Exhibit 8 Users Manual

APPLICANT: MOTOROLA, INC. FCC ID: IHDT6GD1

INSTRUCTION MANUAL

x A preliminary draft copy of the User’s Manual follows this cover page.

x The User’s Manual will have the following text added to it:

"NOTE: This equipment has been tested and found to comply with the limits for a Class B

digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide

reasonable protection against harmful interference in a residential installation. This equipment

generates, uses and can radiate radio frequency energy and, if not installed and used in

accordance with the instructions, may cause harmful interference to radio communications.

However, there is no guarantee that interference will not occur in a particular installation. If

this equipment does cause harmful interference to radio or television reception, which can be

determined by turning the equipment off and on, the user is encouraged to try to correct the

interference by one or more of the following measures:

. Reorient or relocate the receiving antenna.

. Increase the separation between the equipment and receiver.

. Connect the equipment into an outlet on a circuit different from that to which the receiver is

connected.

. Consult the dealer or an experienced radio/TV technician for help."

EXHIBIT 8

motorola.com

HELLOMOTO

Introducing your new Motorola 3G wireless phone. Here’s a quick anatomy lesson.

Left Soft Key

Go online.

Video Call Key

Volume Keys

Internal Camera Lens

Smart Key

Send Key

Make & answer calls.

Navigation Key

Navigate menus.

Center Key

Open menus, select menu items.

Right Soft Key

Clear/Back Key

Camera Key

Microphone

Power/End Key

Turn on/off, hang up, exit menus.

Accessory Connector Port

Insert battery charger

& phone accessories.

Volume Keys

Scroll and adjust volume.

Smart Key

Open the audio player and select options.

Camera Key

External Camera Lens

Camera LightExternal Display

See incoming call information, use as

camera viewfinder when flip is closed.

Touch-Sensitive Audio Player Keys

Rewind

Play/Pause

Fast-forward

Press and hold the

Power

Key

for a few

seconds or until the

display lights up to turn

on your phone.

Press the Navigation Key

up, down, left, or right

(

) to highlight a menu

feature.

Press the Center Key

to select it.

Press the Center Key

key to open the

Main Menu

Service Provider

12/31/07

12:00

Options Main Menu Select

Web Access

Back

Motorola, Inc.

Consumer Advocacy Office

1307 East Algonquin Road

Schaumburg, IL 60196

www.hellomoto.com

Certain mobile phone features are dependent on the capabilities

and settings of your service provider’s network. Additionally,

certain features may not be activated by your service provider,

and/or the provider's network settings may limit the feature’s

functionality. Always contact your service provider about feature

availability and functionality. All features, functionality, and other

product specifications, as well as the information contained in this

user's guide are based upon the latest available information and

are believed to be accurate at the time of printing. Motorola

reserves the right to change or modify any information or

specifications without notice or obligation.

MOTOROLA and the Stylized M Logo are registered in the US

Patent & Trademark Office. All other product or service names are

the property of their respective owners. The Bluetooth trademarks

are owned by their proprietor and used by Motorola, Inc. under

license. Java and all other Java-based marks are trademarks or

registered trademarks of Sun Microsystems, Inc. in the U.S. and

other countries. Microsoft, Windows and Windows Me are

registered trademarks of Microsoft Corporation; and Windows XP

is a trademark of Microsoft Corporation.

Caution:

Changes or modifications made in the radio phone, not

expressly approved by Motorola, will void the user’s authority to

operate the equipment.

Software Copyright Notice

The Motorola products described in this manual may include

copyrighted Motorola and third-party software stored in

semiconductor memories or other media. Laws in the United

States and other countries preserve for Motorola and third-party

software providers certain exclusive rights for copyrighted

software, such as the exclusive rights to distribute or reproduce

the copyrighted software. Accordingly, any copyrighted software

contained in the Motorola products may not be modified,

reverse-engineered, distributed, or reproduced in any manner to

the extent allowed by law. Furthermore, the purchase of the

Motorola products shall not be deemed to grant either directly or

by implication, estoppel, or otherwise, any license under the

copyrights, patents, or patent applications of Motorola or any

third-party software provider, except for the normal, non-exclusive,

royalty-free license to use that arises by operation of law in the

sale of a product.

Manual Number: 68XXXXX147-O

contents

menu map. . . . . . . . . . . . 7

Safety Information . . . . . 9

Use and Care . . . . . . . . 14

EU Conformance . . . . . 15

Recycling Information . 16

essentials . . . . . . . . . . . 17

about this guide . . . . . 17

SIM card . . . . . . . . . . . 17

battery . . . . . . . . . . . . 18

turn it on & off . . . . . . 20

make a call . . . . . . . . . 21

answer a call. . . . . . . . 21

store a phone number 21

call a stored phone

number . . . . . . . . . . . . 22

your phone number . . 22

main attractions . . . . . . 23

SCREEN3™ headlines 23

Bluetooth™ wireless . 24

audio player . . . . . . . . 31

take & send a photo . . 33

record & send a video 36

video calls. . . . . . . . . . 37

text messages . . . . . . 38

memory card . . . . . . . 41

cable connections. . . . 43

phone updates . . . . . . 45

basics. . . . . . . . . . . . . . . 46

display . . . . . . . . . . . . 46

text entry . . . . . . . . . . 49

volume . . . . . . . . . . . . 53

navigation key. . . . . . . 53

smart key . . . . . . . . . . 53

external display. . . . . . 54

handsfree speaker . . . 54

codes & passwords . . 54

lock & unlock phone . . 55

customize . . . . . . . . . . . 56

ring style. . . . . . . . . . . 56

time & date. . . . . . . . . 57

wallpaper . . . . . . . . . . 58

screen saver . . . . . . . . 58

themes . . . . . . . . . . . . 59

display appearance . . . 59

answer options. . . . . . 60

calls . . . . . . . . . . . . . . . . 61

turn off a call alert . . . . 61

recent calls . . . . . . . . . 61

redial. . . . . . . . . . . . . . 62

return a call. . . . . . . . . 62

contents

caller ID . . . . . . . . . . . . 63

emergency calls . . . . . 63

voicemail . . . . . . . . . . . 64

other features . . . . . . . . 65

advanced calling . . . . . 65

phonebook. . . . . . . . . . 69

messages . . . . . . . . . . 74

instant messaging . . . . 77

personalizing . . . . . . . . 79

call times & costs . . . . 81

handsfree . . . . . . . . . . 82

data calls . . . . . . . . . . . 83

network . . . . . . . . . . . . 85

personal organizer . . . . 85

security . . . . . . . . . . . . 88

fun & games . . . . . . . . 88

service and repairs . . . . 92

SAR Data . . . . . . . . . . . . 93

Warranty. . . . . . . . . . . . . 94

WHO Information . . . . . 98

index. . . . . . . . . . . . . . . . 99

menu map

main menu

Video Camera

Tools

•USIM*

•Calculator

• Datebook

•Alarm Clock

• Dialing Services

• Fixed Dial *

• Service Dial *

•Quick Dial

• Activation List

• Messenger *

• World Clock

Camera

Multimedia

• Media Finder

•Music

• Pictures

• Videos

• Voice Records

• Ring Tones

• Wallpapers

• Themes

• Camera

• Video Camera

• Voice Record

Web Access

•Browser

• My Bookmarks

•History

•Go To URL

•Browser Setup

• Web Sessions *

Games & Apps

Messages

• Create Message

• Voicemail

• Message Inbox

•EmailMsgs

• Hot Messages

•Browser Msgs

• Info Services *

• Outbox

•Drafts

• Templates

Recent Calls

• (press the

to scroll

through the call lists)

Phonebook

Settings

• (see next page)

Connection

• Bluetooth™ Link

• USB Settings

•MOTOSYNC™*

Airplane Mode

• Airplane Mode

• Prompt at Startup

* optional features

This is the standard main menu layout. Your

phone’s menu may be a little different.

menu map

settings menu

Personalize

• Home Screen

• Headlines

• Main Menu

•Voice Dial Setup

•Skin

• Greeting

• Wallpaper

• Screen Saver

Ring Styles

•Style

• style Detail

Connection

• Bluetooth™ Link

• USB Settings

•MOTOSYNC™*

Call Forward *

• Voice Calls

• Video Calls

•Cancel All

• Forward Status

In-Call Setup

• In-Call Timer

• Call Cost Setup *

• My Caller ID

• Answer Options

• Call Waiting

•MSG Alert

* optional features

Initial Setup

• Time and Date

• Speed Dial

•AutoRedial

• Display Timeout

• Backlight

• Charging Lights

• TTY Setup *

•Scroll

• Text Marquee

• Language

•Battery Save

• Brightness

•DTMF

• Live Video Share Service *

• Master Reset

•Master Clear

Phone Status

• My Tel. Numbers

• Credit Info/Available *

• Active Line *

•Battery Meter

• User Accounts

• Download Location

• Storage Devices

• Voice Dial Languages

• Software Update *

• Other Information

Headset

• Auto Answer

• Ringer Options

•Voice Dial

Car Settings

• Auto Answer

• Auto Handsfree

• Power-Off Delay

• Charger Time

Airplane Mode

Network

•New Network

•Network Setup

• Available Networks

• My Network List *

• Service Tone

• Call Drop Tone

Security

• Phone Lock

• Keypad Lock

• Lock Application

• Show Private Entries

• Fixed Dial *

• Restrict Calls *

• Call Barring *

•SIM PIN

•SIM PIN2

• New Passwords

• Certificate Mgmt *

Java™ Settings

• Java System

• Delete All Apps

• App Vibration

• App Volume

• App Priority *

• App Backlight

• Set Standby App *

•DNS IP*

Safety Information

Safety and General Information

Safet y Informa tion

This section contains important information on the safe and

efficient operation of your mobile device. Read this

information before using your mobile device.

Exposure to Radio Frequency (RF)

Energy

Your mobile device contains a transmitter and receiver. When it is

ON, it receives and transmits RF energy. When you communicate

with your mobile device, the system handling your call controls the

power level at which your mobile device transmits.

Your Motorola mobile device is designed to comply with local

regulatory requirements in your country concerning exposure of

human beings to RF energy.

Operational Precautions

For optimal mobile device performance and to be sure that human

exposure to RF energy does not exceed the guidelines set forth in

the relevant standards, always follow these instructions and

precautions.

External Antenna Care

If your mobile device has an external antenna, use only a

Motorola-supplied or approved replacement antenna. Use of

unauthorized antennas, modifications, or attachments could

damage the mobile device and/or may result in your device not

complying with local regulatory requirements in your country.

DO NOT hold the external antenna when the mobile device is IN

USE. Holding the external antenna affects call quality and may

cause the mobile device to operate at a higher power level than

needed.

Product Operation

When placing or receiving a phone call, hold your mobile device

just like you would a landline phone.

If you wear the mobile device on your body, always place the

mobile device in a Motorola-supplied or approved clip, holder,

holster, case, or body harness. If you do not use a body-worn

accessory supplied or approved by Motorola, keep the mobile

device and its antenna at least 2.5 centimeters (1 inch) from your

body when transmitting.

* The information provided in this document supersedes the general

safety information in user’s guides published prior to May 1, 2006.

Safety Information

When using any data feature of the mobile device, with or without

an accessory cable, position the mobile device and its antenna at

least 2.5 centimeters (1 inch) from your body.

Using accessories not supplied or approved by Motorola may

cause your mobile device to exceed RF energy exposure

guidelines. For a list of Motorola-supplied or approved

accessories, visit our Web site at:

www.motorola.com

RF Energy Interference/Compatibility

Nearly every electronic device is subject to RF energy interference

from external sources if inadequately shielded, designed, or

otherwise configured for RF energy compatibility. In some

circumstances your mobile device may cause interference with

other devices.

Follow Instructions to Avoid Interference

Problems

Turn off your mobile device in any location where posted notices

instruct you to do so. These locations include hospitals or health

care facilities that may be using equipment that is sensitive to

external RF energy.

In an aircraft, turn off your mobile device whenever instructed to

do so by airline staff. If your mobile device offers an airplane mode

or similar feature, consult airline staff about using it in flight.

Pacemakers

If you have a pacemaker, consult your physician before using this

device.

Persons with pacemakers should observe the following

precautions:

•

ALWAYS keep the mobile device more than

20 centimeters (8 inches) from your pacemaker when the

mobile device is turned ON.

•

DO NOT carry the mobile device in the breast pocket.

•

Use the ear opposite the pacemaker to minimize the

potential for interference.

•

Turn OFF the mobile device immediately if you have any

reason to suspect that interference is taking place.

Hearing Aids

Some mobile devices may interfere with some hearing aids. In the

event of such interference, you may want to consult your hearing

aid manufacturer or physician to discuss alternatives.

Other Medical Devices

If you use any other personal medical device, consult your

physician or the manufacturer of your device to determine if it is

adequately shielded from RF energy.

Safety Information

Driving Precautions

Check the laws and regulations on the use of mobile devices in the

area where you drive. Always obey them.

When using your mobile device while driving, please:

•

Give full attention to driving and to the road. Using a

mobile device may be distracting. Discontinue a call if you

can’t concentrate on driving.

•

Use handsfree operation, if available.

•

Pull off the road and park before making or answering a

call if driving conditions so require.

Responsible driving practices can be found in the “Smart Practices

While Driving” section at the end of this guide and/or at the

Motorola Web site:

www.motorola.com/callsmart

Operational Warnings

Obey all posted signs when using mobile devices in public areas,

such as health care facilities or blasting areas.

Automobile Air Bags

Do not place a mobile device in the air bag deployment area.

Potentially Explosive Atmospheres

Areas with potentially explosive atmospheres are often but not

always posted, and can include fueling areas such as below decks

on boats, fuel or chemical transfer or storage facilities, or areas

where the air contains chemicals or particles, such as grain, dust,

or metal powders.

When you are in such an area, turn off your mobile device, and do

not remove, install, or charge batteries. In such areas, sparks can

occur and cause an explosion or fire.

Damaged Products

If your mobile device or battery has been submerged in water,

punctured, or subjected to a severe fall, do not use it until you take

it to a Motorola Authorized Service Center. Do not attempt to dry it

with an external heat source, such as a microwave oven.

Batteries and Chargers

If jewelry, keys, beaded chains, or other conductive

materials touch exposed battery terminals, this

could complete an electrical circuit (short circuit),

become very hot, and could cause damage or

injury. Be careful when handling a charged battery,

particularly when placing it inside a pocket, purse, or other

container with metal objects.

Use only Motorola Original

batteries and chargers.

Caution:

To avoid risk of personal injury, do not dispose of your

battery in a fire.

Safety Information

Your battery, charger, or mobile device may contain symbols,

defined as follows:

Choking Hazards

Your mobile device or its accessories may include detachable

parts, which may present a choking hazard to small children. Keep

your mobile device and its accessories away from small children.

Glass Parts

Some parts of your mobile device may be made of glass. This glass

could break if the product is dropped on a hard surface or receives

a substantial impact. If glass breaks, do not touch or attempt to

remove. Stop using your mobile device until the glass is replaced

by a qualified service center.

Seizures/Blackouts

Some people may be susceptible to epileptic seizures or blackouts

when exposed to flashing lights, such as when playing video

games. These may occur even if a person has never had a previous

seizure or blackout.

If you have experienced seizures or blackouts, or if you have a

family history of such occurrences, please consult with your

physician before playing video games or enabling a flashing-lights

feature (if available) on your mobile device.

Discontinue use and consult a physician if any of the following

symptoms occur: convulsion, eye or muscle twitching, loss of

awareness, involuntary movements, or disorientation. It is always

a good idea to hold the screen away from your eyes, leave the

Symbol Definition

Important safety information follows.

Do not dispose of your battery or mobile

device in a fire.

Your battery or mobile device may require

recycling in accordance with local laws.

Contact your local regulatory authorities

for more information.

Do not throw your battery or mobile device

in the trash.

Your mobile device contains an internal

lithium ion battery.

Do not let your battery, charger, or mobile

device get wet.

Listening at full volume to music or voice

through a headset may damage your

hearing.

032374o

032376o

032375o

032378o

Li Ion BATT

Safety Information

lights on in the room, take a 15-minute break every hour, and stop

use if you are very tired.

Caution About High Volume Usage

Listening at full volume to music or voice through a

headset may damage your hearing.

Repetitive Motion

When you repetitively perform actions such as pressing keys or

entering finger-written characters, you may experience occasional

discomfort in your hands, arms, shoulders, neck, or other parts of

your body. If you continue to have discomfort during or after such

use, stop use and see a physician.

Use and Care

To care for your Motorola phone, please keep it away from:

liquids of any kind dust and dirt

Don’t expose your phone to water, rain,

extreme humidity, sweat, or other moisture.

Don’t expose your phone to dust, dirt, sand,

food, or other inappropriate materials.

extreme heat or cold cleaning solutions

Avoid temperatures below -10°C/14°F or

above 45°C/113°F.

To clean your phone, use only a dry soft cloth.

Don’t use alcohol or other cleaning solutions.

microwaves the ground

Don’t try to dry your phone in a microwave

oven.

Don’t drop your phone.

EU Conformance

European Union Directives Conformance Statement

EU Conformance

Hereby, Motorola declares that this product is in compliance with

•

The essential requirements and other relevant provisions

of Directive 1999/5/EC

•

All other relevant EU Directives

The above gives an example of a typical Product Approval Number.

You can view your product’s Declaration of Conformity (DoC) to

Directive 1999/5/EC (to R&TTE Directive) at

www.motorola.com/rtte

. To find your DoC, enter the

product Approval Number from your product’s label in the “Search”

bar on the web site.

Recycling Information

Caring for the Environment by Recycling

This symbol on a Motorola product means the product

should not be disposed of with household waste.

Disposal of your Mobile Telephone and Accessories

Please do not dispose of mobile telephones or electrical

accessories, such as chargers or headsets, with your household

waste. In some countries or regions, collection systems have been

set up to handle waste electrical and electronic items. Please

contact your regional authorities for more details. If no suitable

scheme exists, you may return unwanted mobile telephones and

electrical accessories to any Motorola Approved Service Centre in

your region.

essentials

about this guide

This guide shows how to open a menu

feature as follows:

Find it:

eMessages

Create Message

This means that, from the home screen:

Press the center key

to open the

menu.

Press the navigation key

to scroll to

eMessages

, and press the center key

to select it.

Press the navigation key

to scroll to

Create Message

, and press the center key

to select it.

SIM card

Caution:

Don’t bend or scratch your SIM card.

Keep it away from static electricity, water, and

dirt.

Yo u r Subscriber Identity Module (SIM) card

contains personal information like your phone

symbols

This means a feature is network,

SIM card, or subscription

dependent and may not be available

in all areas. Contact your service

provider for more information.

This means a feature requires an

optional accessory.

essentials

number and phonebook entries. It can also

contain your voicemail, text message, and

Internet access settings. If you put your SIM

card in another phone, that phone uses your

phone number.

To insert and use a

memory card

, see

page 41.

Turn off your phone and remove your

battery before you install or remove a SIM

card.

battery

battery tips

Battery life depends on the network, signal

strength, temperature, features, and

accessories you use.

•

Always use Motorola

Original batteries and

chargers. The warranty does

not cover damage caused by

non-Motorola batteries and/or chargers.

•

New batteries or batteries stored for a

long time may take more time to

charge.

•

When charging your battery, keep it

near room temperature.

When storing your battery, keep it

uncharged in a cool, dark, dry place.

essentials

•

Never expose batteries to

temperatures below -10°C (14°F) or

above 45°C (113°F). Always take your

phone with you when you leave your

vehicle.

•

It is normal for batteries to gradually

wear down and require longer charging

times. If you notice a change in your

battery life, it is probably time to

purchase a new battery.

Contact your local recycling center for

proper battery disposal.

Warning:

Never dispose of batteries in a fire

because they may explode.

Before using your phone, read the battery

safety information in the “Safety and General

Information” section included in this guide.

battery installation

032375o

essentials

battery charging

New batteries

are not fully

charged. Plug

the battery

charger into

your phone

and an

electrical outlet. Your phone might take

several seconds to start charging the battery.

Your display shows

Charge Complete

when

finished.

Tip:

Relax, you can’t overcharge your battery.

It will perform best after you fully charge and

discharge it a few times.

The battery charger shipped with this device

is designed for Motorola 3G mobile phones.

Other chargers might take longer to charge

your battery, or cause your calls to fail during

charging.

turn it on & off

Caution:

Some phones ask for your SIM card

PIN code when you turn them on. If you enter

an incorrect PIN code three times before the

correct code, your SIM card is disabled, and

your display shows

SIM Blocked

. Contact your

service provider.

To turn on your phone,

press and hold

for

a few seconds or until

the keypad or display

lights up. If prompted,

enter your eight-digit

SIM card PIN code and/or four-digit unlock

code.

To turn off your phone, press and hold

for

a few seconds.

essentials

make a call

Enter a phone number and press

to make

a call.

To “hang up,” close the flip or press

To make video calls, see page 37.

answer a call

When your phone rings and/or vibrates, just

open the flip or press

to answer.

To “hang up,” close the flip or press

store a phone number

You can store a phone number in your

Phonebook

Enter a phone number in the home

screen.

Press the

Store

key.

Select

Create New Contact

, if necessary.

Enter a name and other details for the

phone number. To select a highlighted

item, press the center key

Press the

Done

key to store the number.

To edit or delete a

Phonebook

entry, see

page 70.

To store an email address from the home

screen, press

nPhonebook

New Entry

Enter the new contact’s name and

information.

Note:

Your phonebook can show you the

entries stored in your phone’s memory or on

your SIM card. To choose which entries you

see, press

nPhonebook

, then press

Options

View

. You can select

Phone & SIM Card

SIM Card

, or

Phone Contacts

essentials

call a stored phone

number

Find it:

nPhonebook

Scroll to the phonebook entry.

Shortcut:

In the phonebook, press

keypad keys to enter the first letters of an

entry you want.

Press

to call the entry.

your phone number

From the home screen, press

the clear key

then

to see your

number.

Tip:

Want to see your phone number while

you’re on a call? Press

Options

My Tel. Number

You can edit the name and phone

number stored on your SIM card. From

the home screen, press

, select an

entry, press the

View

key, press the

Options

key,

and select

Edit

. If you don’t know your phone

number, contact your service provider.

main attractions

You can do much more with your phone than

make and receive calls!

SCREEN3™ headlines

A few minutes after you turn on your

phone, headlines begin scrolling at the

bottom of your home screen. These headlines

give you news, sports, weather, and other

information.

read headlines

To go to the next or previous headlines:

press

right or left.

To go to the next or previous headline

channels: hold

right or left.

To see the current headline’s details: press

the center key

. While viewing details:

•

To go to the next or previous headline’s

details, press

right or left.

•

If a full article is available, you can

press the

key to see it.

change headline settings

Find it:

wSettings

Personalize

Headlines

options

Headlines

Turn headlines on or off.

main attractions

Bluetooth™ wireless

Your phone supports Bluetooth wireless

connections. You can connect your phone

Add New

Channels

Open a list of channel

categories. To subscribe to a

channel, select it from a

category or select

Search Channels

to search for it.

Manage My

Channels

Open a list of the channels

to which you subscribe.

Select a channel to see its

details, see its license

information, cancel its

subscription, or remove it

from the list.

Note:

If you cancel a

subscription, the channel

stays in this list until you

remove it or the subscription

period ends.

What Are

Headlines?

Show a description of the

headline service.

options

Home Keys

Show or hide feature icons

in your home screen, or

change the features for the

soft keys and navigation key

in the home screen.

Display

Connections

Change your settings for

downloading headlines and

see details of your last

connection.

Note:

To manually update

your headline contents,

select

Connection Details

, then

Refresh

options

main attractions

with a Bluetooth headset or car kit to make

handsfree calls. You can also connect your

phone with a phone or computer that

supports Bluetooth connections to exchange

files.

Note:

The use of wireless phones while

driving may cause distraction. Discontinue a

call if you can’t concentrate on driving.

Additionally, the use of wireless devices and

their accessories may be prohibited or

restricted in certain areas. Always obey the

laws and regulations on the use of these

products.

For maximum Bluetooth security

, you

should always connect Bluetooth devices in a

safe, private environment.

use a headset or handsfree car

kit

Before you try to connect your phone with

a handsfree device

, make sure the device is

and

ready

in pairing or bonding mode

(see the user’s guide for the device).

Find it:

wSettings

Connection

Bluetooth Link

Audio Devices

[Look For Devices]

Your phone lists the devices it finds within

range.

Scroll to a device in the list and press the

center key

Press the

Yes

key to connect to the

device.

If necessary, enter the device passkey

(such as

0000

) and press the

key.

main attractions

When your phone is connected, the

Bluetooth indicator

shows in the home

screen. You cannot play some copyrighted

files over a Bluetooth connection.

Shortcut:

When Bluetooth power is on, your

phone can automatically connect to a

handsfree device you have used before. Just

turn on the device or move it near the phone.

During a call or while playing a sound file, you

can press

Options

Use Bluetooth

to connect to a

headset or handsfree device you have used

before.

Tip:

Want to know more about your headset

or car kit? For specific information about a

device, refer to the instructions that came

with it.

copy files to another device

You can copy a media file, phonebook

entry, datebook event, or Web shortcut

from your phone to a computer or other

device.

Note:

You can’t copy some copyrighted

objects.

On your phone, scroll to the object that

you want to copy to the other device.

Press

Options

, then select:

•

Manage

Copy

for media files.

•

Send Contact

for phonebook entries.

•

Send

for datebook events.

Select a recognized device name, or

[Look For Devices]

to search for the device

where you want to copy the file.

main attractions

If your phone could not copy the file to the

other device

, make sure the device is

and

ready

in discoverable mode (see the user’s

guide for the device). Also, make sure the

device is not busy with another similar

Bluetooth connection.

Note:

Once you connect your phone to a

Bluetooth device, that device can start similar

Bluetooth connections with your phone. Your

display shows the Bluetooth indicator

the top when there is a Bluetooth connection.

To change a device’s

Access

setting, see

page 30.

receive files from another

device

If you do not see the

Bluetooth indicator

at the top of your

phone display, turn on your phone’s

Bluetooth feature by pressing

wSettings

Connection

Bluetooth Link

Setup

Power

Place your phone near the device, and

send the file from the device.

If your phone and the sending device

don’t recognize each other, place your

phone in discoverable mode so the

sending device can locate it. Press

wSettings

Connection

Bluetooth Link

Find Me

Press the

key on your phone to

accept the file from the other device.

Your phone notifies you when file transfer is

complete. If necessary, press the

Save

key to

save the file.

main attractions

send files to a printer

You can use a Bluetooth connection to

send a picture, message, phonebook

entry, or datebook view from your phone to a

printer.

Note:

You cannot print message

Templates

or a

phonebook

Mailing List

On your phone, scroll to the object that

you want to print, then press

Options

In the datebook, you can print the month,

week, or day.

Tip:

If you see it, you can print it. After

you capture a picture in the camera, you

can press the

Options

key and select

If available, choose additional objects or

print options.

Select a recognized printer name listed in

the

Printers

menu, or

[Look For Devices]

search for the printer where you want to

print the object.

Note:

If you see

Service Not Supported

when

you try to print, select

Options

Manage

Copy

Bluetooth

instead. Always use this

option to print 4x6 photos.

advanced Bluetooth features

A device is recognized after you connect to it

once (see page 25).

features

make phone

visible to

other

device

Allow a Bluetooth

device to discover

your phone:

wSettings

Connection

Bluetooth Link

Setup

Find Me

main attractions

connect to

recognized

device

Connect your phone

to a recognized

handsfree device:

wSettings

Connection

Bluetooth Link

Audio Devices

>device name

drop

connection

with

headset or

handsfree

device

Scroll to the device

name and press the

Drop

key.

features

switch to

headset or

handsfree

device

during call

During a call, press

Options

Use Bluetooth

switch to a recognized

headset or car kit.

Your phone connects

automatically, or shows a list

of devices you can select.

play sound

files on a

recognized

headset

While playing a sound

file, press

Options

Use Bluetooth

to switch

to a recognized headset.

Your phone connects

automatically, or shows a list

of devices you can select.

You cannot play some

copyrighted files over a

Bluetooth connection.

features

main attractions

move

multimedia

object to

device

Caution:

Moving an object

deletes

the original object

from your phone.

Scroll to the object,

press

Options

Manage

Move

, select

the device name.

copy

multimedia

object to

device

Scroll to the object,

press

Options

Manage

Copy

, select

the device name.

features

edit device

properties

wSettings

Connection

Bluetooth Link

Device History

Scroll to the device name

and press the

center key

Note:

The

Access

setting can

restrict how this device

connects to your phone. You

can choose

Automatic

(always

connects),

Always Ask

(asks

you before connecting),

Just Once

Never

, or

Custom

set

Bluetooth

options

wSettings

Connection

Bluetooth Link

Setup

features

main attractions

audio player

Your phone can play and store MP3 and

AAC song files. You can use a

removable memory card with your phone to

store more songs (see page 41).

Find it:

hMultimedia

Media Finder

Music

Press

up or down to scroll to an option,

and press the center key

to select it:

When you select a song:

• Play or pause

the song by pressing

the center key

• Skip back or forward

by pressing

left or right.

options

All Songs

Show and play individual songs.

Note:

All of your phone’s songs

appear in this list. Some songs

do not have any

Artist

Album

, or

Genre

information, so they don’t

appear in those lists.

Recently

Played

Show songs you played

recently.

Playlists

Create or play a playlist (see

page 32).

Artists

Select an artist to show or play

their songs.

Albums

Select an album to show or play

its songs.

Genres

Select a type of music to show

or play songs.

Composers

Select a composer to show or

play songs.

options

main attractions

• Change volume

by pressing the

volume keys.

• Hide the player

by pressing

Options

Hide

. This lets you use other phone

features while the song plays.

Tip:

You can listen to tunes on your way. You

can use Bluetooth™ A2DP stereo

headphones (page 24), and use airplane mode

to make your phone safe to use even while

you’re on a plane (page 91).

Your phone also has a

Ring Tones

player. To use

it, press

hMultimedia

Media Finder

Ring Tones

load music files

To download songs to your phone, see

page 89. To copy files between your phone

and a computer, see page 44.

Note:

Your phone may not play MP3 files that

have a bit rate higher than 128 kbps. If you try

to download or play one of these files, your

phone might show you an error or ask you to

delete the file. Metadata information is

not

supported for

MP4

formatted files.

create a playlist

Find it:

hMultimedia

Media Finder

Music

Playlists

Create New Playlist

Open a song list, and press the center key

to select each song you want. After you press

the

Done

key, enter a name for your list.

To hear your playlist, highlight it under

Playlists

and press

Options

Play

main attractions

play music with your phone

closed

You can close your phone while you listen to

music. When your phone is closed, the

external display shows the song artist, title,

and time. While a song is playing:

• Press the volume keys

to adjust

playback volume.

• Hold the smart key

to lock or unlock

the side keys.

• Press the smart key

to open the audio

player menu. Press your volume keys

to scroll through the menu, and press

the smart key to select a menu item.

Tip:

To lock your phone’s external keys while

the phone is closed, see page 54.

take & send a photo

To view, edit, or delete photos you’ve taken,

see page 88.

Your camera lens is on the back of your phone

when the phone is open.

main attractions

Press

Camera

to see the camera

viewfinder.

Press the center key

to take the photo

in the viewfinder. You can:

•

Press the

Options

key to store or discard

the photo.

If you press

Options

, you can print

the picture over a Bluetooth™

connection (see page 28).

•

Press the

Send

key to send the photo in

a message.

Your phone might tell you that this is a

Multimedia Msg

, since it has a picture in it.

Some other phones or networks do not

support picture messages. Press the

Yes

key to send the message.

•

Press

to discard the photo and

return to the active viewfinder.

232

Press

up or down to

view camera

settings.

Press left or

right to

change.

Exit the

camera.

Focus point

BackOptions

Zoom

Open the camera menu.

Camera

Mode (photo

or video)

Camera Light

(on or off)

Resolution

Remaining

photos

Storage

(phone or

memory card)

Timer

main attractions

Before you capture the photo, you can press

Options

to open the camera menu:

self portrait

If you close your phone while the viewfinder

is active, the external display shows the

image. Press the volume keys to zoom, or

options

Go To Pictures

See stored pictures and

photos.

Go To Video Mode

Switch to the video

camera.

Internal / External

View

Switch to the camera

facing you (

Internal

) or facing

away from you (

External

Light On / Off

Turn the camera light on or

off.

Note:

The light stays on

until you take a picture,

receive a phone call, or

select

Light Off

Auto-Timed Capture

Set a timer for the camera

to take a photo.

Camera Setup

Open the setup menu to

adjust photo settings.

Switch Storage

Device

Choose to store

videos on your

phone or a memory

card.

Free Space

See how much memory

remains.

Note:

Your service

provider may store some

content in user memory

before you receive the

phone.

options

main attractions

press the smart key to capture and store the

image.

record & send a video

To view, edit, or delete videos you’ve

recorded, see page 89.

Your camera lens is on the back of your

phone, when your phone is open.

Press

9Video Camera

to see the video

viewfinder.

Zoom

Press

or down to

view camera

settings.

Press left or

right to

change.

Open the video

camera menu.

Exit the

camera.

Focus point

Options Back

Camera

Mode (photo

or video)

Camera Light

(on or off)

Minutes

remaining

Storage

(phone or

memory card)

main attractions

Note:

The number of minutes remaining is an

estimate.

If you want to send your video in a message,

the video length must be set to

MMS

. To set

length, press

Options

Video Camera Setup

Video Length

Press the center key

to start recording

the video in the viewfinder.

Press the

Stop

key to stop recording the

video. You can:

•

Press the

Options

key to preview, store,

or discard the video.

To play a stored video from the home

screen, press

hMultimedia

Media Finder

Videos

> video name.

•

Press the

Send

key to send the

video in a message.

Enter text and press

Send To

, then scroll

to a recipient address and press the

center key

to select it. Press the

Options

key to enter a new number. To

send the message, press the

Send

key.

Note:

Some other phones or networks

do not support messages with videos.

•

Press

to discard the video and

return to the active viewfinder.

video calls

If you call someone else who has a 3G

video phone, you can see each other

while you talk. If your phone is roaming on a

non-3G network

, video calls will not work

(see the Roam indicator on page 47).

main attractions

Note:

Your phone’s external

camera light

blinks during a video call, to let people around

you know that they might be in your video.

make a video call

Enter a phone number and press

see the video call preview.

Press

to make the call.

During the call:

•

Press the

Stop Video

key to change the

call to a voice call with the

speakerphone on.

•

If you accept another

incoming voice

call

, your phone changes this video call

to a voice call.

•

If you accept another

incoming video

call

, your phone ends this video call.

To end the call, press

Tip:

Want to add video during a call? Press

Options

Share Live Video

during a voice call to

make it a video call.

turn video calling on or off

If you turn off video calling, your phone

will not accept video calls.

Find it:

wSettings

Initial Setup

Live Video Share Service

Off

After you change this setting, turn your phone

off and back on to complete the change.

text messages

To create a group mailing list, see page 72.

For more message features, see page 74.

main attractions

send a text message

A text message can contain text and

pictures, sounds, or other media

objects. You can add multiple pages to a

message, and you can put text and media

objects on each page. You can send a

message to other compatible phones, or to

email addresses.

Find it:

eMessages

Create Message

Message

Press keypad keys to enter text on the

page (for details about text entry, see

page 49).

To insert a

picture, sound, or other

object

on the page, press

Options

Insert

Select the file type and the file.

To insert

another page

in the message,

enter text or objects on the current page

and press

Options

Insert

New Page

. You can

enter more text and objects on the new

page.

When you finish the message, press the

key.

send

the message, press the

Send

key.

receive a text message

When you receive a message, your

phone plays an alert, and the display

shows

New Message

with a message indicator,

such as

Press the

Read

key to open the message.

If a multimedia message contains media

objects:

•

Photos, pictures, and animations show

as you read the message.

main attractions

•

A sound file plays when its slide

shows. Use the volume keys to adjust

the sound volume.

•

Attached files are added to the end of

the message. To open an attachment,

scroll to the file indicator/filename and

press the

View

key (image),

Play

key

(sound), or

Open

key (phonebook vCard,

datebook vCalendar entry, or unknown

file type).

manage text messages

You can sort and move your messages.

Find it:

eMessages

Message Inbox

Scroll to a message and press the

Options

key.

Your options include:

options

Sort by

Sort messages by

Time

Sender

Priority

, or other details.

Note:

You can also sort the

messages in your

Email Msgs

and

Outbox

lists.

Move to Hot

Messages

Move the selected message

your

Hot Messages

list, where you

can keep your most important

messages. To see your

Hot Messages

list:

eMessages

Hot Messages

main attractions

memory card

You can use a removable memory card

with your phone to store and retrieve

multimedia objects (such as photos and

sounds).

Note:

If you download a copyrighted file and

store it on your memory card, you can use the

file only while your memory card is inserted in

your phone. You cannot send, copy, or change

copyrighted files.

install a memory card

Remove the

battery door.

Push the card

into the metal

holder until it

clicks into

place.

To remove the memory card

, push it in

until it clicks again. It begins to slide out,

and you can slide it the rest of the way

out.

Replace the battery door.

Mark /

Unmark as

SPAM

Mark the selected message

with a SPAM icon.

Note:

To turn on a SPAM filter,

press

eMessages

, then

press >

Options

Setup

Message Setup

SPAM Filter

This automatically adds a SPAM

icon and turns off notification for

new messages from anyone not

in your phonebook.

options

main attractions

see and change memory card

information

see the files

stored on your memory card

and on your phone, open a file list such as

Pictures

(see page 88). Icons can indicate if a

file is stored in your phone memory ( ) or on

your memory card ( ).To copy or move a file

from your phone to your memory card,

highlight it in the list and press and press

Options

Manage

Copy

Move

Memory Card

. You

cannot copy or move some copyrighted files.

copy files

between your memory card and

a computer, you can use a cable connection

(see page 44) or a Bluetooth connection (see

page 26).

To see your

memory card name, available

memory,

and other information about the

card:

Find it:

wSettings

Phone Status

Storage Devices

Press

to scroll to the memory card

that is installed.

Press the center key

to see the

memory card information. Your phone

stores any content that you add, like ring

tones or games, in user memory. Your

service provider may store some content

in user memory before you receive the

phone.

Press

Options

to see the

Storage Device

menu,

which lets you

Format

Rename

the memory

card.

store and use protected content

If you try to play a copyrighted file, it might

ask you to download a license. Some licenses

main attractions

only let you play a file for a certain number of

times or days. You cannot send, copy, or

change copyrighted files.

For example, a license may allow you to play

the content of your download five times or

use the content for three days before it

expires.

To download a file, see page 89. To activate

downloaded copyrighted files:

Find it:

ÉTools

Activation List

> file type

>file

You can see file’s

Status

Type

Activation

, and

Counts Remaining

cable connections

Yo u r

phone

has a mini-USB

port so you can

connect it to a

computer to

transfer data.

Note:

Motorola Original USB data

cables and supporting software

may be sold separately. Check your

computer or hand-held device to

determine the type of cable you need. To

make

data calls

through a connected

computer, see page 83.

main attractions

connect your memory card to a

computer

You can use a cable connection to access your

phone’s memory card with a PC.

Note:

When your phone is connected to a

computer, you can only access the memory

card through the computer.

On your phone:

Press

wSettings

Connection

USB Settings

Default Connection

Memory Card

This directs the USB connection to

your memory card. Attach the

Motorola Original USB cable to the

accessory port on your phone and

to an available USB port on your computer.

Then follow these steps:

On your computer:

Open your “My Computer” window,

where your phone’s memory card shows

as a “Removable Disk” icon.

Click on the “Removable Disk” icon to

access the files on your phone’s memory

card.

To store the desired files onto the

memory card, drag and drop them as

follows:

MP3 or AAC files:

> mobile > audio

screen savers:

> mobile > picture

wallpapers:

> mobile > picture

video clips:

> mobile > video

When you finish, remove the device by

selecting the “Safely Remove Hardware”

icon in the system tray at the bottom of

your computer screen. Then select “USB

Mass Storage Devices” and “Stop”.

main attractions

Select “USB Mass Storage Device” then

“OK”.

On your phone:

To return to

Data

as your USB default

connection, press

wSettings

Connection

USB Settings

Default Connection

Data Connection

phone updates

Sometimes we think of ways to make

your phone’s software faster or more

efficient after you’ve purchased your phone.

You can find out if your phone can be updated

and register for free update notifications at:

http://www.hellomoto.com/support/

update

Note:

Software updates do not affect your

phonebook entries or other personal entries.

If you receive a software update but choose to

install it later, see page 85.

basics

See page 1 for a basic phone diagram.

display

The home screen shows when you turn on

the phone.

Note:

Depending on your service

provider, your home screen might look

different from the one shown. It might show

headlines from your service provider at the

bottom. To change this headline view, press

wSettings

Personalize

Headlines

To dial a number from the home screen, press

number keys and

Press the center key

to open the menu.

Soft Key Labels show the current soft key

functions. For soft key locations, see page 1.

Clock

Press

right to see

headlines, if

available.

Right Soft Key

Label

Left Soft Key

Label

Service Provider

12:00

Headlines and graphics from

your Service Provider

Options Main Menu

basics

Status indicators can show at the top of the

home screen:

1 Signal Strength Indicator –

Vertical bars

show the strength of the network

connection. You can’t make or receive

calls when

shows.

2 GPRS Indicator –

Shows when

your phone is using a high-speed

General Packet Radio Service (GPRS)

network connection. Indicators show PDP

context active

or packet data available

3 Data Indicator –

Shows connection

status.

4 Roam Indicator –

Shows when

your phone is seeking or using a

040079b

5. Active

Line

6. Message

7. Ring Style

8. Battery

Level

4. Roam

3. Data

2. GPRS

1. Signal

Strength

Service Provider

12:00

News and graphics from

your Service Provider

Options Main Menu

= secure

packet data

transfer

= unsecure

packet data

transfer

= secure

application

connection

= unsecure

application

connection

= secure

Circuit Switch Data

(CSD) call

= unsecure

CSD call

= Bluetooth™ connection is active

basics

network outside your home network.

Indicators can include:

5 Active Line Indicator –

Shows

to indicate an active call, or

to indicate when call forwarding is on.

Indicators for dual-line-enabled SIM cards

can include:

When an alarm is activated,

can show

here.

6 Message Indicator –

Shows when

you receive a new message.

Indicators can include:

7 Ring Style Indicator –

Shows the ring

style setting.

8 Battery Level Indicator –

Vertical bars

show the battery charge level. Recharge

the battery when your phone shows

Low Battery

= 2G home

= 2G roam

= 2.5G home

= 2.5G roam

= 3G home

= 3G roam

= line 1

active

= line 1 active, call

forward on

= line 2

active

= line 2 active, call

forward on

= text

message

= voice

message

= IM message

= loud ring

= vibrate & ring

= soft ring

= silent

= vibrate

basics

text entry

Some features let you enter text.

Press

in a text entry view to select an

entry mode:

To set your primary and secondary text entry

modes, press

Options

Text Setup

in a text entry

view and select

Primary Setup

Secondary Setup

iTAP™ and Tap mode tips

•

Press

in a text entry view to

change text case to all capital letters

For indicator

descriptions,

see following

section.

Flashing

cursor

indicates

insertion point.

After you

enter text,

press the

Send To

key to

enter

recipients.

Press the

Options

key to open the

sub-menu.

Msg

Options Send To

ÂÆ

SMS:0

entry modes

Your

Primary

text entry mode can

be set to any iTAP™

or tap

mode.

Your

Secondary

text entry mode can

be set to any iTAP

or tap

mode, or set to

None

if you don’t

want a secondary entry mode.

ÃNumeric

mode enters numbers only.

ÄSymbol

mode enters symbols only.

basics

(

), no capitals (

), or next letter

capital (

•

To enter numbers quickly, press and

hold a number key to temporarily

switch to numeric mode. Press the

number keys to enter the numbers you

want. Enter a space to change back to

iTAP or Tap mode.

•

Press

to enter punctuation or other

characters.

•

Press

to move the flashing cursor

to enter or edit message text.

•

Press

to delete the character to the

left of the cursor. Hold

to delete the

word.

•

To cancel your message, press

iTAP™ mode

Press

in a text entry view to switch to

iTAP mode. If you don’t see

, press

Options

Text Setup

to set iTAP mode as your

primary or secondary text entry mode.

iTAP mode lets you enter words using one

keypress per letter. The iTAP software

combines your keypresses into common

words, and predicts each word as you enter it.

basics

For example, if you press

7764

your display shows:

If you want a different word (such as

Progress

continue pressing keypad keys to enter the

remaining letters.

Tip:

Don’t worry if you forget how iTAP

works. In a text entry display, you can press

Options

Text Setup

Text Tutorial

to see an

explanation.

tap and tap extended modes

Press

in a text entry view to switch to tap

mode. If you don’t see

ÂÔ

ÂÕ

, press

Options

Text Setup

to set tap mode as your

primary or secondary text entry mode.

To enter text in

Tap

mode, press a keypad key

repeatedly to cycle through the letters and

number on the key. Repeat this step to enter

each letter. The

Tap Extended

mode works the

same way, but includes more special

characters and symbols.

ÁÚ

Send To

Prog ram

Options

Msg

SMS:7

Press

Options

key to open

message

options.

Press

right to accept

Program

Press

enter a space

at the cursor.

Hold

up or

down to see a

list of word

options.

Press

Send To

key when the

message is complete.

basics

For example, if you press

one time, your

display shows:

The first character of every sentence is

capitalized. If necessary, press

down to

change the character to lowercase before the

cursor moves to the next position.

numeric mode

Press

in a text entry view until you see

. Press the number keys to enter the

numbers you want.

Shortcut:

You can press and hold a number

key to temporarily switch to numeric mode

from iTAP™ or Tap modes. Press the number

keys to enter the numbers you want. Enter a

space to change back to iTAP mode.

symbol mode

Press

in a text entry view until your phone

shows a list of symbols. Scroll to the symbol

you want, then press the center key

Msg

ÁÔ

SMS:6

Character

displays at

insertion

point.

After you enter text, press the

Send To

key to

enter recipients.

Press the

Options

key to

open message

options.

After

2 seconds,

your phone

suggests a

word. Press

right to

accept it, or

press

enter a space

at the cursor.

Options Send To

Page

basics

volume

Press the volume keys to:

•

turn off an incoming

call alert

•

change the earpiece

volume during calls

•

change the ringer volume from the

home screen

Tip:

Sometimes silence really is

golden. That’s why you can quickly set

your ringer to

Vibrate

Silent

by holding

the down volume key while you are in

the home screen. You can also switch

Silent

or back by holding

in the

home screen.

navigation key

Press the

navigation key

up,

down, left, or right to

scroll to items in the

display. When you scroll

to an item, press the

center key

to select it.

smart key

The smart key gives you another way to do

things. For example, when you scroll to a

menu item, you can press the smart key to

select it (instead of pressing the

center key

). The smart key usually does

the same thing as pressing the

center key

. To find the smart key, see

page 1. To change what the smart key does in

the home screen, see page 80.

basics

external display

When you close your phone, the external

display shows the date, status indicators, and

notifications for incoming calls and other

events. For a list of phone status indicators,

see page 47.

lock external keys

You can lock your phone’s external keys (such

as the volume keys and voice key) to prevent

accidental key presses when your phone is

closed.

lock

your external keys, press

wSettings

Security

Keypad Lock

Sidekey Lock

. You can close your phone.

unlock

your external keys, open your

phone and press the

Unlock

key, then the

key.

handsfree speaker

You can use your phone’s handsfree speaker

to make calls without holding the phone to

your ear.

During a call, press the

Options

key and select

Speakerphone On

to turn the handsfree speaker

on. Your display shows

Speakerphone On

until you

turn it off or end the call.

Note:

The handsfree speaker won’t work

when your phone is connected to a handsfree

car kit or headset.

codes & passwords

Your phone’s four-digit

unlock code

originally set to

1234

. The six-digit

security

code

is originally set to

000000

. If your

service provider didn’t change these codes,

you should change them:

basics

Find it:

wSettings

Security

New Passwords

You can also change your

SIM PIN

or call

barring passwords.

If you forget your unlock code:

At the

Enter Unlock Code

prompt, try entering 1234 or the

last four digits of your phone number. If that

doesn’t work, press

and enter your

six-digit security code instead.

If you forget other codes:

If you forget your

security code, SIM PIN code, PIN2 code, or

call barring password, contact your service

provider.

lock & unlock phone

You can lock your phone to keep others from

using it. To lock or unlock your phone, you

need the four-digit unlock code.

manually lock

your phone:

Press

wSettings

Security

Phone Lock

Lock Now

automatically lock

your phone whenever

you turn it off: Press

wSettings

Security

Phone Lock

Automatic Lock

Note:

You can make emergency calls on a

locked phone (see page 63). A locked phone

still rings or vibrates for incoming calls or

messages,

but you need to unlock it to

answer

customize

ring style

Each ring style profile uses a different set of

sounds or vibrations for incoming calls and

other events. Here are the profiles you can

choose:

The ring style profile’s indicator shows at the

top of your home screen. To choose your

profile:

Find it:

wSettings

Ring Styles

Style:

style name

Shortcut:

In the

home screen

, press the

volume keys up or down to quickly change

your ring style profile. With your

phone

closed

, press a volume key to see your ring

style profile, press the smart key to change it,

then press a volume key to store the change.

Tip:

Do you get a lot of text messages? If you

don’t want to hear incoming message alerts

during phone calls, press

wSettings

In-Call Setup

MSG Alert

Not in Call

change alerts in a ring style

You can change the alerts for incoming calls

and other events. Your changes are saved in

the current ring style profile.

õLoud ÎVibrate ÍSilent

ôSoft ÌVibe & Ring

customize

Find it:

wSettings

Ring Styles

>style

Detail

Note:

Style represents the current ring style.

You can’t set an alert for the

Silent

ring style

setting.

Scroll to

Calls

(or

Line 1

Line 2

for dual-line

phones), then press the

Change

key to

change it.

Scroll to the alert you want, then press

the center key

Press the

Back

key to save the alert setting.

time & date

Your phone can automatically update your

time zone, time, and date. It uses the time

and date for the datebook.

synchronize

the time zone, time,

and date with the network: Press

wSettings

Initial Setup

Time and Date

Autoupdate

Time & Time Zone

. If you don’t want

your phone to automatically update your time

zone and date, choose

Time Only

instead.

manually

set the time zone, time, and

date, turn off

Autoupdate

, then: Press

wSettings

Initial Setup

Time and Date

Time Zone

,time or date. To jump to a city in

the time zone list, enter the first letter of its

name by pressing keypad keys.

Tip:

To choose three time zones for easier

access, press

ÉTools

World Clock

When you open

World Clock

, you can press the

Options

key to see the

Map View

of time zones.

To choose an

analog or digital

clock for your

home screen, press

wSettings

Personalize

Home Screen

Clock

Note:

If your home screen shows

headlines from your service provider, it

uses a digital clock. To choose an analog

customize

clock, you must turn off the headlines. Press

wSettings

Personalize

Headlines

wallpaper

Set a photo, picture, or animation as a

wallpaper (background) image in your home

screen.

Note:

Your theme can set your wallpaper

(page 59).

Find it:

wSettings

Personalize

Wallpaper

screen saver

Set a photo, picture, or animation as a screen

saver. The screen saver shows when the flip

is open and no activity is detected for a

specified time.

Note:

Your theme can set your screen saver

(page 59).

Tip:

This feature helps save your screen, but

not your battery. To extend battery life, turn off

the screen saver.

options


Press

up or down to select a

picture, or select

None

for no

wallpaper.

Layout

Select

Center

to center the image in

the display,

Tile

to repeat the

image across the display, or

Fit-to-screen

to stretch the image

across the display.

options

customize

Find it:

wSettings

Personalize

Screen Saver

themes

Aphone theme is a group of image and

sound files that you can apply to your

phone. Most themes include a wallpaper

image, screen saver image, and ring tone.

Your phone may come with some themes,

and you can download more.

apply

a theme, press

hMultimedia

Themes

> theme.

download

a theme, see page 89.

delete

a theme, press

hMultimedia

Themes

, scroll to the theme, and

press

Options

Delete

Delete All

Note:

You can delete only downloaded

themes.

display appearance

Note:

The

Battery Save

feature tells your phone

not to light the display or keypad unless you’re

in a dark place. To turn on this feature, press

wSettings

Initial Setup

Battery Save

To choose a phone

skin

that sets the look and

feel of your phone’s display: Press

wSettings

Personalize

Skin

. Your theme

can set your phone skin (page 59).

To set your display

brightness

: Press

wSettings

Initial Setup

Brightness

options


Press

up or down to select a

picture or animation, or select

None

for no screen saver.

Delay

Select the length of inactivity

before the screen saver shows.

customize

To save battery life, your keypad

backlight

turns off when you’re not using your phone.

The backlight turns on when you open the flip

or press any key. To set how long your phone

waits before the backlight turns off:

Press

wSettings

Initial Setup

Backlight

Note:

To turn the backlight on or off for Java™

applications, press

wSettings

Java Settings

App Backlight

To save battery life, the

display

can turn off

when you’re not using your phone. The

display turns back on when you open the flip

or press any key. To set how long your phone

waits before the display turns off:

Press

wSettings

Initial Setup

Display Timeout

answer options

You can use different ways to answer an

incoming call. To turn on or turn off an answer

option:

Find it:

wSettings

In-Call Setup

Answer Options

options

Multi-Key

Answer by pressing any key.

Open to Answer

Answer by opening the flip.

calls

To make and answer calls, see page 21.

turn off a call alert

You can press the volume keys to turn off a

call alert before answering the call.

recent calls

Your phone keeps lists of incoming and

outgoing calls, even for calls that didn’t

connect. The most recent calls are listed first.

The oldest calls are deleted as new calls are

added.

Shortcut:

Press

from the home screen to

see a list of recent calls.

Find it:

sRecent Calls

Received Calls

Dialed Calls

Scroll to a call. A

next to a call means the

call connected.

•

To call the number, press

•

To see call details (like time and date),

press the center key

•

To see the

Last Calls Menu

, press

Options

This menu can include:

options

Store

Create a phonebook entry

with the number in the

No.

field.

Store

does not appear if

the number is already

stored.

calls

redial

Press

from the home screen to see a

list of recent calls.

Scroll to the entry you want to call, then

press

If you hear a

busy signal

, and you see

Call Failed

, you can press

or the

Retry

key to redial the number. When the call goes

through, your phone rings or vibrates one

time, shows

Redial Successful

, and connects the

call.

return a call

Your phone keeps a record of your

unanswered calls, and shows

X Missed Calls

where

is the number of missed calls.

Press the

View

key to see the received

calls list.

Delete

Delete the entry.

Delete All

Delete all entries in the list.

Hide ID /

Show ID

Hide or show your caller ID

for the next call.

Send Message

Open a new text message

with the number in the

field.

Add Digits

Add digits after the number.

Attach Number

Attach a number from the

phonebook or recent calls

lists.

Send Tones

Send the number to the

network as DTMF tones.

Note:

This option shows

only during a call.

options

calls

Scroll to the call you want to return, then

press

caller ID

Calling line identification (caller ID)

shows the phone number for an

incoming call in your external and internal

displays.

Your phone shows the caller’s name and

picture when they’re stored in your

phonebook, or

Incoming Call

when caller ID

information isn’t available.

You can set your phone to play a different

ringer ID for an entry stored in your

phonebook (see page 71).

To show or hide

your phone number

from

the next person you call, enter the phone

number and press

Options

Hide ID/Show ID

emergency calls

Your service provider programs one or more

emergency phone numbers, such as 911 or

112, that you can call under any

circumstances, even when your phone is

locked or the SIM card is not inserted.

Note:

Emergency numbers vary by country.

Your phone’s preprogrammed emergency

number(s) may not work in all locations, and

sometimes an emergency call cannot be

placed due to network, environmental, or

interference issues.

Press the keypad keys to dial the

emergency number.

Press

to call the emergency number.

calls

voicemail

Your network stores the voicemail

messages you receive. To listen to your

messages, call your voicemail number.

Note:

Your service provider may include

additional information about using this

feature.

When you

receive

a voicemail message, your

phone shows the voicemail message

indicator

and

New Voicemail

. Press the

Call

key to listen to the message.

check

voicemail messages:

Find it:

eMessages

Voicemail

Your phone may prompt you to store your

voicemail phone number. If you don’t know

your voicemail number, contact your service

provider.

Note:

You can’t store a

(pause),

(wait), or

(number) character in this number. If you want

to store a voicemail number with these

characters, create a phonebook entry for it.

Then you can use the entry to call your

voicemail.

other features—advanced calling

other features

advanced calling

features

voice dial a number not stored in the

phonebook (digit dial)

Press and hold

When prompted, say “

digit dial

” (within

two seconds). When prompted again, say

the digits you want to dial (within two

seconds per digit).

Your phone recognizes the digits you want

to dial. To voice dial a phonebook entry, see

page 69.

attach a phone number

Dial an area code or prefix for a

phonebook number, then press

Options

Attach Number

features

other features—advanced calling

notepad

The last number you entered is stored in

the notepad. You can use the notepad to

“jot down” a number during a call for later

use. To see the notepad:

Press

sRecent Calls

Notepad

•

To call the number, press

•

To create a phonebook entry with the

number in the

No.

field, press the

Store

key.

•

To open the

Dialing Menu

to attach a

number or insert a special character,

press

Options

features

international calls

If your phone service includes

international dialing, press and hold

insert your local international access code

(indicated by

). Then, press the keypad

keys to dial the country code and phone

number.

hold a call

Press

Options

Hold

to put all active calls on

hold.

mute a call

Press the

Mute

key (if available) or

Options

Mute

to put all active calls on mute.

features

other features—advanced calling

call waiting

When you’re on a call, you’ll hear an

alert if you receive a second call.

Press

to answer the new call.

•

To switch between calls, press the

Switch

key.

•

To connect the two calls, press the

Link

key.

•

To end the call on hold, press

Options

End Call On Hold

To turn the call waiting feature on or off,

press

wSettings

In-Call Setup

Call Waiting

Off

features

conference call

During a call:

Dial next number, press

, press the

Link

key.

transfer a call

During a call:

Options

Transfer

, dial transfer number, press

call forwarding

Set up or cancel call forwarding:

wSettings

Call Forward

You can set how long your phone waits

before it forwards a call (

, or

seconds).

features

other features—advanced calling

restrict calls

Restrict outgoing or incoming calls:

wSettings

Security

Restrict Calls

Tell your phone to allow

All

None

, or only the

calls from your

Phonebook

call barring

Restrict outgoing or incoming calls:

Restrict your voice or video calls to block all

calls, international calls, or all calls except

ones on your home network.

wSettings

Security

Call Barring

TTY calls

Set up your phone for use with an

optional TTY device:

wSettings

Initial Setup

TTY Setup

features

fixed dial

When you turn on fixed dialing, you

can call only numbers stored in the fixed

dial list.

Turn fixed dialing on or off:

wSettings

Security

Fixed Dial

Use the fixed dial list:

ÉTools

Dialing Services

Fixed Dial

service dial

Your service provider might give you

phone numbers for taxi companies or other

services. These phone numbers are stored

on your SIM card. To see them:

ÉTools

Dialing Services

Service Dial

features

other features—phonebook

phonebook

quick dial

Dial preprogrammed phone numbers:

ÉTools

Dialing Services

Quick Dial

DTMF tones

Activate DTMF tones:

wSettings

Initial Setup

DTMF

To send DTMF tones during a call, just

press number keys or scroll to a number in

the phonebook or recent calls lists and

press

Options

Send Tones

features

voice dial a phonebook entry (name dial)

Voice dial a number stored in the

phonebook:

Press and hold

When prompted, say “

name dial

” (within

two seconds). When prompted again, say

the entry’s name (within two seconds).

Your phone matches your voice to a

phonebook entry name. To voice dial a

number not stored in the phonebook, see

page 65.

other features—phonebook

speed dial a phonebook entry

You can assign the keys

through

phonebook entries. Then, when you press

and hold a key, your phone calls the entry.

Note:

Your service provider might have

assigned some keys, such as

for your

voicemail number. You can only speed dial

phonebook entries that are stored on your

phone (not on your SIM card).

assign a speed dial key

, press

nPhonebook

and scroll to the phonebook

entry. Then, press

Options

Add to Speed Dial

and pick a speed dial key.

use a speed dial key

, just press and

hold the key in your home screen.

features

edit or delete a phonebook entry

Edit a number stored in the phonebook:

nPhonebook

, scroll to the phonebook

entry, and press

Options

. You can select

Edit Contact

Delete

, or other options.

Shortcut:

In the phonebook, press keypad

keys to enter the first letters of an entry you

want. You can also press

and

to see

the entries you use frequently, or entries in

other categories.

features

other features—phonebook

set ringer ID for a phonebook entry

Assign a ring alert (ringer ID) to an entry:

nPhonebook

> entry, then press

Options

Edit Contact

Ringer ID

> ringer name

Note:

The

Ringer ID

option isn’t available for

entries stored on the SIM card.

Activate ringer IDs:

wSettings

Ring Styles

> style

Detail

Ringer IDs

set picture ID for a phonebook entry

Assign a photo or picture to show when you

receive a call from an entry:

nPhonebook

> entry, then press

Options

Edit Contact


> picture name

Note:

The


option isn’t available for

entries stored on the SIM card.

features

set picture ID view for phonebook

Show entries as a text list, or with picture

caller ID photos:

nPhonebook

, then press

Options

Setup

View by

> view name

set category for a phonebook entry

nPhonebook

> entry, then press

Options

Edit Contact

Category

>category name

Yo u c a n s h o w

All

entries, entries in a

predefined category (

Business

Personal

General

VIPs

), or entries in a category you create.

Shortcut:

When you open your phonebook,

press

to see your categories.

features

create group mailing list

You can put several phonebook entries in a

group mailing list, then send a message to

the list. To create a list:

nPhonebook

, then press

Options

Create New

Message List

You can select the list name as an address

for multimedia messages.

Note:

Message List

cannot include entries

stored on the SIM card.

sort phonebook list

Set the order in which entries are listed:

nPhonebook

, then press

Options

Setup

Sort by

>sort order

You can sort the phonebook list by

First Name

Last Name

features

other features—phonebook

copy one phonebook entry

Copy an entry from the phone to the SIM

card, or from the SIM card to the phone:

nPhonebook

, scroll to the entry, press

Options

Copy to SIM Card

Copy to Phone

copy multiple phonebook entries

Copy multiple phonebook entries between

the phone and SIM card:

nPhonebook

, scroll to one entry, press

Options

Select Multiple to

, then select

Copy to SIM Card

Copy to Phone

features

send phonebook entry to another device

Send a phonebook entry to another phone,

computer, or device:

nPhonebook

, scroll to the entry, press

Options

Send Contact

For more information about copying files to

another device, see page 26.

print phonebook entry over

Bluetooth™ connection

You can use a Bluetooth wireless

connection to send a phonebook entry from

your phone to a printer.

nPhonebook

Scroll to the entry you want to print, and

press

Options

Select Multiple to

You cannot print a

Mailing List

. For more about

Bluetooth connections, see page 24.

features

other features—messages

messages

For basic text message features, see page 38.

Your phone reads message settings from the

USIM card. If you put another USIM card in

your phone, your phone sends and receives

messages for the phone number on the new

card.

features

send email

eMessages

Email Msgs

Create Email

Note:

To use email, you might need to

enter a

User ID

and

Password

in your email

settings (see page 77).

send voice message

eMessages

Create Message

New Voice Msg

To record the voice message, press the

Record

key, speak, then press the

Stop

key.

Your phone inserts the voice recording into

a message and lets you enter email

addresses or phone numbers to receive the

message.

features

other features—messages

read and manage messages

eMessages

Message Inbox

Icons next to each message indicate if it is

read

or unread

. Icons can also

indicate if the message is locked

urgent

, or low priority

, or if it has an

attachment

Forward

Lock

, or

Delete

a message,

scroll to it and press

Options

To open a message, press

. Then, you

can press

Options

to use or store any

phone numbers, email addresses,

Web sites, or files in the message.

features

read and manage email

eMessages

Email Msgs

Forward

Lock

, or

Delete

a message,

scroll to it and press

Options

To open a message, press

. Then, you

can press

Options

to use or store any

phone numbers, email addresses,

Web sites, or files in the message.

store message objects

Go to a multimedia message page, or

scroll to an object in a message, then:

Options

Store

features

other features—messages

print message over Bluetooth™

connection

You can use a Bluetooth wireless

connection to send a message from your

phone to a printer.

eMessages

Message Inbox

Email Msgs

Outbox

, or

Drafts

Scroll to the message you want to print and

press

Options

You cannot print message

Templates

. For

more about Bluetooth connections, see

page 24.

features

store text messages on your SIM

card

To store incoming text messages on your

SIM card, press:

eMessages

, then press

Options

Setup

Message Setup

Text Msg Setup

Default Storage

SIM Card

features

other features—instant messaging

instant messaging

edit email settings

You can edit the settings for your

Email connections. To use email, you need

to store your email

User ID

and

Password

eMessages

, then press

Options

Email Msg Setup

Account Settings

If you have more than one email account,

select an account to edit.

Your phone shows a list of email settings.

Here is where you store your email

User ID

and

Password

Note:

To create a new account, select

New Entry

in the

Account Settings

list. Your display

shows a folder for each email account under

eMessages

Email Msgs

features

browser messages

Read messages received by your

micro-browser:

eMessages

Browser Msgs

info services

Read subscription-based information

services messages:

eMessages

Info Services

features

ÉTools

Messenger

Select an IM account, or select

[New Account]

to set up an IM account.

features

other features—instant messaging

add contacts

After you log in:

Press

Options

Add Contact

and enter the

contact’s name, mobile number, IM ID, and

alias.

find others online

After you log in:

Select

Online Contacts

to see a list of others

online.

start conversation

Scroll to a name in

Online Contacts

and

press the

Send IM

key.

open active conversation

Scroll to a name in

Conversations

and

press the

Select

key.

features

insert items during a conversation

From the conversation view:

Options

Insert

You can insert an

Emoticon

Quick IM

(such as

Are

you there?

), or

Contact Info

(selected from your

phonebook).

end conversation

From the conversation view:

Options

End Conversation

log out

Select

Log Out

from the

IM Online

menu.

features

other features—personalizing

personalizing

features

language

Set menu language:

wSettings

Initial Setup

Language

scroll

Set the scroll bar to

Up/Down

Wrap Around

menu lists:

wSettings

Initial Setup

Scroll

text marquee

Set the speed for scrolling text in your

display:

wSettings

Initial Setup

Text Marquee

Note:

This setting only appears if your

phone has SCREEN3 headlines from your

service provider.

activate ringer IDs

Activate ringer IDs assigned to phonebook

entries and categories:

wSettings

Ring Styles

> style

Detail

Ringer IDs

ring volume

wSettings

Ring Styles

> style

Detail

Ring Volume

keypad volume

wSettings

Ring Styles

> style

Detail

Key Volume

reminders

Set reminder alerts for messages that you

receive:

wSettings

Ring Styles

> style

Detail

Reminders

features

other features—personalizing

headline view

If your home screen shows scrolling

headlines from your service provider, you

can turn them on or off:

wSettings

Personalize

Headlines

menu view

Show the main menu as graphic icons or as

a text-based list:

wSettings

Personalize

Main Menu

View

main menu

Reorder your phone’s main menu:

wSettings

Personalize

Main Menu

Reorder

features

show/hide menu icons

Show or hide menu feature icons in

the home screen:

wSettings

Personalize

Home Screen

Home Keys

Icons

Note:

This option is not available if your

home screen shows scrolling headlines

from your service provider.

change home keys

Change features for the soft keys,

navigation key, and smart key in the home

screen:

wSettings

Personalize

Home Screen

Home Keys

Note:

This option is not available if your

home screen shows scrolling headlines

from your service provider.

features

other features—call times & costs

call times & costs

Network connection time

is the elapsed

time from the moment you connect to your

service provider's network to the moment

you end the call by pressing

. This time

includes busy signals and ringing.

The amount of network connection time

you track on your resettable timer may not

equal the amount of time for which you

are billed by your service provider. For

billing information, contact your service

provider.

master reset

Reset all options

except

unlock code,

security code, and lifetime timer:

wSettings

Initial Setup

Master Reset

master clear

Caution:

Master clear

erases all

information you have entered

(including

phonebook and datebook entries)

and

content you have downloaded

(including

photos and sounds) stored in your phone’s

memory. After you erase the information,

you can’t recover it.

wSettings

Initial Setup

Master Clear

features

call times

Show call timers:

sRecent Calls

Call Times

in-call timer

Show time or cost information during

a call:

wSettings

In-Call Setup

In-Call Timer

other features—handsfree

handsfree

Note:

The use of wireless phones while

driving may cause distraction. Discontinue a

call if you can’t concentrate on driving.

Additionally, the use of wireless devices and

their accessories may be prohibited or

restricted in certain areas. Always obey the

laws and regulations on the use of these

products.

call cost

Show call cost trackers:

sRecent Calls

Call Cost

features

speakerphone

Activate the speakerphone during a

call:

Press the

Speaker

key (if available, or

Options

Spkrphone On

auto answer

(car kit or headset)

Automatically answer calls when

connected to a car kit or headset:

wSettings

Car Settings

Headset

Auto Answer

voice dial

(headset)

Enable voice dial with headset

send/end key:

wSettings

Headset

Voice Dial

other features—data calls

data calls

To connect your phone with a USB cable, see

page 43.

auto handsfree

(car kit)

Automatically route calls to a car kit

when connected:

wSettings

Car Settings

Auto Handsfree

features

send data

Connect your phone to the device,

then place the call through the device

application.

features

receive data

Connect your phone to the device,

then answer the call through the device

application.

features

other features—data calls

setting up Exchange ActiveSync

You can use the Internet to

synchronize your phone’s phonebook and

datebook entries with an email account on a

Microsoft® Exchange 2003 Server.

You need to know the email account’s

user

name

and

password

, the Microsoft®

Exchange

server name

, and the

user

domain name

. Confirm that the

Mobility

option is enabled on the email account, and

that

data service

is activated with your

phone service provider.

set up

an ActiveSync partner, press

wSettings

Connection

MOTOSYNC

Exchange

, press the

Options

key, then >

Setup

Enter the server details, including

Server Name

Domain

, and the

Web Session

to use.

To set up a

Web Session

, see page 90.

features

using Exchange ActiveSync

Once you set up an Exchange

ActiveSync partner, you can schedule your

phone to synchronize with the account

automatically.

schedule

synchronization, press

wSettings

Connection

MOTOSYNC

Exchange

, press the

Options

key, then

Auto Sync Setup

. Enter the time and days you

want your phone to synchronize.

features

other features—network

network personal organizer

features

network settings

See network information and adjust

network settings:

wSettings

Network

software update

Your service provider can send

updated phone software over the air to your

phone. When your phone receives a

software update, you can choose to install it

later. To install the software update later:

wSettings

Phone Status

Software Update

Install Now

features

set alarm

ÉTools

Alarm Clock

turn off alarm

When an alarm happens:

To turn off the alarm, press the

Disable

key or

. To set an eight-minute delay, press the

Snooze

key.

Note:

The

Snooze

key is available only if the

phone is already powered on when the

alarm sounds.

other features—personal organizer

add new datebook event or task

Your datebook can store events (with a start

and end time that can repeat) or tasks (with

a due date).

ÉTools

Datebook

, scroll to the day,

press

, press

Options

Create New Event

Create New Task

see datebook event or task

See or edit event or task details:

ÉTools

Datebook

, scroll to the day,

press

, press the

View

key

If you do not see tasks listed, press

Options

View

Organized Tasks

Tip:

Want to get to the point? To see a list

of your upcoming events, open the

datebook and press

Options

View

Organized Events

features

change datebook settings

ÉTools

Datebook

, then press

Options

Setup

You can choose the

Default View

that appears

when you open your datebook, and you can

show or hide the

Tasks On Day View

. You can

tell your phone to

Power On

if it is turned off

when a datebook alert occurs. Turn on

Lunar Calendar

if you do not want to use a solar

calendar.

event reminder

When an event reminder happens:

To see reminder details, press the

View

key.

To close the reminder, press the

Back

key.

features

other features—personal organizer

send datebook event to another device

Send a datebook event to another phone,

computer, or device:

ÉTools

Datebook

, scroll to the day,

press

, scroll to the event, press

Options

Send

print datebook month, week, or

day over Bluetooth™ connection

You can use a Bluetooth wireless

connection to send a datebook month,

week, or day from your phone to a printer.

ÉTools

Datebook

Go to the month, week, or day view and

press

Options

For more about Bluetooth connections, see

page 24.

features

create voice record

ÉMultimedia

Voice Record

When prompted, speak into the phone.

Note:

Recording phone calls is subject to

varying state and federal laws regarding

privacy and recording of conversations.

Always obey the laws and regulations on

the use of this feature.

play voice record

Play back a voice record:

hMultimedia

Media Finder

Voice Record

>voice record

calculator

ÉTools

Calculator

features

other features—security

security

fun & games

Note:

Icons next to a picture, sound, or other

object can indicate if the file is locked (

), or

if it is stored on your phone ( ) or on your

memory card ( ).

For basic information on the camera, see

page 33.

currency converter

Enter exchange rate, press the

key, enter

amount, and press

Options

Convert Currency

features

SIM PIN

Caution:

If you enter an incorrect PIN code

three times before the correct code, your

SIM card is disabled and your display shows

SIM Blocked

Lock or unlock the SIM card:

wSettings

Security

SIM PIN

lock feature

wSettings

Security

Lock Application

features

view, delete, or manage pictures

Manage photos, pictures, and animations:

hMultimedia

Media Finder

Pictures

copy or move

a file from your

memory card ( ) to your phone

memory ( ), highlight it in the list and

press and press

Options

Manage

Copy

Move

Memory Card

. You cannot copy

or move some copyrighted files.

other features—fun & games

view, delete, or manage video clips

hMultimedia

Media Finder

Videos

copy or move

a file from your

memory card ( ) to your phone

memory ( ), highlight it in the list and

press and press

Options

Manage

Copy

Move

Memory Card

. You cannot copy

or move some copyrighted files.

hear, delete, or manage sounds

Manage your ring tones and music:

hMultimedia

Sounds

copy or move

a file from your

memory card ( ) to your phone

memory ( ), highlight it in the list and

press and press

Options

Manage

Copy

Move

Memory Card

. You cannot copy

or move some copyrighted files.

features

start micro-browser

Just press

Your phone reads micro-browser settings

from the USIM card. When you remove the

USIM card, your phone clears the browser

cache. To edit your settings, see page 90.

download objects from Web page

Download a picture, sound, or other

object from a Web page:

Press

, go to the page that links to the

file, scroll to the link, and select it.

Note:

Normal airtime and/or carrier usage

charges apply.

features

other features—fun & games

Web sessions

AWeb Session stores settings that

your phone uses to access the Internet. To

select or create a Web session:

áWeb Access

Web Sessions

clear micro-browser history

Clear the micro-browser’s history,

cache, or cookies:

áWeb Access

Browser Setup

Clear History

Reset Cache

, or

Clear Cookie

features

download game or application

You can download a Java™ game or

application the same way you download

pictures or other objects:

Press

, go to the page that links to the

file, scroll to the link, and select it.

Note:

Normal airtime and/or carrier usage

charges apply.

start game or application

Start a Java™ game or application:

QGames & Apps

, scroll to the game or

application, press the center key

Note:

To install and run games stored on

your memory card, press

QGames & Apps

[Install New]

features

other features—fun & games

airplane mode

You can switch your phone to airplane mode

to prevent it from communicating with the

network. This lets you use games or other

applications while you are on an airplane,

without interfering with airplane

communications.

%Airplane Mode

Airplane Mode

You can make the airplane mode option

appear whenever you turn on your phone:

%Airplane Mode

Prompt At Startup

features

service and repairs

If you have questions or need assistance,

we're here to help.

Go to

www.motorola.com/consumer/support

where you can select from a number of

customer care options. You can also contact

the Motorola Customer Support Center at

1-800-331-6456 (United States),

1-888-390-6456 (TTY/TDD United States for

hearing impaired), or 1-800-461-4575

(Canada).

SAR Data

Specific Absorption Rate Data

SAR Da ta

This model meets international guidelines for

exposure to radio waves.

Your mobile device is a radio transmitter and receiver. It is

designed not to exceed the limits for exposure to radio waves

recommended by international guidelines. These guidelines were

developed by the independent scientific organization ICNIRP and

include safety margins designed to assure the protection of all

persons, regardless of age and health.

The guidelines use a unit of measurement known as the Specific

Absorption Rate, or SAR. The ICNIRP SAR limit for mobiles devices

used by the general public is 2 W/kg and the highest SAR value for

this device when tested at the ear was ___ W/kg.

As mobile

devices offer a range of functions, they can be used in other

positions, such as on the body as described in this user guide.

this case, the highest tested SAR value is ___ W/kg.

As SAR is measured utilizing the device’s highest transmitting

power, the actual SAR of this device while operating is typically

below that indicated above. This is due to automatic changes to

the power level of the device to ensure it only uses the minimum

level required to reach the network.

While there may be differences between the SAR levels of various

phones and at various positions, they all meet the governmental

requirements for safe exposure. Please note that improvements to

this product model could cause differences in the SAR value for

later products; in all cases, products are designed to be within the

guidelines.

The World Health Organization has stated that present scientific

information does not indicate the need for any special precautions

for the use of mobile devices. They note that if you want to reduce

your exposure then you can do so by limiting the length of calls or

using a “hands-free” device to keep the mobile phone away from

the head and body.

Additional Information can be found on the websites of the World

Health Organization (

http://www.who.int/emf

) or

Motorola, Inc.

(

http://www.motorola.com/rfhealth

1. The tests are carried out in accordance with international guidelines for

testing. The limit incorporates a substantial margin for safety to give

additional protection for the public and to account for any variations in

measurements. Additional related information includes the Motorola

testing protocol, assessment procedure, and measurement uncertainty

range for this product.

2. Please see the Safety and General Information section about body worn

operation.

SAR Data

Specific Absorption Rate Data

SAR Da ta

This model wireless phone meets the

government’s requirements for exposure to radio

waves.

Your wireless phone is a radio transmitter and receiver. It is

designed and manufactured not to exceed limits for exposure to

radio frequency (RF) energy set by the Federal Communications

Commission (FCC) of the U.S. Government and by the Canadian

regulatory authorities. These limits are part of comprehensive

guidelines and establish permitted levels of RF energy for the

general population. The guidelines are based on standards that

were developed by independent scientific organizations through

periodic and thorough evaluation of scientific studies. The

standards include a substantial safety margin designed to assure

the safety of all persons, regardless of age or health.

The exposure standard for wireless mobile phones employs a unit

of measurement known as the Specific Absorption Rate, or SAR.

The SAR limit set by the FCC and by the Canadian regulatory

authorities is 1.6 W/kg.

Tests for SAR are conducted using

standard operating positions accepted by the FCC and by Industry

Canada with the phone transmitting at its highest certified power

level in all tested frequency bands. Although the SAR is

determined at the highest certified power level, the actual SAR

level of the phone while operating can be well below the

maximum value. This is because the phone is designed to operate

at multiple power levels so as to use only the power required to

reach the network. In general, the closer you are to a wireless

base station, the lower the power output.

Before a phone model is available for sale to the public in the U.S.

and Canada, it must be tested and certified to the FCC and Industry

Canada that it does not exceed the limit established by each

government for safe exposure. The tests are performed in

positions and locations (e.g., at the ear and worn on the body)

reported to the FCC and available for review by Industry Canada.

The highest SAR value for this model phone when tested for use at

the ear is 0.39 W/kg, and when worn on the body, as described in

this user guide, is 0.58 W/kg. The SAR value for this product in its

data transmission mode (body-worn use) is 0.54 W/kg. (Body-worn

measurements differ among phone models, depending upon

available accessories and regulatory requirements).

While there may be differences between the SAR levels of various

phones and at various positions, they all meet the governmental

requirements for safe exposure. Please note that improvements to

this product model could cause differences in the SAR value for

later products; in all cases, products are designed to be within the

guidelines.

SAR Data

Additional information on Specific Absorption Rates (SAR) can be

found on the Cellular Telecommunications & Internet Association

(CTIA) Web site:

http://www.phonefacts.net

or the Canadian Wireless Telecommunications Association (CWTA)

Web site:

http://www.cwta.ca

1. In the United States and Canada, the SAR limit for mobile phones used

by the public is 1.6 watts/kg (W/kg) averaged over one gram of tissue.

The standard incorporates a substantial margin of safety to give

additional protection for the public and to account for any variations in

measurements.

2. The SAR information includes the Motorola testing protocol,

assessment procedure, and measurement uncertainty range for this

product.

Warranty

Motorola Limited Warranty for the United States and

Canada

Warran ty

What Does this Warranty Cover?

Subject to the exclusions contained below, Motorola, Inc. warrants

its telephones, pagers, messaging devices, and consumer and

professional two-way radios (excluding commercial, government

or industrial radios) that operate via Family Radio Service or

General Mobile Radio Service, Motorola-branded or certified

accessories sold for use with these Products (“Accessories”) and

Motorola software contained on CD-ROMs or other tangible media

and sold for use with these Products (“Software”) to be free from

defects in materials and workmanship under normal consumer

usage for the period(s) outlined below. This limited warranty is a

consumer's exclusive remedy, and applies as follows to new

Motorola Products, Accessories and Software purchased by

consumers in the United States or Canada, which are accompanied

by this written warranty:

Products and Accessories

Products Covered Length of Coverage

Products and

Accessories

defined above, unless

otherwise provided for

below.

One (1) year

from the date of

purchase by the first consumer

purchaser of the product unless

otherwise provided for below.

Decorative

Accessories and

Cases.

Decorative

covers, bezels,

PhoneWrap™ covers

and cases.

Limited lifetime warranty

for the

lifetime of ownership by the first

consumer purchaser of the product.

Monaural Headsets.

Ear buds and boom

headsets that transmit

mono sound through a

wired connection.

Limited lifetime warranty

for the

lifetime of ownership by the first

consumer purchaser of the product.

Warranty

Exclusions

Normal Wear and Tear.

Periodic maintenance, repair and

replacement of parts due to normal wear and tear are excluded

from coverage.

Batteries.

Only batteries whose fully charged capacity falls below

80% of their rated capacity and batteries that leak are covered by

this limited warranty.

Abuse & Misuse.

Defects or damage that result from:

(a) improper operation, storage, misuse or abuse, accident or

neglect, such as physical damage (cracks, scratches, etc.) to the

surface of the product resulting from misuse; (b) contact with

liquid, water, rain, extreme humidity or heavy perspiration, sand,

dirt or the like, extreme heat, or food; (c) use of the Products or

Accessories for commercial purposes or subjecting the Product or

Accessory to abnormal usage or conditions; or (d) other acts which

are not the fault of Motorola, are excluded from coverage.

Use of Non-Motorola Products and Accessories.

Defects or

damage that result from the use of Non-Motorola branded or

certified Products, Accessories, Software or other peripheral

equipment are excluded from coverage.

Unauthorized Service or Modification.

Defects or damages

resulting from service, testing, adjustment, installation,

maintenance, alteration, or modification in any way by someone

other than Motorola, or its authorized service centers, are

excluded from coverage.

Altered Products.

Products or Accessories with (a) serial

numbers or date tags that have been removed, altered or

obliterated; (b) broken seals or that show evidence of tampering;

non-Motorola housings, or parts, are excluded from coverage.

Communication Services.

Defects, damages, or the failure of

Products, Accessories or Software due to any communication

service or signal you may subscribe to or use with the Products

Accessories or Software is excluded from coverage.

Software

Consumer and

Professional

Two-Way Radio

Accessories.

Ninety (90) days

from the date of

purchase by the first consumer

purchaser of the product.

Products and

Accessories that are

Repaired or

Replaced.

The balance of the original

warranty or for ninety (90) days

from the date returned to the

consumer, whichever is longer.

Products Covered Length of Coverage

Software.

Applies only to physical

defects in the media that embodies

the copy of the software (e.g.

CD-ROM, or floppy disk).

Ninety (90) days

from

the date of purchase.

Warranty

Exclusions

Software Embodied in Physical Media.

No warranty is made

that the software will meet your requirements or will work in

combination with any hardware or software applications provided

by third parties, that the operation of the software products will be

uninterrupted or error free, or that all defects in the software

products will be corrected.

Software NOT Embodied in Physical Media.

Software that is

not embodied in physical media (e.g. software that is downloaded

from the internet), is provided “as is” and without warranty.

Who Is Covered?

This warranty extends only to the first consumer purchaser, and is

not transferable.

What Will Motorola Do?

Motorola, at its option, will at no charge repair, replace or refund

the purchase price of any Products, Accessories or Software that

does not conform to this warranty. We may use functionally

equivalent reconditioned/refurbished/pre-owned or new Products,

Accessories or parts. No data, software or applications added to

your Product, Accessory or Software, including but not limited to

personal contacts, games and ringer tones, will be reinstalled. To

avoid losing such data, software and applications please create a

back up prior to requesting service.

How to Obtain Warranty Service or

Other Information

You will receive instructions on how to ship the Products,

Accessories or Software, at your expense, to a Motorola

Authorized Repair Center. To obtain service, you must include: (a) a

copy of your receipt, bill of sale or other comparable proof of

purchase; (b) a written description of the problem; (c) the name of

your service provider, if applicable; (d) the name and location of the

installation facility (if applicable) and, most importantly; (e) your

address and telephone number.

USA Phones

1-800-331-6456

Pagers

1-800-548-9954

Two-Way Radios and Messaging Devices

1-800-353-2729

Canada All Products

1-800-461-4575

TTY

1-888-390-6456

For

Accessories

and

Software

, please call the telephone

number designated above for the product with which they are

used.

Warranty

What Other Limitations Are There?

ANY IMPLIED WARRANTIES, INCLUDING WITHOUT LIMITATION

THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS

FOR A PARTICULAR PURPOSE, SHALL BE LIMITED TO THE

DURATION OF THIS LIMITED WARRANTY, OTHERWISE THE

REPAIR, REPLACEMENT, OR REFUND AS PROVIDED UNDER THIS

EXPRESS LIMITED WARRANTY IS THE EXCLUSIVE REMEDY OF

THE CONSUMER, AND IS PROVIDED IN LIEU OF ALL OTHER

WARRANTIES, EXPRESS OR IMPLIED. IN NO EVENT SHALL

MOTOROLA BE LIABLE, WHETHER IN CONTRACT OR TORT

(INCLUDING NEGLIGENCE) FOR DAMAGES IN EXCESS OF THE

PURCHASE PRICE OF THE PRODUCT, ACCESSORY OR SOFTWARE,

OR FOR ANY INDIRECT, INCIDENTAL, SPECIAL OR

CONSEQUENTIAL DAMAGES OF ANY KIND, OR LOSS OF

REVENUE OR PROFITS, LOSS OF BUSINESS, LOSS OF

INFORMATION OR DATA, SOFTWARE OR APPLICATIONS OR

OTHER FINANCIAL LOSS ARISING OUT OF OR IN CONNECTION

WITH THE ABILITY OR INABILITY TO USE THE PRODUCTS,

ACCESSORIES OR SOFTWARE TO THE FULL EXTENT THESE

DAMAGES MAY BE DISCLAIMED BY LAW.

Some states and jurisdictions do not allow the limitation or

exclusion of incidental or consequential damages, or

limitation on the length of an implied warranty, so the

above limitations or exclusions may not apply to you. This

warranty gives you specific legal rights, and you may also

have other rights that vary from state to state or from one

jurisdiction to another.

Laws in the United States and other countries preserve for

Motorola certain exclusive rights for copyrighted Motorola

software such as the exclusive rights to reproduce and distribute

copies of the Motorola software. Motorola software may only be

copied into, used in, and redistributed with, the Products

associated with such Motorola software. No other use, including

without limitation disassembly of such Motorola software or

exercise of the exclusive rights reserved for Motorola, is

permitted.

WHO Information

Information from the World Health Organization

WHO Info rmation

Present scientific information does not indicate the need for any

special precautions for the use of mobile phones. If you are

concerned, you may want to limit your own or your children’s RF

exposure by limiting the length of calls or by using handsfree

devices to keep mobile phones away from your head and body.

Source: WHO Fact Sheet 193

Further information:

http://www.who.int./peh-emf

index

accessories 17, 82

accessory connector port 1

active line indicator 48

airplane mode 91

alarm clock 85

alarm indicator 48

alert

set 53, 56

turn off 53, 56, 61

animation 88

answer a call 21, 60

attach a number 62, 65

audio player 31

backlight 59, 60

battery 19, 20

extending battery life 18

battery indicator 48

battery life, extending 58,

59, 60

Bluetooth connection

datebook entry, printing

datebook entry, sending

description 24

messages, printing 76

phonebook entries,

printing 73

phonebook entries,

sending 73

restricting access 30

brightness 59

browser messages 77

browser. See micro-browser

cables 43

calculator 87

call

answering 21, 60

barring 55, 68

end 21

ending 21, 38

forwarding 67

making 21

timers 81

waiting 67

call forward indicator 48

100

index

caller ID 62, 63, 71

camera 33

car kit 82

categories 72

center key 1, 53

center select key 17

channels for headlines 24

clock 57

codes 54, 55

conference call 67

copy files 26

copyrighted files 42

costs, tracking 82

data call 83

data indicator 47

date, setting 57

datebook 86

dial a phone number 21, 68,

dialed calls 61

digit dial 65

digital audio 31

display 3, 24, 46, 59, 80

downloaded files

from Web pages 89

in messages 75

DTMF tones 62, 69

earpiece volume 53

reading and managing 75

sending 74

settings 77

emergency number 63

emoticon 78

end a call 21

end key 1, 21

ending a call 38

Enter Unlock Code message

external display 35, 54

fax call 83

fixed dial 68

flip 21, 60

forward calls 67

games 90

GPRS indicator 47

group mailing list 72

handsfree speaker 54

headlines 23, 46, 80

headset 82

headset jack 1

index

101

hold a call 66

home screen 3, 46, 80

hot message 40

IM 77

in-call indicator 48

Incoming Call message 63

information services 77

instant messaging. See IM

international access code 66

iTAP text entry mode 50

Java applications 90

keypad 60, 79

language 79

licenses 42

linking. See Bluetooth

connection

lock

application 88

phone 55

SIM card 88

Low Battery message 48

make a call 21

master clear 81

master reset 81

Media Finder 31

memory card 41

menu 3, 17, 46, 79, 80

menu icons 80

message 74, 75, 76

message alerts 56

message indicator 39, 48

message reminders 79

micro-browser 77, 89, 90

Missed Calls message 62

MMS, defined 39

MP3 sound files 31, 32

multimedia message 38, 75,

music 89

mute a call 66

name dial 69

navigation key 1, 17, 53

network settings 85

notepad 66

number. See phone number

numeric entry mode 52

object exchange 26

102

index

open to answer 60

optional accessory 17

optional feature 17

pairing. See Bluetooth

connection

passwords. See codes

personalize 79

phone number 22

phonebook 62, 65, 69, 70

photo 33, 88

picture 88

picture ID 63, 71

PIN code 20, 55, 88

PIN2 code 55

power key 1, 20

printing 28

quick dial 69

received calls 61

recent calls 61

redial 62

reminders 79

restrict calls 68

return a call 62

ring style indicator 48

ring style, setting 53, 56

ring tone 89

ringer ID 63, 71, 79

ringer volume 53, 79

roam indicator 47

safety information 9

screen saver 58

SCREEN3. See headlines

scrolling 79

security code 54

send key 1, 21

service dial 68

signal strength indicator 47

SIM Blocked message 20,

SIM card 17, 20, 55, 68, 76,

skin 59

smart key 53, 80

smiley. See emoticon

soft keys 1, 46, 80

software update 85

speakerphone 82

speed dial 70

store your number 22

symbol entry mode 52

synchronizing 84

tap text entry mode 51

telephone number. See

phone number

index

103

text entry 49

text marquee 79

text message 75, 76

theme 59

time zone 57

time, setting 57

timers 81

transfer a call 67

TTY device 68

turn on/off 20

unlock

application 88

phone 20, 55

SIM card 88

unlock code 54, 55

USB cables 43

video clip 89

videos 36, 38

voice dial 65, 69, 82

voice message 74

voice record 87

voicemail 64

voicemail message indicator

48, 64

volume 53, 79

wallpaper 58

warranty 94

Web pages 89

Web sessions 90

your phone number 22

U.S. patent Re. 34,976

Motorola Mobility T6GD1 Portable PCS GSM/ EDGE Transceiver with Bluetooth User Manual

Motorola Mobility LLC Portable PCS GSM/ EDGE Transceiver with Bluetooth

Exhibit 8 Users Manual

Navigation menu

Namespaces

Views

Navigation
