Response to Reference 11299 users guide information
APPLICANT: MOTOROLA FCC ID: IHDT5ZY1
EXHIBIT 8
Revised 1-21-00
USER MANUAL INFORMATION
This product provides automatic notification of emergency and status information. Only
minimal user interface is possible. Limited user documentation may be provided by individual
automobile manufacturers. If requested by the FCC, Motorola will contact the automobile
manufacturers to obtain their specific wording or actual manuals.
IMPORTANT INSTALLATION INFORMATION
Motorola provides the following information, with the product, when delivered to the automobile
manufacturer: (Draft copy follows:)
ANTENNA INSTALLATION
IMPORTANT:
To meet the FCC's RF Exposure Guidelines, the antenna should be installed to ensure a
minimum distance between the body of the user and nearby persons and the antenna. To
determine the minimum distance, calculate the combined cable loss and antenna gain and
refer to the graph below to identify the required minimum separation distance in centimeters.
Combined Cable Loss and Antenna Gain vs. Minimum Separation Distance
-4
-3
-2
-1
0
1
2
3
4
5
20 25 30 35 40 45 50
Minimum Separation Distance (cm)
Combined Cable Loss and Antena Gain (dB)
