Type1NX User Manual for FCC
1
Copyright © Murata Manufacturing Co., Ltd. All rights reserved.
30 January 2018
FCC ID:VPYLB1NX
Since this module is not sold to general end users directly, there is no user manual of module.
For the details about this module, please refer to the specification sheet of module.
This module should be installed in the host device according to the interface specification (installation procedure).
●
The following information must be indicated on the host device of this module.
Contains Transmitter Module FCC ID:VPYLB1NX or Contains FCC ID: VPYLB1NX
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not
cause harmful interference, and (2) this device must accept any interference received, including interference that may cause
undesired operation.
*If it is difficult to describe this statement on the host device due to the size,
please describe in the user's manual and also either describe on the device packaging or on a removable label attached to the device.
Type1NX User Manual for FCC
2
Copyright © Murata Manufacturing Co., Ltd. All rights reserved.
30 January 2018
●
The
following statements must be described on the user manual of the host device of
this module;
FCC CAUTION
Changes or modifications not expressly approved by the party responsible for compliance
could void the user’s authority to operate the equipment.
This transmitter must not be co-located or operated in conjunction with any other antenna or transmitter.
When
installing it in a mobile equipment.
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment and meets the FCC radio
frequency (RF) Exposure Guidelines. This equipment should be installed and operated keeping the radiator at least 20cm or more
away from person’s body.
When
installing it in a portable equipment.
It is necessary to take a SAR test with your set mounting this module.
Class II permissive change application is necessary using the SAR report.
Please contact Murata.
Note)
Portable equipment : Equipment for which the spaces between human body and antenna are used within 20cm.
Mobile equipment : Equipment used at position in which the spaces between human body and antenna exceeded 20cm.
Type1NX User Manual for FCC
3
Copyright © Murata Manufacturing Co., Ltd. All rights reserved.
30 January 2018
Compliance with FCC requirement 15.407(c)
Data transmission is always initiated by software, which is the passed down through the MAC, through the digital
and analog baseband, and finally to the RF chip. Several special packets are initiated by the MAC. These are
the only ways the digital baseband portion will turn on the RF transmitter, which it then turns off at the end of the
packet. Therefore, the transmitter will be on only while one of the aforementioned packets is being transmitted.
In other words, this device automatically discontinue transmission in case of either absence of information to
transmit or operational failure.
Frequency Tolerance:
±
20 ppm
