PRELIMINARY SPECIFICATION
InVisionTM Wireless Network
Gateway GTW-1
Designer Specifications
June 29, 2006
CONFIDENTIAL. THE PROPERTY IN THIS DOCUMENT IS THE PROPERTY OF COOPER INDUSTRIES, INC. IT IS NOT FOR PUBLIC DISCLOSURE. POSSESSION OF THE
INFORMATION DOES NOT CONVEY ANY RIGHT TO LOAN, SELL OR DISCLOSE THE INFORMATION. UNAUTHORIZED REPRODUCTION OR USE OF THE INFORMATION IS
PROHIBITED. THIS DOCUMENT IS TO BE RETURNED TO COOPER INDUSTRIES, INC. UPON COMPLETION OF THE PURPOSE FOR WHICH IT IS LOANED OR UPON
REQUEST.
COPYRIGHT. COOPER INDUSTRIES, INC. This is an unpublished work. The disclosure of this work is limited to select personnel. Further dissemination or disclosure to the public
is PROHIBITED. This unpublished work is protected by Federal Copyright law and all rights thereunder are reserved by Cooper Industries, Inc.
InVisionTM Wireless Network
Preliminary Designer Specifications
Gateway GTW-1
June 29, 2006
Page 1 of 5
CONFIDENTIAL. THE PROPERTY IN THIS DOCUMENT IS THE PROPERTY OF COOPER INDUSTRIES, INC. IT IS NOT FOR PUBLIC DISCLOSURE. POSSESSION OF THE
INFORMATION DOES NOT CONVEY ANY RIGHT TO LOAN, SELL OR DISCLOSE THE INFORMATION. UNAUTHORIZED REPRODUCTION OR USE OF THE INFORMATION IS
PROHIBITED. THIS DOCUMENT IS TO BE RETURNED TO COOPER INDUSTRIES, INC. UPON COMPLETION OF THE PURPOSE FOR WHICH IT IS LOANED OR UPON
REQUEST.
SYSTEM DESCRIPTION
The Bussmann InVisionTM Network is a wireless sensor network that will allow data to be
transmitted about the status of sensors monitoring overcurrent protection devices with in a
facility. The system uses a mesh network topology to enable highly reliable data
transmission. The data is then sent to a web based portal. The portal allows the user to
define how they wish to be notified upon an event occurring with in the network of sensors
they are monitoring. The network operates in the 900MHz range of the ISM band of the
frequency spectrum.
The sensors operate on a different frequency from the data transport layer of the network.
The mesh network operates on a second frequency. This allows for the system to have a
high reliability and minimize data collisions.
GATEWAY DESCRIPTION
The gateway is the central point for data collection and transmission to the web based
portal. The gateway is comprised of several separate sub-systems. It contains a power
supply, a single board computer, and a base station radio. The power supply is a medical
grade UL rated 120/240V AC power supply with on board overvoltage and overcurrent
protection. The single board computer is a PC 104 form factor running Linux operating
system. It provides a serial port for direct access. Additionally, it provides Ethernet
connectivity to allow data to be sent to the web portal. The base station radio collects all
incoming messages from the mesh network. There is an external antenna for the base
radio. It then passes this information to the computer. The computer then processes this
data eliminates duplicates and transmits via Ethernet. The gateway uses CompactFlash for
storage.
The gateway has two sets of status LED’s. One set is used to give status of the mesh
network. The second set is used to provide status of the computer and Ethernet
connectivity.
The gateway allows for bidirectional communication. The portal is capable of issuing
network commands to the gateway to assist in network management. Communication is
secure via SSL. Data is also encrypted for provide and additionally layer of security.
COPYRIGHT. COOPER INDUSTRIES, INC. This is an unpublished work. The disclosure of this work is limited to select personnel. Further dissemination or disclosure to the public
is PROHIBITED. This unpublished work is protected by Federal Copyright law and all rights thereunder are reserved by Cooper Industries, Inc.
InVisionTM Wireless Network
Preliminary Designer Specifications
Gateway GTW-1
June 29, 2006
Page 2 of 5
CONFIDENTIAL. THE PROPERTY IN THIS DOCUMENT IS THE PROPERTY OF COOPER INDUSTRIES, INC. IT IS NOT FOR PUBLIC DISCLOSURE. POSSESSION OF THE
INFORMATION DOES NOT CONVEY ANY RIGHT TO LOAN, SELL OR DISCLOSE THE INFORMATION. UNAUTHORIZED REPRODUCTION OR USE OF THE INFORMATION IS
PROHIBITED. THIS DOCUMENT IS TO BE RETURNED TO COOPER INDUSTRIES, INC. UPON COMPLETION OF THE PURPOSE FOR WHICH IT IS LOANED OR UPON
REQUEST.
Simplified Gateway Diagram
COPYRIGHT. COOPER INDUSTRIES, INC. This is an unpublished work. The disclosure of this work is limited to select personnel. Further dissemination or disclosure to the public
is PROHIBITED. This unpublished work is protected by Federal Copyright law and all rights thereunder are reserved by Cooper Industries, Inc.
InVisionTM Wireless Network
Preliminary Designer Specifications
Gateway GTW-1
June 29, 2006
Page 3 of 5
CONFIDENTIAL. THE PROPERTY IN THIS DOCUMENT IS THE PROPERTY OF COOPER INDUSTRIES, INC. IT IS NOT FOR PUBLIC DISCLOSURE. POSSESSION OF THE
INFORMATION DOES NOT CONVEY ANY RIGHT TO LOAN, SELL OR DISCLOSE THE INFORMATION. UNAUTHORIZED REPRODUCTION OR USE OF THE INFORMATION IS
PROHIBITED. THIS DOCUMENT IS TO BE RETURNED TO COOPER INDUSTRIES, INC. UPON COMPLETION OF THE PURPOSE FOR WHICH IT IS LOANED OR UPON
REQUEST.
Simplified Network Layout
COPYRIGHT. COOPER INDUSTRIES, INC. This is an unpublished work. The disclosure of this work is limited to select personnel. Further dissemination or disclosure to the public
is PROHIBITED. This unpublished work is protected by Federal Copyright law and all rights thereunder are reserved by Cooper Industries, Inc.
InVisionTM Wireless Network
Preliminary Designer Specifications
Gateway GTW-1
June 29, 2006
Page 4 of 5
CONFIDENTIAL. THE PROPERTY IN THIS DOCUMENT IS THE PROPERTY OF COOPER INDUSTRIES, INC. IT IS NOT FOR PUBLIC DISCLOSURE. POSSESSION OF THE
INFORMATION DOES NOT CONVEY ANY RIGHT TO LOAN, SELL OR DISCLOSE THE INFORMATION. UNAUTHORIZED REPRODUCTION OR USE OF THE INFORMATION IS
PROHIBITED. THIS DOCUMENT IS TO BE RETURNED TO COOPER INDUSTRIES, INC. UPON COMPLETION OF THE PURPOSE FOR WHICH IT IS LOANED OR UPON
REQUEST.
INTENDED APPLICATION
The InVisionTM Wireless Network can be used for any industrial or commercial application
that requires overcurrent circuit protection products that has the need to be monitored and
notification to the user.
Gateway GTW-1 ELECTRICAL SPECIFICATIONS
Input voltage:.....................................................120/240 V AC
Input Frequency: ...............................................50 – 60 Hz
Power Consumption:.........................................11.5 W
Operating Frequency:........................................
IFM Receiver Channel............................916.5MHz
Mesh Transceiver Channel.....................904.0MHz
THERMAL SPECIFICATIONS
Operating temperature range:...........................-20°C to 50°C
Relative Humidity: .............................................10-95% Non-condensing
MECHANICAL SPECIFICATIONS
Dimensions:...................................................... 12.4” x 2.875” x 7.5”
Enclosure Material:...........................................Cold Rolled Steel, Powder Coated
Weight:..............................................................3.0 pounds
HANDLING & STORAGE SPECIFICATIONS
Storage Temperature: ............................ -40°C to 85°C
COPYRIGHT. COOPER INDUSTRIES, INC. This is an unpublished work. The disclosure of this work is limited to select personnel. Further dissemination or disclosure to the public
is PROHIBITED. This unpublished work is protected by Federal Copyright law and all rights thereunder are reserved by Cooper Industries, Inc.
InVisionTM Wireless Network
Preliminary Designer Specifications
Gateway GTW-1
June 29, 2006
Page 5 of 5
CONFIDENTIAL. THE PROPERTY IN THIS DOCUMENT IS THE PROPERTY OF COOPER INDUSTRIES, INC. IT IS NOT FOR PUBLIC DISCLOSURE. POSSESSION OF THE
INFORMATION DOES NOT CONVEY ANY RIGHT TO LOAN, SELL OR DISCLOSE THE INFORMATION. UNAUTHORIZED REPRODUCTION OR USE OF THE INFORMATION IS
PROHIBITED. THIS DOCUMENT IS TO BE RETURNED TO COOPER INDUSTRIES, INC. UPON COMPLETION OF THE PURPOSE FOR WHICH IT IS LOANED OR UPON
REQUEST.
FCC Labels and Notices
This device complies with Part 15 of the FCC rules. Operation is subject to the following
two conditions: (1) this device may not cause and harmful interference, and (2) this device
must accept any interference received, including interference that may cause undesired
operation.
WARNING: This devices operates under part 15 of the FCC rules. Any modification to this
device not expressly authorized by Cooper Bussmann, Inc. may void the user’s authority to
operate this device.
Note: This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This
equipment generates, uses, and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on, the user
is encouraged to try to correct the interference by one or more of the following measures:
1. Reorient or relocate the receiving antenna.
2. Increase the separation between the equipment and receiver.
3. Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
4. Consult the dealer or an experienced radio/TV technician for help
This product specification is intended to clearly present comprehensive product data and
provide technical information that will help the end user with design applications.
Bussmann reserves the right, without notice, to change design or construction of any
products and to discontinue or limit distribution of any product. Bussmann also reserves
the right to change or update, without notice, any technical information contained in this
bulletin. Once a product has been selected, it should be tested by the user in all possible
applications.
For the current revision of this document please contact the person(s) below.
Michael C. Henricks
mhenricks@cooperbussmann.com
636-527-1366 Phone
636-207-4838 FAX
