Introduction 1English
Introduction
Welcome
Thank you for choosing your Motorola phone from a global leader in communications
technology. All Motorola digital cellular phones are designed and manufactured to
meet Motorola’s rigorous specifications and world-class quality standards. During
development, our laboratory testing team took your cellular phone through rigorous
durability tests including temperature, humidity, shock, dust, vibration, and drop
tests—and the phone still worked!
We are confident that the phone you purchased will meet your own exacting standards.
Enjoy your Motorola phone.
PHONE GRAPHIC TO BE SUPPLIED
OR ON INSIDE OF FRONT COVER
m3td_us.bk : intro.fm5 Page 1 Thursday, November 18, 1999 9:46 PM
Introduction
2
English
Understanding this Manual
Many of your phone options are accessed by a simple menu
system. A full description of the menus and how to move around
them is covered in the next section Menu Navigation. When
the manual describes the use of each menu item, it will be
assumed that you are familiar with the menu system.
Key Presses
Key presses are represented in this manual using symbols so that
you may locate and use the required sequence quickly. A
sequence of key presses may be shown as follows:
Ä â 7 C
This means you should press Ä followed by â, 7, and
then C, in sequence, not simultaneously.
Prompts and Messages
Your phone responds to key presses by displaying either easy to
understand prompts that guide you to the next action, or simple
messages confirming that your action is complete. Prompts and
messages are represented in this manual in LCD style, for
example:
Enter 1st Letter or Location __
Other Symbols
You will find the following symbols used throughout this manual:
AA Note contains additional information which is relevant to
the feature/item.
!A Caution contains important additional information
which is relevant to the efficient and/or safe usage of
your phone.
iThis symbol indicates a short key sequence for the feature.
m3td_us.bk : intro.fm5 Page 2 Thursday, November 18, 1999 9:46 PM
Introduction 3
English
Menu Navigation
A large number of your phone's options are accessed by using
menus which use a common approach for selection, change and
cancellation.
Please read this section carefully before attempting to access a
menu option. When you understand the common approach to
menu navigation and how the menus are shown on the page,
you will be able to access and change options with ease.
Menus and Sub-menus
A menu is a simple list of options. Some of these options provide
access to a further list of options called a sub-menu. When
navigating through the menus you may find it is helpful to think
in terms of menu levels - the ‘parent’ menu being on one level
and its sub-menus being on a lower level.
Navigating the Menus
Press Ä, then press A to access the menu. You can also enter
the menu system by pressing Ä Ú.
You can navigate through the menu system using the volume
keys located on the left side of the phone and the Smart Button
located on the right side of the phone. Use the upper and lower
volume keys to scroll to sub-menus. Use the Smart Button to
choose menus and functions.
Follow these symbols as a guide for using the keys on the side of
your phone:
Press q to scroll up.
Press Z to scroll down.
Press A to select.
You can also use your phone’s Ç and È keys to scroll
through the menu system.
Leaving the Menus
Press ¼ to exit the menu.
Menu Options with Security Codes
Some options are protected from misuse by requiring you to
entry one of the security codes. To use these options, you must
enter the requested code before proceeding.
m3td_us.bk : intro.fm5 Page 3 Thursday, November 18, 1999 9:46 PM
Introduction
4
English
Total Customer Satisfaction
At Motorola, Total Customer Satisfaction is a top priority. If you
have a question, a suggestion or a concern about your Motorola
Cellular Phone, Motorola wants to hear from you.
Please contact the Motorola Cellular Response Center by fax on:
+44 (0) 131 458 6732, or use one of the local phone numbers in
the following countries:
Austria 0800 297246
Belgium 0800 72 370
Czech Republic 00420 2 21 85 21 01
Denmark 4348 8005
Egypt 02 3411800
Eire 01 402 6887
Finland 0800 117 036
France 0 803 303 302
Germany 0180 35050
Greece 00800 441 28150
Italy 02 696 333 16
Jordan 06 863750
Kuwait 484 2000 Ext 1177
Lebanon 01 744156
Luxembourg 0800 21 99
Netherlands 0800 022 27 43
Norway 22 55 10 04
Oman 790925
Portugal 01 318 0051
Qatar 418999
Saudi Arabia 01 2303294
South Africa 0800 11 48 49
Spain 902 100 077
Sweden 08 445 1210
Switzerland 0800 553 109
Turkey 0212 425 9090
UK 0500 55 55 55
United Arab Emirates 04 32 11 66
Hong Kong 852 25063888
People’s Republic of China 86 10 68466060
Singapore 65 4855 333
Taiwan 886 2 87731746
United States of America 1 800 331 6456
Canada 1 800 461 4575
For e-mail questions contact:mcrc@ei.css.mot.com
For Internet questions contact:http://www.mot.com
m3td_us.bk : intro.fm5 Page 4 Thursday, November 18, 1999 9:46 PM
Contents 5English
Contents
Safety
Important information for the efficient and safe operation of your phone ................................................................................7
About Your Phone and Battery
Introduces your phone, explains how to charge and maintain batteries...................................................................................13
Using Your Phone
Explains how to place calls, how to redial, how to end a call, and how to use the phone memory .......................................19
Using the Menu Features
Provides an explanation of the Menu Features and how to use them.......................................................................................25
Using the Message Center
Provides an explanation of the Message Center and how to use it ...........................................................................................51
Accessories
Details the accessories available for use with your phone..........................................................................................................57
What to do if...
Helps you to solve any problems that may occur.........................................................................................................................59
Index
A comprehensive Index ..................................................................................................................................................................69
The Manufacturer reserves the right to make changes in technical and product specifications without prior notice.
m3td_us.bk : toc.fm5 Page 5 Thursday, November 18, 1999 9:46 PM
Contents
6
English
m3td_us.bk : toc.fm5 Page 6 Thursday, November 18, 1999 9:46 PM
Safety 7
English
Safety
Wireless Phone Safety Tips
“Safety is your most important call!”
Your Motorola wireless telephone gives you the powerful ability
to communicate by voice - almost anywhere, anytime, wherever
wireless phone service is available and safe conditions allow. But
an important responsibility accompanies the benefits of wireless
phones, one that every user must uphold.
When driving a car, driving is your first responsibility. If you find it
necessary to use your wireless phone while behind the wheel of a
car, practice good common sense and remember the following
tips:
1. Get to know your Motorola wireless phone and its features
such as speed dial and redial. If available, these features help
you to place your call without taking your attention off the
road.
2. When available, use a hands-free device. If possible, add an
additional layer of convenience to your wireless phone with
one of the many Motorola Original hands-free accessories
available today.
3. Position your wireless phone within easy reach. Be able to
access your wireless phone without removing your eyes from
the road. If you receive an incoming call at an inconvenient
time, if possible, let your voice mail answer it for you.
4. Let the person you are speaking with know you are driving; if
necessary, suspend the call in heavy traffic or hazardous
weather conditions. Rain, sleet, snow, ice, and even heavy
traffic can be hazardous.
5. If you receive an incoming call at an inconvenient time do not
take notes or look up phone numbers while driving. Jotting
down a “to do” list or going through your address book takes
attention away from your primary responsibility—driving
safely.
6. Dial sensibly and assess the traffic; if possible, place calls when
you are not moving or before pulling into traffic. Try to plan
calls when your car will be stationary. If you need to make a
call while moving, dial only a few numbers, check the road
and your mirrors, then continue.
7. Do not engage in stressful or emotional conversations that
may be distracting. Make people you are talking with aware
you are driving and suspend conversations which have the
potential to divert your attention away from the road.
8. Use your wireless phone to call for help. Dial 9-1-1 or other
local emergency number in the case of fire, traffic accident or
medical emergencies.1
9. Use your wireless phone to help others in emergencies. If you
see an auto accident, crime in progress or other serious
emergency where lives are in danger, call 9-1-1 or other local
emergency number, as you would want others to do for you.1
10. Call roadside assistance or a special non-emergency wireless
assistance number when necessary. If you see a broken-down
vehicle posing no serious hazard, a broken traffic signal, a
minor traffic accident where no one appears injured, or a
vehicle you know to be stolen, call roadside assistance or
other special non-emergency wireless number.1
1. Wherever wireless phone service is available.
m3td_us.bk : safety.fm5 Page 7 Thursday, November 18, 1999 9:46 PM
Safety
8
English
Check the laws and regulations on the use of wireless telephones
and their accessories in the areas where you drive. Always obey
them. The use of these devices may be prohibited or restricted in
certain areas.
For more information, please call 1-888-901-SAFE or visit the
CTIA website at www.wow-com.com ™ .
m3td_us.bk : safety.fm5 Page 8 Thursday, November 18, 1999 9:46 PM
Safety 9English
Hand-Held Portable PCS Telephone
IMPORTANT
Read this information before using
your PCS Telephone
Exposure To Radio Frequency Signals
Your wireless handheld portable telephone is a low power radio
transmitter and receiver. When it is ON, it receives and also sends
out radio frequency (RF) signals.
In August 1996, the Federal Communications Commission (FCC)
adopted RF exposure guidelines with safety levels for hand-held
wireless phones. Those guidelines are consistent with the safety
standards previously set by both U.S. and international standard
bodies:
•ANSI C95.1 (1992)1
•NCRP Report 86 (1986)1
•ICNIRP (1996)1
1. American National Standard Institute: National Council on radiation
Protection and Measurements; International Commission on Non-
Ionizing Radiation Protection
These standards are based on comprehensive and periodic
evaluations of relevant scientific literature. For example, over 120
scientists, engineers and physicians from universities, government
health agencies and industry reviewed the available body of
research to develop the updated ANSI Standard (C95.1).
The design of your phone complies with the FCC guidelines (and
these standards).
Antenna Care
Use only the supplied or approved replacement antenna.
Unauthorised antennas, modifications or attachments could
damage the phone and may violate FCC regulations.
Phone Operation
Normal Position: Hold the phone as you would any other
telephone with the antenna pointed up and over your shoulder.
Tips on Efficient Operation: For your phone to operate most
efficiently:
•Extend your antenna fully (if applicable).
•Do not touch the antenna unnecessarily when the phone is in
use. Contact with the antenna affects call quality and may
cause the phone to operate at a higher power level than
otherwise needed.
m3td_us.bk : safety.fm5 Page 9 Thursday, November 18, 1999 9:46 PM
Safety
10
English
Batteries
!All batteries can cause property damage, injury or burns
if a conductive material such as jewelry, keys or beaded
chains touches exposed terminals. The material may
complete an electrical circuit and become quite hot. To
protect against such unwanted current drain, exercise
care in handling any charged battery, particularly when
placing it inside your pocket, purse or other container
with metal objects. When the battery is detached from
the phone, your batteries are packed with a protective
battery cover; please use this cover for storing your
batteries when not in use.
Driving
Check the laws and regulations on the use of wireless telephones
in the areas where you drive. Always obey them. Also, if using
your phone while driving, please:
•give full attention to driving - driving safely is your first
responsibility
•use hands-free operation, if available
•pull off the road and park before making or answering a call if
driving conditions so require.
Electronic Devices
Most modern electronic equipment is shielded from RF signals.
However, certain electronic equipment may not be shielded
against the RF signals from your wireless phone.
Pacemakers
The Health Industry Manufacturers Association recommends that
a minimum separation of six (6”) inches be maintained between
a handheld wireless phone and a pacemaker to avoid potential
interference with the pacemaker. These recommendations are
consistent with the independent research by and
recommendations of Wireless Technology Research.
Persons with pacemakers:
•Should ALWAYS keep the phone more than six inches from
their pacemaker when the phone is turned on.
•Should not carry the phone in a breast pocket.
•Should use the ear opposite the pacemaker to minimise the
potential for interference.
If you have any reason to suspect that interference is taking
place, turn your phone OFF immediately.
Hearing Aids
Some digital wireless phones may interfere with some hearing
aids. In the event of such interference you may want to consult
your hearing aid manufacturer to discuss alternatives.
Other Medical Devices
If you use any other personal medical device, consult the
manufacturer of your device to determine if they are adequately
shielded from external RF energy. Your physician may be able to
assist you in obtaining this information.
Turn your phone OFF in health care facilities when any
regulations posted in these areas instruct you to do so. Hospitals
or health care facilities may be using equipment that could be
sensitive to external RF energy.
m3td_us.bk : safety.fm5 Page 10 Thursday, November 18, 1999 9:46 PM
Safety 11 English
Vehicles
RF signals may affect improperly installed or inadequately
shielded electronic systems in motor vehicles. Check with the
manufacturer or its representative regarding your vehicle. You
should also consult the manufacturer of any equipment that has
been added to your vehicle.
Posted Facilities
Turn your phone OFF in any facility where posted notices so
require.
Aircraft
FCC regulations prohibit using your phone while in the air.
Switch OFF your phone before boarding an aircraft.
Blasting Areas
To avoid interfering with blasting operations, turn your phone
OFF when in a “blasting area” or in areas posted: “turn off two-
way radio”. Obey all signs and instructions.
Potentially Explosive Atmospheres
Turn your phone OFF and do not remove the battery when in any
area with a potentially explosive atmosphere and obey all signs
and instructions. Sparks, from your battery, in such areas could
cause an explosion or fire resulting in bodily injury or even death.
Areas with a potentially explosive atmosphere are often, but not
always clearly marked. They include fueling areas such as
gasoline stations; below deck on boats; fuel or chemical transfer
or storage facilities; areas where fuel odors are present, i.e. if a
gas/propane leak occurs in a car or home; areas where the air
contains chemicals or particles, such as grain, dust, or metal
powders; and any other area where you would normally be
advised to turn off your vehicle engine.
For Vehicles Equipped with an Air Bag
An air bag inflates with great force. DO NOT place objects,
including both installed or portable wireless equipment, in the
area over the air bag or in the air bag deployment area. If in-
vehicle wireless equipment is improperly installed and the air bag
inflates, serious injury could result.
m3td_us.bk : safety.fm5 Page 11 Thursday, November 18, 1999 9:46 PM
Safety
12
English
m3td_us.bk : safety.fm5 Page 12 Thursday, November 18, 1999 9:46 PM
About Your Phone and Battery 13 English
About Your Phone and Battery
Phone Overview
See the inside front cover of this manual for a diagram of the
components described below.
Fixed Antenna—Provides superior connectability.
Earpiece—Ultra-compact phone speaker.
Power Connector Port—Provides the connections for an
external power supply and vehicular accessories.
Headset Jack—Provides the connection for an optional headset.
Microphone—Positioned for convenient conversation.
Function Keys
Á—Turns the phone On and Off.
Ä—Acts as a “shift” key to access the secondary functions of
other keys.
ä—Recalls phone numbers from memory.
—Stores phone numbers into memory.
C—Clears characters from the screen.
¼—Ends phone calls.
¾—Places or answers calls.
Ç and È—Can be used to scroll through memory entries
and menu features.
¿ Message Center Button—Allows access to digital
messages and voice mail messages.
A Smart Button—Use the Smart Button to recall information
from memory, place and end calls, select menu features, and
toggle features on and off. The symbol § in your display
represents the Smart Button.
qZ Volume Keys—The upper and lower volume keys can adjust
keypad, earpiece, and ringer volume. After pressing the Smart
Button, the volume keys also scroll through memory entries and
menu features.
Using the Smart Button
Use the Smart Button to place and end calls, enter menus, toggle
features on and off, and select items in the display. The Smart
Button is on the right side—easy to feel, easy to find, and easy to
use.
The symbol § in your display represents the Smart Button.
Selecting Items in the Display
The most basic use of the Smart Button is for making selections.
Whenever you are given a choice such as a ringer setting, press
the Smart Button to select the setting you want.
Toggling Features On and Off
Some of your phone’s features toggle on and off. Use the upper
or lower volume key to scroll to the desired feature, then press
the Smart Button to select it.
Entering the Menu System
Press Ä, then press A to access the menu. You will see Recent
Calls.
AYou can also enter the menu system by pressing Ä Ú.
m3td_us.bk : abtphone.fm5 Page 13 Thursday, November 18, 1999 9:46 PM
About Your Phone and Battery
14
English
Placing and Ending a Call
You can use the Smart Button to place and end a call, as
described in “Using Your Phone” on page 19.
Controlling Volume
Use the upper and lower volume keys to adjust earpiece, keypad,
and ringer volume. When you press these keys, the phone’s
speaker demonstrates the current volume level.
To adjust earpiece volume during a phone call:
Press qZ to raise or lower the volume.
To adjust the ringer volume and keypad while not in a
phone call
Press qZ to raise or lower the volume.
The Display
The display on your phone can show alphanumeric characters as
well as useful information symbols.The various elements of the
display are as follows:
1. rx Signal Strength. The more segments
displayed in the bar graph, the better the
signal strength.
1
2
34567
8
2. D Digital Indicator. If you are in a digital
coverage area, the digital indicator appears.
Your phone operates more efficiently in
Digital mode.
3. IU In Use Indicator. Displayed when a call is in
progress.
4. nIn-Building Indicator. The In-Building
Indicator lights when the phone accesses an
In-Building Cellular System or other non-
public system.
5. NS No Service Indicator. If you travel beyond
the range of a cellular system, the No Service
Indicator appears to let you know that calls
cannot be placed or received from your
location.
6. oShort Message Service. Displayed when
the phone has received a message. The
symbol will flash when your message storage
area is full.
7. pVoicemail Waiting Indicator. Displayed
when you have a voice message waiting. The
availability of this feature depends on your
service provider.
8. qBattery Charge Indicator. The more
segments displayed, the greater the battery
charge.
m3td_us.bk : abtphone.fm5 Page 14 Thursday, November 18, 1999 9:46 PM
About Your Phone and Battery 15 English
Your Battery
Installing the Batteries
New batteries are supplied uncharged and fitted within a
protective battery carrier. To remove the batteries, press the
release catch on the battery carrier and open the cover.
To install the batteries in your phone:
1Press the release catch of the phone battery cover and slide
the battery cover towards the bottom of the phone.
2Align the positive and negative (+ and -) connections on the
battery with the positive and negative (+ and -) connections
within the phone.
3Press the battery towards the connections and push it
downwards until it clicks into place.
4Replace the phone battery cover.
Important Battery Information
!Always treat your batteries with care. See ‘Batteries’, at
the beginning of this manual.
!Never leave your battery in extremely high
temperatures (over 60°C), for example behind glass in
very hot, direct sunlight.
!Only Motorola Original Accessory batteries can be
charged in the phone. This is to protect you and your
phone from the risks of incorrect charging.
Charging a New Battery
New batteries are supplied in a totally uncharged state.
To ensure maximum battery performance, a new battery (or
battery that has not been used for several months) should be
charged for at least 14 hours before use.
AA new battery will require several full charge/discharge
cycles in order to achieve its optimum performance.
AA new battery, or a battery that has not been used for
several months, may cause a premature fully charged
indication. Ignore this indication and let the battery charge
for several more hours, remove and re-insert the battery
into the charger, and charge for an additional 14 hours.
!Your batteries will not charge if they are not matched
properly to the phone connection markings (+ and -).
Please ensure that you have installed the batteries
properly before initiating a charge.
m3td_us.bk : abtphone.fm5 Page 15 Thursday, November 18, 1999 9:46 PM
About Your Phone and Battery
16
English
To ensure that you enjoy maximum battery life and use your
battery to its fullest capacity:
•The battery should be at or near room temperature when
charging.
Battery Performance and Maintenance
•Best battery performance will be achieved when you regularly
charge and discharge batteries as instructed in this manual.
•Battery performance is greatly affected by network coverage.
•If left unused, a fully charged battery will discharge itself in
approximately one month.
•When not in use, store your battery uncharged in a cool, dark
and dry place.
Removing Your Batteries
!Switch off your phone before removing batteries.
Failure to do so may damage your phone memory.
1Press the release catch of the phone battery cover and slide
the battery cover towards the bottom of the phone.
2Remove the batteries.
m3td_us.bk : abtphone.fm5 Page 16 Thursday, November 18, 1999 9:46 PM
About Your Phone and Battery 17 English
Charging Your Battery Using the Travel
Charger
The travel charger can power the phone and charge a fitted
battery.
!Ensure that the local mains voltage at your location
matches that of your travel charger.
Install the batteries into your phone (see ’Installing the Batteries’).
To charge your battery:
1Attach the correct adapter plug to the travel charger.
2Connect the travel charger to the phone.
3Insert the travel charger plug into a suitable mains power
socket.
A beep-tone is heard and the battery icon flashes when charging
begins.
AThe beep-tone on the phone will not occur if the batteries
are installed improperly. The beep-tone may take two
minutes to occur with new or fully drained batteries.
The state of charging is monitored and displayed by your phone.
See ‘Battery Meter Indicators’ later in this section for details.
Low Battery Warning
When the battery level is low and only a few minutes of talk time
remain, a warning signal (two double beeps) will sound, and Low
Battery will be displayed.
For a detailed battery level reading: Press Ä Ý.
The more segments filled on the battery gauge (Bx), the
greater the charge.
When the battery is completely discharged, your phone will turn
off.
m3td_us.bk : abtphone.fm5 Page 17 Thursday, November 18, 1999 9:46 PM
About Your Phone and Battery
18
English
Battery Indicators
Your phone monitors and displays information about your
battery. The following message will appear on the display, as the
condition occurs:
Battery Meter Indicators
The battery meter displays different messages depending on the
batteries attached, and whether or not there is an external power
source. The battery meter is found in the Call Related Features
part of the Options Menu.
AWhen the battery is completely discharged, you must
charge the battery for one minute before you can make or
accept a phone call.
Low Battery The battery charge is low. The battery should
be recharged.
Charging
Battery
The battery is being charged.
Charging
Complete
Charging is complete.
m3td_us.bk : abtphone.fm5 Page 18 Thursday, November 18, 1999 9:46 PM
Using Your Phone 19 English
Using Your Phone
Placing and Receiving Calls
To turn the phone on, press and hold Á until the display
appears and you hear an audible alert.
Press and hold Á again to turn the phone off. Powering off
will be displayed, and you will hear an audible alert.
What You Will See
When you turn on your phone, it performs a self-test to let you
know it is operational. When the test is completed, the display
shows:
•one of several possible greetings, such as:
- the name of your Service Provider
or
- an indication of local or non-local coverage area
•your phone number
•the Digital or Analog icon
Placing a Call
To place a call:
1Turn the phone on.
2Enter the number you want to call.
If you make a mistake, press C to erase one digit at a time.
Press and hold C to clear the entire entry.
You can also recall a previously dialed or stored number. (See
“Using Phone Memory” on page 21 for details on storing or
recalling.)
3Press and hold A until you hear a second tone.
or
Press ¾ to place the call.
You will hear a single-tone alert (if the keypad tones are
turned on) and see Dialing XXXXXXX.
4You can dial phone numbers with up to 32 digits, but only the
last 20 digits appear in the display.
Press ä to see the entire phone number.
Ending a Call
To end a call: Press ¼.
or
1Press and hold A until you hear a second tone.
You will see Press § To End Call.
2Press A again to end the call.
Receiving a Call
Your phone must be powered on to receive calls.
Press ¾.
Unanswered Call Indicator
When you cannot take a call, your phone keeps a count of your
unanswered calls and alerts you with the message Missed XX
Calls, where XX is the number of missed calls.
Press A to view missed calls.
m3td_us.bk : usephone.fm5 Page 19 Thursday, November 18, 1999 9:46 PM
Using Your Phone
20
English
Redialing a Number
A fast busy signal indicates that the cellular system is busy. With
Automatic Redial, your phone calls continuously for the next four
minutes.
When it makes a connection, the phone rings. You can
distinguish this ring because it is half as long as the ring for a new
incoming call. When the person you are calling answers, you can
begin talking.
If you hear a fast busy signal:
1You will see Redial Call?
Press A or press ¾ to redial, or press ¼ to exit.
2If the call does not go through after four minutes, press A, or
press ¾ to continue the call attempt.
You will see Redial.
If you hear an ordinary busy signal:
1Press ¼ to hang up.
2Press A or press ¾ to redial the busy number.
You will see Dialing 5551234.
Muting the Microphone
For privacy during a call, mute the microphone. You can hear the
person on the other end, but he or she cannot hear you.
1Press Ä ß to mute the microphone. You will see Mute.
2Press Ä ß again to resume normal conversation.
Switching Between Digital and Analog
Modes
During a call, you can switch from digital to analog modes, or
from analog to digital:
To switch modes, press Ä Û.
Your phone selects the TDMA digital system, depending upon
availability, or the analog system.
m3td_us.bk : usephone.fm5 Page 20 Thursday, November 18, 1999 9:46 PM
Using Your Phone 21 English
Using Phone Memory
Use your phone’s internal Phone Book to store up to 99 names
and numbers for easy access.
In this section you will learn how to:
•store names and numbers into the Phone Book
•recall phone numbers from memory
•clear names and numbers
•dial a number with Speed Dial and Turbo Dial™
•make notes on the scratchpad
Using Your Phone’s Built-in Phone Book
Each phone number in your phone book is stored in a memory
location numbered 01-99.
Arrange numbers for easy recall by storing related numbers in
groups. If you store the numbers you call most in locations 01-
09, then you can use Turbo Dial™ to call those numbers with a
single key. (See “Using the Turbo Dial™ Function” on page 23
for details.)
You can also store names to identify phone numbers. Later, you
can recall a number by the name that corresponds to it.
Storing Names and Numbers
How to Store Phone Numbers
1Enter the phone number you want to store.
AYou can store up to 32 digits per phone number entry.
2Press  to begin storing.
The phone prompts you to enter a memory location. You will
see Location __.
3Enter the two-digit memory location where you want the
sequence stored.
or
Press Ç to store the sequence in the first available location.
or
Enter the first digit of the memory location, then press Ç to
store the sequence in the first available location beginning
with that digit.
You will see Alpha Or §.
AThe § symbol in your display represents the Smart Button.
4Enter a name to identify the phone number. (See the
following section for details on entering names.)
5Press A or  when you finish entering the name.
Your phone confirms your entry by displaying the information
you stored.
m3td_us.bk : usephone.fm5 Page 21 Thursday, November 18, 1999 9:46 PM
Using Your Phone
22
English
How to Enter Letters and Numbers
When the display shows Alpha Or §, you can press the numeric
keys one or more times to produce any letter or number in the
alphabet. Use the letters printed on each key as a guide. For
example, press Û to enter “A,” “B,” “C,” or “2” as shown:
How to Enter a Name
APress the upper or lower volume key first, to toggle
between upper and lower case letters.
1Enter a letter by pressing a key as many times as necessary.
Enter punctuation by pressing Ú as many times as indicated
by the chart below. Pressing Ú a single time produces a
single space.
The cursor advances automatically to the next space after you
enter a letter or after three seconds of inactivity. If you are
repeating a character, then press È to advance the cursor
to the next space.
2Press Ç or C to erase a letter if you make an error.
3Press A or  when you finish entering the name.
Your phone confirms your entry by displaying the information
you stored.
Recalling an Entry by Name
After storing names and numbers, you can recall them
alphabetically and immediately place calls. Use the Smart Button
for instant access to the name directory.
1Press A once to enter your name directory.
2Press qZ to scroll to the name you are looking for.
or
Enter the first letter of the name you want to recall. The
display shows the first name in the phone book that begins
with that letter. If no entry beginning with that letter is found,
No A s is displayed.
When the name is displayed, the corresponding number is
displayed on a third line, and the phone memory location is
displayed in the upper right corner.
3Press and hold A, or press ¾, to call the number you
selected.
Recalling an Entry by Memory Location
Each name and number you store is placed in a memory location
numbered 01-99. Once you have stored names and numbers,
you can recall them by memory location:
1Press ä.
2Enter the two-digit memory location of the phone number
you want.
3Press and hold A, or press ¾ to call the number you
selected.
2345678910
1
m3td_us.bk : usephone.fm5 Page 22 Thursday, November 18, 1999 9:46 PM
Using Your Phone 23 English
Clearing a Phone Memory Entry
Clearing an Entry by Name
1Recall by name the entry that you want to erase. (See
“Recalling an Entry by Name” on page 22.)
2Press C to clear the entry.
You will see Clear Entry?.
3Press A or  to confirm that you want to erase the entry.
The numbered location of the cleared entry is shown in the
display.
Clearing an Entry by Location Number
1Recall by location the entry that you want to erase.
2Press C to clear the display.
3Press  and the location you want to clear.
You will see XX Full Change?
4Press  to confirm that you want to erase the entry.
Shortcuts for Recalling Phone Book Entries
Using Speed Dial
If you know the memory location of the number you want to call,
try the Speed Dial function:
1Enter the two-digit memory location (01-99).
2Press and hold A, or press ¾ to place the call.
Using the Turbo Dial™ Function
The Turbo Dial™ function enables you to dial numbers stored in
locations 01-09 with the push of a single button:
Press and hold a number Ú through á on the keypad,
and your call is placed. You will hear a two-tone alert
afterwards.
Your phone’s Priority Call feature gives you fast access to any
number stored in location 01. To learn more about this feature,
see “Activating Priority Calling” on page 42.
Making Notes on the Scratchpad
In addition to your internal phone book, you also have a built-in
scratchpad for making quick notes. The scratchpad remembers
the last phone number shown on your display.
Entering a Number in the Scratchpad
If you are on the phone and your party gives you another number
to call, enter the number on the scratchpad so you can place the
call later.
1Enter the number into the keypad. (The person on the line can
hear tones as you dial.)
2Press ¼ to end the current call, if necessary.
3Press ¾ to call the number you saved on the Scratchpad.
Storing Numbers During a Call
You can also store numbers during a call:
1Enter the number into the keypad. (The person on the line can
hear tones as you dial.)
2Press  and continue storing with step 3 in “Storing Names
and Numbers” on page 21.
m3td_us.bk : usephone.fm5 Page 23 Thursday, November 18, 1999 9:46 PM
Using Your Phone
24
English
m3td_us.bk : usephone.fm5 Page 24 Thursday, November 18, 1999 9:46 PM
Using the Menu Features 25 English
Using the Menu Features
Using the Menu System
Your cellular phone includes many features to help you be more
productive. The phone’s user-friendly menu system helps you
find what you need quickly and easily.
In this section you will learn:
•what are the main menu features
•how to navigate through the menus
•how to read a menu road map
Introducing the Menu Features
As you scroll through the menu system, you will see the following
icons, each representing a high-level menu.
Navigating the Menu
You can navigate through the menu system using the volume
keys located on the left side of the phone and the Smart Button
located on the right side of the phone. Use the upper and lower
volume keys to scroll to sub-menus. Use the Smart Button to
choose menus and functions.
Follow these symbols as a guide for using the keys on the side of
your phone:
Press q to scroll up.
Press Z to scroll down.
Press A to select.
You can also use your phone’s Ç and È keys to scroll
through the menu system.
Road Maps
To help you navigate through the phone’s menu system, each
section begins with an easy-to-follow visual “road map.” To
enter the menu features:
1Press Ä, then press A
or
Press Ä Ú. “menu” is printed on the Ú key as a
reminder.
2Press qZ to scroll through the menu’s top level
3Press ¼ to exit the menu.
Detailed instructions within each section describe how each
feature works.
Tone
Recent Calls
Phone Book
Lock Secure Phone Options
Timers
m3td_us.bk : opt_menu.fm5 Page 25 Thursday, November 18, 1999 9:46 PM
Using the Menu Features
26
English
Managing Recent Calls
The recent calls menu option allows you to access your Caller
Line ID and review previous calls.
In this section you will learn how to review all calls that you have
received or dialed.
Start:
About Recent Calls
The Recent Calls menu allows you to review previous calls that
you have received or dialed. Following are some useful tips and
information about reviewing recent calls.
•Your cellular phone can store the telephone numbers and
names of the last thirty incoming calls.
•If the caller’s phone number matches a phone number stored
in the phone’s memory, the phone automatically displays the
name associated with that phone number.
•If you subscribe to call waiting and receive a call while another
call is in progress, you hear a call waiting tone, and the caller’s
name and number appear on the display. The name and
number are automatically stored and can be viewed after
ending the call, using the procedure described in “Reviewing
Received Call” on page 27.
•Caller Line ID allows you to view the name and number of the
calling party in the phone’s display while the phone is ringing.
Caller Line ID is an optional feature that is not available in all
markets. Contact your Service Provider for availability
information.
•If the caller has restricted transmission of the phone number,
your phone displays Anonymous. If the Calling Number ID
information is not available to the cellular network, your
phone displays Unavailabl.
m3td_us.bk : opt_menu.fm5 Page 26 Thursday, November 18, 1999 9:46 PM
Using the Menu Features 27 English
•You can store any number contained in your Caller Line ID
memory to a memory location in the same way you would
save any phone number. Once the correct number is
displayed, press  and a memory location or  Çto
autoload. See “Storing with the Menu” on page 30 for more
information on storing phone numbers.
•The number of received calls is displayed when you select
Received Calls. However, if a call is private or has no Caller
Line ID number, then its actual phone number is not displayed
and will not be included in the count of missed calls.
Reviewing Received Call
iPress ä ä to view your received calls. You must hold
the second ä until the received call list is displayed.
1Select Received Calls. The total numbers of received calls
stored is displayed in the upper right corner. If there are no
numbers in the Caller Line ID list, you will see 00 in the upper
right corner.
2Press A to enter your Caller Line ID list of received calls.
3Press qZ to scroll through the list.
The display shows the order in which the call was received in
the upper right corner, with the phone number and name of
the calling party (if available).
The received call list can range from 01 (the most recent
previous phone call) to 30 (the least recent phone call).
The following symbols appear next to the received calls:
4Press ¾ to dial the displayed number.
Answered
Missed
m3td_us.bk : opt_menu.fm5 Page 27 Thursday, November 18, 1999 9:46 PM
Using the Menu Features
28
English
Reviewing Dialed Calls
iPress ä â â to enter your dialed calls list.
1Select Dialed Calls.
The total number of dialed calls that are stored is displayed in
the upper right corner. You can see up to the last twenty
numbers dialed. If there are no numbers in the Dialed Call list,
you will see 00.
2Press A to enter your dialed calls list.
3Press qZ to scroll through the list. The dialed call list can
range from 01 (the most recent dialed phone call) to 20 (the
least recent dialed phone call).
The display shows the order of the previously dialed phone call
in the upper right corner, with the phone number and name
(if available) of the party called.
4Press ¾ to dial the displayed number.
Clearing Caller Line ID
ATo erase all entries you must press and hold C, whereas
to erase a single entry you simply press C.
To erase all entries saved in your Caller Line ID memory:
1Select Received Calls.
2Press and hold C when a Caller Line ID name and number is
displayed. You will see Clear All?.
3Press A or  to clear.
or
Press ¼ to leave your Caller Line ID memory intact.
To erase a single entry saved in your Caller Line ID memory:
1Press C or any other key when a Caller Line ID name and
number is displayed. You will see Clear Entry?.
2Press A or  to clear.
or
Press ¼ to leave your Caller Line ID memory intact.
m3td_us.bk : opt_menu.fm5 Page 28 Thursday, November 18, 1999 9:46 PM
Using the Menu Features 29 English
Managing the Phone Book
In “Using Phone Memory” you learned how to store and recall
phone numbers with the internal Phone Book. You can access
the same features, along with several advanced features, using
your phone’s convenient menu system.
In this section you will learn how to:
•recall and store phone numbers using the menu system
•store numbers with pause dialing
•store calling card sequences for easy access
•edit your memory information
•select the individual ringer style
AYou can also recall phone numbers without using the Phone
Book. See “Recalling an Entry by Name” on page 22 or
“Recalling an Entry by Memory Location” on page 22.
Start:
m3td_us.bk : opt_menu.fm5 Page 29 Thursday, November 18, 1999 9:46 PM
Using the Menu Features
30
English
Recalling an Entry by Name
To recall a stored name with the Phone Book menu:
1Select Recall By Name. You will see Enter 1st Letter.
2Enter the first letter of the name you want to recall. The
display shows the first name in the phone book that begins
with that letter. If no entry beginning with that letter is found,
No A s is displayed.
3Press qZ to scroll to the name you want.
4Press and hold A, or press ¾ to call the number you
selected.
Recalling an Entry by Location
Each name and number you store is placed in a memory location
numbered 01-99. After storing names and numbers, you can
recall them by memory location with the Phone Book menu.
1Select Recall By Location. You will see Location __.
2Enter the two-digit memory location of the number you want.
3Press and hold A, or press ¾, to call the number you
selected.
Storing with the Menu
Use the phone’s menu system to store names and numbers into
the Phone Book.
1Select Store Number.You will see Enter Number.
2Enter the phone number you want to store. See “How to
Enter Letters and Numbers” on page 22.
3Press A when you finish entering the number.
You will see Location __.
4Press Çto store the sequence in the next available location.
or
Enter the first digit of the memory location and press Çto
store the sequence in the first available location beginning
with that digit.
or
Enter the two-digit memory location where you want the
sequence stored.
AIf the chosen location is full, press ¼ and restart the
storing sequence.
5You will see Alpha Or §. Enter a name to identify the phone
number, or skip this step and continue with step 6. (See “How
to Enter a Name” on page 22 for details on entering names.)
6Press A, or Â, when you finish entering the name. Your
phone confirms your entry by displaying the location, number,
and name you stored. Proceed with step 7 below, or return to
step 2 above to store more numbers.
7Press ¼ to exit the menu.
m3td_us.bk : opt_menu.fm5 Page 30 Thursday, November 18, 1999 9:46 PM
Using the Menu Features 31 English
Storing and Placing Numbers with Pause
Dialing
Entering a Pause in a Number
When you call automated systems, a recorded message prompts
you for PIN numbers, Voice Mail numbers, etc.
You can store these numbers in your phone’s memory, separated
by “pauses”—special characters that tell your phone to wait
before sending additional numbers.
1Select Store Number.You will see Enter Number.
2Enter the phone number you use to access the automated
system.
3Press Ä, then press ¾.
You will see Insert Wait o.
4Press A to insert a pause (o) into the sequence.
5Enter the next group of numbers (such as an account number
or PIN number.)
6Enter any other required symbols (such as * or #).
7Insert another pause, and enter the next group of numbers by
repeating steps 3 through 5 as many times as necessary.
You can store up to 32 digits, including pauses. Then store the
entire sequence as you would any phone number.
8Press  to begin storing.
You will see Location __.
9Enter the two-digit memory location where you want the
sequence stored.
You will see Alpha Or §.
10 Enter a name for your sequence.
(See “How to Enter a Name” on page 22 for details on
entering names.)
11 Press A when you finish entering the name.
Your phone confirms your entry by displaying the location,
number, and name you stored.
Placing a Call with Pauses
To use your stored sequence:
1Recall the stored number with the pause inserted.
2Press and hold A, or press ¾, to place the call.
3When the recording prompts you for information, press A or
¾ to send the next set of stored numbers.
4Press A or press ¾ as many times as necessary, to transmit
all the numbers.
m3td_us.bk : opt_menu.fm5 Page 31 Thursday, November 18, 1999 9:46 PM
Using the Menu Features
32
English
Storing and Placing Numbers for Calling
Card Information
Storing Calling Card Information
Like Pause Dialing, you can store calling card access numbers,
separated by pauses, for recall later. You can also store a Number
Character in the sequence to save a place for the number you call
when you use your calling card.
See “Using Lock/Security Features” on page 40 for more
information on protecting your calling card information.
1Select Store Number.You will see Enter Number.
2Enter the phone number you use to access your calling card
system. (Skip this step if you only dial 0.)
3Press Ä ¾. You will see Insert Wait o.
4Press A to insert a pause (o) into the sequence.
5Enter the next numbers, if needed. (For example, some long
distance carriers require you to dial a 0 first. If no further
numbers are needed, skip to step 7.)
6Press Ä ¾.
7Press Z to scroll to the Number Character. You will see Insert
Number 'N.
8Press A to insert the 'N Character.
This special character saves a place for the phone number you
will be calling. The number is inserted automatically when you
place the call.
9Press Ä ¾.
10 Press A to insert another pause, as in steps 3 and 4.
11 Enter your calling card PIN number.
12 Press  to store your calling card sequence.
You will see Location __.
13 Enter the two-digit memory location where you want the
sequence stored.
You will see Alpha Or §.
14 Enter a name for your sequence. (See “How to Enter a Name”
on page 22 for details on entering names.)
15 Press A when you are finished entering the name.
Your phone confirms your entry by displaying the location,
number, and name you stored.
Placing a Calling Card Call
To recall your stored calling card information:
1Recall the calling card information you stored.
(See “Recalling an Entry by Name” and “Recalling an Entry by
Location” on page 30 for more information on Recalling
Numbers.)
2Press ¾ before entering the number. You will see Enter
Number.
3Enter the phone number you want to call, including the area
code.
Enter the number manually, by location, or recall.
4Press and hold A, or press ¾, to place the call.
Your phone dials the number to access your long distance
provider.
m3td_us.bk : opt_menu.fm5 Page 32 Thursday, November 18, 1999 9:46 PM
Using the Menu Features 33 English
5Press A, or press ¾, to send the next group of numbers
when you are prompted.
The phone automatically inserts the selected number to call at
the appropriate time in the sequence.
6Repeat step 5 to send the next group of numbers as many
times as necessary.
Editing a Memory Location
After you store names and numbers in the Phone Book, you can
edit the information or erase entries at any time.
1Select Edit.
2Recall the entry by location or by name.
(See “Recalling an Entry by Name” and “Recalling an Entry by
Location” on page 30.)
3Press A to begin editing the phone number.
The display shows the name briefly, then the phone number.
4Press C to erase one digit at a time.
Press and hold C to erase the entire number.
5Enter your changes to the phone number.
6Press A when you finish editing the phone number.
The display shows the location where your number is currently
stored.
7Press C to erase the memory location, then enter a new
two-digit location.
or
Press A to keep the phone number in its current location.
The display shows the name stored with the phone number
you are editing.
8Enter your changes to the name. (See “How to Enter a Name”
on page 22.)
Press C to erase one letter at a time, or skip to step 9 to
leave the name unchanged.
9Press A when you finish editing the name. The display shows
the new information.
10 Press A to save your changes.
Your phone confirms your entry by displaying the location,
number, and name you stored.
or
Press C to leave the information unchanged.
When you see Location __, enter a new two-digit memory
location to avoid overwriting the information in the current
location.
11 Press ¼ to exit, or scroll to other features.
m3td_us.bk : opt_menu.fm5 Page 33 Thursday, November 18, 1999 9:46 PM
Using the Menu Features
34
English
Timing Your Calls
Your phone’s Call Timers give you a variety of options for
managing your time. You can monitor the length of individual
calls, set a timer to track monthly usage, or have the phone alert
you at intervals that you specify.
In this section you will learn how to:
•view the timers
•monitor the length of your calls
•set and view the resettable timer for long-term monitoring
•program audible timers for your individual needs
Start:
m3td_us.bk : opt_menu.fm5 Page 34 Thursday, November 18, 1999 9:46 PM
Using the Menu Features 35 English
Viewing the Individual Call Timer
iPress ä È È for a quick look at this timer.
You can view the air-time of the most recent call or the call in
progress (in minutes and seconds) at any time using this feature.
The Individual Call Timer resets when you place the next call and
when you turn the phone off. You can also choose to have the
timer display while calls are in progress. See “Displaying the
Individual Timer Automatically” on page 36.
1Select Individual XX YY. The display shows the air-time of
your last call in minutes (XX) and seconds (YY).
2Press ¼ to exit, or scroll to other features.
Viewing the Resettable Call Timer
iPress ä È È È for a quick look at this timer.
You can track how much air time you have accumulated at any
time. Use this feature to view the time elapsed, and follow the
instructions in “Resetting the Timer” on page 35 to reset the
timer.
1Select Resettable XXXXX. The display shows your air time in
minutes since you last reset the timer.
2Press ¼ to exit, or scroll to other features.
Viewing the Cumulative Timer
iPress ä È È È È for a quick look at this timer.
This is a non-resettable timer that keeps track of your phone’s
total air time (in minutes).
1Select Cumulative XXXXX. The display shows your air time in
minutes since your phone was activated.
2Press ¼ to exit, or scroll to other features.
Resetting the Timer
By resetting this timer at the beginning of each billing cycle, you
can keep a running tab of your monthly usage. After you reset
the timer, it continues to keep track of your air time (in minutes)
until you reset it again.
1Select Individual XX YY.
2Press Z to scroll to Reset Timer.
3Press A to reset the timer.
4Press ¼ to exit, or scroll to other features.
m3td_us.bk : opt_menu.fm5 Page 35 Thursday, November 18, 1999 9:46 PM
Using the Menu Features
36
English
Displaying the Individual Timer
Automatically
AActivating the Individual Timer may reduce both standby
and talk times.
When you turn this feature on, your phone automatically displays
your air time in minutes (XX) and seconds (YY) during and after
each call.
1Select Individual Timer. You will see Individual Timer Off
or Individual Timer On.
2Press A to toggle between Individual Timer Off and
Individual Timer On.
3Press ¼ to exit, or scroll to other features.
Setting the One-Minute Audible Timer
Activate this feature to hear an audible beep 10 seconds before
the end of every minute during a call. The party on the other end
does not hear the beeps.
1Select One Minute Timer. You will see One Minute Timer Off
or One Minute Timer On.
2Press A to toggle between One Minute Timer Off and One
Minute Timer On.
3Press ¼ to exit, or scroll to other features.
Setting the Repeating Audible Timer
You can set this timer to beep during your calls at an interval that
you select—from 11-999 seconds. You will hear the beep 10
seconds before the end of each interval, but the party on the
other end does not hear the beeps.
1Select Repeat Timer. You will see Repeat Timer Off or
Repeat Timer On.
2Press A to toggle between Repeat Timer Off and Repeat
Timer On.
The prompt to enter seconds appears only if you have turned
the feature on. If you have turned it off, you will see Repeat
Timer Off.
3Enter the number of seconds you would like between audible
beeps. You will see Beep At YYY Secs.
4Press A to set the timer. The phone confirms the setting by
displaying Set At YYY Secs.
5Press ¼ to exit, or scroll to other features.
m3td_us.bk : opt_menu.fm5 Page 36 Thursday, November 18, 1999 9:46 PM
Using the Menu Features 37 English
Setting the Single Timer
Like the Repeating Timer, you can set the Single Timer to beep at
a time that you select—from 11-999 seconds. It beeps once
during each call, 10 seconds before the end of the interval. The
party on the other end does not hear the beep.
1Select Single Timer. You will see Single Timer Off or
Single Timer On.
2Press A to toggle between Single Timer Off and Single
Timer On.
The prompt to enter seconds appears only if you have turned
the feature on. If you have turned it on, you will see Single
Timer Off.
3Enter the number of seconds you would like between audible
beeps. You will see Beep At YYY Secs.
4Press A to set the timer. The phone confirms the setting by
displaying Set At YYY Secs.
5Press ¼ to exit, or scroll to other features.
m3td_us.bk : opt_menu.fm5 Page 37 Thursday, November 18, 1999 9:46 PM
Using the Menu Features
38
English
Adjusting Tone Controls
Use these features to personalize your phone’s ringer styles, or
turn the ringer off.
In this section you will learn how to:
•choose from nine different ringer styles
•silence the keypad
•silence the scratchpad
Start:
m3td_us.bk : opt_menu.fm5 Page 38 Thursday, November 18, 1999 9:46 PM
Using the Menu Features 39 English
Selecting a Ring Style
Your phone lets you select any of nine different ring styles. After
you choose a style, the phone give you a brief sample of the new
ring style.
1Select Call Alert Ring Style.
2Press Ú through á to hear the different ring styles, or
scroll through the ring styles. Ring Style 1 is the default
setting.
3Press A when you reach the ring style you want.
The display will show Ring Style X Set.
4Press ¼ to exit, or scroll to other features.
Turning Keypad Tones On and Off
Keypad tones are the sounds you hear when you press any key
on the phone. By default, keypad tones are turned on. If you
want to be discreet, use this feature to silence the audio
feedback from the keypad.
AThe other party still hears tones.
1Select Keypad Tone. You will see Keypad Tone On or Keypad
Tone Off.
2Press A to toggle between Keypad Tone On and Keypad Tone
Off.
3Press ¼ to exit, or scroll to other features.
Turning Scratchpad Tones On and Off
Scratchpad tones are the tones that your phone sends to access
automated calling systems like Voice Mail. By default, scratchpad
tones are turned on. If you don’t want your party to hear these
sounds when you use the scratchpad, turn the scratchpad tones
off.
1Select Scratchpad Tone. You will see Scratchpad Tone On or
Scratchpad Tone Off.
2Press A to toggle between Scratchpad Tone On and
Scratchpad Tone Off.
3Press ¼ to exit, or scroll to other features.
AIf you turned the scratchpad tones off but want to access a
tone-activated system like Voice Mail, place the call, enter
the numbers you need to transmit, then:
Press ä ¾ to send the tones.
m3td_us.bk : opt_menu.fm5 Page 39 Thursday, November 18, 1999 9:46 PM
Using the Menu Features
40
English
Using Lock/Security Features
While you probably would not want to leave your phone
unattended, your phone has a number of built-in security
features to prevent unauthorized use.
In this section you will learn how to:
•activate the Voice Privacy feature
•lock and unlock your phone
•place priority calls
•change your lock code
•restrict call placement and memory access
•reset or clear your phone’s settings
Start:
m3td_us.bk : opt_menu.fm5 Page 40 Thursday, November 18, 1999 9:46 PM
Using the Menu Features 41 English
Activating Voice Privacy
ANetwork and subscription dependant feature. Not available
in all areas.
When you activate your phone’s Voice Privacy feature, you
request your cellular system to search for a Voice Privacy channel
with each call. If no Voice Privacy channel is available (or your call
is “handed off” to a cell where a Voice Privacy channel is not
available), five short beeps alert you that the call is no longer
private.
You must select the Voice Privacy feature before you make a call
in order for that call to search for a Voice Privacy channel.
AThis feature is not available in all markets. Contact your
Service Provider for additional information about your
service area.
To turn the Voice Privacy feature on or off:
1Select Voice Privacy. You will see Privacy Off or Privacy
Preferred.
2Press A to toggle between Privacy Off and
Privacy Preferred.
3Press ¼ to exit, or scroll to other features.
Locking/Unlocking Your Phone
For your protection, you must enter the six-digit security code to
access the features that your phone contains. The factory-
programmed lock code for unlocking the phone is 123. The six-
digit security code is 000000. These may have been changed
when your phone was activated.
Locking Your Phone Automatically
iPress Ä, the Smart Button, Ú Þ, and continue with
step 2.
When you turn this feature on, your phone automatically locks
itself each time you turn it off.
1Select Automatic Lock. You will see Automatic Lock Off or
Automatic Lock On.
2Press A to toggle between Automatic Lock Off and
Automatic Lock On.
3Press ¼ to exit, or scroll to other features.
Locking Your Phone Manually
You can lock your phone manually at any time to prevent
unwanted use. Once you lock the phone, it remains locked
whether it is powered on or off.
1Press Ä.
2Press and hold Þ for at least one full second.You will see
Lock?.
A“LOCK” is printed on the Þ key, as a reminder.
3Press  or A to lock. You will see Locked.
m3td_us.bk : opt_menu.fm5 Page 41 Thursday, November 18, 1999 9:46 PM
Using the Menu Features
42
English
Unlocking Your Phone
To unlock your phone:
Once your phone is on, enter your three-digit lock code to unlock
your phone. (See “Viewing the Lock Code” on page 42 and
“Changing the Lock Code” on page 42 for more information on
your lock code.)
Answering Calls While the Phone Is Locked
You can still receive calls when the phone is locked. To answer an
incoming call:
1Enter your three-digit lock code.
2Press and hold A, or press ¾ to receive the call.
AIf you forget your lock code, try pressing Ú Û Ü or
the last three digits of your cellular phone number.
Activating Priority Calling
iPress Ä, the Smart Button, Û á, and continue with
step 2.
Priority Call allows the Turbo Dial™ function to dial from memory
location 01—even when the phone is locked. You can store an
emergency number or the number of someone you would like to
contact in case of emergency.
ASome cellular systems have their own emergency numbers
and deny access to emergency numbers like 911 (not
available in some areas). Check with your Service Provider
for more information.
By default, Priority Call is activated. To turn it off or to switch it
back on, complete the following steps:
1Select Priority Call. You will see Priority Call Off or
Priority Call On.
2Press A to toggle between Priority Call Off and Priority
Call On.
3Press ¼ to exit, or scroll to other features.
Viewing the Lock Code
To display the active three-digit lock code:
1Select Secure Options and enter your six-digit security code.
2Select View Lock Code. You will see View Lock Code.
3Press A to display your three-digit lock code. The code appears
for a few seconds.
4Press ¼ to exit, or scroll to other features.
Changing the Lock Code
To change your three-digit lock code:
1Select Secure Options and enter your six-digit security code.
2Select Change Lock Code. You will see Enter Code ___.
3Enter the new three-digit code. You will see
Changed To XXX.
4Press ¼ to exit, or scroll to other features.
AIf you try to change your lock code to 911 or the first three
digits of an emergency number, you will see Code Invalid,
and the code you entered will not be accepted. You will
return to step 1 above.
m3td_us.bk : opt_menu.fm5 Page 42 Thursday, November 18, 1999 9:46 PM
Using the Menu Features 43 English
Restricting Call Placement
ANetwork and subscription dependant feature. Not available
in all areas.
You may want to restrict call placement or hide memory
information when loaning your phone to others.
Selecting a Service Level
1Select Secure Options and enter your six-digit security code.
2Select Service Level. The phone displays your current service
level. Refer to the chart on the next page.
3Press qZ to scroll through the service level settings, and press
A to select the service level you want.
If you select Level 7, the phone prompts you for the range of
memory locations you want to remain active. You will see
Range 1-__.
Enter the range of digits memory locations from which calls
are allowed. The phone confirms the allowed range, and you
will see 1-XX Allowed.
4Press ¼ to exit, or scroll to other features.
Service Level Settings
Each of your phone’s eight service levels offers a different
combination of access privileges and restriction.
A Caller Line ID is an optional network and subscription
feature that is not available in all areas.
Level Description Display
1
• Calls can be placed from memory
locations 1-10 only.
• No dialing from keypad
• No memory edit or storage
• No access to name directory
• No access to last number dialed
1 Memory 1-10
2
• Calls can be placed from all
memory locations.
• No dialing from keypad
• No memory edit or storage
• No access to Caller Line ID stack
or Last Number Dialed
2 Memory Only
3
• Calls can be placed manually
from the keypad only.
• No access to memory information
• No memory edit or storage
• No access to Caller Line ID stack
or Last Number Dialed
3 Keypad Only
4Standard setting, no restrictions 4 Standard
Setting
5 Seven-digit (local) dialing only 5 Local Only
m3td_us.bk : opt_menu.fm5 Page 43 Thursday, November 18, 1999 9:46 PM
Using the Menu Features
44
English
Resetting All Options
Use the Master Reset feature to reset all user-selectable options
back to their original factory settings.
AOnce you select this feature, the reset process cannot be
canceled or reversed.
1Select Secure Options and enter your six-digit security code.
2Select Master Reset.
3Press A if you want to reset all your phone’s options back to
their factory settings. You will see Standard Setting.
or
Press ¼ to exit the menu if you do not want to reset your
phone’s options.
4Press ¼ to exit, or scroll to other features.
Clearing All Stored Information
If you want to start over, use Master Clear to reset all user-
selectable options, clear the resettable timer, and erase all Phone
Book information.
AOnce you select this feature, the process cannot be
canceled or reversed.
1Select Secure Options and enter your six-digit security code.
2Select Master Clear.
3Press A to clear the memory and reset all your phone’s options
back to their factory settings. You will see Busy. (This takes a
few seconds.)
or
Press ¼ to exit the menu if you do not want to reset your
phone’s options.
4Press ¼ to exit, or scroll to other features.
6
• Calls can be placed from the
keypad and from memory.
• No edit or memory storage to
memory locations 1-10
6 No Store
1-10
7
• Calls can be placed from a
selected memory range only.
• Memory edit and storage allowed
with the selected range.
• No access to name directory
7 Allow Range
8No edit, storage, or recall from
memory locations 1-9 8 Hide Turbo
Level Description Display
m3td_us.bk : opt_menu.fm5 Page 44 Thursday, November 18, 1999 9:46 PM
Using the Menu Features 45 English
Customizing Phone Options
The Phone Options menu lets you customize the way your phone
sends and receives calls.
You can tune your phone for optimal performance, view
information about the phone, and choose from a number of
convenient features.
In this section you will learn how to:
•activate pager mode
•switch between analog or digital mode
•view your own phone number
•switch cellular phone numbers
•select the type of cellular system
•review your phone’s feature settings
•select features for vehicular use
•conserve battery power
•display your system identification
•select a language
Start:
m3td_us.bk : opt_menu.fm5 Page 45 Thursday, November 18, 1999 9:46 PM
Using the Menu Features
46
English
Activating Pager Mode
When Pager Mode is activated, the phone simulates a pager.
Pager Mode suppresses incoming call alerts but leaves message
alerts active. The following conditions occur:
•Voice call alerts are suppressed.
•Message alerts are allowed.
By default, Pager Mode is turned off. Complete the following
steps to turn Pager Mode on and off.
1Select Pager Mode on/off. The display shows your current
Pager Mode setting.
2Press A to toggle between Pager Mode on and off.
3Press ¼ to exit, or scroll to other features.
Selecting Call Mode Preference
ANetwork and subscription dependant feature. Not available
in all areas.
Either a digital or analog channel can be assigned to your phone,
based upon system channel availability.
Examples of peripheral devices that require analog operation
include fax machines, personal computers with modems, and
telemetry monitors (EKG). You must select this feature before a
call originates in order for the call to be analog.
AIf this feature is selected during a call, the feature is effective
with the next call. Press Ä Û to switch between digital
and analog mode.
AWhen powered on, your cellular phone first searches for a
digital channel. If no digital channel is available, your phone
switches to an analog channel.
1Select Call Mode Preference.
2Press qZ to toggle among Digital Voice preferred, Analog
Voice Only, or Digital Voice Only modes.
3Press A to make your selection.
4Press ¼ to exit, or scroll to other features.
AAnalog only is a temporary setting that is only active for a
single call or until you turn the phone off and back on.
!If you select either Analog Voice Only or Digital Voice
Only, you will not be able to make a call if the selected
system is not available.
Viewing Your Own Number
iPress ä È for a quick look at your phone number.
Use this feature to view your phone’s currently active phone
number. If you have more than one phone number, you can
change the active number with the Change Number feature in
the Phone Options menu. (See “Switching Between Numbers”
on page 47.)
1Select My Number.
2Press A to view your own phone number.
Your active phone number appears on the screen. After six
seconds, the phone returns to step 1.
3Press ¼ to exit, or scroll to other features.
m3td_us.bk : opt_menu.fm5 Page 46 Thursday, November 18, 1999 9:46 PM
Using the Menu Features 47 English
Switching Between Numbers
Your phone can operate on two different home systems. If you
travel often, you can have your phone programmed with two
cellular numbers to reduce roaming. This feature allows you to
change your active number to the one appropriate for the area
you are in.
When your phone has two numbers, both are designated as your
home system but only one number can be active at any given
time. Calls are placed and received by the currently active
number only. Each time you turn your phone ON, you’ll see a
message in the display that indicates which phone number and
home system are currently active:
In most areas, there are two competing cellular carriers, the
wireline carrier and the non-wireline carrier. Your display
indicates which type of carrier your home system is as follows:
non-wireline carrier—The display indicates that your home
system is system A.
wireline carrier—The display indicates that your home system is
system B.
To switch your phone number:
1Select Change Number. The active phone number appears in
the display (for example, 5155551515).
2Press Z to switch to your other phone number (for example,
7085551212).
3Press A to confirm the new setting.
4Press ¼ to exit, or scroll to other features.
Selecting a Cellular System
iPress ä Ç, and continue with step 3.
ANetwork and subscription dependant feature. Not available
in all areas.
Your Service Provider configures the System Mode feature when
you receive a cellular phone number. Use this feature to select
the type of cellular system your phone will access.
1Select System Mode.
2Press Z to scroll through the mode settings:
Non-wireline type with phone number 1 A1
Non-wireline type with phone number 2 A2
Wireline with phone number 1 B1
Wireline with phone number 2 B2
Standard Mode—Your phone first seeks a
home type system, then a non-home type
system
If home is non-wireline (type A) Std AB
If home is wireline (type B) Std BA
m3td_us.bk : opt_menu.fm5 Page 47 Thursday, November 18, 1999 9:46 PM
Using the Menu Features
48
English
3Press A to select the system mode setting you want.
4Press ¼ to exit, or scroll to other features.
Activating Multiple Key Answer
Turn on the Multiple Key Answer feature to answer calls by
pressing the Smart Button, any key on the upper keypad Ú-
È, or the upper and lower volume keys.
1Select Mult Key Answer. You will see Mult Key Answer On or
Mult Key Answer Off.
2Press A to toggle between Mult Key Answer On and Mult Key
Answer Off.
3Press ¼ to exit, or scroll to other features.
Activating Automatic Answer
Turn Auto Answer on to have your phone automatically answer
incoming calls after two rings.
AAuto Answer does not work if Pager Mode is activated.
1Select Automatic Answer. You will see Automatic Answer On
or Automatic Answer Off.
2Press A to toggle between Automatic Answer On and
Automatic Answer Off.
3Press ¼ to exit, or scroll to other features.
Reversed Preference Mode—Your phone
first seeks a non-home type system, then a
home type system. (May be useful in fringe
areas or certain roaming situations)
If home is non-wireline (type A) Scan
BA
If home is wireline (type B) Scan
AB
Home Only Mode—The phone will not
operate outside its home system. Home
Scan A Mode—The phone will operate only
within nonwireline (type A) systems. Scan A
Scan B Mode—The phone will operate only
within wireline (type B) systems.
Scan B
m3td_us.bk : opt_menu.fm5 Page 48 Thursday, November 18, 1999 9:46 PM
Using the Menu Features 49 English
Displaying System Identification
This feature shows the System ID number that identifies the
cellular system your phone is currently accessing. An even
number indicates a wireline system, while an odd number
indicates a non-wireline system.
1Select the System Options sub-menu. You will see Display
SID.
2Press A to view the System ID number. After six seconds, the
phone goes back to step 2.
3Press ¼ to exit, or scroll to other features.
Selecting Language
This feature enables you to select the language in which your
phone displays prompts and messages.
1Select the Language sub-menu.
2Press Z to scroll through the language options. The choices
include English, Spanish, French, Portuguese, Hebrew, and
Russian. English, Espanol, Francais, Portuguesa, Hebrew,
and Russian.
3Press A to select the language setting you want.
4Press ¼ to exit, or scroll to other features.
m3td_us.bk : opt_menu.fm5 Page 49 Thursday, November 18, 1999 9:46 PM
Using the Menu Features
50
English
m3td_us.bk : opt_menu.fm5 Page 50 Thursday, November 18, 1999 9:46 PM
Using the Message Center 51 English
Using the Message Center
ANetwork and subscription dependant feature. Not available
in all areas.
The Message Center gives you easy access to both voice mail and
your text messages. In this section you will learn how to:
•use voice mail
•edit a phone number to access voice mail
•use short messaging services (SMS) to view, lock/unlock, and
clear messages
•adjust speed of your scrolling messages
AVoice mail and SMS are optional network and subscription-
dependent features that are not available in all areas.
Start:
m3td_us.bk : msg.fm5 Page 51 Thursday, November 18, 1999 9:46 PM
Using the Message Center
52
English
Voice Mail Alerts
This feature updates you each time a message is sent to your
voice mail number, providing you with real-time information on
messages waiting to be retrieved.
When a voice mail message is received:
•Voice Mail XX Msgs appears.
•The p icon appears.
•The phone beeps three times for a message.
Dialing Voice Mail
You can retrieve your voice mail messages in one of two ways.
From the Voice Mail Alert Screen
When you receive a voice mail alert and the Voice Mail XX
message appears, press A to dial your voice mail number.
Your access number for the voice mail center is dialed
automatically, and Dialing XXXX appears on the display, where
XXXX is your access number.
From the Message Center
1Press ¿ to enter the message center.
2Press qZ to scroll to Voice Mail.
3Press A or ¿ to dial your voice mail number.
Your access number for the voice mail center is dialed
automatically, and Dialing XXXX appears on the display, where
XXXX is your access number.
Editing the Voice Mail Number
This feature allows you to save your voice mail access number.
AWhen you receive your phone, the default voice mail
number is your phone number.
1Press ¿ to enter the message center.
2Select Voice Mail.
3Select Set Voice Mail No.
4Enter your voice mail number.
The digits appear as you enter them.
5Press A or Â.
A message confirms that your number has been saved.
AIf you subscribe to a system that provides a shortcut number
for voice mail, enter the complete number—not the
shortcut number.
6Press ¼ to exit, or scroll to other features.
m3td_us.bk : msg.fm5 Page 52 Thursday, November 18, 1999 9:46 PM
Using the Message Center 53 English
Reading Text Messages
ANetwork and subscription dependant feature. Not available
in all areas.
Some Service Providers let you subscribe to a Short Message
Service (SMS), which allows you to receive alphanumeric
messages on your phone, just like a pager. Contact your Service
Provider for information about the availability of messaging in
your area.
SMS enables your phone to save up to 15 short messages, each
up to 80 characters in length, or five full-length 239-character
messages.
Your phone automatically replaces the oldest messages with the
newest as they are received. You can store Call Back messages
and numbers for later review. The one-touch Message Button
makes viewing your messages easy.
How Your Phone Receives Message Alerts
New Message Alerts
If your phone is on and receives a new digital message, the
phone alerts you in two different ways:
•Message Received appears in the display, and:
- The message icon o appears.
- The phone beeps three times .
or
•Urgent Msg Received or EMERGENCY MSG RECVD appears in the
display, and:
- The message icon o appears.
- The phone beeps five times .
Short Message Indicators
If the sender has marked the message “Emergency” or “Urgent,”
the display shows the message content on the first line and either
Urgent or Emergency on the second line. The message number
appears in the upper right of the display.
Selecting and Reading Short Messages
1Press ¿ to enter the message center.
2Press qZ to scroll to Text Msgs.
• If the message center has messages, you will see Text
Msgs XX New, where XX is the number of unread
messages.
The total number of messages stored, YY appears in the
upper right of the display.
• If the message center has no messages, you will see Text
Msgs Empty, and 00 will appear in the upper right portion
of the display.
3Press A or ¿ to view the message headers.
If the message center is full, you will see Msg Memory Full
displayed for two seconds prior to viewing the message
headers.
m3td_us.bk : msg.fm5 Page 53 Thursday, November 18, 1999 9:46 PM
Using the Message Center
54
English
4Now you can scroll through a list of message headers. Each
header includes:
• the message number
• its urgency
• the beginning of the message text
Press qZ to scroll forward or backward through the list of
message headers. The newest message is placed at the top of
the list, and the oldest message is at the bottom.
5Press A to select and view a message, and then the message
text appears, starting on the top line.
Press ¿ to halt the display of the message text. Press ¿
again to restart it.
6After reading a selected message, press qZ to scroll through
the list of message headers.
7Press ¼ or press and hold ¿ to exit, or scroll to other
features.
Initiating a Call Back
When the current message has scrolled across the display, you
can call back a number embedded in the text message.
1Press and hold A, or press ¾ to initiate a Call Back, if a Call
Back number was included in the message.
You will see Dial No.? XXXXXXX.
If a Call Back number was not included in the text message,
the phone dials the first number present in the text message.
2Press A, or press ¾ to dial the number shown.
or
Press qZ to search the text message for the next call back
number.
AWhile in the message center, you can enter a Call Back
number at any time by using the keypad, and then pressing
¾ to place the call.
Locking and Unlocking a Message
You can lock important messages to ensure their safekeeping for
later review. A locked message cannot be deleted until the
message is unlocked.
Press Ä Þ, to toggle the current message between locked
and unlocked.
Msg Locked is displayed when a message is locked.
AIf your message memory is full and a new message is
received, the oldest unlocked message that has been read is
deleted.
Clearing Messages
Clearing the Current Message
1Press C when the message you want to erase is on the
display.
You will see Clear Message?, where XX is the number of the
message you will clear. This number will appear in the upper
right portion of the display.
2Press A or  to clear the message.
You will see Message Cleared.
or
m3td_us.bk : msg.fm5 Page 54 Thursday, November 18, 1999 9:46 PM
Using the Message Center 55 English
Press ¼or any other key if you do not wish to clear the
message. You will see Msg Not Cleared.
AYou must unlock a locked message before you can clear it.
For more information, see “Locking and Unlocking a
Message” above.
Clearing All Messages
To erase all the messages from your Message Center at once:
1Press and hold C when you are in the message center.
You will see Clear All?.
2Press A or  to verify that you want all the messages
cleared.
or
Press ¼ if you decide not to clear all the messages. You are
returned to the message center.
3Press ¼ to exit from the message center.
If all messages have been cleared and no locked messages
remain in the message center, Msg Center Empty appears in
the display.
AYou must unlock any locked messages before they can be
cleared. For more information, see “Locking and Unlocking
a Message” on page 54.
4Press ¼ to exit, or scroll to other features.
Setting the Scrolling Speed
To adjust the scrolling speed of your incoming messages:
1Press ¿ to enter the message center.
2Select Text Msgs.
3Select the Set Scroll Speed option.
4Press qZ to scroll through scrolling speed settings:
•To scroll slowly, select Slow Scrolling.
•For medium scrolling, select Medium Scrolling.
•To scroll quickly, select Fast Scrolling.
5Press A to select a scrolling speed.
6Press ¼ to exit, or scroll to other features.
m3td_us.bk : msg.fm5 Page 55 Thursday, November 18, 1999 9:46 PM
Using the Message Center
56
English
m3td_us.bk : msg.fm5 Page 56 Thursday, November 18, 1999 9:46 PM
Accessories 57 English
Accessories
The following accessories have been designed to work with your
phone. Additional accessories may be available and are packaged
separately. Please refer to your local service provider or retail
outlet for more information.
Travel Charger
The Power Adapter (charger) connects to the phone. When
connected directly to the phone, it charges the battery and also
provides dead battery operation.
The Power Adapter requires an appropriate Adapter Plug.
Vehicle Power Adapter
AThe use of wireless devices and their accessories (“Devices“)
may be prohibited or restricted in certain areas. Always obey
the laws and regulations on the use of these devices.
The Vehicle Power Adapter connects to your phone and allows
you to charge your phone's battery while driving.
AIn some cars, the engine must be running in order for the
cigarette lighter to operate.
Headset
The convenient headset provides both an earphone and
microphone for simple handsfree and private telephone
conversations. The headset plugs directly into the jack on the top
of your phone, so that you can wear your phone and move
freely.
Belt Clip
The Belt Clip holds the phone while being worn on your belt.
AThe belt clip has been designed for your convenience and is
not meant to secure your phone under all circumstances.
Accessory Limited Warranty Information
We recommend that you use Motorola original batteries and
accessories. Under its limited cellular telephone warranty,
Motorola specifically disclaims any responsibility for damage
caused by the use of portable cellular telephone accessories not
manufactured by Motorola.
For details on the complete line of Motorola cellular accessories,
see your dealer or visit our Web site at
http://www.mot.com/
m3td_us.bk : access.fm5 Page 57 Thursday, November 18, 1999 9:46 PM
Accessories
58
English
m3td_us.bk : access.fm5 Page 58 Thursday, November 18, 1999 9:46 PM
What to do if... 59 English
What to do if...
I pressed the power button, but
nothing happened. What’s
wrong with my phone?
Make sure that you press and hold the power button until the display appears and you hear an audible
alert. If nothing still happens, then check that you have installed the batteries and that the batteries are fully
charged. For more information about batteries and charging see “Your Battery” on page 15.
The battery won’t charge. Check the alignment of the batteries to ensure that they are installed properly. Make sure the positive (+)
and negative (-) marks on the batteries match the markings on the phone.
Check the charger. Is it properly connected? Is it fully inserted? Are its contacts clean and dry? The phone
should provide a beep-tone and the display should read “Charging Battery” within two minutes from the
transformer being installed.Check the charger is fully inserted and properly connected. See ‘Your Battery’.
My battery didn’t last as long as
I expected. What can I do to
extend battery life?
Your battery’s “talk-time” and “standby-time” are relative measurements of the battery’s capacity. The
more you talk on the phone, the less standby-time you have, and vice versa.
To get the most from your battery, allow it to charge fully. To charge the battery to 100% of its capacity,
leave it charging for an extra hour after the charger’s light turns green.
Certain features demand power from your battery and reduce battery life. If you have selected the
Automatic Display of Individual Call Timer feature, the display uses battery power to remain active during
each call. Turn this feature off to conserve battery energy. (See “Displaying the Individual Timer
Automatically” on page 36 for more information on this feature.)
Make sure that you are using batteries that are compatible with your phone.
Exposing your battery to extreme temperatures—below -10°C (14°F) or above 45°C (113°F)—can shorten
battery life. Batteries are especially sensitive to high temperature extremes. As a good rule, always take your
phone with you when you leave your car.
The display says, “Locked.” How
do I unlock my phone?
Enter the last three digits of your cellular number. If that doesn’t work, use the factory preset lock code:
123. If all else fails, call your service provider (the company that sends you your monthly cellular bill) for
assistance. (See “Using Lock/Security Features” on page 40 for more information on Security Features.)
I tried to place a call and
received a fast busy signal.
This sound means that the cellular system did not process your call. For example, the cellular system may be
overloaded with call attempts. To redial the number, press ¾ before ending your call attempt, or press
¼ and try the call again later. (See “Redialing a Number” on page 20 for more information on redialing.)
m3td_us.bk : notes.fm5 Page 59 Thursday, November 18, 1999 9:46 PM
What to do if...
60
English
I tried to place a call and
received an alternating high/
low tone.
This sound means your call did not reach the cellular system. You may have dialed the number too soon
after turning the phone on. Wait until the “NS” light stops blinking before placing a call.
An alternating tone may also indicate that your phone’s signal is blocked. Make sure the antenna is fully
extended and you’re clear of any obstructions such as bridges, parking garages, or tall buildings.
I tried to listen to my Voice Mail
(or use a paging service, a
calling card, etc.) but nothing
happened.
You have probably turned off the Scratchpad tones. Place your call, enter the access numbers when
prompted by the recording, then press ä ¾. To avoid this problem in the future, follow the directions
“Turning Scratchpad Tones On and Off” on page 39 to turn the Scratchpad tones on.
My phone was stolen. What
should I report and to whom?
Report a stolen phone to the police and to your service provider (the company that sends you your monthly
cellular service bills).
I tried to place a calling card call
using the internal Phone Book,
but it didn’t work.
You may have turned off your Scratchpad tones. Follow the directions in “Turning Scratchpad Tones On
and Off” on page 39 to turn the Scratchpad tones on.
Check that you stored your calling card information in the correct order, and make sure the groups of
numbers are separated by pauses. The easiest way to correct the sequence may be to start from scratch.
Follow the instructions on “Storing Calling Card Information” on page 32, enter your calling card
information again, and store it in the same memory location as your previous attempt.
Also keep in mind that when using your calling card, you must enter the number you are calling with the
area code, but without the initial “1.” Check with your long distance carrier for details on using your calling
card.
m3td_us.bk : notes.fm5 Page 60 Thursday, November 18, 1999 9:46 PM
Patent Information 61 English
Patent Information
Manufactured under one or more of the following patents:
4121218 4127824 4128740 4138681 4193036 4254382
4302845 4312074 4327319 4329666 4369516 4369522
4378603 4390963 4398265 4400584 Re.31470 4431977
4434461 4455534 4462098 4484153 4485486 4486624
4491972 4504834 D278708 4523155 4546329 4549311
4550426 4551696 4564821 D282169 4571595 4573017
4574243 4585957 4602218 D284759 4616314 4617520
4626309 4628529 4629829 4630304 4630305 4633141
4636593 4636741 4644351 D288432 4648125 4649543
D288683 4654655 4654867 4662691 4667333 4668917
4670747 4672502 4692726 4704588 D292578 4706036
D292920 4710724 4711361 4715063 4716319 4716391
4723305 D294257 4727306 4727583 4730195 4734635
4737976 4740794 4741018 4741034 4742562 D295627
D295975 4751737 4761621 4764737 D297734 D297735
D297736 4777564 Re.32768 4783697 D299232 4797929
4798975 4800348 4802236 4803726 4809356 4811377
4811404 4816774 4817157 4823098 D300742 D300827
4827226 4827507 4829274 4829543 4837534 4843621
4845772 4851966 4868576 4872196 4873683 4876552
4876740 D304189 4879533 4885553 4887050 4890199
D305427 4896124 4896361 4897873 D305717 4903327
D306163 4904549 4905288 4905301 D306299 4910470
4912602 4916262 4918403 4918732 4922209 4924194
4930126 D309301 D309451 4945570 4954796 4956854
4963812 4963843 4965537 4970475 4972355 4972432
4972455 4975808 4982108 4984219 4989230 D314173
4992753 4998289 D315330 D315543 5004992 5008925
5010309 5010570 5014294 5014346 D316859 5017856
5018188 5020076 5020091 5020092 5020093 5023580
5023866 5023911 5025387 5028859 5029233 5036532
5040127 5042071 5045824 5053924 5055800 5055802
5055803 5057762 5058136 5059885 5060264 5060294
5063340 5065408 5067139 5068625 5070310 5077757
5081674 5083304 5093632 D325028 5107487 5109536
5111162 5113400 5113436 5117441 5117449 5121047
5121288 5121412 5122722 D327062 5124889 5127040
5127042 5128834 5130682 5130683 5133010 5136135
5140286 5142551 5142696 5148471 5150075 5150359
5150384 5152006 5152007 5153590 5157693 5159283
5160898 5163159 5164652 5166596 5166642 5170173
5170492 5173672 5175759 5175874 5177458 5182749
5185566 5187640 5187809 5192924 5193223 5195106
5195108 5198887 5200655 5201069 5202654 5203009
D334746 5204977 5205751 5208566 5210793 5211581
5212815 5212826 5214675 5214774 5220290 5222078
5222104 5222251 5224122 5230007 5230093 5233506
5233633 5235492 5237257 5237570 5239127 5239294
5241545 5241548 5241592 5241650 5241688 5241693
D338887 5242767 D339127 D339335 D339336 D339337
5247544 D339578 5249302 5250916 5251331 5253292
m3td_us.bk : patent.fm5 Page 61 Thursday, November 18, 1999 9:46 PM
Patent Information
62
English
5255292 5257414 5259005 5260170 5260988 5261119
5262710 5263052 5263055 5265219 D341589 5271042
D342248 5276685 5276707 5276913 5278527 5278832
5278994 5280637 5280644 D343615 D343616 D343834
D343835 5287553 5287555 5287556 5289505 D344512
5297142 5299232 5301364 5301365 5308716 5312705
5321847 5323421 5325429 D348250 D348427 5327642
D348665 D348666 D348668 5331123 D349273 5336984
5338909 D350113 D350348 D350349 D350350 5349588
5351245 D351375 5359696 5361400 5363071 5365549
D352503 5366826 5367538 5367558 5371791 D353131
5373101 D353361 5375143 5375258 D353587 D353588
5379324 5384825 5392000 5392023 5396654 D356309
5402447 5404120 5404582 5406146 5406562 D357224
D357457 5410275 5414711 D358148 5420759 5424689
5428820 5428836 5430416 5432017 5434947 5436589
5436802 5438684 D361070 5444764 5446763 5448763
5448770 5448771 5453997 D362840 D362852 5461643
5463628 5465412 5469177 5475752 D365094 5477192
D365817 5486843 5487184 5488335 5490177 5493198
5493700 5493714 5495206 5497126 5497383 D367640
5499273 5504812 5506490 D368696 5508709 5510693
5511235 5513078 5513382 D369359 5513996 D369598
D369797 5519303 5519346 5519506 5519777 D370016
D370463 5526398 D370672 5530922 5539360 5542103
5542106 5544250 D372481 5546380 D372896 5551078
5555550 5559471 D374013 5561436 D374227 D374424
5565881 5570453 5572223 5572224 5577267 5577268
D375932 D375952
Other patents pending
m3td_us.bk : patent.fm5 Page 62 Thursday, November 18, 1999 9:46 PM
Motorola Limited Warranty 63 English
Motorola Limited Warranty
I. What This Warranty Covers And For How Long:
Motorola Inc. (Motorola) warrants the Motorola PCS Subscriber
Radiotelephone products and accessories against defects in
material and workmanship under normal use and service for a
period of time specified by the product’s serial number from the
date of installation.
AA Installation, in the case of radiotelephones, accessories or
batteries that are not installed in a vehicle, means the date
that the product is placed into subscriber service. Installation
will be deemed to be no later than thirty (30) days from
date of delivery of the Product to you the owner.
The warranty time period is specified by the last digit of the
mechanical serial number found on each PCS product. Products
sold under this warranty may have either a “P”, “Y”, “A”, “B”,
“C”, or “D” or nothing in the eleventh position of the serial
number. If there is no letter or an “A”, the product comes with a
(1) one year warranty. Products that have a “D” have a (2) two
year warranty. Products that have a “Y” or a “B” have a (3) three
year warranty, and products that have a “P” or a “C” have a (5)
five year warranty commencing from the date of installation. The
warranty time period for radiotelephone accessories and batteries
is as follows:
PCS portable telephone batteries 1 year
Carrying cases Defect free at time of shipment
Other radiotelephone accessories 1 year
Motorola, at its option, will, at no charge, either repair, replace,
or refund the purchase price of the PCS Subscriber
Radiotelephone Product during the warranty period, provided it
is returned in accordance with the terms of this warranty to the
Motorola National Service Center or Service Providers service
shop qualified by Motorola. Repair, at Motorola’s option, may
include the replacement of parts or boards with functionally
equivalent reconditioned or new parts or boards. Replaced parts
or accessories, batteries or boards are warranted for the balance
of the original time period. All returned accessories, batteries,
parts and PCS telephone equipment shall become the property of
Motorola.
m3td_us.bk : warrant.fm5 Page 63 Thursday, November 18, 1999 9:46 PM
Motorola Limited Warranty
64
English
II. Warranty Conditions:
This express limited warranty is extended by Motorola to the
original subscriber buyer or lessee only and is not assignable or
transferrable to subsequent subscriber buyers or lessees. This is
the complete warranty for PCS Subscriber Radiotelephone
Products by Motorola. Motorola assumes no obligation or liability
for additions or modifications to this warranty unless made in
writing and signed by an officer of Motorola. Unless made in
separate written agreement between Motorola and you,
Motorola does not warrant the installation, maintenance or
service of the equipment, accessories, batteries or parts.
Rechargeable batteries are warranted only if battery capacity falls
below 80% of rated capacity, or the battery develops leakage.
This warranty becomes void for all types of batteries if:
a. the batteries are charged by other than Motorola approved
battery chargers specified for the charging of the battery.
b. any of the seals on the battery are broken or show evidence of
tampering.
c. the battery is used in equipment or service other than the PCS
radiotelephone equipment for which it is specified.
Motorola cannot be responsible in any way for any ancillary
equipment not furnished by Motorola which is attached to or
used in connection with Motorola’s PCS Subscriber
Radiotelephone Products, or for operation of our equipment with
any ancillary equipment and all such equipment is expressly
excluded from this warranty. Furthermore, Motorola cannot be
responsible for any damage to Motorola equipment resulting
from the use of ancillary equipment not furnished by Motorola
for use with PCS subscriber equipment.
When the product is used in conjunction with ancillary or
peripheral equipment not manufactured by Motorola, Motorola
does not warrant the operation of the product/ peripheral
combination, and Motorola will honor no warranty claim where
the product is used in such a combination and it is determined by
Motorola that there is no fault with the Motorola product.
Motorola specifically disclaims any responsibility for any damage
caused in any way by the use of portable radiotelephone
accessories and peripherals (specific examples include, but are
not limited to: batteries, chargers, adapters, and power supplies)
when such accessories and peripherals are not manufactured or
supplied by Motorola. Motorola disclaims liability for range,
coverage, availability, or operation of the PCS System which is
provided by the Service Provider.
m3td_us.bk : warrant.fm5 Page 64 Thursday, November 18, 1999 9:46 PM
Motorola Limited Warranty 65 English
III. What This Warranty Does Not Cover:
(a) Defects or damage resulting from use of the product in other
than its normal and customary manner.
(b) Defects or damage from misuse, accident or neglect.
(c) Defects or damage from improper testing, operation,
maintenance, installation, adjustment, or any alteration or
modification of any kind.
(d) Breakage or damage to antennas unless caused directly by
defects in material or workmanship.
(e) Products disassembled or repaired in such a manner as to
adversely affect performance or prevent adequate inspection
and testing to verify any warranty claim.
(f) Products which have had the serial number removed or made
illegible.
(g) Defects or damage due to spills of food or liquid.
(h) All plastic surfaces and all other externally exposed parts that
are scratched or damaged due to customer normal use.
(i) Products rented on a month- to- month basis.
(j) The portable phone keypad assembly and displays are not
covered after the first year.
IV. How To Get Warranty Service:
To receive warranty service, present your equipment to the
facility described below, along with your bill of sale or
comparable substitute proof of sale or lease bearing the date of
purchase, transceiver serial number and place of purchase or
installation if applicable.
Warranty service is available by returning Motorola branded
Radiotelephone Products to a Motorola Service Center,
authorized in writing by a Motorola Area Service Manager to
perform warranty work on Motorola PCS Subscriber
Radiotelephone products. A Carrier or Distributor branded
Radiotelephone Product may be returned to either (a) the specific
service shop qualified by Motorola’s National Service Center in
writing and operated by or affiliated with the PCS Service
Provider, or (b) a Motorola Authorized PCS Service Center.
In most cases the service shop which sold your PCS
Radiotelephone and accessories will provide warranty service. If
you need additional information, contact that shop, the customer
service department of your Service Provider, or Motorola at the
address at the end of this document. The unit or accessories,
together with any detachable parts such as antennas, battery
packs, and chargers, must be delivered to a qualified Motorola
Service Center, or a Motorola- qualified service shop,
transportation and insurance prepaid. When sent or brought to
the servicer, the Radiotelephone Product must be accompanied
by your name, address, and telephone number, name of Service
Provider, and a description of the problem.
m3td_us.bk : warrant.fm5 Page 65 Thursday, November 18, 1999 9:46 PM
Motorola Limited Warranty
66
English
V. General Provisions:
This warranty sets forth our responsibilities regarding this
product. Repair, replacement or refund of the purchase price at
Motorola’s option, is your exclusive remedy. This warranty is
given in lieu of all other express warranties, implied warranties,
including without limitation implied warranties of merchantability
and fitness for a particular purpose, are limited to the duration of
this limited warranty. Further, as the Service Provider is not
controlled by Motorola, no warranty is made as to coverage,
availability or grade of service provided by the Service Provider. In
no event shall Motorola be liable for damages in excess of the
purchase price of the PCS radiotelephone product, for any loss of
use, loss of time, inconvenience, commercial damages arising out
of the use or inability to use such product, to the full extent such
may be disclaimed by law.
VI. Patent And Software Provisions:
Motorola will defend at its own expense, any suit brought
against you to the extent that it is based on a claim that the PCS
Subscriber Radiotelephone Product parts infringes a United States
patent, and Motorola will pay those costs and damages finally
awarded against you in any such suit which are attributable to
any such claim, but such defense and payments are conditioned
on the following:
(i) that Motorola will be notified promptly in writing by you of
any notice of such claim; and
(ii) that Motorola will have sole control of the defense of such suit
and all negotiations for its settlement or compromise; and
(iii) should the PCS Radiotelephone, accessory, battery or parts
become, or in Motorola’s opinion be likely to become the
subject of a claim of infringement of a United States patent
that you will permit Motorola, at its option and expense,
either to procure for you the right to continue using the PCS
Radiotelephone or parts or to replace or modify the same so
that it becomes non- infringing or to grant you a credit for
such PCS Radiotelephone or parts as depreciated and accept
its return. The depreciation will be an equal amount per year
over the lifetime of the PCS Subscriber Radiotelephone,
accessories, battery or parts as established by Motorola.
Motorola will have no liability to you with respect to any claim of
patent infringement which is based upon the combination of the
PCS Radiotelephone or parts furnished hereunder with software,
apparatus or devices not furnished by Motorola, nor will
Motorola have any liability for the use of ancillary equipment or
software not furnished by Motorola which is attached to or used
in connection with the PCS Radiotelephone. The foregoing states
the entire liability of Motorola with respect to infringement of
patents by the PCS Radiotelephone, accessories, batteries or any
parts thereof.
Laws in the United States and other countries preserve for
Motorola certain exclusive rights for copyrighted Motorola
software such as the exclusive rights to reproduce in copies and
distribute copies of such Motorola software. Motorola software
may be copied into, used in and redistributed with only the PCS
Subscriber Radiotelephone Product associated with such
Motorola software. No other use, including without limitation
disassembly, of such Motorola software or exercise of exclusive
rights in such Motorola software is permitted.
m3td_us.bk : warrant.fm5 Page 66 Thursday, November 18, 1999 9:46 PM
Motorola Limited Warranty 67 English
VII. State Law Rights:
Some states do not allow the exclusion or limitation of incidental
or consequential damages, or limitations on how long an implied
warranty lasts, so the above limitations or exclusions may not
apply to you.
This warranty gives you specific legal rights, and you may also
have other rights which vary from state to state.
m3td_us.bk : warrant.fm5 Page 67 Thursday, November 18, 1999 9:46 PM
Motorola Limited Warranty
68
English
m3td_us.bk : warrant.fm5 Page 68 Thursday, November 18, 1999 9:46 PM
Index 69 English
Index
A
access number for voice mail ................52
Accessories ..........................................57
accessory connector port ......................13
analog
channel ...........................................46
mode ..............................................20
antenna ...............................................13
audible timer
one-minute .....................................36
repeating .........................................36
automatic answer ................................48
B
Batteries
Charging .........................................15
Installing the Batteries ......................15
Low battery warning ........................17
Maintaining .....................................16
Removing ........................................16
battery
life ...................................................59
Battery charge indicator .......................14
busy signal ...........................................59
button
Message ..........................................13
Smart ..............................................13
C
call
ending .............................................19
placing ..................................... 14, 19
calling card call ......................32
restricting call placement .......43
receiving ..........................................19
while phone is locked ............42
Call Back number .................................54
call timer
automatically display individual ........36
cumulative .......................................35
individual .........................................35
resettable ........................................35
resetting ..........................................35
call waiting ..........................................26
Caller ID ...............................................28
Caller Line ID ................................. 26, 27
calling card
PIN number .....................................32
placing calling card call ....................32
storing information ................... 32, 60
calls
dialed ..............................................28
managing recent .............................26
received ...........................................27
cellular system .....................................47
changing your number .........................47
clearing a memory entry ......................23
connector port .....................................13
cumulative timer ..................................35
D
dialed calls ...........................................28
digital
channel ...........................................46
indicator ................................... 14, 19
mode ..............................................20
Display .................................................14
display
System Identification .......................49
E
earpiece ...............................................13
ending a call ........................................19
F
Fault finding ................................. 59, 61
function keys .......................................13
H
headset jack .........................................13
Home Only Mode ................................48
home system .......................................47
m3td_us.bk : m3td_us.IX Page 69 Thursday, November 18, 1999 9:46 PM
Index
70
English
I
In Use Indicator ................................... 14
In-Building Indicator ............................ 14
indicator
Digital ............................................. 14
In Use ............................................. 14
In-Building ...................................... 14
No Service ...................................... 14
Short Message Service .................... 53
Installing the Batteries ......................... 15
J
jack, headset ....................................... 13
K
key answer, multiple ........................... 48
keypad tones ....................................... 39
L
language, select for display ................. 49
lock code
changing ........................................ 42
viewing ........................................... 42
locking phone
answering calls while phone
is locked ....................................... 42
automatically .................................. 41
manually ......................................... 41
locking/unlocking phone ..................... 41
Low battery warning ........................... 17
M
Master Clear ........................................44
Master Reset ........................................44
memory location
editing .............................................33
service level .....................................43
using phone book ............................21
menus
entering ...........................................13
navigating ..................................3, 25
message
clearing ...........................................55
unlocking ........................................54
viewing a short message ..................53
message alert .......................................53
Message Center button ........................13
messages, locking ................................54
microphone ..........................................13
Multiple Key Answer ............................48
N
No Service Indicator ..............................14
non-wireline carrier ..............................47
O
option
clearing stored information ..............44
reset ................................................44
P
Pager Mode .........................................46
pause dialing ........................................31
pauses
entering into a number ....................31
placing a call with pauses ................31
phone book
clearing entry ..................................23
editing entries .................................33
entering a name ..............................22
entering letters ................................22
entry
recalling by location ...............30
recalling by name ..................30
recalling with short cuts .........23
recalling entry
by location .............................22
by name ................................22
storing entry ....................................30
storing names and numbers .............21
using ...............................................21
phone number
viewing your own ..................... 19, 46
phone overview ...................................13
PIN number ..........................................32
placing a call .................................14, 19
power button ................................ 13, 59
Priority Call ..........................................23
m3td_us.bk : m3td_us.IX Page 70 Thursday, November 18, 1999 9:46 PM
Index 71 English
R
recalling entry by location ....................22
recalling entry by name ........................22
received calls ........................................27
receiving call
automatic answer ............................48
multiple key answer .........................48
procedure ........................................19
Recent Calls menu ...............................26
redialing a number ...............................20
Removing your battery .........................16
retractable antenna ..............................13
Reversed Preference Mode ...................48
ringer
selecting style ..................................39
road map .............................................25
S
Scan A Mode .......................................48
Scan B Mode ........................................48
scratchpad tones .................... 23, 39, 60
scrolling speed
setting .............................................55
security options
resetting ..........................................44
service level .....................................43
Short Message Service
clearing message .............................55
indicators ........................................53
locking message ..............................54
unlocking a message .......................54
viewing messages ............................53
Short message service symbol ..............14
Short Messaging Services (SMS) ...........53
Signal strength symbol .........................14
single timer ..........................................37
Smart Button .......................................13
smart button ........................................13
Speed Dial ............................................23
Standard Mode ....................................47
storing
calling card information ...................32
names and numbers ........................21
storing names and numbers .................30
Symbols ...............................................14
System Identification
viewing ...........................................49
System Mode .......................................47
T
timer
audible one-minute .........................36
audible repeating ............................36
automatically display
individual timer .............................36
cumulative call timer ........................35
individual call timer ..........................35
one-minute audible .........................36
repeating audible timer ...................36
reset ................................................35
resettable call timer .........................35
single ..............................................37
tones
alternating high/low ........................60
turning scratchpad tones
on and off .....................................39
Troubleshooting ............................ 59, 61
Turbo Dial™ ................................. 21, 23
turning the phone off ..........................19
turning the phone on ...........................19
U
unanswered call indicator ....................19
unlock phone .......................................59
V
voice mail ............................................60
dialing .............................................52
edit access number ..........................52
voice privacy ........................................41
volume
adjusting .........................................14
muting ............................................20
volume keys .........................................13
W
What to do if... ............................. 59, 61
wireline carrier .....................................47
m3td_us.bk : m3td_us.IX Page 71 Thursday, November 18, 1999 9:46 PM
Index
72 68P To be advised
English
m3td_us.bk : m3td_us.IX Page 72 Thursday, November 18, 1999 9:46 PM
