Motorola Solutions, Inc. Hand Held Portable Radio Instruction Manual
Instruction Manual
FCC ID: AZ489FT4831
INSTRUCTION MANUAL
X Preliminary Manual attached.
Complete Manual attached.
FCC ID: AZ489FT4831
EXHIBIT 8
FCC Licensing Information
Your Motorola radio operates on FM radio communication frequencies and is subject to the
Rules and Regulations of the Federal Communications Commission (FCC). The FCC requires
that all operators using Private Land Mobile frequencies obtain a radio license before operating
their equipment. Application for your FCC license is made on FCC Form 600 and schedules D,
E, and G.
To have the forms faxed to you by the FCC, call the FCC Fax-On-Demand system at
1-202-418-0177 from your fax machine and request document 000600 for all forms and
instructions.
To have the forms mailed to you, call the FCC forms hotline at : 1-800-418-FORM.
For questions concerning the license application, contact the FCC at : 1-888-Call-FCC (or 1-
888-225-5322)
Before filling out your application, you must first determine your radio frequency. Radio
frequency can be determined by first identifying the frequency number the radio is set to and then
matching the number to the corresponding frequency in the Frequency Tables. See page ... and ...
of this manual for additional information.
For questions on determining your radio frequency, please call : 1-800-448-6686
Copyright Information
The Motorola products described in this manual may include copyrighted Motorola programs
stored in semiconductor memories or other media. Laws in the United States and other countries
preserve for Motorola, certain exclusive rights for copyrighted computer programs, including the
exclusive right to copy or reproduce in any form, the copyrighted Motorola programs.
Accordingly, any copyrighted Motorola computer programs contained in the Motorola products
described in this manual may not be copied or reproduced in any manner without the express
written permission of Motorola. Furthermore, the purchase of Motorola products shall not be
deemed to grant either directly or by implication, estoppel, or otherwise, any license under the
copyrights, patents or patent applications of Motorola, except for the normal non-exclusive
royalty free license to use that arises by operation of law in the sale of a product.
Getting Started
Thank you for purchasing a Motorola Spirit radio. Your radio is a product of Motorola’s 50
years of experience as a world leader in the designing and manufacturing of communications
equipment. With proper care and use, your Motorola radio should give you years of reliable
communication.
Contents of Package :
• Radio • NiCd Battery Pack • Optional: Charger Tray
• Belt Clip • 10 Hour Charger Adapter
FCC ID: AZ489FT4831
• Antenna • Operator Manual
FCC ID: AZ489FT4831
Batteries
CAUTION
Do not remove the plastic wrap from the battery pack. This may permanently damage the battery.
The Ni-Cd battery ships uncharged, it must be fully charged for 16 hours before use (first charge
only). It is recommended that only Motorola batteries and chargers are used with the radio.
The Ni-Cd rechargeable battery pack will provide approximately 8 hours of use on a 2 watt radio
and 10 hours on a 1 watt radio with normal use i.e. 5% sending messages, 5% receiving messages
and 90% in standby mode.
To Install/Remove battery :
Note : Radio must be in OFF position before installing/removing battery.
1. Push back battery cover latches until you see the orange tabs.
2. Slide battery cover down and lift to remove.
3. To replace/install battery, insert the battery pack with arrows facing you and towards top of
radio..
4. Replace the battery cover and lock latches.
5. To remove battery: remove cover (steps 1 & 2), turn the radio over and tap the battery end of
the radio against the palm of your hand. The battery will drop into your hand.
Charging the Ni-Cd battery Pack
Charging Adapter Instructions :
1. Turn the radio off.
2. Lift accessory cover and plug the Charger Adapter firmly into the small jack (lower hole).
3. Plug the Charger into an electric outlet.
The red light on the charger will glow continuously if charging properly.
4. Allow 10 hours for the battery to fully charge.
NOTE: For optimum battery life, the battery should not be left charging for prolonged periods
after reaching full charge. Charging the battery over the weekend is acceptable.
NOTE: Transmitting while radio is charging in the Wall Charger can cause the radio transmitter
or the charger to operate improperly. Do not transmit while radio is charging. If radio is on while
charging, at least twice as much time is required to charge the battery. Turn the radio off when
charging.
10 Hour Desktop Charger Instructions :
1. Connect Desktop Charger and Charger Adapter.
2. Charge the battery while inside the radio by placing the radio in the Charger Tray with
radio facing towards you. You can also charge the battery by removing battery from radio
and placing it in Charger Tray with silver contacts facing down and arrow facing toward
the front.
FCC ID: AZ489FT4831
3. The LED light on top of the charger will glow red continuously when radio / battery is
inserted in charger. If light does not come on, check radio / battery is properly inserted
and check battery/ charger contacts to be sure they are clean. The red LED will continue
to glow until the radio / battery is removed from Charger Tray.
4. Allow 10 hours for the battery to fully charge.
Note: The Desktop Charger is optional and may not be included in your package. For
more information, please contact your place of purchase or call 1-800-448-6686.
Low Battery Alert:
When the battery is low, the radio will beep 3 to 4 seconds after turning power on, every 10
minutes, and after release of the Push-To-Talk button. Recharge the battery pack immediately to
avoid interrupted use.
Note: Remove battery pack before storing your radio for extended periods. Batteries corrode over
time and may cause permanent damage to your radio.
Antenna
To attach the antenna, rotate the antenna clockwise onto the top of the radio until hand tight.
Note: The antenna should always be installed when operating the radio. Operating the radio
without an antenna greatly reduces the range of the radio and causes battery to get used more
quickly.
Belt Clip
Spirit radios come standard with a belt clip.
To Attach / Remove:
1. Align the belt clip to the mounting rails on the back of the radio
2. Push the belt clip down until it clicks into place.
3. To remove, pull tab on belt clip away from radio to release.
4. Slide belt clip up and off.
Before You Can Talk
Please read this manual carefully to ensure you know how to properly operate the radio before
use.
There are default settings programmed into your radio for Frequency per Channel, Interference
Eliminator Code and Bandwidth. If it is necessary to change these default settings, the radio will
audibly guide you through a series of programming steps.
FCC ID: AZ489FT4831
Change Frequency, Code and Band:
1 channel models
1 While holding down Push-To-Talk button, turn radio on. The radio will announce the
Frequency your radio is set to. See Frequency chart below for details
2. Press the Push-To-Talk button repeatedly or hold down to here Frequency
choices.
3. Select and save your chosen frequency by pressing the monitor button.
You are now in the Code change mode. The radio will announce the Code the radio is set to.
4. Press Push-To-Talk repeatedly or hold down to hear Code choices. See Interference
Eliminator Table below for details.
5. Select and save your chosen Code by pressing the monitor button.
You are now in Band change mode. The radio will announce Band 25 as the current
setting.
6. Press monitor button to save this Band setting
7. Radio is now ready to use.
2 and 4 channel models
1 While holding Push-To-Talk button down, turn radio on. The radio will announce
the Frequency of the channel your Channel Selector Knob is set to. See Frequency
chart below for details.
2. Press the Push-To-Talk button repeatedly or hold down to hear Frequency choices.
3. Once you have reached your chosen Frequency, move your Channel Selector Knob to
the next channel and the radio will announce the Frequency of this channel. Repeat
step 2 until you reach your desired frequency. For 4 Channel radios, repeat steps 2 and
3 for the remaining channels.
4. When you have selected the frequency for each channel you wanted to change, press
monitor button to save your selections.
You are now in the Code change mode. The radio will announce the Code the radio is set to.
5. Press Push-To-Talk repeatedly or hold down to hear Code choices. See Interference
Eliminator Table below for details.
7. Select and save your chosen Code by pressing the monitor button.
You are now in Band change mode. The radio will announce Band 25 as the current
setting.
6. Press monitor button to save this Band setting
7. Radio is now ready to use.
FCC ID: AZ489FT4831
Things to Note :
• Interference Eliminator Code: Codes filter out static, noise and unwanted chatter on radio
channels. You can only communicate with radios using the same channel and code. This will
not make your conversations private as other users with uncoded radios will hear you. If the
channel you are using is busy, change to another channel. For compatibility with radios that
do not have the Interference Eliminator Code feature, the radio can be set to “Code Off”
mode.
• Bandwidth : In the USA, the FCC is allocating new frequencies to the business radio
service. All these future frequencies must operate on 12.5kHz Bandwidth. All frequencies
currently available for Business Radio use operate on 25kHz Bandwidth. All M-Series radios
will ship with Band 25 as default but will have the capability to upgrade to Band 12.5 to
work with next generations of business radio. This gives users the flexibility to add to their
radio fleet in the future without changing out their complete radio system.
FOR ALL M SERIES RADIOS, ENSURE YOU SET YOUR RADIO TO BAND 25kHz.
• To talk to others in your group, the radios must be set to the same channel and code (see
Tables below for complete list).
• If you do not want to change frequencies on each channel, then push the monitor button after
you have changed the positions you need and the radio will then go into code change mode.
• No programming is required for the “S” position on your Channel Selector Knob. Only
select models have “S” position.
• Code numbers that have two digit (10-38) will be announced as “one zero”...”one one”... etc.
• You cannot transmit when you are in change Frequency, Code or Band mode.
• Code and Band settings apply to all channels.
Frequency Tables
UHF Models (Model number begins with MU)
Frequency
Number
Frequency MHz
Color
*
1
464.5500
Yellow
*
2
467.7625
J
*
3
467.9250
Blue Star
*
4
467.8500
Silver Star
5
464.5000
Brown
6
467.8750
Gold Star
7
467.9000
Red Star
8
467.8125
K
FCC ID: AZ489FT4831
VHF Models (Model number begins with MV)
Frequency
Number
Frequency MHz
Color
*
1
154.5700
Blue
*
2
154.6000
Green
*
3
151.6250
Red
*
4
151.9550
Purple
• Radios ship to users with default frequencies.
• For 1 channel models, radio ships with Frequency 1
• For 2 Channel models, radio ships with Frequencies 1 & 2
• For 4 Channel models, radio ships with Frequencies 1, 2, 3 & 4
FCC ID: AZ489FT4831
Interference Eliminator Table :
M-Series Non M-Series Switch Position
Code #
Code
Frequency (Hz)
S1
S2
S3
S4
S5
S6
S7
S8
1
XZ
67.0
D
D
D
D
D
D
U
U
2
XA
71.9
U
D
D
D
D
D
U
U
3
WA
74.4
D
D
D
D
D
U
U
U
4
XB
77.0
U
U
D
D
D
D
U
U
5
WB
79.7
D
D
D
D
U
D
U
U
6
YZ
82.5
U
D
D
D
D
U
U
U
7
YA
85.4
D
D
D
D
U
U
U
U
8
YB
88.5
U
U
D
D
D
U
U
U
9
ZZ
91.5
D
D
D
U
D
D
U
U
10
ZA
94.8
U
D
D
D
U
D
U
U
11
ZB
97.4
D
D
D
U
D
U
U
U
12
1Z
100.0
U
U
D
D
U
D
U
U
13
1A
103.5
U
D
D
D
U
U
U
U
14
1B
107.2
U
U
D
D
U
U
U
U
15
2Z
110.9
U
D
D
U
D
D
U
U
16
2A
114.8
U
U
D
U
D
D
U
U
17
2B
118.8
U
D
D
U
D
U
U
U
18
3Z
123.0
U
U
D
U
D
U
U
U
19
3A
127.3
U
D
D
U
U
D
U
U
20
3B
131.8
U
U
D
U
U
D
U
U
21
4Z
136.5
U
D
D
U
U
U
U
U
22
4A
141.3
U
U
D
U
U
U
U
U
23
4B
146.2
U
D
U
D
D
D
U
U
24
5Z
151.4
U
U
U
D
D
D
U
U
25
5A
156.7
U
D
U
D
D
U
U
U
26
5B
162.2
U
U
U
D
D
U
U
U
27
6Z
167.9
U
D
U
D
U
D
U
U
28
6A
173.8
U
U
U
D
U
D
U
U
29
6B
179.9
U
D
U
D
U
U
U
U
30
7Z
186.2
U
U
U
D
U
U
U
U
31
7A
192.8
U
D
U
U
D
D
U
U
32
M1
203.5
U
U
U
U
D
D
U
U
33
M2
210.7
U
D
U
U
D
U
U
U
34
M3
218.1
U
U
U
U
D
U
U
U
35
M4
225.7
U
D
U
U
U
D
U
U
36
M5
233.6
U
U
U
U
U
D
U
U
37
M6
241.8
U
D
U
U
U
U
U
U
38
M7
250.3
U
U
U
U
U
U
U
U
FCC ID: AZ489FT4831
OFF
None
None
X
X
X
X
X
X
X
D
NOTE : All radios ship on Code # 29 (6B) as default
To Use Your Radio
Turn The Radio On/Off :
Turn the volume/on/off knob clockwise. You will hear a beep and see the red LED flash
momentarily to indicate the radio is on. To turn the radio off, turn the volume/on/off knob
counterclockwise. You will hear a click to indicate the radio is turned off.
Adjust The Volume:
Hold Monitor button down to listen to audio level while rotating Volume knob. Rotate dial
clockwise to increase and counter clockwise to decrease volume.
To Send and Receive messages:
Check channel activity by pressing Monitor button. You will hear static if the channel is clear to
use. Do not transmit if someone is talking on channel.
1. To send a message, press the Push-To-Talk and speak into the radio. (To maximize clarity,
hold radio 3 to 5 inches from mouth).
2. The red LED Indicator Light will glow continuously when sending messages.
3. To listen for messages, release the Push-To-Talk button.
Time-out Timer:
The Time-out Timer feature helps extend battery life. The radio will emit a warning tone if the
Push-To-Talk button is pressed for 2 continuous minutes and will stop transmitting.
Hands-Free Use (Optional Feature)
Built-in Voice Activated Transmission (VOX) allows you hands free operation of your radio.
The sound of your voice activates transmission when the radio is used with a Headset With
Swivel Boom Mic (HMN9038) or Earpiece with Microphone (HMN9039) (Both headset and
earpiece are sold separately).
To Use VOX Feature:
1. Turn the radio off.
2. Open accessory connector cover and plug the accessory’s connector into jack.
3. Turn radio on and lower volume before placing accessory on head or in ear.
Press Monitor button while rotating Volume Knob to adjust volume to a comfortable
listening level.
4. To transmit, speak into accessory microphone. To receive, stop talking.
Note: There will be a brief delay between when you start or stop talking and radio
transmission.
FCC ID: AZ489FT4831
Exit VOX mode:
Press Push-To-Talk button once.
To transmit, press Push-To-Talk button on radio. To receive, release the Push-To-Talk.
To return to VOX mode, turn the radio off, then on again.
Note: The accessory jack cover is not detachable and should be closed when not in use.
Scan (Optional Feature)
Some M Series models have scan. Scan allows the user to monitor two or more channels for
activity, so you will not miss any messages.
To scan :
1. Move Channel Selector Knob to scan “S” position.
The radio will scan the radio’s programmed channels. If there are any transmissions on any
of the channels, the radio will switch to that channel and you will receive the message.
2. You can transmit back to last channel that you received a message from by pressing the Push-
To-Talk button within 5 seconds of message being received. If you do not want to reply to
the message, the radio will go back to Scan mode after 5 seconds.
While in Scan mode, if you press the Push-To-Talk button before the radio picks up any
activity on a channel, you will transmit on Channel 1.
Care and Safety
1. Don’t use cleaners or solvents on the radio, they can harm the body and leak inside, causing
permanent damage.
2. Battery contacts may be wiped with a dry, lint-free cloth.
3. To clean the radio, wipe with a soft cloth dampened with water.
If the radio gets wet, turn it off and remove batteries immediately. Dry battery compartment with
a soft cloth to minimize potential water damage. If possible, leave cover off the battery
compartment overnight or until completely dry.
FCC ID: AZ489FT4831
Troubleshooting
Problem
Solution
Radio is dead
Reposition or charge battery pack.
Battery does not charge
If Charger Tray is used, make sure battery is positioned properly. See page xx.
If using Charger Adapter, make sure the red LED on the adapter glows indicating correct
charging status. Radio should be turned off when using Charger Adapter. Charge time will
be longer if radio is left on.
Message not Transmitted
Make sure the Push-To-Talk button is completely pressed as you transmit.
Reposition or charge battery pack.
Message not Received
Confirm radios have the same Channel
and Interference Eliminator Code settings.
Make sure Push-To-Talk is not inadvertently being pressed.
Obstructions, operating indoors or in vehicles may interfere with communication. Change
your location.
Check to make sure volume is turned up.
Hearing Other Conversations
Check that your Interference Eliminator
or noise on radio
Code is set (Active settings are 1 - 38)
Other users may be using channel - change channel to avoid congestion.
Limited Talk Range
Steel/concrete structures, heavy foliage and use in buildings and in vehicles will decrease
range, check for clear line of sight to improve transmission.
Wearing radio close to body such as in a pocket or on a belt will decrease range, change
location of radio.
FCC ID: AZ489FT4831
Heavy Static or interference
Radios too close. Radios must be at least 5 feet apart. Increase your distance apart.
Radios too far apart. Obstacles interfere with transmission. Talk range is up to two miles in
clear unobstructed conditions.
If the radio still doesn’t work properly contact your place of purchase or call Motorola product
services at 1800-448-6686
Battery / Charger Safety Information :
WARNING
Do not replace or recharge batteries in a hazardous atmosphere. Sparking may occur while
installing or removing batteries from the radio and chargers which could trigger an explosion.
Charge batteries at about 77°F. Charging in cold temperatures (below 45°F) can result in
electrolyte leakage and destroy the battery. Charging in hot temperatures (above 95°F) does not
damage the battery, but reduced charge capacity will result.
WARNING
Do not dispose of batteries in fire. This could create a fire or explosion hazard. Also, improper
use of batteries may create a fire or explosion.
CAUTION
• To reduce risk of damage to electric plug and cord, pull by the plug rather than the cord when
disconnecting the charger.
• Make sure cord is located so that it will not be stepped on, tripped over, or otherwise
subjected to damage or stress.
• Do not operate charger with damaged cord or plug, replace them immediately. Do not operate
charger if it has received a sharp blow, been dropped, or otherwise damaged in any way;
contact place of purchase or call 1-800-448-6686.
• Do not expose chargers to rain or snow.
FCC ID: AZ489FT4831
CAUTION
An extension cord should not be used unless absolutely necessary. Use of an improper extension
cord may result in a fire or electric shock. However, if an extension cord must be used, make
sure:
• That pins and plug of extension cord are the same number, size and shape as those on the
plug of the charger.
• That extension cord is properly wired and in good condition.
• That cord size is 18AWG for lengths of up to 100 feet, and 16AWG for lengths up to 150
feet.
CAUTION
• Do not disassemble charger; contact place of purchase or call 1-800-448-6686 if charger is
not functioning. Incorrect reassembly can result in electric shock or fire.
• To reduce risk of injury, charge only Motorola Ni-Cd rechargeable batteries. Other types of
batteries may burst, causing personal injury and damage.
• Use of an attachment not sold or recommended by Motorola can result in a risk of fire,
electric shock, or injury to personnel.
• To reduce risk of electric shock, unplug charger from outlet before cleaning. Turning off
controls does NOT reduce this risk.
FCC ID: AZ489FT4831
INFORMATION FOR SAFE, EFFICIENT OPERATION
EXPOSURE TO RADIO FREQUENCY ENERGY
In August 1996 the Federal Communications Commission (FCC) adopted updated RF energy
exposure guidelines for wireless products regulated by the FCC. Those guidelines are consistent
with the safety standards* previously set by both U.S. and international standards bodies. The
design of your Motorola two-way radio complies with the FCC guidelines and these standards.
• American National Standards Institute (C95.1 - 1992);
• National Council on Radiation Protection and Measurements (NCRP-1986);
• International Commission on Non-Ionizing Radiation Protection (ICNRP- 1986)
To assure optimal radio performance and to insure that exposure to RF energy is within the
guidelines in the above standards, the following operating procedures should be observed:
FOR PORTABLE TWO-WAY RADIOS
• For hand held operation, the radio should be held in a vertical position with the microphone
one to two inches away from the mouth, and the antenna should be kept one to two inches
from the head or body when transmitting.
• For body worn operation, the antenna should be kept at least one inch from the body when
transmitting.
ELECTROMAGNETIC INTERFERENCE/COMPATIBILITY
Nearly every electronic device is susceptible to electromagnetic
interference (EMI) if inadequately shielded, designed or otherwise
configured for electromagnetic compatibility.
• Turn your radio OFF in any facilities where posted notices instruct you to do so.
Hospitals or health care facilities may be using equipment that could be sensitive to
external RF energy.
• Turn your radio off when on board aircraft when instructed to do so. Any use of the radio
must be in accordance with Federal Aviation Administration (FAA) and FCC regulations
or crew instructions.
======================================
CAUTION (use appropriate ANSI symbol)
• Do not use the radio with a damaged antenna. If a damaged antenna comes into contact with
the skin, a minor burn may result.
FCC ID: AZ489FT4831
• All batteries can cause property damage, injury or burns if a conductive material such as
jewelry, keys or beaded chains touches exposed terminals. The material may complete an
electrical circuit (short circuit) and become quite hot. Exercise care in handling any charged
battery, particularly when placing it inside a pocket, purse or other container with metal
objects.
============================================================
WARNING (use appropriate ANSI symbol)
POTENTIALLY EXPLOSIVE ATMOSPHERES
• Turn your radio OFF when in any area with a potentially explosive atmosphere, unless it is a
type especially qualified for such use (for example, FMRC Approved)... Sparks in such areas
could cause an explosion or fire resulting in bodily injury or even death.
• Do not replace or charge batteries in a hazardous atmosphere. Contact sparking may occur
while installing or removing batteries and cause an explosion.
Areas with potentially explosive atmospheres are often, but not always, clearly marked. They
include fueling areas such as below deck on boats, fuel or chemical transfer or storage facilities;
areas where the air contains chemicals or particles, such as grain, dust, or metal powders; and any
other area where you would normally be advised to turn off your vehicle engine.
WARNING (use appropriate ANSI symbol)
BLASTING CAPS AND AREAS
• To avoid possible interference with blasting operations, turn your radio OFF near electrical
blasting caps or in a “blasting area” or in areas posted: “Turn off two-way radio” . Obey all
signs and instructions.
WARNING (use appropriate ANSI symbol)
FOR VEHICLES WITH AN AIR BAG
• An air bag inflates with great force. Do not place objects, including portable or mobile two-
way radios, in the area over the air bag or in the air bag deployment area. If improperly
installed or placed wireless equipment is in the air bag deployment area and the air bag
inflates, serious injury could result.
=============================================================
Important
Do not depress Push-To-Talk button unless you are transmitting
Important
Do not allow children to play with any radio equipment containing a transmitter.
FCC ID: AZ489FT4831
WARRANTY
This warranty applies within the fifty (50) United States and the District of Columbia.
LIMITED WARRANTY
MOTOROLA COMMUNICATION PRODUCTS
I. WHAT THIS WARRANTY COVERS AND FOR HOW LONG:
MOTOROLA INC. (“MOTOROLA”) warrants the MOTOROLA products listed below in the
product warranty schedule section of this warranty document (“Product”) against defects in
material and workmanship under normal use and service for a period of time from the date of
purchase as scheduled below:
MOTOROLA, at its option, will, at no charge, either repair the Product (with new or
reconditioned parts), replace it (with a new or reconditioned Product), or refund the purchase
price of the Product during the warranty period provided it is returned in accordance with the
terms of this warranty. Replaced parts or boards are warranted for the balance of the original
applicable warranty period. All replaced parts of Product shall become the property of
MOTOROLA.
This express limited warranty is extended by MOTOROLA to the original end user purchaser
only and is not assignable or transferable to any other party. This is the complete warranty for the
Product manufactured by MOTOROLA. MOTOROLA assumes no obligations or liability for
additions or modifications to this warranty unless made in writing and signed by an officer of
MOTOROLA. Unless made in a separate agreement between MOTOROLA and the original end
user purchaser, MOTOROLA does not warrant the installation, maintenance or service of the
Product.
MOTOROLA cannot be responsible in any way for any ancillary equipment not furnished by
MOTOROLA which is attached to or used in connection with the Product, or for operation of the
Product with any ancillary equipment, and all such equipment is expressly excluded from this
warranty. Because each system which may use the Product is unique, MOTOROLA disclaims
liability for range, coverage, or operation of the system as a whole under this warranty.
II. GENERAL PROVISIONS:
This warranty sets forth the full extent of MOTOROLA’s responsibilities regarding the Product.
Repair, replacement or refund of the purchase price, at MOTOROLA’S option, is the exclusive
remedy. THIS WARRANTY IS GIVEN IN LIEU OF ALL OTHER EXPRESS WARRANTIES.
IMPLIED WARRANTIES, INCLUDING WITHOUT LIMITATION IMPLIED WARRANTIES
OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE, ARE LIMITED
TO THE DURATION OF THIS LIMITED WARRANTY. IN NO EVENT SHALL
MOTOROLA BE LIABLE FOR DAMAGES IN EXCESS OF THE PURCHASE PRICE OF
THE PRODUCT, FOR ANY LOSS OF USE, LOSS OF TIME, INCONVENIENCE,
COMMERCIAL LOSS, LOST PROFITS OR SAVINGS OR OTHER INCIDENTAL, SPECIAL
OR CONSEQUENTIAL DAMAGES ARISING OUT OF THE USE OR INABILITY TO USE
SUCH PRODUCT, TO THE FULL EXTENT SUCH MAY BE DISCLAIMED BY LAW.
FCC ID: AZ489FT4831
III. STATE LAW RIGHTS:
SOME STATES DO NOT ALLOW THE EXCLUSION OR LIMITATION OF INCIDENTAL
OR CONSEQUENTIAL DAMAGES, OR LIMITATION ON HOW LONG AN IMPLIED
WARRANTY LASTS, SO THE ABOVE LIMITATIONS OR EXCLUSIONS MAY NOT
APPLY.
This warranty gives specific legal rights, and there may be other rights which may vary from state
to state.
IV. HOW TO GET WARRANTY SERVICE:
To receive warranty service, deliver or send the Product item, transportation and insurance
prepaid, to the place of purchase along with your proof of purchase or lease and Product item
serial number. Alternatively call 1-800-448-6686 for other locations.
V. WHAT THIS WARRANTY DOES NOT COVER:
a) Defects or damage resulting from use of the Product in other than its normal and customary manner.
b) Defects or damage from misuse, accident, liquid, or neglect.
c) Defects or damage from improper testing, operation, maintenance, installation, alteration, modification,
or adjustment.
d) Breakage or damage to antennas unless caused directly by defects in material workmanship.
e) A Product subjected to unauthorized Product modifications, disassemblies or repairs (including, without
limitation, the addition to the Product of non-Motorola supplied equipment) which adversely affect
performance of the Product or interfere with Motorola’s normal warranty inspection and testing of the
Product to verify any warranty claim.
f) Product which has had the serial number removed or made illegible.
g) Rechargeable batteries if:
1) any of the seals on the battery enclosure of cells are broken or show evidence of tampering.
2) the damage or defect is caused by charging or using the battery in equipment or service other
than the Product for which it is specified.
h) Freight costs to the repair depot.
i) A Product which, due to illegal or unauthorized alteration of the software/firmware in the Product, does
not function in accordance with Motorola’s published specifications or the FCC type acceptance labeling in
effect for the Product at the time the Product was initially distributed from Motorola.
j) Scratches or other cosmetic damage to Product surfaces that does not effect the operation of the Product.
k) Normal and customary wear and tear.
FCC ID: AZ489FT4831
VI. PATENT AND SOFTWARE PROVISIONS:
MOTOROLA will defend, at its own expense, any suit brought against the end user purchaser to
the extent that it is based on a claim that the Product or parts infringe a United States patent, and
MOTOROLA will pay those costs and damages finally awarded against the end user purchaser in
any such suit which are attributable to any such claim, but such defense and payments are
conditioned on the following:
a) that MOTOROLA will be notified promptly in writing by such purchaser of any notice of such claim;
b) that MOTOROLA will have sole control of the defense of such suit and all negotiations for its settlement or
compromise; and
c) should the Product or parts become, or in MOTOROLA’s opinion be likely to become, the subject of a
claim of infringement of a Unites States patent, that such purchaser will permit MOTOROLA, at its option and
expense, either to procure for such purchaser the right to continue using the Product or parts or to replace
or modify the same so that it becomes non-infringing or to grant such purchaser a credit for the Product or
parts as depreciated and accept its return. The depreciation will be an equal amount per year over the
lifetime of the Product or parts as established by MOTOROLA.
MOTOROLA will have no liability with respect to any claim of patent infringement which is
based upon the combination of the Product or parts furnished hereunder with software, apparatus
or devices not furnished by MOTOROLA, nor will MOTOROLA have any liability for the use of
ancillary equipment or software not furnished by MOTOROLA which is attached to or used in
connection with the Product. The foregoing states the entire liability of MOTOROLA with
respect to infringement of patents by the Product or any parts thereof.
Laws in the United States and other countries preserve for MOTOROLA certain exclusive rights
for copyrighted MOTOROLA software such as the exclusive rights to reproduce in copies and
distribute copies of such Motorola software. MOTOROLA software may be used in only the
Product in which the software was originally embodied and such software in such Product may
not be replaced, copied, distributed, modified in any way, or used to produce any derivative
thereof. No other use including, without limitation, alteration, modification, reproduction,
distribution, or reverse engineering of such MOTOROLA software or exercise of rights in such
MOTOROLA software is permitted. No license is granted by implication, estoppel or otherwise
under MOTOROLA patent rights or copyrights.
VII. PRODUCT WARRANTY SCHEDULE:
Spirit Radios:
One (1) year
Spirit Accessories:
One (1) year.
Rechargeable Batteries will be replaced during the applicable warranty period if:
a) the battery capacity falls below 80% of rated battery capacity or,
b) the battery develops leakage.
EXHIBIT 8
