Motorola’s STARLINE® series line extender, model BLE87*/*, leads the

industry in features and performance and is designed to meet the needs of

today's expanding broadband communication networks. This two-way

capable single output amplifier offers high gain, high output levels,

ergonomics, superior distortion performance, four diplex filter options, 16

dB return loss, and Bode equalization. The BLE87*/* also allows optional

advanced features such as ingress control switching and status monitoring.

ENHANCED GALLIUM ARSENIDE

Enhanced Gallium Arsenide (E-GaAs) hybrids are standard in the STARLINE BLE87. This second generation

technology provides superior distortion performance in CTB and CSO over the standard GaAs technology. Compared to

silicon and competing GaAs technology, E-GaAs distortion performance remains linear at significantly higher output

levels. This higher output level allows the customer to maximize system performance and reduce system costs. We

encourage our customers to contact their Motorola Account Representative to determine the optimal levels for their

systems.

HIGH GAIN

The BLE87 also offers high gain. This allows the operator to hold existing amplifier locations during system upgrades

thereby reducing system costs.

The BLE87 two-way line

extender offers 870 MHz

bandwidth capability,

high gain, high output

level, ergonomics, and

superior distortion

performance.

BLE87 870 MHz Line Extender

STARLINE Series

BENEFITS INCLUDE:

• 870 MHz Enhanced Gallium Arsenide (E-GaAs) power

doubling technology

• High gain

• High output level

• Four diplex filter options

• Ease-of-use ergonomics

• 16 dB return loss

• 60/90 V powering

• Meets Telcordia GR-1098-Core voltage surge

requirements using surge waveforms as described in

IEEE C62.41

• FCC, CENELEC and CCC approved

• Bode equalization (thermal or auto controlled)

• 15 ampere AC capability

• Optional return path ingress control and status

monitor

• Directional coupler –20 dB test points

Motorola, Inc.

Connected Home Solutions

101 Tournament Drive

Horsham, PA 19044

1.800.523.6678

www.motorola.com/broadband

Rev. 1.0

09.01.05

MOTOROLA and the Stylized M Logo are registered in the US Patent & Trademark Office.

All other product or service names are the property of their respective owners.

© Motorola, Inc. 2003

Specifications are subject to change without notice.

2

BACKWARD COMPATIBILITY

The reversible BLE87 electronics package can be made backward compatible with the STARLINE JLX and 10-Amp BLE

housing by installing the BLE-15A Kit. This kit contains 50 mil gold plated platform assemblies. This makes it possible for

the amplifier to carry 15 Amperes continuous through the input or output ports.

If an “electronics only” package is ordered, it will include the deeper housing cover to accommodate ergonomic

accessories. Note: this is not the deeper housing cover associated with the status monitor. When ordering the status

monitor option, a deep housing cover is also required.

FORWARD PATH

The operational gain of the BLE87 is 28 dB or 32 dB depending on model, with 16 dB return loss. Output level control is

achieved through the use of an interstage Bode equalizer, which compensates for coaxial cable attenuation changes due

to temperature. Equalization may be controlled manually, with a thermal drive unit (model TDU) or with a single pilot

closed loop automatic drive unit (model ADU-* or QADU). Both the TDU and the ADU boards are common to the

STARLINE family of amplifiers (with the exception of the SLE). ADUs utilize Surface Acoustic Wave (SAW) filters for

determining pilot frequency. This improves amplifier stability over temperature.

To further ensure system flexibility, installation ease and maintenance, the amplifier is engineered for compatibility with

standard accessories, such as attenuators, equalizers, ADUs or TDUs, return amplifiers, automotive fuses and FTEC-

BTA crowbar circuits.

The BLE87 uses modular diplex filters which can be changed for a different frequency split as required. The amplifier can

be configured with S-split filters for a 5-40 MHz return and a 52-870 MHz forward band. K-splits (5-42 MHz/54-870

MHz), J-splits (5-55 MHz/70-870 MHz), and A-splits (5-65 MHz/85-870 MHz) are also available. These same filters can

be used for all current US-style Motorola RF distribution amplifiers (models BLE, MB/MBE, BT).

RETURN PATH

Return amplifier kits can be ordered with either high gain or low gain hybrids providing 24 dB and 19 dB minimum station

gain, respectively. Return path equalizers from 0 to 12 dB can be customer selected. Optional features include thermal

compensation and ingress control switching. Thermal compensation comes in the form of a plug-in JXP-TH*C, which

stabilizes gain and match over temperature extremes.

Also available is Ingress Control Switching (ICS) in 3 states. This pin diode attenuator circuit can lower levels by 6 dB or

by 38 dB with a controlled slew rate for minimum bit errors. The LIFELINE® Broadband Line Extender transponder,

model LL-BLE-HMS-*/*, and accompanying deeper housing lid are required to operate the Ingress Control Switch from a

remote location.

MODEL AVAILABILITY

To reduce customer costs and to accommodate customer specific needs, the STARLINE BLE87 can be ordered in a

variety of different models. Please refer to the BLE87 ordering information below for options.

Motorola, Inc.

Connected Home Solutions

101 Tournament Drive

Horsham, PA 19044

1.800.523.6678

www.motorola.com/broadband

Rev. 1.0

09.01.05

MOTOROLA and the Stylized M Logo are registered in the US Patent & Trademark Office.

All other product or service names are the property of their respective owners.

© Motorola, Inc. 2003

Specifications are subject to change without notice.

3

STARLINE® Single Output Line Extender

Enhanced Gallium Arsenide BLE87S/H* SPECIFICATIONS

Broadband Line Extender RETURN

PARAMETER UNITS NOTE FORWARD RA-KIT/L

Passband MHz 1 5 - 40

Flatness dB 2 ± 0.50

Minimum Full Gain dB 3 NA

Operational Gain dB 4 19

Manual Bode Slope Control Range dB 5 NA

Interstage Equalizer Slope dB 6 NA

Noise Figure 40 / 52 / 870 MHz dB 7 6 / NA / NA

Reference Frequency MHz 8 40

Output Level dBmV 41 Flat

Channel Loading NTSC 4

Compressed data loading MHz 22 NA

Distortion CTB dBc 9,21,23 NA

XM dBc 10,21 74

CSO dBc 9,11,21 NA

CCN (-6) dBc 12 NA

STB dBc 9 82

SSO dBc 9 77

Test Point (all) dB 13 20 ± 0.5

Return Loss dB 14

Hum Modulation dBc 15,20 60

DC Voltage VDC 16

Current DC mA 17 925

DC Ripple mV

Power Consumption W 26.6

AC Input Voltage Range VAC

AC Current Draw @90 VAC A 18 0.56

@75 VAC A 0.59

@60 VAC A 0.65

@53 VAC A 0.70

@45 VAC A 0.78

@38 VAC A 0.88

AC Bypass Current A 18

Group Delay 19

55.25 to 58.83 MHz nSec NA

5.0 to 6.5 MHz nSec 45

10.0 to 11.5 MHz nSec 10

33.5 to 35.0 MHz nSec 12

38.5 to 40.0 MHz nSec 35

Housing Dimensions 10.6" L x 8.0" W x 4.7" D 26.9cm x 20.3cm x 11.9 cm

Weight 7.2 Pounds 3.2 kg

Ambient Operating Temperature -40° to +140° F -40° to +60° C

NA

15

38 - 90

NA

NA

NA

28

0.56

0.60

0.67

0.75

22.6

0.48

0.50

65

800

15 P-P

+ 24.0 ± 0.25

NA

NA

20 ± 0.7

16

74

63

74

58 (50 dBmV at 550 MHz)

870 / 550 / 52

43 / 44 / 37

79

320

32

± 4.0

8 ± 1

NA / 9 / 9

52-870

± 0.70

36

BLE87 Specifications

Motorola, Inc.

Connected Home Solutions

101 Tournament Drive

Horsham, PA 19044

1.800.523.6678

www.motorola.com/broadband

Rev. 1.0

09.01.05

MOTOROLA and the Stylized M Logo are registered in the US Patent & Trademark Office.

All other product or service names are the property of their respective owners.

© Motorola, Inc. 2003

Specifications are subject to change without notice.

4

STARLINE®

Enhanced Gallium Arsenide BLE87S/G* SPECIFICATIONS

Broadband Line Extender RETURN

PARAMETER UNITS NOTE FORWARD RA-KIT/L

Passband MHz 1 5 - 40

Flatness dB 2 ± 0.50

Minimum Full Gain dB 3 NA

Operational Gain dB 4 19

Manual Bode Slope Control Range dB 5 NA

Interstage Equalizer Slope dB 6 NA

Noise Figure 40 / 52 / 870 MHz dB 7 6 / NA / NA

Reference Frequency MHz 8 40

Output Level dBmV 41 Flat

Channel Loading NTSC 4

Compressed data loading MHz 22 NA

Distortion CTB dBc 9,21,23 NA

XM dBc 10,21 74

CSO dBc 9,11,21 NA

CCN (-6) dBc 12 NA

STB dBc 9 82

SSO dBc 9 77

Test Point (all) dB 13 20 ± 0.5

Return Loss dB 14

Hum Modulation dBc 15,20 60

DC Voltage VDC 16

Current DC mA 17 925

DC Ripple mV

Power Consumption W 26.6

AC Input Voltage Range VAC

AC Current Draw @90 VAC A 18 0.56

@75 VAC A 0.59

@60 VAC A 0.65

@53 VAC A 0.70

@45 VAC A 0.78

@38 VAC A 0.88

AC Bypass Current A 18

Group Delay 19

55.25 to 58.83 MHz nSec NA

5.0 to 6.5 MHz nSec 45

10.0 to 11.5 MHz nSec 10

33.5 to 35.0 MHz nSec 12

38.5 to 40.0 MHz nSec 35

Housing Dimensions 10.6" L x 8.0" W x 4.7" D 26.9cm x 20.3cm x 11.9 cm

Weight 7.2 Pounds 3.2 kg

Ambient Operating Temperature -40° to +140° F -40° to +60° C

NA

15

38 - 90

NA

NA

NA

28

0.56

0.60

0.67

0.75

22.6

0.48

0.50

65

800

15 P-P

+ 24.0 ± 0.25

NA

NA

20 ± 0.7

16

74

63

74

58 (50 dBmV at 550 MHz)

870 / 550 / 52

43 / 44 / 37

79

200

28

± 4.0

8 ± 1

NA / 9 / 9

Single Output Line Extender

52-870

± 0.70

32

Motorola, Inc.

Connected Home Solutions

101 Tournament Drive

Horsham, PA 19044

1.800.523.6678

www.motorola.com/broadband

Rev. 1.0

09.01.05

MOTOROLA and the Stylized M Logo are registered in the US Patent & Trademark Office.

All other product or service names are the property of their respective owners.

© Motorola, Inc. 2003

Specifications are subject to change without notice.

5

Notes:

1. Operating passband of station. Diplex filters are plugged into the electronic chassis.

2. Referenced to the average gain across the stated passband.

3. Minimum full gain at 870 MHz includes loss of equalizer but Bode slope reserves have not been set. Return gain includes loss of SRE-*-4 return

equalizer.

4. Operational gain includes loss of slope reserves as well as equalizer.

5. Amount of Bode slope control range from midpoint (typical setting is -4 dB at 870 MHz @ 20°C). This control should not be used for gain

reduction.

6. Amount of slope created and cable equivalence of fixed interstage equalizer. Interstage equalizer is a plug-in.

7. Noise Figure performance is specified typical. Noise Figure is specified at the cable entry facility of the housing and includes the loss of 1 dB for

the pre-stage equalizer. The return Noise Figure includes the station loss preceding the RF hybrid.

8. Frequencies that relate the picture carriers or passband edges to the specified output levels and tilts.

9. Measured with CW carriers and spectrum analyzer over specified temperature range. References the worst-case channel. Specifications are

compliant with the test methods as stated in NCTA RECOMMENDED PRACTICES FOR MEASUREMENTS ON CABLE TELEVISION

SYSTEMS.

10. Measured with wave analyzer and synchronous, 100% depth modulated channels. References the worst-case channels over specified

temperature range. Specifications are compliant with the test methods as stated in NCTA RECOMMENDED PRACTICES FOR

MEASUREMENTS ON CABLE TELEVISION SYSTEMS.

11. Composite Second Order distortion refers only to those beat clusters that fall +0.75 MHz and +1.25 MHz above the subject picture carrier. CSO

beat clusters that have a -0.75 MHz and -1.25 MHz relationship to the subject picture carrier are not included in this specification.

12. CCN (Composite, Carrier-to-Noise Ratio) is a 10 log addition of both the Carrier-to-Noise Ratio (CNR) and Carrier-to-Intermodulation Noise Ratio

(CIN).

13. Test points should be used with GFAL adaptor.

14. Match measurement at the station input and output, cable-entry facilities, at the specified passbands for operational gain.

15. Measured with the stated AC Bypass Current.

16. Measured at the power connector.

17. Current draw at +24.0 VDC.

18. AC current is stated in RMS continuous.

19. Group Delay is specified for standard NTSC video, where delay is the delta from picture carrier to 3.58 MHz color subcarrier. Reverse delay is in

a 1.5 MHz bandwidth.

20. Hum Modulation performance is stated typical. Return band specified from 15 MHz. Hum Modulation (5 MHz to 15 MHz) is –55 dBc.

21. Distortion numbers are worst case over temperature in a cascade.

22. The compressed data loading is QAM carriers and are –6 dB relative to the analog CW carriers.

23. CTB (Composite Triple Beat). At the specified channel loading, Enhanced Gallium Arsenide performance varies on a two point three-for-one

(2.3:1) basis with amplifier output level.

Motorola, Inc.

Connected Home Solutions

101 Tournament Drive

Horsham, PA 19044

1.800.523.6678

www.motorola.com/broadband

Rev. 1.0

09.01.05

MOTOROLA and the Stylized M Logo are registered in the US Patent & Trademark Office.

All other product or service names are the property of their respective owners.

© Motorola, Inc. 2003

Specifications are subject to change without notice.

6

Input

port

Output

port

**

**

** ** ** ****

H

L

SFE JXP-B

**

SRE

-16 dB

JXP-B

LPF

BODERCB

**

Therm

PP PD

TP

-20 dB

TP

-20 dB

** **

**

**

ICS JXP

JXP-B

**

Manual

**

LDR

H

L

Auto

TP

-20 dB

24 Vdc

DC test point

Power

supply

Fuse

Power

Block

Jumper

** Plug-in module

FTEC

Surge

protector

Surge

protector

**

Status

monitor

ADU/

TDU

SCS

-1.0dB

-1.0dB

-1.0dB

24dB -6.5dB

-1.0dB

-1.0dB

-1.0dB

-0.5dB

+25.0dB L

+30.0dB H -0.3dB

-0.4dB

-0.4dB

-0.4dB

-1.0dB

~0.0dB with

jumper

RF

RF/

AC

AC

-1.7 dB F

-1.0 dB R

RF/

AC

AC

RF

-1.7 dB F

-1.0 dB R

Std Gain E-GaAs: 18dB

High Gain E-GaAs: 23dB

TP

Return

injection point

-20 dB

OnBrd

Atten

BLE87 Block Diagram

Motorola, Inc.

Connected Home Solutions

101 Tournament Drive

Horsham, PA 19044

1.800.523.6678

www.motorola.com/broadband

Rev. 1.0

09.01.05

MOTOROLA and the Stylized M Logo are registered in the US Patent & Trademark Office.

All other product or service names are the property of their respective owners.

© Motorola, Inc. 2003

Specifications are subject to change without notice.

7

Model Description Motorola

Part Number

Qty

per BLE

STANDARD BLE MODELS

S-SPLIT

BLE87S/HXX-LXX-XXX-XC-XXX-XXX-E

5-40 / 52-870 MHz split, one-output, 32 dB high gain forward, E-GaAs, manual

gain control, 8 dB internal slope, low gain return, 20A fuses, FTEC, full station 478000-213-00

BLE87S/HAX-LXX-XXX-XC-XXX-XXX-E

5-40 / 52-870 MHz split, one-output, 32 dB high gain forward, E-GaAs, ADU

499.25 MHz gain control, 8 dB internal slope, low gain return, 20A fuses, FTEC,

full station 478000-212-00

BLE87S/HTX-LXX-XXX-XC-XXX-XXX-E

5-40 / 52-870 MHz split, one-output, 32 dB high gain forward, E-GaAs, TDU gain

control, 8 dB internal slope, low gain return, 20A fuses, FTEC, full station 478000-211-00

BLE87S/HXX-HXX-XXX-XC-XXX-XXX-E

5-40 / 52-870 MHz split, one-output, 32 dB high gain forward, E-GaAs, manual

gain control, 8 dB internal slope, high gain return, 20A fuses, FTEC, full station 478000-274-00

BLE87S/GXX-LXX-XXX-XC-XXX-XXX-E

5-40 / 52-870 MHz split, one-output, 28 dB standard gain forward, E-GaAs,

manual gain control, 8 dB internal slope, low gain return, 20A fuses, FTEC, full

station 478000-053-00

BLE87S/GAX-LXX-XXX-XC-XXX-XXX-E

5-40 / 52-870 MHz split, one-output, 28 dB standard gain forward, E-GaAs, ADU

499.25 MHz gain control, 8 dB internal slope, low gain return, 20A fuses, FTEC,

full station 478000-052-00

BLE87S/GTX-LXX-XXX-XC-XXX-XXX-E

5-40 / 52-870 MHz split, one-output, 28 dB standard gain forward, E-GaAs, TDU

gain control, 8 dB internal slope, low gain return, 20A fuses, FTEC, full station 478000-051-00

BLE87S/HXX-LXX-XXX-XX-XXX-XXX-E

5-40 / 52-870 MHz split, one-output, 32 dB high gain forward, E-GaAs, manual

gain control, 8 dB internal slope, low gain return, 20A fuses, standard surge

arrestor, full station 478000-256-00

K-SPLIT

BLE87K/HXX-HXX-XXX-XC-XXX-XXX-E

5-42 / 54-870 MHz split, one-output, 32 dB high gain forward, E-GaAs, manual

gain control, 8 dB internal slope, high gain return, 20A fuses, FTEC, full station 478000-305-00

BLE87K/HXX-HXX-XXX-XX-XXX-XXX-E

5-42 / 54-870 MHz split, one-output, 32 dB high gain forward, E-GaAs, manual

gain control, 8 dB internal slope, high gain return, 20A fuses, standard surge

arrestor, full station 478000-234-00

BLE87K/HAX-HXX-XXX-XX-XXX-XXX-E

5-42 / 54-870 MHz split, one-output, 32 dB high gain forward, E-GaAs, ADU

499.25 MHz gain control, 8 dB internal slope, high gain return, 20A fuses,

standard surge arrestor, full station 478000-263-00

BLE87K/HTX-HXX-XXX-XX-XXX-XXX-E

5-42 / 54-870 MHz split, one-output, 32 dB high gain forward, E-GaAs, TDU gain

control, 8 dB internal slope, high gain return, 20A fuses, standard surge arrestor,

full station 478000-301-00

BLE87K/GXX-HXX-XXX-XC-XXX-XXX-E

5-42 / 54-870 MHz split, one-output, 28 dB standard gain forward, E-GaAs,

manual gain control, 8 dB internal slope, high gain return, 20A fuses, FTEC, full

station 478000-306-00

BLE87K/GXX-LXX-XXX-XC-XXX-XXX-E

5-42 / 54-870 MHz split, one-output, 28 dB standard gain forward, E-GaAs,

manual gain control, 8 dB internal slope, low gain return, 20A fuses, FTEC, full

station 478000-080-00

A-SPLIT

BLE87A/HXH-LXX-XXX-XX-XXX-XXX-E

5-65 / 85-870 MHz split, one-output, 32 dB high gain forward, E-GaAs, manual

gain control, 12 dB internal slope, low gain return, 20A fuses, standard surge

arrestor, full station 478000-176-00

BLE87A/HXX-HXX-XXX-XX-XXX-XXX-E

5-65 / 85-870 MHz split, one-output, 32 dB high gain forward, E-GaAs, manual

gain control, 8 dB internal slope, high gain return, 20A fuses, standard surge

arrestor, full station 478000-205-00

BLE87A/GXX-LXX-XXX-XX-XXX-XXX-E

5-65 / 85-870 MHz split, one-output, 28 dB standard gain forward, E-GaAs,

manual gain control, 8 dB internal slope, low gain return, 20A fuses, standard

surge arrestor, full station 478000-149-00

J-SPLIT

BLE87J/HTX-LXX-XXX-XC-XXX-XXX-E

5-55 / 70-870 MHz split, one-output, 32 dB high gain forward, E-GaAs, TDU gain

control, 8 dB internal slope, low gain return, 20A fuses, FTEC, full station 478000-321-00

BLE87 Ordering Information

Motorola, Inc.

Connected Home Solutions

101 Tournament Drive

Horsham, PA 19044

1.800.523.6678

www.motorola.com/broadband

Rev. 1.0

09.01.05

MOTOROLA and the Stylized M Logo are registered in the US Patent & Trademark Office.

All other product or service names are the property of their respective owners.

© Motorola, Inc. 2003

Specifications are subject to change without notice.

8

NON-STANDARD BLE MODELS

BLE87S/GXX-LXX-XXX-XX-DXX-XXX-E

5-40 / 52-870 MHz split, one-output, 28 dB standard gain forward, E-GaAs,

manual gain control, 8 dB internal slope, low gain return, 20A fuses, standard

surge arrestor, full station w/ deep lid for status monitor 478000-079-00

BLE87S/HXX-LXX-XXX-XX-NXX-XXX-E

5-40 / 52-870 MHz split, one-output, 32 dB high gain forward, E-GaAs, manual

gain control, 8 dB internal slope, low gain return, 20A fuses, standard surge

arrestor, 15 A electronics module only (no housing) 478000-308-00

BLE75S/HXX-LXX-XXX-XC-XXX-XXX-E

5-40 / 52-750 MHz split, one-output, 32 dB high gain forward, E-GaAs, manual

gain control, 8 dB internal slope, low gain return, 20A fuses, FTEC, full station 478000-291-00

BLE87K/HXX-HXX-XXX-XX-NXX-XXX-E

5-42 / 54-870 MHz split, one-output, 32 dB high gain forward, E-GaAs, manual

gain control, 8 dB internal slope, high gain return, 20A fuses, standard surge

arrestor, 15 A electronics module only (no housing) 478000-318-00

BLE87J/HXX-XXX-XXX-XX-XXX-XXX-E

5-55 / 70-870 MHz split, one-output, 32 dB high gain forward, E-GaAs, manual

gain control, 8 dB internal slope, no return, 20A fuses, standard surge arrestor,

full station 478000-284-00

Accessories

SFE-0

or SFE-1

or SFE-87-*

or SFE-75-*

or SCS-*

Starline Forward Equalizer, 5 – 1 GHz, 0 dB

Starline Forward Equalizer, 5 – 1 GHz, 1 dB

Starline Forward 870 MHz equalizer (values 0 to 22 dB in 1 dB steps)

Starline Forward 750 MHz equalizer (values 0 to 22 dB in 1 dB steps)

Starline Cable Simulators

479309-001-00

479309-002-00

477725-*

477822-*

477888-*

1

SRE-*-* Starline Return Equalizer, 5-40 MHz (S-split), 5-42 (K-split), 5-55 (J-split), 5-65

(A-split), values 0-12 dB in 1 dB steps for S-split (2 dB steps for all other

frequency splits)

478176-* 1

JXP-*B Plug-in attenuator/pad (values 0 to 26 dB, in 1 dB steps)

474011-* 6

Key

X

Key N

H

G

Key

* Other ADU values available for separate purchase, see accessory list for details X

Key

XKey

TX

AKey

X

BLE -

X

-

X

X

-

X

X

X

-

X

-

X

X

-

X

X

X

-E

Key

87S Key

87K Key X

87A H

87J L Key

X

Key C

X

** Other slope values may be created by

varying the forward input equalizer value

MOTOROLA Standard Broadband Line Extender Model Guide/Description

Return Gain

5 - 40 MHz / 52 - 870 MHz

5 - 42 MHz / 54 - 870 MHz

Bandpass Split

Reserved

Reserved

ADU - 499.25/S

TDU

Standard (Full Station)

Housing

Standard (15 Amp)

AC Current Capability

No Housing (electronics only - 15 Amp)Hybrid Technology/Gain

Reserved

Reserved

8 dB (Fmin - 870 MHz)

Station Slope **

High (24 dB)

Low (19 dB)

Level Control *

None

FTEC (Fast Transfer Electronic Crowbar)

E-GaAs (High Output / High Gain = 32 dB)

Gas Tube Surge Arrestor

Voltage Surge Protection

5 - 65 MHz / 85 - 870 MHz

5 - 55 MHz / 70 - 870 MHz

E-GaAs (High Output / Standard Gain = 28 dB)

Ergonomics

Ergonomics

Motorola, Inc.

Connected Home Solutions

101 Tournament Drive

Horsham, PA 19044

1.800.523.6678

www.motorola.com/broadband

Rev. 1.0

09.01.05

MOTOROLA and the Stylized M Logo are registered in the US Patent & Trademark Office.

All other product or service names are the property of their respective owners.

© Motorola, Inc. 2003

Specifications are subject to change without notice.

9

Model P/N Description

ADU-* 928129-* Automatic drive unit

ADU-499.25/S 928129-017 Automatic drive unit - pilot at 499.25 MHz (uses SAW filter)

ADU-439.25/S 928129-018 Automatic drive unit - pilot at 439.25 MHz (uses SAW filter)

ADU-403.25/S 928129-019 Automatic drive unit - pilot at 403.25 MHz (uses SAW filter)

ADU-445.25/S 928129-020 Automatic drive unit - pilot at 445.25 MHz (uses SAW filter)

ADU-549.00/S 928129-010 Automatic drive unit - pilot at 549.00 MHz (uses SAW filter)

ADU-423.25 928129-023 Automatic drive unit - pilot at 423.25 MHz

ADU-498.00 928129-009 Automatic drive unit - pilot at 498.00 MHz

QADU-609.00/S 928129-026 QAM Automatic drive unit - QAM pilot at 609 MHz (uses SAW filter)

BLE 15 Amp Kit 951941-006 For line extender upgrades to 15A

BLE-HSG/15 484104-001 BLE housing

BLE-LID/SM 928197-001 BLE deep lid for status monitor

BLE-CVR/E 513932-001 BLE ergonomic lid

BLE-RCB87 484145-001 Response correction board for ergonomic BLE

F/JXP-20 927714-001 Test probe

FTEC/BTA 928103-000 Fast transfer electronic crowbar surge protector (230V)

Fuses 928303-tab Automotive style fuses

Shunts 928303-000 35A automotive style fuses

GFAL 927709-000 Test probe

ICS-II 454056-002 Ingress control switch for amplifiers

JXP-75T 927265-075 75 ohm terminator (short profile)

JXP-RC 927703-002 Forward path (full band) correction board

JXP-RPC 927703-003 Return path correction board (mid-band)

JXP-TH2C 479310-007 2 dB plug-in thermal pad used in return path (two-tier ergonomic)

JXP-TH3C 479310-008 3 dB plug-in thermal pad used in return path (two-tier ergonomic)

RA-KIT/H 927810-007 Return path kit (high gain)

RA-KIT/L 927810-006 Return path kit (low gain)

TDU 928119-000 Thermal drive unit

SHP 815 447983-001 Return high pass filter (15 - 65 MHz)

SHP 815-II 447983-003 Return high pass filter (15 - 65 MHz) - smaller design

SHP 825 447983-002 Return high pass filter (25 - 65 MHz) - smaller design

SZW 852 516299-001 Diplex filter, 40/52 MHz S-split

SZW 854 478005-001 Diplex filter, 42/54 MHz K-split

SZW 885 440168-001 Diplex filter, 65/85 MHz A-split

SZW 870 516301-001 Diplex filter, 55/70 MHz J-split

SZW 847 447280-001 Diplex filter, 30/47 MHz E-split

Other Accessories for BLE87
