CDM1550 •LS

CDM1550 •LS+

Professional Series

Two-Way Radios and Accessories

VHF

UHF

200 MHz

700 MHz

TAKING TWO-WAY COMMUNICATION FARTHER

THAN EVER.

Motorola Two-Way Radios: The Choice

of Professionals

Success in today’s constantly changing marketplace depends

on knowing – and making – the right moves. To stay on

top, you have to continually expand your horizons, always

keeping one step ahead of your competition. You also need

communication tools that deliver immediate, reliable

access to the people and information you need to get the

job done. And that’s exactly what two-way radio gives you.

At the touch of a button, two-way radio lets you talk with

one, ten, or more people instantly – providing the individual

and team communication you need to maximize productivity

and meet your customers’ demands. And when you choose a

Motorola radio, you know you’re getting a product designed

to meet your requirements as a professional.

The Intelligent Radio – So Advanced, It

Practically Thinks for You

High-performing features combined with versatile trunking

capabilities make the CDM1550•LS and CDM1550•LS+

two-way radios the smart choice to keep mobile work teams

performing at their best. The CDM1550•LS and CDM1550•LS+

radios incorporate LTR®trunking capabilities – offering you

wider calling range, faster channel access, greater privacy,

and higher user and talkgroup capacity. The CDM1550•LS+

also offers innovative PassPort®trunking. Ideal for users

with growing communication needs, PassPort includes all

the advantages of LTR trunking plus:

• Wider Area Coverage, Seamless Roaming – Automatic

switching between networked PassPort sites lets you

maintain constant communication over long distances

without touching a button

• Exceptional Audio Quality – Received Signal Strength

Indicator (RSSI) communication technology utilizes the

strongest signal available, giving you optimal sound quality

• Superior System Access – Automatic site registration/

deregistration can reduce busy channels and enhance

system efficiency

• Efficient Channel Expansion – Direct frequency assignment

allows you to add channels and sites over the air without

taking radios out of service

• Electronic Serial Number Protection – Helps keep system

resources available by preventing unauthorized radio cloning

CDM1550•LS

with LTR®Trunking

CDM1550•LS and CDM1550•LS+Radio Features

15 PassPort and/or LTR Zones (16 talkgroups each)*

16 or 160 Conventional Channels*

RSSI Indicator

Displays signal strength level

Large Control Buttons

Easy management of menu, navigation, and exit functions

Conventional Talkaround

Unit-to-unit communications, bypassing the repeater

Home Channel Revert

Automatic, one-button return to a preferred talkgroup or channel

User-Defined Lists

Change scan, phone, and call lists on the fly

Voice Storage

Record important messages or personal memos

Telephone Interconnect

Place and receive phone calls with the radio

MDC1200 Signaling (Encode/Decode) Features on Conventional

and LTR Zones*

• Caller ID – Identifies incoming callers

• Selective Call – Lets you call a specific group or individual

• Call Alert – Notifies individual users that you’re trying to reach them

• Radio Check – Tells you whether another user’s radio is activated

• Message – Allows you to send and receive pre-programmed messages

Quick Call IITM on Conventional Zones*

Send and receive information via tone or digital signals

Roam Request*

Optional manual initiation of roaming function

Horn and Lights Activation

Notifies you of calls when you’re away from your vehicle

Additional CDM1550•LS and CDM1550•LS+Mobile Features

• 12.5/25 kHz switchable channel spacing*

• Remote mountable control head

• Data capable

• Operates on LTR or LTR and PassPort systems*

* Only available on certain models. Check with your

Motorola Authorized Dealer for availability.

Motorola – A Name You Know and Trust

For more than 65 years, Motorola has been an undisputed

leader in creating state-of-the-art wireless communications for

people like you. The CDM1550•LS and the CDM1550•LS+

mobiles uphold that superior standard. What’s more, each

radio is backed by a limited two-year* warranty on parts

and labor. So when you select the CDM1550•LS or the

CDM1550•LS+mobile, you’ll experience the same exceptional

quality you’ve come to expect from all Motorola products.

*Radio accessories are covered by Motorola’s one-year accessories warranty.

CDM1550•LS+

Exceptional Functionality and Convenience

The CDM1550•LS and the CDM1550•LS+mobiles utilize

the latest in two-way technology to deliver extraordinary

performance and ease-of-use, including:

• Compact, Ergonomic Design to give you optimal mounting

flexibility and durability

• 14-Character Alphanumeric Display with User-Friendly Icons

to help make the radio’s information easy to understand

• Convenient Menu Navigation so you can program scan,

phone, and call lists in virtually no time

• Four Programmable Buttons that you can customize and

label for quick access to your favorite features

• Selectable Scanning Capabilities that allow you to define

the transmissions your radio monitors

• Motorola’s Unique X-Pand™Audio Enhancement combined

with a powerful front-projecting speaker can help reduce

background noise and improve sound quality

The CDM1550•LS+mobile can also be programmed with both

LTR and PassPort trunking systems – allowing a smooth

transition when your business requires a more extensive

calling area for maximum communication efficiency. The radio

operates on 16 conventional channels as well.

Motorola Original™accessories provide an easy way to turn your CDM1550•LS or CDM1550•LS+ mobile radio into a custom

communication solution to fit your business requirements—maximizing on-the-job productivity and efficiency for mobile

work teams and individuals.

CDM1550•LS

CDM1550•LS+

Radio Accessories

Talk However You Want

Enhanced Keypad Microphone—

AARMN4026

You can dial phone numbers on this microphone’s

full keypad, or customize its three programmable

buttons with any control head features.

Visor Microphone—AARMN4027

Attach this microphone to your visor or hat for

hands-free operation of your radio (must be used

with an external PTT).

Push Button Push-to-Talk—RLN4857

Simply depress the button to talk with other users.

Foot Switch Push-to-Talk—RLN4856

A handy foot switch provides hands-free

PTT functionality.

Gooseneck Mount

Push-to-Talk—RLN4858

This PTT mounts conveniently on your steering wheel

column for control that’s right at your fingertips.

Telephone Style Handset—AAREX4617

Conduct private conversations on your radio quietly

and discreetly.

Get Your Message Across

13-Watt Speaker—RSN4001

Powerful sound control allows you to increase

your radio’s volume output when working in

noisy environments.

Take It With You

High-Profile Mount—GLN7317

Offers a space-saving option for vehicles where

every inch counts.

Key Lock Mount—RLN4779

Securely mounts and locks radio in your vehicle

to protect against theft.

Power It Up

1-25 Watt Power Supply—HPN4002

For use with low power radios. Provides power

for using mobile radio on a desktop.

25-60 Watt Power Supply—HPN4001

For use with low power radios. Provides power

for using mobile radio on a desktop.

Enhance Your Calling Range

200 MHz Wave Roof Mount

Antenna— HKAD4001

Mini U 746-794 MHz Wave Rod

Antenna—HAF4012

450-476 MHz 1/4 Wave Roof Mount

Antenna—HAE4003

For more information, please contact:

MOTOROLA and the Stylized M Logo are registered in the US Patent and Trademark Office. All other product or service

names are the property of their respective owners.

© Motorola, Inc. 2002.

www.motorola.com/cgiss

MD-CDM1550LS-03

CDM1550•LS and CDM1550•LS+Radio Specifications

ENVIRONMENTAL SPECIFICATIONS

Operating Temperature -30 to +60°C

Storage Temperature -55 to +85°C

Thermal Shock -40 to +85°C

Humidity 95% RH @ 8 Hr.

ESD IEC 801-2 KV

Water Intrusion IPX4

Packing Test Impact Test

MOBILE MILITARY STANDARDS 810 C, D, & E

Applicable MIL-STD 810C 810D 810E

Methods Procedures Methods Procedures Methods Procedures

Low Pressure 500.1 1 500.2 2 500.3 2

High Temperature 501.1 1,2 501.2 1,2 501.3 1,2

Low Temperature 502.1 2 502.2 1,2 502.3 1,2

Temperature Shock 503.1 1 503.2 1 503.3 1

Solar Radiation 505.1 1 505.2 1 505.3 1

Rain 506.1 2 506.2 2 506.3 2

Humidity 507.1 2 507.2 2,3 507.3 3

Salt Fog 509.1 1 509.2 1 509.3 1

Dust 510.1 1 510.2 1 510.3 1

Vibration 514.2 8,10 514.3 1 514.4 1

Shock 516.2 1,5 516.3 1 516.4 1

RECEIVER SPECIFICATIONS

VHF 200 MHz UHF 700 MHz

Frequencies 136–174 MHz, 217–218 MHz, 403–470 MHz, 746–747 MHz,

219–220 MHz, 450–512 MHz 762–764 MHz

220–222 MHZ

Channel Spacing 12.5/20/25 kHz 12.5 kHz 12.5/20/25 kHz 12.5 kHz

Frequency Stability ± 2.5 ppm ± 2.5 ppm ± 2.5 ppm ± 1.5 ppm

(-30°C to +60°C, +25°Ref.)

Sensitivity (12 dB SINAD) EIA 0.3 µV 0.23 µV typical 0.30 µV (0.25 µV typical) 0.3 µV 0.23 uV typical 0.35 µV (0.3 µV typical)

Intermodulation 75 dB @ 12.5 kHz 75dB 75 dB @ 12.5 kHz 75dB

78 dB @ 25 kHz 75 dB @ 25 kHz

Adjacent Channel Selectivity 65 dB @ 12.5 kHz 65 dB (TIA 603) 65 dB @ 12.5 kHz 65 dB (TIA 603)

80 dB @ 25 kHz 40 dB (TIA 603-A) 75 dB @ 25 kHz 40 dB (TIA 603-A)

Spurious Rejection 75 dB @ 12.5 kHz 75 dB 70 dB @ 12.5 kHz 75 dB

80 dB @ 25 kHz 75 dB @ 25 kHz

Rated Audio 3W Internal 3W Internal 3W Internal 3W Internal

(External audio w/4 ohm speaker) 13W External 13W External 13W External 13W External

Audio Distortion @ Rated Audio 3% typical 3% typical 3% typical 3% typical

Hum and Noise -40 dB 12.5 kHz -40 dB -40 dB 12.5 kHz -40 dB

-45 dB 25 kHz -45 dB 25 kHz

Audio Response TIA603 & ETS300 & +1 to -3 dB TIA603 & ETS3000 & +1 to -3 dB

CEPT 84 Annex 2 CEPT 84 Annex 2

Conducted Spurious Emmision -57dBm < 1 GHZ -57dBm < 1 GHz -57dBm < 1 GHZ -57dBm < 1 GHz

FCC Part 15 -47dBm > 1 GHZ -47 dBm > 1GHz -47dBm > 1 GHZ -47 dBm > 1GHz

TRANSMITTER SPECIFICATIONS

VHF 200 MHz UHF 700 MHz

Frequencies 136–174 MHz 217–218 MHz (Talkaround), 403 –470 MHz 776–777 MHz,

219–220 MHz, 450-512 MHz 792 –794 MHz,

220–221 MHz (Talkaround), 746–747 MHz (Talkaround),

221–222 MHz 762–764 MHz (Talkaround)

Power Output 1–25 W or 25–45 W 1–25 W 1–25 W or 25–40 W 1–15 W

Frequency Stability ± 2.5 ppm ± 2.5 ppm ± 5 ppm @ 25 kHz ± 1.5 ppm

(-30°C to +60°C, +25°Ref.) ± 2.5 ppm @ 12.5 kHz

Modulation Limiting ± 2.5 @ 12.5 kHz ± 2.5 kHz ± 2.5 @ 12.5 kHz ± 2.5 kHz

± 4.0 @ 20 kHz ± 4.0 @ 20 kHz

± 5.0 @ 25 kHz ± 5.0 @ 25 kHz

Conducted and Radiated -36 dBm < 1 GHz -16 dBm -36 dBm < 1 GHz -16 dBm (except – 40 dBm

Emissions -30 dBm > 1 GHz -30 dBm > 1 GHz from 1559 to 1610 MHz)

Channel Spacing 12.5/20/25 kHz 12.5 kHz 12.5/20/25 kHz 12.5 kHz

FM Hum & Noise -40 dB 12.5 kHz - 40 dB typical -40 dB typical - 40 dB typical

-45 dB 25 kHz

Adjacent Channel Power -60 dB @ 12.5 kHz -60 dB -60 dB @ 12.5 kHz -60 dB

-70 dB @ 25 kHz -70 dB @ 25 kHz

Audio Response TIA 603 & ETS300 & +1 to -3 dB TIA 603 & ETS300 & +1 to -3 dB

CEPT 84 Annex 2 CEPT 84 Annex 2

Audio Distortion 3% typical 3% typical 3% typical 3% typical

FM Modulation Designator 11K0F3E (12.5 kHz) 11K0F3E 11K0F3E (12.5 kHz) 11K0F3E

16K0F3E (25 kHz) 16K0F3E (25 kHz)

Adjacent Channel Coupled Power N/A N/A N/A Complies with 47

CFR 27.53 (d) (1)

GENERAL SPECIFICATIONS

VHF 200 MHz UHF 700 MHz

Channel Capacity

Trunking zone capacity 15 15 15 15

Trunking talkgroup capacity (per zone) 16 16 16 16

Conventional channel capacity 160 16 16 16

Typical RF Output

VHF Low Power 1-25W

VHF High Power 25-45W

200 MHz 1-25W

UHF Low Power 1-25W

UHF High Power 25-40W

700 MHZ 1-15W

Frequency

VHF 136-174 MHz

200 MHz 217-218 MHz, 219-222 MHz

UHF 403-470 MHz, 450-512 MHz

700 MHz 746-747 MHz, 762-764 MHz, 776-777 MHz, 792-794 MHz

Dimension (H x W x L)

VHF/UHF Low Power and 200 MHz 2.34” x 7.05” x 7.32” (60 mm x 179 mm x 186 mm)

VHF/UHF High Power and 700 MHz 2.34” x 7.05” x 7.79” (60 mm x 179 mm x 198 mm)

Weight

VHF/UHF Low Power and 200 MHz 3.15 lbs. (1.43 kg)

VHF/UHF High Power and 700 MHz 3.5 lbs. (1.59 kg)

Current Drain VHF 200 UHF 700

Standby .3 A .3 A .3 A .3 A

Rx @ rated, external 8 ohm 1.5 A 1.5 A 1.5 A 1.5 A

Transmit 7 A @ 25W 7 A @ 25W 8 A @ 25W 7 A @ 15W

13.5 A @ 45W 13.5 A @ 40W

FCC Description AZ492FT3796 (25W, 136-174 MHz)

AZ492FT3795 (45W, 136-174 MHz)

ABZ99FT3081 (25W, 217-218/219-222 MHz)

AZ492FT4835 (25W, 403-470 MHz)

AZ492FT4830 (40W, 403-470 MHz)

AZ492FT4829 (25W, 450-512 MHz)

AZ492FT4836 (40W, 450-512 MHz)

ABZ99FT5001 (15W, 746-747/762-764/776-777/792-794 MHZ)
