Contents
- 1. Instruction Manual
- 2. Latest Version of Users Manual
Instruction Manual
EXHIBIT 8
kwh- Apr. 00
Mode
Up
Menu
Power
Push-to-Talk
T6300-series
Feature Description
VOX
- Voice operated transmit when used with or without specialized
audio accessory
Scrambler
- Additional privacy for user’s transmission. To receive
scrambled TX, the channel interference code and scrambling code (3
available) must match.
Keypad lock
- Locks radio’s keypad, except for volume control.
Child lock
- Allows parents to more securely lock the settings of their
child’s radio, locks power and volume as well.
Scan - Monitors radio traffic on other channels.
Scan list editing
- Allows users to create a list of channels/interference
codes they want to scan.
Auto off
- The radio will automatically turn off after a preset period of
time of radio inactivity.
Clock - Current time of day, with alarm
Vibrator
- For more discrete use of the radio, when set, radio will
vibrate when it receives a call tone from another T6300-series radio.
Audible call tones
- Can be used in place of voice in transmit mode.
Silence alert tones - Disables all audible beeps on the radio.
Factory settings reset
- Used to reset the radio to it’s original factory
programmed settings.
FM radio
- The radio is capable of receiving FM stereo. Will ship
with stereo earbuds.
Weather Channel
- The radio is capable of the 10 NOAA weather
channels, and weather alert can be enabled.
Compass
- The radio will digitally display the heading and direction of
the user.
Barometer
- The radio will display the air pressure in inches of
mercury or millibars
Altimeter
- The radio will display the current height, above sea level,
in feet or meters.
Weather Channel
- The radio is capable of the 10 NOAA weather
channels, and weather alert can be enabled.
T6310
only
T6320
only
All models
EXHIBIT 8
kwh- Apr. 00
MODE
Motorola Confidential Proprietary
MENU
SET CHAN
SET CODE
SETSCRAM
SET CALL
SET MON
SET SCAN
MENU MENU MENUMENUMENU
TWO WAY
MENU
SET TIME
SETALARM
SET 24HR
SET DISP
MENU MENU MENU
TIME MODE MODE
MENU
Lap time
& reset
STPWATCH
CALL
Start/stop
T6300 Operation
MENU
SETQUIET
SET VIB
SETROGER
SETPWRDN
SET BEEPS
SET VOX
MENU MENU MENUMENUMENU
SETTINGS
EXHIBIT 8
kwh- Apr. 00
MODE
Motorola Confidential Proprietary
SET CHAN
SET CODE
SETSCRAM
SET CALL
SET MON
SET SCAN
TWO WAY
MENU
SET FM
PRESET
SEEK FM
TUNE FM
SET 2WAY
MENU MENU MENUMENU
FMSTEREO
MENU
SET CHAN
SET ALERT
MENU
SET WEA
MODE MODE MODE MODE
MENU
Lap time
& reset
STPWATCH
CALL
Start/stop
T6310 Operation
MENU
SET TIME
SETALARM
SET 24HR
SET DISP
MENU MENU MENU
TIME
SETQUIET
SET VIB
SETROGER
SETPWRDN
SET BEEPS
SET VOX
SETTINGS
EXHIBIT 8
kwh- Apr. 00
MODE
Motorola Confidential Proprietary
SET CHAN
SET CODE
SETSCRAM
SET CALL
SET MON
SET SCAN
TWO WAY
MENU
SET COMP
COMPASS
MENU
SET CHAN
SET ALERT
MENU
SET WEA
SETQUIET
SET VIB
SETROGER
SETPWRDN
SET BEEPS
SET VOX
SETTINGS
MENU
Lap time
& reset
STPWATCH
CALL
Start/stop
T6320 Operation
MODE MODE
MENU
SETUNITS
BAROMETR MODE MODE
MODE
MODE *
MENU
SETUNITS
ALTIMETR
MENU
SETLEVEL
MENU
SET TIME
SETALARM
SET 24HR
SET DISP
MENU MENU MENU
TIME
EXHIBIT 8
kwh- Apr. 00
EXHIBIT 8
kwh- Apr. 00
