Murata LB1CA Communication Module User Manual LBWA1ZZ1CA Installation Manual
Murata Manufacturing Co., Ltd. Communication Module LBWA1ZZ1CA Installation Manual
Murata >
Users manual
1
Copyright © Murata Manufacturing Co., Ltd. All rights reserved. 19 February 2016
1CA Installation Manual
FCC ID of this product is as follows.
FCC ID:VPYLB1CA
For OEM integration only – device cannot be sold to general public.
Therefore we will ask OEM to include the following statements required
by FCC on the product and in the Installation manual Notice.
Contents
1.Connector
2.Supply Voltage
3.Power Levels
4.Notice
Confidential
6
Copyright © Murata Manufacturing Co., Ltd. All rights reserved. 19 February 2016
4. Notice
Contains Transmitter Module FCC ID:VPYLB1CA
Contains FCC ID:VPYLB1CA
or
Please describe the following warning on the final product which contains this module.
Confidential
※When the product is small, as for these words mentioned above, the posting to a manual is possible.
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This
device may not cause harmful interference, and (2) this device must accept any interference received, including
interference that may cause undesired operation.
7
Copyright © Murata Manufacturing Co., Ltd. All rights reserved. 19 February 2016
4. Notice
Confidential
●Please describe the following warning to the manual.
Note)
Portable equipment : Equipment for which the spaces between human body and antenna are used within 20cm.
Mobile equipment : Equipment used at position in which the spaces between human body and antenna exceeded 20cm.
●When installing it in a mobile equipment. Please describe the following warning to the manual.
●When installing it in a portable equipment.
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment and meets
the FCC radio frequency (RF) Exposure Guidelines. This equipment should be installed and operated keeping the
radiator at least 20cm or more away from person’s body.
It is necessary to take a SAR test with your set mounting this module.
Class II permissive change application is necessary using the SAR report.
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This
device may not cause harmful interference, and (2) this device must accept any interference received, including
interference that may cause undesired operation.
FCC CAUTION
Changes or modifications not expressly approved by the party responsible for compliance could void the user’s
authority to operate the equipment.
This transmitter must not be co-located or operated in conjunction with any other antenna or transmitter.
