NEC Platforms RGA100L Wireless N ADSL2+ Modem Router User Manual
NEC Platforms, Ltd. Wireless N ADSL2+ Modem Router
User manual
RG-A100L
Instruction Manual
Wireless N ADSL2+ Modem Router
2
Contents
Contents ............................................. .................................... ........ 2
Important Product Information ....................................................... 3
FCC Regulatory Statements .......................................................... 4
Safety Instructions ......................................................................... 6
Notice ........................................................................................... 13
1. Package Contents ................................................................... 16
2. Part Names and Functions ...................................................... 17
3. Installation Space .................................................................... 22
4. Network Setup ......................................................................... 23
5. Web Setting ............................................................................. 25
6. Products Specifications ........................................................... 26
Customer Information .................................................................. 28
Windows® and Windows Vista® are registered trademarks of Microsoft
Corporation in the United States and other countries.
Windows Vista® is an operating system.
Copyright© NEC AccessTechnica, Ltd. 2013
3
Important Product Information
Important safety information regarding radio frequency (RF)
exposure and use when worn
To ensure compliance at all times with the Radio Equipment and
Telecommunications Terminal Equipment Directive 1999/5/EC*
(R&TTE Directive) the equipment when in operation requires a
minimum of 7cm separation from the body. Failure to observe
these instructions could result in your RF exposure exceeding the
compliance with Annex II of Council Recommendation 1999/519/EC.
* The General Public RF exposure limits referenced in the R&TTE
Directive are consistent with the guidelines of the International
Commission on Non-Ionizing Radiation Protection (ICNIRP)
published in 1998.
ICNIRP is the formally recognized non-governmental organization
in Non-Ionizing Radiation Protection for the World Health
Organization (WHO), the International Labour Organization (ILO)
and the European Union (EU).
We, NEC AccessTechnica, Ltd. hereby, declare that the residential
gateway model RG-A100L is in compliance with the essential
requirements and other relevant provisions of Directive 1999/5/EC.
A copy of the 1999/5/EC Declaration of Conformity can be perused
in this Web address:
http://www.necat.co.jp/en/ce/RG-A100L_DoC.pdf
4
FCC Regulatory Statements
FCC part 68
This equipment complies with Part 68 of the FCC Rules. On the
bottom of this equipment is a label that contains the FCC
Registration Number and Ringer Equivalence Number (REN) for this
equipment. You must provide this information to the telephone
company upon request. The REN is useful to determine the quantity
of devices you may connect to the telephone line and still have
those entire devices ring when your number is called. In most, but
not all areas, the sum of the REN of all devices connected to one
line should not exceed five (5.0). To be certain of the number of
devices you may connect to your line, as determined by the REN,
you should contact your local telephone company to determine the
maximum REN for your calling area.
If the modem causes harm to the telephone network, the telephone
company may discontinue your service temporarily. If possible, they
will notify you in advance. But if advance notice isn't practical, you
will be notified as soon as possible. You will be advised of your right
to file a complaint with the FCC. The telephone company may make
changes in its facilities, equipment, operations, or procedures that
could affect the proper operation of your equipment. If they do, you
will be notified in advance to give you an opportunity to maintain
uninterrupted telephone service.
If you experience trouble with this modem, please contact your
dealer for repair/warranty information. The telephone company may
ask you to disconnect this equipment from the network until the
problem has been corrected or you are sure that the equipment is
not malfunctioning.
This equipment may not be used on coin service provided by the
telephone company. Connection to party lines is subject to state
tariffs.
Installation: This device is equipped with a USOC RJ-11C
connector.
5
FCC part 15
This equipment has been tested and found to comply with the limits
for Class B digital device, pursuant to Part 15 of the FCC regulations.
These limits are designed to provide reasonable protection against
harmful interface in a residential installation.
This equipment generates, uses and can radiate radio frequency
energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interface will
not occur in a particular installation. If this equipment does cause
harmful interface to radio or television reception, which can be
determined by turning the equipment off and on, the user is
encouraged to try to correct the interface by one or more of the
following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from
that to which the receiver is connected.
- Consult the dealer or an experienced radio/TV technician for
help.
Caution: Any changes or modifications not expressly approved by
the party responsible for compliance could void the user’s authority
to operate this equipment.
Note: This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions:
(1) This device may not cause harmful interface.
(2) This device must accept any interface received, including
interface that may cause undesired operation.
6
Safety Instructions
Please read these Safety Instructions carefully before using this product.
These Safety Instructions show items that must be followed to prevent danger
to any person and damage to property. Alert symbols below are important to
fully understand these Safety Instructions.
Alert symbols in this instruction manual
Warning ：Indicates a hazardous situation which could
result in death or serious injury.
Caution ：Indicates a situation which could result in
minor injury or physical damage.
Other alert symbols
Power
●Only use household power 100V-240V (50/60Hz). Do not
use any other power sources. Doing so may cause fire or
electric shock or malfunction.
Do not plug this product in a wall outlet where other
products are already plugged in and there is a risk of
exceeding the current rating of the outlet. Otherwise, a
fire, electric shock or malfunction may occur.
■ Warnings and cautions
Flammable Electric shock High Temperature
■ Prohibited actions
General No disassembly No water No wet hands No naked flames
■ Instructions
Remove plug from outlet
Warning
7
●Do not scratch, damage, or modify the power cord. Also,
do not forcibly bend, pull, twist or tie the cord. Otherwise,
a fire or electric shock may occur. If the power cord is
excessively pressed or heated up, the cord may be
damaged and a fire and electric shock may occur.
●Do not use an overloaded multi-plug adaptor. Otherwise,
the multi-plug adaptor may heat up and be degraded, and
then a fire may occur.
●For this product, only use the provided AC adaptor. Also,
do not use the AC adaptor of this product for other
products. Otherwise, a fire, electric shock or malfunction
may occur.
●Do not put anything on the AC adaptor or cover it with
cloth. Otherwise, the adaptor may heat up, the case and
cord may melt, and then a fire or electric shock may
occur.
●Do not place the AC adaptor in a poorly ventilated, or
confined area such as in storage rack or behind a
bookshelf. The AC adaptor may overheat and cause a
fire or damage. Also, place the AC adaptor near the
power outlet and ensure that you can easily plug in and
remove the AC adaptor.
Warning
8
In these cases
●Do not use this product if it smokes or has an abnormal
odor. Otherwise, a fire or electric shock may occur.
Remove the AC adapter from the outlet immediately.
Make sure that this product stops smoking, and call the
repair center or customer service shown in the attached
form. Never try to repair this product on your own.
●If water has entered inside of this product, remove the AC
adaptor from the outlet immediately and call the repair
center or customer service shown in the attached form. If
you continue using this product without having it repaired,
a fire, electric shock or malfunction may occur.
●Do not insert or drop metals or combustible materials into
the gaps. If those objects get inside this product, remove
the AC adaptor from the outlet immediately and call the
repair center or customer service shown in the attached
form. If you continue using this product without having it
repaired, a fire, electric shock or malfunction may occur.
Be cautious if you have any children in your family.
Warning
9
●Do not use this product with the power cord damaged, for
example with the core exposed or cut. Otherwise, a fire or
electric shock may occur. Immediately remove the AC
adaptor from the outlet and call the repair center or
customer service shown in the attached form.
●If this product is dropped or damaged, remove the AC
adaptor from the outlet immediately and call the repair
center or customer service shown in the attached form. If
you continue to use this product without having it
repaired, a fire or electric shock may occur.
●This product is an appliance designed for domestic use. It
must not be used in life-supporting medical equipment or
in any other system requiring extremely high reliability
(trunk-line communications equipment, calculation
systems etc.). Otherwise, death or serious injury may be
caused, and also huge social confusion may occur.
●Do not disassemble or convert this product. Otherwise, a
fire, electric shock or malfunction may occur.
●Do not operate or connect this product with wet hands.
Otherwise, an electric shock may occur.
●Do not use flammable gases such as an air duster or dust
spray inside or around this product. The gases may
ignite, causing a fire or explosion.
Warning
10
Other warnings
●Turn off this product in any place where use of a wireless
device is prohibited, for example in an airplane or
hospital. Otherwise, it may influence electronics and
medical devices, and cause an incident.
●Do not place or use this product near high-precision
electronics or devices which handle weak signals, for
example pacemakers. Otherwise, electronics such as
pacemakers may malfunction. Do not use this product
near medical electronics, or in any place where you are
prohibited from using this product, for example in a
hospital.
●Do not place this product near vases, pots, cups,
cosmetics, vessels with chemicals or water, or near any
small metal objects (staples etc.) which could fall through
the ventilation slots. If this product gets wet or a short
circuit occurs, it may cause a fire, electric shock or
malfunction.
●Do not place or use this product in a humid location such
as a bathroom and humidifier. Otherwise, a fire, electric
shock or malfunction may occur.
Warning
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions:(1) this device may
not cause harmful interference, and (2) this device must accept any
interference received, including interference that may cause undesired
operation.
The user that changes or modifications not expressly approved by the
party responsible for compliance could void the user's authority to
operate the equipment.
This equipment complies with RFCC radiation exposure limits set forth
for an uncontrolled environment .
This equipment should be installed and operated at least 20cm between
the radiator and your body.
11
Caution
Where you should place this product
●Do not place this product in an area exposed to direct
sunlight, near a heat generating appliance such as a
stove or a heater, or in a highly hot place. Otherwise, the
internal parts of this product may heat up, and a fire may
occur.
●Do not place this product in a place where the
temperatures change dramatically, for example near an
air conditioner or a heater. Otherwise, the internal parts of
this product may be wetted by condensation, and a fire,
electric shock or malfunction may occur.
●Do not place this product in a location exposed to cooking
oil or steam, for example near a cooker. Also, do not
place this product in a dusty place. Otherwise, a fire,
electric shock or malfunction may occur.
●Do not place this product in an unstable location such as
on an unstable table or inclined surface. Do not place any
heavy object on this product. Otherwise, this product may
lose balance and collapse, or the heavy object may drop
and an injury may occur.
●Do not place this product in a poorly ventilated space.
This product may heat up, and then a fire may occur.
Avoid the following.
- Placing this product inside a storage rack, bookshelf,
box, etc.
- Placing this product on a carpet and a mat
- Covering this product with a tablecloth, etc.
●Do not stack this product. Stacking this product may
cause a fire because of overheating inside product. Also,
ensure that there is enough space at either side of the
product.
12
Caution
Power
●When using this product, ensure that the power plug is
securely inserted into the outlet. Remove the power plug
from the outlet by pulling on the plug. Do not pull the
power cord. Otherwise, it may be damaged, and a fire or
electric shock may occur.
●Do not use in a state in which there is an accumulation of
dust between the power plug and outlet. Regularly, or
once every six months, remove dust. Otherwise, a fire
may occur.
●Before cleaning this product, pull out the AC power cord
from the outlet. Otherwise, an electric shock may occur.
●Before moving this product, remove the AC adaptor from
the outlet and disconnect all cords. Otherwise, the cords
may be damaged, and a fire or electric shock may occur.
●If this product will not be used for a long time, remove the
AC adaptor from the outlet for safety reasons.
●When or after using this product, the AC adaptor can
reach high temperatures. Be careful of burn injuries.
What you must not do
●During thunderstorms, do not touch the power cord or
connect to any surrounding product. Otherwise, an
electric shock caused by a thunderbolt may occur.
●Be careful not to stick the eyes into the antenna by
mistake.
13
Notice
Indicates a situation which could result in this product performing poorly or
malfunctioning.
Where you should place this product
●Do not place this product in any of the following locations:
- a place affected by vibration,
- a place where volatile chemicals are filled or where chemicals
are close by,
- a place affected by magnetism from an electric product or AV/OA
device, or a place where electromagnetic waves are emitted
(microwave ovens, speakers, TV sets, radios, fluorescent lamps,
air conditioners, electric cooking equipment, etc.), or
- a place near a high-frequency noise generating high-frequency
sewing machine or welding machine.
●If you use this product near a cordless phone or a radio, you may
hear noises. If you use it near a TV set, you may hear noises and
the screen may be unclear. Also, you may have poor reception.
Keep this product a few meters away from those devices.
●You may cause a data communication error if this product and the
wireless LAN terminal [client] are very close to each other. Keep
this product at least a meter away from other devices.
●Do not place this product in the vertical position. Otherwise this
product will be toppled over and then malfunction or damage may
occur. Do not use this product down on the ramp surface.
Otherwise it may cause malfunction or degrade communication
features because of inside overheating.
14
What you must not do
●Do not drop or hit this product. Otherwise, it may malfunction.
●Do not leave this product in a cold place such as an ice
warehouse. Otherwise, this product may operate abnormally.
●Disconnect all cords before moving this product. Otherwise, it may
malfunction.
●This product may operate abnormally if the connecting cords are
disconnected when it is on, or if the connection is unstable. When
this product is on, do not touch the connecting parts.
●Do not turn on this product immediately after you turn it off. Wait at
least 10 seconds to restart. It may not turn on if you attempt to turn
it back on immediately.
Other warnings
●If you turn off or disconnect this product during data
communication, communication may fail or data may be damaged.
If your data are important, check them against the original.
Notes on wireless LAN
●The standard values of wireless LAN are the maximum theoretical
values when communication is carried out with other products with
the same configuration as this product. The standard values may
not indicate the actual data transfer rate.
●The interconnectivity of this product with other products is not
guaranteed.
●Wireless LAN transmission distance and transmission speed
varies greatly depending on objects in the surrounding
environment such as walls and furniture.
15
Security notes on wireless LAN products
Wireless LAN has the advantage of a LAN connection without the
use of LAN cables if the device is placed within the reach of radio
waves. You can send and receive information between devices that
use radio waves such as a computer and the wireless LAN access
point (base unit). On the other hand, you may encounter the
following problems if you do not complete the settings related to
security because the radio waves reach beyond all obstacles such
as walls if within a certain range.
●Interception of information: Some malicious computer users
may intercept radio waves intentionally to discover your IDs,
passwords, credit card numbers, e-mails, etc.
●Unauthorized intrusion: Some malicious computer users may
access personal or office networks to gain personal or
confidential information and send out false data. Also, they may
intercept communication content, rewrite it, and then send it out.
Furthermore, they may send out computer viruses to destroy
data and systems.
Wireless LAN products already have security systems so there is a
low probability that any of the above problems will occur if you use
the product with these settings.
You should be fully aware of problems which may happen to you if
you do not do your security configuration. We recommend that you
use this product only after making the security setting you judge to
be necessary based on a proper understanding of the problems
which may occur if security settings are not configured.
We, NEC AccessTechnica, Ltd., do not take responsibility for any
damage caused by a security problem occurring because of a lack
of a security measure or an unavoidable issue with the wireless LAN
specifications.
In addition, we recommend changing the encryption key and PIN
code of the wireless LAN access point (base unit) on a regular basis
to ensure safe use of the wireless LAN.
16
1. Package Contents
This product package contains the following items.
□RG-A100L □AC adaptor □Line cable (1)
*The antenna and the main unit are packaged separately.
□Ethernet cable (1) □Splitter □Instruction manual
(With short line cable)
17
2. Part Names and Functions
Top
Indicators
Name Display Color of lamp Condition
(1) WPS
Illuminating in green. WPS setting succeeded.
Blinking in green. WPS is starting up.
OFF WPS is ready to start up.
(2) WLAN
Illuminating in green. Wireless connection is established.
Blinking in green. Wireless connection is activated.
OFF Wireless function is off.
(3) Internet
Illuminating in green. The Internet is available/without traffic.
Blinking in green. The Internet is available/with traffic.
Illuminating in red. The Internet is unavailable. (The IP
address could not be acquired)
OFF No DSL connection.
(4) DSL
Illuminating in green. The DSL link is established.
Blinking in green. The DSL link is having a trial.
OFF No signal.
(5) LAN(1~4)
Illuminating in green. The LAN port link is established.
Blinking in green. The LAN port is activated.
OFF The LAN port link is not established.
18
Indicators
Name Display Color of lamp Condition
(6) Power
Illuminating in green. Power is on.(normal)
Illuminating in red. Device startup failed.
OFF Power is off.
19
Back
Ports and others
Name Display Description
(1) DCIN jack Connect the AC adaptor to this jack.
(2) LAN port LAN(1~4) Connect the Ethernet cable to this port.
(3) DSL port DSL Connect the Line cable to this port.
Configuration switch
Name Display Description
(4) Power
ON/OFF
switch
ON/OFF This switch is for turning this product on or off.
(5) Reset switch RESET
This switch is for initialization.
Please use a non-conductive stick such as toothpick
to push the recessed reset switch.
20
Side
Switch
Name Display Description
(1) WPS switch WPS This switch is for activation of the WPS
configurations.
21
Product label
Look at the product label on the bottom of
this product to configure a wireless LAN
terminal [client].
*The label is an
example.
Network name
(SSID)
of initial
state and coded key
22
3. Installation Space
This product should be installed and operated with a minimum
separation of 7 cm from any nearby walls (on all sides except the
bottom).
Keep this product away from refrigerators, TV sets and other noise
sources.
Caution
This product heats up
excessively if it is installed
in a poorly ventilated area.
It may cause a malfunction.
23
4. Network Setup
(1) Access the ADSL line.
① Connect the Splitter's DSL port and this product's DSL port using the
Line cable.
② Connect the Splitter's Phone port and the Phone's Line port using the
Telephone line cable.
③ Connect the Splitter's Line port into the modular jack.
PC
(2) Connect the PC.
Turn off the PC beforehand. Connect the LAN port of this product and your
PC using an Ethernet cable.
(3) Connect the AC adaptor to the DCIN jack.
(4) Plug the AC adaptor into an outlet.
24
(5) Turn on this product by pushing the power ON/OFF switch.
(6) Make sure that the power lamp illuminates in green.
Caution
Ensure that you make connections in accordance with the
instruction manual. Any connection mistakes may cause a
malfunction in the connected devices or connection equipment.
25
5. Web Setting
(1) Start the PC and others.
(2) Start a WWW browser, enter "http://192.168.1.1/" and open the
page for Web configurations.
(3) Enter the user name and password. The user name is "admin"
and the password is "1234" (default value).
(4) Select the menu you want to modify, and proceed.
26
6. Products Specifications
Item Condition
DSL port
Physical interface 6 PIN modular jacks (RJ-11)
Port 1 port
Type Type ITU-T G.992.1/2/3/5 Annex A/L/M
ANSI T1.413
LAN port
Physical interface 8 PIN modular jacks (RJ-45)
Port 4 ports (switching hub built in)
Type 100BASE-TX/10BASE-T (IEEE802.3u/IEEE802.3)
Auto MDI/MDI-X
Wireless
LAN
Antenna External Antenna
IEEE802.11b
Frequency
band/CH 2.4GHz (2412-2472MHz)/1-13ch
Bit rate 1/2/5.5/11Mbps
IEEE802.11g
Frequency
band/CH 2.4GHz (2412-2472MHz)/1-13ch
Bit rate 6/9/12/18/24/36/48/54Mbps
IEEE802.11n
Frequency
band/CH 2.4GHz (2412-2472MHz)/1-13ch
Bit rate 6.5 Mbps to 150 Mbps (HT20/40)
Operating conditions Temperature: 0 to 40 °C
Humidity: 10 to 90%
Dimensions Approx. 147.5 (W) x 114.5 (D) x 35.5 (H) mm
(Not including the projection portion)
Power source AC100V-240V 50/60Hz
Power consumption Up to 4.5W
Weight Approx. 0.25 kg (excluding the AC adaptor)
27
Notice
(1) All rights reserved. No part of this manual may be copied or
reproduced without prior permission.
(2) Contents of this manual may change without notice.
(3) We take every possible precaution to ensure the accuracy of this
manual, but if anything is unclear or erroneous in the content,
please contact us. (http://www.necat.co.jp/)
(4) We assume no responsibility whatsoever for any failure,
malfunction, accident, trouble or damage resulting from external
causes such as erroneous operation, natural disasters, faults
power cuts, etc.
(5) Please note that we shall not be responsible for any damage
resulting from security problems if no security measures are in
place or the wireless LAN specification is insecure.
(6) If the product is damaged in accidentally through inappropriate
use or unpredictable circumstances (e.g. thunderstorms or
electric current leakage), the product may not operate properly.
Please read this manual and follow the instructions carefully.
Disposing of your used NEC product
In the European Union
EU-wide legislation as implemented in each Member State
requires that used electrical and electronic products carrying the
mark (left) must be disposed of separately from normal
household waste. This includes the residential gateway or
electrical accessories, such as the AC Adaptor.
When you dispose of such products, please follow the guidance
of your local authority and/or ask the shop where you purchased
the product.
The mark on the electrical and electronic products only applies to
the current European Union Member States.
Outside the European Union
If you wish to dispose of used electrical and electronic products
outside the European Union, please contact your local authority
and ask for the correct method of disposal.
28
Customer Information
FCC 68
Customer Information
This equipment complies with Part 68 of the FCC rules and the
requirements adopted by the ACTA. On bottom of this equipment is
a label that contains, among other information, a product identifier of
[US: 7S4DL03BRG-A100L]. If requested, this number must be
provided to the telephone company. If this equipment [Wireles N
ADSL2+ Modem Router] causes harm to the telephone network, the
telephone company will notify you in advance that temporary
discontinuance of service may be required. But if advance notice
isn't practical, the telephone company will notify the customer as
soon as possible. Also, you will be advised of your right to file a
complaint with the FCC if you believe it is necessary. The telephone
company may make changes in its facilities, equipment, operations
or procedures that could affect the operation of the equipment. If this
happens the telephone company will provide advance notice in
order for you to make necessary modifications to maintain
uninterrupted service. If you experience trouble with this equipment,
you disconnect it from the network until the problem has been
corrected or until you are sure that the equipment is not
malfunctioning. Please follow instructions for repairing if any (e.g.
battery replacement section); otherwise do not alternate or repair
any parts of device except specified.
If the telephone company requests information on what equipment is
connected to their lines, inform them of:
(a) The telephone number that this unit is connected to,
(b) The ringer equivalence number [03]
(c) The USOC jack required [RJ11C], and
(d) The FCC Registration Number [7S4]
Items (b) and (d) are indicated on the label. The ringer equivalence
number (REN) is used to determine how many devices can be
connected to your telephone line. In most areas, the sum of the
RENs of all devices on any one line should not exceed five (5.0). If
too many devices are attached, they may not ring properly.
29
Service Requirements
In the event of equipment malfunction, all repairs should be
performed by our Company or an authorized agent. It is the
responsibility of users requiring service to report the need for service
to our Company or to one of our authorized agents. Service can be
facilitated through our office at:
Company name: NEC Corporation of America Company
Company address: 6535 N.State Hwy 161 Irving, TX 75039-2402
Tel: +01-214-262-3789
NEC AccessTechnica, Ltd.
RG-A100L Instruction Manual 1st Edition
AM1-002316-001 09/2013
