Motorola Mobility T5GK1 Portable Cellular CDMA Transceiver User Manual INSTRUCTION MANUAL

Motorola Mobility LLC Portable Cellular CDMA Transceiver INSTRUCTION MANUAL

Exhibit 8 Users Manual

APPLICANT: MOTOROLA, INC. FCC ID: IHDT5GK1
INSTRUCTION MANUAL
• A preliminary draft copy of the User’s Manual follows this cover page.
• The User’s Manual will have the following text added to it:
"NOTE: This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This equipment
generates, uses and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If
this equipment does cause harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
. Reorient or relocate the receiving antenna.
. Increase the separation between the equipment and receiver.
. Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
. Consult the dealer or an experienced radio/TV technician for help."
The text on the following two pages will be added for SAR Data, related to FCC requirements.
EXHIBIT 8
motorola.com
680XXXX142-O
battery & SIM card
using your phone
1 2 34
5
6
List
Change Ringtone
Set Alarm
Adjust Date & Time
12
4
Call in-process
Out of network
Keypad Locked
Vibrate
Silent
action icons
Enter numbers.
Enter letters.
Add a number to your phonebook.
Delete an item.
Select an option
Write a Message
Use Speakerphone
These icons help you use your phone. When the fol-
lowing icons show on your screen you can:
speed dial
U
se s
p
ee
d
di
a
l
num
b
ers to qu
ic
kly call so
in your phonebook.
For contacts 1-9 in
y
our phon
the corresponding k
e
F
or the remaining
t
h
e con
t
act n
to call y
pre
phonebook
use the phonebook to make a call
| [select name] |
add a new phonebook entry
enter number | | enter name |
Whenever you see press to add the
number to the phonebook.
or
delete phonebook entry
| [select name] |
text messages
send a text message
|
enter message
|
|
enter number or press
an
|
TIP: Press a ke
y mo
letters. For e
xample
times.
To
delete
automatically deleted
he SIM card is full.
date, time, & alarms
just dat
e & time
| enter date & time |
| |
r
m
| enter alarm time |
|
|
cemail
t
o
v
oicemail
|
ca
ll
v
o
icemail number
If y
our
v
oicemail number is stored as phonebo
contact 1, press and hold the 1 ke
y to qu
your voicemail messages.
loc
k/unloc
k
To lock/unloc
k y
presses, pre
m
| |
15
rted b
y your service provider.
Press *** [number code] * to
access adv
anced phone settings.
nge language
time f
ormat
mail
number
s ON
| OFF
N
| OFF
nce Displa
y* ON | OFF
y
pad loc
k ON | OFF
t SIM Pin
S
IM Pin
O
N | OFF
Restricted Calling (Phon
Reset factory settings
520
470
644
510 | 511
250 | 251
500 |
1
260
|
hone Set
ting Number Code
advanced settings
mess
To displa
**
TIP: Press a key more than once to see more
ters. F
or example, for the letter N, press 6 two
mes.
ON OFF
change ringtones
change ringer volume
change earpiece volume
|
| | | |
screen, press
| | |
|
|
TIP: To change your ringer to vibrate, press
until the phone vibrates.
|
Navigation Pad
Signal Strength
Make &
answer calls.
Battery Strength
Action Key
Phonebook
Turn on & off,
hang up, exit
menus.
Lock & unlock
keypad.
Headset &
Phone Charge
Connector
MOTOFONE F3
weak strong
rings and volume
|
|
Set Balance Inq
Reserved for
MOTOROLA warranty
Language 2
DRAFT
FT
A
DR
R
R
D
DR
DR
DR
DR
DR
DR
DR
D
D
DR
DR
DR
DR
DR
DR
DR
DR
DR
D
DR
DR
DR
DR
DR
DR
DR
DR
DR
DR
DR
DR
D
D
D
D
D
D
D
D
D
D
D
D
D
D
D
D
D
D
D
D
D
D
D
D
D
D
D
D
D
D
D
D
D
D
D
D
D
D
D
D
D
D
D
D
D
D
D
D
D
D
D
D
D
D
AFT
F
T
T
T
T
T
T
T
T
T
T
T
T
T
T
AF
AF
AF
FT
T
T
FT
T
FT
FT
T
T
T
FT
FT
FT
T
FT
FT
FT
T
T
F
A
c
tion
K
e
y
P
r
ess
t
hi
s
k
e
y
to select
to sele
i
tems in menus & on th
eitems in menus & on th
T
T
s
creen.
scre
Phon
e
boo
kPhonebook
O
pens
ys y
oo
u
r
sto
r
edur stored
T
T
p
hone number list.
number list.
M
ain M
e
n
uMain Menu
N
a
v
igation
K
e
y
FT
FT
M
o
Mo
v
e
le
f
t, ri
g
ht, u
p
& do
wn.
F
FT
FT
FT
FT
FT
FT
FT
FT
T
T
T
5
6
1
W
r
i
te
M
essa
g
es
Write Me
R
ead Messages
Read Messag
View Recent Call Listew Recent Call L
Ch
3
RAF
RAF
A
A
A
A
A
A
A
A
A
A
A
A
V
oic
V
T
e
T
xt messa
Successful
T
let
te
t
time
T
T
DR
DRA
A
RA
RA
ma
k
e
a ca
lle a call
enter num
b
er
enter num
|
e
nd a call
a call
|
A
A
A
A
A
A
A
AA
u
se s
p
ea
kuse speak
e
r
ph
on
ephone
Wh
ene
Whe
v
e
r
y
o
u see on the scree on the scr
t
o s
tto s
art
/
stop spea
k
e
rp
h
one.
erphone.
RA
RA
RARA
R
vi
e
w
rview r
ecent callsec
R
R
R
A
A
A
A
A
|
RA
RA
calls
R
R
R
R
DR
DR
R
R
R
R
R
R
R
RA
RA
R
R
FT
T
DRAFT
D
DRA
A
RA
AFT
T
T
AF
A
FT
AF
T
|
||
A
A
A
A
A
A
A
A
||
and select a name nd select a name
|
|
|
|
r
e
ad
a
t
ee
x
t messa
gxt messag
ee
more than once to see moremore than once to see more
mple, fmple, f
oo
r the letr the let
ter N, press
t
6
tww
oo
ete a cete a c
haracterharacter
,
r
press . To delete the entire
AA
A
A
A
A
A
A
A
A
A
A
A
A
A
A
A
A
A
A
A
A
A
A
A
A
|
||
||
|
|
T
o
T
read and scroll through the message press .roll through th
|
|
[
messa
g
e o
p
ens
]
rr
ee
ply t
ply t
oo
a
t
e
x
t
messa
gg
ee
A
A
A
A
A
A
A
A
A
A
A
A
A
A
A
A
A
A
A
A
A
A
A
A
HiHi
NONO
TETE
::
TT
ee
TT
T
xt messages are autoxt messages are auto
(
oldest to n
e(oldest to ne
ww
ee
st) when the Sst) when
|
enter messa
g
e
essage
||
||
T
adju
|
set an alar
m
|
|
T
T
vv
oicem
oi
l
is
t
en ten t
oo
If
T
T
FT
T
AF
AF
FT
FT
AF
AF
F
F
T
T
T
T
T
F
AF
AF
AF
AF
AF
AF
AF
AF
AF
T
T
T
T
T
T
T
T
T
T
T
T
T
T
T
T
FT
FT
FT
FT
FT
FT
FT
FT
FT
FT
FT
FT
FT
FT
TT
o
T
vi
e
w
a p
re
vious message, press .s message, pr
FT
FT
FT
F
F
F
F
F
A
A
A
A
A
A
A
A
A
A
A
A
A
A
A
A
A
A
A
A
T
T
T
T
tt
u
u
rr
n
of
f
an alar
f
m
|
|
|
T
T
T
T
T
T
T
T
T
T
T
T
T
T
T
A
A
|
message, press and hold .sage, press a
FT
F
F
F
F
FT
DRAFT
DR
DRA
A
A
RA
AFT
FT
l someone l someone
honebook, press and hold honebook, press and hol
ypad number for two seconds.ypad number for two seconds.
ing conting cont
a
cts
i
n
yacts in
o
ur
ph
one
b
oo
k
, enter
k, enter
ct number and press ct number and
#
.
F
o
r
exam
pl
e,
e,
l yl y
our 1our 1
55
phonebook cont
phone
ac
t,
press ress
15# 15#
.
er
ebook ebo
o quico quic
kly access
kly ac
oc
k k
e
y
p
a
dpad
y
o
u
r
k
e
ypa
d
to pr
e
v
e
nt acc
id
en
tt accident
al
k
e
y
press and hold the press and hol
*
k
e
y
f
f
oo
r 2 secon
d
s.
r 2 sec
T
o
T
v
i
e
w
y
our
b
a
l
ance an
d
exp
i
rat
i
on
balance and e
date, press . .
TT
oo
TT
T
top up y top u
o
y
ur balance, press and
ce, press and
h
o
ld
hold
##
..
prpr
ep
aepa
i
d (optional)
id (option
AF
AF
AF
AF
AF
F
AF
AF
AF
A
FT
FT
FT
FT
FT
FT
FT
FT
F
N
ONO
T
E
TE
F
: M
a: Ma
y not be supportedy not be supported
F
F
F
T
a
T
Chang
Select tim
Set V
oicema
V
V
oice P
V
r
ompts
KK
ee
ypad tones ON
PP
repaid B
repa
a
lance
AA
uto
kuto k
e
e
y
y
pa
Set SSet S
Pho
DRAFT
AFT
DR
RA
A
RAF
honebook only) honebook o
00
11
0 0
||
261
261
30
0
31
0
|
3131
11
000
splay
P
hon
e
In
f
ormation D
e
tails
nformation Details
press:
press:
**9999*9*
RA
A
160 161
|
* if su
pp
orted b
y
y
our service
p
rovide
r* if supported by your service prov
Inquiry Number to *ry Number to *
6
42
##
R
ese
rv
ed
fo
r
Reserved
M
O
T
O
R
O
LA warrant
yMOTOROLA warranty
Lan
g
ua
g
e
1
DRAFT
DRAFT
DRAFT
DRAFT
Motorola, Inc.
Consumer Advocacy Office
1307 East Algonquin Road
Schaumburg, IL 60196
www.hellomoto.com
Certain mobile phone features are dependent on the capabilities and settings
of your service provider’s network. Additionally, certain features may not be
activated by your service provider, and/or the provider’s network settings may
limit the feature’s functionality. Always contact your service provider about
feature availability and functionality. All features, functionality, and other
product specifications, as well as the information contained in this user’s
guide are based upon the latest available information and are believed to be
accurate at the time of printing. Motorola reserves the right to change or
modify any information or specifications without notice or obligation.
MOTOROLA and the Stylized M Logo are registered in the US Patent &
Trademark Office. All other product or service names are the property of their
respective owners.
© Motorola, Inc., 2006.
Caution: Changes or modifications made in the radio phone, not expressly
approved by Motorola, will void the user’s authority to operate the equipment.
Manual Number: 680XXX142-O
Safety and General Information
This section contains important information on the safe and efficient operation
of your mobile device. Read this information before using your mobile device.
Exposure To Radio Frequency (RF) Energy
Your mobile device contains a transmitter and receiver. When it is ON, it
receives and transmits RF energy. When you communicate with your mobile
device, the system handling your call controls the power level at which your
mobile device transmits.
Your Motorola mobile device is designed to comply with local regulatory
requirements in your country concerning exposure of human beings to RF
energy.
Operational Precautions
For optimal mobile device performance and to be sure that human exposure to
RF energy does not exceed the guidelines set forth in the relevant standards,
always follow these instructions and precautions.
Product Operation
When placing or receiving a phone call, hold your mobile device just like you
would a landline phone.
If you wear the mobile device on your body, always place the mobile device in a
Motorola-supplied or approved clip, holder, holster, case, or body harness. If
you do not use a body-worn accessory supplied or approved by Motorola, keep
the mobile device and its antenna at least 2.5 centimeters (1 inch) from your
body when transmitting.
When using any data feature of the mobile device, with or without an accessory
cable, position the mobile device and its antenna at least 2.5 centimeters (1
inch) from your body.
Using accessories not supplied or approved by Motorola may cause your
mobile device to exceed RF energy exposure guidelines. For a list of
Motorola-supplied or approved accessories, visit our website at
www.motorola.com
RF Energy Interference/Compatibility
Nearly every electronic device is subject to RF energy interference from
external sources if inadequately shielded, designed, or otherwise configured
for RF energy compatibility. In some circumstances your mobile device may
cause interference with other devices.
This device complies with Part 15 of the FCC Rules. Operation is subject to
the following two conditions: (1) this device may not cause harmful
interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation.
Follow Instructions to Avoid Interference Problems
Turn off your mobile device in any location where posted notices instruct you
to do so. These locations include hospitals or health care facilities that may be
using equipment that is sensitive to external RF energy.
In an aircraft, turn off your mobile device whenever instructed to do so by
airline staff. If your mobile device offers an airplane mode or similar feature,
consult airline staff about using it in flight.
Pacemakers
If you have a pacemaker, consult your physician before using this device.
Persons with pacemakers should observe the following precautions:
* ALWAYS keep the mobile device more than 20 centimeters (8 inches) from
your pacemaker when the mobile device is turned ON.
* DO NOT carry the mobile device in the breast pocket.
Use the ear opposite the pacemaker to minimize the potential for interference.
* Turn OFF the mobile device immediately if you have any reason to suspect
that interference is taking place.
Hearing Aids
Some digital mobile devices may interfere with some hearing aids. In the
event of such interference, you may want to consult your hearing aid
manufacturer or physician to discuss alternatives.
Other Medical Devices
If you use any other personal medical device, consult your physician or the
manufacturer of your device to determine if it is adequately shielded from
RF energy.
Driving Precautions
Check the laws and regulations on the use of mobile devices in the area
where you drive. Always obey them.
When using your mobile device while driving, please:
* Give full attention to driving and to the road. Using a mobile device may
be distracting. Discontinue a call if you can’t concentrate on driving.
* Use handsfree operation, if available.
* Pull off the road and park before making or answering a call if driving
conditions so require.
Responsible driving practices can be found in the “Smart Practices While
Driving” section at the end of this guide and/or at the Motorola website:
www.motorola.com/callsmart.
Operational Warnings
Obey all posted signs when using mobile devices in public areas, such as
health care facilities or blasting areas.
Automobile Air Bags
Do not place a mobile device in the air bag deployment area.
Potentially Explosive Atmospheres
Areas with potentially explosive atmospheres are often but not always posted,
and can include fueling areas such as below decks on boats, fuel or chemical
transfer or storage facilities, or areas where the air contains chemicals or
particles, such as grain, dust, or metal powders.
When you are in such an area, turn off your mobile device, and do not remove,
install, or charge batteries. In such areas, sparks can occur and cause an
explosion or fire.
Damaged Products
If your mobile device or battery has been submerged in water, punctured, or
subjected to a severe fall, do not use it until you take it to a Motorola Authorized
Service Center. Do not attempt to dry it with an external heat source, such as a
microwave oven.
Batteries and Chargers
If jewelry, keys, beaded chains, or other conductive materials touch exposed
battery terminals, this could complete an electrical circuit (short circuit), become
very hot, and could cause damage or injury. Be careful when handling a
charged battery, particularly when placing it inside a pocket, purse, or other
container with metal objects. Use only Motorola Original ™ batteries and
chargers.
CAUTION: To avoid risk of personal injury, do not dispose of your battery in a
fire.
Your battery, charger, or mobile device may contain symbols, defined as
follows:
Symbol Definition
Important safety information follows.
Do not dispose of your battery or mobile device in a fire.
Your battery or mobile device may require recycling in
accordance with local laws. Contact your local regulatory
authorities for more information.
Do not throw your battery or mobile device in the trash.
Your mobile device contains an internal lithium ion battery.
Choking Hazards
Your mobile device or its accessories may include detachable parts, which
may present a choking hazard to small children. Keep your mobile device and
its accessories away from small children.
Glass Parts
Some parts of your mobile device may be made of glass. This glass could
break if the product is dropped on a hard surface or receives a substantial
impact. If glass breaks, do not touch or attempt to remove. Stop using your
mobile device until the glass is replaced by a qualified service center.
Repetitive Motion
When you repetitively perform actions such as pressing keys or entering
finger-written characters, you may experience occasional discomfort in your
hands, arms, shoulders, neck, or other parts of your body. If you continue to
have discomfort during or after such use, stop use and see a physician.
Information from the World Health Organization
Present scientific information does not indicate the need for any special
precautions for the use of mobile phones. If you are concerned, you may want
to limit your own or your children’s RF exposure by limiting the length of calls
or by using handsfree devices to keep mobile phones away from your head
and body.
Source: WHO Fact Sheet 193
Further information: http://www.who.int./peh-emf
Export Law Assurances
This product is controlled under the export regulations of the United States of
America and Canada. The Governments of the United States of America and
Canada may restrict the exportation or re-exportation of this product to certain
destinations. For further information contact the U.S. Department of Commerce
or the Canadian Department of Foreign Affairs and International Trade.
Wireless: The New Recyclable
Your wireless phone can be recycled. Recycling your wireless phone reduces
the amount of waste disposed in landfills and allows recycled materials to be
incorporated into new products.
The Cellular Telecommunications Industry Association (CTIA) and its members
encourage consumers to recycle their phones and have taken steps to
promote the collection and environmentally sound recycling of end-of-life
wireless devices.
As a wireless phone user, you have an important role in ensuring that this
phone is recycled properly. When it comes time to give this phone up or trade it
in for a new one, please remember that the phone, the charger, and many of
its accessories can be recycled. It's easy. To learn more about CTIA's
Recycling Program for Used Wireless Devices, please visit us at
http://promo.motorola.com/recycle/phones/whyrecycle.html
032374o
032376o
032375o
032378o
Li Ion BATT
Software Copyright Notice
The Motorola products described in this manual may include copyrighted M
otorola and third-party software stored in semiconductor memories or other
media. Laws in the United States and other countries preserve for Motorola and
third-party software providers certain exclusive rights for copyrighted software,
such as the exclusive rights to distribute or reproduce the copyrighted software.
Accordingly, any copyrighted software contained in the Motorola products
may not be modified, reverse-engineered, distributed, or reproduced in any
manner to the extent allowed by law. Furthermore, the purchase of the Motorola
products shall not be deemed to grant either directly or by implication, estoppel,
or otherwise, any license under the copyrights, patents, or patent applications of
Motorola or any third-party software provider, except for the normal, non-exclusive,
royalty-free license to use that arises by operation of law in the sale of a product.
Specific Absorption Rate Data
This model wireless phone meets the government’s requirements for
exposure to radio waves.
Your wireless phone is a radio transmitter and receiver. It is designed and
manufactured not to exceed limits for exposure to radio frequency (RF)
energy set by the Federal Communications Commission (FCC) of the U.S.
Government and by the Canadian regulatory authorities. These limits are
part of comprehensive guidelines and establish permitted levels of RF
energy for the general population. The guidelines are based on standards
that were developed by independent scientific organizations through
periodic and thorough evaluation of scientific studies. The standards
include a substantial safety margin designed to assure the safety of all
persons, regardless of age or health.
The exposure standard for wireless mobile phones employs a unit of
measurement known as the Specific Absorption Rate, or SAR. The SAR
limit set by the FCC and by the Canadian regulatory authorities is 1.6
W/kg.1 Tests for SAR are conducted using standard operating positions
accepted by the FCC and by Industry Canada with the phone transmitting
at its highest certified power level in all tested frequency bands. Although
the SAR is determined at the highest certified power level, the actual SAR
level of the phone while operating can be well below the maximum value.
This is because the phone is designed to operate at multiple power levels
so as to use only the power required to reach the network. In general, the
closer you are to a wireless base station, the lower the power output.
Before a phone model is available for sale to the public in the U.S. and
Canada, it must be tested and certified to the FCC and Industry Canada
that it does not exceed the limit established by each government for safe
exposure. The tests are performed in positions and locations (e.g., at the
ear and worn on the body) reported to the FCC and available for review by
Industry Canada. The highest SAR value for this model phone when
tested for use at the ear is 0.78 W/kg, and when worn on the body, as
described in this user guide, is 0.78 W/kg. (Body-worn measurements
differ among phone models, depending upon available accessories and
regulatory requirements).2
While there may be differences between the SAR levels of various phones
and at various positions, they all meet the governmental requirements for
safe exposure. Please note that improvements to this product model could
cause differences in the SAR value for later products; in all cases, products
are designed to be within the guidelines.
Additional information on Specific Absorption Rates (SAR) can be found on
the Cellular Telecommunications & Internet Association (CTIA) Web site:
http://www.phonefacts.net
or the Canadian Wireless Telecommunications Association (CWTA) Web
site:
http://www.cwta.ca
1. In the United States and Canada, the SAR limit for mobile phones used by
the public is 1.6 watts/kg (W/kg) averaged over one gram of tissue. The
standard incorporates a substantial margin of safety to give additional
protection for the public and to account for any variations in measurements.
2. The SAR information includes the Motorola testing protocol, assessment
procedure, and measurement uncertainty range for this product.

Navigation menu
