Motorola Mobility T56VE4 Mobile Cellular Phone User Manual 1
Motorola Mobility LLC Mobile Cellular Phone Users Manual 1
Contents
Users Manual 1
![](/img.php?id=3213063&img=bg1.png)
motorola.com
This product meets the applicable national or
international RF exposure guidance (SAR guideline)
when used normally against your head or, when worn
or carried, at a distance of 1.0 cm from the body. The
SAR guideline includes a considerable safety margin
designed to assure the safety of all persons, regardless
of age and health.
To view the SAR values for your phone, visit
https://motorola.com/sar. To view additional SAR
information on your phone, tap Apps > Settings >
Legal information > RF information.
To view the information on the web, visit
www.motorola.com/rfhealth.
en
read me
Caution: Before using your phone, please read the safety,
regulatory and legal information provided with your product.
At a glance
Let’s get started. We’ll guide you through startup and
tell you about your phone.
Note: Software updates happen frequently, so your
phone may look a little dierent.
Front Camera
SIM &
microSD
Card Slots
Power Button
Press:
Display on/o.
Press & hold:
Phone on/o.
Volume
Control
Fingerprint
Sensor
USB/Charger
Microphone
Headset
Jack/
TV Antenna
Port
Back
Camera
Put in the cards
Your phone might support using two SIM cards.
Caution: Make sure you use the correct size
SIM card and don’t cut the SIM card.
Micro SIM
Finish up
Connect your charger to charge your phone fully and
turn the power on. Then select your language and
follow the screen prompts to get started.
For phones that use two SIM cards, follow the
prompts to set them up.
Push tray back into your phone.
P
2
1Put in the nano SIM and memory cards.
Put the SIM cards into the tray
with gold contacts facing up.
Turn tray over to put in an
optional microSD card.
Nano SIM
With phone facing
down, insert the tool
included with your
phone into the hole in
the SIM tray to pop
out the tray.
(optional)
SIM 2
SIM 1
microSD
NOVEMBER 7 2016
FCC
(Optional)
![](/img.php?id=3213063&img=bg2.png)
Home screen & settings
From the home screen, you can explore apps, check
notifications, speak commands, and more.
• Add a shortcut: Tap Apps , tap and hold an app,
then drag it to your home screen.
• Settings: To change your Wi-Fi, display brightness,
and more, swipe the status bar down with two
fingers. To open more settings, tap .
• Share your phone: To add a guest user, swipe the
status bar down with two fingers and tap .
Search by typing or
say "OK, Google".
Tap Apps
to see all your apps.
Swipe down with one
finger for notifications
or with two fingers for
profiles and settings.
Touch and hold an
empty spot to change
widgets, wallpaper, and
more.
Discover your Moto app
Find it: Apps > Moto
• Actions: Your phone responds to your gestures
instantly. Chop twice to turn on the flashlight,
swipe up to shrink the screen, turn over to activate
the do not disturb mode, and more.
• Display: See messages, calls, and other
notifications, even when your phone is asleep.
Touch and hold a notification to see what’s new,
then swipe to take action.
12:36
Note: Your phone may not have all features.
Photos
With two twists of the wrist and a tap on the screen,
take crisp, clear photos.
• Launch it: Even when your phone is asleep, open
your camera with two twists of your wrist.
• See it: Swipe left for your photo gallery.
• Share it: View a photo or video from your gallery,
then tap .
Tip: Swipe right for camera settings and help
information.
GALLERYSETTINGS
Switch to front camera.
Switch to video camera,
slow motion, panorama,
or professional mode.
Tap anywhere to
change the focus.
Tap to take a photo.
Touch and hold to
take multiple shots.
Swipe right for settings.
Help & more
Get answers, updates, and info:
• Help is here: Tap Apps > Device Help to get
walk-through tutorials, how-tos, or FAQs, right on
your phone.
• Everything Moto G: Get software, user guides, and
more at www.motorola.com/mymotog.
• Get apps: Tap Apps > Play Store to buy and
download apps.
• News: Here’s how to find us:
YouTube™ www.youtube.com/motorola
Facebook™ www.facebook.com/motorola
Twitter www.twitter.com/moto
Google+™ www.google.com/+moto
Where is my legal, safety and
regulatory information?
In order to provide you with better access to this
important information, we’ve made the materials
accessible from the phone’s settings menu and on
the web. Review these materials prior to using your
device. To access the materials from a connected
phone, go to Settings > Legal information, and select
a topic. To access the materials on the web, visit
www.motorola.com/device-legal.
Battery Safety
Before assembling, charging or using your mobile device for the first time,
please read the important product safety and legal information provided
with your product.
If your mobile device becomes unresponsive, try a reboot—press and hold
the Power button until the screen goes dark and your device restarts.
For your safety, the battery in your mobile device should only be removed
by a Motorola approved service center or independent qualified professional.
Don’t try to remove or replace the battery yourself—doing so might damage
the battery and could cause burning and injury. Don’t crush, bend, or expose
your mobile device to heat or liquid. This might damage the battery and
could cause burning and injury. Don’t try to dry your mobile device using a
microwave oven, conventional oven, or dryer.
Warning about High Volume
Usage
To prevent possible hearing damage, do not listen at high volume
levels for long periods.
Disposal & Recycling
Help do your part! Please don’t dispose of mobile devices or electrical
accessories (such as chargers, headsets, or batteries) with your
household waste. Product packaging and product guides should
only be disposed of in accordance with national collection and recycling
requirements. For details on approved national recycling schemes and
Motorola recycling activities, go to: www.motorola.com/recycling.
Usage
This phone supports apps and services that could use a lot of data, so make
sure your data plan meets your needs. Contact your service provider for
details. Certain apps and features might not be available in all countries.
Regulatory Information
To view the Regulatory ID (such as FCC ID) for this device, on the phone, go
to Settings > Legal information > Regulatory ID/Markings, or visit
www.motorola.com/device-legal.
Warranty
This product is covered by Motorola’s limited warranty. To review the
warranty on your phone, go to Settings > Legal information > Warranty,
or visit www.motorola.com/device-legal. You may also obtain a copy of
the warranty by contacting Motorola at: Motorola Mobility LLC, Attention
Customer Service--Warranty Request, 222 West Merchandise Mart Plaza,
Suite 1800, Chicago, IL 60654.
Arbitration & opt-out
Except where prohibited by law, any controversy or claim arising out of or
relating to any Motorola product will be resolved by binding arbitration,
instead of in court, unless you opt-out. To opt-out, send a written rejection
notice within 30 days of purchase that includes your name, address, phone
number, device, and device serial number, and tells Motorola that you are
rejecting this Arbitration provision to: Motorola Mobility LLC, 222 West
Merchandise Mart Plaza, Suite 1800, Attn: Arbitration Provision Opt-Out,
Chicago, IL 60654 or arbitrat@motorola.com. For more information on this
arbitration provision, on your phone, go to Settings > Legal information >
Arbitration and Opt-out, or visit www.motorola.com/device-legal .
Legal Disclaimers
Certain features, services and applications are network dependent and
might not be available in all areas; additional terms, conditions and/or
charges might apply. Contact your service provider for details. All features,
functionality, and other product specifications, as well as the information
contained in this guide, are based upon the latest available information and
believed to be correct at the time of printing. Motorola reserves the right
to change or modify any information or specifications without notice or
obligation.
Copyright & Trademarks
MOTOROLA, the stylized M logo, MOTO, and the MOTO family of marks are
trademarks or registered trademarks of Motorola Trademark Holdings, LLC.
LENOVO is a trademark of Lenovo. Google, Android, Google Play and other
marks are trademarks of Google Inc. microSD Logo is a trademark of SD-3C,
LLC. All other product or service names are the property of their respective
owners. © 2016 Motorola Mobility LLC. All rights reserved.
Product ID: Models XT1680, XT1681, XT1683, XT1684, XT1685, XT1686,
XT1687
Manual Number: XXXXXXXXXX
Motorola Mobility LLC
222 W. Merchandise Mart Plaza
Chicago, IL 60654
www.motorola.com
NOVEMBER 7 2016
FCC
