PC*MILER|Mobile

Navigation Application for Nextel Java

Phones i88s/i58sr

Standard User Guide

for Corporate Customers

System Release 2.2.x

TECHNOLOGY THAT DRIVES TRANSPORTATION

Trademark Office. All other product or service names are the property of their respective owners.

PC*MILER|Mobile User’s Guide i

Table of Contents

INTRODUCTION ..................................................................................................1

Overview ....................................................................................................................................................1

Device Requirements.................................................................................................................................2

Minimum Memory Requirements ...........................................................................................................2

Verifying Phone Software.......................................................................................................................2

Upgrading Software ................................................................................................................................3

PC*MILER|Mobile End-User License Agreement ................................................................................4

i88s/i58sr PC*MILER|Mobile Features..................................................................................................9

GETTING STARTED WITH PC*MILER|Mobile .................................................11

Installation ...............................................................................................................................................11

Setting the Java Option Key...................................................................................................................11

GPS Privacy Settings...............................................................................................................................12

PC*MILER|Mobile Administration.....................................................................................................12

De-installation..........................................................................................................................................14

SETTING UP THE DEVICE................................................................................15

Introduction.............................................................................................................................................15

Phone Settings..........................................................................................................................................15

Speaker Volume ....................................................................................................................................15

Display Contrast....................................................................................................................................15

Phone Placement......................................................................................................................................16

Phone Power ............................................................................................................................................17

USING PC*MILER|Mobile..................................................................................19

Launching the Application .....................................................................................................................19

Setting a Destination Using Address Book............................................................................................21

ii PC*MILER|Mobile User’s Guide

Changing an Origin.................................................................................................................................23

Setting Routing and Tracking Options..................................................................................................24

Following Voice Guidance......................................................................................................................25

Suspending PC*MILER|Mobile for Incoming Calls...........................................................................26

Suspending PC*MILER|Mobile for Outgoing Calls...........................................................................27

Exiting PC*MILER|Mobile....................................................................................................................27

PC*MILER|Mobile WEB SITE............................................................................29

Introduction.............................................................................................................................................29

My PC*MILER|Mobile Home Page......................................................................................................30

PC*MILER|Mobile TRACKING .........................................................................32

Overview ..................................................................................................................................................32

Tracking Web Page.................................................................................................................................32

Setting Tracking Options on the Device................................................................................................33

TROUBLESHOOTING .......................................................................................34

Error Messages........................................................................................................................................34

Technical Support ...................................................................................................................................35

FAQs ..................................................................................................................36

General.....................................................................................................................................................36

Technical ..................................................................................................................................................36

PC*MILER|Mobile.................................................................................................................................37

PC*MILER|Mobile Group Management and Tracking.......................................................................39

PC*MILER|Mobile User’s Guide 1

Introduction

Overview

PC*MILER®|Mobile is a portable navigation system that provides step-by-step voice

guidance to your selected destination. This series of driving instructions are

delivered to your Global Positioning System (GPS)-enabled cell phone.

The PC*MILER|Mobile solution transforms GPS, data capable mobile phones into

in-vehicle personal navigation systems that guide drivers to their next stop over truck

drivable streets and roads.

The PC*MILER|Mobile Web-based driver tracking system enables dispatchers to

send new delivery locations via their phones and to track any number of vehicles on a

map. The operation center can efficiently assign loads or jobs, respond to emergency

pickups, and inform customers of real-time arrival information.

PC*MILER|Mobile provides drivers with turn-by-turn spoken directions, and

delivers automatic re-routing almost instantly when a driver goes off route. Route

guidance instructions are provided as audible prompts and on-screen text and

graphics. Drivers will never have to look at a map again!

Drivers using PC*MILER|Mobile can employ two convenient ways to select a

destination. You can:

• Log onto the PC*MILER|Mobile Destination Center Web site at

http://www.pcmilermobile.com and enter a specific address or search for and

select a hotel, restaurant, truck stop, or other destination.

• Enter a destination address into PC*MILER|Mobile using the i88s/i58sr phone

keypad or select an existing address.

The PC*MILER|Mobile equipped GPS-enabled i88s/i58sr can be used just like any

other cell phone. The iDEN handset cannot transfer phone data and packet data at

the same time. When a network-enabled application is transmitting packet data, the

phone services will be blocked. Packet data service will incur charges to the account.

This document covers the options available when you select PC*MILER|Mobile on

the Java Applications screen and press the button under RUN. It also describes the

features available on the PC*MILER|Mobile Destination Center Web site.

PC*MILER|Mobile uses ALK Technologies’ proprietary

truck-specific digital map data, which includes:

• Comprehensive street-level coverage of the United

States and Canada

• 13’6” height, 48’ length, and 80,000 lbs. weight restrictions

• Hazmat and 53’/102” trailer restrictions

2 PC*MILER|Mobile User’s Guide

• Over 100 million addresses

• Over 7 million miles of North American roadway

• Over 5 million points of interest (ALK and Motorola combined) including

weight stations, truck stops, and truck washes

Device Requirements

PC*MILER|Mobile can be installed on either an iDEN i88s or iDEN i58sr cell

phone. The phone’s software must be R88.01.05 or higher to be compatible with

PC*MILER|Mobile.

The phone must have these Nextel services:

• Total Connect data service, 1 MB or greater with either a private or public IP

address, or Packetstream Gold data service, allowing unlimited data use.

• A voice service plan that includes a personal telephone number.

Minimum Memory Requirements

Free space required to install PC*MILER|Mobile:

 26 KB data space

 139 KB program space

Free space required to install PC*MILER|Mobile Administration:

 1 KB data space

 25 KB program space

To download audio clips after PC*MILER|Mobile applications have been installed,

approximately 80 KB of data space is needed.

Verifying Phone Software

PC*MILER|Mobile requires version R88.01.05 or newer software on your i88s or

i58sr phone.

To view the current software version on your phone:

1. Power on your phone.

2. On the Nextel screen, press the following four keys, one after the

other, allowing no more than a second between key presses:

• # key

PC*MILER|Mobile User’s Guide 3

• * key

• Menu button

• Right arrow on 4-way navigation key

The system displays the Trace Mode menu.

3. With Unit Info highlighted, press the button under VIEW.

The system displays the Unit Info menu.

4. Scroll down, highlight Software, and press the button under SELECT.

The system displays the Software screen. Under the Software Ver line,

the system displays your phone’s software version.

If the version is R88.01.05, or a higher sequence of numbers, your

phone is ready for PC*MILER|Mobile use.

If you see an older version number, like R88.00.01 or R88.01.00, you

will need to update your phone’s software.

5. Press the red End key.

The system exits the Trace Mode screens.

Upgrading Software

To update your phone’s software, you can do it yourself or take it to a Nextel

authorized service center.

Note: If you manage multiple Nextel phones for your company, contact your Nextel

representative for system software update information.

Contact your Nextel representative for the service center nearest you. You will pay a

service charge at a service center for the update (approximately $35).

To update your phone’s software yourself, you will need to:

1. Set up an account on the iDEN Update Web site at

http://www.idenupdate.com/ (accounts are free).

2. Click on the Download Quick Guide link on the Web site to ensure

you meet the minimum requirements to download software.

3. Click on the Phone Software link, select an i88s or i58sr phone, and

then add the R88.01.05 – or newer – software to your shopping cart.

This is a free update.

4. Connect your phone-to-PC serial data cable from your Windows

computer’s serial port to your phone to install the updated software.

Note: If you do not already own the serial cable, you must purchase

one before proceeding (part number NKN6544). Click on the cable

links on the software upgrade page that will take you to the Nextel or

iDEN Web sites where you can directly purchase the cable. You also

can purchase the cable from your local Nextel authorized dealer or

Internet stores. The cost is approximately $30.

4 PC*MILER|Mobile User’s Guide

5. Go to the checkout screen and follow the prompts. If the free iDEN

Update Application Software is not already installed on your

computer, choose to install it when the installation window displays.

6. Follow the iDEN Update Application Software prompts and screens to

update your phone’s software.

PC*MILER®|Mobile End-User License Agreement

ALK Technologies, Inc., a New Jersey corporation ("ALK"), agrees to furnish you,

the end-user, the PC*MILER|Mobile service, subject to your acceptance of the terms

and conditions in this agreement. By registering as a user of the service, you agree

to follow and be bound by these terms and conditions.

ALK represents and warrants that it has sufficient right, title, and interest in the

service to grant you the right to use the service, and that during the term of your

subscription, the service will function substantially according to its specifications.

THE FOREGOING WARRANTY IS IN LIEU OF ALL OTHER WARRANTIES

EXPRESS OR IMPLIED, INCLUDING WITHOUT LIMITING THE

GENERALITY OF THE FOREGOING ANY WARRANTY OF

MERCHANTABILITY OR FITNESS FOR A PARTICULAR USE. THE

PC*MILER|MOBILE SERVICE IS SOLD "AS IS". IN NO EVENT SHALL ALK

BE LIABLE FOR ANY INDIRECT, SPECIAL OR CONSEQUENTIAL

DAMAGES SUCH AS, BUT NOT LIMITED TO, LOSS IN CONNECTION WITH

OR ARISING OUT OF THE EXISTENCE OF THE FURNISHING,

FUNCTIONING OR USE OF THE SERVICES PROVIDED IN THIS

AGREEMENT. IN THE EVENT THAT A COURT OF PROPER JURISDICTION

DETERMINES THAT THE DAMAGE LIMITATIONS SET FORTH ABOVE ARE

ILLEGAL OR UNENFORCEABLE THEN, IN NO EVENT SHALL DAMAGES

EXCEED THE PRICE PAID. THIS WARRANTY SHALL NOT ACCRUE TO

THE BENEFIT OF THIRD PARTIES OR ASSIGNEES.

PC*MILER|Mobile suggested routings are based on official highway maps, the Code

of Federal Regulations, and information provided by state governments. They are

provided without a warranty of any kind. You agree to assume full responsibility for

any delay, expense, loss or damage that may occur as a result of their use.

You agree to locate and secure the mobile telephone on which you use the service so

that it does not interfere with the safe and attentive operation of a vehicle. Do not

place your mobile telephone, GPS receiver, antenna, or power supply where it may

strike the driver or passengers if the vehicle turns sharply or stops abruptly.

The accuracy of PC*MILER|Mobile is insufficient for it to be used for automated

navigation or in any situation in which errors or omissions in the service could lead

directly to death, personal injury, or physical or environmental damage. You must

remain alert at all times to actual road conditions and obey all posted signs and traffic

regulations.

PC*MILER|Mobile User’s Guide 5

You hereby expressly agree to indemnify, defend and hold ALK harmless against

any and all liability, loss, damage, cost and expense, including reasonable attorneys'

fees, in connection with all claims in contract or in tort, including negligence arising

as a result of your use of the service in a manner not authorized by the terms of this

Agreement.

You acknowledge and agree that the service is provided to you solely for your

personal use. You may disclose information from PC*MILER|Mobile to trading

partners for specific origin-destination moves for which you provide or contract for

transportation services. You may not make any other disclosure of any

PC*MILER|Mobile information to anyone outside the legal entity that is paying for

this license. You may not directly or indirectly lease, sublicense, sell or otherwise

transfer the service to third parties, or use PC*MILER|Mobile to provide information

services to third parties, without ALK’s prior written consent.

This agreement shall be construed and applied in accordance with the laws of the

State of New Jersey, and the courts of the State of New Jersey shall be the exclusive

forum for all actions or interpretations pertaining to this agreement. This is the entire

Agreement between you and ALK and supersedes any prior or contemporaneous

agreements or understandings. Should any provision of this agreement be found to

be illegal or unenforceable, then only so much of this agreement as shall be illegal or

unenforceable shall be stricken and the balance of this agreement shall remain in full

force and effect.

User Consent

Laws in some areas prohibit the use of a cellular phone when driving a motor vehicle.

It is the responsibility of each cellular phone user to be aware of and abide by any

and all local laws and ordinances, which may restrict the use of cellular phones. The

user must take the utmost care in using a cellular phone safely under all

circumstances.

Traffic laws and current traffic conditions must always be observed and take

precedence over the instructions issued by the navigation system. The user should be

aware of situations where current traffic conditions and the instructions from the

navigation system may be in conflict.

The use of the navigation system does not relieve the user of his/her responsibilities.

The user is ultimately responsible for the vehicle under his/her control and should be

aware of the surroundings at all times. For traffic safety reasons, it is recommended

that routes should be set-up in a stationary vehicle before starting a trip.

Privacy: Operation of the PC*MILER | Mobile service requires that the user's

position be sent to a central server for use in preparing the route information. This

information will only be used to provide the navigation and tracking services and will

not be shared with any third parties. A user who wishes to keep their current location

private should not use the PC*MILER | Mobile service.

6 PC*MILER|Mobile User’s Guide

Motorola is not responsible for any financial loss, or other incidental or consequential

damage arising out of the use of, or inability to use, this product. This includes

damage to property and, to the extent permitted by law, damages for personal injury

and death.

PC*MILER | Mobile suggested routings are based on official highway maps, the

Code of Federal Regulations, and information provided by state governments. They

are provided without a warranty of any kind. The User agrees to assume full

responsibility for any delay, expense, loss or damage that may occur as a result of

their use.

The User agrees to locate and secure the mobile telephone on which the service is

used so that it does not interfere with the safe and attentive operation of a vehicle.

Do not place your mobile telephone, GPS receiver, antenna, or power supply where it

may strike the driver or passengers if the vehicle turns sharply or stops abruptly.

The accuracy of PC*MILER | Mobile is insufficient for it to be used for automated

navigation or in any situation in which errors or omissions in the service could lead

directly to death, personal injury, or physical or environmental damage. The User

must remain alert at all times to actual road conditions and obey all posted signs and

traffic regulations.

If after reading these statements the User decides not to accept these terms, the User

should not use the PC*MILER | Mobile service

Wireless Carrier Agreement

Nextel makes no warranties, express or implied, including without limitation, any

implied warranty of merchantability or fitness for a particular purpose to end user in

connection with its use of the PC*MILER | Mobile service. End user acknowledges

that service disruptions will occur from time to time and agrees to hold Nextel

harmless for all such disruptions. Nextel shall not be responsible for special, indirect,

incidental, consequential or punitive damages of any kind, including without

limitation, lost profits or other monetary loss, arising out of Nextel’s performance of

the services or failure to do so or due to the failure of poor performance of systems

under this agreement, whether or not any such matters or causes are within Nextel's

control due to negligence or other fault on the part of Nextel, its agents, affiliates,

employees or other representatives.

Map Data License Agreement

The data ("Data") is provided for the User's personal, internal use only and not for

resale. It is protected by copyright, and is subject to the following terms and

conditions which are agreed to by the user on the one hand, and Motorola and its

licensors (including their licensors and suppliers) on the other hand.

PC*MILER|Mobile User’s Guide 7

The Data for areas of Canada includes information taken with permission from

Canadian authorities, including © Her Majesty the Queen in Right of Canada, ©

Queen's Printer for Ontario

Terms and Conditions

Personal Use Only. The User agrees to use this Data together with PC*MILER |

Mobile for the solely personal, non-commercial purposes for which the User

was/were licensed, and not for service bureau, time-sharing or other similar purposes.

Accordingly, but subject to the restrictions set forth in the following paragraphs, the

User may copy this Data only as necessary for the User's personal use to (i) view it,

and (ii) save it, provided that the User does not remove any copyright notices that

appear and do not modify the Data in any way. The User agrees not to otherwise

reproduce, copy, modify, decompile, disassemble or reverse engineer any portion of

this Data, and may not transfer or distribute it in any form, for any purpose, except to

the extent permitted by mandatory laws.

Restrictions. Except where the User has been specifically licensed to do so by

Motorola, and without limiting the preceding paragraph, the User may not (a) use this

Data with any products, systems, or applications installed or otherwise connected to

or in communication with vehicles, capable of vehicle navigation, positioning,

dispatch, real time route guidance, fleet management or similar applications; or (b)

with or in communication with any positioning devices or any mobile or wireless-

connected electronic or computer devices, including without limitation, cellular

phones, palmtop and handheld computers, pagers, or personal digital assistants or

PDAs.

No Warranty. The Service is provided to the User "as is," and the User agrees to use

it at their own risk. Motorola and its licensors (and their licensors and suppliers)

make no guarantees, representations or warranties of any kind, express or implied,

arising by law or otherwise, including but not limited to, content, quality, accuracy,

completeness, effectiveness, reliability, fitness for a particular purpose, usefulness,

use or results to be obtained by this Data, or that the Data or server will be

uninterrupted or error-free.

Disclaimer of Warranty. MOTOROLA AND ITS LICENSORS (INCLUDING

THEIR LICENSORS AND SUPPLIERS) DISCLAIM ANY WARRANTIES,

EXPRESS OR IMPLIED, OF QUALITY, PERFORMANCE,

MERCHANTABILITY, FITNESS FOR A PARTICULAR PURPOSE OR NON-

INFRINGEMENT. Some States, Territories and Countries do not allow certain

warranty exclusions, so to that extent the above exclusion may not apply to the User.

Disclaimer of Endorsement. Reference to any products, services, processes,

hypertext links to third parties or other Data by trade name, trademark, manufacturer,

supplier or otherwise does not necessarily constitute or imply its endorsement,

sponsorship or recommendation by Motorola or its licensors. Product and service

information are the sole responsibility of each individual vendor. The Motorola,

Nextel or Navigation Technologies name or logo, the NAVTEQ and NAVTEQ ON

BOARD trademarks and logos, and other trademarks and trade names owned by

8 PC*MILER|Mobile User’s Guide

Motorola, Inc, Nextel, Inc or Navigation Technologies Corporation may not be used

in any commercial manner without the prior written consent of respective company.

Export Control. The User agrees not to export from anywhere any part of the

Service or Data provided to the User and any direct product thereof except in

compliance with and with all licenses and approvals required under, applicable

export laws, rules and regulations.

Indemnity. The User agrees to indemnify, defend and hold Motorola and its

licensors (including their respective licensors, suppliers, assignees, subsidiaries,

affiliated companies, and the respective officers, directors, employees, shareholders,

agents and representatives of each of them) free and harmless from and against any

liability, loss, injury (including injuries resulting in death), demand, action, cost,

expense or claim of any kind or character, including but not limited to attorney’s

fees, arising out of or in connection with any use or possession by the User of this

Data.

Entire Agreement. These terms and conditions constitute the entire agreement

between Motorola (and its licensors, including their licensors and suppliers) and the

User pertaining to the subject matter hereof, and supersedes in their entirety any and

all written or oral agreements previously existing between us with respect to such

subject matter.

Governing Law. The above terms and conditions shall be governed by the laws of

the Illinois, without giving effect to (i) its conflict of laws provisions, or (ii) the

United Nations Convention for Contracts for the International Sale of Goods, which

is explicitly excluded. The User agrees to submit to the jurisdiction of Illinois for any

and all disputes, claims and actions arising from or in connection with the Data

provided to the User hereunder

United States Federal Government Subscriptions

Purchases of this service for the United States Federal government use will not

exceed a total transaction amount of US$2,500.00 and will comply with the micro-

purchase regulations.

I hereby have read, and understood the above agreement and accept the terms and

conditions as stated.

PC*MILER|Mobile User’s Guide 9

i88s/i58sr PC*MILER|Mobile Features

The following diagram illustrates the i88s/i58sr features that are used in operating

PC*MILER|Mobile.

N CENTRAL AVE

GPS OK

BACK

0.1 mi. 3.3 mi.

Press and Hold

for On/Off

Press to

Activate/Deactivate

Speakerphone

Press to

Adjust Volume

(when prompts are spoken)

Move Up/Down or

Right/Left Send Call/

Repeat Last

Instruction/View

Directory Listing Details

Distance

to Left

Turn Distance

to Destination

Direction of

Travel

End Call

Street Name

to Turn onto

Press to

Enter Text

(e.g., press 9

twice to type w)

Press to go

Back/Exit Press to Run application

/Select/Go

GPS Status

Press to

Check Traffic

during Guidance

(Sorry, traffic checking not

available in current version of

PC*MILER|Mobile)

10 PC*MILER|Mobile User’s Guide

Notes

PC*MILER|Mobile User’s Guide 11

Getting Started with

PC*MILER|Mobile

Installation

Before the PC*MILER|Mobile application can be run, there are two simple steps that

are required to initialize the application.

• Install Audio Clips

The PC*MILER|Mobile guidance system utilizes the Voice Notes file system

to store audio clips that are used during the guidance process to announce the

next instruction. The prerequisites are to have at least 80k of free data space

and to be in an area that has strong Nextel coverage. This will help keep the

installation time short and reduce the cost of data transfer.

If you do not install the audio clips, the PC*MILER|Mobile application will

“beep” when attempting to play the given audio selection. To install the

clips, select PCMILERi88Adm and run the AudioLoader. (See the Audio

Loader directions on page 11.)

• Provision the User

The PC*MILER|Mobile guidance system requires that you register with

a valid user ID and password. If you fail to register, the

PC*MILER|Mobile application will respond with an error message

indicating you are not a valid subscriber.

Setting the Java Option Key

You can change the names and actions of the phone’s two option keys (the buttons to

the right and left of the Menu button), the power up application, and the ordering of

items in the Menu.

To make PC*MILER|Mobile applications readily available when you power up your

phone, you should change the right option key to JAVA. This will make it easier to

start PC*MILER|Mobile and easier to return to PC*MILER|Mobile if a phone call,

message, or other interruption happens when running PC*MILER|Mobile.

From the Nextel screen, press the Menu button. Highlight Settings and press the

button under SELECT. On the Settings screen, scroll to Personalize and press the

button under SELECT. Highlight Keys and press the button under SELECT.

Highlight Right and repeatedly press the right arrow of the 4-way navigation key

until the setting displays Java Apps. Press the button under BACK and to return to

the Personalize screen for the next change.

12 PC*MILER|Mobile User’s Guide

If you will be using PC*MILER|Mobile often, you may wish to have the Java Apps

screen appear immediately when you power up so you can select PC*MILER|Mobile

with one key press.

From the Personalize screen, scroll to Power Up App and press the button under

SELECT. Repeatedly press the right arrow of the 4-way navigation key until the

setting shows Java Apps and then press the button under BACK to return to the

Personalize screen. Press the button under BACK and then the button under EXIT to

return to the Nextel screen.

GPS Privacy Settings

There are three GPS settings on the i88s/i58sr. They are Restricted, Unrestricted, or

By Permission.

To check the setting, from the Nextel screen press the Menu button. Scroll down and

select GPS. Then select Privacy. The current setting will be marked.

The recommended setting is By Permission. This setting triggers a question to the

user when an application first tries to obtain the GPS position information. You must

agree to allow the access for the application to proceed. When the phone displays a

message asking if you always want to grant permission, you can select YES or NO, in

which case the grant permission screen will always display.

The Unrestricted setting allows all applications to obtain the GPS position

information.

The Restricted setting prevents any application from obtaining the GPS position

information.

PC*MILER|Mobile Administration

If you highlight PCMILERi88Adm on the Java Applications

screen and press the button under SELECT,

PC*MILER|Mobile displays the Applications screen, where

you can download audio clips, provision the i88s/i58sr, or

remove audio clips in preparation for de-installing

PC*MILER|Mobile.

These utilities generally are used only for set up.

EXIT RUN

……

Java Apps

VIAMOTOi88

VIAMOTOi88Adm

Java System

IPIP

PCMILERi88

PCMILERi88Adm

PC*MILER|Mobile User’s Guide 13

To download audio clips, highlight AudioLoader and press

the button under RUN.

Note: To speed up the download process, the signal icon

should display at least 2-3 bars.

PC*MILER|Mobile displays the Audio Loader screen.

The AudioLoader first deletes the old audio clips.

PC*MILER|Mobile then downloads the new ones. When

complete, PC*MILER|Mobile displays a message stating

“Download Completed!”

Note: If you do not have adequate space to download the

new clips, PC*MILER|Mobile displays an error message

stating “Unable to complete loading operation.” Press the

button under EXIT. Remove unneeded voice recording and

try to run the Audio Loader again.

To remove audio clips in preparation for de-installing

PC*MILER|Mobile, highlight AudioRemover and press the

button under RUN.

Note: To speed up the download process, the signal icon

should display at least 2-3 bars.

PC*MILER|Mobile displays the Audio Remover screen.

When complete, PC*MILER|Mobile displays a message

stating “Delete completed!!”

Audio Loader

Deleting old audio.

EXIT

Audio Loader

Connecting…connected.

Download Completed!

EXIT

Audio Remover

Deleting old audio.

EXIT

BACK RUN

Apps

AudioLoader

AudioRemover

IPIP

BACK RUN

Apps

AudioLoader

AudioRemover

IPIP

14 PC*MILER|Mobile User’s Guide

De-installation

Important: For a clean de-installation, you must remove

audio clips first. (See the procedure on page 11.)

To de-install PC*MILER|Mobile, highlight

PC*MILER|Mobile and press the Menu button.

PC*MILER|Mobile displays a Java Applications screen.

Highlight Deinstall and press the button under SELECT.

PC*MILER|Mobile displays a screen asking you to confirm

that you want to delete the application.

Press the button under OK.

Next, de-install PC*MILER|Mobile Administration.

Highlight PCMILERi88Adm and press the Menu button.

PC*MILER|Mobile displays a Java Applications screen.

Highlight Deinstall and press the button under SELECT.

PC*MILER|Mobile displays a screen asking you to confirm

that you want to delete the application.

Press the button under OK.

BACK SELECT

Java Apps

About

Deinstall

IPIP

PC*MILER|Mobile User’s Guide 15

Setting Up the Device

Introduction

To effectively use PC*MILER|Mobile in your vehicle, you should:

• Change phone settings for best in-vehicle use before you first run

PC*MILER|Mobile

• Place your phone as close to the windshield as possible

• Power your phone from the vehicle

Phone Settings

Following are suggested changes to your phone’s settings to make

PC*MILER|Mobile easier to use when driving.

Speaker Volume

PC*MILER|Mobile provides you with both audio and visual directions when

navigating to your destination.

If you are not using a headset with your phone, your phone’s speakerphone should be

on in order to hear audio directions. If your speakerphone is turned off, you will see

an icon at the top of your screen showing a speaker with a line through it.

To check the status of your speakerphone, power up your i88s/i58sr phone, and

check to see if the speaker icon has a red line through it. If so, press the

speakerphone button on the top left side of your phone (a speaker icon is on the

button). A message briefly displays, indicating the speaker is on. The speaker icon

on the screen no longer displays.

To set your initial speakerphone volume high enough for directions to be heard under

most road conditions, from the Nextel screen, press the Menu button. Scroll to

Settings and press the button under SELECT. Scroll to Voice Volume and press the

button under SELECT. Highlight Speaker Vol and repeatedly press the right arrow of

the 4-way navigation key until the volume setting is at 4 or 5. Then press the button

under BACK to return to the Settings screen.

Display Contrast

To best see the phone’s screen in all lighting conditions, you may want to increase

the screen’s contrast setting. From the Nextel screen, press the Menu button. Scroll

to Settings and press the button under SELECT. Highlight Contrast and repeatedly

16 PC*MILER|Mobile User’s Guide

press the right arrow of the 4-way navigation key until the contrast setting is at 4 or

5. Then press the button under BACK to return to the Settings screen.

Optionally, you may want to select an existing car or outdoor style. Refer to your

phone’s manual for more information on using and creating phone styles.

Phone Placement

For best GPS satellite reception on your GPS-enabled phone, place your phone as

close to the windshield as possible.

While many fixed and temporary mount phone holder types are available (adhesive

mounts, vent clip mounts, etc.), for closest placement to

the windshield you may wish to purchase a windshield

suction mount holder such as the one shown here.

Note: Check legal restrictions in your community on

such devices and attach the mount to the windshield in

an area that will not block your vision.

Universal mount suction holders are available from

many manufacturers and are commonly available at

cellular phone accessory retailers and Internet stores.

Two such examples include:

Radio Shack’s Adjustable Subcompact Universal

Phone Mount, Model 17-551

• Includes a universal phone grip and pedestal. This model can be suction

mounted to the windshield or adhesive mounted to the dash.

• Search http://www.radioshack.com with the part number, call 1-800-

THESHACK, or check a Radio Shack store near you.

Arkon Resource’s CM 30 Universal Gripmatic Cell Phone Cradle plus CM52 8”

pedestal or CM53 14” pedestal

• See http://www.arkon.com for details and lists of retail vendors or call 1-800-

841-0884.

Note: To keep the phone and PC*MILER|Mobile operating properly, do not leave

your phone on the dash where it could be exposed to the sun’s heat. If your phone is

left in the sun for prolonged periods, hold it in front of the air conditioning vent for a

few minutes before using.

PC*MILER|Mobile User’s Guide 17

Phone Power

Powering your GPS-enabled cell phone with an optional cigarette lighter adapter

while using the phone for navigation provides three advantages:

• Your phone’s battery will be charged while you are using the phone for

navigation. GPS operation consumes power when in constant use, and so it

can drain batteries. If the phone is used for navigation over long hours – such

as an 8-hour work day – fully charged batteries can be completely drained.

• The phone’s back light will be constantly on while the phone is charging. A

back-lighted screen is easier to see even in daylight conditions. At night, a

back-lighted screen is absolutely essential when navigating.

Note: Since back lighting consumes battery power, it is best to use it with a

power adapter.

• The GPS unit inside the device will provide the best location resolution

possible.

Power adapters for the i88s and i58sr phones can be purchased from resellers of

iDEN accessories, from Nextel (http://www.nextel.com) or Nextel dealers, or directly

from Motorola (http://www.idenstore.com).

The Motorola part number for an i88s/i58sr compatible vehicle battery charger is

SYN7818A. The chargers are also available in multiple translucent colors. Each

color has its own part number.

18 PC*MILER|Mobile User’s Guide

Notes

PC*MILER|Mobile User’s Guide 19

Using PC*MILER|Mobile

Launching the Application

This section covers the start-up screens when you select

PC*MILER|Mobile on the Java Applications screen and

press the button under RUN.

When you press the button under RUN,

PC*MILER|Mobile displays the start screen.

PC*MILER|Mobile then displays the User Consent

screen.

Review the information and press the button under

ACCEPT to accept the terms listed in the warnings

and disclaimers.

PC*MILER|Mobile then displays the

PC*MILER|Mobile splash screen.

Note: If you do not accept the terms listed in the

warnings and disclaimers and press the button under

DECLINE, PC*MILER|Mobile returns to the Java

Applications screen.

VIAMOTOTM

Maps by

EXIT RUN

……

Java Apps

VIAMOTOi88

VIAMOTOi88Adm

Java System

IPIP

VIAMOTOi88

starting...

EXIT

User Consent

Notice: Please read the

warnings and

disclaimers at www. viamo

to.com/consent before

using this product.

Press the ACCEPT button

to indicate your

acceptance of the terms

and your acceptance of

the full responsibility

for use of this product.

DECLINE ACCEPT

PCMILERi88

PCMILERi88Adm

PCMILERi88

20 PC*MILER|Mobile User’s Guide

PC*MILER|Mobile then displays the Signing In

screen, followed by the Login screen, where the

provisioned user is logged onto PC*MILER|Mobile.

Note: The first time you log in,

you must enter the unit’s phone

number in the Username and

Password fields. Highlight Save

button. Then press the button

under OK. PC*MILER|Mobile

will bypass the entry screen in

the future.

Note: If the unit has not been properly provisioned,

PC*MILER|Mobile displays a message that the logon

was not successful. Press the button under CANCEL

to return to the Java Applications screen.

PC*MILER|Mobile then displays the Connecting

screen while your personal preferences are

downloaded.

The main PC*MILER|Mobile screen is then

displayed.

Logging in as xxxx...

VIAMOTO

Use Address Book

Search Directory

Check Traffic

Change Origin

EXIT SELECT

Signing In

Version REL-

VIAMOTO_1.9.x

Connecting

Please wait while

your personal

preferences are

downloaded.

Signing In

Username

Password

Save Login

EXIT OK

PCMILER|Mobile_2.2.x

PC*MILER

Mobile

Chan

e Ori

PC*MILER|Mobile User’s Guide 21

Setting a Destination Using Address Book

This section covers the screens you see when selecting

Use Address Book and pressing the button under

SELECT.

The Address Book allows you to select destination

addresses you already have listed in your address book,

save your current position to as an address entry to your

address book, and/or add addresses to your destination

list by typing the entry on the keypad.

Note: PC*MILER|Mobile defaults to your current

position as the point of origin for the route. If you want

to plan a route from another starting location, highlight

Change Origin, press the button under SELECT, and

select a starting point.

Note: The + is the only special character allowed.

To enter letters, press the key multiple times

to display each letter.

For example, press 2 two times to type

a; three times to type b; four times to type c.

If you have multiple letters and/or numbers

that are located on the same key, wait three

seconds before typing the next letter or

number.

When you press the button under SELECT,

PC*MILER|Mobile displays the Address Book screen.

To enter a new address, highlight Enter New

Address and press the button under SELECT.

PC*MILER|Mobile displays the Enter Address screen.

Type the street, city, and two-letter state

abbreviation, using the GPS unit keypad.

Note: For Number and Street field, you can type

cross streets for an intersection, separated by a plus

sign (+).

To save the address to your address book, you must

enter the Name field, then press the button under OK.

Note: If you saved the address (by typing the Name

Press to

add space

Press

to backspace

Press down

arrow to move

to next line

Press 0twice to

type plus sign (+)

Enter Address

Number and Street

(+ for cross st)

CANCEL OK

City

State (Abbr)

Name

If name not entered,

address will not be

saved upon exit.

VIAMOTO

Use Address Book

Search Directory

Check Traffic

Change Origin

EXIT SELECT

Address Book

New Address

Save Position

--------

Address Entry #1

Address Entry #2

BACK SELECT

PC*MILER

Mobile

Chan

e Ori

22 PC*MILER|Mobile User’s Guide

field), PC*MILER|Mobile displays the Connecting

screen. When the entry has been saved,

PC*MILER|Mobile returns to the Address Book

screen and highlights the newly added address. To

view details of any address entry, highlight the entry

and press the green Send button.

To add your current position to your address

book, highlight Save Current Position and press the

button under SELECT. PC*MILER|Mobile attempts

to obtain your current position.

Once your current position is sent to the server,

PC*MILER|Mobile displays the Position screen. In

the Name field, type the name you want to use to list

the position in your address book, using the GPS unit

keypad.

Press the button under OK. PC*MILER|Mobile

displays the Connecting screen.

When the entry has been saved, PC*MILER|Mobile

returns to the Address Book screen and highlights

your current position (by name) in your list of

address entries.

To set a destination, highlight the address entry for

which you want directions. Press the button under

SELECT.

PC*MILER|Mobile displays the Connecting screen

retrieves directions. PC*MILER|Mobile then

displays directions to the address you entered.

You can use the down arrow to scroll through the

written directions.

When ready to begin guidance, press the button

under GO.

Connecting

Sending address to

address book. Please

wait.

Connecting

Retrieving directions.

Please wait.

Position

Name

CANCEL OK

Lat: 33.355896

Lon: -111.899445

Date: 01-14-2004

Time: 11:09:43 AM

Address Book

New Address

Save Position

--------

Address Entry #1

Address Entry #2

BACK SELECT

Address Book

New Address

Save Position

--------

Address Entry #1

Address Entry #2

Address Entry #3

BACK SELECT

Directions

Total route distance:

0.2 miles

>Start out going west on

E COLTER ST

>In 180 yards turn left

onto N CENTRAL AVE

>In 0.2 miles turn left

BACK GO

PC*MILER|Mobile User’s Guide 23

Changing an Origin

This section covers the screens you see when you

highlight Change Origin and press the button under

SELECT.

This feature allows you to plan a route from any

starting location. It can be used to plan for a future

travel route. For example, you can plan a route from

your hotel to the local art museum while waiting for a

meeting to begin at a client’s office.

When you press the button under SELECT,

PC*MILER|Mobile displays the Change Origin

screen.

Highlight Address Book and press the button under

SELECT. PC*MILER|Mobile displays the Address

Book screen, where you can select an address entry or

enter a new address as the origin.

The starting position will remain the selected origin

until you exit PC*MILER|Mobile or you change it

back to your current position. To change the origin

back to your current position, highlight Current

Position and press the button under SELECT.

PC*MILER|Mobile returns to the main

PC*MILER|Mobile screen.

VIAMOTO

Use Address Book

Search Directory

Check Traffic

Change Origin

EXIT SELECT

Change Origin

Current Position

Address Book

BACK SELECT

Address Book

New Address

Save Position

--------

Address Entry #1

Address Entry #2

BACK SELECT

PC*MILER

Mobile

Use Address Book

Change Origin

24 PC*MILER|Mobile User’s Guide

Setting Routing and Tracking Options

Routing and tracking options can be set when you log on to the PC*MILER|Mobile

web site – see the PC*MILER|Mobile Web Site section in this User Guide.

Available Route Guidance options are:

• Practical: Practical routes represent routing a driver would normally take to

minimize time and cost. Practical routing models the trade-off between

taking the most direct path and staying on major, high quality highways.

Interstate highways are given a higher priority than toll roads, which in turn

are given a higher priority than secondary highways, and so on. Practical

routings consider distance, road quality, terrain, urban/rural classifications,

truck-restricted roads, and designated principal and secondary through

routes.

• Shortest: PC*MILER Shortest Routes represent distances and driving

routes that a vehicle would take to minimize total distance traveled while still

following a reasonable route. For instance, Shortest Route mileages and

routes will also avoid truck-restricted roads and, in some cases, may favor a

beltway rather than traveling directly through a city.

• National Network: The National Network is a government-designated

system of highways originally established by the Surface Transportation

Assistance Act of 1982 and updated in 1992. PC*MILER National Network

routing represents distances and driving routes which are most reasonable

and legal for the larger trucks authorized by the Surface Transportation

Assistance Act of 1982. This routing stays on the National Network to the

maximum extent possible.

• 53 Foot Trailer: Calculations for these routes are based on National

Network routing, with the addition of roads that permit 53’ trailers.

• Toll-Discouraged: These routes will avoid long stretches of toll roads but

will not take long, impractical detours to avoid toll bridges and tunnels.

• Hazardous Material: Hazmat routes are constrained by US federal, state,

and local hazardous materials restrictions.

Note 1: Tracking can be turned ON or OFF, and a Tracking Interval and

Reporting Interval may be set.

Note 2: Selecting routing options does not prevent PC*MILER|Mobile from

providing routes that may not meet your requirements. No warnings are given

regarding bridges, underpasses, etc. that may be problematic, so drivers must

remain attentive.

PC*MILER|Mobile User’s Guide 25

Following Voice Guidance

When you are ready to begin guidance, on the

Directions screen, press the button under GO.

PC*MILER|Mobile displays the Connecting screen

while loading the route to your destination.

PC*MILER|Mobile then graphically displays the

direction to start navigation.

Note: To review the route, you can press the right

arrow of the 4-way navigation key to scroll through

the guidance screens. If driving a route when

scrolling through instructions, you should return to the

current instruction screen to keep the display in synch

with the route’s progress.

PC*MILER|Mobile indicates the next maneuver to

make.

Note: To repeat the audio directions, you can press

the green Send button.

As you approach a turn, PC*MILER|Mobile displays

the decreasing distance to the turn.

Directions

Total route distance:

8.7 miles

>Start out going west on

E COLTER ST

>In 180 yards turn left

onto N CENTRAL AVE

>In 1.3 miles turn left

BACK GO

E COLTER ST

BACK

GPS OK

3.3 mi.

N CENTRAL AVE

GPS OK

BACK

0.1 mi. 3.3 mi.

N CENTRAL AVE

BACK

300 yds

Connecting

Loading route to

Address Entry

Address

26 PC*MILER|Mobile User’s Guide

Note: If you make an

improper turn,

PC*MILER|Mobile warns that

you have left the route. You

can either take actions to

return safely to the route, or

press the button under

REROUTE to obtain new

guidance instructions.

After the last turn, PC*MILER|Mobile displays the

distance to your destination and provides information

on which side of the road the final destination is

located.

Suspending PC*MILER|Mobile for Incoming Calls

To accept an incoming call while using

PC*MILER|Mobile, you must press the button under

YES. For hands-free phone operation, then press the

button under SPEAKER.

Note: Incoming calls are blocking when in guidance

mode.

When the call has ended, press the button under

RESUME to return to the PC*MILER|Mobile

application.

Note: The same process is used for Direct Connect or

other applications. To return to the PC*MILER|Mobile

application, press the button under JAVA and then

presses the button under RESUME.

YES NO

Take Call From

Line 1

IPIP

EXIT RESUME

VIAMOTO

suspended

IPIP

Destination

BACK

3.3 mi.

GPS OK

N CENTRAL AVE

Off Route

BACK

3.3 mi.

REROUTE

PCMILER|Mobile

PC*MILER|Mobile User’s Guide 27

Suspending PC*MILER|Mobile for Outgoing Calls

To make a call while using PC*MILER|Mobile, press

the red End button twice. The system suspends

PC*MILER|Mobile.

Make your call.

When the call has ended, press the button under JAVA

and then presses the button under RESUME.

Exiting PC*MILER|Mobile

To exit PC*MILER|Mobile from a guidance screen,

press the button under BACK to return to the main

PC*MILER|Mobile screen. Press the button under

EXIT to exit PC*MILER|Mobile and return to the Java

Applications screen.

Note: Properly exiting PC*MILER|Mobile ensures

that the GPS unit is shut down so that it will not drain

your battery excessively.

VIAMOTO

Use Address Book

Search Directory

Check Traffic

Change Origin

EXIT SELECT

EXIT RESUME

VIAMOTO

suspended

IPIP

Destination

BACK

3.3 mi.

GPS OK

PCMILER|Mobile

PC*MILER

Mobile

Chan

e Ori

28 PC*MILER|Mobile User’s Guide

Notes

PC*MILER|Mobile User’s Guide 29

PC*MILER|Mobile

Web Site

Introduction

Instead of using your i88s/i58sr phone to search for destinations or enter destinations

into your address book, you can use the PC*MILER|Mobile Web site to perform

these functions and set destination addresses. You can also set preferences such as

route type and tracking frequency on the site.

The Web site is located at http://www.pcmilermobile.com. Click on the Login link.

PC*MILER|Mobile Homepage

30 PC*MILER|Mobile User’s Guide

My PC*MILER|Mobile Home Page

From the My PC*MILER|Mobile Home Page, you can manage your

PC*MILER|Mobile application, conducting many of the tasks you also can complete

on your phone. In addition you can plan a trip, set preferences, change your

password, set up and manage groups of users, and track trip progress.

Address Book lists entries in your PC*MILER|Mobile address list, which display on

the Address Book screen. From this page, you can add or delete addresses, as well as

update current addresses in your address book.

Tracking displays group users’ current positions and routes traveled in near-real time

and for a historical time period.

Group Management allows you to set up and maintain a group of users, including

adding and deleting group members, add a destination to the address books of all or

select group members, and set preferences for all or select group members. When

setting up groups, only users that have the same client application can be grouped.

For example, a customer with i58 phones can only create a group that only has i58

phones.

Account Management displays contact information and provides access to change

your logon password.

Directory Search allows you to search for a destination by name and/or category.

You can choose to search for addresses near your current position, near a designated

PC*MILER|Mobile User’s Guide 31

location, or within a defined area or on a specific street. You also can display map of

multiple entries.

Preferences allow you to add or remove categories from the list of directory search

categories that display on your phone.

Configure Options allows you to choose the routing options appropriate for your

vehicle and auto reroute preferences.

Help provides access to frequently asked questions and documentation, as well as

provides a forum by which to send comments or questions to PC*MILER|Mobile.

Log Out is used to end your session in the PC*MILER|Mobile Web site.

PC*MILER|Mobile User’s Guide 32

PC*MILER|Mobile

Tracking

Overview

Web-based driver tracking is an optional feature available from PC*MILER|Mobile.

The tracking system enables dispatchers to track any number of vehicles on a map,

which can aid in efficiently assigning loads or jobs, responding to emergency

pickups, and providing customers of real-time arrival information.

The PC*MILER|Mobile application records the position of the device, which then

can be tracked visually on the PC*MILER|Mobile Web site. PC*MILER|Mobile

must be running in order for the position data to be collected.

The feature has following characteristics:

• 20 meter resolution

• Maximum record rate is 1 minute

• Minimum report interval is 5 minute

• Ability to record up to 4 hours of tracking when out of network coverage

Tracking Web Page

The PC*MILER|Mobile Web site provides the ability to view historical data, as well,

by entering a select start and end dates for which to view data.

PC*MILER|Mobile User’s Guide 33

Clicking on the red locator dot on the map displays the latitude/longitude of the user's

most current position. Clicking on the user's Address link displays the address of the

user's most current position.

Note: If the user has pop-up blocker on his/her Web browser, the tracking window

will not display.

Setting Tracking Options on the Device

Some tracking settings can be configured by the user on the PC*MILER|Mobile

unit. On the main PC*MILER|Mobile screen, the user highlights Change Options

and presses the button under SELECT.

• Tracking mode: ON / OFF

• Tracking interval (how often the GPS position is recorded): 1 minute to 1440

minutes (1 day)

• Reporting interval (how often the recorded positions are sent to the server): 5

minutes to 10080 minutes (1 week)

These settings also can be configured on the PC*MILER|Mobile Web site.

Once the application is terminated all data are erased from the phone.

PC*MILER|Mobile User’s Guide 34

Troubleshooting

Error Messages

The following error messages may be encountered when you log on:

• Initial user/password must be set, Login failed: Fail to logon: Incorrect user name

or password, or Login failed: User is not valid subscriber. The application has not

been properly set up for use. You could have entered the information incorrectly,

please try again. If still unsuccessful, contact technical support to resolve any

issues with the account.

• Failed to contact server. The GPS unit is unable to make a data connection to the

server. This will happen if the power indicator on the top of the GPS unit is solid

red or if the IP indicator on the GPS unit does not display. You may not be in an

area with wireless data coverage. Relocate and, when the power indicator light

turns green, try again. This may take a couple of minutes.

The following errors may be encountered on the Address Entry or Directions screen:

• Destination/Address is incorrect or incomplete. Please check and re-enter. The

server failed to verify that the address exists. This can be for several different

reasons: misspelled street name or city; state is not the standard two-character

abbreviation; improper abbreviations of names used; missing data; or the address is

too new to be found on a road network.

• Move your vehicle closer to a public street to find a starting street. You are not

close enough to the road network. Move the car closer to a public street and retry.

This also may happen if you are in a very new neighborhood that is not yet

supported by the map data.

• ERR_0100. Indicates that the server was unable to generate a route using the

specified parameters for one of many reasons (i.e., route server is down, the route

cannot be routed to, etc.).

The following errors may be encountered on the Guidance screens:

• Download Error. An error occurred during the download. Press the button under

BACK and try to obtain the route again.

• Out Of Memory. The route contains more data than the GPS unit can handle at this

time. There is not enough memory to download the entire route. Exit the

application and design a route with intermediate destination points. The length of

the route and the number of maneuvers impact how large the entire route can be.

PC*MILER|Mobile User’s Guide 35

The following error message may be encountered when you are downloading voice

clips:

• Unable to complete loading operation. The application does not have the available

space to download new voice clips. Remove unneeded voice recordings and try

again.

Technical Support

To contact PC*MILER|Mobile with technical issues, send an email to

pcmmtech@alk.com. You should include a detailed description of the issue and any

additional contact information for technical support to use in responding to the email.

You also can contact PC*MILER|Mobile by calling technical support at 1-800-311-

3835.

PC*MILER|Mobile User’s Guide 36

FAQs

General

Q. What is PC*MILER|Mobile?

A. PC*MILER|Mobile is a navigation system that provides automated turn-by-turn

spoken directions along your route to guide you to your destination.

Q. How does PC*MILER|Mobile work?

A. PC*MILER|Mobile is able to determine your position using the Global Positioning

System (GPS). When you enter a destination using the phone or Web site, the route

information is downloaded to your phone, and turn-by-turn directions are provided to

guide you to your destination. If you miss or make an incorrect turn,

PC*MILER|Mobile will alert you and will offer a new route.

Q. Where can I use PC*MILER|Mobile?

A. PC*MILER|Mobile can be used in most metropolitan areas where there is Nextel

coverage. You can use the phone in or out of a vehicle to provide directions to your

destinations. For the GPS to work properly, the phone should have a clear view of the

sky and be away from tall buildings, covered parking areas, tunnels, and dense foliage.

In order to get a route you should be near a public road.

Technical

Q. What is GPS?

A. The Global Positioning System (GPS) is a satellite positioning system. A

constellation of satellites broadcasts signals around the world that can be used by GPS

receivers to determine positions using triangulation. The signals are free and can be

received anywhere on Earth where there is a clear view of the sky.

Q. How accurate is the GPS receiver?

A. GPS accuracy ranges from 20 meters to 100 meters. Most of the time the GPS is

accurate within 30 meters, which is about 32 yards.

Q. What is an ideal GPS environment?

A. The GPS receiver requires an open, clear view of the sky. Buildings, covered

parking areas, tunnels, and dense foliage can hinder the GPS signals. Weather

conditions do not impact the performance of GPS. If you are parked in a covered

parking lot or near a tall building, it is recommended that you move away to have a

clear view of the sky and then use PC*MILER|Mobile. The phone should be attached

to the windshield in the holder for best performance.

PC*MILER|Mobile User’s Guide 37

Q. Where is the GPS receiver?

A. The GPS receiver is embedded in the i88s/i58sr phone. The internal GPS antenna

is near the top of the phone by the power button. For best performance, the phone

should be attached to the windshield in glass-mount phone holder.

Q. How do I know that the GPS has a signal?

A. The PC*MILER|Mobile application on your phone will alert you if the GPS does

not have a valid signal by displaying NO GPS on the screen. If this happens, and lasts

more than a few seconds, drive to an area where there is a clear view of the sky so the

GPS can receive the satellite signals.

Q. How do I know if I am in a Nextel coverage area?

A. Check the power button. If it is flashing green, you are within the coverage area.

If the power button is red, the phone is out of network coverage.

Q. How do I know if I have data services?

A. On the top of the Nextel screen, you should see an IP symbol next to the signal

strength indicator. If the signal strength has 2 or more bars but the IP icon is missing,

the phone does not have data services and will not work properly.

Q. What maps are used in PC*MILER|Mobile?

A. Navtech provides the digital road map data that is used to compute routes and

directions for the PC*MILER|Mobile system.

Q. How well does ALK Technologies’ map data cover the U.S.?

A. ALK’s map data covers metropolitan and suburban areas in the US extremely well,

and they are continually improving their coverage of the rural areas. Additionally,

ALK has the most extensive road attributes in order to enable PC*MILER|Mobile to

provide the best possible turn-by-turn guidance experience.

PC*MILER|Mobile

Q. How do I repeat an instruction?

A. You can repeat the audio message by pressing the green Send button on the phone.

Q. Can I preview the navigation instructions?

A. Yes. You can preview the list of directions by scrolling up or down through the

list. In guidance mode, you can scan forward or backward through the maneuvers at

any time during guidance using the right/left navigation button. If driving a route when

scrolling through instructions, you should return to the current instruction screen to

keep your display in synch with your route’s progress.

38 PC*MILER|Mobile User’s Guide

Q. Can I enter the intersection of two streets?

A. Yes. To enter an intersection of two streets, type in both street names separated by

a plus sign (+). To enter the plus sign, press the 0 key twice.

Q. Why won’t PC*MILER|Mobile accept my address?

A. It may be that the spelling is incorrect or the abbreviations are not recognized. Try

using alternate abbreviations or spelling them out; e.g. “Saint” instead of “St.”

Q. Can I receive calls when using PC*MILER|Mobile?

A. Yes. However, the iDEN handset cannot transfer phone data and packet data at the

same time. When a network-enabled application is transmitting packet data, the phone

services will be blocked. Packet data service will incur charges to the account.

Q. Can I place calls when using PC*MILER|Mobile?

A. To make a call, press the red End button twice to pause PC*MILER|Mobile.

Q. How do I make a call using hands-free operation?

A. Press the button under SPEAKER to toggle between speaker on/off. For hands-free

operation, the speaker should be set to on.

Q. How do I make the guidance instructions louder?

A. You can change the volume of the verbal guidance instructions in

PC*MILER|Mobile by changing the ringer volume, using the rocker keys on the left

side of the phone. You must do this while PC*MILER|Mobile is running and giving a

verbal instruction.

Q. Why do the verbal instructions sound muffled?

A. You may not have the speakerphone activated. Press the button on the upper left

side of the phone to activate the speakerphone.

Q. When I turn off my engine, why is the PC*MILER|Mobile backlight on?

A. Most vehicles provide power to the cigarette lighter adapter even when the engine

is off and the ignition key is removed. You should remove the power plug from the

lighter socket and turn the phone off to avoid draining the battery.

Q. Why do I hear “You have left the route” when I have not?

A. Temporarily, the inaccuracy of the map data and the GPS results may cause the

phone to think that it is not on the planned route. If you have not left the route, the

phone should resume guidance momentarily.

PC*MILER|Mobile User’s Guide 39

PC*MILER|Mobile Group Management and Tracking

Q. Can the tracking mode be switched off?

A. Yes, the user can switch the tracking feature to ON or OFF on the phone menu, by

selecting the Change Options menu item.

Q. Can the access to the group management feature be restricted?

A. Yes, you can use an administrator password to restrict the access to the group

management functionalities.

Q. My tracking feature is activated. Why is the handset position not

displayed on the tracking web page?

A. Please check and adjust the date and time settings of the handset. This information

is used to validate that the GPS position is not outdated.

Motorola I88s PCM Mobile User Guide.2.2.x I88 Manual To The 0b8aa718 2a89 461d Ba28 9de65c4b8589

Navigation menu

Versions of this User Manual:

Views

Navigation
