Quick Reference Guide
Guide de Référence Rapide
accessories and user’s guide:
accessoires et guide de l’utilisateur :
CP185
™
www.motorola.com/business
![](/img.php?id=1100623&img=bg3.png)
1
English
Congratulations on your purchase of the CP185
Two-Way Radio.
This is a Quick Reference Guide; for more information
on this radio features please download the full User
Guide from https://motonline.mot.com or
www.motorola.com/business or call our Customer
Care Service at 1-800-422-4210.
![](/img.php?id=1100623&img=bg4.png)
2
English
Radio Overview
CP185
1
2
3
5
6
4
9
10
11
12
8
7
![](/img.php?id=1100623&img=bg5.png)
3
English
Radio Control Indicators
Channel Selector Knob
ON/OFF/Volume Control Knob
LED Indicator
Speaker
Microphone
Liquid Crystal Display (LCD)
Push-to-Talk (PTT) Button
Side Programmable Buttons
Accessory Connector
Programming Port
Left/Right Buttons
Front Programmable Buttons
1
2
3
4
5
6
7
8
9
10
11
12
![](/img.php?id=1100623&img=bg6.png)
4
English
Menu Navigation Buttons
Programmable Buttons
The following functions can be assigned as
short press (press and release) or long press
(press and hold for more than 1 second):
Front Left/Right Buttons
Front Programmable Buttons
Button Function
Backlight Toggles backlight display between ON
and OFF.
Channel Alias Toggles display between Channel
Number and Channel Alias.
A
B
B
A
![](/img.php?id=1100623&img=bg7.png)
5
English
Button Function
Keypad Lock Locks or unlocks all buttons except
PTT, Side Programmable Button 1 and
Side Programmable Button 2, Channel
Selector Knoband ON/OFF/Volume
Knob. Applicable for Long Press Only.
Monitor Monitors the channel for any activity as
long as the button is pressed.
Nuisance
Channel
Delete
Removes unwanted channel(s)
temporarily from scan list during Scan.
Applicable for Long Press Only.
TPL/DPL
Enable Enables or disables radio from
requiring matching TPL/DPL to
unsquelch.
Power Level Selects required power level: High or
Low.
Reverse
Burst Select the Reverse Burst Type: None,
180 or 240.
Channel
Scan Starts or stops Channel Scan.
Scrambling
Code Select Toggles between the two scrambling
codes available.
![](/img.php?id=1100623&img=bg8.png)
6
English
Button Function
Scrambling
Enable/
Disable
Enables or disables scrambling feature
for the selected channel. Applicable for
Long Press only.
Squelch
Level Selects desired squelch level: Normal
or Tight.
Sticky
Monitor Toggles the permanent monitor
function until the button is pressed
again. Applicable for Long Press Only.
Talkaround/
Repeater
Mode
Enables toggle between repeater and
talkaround mode operations.
Unassigned No function is programmed to this
button.
Volume Set Controls the audio level. The button
emits a continuous tone to indicate the
current volume level. To change
volume level, turn the volume knob to
the desired level while pressing the
programmable button. Applicable for
Long Press Only.
VOX Enables or disables VOX feature for
the selected channel.
![](/img.php?id=1100623&img=bg9.png)
7
English
LCD Display Icons
The following are the icons that appear on the
radio’s display.
LCD
Indicator Description Function
Signal
Strength
Indicator
Shows the signal
strength. More bars
indicate a stronger
signal received by
radio.
Power Level
Indicator “L” illuminates to
indicate radio is
configured to transmit
in low power; “H”
illuminates when radio
transmits in high power.
Talkaround
Indicator Illuminates when radio
is not transmitting
through the repeater.
Monitor
Indicator Illuminates when
monitoring a selected
channel.
Voice
Inversion
Scrambling
Indicator
Illuminates when
Scrambling Mode is
ON.
![](/img.php?id=1100623&img=bga.png)
8
English
LCD
Indicator Description Function
Scan
Indicator Blinks without dot when
normal scan is
activated.Illuminates
without dot when there
is some activity on a
non-priority channel.
Illuminates with dot
blinking to indicate that
there is some activity
on the priority channel.
Prog. Mode
Indicator Illuminates when
Programming Mode is
ON.
Keypad Lock
Indicator Illuminates when
keypad is locked.
Battery Level
Indicator Shows remaining
charge in battery based
on how many bars (1 –
3) are displayed. Blinks
when the battery is low.
![](/img.php?id=1100623&img=bgb.png)
9
English
LED Color Indicators
LED
Color State Indication
Green Illuminated Radio is transmitting in
normal mode. Radio is
transmitting in
Scrambling Mode.
Normal
Blinking
Radio is receiving in
normal mode.
Channel is busy.
Radio passed self-test
during powering up.
Amber Illuminated Monitor activated.
Permanent Sticky
Monitor activated.
Normal
Blinking
Radio is in active Scan
Mode. Radio is
receiving in
Scrambling Mode.
![](/img.php?id=1100623&img=bgc.png)
10
English
LED
Color State Indication
Red Normal
Blinking
Radio is transmitting in
normal mode. Radio is
transmitting in
Scrambling Mode
while battery is low.
Fast
Blinking
Radio failed self-test
during powering up.
![](/img.php?id=1100623&img=bgd.png)
11
English
Attaching/Removing the Antenna
CP185
Antenna
Connector
Threaded End
of Antenna
To attach, fasten the antenna to the radio by placing
the threaded end of the antenna into the Antenna
Connector and rotate clockwise until tight.
To remove, turn the antenna in a counterclockwise
direction until it disengages from the radio.
![](/img.php?id=1100623&img=bge.png)
12
English
Attaching/Removing the Battery
Battery Slots
Grooves
Battery
Latch
To attach, fit the battery slots with the grooves on the radio
and slide the battery upwards until a click is heard.
To remove, slide the battery latch away from the radio,
slide the battery downwards and pull it away from the radio.
![](/img.php?id=1100623&img=bgf.png)
13
English
Attaching/Removing the Belt Clip
To attach, align mounting rails of the belt clip with the grooves
of the radio.
To remove, safely insert a flat tool between release tab and the
back surface of the radio and lift the release tab.
Slide the belt clip upwards.
Release Tab
Mounting
Grooves
![](/img.php?id=1100623&img=bg10.png)
14
English
Charging the Battery
Make sure radio is OFF , and plug the power supply into an electric outlet
and into the rear of the desktop charging tray. The LED on the charger
blinks green once to indicate the charger is turned ON.
CP185
Turn the radio OFF before charging the battery. Insert a battery, or a
radio with a battery into the charger’s pocket. The charger’s LED color
will indicate the battery charging status. (See “Charging Status” on
page 11 of the User Guide On-Line.
Battery insert
visual guide line
Battery
charging tray
![](/img.php?id=1100623&img=bg11.png)
15
English
Receiving Transmission
1 Turn the radio ON and adjust volume to the
desired level.
2 Select desired channel/talkgroup.
3 Listen for voice activity. The LED indicator
blinks red while receiving.
Transmitting a Message
1 Hold the radio vertically at 1 to 2 inches (2.5 to
5cm) from your mouth. Press the PTT button to
talk. The LED indicator illuminates a steady red
light while transmitting.
2 Release PTT button to listen.
![](/img.php?id=1100623&img=bg12.png)
16
English
Scan
Two types of scan are supported: Normal Scan and
Priority Scan. Normal Scan searches all channels
sequentially in the radio’s scan list, whereas Priority
Scan allocates 50% of the scanning time to the
Priority Channel (the first channel in the designated
scan list).
During scan, when activity is detected that meets
the unsquelch condition, the radio stops scanning
and switches to that channel; the indicator is
illuminated, and the channel number is displayed.
Ch. 2 Ch. 3 Ch. 4
Ch. 1
Ch. 15
Ch. 14
Ch. 16
Home
Normal Scan
Start
Ch. 2 Ch. 1 Ch. 3
Ch. 1
Ch. 16
Ch. 1
Ch. 1
Home
Start
Priority Scan
Channel 1 Prioritized
![](/img.php?id=1100623&img=bg13.png)
17
English
When no activity is detected for a pre-set time, the
radio resumes scanning.
Nuisance Channel Delete
A channel with unwanted activity is called a
Nuisance Channel. You can remove a Nuisance
Channel from the scan list temporarily.
To remove a Nuisance Channel
Press the Nuisance Channel Delete programmable
button, when your radio stops on a Nuisance
Channel. A high-pitched tone is heard. You cannot
remove the Home or Priority Channel from the scan
list. If attempted, a low-pitched tone is heard, and
no action is taken.
To reinstate the deleted channel(s) into the scan
list, restart scan, or simply turn OFF your radio and
turn it ON again.
![](/img.php?id=1100623&img=bg14.png)
18
English
Voice Operated Transmit VOX
When the VOX headset/microphone is connected,
your radio may be used in hands-free operation.
To start VOX
1 Connect the VOX headset to the accessory
connector of the radio. Make sure the radio is
turned OFF before connecting the VOX
accessory.
2 Turn the radio ON.
To disable VOX
1 Press the PTT button on the radio. This allows
you to use the VOX headset, but you must
press the radio PTT to transmit.
To re-enable VOX
1 Turn the radio OFF, and turn it ON again, with
the headset connected to the accessory
connector, or
2 Change channel with the VOX headset
connected.
Note: VOX needs to be enabled for each channel in the
CPS before VOX accessories can be used with
radio.
![](/img.php?id=1100623&img=bg15.png)
19
English
Voice Inversion Scrambling
Your radio has the Voice Inversion Scrambling
feature which gives you an extra layer of privacy.
This scrambling function is implemented via a
frequency inversion in analog mode using two
standard codes.
To Enable and Disable the Scrambling Mode
Configure one of the programmable buttons for
Scrambling Mode via the CPS. Press this button to
enable or disable the function. You can also
configure this function via the Front Panel Feature
and Button Configuration Mode. See the Front Panel
Feature and Button Configuration Mode chapter of
the User Guide.
To Change the Scrambling Code
Configure one of the programmable buttons for
Scrambling Code. Press this button to toggle
between the two codes. You can also configure this
function via the Front Panel Feature and Button
Configuration Mode. See the Front Panel Feature
and Button Configuration Mode chapter of the User
Guide.
![](/img.php?id=1100623&img=bg16.png)
20
English
Product Safety and RF Energy Exposure
for Portable Two-Way Radios
The information provided in this document supersedes the general
safety information in user’s guides published prior to February 2002.
Symbol Key
Your battery, charger, or radio may contain symbols, defined as follows:
BEFORE USING THIS RADIO, READ THIS BOOKLET WHICH
CONTAINS IMPORTANT OPERATING INSTRUCTIONS FOR
SAFE USAGE AND RF ENERGY AWARENESS AND CONTROL
INFORMATION AND OPERATIONAL INSTRUCTIONS FOR
COMPLIANCE WITH RF ENERGY EXPOSURE LIMITS IN
APPLICABLE NATIONAL AND INTERNATIONAL
STANDARDS. ALSO READ THE OPERATIONAL INSTRUCTIONS
FOR SAFE USAGE. FOR RADIOS THAT HAVE BEEN APPROVED
AS INTRINSICALLY SAFE, READ THE INSTRUCTIONS AND
INFORMATION ON INTRINSIC SAFETY ON THIS BOOKLET.
Symbol Definition
Restricted to occupational use to satisfy FCC RF
exposure limits. See User’s Manual for operating
requirements.
This product is in compliance with the essential
requirements and other relevant provisions of
Directive 1999/5/EC and all other relevant EU
Directives.
Important safety information follows.
032374o
Caution
032374o
WARNING
![](/img.php?id=1100623&img=bg17.png)
21
English
RF Energy Exposure Awareness and Control Information and
Operational Instructions for Occupational Use
NOTICE: This radio is intended for use in occupational/controlled
conditions where users have full knowledge of their exposure and can
exercise control over their exposure to meet the occupational limits in
FCC and International standards. This radio device is NOT authorized
for general population consumer use.
This two-way radio uses electromagnetic energy in the radio frequency
(RF) spectrum to provide communications between two or more users
over a distance. It uses radio frequency (RF) energy or radio waves to
send and receive calls. RF energy is one form of electromagnetic energy.
Other forms include, but are not limited to, sunlight and x-rays. RF
energy, however, should not be confused with these other forms of
electromagnetic energy, which when used improperly, can cause
biological damage. Very high levels of x-rays, for example, can damage
tissues and genetic material.
Do not dispose of your battery or radio in a fire.
Do not throw your battery in the trash.
Do not throw your radio in the trash.
Battery or radio may require recycling in accordance
with local laws. Do no trow your battery or radio in the
trash. www.motorola.com/recycling.
Symbol Definition
032376o
![](/img.php?id=1100623&img=bg18.png)
22
English
Experts in science, engineering, medicine, health, and industry work with
organizations to develop standards for safe exposure to RF energy.
These standards provide recommended levels of RF exposure for both
workers and the general public. These recommended RF exposure
levels include substantial margins of protection.
All Motorola two-way radios are designed, manufactured, and tested to
ensure they meet government-established RF exposure levels. In
addition, manufacturers also recommend specific operating instructions
to users of two-way radios. These instructions are important because
they inform users about RF energy exposure and provide simple
procedures on how to control it.
Please refer to the following websites for more information on what RF
energy exposure is and how to control your exposure to assure
compliance with established RF exposure limits:
http://www.fcc.gov/oet/rfsafety/rf-faqs.html
http://www.osha.gov/SLTC/radiofrequencyradiation/index.html
Federal Communication Commission (FCC) Regulations
The FCC rules require manufacturers to comply with the FCC RF energy
exposure limits for portable two-way radios before they can be marketed
in the U.S. When two-way radios are used as a consequence of
employment, the FCC requires users to be fully aware of and able to
control their exposure to meet occupational requirements. Exposure
awareness can be facilitated by the use of a product label directing users
to specific user awareness information. Your Motorola two-way radio has
a RF Exposure Product Label. Also, your Motorola user manual, or
separate safety booklet includes information and operating instructions
required to control your RF exposure and to satisfy compliance
requirements.
Compliance with RF Exposure Standards
Your Motorola two-way radio is designed and tested to comply with a
number of national and International standards and guidelines (listed
below) for human exposure to radio frequency electromagnetic energy.
This radio complies with the IEEE (FCC) and ICNIRP exposure limits for
occupational/controlled RF exposure environments at operating duty
![](/img.php?id=1100623&img=bg19.png)
23
English
factors of up to 50% talk-50% listen and is authorized by the FCC for
occupational use only. In terms of measuring RF energy for compliance
with these exposure guidelines, your radio generates measurable RF
energy only while it is transmitting (during talking), not when it is receiving
(listening) or in standby mode.
Note:
The approved batteries, supplied with this radio, are rated for a
5-5-90 duty factor (5% talk-5% listen-90% standby) even though
this radio complies with FCC occupational exposure limits and
may operate at duty factors of up to 50% talk.
Your Motorola two-way radio complies with the following RF energy
exposure standards and guidelines:
•
United States Federal Communications Commission, Code of
Federal Regulations; 47CFR part 2 sub-part J
•
American National Standards Institute (ANSI) I Institute of
Electrical and Electronic Engineers (IEEE) C95.1-1992
•
Institute of Electrical and Electronic Engineers (IEEE)
C95.1-2005 Edition
•
International Commission on Non-Ionizing Radiation Protection
(lCNIRP) 1998
•
Ministry of Health (Canada) Safety Code 6. Limits of Human
Exposure to Radio frequency Electromagnetic Fields in the
Frequency Range from 3 kHz to 300 GHz, 1999
•
Australian Communications Authority Radiocommunications
(Electromagnetic Radiation - Human Exposure) Standard, 2003
•
ANATEL ANNEX to Resolution No. 303 of July 2, 2002
“Regulation of limitation of exposure to electrical, magnetic and
electromagnetic field in the radio frequency range between 9
KHz and 300GHz “and “Attachment to resolution # 303 from July
2, 2002."
![](/img.php?id=1100623&img=bg1a.png)
24
English
RF Exposure Compliance and Control Guidelines and Operating
Instructions
To control your exposure and ensure compliance with the occupational/
controlled environment exposure limits, always adhere to the following
procedures.
Guidelines:
•
Do not remove the RF Exposure label from the device.
•
User awareness instructions should accompany device when
transferred to other users.
•
Do not use this device if the operational requirements described
herein are not met.
Operating Instructions
•
Transmit no more than the rated duty factor of 50% of the time. To
transmit (talk), push the Push-To-Talk (PTT) button. To receive
calls, release the PTT button. Transmitting 50% of the time, or less,
is important because this radio generates measurable RF energy
exposure only when transmitting (in terms of measuring for
standards compliance).
Two-Way Radio Operation
•
Hold the radio in a vertical position in front of the
face with the microphone (and other parts of the
radio including the antenna) at least one inch (2.5
centimeters) away from the nose or lips. Antenna
should be kept away from the eye. Keeping the
radio at a proper distance is important since RF exposures
decrease with increasing distance from the antenna.
Body Worn Operation
•
When worn on the body, always place the radio in a
Motorola-approved clip, holder, holster, case, or body harness for this
product. Using approved bodyworn accessories is important because
![](/img.php?id=1100623&img=bg1b.png)
25
English
the use of non-Motorola-approved accessories may result in
exposure levels, which exceed the FCC occupational/controlle
d
environment RF exposure limits.
•
If you are not using a body-worn accessory and are not using the
radio in the intended use position in front of the face, ensure the
antenna and the radio are kept at least one inch (2.5 centimeters)
from the body when transmitting. Keeping the radio at a proper
distance is important because RF exposures decrease with
increasing distance from the antenna.
•
DO NOT hold the antenna when the radio is transmitting. Holding
the antenna affects call quality and may cause the radio product to
operate at higher or lower level than needed.
•
DO NOT touch the metal surface of the antenna (in extended
position) when he radio is transmitting. RF discomfort may result.
Approved Accessories
•
Use only Motorola-approved supplied or replacement antennas,
batteries, and accessories. Use of non-Motorola-approved
antennas, batteries, and accessories may exceed the FCC (IEEE)
and ICNIRP RF exposure guidelines.
•
For a list of Motorola-approved accessories, visit the following
website, which lists approved accessories for your radio model:
http://www.motorola.com/business.
Additional Information
For additional information on exposure requirements or other training
information, visit http://www.motorola.com/rfhealth.
Electromagnetic Interference/Compatibility
Note:
Nearly every electronic device is susceptible to electromagnetic
interference (EMI) if inadequately shielded, designed, or
otherwise configured for electromagnetic compatibility.
![](/img.php?id=1100623&img=bg1c.png)
26
English
Facilities
To avoid electromagnetic interference and/or compatibility conflicts,
turn OFF your radio in any facility where posted notices instruct you
to do so. Hospitals or health care facilities may be using equipment
that is sensitive to external RF energy.
Aircraft
When instructed to do so, turn OFF your radio when on board an
aircraft. Any use of a radio must be in accordance with applicable
regulations per airline crew instructions.
Medical Devices
Pacemakers
The Advanced Medical Technology Association (AdvaMed)
recommends that a minimum separation of 6 inches (15 centimeters)
be maintained between a handheld wireless radio and a pacemaker.
These recommendations are consistent with those of the U.S. Food
and Drug Administration.
Persons with pacemakers should:
•
ALWAYS keep the radio more than 6 inches (15 centimeters)
from their pacemaker when the radio is turned ON.
•
DO NOT carry the radio in the breast pocket.
•
Use the ear opposite the implantable medical device to minimize
the potential for interference.
•
Turn OFF the radio immediately if you have any reason to
suspect that interference is taking place.
Hearing Aids
Some digital wireless radios may interfere with some hearing aids. In
the event of such interference, you may want to consult your hearing
aid manufacturer or physician to discuss alternatives.
![](/img.php?id=1100623&img=bg1d.png)
27
English
Other Medical Devices
If you use any other personal medical devices, consult your
physician or the manufacturer or your device to determine if it is
adequately shielded from RF energy. Your physician may be able to
assist you in obtaining this information.
Use of Communication Devices While Driving
Always check the laws and regulations on the use of radio products
in the area where you drive.
When using your radio product while driving, please:
•
Give full attention to driving and to the road. Using a radio may
be distracting. Discontinue a call if you can’t concentrate on
driving.
•
Use hands free operation, if available.
•
Pull OFF the road and park before making or answering a call if
driving conditions so require.
Operational Warnings
For Vehicles With Air Bags:
Refer to vehicle manufacturer's manual prior to installation
of electronic equipment to avoid interference with air bag
wiring.
DO NOT place a portable radio in the area over an air bag
or in the air bag deployment area. Air bags inflate with
great force. If a portable radio is placed in the air bag
deployment area and the air bag inflates, the radio may be
propelled with great force and cause serious injury to
occupants of the vehicle.
Potentially Explosive Atmospheres:
(Explosive atmospheres refers to hazard classified
locations that may contain hazardous gas, vapors, or
dusts.) Turn OFF your radio prior to entering any area with
a
032374o
WARNING
![](/img.php?id=1100623&img=bg1e.png)
28
English
potentially explosive atmosphere unless it is a portable
radio type especially qualified for use in such areas as
Intrinsically Safe (for example, Factory Mutual, CSA, UL,
or CENELEC).
DO NOT remove, install, or charge batteries in such areas.
Sparks in a potentially explosive atmosphere can cause an
explosion or fire resulting in bodily injury or even death.
The areas with potentially explosive atmospheres referred
to above include fueling areas such as below decks on
boats, fuel or chemical transfer or storage facilities, and
areas where the air contains chemicals or particles such as
grain, dust or metal powders. Areas with potentially
explosive atmospheres are often, but not always, posted.
Blasting Caps and Blasting Areas:
To avoid possible interference with blasting operations,
turn OFF your radio when you are near electrical blasting
caps, in a blasting area, or in areas posted: “Turn OFF
two-way radio.” Obey all signs and instructions.
032374o
WARNING
![](/img.php?id=1100623&img=bg1f.png)
29
English
Operational Cautions
Intrinsically Safe Radio Information
The Intrinsically safe approval unit refers to a product that has been
approved as intrinsically safe by an approval agency (for example
FM Approvals, CSA, UL, or Cenelec) and certifies that a particular
product meets the Agency's applicable intrinsic safety standards for
specific types of hazardous classified locations. A portable radio that
has been approved for intrinsic safety will have Approval label
attached to the radio to identify the unit as being Approved for
specified hazardous atmospheres. This label specifies the
hazardous Class/Division/Group along with the part number of the
battery that must be used. The Intrinsically Safe Approval Label will
be located on the portable radio unit.
Antennas
DO NOT use any portable radio that has a damaged
antenna. If a damaged antenna comes into contact with
your skin, a minor burn can result.
Batteries
All batteries can cause property damage and/or bodily
injury, such as burns, if a conductive material such as
jewelry, keys, or beaded chains touches exposed
terminals. The conductive material may complete an
electrical circuit (short circuit) and become quite hot.
Exercise care in handling any charged battery,
particularly when placing it inside a pocket, purse, or
other container with metal objects.
032374o
WARNING
![](/img.php?id=1100623&img=bg20.png)
30
English
Operational Cautions for Intrinsic Safe Equipment
Warnings for Radios Approved as Intrinsically Safe
Radios must ship from the Motorola manufacturing facility with the
hazardous atmosphere capability and the intrinsic safety approval
labelling (FM, UL, CSA, CENELEC). Radios will not be upgraded to
this capability and labeled once they have been shipped to the field.
•
DO NOT operate radio communications equipment in a
hazardous atmosphere unless it is a type especially
qualified (for example, FM, UL, CSA, or CENELEC
approved). An explosion or fire may result.
•
DO NOT operate a radio unit that has been approved as
intrinsically safe product in a hazardous atmosphere if it
has been physically damaged (for example, cracked
housing). An explosion or fire may result.
•
DO NOT replace or charge batteries in a hazardous
atmosphere. Contact sparking may occur while installing
or removing batteries and cause an explosion or fire.
032374o
WARNING
![](/img.php?id=1100623&img=bg21.png)
31
English
A modification changes the unit’s hardware from its original design
configuration. Modifications can only be made by the original product
manufacturer.
Repair
•
DO NOT replace or change accessories in a
hazardous atmosphere. Contact sparking may occur
while installing or removing accessories and cause an
explosion or fire.
•
Turn the radio OFF before removing or installing a
battery or accessory.
•
DO NOT disassemble an intrinsically safe product in
any way that exposes the internal circuits of the unit.
•
Failure to use an intrinsically safe approved battery or
Approved accessories specifically approved for the
radio unit may result in the dangerously unsafe
condition of an unapproved radio combination being
used in a hazardous location.
•
Unauthorized or incorrect modification of the
intrinsically safe approved Product will negate the
approval rating of the product.
•
Incorrect repair or relabeling of any intrinsically safe
Agency approved radio could adversely affect the
approval rating of the unit.
•
Use of a radio that is not intrinsically safe in a
hazardous atmosphere could result in serious injury or
death.
REPAIRS FOR MOTOROLA PRODUCTS WITH
INTRINSICALLY SAFE APPROVAL ARE THE
RESPONSIBILITY OF THE USER.
Repairs to a Motorola FM approved radio product should
only be done at a location that has been FM audited under
the FM 3605 repairs and service standard.
Contact Motorola for assistance regarding repairs and
service of Motorola intrinsically safe equipment.
032374o
WARNIN
G
032374o
WARNING
![](/img.php?id=1100623&img=bg22.png)
32
English
A repair constitutes something done internally to the unit that would
bring it back to its original condition.
Items not considered as repairs are those in which an action is
performed on a unit which does not require the outer casing of the
unit to be opened in a manner that exposes the internal electrical
circuits of the unit.
Do Not Substitute Options or Accessories
The Motorola communications equipment certified as intrinsically
safe by the approving agency, (FM, UL, CSA, CENELEC) is tested
as a complete system which consists of the listed agency Approved
portable, Approved battery, and Approved accessories or options, or
both. This Approved portable and battery combination must be
strictly observed. There must be no substitution of items, even if the
substitute has been previously Approved with a different Motorola
communications equipment unit. Approved configurations are listed
by the Approving Agency (FM, UL, CSA, CENELEC).
The Intrinsically Safe Approval Label affixed to radio refers to the
intrinsically safe classification of that radio product, and the approved
batteries that can be used with that system.
The manual PN referenced on the Intrinsically Safe Approval Label
identifies the approved Accessories and or options that can be used
with that portable radio unit.
Using a non-Motorola-intrinsically-safe battery and or accessory with
the Motorola approved radio unit will void the intrinsically safe
approval of that radio unit.
![](/img.php?id=1100623&img=bg23.png)
33
English
Motorola Limited Warranty for the United
States and Canada
Warra nty
What Does this Warranty Cover?
Subject to the exclusions contained below, Motorola, Inc. warrants its
manufactured Radius Communication Products (“Products”),
Motorola-branded or certified accessories sold for use with these
Products (“Accessories”) and Motorola software contained on
CD-ROMs or other tangible media and sold for use with these
Products (“Software”) to be free from defects in materials and
workmanship under normal consumer usage for the period(s)
outlined below. This limited warranty applies as follows to new
Motorola Products, Accessories and Software purchased by
consumers in the United States or Canada, which are accompanied
by this written warranty:
Products and Accessories
Products Covered Length of Coverage
Motorola CP185 Radio
Kit Two (2) years
Motorola Accessories
One (1) year
Mag One Accessories
Six (6) months
Products and
Accessories that are
Repaired or Replaced.
The balance of the original
warranty or for ninety (90) days
from the date returned to the
consumer, whichever is longer.
![](/img.php?id=1100623&img=bg24.png)
34
English
Exclusions
Normal Wear and Tear.
Periodic maintenance, repair and
replacement of parts due to normal wear and tear are excluded from
coverage.
Batteries.
Only batteries whose fully charged capacity falls below
80% of their rated capacity and batteries that leak are covered by
this limited warranty.
Abuse & Misuse.
Defects or damage that result from: (a) improper
operation, storage, misuse or abuse, accident or neglect, such as
physical damage (cracks, scratches, etc.) to the surface of the
product resulting from misuse; (b) contact with liquid, water, rain,
extreme humidity or heavy perspiration, sand, dirt or the like,
extreme heat, or food; (c) use of the Products or Accessories for
commercial purposes or subjecting the Product or Accessory to
abnormal usage or conditions; or (d) other acts which are not the
fault of Motorola, are excluded from coverage.
Use of Non-Motorola Products and Accessories.
Defects or
damage that result from the use of non-Motorola branded or certified
Products, Accessories, Software or other peripheral equipment are
excluded from coverage.
Unauthorized Service or Modification.
Defects or damages
resulting from service, testing, adjustment, installation, maintenance,
alteration, or modification in any way by someone other than
Motorola, or its authorized service centers, are excluded from
coverage.
Altered Products.
Products or Accessories with (a) serial numbers
or date tags that have been removed, altered or obliterated;
(b) broken seals or that show evidence of tampering; (c) mismatched
board serial numbers; or (d) nonconforming or non-Motorola
housings, or parts, are excluded from coverage.
Communication Services.
Defects, damages, or the failure of
Products, Accessories or Software due to any communication
service or signal you may subscribe to or use with the Products
Accessories or Software is excluded from coverage.
![](/img.php?id=1100623&img=bg25.png)
35
English
Software
Exclusions
Software Embodied in Physical Media.
No warranty is made that the
software will meet your requirements or will work in combination with any
hardware or software applications provided by third parties, that the
operation of the software products will be uninterrupted or error free, or
that all defects in the software products will be corrected.
Software NOT Embodied in Physical Media.
Software that is not
embodied in physical media (e.g. software that is downloaded from the
internet), is provided “as is” and without warranty.
Who Is Covered?
This warranty extends only to the first consumer purchaser, and is not
transferable.
What Will Motorola Do?
Motorola, at its option, will at no charge repair, replace or refund the
purchase price of any Products, Accessories or Software that does not
conform to this warranty. We may use functionally equivalent
reconditioned/refurbished/pre-owned or new Products, Accessories or
parts. No data, software or applications added to your Product, Accessory
or Software, including but not limited to personal contacts, games and
ringer tones, will be reinstalled. To avoid losing such data, software and
applications please create a back up prior to requesting service.
Products Covered Length of Coverage
Software.
Applies only to physical
defects in the media that embodies
the copy of the software (e.g.
CD-ROM, or floppy disk).
Ninety (90) days
from
the date of purchase.
![](/img.php?id=1100623&img=bg26.png)
36
English
How to Obtain Warranty Service or Other Information
You will receive instructions on how to ship the Products,
Accessories or Software, at your expense, to a Motorola Authorized
Repair Center. To obtain service, you must include: (a) a copy of your
receipt, bill of sale or other comparable proof of purchase; (b) a
written description of the problem; (c) the name of your service
provider, if applicable; (d) the name and location of the installation
facility (if applicable) and, most importantly; (e) your address and
telephone number.
What Other Limitations Are There?
ANY IMPLIED WARRANTIES, INCLUDING WITHOUT LIMITATION THE
IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A
PARTICULAR PURPOSE, SHALL BE LIMITED TO THE DURATION OF
THIS LIMITED WARRANTY, OTHERWISE THE REPAIR,
REPLACEMENT, OR REFUND AS PROVIDED UNDER THIS EXPRESS
LIMITED WARRANTY IS THE EXCLUSIVE REMEDY OF THE
CONSUMER, AND IS PROVIDED IN LIEU OF ALL OTHER
WARRANTIES, EXPRESS OR IMPLIED. IN NO EVENT SHALL
MOTOROLA BE LIABLE, WHETHER IN CONTRACT OR TORT
(INCLUDING NEGLIGENCE) FOR DAMAGES IN EXCESS OF THE
PURCHASE PRICE OF THE PRODUCT, ACCESSORY OR
SOFTWARE, OR FOR ANY INDIRECT, INCIDENTAL, SPECIAL OR
CONSEQUENTIAL DAMAGES OF ANY KIND, OR LOSS OF REVENUE
OR PROFITS, LOSS OF BUSINESS, LOSS OF INFORMATION OR
USA
1-800-422-4210
Canada
1-800-461-4575
TTY
1-888-390-6456
For
Accessories
and
Software
, please call the telephone
number designated above for the product with which they are
used.
![](/img.php?id=1100623&img=bg27.png)
37
English
DATA, SOFTWARE OR APPLICATIONS OR OTHER FINANCIAL LOSS
ARISING OUT OF OR IN CONNECTION WITH THE ABILITY
OR INABILITY TO USE THE PRODUCTS, ACCESSORIES OR
SOFTWARE TO THE FULL EXTENT THESE DAMAGES MAY BE
DISCLAIMED BY LAW.
Some states and jurisdictions do not allow the limitation or
exclusion of incidental or consequential damages, or limitation
on the length of an implied warranty, so the above limitations or
exclusions may not apply to you. This warranty gives you
specific legal rights, and you may also have other rights that
vary from state to state or from one jurisdiction to another.
Laws in the United States and other countries preserve for Motorola
certain exclusive rights for copyrighted Motorola software such as
the exclusive rights to reproduce and distribute copies of the
Motorola software. Motorola software may only be copied into, used
in, and redistributed with, the Products associated with such
Motorola software. No other use, including without limitation
disassembly of such Motorola software or exercise of the exclusive
rights reserved for Motorola, is permitted.
![](/img.php?id=1100623&img=bg28.png)
38
English
Software Copyright Notice
The Motorola products described in this manual may include
copyrighted Motorola and third-party software stored in
semiconductor memories or other media. Laws in the United States
and other countries preserve for Motorola and third-party software
providers certain exclusive rights for copyrighted software, such as
the exclusive rights to distribute or reproduce the copyrighted
software. Accordingly, any copyrighted software contained in the
Motorola products may not be modified, reverse-engineered,
distributed, or reproduced in any manner to the extent allowed by
law. Furthermore, the purchase of the Motorola products shall not be
deemed to grant either directly or by implication, estoppel, or
otherwise, any license under the copyrights, patents, or patent
applications of Motorola or any third-party software provider, except
for the normal, non-exclusive, royalty-free license to use that arises
by operation of law in the sale of a product.
