Motorola Solutions 89FT4930 2-way Radio with GMRS and FRS User Manual
Motorola Solutions, Inc. 2-way Radio with GMRS and FRS
User Manual
m
TALKABOUT ® TWO-WAY RADIO
T1XX SERIES
*MN002664A01*
MN002664A01-EN
MOTOROLA, MOTO, MOTOROLA SOLUTIONS and the Stylized M logo are trademarks
or registered trademarks of Motorola Trademark Holdings, LLC and are used under
license. All other trademarks are the property of their respective owners.
© 2016 Motorola Solutions, Inc. All rights reserved.
Printed in China
RF Exposure and Product Safety Instructions for
Portable Two-Way Radios General Populated and
Uncontrolled Environments.
ATTENTION:
Before using this radio, refer to the important operating instructions
for safe usage and RF energy awareness and control for compliance
with applicable Standards and Regulations.
Compliance with RF Exposure Standards
Your Motorola Two-Way radio complies with the following RF energy
exposure standard and guidelines:
United States Federal Communications Commission,
Code of Federal Regulations; 47 CFR et seq. & FCC.
• Institute of Electrical and Electronic Engineers (IEEE) C95.1.
• International Commission on Non-Ionizing Radiation
Protection (ICNIRP).
• Ministry of Health (Canada) Safety Code 6 & Industry Canada
RSS-102.
• Australian Communications Authority Radiocommunications
Standard et seq.
Transmit and Receive Procedure
Your two-way radio contains a transmitter and a receiver. To control
your exposure and ensure compliance with the general population/
uncontrolled environment exposure limits, always adhere to the
following procedure:
• Transmit no more than 50% of the time.
• To receive calls, release the Push-to-Talk (PTT) button.
• To transmit (talk), press the PTT button in front of the face.
• Hold the radio in a vertical position with the microphone (and
other parts of the radio including the antenna) at least one inch
(2.5 centimeters) away from the nose or lips. Keeping the radio
at a proper distance is important to ensure compliance.
Note: RF exposure decreases with increasing distance from the
antenna.
• Body Worn Operation. When worn on the body, always place
the radio in a Motorola-approved clip, holder, holster, case or
body harness for this product.
Please refer to the following websites for more information on what
RF energy exposure is and how to control your exposure to assure
compliance with established RF exposure limits:
• http://www.fcc.gov/oet/rfsafety/rf-faqs.html
• www.who.int/en/
• http://responsibility.motorolasolutions.com/index.php/
downloads/dow07-rfexposureassessmentstand/
Two-way Radio Operation
• Use only Motorola-approved supplied or replacement
antennas, batteries, and audio accessories. Use of non-
Motorola-approved antennas, batteries, and wired or wireless
accessories may exceed the applicable RF exposure
guidelines (iEEE, ICNIRP or FCC).
• For a list of Motorola-approved accessories for your radio
model, visit the following website: http://
www.motorolasolutions.com/TalkaboutAccessories.
Electromagnetic Interference/Compatibility
Note: Nearly every electronic device is susceptible to
electromagnetic interference (EMI) if inadequately shielded,
designed or otherwise configured for electromagnetic
compatibility.
This device complies with part 15 of the FCC Rules. Operation is
subject to the following two conditions:
1. This device may not cause harmful interference, and
2. This device must accept any interference received, including
interference that may cause undesired operation.
This device complies with Industry Canada licence-exempt RSS
standard(s). Operation is subject to the following two conditions:
1. This device may not cause interference, and
2. This device must accept any interference received, including
interference that may cause undesired operation of the device.
Facilities
To avoid electromagnetic interference and/or compatibility conflicts,
turn off your radio in any facility where posted notices instruct you to
do so. Hospitals or health care facilities may be using equipment that
is sensitive to external RF energy.
Aircraft
When instructed to do so, turn off your radio when onboard an
aircraft. Any use of a radio must be in accordance with applicable
regulations per airline crew instructions.
Medical Devices – Pacemakers, Defibrillators or other
Implanted Medical Devices
Persons with pacemakers, Implantable cardioverter-defibrillators
(ICDs) or other active implantable medical devices (AIMD) should:
• Consult with their physicians regarding the potential risk of
interference from radio frequency transmitters, such as
portable radios (poorly shielded medical devices may be more
susceptible to interference).
• Turn the radio OFF immediately if there is any reason to
suspect that interference is taking place.
• Do not carry the radio in a chest pocket or near the
implantation site, and carry or use the radio on the opposite
side of their body from the implantable device to minimize the
potential for interference.
Hearing Aids
Some digital wireless radios may interfere with some hearing aids. In
the event of such interference, you may want to consult your hearing
aid manufacturer to discuss alternatives.
Other Medical Devices
If you use any other personal medical device, consult the
manufacturer of your device to determine if it is adequately shielded
from RF energy. Your physician may be able to assist you in
obtaining this information.
Use of Communication Devices While Driving
Always check the laws and regulations on the use of radios in the
areas where you drive.
• Give full attention to driving and to the road.
• Use hands-free operation, if available.
• Pull off the road and park before making or answering a call, if
driving conditions or regulations so require.
For Vehicle With Air Bags
Refer to the vehicle manufacturer’s manual prior to installation of
electronic equipment to avoid interference with air bag wiring.
Do not place a portable radio in the area over an air bag or in the air
bag deployment area. Air bags inflate with great force. If a portable
radio is placed in the air bag deployment area and the air bag
inflates, the radio may be propelled with great force and cause
serious injury to occupants of the vehicle.
Potentially Explosive Atmosphere
Turn off your radio prior to entering any area with a potentially
explosive atmosphere. Only radio types that are especially qualified
should be used in such areas as “Intrinsically Safe”. Do not remove,
install or charge batteries in such areas. Sparks in a potentially
explosive atmosphere can cause an explosion or fire resulting in
bodily injury or even death.
Note:The areas with potentially explosive atmosphere referred to
above include fueling areas such as below decks on boats,
fuel or chemical transfer or storage facilities, areas where the
air contains chemicals or particles (such as grain, dust or
metal powders) and any other area where you would normally
be advised to turn off your vehicle engine. Areas with
potentially explosive atmospheres are often – but not always
posted.
Blasting Caps and Areas
To avoid possible interference with blasting operations, turn off your
radio when you are near electrical blasting caps, in a blasting area, or
in areas posted “Turn off two-way radios”. Obey all signs and
instructions.
Operational Cautions
Antennas
Do not use any portable radio that has a damaged antenna. If a
damaged antenna comes into contact with your skin, a minor burn
can result.
Batteries
All batteries can cause property damage and/or bodily injury such as
burns if a conductive material touches exposed terminals. The
conductive material may complete an electrical circuit (short circuit)
and become hot.
• Exercise care when removing AAA batteries. Do not use sharp
or conductive tools to remove these batteries.
• Exercise care in handling any charged battery, particularly
when placing it inside a pocket, purse or other container with
metal objects.
Do not discard your battery in a fire.
• Do not replace the battery in any area labeled “Hazardous
Atmosphere”. Any sparks created in a potentially explosive
atmosphere can cause explosion or fire.
• Do not disassemble, crush, puncture, shred or otherwise
attempt to change the form of your battery.
• Do not dry a wet battery or damp battery with an appliance or
heat source, such as a hair dryer or microwave oven.
• If the radio battery contact area has been submerged in water,
dry and clean the battery contacts before attaching the battery
to the radio.
USA
Use of GMRS frequencies is subject to the Rules and Regulations of
the Federal Communications Commission (FCC).
The FCC requires that all operators using GMRS frequencies obtain
a radio license before operating their equipment. To obtain the FCC
forms, please visit the FCC website at wireless.fcc.gov/uls/
index.htm?job=home to source form 605 and 159, which includes all
the instructions you will need.
If you wish to have the document faxed or mailed, or if you have
questions, please use the following contact information:
Canada
Use of Motorola radio in Canada is subject to the rules & regulations
of Industry Canada (IC). IC requires no license when operated in
Canada.
Changes or modifications not expressly approved by Motorola
Solutions may void the user authority granted by the IC/FCC to
operate this radio and should not be made. To comply with IC/FCC
requirements, transmitter adjustments should be made only by or
under the supervision of a person certified as technically qualified to
perform transmitter maintenance and repairs in the private land
mobile and fixed services as certified by an organization
representative of the user of those services. Replacement of any
transmitter component (crystal, semiconductor, etc) not authorized by
the IC/FCC equipment authorization for this radio could violate IC/
FCC rules.
Note: Use of this radio outside the country where it was intended to
be distributed is subject to government regulations and may
be prohibited.
Mexico
Use of GMRS frequencies is subject to the Rules and Regulations of
the Federal Communications Institute (IFT) requires that all operators
using GMRS frequencies obtain a permit before operating their
equipment. To obtain a permit from the IFT, the user must proceed in
accordance with Articles 14 and 15 of the Federal
Telecommunications Law. Consult your local IFT office for more
information: www.ift.org.mx
Uruguay
Use of GMRS frequencies is subject to the Rules and Regulations of
the Regulatory Unit Communications Services (URSEC). URSEC
requires that all operators using GMRS frequencies obtain a permit
before operating their equipment. The authorization shall depend on
the channel availability at the time the authorization is requested. To
obtain a permit from URSEC, consult your local URSEC office for
more information: www.ursec.gub.uy.
Panama
The Republic of Panama does not require authorization to use FRS/
GMRS radio equipment frequencies.
Installing the Batteries
1. Make sure your radio is OFF.
2. To remove the battery compartment door, by pressing the tab
at the bottom of the compartment door. Remove the door.
Insert 3 AAA batteries into the battery compartment.
3. Replace the battery compartment door.
Battery Level and Low Battery Alert
Removing the Three AAA Alkaline Batteries
1. Turn the radio off.
2. With the back of the radio facing you, lift the battery cover latch
up and remove the cover.
3. Gently remove each alkaline battery by pulling the ribbon
attached to the radio.
4. Close the battery cover firmly.
Note:
• Exercise care when removing AAA batteries. Do not use sharp
or conductive tools to remove either of these batteries.
• Remove the batteries before storing your radio for extended
periods of time. Batteries corrode over time and may cause
permanent damage to your radio.
Attaching and Removing the Belt Clip
1. Attach the belt clip to the back of the radio until the clip clicks in
place.
2. Attach the belt clip to pocket or belt strap until the clip clicks in
place.
To Remove
1. Push the release tab on top of the belt clip to release the latch.
2. Pull the belt clip away from the back of the radio.
Read this reference guide completely before attempting to operate
the unit.
Turning Your Radio On/Off
Press and hold the MENU/ button to turn your radio ON/OFF.
Adjusting the Volume
1. Adjust the volume by pressing the and buttons.
2. When the volume reached level 0, the mute icon appears
permanently on screen.
Adjusting the Sound (Key Beeps)
Your radio emits a beep each time one of the buttons is pressed
(except the PTT button).
Press and hold the button while turning the radio ON to switch the
sound OFF.
To turn this sound ON, turn the radio OFF and ON again without
pressing the button.
Selecting a Channel
In order to speak to someone, both your radios must be set to the
same channel.
To select a channel:
1. Press MENU/ one time to enter Menu.
2. Press or to the required channel. An extended press
of or allows you to scroll through the channel rapidly.
3. Press PTT button to confirm the selection or MENU/ to
continue setup.
To communicate, all radios in your group must be set to the same
channel.
1. To talk, press and hold the PTT button. When transmitting, the
is shown.
2. When you are finished talking, release the PTT button.
3. When receiving, the is shown.
For maximum clarity, hold the radio one inch away from your mouth
and speak directly into the microphone. Do not cover the microphone
while talking.
Talk Range
Your radio is designed to maximize performance and improve
transmission range. Do not use the radios closer than five feet apart.
Push-to-Talk Timeout Timer
To prevent accidental transmissions and save battery life, the radio
emits a continuous warning tone and stops transmitting if you press
the PTT button for 60 continuous seconds.
Channel Scan Mode
Channel Scan Mode enables your radio to scan for active channels.
When activity is detected, your radio lands (stays) on that channel
(for two seconds). To transmit on that channel, press the PTT button.
When activity on the landed channel ends, your radio continues
scanning other channels.
To turn the channel scan ON:
1. Press MENU/ two times until appears.
2. Press / to start scanning. Press MENU/ or PTT to turn
OFF Scan mode.
Key Lock
1. Press and hold / until appears to lock the keypad.
2. When in lock mode, you can turn the radio on and off, adjust
the volume, send a call tone, receive, and transmit. All other
functions are locked.
3. Press and hold / , until disappears to unlock the
keypad.
Monitor Mode
Your radio enables you to listen for weak signals on the current
channel.
To turn the Monitor Mode ON:
1. Press MENU/ three times until the Channel Monitor setting
flashes and the appears.
2. Press the / button for continuous listening. The icon
continues to appears.
To turn the Monitor Mode OFF:
1. Press the MENU/ button to return to “Normal” mode. The
icon stops appearing.
Roger Beep
Roger beep sounds to indicate the end of a PTT transmission. It can
be heard through the speaker when Key Beep is on. It cannot be
heard through the speaker if Key Beep is turned off.
Press and hold the button while turning the radio ON to turn the
Roger Beep ON. Repeat the step to turn Roger Beep OFF.
Automatic Power Save
For better battery life, your radio is designed to switch to Power Save
mode when there has been no transmissions after three seconds.
The radio can receive transmissions in this mode
USA, Canada, Mexico, Panama, Uruguay
MOTOROLA, MOTO, MOTOROLA SOLUTIONS and the Stylized M
logo are trademarks or registered trademarks of Motorola Trademark
Holdings, LLC and are used under license. All other trademarks are
the property of their respective owners.
© 2016 Motorola Solutions, Inc. All rights reserved.
Consumer Two-Way Radio Products and Accessories
purchased in the USA, Canada, Mexico, Uruguay, and
Panama
What Does this Warranty Cover?
Subject to the exclusions contained below, Motorola Solutions, Inc.
(“Motorola”) warrants the Motorola branded consumer
two-way radios that operate via Family Radio Service or General
Mobile Radio Service (“Products”), the Motorola branded or certified
accessories sold for use with these Products (“Accessories”) to be
free from defects in materials and workmanship under normal
consumer usage for the period(s) outlined below. This limited
warranty is the exclusive remedy of a consumer, and applies as
follows to new Products and Accessories and purchased by
consumers in the United States or Canada, which are accompanied
by this written warranty:
Who is Covered?
This warranty extends only to the first consumer purchaser, and is
not transferable.
What will MOTOROLA SOLUTIONS, INC. do?
Motorola Solutions, Inc., at its option, will at no charge repair, replace
or refund the purchase price of any Products or Accessories that do
not conform to this warranty. We may use functionally equivalent
reconditioned/ refurbished/ pre-owned or new Products or
Accessories.
What Other Limitations Are There?
Any Implied Warranties, Including Without Limitation
The implied warranties of merchantability and fitness for a particular
purpose, shall be limited to the duration of this limited warranty,
otherwise the repair, replacement, or refund as provided under this
express limited warranty is the exclusive remedy of the consumers,
and is provided in lieu of all other warranties, express or implied. In
no event shall Motorola Solutions be liable, whether in contract or tort
(including negligence) for damages in excess of the purchase price
of the product or accessory, or for any indirect, incidental, special or
consequential damages of any kind, or loss of revenue or profits, loss
of business, loss of information or other financial loss arising out of or
in connection with the ability or inability to use the products or
accessories to the full extent these damages may be disclaimed by
law.
Some states and jurisdictions do not allow the limitation or exclusion
of incidental or consequential damages, or limitation on the length of
an implied warranty, so the above limitations or exclusions may not
apply to you. This warranty gives you specific legal rights, and you
may also have other rights that vary from state to state or from one
jurisdiction to another.
How to Obtain Warranty Service or Other Information?
To obtain customer service or information:
USA and Canada
1-800-448-6686.
www.motorolasolutions.com/talkabout
E-mail us at consumerradio@motorolasolutions.com
Latin America
Toll free:
Mexico 001-855-241-8253
Panama 001-800-205-3867
Uruguay 598 – 24001716
Toll or long distance:
Spanish +001-312-725-5372
English +001-312-725-5368
motorolasolutions.com/talkabout/es (Spanish)
For Accessories:
Please call the telephone number designated above for the Product
with which they are used.
You will receive instructions on how to ship the Products or
Accessories at your expense, to Motorola or a Motorola Authorized
Repair Center. To obtain service, you must include: (a) a copy of your
receipt, bill of sale or other comparable proof of purchase; (b) a
written description of the problem; (c) the name of your service
provider, if applicable; (d) the name and location of the installation
facility (if applicable) and, most importantly; (e) your address and
telephone number.
For more information, please visit us at:
Safety and General Information
For a fax:
Contact the Fax-On-
Demand system
For mail service:
Call the FCC Forms
Hotline
If you have questions
about the FCC License:
Call the FCC
1-202-418-0177 1-800-418-FORM (3676) 1-888-CALL-FCC
(225-5322)
Licensing Information
Control Buttons
Antenna
Volume/
Scroll
Call Tone/ Lock
Speaker
Microphone
Menu/Power
Push-to-Talk
Screen
Display Screen Guide
Channel
Battery (2
Battery Levels)
Keypad Lock
Mute Status (transmit/
receive)
Scan
This icon will show when battery is low and will blink
when battery is extremely low. Replace the batteries
immediately.
Getting Started
Basic Radio Operations
Talking and Listening
Channel Frequency Description Channel Frequency Description
1 462.5625 MHz GMRS/FRS 12 467.6625 MHz FRS
2 462.5875 MHz GMRS/FRS 13 467.6875 MHz FRS
3 462.6125 MHz GMRS/FRS 14 467.7125 MHz FRS
4 462.6375 MHz GMRS/FRS 15 462.5500 MHz GMRS
5 462.6625 MHz GMRS/FRS 16 462.5750 MHz GMRS
6 462.6875 MHz GMRS/FRS 17 462.6000 MHz GMRS
7 462.7125 MHz GMRS/FRS 18 462.6250 MHz GMRS
8 467.5625 MHz FRS 19 462.6500 MHz GMRS
9 467.5875 MHz FRS 20 462.6750 MHz GMRS
10 467.6125 MHz FRS 21 462.7000 MHz GMRS
11 467.6375 MHz FRS 22 462.7250 MHz GMRS
Channels and Frequencies
Patent and Copyright Information
Warranty
Products Covered Length Of Coverage
Products and Accessories
as defined above, unless
otherwise provided for
below: One (1) year from the date of
purchase by the first consumer
purchaser of the product unless
otherwise provided for below.
Batteries
whose fully charged capacity
falls below 80% of their rated
capacity and batteries that
leak
Products and Accessories
that are repaired or replaced
The balance of the original
warranty or for ninety (90) days
from the date returned to the
consumer, whichever is longer.
Exclusions From Warranty Coverage
Normal Wear and Tear:
Periodic maintenance, repair and replacement of Products or
Accessories due to normal wear and tear.
Abuse & Misuse:
Defects or damage that result from: (a) improper operation, storage,
misuse or abuse, accident or neglect, such as physical damage
(cracks, scratches, etc.) to the surface of the Products and
Accessories resulting from misuse; (b) contact with liquid, water,
rain, extreme humidity or heavy perspiration, sand, dirt or the like,
extreme heat, or food; (c) use of the Products or Accessories for
commercial purposes or subjecting the Product or Accessory to
abnormal usage or conditions; or (d) other acts which are not the
fault of Motorola.
Use of Non-Motorola branded Products and Accessories:
Defects or damage that result from the use of Non-Motorola
branded or certified products, accessories, software or other
peripheral equipment.
Unauthorized Service or Modification:
Defects or damages resulting from service, testing, adjustment,
installation, maintenance, alteration, or modification in any way by
someone other than Motorola or its authorized service centers.
Altered Products:
Products or Accessories with (a) serial numbers or date tags that
have been removed, altered or obliterated; (b) broken seals or that
show evidence of tampering; (c) mismatched board serial numbers;
or (d) nonconforming or non-Motorola branded housings, or parts.
Communication Services:
Defects, damages, or the failure of Products or Accessories due to
any communication service or signal you may subscribe to or use
with the Products or Accessories.
https://www.facebook.com/
MotorolaTalkaboutWalkieTalkies
http://bit.ly/Talkabout
www.motorolasolutions.com/talkabout
www.motorolasolutions.com/talkabout/es
(Spanish)
