Motorola Solutions 89FT4952 Consumer Radio 462-467 MHz User Manual MN002664A01
Motorola Solutions, Inc. Consumer Radio 462-467 MHz MN002664A01
User Manual
11 6
4
23 5
m
TALKABOUT ® TWO-WAY RADIO
T1XX SERIES
*MN002664A01*
MN002664A01-AE
MOTOROLA, MOTO, MOTOROLA SOLUTIONS and the Stylized M logo
are trademarks or registered trademarks of Motorola Trademark Holdings,
LLC and are used under license. All other trademarks are the property of
their respective owners. © 2016 and 2019 Motorola Solutions, Inc.
All rights reserved.
Printed in
Caution
Before using this radio, read this booklet which contains important
operating instructions.
For information on product details, brochures, user manuals and
approved accessories. Please refer to www.motorolasolutions.com.
Compliance with RF Exposure Standards
National and international regulations require manufacturers to
comply with the RF energy exposure limits for portable two-way
radios before they can be marketed. Your Motorola Solutions two-
way radio is designed, manufactured, and tested to comply with all
applicable national and international regulations for human exposure
to radio frequency electromagnetic energy.
RF Energy Exposure Awareness and Control
Information and Operational Instructions for General
Population and Uncontrolled Environment Use
For more information on what RF energy exposure is, see the
following websites:
• https://www.fcc.gov/
• http://www.who.int/peh-emf/project/en/
For additional information, see https://www.motorolasolutions.com/
en_us/about/ company-overview/corporate-responsibility/
governance-and-policies/wirelesscommunication-and-health-
faqs.html.
Operating Instructions
• Transmit no more than 50% of the time. To transmit (talk),
press the Push-To-Talk (PTT) button. To receive calls, release
the PTT button.
• Hold the radio in a vertical position in front of the face with the
microphone (and other parts of the radio including the
antenna) at least 1 in. (2.5 cm) away from the nose or lips.
Antenna should be kept away from the eye.
• When worn on the body, always place the radio in a Motorola
Solutions-approved clip, holder, holster, case, or body harness
for this product.
• DO NOT hold the antenna when the radio is transmitting.
• DO NOT use any portable radio that has a damaged antenna.
If a damaged antenna comes into contact with your skin, a
minor burn can result.
• To ensure continued compliance with applicable RF exposure
limits, use only Motorola Solutions-approved, supplied or
replacement antennas, batteries, and accessories.
• For a list of Motorola Solutions-approved accessories please
refer to your user manual or visit www.motorolasolutions.com
Acoustic Safety
Exposure to loud noises from any source for extended periods of
time may temporarily or permanently affect your hearing. The louder
the volume of the radio, the sooner your hearing will be affected.
Hearing damage from loud noise is sometimes undetectable at first,
and can have a cumulative effect.
To protect your hearing, follow these precautions:
• Use the lowest volume necessary to do your job.
• Turn up the volume only if you are in noisy surroundings.
• Turn down the volume before putting on a headset or
headphones.
• Limit the amount of time you use a headset or headphones at
high volume.
• When using the radio without a headset or headphones, do not
place the speaker of the radio directly against your ear.
Medical Devices
If you use a personal medical device, such as a pacemaker or
hearing aid, consult the manufacturer of your device to determine if it
is adequately shielded from RF energy. Your physician may be able
to assist you in obtaining this information.
Holsters Incorporating Magnets
Some Motorola Solutions holsters incorporate strong, neodymium
magnets. If you use a personal medical device, such as a pacemaker
or hearing aid, consult the manufacturer of your device to determine
if it can be used in close proximity to magnets. Your physician may be
able to assist you in obtaining this information. Also be aware that
magnets can damage other products, including cell phones,
computers, hard drives, and other electronic devices, as well as
credit cards and magnetic media. Keep the holster away from any
mechanical device that could be affected by a magnetic field. Consult
the manufacturer of your product to determine if your device or
product can be used in close proximity to magnets.
Operational Warnings
The following explains the operational warnings:
For Vehicle With Air Bags
Potentially Explosive Atmospheres
Blasting Caps and Blasting Areas
Batteries
• Charge your battery using the approved Motorola Solutions
charger.
• Use the battery in accordance with its water and/or dust
Ingress Protection (IP) rating.
• DO NOT discard your battery into a fire.
• Do not replace the battery in any area labeled “Hazardous
Atmosphere”.
• DO NOT disassemble, crush, puncture, shred, or otherwise
attempt to change the form of your battery.
• DO NOT dry a wet or damp battery with an appliance or heat
source, such as a hair dryer or microwave oven.
• DO NOT allow conductive material such as jewelry, keys, or
beaded chains to touch exposed battery terminals.
• Do not dispose of batteries with household waste.
Repair
Do Not Substitute Options or Accessories
The Motorola Solutions communications equipment certified as
intrinsically safe by the approving agency (FM, UL, CSA, CENELEC)
is tested as a complete system which consists of the listed agency
approved portable, approved battery, and approved accessories or
options, or both. This approved portable and battery combination
must be strictly observed. There must be no substitution of items,
even if the substitute has been previously approved with a different
Motorola Solutions communications equipment unit. Approved
configurations are listed by the approving agency (FM, UL, CSA,
CENELEC).
The Intrinsically Safe Approval Label affixed to radio refers to the
intrinsically safe classification of that radio product, and the approved
batteries that can be used with that system.The manual PN
referenced on the Intrinsically Safe Approval Label identifies the
approved accessories and/or options that can be used with that
portable radio unit. Using a non-Motorola Solutions-intrinsically safe
battery and/or accessory with the Motorola Solutions-approved radio
unit will void the intrinsically safe approval of that radio unit.
European Union (EU) Waste of Electrical and Electronic
Equipment (WEEE) Directive
Declaration of Conformity
FCC Licensing Information
For a Class B digital device or peripheral, the instructions furnished
the user shall include the following or similar statement, placed in a
prominent location in the text of the manual:
Note:This equipment has been tested and found to comply with the limits
for a Class B digital device, pursuant to part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against
harmful interference in a residential installation. This equipment
generates, uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause
harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation.
If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from
that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for
help.
Notice to Users (FCC and Industry Canada)
This device complies with Part 15 of the FCC rules and Industry
Canada's license-exempt RSS's per the following conditions:
• This device may not cause harmful interference.
• This device must accept any interference received, including
interference that may cause undesired operation.
• Changes or modifications made to this device, not expressly
approved by Motorola Solutions, could void the authority of the
user to operate this equipment.
USA (FCC)/CANADA
According to FCC Part 95, FRS devices do not require a license. Use
of Motorola radio in Canada is subject to the rules regulations in
ISED RSS 210 and do not require a license.
Changes or modifications not expressly approved by Motorola
Solutions may void the user authority granted by the FCC or ISED to
operate this radio and should not be made. To comply with FCC or
ISED requirements, transmitter adjustments should be made only by
or under the supervision of a person certified as technically qualified
to perform transmitter maintenance and repairs in the private land
mobile and fixed services as certified by an organization
representative of the user of those services. Replacement of any
transmitter component (crystal, semiconductor, etc) not authorized by
the FCC or ISED equipment authorization for this radio could violate
FCC or ISED rules.
Note: Use of this radio outside the country where it was intended to be
distributed is subject to government regulations and may be
prohibited.
Mexico
Use of GMRS frequencies is subject to the Rules and Regulations of
the Federal Communications Institute (IFT) requires that all operators
using GMRS frequencies obtain a permit before operating their
equipment. To obtain a permit from the IFT, you must proceed in
accordance with Articles 14 and 15 of the Federal
Telecommunications Law. Consult your local IFT office for more
information: www.ift.org.mx
Uruguay
Use of GMRS frequencies is subject to the Rules and Regulations of
the Regulatory Unit Communications Services (URSEC). URSEC
requires that all operators using GMRS frequencies obtain a permit
before operating their equipment. The authorization shall depend on
the channel availability at the time the authorization is requested. To
obtain a permit from URSEC, consult your local URSEC office for
more information: www.ursec.gub.uy.
Panama and Paraguay
The Republic of Panama and Paraguay do not require authorization
to use FRS/GMRS radio equipment frequencies.
Installing the Batteries
1. Make sure your radio is OFF.
2. To remove the battery compartment door, by pressing the tab
at the bottom of the compartment door. Remove the door.
Insert three AAA batteries into the battery compartment.
3. Replace the battery compartment door.
Battery Level and Low Battery Alert
Removing the Alkaline Batteries
1. Turn the radio off.
2. With the back of the radio facing you, lift the battery cover latch
up and remove the cover.
3. Gently remove each alkaline battery.
4. Close the battery cover firmly.
Note:
• Exercise care when removing AAA batteries. Do not use sharp
or conductive tools to remove either of these batteries.
• Remove the batteries before storing your radio for extended
periods of time. Batteries corrode over time and may cause
permanent damage to your radio.
Attaching and Removing the Belt Clip
1. Attach the belt clip to the back of the radio until the clip clicks in
place.
2. Attach the belt clip to pocket or belt strap until the clip clicks in
place.
To Remove
1. Pull the release tab on top of the belt clip to release the latch.
2. Push the belt clip with the other hand towards the top of radio.
Read this reference guide completely before attempting to operate
the unit.
Turning Your Radio On/Off
Press and hold the MENU/ button to turn your radio ON/OFF.
Adjusting the Volume
1. Adjust the volume by pressing the and buttons.
2. When the volume reached level 0, the mute icon appears
permanently on screen.
Adjusting the Sound (Key Beeps)
Your radio emits a beep each time one of the buttons is pressed
(except the PTT button).
Press and hold the button while turning the radio ON to switch the
sound OFF.
To turn this sound ON, turn the radio OFF and ON again without
pressing the button.
Selecting a Channel
In order to speak to someone, both your radios must be set to the
same channel.
To select a channel:
1. Press MENU/ one time to enter Menu.
2. Press or to the required channel. An extended press
of or allows you to scroll through the channel.
3. Press PTT button to confirm the selection or MENU/ to
continue setup.
To communicate, all radios in your group must be set to the same
channel.
1. To talk, press and hold the PTT button. When transmitting, the
is shown.
2. When you are finished talking, release the PTT button.
3. When receiving, the is shown.
For maximum clarity, hold the radio 1 in. away from your mouth and
speak directly into the microphone. Do not cover the microphone
while talking.
Talk Range
Your radio is designed to maximize performance and improve
transmission range. Do not use the radios closer than 5 ft apart.
Push-to-Talk Timeout Timer
To prevent accidental transmissions and save battery life, the radio
emits a continuous warning tone and stops transmitting if you press
the PTT button for 60 s continuously.
Channel Scan Mode
Channel Scan Mode enables your radio to scan for active channels.
When activity is detected, your radio lands (stays) on that channel
(for two seconds). To transmit on that channel, press the PTT button.
When activity on the landed channel ends, your radio continues
scanning other channels.
To turn the channel scan ON:
1. Press MENU/ two times until appears.
2. Press / to start scanning. Press MENU/ or PTT to turn
OFF Scan mode.
Key Lock
1. Press and hold / until appears to lock the keypad.
2. When in lock mode, you can turn the radio on and off, adjust
the volume, send a call tone, receive, and transmit. All other
functions are locked.
3. Press and hold / , until disappears to unlock the
keypad.
Monitor Mode
Your radio enables you to listen for weak signals on the current
channel.
To turn the Monitor Mode ON:
1. Press MENU/ three times until the Channel Monitor setting
flashes and the appears.
2. Press the / button for continuous listening. The icon
continues to appears.
To turn the Monitor Mode OFF:
1. Press the MENU/ button to return to “Normal” mode. The
icon stops appearing.
Roger Beep
Roger beep sounds to indicate the end of a PTT transmission. It can
be heard through the speaker when Key Beep is on. It cannot be
heard through the speaker if Key Beep is turned off.
Press and hold the button while turning the radio ON to turn the
Roger Beep ON. Repeat the step to turn Roger Beep OFF.
Automatic Power Save
For better battery life, your radio is designed to switch to Power Save
mode when there has been no transmissions after 3 s. The radio can
receive transmissions in this mode.
USA, Canada, Mexico, Panama, Paraguay, Uruguay
MOTOROLA, MOTO, MOTOROLA SOLUTIONS and the Stylized M
logo are trademarks or registered trademarks of Motorola Trademark
Holdings, LLC and are used under license. All other trademarks are
the property of their respective owners.
© 2016 and 2019 Motorola Solutions, Inc. All rights reserved.
Consumer Two-Way Radio Products and Accessories
purchased in the USA, Canada, Mexico, Uruguay,
Panama, and Paraguay
What Does this Warranty Cover?
Subject to the exclusions contained below, Motorola Solutions, Inc.
(“Motorola”) warrants the Motorola Solutions branded consumer
two-way radios that operate through Family Radio Service or General
Mobile Radio Service (“Products”), the Motorola Solutions branded or
certified accessories sold for use with these Products (“Accessories”)
to be free from defects in materials and workmanship under normal
consumer usage for the period(s) outlined below. This limited
warranty is the exclusive remedy of a consumer, and applies as
follows to new Products and Accessories and purchased by
consumers in the United States or Canada, which are accompanied
by this written warranty:
Who is Covered?
This warranty extends only to the first consumer purchaser, and is
not transferable.
What will MOTOROLA SOLUTIONS, INC. do?
Motorola Solutions, Inc., at its option, will at no charge repair, replace
or refund the purchase price of any Products or Accessories that do
not conform to this warranty. We may use functionally equivalent
reconditioned/refurbished/pre-owned or new Products or
Accessories.
What Other Limitations Are There?
Any Implied Warranties, Including Without Limitation
The implied warranties of merchantability and fitness for a particular
purpose, shall be limited to the duration of this limited warranty,
otherwise the repair, replacement, or refund as provided under this
express limited warranty is the exclusive remedy of the consumers,
and is provided in lieu of all other warranties, express or implied. In
no event shall Motorola Solutions be liable, whether in contract or tort
(including negligence) for damages in excess of the purchase price
of the product or accessory, or for any indirect, incidental, special or
consequential damages of any kind, or loss of revenue or profits, loss
of business, loss of information or other financial loss arising out of or
in connection with the ability or inability to use the products or
accessories to the full extent these damages may be disclaimed by
law.
Some states and jurisdictions do not allow the limitation or exclusion
of incidental or consequential damages, or limitation on the length of
an implied warranty, so the above limitations or exclusions may not
apply to you. This warranty gives you specific legal rights, and you
may also have other rights that vary from state to state or from one
jurisdiction to another.
USA and Canada
Latin America
How to Obtain Warranty Service or Other Information?
To obtain customer service or information:
USA and Canada
1-800-448-6686.
www.motorolasolutions.com/talkabout
E-mail us at consumerradio@motorolasolutions.com
Latin America
Toll free:
Mexico 001-855-241-8253
Panama 001-800-507-3589
Uruguay 598 – 24001716
Toll or long distance:
Spanish +001-312-725-5372
English +001-312-725-5368
Paraguay +595 61 548 1000
www.motorolasolutions.com/talkabout/es (Spanish)
Safety and General Information
Warning:
• Refer to vehicle manufacturer's manual prior to
installation of electronic equipment to avoid
interference with air bag wiring.
• DO NOT place a portable radio in the area over
an air bag or in the air bag deployment area.
Air bags inflate with great force. If a portable
radio is placed in the air bag deployment area
and the air bag inflates, the radio may be
propelled with great force and cause serious
injury to occupants of the vehicle.
Warning:
• Use of a radio that is not intrinsically safe in a
potentially explosive atmosphere could result in
a serious injury, or death. You should only use
a certified Intrinsically Safe radio in potentially
explosive atmospheres.
• Explosive atmospheres refer to hazard
classified locations that may contain hazardous
gas, vapors, dusts, such as fueling areas below
decks on boats, fuel, or chemical transferor
storage facilities, and areas where the air
contains chemicals or particles such as grain,
dust, or metal powders. Areas with potentially
explosive atmospheres are often, but not
always, posted.
• Turn off your radio prior to entering any area
with a potentially explosive atmosphere unless
it is a radio type specifically certified for use in
hazardous location areas.
• DO NOT remove, install, or charge batteries in
such areas, or remove or install antennas.
Sparks in a potentially explosive atmosphere
can cause an explosion or fire resulting in
bodily injury or even death.
Warning: To avoid possible interference with blasting
operations, turn off your radio when you are near
electrical blasting caps, in a blasting area, or in areas
posted: “Turn off two-way radio.” Obey all signs and
instructions.
Warning:
Repairs to a Motorola Solutions intrinsically safe radio
product certified by, for example, FM, UL, CSA,
CENELEC, should only be done at a location that has
been audited under the certifying body's repair and
service standard.
Contact Motorola Solutions for assistance regarding
repairs and service of Motorola Solutions intrinsically
safe equipment.
A repair constitutes something done internally to the
unit that would bring it back to its original condition.
Items not considered as repairs are those in which an
action is performed on a unit which does not require
the outer casing of the unit to be opened in a manner
that exposes the internal electrical circuits of the unit.
!
W A R N I N G
!
!
W A R N I N G
!
!
W A R N I N G
!
!
W A R N I N G
!
The European Union's WEEE directive requires that
products sold into EU countries must have the
crossed out trash bin label on the product (or the
package in some cases). As defined by the WEEE
directive, this cross-out trash bin label means that
customers and end-users in EU countries should not
dispose of electronic and electrical equipment or
accessories in household waste. Customers
or end-users in EU countries should contact their
local equipment supplier representative or service
centre for information about the waste collection
system in their country.
Declaration of Conformity
Per FCC CFR 47 Part 2 Section 2.1077(a)
Responsible Party
Name: Motorola Solutions, Inc.
Address: 1303 East Algonquin Road, Schaumburg, IL
60196-1078, U.S.A.
Phone Number: 1-800-927-2744
Hereby declares that the product:
Model Name: T100, T107, T100TP, T100MC,
T107MC, T100TMC
conforms to the following regulations:
FCC Part 15, subpart B, section 15.107(a), 15.107(d),
and section 15.109(a)
Licensing Information
This icon will show when battery is low and will blink
when battery is extremely low. Replace the batteries
immediately.
Control Buttons
Antenna
Volume/
Scroll
Call Tone/ Lock
Speaker
Microphone
Menu/Power
Push-to-Talk Screen
Display Screen Guide
Channel
Battery (2
Battery Levels)
Keypad Lock
Mute Status (transmit/
receive)
Scan
Getting Started
Basic Radio Operations
Channel Frequency Max Power
Output Channel Frequency Max Power
Output
1 462.5625 MHz 2 W 12 467.6625 MHz 0.5 W
2 462.5875 MHz 2 W 13 467.6875 MHz 0.5 W
3 462.6125 MHz 2 W 14 467.7125 MHz 0.5 W
4 462.6375 MHz 2 W 15 462.5500 MHz 2 W
5 462.6625 MHz 2 W 16 462.5750 MHz 2 W
6 462.6875 MHz 2 W 17 462.6000 MHz 2 W
7 462.7125 MHz 2 W 18 462.6250 MHz 2 W
8 467.5625 MHz 0.5 W 19 462.6500 MHz 2 W
9 467.5875 MHz 0.5 W 20 462.6750 MHz 2 W
10 467.6125 MHz 0.5 W 21 462.7000 MHz 2 W
11 467.6375 MHz 0.5 W 22 462.7250 MHz 2 W
Talking and Listening
Channels and Frequencies
Patent and Copyright Information
Warranty
Products Covered Length Of Coverage
Products and Accessories
as defined above, unless
otherwise provided for
below.
Two (2) years from the date of
purchase by the first consumer
purchaser of the product unless
otherwise provided for below.
Products and Accessories
that are repaired or replaced.
The balance of the original
warranty or for ninety (90) days
from the date returned to the
consumer, whichever is longer.
Products Covered Length Of Coverage
Products and Accessories
as defined above, unless
otherwise provided for
below.
One (1) year from the date of
purchase by the first consumer
purchaser of the product unless
otherwise provided for below.
Products and Accessories
that are repaired or replaced.
The balance of the original
warranty or for ninety (90) days
from the date returned to the
consumer, whichever is longer.
Exclusions From Warranty Coverage
Normal Wear and Tear:
Periodic maintenance, repair, and replacement of products or
accessories due to normal wear and tear.
Abuse and Misuse:
Defects or damage that result from: (a) improper operation, storage,
misuse or abuse, accident, or neglect, such as physical damage
(cracks, scratches, etc.) to the surface of the Products and
Accessories resulting from misuse; (b) contact with liquid, water,
rain, extreme humidity or heavy perspiration, sand, dirt, or the like,
extreme heat, or food; (c) use of the Products or Accessories for
commercial purposes or subjecting the Product or Accessory to
abnormal usage or conditions; or (d) other acts which are not the
fault of Motorola Solutions.
Use of Non-Motorola Solutions branded Products and
Accessories:
Defects or damage that result from the use of Non-Motorola
Solutions branded or certified products, accessories, software, or
other peripheral equipment.
Unauthorized Service or Modification:
Defects or damages resulting from service, testing, adjustment,
installation, maintenance, alteration, or modification in any way by
someone other than Motorola Solutions, or its authorized service
centers.
Altered Products:
Products or Accessories with (a) serial numbers or date tags that
have been removed, altered, or obliterated; (b) broken seals or that
show evidence of tampering; (c) mismatched board serial numbers;
or (d) non-conforming or non-Motorola Solutions branded housings,
or parts.
Communication Services:
Defects, damages, or the failure of Products or Accessories due to
any communication service or signal you may subscribe to or use
with the Products or Accessories.
22 6
4
23 5
For Accessories:
Please call the telephone number designated above for the Product
with which they are used.
You will receive instructions on how to ship the Products or
Accessories at your expense, to Motorola Solutions or a Motorola
Solutions Authorized Repair Center. To obtain service, you must
include: (a) a copy of your receipt, bill of sale or other comparable
proof of purchase; (b) a written description of the problem; (c) the
name of your service provider, if applicable; (d) the name and
location of the installation facility (if applicable) and, most importantly;
(e) your address and telephone number.
For more information, please visit us at:
https://www.facebook.com/
MotorolaTalkaboutWalkieTalkies
http://bit.ly/Talkabout
www.motorolasolutions.com/talkabout
www.motorolasolutions.com/talkabout/es
(Spanish)
