Motorola Mobility T56WE3 Mobile Cellular Phone User Manual User Guide
Motorola Mobility LLC Mobile Cellular Phone User Guide
Contents
- 1. User Manual
- 2. Safety Regulatory and Legal User Manual
User Manual
motorola.com
This product meets the applicable national or
international RF exposure guidance (SAR guideline)
when used normally against your head or, when worn
or carried, at a distance of 1.0 cm from the body. The
SAR guideline includes a considerable safety margin
designed to assure the safety of all persons, regardless
of age and health.
To view the SAR values for your phone, visit
https://motorola.com/sar. To view additional SAR
information on your phone, swipe up > Settings >
Legal information > RF information.
To view the information on the web, visit
www.motorola.com/rfhealth.
read me
Caution: Before using your phone,
please read the safety, regulatory and legal
information provided with your product.
en
At a glance
Let’s get started. We’ll guide you through startup and
tell you about your phone.
Note: Software updates happen frequently, so your
phone may look a little dierent.
2NC[5VQTG&WQ%QPVCEVU)QQING 2NC[5VQTG&WQ%QPVCEVU)QQING
Microphone
Selfie Flash/
Light
Volume
Buttons
Power Button
Press:
Display on/o.
Press & hold:
Phone on/o.
Front
Camera
Back
Home
Recents
Back
Camera
SIM & microSD
Card Slots
(under back cover)
USB/
Charger
Headset
Jack
MON
Remove the back cover & battery
To insert SIM and memory cards, remove the back
cover.
Caution: Don’t use tools to remove the cover—doing
so may damage your phone.
Put in the cards
Your phone might support using two SIM cards.
Caution: Make sure you use the correct size
SIM cards and don’t cut the SIM cards. Don’t
use tools to remove the battery—doing so
may damage your battery or your phone.
Nano SIM
3
1
2
2. SIM 2
1. SIM 1
3. microSD
1. SIM
One SIM card
If your phone uses one SIM card, insert the SIM
card first, then insert the optional microSD card.
2. microSD
(optional)
(optional)
Two SIM cards
If your phone uses two SIM cards, insert the SIMs
first, then insert the optional microSD card.
2
1
Remove the battery.
Take o the back cover.
Finish up
Put on the back cover. Connect your charger to
charge your phone fully, then turn on the power.
Select your language and follow the screen prompts
to get started.
For phones that use two SIM cards, follow the
prompts to set them up.
Charge up & power on.
Press & hold Power
until the screen lights
up.
Note: Fully charge
your phone before
using it.
Put in the battery & put on the cover.
Home screen & settings
From the home screen, you can explore apps, check
notifications, speak commands, and more.
•Add a shortcut: Swipe up , tap and hold an app,
then drag it to your home screen.
•Settings: To change your Wi-Fi, display brightness,
and more, swipe the status bar down with two
fingers. To open more settings, tap .
•Share your phone: To add a guest user, swipe the
status bar down with two fingers and tap .
Search by typing or
say "OK, Google.”
Swipe up to see
all your apps.
Touch and hold an
empty spot to change
widgets, wallpaper,
and more.
$35 021
)QQING 2NC[5VQTG&WQ%QPVCEVU
Swipe down with one
finger for notifications
or with two fingers for
profiles and settings.
Google Duo™
Make and receive video calls with any friend who also
has the Duo app.
Find it: Swipe up > Duo
•Start a new video call: Tap , then tap a name in
your contacts to start the video call.
•Preview incoming calls: Tap > Settings > Knock
Knock.
•Change settings: Tap to change the vibration
setting, block numbers, and more.
9LGHRFDOO
Change settings.
Choose a contact.
Photos
Take crisp, clear photos.
•Launch it: From the lockscreen, open your camera
by swiping up.
•See it: Swipe left for your photo gallery.
•Share it: View a photo or video from your gallery,
then tap .
Tip: Swipe right for eects and settings.
GALLERYSETTINGS
GALLERY
SETTINGS
Switch to front camera.
Switch to video camera
or panorama mode.
Tap anywhere to
change the focus.
Tap to take a photo.
Touch and hold to
take multiple shots.
Swipe right for camera
settings.
Help & more
Get answers, updates, and info:
•Help is here: Swipe up > Device Help to get
walk-through tutorials, how-tos, or FAQs, right on
your phone.
•Everything Moto C Plus: Get software, user guides,
and more at www.motorola.com/mymotoc.
•Get apps: Swipe up > Play Store to buy and
download apps.
•News: Here’s how to find us:
YouTube™ www.youtube.com/motorola
Facebook™ www.facebook.com/motorola
Twitter www.twitter.com/moto
Google+™ www.google.com/+moto
Where is my legal, safety and
regulatory information?
In order to provide you with better access to this
important information, we’ve made the materials
accessible from the phone’s settings menu and on
the web. Review these materials prior to using your
device. To access the materials from a connected
phone, go to Settings > Legal information, and select
a topic. To access the materials on the web, visit
www.motorola.com/device-legal
.
Warranty
This product is covered by Motorola’s limited warranty. To review the
warranty on your phone, go to Settings > Legal information > Warranty,
or visit www.motorola.com/device-legal. You may also obtain a copy of
the warranty by contacting Motorola at: Motorola Mobility LLC, Attention
Customer Service--Warranty Request, 222 West Merchandise Mart Plaza,
Suite 1800, Chicago, IL 60654.
Arbitration & Opt-out
Except where prohibited by law, any controversy or claim arising out of or
relating to any Motorola product will be resolved by binding arbitration,
instead of in court, unless you opt-out. To opt-out, send a written rejection
notice within 30 days of purchase that includes your name, address, phone
number, device, and device serial number, and tells Motorola that you are
rejecting this Arbitration provision to: Motorola Mobility LLC, 222 West
Merchandise Mart Plaza, Suite 1800, Attn: Arbitration Provision Opt-Out,
Chicago, IL 60654 or arbitrat@motorola.com. For more information on this
arbitration provision, on your phone, go to Settings > Legal information >
Arbitration and opt-out, or visit www.motorola.com/device-legal.
Legal Disclaimers
Certain features, services and applications are network dependent and
might not be available in all areas; additional terms, conditions and/or
charges might apply. Contact your service provider for details. All features,
functionality, and other product specifications, as well as the information
contained in this guide, are based upon the latest available information and
believed to be accurate at the time of printing. Motorola reserves the right to
correct, change or modify any information or specifications without notice
or obligation.
Copyright & Trademarks
MOTOROLA, the stylized M logo, MOTO, and the MOTO family of marks
are trademarks or registered trademarks of Motorola Trademark Holdings,
LLC. LENOVO is a trademark of Lenovo. Google, Android, Google Play and
other marks are trademarks of Google Inc. microSD Logo is a trademark
of SD-3C, LLC. All other product or service names are the property of their
respective owners.
© 2017 Motorola Mobility LLC. All rights reserved.
Product ID: Moto C Plus (Model XT1721, XT1723, XT1724, XT1725)
Manual Number: XXXXXXXXXX
Motorola Mobility LLC
222 W. Merchandise Mart Plaza
Chicago, IL 60654
www.motorola.com
Battery Safety
Before assembling, charging or using your mobile device for the first time,
please read the important product safety and legal information provided
with your product.
If your mobile device becomes unresponsive, try a reboot—press and hold
the Power button until the screen goes dark and your device restarts. Your
mobile device uses a removable battery. Only use Motorola Original batteries
for safety and best performance.
Warning:
• Don’t use tools, sharp objects, or excessive force to insert or remove
the battery. This may damage the battery and could cause burning and
injury.
• Don’t try to take apart or fix your battery. This may damage the battery
and could cause burning and injury.
• Don’t crush, bend, or expose your battery or mobile device to heat or
liquid. This may damage the battery and could cause burning and injury.
• Don’t try to dry your mobile device using a microwave oven,
conventional oven, or dryer.
Warning about High Volume
Usage
To prevent possible hearing damage, do not listen at high volume
levels for long periods.
Disposal & Recycling
Help do your part! Please don’t dispose of mobile devices or electrical
accessories (such as chargers, headsets, or batteries) with your
household waste. Product packaging and product guides should
only be disposed of in accordance with national collection and recycling
requirements. For details on approved national recycling schemes and
Motorola recycling activities, go to: www.motorola.com/recycling.
Usage
This phone supports apps and services that could use a lot of data, so make
sure your data plan meets your needs. Contact your service provider for
details. Certain apps and features may not be available in all countries.
Regulatory Information
To view the Regulatory ID (such as FCC ID) for this device, on the phone, go
to Settings > Legal information > Regulatory information, or visit
www.motorola.com/device-legal.
