Moxa IAW5X50A RS-232/422/485 IEEE 802.11a/b/g/n wireless device server with I/O User Manual
Moxa Inc. RS-232/422/485 IEEE 802.11a/b/g/n wireless device server with I/O Users Manual
Moxa >
Users Manual
![](/img.php?id=3267113&img=bg1.png)
![](/img.php?id=3267113&img=bg2.png)
![](/img.php?id=3267113&img=bg3.png)
Risk of Explosion if Battery is replaced by an Incorrect Type. Dispose of
Used Batteries According to the Instructions."
![](/img.php?id=3267113&img=bg4.png)
![](/img.php?id=3267113&img=bg5.png)
![](/img.php?id=3267113&img=bg6.png)
![](/img.php?id=3267113&img=bg7.png)
![](/img.php?id=3267113&img=bg8.png)
![](/img.php?id=3267113&img=bg9.png)
-10-
D. Federal Communication Commission
Interference Statement
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant
to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates, uses and can radiate radio frequency
energy and, if not installed and used in accordance with the instructions, may cause harmful interference
to radio communications. However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or television reception, which can
be determined by turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
CAUTION:
Any changes or modifications not expressly approved by the grantee of this device could void the user’s
authority to operate the equipment.
Labeling requirements
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) this device may not cause harmful interference, and (2) this device must accept any interference
received, including interference that may cause undesired operation.
RF exposure warning
This equipment must be installed and operated in accordance with provided instructions and the
antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm
from all persons and must not be co-located or operating in conjunction with any other antenna or
transmitter. End-users and installers must be provide with antenna installation instructions and
transmitter operating conditions for satisfying RF exposure compliance.
This radio transmitter FCCID: SLE-IAW5X50A has been approved by FCC to operate with the
antenna types listed below with the maximum permissible gain and required antenna
impedance for each antenna type indicated. Antenna types not included in this list, having a
gain greater than the maximum gain indicated for that type, are strictly prohibited for use
![](/img.php?id=3267113&img=bgb.png)
-11-
with this device.
Antenna List
No.
Manufacturer Part No. Antenna Type Peak Gain
1 KINSUN 6602D03081 Dipole 2.04 dBi for 2.4 GHz
0.38 dBi for 5 GHz
Note: The antenna connector is Reverse SMA type.
