “Wi-Fi Networks”.
•Watch a movie: see “Movies & TV on Google Play™”.
•Protect your phone: see “Screen lock”.
•Watch interactive guided tutorials: see “MOTO Care”.
•Get all the help you need: see “Get more”.
Tips & tricks
•Intuitive: To get started quickly, touch Apps >
Moto
Care
for interactive tutorials.
At a glance
Your phone
Top topics
16 APR 2013
FCC
BackNext
Menu More
Start
let’s get up & running
Charge up
SIM in, charge up, then power up.
Note: Certain apps and features may not be available in all
countries.
Caution: Before using your phone, please read the
safety, regulatory and legal information provided with
your product.
1
Use the tool from in the box to slide out
the SIM tray. Pop in the nano SIM.
2Charge up.
Note: Your phone uses a
non-removable battery.
3 H
3Power up.
C
har
g
e u
p
.
C
Power
Key
Tips & tricks
•Power/Sleep Key: To make the screen sleep or wake up,
press the Power key. To turn your phone on or off, press and
hold it.
• Notification Light: The notification light turns on when your
phone starts charging and blinks when you have a new
message or notification.
• Battery: Squeeze every bit of juice out of your battery, see
“Battery life”.
Note: This product uses a non-removable battery. The battery
should only be replaced by a Motorola-approved service
facility. Any attempt to remove or replace your battery, unless
performed by a service representative, may damage the
product and void your warranty.
Start
Charge up
Battery life
Register
The best of Google™
Old phone to new phone
16 APR 2013
FCC
BackNext
Menu More
Start
Battery life
Your phone is like a small computer, giving you tons of
information and apps, at 4G LTE speed. Depending on what
you use, that can take a lot of power.
To see what's using up battery power, touch Apps >
Settings
>
Battery
. To set automatic rules to save power,
touch Apps >
SmartActions
. See “SMARTACTIONS™”.
Tips & tricks
To save even more battery life between charges, you could
reduce:
•recording or watching videos, listening to music, or taking
pictures.
•widgets that stream information to your home screen, like
news or weather.
•unused online accounts that you registered: Touch
Apps >
Settings
>
Accounts & sync
.
•Wi-Fi and Bluetooth® use: Touch Apps >
Settings
,
then touch the switch next to
Wi-Fi
or
Bluetooth
to turn them
when you don’t need them.
•GPS use: Touch Apps >
Settings
>
Location services
,
and uncheck
GPS satellites
.
•display brightness: Touch Apps >
Settings
>
Display
>
Brightness
> (dimmer setting).
•display timeout delay: Touch Apps >
Settings
>
Display
>
Sleep
> (shorter setting).
OFF
Start
Charge up
Battery life
Register
The best of Google™
Old phone to new phone
16 APR 2013
FCC
BackNext
Menu More
Start
Register
After you power up, create or log into a Google™ account to
access all of your Google services. Registration is secure and
only takes a few minutes.
Tip : To get your contacts, visit
www.motorola.com/transfercontacts.
Note: This phone supports apps and services that use a lot of
data, so make sure your data plan meets your needs. Contact
your service provider for details.
Turn it on.
T
1
Do a few easy setup steps.
D
3
Got Google?
Do you have a Google Account?
If you use Gmail, answer Yes.
No
Yes
Select a language.
Se
2
Welcome
English
Start
Choose your language to begin
Tips & tricks
•Wi-Fi network: For faster Internet access, touch >
>
Wi-Fi
.
•Reboot: In the unlikely event that your phone becomes
unresponsive, try a forced reboot. Press and hold both the
Power and Volume Down keys for about 15 seconds.
• Accounts: To add, edit, or delete accounts anytime, touch
Apps >
Settings
>
Accounts & sync
. For more, see
“Remove accounts”. To set up email accounts, see “Email”.
For help with your Google account, visit
www.google.com/accounts.
Start
Charge up
Battery life
Register
The best of Google™
Old phone to new phone
16 APR 2013
FCC
BackNext
Menu More
Start
The best of Google™
Your whole world, organized and accessible. Browse, locate,
watch, shop, play, work...Google has you covered. One
account, access everywhere—phone, tablet, computer.
Google Play
APPS
MOVIES & TV
BOOKS
GAMES
MUSIC
MAGAZINES
Google Play has a new design to make it easier to
browse and discover new favorites. Enjoy!
We’ve changed a few
things around here...
Free Music
Coachella Festival Sampler
Read Free Previews SEE MORE
Change your
settings, redeem a
Google Play card,
and more.
Search for the
perfect app.
Tips & tricks
•Find more about Google products: See
www.google.com/about/products.
•Log in or open a Google account: Visit
www.google.com/accounts.
• Google help: See www.google.com/support/.com.
• Download Google apps: To uch
Play Store
.
•Access all of your files in the cloud: Check out “Your
cloud”.
Start
Charge up
Battery life
Register
The best of Google™
Old phone to new phone
16 APR 2013
FCC
BackNext
Menu More
Start
Old phone to new phone
Moving your settings, texts, contacts, and more from your old
Android phone is quick and painless—we promise.
Download the Migrate app from Google Play™ Store on your
old phone to get started. Then on your new phone, touch
Apps > Migrate.
Start
Charge up
Battery life
Register
The best of Google™
Old phone to new phone
16 APR 2013
FCC
BackNext
Menu More
Home screen & apps
you have quick access
Quick start: Home screen & apps
Start from the home screen, to explore apps and more.
•Home screen: You’ll see the home screen when you turn on
your phone or touch Home .
• App & widget list: To show all of your apps and widgets,
touch Apps .
•More: To download more apps and widgets from Google
Play™ Store, touch
Play Store
.
Tips & tricks
•Pages: To add or show other pages of shortcuts and
widgets, flick the home screen left. To delete pages from
your home screen, touch Home , touch and hold a
page, then drag it up to
Remove
.
• Settings: To quickly open settings, flick the home screen
right.
• Uninstall: To uninstall apps, touch Apps , touch and hold
an app, then drag it to
More options
and choose
Uninstall
(if available).
Home screen & apps
Quick start: Home screen & apps
Redecorate your home
MOTO Care
Search
Status & notifications
Download apps
Take Care of your apps
Update your phone
16 APR 2013
FCC
BackNext
Menu More
Home screen & apps
Redecorate your home
For quick access to your favorite things, customize your home
screen the way you want.
• Change wallpaper: Touch and hold an empty spot on your
home screen to choose your wallpaper.
•Create shortcut groups: You can group app shortcuts
together on your home screen to organize them.
To create a shortcut group on your home screen, drag
one shortcut onto another. Add more shortcuts by
dragging them onto the first shortcut. To name the
group, touch it and enter a name below the apps.
• Add widgets & shortcuts: Touch Apps , touch and hold
the app or widget, then drag it to one of your home screen
pages. To see all your apps and widgets, flick the menu to
the left, or touch
ALL APPS
or
WIDGETS
at the top. To see
your
Favorites
touch , then touch
ADD/REMOVE
to edit
your favorite apps.
Tip : Some apps include widgets. To download apps,
touch
Play Store
.
• Resize widgets: You can resize some widgets—touch and
hold a widget until you feel a vibration, then release. Drag
the blue diamonds at the edges to resize.
• Move or delete widgets & shortcuts: Touch and hold a
widget or shortcut until you feel a vibration, then drag it to
another spot, another page, or
Remove
at the top of the
screen.
• Add, rearrange, or delete pages: To show other pages of
shortcuts and widgets, flick the home screen right.
To add, reorder, or delete pages, from your home
screen, flick right to show
Add a page
. Then, touch
Blank page
or
Start with a template
.
To uch
Manage pages
, then touch and hold a page to
rearrange or remove. Touch to add, or touch and
hold an existing page and drag it to left or right to
reorder, or drag it up to
Remove
.
•Ringtones and more: For more about customizing, see
“Control & customize”.
MOTO Care
To show interactive walk-through tutorials, touch Apps >
Moto Care
.
Home screen & apps
Quick start: Home screen & apps
Redecorate your home
MOTO Care
Search
Status & notifications
Download apps
Take Care of your apps
Update your phone
16 APR 2013
FCC
BackNext
Menu More
Home screen & apps
Moto Care
makes things easy for you by taking you through
your phone’s features.
Search
At the top of the home screen, touch the Google search
widget for a text search, or for voice search.
As you type, suggestions appear below the search field:
•To search for a suggestion, touch it.
•To search for text in the search field, touch on the
keypad.
Explain how to use Google Now
to get info such as weather and
traffice when you need it.
Show me how I can ask Google
questions using Voice Search.
Show me the improvements to
my Notifications and how to
manage them.
Show me how to use my
touchscreen.
Show me how to to turn my
screen on and off.
Guide Me
TUTORIALS
What’s new
HELP TOPICS
General
Touch a topic to
learn more.
Google Now™
Google Now shows you what’s around you, relevant to the
moment: current traffic, weather, your appointments, and
more. It all happens automatically.
To get started, touch and hold Home , and then flick up to
the Google icon .
To turn Google Now on/off or learn more, touch the Google
search widget on your home screen, then touch Menu
>
Settings
>
Google Now
.
Search, or say Google
Show sample cards
Over time, prediction improves and more cards
appear. To see examples, check out the sample
cards.
Cards show up here when
you need them
$37 New TEVA Brown Leather Mules Fleece...
5:45PM, Thursday, April 4
Package: Shipped
1 Women’s Comfort Touring Bike, Hipster Blue
Package: Shipped
Touch to start a
voice search.
Stu that’s
important to you
shows up here.
Home screen & apps
Quick start: Home screen & apps
Redecorate your home
MOTO Care
Search
Status & notifications
Download apps
Take Care of your apps
Update your phone
16 APR 2013
FCC
BackNext
Menu More
Home screen & apps
Status & notifications
At the top of the screen,
icons on the left notify you
about new messages or
events (flick the bar down
for details).
Tip : To uc h to sh o w
Settings.
Icons on the right tell you
about phone status:
Network and Wi-Fi icons turn blue when your phone
exchanges data with your Google™ account.
Note: Apps you download from Google Play™ Store might
show other icons in the status bar to alert you to specific events.
network strength
(=4G LTE network)
/ battery charging/full
/Wi-Fi
in range/connected
silent
/Bluetooth™
on/connected
vibrate
GPS active alarm set
airplane mode warning
December 20, 2012
New voicemail
Dial *86
10:41 AM
Wi-Fi networks available
Select a Preferred Network
11:20 AM
Jim Somers: Meeting time?
paul.wang.6@gmail.com
11:23 AM
3 new messages
Gmail
10:49 AM
4:00
Thursday
Download apps
Google Play™
Google Play is a new entertainment hub full of music, movies,
books, apps, and games. You can instantly access your content
from all your Android devices.
Find it:
Play Store
•Find: To search, touch in the top right.
•Review: To show details and reviews for an app you found,
just touch it.
Ti p: For the full list of reviews, touch
See all
below the third
review, then touch
Most helpful first
or
Options
to
customize the list.
• Download: To download an app you found, touch it to open
details and then touch
Download
, or the price.
•Share: To share an app you found, touch it to open details
and then touch .
• Reinstall: To show or reinstall apps you downloaded from
the Google Play Store app, touch Menu >
My Apps
.
•Use a computer: To find and manage apps from any
computer, go to http://play.google.com using your Google
account and password.
There, you can browse apps on the big screen,
manage your apps across multiple devices (like a
phone and tablet), and even set new apps to download
to your devices.
Home screen & apps
Quick start: Home screen & apps
Redecorate your home
MOTO Care
Search
Status & notifications
Download apps
Take Care of your apps
Update your phone
16 APR 2013
FCC
BackNext
Menu More
Home screen & apps
• Enjoy music, books & movies: Yo u c a n a l s o u s e t h e
Google Play Store app to download “Music on Google
Play™”, “Books on Google Play™”, and “Movies & TV on
Google Play™”.
•Get help: To get help and more, touch Menu in the top
right.
Apps from the web
You can get apps from online app stores using your browser.
Tip : Choose your apps and updates carefully, as some may
impact your phone’s performance—see “Choose carefully”.
Note: When installing an app, make sure you read the alerts
that tell you what information the app will access. If you don’t
want the app to have access to this information, cancel the
installation.
To let your phone install apps that are not from Google Play,
touch Apps >
Settings
>
Security
and check
Unknown
sources
.
To download files from your browser, see “Downloads”.
Choose carefully
Apps are great. There's something for everyone. Play,
communicate, work, or have fun. But remember, choose your
apps carefully. Here are a few tips:
•To help prevent spyware, phishing, or viruses from affecting
your phone or privacy, use apps from trusted sites, like
Google Play Store.
•In Google Play Store, check the app’s ratings and comments
before installing.
•If you doubt the safety of an app, don't install it.
•Like all apps, downloaded apps will use up memory, data,
battery, and processing power—some more than others.
For example, a simple battery level widget will use less than
a streaming music player app. After installing an app, if
you're not happy with how much memory, data, battery or
processing power it's using, uninstall it. You can always
install it again later.
•Just like web browsing, you may want to monitor childrens’
access to apps to help prevent exposure to inappropriate
content.
•Certain apps may not provide completely accurate
information. Take care, especially when it comes to personal
health.
Take Care of you r app s
From your home screen, touch Apps , then flick left to scroll
through apps. To close the apps screen, touch Home or
Back .
•Favorites: To show your favorite apps, touch at the top of
the screen. Then touch
ADD/REMOVE
to edit your favorite
apps.
Ti p: Apps you download are added to your favorites.
Home screen & apps
Quick start: Home screen & apps
Redecorate your home
MOTO Care
Search
Status & notifications
Download apps
Take Care of your apps
Update your phone
16 APR 2013
FCC
BackNext
Menu More
Home screen & apps
• Uninstall apps: Touch Apps >
Settings
>
Apps
>
ALL
,
touch an app, then touch
Disable
or
Uninstall
in the top right
(if available).
Disable
removes the app from your menu. To
Enable
it,
reopen this window and touch
Enable
(disabled apps
are at the bottom of the list).
If an app locks up your phone as soon as you turn it on,
restart in Safe Mode: Turn off your phone, then turn it
back on—when you see the “Motorola” logo during
power-up, press and hold both volume keys until you
see the home screen, with
Safe Mode
in the lower left.
Then, try removing the app.
• Reinstall apps: To reinstall apps from the Google Play Store,
touch Apps >
Play Store
>
My apps
. The apps you
downloaded are listed and available for download.
• Share, show, or clear app details: Touch Apps >
Settings
>
Apps
. A bar at the bottom tells you how much
app storage space you have left. At the top, touch the list of
DOWNLOADED
,
RUNNING
, or
ALL
apps, then touch an app
in the list to show its details and storage usage. You can
touch
Share
,
Clear data
or other options.
Tip : To quickly show these app details from your app
screen: Just touch and hold an app, drag it to
More
options
at the top of your screen, then choose
App info
.
•Show app data usage: To show which apps are using the
most data, touch Apps >
Settings
>
Data usage
. For
more, see “Data use”.
Update your phone
Use your phone or computer to check, download, and install
phone software updates:
•Using your phone:
If your phone notifies you about an update, follow the
instructions to download and install it.
To manually check for updates, touch Apps >
Settings
>
About phone
>
System updates
.
Your phone downloads updates over your Wi-Fi
connection (if available) or mobile network. We
recommend that you download updates when you
have a Wi-Fi connection. Remember, these updates
can be quite large (25MB or more) and may not be
available in all countries. If the mobile network updates
are not available in your country, update using a
computer.
•Using your computer:
On your computer, go to www.motorola.com/support
and check the “Software” links. If an update is
available, just follow the installation instructions.
Home screen & apps
Quick start: Home screen & apps
Redecorate your home
MOTO Care
Search
Status & notifications
Download apps
Take Care of your apps
Update your phone
16 APR 2013
FCC
BackNext
Menu More
Control & customize
how it acts & looks
Quick start: Control & customize
Take control of your phone:
•Touch: It’s all in the touch. Simple gestures and touch keys
to move about.
•Speak: Tell your phone what you want—touch for
Google Voice Actions.
•Customize: Change notifications or display settings—flick
the status bar down and touch .
Tips & tricks
•Touch: Choose an icon or option.
•Touch & hold: Move items on the home screen, or open
options for items in lists (like
People
).
•Drag or flick: Scroll slowly (drag) or quickly (flick).
• Pinch or double-tap: Zoom in and out on websites, photos,
and maps.
•Twist: Twist a map with two fingers to rotate it, and pull two
fingers down to tilt it.
•Speak: You can touch in a search window or in a
keypad, or touch Apps >
Voice Commands
.
•Ringtone for a contact: To set a ringtone for a contact,
touch
People
, touch the contact, then touch Menu
>
Set ringtone
.
• Quick settings: To chan g e
Phone ringtone
,
Wi-Fi
,
Bluetooth
,
GPS
,
Airplane mode
,
Mobile data
, and
Phone lock
settings, flick the home screen right. Then, touch the switch
to turn or .
•Home screen: For more about changing your home screen,
see “Redecorate your home”.
ON
OFF
Control & customize
Quick start: Control & customize
On, off, lock & unlock
Touch
Press
Speak
Customize
Quick settings
SMARTACTIONS™
Accessibility
16 APR 2013
FCC
BackNext
Menu More
Control & customize
On, off, lock & unlock
Your touchscreen is on when you need it, and off when you
don’t:
• Screen off & on: Press the Power key to turn the screen off
& on.
Note: During a call, your
touchscreen might stay
dark if the sensor just
above it is covered. Don't use covers or screen
protectors (even clear ones) that cover this sensor.
• Screen lock: To unl o c k the
screen, touch and flick
to . To add a password or
facial recognition security to
your unlock screen,
touch Apps >
Settings
>
Security
>
Screen lock
. See “Screen
lock”.
• Screen timeout: To c h a ng e
your timeout (screen locks
automatically),
touch Apps >
Settings
>
Display
>
Sleep
.
Touch
Find your way around:
Phone
Unlock
Messages
Camera
Touch and flick to:
Messages Camera
UnlockPhone
•Back: Touch Back to go to the previous screen.
•Home: Touch Home to return to the home screen. On
your first home screen page, touch Home to show all
the pages.
• Recent apps: Touch Recent to show your recent apps,
and touch an app to reopen it. To remove an app from the
list, flick it left or right. To scroll the list, flick up or down.
•Menu: When Menu appears in the corner of the screen,
you can touch it to open options for the current screen.
Lost or stuck? If you’re not sure what to do next, try one of
these:
•To open a text message, see contact details, or open items
in a list, touch the message, contact, or item.
•To show options for a list item (if available), touch and hold
the item.
•To show a menu for the current screen, touch Menu in
the corner of the screen (if available).
•To return home to the home screen, touch Home .
•To go back just one screen, touch Back .
•To reopen an app you closed, touch Recent and touch
the app in the list.
•To reboot an unresponsive phone, press and hold both
Power and Volume Down keys for about 15 seconds.
Control & customize
Quick start: Control & customize
On, off, lock & unlock
Touch
Press
Speak
Customize
Quick settings
SMARTACTIONS™
Accessibility
16 APR 2013
FCC
BackNext
Menu More
Control & customize
Press
Power key
Press and hold the Power key to
choose
Power off
,
Airplane
mode
, vibrate , or silent .
To conserve battery, prevent
accidental touches, or when you
want to wipe smudges off your
touchscreen, put the
touchscreen to sleep by
pressing the Power key. To wake
up the touchscreen, just press
the Power key again.
Tip : To add more security to your phone, see “Protect”.
Volume keys
Your volume keys help in a few ways:
• Ringer volume: Press the keys in the home screen, or press
them when your phone is ringing to silence it.
• Earpiece volume: Press the keys during a call.
•Music/video volume: Press the keys during a song or
video.
Speak
Just tell your phone what you’d like:
Tip : Speak naturally but clearly, like using a speakerphone.
Power
Key
• Dialing and commands: Tou c h Ap p s >
Voice
Commands
. To dial, say “Call” and then a contact name or
phone number. Or, say a command like “Send Text,” “Go to”
and app, or “Help” for voice command help.
To choose the confirmations and prompts you want to
hear, touch Apps >
Voice Commands
, then touch
in the top right.
• Search: Enter text in the Google search widget at the top of
your home screen, or touch to search by voice.
To change your voice search and text-to-speech
settings, touch Apps >
Settings
>
Language &
input
.
• Text entry: On a touchscreen keyboard, touch , then
speak your message. You can also speak punctuation.
Tip : To make your phone read out loud, see “TalkBack”.
Customize
Customize your phone’s sounds and appearance:
• Ringtone and notifications: To choose ringtones or
notifications, touch Apps >
Settings
>
Sound
.
To use a song as a ringtone, touch Apps >
Play Music
>
Songs
, touch and hold the song name,
then touch
Use as phone ringtone
.
• Vibrate or silent: To choose whether your phone vibrates
for incoming calls, touch Apps >
Settings
>
Sound
.
Choose
Silent mode
to set whether it vibrates when you set
Control & customize
Quick start: Control & customize
On, off, lock & unlock
Touch
Press
Speak
Customize
Quick settings
SMARTACTIONS™
Accessibility
16 APR 2013
FCC
BackNext
Menu More
Control & customize
the lock screen slider to silent. Check
Vibrate and ring
to
make it vibrate when the ringer is not silent.
•Ringtone for a contact: To set a ringtone for a contact,
touch
People
, touch the contact, then touch Menu
>
Set ringtone
.
•Volume: To set volume, just press the volume keys in the
home screen (ringtone volume), during a call (earpiece
volume), or while playing music or a video (media volume).
• Message alert: To change your new message notification,
touch Apps >
Messages
> Menu >
Messaging
Settings
, then choose
Text Messaging
,
Social Messaging
, or
Email
.
• Display settings: To change brightness, animation, and
other display settings, touch Apps >
Settings
>
Display
.
•Rotate: In many apps, the touchscreen switches from
portrait to landscape when you rotate your phone. To turn
this on or off, touch Apps >
Settings
>
Display
>
Auto-rotate screen
.
•Home screen: To change your wallpaper, touch and hold an
empty spot on your home screen. For more, see
“Redecorate your home”.
• Language and region: To set your menu language and
region, touch Apps >
Settings
>
Language & input
>
Locale
.
Control & customize
Quick start: Control & customize
On, off, lock & unlock
Touch
Press
Speak
Customize
Quick settings
SMARTACTIONS™
Accessibility
16 APR 2013
FCC
BackNext
Menu More
Control & customize
Quick settings
To chan g e
Phone ringtone
,
Wi-Fi
,
Bluetooth
,
GPS
,
Flight mode
,
Mobile data
, and
Phone lock
settings, from the home screen
flick left. Then, touch the switch to turn or .
ON
OFF
SMARTACTIONS™
Wish your phone could automatically reply to texts when
you’re driving, silence your ringer during meetings, and
conserve your battery when it runs low? It can.
SMARTACTIONS suggests actions to automate, based on how
you use your phone. When you see a suggestion in the
status bar, flick the bar down to accept or delete it.
To get started, touch Apps >
SmartActions
.
•To create an action, touch
Add a new SmartAction
.
•For help in
SmartActions
, touch Menu >
Help
.
Battery Saver
My charging status
changes
Not charging
Automatic brightness
Keep apps synced only..
Adjust background
data
Processor speed
TRIGGERS
ACTIONS
SAVE CANCEL
Set my screen
brightness
Change the icon or name.
Save your changes.
Add Triggers (like events,
times, or places) that start
the action.
Turn off triggers by dragging
them to the right.
Add an Action (like silencing the
ringer) to make it happen when
the trigger does.
Control & customize
Quick start: Control & customize
On, off, lock & unlock
Touch
Press
Speak
Customize
Quick settings
SMARTACTIONS™
Accessibility
16 APR 2013
FCC
BackNext
Menu More
Control & customize
Accessibility
See, hear, speak, feel, and use. Accessibility features are there
for everyone, helping to make things easier.
Note: For general information, accessories, and more, visit
www.motorola.com/accessibility.
Voice recognition
Just tell your phone what you’d like to do—dial, browse,
search, send a message, and a whole range of other actions
and commands. Touch Apps >
Voice Commands
. For
more, see “Speak”.
Talk B ack
Use
TalkBack
to read out loud—your navigation, your
selections, even your books.
To turn on
TalkBack
, touch Apps >
Settings
>
Accessibility
>
TalkBack
, then touch at the top to turn
it to .
Note: You might need to download text-to-speech software
(data charges may apply).
To use
TalkBack
:
• Menus and screens: Touch an item in a menu or
screen—your phone speaks the name.
• Dialer & text entry: Start typing, and your phone speaks
each number or letter.
• Notifications: Flick the status bar down. Your phone speaks
all of the notifications.
OFF
ON
•Books & more: Open a book, file, message, and more—it’s
read out loud (app dependent).
Tip : Navigate through your apps and menus to hear how voice
readouts work on your phone.
Ta ke
TalkBack
to the next level. See “Explore by touch”.
Explore by touch
Use
Explore by touch
to expand
TalkBack
, and have your
touches read out loud as you move your finger around the
screen.
To t u r n on
Explore by touch
, turn on
TalkBack
then touch
Apps >
Settings
>
Accessibility
>
Explore by touch
, then
touch at the top to turn it to .
Explore by touch
changes some touch gestures slightly so that
the location of your touches can be read out loud. Just follow
the handy tutorial to learn more.
Caller ID
When you want to hear who’s calling:
•Read out loud: Have your caller announced—touch
Apps >
Settings
>
Accessibility
>
Caller ID Readout
.
•Ringtones: Assign a unique ringtone to a contact.
To u c h
People
, touch the contact, then touch Menu
>
Set ringtone
.
Volume & vibrate
Find it: Apps >
Settings
>
Sound
>
Volumes
or
Vibrate and ring
OFF
ON
Control & customize
Quick start: Control & customize
On, off, lock & unlock
Touch
Press
Speak
Customize
Quick settings
SMARTACTIONS™
Accessibility
16 APR 2013
FCC
BackNext
Menu More
Control & customize
•
Volumes
: Set different volumes for your music or videos,
ringtone, text or email notifications, and alarms.
•
Vibrate and ring
: Set your phone to vibrate for incoming
calls (even if the ringer is silent).
Zoom
Get a closer look.
•Pinch to zoom: Pinch to zoom in and on web pages and
photos: To zoom in, touch the screen with two fingers and
then drag them apart. To zoom out, drag your fingers
together.
Tip : To zoom in, you can also double-tap.
•Big text: Show bigger text throughout your phone: touch
Apps >
Settings
>
Accessibility
>
Large text
.
•Browser: Choose zoom, text size and other accessibility
settings for your browser: touch
Chrome
>Menu
>
Settings
>
Accessibility
.
Display brightness
Your phone automatically adjusts the screen brightness when
you’re in bright or dark places. But you can set your own
brightness level instead:
Find it: Apps >
Settings
>
Display
>
Brightness
Uncheck
Automatic brightness
to set your own level.
Touchscreen & keys
To hear or feel when you touch the screen, touch Apps >
Settings
>
Sound
:
•Touchscreen: To hear screen touches (clicks), select
Touch
sounds
.
•Keys: To feel screen keyboard touches (vibrate), select
Vibrate on touch
.
• Screen lock: To hear when you lock or unlock the screen
(click), select
Screen lock sound
.
Messages
To make text entry even easier, use features like auto-complete,
auto-correct, and auto-punctuate—touch Apps >
Settings
>
Language & input
, then touch next to a
keyboard type. Of course if you don’t want to type at all, then
use your voice—touch on the touchscreen keyboard.
Hearing aids
To help get a clear sound when using a hearing aid or cochlear
implant, your phone may have been rated for use with hearing
aids. If your phone’s box has “Rated for Hearing Aids” printed
on it, then please read the following guidance.
Note: Ratings are not a guarantee of compatibility
(see”Hearing Aid Compatibility with Mobile Phones” in your
legal and safety information). You may also want to consult your
hearing health professional, who should be able to help you get
the best results.
• Settings: Tou c h
Phone
>Menu >
Settings
>
Hearing
aids
.
• Call volume: During a call, press the side volume keys to set
a call volume that works for you.
Control & customize
Quick start: Control & customize
On, off, lock & unlock
Touch
Press
Speak
Customize
Quick settings
SMARTACTIONS™
Accessibility
16 APR 2013
FCC
BackNext
Menu More
Control & customize
• Position: During a call, hold the phone to your ear as
normal, and then rotate/move it to get the best position for
speaking and listening.
TTY
You can use your phone in TTY mode with standard teletype
machines. Touch
Phone
>Menu >
Settings
>
TTY mode
and select the mode you need:
•
TTY full
: Type and read text on your TTY device.
•
TTY HCO
: Hearing-Carry-Over—type text on your TTY
device and listen to voice replies on your phone’s speaker.
•
TTY VCO
: Voice-Carry-Over—speak into your phone and
read text replies on your TTY device.
Note: You’ll need a cable/adapter to connect your TTY device
to the headset jack on your phone.
Refer to your TTY device guide for mode and usage
information.
Apps
Want more? No problem. The Google Play Store provides
access to thousands of apps, and many provide useful
accessibility features.
Find it: Apps >
Play Store
Control & customize
Quick start: Control & customize
On, off, lock & unlock
Touch
Press
Speak
Customize
Quick settings
SMARTACTIONS™
Accessibility
16 APR 2013
FCC
BackNext
Menu More
Calls
when you need to talk
Quick start: Calls
Dial numbers, recent calls, or contacts, all from one app.
Find it:
Phone
Tip : In the phone unlock screen, drag to .
To make a call, enter a number then touch in the
DIALER
,
or flick to the
RECENT
and
FAVORITES
tabs for quick access
to your calls and contacts.
Most recent
DIALER FAVORITESRECENT
1 2ABC 3DEF
4GHI 5JKL 6MNO
7PQRS 8TUV 9WXYZ
0
Victor Harp
April 26, 2012
Mobile 555-555-4570
Dialpad Speaker Mute Add call Hold
During a call:
Hang up
Recent & Favorite Contacts
Call Settings
Delete numbers you entered.
Search People
Call
Voice Dial
Dialpad
Mute
Add Call
Speaker
Hold
Tips & tricks
• During a call: Your touchscreen goes dark to avoid
accidental touches. To wake it up, move it away from your
face or press the Power key.
•Multi-task: Touch Home to hide the call display and
look up a phone number, address, or open other apps
during a call. To reopen the call display, flick down the status
bar and touch
Current call
.
•People: To search your
People
, touch ,.
•Voicemail: appears in the status bar when you have new
voicemail. To hear it, touch
Phone
, then touch and hold
1
.
Calls
Quick start: Calls
Make, answer & end calls
Recent calls
Favorites
3-way calls
Your phone number
Emergency calls
Cool down
16 APR 2013
FCC
BackNext
Menu More
Calls
Make, answer & end calls
When you make or answer a call, you have options:
• Make a call: To uc h
Phone
, enter a number, then
touch .
To enter the international dialing code (+), touch and
hold . To add a pause or wait after numbers,
touch Menu .
• Answer a call: Touc h a n d f l i c k to .
With call waiting on, touch and flick to to answer
the new call, then touch
Hold current call + Answer
or
End current call + Answer
.
• Ignore a call: Touch and flick to . You can also press
the Power key to ignore the call, or press a volume key to
silence the ring.
• End a call: To u c h .
• During a call: Touch icons at the bottom of the call display
to mute or hold the call. To hide the call display,
touch Home . To reopen it, flick down the status bar and
touch
Current call
.
Note: When you hold your phone to your ear, the
touchscreen goes dark to avoid accidental touches.
When you move your phone away from your ear, the
display lights up again.
During a call, your
touchscreen might stay
dark if the sensor just
above it is covered. Don't use covers or screen
protectors (even clear ones) that cover this sensor.
Recent calls
Show your calls (with newest first), to call, text, or store them:
Find it:
Phone
>
RECENT
•To call a number, touch on the right.
•To send a text message, store the number, or other options,
touch and hold an entry.
•To search the list, touch at the bottom.
•To clear the list, touch Menu >
Clear List
.
Favorites
Find it: Apps >
People
>
FAVORITES
•To call, text, email, or view contact information, touch the
contact.
•To edit, share, delete, or set a ringtone for a contact, touch
the contact, then touch Menu .
Calls
Quick start: Calls
Make, answer & end calls
Recent calls
Favorites
3-way calls
Your phone number
Emergency calls
Cool down
16 APR 2013
FCC
BackNext
Menu More
Calls
3-way calls
During a call, you can start another call, switch between them,
or join them in a 3-way call:
•To answer a second call, touch and flick to . To ignore
it, touch and flick to .
The first call goes on hold if you answer the second
call. To switch between calls, touch .
•To dial a second call, touch , enter a number in
DIALER
,
RECENT
, or
FAVORITES
, then touch .
The first call goes on hold when you touch . To join
the calls after the second call answers, touch .
Your phone number
Find it: Apps >
Settings
>
About phone
>
Status
>
My Phone number
Emergency calls
Note: Your service provider programs one or more emergency
phone numbers that you can call under any circumstances,
even when your phone is locked. Emergency numbers vary by
country. Your pre-programmed emergency number(s) may not
work in all locations, and sometimes an emergency call cannot
be placed due to network, environmental, or interference
issues.
1Touch
Phone
(if your phone is locked,
touch
Emergency Call
or touch Menu >
Emergency
call
).
2Enter the emergency number.
3Touch to call the emergency number.
Note: Your phone can use location based services (GPS and
AGPS) to help emergency services find you. See “Location
Services” in your legal and safety information.
Cool down
In very limited circumstances, such as where your phone has
been exposed to extreme heat, you may see “Cool Down”
messages. To avoid possible damage to your battery and
phone, you should follow these instructions until the phone is
within its recommended temperature range. When your
phone is in “Cool Down” mode, only emergency calls can be
made.
Calls
Quick start: Calls
Make, answer & end calls
Recent calls
Favorites
3-way calls
Your phone number
Emergency calls
Cool down
16 APR 2013
FCC
BackNext
Menu More
Contacts
you can be a people person
Quick start: Contacts
Combine information from your Google contacts and social
networks for quick access to everyone.
Find it:
People
•Create: Touch below the
People
list.
• Edit or delete: Touch and hold a contact, then touch
edit or delete .
• Call, text, or email: Touch a contact, then touch an option.
ME
ME
A
Set up my profile
297 contacts
Abe Baudo
Astrid Fanning
Anna Medina
Avery Durning
Allie Smyth
Barry Smyth
A
B
C
D
E
F
G
H
I
J
K
L
M
N
O
P
Q
R
S
T
U
V
W
X
Y
Z
GROUPS FAVORITESPEOPLE Create & view groups
of contacts.
Touch to view contact
information, call, send a text
message, & more.
Search your People.
Switch to dialer.
Add a contact.
Open settings, accounts, or
share.
Touch a letter to jump to contact
names that start with that letter.
Tips & tricks
•Groups: To show or create a group of contacts, touch
GROUPS
, touch the group or .
• Search contacts: From the home screen, just touch the
Google search widget and enter a contact’s name. In the
People
list, touch .
• Send contacts: Touch a contact, then touch Menu >
Share
to send a contact’s details in a message or over a
Bluetooth® connection.
•Shortcuts: Touch Apps , touch
WIDGETS
at the top, then
touch and hold a
Contact
widget.
•Synchronize: On your computer, upload contacts to your
Google™ account at www.google.com/contacts. On your
phone, touch Apps >
Settings
>
Accounts & sync
,
choose your Google account, then check
Sync Contacts
.
You can also see these contacts at www.gmail.com.
For help with transferring contacts, go to
www.motorola.com/TransferContacts.
Contacts
Quick start: Contacts
Create contacts
Call, text, or email contacts
Favorite contacts
Edit, delete, or hide contacts
Get contacts
Share contacts
Groups
16 APR 2013
FCC
BackNext
Menu More
Contacts
Create contacts
Find it:
People
>
Touch a text box to type the name and details. When you’re
finished, touch
SAVE
at the top.
Note: To import contacts or change where they’re stored, see
“Get contacts”.
Call, text, or email contacts
Find it:
People
Touch and hold the contact to open option icons at the bottom
of your screen (touch and hold an icon to show what it does).
You can also use “Voice recognition”.
Favorite contacts
To see your favorite contacts, touch
People
>
FAVORITES
.
To tag a favorite, touch
People
>
PEOPLE
, touch a contact
to open it, then touch next to their name.
Edit, delete, or hide contacts
Find it:
People
•To edit a contact, touch it, then touch Menu >
Edit
contact
. Then, touch a field to edit or touch to choose
the contact’s picture.
•To set a special ringtone for the contact, touch it, then touch
Menu >
Set ringtone
.
•To delete the contact, touch it, then touch Menu
>
Delete
.
Contacts from social networks will become hidden if
you select
Delete
. To view these contacts, or delete
them permanently, use the social network's app or
website.
•To hide the contacts from an account or group in your
People
list, touch Menu >
Contacts to display
. Touch a
group name to show it, or touch
Customize
to uncheck
groups you always want to hide.
Get contacts
•To add your social networking contacts, add your account in
“Remove accounts”.
•To add your email contacts, see “Email”.
Ti p: If you add a
Corporate Sync
account, you can send
messages to your coworkers, even if you don’t have them
stored in your contacts.
•To import contacts from your SIM card (if that didn’t happen
automatically): Touch
People
>Menu >
Import/Export
>
Import contacts from: SIM card
. Touch
OK
to confirm.
•To import contacts from your computer, upload the contacts
to your Google™ account at http://contacts.google.com.
On your phone, touch
People
>Menu >
Accounts
>
Auto-sync app data
. You can also see these contacts at
http://mail.google.com.
Contacts
Quick start: Contacts
Create contacts
Call, text, or email contacts
Favorite contacts
Edit, delete, or hide contacts
Get contacts
Share contacts
Groups
16 APR 2013
FCC
BackNext
Menu More
Contacts
Where are contacts stored? Your phone can store contacts in
its memory or your Google account: To choose where contacts
are stored, touch Apps >
People
> Menu >
Settings
>
Contact storage
>
Contact storage account
. If you don’t see
your Google account listed, make sure you’re syncing contacts
with it: Touch
People
>Menu >
Accounts
>
Auto-sync
app data
. Contacts are not stored on your SIM card.
For help with transferring contacts, go to
www.motorola.com/TransferContacts.
Share contacts
Send a contact with a Bluetooth™ connection, text message,
or email:
Find it:
People
To send a contact, touch it, then touch Menu >
Share
and
choose how you want to send it.
Note: You can’t send your social network contacts.
Groups
Create groups of
Contacts
(like “friends,” “family,” or “work”),
then find contacts faster by showing one group.
To create or show a group in your
Contacts
, touch
Contacts: All
contacts
at the top of your screen and choose the group name.
Contacts
Quick start: Contacts
Create contacts
Call, text, or email contacts
Favorite contacts
Edit, delete, or hide contacts
Get contacts
Share contacts
Groups
16 APR 2013
FCC
BackNext
Menu More
Messages
say it & go
Quick start: Messages
Stay in touch with messages and pictures.
Find it: Apps >
Text Messaging
Tip : When your phone is locked, drag to
Text
.
•Create: To u c h a b ove the i n b ox l i s t .
• Attach: When you’re typing a message, touch to attach
a picture, video, or other file.
Text Messaging
Change notifications and other
options.
Create a message.
Flick up for more.
Touch a conversation to open it, or
touch and hold for options.
Touch a sender to add them to
People, or open options for
contacting them.
Tips & tricks
• Forward, or save attachments:
Open a conversation, touch and
hold a message, then touch to
forward. Touch and hold a picture
to save it.
•Voice entry: Just touch a text box, then touch on the
touchscreen keyboard.
• Reply to all in text messages: When you send a text
message to multiple people, you can let everyone see the
other recipients and reply to all, or hide the other recipients
so that replies only go to you. To change this, touch
Apps >
Text Messaging
>Menu >
Settings
>
Group message type
.
• Text your best friend: Use a widget to text your favorite
contact quickly: Touch Apps , touch
WIDGETS
at the top,
touch and hold
Direct message
to drag it to your home
screen, then choose a contact.
Sent: February 13, 4:00 PM
Messages
Quick start: Messages
Read, reply, forward & delete text messages
Create text messages
Email
Chat
Wireless Emergency Alerts
16 APR 2013
FCC
BackNext
Menu More
Messages
Read, reply, forward & delete text
messages
Find it: Apps >
Text Messaging
Tip : When your phone is locked, drag to
Text
.
•Open: Touch a conversation to open it.
• Attachments: When you open a message with an
attachment, touch the attachment to open it, or touch and
hold it to save it.
•Reply: Open a conversation, then enter your response in
the text box at the bottom.
•Forward: Open a conversation, touch and hold the
message you want to forward, then touch at the top.
• Delete: Touch and hold a conversation you want to delete
(or open the conversation and touch and hold just one
message), then touch at the top.
• Settings: Touch Menu >
Settings
to change your
signature and other options.
Create text messages
Find it: Apps >
Text Messaging
>
1Enter the recipients at the top.
2Touch the text box at the bottom to enter the
message. For text entry details, see “Type”.
To add an attachment, touch . To send and receive
large attachments faster, use “Wi-Fi Networks”.
Email
Check email accounts, and send responses, photos, websites,
and more.
Find it: Apps >
Gmail
or
Email
• Add Gmail™ accounts: The first time you turned on your
phone, you probably set up or logged in to your Google™
account—that sets up the
Gmail
app for one account,
but you can add more in Apps >
Settings
>
Accounts
& sync
.
• Add email accounts: To add accounts for
Email
, follow
the prompts when you first open the app or touch >
ADD
you@gmail.com
Inbox
2
“Star” a message to add it to the
Starred Gmail label.
Choose accounts or folders.
Touch & hold icons to show
labels.
Choose multiple messages, then
choose an action at the bottom.
Create an email.
Search Gmail.
Show Gmail labels.
Check Gmail.
Open settings & options.
Messages
Quick start: Messages
Read, reply, forward & delete text messages
Create text messages
Email
Chat
Wireless Emergency Alerts
16 APR 2013
FCC
BackNext
Menu More
Messages
ACCOUNT
, then enter details. For Microsoft™ Exchange
server work email accounts, enter details from your IT
administrator.
• Change or delete accounts: To change an account’s sync
and notifications, or delete it, touch Apps >
Settings
>
Accounts & sync
, touch an account, then touch Menu
>
Settings
or
Remove account
.
Chat
Sign in and try a quick chat.
Find it: Apps >
Talk
and select your Google
account. Your friends list opens, and icons tell you who is
available for text chat, video chat, voice chat,
or who is offline.
• Invite a friend: Touch in the top right, then enter the
email address for a friend’s Google account. They’ll receive
the invitation when they sign into Google Talk™.
• Start a text chat: Touch a name in your list of friends, then
enter text and touch .
• Start a voice or video chat: To u c h t h e vo i c e or
video icon next to a friend’s name.
• Chat from a computer: You can chat from a computer, too.
Find out more at www.google.com/talk.
For other chat options, use:
•Webbrowser: In your home screen, touch the Google
search widget and enter your IM provider’s web site. Once
you’re there, follow the link to sign in.
• Apps: To search for an instant messaging app, touch
Play
Store
. Your IM options will depend on your IM provider.
Wireless Emergency Alerts
Wireless Emergency Alerts, also known
as CMAS or PLAN, is a U.S. national
emergency alert system. Emergency
alerts can pop up to tell you about a
national or local crisis. After you close an
alert, you can reopen it by touching Apps >
Emergency
Alerts
.
Tip : Emergency alerts have a special sound and vibration that
is two seconds long, followed by one second, then another one
second.
To choose which types of alerts you receive, touch Apps >
Emergency Alerts
>Menu >
Settings
. The U.S. and local
governments send these alerts through your service provider.
So you will always receive alerts for the area where you are, and
you won’t receive alerts if you’re outside of the U.S.
For more, visit www.ctia.org/consumer_info/safety/.
A
LERTS
WIRELESS
CAPABLE
EMERGENCY
TM
Messages
Quick start: Messages
Read, reply, forward & delete text messages
Create text messages
Email
Chat
Wireless Emergency Alerts
16 APR 2013
FCC
BackNext
Menu More
Type
keypad when you need it
Quick start: Type
When you touch a text box, like in a message or search, you
have keyboard options.
• Choose a keyboard: In a text box, flick down the status bar
and touch
Select input method
.
Android keyboard: Enter letters by touching them one
at a time.
•Close the keyboard: Touch Back .
asdfgh j k l
qwe r t y u i o p
1234567890
zxcvbnm
.
?123
... ... ...
Send
Anne
asdfgh j k l
qwe r t y u i o p
1234567890
@$&_ ( ) : ; “
EN ! # = / +
-’
?
zxcvbnm
,.
+!=
123
To switch keyboards, touch & hold.
Swype Keyboard:
To enter a word, just trace a path
through the letters.
To capitalize, go above the
keypad.
For double letters, circle the letter.
Android Keyboard:
Touch a key for each letter, then
touch predicted words to enter
them.
a
e
n
a
e
n
TM
Tips & tricks
• Keyboard adaptation: Your touchscreen keyboard
changes, depending on whether you’re entering a text
message, email, or other text.
• Move the cursor: Touch a spot in the text to place the
cursor, then drag the arrow under the cursor to move it.
•Copy & paste: Double-tap a word to highlight it (if needed,
drag the ends of the highlight). Touch icons at the top to
select all, cut, copy, or paste (touch and hold the icons to
show labels).
• Your dictionary: To add a word you enter often, enter it,
touch the word in the word list below the text box, then
touch there again to add it to your dictionary.
If Swype doesn’t know a word, touch individual letters
to enter it.
• Symbols: Touch and hold a key to enter the small number or
symbol at the top of it.
To enter several numbers or symbols, touch .
?123
?123
Type
Quick start: Type
Text entry settings & dictionary
Cut, copy & paste
16 APR 2013
FCC
BackNext
Menu More
Type
Text entry settings & dictionary
Choose your keyboard style and edit the dictionary of words
your phone suggests:
Find it: Apps >
Settings
>
Language & input
•To choose your display keyboard, touch
Default
.
Motorola input lets you enter text one letter at a time.
As you type, your phone suggests words. If you enter
a word that wasn’t one of the suggestions, touch the
completed word in the suggestion bar twice to add it
to your dictionary for next time.
Swype™ lets you enter words with one continuous
motion. Just drag your finger over the letters in the
word. If Swype doesn’t know a word, you can touch
letters to enter it—then, touch the word in the
suggestion bar, and touch
Add to dictionary
for next
time.
•To change the preferences for your keyboards, touch
next to a keyboard type. You can change the language,
automatic punctuation, and more.
•To add or edit the words that your phone suggests and
recognizes, touch
Personal dictionary
.
Cut, copy & paste
Cut, copy, and past names, phone numbers, addresses,
quotes, or anything else in a text box.
1To highlight a word, double-tap it.
To highlight more words, drag the selector arrow at the
edge of the highlight.
2Touch the icons for cut or copy.
Ti p: Touch and hold icons to show labels.
3Open the text box where you want to paste the text
(even if it’s in a different app).
4Touch in the text box, then touch and hold to show the
PASTE
option. Touch
PASTE
to paste the text.
Send
Anne Hotel
To highlight a word, double-tap it.
To highlight more, drag the arrows.
Copy
Cut
Select All
Type
Quick start: Type
Text entry settings & dictionary
Cut, copy & paste
16 APR 2013
FCC
BackNext
Menu More
Socialize
your life & your friends
Quick start: Socialize
Google+™ makes connecting on the web more like
connecting in the real world. Share your thoughts, links and
photos with the right circles.
Find it: Apps >
Google+
Posts
Motorola Mobility
Added by
12,225 people
Add to circles +1067
Open options.
Update the Stream.
Tips & tricks
• Automatically upload photos: Touch
Apps >
Gallery
and touch a photo or video. Choose
share >
Google+
and select your account.
• Add a widget: In your home screen, touch Apps , touch
Widgets
at the top, then touch and hold
Google+ Photos
or
Google+ Posts
to drag them to your home screen.
• Help: For more about Google+, visit www.google.com/+.
• Other social networks: You can also use Facebook™,
Twitter, and more. Use the Google Play Store app to find the
latest official apps and widgets.
Socialize
Quick start: Socialize
Remove accounts
16 APR 2013
FCC
BackNext
Menu More
Socialize
Remove accounts
To delete an account (along with its contacts and messages on
your phone), touch Apps >
Settings
>
ACCOUNTS
,
select the account. Touch the account again, then touch
Menu >
Remove account
.
Socialize
Quick start: Socialize
Remove accounts
16 APR 2013
FCC
BackNext
Menu More
Browse
explore & find
Quick start: Chrome™
Find it: Apps >
Chrome
• Go to a webpage: Touch the address bar at the top of a
page and enter an address.
• Add or open bookmarks: Open the address bar (flick down
if you don’t see it), then touch Menu > or
Bookmarks
.
www.google.com
Web
Restaurants Coffee Bars Fast Food Sho
Images
Chicago, IL - Update precise location
Sign in
Sign in
Touch a link to
select it. Touch &
hold for more
options.
Open options.
Show other
browser tabs, or
open a new one.
Tips & tricks
• Home screen shortcut: In your home screen, touch the
Google search widget at the top and enter a website
address.
Note: If you can’t connect, contact your service
provider.
• Mobile sites: Some websites automatically show you a
“mobile” version of their page. If you want to see the
standard computer versions of all websites, touch Menu
>
Request desktop site
.
•Reload: If a page doesn’t load correctly, try touch .
• Clear history: In the browser, touch Menu >
Settings
>
Privacy
>
Clear browsing data
. Then choose history, cache,
cookies, and other options.
• Help: For more about Google Chrome, visit
www.support.google.com/chrome.
Browse
Quick start: Chrome™
Web connection
Bookmarks
Downloads
Browser options
Safe surfing & searching
16 APR 2013
FCC
BackNext
Menu More
Browse
Web connection
To access the web, your phone uses your Wi-Fi network (or
your mobile phone network if no Wi-Fi network is connected).
Note: Your service provider may charge to surf the web or
download data over your mobile phone network.
To connect to a Wi-Fi network, see “Wi-Fi Networks”.
Bookmarks
To bookmark a page in your browser, touch Menu > .
To go to a bookmark, touch Menu >
Bookmarks
, then touch
the bookmark.
Downloads
Warning: Apps downloaded from the web can be from
unknown sources. To protect your phone and personal
data, only download apps from sources you trust, like
“Google Play™”.
To download a file, picture, or webpage, touch
Chrome
and
go to the website, and then:
•Files: Touch the download link. To show the file or app,
touch Apps >
Downloads
.
• Pictures: Touch and hold it to choose
Save image
. To show
the picture, touch Apps >
Gallery
>
Download
.
To download apps or phone updates, see “Download apps” or
“Update your phone”.
Browser options
To change your browser security settings, text size, and other
options, touch Menu >
Settings
.
Safe surfing & searching
Keep track of what your browser and searches show:
• Browse incognito: To open a tab that won’t appear in your
browser or search history, touch
Chrome
>
>Menu >
New incognito tab
.
• Browser history, cache, and passwords: To clear your
browser history and other saved information,
touch
Chrome
>Menu >
Settings
>
Privacy
.
• Automatic form completion: When you enter your name
in an online form, your browser can automatically enter your
address information. If you don’t want that,
touch
Chrome
>Menu >
Settings
>
Auto-fill forms
.
• Browser pop-ups: To stop pop-up windows from opening,
touch
Chrome
>Menu >
Settings
>
Advanced
>
Block pop-ups
.
•Voice search: Touch , then touch to open options.
Browse
Quick start: Chrome™
Web connection
Bookmarks
Downloads
Browser options
Safe surfing & searching
16 APR 2013
FCC
BackNext
Menu More
Photos & videos
see it, capture it, share it!
Quick start: Photos & Videos
Capture super clear photos and HD videos to savor that
“Wow!” moment. Send them to friends or save them for later.
Find it: Apps >
Camera
Tip : When the phone is locked, drag to
Camera
.
Touch anywhere to
take the photo.
See more options.
Change eects &
settings.
Who’s a good boy?
Max is. Yes, he is.
Tips & tricks
• Take a photo: Open the camera, then touch .
• Record a video: Touch in the camera, then touch to
start or stop recording.
• View, share, or delete: Touch your last photo/video in the
corner of your viewfinder, or touch Apps >
Gallery
and touch a photo or video. You can choose share,
delete, Menu , and more.
•Zoom: Press the volume keys.
• Multi-shot: Set the mode to
Multi-shot
to take a burst of
photos with one press of the camera key.
• Focus and flash: To choose an off-center focus point and
test the automatic flash, touch a spot in the viewfinder
before you take the picture. A green square marks the focus
point—touch to take the picture.
• Take photos while shooting video: While recording a
video, touch to take a high-res still picture.
•Memory card: Photos and videos are stored in your phone
memory unless you use an optional memory card. Then
open the viewfinder and touch >
Storage Location
>
SD
card
.
• Clarify: For the clearest photos and videos, clean the lens
with a soft, dry cloth.
Photos & videos
Quick start: Photos & Videos
Take photos
Record videos
The perfect shot
Edit, share, or delete photos & videos
Capture your screen
Movies & TV on Google Play™
YouTube™
16 APR 2013
FCC
BackNext
Menu More
Photos & videos
Take photos
Find it:
Camera
Touch anywhere on the screen to take the photo.
Record videos
Find it:
Camera
, then touch .
Touch to start or stop recording.
Tip : To send a video in a text message, set the video quality
first: Touch to switch to the camcorder. After you record
the video, touch its thumbnail, then touch it for sharing options.
The perfect shot
Point and click—done. But when you want the perfect shot or
something a little different, play with these camera options:
Options
Settings
•
Widescreen
(6MP or 8MP photo
resolution)
•
Volume Key Function
(use volume
keys to zoom)
•
Geo-tag
(auto location information)
•
Storage Location
(phone or
optional microSD memory card)
•
Shutter Tone
Or these video options:
Effects
Set a photo effect:
Normal
,
Black &
White
,
Negative
, and more.
Scenes
Set the type of photo you want to take:
Auto
,
Portrait
,
Landscape
, and more.
Modes
Set to
Single shot
,
Panorama
,
Multi-shot
, or
Timer
.
Exposure
Select an exposure setting.
Flash
Set
Flash On
,
Flash Off
, or
Auto Flash
.
Options
Settings
•
Video Resolution
(1080p, 720p,
DVD, VGA, or QVGA)
•
Volume Key Function
(use volume
keys to zoom)
•
Geo-tag
(auto location information)
•
Storage Location
(phone or
optional microSD memory card)
•
Shutter Tone
Effects
Set a video effect:
Normal
,
Black &
White
,
Negative
, and more.
Audio Scenes
Set sound recording options:
Stereo
,
Wind Reduction
, or
Concert
.
Options
Photos & videos
Quick start: Photos & Videos
Take photos
Record videos
The perfect shot
Edit, share, or delete photos & videos
Capture your screen
Movies & TV on Google Play™
YouTube™
16 APR 2013
FCC
BackNext
Menu More
Photos & videos
Edit, share, or delete photos & videos
Find it: Apps >
Gallery
• View, share, or delete: Touch a thumbnail to open it, then
choose share, delete, Menu , and more.
Tip : To select multiple files, open a folder, touch and hold a
photo, then touch others.
• Zoom: Open a photo,
then drag two fingers
apart or together on the
screen.
Tip : Turn the phone
sideways for a widescreen
view.
• Wallpaper or contact
photo: Open a picture, then touch Menu >
Set picture
as
.
•Edit: Open a picture, then touch Menu >
Edit
.
•Slideshow: Open a folder, then touch at the top. To stop
the slideshow, touch the display or Back .
Modes
Set to
Normal Video
,
Slow Motion
, or
Time Lapse
.
Exposure
Select an exposure setting.
Light
Set
Light On
or
Light Off
.
Options Ti p: To show the slideshow on a television or other device,
see “Connect & transfer”.
To copy photos to/from a computer, go to “Memory card &
file management”.
Capture your screen
Sometimes a picture speaks louder than words. Share a screen
capture of your favorite playlist, your new high score, or a
friend’s contact information. If you can show it on your phone,
you can share it with your friends.
To capture your phone’s screen, press and hold the Power and
Volume Down keys at the same time.
To see the screen capture, touch Apps >
Gallery
>
Screenshots
.
Movies & TV on Google Play™
Find and rent movies to watch on your tablet or computer:
Find it: Apps >
Play Movies & TV
To shop, rent, or watch on a computer, go to
www.google.com/play and choose “Movies & TV.”
Yo uTu b e ™
Watch videos from YouTube users everywhere—or log into
your account to share your own.
Find it: Apps >
YouTube
Photos & videos
Quick start: Photos & Videos
Take photos
Record videos
The perfect shot
Edit, share, or delete photos & videos
Capture your screen
Movies & TV on Google Play™
YouTube™
16 APR 2013
FCC
BackNext
Menu More
Music on Google Play™
when life needs a soundtrack
Quick start: Music
Music everywhere—stream it, buy it, save it, play it. Listen and
create playlists anytime.
Find it: Apps >
Play Music
To access your Google Play Music with a computer, visit
www.google.com/music.
SONGS GENRESPLAYLISTS
Last added
Allie live shows
Portland
road trip
summer songs
workout 1
Allie’s mix
Google Play
Song Title
Artist
Flick left or right for songs,
playlists & more.
Touch for options.
Search
Shop
Settings
Play your music & more.
Tips & tricks
•Go back: When you open a song or artist list, touch in
the top left to go back.
• Shuffle or repeat: During a song, touch to show
shuffle and repeat at the bottom. Touch once to
repeat the current song list, or twice to repeat only the
current song.
•Volume: Press the volume keys.
• Hide the music player: To use a n ot h e r ap p wh i l e your
music plays, touch Home . To return to the music
player, flick down the status bar and touch the song title.
•Home screen: Control music playback from the home
screen by adding the
Google Play Music
widget.
•Shop: Touch to shop for more music.
• Playlists: Touch and hold a song in your library to add it to a
playlist or show other options. To edit, delete and rename a
playlist, touch and hold its name in the music library.
• During a flight: Press and hold the Power key >
Airplane
mode
to turn off all your network and wireless connections
and listen to music during a flight.
• File types: Your phone can play MP3, M4A, AAC, AAC+,
MIDI, and WAV files.
Note: Copyright—do you have the right? Always follow the
rules. See “Content Copyright” in your legal and safety
information.
Music on Google Play™
Quick start: Music
16 APR 2013
FCC
BackNext
Menu More
Books on Google Play™
even thick books fit
Quick start: Books
Read your favorite books, magazines, and newspapers when
and where you want.
Find it: Apps >
Play Books
•Open: Flick left and right to see more books in your library.
To o p e n a b o ok , to u c h i t .
• Read offline: To store books for reading when you’re not
connected, touch Menu >
Make available offline
,
choose the books, then touch .
Google Play
Jane Austen
Pride &
Prejudice
Lewis Carroll
Alice’s Adventures in
Wonderland
Download books.
Touch a book to open & read it.
Drag or flick to show all your
books.
Tips & tricks
•Turn pages: While reading the book, turn the pages by
flicking them.
• Recent page: When you open book, it shows the last page
you were reading.
• Table of contents: Touch a book page, then
touch Menu to open its table of contents or your book
display options.
•Close: To return to your book list, touch in the top left.
•Shop: To shop for books, touch Apps >
Play Books
,
then in the top right.
Browse by category, or touch and search for a title
or author. Touch a book to show details. Then, touch
the book’s price to buy it (or touch
OPEN
to open a free
book). After you confirm a purchase, the book is added
to your library.
• Magazines: To u c h Ap p s >
Play Magazines
.
Books on Google Play™
Quick start: Books
16 APR 2013
FCC
BackNext
Menu More
Locate & navigate
where you are, where you’re going
Quick start: Locate & navigate
Find an address, find a place, see what’s close by, get
directions or full navigation, and so much more—all with the
Google Maps™ you know and love.
Find it: Apps >
Maps
Chicago
Clear Map
Make available offline
Layers
Settings
Help
GET DIRECTIONS
Chicago, IL
See options,
settings, & more.
Go back a
screen or search
for someplace
else.
Tips & tricks
• Find an address: Enter the address in the search box at the
top. The map moves to show the address.
•Get directions: Find an address on the map, touch it, then
touch .
• Save an address: Touch the address, then touch the star by
its name. To show your starred places, touch
Maps
and
choose
My Places
. Touch a star to remove it.
•Zoom: To zoom in or out, drag two fingers together or apart
on the screen.
• Turn and tilt: Rotate two fingers on map to turn it or drag
down/up to tilt.
• Send your location: To tell others where you are, touch your
location on the map, touch the
My Location
bubble, then
choose
Send location to others
.
• Find nearby businesses or attractions: Touch at the
bottom.
• Identify address: Touch and hold a spot on the map to
show the nearest address.
• Get map help: To uch Me nu >
Help
.
Locate & navigate
Quick start: Locate & navigate
Google+ Local™
Google Maps™ with Navigation beta
Google Latitude™
16 APR 2013
FCC
BackNext
Menu More
Locate & navigate
Google+ Local™
Google+ Local lets you find the restaurants, cafes, bars, and
attractions that are close to you:
Find it: Apps >
Local
Tip : In
Maps
, just touch at the bottom.
Google Maps™ with Navigation beta
Get spoken turn-by-turn directions to the destination you
specify.
Find it: Apps >
Navigation
Speak, type, or select your destination.
Navigation
shows a
map and starts telling you directions.
Tip : To add to your
STARRED
places, open Google Maps™,
find an address, then touch the next to it.
To exit navigation or see other options, touch at the bottom.
Touch to show gas stations and other points along the way.
Note: Using a mobile device or accessory while driving may
cause distraction and may be illegal. Always obey the laws and
drive safely.
For more, go to www.google.com/mobile/navigation.
Google Latitude™
Google Latitude lets you see where your friends and family are
on Google Maps™. Plan to meet up, check that they got home
safely, or just stay in touch. Don’t worry, your location is not
shared unless you agree to it. After you join Google Latitude,
you can invite your friends to view your location, or accept their
invitations.
To join Google Latitude, touch Apps >
Maps
, touch
Maps
at the top, then choose
Join Latitude
.
To use Google Latitude after you join, touch Apps >
Latitude
:
•To add friends, touch .
To uch
Select from Contacts
or
Add via email address
. Your
friend will receive an email notice.
•To remove friends, touch next to their name.
•To share your location when you receive a request, you can
choose
Accept and share back
(show your location and see
theirs),
Accept, but hide my location
(hide your location, but
see theirs), or
Don’t accept
(hide both locations).
•To hide your location, touch Menu >
Location Settings
>
Location reporting
>
Do not update your location
.
•To sign out, touch Menu >
Location Settings
>
Sign out
of Latitude
.
Locate & navigate
Quick start: Locate & navigate
Google+ Local™
Google Maps™ with Navigation beta
Google Latitude™
16 APR 2013
FCC
BackNext
Menu More
Work
get it done anytime
Corporate sync
If you use Microsoft™ Office Outlook on your work computer,
your phone can synchronize emails, events, and contacts with
your Microsoft Exchange server.
•To a dd y o u r
Corporate
account, see “Email”.
•To choose what to sync from your
Corporate
account, touch
Apps >
Settings
>
Accounts & sync
, touch your
account, then choose options like
Calendar
,
Contacts
, or
Email
.
Quickoffice
Use
Quickoffice
to view and edit files on your memory card
(optional).
Find it: Apps >
Quickoffice
Touch a file or folder to open, or touch and hold a file for
options. You can edit most text or spreadsheet files:
•Place your cursor by touching the text.
•Select text by double-tapping it.
•Open a keyboard, choose formatting, save the file, or
choose other options by touching Menu .
Office network
To connect your office network with a Virtual Private Network
connection, see “Virtual Private Networks (VPN)”.
Clock
Find it: Apps >
Clock
>
Set alarm
•Alarm: Touch an alarm to edit it, or touch to add a new
alarm.
When an alarm sounds, touch
Dismiss
to turn it off or
Snooze
to delay for ten minutes.
• Settings: To change your alarm sound, snooze delay, or
other settings, touch Menu >
Settings
.
Tip : To set your date, time, time zone, and formats, touch
Apps >
Settings
>
Date & time
.
Work
Corporate sync
Quickoffice
Office network
Clock
Calendar
16 APR 2013
FCC
BackNext
Menu More
Work
Calendar
Show events stored on your phone and in your online
calendars, all together in one place.
Find it: Apps >
Calendar
• Change the view: Touch the date at the top left to choose
Day
,
Week
,
Month
, or
Agenda
.
• Add events: From any view, touch Menu >
New event
,
enter event details, then touch
DONE
.
• Show, edit, or delete events: Touch an event to open it,
then touch edit or delete .
25 126 27 28 29 30
16 2217 18 19 20 21
23 2924 25 26 27 28
30 531 1234
91510 11 12 13 14
2834567
SUN FRITHUWEDTUEMON SAT
December 2012 21
1
1
1
1
7
28
29
30
15
5
5
5
5
5
12
13
14
8
8
8
8
8
8
4
5
6
7
FR
FR
FR
I
I
I
TH
TH
TH
U
U
U
WE
WE
WE
D
D
D
E
SA
SA
SA
T
T
T
T
T
T
T
New event
Settings
Calendars to display
Search
Refresh Calendar Menu
Change calendar view.
Event colors indicate
different calendars.
Scroll
• Show, hide, or add calendars: Touc h
Menu >
Calendars to display
to show or hide calendars
from your Google account. You can use a computer to add
or remove calendars on your Google account at
www.google.com/calendar.
Tip : Add a
Calendar
widget to your home screen. Touch
Apps >
WIDGETS
, then touch and hold the
Calendar
widget to add it to you home screen.
Work
Corporate sync
Quickoffice
Office network
Clock
Calendar
16 APR 2013
FCC
BackNext
Menu More
Connect & transfer
wired up or wireless
Quick start: Connect & transfer
Connect accessories, computers, networks, and more.
Find it: Apps >
Settings
Wi-Fi
WIRELESS & NETWORKS
DEVICE
Bluetooth
Tethering & Mobile Hotspot
Data usage
More...
Sound
Display
Storage
OFF
Settings
Airplane mode
ON
ON
Change Wi-Fi settings.
disables all wireless
connections.
ON
Turn Wi-Fi or Bluetooth
power ONON or .
Change Bluetooth settings.
Change connection & sharing
settings.
Move pictures, music, & other
media to an optional microSD
memory card.
OFF
ON
Tips & tricks
•Bluetooth™ devices: To connect a Bluetooth headset,
keypad, or other device, touch
Bluetooth
.
•Wi-Fi networks: To connect, touch
Wi-Fi
.
•Wi-Fi hotspot: To make your phone a hotspot, touch
Tethering & Mobile Hotspot
, then check
Mobile Hotspot
.
You can change hotspot security.
•USB cable: Your phone’s micro USB port lets you exchange
media and other files with a connected computer. To
change the type of USB connection, touch Apps >
Settings
>
Storage
>Menu >
USB computer
connection
.
• Automatic connections: When Bluetooth® or Wi-Fi power
is , your phone automatically reconnects to available
devices or networks it has used before.
ON
Connect & transfer
Quick start: Connect & transfer
Bluetooth® wireless
Wi-Fi Networks
USB cables
Memory card & file management
Share your data connection
Data use
NFC
Your cloud
Phone & tablet
DLNA™ media devices
Virtual Private Networks (VPN)
Mobile network
Airplane mode
16 APR 2013
FCC
BackNext
Menu More
Connect & transfer
Bluetooth® wireless
Turn Bluetooth power on/off
Find it: Apps >
Settings
, then touch the
Bluetooth
switch to turn it
Tip : To extend battery life or stop connections, turn the
Bluetooth them when you’re not using it.
Connect devices
The first time you connect a device, follow these steps:
1Make sure the device you are pairing with is in
discoverable mode (for details, refer to the guide that
came with the device).
2Touch Apps >
Settings
>
Bluetooth
.
3Make sure the switch at the top is , then touch
SEARCH FOR DEVICES
.
4Touch a found device to connect it (if necessary, touch
Pair
or enter a passkey like
0000
).
Tip : Touch next to a device to rename it.
When the device connects, the Bluetooth status
indicator turns blue .
To automatically disconnect or reconnect a device anytime,
just turn it off or on.
Note: Using a mobile device or accessory while driving may
cause distraction and may be illegal. Always obey the laws and
drive safely.
ON
OFF
ON
Manage devices
To manually reconnect your phone with a paired device, touch
the device name in the
AVAILABLE DEVICES
list.
To manually disconnect your phone from a paired device,
touch the device name in the devices list, then touch
OK
.
To remove a paired device, touch the next to the device
name in the
PAIRED DEVICES
list, then touch
Unpair
.
To u c h A p p s >
Settings
>
Bluetooth
, turn Bluetooth
power on, then touch Menu >
Rename phone
. Enter a name
and touch
OK
.
Let devices find your phone
To let a Bluetooth device discover your phone:
1Touch Apps >
Settings
>
Bluetooth
.
2To uch
Only visible to paired devices
to make your phone
visible to all devices for two minutes.
Transfer fi l e s
•Photos or videos: Open the photo or video, then
touch >
Bluetooth
.
•People: To u c h
People
>Menu >
Share contacts
,
check what you want to share (you can choose
Unselect all
),
then touch
OK
>
Bluetooth
.
Connect & transfer
Quick start: Connect & transfer
Bluetooth® wireless
Wi-Fi Networks
USB cables
Memory card & file management
Share your data connection
Data use
NFC
Your cloud
Phone & tablet
DLNA™ media devices
Virtual Private Networks (VPN)
Mobile network
Airplane mode
16 APR 2013
FCC
BackNext
Menu More
Connect & transfer
Wi-Fi Networks
Turn Wi-Fi power on/off
Find it: Apps >
Settings
, then touch the
Wi-Fi
switch to turn it .
Note: To extend battery life, turn Wi-Fi when you’re not
using it.
Connect to networks
To find networks in your range:
1Touch Apps >
Settings
>
Wi-Fi
.
Tip : To see your phone’s MAC address and Wi-Fi
settings, touch Menu >
Advanced
.
2Make sure the switch at the top is , then touch
SCAN
.
3Touch a found network to connect it (if necessary,
enter
Network SSID
,
Security
, and
Wireless password
, and
touch
Connect
).
When your phone connects, the Wi-Fi status
indicator appears in the status bar.
Note: If you see a question mark in the Wi-Fi status
indicator , pull down the status bar, touch the
network, and enter the network’s password.
Tip : When Wi-Fi power is on, your phone automatically
reconnects to available networks it has used before
ON
OFF
ON
Manage networks
To remove a network, touch it in the list, then touch
Forget
.
To manage your networks, touch Apps >
Settings
>
Wi-Fi
, turn Wi-Fi power on, then touch Menu >
Manage
Networks
.
Wi-Fi hotspot
Your can make your phone a Wi-Fi hotspot to provide portable,
convenient internet access to other Wi-Fi enabled devices.
Note: Keep it secure. To protect your phone and hotspot from
unauthorized access, it is strongly recommended that you set
up hotspot security (WPA2 is the most secure), including
password.
Find it: Apps >
Settings
>
Tethering & Mobile Hotspot
and check
Mobile Hotspot
.
1Your phone turns off
Wi-Fi
power and uses the mobile
network for Internet access. Touch
Mobile Hotspot
Settings
>
Configure Mobile Hotspot
to set up security:
•SSID—Enter a unique name for your hotspot.
•Security—Select the type of security you want:
Open
or
WPA2
. For
WPA2
, enter a unique
password that others will need to access your
Wi-Fi hotspot.
Note:
WPA2
is recommended by IEEE.
• Channel—If you notice interference after your
hotspot has been active for a while, try different
channels.
Connect & transfer
Quick start: Connect & transfer
Bluetooth® wireless
Wi-Fi Networks
USB cables
Memory card & file management
Share your data connection
Data use
NFC
Your cloud
Phone & tablet
DLNA™ media devices
Virtual Private Networks (VPN)
Mobile network
Airplane mode
16 APR 2013
FCC
BackNext
Menu More
Connect & transfer
2Touch
Save
when the settings are complete.
When
Mobile Hotspot
is active, other Wi-Fi enabled devices
can connect by entering your hotspot’s
SSID
, selecting a
Security
type, and entering the correct
Wireless password
.
Wi-Fi modes
For those who like to get a bit more technical, your phone
supports the following Wi-Fi modes: 802.11a, b, g, n.
USB cables
Note: Copyright—do you have the right? Always follow the
rules. See “Content Copyright”.
To load music, pictures, videos, documents, or other files from
your computer, connect your phone to your computer with a
USB cable. To change the type of USB connection, touch
Apps >
Settings
>
Storage
>Menu >
USB computer
connection
.
•For Microsoft™ Windows™ XP, Windows Vista, and
Windows 7: On your computer, choose Start, then select
Windows Explorer from your list of programs. In Windows
Explorer, your phone will appear as a connected drive (mass
storage device) where you can drag and drop files, or it will
appear as an MTP or PTP device that lets you use Windows
Media Player to transfer files. For more instructions or driver
files, visit www.motorola.com/myxfon.
•For Apple™ Macintosh™: Use Android File Transfer,
available at www.android.com/filetransfer.
Memory card & file management
Your photos, videos, and other files are automatically stored in
your phone’s internal memory.
Optional microSD memory cards can
help store more files.
Tip : To move media from int ernal
memory to a microSD card, touch
Apps >
Settings
>
Storage
>
Manage internal storage
.
Manage files on your phone
Find it: >
Files
>
Device storage
or
SD card
Touch a file or folder to open, then touch and hold a file to
Delete
or
Share
.
Remove or erase a memory card
Note: Do not remove a microSD memory card while your
phone is using it or writing files on it.
Before you remove a microSD card you need to unmount it.
Tou c h Ap p s >
Settings
>
Storage
>
Unmount SD card
.
To erase a microSD card, touch Apps >
Settings
>
Storage
>
Erase SD card
.
Warning: All data on the microSD card will be deleted.
USB connection
You can connect your phone to a computer with a USB cable.
microSD
micro SIM
Connect & transfer
Quick start: Connect & transfer
Bluetooth® wireless
Wi-Fi Networks
USB cables
Memory card & file management
Share your data connection
Data use
NFC
Your cloud
Phone & tablet
DLNA™ media devices
Virtual Private Networks (VPN)
Mobile network
Airplane mode
16 APR 2013
FCC
BackNext
Menu More
Connect & transfer
Note: The first time you use a USB connection, your computer
may indicate that drivers are being installed. Follow any
prompts you see to complete the installation. This may take a
few minutes.
1With the home screen showing, connect a Motorola
micro USB data cable from your phone’s micro USB
port to a USB port on your computer. Your phone
should show in the status bar.
Note: Make sure to connect the phone to a high power
USB port. Typically, these are located directly on your
computer. To change the type of USB connection if
necessary, touch Apps >
Settings
>
Storage
>Menu >
USB computer connection
>
Mass Storage
.
2Your phone and optional microSD memory card appear
as two separate removable disks on your computer.
Drag and drop files between your computer and the
phone or microSD card folders. When you’re done,
use “Safely Remove Hardware” before disconnecting
the USB cable.
Note: You can’t use files on the microSD card while your phone
is connected to the computer.
Share your data connection
Your computer can access the internet through your phone's
mobile network—you just need a USB cable.
Tip : To share a Wi-Fi connection, see “Wi-Fi hotspot”.
1Connect your phone to your computer using a USB
cable.
Note: If your computer is running something older than
Microsoft™ Windows™ 7 or Apple™ Macintosh™
OSX, it might require special configuration.
2On your phone, touch Apps >
Settings
, then
make sure the
Wi-Fi
switch is set to .
3In
Settings
, touch
Tethering & Mobile Hotspot
, then check
USB tethering
to start the connection.
To stop the connection, uncheck
USB tethering
, then
disconnect your phone from your computer.
Data use
You can track the amount of data uploaded and downloaded
by your phone.
Note: Usage information is provided to help you manage your
phone. This may not match the amounts charged by your
service provider, as they’re not measured in the same way.
Find it: Apps >
Settings
>
Data usage
Your phone shows a data usage graph, followed by a list of the
apps that are running, from highest data usage down to least.
OFF
Connect & transfer
Quick start: Connect & transfer
Bluetooth® wireless
Wi-Fi Networks
USB cables
Memory card & file management
Share your data connection
Data use
NFC
Your cloud
Phone & tablet
DLNA™ media devices
Virtual Private Networks (VPN)
Mobile network
Airplane mode
16 APR 2013
FCC
BackNext
Menu More
Connect & transfer
Touch an app to open its details. Apps that use a lot of data
might also use a lot of battery power.
The data usage screen shows information and settings for data
transferred over your service provider's mobile network.
NFC
Near Field Communication technology lets you instantly share
content (like web links, contacts, and photos), information, and
more, by touching the back of your phone to another
NFC-enabled device.
Data usage
Apr 26
-
May 26
Data usage cycle
May 19
-
26: about 16.67MB used
Apr 26 May 26
Google Play Store
14.46MB
Google+
2.21MB
Drag white bars to
change date ranges.
View hotspots or turn off
auto-sync for data.
Share with Android Beam™
Use Android Beam to share content on your phone with
another NFC-enabled phone or tablet.
Note: The other device must support NFC too.
1Open the screen that contains the map page or
browser page you want to share.
2Touch the back of your phone to the back of the other
device.
When the devices connect, you’ll see
Touch to Beam
on
your phone.
3Touch your screen to share your content.
Receive with NFC
Receive web links, e-coupons, brochures, maps and more from
an NFC tag. Look for the NFC logo on posters, signs, store
displays and other areas. Just touch the back of your phone to
the logo to receive its tag information.
Bluetooth & Wi-Fi one-touch setup
Just touch your phone to an NFC-enabled Bluetooth device or
Wi-Fi access point to automatically pair or connect with the
device.
Connect & transfer
Quick start: Connect & transfer
Bluetooth® wireless
Wi-Fi Networks
USB cables
Memory card & file management
Share your data connection
Data use
NFC
Your cloud
Phone & tablet
DLNA™ media devices
Virtual Private Networks (VPN)
Mobile network
Airplane mode
16 APR 2013
FCC
BackNext
Menu More
Connect & transfer
Mobile payment
You can use any secure payment
app to pay for your purchase
(where available).
Look for the NFC logo to confirm
that you can make a mobile
payment. Touch the back your
phone to the payment device to
pay for your purchase.
Security
Mobile payments, wireless connections, and content sharing
all demand security:
•Range: NFC only works over a short range (about
4 cm/1.5 inches), so it's unlikely you’ll connect by
mistake—if you did, you would still have to accept the
connection to send or receive information.
•Encryption: Your phone uses the latest security, encryption,
and authentication features to protect your personal
information for mobile payments and content sharing.
Yo u r c l o u d
One account with access to everything, everywhere—phone,
tablet, computer.
Sync your Google account
When you log in to the same Google account, all devices can
get to all the same apps, movies, books, and music from
“Google Play™”—plus you share the same Gmail™, Google
Calendar™, and other Google services. To add accounts to
your phone, touch Apps >
Settings
>
Accounts & sync
.
Phone & tablet
Your Android phone and tablet can work together to help you
get the most out of both:
• Transfer media and files: Copy files to your phone’s
memory card (optional) and transfer it to other devices with
“Memory card & file management”.
• Phone hotspot: If you have a Wi-Fi tablet, turn your phone
into a Wi-Fi hotspot to let your tablet access the Internet
anywhere—see “Wi-Fi hotspot”,
• Bluetooth accessories: If you have a Bluetooth keyboard or
other accessories to use with your tablet, remember you can
use them with your phone too. To connect them, see
“Bluetooth® wireless”,
DLNA™ media devices
Use DLNA Certified computers, TVs,
and other devices to show the videos
and pictures stored on your phone.
1Make sure your phone is
connected to a Wi-Fi network that has another DLNA
Certified device.
2To u ch A p p s >
Gallery
, then open the picture or
video you want to show.
Connect & transfer
Quick start: Connect & transfer
Bluetooth® wireless
Wi-Fi Networks
USB cables
Memory card & file management
Share your data connection
Data use
NFC
Your cloud
Phone & tablet
DLNA™ media devices
Virtual Private Networks (VPN)
Mobile network
Airplane mode
16 APR 2013
FCC
BackNext
Menu More
Connect & transfer
3Touch at the top of the screen.
Your phone searches for DLNA devices on your
network.
4Choose a device to connect.
For more about DLNA devices, visit www.dlna.org.
Virtual Private Networks (VPN)
A VPN lets you access files on a secured network (like an office
network with a firewall). Contact the network administrator to
ask for VPN settings, and any additional apps or other
requirements.
To enter VPN settings, touch Apps >
Settings
>
More...
>
VPN
. Choose the type of VPN and enter settings from the
network administrator. The network is stored in the
VPN
list so
that you can select it whenever you need to connect.
Mobile network
You should not need to change any network settings. Contact
your service provider for help.
Touch A pps >
Settings
>
More...
>
Mobile networks
to
see network settings options.
Airplane mode
Use airplane mode to turn all your wireless connections
off—useful when flying. Press and hold the Power key
>
Airplane mode
.
Note: When you select airplane mode, all wireless services are
disabled. You can then turn Wi-Fi and/or Bluetooth power back
on, if permitted by your airline. Other wireless voice and data
services (such as calls and text messages) remain off in airplane
mode. Emergency calls to your region's emergency number
can still be made.
Connect & transfer
Quick start: Connect & transfer
Bluetooth® wireless
Wi-Fi Networks
USB cables
Memory card & file management
Share your data connection
Data use
NFC
Your cloud
Phone & tablet
DLNA™ media devices
Virtual Private Networks (VPN)
Mobile network
Airplane mode
16 APR 2013
FCC
BackNext
Menu More
Protect
help keep it safe
Quick start: Protect
Make sure your information is protected, in case your phone is
lost or stolen.
Find it: Apps >
Settings
>
Security & Screen Lock
The easiest way to protect your phone is to use
Screen lock
.
You can choose facial recognition, a pattern, or a PIN to unlock
your phone.
Security & Screen Lock
SCREEN SECURITY
ENCRYPTION
Screen lock
Owner info
Slide
Encrypt phone
Require a numeric PIN or password to decrypt
your phone each time you power it on
Encrypt SD card
Protect the data on your memory card
Allow Bluetooth bypass
Allow Voice Commands to be launched
via Bluetooth Multi-function button
while device is locked
SIM CARD LOCK
Set up SIM card lock
Change your screen lock to use a
slide, facial recognition, a pattern,
PIN, password, or no lock.
Your info can show on the lock
screen.
Encrypt the data stored on your
phone or memory card.
Tips & tricks
•Face unlock: Unlock your phone by looking at it!
To u c h A p p s >
Settings
>
Security & Screen Lock
>
Screen lock
>
Face Unlock
and follow the prompts.
• Forgotten pattern: If you enter the wrong unlock
Pattern
five times, your device shows a
Forgot pattern?
option that
lets you enter your Google™ account email and password
to unlock your device.
• Forgotten password: You will need to reset your phone
(see “Reset”).
Protect
Quick start: Protect
Screen lock
SIM lock
Encrypt your phone
Backup & restore
Reset
16 APR 2013
FCC
BackNext
Menu More
Protect
Screen lock
To keep your phone secure, you can make the touchscreen
lock when it goes to sleep.
Find it: Apps >
Settings
>
Security & Screen Lock
>
Screen lock
, then select the lock type:
•
None
: turn off the screen lock.
•
Slide
: flick to the right to unlock.
•
Face Unlock
: look at your phone to unlock it.
Follow the prompts to capture your face and enter a
PIN or password (for backup or to change the lock
setting). When the screen is dark, press the
Power key, then frame your face in the square at the
bottom to unlock.
Note: This feature is less secure than a pattern, PIN, or
password.
•
Pattern
: draw a pattern to unlock.
•
PIN
: enter four to sixteen digits to unlock.
•
Password
: enter four to sixteen letters, digits, or symbols to
unlock.
To change when your touchscreen goes to sleep, see “Power
key”.
Note: You can make emergency calls on a locked phone (see
“Emergency calls”). A locked phone still rings, but you need
to unlock it to answer.
Can’t unlock?
Face unlock: If your phone doesn’t recognize your face, you’ll
be prompted to enter your backup pattern or PIN code to
unlock it.
Pattern, PIN, or password: If you forget your pattern, PIN, or
password, contact your service provider.
SIM lock
Caution: If you enter an incorrect PIN code three times,
your phone locks your SIM card and asks for your PIN
unlock code. Contact your service provider for your PIN
unlock code.
To set a SIM card PIN that you must enter when you turn on
your phone:
Find it: Apps >
Settings
>
Security & Screen Lock
>
Set up SIM card lock
>
Lock SIM card
To set your SIM PIN, enter a 4-digit code. To change your code,
choose
Change SIM PIN
.
Encrypt your phone
Caution: If you forget your encryption code, you cannot
recover the data stored on your phone or optional
memory card. Encrypting your files can take an hour or
more. Leave your phone plugged in, and be careful not to
interrupt the process.
Protect
Quick start: Protect
Screen lock
SIM lock
Encrypt your phone
Backup & restore
Reset
16 APR 2013
FCC
BackNext
Menu More
Protect
Encryption protects the accounts, settings, apps, and files on
your phone, so that people cannot access them if your phone is
stolen.
To encrypt your phone and require a PIN or password
whenever you turn on your phone:
Find it: Apps >
Settings
>
Security & Screen Lock
>
Encrypt phone
Backup & restore
Your Google account data is backed up online. So, if you reset
or replace your phone, just log into your Google account to
restore the contacts, events, and other details you synced with
the account. To choose what syncs with the account, touch
Apps >
Settings
>
Accounts & sync
, touch your
Google™ account, and check things to sync. Please note that
text messages, call logs, and items stored on your phone will
not be restored. To restore your Google Play Store apps, see
“Take Care of your apps”.
Reset
To reset your phone to factory settings and erase all the data on
your phone, touch Apps >
Settings
>
Privacy
>
Factory
data reset
>
Reset Phone
.
Warning: All downloaded apps and user data on your
phone will be deleted. Data on your memory card will not
be deleted.
Protect
Quick start: Protect
Screen lock
SIM lock
Encrypt your phone
Backup & restore
Reset
16 APR 2013
FCC
BackNext
Menu More
Want more?
there’s always more
Get more
There’s more help, updates, and information right here:
• Tutorials & answers: Touch Apps >
Moto Care
to get
walk-through tutorials. For
HELP TOPICS
, touch the tab.
• Updates: Get phone updates, PC software, online help,
guides, and more at www.motorola.com/myxfon
• Accessories: Find accessories for your phone at
www.motorola.com/mobility.
• Apps: To u c h
Play Store
.
•News: Get the latest news, apps, tips & tricks, videos and so
much more—join us on:
YouTube™ www.youtube.com/motorola
Facebook™ www.facebook.com/motorola
Twi tte r www.twitter.com/motomobile
Google+™ https://plus.google.com/#s/Motorola
Grab a barcode scanner on
Google Play™ and scan this
code. Enjoy :-)
Tips & tricks
• Google help: In Google apps, touch Menu >
Help
. You
can also view the Google Help Centers online at
www.google.com/support.
Want more?
Get more
16 APR 2013
FCC
BackNext
Menu More
Troubleshooting
we can help
Crash recovery
In the unlikely event that your phone stops responding to
touches and key presses, try a forced reboot—press and hold
both the Power and Volume Down keys for about 15 seconds. If
necessary, hold the Power key to turn your phone back on.
Service & repairs
If you have questions or need assistance, we’re here to help.
Go to www.motorola.com/repair (United States) or
www.motorola.com/support (Canada), where you can select
from a number of customer care options. You can also contact
the Motorola Customer Support Center at: 1-800-734-5870
(United States), 1-888-390-6456 (TTY/TDD United States for
hearing impaired), or 1-800-461-4575 (Canada).
Troubleshooting
Crash recovery
Service & repairs
16 APR 2013
FCC
BackNext
Menu More
Product Safety & Legal
safe, smart, protected
Battery Use & Safety
Battery Use & Safet y
The following battery use and safety information applies to all Motorola mobile devices. If your
mobile device uses a non-removable main battery (as stated in your product information), details
related to handling and replacing your battery should be disregarded—the battery should only be
replaced by a Motorola-approved service facility, and any attempt to remove or replace your
battery, unless performed by a service representative, may damage the product and void your
warranty.
Important: Handle and store batteries properly to avoid injury or damage. Most battery safety
issues arise from improper handling of batteries, and particularly from the continued use of
damaged batteries.
DON’Ts
•
Don’t disassemble, crush, puncture, shred, or otherwise attempt to change the form of your
battery.
•
Don’t use tools, sharp objects, or excessive force to insert or remove the battery as this can
damage the battery.
•
Don’t let the mobile device or battery come in contact with liquids.* Liquids can get into the
mobile device’s circuits, leading to corrosion.
•
Don’t allow the battery to touch metal objects. If metal objects, such as jewelry, stay in
prolonged contact with the battery contact points, the battery could become very hot.
•
Don’t place your mobile device or battery near a heat source.* High temperatures can cause
the battery to swell, leak, or malfunction.
•
Don’t dry a wet or damp battery with an appliance or heat source, such as a hair dryer or
microwave oven.
DOs
•
Do avoid leaving your mobile device in your car in high temperatures.*
•
Do avoid dropping the mobile device or battery.* Dropping these items, especially on a hard
surface, can potentially cause damage.*
•
Do contact your service provider or Motorola if your mobile device or battery has been
damaged in any of the ways listed here.
* Note: Always make sure that any battery, connector and compartment covers are closed and
secure to avoid direct exposure of the battery to any of these conditions, even if your product
information states that your mobile device can resist damage from these conditions.
Important: Motorola recommends you always use Motorola-branded batteries and chargers for
quality assurance and safeguards. Motorola’s warranty does not cover damage to the mobile
device caused by non-Motorola batteries and/or chargers. To help you identify authentic Motorola
batteries from non-original or counterfeit batteries (that may not have adequate safety protection),
Motorola provides holograms on its batteries. You should confirm that any battery you purchase
has a “Motorola Original” hologram.
If you see a message on your display such as
Invalid Battery
or
Unable to Charge
,
take the following steps:
•
Remove the battery and inspect it to confirm that it has a “Motorola Original” hologram;
•
If there is no hologram, the battery is not a Motorola battery;
•
If there is a hologram, replace the battery and try charging it again;
•
If the message remains, contact a Motorola authorized service center.
Wa rn i ng :
Use of a non-Motorola battery or charger may present a risk of fire, explosion, leakage, or
other hazard.
Proper and safe battery disposal and recycling: Proper battery disposal is not only important for
safety, it benefits the environment. You can recycle your used batteries in many retail or service
provider locations. Additional information on proper disposal and recycling can be found at
www.motorola.com/recycling
Disposal: Promptly dispose of used batteries in accordance with local regulations.
Contact your local recycling center or national recycling organizations for more
information on how to dispose of batteries.
Wa rn i ng :
Never dispose of batteries in a fire because they may explode.
Battery Charging
Batter y Charging
Notes for charging your product’s battery:
•
During charging, keep your battery and charger near room temperature for efficient battery
charging.
•
New batteries are not fully charged.
•
New batteries or batteries stored for a long time may take more time to charge.
•
Motorola batteries and charging systems have circuitry that protects the battery from damage
from overcharging.
Third Party Accessories
Third Part y Accessori es
Use of third party accessories, including but not limited to batteries, chargers, headsets, covers,
cases, screen protectors and memory cards, may impact your mobile device’s performance. In
some circumstances, third party accessories can be dangerous and may void your mobile device’s
warranty. For a list of Motorola accessories, visit
www.motorola.com/products
Driving Precautions
Drivin g Precauti ons
Responsible and safe driving is your primary responsibility when behind the wheel of a vehicle.
Using a mobile device or accessory for a call or other application while driving may cause
distraction, and may be prohibited or restricted in certain areas—always obey the laws and
regulations on the use of these products.
While driving, NEVER:
•
Type, read, enter or review texts, emails, or any other written data.
•
Surf the web.
•
Input navigation information.
•
Perform any other functions that divert your attention from driving.
While driving, ALWAYS:
•
Keep your eyes on the road.
•
Use a handsfree device if available or required by law in your area.
•
Enter destination information into a navigation device before driving.
•
Use voice activated features (such as voice dial) and speaking features (such as audible
directions), if available.
•
Obey all local laws and regulations for the use of mobile devices and accessories in the vehicle.
•
End your call or other task if you cannot concentrate on driving.
032375o
Product Safety & Legal
Battery Use & Safety
Battery Charging
Third Party Accessories
Driving Precautions
Seizures, Blackouts & Eyestrain
High Volume
Repetitive Motion
Children
Glass Parts
Operational Warnings
RF Energy
Regulatory Information
Location
Navigation
Privacy & Data Security
Use & Care
Recycling
Perchlorate Label
Hearing Aid Compatibility
Software Copyright
Content Copyright
OSS Information
Export Law
Registration
Service & Repairs
Global Warranty
Copyright & Trademarks
16 APR 2013
FCC
BackNext
Menu More
Product Safety & Legal
Remember to follow the “Smart Practices While Driving” at
www.motorola.com/callsmart
(in English only).
Seizures, Blackouts & Eyestrain
Seiz ures, Blackou ts & Eyestr ain
To reduce eyestrain and avoid headaches, it is always a good idea to hold the screen a comfortable
distance from your eyes, use in a well-lit area, and take frequent breaks.
Some people may be susceptible to seizures or blackouts (even if they have never had one before)
when exposed to flashing lights or light patterns, such as when playing video games, or watching
videos with flashing-light effects.
Discontinue use and consult a physician if any of the following symptoms occur: seizures, blackout,
convulsion, eye or muscle twitching, loss of awareness, or disorientation.
If you or someone in your family has experienced seizures or blackouts, please consult with your
physician before using an application that produces flashing-light effects on your mobile device.
Caution About High Volume Usage
High Volume
Warning:
Exposure to loud noise from any source for extended periods of time may
affect your hearing. The louder the volume sound level, the less time is required
before your hearing could be affected. To protect your hearing:
•
Limit the amount of time you use headsets or headphones at high volume.
•
Avoid turning up the volume to block out noisy surroundings.
•
Turn the volume down if you can’t hear people speaking near you.
If you experience hearing discomfort, including the sensation of pressure or fullness
in your ears, ringing in your ears, or muffled speech, you should stop listening to the device
through your headset or headphones and have your hearing checked.
For more information about hearing, see our website at
http://direct.motorola.com/hellomoto/nss/AcousticSafety.asp
(in English only).
Repetitive Motion
Repetitive Motion
When you repetitively perform actions such as pressing keys or entering finger-written characters,
you may experience occasional discomfort in your hands, arms, shoulders, neck, or other parts of
your body. If you continue to have discomfort during or after such use, stop use and see a
physician.
Children
Childre n
Keep your mobile device and its accessories away from small children. These products are not toys
and may be hazardous to small children. For example:
•
A choking hazard may exist for small, detachable parts.
•
Improper use could result in loud sounds, possibly causing hearing injury.
•
Improperly handled batteries could overheat and cause a burn.
Supervise access for older children. Similar to a computer, if an older child does use your mobile
device, you may want to monitor their access to help prevent:
•
Exposure to inappropriate apps or content.
•
Improper use of apps or content.
•
Loss of data.
Glass Parts
Glass Par ts
Some parts of your mobile device may be made of glass. This glass could break if the product
receives a substantial impact. If glass breaks, do not touch or attempt to remove. Stop using your
mobile device until the glass is replaced by a qualified service center.
Operational Warnings
Operati onal Warning s
Obey all posted signs when using mobile devices in public areas.
Potentially Explosive Areas
Potentially explosive areas are often, but not always, posted and can include blasting areas, fueling
stations, fueling areas (such as below decks on boats), fuel or chemical transfer or storage facilities,
or areas where the air contains chemicals or particles, such as grain dust, or metal powders.
When you are in such an area, turn off your mobile device, and do not remove, install, or charge
batteries, unless it is a radio product type especially qualified for use in such areas and certified as
“Intrinsically Safe” (for example, Factory Mutual, CSA, or UL approved). In such areas, sparks can
occur and cause an explosion or fire.
Symbol Key
Your battery, charger, or mobile device may contain symbols, defined as follows:
Symbol Definition
Important safety information follows.
Do not dispose of your battery or mobile device in a fire.
Your battery or mobile device may require recycling in
accordance with local laws. Contact your local regulatory
authorities for more information.
Do not dispose of your battery or mobile device with your
household waste. See “Recycling” for more information.
Do not use tools.
For indoor use only.
032374o
032376o
032375o
Product Safety & Legal
Battery Use & Safety
Battery Charging
Third Party Accessories
Driving Precautions
Seizures, Blackouts & Eyestrain
High Volume
Repetitive Motion
Children
Glass Parts
Operational Warnings
RF Energy
Regulatory Information
Location
Navigation
Privacy & Data Security
Use & Care
Recycling
Perchlorate Label
Hearing Aid Compatibility
Software Copyright
Content Copyright
OSS Information
Export Law
Registration
Service & Repairs
Global Warranty
Copyright & Trademarks
16 APR 2013
FCC
BackNext
Menu More
Product Safety & Legal
Radio Frequency (RF) Energy
RF Energy
Exposure to RF Energy
Your mobile device contains a transmitter and receiver. When it is ON, it receives and transmits RF
energy. When you communicate with your mobile device, the system handling your call controls
the power level at which your mobile device transmits.
Your mobile device is designed to comply with local regulatory requirements in your country
concerning exposure of human beings to RF energy.
RF Energy Operational Precautions
For optimal mobile device performance, and to be sure that human exposure to RF energy does
not exceed the guidelines set forth in the relevant standards, always follow these instructions and
precautions:
•
When placing or receiving a phone call, hold your mobile device just like you would a landline
phone.
•
If you wear the mobile device on your body, ensure that the device is positioned at least 2.5 cm
(1 inch) away from the body, and if you use an accessory case or holder, ensure it is free of any
metal.
RF Energy Interference/Compatibility
Nearly every electronic device is subject to RF energy interference from external sources if
inadequately shielded, designed, or otherwise configured for RF energy compatibility. In some
circumstances, your mobile device may cause interference with other devices.
Follow Instructions to Avoid Interference Problems
Turn off your mobile device in any location where posted notices instruct you to do so, such as
hospitals or health care facilities.
In an aircraft, turn off your mobile device whenever instructed to do so by airline staff. If your
mobile device offers an airplane mode or similar feature, consult airline staff about using it in flight.
Medical Devices
If you have a medical device, including an implantable medical device such as a pacemaker or
defibrillator, consult your healthcare provider and the device manufacturer’s directions before
using this mobile device.
Persons with implantable medical devices should observe the following precautions:
•
ALWAYS keep the mobile device more than 20 centimeters (8 inches) from the implantable
medical device when the mobile device is turned ON.
•
DO NOT carry the mobile device in the breast pocket.
•
Use the ear opposite the implantable medical device to minimize the potential for interference.
Listening at full volume to music or voice through a headset may
damage your hearing.
Symbol Definition
•
Turn OFF the mobile device immediately if you have any reason to suspect that interference is
taking place.
Regulatory Information
Regulat ory Info rmation
Your Motorola mobile device is designed to comply with national and international regulatory
requirements. For full compliance statements and details, please refer to the regulatory information
in your printed product guide.
Specific Absorption Rate (FCC & IC)
SAR (FCC & IC)
YOUR MOBILE DEVICE MEETS FCC AND IC LIMITS
FOR EXPOSURE TO RADIO WAVES.
Your mobile device is a radio transmitter and receiver. It is designed not to exceed the limits for
exposure to radio waves (radio frequency electromagnetic fields) adopted by the Federal
Communications Commission (FCC) and Industry Canada (IC). These limits include a substantial
safety margin designed to assure the safety of all persons, regardless of age and health.
The radio wave exposure guidelines use a unit of measurement known as the Specific Absorption
Rate, or SAR. The SAR limit for mobile devices is 1.6 W/kg.
Tests for SAR are conducted using standard operating positions with the device transmitting at its
highest certified power level in all tested frequency bands. The highest SAR values under the FCC
and IC guidelines for your device model are listed below:
During use, the actual SAR values for your device are usually well below the values stated. This is
because, for purposes of system efficiency and to minimize interference on the network, the
operating power of your mobile device is automatically decreased when full power is not needed
for the call. The lower the power output of the device, the lower its SAR value.
If you are interested in further reducing your RF exposure then you can easily do so by limiting your
usage or simply using a hands-free kit to keep the device away from the head and body.
Additional information can be found at
www.motorola.com/rfhealth
.
FCC Notice to Users
FCC Notice
The following statement applies to all products that bear the FCC logo and/or FCC ID on the
product label.
This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to part 15 of the FCC Rules. See 47 CFR Sec. 15.105(b). These limits are designed to
provide reasonable protection against harmful interference in a residential installation. This
equipment generates, uses and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television reception, which can be
Head SAR Band 4 LTE (1700 MHz), Wi-Fi, Bluetooth 1.21 W/kg
Body-worn SAR Band 2 LTE (1900 MHz), Wi-Fi, Bluetooth 0.42 W/kg
Product Safety & Legal
Battery Use & Safety
Battery Charging
Third Party Accessories
Driving Precautions
Seizures, Blackouts & Eyestrain
High Volume
Repetitive Motion
Children
Glass Parts
Operational Warnings
RF Energy
Regulatory Information
Location
Navigation
Privacy & Data Security
Use & Care
Recycling
Perchlorate Label
Hearing Aid Compatibility
Software Copyright
Content Copyright
OSS Information
Export Law
Registration
Service & Repairs
Global Warranty
Copyright & Trademarks
16 APR 2013
FCC
BackNext
Menu More
Product Safety & Legal
determined by turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
•
Reorient or relocate the receiving antenna.
•
Increase the separation between the equipment and the receiver.
•
Connect the equipment to an outlet on a circuit different from that to which the receiver is
connected.
•
Consult the dealer or an experienced radio/TV technician for help.
This device complies with part 15 of the FCC Rules. Operation is subject to the following two
conditions: (1) This device may not cause harmful interference, and (2) this device must accept any
interference received, including interference that may cause undesired operation. See 47 CFR
Sec. 15.19(a)(3).
Motorola has not approved any changes or modifications to this device by the user. Any changes or
modifications could void the user’s authority to operate the equipment. See 47 CFR Sec. 15.21.
For products that support Wi-Fi 802.11a (as defined in product information): In the United States,
do not use your device outdoors while connected to an 802.11a Wi-Fi network. The FCC prohibits
such outdoor use since frequencies 5.15-5.25 GHz can cause interference with Mobile Satellite
Services (MSS). Public Wi-Fi access points in this range are optimized for indoor use.
Industry Canada Notice to Users
Indus try Canada Notice
This device complies with Industry Canada license-exempt RSS standard(s). Operation is subject
to the following two conditions: (1) This device may not cause interference and (2) This device
must accept any interference, including interference that may cause undesired operation of the
device. See RSS-GEN 7.1.3. This Class B digital apparatus complies with Canadian ICES-003.
Software Notices
Software Notices
Warning against unlocking the bootloader or altering a product's operating system software:
Motorola strongly recommends against altering a product's operating system, which includes
unlocking the bootloader, rooting a device or running any operating software other than the
approved versions issued by Motorola and its partners. Such alterations may permanently damage
your product, cause your product to be unsafe and/or cause your product to malfunction. In such
cases, neither the product nor any damage resulting therefrom will be covered by warranty.
Important FCC information: You must not make or enable any changes to the product that will
impact its FCC grant of equipment authorization. The FCC grant is based on the product's
emission, modulation, and transmission characteristics, including: power levels, operating
frequencies and bandwidths, SAR levels, duty-cycle, transmission modes (e.g., CDMA, GSM), and
intended method of using the product (e.g., how the product is held or used in proximity to the
body). A change to any of these factors will invalidate the FCC grant. It is illegal to operate a
transmitting product without a valid grant.
Location Services
Locati on
The following information is applicable to Motorola mobile devices that provide location based
functionality. Location sources can include GPS, AGPS and Wi-Fi.
Your mobile device can use Global Positioning System (GPS) signals for location-based
applications. GPS uses satellites controlled by the U.S. government that are subject to changes
implemented in accordance with the Department of Defense policy and the Federal Radio
Navigation Plan. These changes may affect the performance of location technology on your
mobile device.
Your mobile device can also use Assisted Global Positioning System (AGPS), which obtains
information from the cellular network to improve GPS performance. AGPS uses your wireless
service provider's network and therefore airtime, data charges, and/or additional charges may
apply in accordance with your service plan. Contact your wireless service provider for details.
Your mobile device can also use Wi-Fi signals to determine your approximate location, using
information from known and available Wi-Fi networks.
Yo u r L o c a t i o n
Location-based information includes information that can be used to determine the approximate
location of a mobile device. Mobile devices which are connected to a wireless network transmit
location-based information. Devices enabled with location technology also transmit location-based
information. Additionally, if you use applications that require location-based information (e.g.
driving directions), such applications transmit location-based information. This location-based
information may be shared with third parties, including your wireless service provider, applications
providers, Motorola, and other third parties providing services.
Emergency Calls
When you make an emergency call, the cellular network may activate the AGPS technology in your
mobile device to tell the emergency responders your approximate location.
AGPS has limitations and might not work in your area. Therefore:
•
Always tell the emergency responder your location to the best of your ability; and
•
Remain on the phone for as long as the emergency responder instructs you.
Navigation
Navigation
The following information is applicable to Motorola mobile devices that provide navigation
features.
When using navigation features, note that mapping information, directions and other navigational
data may contain inaccurate or incomplete data. In some countries, complete information may not
be available. Therefore, you should visually confirm that the navigational instructions are consistent
with what you see. All drivers should pay attention to road conditions, closures, traffic, and all other
factors that may impact driving. Always obey posted road signs.
Privacy & Data Security
Privac y & Data Secur ity
Motorola understands that privacy and data security are important to everyone. Because some
features of your mobile device may affect your privacy or data security, please follow these
recommendations to enhance protection of your information:
•
Monitor access—Keep your mobile device with you and do not leave it where others may have
unmonitored access. Use your device’s security and lock features, where available.
•
Keep software up to date—If Motorola or a software/application vendor releases a patch or
software fix for your mobile device that updates the device’s security, install it as soon as
possible.
•
Secure Personal Information—Your mobile device can store personal information in various
locations including your SIM card, memory card, and phone memory. Be sure to remove or
Product Safety & Legal
Battery Use & Safety
Battery Charging
Third Party Accessories
Driving Precautions
Seizures, Blackouts & Eyestrain
High Volume
Repetitive Motion
Children
Glass Parts
Operational Warnings
RF Energy
Regulatory Information
Location
Navigation
Privacy & Data Security
Use & Care
Recycling
Perchlorate Label
Hearing Aid Compatibility
Software Copyright
Content Copyright
OSS Information
Export Law
Registration
Service & Repairs
Global Warranty
Copyright & Trademarks
16 APR 2013
FCC
BackNext
Menu More
Product Safety & Legal
clear all personal information before you recycle, return, or give away your device. You can also
backup your personal data to transfer to a new device.
Note:
For information on how to backup or wipe data from your mobile device, go to
www.motorola.com/support
•
Online accounts—Some mobile devices provide a Motorola online account (such as
MOTOBLUR). Go to your account for information on how to manage the account, and how to
use security features such as remote wipe and device location (where available).
•
Applications and updates—Choose your apps and updates carefully, and install from trusted
sources only. Some apps can impact your phone’s performance and/or have access to private
information including account details, call data, location details and network resources.
•
Wireless—For mobile devices with Wi-Fi features, only connect to trusted Wi-Fi networks. Also,
when using your device as a hotspot (where available) use network security. These precautions
will help prevent unauthorized access to your device.
•
Location-based information—Mobile devices enabled with location based technologies such
as GPS, AGPS or Wi-Fi, can transmit location-based information. See “Location Services” for
more details.
•
Other information your device may transmit—Your device may also transmit testing and other
diagnostic (including location-based) information, and other non-personal information to
Motorola or other third-party servers. This information is used to help improve products and
services offered by Motorola.
If you have further questions regarding how the use of your mobile device may impact your privacy
or data security, please contact Motorola at
privacy@motorola.com
, or contact your service
provider.
Use & Care
Use & Care
To care for your Motorola mobile device, please observe the following:
liquids
Don’t expose your mobile device to water, rain, extreme humidity, sweat, or other
liquids.
drying
Don’t try to dry your mobile device using a microwave oven, conventional oven, or
dryer, as this may damage the mobile device.
extreme heat or cold
Don’t store or use your mobile device in temperatures below -10°C (14°F) or above
60°C (140°F). Don’t recharge your mobile device in temperatures below 0°C (32°F)
or above 45°C (113°F).
dust and dirt
Don’t expose your mobile device to dust, dirt, sand, food, or other inappropriate
materials.
cleaning
To clean your mobile device, use only a dry soft cloth. Don’t use alcohol or other
cleaning solutions.
shock and vibration
Don’t drop your mobile device.
protection
To help protect your mobile device, always make sure that any battery, connector
and compartment covers are closed and secure.
Recycling
Recycli ng
Mobile Devices & Accessories
Please do not dispose of mobile devices or electrical accessories (such as chargers,
headsets, or batteries) with your household waste, or in a fire. These items should be
disposed of in accordance with the national collection and recycling schemes
operated by your local or regional authority. Alternatively, you may return unwanted
mobile devices and electrical accessories to any Motorola Approved Service Center
in your region. Details of Motorola approved national recycling schemes, and further information
on Motorola recycling activities can be found at:
www.motorola.com/recycling
Packaging & Product Guides
Product packaging and product guides should only be disposed of in accordance with national
collection and recycling requirements. Please contact your regional authorities for more details.
California Perchlorate Label
Perchlorat e Label
Some mobile phones use an internal, permanent backup battery on the printed circuit board that
may contain very small amounts of perchlorate. In such cases, California law requires the following
label:
Perchlorate Material – special handling may apply when the battery is recycled or disposed of. See
www.dtsc.ca.gov/hazardouswaste/perchlorate
(in English only).
There is no special handling required by consumers.
Hearing Aid Compatibility with Mobile Phones
Hearing Aid Compatibility
Some Motorola phones are measured for compatibility with hearing aids. If the box for your
particular model has “Rated for Hearing Aids” printed on it, the following explanation applies.
Product Safety & Legal
Battery Use & Safety
Battery Charging
Third Party Accessories
Driving Precautions
Seizures, Blackouts & Eyestrain
High Volume
Repetitive Motion
Children
Glass Parts
Operational Warnings
RF Energy
Regulatory Information
Location
Navigation
Privacy & Data Security
Use & Care
Recycling
Perchlorate Label
Hearing Aid Compatibility
Software Copyright
Content Copyright
OSS Information
Export Law
Registration
Service & Repairs
Global Warranty
Copyright & Trademarks
16 APR 2013
FCC
BackNext
Menu More
Product Safety & Legal
When some mobile phones are used near some hearing devices (hearing aids and cochlear
implants), users may detect a buzzing, humming, or whining noise. Some hearing devices are
more immune than others to this interference noise, and phones also vary in the amount of
interference they generate.
The wireless telephone industry has developed ratings for some of their mobile phones, to assist
hearing device users in finding phones that may be compatible with their hearing devices. Not all
phones have been rated. Phones that are rated have the rating on their box or a label on the box. To
maintain the published Hearing Aid Compatibility (HAC) rating for this mobile phone, use only the
original equipment battery model.
This phone has been tested and rated for use with hearing aids for some of the wireless
technologies that it uses. However, there may be some newer wireless technologies used in this
phone that have not been tested yet for use with hearing aids. It is important to try the different
features of this phone thoroughly and in different locations, using your hearing aid or cochlear
implant, to determine if you hear any interfering noise. Contact your service provider or Motorola
for information on hearing aid compatibility. If you have questions about return or exchange
policies, contact your service provider or phone retailer.
The ratings are not guarantees. Results will vary depending on the user’s hearing device and
hearing loss. If your hearing device happens to be vulnerable to interference, you may not be able
to use a rated phone successfully. Trying out the phone with your hearing device is the best way to
evaluate it for your personal needs.
M-Ratings: Phones rated M3 or M4 meet FCC requirements and are likely to generate less
interference to hearing devices than phones that are not labeled. M4 is the better/higher of the two
ratings.
T-Ratings: Phones rated T3 or T4 meet FCC requirements and are likely to be more usable with a
hearing device’s telecoil (“T Switch” or “Telephone Switch”) than unrated phones. T4 is the
better/higher of the two ratings. (Note that not all hearing devices have telecoils in them.)
Hearing devices may also be measured for immunity to this type of interference. Your hearing
device manufacturer or hearing health professional may help you find results for your hearing
device. The more immune your hearing aid is, the less likely you are to experience interference
noise from mobile phones.
Software Copyright
Softwar e Copyright
Motorola products may include copyrighted Motorola and third-party software stored in
semiconductor memories or other media. Laws in the United States and other countries preserve
for Motorola and third-party software providers certain exclusive rights for copyrighted software,
such as the exclusive rights to distribute or reproduce the copyrighted software. Accordingly, any
copyrighted software contained in Motorola products may not be modified, reverse-engineered,
distributed, or reproduced in any manner to the extent allowed by law. Furthermore, the purchase
of Motorola products shall not be deemed to grant either directly or by implication, estoppel, or
otherwise, any license under the copyrights, patents, or patent applications of Motorola or any
third-party software provider, except for the normal, non-exclusive, royalty-free license to use that
arises by operation of law in the sale of a product.
Content Copyright
Content Copyright
The unauthorized copying of copyrighted materials is contrary to the provisions of the Copyright
Laws of the United States and other countries. This device is intended solely for copying
non-copyrighted materials, materials in which you own the copyright, or materials which you are
authorized or legally permitted to copy. If you are uncertain about your right to copy any material,
please contact your legal advisor.
Open Source Software Information
OSS Information
For instructions on how to obtain a copy of any source code being made publicly available by
Motorola related to software used in this Motorola mobile device, you may send your request in
writing to the address below. Please make sure that the request includes the model number and
the software version number.
MOTOROLA MOBILITY LLC
OSS Management
600 North US Hwy 45
Libertyville, IL 60048
USA
The Motorola website
opensource.motorola.com
(in English only) also contains information
regarding Motorola's use of open source.
Motorola has created the
opensource.motorola.com
website to serve as a portal for
interaction with the software community-at-large.
To view additional information regarding licenses, acknowledgments and required copyright
notices for open source packages used in this Motorola mobile device, please go to
Apps >
Settings
>
About phone
>
Legal information
>
Open source licenses
. In addition, this Motorola device may include self-contained
applications that present supplemental notices for open source packages used in those
applications.
Export Law Assurances
Export Law
This product is controlled under the export regulations of the United States of America and
Canada. The Governments of the United States of America and Canada may restrict the
exportation or re-exportation of this product to certain destinations. For further information contact
the U.S. Department of Commerce or the Canadian Department of Foreign Affairs and
International Trade.
Product Registration
Registration
Online Product Registration:
www.motorola.com/us/productregistration
(in English only)
Product registration is an important step toward enjoying your new Motorola product. Registering
permits us to contact you for product or software updates and allows you to subscribe to updates
on new products or special promotions. Registration is not required for warranty coverage.
Please retain your original dated sales receipt for your records. For warranty service of your
Motorola product you will need to provide a copy of your dated sales receipt to confirm warranty
status.
Product Safety & Legal
Battery Use & Safety
Battery Charging
Third Party Accessories
Driving Precautions
Seizures, Blackouts & Eyestrain
High Volume
Repetitive Motion
Children
Glass Parts
Operational Warnings
RF Energy
Regulatory Information
Location
Navigation
Privacy & Data Security
Use & Care
Recycling
Perchlorate Label
Hearing Aid Compatibility
Software Copyright
Content Copyright
OSS Information
Export Law
Registration
Service & Repairs
Global Warranty
Copyright & Trademarks
16 APR 2013
FCC
BackNext
Menu More
Product Safety & Legal
Thank you for choosing a Motorola product.
Service & Repairs
Serv ice & Repairs
If you have questions or need assistance, we're here to help.
Go to
www.motorola.com/repair
(United States) or
www.motorola.com/support
(Canada), where you can select from a number of customer care options. You can also contact the
Motorola Customer Support Center at 1-800-734-5870 (United States), 1-888-390-6456 (TTY/TDD
United States for hearing impaired), or 1-800-461-4575 (Canada).
How to Obtain Service or Other Information
1. Please access and review the online Customer Support section of Motorola's consumer website
prior to requesting warranty service.
2. If the Product is still not functioning properly after making use of this resource, please contact
the Warrantor listed at the Motorola website or the contact information for the corresponding
location.
3. A representative of Motorola, or of a Motorola Authorized Repair Center, will help determine
whether your Product requires service. You may be required to download, or otherwise obtain
and accept software updates from Motorola or a Motorola Authorized Repair Center. You are
responsible for any applicable carrier service fees incurred while obtaining the required down-
loads. Complying with the warranty process, repair instructions and accepting such software
updates is required in order to receive additional warranty support.
4. If the software update does not fix the problem, you will receive instructions on how to ship the
Product to a Motorola Authorized Repair Center or other entity.
5. To obtain warranty service, as permitted by applicable law, you are required to include: (a) a
copy of your receipt, bill of sale or other comparable proof of purchase; (b) a written description
of the problem; (c) the name of your service provider, if applicable; (d) your address and tele-
phone number. In the event the Product is not covered by the Motorola Limited Warranty, Mo-
torola will inform the consumer of the availability, price and other conditions applicable to the
repair of the Product.
To obtain service or other information, please access and review the online Customer Support
section of Motorola's consumer website at www.motorola.com.
Motorola Mobility LLC Limited Global
Warranty Mobile Phones
Global Warranty
Note: This Limited Warranty is not applicable in Quebec, Canada.
FOR CONSUMERS WHO ARE COVERED BY CONSUMER PROTECTION LAWS OR
REGULATIONS IN THEIR COUNTRY OF PURCHASE OR, IF DIFFERENT, THEIR COUNTRY OF
RESIDENCE, THE BENEFITS CONFERRED BY THIS LIMITED WARRANTY ARE IN ADDITION TO
ALL RIGHTS AND REMEDIES CONVEYED BY SUCH CONSUMER PROTECTION LAWS AND
REGULATIONS.
Who is Covered?
This Limited Warranty extends only to the first consumer purchaser of the Product, and is not
transferable.
What Does this Limited Warranty Cover?
Motorola Mobility LLC or its subsidiaries' warranty obligations are limited to the terms and
conditions set forth herein. Subject to the exclusions contained below, Motorola Mobility LLC or its
subsidiaries (”Motorola”) warrant this Mobile Phone, and any in-box accessories which accompany
such Mobile Phone (”Product”) against defects in materials and workmanship, under normal
consumer use, for a period of ONE (1) YEAR from the date of retail purchase by the original
end-user purchaser, or the period of time required by the laws of the country where the Product is
purchased, whichever is longer (”Warranty Period”).
Repairs made under this Limited Warranty are covered for the balance of the original Warranty
Period, or 90 days from the date of service, whichever is longer. Any upgrade to the original
product will be covered only for the duration of the original Warranty Period.
This Limited Warranty is only available in the country where the Product was purchased. Motorola
may provide service outside the country of purchase, to the extent that it is possible and under the
terms and conditions of the country of purchase.
This Limited Warranty applies only to new Products which are a) manufactured by or for Motorola
as identified by the ”Motorola” trademark, trade name, or logo legally affixed to them; b)
purchased by consumers from an authorized reseller or distributor of Motorola Products; and c)
accompanied by this written Limited Warranty.
What Will Motorola Do?
If a covered defect or damage arises and a valid warranty claim is received within the applicable
Warranty Period, Motorola, at its sole option, unless otherwise required by applicable law, will
either (1) repair, at no charge, the defect or damage using new, used or reconditioned/refurbished
functionally equivalent replacement parts; or (2) exchange the Product with a replacement
Product that is new or which has been reconditioned/refurbished or otherwise remanufactured
from new or used parts and is functionally equivalent to the original Product; or (3) refund the
purchase price of any Products covered by the terms and conditions of this Limited Warranty.
Products, parts and supporting documentation provided to Motorola as part of the warranty
process, shall become the property of Motorola, and may not be returned. When a replacement or
refund is given, the Product for which the replacement or refund is provided must be returned to
Motorola and shall become the property of Motorola.
Exclusions (Products and Accessories)
This warranty does not apply to:
(a) Consumable parts, such as batteries or protective coatings designed to diminish over time
unless failure has occurred due to a defect in materials or workmanship. As with all batteries, the
maximum capacity of the battery will decrease with time and use; this is not a defect. Only
defective batteries and batteries that leak are covered by this warranty.
(b) Cosmetic damage, including but not limited to scratches, dents, cracks or other cosmetic
damage.
(c) Damage caused by use with non-Motorola products. Defects or damage that result from the use
of non-Motorola branded or certified Products, accessories or other peripheral equipment,
including without limitation housings, parts, or software, are excluded from coverage.
(d) Damage caused by accident, abuse, misuse, liquid contact, fire, earthquake or other external
causes; including but not limited to: (i) improper usage or operation (e.g. operating the Product
outside their permitted or intended uses as defined by Motorola, including but not limited to as set
Product Safety & Legal
Battery Use & Safety
Battery Charging
Third Party Accessories
Driving Precautions
Seizures, Blackouts & Eyestrain
High Volume
Repetitive Motion
Children
Glass Parts
Operational Warnings
RF Energy
Regulatory Information
Location
Navigation
Privacy & Data Security
Use & Care
Recycling
Perchlorate Label
Hearing Aid Compatibility
Software Copyright
Content Copyright
OSS Information
Export Law
Registration
Service & Repairs
Global Warranty
Copyright & Trademarks
16 APR 2013
FCC
BackNext
Menu More
Product Safety & Legal
forth by Motorola in the Products' User Manual, Quick Start Guide, Online Tutorials, and other
documentation), improper storage (e.g. subjecting the Product to extreme temperatures), abuse
or neglect (e.g. broken/bent/missing clips/fasteners/connectors); impact damage (e.g. dropping
the Product) (ii) contact with liquids, water, rain, extreme humidity, heavy perspiration or other
moisture; sand, food, dirt or similar substances (except for Products sold as resistant to such
substances, but only to the extent the damage was not caused by incorrectly securing the phone's
protective elements or subjecting the Product to conditions beyond its stated specifications or
limits); (iii) use of the Products for commercial rental purposes; or (iv) external causes or acts which
are not the fault of Motorola, including but not limited to flood, fire, earthquake, tornado or other
acts of God, are excluded from coverage.
(e) Unauthorized Service or Modification. Defects or damage resulting from service, testing,
adjustment, installation, maintenance, alteration, or modification in any way, including but not
limited to tampering with or altering the software, by someone other than Motorola, or its
authorized service centers, are excluded from coverage. Notwithstanding the foregoing, any
Product which has had its bootloader unlocked, or whose operating system has been altered,
including any failed attempts to unlock the bootloader or alter such operating system, is not
covered by this warranty, regardless of whether such modifications are authorized, approved, or
otherwise sanctioned by Motorola.
(f) A product or part that has been modified in any manner without the written permission of
Motorola. Products that have been altered in any manner so as to prevent Motorola from
determining whether such Products are covered under the terms of this Limited Warranty are
excluded from coverage. The forgoing shall include but not be limited to (i) serial numbers, date
tags or other manufacturer coding that has been removed, altered or obliterated; (ii) mismatched
or duplicated serial numbers; or (iii) broken seals or other evidence of tampering. Do not open the
Product or attempt to repair the Product yourself; such conduct may cause damage that is not
covered by this warranty.
(g) Normal wear and tear or otherwise due to the normal aging of the Product.
(h) Defects, damages, or the failure of the Product due to any communication service or network
you subscribe to or use with the Products.
(i) All software, including operating system software, third-party software, applications, and all
other software of any kind. Software distributed by Motorola is provided ”AS-IS” and ”AS
AVAILABLE,” ”WITH ALL FAULTS” and without a warranty of any kind. The Limited Warranty does
not apply to any non-Motorola product or any software, even if packaged or sold with the Motorola
hardware, unless otherwise required by applicable local law.
(j) Products that have been refurbished, reconditioned, or remanufactured, except for Products
repaired or replaced pursuant to the terms of this Limited Warranty.
If damage is outside the scope of warranty coverage, repair services may be available, but all costs
associated with such out of warranty repair will be your responsibility.
What Other Limitations are There?
•
TO THE EXTENT PERMITTED BY APPLICABLE LAW, THIS LIMITED WARRANTY AND THE
REMEDIES SET FORTH HEREIN ARE EXCLUSIVE AND IN LIEU OF ALL OTHER WARRANTIES
AND REMEDIES, WHETHER ORAL OR WRITTEN, STATUTORY, EXPRESS OR IMPLIED. NO
ORAL OR WRITTEN REPRESENTATIONS MADE BY MOTOROLA OR ANY SELLER,
RESELLER OR DISTRIBUTOR OF THE PRODUCTS, INCLUDING EMPLOYEES AND AGENTS
THEREOF, SHALL CREATE ANY ADDITIONAL WARRANTY OBLIGATIONS, INCREASE THE
SCOPE, OR OTHERWISE MODIFY IN ANY MANNER THE TERMS OF THIS LIMITED
WARRANTY.
•
TO THE EXTENT PERMITTED BY APPLICABLE LAW, MOTOROLA SPECIFICALLY
DISCLAIMS ANY AND ALL STATUTORY OR IMPLIED WARRANTIES, INCLUDING, WITHOUT
LIMITATION, WARRANTIES OF MERCHANTABILITY, FITNESS FOR A PARTICULAR
PURPOSE, NONINFRINGEMENT AND ALL WARRANTIES AGAINST HIDDEN OR LATENT
DEFECTS. WHERE SUCH STATUTORY OR IMPLIED WARRANTIES CANNOT LAWFULLY BE
DISCLAIMED, THEN TO THE EXTENT PERMITTED BY LAW, ALL SUCH WARRANTIES SHALL
BE LIMITED IN DURATION TO THE DURATION OF THE EXPRESS LIMITED WARRANTY
CONTAINED HEREIN AND THE REMEDIES OF REPAIR, REPLACEMENT, OR REFUND AS
DETERMINED BY MOTOROLA IN ITS SOLE DISCRETION SHALL BE THE EXCLUSIVE
REMEDY OF THE CONSUMER.
•
TO THE EXTENT PERMITTED BY APPLICABLE LAW, MOTOROLA DOES NOT WARRANT
THAT THE OPERATION OF ANY PRODUCTS OR SOFTWARE COVERED UNDER THIS
LIMITED WARRANTY WILL MEET YOUR REQUIREMENTS, WORK IN COMBINATION WITH
ANY HARDWARE OR SOFTWARE APPLICATIONS OR THIRD PARTY SERVICES, BE
UNINTERRUPTED, ERROR-FREE, OR WITHOUT RISK TO, OR LOSS OF, ANY
INFORMATION, DATA, SOFTWARE OR APPLICATIONS CONTAINED THEREIN, OR THAT
DEFECTS IN THE PRODUCTS OR SOFTWARE WILL BE CORRECTED.
•
TO THE EXTENT PERMITTED BY APPLICABLE LAW, IN NO EVENT SHALL MOTOROLA BE
LIABLE, WHETHER IN CONTRACT, TORT OR UNDER OTHER LEGAL THEORY (INCLUDING
NEGLIGENCE), FOR DAMAGES IN EXCESS OF THE PURCHASE PRICE OF THE
PRODUCTS, OR FOR ANY INDIRECT, INCIDENTAL, SPECIAL OR CONSEQUENTIAL
DAMAGES OF ANY KIND, OR LOSS OF REVENUE OR PROFITS; LOSS OF BUSINESS;
BUSINESS INTERRUPTION; LOSS OF OPPORTUNITY; LOSS OF GOODWILL; LOSS OF
REPUTATION; LOSS OF, DAMAGE TO, OR CORRUPTION OF INFORMATION, DATA,
SOFTWARE OR APPLICATIONS (INCLUDING ANY COSTS ASSOCIATED WITH
RECOVERING, PROGRAMMING, OR REPRODUCING ANY INFORMATION, DATA,
SOFTWARE OR APPLICATIONS STORED ON OR USED WITH MOTOROLA PRODUCTS, OR
ANY FAILURE TO MAINTAIN THE CONFIDENTIALITY OF ANY INFORMATION OR DATA
STORED ON THE PRODUCTS); OR OTHER FINANCIAL LOSS ARISING OUT OF OR IN
CONNECTION WITH THE ABILITY OR INABILITY TO USE THE PRODUCTS.
•
SOME STATES OR JURISDICTIONS DO NOT ALLOW THE LIMITATION OR EXCLUSION OF
INCIDENTAL OR CONSEQUENTIAL DAMAGES, OR THE EXCLUSION OR LIMITATION ON
THE LENGTH OF AN IMPLIED WARRANTY, OR THE LIMITATION OR EXCLUSION OF
DAMAGES FOR PERSONAL INJURIES CAUSED BY NEGLIGENCE, SO THE ABOVE
LIMITATIONS OR EXCLUSIONS MAY NOT APPLY TO YOU. THIS WARRANTY GIVES YOU
SPECIFIC LEGAL RIGHTS, AND YOU MAY ALSO HAVE OTHER RIGHTS THAT VARY FROM
STATE OR JURISDICTION.
•
DATA BACKUP: ALL INFORMATION, DATA, SOFTWARE OR OTHER APPLICATIONS,
INCLUDING BUT NOT LIMITED TO PERSONAL CONTACTS, ADDRESS BOOKS, PICTURES,
MUSIC AND GAMES WILL BE ERASED DURING THE REPAIR PROCESS, AND CAN NOT BE
REINSTALLED BY MOTOROLA. TO AVOID LOSING SUCH INFORMATION, DATA,
SOFTWARE OR OTHER APPLICATIONS PLEASE CREATE A BACK UP BEFORE YOU
DELIVER YOUR PRODUCT FOR WARRANTY SERVICE, REMOVE ANY CONFIDENTIAL,
Product Safety & Legal
Battery Use & Safety
Battery Charging
Third Party Accessories
Driving Precautions
Seizures, Blackouts & Eyestrain
High Volume
Repetitive Motion
Children
Glass Parts
Operational Warnings
RF Energy
Regulatory Information
Location
Navigation
Privacy & Data Security
Use & Care
Recycling
Perchlorate Label
Hearing Aid Compatibility
Software Copyright
Content Copyright
OSS Information
Export Law
Registration
Service & Repairs
Global Warranty
Copyright & Trademarks
16 APR 2013
FCC
BackNext
Menu More
Product Safety & Legal
PROPRIETARY OR PERSONAL INFORMATION AND DISABLE ANY SECURITY PASSWORDS.
YOU WILL BE RESPONSIBLE FOR REINSTALLING ALL SUCH INFORMATION, DATA,
SOFTWARE, OTHER APPLICATIONS AND PASSWORDS. MOTOROLA AND/OR ITS
AUTHORIZED SERVICE CENTERS ARE NOT RESPONSIBLE FOR THE LOSS OR MISUSE OF
ANY DATA, FILES, CONTENT, APPLICATIONS AND PROGRAMS WHEN THE PRODUCT IS
DELIVERED FOR WARRANTY SERVICE. YOUR PRODUCT OR A REPLACEMENT PRODUCT
WILL BE RETURNED TO YOU AS YOUR PRODUCT WAS CONFIGURED WHEN ORIGINALLY
PURCHASED, SUBJECT TO APPLICABLE SOFTWARE UPDATES. MOTOROLA MAY INSTALL
OPERATING SYSTEM SOFTWARE UPDATES AS PART OF WARRANTY SERVICE THAT MAY
PREVENT THE PRODUCT FROM REVERTING TO AN EARLIER VERSION OF THE
OPERATING SYSTEM SOFTWARE. THIRD PARTY APPLICATIONS INSTALLED ON THE
PRODUCT MAY NOT BE COMPATIBLE OR WORK WITH THE PRODUCT AS A RESULT OF
THE OPERATING SYSTEM SOFTWARE UPDATE. MOTOROLA AND ITS AUTHORIZED
SERVICE CENTERS ARE NOT RESPONSIBLE FOR THE LOSS OF, OR INABILITY TO USE,
SUCH INFORMATION, DATA, SOFTWARE OR OTHER APPLICATIONS.
•
WARNING AGAINST UNLOCKING THE BOOTLOADER OR ALTERING A PRODUCT'S
OPERATING SYSTEM SOFTWARE: MOTOROLA STRONGLY RECOMMENDS AGAINST
ALTERING A PRODUCT'S OPERATING SYSTEM, WHICH INCLUDES UNLOCKING THE
BOOTLOADER, ROOTING A DEVICE OR RUNNING ANY OPERATING SOFTWARE OTHER
THAN THE APPROVED VERSIONS ISSUED BY MOTOROLA AND ITS PARTNERS. SUCH
ALTERATIONS MAY PERMANENTLY DAMAGE YOUR PRODUCT, CAUSE YOUR PRODUCT
TO BE UNSAFE AND/OR CAUSE YOUR PRODUCT TO MALFUNCTION. IN SUCH CASES,
NEITHER THE PRODUCT NOR ANY DAMAGE RESULTING THEREFROM WILL BE
COVERED BY THIS WARRANTY.
•
IMPORTANT FCC INFORMATION: YOU MUST NOT MAKE OR ENABLE ANY CHANGES TO
THE PRODUCT THAT WILL IMPACT ITS FCC GRANT OF EQUIPMENT AUTHORIZATION.
THE FCC GRANT IS BASED ON THE PRODUCT'S EMISSION, MODULATION, AND
TRANSMISSION CHARACTERISTICS, INCLUDING: POWER LEVELS, OPERATING
FREQUENCIES AND BANDWIDTHS, SAR LEVELS, DUTY-CYCLE, TRANSMISSION MODES
(E.G., CDMA, GSM), AND INTENDED METHOD OF USING THE PRODUCT (E.G., HOW THE
PRODUCT IS HELD OR USED IN PROXIMITY TO THE BODY). A CHANGE TO ANY OF
THESE FACTORS WILL INVALIDATE THE FCC GRANT. IT IS ILLEGAL TO OPERATE A
TRANSMITTING PRODUCT WITHOUT A VALID GRANT.
Copyright & Trademarks
Copyri ght & Trademarks
Motorola Mobility LLC
Consumer Advocacy Office
600 N US Hwy 45
Libertyville, IL 60048
www.motorola.com
Note:
Do not ship your product to the above address. If you need to return your product for
repairs, replacement, or warranty service, please contact the Motorola Customer Support
Center at:
1-800-734-5870 (United States)
1-888-390-6456 (TTY/TDD United States for hearing impaired)
1-800-461-4575 (Canada)
Certain features, services and applications are network dependent and may not be available in all
areas; additional terms, conditions and/or charges may apply. Contact your service provider for
details.
All features, functionality, and other product specifications, as well as the information contained in
this guide, are based upon the latest available information and believed to be accurate at the time
of printing. Motorola reserves the right to change or modify any information or specifications
without notice or obligation.
Note:
The images in this guide are examples only.
MOTOROLA and the Stylized M Logo are trademarks or registered trademarks of Motorola
Trademark Holdings, LLC. Android, Google and other trademarks are owned by Google Inc. The
Android robot is reproduced or modified from work created and shared by Google and used
according to terms described in the Creative Commons 3.0 Attribution License. All other product
or service names are the property of their respective owners.
© 2013 Motorola Mobility LLC. All rights reserved.
Caution:
Motorola does not take responsibility for changes/modification to the transceiver.
© 2013 Motorola Mobility LLC. All rights reserved.
Product ID: Motorola X (Model XT1058)
Manual Number: 68017460001-A
Product Safety & Legal
Battery Use & Safety
Battery Charging
Third Party Accessories
Driving Precautions
Seizures, Blackouts & Eyestrain
High Volume
Repetitive Motion
Children
Glass Parts
Operational Warnings
RF Energy
Regulatory Information
Location
Navigation
Privacy & Data Security
Use & Care
Recycling
Perchlorate Label
Hearing Aid Compatibility
Software Copyright
Content Copyright
OSS Information
Export Law
Registration
Service & Repairs
Global Warranty
Copyright & Trademarks
16 APR 2013
FCC

Navigation menu
