Murata SUX-1277 WirelessHD source radio module User Manual Murata WirelessHD Source Radio Module
Murata Manufacturing Co.,Ltd. WirelessHD source radio module Murata WirelessHD Source Radio Module
Murata >
Installation Manual
WMCS-09-9
Murata Confidential Page 1 May 2009
Murata WirelessHD Source Radio Module
SUX-1277
Installation Manual
Contents
1. Overview
2. Installation
Murata Manufacturing Co., Ltd.
WMCS-09-9
Murata Confidential Page 2 May 2009
1. Overview
SUX-1277 is a WirelessHD source transceiver module that is installed in a
high-definition (HD) video/audio source system, e.g. DVD player, set top box, or HDTV
control box,.... It is designed to operate as part of a Wireless video/audio Network
(WVAN) in the 57 to 64GHz band. HD video/audio data input from a video connector is
re-processed and up-converted to 60 GHz-band mm-wave signal, and is transmitted
via the patch-array antenna.
2. Installation
SUX-1277 shall be installed into a video/audio source system with the patch array
antenna facing the front of the system. SUX-1277 needs to be grounded to a system
ground. Some fixing holes can be used as a ground terminal. A shielded cable needs to
be used as a video/audio cable connected to the module.
Patch array antenna
Connect video/audio cable
Fixing holes
Fig.1 SUX-1277 Installation Overview
WMCS-09-9
Murata Confidential Page 3 May 2009
USA-Federal Communications Commission (FCC)
This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to Part 15 of FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This
equipment generates, uses, and can radiate radio frequency energy. If not installed and
used in accordance with the instructions, it may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a
particular installation.
If this equipment does cause harmful interference to radio or television reception, which
can be determined by tuning the equipment off and on, the user is encouraged to try
and correct the interference by one or more of the following measures:
-Reorient or relocate the receiving antenna.
-Increase the distance between the equipment and the receiver.
-Connect the equipment to outlet on a circuit different from that to which the receiver is
connected.
-Consult the dealer or an experienced radio/TV technician for help.
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and
(2) This device must accept any interference received, including interference that may
cause undesired operation.
Any changes or modifications not expressly approved by the party responsible for
compliance could void the user‟s authority to operate the equipment.
Labeling
MURATA Wireless HD source radio module SUX-1277 labeled as below.
FCC ID: XCSSUX-1277
The proposed with FCC ID label format is to be placed on the module. If FCC ID is not
visible when the module is installed into the system, “Contains FCC ID: XCSSUX-1277”
shall be placed on the outside of final host system.
WMCS-09-9
Murata Confidential Page 4 May 2009
Caution: Exposure to Radio Frequency Radiation.
To comply with FCC RF exposure compliance requirements, a separation distance of at
least 20 cm must be maintained between the antenna of this device and all persons.
This device must not be co-located or operating in conjunction with any other antenna
or transmitter.
WMCS-09-9
Murata Confidential Page 5 May 2009
Canada-Industry Canada (IC)
This device complies with RSS 210 of Industry Canada.
Operation is subject to the following two conditions:
(1) This device may not cause interference, and
(2) This device must accept any interference, including interference that may cause
undesired operation of this device.
L „ utilization de ce dispositif est autorisée seulement aux conditions suivantes :
(1) il ne doit pas produire de brouillage et
(2) l‟ utilisateur du dispositif doit étre prêt à accepter tout brouillage radioélectrique reçu,
même si ce brouillage est susceptible de compromettre le fomctionnement du
dispositif.
The term “IC” before the equipment certification number only signifies that the Industry
Canada technical specifications were met.
To reduce potential radio interference to other users, the antenna type and its gain
should be so chosen that the equivalent isotropic radiated power (EIRP) is not more
than that required for successful communication.
To prevent radio interference to the licensed service, this device is intended to be
operated indoors and away from windows to provide maximum shielding. Equipment
(or its transmit antenna) that is installed outdoors is subject to licensing.
Pour empecher que cet appareil cause du brouillage au service faisant l‟objet d‟une
licence, il doit etre utilize a l‟interieur et devrait etre place loin des fenetres afinde
Fournier un ecram de blindage maximal. Si le matriel (ou son antenne d‟emission) est
installe a l‟exterieur, il doit faire l‟objet d‟une licence.
Labeling
MURATA Wireless HD source radio module SUX-1277 labeled as below.
IC: 8343A-SUX1277
The proposed with IC ID label format is to be placed on the module. If IC ID is not
visible when the module is installed into the system, “Contains IC: 8343A-SUX1277”
WMCS-09-9
Murata Confidential Page 6 May 2009
shall be placed on the outside of final host system.
Caution: Exposure to Radio Frequency Radiation.
The installer of this radio equipment must ensure that the antenna is located or pointed
such that it does not emit RF field in excess of Health Canada limits for the general
population; consult Safety Code 6, obtainable from Health Canada‟s website at
www.hc-sc.gc.ca/rpb.
