Motorola Mobility T56QD1 WCDMA/GSM/CDMA/LTE Transceiver with BT, WLAN & NFC User Manual
Motorola Mobility LLC WCDMA/GSM/CDMA/LTE Transceiver with BT, WLAN & NFC
Users Manual
APPLICANT: MOTOROLA MOBILITY LLC FCC ID: IHDT56QD1 / IC ID: 109O-T56QD1
Temporary Confidentiality Requested
Motorola Mobility LLC; 8000 W. Sunrise Blvd, Suite A; Plantation, FL 33322, USA www.motorola.com Page 8 - 1
Exhibit 8: Draft User’s Manual -- 47 CFR 2.1033(b)(3) and
RSP100, Section 5.
The Operating Guide for this device will be deployed electronically, via a web site. This manual is in
development, but will be located at this site: Google Nexus Device User Guide.
The attached User’s Manual is the final production-intended version of the generic Motorola English
User Manual. This guide will be adapted to carrier-specific versionsi, but the key information herein
will be retained. Translations into other languages will also be done to support the needs of other
markets. Minor revisions may be made to these manuals, prior to and subsequent to, placing this
product onto the market. Selected portions of the User Guide can be found as indicated below:
8.1 Getting Started Guide (Charging/SIM – In Box): Page 2
8.2 Safety and Regulatory Guide (In Box): Page 4
8.3 Specific Absorption Rate (SAR) Data: Page 7
i Motorola Mobility attests that the User’s Guide provided with product shipping into Canada will provide any required Industry
Canada notices and/or statements in both English and French, per the requirements of RSS-Gen.
QSG / Front Cover
6
NFC
QSG / Back Cover
1
1, 2, 3...
2
support.google.com/nexus
?
56014493013
Safety + Warranty
ENGLISH
1
Contents
Safety, Regulatory, & Legal 2
Driving Precautions 2
Caution about High
Volume Usage 2
Allergens 3
Specific Absorption Rate
(FCC & IC) 3
European Union Directives Conformance
Statement 4
FCC Notice to Users 5
Industry Canada Notice
to Users 6
Use & Care 6
Motorola Mobility LLC
Global Limited Warranty 7
Copyright & Trademarks 12
2
Safety, Regulatory,
&Legal
Note: For full Safety, Regulatory, and Legal
information, visit
www.motorola.com/mynexus6/legalguide.
Driving Precautions
Driv ing Prec autio ns
Responsible and safe driving is your primary
responsibility when driving a vehicle. Always obey
local laws and regulations.
While driving, ALWAYS:
•Keep your eyes on the road.
•Use a handsfree device if available or required
by law in your area.
•Enter destination information into a navigation
device before driving.
•Use voice activated features (such as voice dial)
and speaking features (such as audible
directions), if available.
•Concentrate on driving, and stop using the
mobile device if you can’t concentrate.
Pull over safely before using your mobile device to
send messages, surf the web, or use other
applications.
Caution about High
Volume Usage
High Volume
Warning: Exposure to loud noise from
any source for extended periods of time
may affect your hearing. The louder the
sound, the less time is required before
your hearing could be affected. To protect your
hearing:
•Limit the amount of time you use headsets or
headphones at high volume.
•Avoid turning up the volume to block out noisy
surroundings.
3
•Turn the volume down if you can’t hear people
speaking near you.
If you experience hearing discomfort, including the
sensation of pressure or fullness in your ears,
ringing in your ears, or muffled speech, you should
stop listening to the device through your headset
or headphones and have your hearing checked.
Allergens
Allergens
Motorola Mobility avoids using known allergens in
our products. From time to time, trace amounts of
an allergen may be added during manufacture of a
device or device component that could cause
discomfort for some individuals. This approach is
common for many types of products. We
recommend that you monitor any products that
may be in prolonged contact with your skin, and
remove them if you experience skin irritation.
Specific Absorption Rate
(FCC & IC)
SAR (FCC & IC)
YOUR MOBILE DEVICE MEETS FCC AND IC
LIMITS FOR EXPOSURE TO RADIO WAVES.
Your mobile device is a radio transmitter and
receiver. It is designed not to exceed the limits for
exposure to radio waves (radio frequency
electromagnetic fields) adopted by the Federal
Communications Commission (FCC) and Industry
Canada (IC). These limits include a substantial
safety margin designed to assure the safety of all
persons, regardless of age and health.
The radio wave exposure guidelines use a unit of
measurement known as the Specific Absorption
Rate, or SAR. The SAR limit for mobile devices is
1.6 W/kg.
Tests for SAR are conducted using standard
operating positions with the device transmitting at
its highest certified power level in all tested
frequency bands. The highest SAR values under
the FCC and IC guidelines for your device model
are listed below:
Head SAR Wi-Fi (2.4 GHz),
Bluetooth
0.93 W/kg
Body-
worn SAR
WCDMA Band IV,
Wi-Fi, Bluetooth
1.47 W/kg
4
During use, the actual SAR values for your device
are usually well below the values stated. This is
because, for purposes of system efficiency and to
minimize interference on the network, the
operating power of your mobile device is
automatically decreased when full power is not
needed for the call. The lower the power output of
the device, the lower its SAR value.
If you are interested in further reducing your RF
exposure then you can easily do so by limiting your
usage or simply using a hands-free kit to keep the
device away from the head and body.
Additional information can be found at
www.motorola.com/rfhealth.
European Union Directives
Conformance Statement
EU Confor mance
The following CE compliance information is
applicable to Motorola mobile devices that carry
one of the following CE marks:
Hereby, Motorola declares that this product is in
compliance with:
•The essential requirements and other relevant
provisions of Directive 1999/5/EC
•All other relevant EU Directives
For products that support Wi-Fi 802.11a/ac (as
defined in your product information): Outside the
United States, this device is restricted to indoor
use when operating in the 5.15 to 5.25 GHz
(802.11a/ac) Wi-Fi frequency band.
The following gives an example of a typical Type
name:
You can view your product’s Declaration of
Conformity (DoC) to Directive 1999/5/EC (to
0168
0168
0168
Type
Name
5
R&TTE Directive) at www.motorola.com/rtte (in
English only). To find your DoC, enter the Type
name from your product’s label in the “Search” bar
on the website.
Regulatory authorities within the EU may obtain compliance information by
writing to: Product Safety and Compliance, Motorola Mobility UK Ltd.,
Redwood, Crockford Lane, Chineham Business Park, Basingstoke,
RG24 8WQ, UNITED KINGDOM.
FCC Notice to Users
FCC Notice
The following statement applies to all products
that bear the FCC logo and/or FCC ID on the
product label.
This equipment has been tested and found to
comply with the limits for a Class B digital device,
pursuant to part 15 of the FCC Rules. See 47 CFR
Sec. 15.105(b). These limits are designed to
provide reasonable protection against harmful
interference in a residential installation. This
equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in
accordance with the instructions, may cause
harmful interference to radio communications.
However, there is no guarantee that interference
will not occur in a particular installation. If this
equipment does cause harmful interference to
radio or television reception, which can be
determined by turning the equipment off and on,
the user is encouraged to try to correct the
interference by one or more of the following
measures:
•Reorient or relocate the receiving antenna.
•Increase the separation between the equipment
and the receiver.
•Connect the equipment to an outlet on a circuit
different from that to which the receiver is
connected.
•Consult the dealer or an experienced radio/TV
technician for help.
This device complies with part 15 of the FCC
Rules. Operation is subject to the following two
conditions: (1) This device may not cause harmful
interference, and (2) this device must accept any
interference received, including interference that
may cause undesired operation. See 47 CFR Sec.
15.19(a)(3).
Motorola has not approved any changes or
modifications to this device by the user. Any
changes or modifications could void the user’s
6
authority to operate the equipment. See 47 CFR
Sec. 15.21.
For products that support Wi-Fi 802.11a/ac (as
defined in product information): Outside the United
States, do not use your device outdoors while
connected to an 802.11a/ac Wi-Fi network. Public
Wi-Fi access points in this range are optimized for
indoor use.
Industry Canada Notice
to Users
Industry Ca nada Notice
This device complies with Industry Canada
licence-exempt RSS standard(s). Operation is
subject to the following two conditions: (1) This
device may not cause interference and (2) This
device must accept any interference, including
interference that may cause undesired operation
of the device. See RSS-Gen, Section 7.1.3. This
device complies with ICES-003 requirements for
Class B ITE (Information Technology Equipment).
CAN ICES-3 (B)/NMB-3(B)
For products that support Wi-Fi 802.11a/ac (as
defined in your product information): Do not use
your product outdoors while connected to an
802.11a/ac network or when using hotspot or
Wi-Fi Direct features in the 5 GHz band. Industry
Canada prohibits outdoor use of Wi-Fi devices
between 5.15 and 5.25 GHz, as this may cause
interference with the Mobile Satellite Service
(MSS).
Use & Care
Use & Care
To care for your Motorola mobile device, please
observe the following:
• Liquids: Don’t expose your mobile device to
water, rain, extreme humidity, sweat, or other
liquids.
• Drying: Don’t try to dry your mobile device using
a microwave oven, conventional oven, or dryer.
•Extreme heat or cold: Don’t store or use your
mobile device in temperatures below -10°C
(14°F) or above 60°C (140°F). Don’t recharge
your mobile device in temperatures below 0°C
(32°F) or above 45°C (113°F).
• Dust and dirt: Don’t expose your mobile device
to dust, dirt, sand, food, or similar materials.
7
• Cleaning: To clean your mobile device, use only
a dry soft cloth. Don’t use alcohol or other
cleaning solutions.
• Shock and vibration: Don’t drop your mobile
device or expose it to strong vibration.
•Protection: To help protect your mobile device,
always make sure that all connector and
compartment covers are closed and secure,
and avoid carrying it with hard objects such as
keys or coins.
Motorola Mobility LLC Global
Limited Warranty
Global Warrant y
What does this Limited Warranty
cover?
Motorola Mobility LLC (“Motorola”) promises to
the original purchaser (“you”) that this Mobile
Phone, and any in-box accessories which
accompany it (the “Products”), will be free of
defects for a period of 12 months from the date of
original purchase (“Warranty Period”) provided
that the Products are used for normal
[consumer/end user] purposes (the “Limited
Warranty”). This Limited Warranty covers only a
purchase of new Products from Motorola or an
authorized reseller or distributor of Motorola
Products and accompanied in-box by this written
Limited Warranty. This Limited Warranty is
personal to you and not transferable. Claims under
this Limited Warranty may only be made in the
country of purchase. If, following a repair, there are
fewer than 90 days remaining in the Warranty
Period, the Warranty Period will be extended to end
90 days from the date of repair.
THE PROMISES MADE TO YOU IN THIS LIMITED
WARRANTY ARE IN ADDITION TO, AND DO NOT
REDUCE OR OTHERWISE AFFECT, YOUR
STATUTORY RIGHTS.
What will we do if you make a claim
under this Limited Warranty?
If you make a valid claim under this Limited
Warranty, Motorola will (at its discretion) either (1)
repair the Product using new, used, or
reconditioned replacement parts; or (2) replace the
Product with a new or ‘as new’ reconditioned
Product; or (3) refund the purchase price. Any
8
refunded or replaced Product shall become the
property of Motorola.
What is not covered?
This Limited Warranty does not cover the
following unless they occurred because of a
defect in materials or workmanship:
(a) Batteries or any protective coatings the
performance of which naturally deteriorates over
time.
(b) Cosmetic damage, including scratches, dents,
cracks or other cosmetic damage from normal
wear and tear.
(c) Damage caused by use with non-Motorola
products. Defects or damage that result from the
use of non-Motorola branded or certified
compatible products, accessories or other
peripheral equipment and/or software.
(d) Damage caused beyond the reasonable control
of Motorola, including damage caused by
(i) accident, abuse, misuse; (ii) operating a Product
outside its permitted or intended uses as defined
in the Products’ User Manual, Quick Start Guide,
Online Tutorials, and other documentation
provided to you (including use of the Products for
[commercial rental] purposes); (iii) improper
storage (e.g. subjecting the Product to extreme
temperatures), abuse or neglect (e.g.
broken/bent/missing clips/fasteners/connectors);
impact damage (e.g. dropping the Product);
(iv) contact with liquids, water, rain, extreme
humidity, unusually heavy perspiration or other
moisture; sand, food, dirt or similar substances
(except for Products sold as resistant to such
substances, but then only to the extent the
damage was not caused by incorrectly securing
the phone’s protective elements or subjecting a
Product to conditions beyond its stated
specifications or limits); or (v) flood, fire,
earthquake, tornado or other acts of God not
within Motorola's reasonable control.
(e) Unauthorized service. Defects or damage
resulting from someone other than Motorola or a
Motorola authorized service center servicing,
testing, adjusting, installing, maintaining, altering,
or tampering with the Products.
(f) Products that have been modified in any
manner without the written permission of
Motorola, including (i) serial numbers, date tags or
9
other manufacturer coding that has been
removed, altered or obliterated; (ii) mismatched or
duplicated serial numbers; (iii) broken seals or
other evidence of tampering; or (iv) which have
been modified or show evidence of attempts to
modify them.
IMPORTANT: IT IS ILLEGAL TO USE THIS
PRODUCT IF IT CEASES TO COMPLY WITH THE
GOVERNMENT AUTHORIZATIONS THAT
APPROVED ITS RELEASE. THEREFORE, YOU
MUST NOT MAKE CHANGES TO THE PRODUCT
AFFECTING ITS EMISSION, MODULATION,
TRANSMISSION CHARACTERISTICS, INCLUDING
POWER LEVELS, OPERATING FREQUENCIES AND
BANDWIDTHS, SAR LEVELS, DUTY-CYCLE,
TRANSMISSION MODES AND THE INTENDED
METHOD OF THE PRODUCT.
(g) Normal wear and tear or otherwise due to the
normal aging of the Product.
(h) Defects, damages, or the failure of the Product
due to any third party communication service or
network you subscribe to or use with the Product.
(i) Software.
What other limitations are there?
•TO THE EXTENT PERMITTED BY APPLICABLE
LAW, MOTOROLA DOES NOT GIVE ANY
WARRANTIES OR MAKE ANY
REPRESENTATIONS, EXPRESS OR IMPLIED, IN
RELATION TO THE PRODUCTS. IN
PARTICULAR, MOTOROLA DOES NOT
WARRANT OR REPRESENT THAT THE
PRODUCTS WILL MEET YOUR
REQUIREMENTS, WORK IN COMBINATION
WITH ANY THIRD PARTY HARDWARE OR
SOFTWARE OR SERVICES, PROVIDE
UNINTERRUPTED OR ERROR-FREE SERVICE,
OR OPERATE WITHOUT RISK OF DATA LOSS.
•YOU SHOULD BE AWARE THAT NO RETAILER
OR OTHER THIRD PARTY IS AUTHORIZED TO
MAKE ANY REPRESENTATIONS ON BEHALF
OF MOTOROLA OR TO MODIFY THIS LIMITED
WARRANTY.
•TO THE EXTENT PERMITTED BY APPLICABLE
LAW, MOTOROLA SPECIFICALLY DISCLAIMS
ANY STATUTORY WARRANTIES WHICH
MIGHT OTHERWISE APPLY.
•TO THE EXTENT PERMITTED BY APPLICABLE
LAW, MOTOROLA SPECIFICALLY DISCLAIMS
10
LIABILITY, WHETHER IN CONTRACT, TORT OR
UNDER OTHER LEGAL THEORY (INCLUDING
NEGLIGENCE), FOR DAMAGES IN EXCESS OF
THE PURCHASE PRICE OF THE PRODUCTS, OR
FOR ANY INDIRECT, INCIDENTAL, SPECIAL OR
CONSEQUENTIAL DAMAGES OF ANY KIND, OR
LOSS OF REVENUE OR PROFITS; LOSS OF
BUSINESS; BUSINESS INTERRUPTION; LOSS
OF OPPORTUNITY; LOSS OF GOODWILL; LOSS
OF REPUTATION; LOSS OF, DAMAGE TO, OR
CORRUPTION OF INFORMATION, DATA,
SOFTWARE OR APPLICATIONS (INCLUDING
ANY COSTS ASSOCIATED WITH RECOVERING,
PROGRAMMING, OR REPRODUCING ANY
INFORMATION, DATA, SOFTWARE, OR
APPLICATIONS STORED ON OR USED WITH
MOTOROLA PRODUCTS); OR OTHER
FINANCIAL LOSS ARISING OUT OF OR IN
CONNECTION WITH THE ABILITY OR
INABILITY TO USE THE PRODUCTS OR
SERVICES PROVIDED UNDER THIS LIMITED
WARRANTY. BY MAKING A CLAIM UNDER
THIS LIMITED WARRANTY YOU
ACKNOWLEDGE THAT YOU UNDERSTAND
THAT.
•SOME JURISDICTIONS DO NOT ALLOW THE
LIMITATION OR EXCLUSION OF CERTAIN
DAMAGES SO THE DISCLAIMERS MAY NOT
LIMIT YOUR LEGAL RIGHTS AGAINST
MOTOROLA. THIS WARRANTY GIVES YOU
SPECIFIC LEGAL RIGHTS. YOU MAY ALSO
HAVE OTHER RIGHTS THAT VARY FROM
JURISDICTION TO JURISDICTION. THIS
LIMITED WARRANTY DOES NOT SEEK TO
TAKE THOSE RIGHTS AWAY UNLESS THE
APPLICABLE LAW ALLOWS YOU TO
CONTRACT OUT OF THOSE RIGHTS.
My Product is defective, what should
Ido?
1. Review the online Motorola customer support
website at www.motorola.com/support for
troubleshooting information.
2. If the Product is still not functioning properly
after you have followed troubleshooting
instructions suggested on this website, please
contact Motorola using the contact details
provided on the customer support website at
www.motorola.com/support.
11
3. If your Product is covered by this Limited
Warranty, you may be required to download, or
otherwise obtain and accept software updates.
You are responsible for any third party data
costs incurred when obtaining the downloads.
Before we can provide any further support under
this Limited Warranty you must first comply
with the warranty processes (1), (2), and (3),
repair instructions, and accept any necessary
software updates.
4. If the software update does not fix the problem,
you will receive instructions on how and where
to ship the Product for assessment. We will
generally need: (i) proof of purchase; (ii) a
written description of the problem; (iii) the name
of your mobile network service provider, if
applicable; (iv) your address and telephone
number. We will only use this information for the
purposes of processing your claim under this
Limited Warranty.
5. If the Product is not covered by this Limited
Warranty (and you do not have any other
statutory rights in your place of usual
residence), Motorola will inform you of the
availability, price, and other conditions
applicable to the repair, replacement, or refund
of the Product.
Copyright & Trademarks
Copyright & Trademarks
Motorola Mobility LLC
222 W. Merchandise Mart Plaza
16th Floor
Chicago, IL 60654
www.motorola.com
Note: Do not ship your product to the above
address. If you need to return your product for
repairs, replacement, or warranty service, please
contact the Motorola Customer Support Center at:
1-800-734-5870 (United States)
1-888-390-6456 (TTY/TDD United States for
hearing impaired)
1-800-461-4575 (Canada)
MOTOROLA and the Stylized M Logo are
trademarks or registered trademarks of Motorola
Trademark Holdings, LLC. Android, Google and
other trademarks are owned by Google Inc. All
other product or service names are the property of
their respective owners.
12
© 2014 Motorola Mobility LLC. All rights reserved.
Caution: Motorola does not take responsibility for
changes/modification to the transceiver.
Manual Number: 68017770001-A
This product meets the applicable national or
international RF exposure guidance (SAR
guideline) when used normally against your
head or, when worn or carried, at a distance of
1.5 cm from the body. The SAR guideline
includes a considerable safety margin designed
to assure the safety of all persons, regardless
of age and health.
