Murata LB1EU Communication Module User Manual LBWA1ZZ1CA Installation Manual
Murata Manufacturing Co., Ltd. Communication Module LBWA1ZZ1CA Installation Manual
Murata >
Users manual
1
Copyright © Murata Manufacturing Co., Ltd. All rights reserved. 29 June 2016
LBBA0ZZ1EU User Manual
FCC ID and IC No. of this product is as follows.
FCC ID : VPYLB1EU
IC No. : 772C-LB1EU
Contents
1.Notice
2
Copyright © Murata Manufacturing Co., Ltd. All rights reserved. 29 June 2016
1. Notice
or
※When the product is small, as for these words mentioned above, the posting to a manual is possible.
Contains Transmitter Module FCC ID:VPYLB1EU Contains FCC ID: VPYLB1EU
This device complies with Part 15 of FCC Rules and Industry Canada’s licence-exempt RSSs. Operation is subject
to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept
any interference received, including interference that may cause undesired operation.
Le présent appareil est conforme à la partie 15 des règles de la FCC et aux normes des CNR d'Industrie Canada
applicables aux appareils radio exempts de licence. L'exploitation est autorisée aux deux conditions suivantes : (1)
l'appareil ne doit pas produire de brouillage, et (2) l'appareil doit accepter tout brouillage subi, même si le brouillage
est susceptible d'en compromettre le fonctionnement.
For OEM integration only – device cannot be sold to general public.
Therefore we will ask OEM to include the following statements required
by FCC/IC on the product and in the Installation manual Notice.
Please describe the following warning on the final product which contains this module.
Contains IC: 772C-LB1EU
This radio transmitter (772C-LB1EU) has been approved by Industry Canada to operate with the antenna types listed
below with the maximum permissible gain indicated. Antenna types not included in this list, having a gain greater
than the maximum gain indicated for that type, are strictly prohibited for use with this device.
Antenna type : Monopole Antenna Gain : 1.7dBi
Le présent émetteur radio (772C-LB1EU) a été approuvé par Industrie Canada pour fonctionner avec les types
d'antenne énumérés ci-dessous et ayant un gain admissible maximal. Les types d'antenne non inclus dans cette
liste, et dont le gain est supérieur au gain maximal indiqué, sont strictement interdits pour l'exploitation de l'émetteur.
Type d’antenne : Antenne de Monopôle Gain : 1.7dBi
3
Copyright © Murata Manufacturing Co., Ltd. All rights reserved. 29 June 2016
1. Notice
Note)
Portable equipment : Equipment for which the spaces between human body and antenna are used within 20cm.
Mobile equipment : Equipment used at position in which the spaces between human body and antenna exceeded 20cm.
●When installing it in a portable equipment.
FCC：Class II permissive change application is necessary.
IC： Class II permissive change application and SAR test are necessary.
Please contact Murata.
This equipment complies with FCC/IC radiation exposure limits set forth for an uncontrolled environment and meets
the FCC radio frequency (RF) Exposure Guidelines and RSS-102 of the IC radio frequency (RF) Exposure rules. This
equipment should be installed and operated keeping the radiator at least 20cm or more away from person’s body.
Cet équipement est conforme aux limites d’exposition aux rayonnements énoncées pour un environnement non
contrôlé et respecte les règles les radioélectriques (RF) de la FCC lignes directrices d'exposition et d’exposition
aux fréquences radioélectriques (RF) CNR-102 de l’IC. Cet équipement doit être installé et utilisé en gardant une
distance de 20 cm ou plus entre le radiateur et le corps humain.
●When installing it in a mobile equipment.
Please describe the following warning to the manual.
●Please describe the following warning to the manual.
FCC CAUTION
Changes or modifications not expressly approved by the party responsible for compliance could void the user’s
authority to operate the equipment.
This transmitter must not be co-located or operated in conjunction with any other antenna or transmitter.
