Motorola Mobility T5HA1 Portable Cellular CDMA Transceiver User Manual W212 UM EN
Motorola Mobility LLC Portable Cellular CDMA Transceiver W212 UM EN
Exhibit 8 Users Manual
INSTRUCTION MANUAL
A preliminary draft of the User’s Manual follows this page.
The text on the following two pages will be added to the user manual.
APPLICANT: MOTOROLA,INC.
FCC ID: IHDT5HA1
EXHIBIT 8
SAR Data
Specific Absorption Rate Data
SAR Da ta
This model wireless phone meets the
government’s requirements for exposure to radio
waves.
Your wireless phone is a radio transmitter and receiver. It is
designed and manufactured not to exceed limits for exposure to
radio frequency (RF) energy set by the Federal Communications
Commission (FCC) of the U.S. Government and by the Canadian
regulatory authorities. These limits are part of comprehensive
guidelines and establish permitted levels of RF energy for the
general population. The guidelines are based on standards that
were developed by independent scientific organizations through
periodic and thorough evaluation of scientific studies. The
standards include a substantial safety margin designed to assure
the safety of all persons, regardless of age or health.
The exposure standard for wireless mobile phones employs a unit
of measurement known as the Specific Absorption Rate, or SAR.
The SAR limit set by the FCC and by the Canadian regulatory
authorities is 1.6 W/kg.
1
Tests for SAR are conducted using
standard operating positions accepted by the FCC and by Industry
Canada with the phone transmitting at its highest certified power
level in all tested frequency bands. Although the SAR is
determined at the highest certified power level, the actual SAR
level of the phone while operating can be well below the
maximum value. This is because the phone is designed to operate
at multiple power levels so as to use only the power required to
reach the network. In general, the closer you are to a wireless
base station, the lower the power output.
Before a phone model is available for sale to the public in the U.S.
and Canada, it must be tested and certified to the FCC and Industry
Canada that it does not exceed the limit established by each
government for safe exposure. The tests are performed in
positions and locations (e.g., at the ear and worn on the body)
reported to the FCC and available for review by Industry Canada.
The highest SAR value for this model phone when tested for use at
the ear is 1.50W/kg, and when worn on the body, as described in
this user guide, is 0.71 W/kg.
(Body-worn
measurements differ among phone models, depending upon
available accessories and regulatory requirements).
2
While there may be differences between the SAR levels of various
phones and at various positions, they all meet the governmental
requirements for safe exposure. Please note that improvements to
this product model could cause differences in the SAR value for
later products; in all cases, products are designed to be within the
guidelines.
SAR Data
Additional information on Specific Absorption Rates (SAR) can be
found on the Cellular Telecommunications & Internet Association
(CTIA) Web site:
http://www.phonefacts.net
or the Canadian Wireless Telecommunications Association (CWTA)
Web site:
http://www.cwta.ca
1. In the United States and Canada, the SAR limit for mobile phones used
by the public is 1.6 watts/kg (W/kg) averaged over one gram of tissue.
The standard incorporates a substantial margin of safety to give
additional protection for the public and to account for any variations in
measurements.
2. The SAR information includes the Motorola testing protocol,
assessment procedure, and measurement uncertainty range for this
product.
motorola.com
W212
CDMA
1
HELLOMOTO
Welcome to the world of Motorola digital wireless communications! We are pleased that
you have chosen the Motorola W212 wireless phone.
Note:
The above illustration is for reference only. There may be slight differences between the appearances of handset,
keys and contents of display used in this manual and those of your handset. Please refer to your handset for actuality.
Earpiece
Listen to your voice
calls & messages.
Right Soft Key
Performs functions in
lower right display.
Power/End Key
Turn the phone on/off,
end calls, exit menus.
Navigation Key
Scroll up, down, left or right.
Microphone
Menu Key
Opens a sub-menu when
appears in the
display,or selects
a highlighted
feature.
Left Soft Key
Performs functions in lower
left display.
Send/Answer Key
Make & answer calls. Press in
idle screen to see list
of recently dialled calls.
2
Motorola, Inc.
Consumer Advocacy Office
1307 East Algonquin Road
Schaumburg, IL 60196
ZZZKHOORPRWRFRP
Certain mobile phone features are dependent on the capabilities
and settings of your service provider’s network. Additionally,
certain features may not be activated by your service provider,
and/or the provider's network settings may limit the feature’s
functionality. Always contact your service provider about feature
availability and functionality. All features, functionality, and other
product specifications, as well as the information contained in this
user's guide are based upon the latest available information and
are believed to be accurate at the time of printing. Motorola
reserves the right to change or modify any information or
specifications without notice or obligation.
MOTOROLA and the Stylized M Logo are registered in the US
Patent & Trademark Office. All other product or service names are
the property of their respective owners.
© Motorola, Inc. 2006.
Caution:
Changes or modifications made in the radio phone, not
expressly approved by Motorola, will void the user’s authority to
operate the equipment.
Software Copyright Notice
The Motorola products described in this manual may include
copyrighted Motorola and third-party software stored in
semiconductor memories or other media. Laws in the United
States and other countries preserve for Motorola and third-party
software providers certain exclusive rights for copyrighted
software, such as the exclusive rights to distribute or reproduce
the copyrighted software. Accordingly, any copyrighted software
contained in the Motorola products may not be modified, reverse-
engineered, distributed, or reproduced in any manner to the extent
allowed by law. Furthermore, the purchase of the Motorola
products shall not be deemed to grant either directly or by
implication, estoppel, or otherwise, any license under the
copyrights, patents, or patent applications of Motorola or any
third-party software provider, except for the normal, non-exclusive,
royalty-free license to use that arises by operation of law in the
sale of a product.
3
check it out!
Note:
The above illustration is for reference only. There may be slight differences between the appearances of handset,
keys and contents of display used in this manual and those of your handset. Please refer to your handset for actuality.
Note:
The function available on this handset may vary in different regions and nations. Please contact your local customer
service centres, agencies or retailers if you have any questions about the handset function. Motorola reserves all rights to
revise and change this user's manual without obligation to notify any person of such revision or changes.
Speakerphone
Headset Jack
Insert the headset
accessory for
handsfree use.
Power Connector
Charge the battery.
Battery Note: Your phone may not appear
exactly as the phone image above,
but all the key locations, sequences,
and functions remain the same.
4
contents
contents
check it out! . . . . . . . . . . . 3
Safety and General
Information . . . . . . . . . . . 7
Use and Care . . . . . . . . . 12
essentials . . . . . . . . . . . . 14
about this guide. . . . . . 14
RUIM card . . . . . . . . . . 15
battery . . . . . . . . . . . . . 15
Battery tips . . . . . . . . . 16
turn it on & off . . . . . . . 17
make a call. . . . . . . . . . 18
answer a call . . . . . . . . 18
correcting entry errors. 18
main attractions . . . . . . 19
zoom number display . 19
datebook . . . . . . . . . . . 19
read messages with
iMelody . . . . . . . . . . . . 24
iMelody downloadable
ring tones via EMS . . . 24
FM radio . . . . . . . . . . . 24
speakerphone . . . . . . . 26
multi-letter phonebook
search . . . . . . . . . . . . . 26
basics . . . . . . . . . . . . . . . 27
display . . . . . . . . . . . . . 27
menus . . . . . . . . . . . . . 29
text entry . . . . . . . . . . . 31
volume. . . . . . . . . . . . . 33
navigation key . . . . . . . 34
codes & passwords. . . 34
restrict calls . . . . . . . . . 34
customize. . . . . . . . . . . . 35
ring style . . . . . . . . . . . 35
time & date . . . . . . . . . 36
animation. . . . . . . . . . . 36
wallpaper . . . . . . . . . . . 36
screen saver . . . . . . . . 36
answer options . . . . . . 36
calls. . . . . . . . . . . . . . . . . 38
recent calls . . . . . . . . . 38
redial . . . . . . . . . . . . . . 38
speed dialing . . . . . . . . 39
return a call . . . . . . . . . 39
mute a call . . . . . . . . . . 39
speakerphone . . . . . . . 39
caller ID . . . . . . . . . . . . 39
emergency calls . . . . . 40
international calls . . . . . 40
voicemail . . . . . . . . . . . 41
special characters . . . . 41
other features . . . . . . . . 42
phonebook. . . . . . . . . . 42
recent calls . . . . . . . . . 43
5
contents
messages. . . . . . . . . . 44
settings. . . . . . . . . . . . 46
more features . . . . . . . 51
game . . . . . . . . . . . . . 52
alarm clock . . . . . . . . . 52
voice memo . . . . . . . . 52
service & repairs. . . . . . 53
index . . . . . . . . . . . . . . . 61
6
menu map
menu map
main menu
e
Messages
• Create Message
•Voicemail
•Text Msgs
•Quick Notes
• Outbox
•Drafts
n
Phonebook
•[New Entry]
s
Recent Calls
• Missed Calls
• Received Calls
• Dialed Calls
• Call Timer
Q
Games
• Football
•Crazy
• Rebels
x
MyMenu
• [New MyMenu]
A
Alarm Clock
•[New Entry]
y
UTK *
Brew
• Mobile Shop
• Settings
•Help
M
Datebook *
w
Settings
• Ring Styles
• Phone Status
• In-Call Setup
• Security
• Personalize
•Initial Setup
•Network
• Airplane Mode
• Headset
f
More
• Calculator
•Voice Memo
• Stop Watch
• Lantern
• Datebook
•Alarm Clock
•FM Radio
• Service Dial
*
Network Dependent
The above gives an example of the typical
structure of the main menu. Please refer to the
handset for the actual structure.
Safety Information
7
Safety and General Information
Safety Information
This section contains important information on the safe and
efficient operation of your mobile device. Read this
information before using your mobile device.
*
Exposure to Radio Frequency (RF)
Energy
Your mobile device contains a transmitter and receiver. When it is
ON, it receives and transmits RF energy. When you communicate
with your mobile device, the system handling your call controls the
power level at which your mobile device transmits.
Your Motorola mobile device is designed to comply with local
regulatory requirements in your country concerning exposure of
human beings to RF energy.
Operational Precautions
For optimal mobile device performance and to be sure that human
exposure to RF energy does not exceed the guidelines set forth in
the relevant standards, always follow these instructions and
precautions.
External Antenna Care
If your mobile device has an external antenna, use only a
Motorola-supplied or approved replacement antenna. Use of
unauthorized antennas, modifications, or attachments could
damage the mobile device and/or may result in your device not
complying with local regulatory requirements in your country.
DO NOT hold the external antenna when the mobile device is IN
USE. Holding the external antenna affects call quality and may
cause the mobile device to operate at a higher power level than
needed.
Product Operation
When placing or receiving a phone call, hold your mobile device
just like you would a landline phone.
If you wear the mobile device on your body, always place the
mobile device in a Motorola-supplied or approved clip, holder,
holster, case, or body harness. If you do not use a body-worn
accessory supplied or approved by Motorola, keep the mobile
* The information provided in this document supersedes the general
safety information in user’s guides published prior to May 1, 2006.
8
Safety Information
device and its antenna at least 2.5 centimeters (1 inch) from your
body when transmitting.
When using any data feature of the mobile device, with or without
an accessory cable, position the mobile device and its antenna at
least 2.5 centimeters (1 inch) from your body.
Using accessories not supplied or approved by Motorola may
cause your mobile device to exceed RF energy exposure
guidelines. For a list of Motorola-supplied or approved
accessories, visit our Web site at:
www.motorola.com
.
RF Energy Interference/Compatibility
Nearly every electronic device is subject to RF energy interference
from external sources if inadequately shielded, designed, or
otherwise configured for RF energy compatibility. In some
circumstances your mobile device may cause interference with
other devices.
Follow Instructions to Avoid Interference
Problems
Turn off your mobile device in any location where posted notices
instruct you to do so. These locations include hospitals or health
care facilities that may be using equipment that is sensitive to
external RF energy.
In an aircraft, turn off your mobile device whenever instructed to
do so by airline staff. If your mobile device offers an airplane mode
or similar feature, consult airline staff about using it in flight.
Pacemakers
If you have a pacemaker, consult your physician before using this
device.
Persons with pacemakers should observe the following
precautions:
•
ALWAYS keep the mobile device more than
20 centimeters (8 inches) from your pacemaker when the
mobile device is turned ON.
•
DO NOT carry the mobile device in the breast pocket.
•
Use the ear opposite the pacemaker to minimize the
potential for interference.
•
Turn OFF the mobile device immediately if you have any
reason to suspect that interference is taking place.
Hearing Aids
Some mobile devices may interfere with some hearing aids. In the
event of such interference, you may want to consult your hearing
aid manufacturer or physician to discuss alternatives.
Other Medical Devices
If you use any other personal medical device, consult your
physician or the manufacturer of your device to determine if it is
adequately shielded from RF energy.
Safety Information
9
Driving Precautions
Check the laws and regulations on the use of mobile devices in the
area where you drive. Always obey them.
When using your mobile device while driving, please:
•
Give full attention to driving and to the road. Using a
mobile device may be distracting. Discontinue a call if you
can’t concentrate on driving.
•
Use handsfree operation, if available.
•
Pull off the road and park before making or answering a
call if driving conditions so require.
Responsible driving practices can be found in the “Smart Practices
While Driving” section at the end of this guide and/or at the
Motorola Web site:
www.motorola.com/callsmart
.
Operational Warnings
Obey all posted signs when using mobile devices in public areas,
such as health care facilities or blasting areas.
Automobile Air Bags
Do not place a mobile device in the air bag deployment area.
Potentially Explosive Atmospheres
Areas with potentially explosive atmospheres are often but not
always posted, and can include fueling areas such as below decks
on boats, fuel or chemical transfer or storage facilities, or areas
where the air contains chemicals or particles, such as grain, dust,
or metal powders.
When you are in such an area, turn off your mobile device, and do
not remove, install, or charge batteries. In such areas, sparks can
occur and cause an explosion or fire.
Damaged Products
If your mobile device or battery has been submerged in water,
punctured, or subjected to a severe fall, do not use it until you take
it to a Motorola Authorized Service Center. Do not attempt to dry it
with an external heat source, such as a microwave oven.
Batteries and Chargers
If jewelry, keys, beaded chains, or other conductive
materials touch exposed battery terminals, this
could complete an electrical circuit (short circuit),
become very hot, and could cause damage or
injury. Be careful when handling a charged battery,
particularly when placing it inside a pocket, purse, or other
container with metal objects.
Use only Motorola Original
batteries and chargers.
Caution:
To avoid risk of personal injury, do not dispose of your
battery in a fire.
Your battery, charger, or mobile device may contain symbols,
defined as follows:
10
Safety Information
Choking Hazards
Your mobile device or its accessories may include detachable
parts, which may present a choking hazard to small children. Keep
your mobile device and its accessories away from small children.
Glass Parts
Some parts of your mobile device may be made of glass. This glass
could break if the product is dropped on a hard surface or receives
a substantial impact. If glass breaks, do not touch or attempt to
remove. Stop using your mobile device until the glass is replaced
by a qualified service center.
Seizures/Blackouts
Some people may be susceptible to epileptic seizures or blackouts
when exposed to flashing lights, such as when playing video
games. These may occur even if a person has never had a previous
seizure or blackout.
If you have experienced seizures or blackouts, or if you have a
family history of such occurrences, please consult with your
physician before playing video games or enabling a flashing-lights
feature (if available) on your mobile device.
Discontinue use and consult a physician if any of the following
symptoms occur: convulsion, eye or muscle twitching, loss of
awareness, involuntary movements, or disorientation. It is always
a good idea to hold the screen away from your eyes, leave the
Symbol Definition
Important safety information follows.
Do not dispose of your battery or mobile
device in a fire.
Your battery or mobile device may require
recycling in accordance with local laws.
Contact your local regulatory authorities
for more information.
Do not throw your battery or mobile device
in the trash.
Your mobile device contains an internal
lithium ion battery.
Do not let your battery, charger, or mobile
device get wet.
Listening at full volume to music or voice
through a headset may damage your
hearing.
032374o
032376o
032375o
032378o
Li Ion BATT
Safety Information
11
lights on in the room, take a 15-minute break every hour, and stop
use if you are very tired.
Caution About High Volume Usage
Listening at full volume to music or voice through a
headset may damage your hearing.
Repetitive Motion
When you repetitively perform actions such as pressing keys or
entering finger-written characters, you may experience occasional
discomfort in your hands, arms, shoulders, neck, or other parts of
your body. If you continue to have discomfort during or after such
use, stop use and see a physician.
FCC Notice to Users
Motorola has not approved any changes or modifications to this
device by the user. Any changes or modifications could void the
user’s authority to operate the equipment. See 47 CFR Sec. 15.21.
This device complies with part 15 of the FCC Rules. Operation is
subject to the following two conditions: (1) This device may not
cause harmful interference, and (2) this device must accept any
interference received, including interference that may cause
undesired operation. See 47 CFR Sec. 15.19(3).
If your mobile device or accessory has a USB connector, or is
otherwise considered a computer peripheral device whereby it can
be connected to a computer for purposes of transferring data, then
it is considered a Class B device and the following statement
applies:
This equipment has been tested and found to comply with the
limits for a Class B digital device, pursuant to part 15 of the FCC
Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This
equipment generates, uses and can radiate radio frequency energy
and, if not installed and used in accordance with the instructions,
may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in
a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the
following measures:
•
Reorient or relocate the receiving antenna.
•
Increase the separation between the equipment and the
receiver.
•
Connect the equipment to an outlet on a circuit different
from that to which the receiver is connected.
•
Consult the dealer or an experienced radio/TV technician
for help.
12
Use and Care
To care for your Motorola phone, please keep it away from:
liquids of any kind dust and dirt
Don’t expose your phone to
water, rain, extreme humidity,
sweat, or other moisture.
Don’t expose your phone to
dust, dirt, sand, food, or other
inappropriate materials.
extreme heat or cold cleaning solutions
Avoid temperatures below
-10°C/14°F or
above 45°C/113°F.
To clean your phone, use only a
dry soft cloth. Don’t use alcohol
or other cleaning solutions.
microwaves the ground
Don’t try to dry your phone in a
microwave oven.
Don’t drop your phone.
Recycling Information
13
Recycling Informa tion
Caring for the Environment by Recycling
This symbol on a Motorola product means the product
should not be disposed of with household waste.
Disposal of your Mobile Telephone and Accessories
Please do not dispose of mobile telephones or electrical
accessories, such as chargers or headsets, with your household
waste. In some countries or regions, collection systems have been
set up to handle waste electrical and electronic items. Please
contact your regional authorities for more details. If no suitable
scheme exists, you may return unwanted mobile telephones and
electrical accessories to any Motorola Approved Service Centre in
your region.
14
essentials
essentials
about this guide
This guide shows how to locate a menu
feature as follows:
Find it:
Press
M
>
Recent Calls > Dialed Calls
This example shows that, from the home
screen, you press
M
to open the menu,
highlight and select
Recent Calls
, then highlight
and select
Dialed Calls
.
Press
S
up or down to highlight a menu
feature. Press
SELECT
to select the highlighted
menu feature.
symbols
This means a feature is network/
subscription dependent and may
not be available in all areas. Contact
your service provider for more
information.
This means a feature requires an
optional accessory.
15
essentials
RUIM card
Yo ur Removable-User Identity Module
(RUIM) card contains personal
information like your phone number
and phonebook entries.
RUIM card installation
Caution:
Do not bend or scratch your RUIM
card. Avoid exposing your RUIM card to static
electricity, water, or dirt.
battery
battery installation
12
12
34
16
essentials
battery charging
New batteries are
shipped partially
charged. Before you can
use your phone, install
and charge the battery as
shown in the battery
installation and battery
charging sections. Some
batteries perform best
after several full charge/
discharge cycles.
When the battery
charging is complete, the battery icon will
change to a battery full icon ( ) and the
screen displays
Charging Complete
.
Tip:
Relax, you can't overcharge your battery.
It will perform best after you fully charge and
discharge it a few times.
battery tips
Battery life depends on the network, signal
strength, temperature, features, and
accessories you use.
•
Always use Motorola
Original batteries and
chargers. The warranty
does not cover damage
caused by non-Motorola batteries and/
or chargers.
•
New batteries or batteries stored for a
long time may take more time to
charge.
•
When charging your battery, keep it
near room temperature.
•
When storing your battery, keep it
uncharged in a cool, dark, dry place.
•
Never expose batteries to
temperatures below -10°C (14°F) or
17
essentials
above 45°C (113°F). Always take your
phone with you when you leave your
vehicle.
•
It is normal for batteries to gradually
wear down and require longer
charging times. If you notice a change
in your battery life, it is probably time
to purchase a new battery.
Contact your local recycling center
for proper battery disposal.
Warning:
Never dispose of batteries in a
fire because they may explode.
Before using your phone, read the battery
safety information in the “Safety and
General Information” section included in
the gray-edged pages at the back of this
guide.
turn it on & off
To turn your phone
on, press and hold
O
for 2 seconds.
If prompted, enter
your 8-digit RUIM
card PIN code and/or 4-digit unlock code.
Caution:
If you enter an incorrect PIN code 3
times in a row, your RUIM card becomes
disabled and your phone displays
RUIM Blocked
.
Contact your service provider if your RUIM is
blocked.
To turn your phone off, press and hold
O
for
2 seconds. If prompted, enter your 4-digit
unlock code.
18
essentials
make a call
From the home screen, enter a phone
number (up to 32 digits) and press
N
.
To end a call, press
O
.
answer a call
To answer an incoming call, press
N
. Refer
to “answer options” on page 36 for
alternative methods to answer an incoming
call.
To end the call, press
O
.
If your phone has Caller ID, the caller's phone
number will be displayed on the screen. If the
caller's number is stored in the
Phonebook
, the
caller's name will be displayed.
correcting entry errors
To correct a misdialed digit, press
Delete
to
erase one digit at a time. To erase all digits
at once, press and hold
Delete
for more than
one second.
19
main attractions
main attractions
You can do much more with your phone than
make and receive calls! This section
describes some of your phone’s highlights.
zoom number display
Zoom number display is a smart function that
lets you see the enlarged font size of the
numbers on the screen, depending on how
many digits are in the dialed number.
Because most people enter seven digits most
frequently, your font size is large most of the
time and becomes smaller only when
necessary.
datebook
The datebook is a calendar that lets you
schedule and organize events such as
appointments and meetings. You can review
your schedule of events for the week or by
the day, and have the datebook play a
reminder alarm for specific events.
Note:
You must set the phone’s correct time
and date in order to use the datebook.
To schedule or review events in the
datebook:
Find it:
Press
M
>
More
>
Datebook
20
main attractions
viewing by the week
When you open the datebook, your phone
displays a calendar for the week. Lines or
filled boxes under each day indicate
scheduled events.
view by day
Select a day in the week view and press
VIEW
to see the day's events. You can store, edit,
view, copy, and delete any event from the day
view.
view by event
Select an event in the day view and press
VIEW
to open the detailed event view. You can
edit, copy, and delete events from the event
view.
add a new event
You can add a new event in two different
ways.
Find it:
Press
M
>
More
>
Datebook
> Press
M
>
Day View
>
[New Entry]
or
Press
M
>
Datebook
> day >
M
>
New
>
Event
To set up the
Event
detail, follow the steps
below. A title is required for a datebook event.
All other information is optional.
1
Press
CHANGE
to select
Title
.
2
Use the keypad keys to enter a title for
the event.
3
Press
OK
to store the event title.
21
main attractions
4
Press
S
up and down to scroll to other
fields and enter information as necessary.
Other fields let you enter
Start
,
Duration
,
Date
,
Repeat
, and
Alarm
.
5
Press
DONE
to store the new event and
return to the day view.
add a new task
You can add a new task by doing the
following:
Find it:
Press
M
>
More
>
Datebook
> day >
M
>
New
>
Task
To set up the
Task
detail, follow the steps
below. A summary is required for a datebook
task. All other information is optional.
1
Press
CHANGE
to select
Summary
.
2
Use the keypad keys to enter a summary
for the task.
3
Press
OK
to store the task summary.
4
Press
S
up or down to scroll to other
fields and enter information as necessary.
Other fields let you enter
Start Date
,
Deadline
,
Priority
,
Completed
,
Category
, and
Status
.
5
Press
DONE
to store the new task and
return to the day view.
change event/task information
To change information about an existing
event/task:
Find it:
Press
M
>
More
>
Datebook
1
Press
S
left or right to scroll to the
scheduled event/task day.
2
Press
M
>
Day View
to display the day
view.
3
Press
S
up or down to scroll to the
event/task you want to change.
4
Press
VIEW
to display the event/task.
22
main attractions
5
Press
EDIT
to edit the event/task.
6
Press
S
up or down to scroll to the detail
you want to change.
7
Press
CHANGE
to edit the information.
8
Use the keypad keys to enter the new
information.
9
Press
DONE
to store the information.
copy an event/task
To copy information from a current event/task
to a new event/task:
Find it:
Press
M
>
More
>
Datebook
1
Press
S
left or right to scroll to the
scheduled event/task day.
2
Press
M
>
Day View
to display the day
view.
3
Press
S
up or down to scroll to the
event/task to copy.
4
Press
M
to open the
Datebook Menu
.
5
Press
S
up or down to scroll to
Copy
.
6
Press
SELECT
to copy the event/task.
7
Press
YES
to confirm the copy.
Your phone assumes that you want to
change the date, and displays the
Date
field.
8
Use the keypad keys to enter the date
information.
9
Press
S
left or right to scroll to the day,
month, and year.
10
Press
OK
to save the copy of the event/
task.
11
Press
S
up or down to scroll to event/
task details and edit the information as
necessary.
12
Press
DONE
to store the new event/task
and return to the day view.
23
main attractions
delete an event
Find it:
Press
M
>
More
>
Datebook
1
Press
S
left or right to scroll to the
scheduled event day.
2
Press
M
>
Day View
to display the
day view.
3
Press
S
up or down to scroll to the
event to delete.
4
Press
M
to open the
Datebook Menu
.
5
Press
S
up or down to scroll to
Delete
.
6
Press
SELECT
to select
Delete
.
For non-repeating events, a confirmation
message will pop up. Choose
Yes
or
No
to confirm or cancel the delete. For
repeating events, the phone displays a
delete event menu:
Press
S
up or down to scroll to
This Event
Only
or
Repeat Events
. Press
SELECT
to select
the event(s) to delete.
delete a task
Find it:
Press
M
>
More
>
Datebook
1
Press
S
left or right to scroll to the
scheduled task day.
2
Press
M
>
Day View
to display the
day view.
3
Press
S
up or down to scroll to the
event to delete.
4
Press
M
to open the
Datebook Menu
.
5
Press
S
up or down to scroll to
Delete
.
6
Press
SELECT
to select
Delete
.
7
A confirmation message will pop up.
Choose
Yes
or
No
to confirm or cancel
the delete.
24
main attractions
read messages with
iMelody
Find it:
Press
M
>
Messages
>
Text Msgs
To open the message:
1
Press
S
to scroll to the message.
2
Press
READ
to open the message.
The phone asks
Play Ring Tone?
3
Press
YES
to play the iMelody. (iMelody
will play only if the format is correct.
A pop-up screen will notify you
otherwise.) Press
NO
to cancel the playing.
iMelody downloadable
ring tones via EMS
iMelody ringtones can be delivered via EMS
to the handset, and can be set as ringers. You
can download up to 20 iMelody ringtones.
store iMelody
You can store the iMelody.
1
Press
STORE
and the file name appears on
the display.
2
Press
OK
to save the iMelody into
My Tones
.
Note:
Storing your iMelody may fail for two
reasons: if the file name is duplicated or if the
memory is full. If the file name is duplicated,
rename the file under
Tone details
. If the
memory is full, replace old ring tones with the
new one.
FM radio
Find it:
Press
M
>
More
>
FM Radio
Note:
A headset must be plugged in to
activate the FM radio function.
When activated, press
S
left or right to
adjust the frequency. Press
S
up or down to
25
main attractions
adjust the volume. Press
MUTE
to mute the
radio. Press
M
>
FM Radio Off
to turn off the
radio.
use the radio presets
You can store up to nine preset radio stations.
1
Tune in the desired frequency by pressing
S
left or right or press
M
>
Scan
to scan
for all available radio stations. You can
also enter a frequency manual by pressing
M
>
Set Frequency
.
2
Press and hold number keys to save that
number as the reset.
select a radio preset
Press number keys to select the
corresponding radio preset or press
M
>
Station Presets
to view a list of all radio presets.
Press
S
up or down to select a preset.
Note:
To achieve the best FM radio
performance, a Motorola accessory is highly
recommended.
organize the radio presets
You can organize your radio presets into two
groups:
Home
and
Travel
.
1
Press
M
>
Preset Selector
2
Press
S
up or down to select
Home
or
Travel
.
select the radio output
You can play the radio through either a
headset or speaker.
Press
M
>
Speaker
When
Speaker
is selected, press
M
>
Earpiece
to
switch back to headset output.
26
main attractions
speakerphone
You can activate the speakerphone during a
call by pressing
SPKR ON
and turn it off by
pressing
SPKR OFF
.
multi-letter phonebook
search
There are two search methods, search by
Find
,
and search by
Jump
, for phonebook entry
searching.
To define the search method:
Find it:
Press
M
>
Phonebook
>
M
>
Search By
>
Find
or
Jump
search by jump
Press a keypad key 1 or more times to jump
to entries that begin with the key’s letters.
Press a second letter to jump to entries
beginning with the two letters you entered.
You can enter up to three letters.
search by find
When you enter the first letter of an entry in
your phonebook, a pop-up screen will ask
you to input the name you would like to
search for.
You can input the first several letters of
the target entry’s name, then press
OK
,
and the phonebook will jump to the closest
match entry.
27
basics
basics
See page 1 for a basic phone diagram.
display
The home screen displays when you turn on
the phone. To dial a number from the home
screen, use the keypad keys to enter the
number and press
N
.
Note:
Your home screen may look different
from the one shown here, depending on your
service provider.
Soft key labels show the current soft key
functions. For soft key locations, see page 1.
Status
Left Soft Key Label
Main Menu
Right Soft Key Label
Time
Motorola
02/14/07 15:08
SETTING MYMENU
28
basics
status indicators
Status indicators display at the top of the
home screen:
1 Signal Strength Indicator –
Shows the strength of your
phone's connection with the network.
2 1X Indicator
–
Shows that the phone is
operating in 1X mode.
3 Roam Indicator –
Appears when
your phone uses a network system
outside your home network. This icon can
also indicate your text entry mode, alpha,
numeric, symbol and etc.
4 In Use Indicator –
Indicates when
a call is in progress, and when you
have a secure or insecure connection.
5 Message Indicator
– Appears
when you have a new voice or text
message.
Note:
When the message full indicator
appears, it means the message inbox has
reached the storage limit. Delete the old
messages so that your phone can receive
new ones.
Motorola
02/14/07 15:08
SETTING MYMENU
1 2 3 4 5 6 7
8
= text/voice
message
= message
full
29
basics
6 Alert Type Indicator –
Displays your alert
type setting.
7 Battery Level Indicator –
Shows the
amount of charge left in your battery.
The more bars present, the greater
the charge.
8 FM Radio Indicator
- Displays when a
headset is attached and the FM Radio
function is available.
menus
From the home screen, press
M
to enter the
main menu and scroll up and down through
the main menu list.
= Loud Ring = Vibe then
Ring
= Soft Ring = Silent
= Vibrate
Select the
highlighted
menu
feature
Exit the main
menu
Exit to home
screen
Scroll left or
right
Scroll up or
down
30
basics
The following menu icons may be available,
depending on your service provider and
service subscription options.
* Network dependent
select a feature option
Some features require you to select an option
from a list:
Press
S
up or down to highlight the option
you want.
Note:
The UTK icon is displayed if your SIM
card supports UTK. If not, the alarm clock icon
is displayed instead.
menu features
eMessages
A
Alarm Clock
nPhonebook
y
UTK *
sRecent Calls Brew *
Q
Games
M
Datebook
xMyMenu wSettings
fMore
31
basics
text entry
Some features let you enter text.
text entry mode
Press
M
in a text entry screen to select an
entry mode:
AB 160
Msg:
INSERT CANCEL
Press CANCEL
to abort the
message.
Cursor
indicates
insertion
point.
Press INSERT
to add a
quick note.
Press to
change
entry
method.
entry mode
TAP
Your Tap entry modes
include:
• TAP English
iTAP™
Your Tap entry modes
include:
• iTAP English
Numeric
Numeric
mode ( ) enters
numbers only.
Symbol
Symbol
mode ( ) enters
symbols only.
32
basics
iTAP
™
mode
Press
M
in a text entry screen to select
and switch to
iTAP
mode.
iTAP
mode lets you
enter words using one key press per letter.
When
iTAP
is selected, displays on the
home screen. The
iTAP
software combines
your key presses into common words,
and predicts each word as you enter it.
For example, if you press
2775
,
your phone displays a list of word
combination such as
appl
,
aspj
, and
aspk
.
When you enter three or more characters in a
row, your phone will guess the rest of the
word.
For example, if you enter
CH
, your phone
might display:
AB 158
CH
Msg:
OK DELETE
Character
displays at
insertion
point.
Press OK to
accept and
store text.
Press to
change entry
method.
Press DELETE
to delete the
letter.
33
basics
tap mode
Press
M
in a text entry screen and select
Tap
mode. To enter text in tap mode, press a
keypad key repeatedly to cycle through the
letters and number on the key. Repeat this
step to enter each letter.
numeric mode
Press the number keys to enter the numbers
you want.
symbol mode
Press a keypad key to show its symbols at the
bottom of the display.
Highlight the symbol you want and press the
SELECT
key.
volume
During a call, there are three answering
modes for you to adjust the volume:
Normal
,
Earpiece
, and
Speaker On
. During a call, you can
adjust the volume of the earpiece by pressing
S
right to increase and left to decrease.
Repeatedly press
S
to adjust.
In addition, to mute a call you can press
M
and select
Mute
.
Once a call has ended, no matter which
setting (
Normal
,
Earpiece
or
Speaker On
), the volume
will remain at that current volume setting.
34
basics
navigation key
Press the navigation
key
S
up or down
to highlight menu
items, change
feature settings, and
play games. Press
SELECT
to choose a
highlighted menu item.
codes & passwords
To change your 4-digit codes or passwords:
Find it:
Press
M
>
Settings
>
Security
>
New Passwords
Tip:
To change passwords, you must confirm
your password by entering it twice.
restrict calls
You can set Restrict Calls as
Allow All
,
Allow
Phonebook
, and
Allow None
.
Need to enter the password (1234) to change.
etiquette mode
In social situations where audible rings, bells,
or tones are inappropriate, such as in a movie
theater, at a museum, play, etc., your phone
can be set on etiquette mode.
All incoming calls under this mode will be
notified by inaudible vibration. Press and hold
*
to switch between
Long Ring
and
Vibrator
.
35
customize
customize
ring style
Your phone rings and/or vibrates to notify you
of an incoming call, message or other event.
There are five ring types in your phone:
Loud Ring
,
Soft Ring
,
Vibrate
,
Vibe then Ring
, and
Silent
.
my tones
To se le ct
My Tones
:
Find it:
Press
M
>
Settings
>
Ring Styles
>
My Tones
To select a ring type:
Find it:
Press
M
>
Settings
>
Ring Styles
>
Alert
To tu r n
Minute Alert
on/off:
Find it:
Press
M
>
Settings
>
Ring Styles
>
Other Alert
>
Minute Alert
To adjust the volume for different alert:
Find it:
Press
M
>
Settings
>
Ring Styles
>
Loud Ring/Soft Ring/Vibrate/Vibe then Ring/Silent Detail
>
Ring Volume
,
In Call
,
Message Tone
,
Alarms
,
Voicemail
,
Key Volume
,
Earpiece Vol
.
You can adjust the volume for alerts, key
volume, and earpiece volume.
This phone contains 40 preloaded polyphonic
ringtones. More ringtones can be
downloaded via
BREW
.
36
customize
time & date
To set the time and date for your phone:
Find it:
Press
M
>
Settings
>
Initial Setup
>
Time and Date
animation
Your phone plays an animation when it is
powered on.
wallpaper
To set the wallpaper for your phone:
Find it:
Press
M
>
Settings
>
Personalize
>
Wallpaper
This phone comes with several wallpaper
images, which include
None
,
Amber, Caribbean,
Desert, Elevate,
and
Blue
.
screen saver
To set a screen saver for your phone:
Find it:
Press
M
>
Settings
>
Personalize
>
Screen Saver
>
This phone comes with several preloaded
screen savers (
None
,
Water, Moto, Distort, Nocture,
Velvet
). More screen savers may be
downloaded via
BREW
. To set the screen saver
delay time:
Find it:
Press
M
>
Settings
>
Personalize
>
Screen Saver
>
Delay
answer options
You can use additional, alternative methods to
answer an incoming call. To activate or
deactivate an answer option:
37
customize
Find it:
Press
M
>
Settings
>
In-Call Setup
>
Answer Option
option
Any Key
Answer by pressing any
key.
Send Key Only
Answer by pressing
N
.
38
calls
calls
This chapter describes features related to
making and answering calls.
recent calls
Your phone keeps lists of incoming and
outgoing calls, even for calls that didn't
connect. The most recent calls are listed first.
The oldest calls are deleted as new calls are
added.
Find it:
Press
M
>
Recent Calls
> desired
call list
1
Highlight
Missed Calls
,
Received Calls
, or
Dialed
Calls
, and press
SELECT
.
2
Highlight a call. A marker next to a call
means the call connected.
•
To call the number, press
N
.
•
To see call details (like time and date),
press the
VIEW
.
redial
1
Press
N
from the home screen to
see the
Dialed Calls
list. Or press
M
>
Recent Calls
>
Dialed Calls
,
Missed Calls
and
Received Calls
.
2
Highlight the entry you want to call,
then press
N
.
39
calls
speed dialing
Once a phone number is stored in your
Phonebook
, you can access and dial that number
using assigned speed dial keys.
Enter the location number of a stored number
and press
#
. The phone will then
automatically connect to that number. Press
N
to dial the number.
return a call
Your phone keeps a record of your
unanswered calls, and displays
Missed Calls
on
the screen.
1
Press
VIEW
to see the
Missed Calls
list.
2
Highlight the call you want to return, and
press
N
.
mute a call
When you are on a call, press
M
>
Mute
.
For an incoming call, press
S
left to mute
the call/ring.
speakerphone
When you are on a call, you can use the built-
in polyphonic speaker for hands-free
operation.
Press
SPKR ON
during a call to turn the speaker
on or off.
caller ID
Calling Line Identification (caller ID)
shows the phone number for an incoming call
in your internal display.
40
calls
Your phone shows the caller's name when it
is stored in your
Phonebook
or
Incoming Call
when
caller ID information isn't available.
You can set your phone to play a distinctive
ringer ID for specific entries stored in your
phonebook.
emergency calls
Your service provider programs one or more
emergency phone numbers (such as 112 or
911) that you can call under any
circumstances, even if the RUIM card is not
inserted. You can dial and call the emergency
number even when your phone is locked,
when you are prompted to enter a code or
password.
Note:
Emergency numbers vary with
different countries. Your phone's
preprogrammed emergency number(s) may
not work in all locations, and sometimes an
emergency call cannot be placed due to
network, environmental, or interference
issues.
To call the emergency number at any time:
1
Press the keypad keys to dial the
emergency number.
2
Press
N
to call the emergency number.
international calls
If your phone service includes
international dialing, press and hold
0
to
insert your local international access code
(indicated by
+
). Then, press the keypad keys
to dial the country code and phone number.
41
calls
voicemail
You can listen to your voicemail
messages by calling your network voicemail
phone number. Voicemail messages are
stored on the network—not on your phone.
Contact your service provider for more
details.
When you receive a voicemail message,
your phone displays a new voicemail indicator
on the status pane (some networks only
indicate when you have messages, whether
they are new or not). If users delete all
voicemail messages, the voicemail indicator
will disappear.
To listen to your voicemail message:
Find it:
Press
M
>
Messages
>
Voicemail
Your phone calls the voicemail phone number
you stored.
special characters
In addition to pressing numbers on your
keypad, you can insert special characters in a
phone number.
While dialing (with digits visible in the display),
you can press
*
twice to select hard pause
p
, three times to select time pause
w
.
option
Hard pause
(
p
)
Your phone waits until the
call connects, then prompts
you for confirmation before
it dials the next digit(s).
Time pause
(
w
)
Your phone waits until the
call connects before it dials
the next digit(s) in the
series.
42
other features—phonebook
other features
phonebook
feature
add new
entry
To add a new contact to
your phonebook:
M
>
Phonebook
>
[New Entry]
Select a location, enter entry
details, and press
DONE
.
view
contact list
To view phonebook list:
M
>
Phonebook
Shortcut:
In the home
screen, press
S
up to
access the
Phonebook
directly.
search
entry by
name
To search entry by name:
M
>
Phonebook
Tip:
Enter the first letter
of a name to show similar
names.
delete an
entry
To delete a phonebook
entry:
M
>
Phonebook
> highlight
the name >
M
>
Delete
feature
43
other features—recent calls
recent calls
delete all
entries
To delete all phonebook
entries:
M
>
Phonebook
>
M
>
Delete All
attach a
phone
number
To attach a phone number
to an entry:
M
>
Phonebook
> highlight the name >
M
>
Attach Number
view phone
capacity
To view the remaining
phone memory:
M
>
Phonebook
>
M
>
Phone Capacity
feature
feature
view call list
To view outgoing, incoming
and missed call lists:
M
>
Recent Calls
You may refer to your call
history for more information
such as number, time, date,
and duration.
clear call list
To delete missed, called,
received and stored call
lists:
M
>
Recent Calls
> call list
>
M
>
Delete All
>
YES
view call
times
To view the call duration
of last call, dialed calls,
received calls and all calls:
M
>
Recent Calls
>
Call Timer
44
other features—messages
messages
feature
read old
text
messages
M
>
Messages >
Text Msgs
delete text
messages
M
>
Messages >
location
> message
> M
>
Delete
call the
message
sender
M
>
Messages >
location
> message
>
M
>
Call Back
create a
new
message
M
>
Messages
> Create Messages
edit an old
message
M
>
Messages >
location
> message
>
M
>
Forward
listen to a
voice
message
M
>
Messages >
Voicemail
When you receive a
voicemail, your phone
displays
e
. Sometimes
e
won't disappear even if
you checked the message.
It depends on the condition
of the service provider's
system.
set
message
alert
To set a message alert type:
M
>
Messages >
M
>
Text Msg Setup
>
SMS Reminder
set up
voicemail
box
To set up your voicemail box
before you can receive a
voicemail:
M
>
Messages >
M
>
Voicemail Setup
feature
45
other features—messages
view the
message
memory
meter
To view the remaining
memory space for
messages:
M
>
Messages >
M
>
Memory Meter
delete
messages
To clean up your messages
folders manually:
M
>
Messages >
M
>
Cleanup Now
Select the desired folder
that you would like to
delete.
To clean up your message
folders automatically:
M
>
Messages >
M
>
Auto Delete Inbox
or
Auto Delete
Outbox
feature
auto retry
To set Auto Retry:
M
>
Messages >
M
>
Auto Retry
>
Enable
or
Disable
set call back
display
To set call back display:
M
>
Messages >
M
>
Call Back Display
delivery ack
To s e t
Delivery Ack
:
M
>
Messages >
M
> Delivery Ack > Enable
or
Disable
feature
46
other features—settings
settings
feature
set my tel.
numbers
To se t
My Tel. Numbers
:
M
>
Settings >
Phone Status
>
My Tel. Numbers
Most carriers support up to
two numbers.
To vi ew
My Tel. Numbers
during
a call, press
S
and scroll
down to see the feature.
additional
call
To set additional code:
M
>
Settings
>
In-Call Setup
>
Additional Call
You can set additional call to
Call Forward
,
Call Forward To Voice
Mail
,
Call Waiting
, and
My Caller ID.
Interna-
tional code
To set an international
code:
M
>
Setting
>
In-Call Setup
>
International Code
You can set Mode to
Automatic
or
Manual.
Yo u c an
also set your preferred
Code
.
view MEID
& ESN
M
>
Settings >
Phone Status
>
MEID & ESN
view
battery
meter
M
>
Settings >
Phone Status
>
Battery Meter
view
software
version
M
>
Settings >
Phone Status
>
SW Version
view PRL
version
M
>
Settings >
Phone Status
>
PRL Version
feature
47
other features—settings
set auto
redial
M
>
Settings >
In-Call Setup
>
Auto Redial
>
Enable
or
Disable
set voice
privacy
M
>
Settings >
In-Call Setup
>
Voice Privacy
>
Enable
or
Disable
define
answer
option
To s e t
Answer Option
:
M
>
Settings >
In-Call Setup
>
Answer Option
>
Send Key Only
or
Any Key
set easy
prefix
To s e t
Easy Prefix
:
M
>
Settings >
In-Call Setup
>
Easy Prefix
>
Auto Change
>
Off
,
Add
, or
Replace or Add
reorder
menu
M
>
Settings >
Personalize
>
Main Menu
redefine
left/right
soft keys
M
>
Settings >
Personalize
>
Home Screen >
Home Keys
>
Left or Right soft key
feature
create a
greeting
To enter a greeting
message:
M
>
Settings >
Personalize
>
Greeting
create a
banner
To create a banner on the
standby screen:
M
>
Settings >
Personalize
>
Banner
color
setting
M
>
Settings
>
Personalize
>
Color Setting
Color Settings
selections
include
Pacific
,
Mandarin
,
Evergreen
,
Autumn
,
Dusk
, and
Silver
.
my images
M
>
Settings
>
Personalize
>
My Images
feature
48
other features—settings
wallpaper
M
>
Settings
>
Personalize
>
Wallpaper
Wallpaper
selections include
None, East, Identity, Relax, Sky,
and
Lovely
.
lantern
timeout
M
>
Settings
>
Initial Setup
>
Lantern Timeout
Lantern Timeout
selections
include
30 sec
,
1 minute
, and
2
minutes
.
set time
and date
M
>
Settings >
Initial Setup
>
Time and Date
backlight
M
>
Settings >
Initial Setup
>
Backlight
set scroll
pattern
M
>
Settings >
Initial Setup
>
Scroll
set start-up
animation
M
>
Settings >
Initial Setup
>
Animation
feature
select a
language
To select a language:
M
>
Settings >
Initial Setup
>
Language
set DTMF
To select DTMF length:
M
>
Settings >
Initial Setup
>
DTMF
set
hyphena-
tion
To select hyphenation:
M
>
Settings
>
Initial Setup
>
Hyphenation
set number
speak
To hear the numbers
spoken when dialing a
number:
M
>
Settings
>
Initial Setup
>
Number Speak
feature
49
other features—settings
clear phone
data
To clear the entered
information in the phone:
M
>
Settings >
Initial Setup
>
Master Clear
phone reset
To restore the phone's
default values:
M
>
Settings >
Initial Setup
>
Master Reset
define NAM
setting
To set NAM and enable it:
M
>
Settings
>
Network
>
NAM Setting
Tip:
You are allowed to set
two NAM settings.
set service
tone
To s e t
Service Tone
:
M
>
Settings >
Network
>
Service Tone >
On
or
Off
feature
set call drop
tone
To S e t
Call Drop Tone
:
M
>
Settings >
Network
>
Call Drop Tone >
On
or
Off
select a
band
M
>
Settings >
Network
>
Band Selection
set area
code
To set the area code:
M
>
Settings
>
Network
>
Area Code
>
Show
or
Hide
set auto
answer
To s e t
Auto Answer
when the
headset is connected:
M
>
Settings >
Headset
>
Auto Answer
feature
50
other features—settings
ring styles
M
>
Settings
>
Ring Styles
Ring Styles
selections include
Alert
(
Loud Ring
,
Soft Ring
,
Vibrate
,
Vibe then Ring
, and
Silent
),
Loud
Ring Detail
(
Ring Volume
,
In Call
,
Message Tone
,
Alarms
,
Voicemail
,
Key Volume
,
Earpiece Vol.
),
My Tones
,
Backlight Dancing
(flashing backlight with
ringtone -
On
or
Off
),
Other Alert
(
Minute Alert
>
Enable
or
Disable
)
set ringer
output
M
>
Settings >
Headset
>
Auto Answer
Ringer Output
selections include
Headset only
,
Speaker only
, and
Both
.
feature
changing
password
To change the 4-digit
password:
M
>
Settings
>
Security
>
New Passwords
The default password is set
to 1234.
home
screen
To modify what is displayed
on the home screen:
Press
M
>
Settings
>
Personalize
>
Home Screen
From here, you can choose
to modify the
Home Keys
,
Layout
, and
Clock Set
.
main menu
To modify whether the main
menu uses icons or words
and their order:
Press
M
>
Settings
>
Personalize
>
Main Menu
feature
51
other features—more features
more features
set screen
saver
To s e t
Screen Saver
:
M
>
Settings
>
Personalize
>
Screen Saver
>
or
Delay
set airplane
mode
To s e t
Airplane Mode
to disable
all RF signals during flight:
M
>
Settings
>
Airplane Mode
>
Airplane Mode
set airplane
mode
prompt
To s e t
Airplane Mode
prompt
when the handset is turned
on:
M
>
Settings
>
Airplane Mode
>
Prompt at Startup
When the handset is turned
on, a
Startup in Airplane Mode?
prompt appears. Press
YES
or
NO
.
feature
feature
calculator
M
>
More
>
Calculator
set
exchange
rate
To set exchange currency
rate:
M
>
More
>
Calculator
>
M
>
Exchange Rate
stop watch
To u s e
Stop Watch
:
M
>
More
>
Stop Watch
lantern
To s e t
Lantern
:
M
>
More
>
Lantern
alarm clock
To s e t
Alarm Clock
:
M
>
More
>
Alarm Clock
set service
dial
To s e t
Service Dial
:
M
>
More
>
Service Dial
52
other features—game
game
alarm clock
voice memo
feature
play a game
To start a game
:
M
> Games >
game
feature
set alarm
clock
To set Alarm Clock:
M
> More > Alarm Clock
> [NewEntry] > set the
name and time
When you finish setting, the
alarm will be enabled
automatically. To disable it,
press
DISABLE
.
feature
record voice
memo
To record a voice
memo:
M
> More > Voice Memo
> [NewEntry] > New >speak
into the microphone to
record your voice
memo
When you finish recording,
press
STORE
to save your
voice memo. To discard it,
press
CANCEL
.
53
service & repairs
service & repairs
If you have questions or need assistance,
we’re here to help. Go to
www.motorola.com/consumer/support
,
where you can select from a number of
customer care options. You can also contact
the Motorola Customer Support Center
at 1-866-395-3710 (United States),
1-888-390-6456 (TTY/TDD United States for
hearing impaired), or 1-800-461-4575
(Canada).
54
SAR Data
Specific Absorption Rate Data
SAR Data
This model meets international
guidelines for exposure to radio
waves.
Your mobile device is a radio transmitter and
receiver. It is designed not to exceed the limits for
exposure to radio waves recommended by
international guidelines. These guidelines were
developed by the independent scientific organization
ICNIRP and include safety margins designed to
assure the protection of all persons, regardless of
age and health.
The guidelines use a unit of measurement known as
the Specific Absorption Rate, or SAR. The ICNIRP
SAR limit for mobiles devices used by the general
public is 2 W/kg and the highest SAR value for this
device when tested at the ear was 0.84 W/kg.
1
As
mobile devices offer a range of functions, they can be
used in other positions, such as on the body as
described in this user guide.
2
In this case, the highest
tested SAR value is 0.32 W/kg.
1
As SAR is measured utilizing the device’s highest
transmitting power, the actual SAR of this device
while operating is typically below that indicated
above. This is due to automatic changes to the power
level of the device to ensure it only uses the
minimum level required to reach the network.
While there may be differences between the SAR
levels of various phones and at various positions,
they all meet the governmental requirements for safe
exposure. Please note that improvements to this
product model could cause differences in the SAR
value for later products; in all cases, products are
designed to be within the guidelines.
SAR Data
55
The World Health Organization has stated that
present scientific information does not indicate the
need for any special precautions for the use of
mobile devices. They note that if you want to reduce
your exposure then you can do so by limiting the
length of calls or using a “hands-free” device to keep
the mobile phone away from the head and body.
Additional Information can be found on the websites
of the World Health Organization
(
http://www.who.int/emf
) or Motorola, Inc.
(
http://www.motorola.com/rfhealth
).
1. The tests are carried out in accordance with
international guidelines for testing. The limit
incorporates a substantial margin for safety to give
additional protection for the public and to account for
any variations in measurements. Additional related
information includes the Motorola testing protocol,
assessment procedure, and measurement uncertainty
range for this product.
2. Please see the
Safety and General Information
section
about body worn operation.
56
Warranty
Motorola Limited Warranty for the United States and
Canada
Warranty
What Does this Warranty Cover?
Subject to the exclusions contained below, Motorola, Inc. warrants
its telephones, pagers, messaging devices, and consumer and
professional two-way radios (excluding commercial, government
or industrial radios) that operate via Family Radio Service or
General Mobile Radio Service, Motorola-branded or certified
accessories sold for use with these Products (“Accessories”) and
Motorola software contained on CD-ROMs or other tangible media
and sold for use with these Products (“Software”) to be free from
defects in materials and workmanship under normal consumer
usage for the period(s) outlined below. This limited warranty is a
consumer's exclusive remedy, and applies as follows to new
Motorola Products, Accessories and Software purchased by
consumers in the United States or Canada, which are accompanied
by this written warranty:
Products and Accessories
Products Covered Length of Coverage
Products and
Accessories
as
defined above, unless
otherwise provided for
below.
One (1) year
from the date of
purchase by the first consumer
purchaser of the product unless
otherwise provided for below.
Decorative
Accessories and
Cases.
Decorative
covers, bezels,
PhoneWrap™ covers
and cases.
Limited lifetime warranty
for the
lifetime of ownership by the first
consumer purchaser of the product.
Monaural Headsets.
Ear buds and boom
headsets that transmit
mono sound through a
wired connection.
Limited lifetime warranty
for the
lifetime of ownership by the first
consumer purchaser of the product.
Warranty
57
Exclusions
Normal Wear and Tear.
Periodic maintenance, repair and
replacement of parts due to normal wear and tear are excluded
from coverage.
Batteries.
Only batteries whose fully charged capacity falls below
80% of their rated capacity and batteries that leak are covered by
this limited warranty.
Abuse & Misuse.
Defects or damage that result from:
(a) improper operation, storage, misuse or abuse, accident or
neglect, such as physical damage (cracks, scratches, etc.) to the
surface of the product resulting from misuse; (b) contact with
liquid, water, rain, extreme humidity or heavy perspiration, sand,
dirt or the like, extreme heat, or food; (c) use of the Products or
Accessories for commercial purposes or subjecting the Product or
Accessory to abnormal usage or conditions; or (d) other acts which
are not the fault of Motorola, are excluded from coverage.
Use of Non-Motorola Products and Accessories.
Defects or
damage that result from the use of Non-Motorola branded or
certified Products, Accessories, Software or other peripheral
equipment are excluded from coverage.
Unauthorized Service or Modification.
Defects or damages
resulting from service, testing, adjustment, installation,
maintenance, alteration, or modification in any way by someone
other than Motorola, or its authorized service centers, are
excluded from coverage.
Altered Products.
Products or Accessories with (a) serial
numbers or date tags that have been removed, altered or
obliterated; (b) broken seals or that show evidence of tampering;
(c) mismatched board serial numbers; or (d) nonconforming or
non-Motorola housings, or parts, are excluded from coverage.
Communication Services.
Defects, damages, or the failure of
Products, Accessories or Software due to any communication
service or signal you may subscribe to or use with the Products
Accessories or Software is excluded from coverage.
Software
Consumer and
Professional
Two-Way Radio
Accessories.
Ninety (90) days
from the date of
purchase by the first consumer
purchaser of the product.
Products and
Accessories that are
Repaired or
Replaced.
The balance of the original
warranty or for ninety (90) days
from the date returned to the
consumer, whichever is longer.
Products Covered Length of Coverage
Products Covered Length of Coverage
Software.
Applies only to physical
defects in the media that embodies
the copy of the software (e.g.
CD-ROM, or floppy disk).
Ninety (90) days
from
the date of purchase.
58
Warranty
Exclusions
Software Embodied in Physical Media.
No warranty is made
that the software will meet your requirements or will work in
combination with any hardware or software applications provided
by third parties, that the operation of the software products will be
uninterrupted or error free, or that all defects in the software
products will be corrected.
Software NOT Embodied in Physical Media.
Software that is
not embodied in physical media (e.g. software that is downloaded
from the internet), is provided “as is” and without warranty.
Who Is Covered?
This warranty extends only to the first consumer purchaser, and is
not transferable.
What Will Motorola Do?
Motorola, at its option, will at no charge repair, replace or refund
the purchase price of any Products, Accessories or Software that
does not conform to this warranty. We may use functionally
equivalent reconditioned/refurbished/pre-owned or new Products,
Accessories or parts. No data, software or applications added to
your Product, Accessory or Software, including but not limited to
personal contacts, games and ringer tones, will be reinstalled. To
avoid losing such data, software and applications please create a
back up prior to requesting service.
How to Obtain Warranty Service or
Other Information
You will receive instructions on how to ship the Products,
Accessories or Software, at your expense, to a Motorola
Authorized Repair Center. To obtain service, you must include: (a) a
copy of your receipt, bill of sale or other comparable proof of
purchase; (b) a written description of the problem; (c) the name of
your service provider, if applicable; (d) the name and location of
the installation facility (if applicable) and, most importantly;
(e) your address and telephone number.
USA Phones
1-800-331-6456
Pagers
1-800-548-9954
Two-Way Radios and Messaging Devices
1-800-353-2729
Canada All Products
1-800-461-4575
TTY
1-888-390-6456
For
Accessories
and
Software
, please call the telephone
number designated above for the product with which they are
used.
Warranty
59
What Other Limitations Are There?
ANY IMPLIED WARRANTIES, INCLUDING WITHOUT LIMITATION
THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS
FOR A PARTICULAR PURPOSE, SHALL BE LIMITED TO THE
DURATION OF THIS LIMITED WARRANTY, OTHERWISE THE
REPAIR, REPLACEMENT, OR REFUND AS PROVIDED UNDER THIS
EXPRESS LIMITED WARRANTY IS THE EXCLUSIVE REMEDY OF
THE CONSUMER, AND IS PROVIDED IN LIEU OF ALL OTHER
WARRANTIES, EXPRESS OR IMPLIED. IN NO EVENT SHALL
MOTOROLA BE LIABLE, WHETHER IN CONTRACT OR TORT
(INCLUDING NEGLIGENCE) FOR DAMAGES IN EXCESS OF THE
PURCHASE PRICE OF THE PRODUCT, ACCESSORY OR SOFTWARE,
OR FOR ANY INDIRECT, INCIDENTAL, SPECIAL OR
CONSEQUENTIAL DAMAGES OF ANY KIND, OR LOSS OF
REVENUE OR PROFITS, LOSS OF BUSINESS, LOSS OF
INFORMATION OR DATA, SOFTWARE OR APPLICATIONS OR
OTHER FINANCIAL LOSS ARISING OUT OF OR IN CONNECTION
WITH THE ABILITY OR INABILITY TO USE THE PRODUCTS,
ACCESSORIES OR SOFTWARE TO THE FULL EXTENT THESE
DAMAGES MAY BE DISCLAIMED BY LAW.
Some states and jurisdictions do not allow the limitation or
exclusion of incidental or consequential damages, or
limitation on the length of an implied warranty, so the
above limitations or exclusions may not apply to you. This
warranty gives you specific legal rights, and you may also
have other rights that vary from state to state or from one
jurisdiction to another.
Laws in the United States and other countries preserve for
Motorola certain exclusive rights for copyrighted Motorola
software such as the exclusive rights to reproduce and distribute
copies of the Motorola software. Motorola software may only be
copied into, used in, and redistributed with, the Products
associated with such Motorola software. No other use, including
without limitation disassembly of such Motorola software or
exercise of the exclusive rights reserved for Motorola, is
permitted.
60
WHO Information
Information from the World Health Organization
WHO Information
Present scientific information does not indicate the need for any
special precautions for the use of mobile phones. If you are
concerned, you may want to limit your own or your children’s RF
exposure by limiting the length of calls or by using handsfree
devices to keep mobile phones away from your head and body.
Source: WHO Fact Sheet 193
Further information:
http://www.who.int./peh-emf
61
index
index
A
alert
defined 29
indicators 28
interval 35
message type 35
setting 35
answer key 1
answering a call 18, 35
B
battery
charging 16
extending battery life 16
installing 15
C
call
answer options 18, 35
call waiting 33
dialed calls list 38
international access code
40
missed call 38
mute 38
received calls list 38
redial 38
ring style 30
unanswered call 39
call waiting 39
caller ID 39
calling line identification. See
caller ID
clock
setting 36
codes
changing 34
default 34
forgetting 34
correcting entry errors 18
D
date, setting 36
dialed calls list 38
display
description 27
home screen 27
personalizing 41
E
earpiece 1
emergency number 40
62
index
end key 1
external display 3
F
flip 32
FM radio 22
frequently asked questions
47
H
home screen
defined 27
I
indicators
alert type 29
message waiting 28
status, in home screen 28
international access code
41
iTAP software 32
K
key
answer 1
end 1
left soft key 1, 27
menu 1
navigation key 34
power 1
right soft key 1, 27
send 1
volume control 1, 33
keypad 32
L
left soft key
functions 1, 27
lock
RUIM card 17
M
menu
entering text 26
icons, in home screen 29
using 28
menu key 1
missed call 34
multi-letter phonebook
search 21
mute a call 34
N
navigation key 34
numbers, entering 33
P
passwords. See codes
phone
answer options 18, 31
clear stored call lists 38
codes 29
date, setting 31
ring style 30
63
index
security code 29
time, setting 31
turning on/off 17
unlock code 33
phone number
international access code
40
redialing 37
storing in phonebook 42
phonebook
searching 23
storing an entry 42
PIN code
entering 17
power key 1
predictive text entry 31
R
received calls list 33
recent calls 33
redial
busy number 37
right soft key
functions 1, 25
ring style, setting 35
ring tone
changing 35
ringer volume, setting 35
RUIM card
locking 17
RUIM PIN code
entering 17
S
safety information 5
security code
changing 34
default 34
send key 1
silent alert, setting 35
SIM Blocked message 17
SIM card
defined 15
installing 15
PIN code entry 17
precautions 15
SIM Blocked message 17
soft keys
functions 25
illustration 1
speakerphone 24
symbols, entering 33
T
tap method text entry 28
text
entering 31
iTAP software predictive
text entry 32
numeric method 33
symbol method 33
tap method 33
time, setting 36
64
index
U
unanswered call 39
unlock code
changing 34
default 34
V
vibrate alert
setting 35
voicemail 40
volume
keypad 33
ringer 33
