Contents

Users Manual

1
Voice/Videophone Calls
■ Making a Voice/Videophone Call
Making a Voice/Videophone Call .......................................................................................... 2
Switching a Voice/Videophone Call during a Call (Caller).................................................. 5
Making International Calls ......................................................................... 6
Using Handsfree Call during a Call................................................................. 8
Using the Redial/Dialed Calls/Received Calls Record..... 8
Using Chaku-moji .......................................................................................... 10
Showing/Hiding Caller ID When Making a Call ................................................................... 12
Sending Push Signals Quickly......................................................................... 12
Using the Prefix Function....................................................................................................... 13
Setting Sub-addresses When Making Calls ....................................... 14
Setting the Alarm Used for Reconnection.............................................. 14
Blocking Out Ambient Noise ..................................................................... 14
Making Handsfree Calls in the Car ........................................................ 14
■ Receiving a Voice/Videophone Call
Receiving a Voice/Videophone Call...................................................................................... 15
When the Other Party Switches a Voice/Videophone Call (Caller) ................................... 16
Using the Dial Keys to Answer a Call......................................................... 16
Ending/Holding Calls with the Display Rotated Counterclockwise...... 17
Adjusting the Earpiece Volume............................................................................ 17
Adjusting the Ring Volume............................................................................ 17
■ Settings for when you cannot take calls
Holding the Ringing/Current Call ....................................................... 18
Using the Public Mode.................................................................................................... 18
When You Cannot Answer a Received Call.................................................... 20
Having the Caller Leave a Message ....................................................... 21
Having Callers Leave a Message during an Incoming Call ...................... 22
Playing/Erasing Recorded Messages and Voice Memos................................................... 22
■ Setting the Videophone
Using Chara-den..................................................................................................................... 23
Setting Functions for the Videophone............................................................................. 23
Using the Videophone Connected to External Devices...................................................... 26
WORLD CALL
Hands-free
Redial/Dialed calls/Received calls
Chaku-moji
Pause dial
Sub-address setting
Reconnect signal
Noise reduction
In-car Hands-free
Answer setting
Setting when folded
Volume
Ring volume
Answer hold/Holding
Missed call
Record message
Quick message
2
Voice/Videophone Calls
Making a Voice/Videophone
Call
1Enter the phone number of the other
party
Always start by entering the
area code, even for calls
within the same area.
You can enter up to 80 digits
for the phone number.
However, only the last 26
digits are displayed.
<When you enter a wrong number>
■To insert a number
Press v to move the cursor to the number to
the left of the position where you want to insert
the number, then enter the number.
■To delete a number
Press v to move the cursor to the number you
want to delete, then press t.
Hold down t for 1 second or longer to delete
all the numbers to the left of the cursor and the
number in the cursor position.
■To re-enter the number
Move the cursor to the beginning or end of the
number and hold down t for 1 second or
longer to return to the standby screen.
2r (voice call), o (V.phone)
<Videophone>
■To make a videophone call with Chara-
den
XUu (FUNC)X"Select image"X"Chara-
den"XSelect Chara-den
Enter phone number
Function menu
¨
P.4
<Voice call>
" " flashes while dialing
and lights up during the
call.
■If you hear the busy
tone
The line is busy. Call again
after a while.
■If you hear a message
saying that the other
party cannot be reached
The other party's mobile phone is not turned
on or is out of signal range. Call again after a
while.
■If you hear a message requesting your
caller ID
Call again with Caller ID Notification enabled.
→P. 5 6
<Videophone>
" " flashes while dialing
a videophone call and
lights up during the call.
■If a videophone call is
not connected→P.4
■To switch between
camera image and
substitute image
XUu (FUNC)X
"Substitute image"⇔"My
side"
■To send video from the rear camera
Xd (Change)
Each time you press d (Change), the front
camera/rear camera switches.
■To switch the main screen
Xd (1 second or longer)
"Change main disp."→P. 4
■To enlarge the camera footage to be
sent
XAdjust the zoom using d
Zoom→P.170
■To mute the voice to send
Xa (マナー ) (1 second or longer)
The " " icon is displayed.
To cancel muting, press a (マナー ) for 1
second or longer again.
In-call
Videophone in-call
Function menu
¨
P.4
3
Voice/Videophone Calls
■To switch a voice/videophone call during a
call→P. 5
■To put the current voice/videophone call
on hold→P. 1 8
■When the 2in1 is in Dual mode
The Outgoing number selection screen appears.
Select a phone number.
3To end the call, press y
N
<Videophone call>
zIf you make a videophone call to an emergency
number (110, 119 or 118) from the FOMA terminal,
the call is automatically changed to a voice call.
zYou cannot receive i-mode mail or a MessageR/F
during a videophone call (you can receive SMS).
Received mail is kept at the i-mode Center and can be
retrieved using "Check new messages" after the
videophone call.
zDuring battery charge, when you talk over the
videophone using the rear camera and record 1Seg at
the same time, it may be possible that the videophone
automatically turns into no camera talking after
"Camera Off" message appears. It depends on how
high the FOMA terminal is heated.
zDigital communication charges are still applied to the
caller when the substitute image is displayed during a
videophone call.
Videophone
You can use the videophone call function
between terminals that support the DOCOMO
videophone system.
zDOCOMO's Videophone is compliant with the
3G-324M*2 international standard established
by the 3GPP*1 (the 3rd Generation Partnership
Project that sets standards for 3rd generation
mobile communications systems). Connections
with videophones using different standards
cannot be made.
*1: 3GPP (3rd Generation Partnership Project)
A regional standardization body established to
develop commonly applied technical specifications
for 3rd-generation mobile communications
systems (IMT-2000).
*2: 3G-324M
An international standard for 3rd-generation
mobile videophones.
■How to view the videophone screen
①Main screen (Camera image of the other party
is displayed at the time of purchase)
②Sub-screen (Your own camera image is
displayed at the time of purchase)
③Call duration
④Settings
: Sending or receiving voice/
Transmission error
: Sending or receiving video/
Transmission error
: Sending camera image/substitute
image/Chara-den
: Handsfree ON/OFF
: Muting
: Visual check in progress
: Photo mode (Portrait/Scenery/
Close-up)
: Key operation mode (DTMF
mode*1/Whole action mode*2/Parts
action mode*2)
*1: "Send DTMF tone/DTMF tone OFF"→P. 4
*2: "Using Chara-den"→P. 2 3
1
3
42
4
Voice/Videophone Calls
Enter phone number screen
(P.2)
Notify Caller ID→P. 5 6
Prefix numbers →P. 1 4
Chaku-moji→P. 1 1
Int'l call→P. 7
Multi Number→P. 4 1 2
Add to phonebook→P. 9 5
Compose message*→P. 2 0 0
Select image……Select Me/Chara-den for the image
used during a videophone call.
Select "Release settings" to cancel the setting.
* : Not available when 2in1 is in B mode.
Videophone in-call screen (P.2)
Petit message→P. 2 5
Decoration→P. 2 5
Off decoration……Delete the displayed message or
stamp.
Substitute image ⇔My side……Switch between the
camera image and the substitute image.
Rear camera⇔Front camera……Switch between the
front and rear cameras.
This setting is only retained during the call.
Change main disp.……Change the main display.
The screen changes in the order of "Displaying the image
from the other party's camera on your main screen" →
"Displaying the image from your own camera on your
main screen" → "Displaying only the image from the other
party's camera" → "Displaying only the image from your
own camera".
Visual check ⇔Visual check off……Check your
appearance with the front camera during a videophone
call. Or ends checking. " " appears and the substitute
image is sent to the other party during the visual check.
V.phone settings……Set the screen for videophone call.
Visual prefer.……Set the image sent to and
received from the other party from Normal/Prefer/
img qual/Prefer motion spd.
This setting is only retained during the call.
Brightness……Five brightness levels (-2 to 0 to +2)
are available.
White balance……Set image color tones.→P.159
This setting is also applied to the equivalent camera
functions.
Color mode set……Select Normal/Sepia/
Monochrome as an image effect .
This setting is only retained during the call.
Photo mode……Set the mode suited to the scene
being shot. →P.159
This setting cannot be set for the front camera.
Chara-den set.……You can set the following when
Chara-den is used. This setting cannot be set for the
camera images.
Switch Chara-den
Action List
Change Action
Switch image……Display the image selected in
"Substitute image" (P.24) on the other party's
display.
Display light……Set lighting of backlight.
All time ON (default)
Same as backlight……Light according to Lighting
in Display light.
FrontCamera Rev.……Set whether to display your
camera image as a mirror image (ON) or normal image
(OFF) on the FOMA terminal during a call.
Own number……Display your phone number during a
videophone call.
Send DTMF tone⇔DTMF tone OFF……Set/Cancel
push signal transmission mode during Chara-den.
Except for Chara-den, videophone calls are always in
push signal transmission mode.
Change to voice→P. 5
Loc. notification→P. 2 7 0
●If a videophone call is not connected
When a videophone call is not connected, the cause
of the failure appears.
zThe cause may not appear depending on the
situation.
zDepending on the type of other party's phone or
the possible lack of a network service subscription,
the reason may not accurately reflect the other
party's actual status.
Display Cause
Check number then
redial
The called phone number is not
used
Busy The line is busy
• This message may also
appear during packet
communication, depending on
the other party's terminal.
5
Voice/Videophone Calls
zIf the videophone call is not supported, your call is
automatically switched to a voice call when you set
"Auto redial as voice" to "ON". However, the call
may not be handled in this way if you call an ISDN
synchronous 64K access point, ISDN videophone
which does not support the 3G-324M standard (as
of May, 2008) or if you dial a wrong number. Note
that call charges may be applied in some cases.
Switching a Voice/
Videophone Call during a Call
(Caller)
zYou can use this function with terminals compatible
with voice call/videophone call switch.
zYou can switch the voice call only when you are the
caller.
zTo switch the call, the receiver needs to set "Ntfy
switch-mode" to notify of the switch beforehand.
→P. 2 4
<Example: To switch a voice call to a videophone
call>
1In-call screen (P.2)
X
d (V.phone)
X
"YES"
During switching, the screen which indicates that
the calls are being switched appears and voice
guidance is played.
■To switch a videophone call to a voice call
XVideophone in-call screen (P.2)Xu
(FUNC)X"Change to voice"
Busy with packet
transmission
The other party is using packet
communication
Out of service area/
power off
The other party is out of service
area or the phone is turned off
Your call is being
forwarded
The call is being forwarded (A
Videophone call is made when
the forwarding number is for a
3G-324M-compatible
videophone)
Redial using voice
call
The phone for the forwarding
number is not compatible with
videophone calls
Please activate
caller ID before
dialing again
The other party has set the
Caller ID request service
This number is not
available
The other party has set the
Nuisance call blocking service
Upper limit has been
exceeded
Connection failed
The upper limit set for a Limit
billing plan (Type Limit and
Family Wide Limit) is exceeded
Connection failed Set the Caller ID Notification to
"ON" and retry
• This message may also
appear in other situations
You connected without notifying
your caller ID (when dialing into
visualnet, etc.)
Please make your
call from the i-mode
web page
You attempted to make a
videophone call to watch V-live
without browsing the i-mode
official site
Display Cause
N
zIt takes about 5 seconds to switch the calls. Note that
the signal quality may affect how long it takes.
zYou cannot switch the calls during calling in the
following cases:
• When the other party is holding the call
• When the other party activates Record message
Digital communication
fee is charged after the
appearance of this
screen.
Continued on next page
6
Voice/Videophone Calls
Making International Calls
<WORLD CALL>
WORLD CALL is an international dialing service that
can be used from DOCOMO mobile phones.
FOMA service subscribers are also subscribed to
"WORLD CALL" when they subscribe to the FOMA
service (However, this excludes subscribers who
stated that they did not require the service.).
zYou can make a call to approximately 240 countries
and regions worldwide.
z"WORLD CALL" is charged with your monthly
FOMA call charges.
zIn addition to directly dialing a phone number, you
can make an international call by adding "+" or
selecting "Int'l call" or “Prefix numbers" from the
function menu in the enter phone number screen or
detail screens of the Phonebook/Redial/Dialed
calls/Received calls.
zThis service is not available with some payment
plans.
Dialing a phone number to make an
international call
1Dial the phone number in the following
order: 010 → country code → area
code (long distance code) → other
party's phone number
If the area code (long distance code) begins with
"0", omit the first "0". However, to call fixed-line
phones in Italy, "0" is required.
You can also make an international call by
dialing the phone number in the following order:
009130 → 010 → country code → area code
(long distance code) → other party's phone
number.
2r
The international call is made.
Simple procedures for making
international calls
zYou can store the country codes and IDD prefix
codes in "Int'l dial assistance settings".
●Using "+" to make an international call
You can make an international call without dialing the
IDD prefix code by using "+", which is automatically
replaced by the IDD prefix code set for the "Auto int'l
call set".
zSince "Auto int'l call set." in "Int'l dial assistance
settings" is set to "ON" (automatically added) at the
time of purchase, the FOMA terminal automatically
dials the IDD prefix code.
zThe displayed call duration is reset to 0 second each
time the calls are switched. However, the total time for
a voice and videophone call is displayed after ending
the call.
zDepending on the other party's communication
conditions or the signal quality, you may not be able to
switch the calls and the call may be canceled.
zWhen the call is switched, the first dialed or received
call is registered to the Redial/Dialed calls records or
Received calls records.
<When switching from voice call to videophone call>
zIf the caller is using i-mode, the i-mode
communication is canceled to switch to videophone.
zIf the other party is using packet communication
(including i-mode), you receive the message "No
Switch" meaning you cannot switch the calls.
zYou cannot switch the calls when "Call Waiting" is
activated.
For additional information regarding WORLD
CALL, call the number for general inquiries
provided on the back of the manual.
N"International videophone calls" can be made to
users of some specific overseas 3G mobile
terminals by pressing o (V.phone) to make the
call after using the dialing procedure below.
zSee the DOCOMO website for information such as
accessible countries and operators.
zDepending on the other party's terminal, the image
of the other party displayed on your FOMA terminal
may be distorted or the connection may fail when
making an international videophone call.
7
Voice/Videophone Calls
1On the standby screen, dial the
following: + (0 for 1 second or
longer) → country code → area code
(long distance code) → other party's
phone number
If the area code (long distance code) begins with
"0", omit the first "0". However, to call fixed-line
phones in Italy, "0" is required.
2r
X
"Dial"
The international call is made.
■To make a call without converting "+" into
the IDD prefix code
X"Original Phone No."
■To cancel the call
X"Cancel"
●Making an international call from the
function menu
You can make an international call by adding a
country code and IDD prefix code from the function
menu.
zYou can use the international dial function from the
“Enter phone number screen” and the detail
screens of Phonebook/Received calls/Dialed calls/
Redial.
<Example: To use the international dial function from
the enter phone number screen>
1Enter the phone number of the other
party
2u (FUNC)
X
"Int'l call"
X
Select the
Country code
X
Select the IDD Prefix
code
The selected country code and IDD prefix code
are added. If the area code (long distance code)
begins with "0", the first "0" is automatically
deleted (except when “Italy” is selected for the
country code).
3r
The international call is made.
Making the setting international calls
<Int'l dial assistance settings>
You can set the automatic conversion of "+", and also
edit and store the country codes and IDD prefix code
for international calls.
1i
X
"Settings"
X
"Dialing"
X
"Int'l dial
assistance"
X
Select any item:
Auto int'l call set.……Set the automatic conversion
of "+" for when you make an international call.
X"ON"XSelect a Country codeXSelect an IDD
Prefix code
■When you do not want to convert
automaticallyX"OFF"
Country Code setting……
Store up to 22 country names
and country codes to use
when you make an
international call. See the
DOCOMO website for
information on country codes.
XHighlight an itemXo
(Edit)XEnter the country
nameXEnter the country
code
IDD Prefix setting……Store
the IDD prefix name and IDD
prefix code to use when you
make an international call. You
can store up to 3 entries.
XHighlight an item to be
stored or changedXo
(Edit) XEnter the IDD prefix
name XEnter the IDD prefix code
Country code setting screen
(P.7)
Edit
Delete……Select Delete this/Delete selected/Delete all.
Country code setting
Function menu
¨
P.7
IDD prefix setting
Function menu
¨
P. 1 3
8
Voice/Videophone Calls
Using Handsfree Call during a
Call
<Hands-free>
You can hear the other party's voice from the speaker
while talking.
1In-call screen (P.2)
X
o ()
" " appears and you can hear other party's
voice through a speaker during a handsfree call.
While your terminal is ringing, you can switch to
the handsfree operation by pressing o
(/).
■To cancel the handsfree operation
XPress o ( ) during a handsfree call
" " disappears when you make a voice call or
PushTalk call. " " is changed to " " in the
case of a videophone.
●Notes on using the handsfree operation
It is recommended to keep a distance of about 30 cm
from the FOMA terminal during a handsfree call. If
the distance is longer or shorter than 30 cm, the other
party may find it difficult to hear you or your voice may
sound differently.
Using the Redial/Dialed Calls/
Received Calls Record
<Redial/Dialed calls/Received calls>
Information on dialed or received calls, including the
caller's phone number and the date and time are
stored in the Redial/Dialed calls/Received calls
record. You can make a call to the other party easily
by using these records.
zWhen you make calls to the same phone number
repeatedly, the latest entry is stored as the Redial
record and separate entries are stored for the
Dialed calls record.
zThe Redial record can hold up to 30 phone
numbers for voice calls, videophone calls, and
PushTalk calls.
zThe Dialed calls/Received calls record stores up to
30 voice call, videophone call, and PushTalk call
entries and 30 packet communication and 64K data
communication entries.
zIf the maximum number of entries is exceeded,
entries are overwritten starting with the oldest one.
zAbout Redial/Dialed Calls/Received Calls Record
of PushTalk→P. 8 7
<Example: To make a call from the Redial/Received
calls list screen>
1On the standby screen
X
j (Redial)/
h (Received calls)
■To check Dialed calls
XiX"Own data"X
"Dialed calls"
2Highlight the Redial/Received calls
record entry
■To make a call after
checking the details of
the Redial/Received
calls record
XSelect the Redial/
Received calls record entry
N
zMove to an area where your call will not disturb other
people before switching to a handsfree call.
zWhen a call is finished, the handsfree setting is
canceled.
Ex. voice call Ex. videophone call
Ex. Redial (list)
Function menu
¨
P.9
Ex. Redial (detail)
Function menu
¨
P.9
9
Voice/Videophone Calls
3r (voice call), o (V.phone), @
(PushTalk)
●Checking the number of missed calls
■To confirm only the missed calls from the
Received calls record
XiX"Own data"X"Received calls"
The total number of received calls, the number of
missed calls and the number of unconfirmed missed
calls appear.
When you select "Missed calls", only the missed calls
appear.
■Redial/Dialed calls/Received calls record icons
*1: Some icons look different between the detail screen and
the list screen.
*2: Displayed only when the 2in1 is in Dual mode.
Redial/Dialed calls/Received
calls screen (P.8)
Notify Caller ID*1 →P. 5 6
Prefix numbers*1*2 →P. 1 4
Chaku-moji*1*2 →P. 1 1
Icon*1 Description
//
Incoming and outgoing/missed/
unconfirmed missed voice calls
//
Incoming and outgoing/missed/
unconfirmed missed international
voice calls
//
Incoming and outgoing/missed/
unconfirmed missed videophone
calls
//
Incoming and outgoing/missed/
unconfirmed missed international
videophone calls
//
Incoming and outgoing/missed/
unconfirmed missed PushTalk
calls (one-to-one communication)
//
Incoming and outgoing/missed/
unconfirmed missed PushTalk
calls (communication with multiple
parties)
*2 Incoming and outgoing calls to B
mode for 2in1 setting
/Recorded voice record message/
videophone message
Received calls with Chaku-moji
・/
/
Incoming and outgoing/missed/
unconfirmed missed packet
communication
//
Incoming and outgoing/missed/
unconfirmed missed 64K data
communication
Incoming packet communication or
64K data communication that is
received without an external
device connected
Incoming and outgoing calls when
the Time zone is other than
"GMT+09" regardless of the "Auto
time adjust" setting (the summer
time is displayed when you set the
summer time)
N
zWhen you use 2in1, up to 30 records are stored for
each phone number. Also, when set to Dual mode, up
to 30 Redial/Dialed calls/Received calls records for
both phone numbers and a total of the 60 records are
displayed.
<Redial/Dialed calls>
zSetting "Restrict dialing" deletes all the Redial/Dialed
calls records.
zIf you make a call by selecting Multi number from the
function menu, the registered name and number of the
additional number are displayed under the phone
number in the Redial screen (detail)/Dialed calls
record screen (detail). If you make a call without using
the function menu, nothing is displayed even when
"Set Multi Number" is set to additional number.
<Received calls>
zWhen "Missed calls display" in the "Ring time (sec.)" is
set to "Not display" and you receive a call of which ring
tone sounded for a shorter time than the time set in
the "Set mute seconds", the call is not displayed on
the Received calls record.
zIf the caller is using "Dial-in", a number different from
the "Dial-in" number may be displayed.
zIf the same phone number is registered in multiple
phonebook entries with different names, the name
retrieved by the phonebook search in the order of
reading is displayed in the Received calls record.
→P. 9 8
zWhen you have subscribed to Multi number and make
a call from the Received calls record screen, the
phone call is made from the number which received
the call regardless of the "Set Multi Number" setting.
zWhen you receive a call for the additional number of
Multi number, the registered name of the additional
number is displayed under the phone number in the
Received calls record screen (detail).
Icon*1 Description
Continued on next page
10
Voice/Videophone Calls
Int'l call*1*2 →P. 7
2in1/Multi Num.*1*2*3 →PP.412, 413
Select PushTalk*4*5……Redial/Dialed calls/Received
calls of PushTalk →P. 8 7
Ring time*6*9……Display the missed call record entries
with the ringing times.
Add to phonebook……Select Add to phonebook/Add to
PushTalk*5/Add to PushTalk Group registration*5 for the
registration destination. "Adding to the phonebook from
Redial or Dialed Calls record" →P. 9 6
Look-up phonebook*2……"Accessing the phonebook
from the Redial or Dialed Calls record“ →P. 9 9
Add desktop icon→P. 1 2 2
Compose message*2*5 →P. 2 0 0
Compose SMS*2*5→P. 2 3 5
Search location*2*……Connect to i-mode website and
run イマドコかんたんサーチ (Easy location search) using
the phone number.
Sent address*7*8
Received address*6
Select image*2……Select My side/Chara-den for the
image used during a videophone call.
Select "Release settings" to cancel the setting.
Big font⇔Standard font*9……Switch the character size
of the displayed name.
Delete……Select Delete this/Delete selected/Delete all.
*1: Available only for the detail screen.
*2: Not available for PushTalk (communication with multiple
parties) record screen.
*3: When the 2in1 setting is set to ON, select from "Number
A/Number B/Cancel number" (P.417) (unavailable when A
mode or B mode).
When the 2in1 setting is set OFF, select from “Basic
Number, Additional Number 1, Additional Number 2, and
Cancel number“ (P.413).
*4: Available only for PushTalk (communication with multiple
parties) record screen.
*5: Available only when 2in1 is in A mode or Dual mode, and
the record screen for the A mode is selected.
*6: Available only for the Received calls screen.
*7: Available only for the Redial and Dialed calls screen.
*8: Not available when 2in1 is in B mode.
*9: Available only for the list screen.
Using Chaku-moji
<Chaku-moji>
When making a voice call or videophone call, you can
send a message (Chaku-moji) to the other party to
show a summary of the call, etc. beforehand.
z5 Chaku-moji messages are stored at the time of
purchase. You can change the pre-installed Chaku-
moji messages.
zYou can include pictograms or face marks in
Chaku-moji, and you can send a message of up to
10 characters including pictograms/symbols/
double-byte characters/single-byte characters.
zFor details on Chaku-moji and the compatible
models, refer to the DOCOMO website or "Mobile
Phone User's Guide [Network Services]".
zChaku-moji is not compatible with PushTalk.
Adding, editing and setting messages
1i
X
"Settings/Servie"
X
"Service"
X
"Chaku-moji"
X
Select any item:
Create message……Store or
edits frequently used Chaku-
moji. You can store up to 30
Chaku-moji (including 5 pre-
installed).
XHighlight an item to be
stored or editedXo
(Edit)XEnter the Chaku-moji
MSG display settings……Set the Chaku-moji
display setting when you receive a call with Chaku-
moji.
Display all messages
Only number in PH-book……Display only the
Chaku-moji messages from senders stored in
the phonebook.
Calls with Caller ID……Display only the
Chaku-moji messages from senders providing
caller ID.
N
zSelecting "Compose message" enables you to
compose a mail with a mail address specified as the
address only when the mail address is stored in the
phonebook together with the phone number.
zSelecting "Delete all" from the Redial/Dialed calls
record deletes all the Redial and Dialed calls records.
Note that selecting "Delete this" or "Delete selected"
for the Redial record does not delete the entries of
Dialed calls record, and selecting "Delete this" or
"Delete selected" for the Dialed calls record does not
delete the entries of the Redial record.
N
Create message list
Function menu
¨
P.11
11
Voice/Videophone Calls
Hide all messages
3D message display……Set whether to display
Chaku-moji in 3D animation.
Create message list screen
(P.10)
Edit
Delete……Select Delete this/Delete selected/Delete all.
Making a call with a message
You can add Chaku-moji when making a voice or
videophone call from the "Enter phone number
screen" and the detail screen of the "Phonebook",
“Redial”, “Dialed calls” or “Received calls”.
<Example: To make a call with Chaku-moji from the
enter phone number screen>
1Enter phone number screen (P.2)
X
u (FUNC)
X
"Chaku-moji"
X
Select
any item:
Create message……Enter Chaku-moji. You can
enter up to 10 characters.
Select message…… Select the stored Chaku-moji.
You can edit Chaku-moji by pressing o (Edit) on
the message selection screen.
Sent messages……Select the previously sent
Chaku-moji. You can edit Chaku-moji by pressing
o (Edit) on the sent message screen.
■To delete the entered Chaku-moji (to make
a call without Chaku-moji)
Xu (FUNC)X"Chaku-moji"X"Create
message"XClear all the entered Chaku-moji
2r (voice call), o (V.phone)
N
zYou cannot delete the pre-installed Chaku-moji. Even
when you change a pre-installed Chaku-moji and
delete the Chaku-moji, it is restored to the default.
N
zSending charges apply for Chaku-moji. Receiving
charges do not apply for Chaku-moji.
zYou can store up to 30 Chaku-moji in the sent
messages record (if you use 2in1, up to 30 for the sent
message records when set to each mode, and up to
30 each for both sent message records and a total of
the 60 records are stored when set to Dual mode).
When you send the same Chaku-moji repeatedly, only
the latest one is recorded. When the entries exceed
the maximum number, entries are overwritten from the
oldest entry.
zIf the receiver's terminal is under conditions such as
the following, Chaku-moji cannot be sent. In this case,
no sending charges apply.
• The terminal is not compatible with Chaku-moji
("Transmission failed" appears)
• Chaku-moji does not appear on the screen of the
receiver terminal because of the "MSG display
settings" on the receiver terminal ("Transmission
failed" appears)
• Public mode (Driving mode) is set
• The ringing time for a recording message is set to 0
second.
• " " or the FOMA terminal is turned off.
zDepending on the signal status, the sending result
does not appear on the sender terminal even when
the receiver terminal receives Chaku-moji. In this
case, sending charges apply.
zYou cannot send or receive Chaku-moji when using
the FOMA terminal overseas.
When the other party's terminal receives Chaku-
moji, the result "Transmission completed" appears.
Continued on next page
12
Voice/Videophone Calls
●When you receive a voice or
videophone call with message
The Chaku-moji appears on the ringing screen. The
Chaku-moji disappears when you answer the call.
zThe received Chaku-
moji is displayed in 3D
animation.
●Displaying a message from the
Received calls record
When you receive Chaku-moji, the " " icon
appears on the Received calls record, and you can
check the Chaku-moji message on the "Received
calls screen (detail)".
Showing/Hiding Caller ID
When Making a Call
Adding the "186"/"184" prefix to the
other party's phone number
To show your caller ID, add the "186" prefix when you
dial the phone number. To hide your caller ID, use the
"184" prefix.
zAdding the “186” or “184” prefix to phone numbers
is not valid when making PushTalk calls.
■To provide your phone number
186 - (The other party's phone number)Xr (voice
call) or o (V.phone)
■To withhold your phone number
184 - (The other party's phone number)Xr (voice
call) or o (V.phone)
Showing/Hiding your caller ID from the
function menu
Show/Hide your caller ID from the function menu of a
detail screen such as the “Enter phone number
screen”, “Phonebook”, “Received calls”, “Dialed calls”
or “Redial”.
<Example: To make a voice call from the Enter phone
number screen>
1Enter the phone number of the other
party
2u (FUNC)
X
"Notify Caller ID"
X
"OFF"
or "ON"
■To cancel "Notify Caller ID"
X"Cancel prefix"
When "Cancel prefix" is selected, the "Caller ID
Notification" setting is applied.
3r (voice call), o (V.phone)
Sending Push Signals
Quickly
<Pause dial>
By sending push signals from the FOMA terminal,
you can use services such as ticket ordering and
bank balance requests.
Storing dialing data as pause dial
record entries
You can store the dialing data used as push signals to
Pause dial beforehand. Inserting p (pause) into the
dialing data allows you to send data with a separation
where a pause lies.
zOnly one dialing data can be stored.
zYou can enter numbers from 0 to 9, the # and *
symbols, and p (pause) for dialing data.
zYou cannot enter p (pause) in succession or at the
beginning of the dialing data.
N
zEven when you receive a call whose ring tone
sounded for a shorter time than the time set in the "Set
mute seconds" of "Ring time (sec.)", Chaku-moji is
displayed and recorded in the Received calls record.
zSome pictograms are not displayed in 3D animation.
zDepending on the status of the sender or receiver,
Chaku-moji may not be displayed even if you receive a
call with Chaku-moji.
zWhen the Original lock is set to "Chaku-moji", Chaku-
moji is not displayed even if you receive a call with
Chaku-moji. In this case, Chaku-moji is stored to the
Received calls record after releasing the lock.
N
zEven when you make a call using the Received calls
record, the Chaku-moji in the record is not sent.
Ex. Voice call
Chaku-
moji
13
Voice/Videophone Calls
1i
X
"Settings"
X
"Dialing"
X
"Pause
dial"
■If there is dialing data
already stored
The stored dialing data
appears.
2o (Edit)
X
Enter the dialing data
Press 0 to 9, q and w to enter the
dialing data.
■To enter p (pause)
Xw (1 second or longer)
Pause dial screen (P.12)
Edit
Send pause dial……Enter the phone number of the other
party and sends the dialing data.
Each time you press r, the dialing data up to p (pause)
is transmitted.
Delete
Transmitting the dialing data as a
pause dial
1i
X
"Settings"
X
"Dialing"
X
"Pause
dial"
X
d (Send)
2Dial the phone number of the
destination
X
r
The FOMA terminal calls the entered phone
number and displays the dialing data up to the
first p (pause) while the dialed phone is ringing.
p (pause) is not displayed.
3r
Each time you press r, the dialing data up to
p (pause) is transmitted. Once the FOMA
terminal has finished sending the last number,
the in-call screen reappears.
■To transmit all the dialing data at once
Xj (1 second or longer)
X
"Send at one time"
It may not be possible to send all the data at
once to some recipients.
Using the Prefix Function
You can store prefix numbers such as IDD prefix code
and 186/184 for notifying/withholding your caller ID
beforehand and add these prefix numbers when you
make calls.
Storing the prefix numbers
<Prefix setting>
zYou can store up to 7 prefix numbers.
zYou can enter numbers from 0 to 9 and the #, *
and + symbols.
1i
X
"Settings"
X
"Dialing"
X
"Prefix
setting"
2Highlight the item to store or change
X
o (Edit)
3Enter the name to be stored
4Enter the numbers (prefix)
You can enter up to 10 digits.
Prefix setting screen (P.13)/IDD
prefix setting screen (P.7)
Edit……Edit the prefix number or IDD prefix code.
Delete this*1……Delete one prefix number.
Delete*2……Delete one IDD prefix code.
Delete all……Delete all prefix numbers or IDD prefix
code.
*1: Available only with the Prefix setting screen.
*2: Available only with the IDD prefix setting screen.
N
zSome phones may be unable to receive push signals.
Pause dial
Function menu
¨
P. 1 3
Prefix setting
Function menu
¨
P. 1 3
14
Voice/Videophone Calls
Making a call with the prefix number
<Prefix numbers>
zYou can add the prefix numbers from the "Enter
phone number screen" and the detail screens of
“Phonebook”, “Received calls”, “Dialed calls” or
“Redial”.
<Example: To make a voice call by adding prefix
numbers from the enter phone number screen>
1Enter the phone number of the other
party
2u (FUNC)
X
"Prefix numbers"
X
Select
the stored name
X
r
Setting Sub-addresses When
Making Calls
<Sub-address setting>
You can set whether to specify "*" in the phone
number as a separator so that the numbers following
"*" are recognized as a sub-address (ON or OFF).
zSub-addresses are used in ISDN to identify calls
made from specific communications devices and to
select content in "V-live".
1i
X
"Settings"
X
"Dialing"
X
"Sub-
address setting"
X
"ON" or "OFF"
Setting the Alarm Used for
Reconnection
<Reconnect signal>
When the signal quality deteriorates during a voice/
videophone call or PushTalk communication and the
call drops out, the FOMA terminal will automatically
reconnect the call if the signal quality quickly
improves. Set the type of alarm when a call is
reconnected with this function.
zThe length of time required for reconnection varies
depending on communication conditions or the
signal quality. It takes about 10 seconds.
1i
X
"Settings"
X
"Talk"
X
"Reconnect
signal"
X
Select an alarm tone
Select “No tone”, “High tone” or “Low tone”.
Blocking Out Ambient Noise
<Noise reduction>
This function suppresses ambient noise and makes it
easier for the other party to hear you during a voice/
videophone call or PushTalk communication.
1i
X
"Settings"
X
"Talk"
X
"Noise
reduction"
X
"ON" or "OFF"
Making handsfree Calls in the
Car
<In-car Hands-free>
You can make or receive voice calls with handsfree
compatible devices by connecting the FOMA terminal
to handsfree compatible devices such as the In-Car
Hands-Free Kit 01 (optional) or a car navigation
system.
For information on how to use the handsfree device,
refer to the manual provided with the device. The
FOMA In-Car Hands-Free Cable 01 (optional) is
required to use the In-Car Hands-Free Kit 01.
N
zIn the following cases, "*" does not function as a sub-
address separator. The number including "*" is
recognized as an ordinary phone number.
• When "*" is entered at the beginning of a phone
number
• When "*" immediately follows "186" or "184" at the
beginning of a phone number
• When "*" immediately follows a number entered
using "Prefix numbers"
• When the phone number contains “*590#”,
“*591#” or “*592#”
N
zCall charges apply during the period up until
reconnection (up to about 10 seconds).
N
zTo operate from the handsfree device, set the USB
mode to "Communication mode".
zThe display and ring tones used for incoming calls and
mail are as specified in the FOMA terminal settings.
15
Voice/Videophone Calls
Receiving a Voice/
Videophone Call
1Receiving a voice or videophone call
The ring tone sounds and the incoming call lamp
flashes.
■When you receive a call with Chaku-moji
The Chaku-moji appears on the ringing screen
or videophone ringing screen. →P. 1 2
■To put a voice/videophone call on hold
while the FOMA terminal is ringing →P. 1 8
2r
■To answer a videophone call with the
substitute image
Xd (Subst.)
■Operations during a videophone call
You can perform various operations such as
changing the camera image to the substitute
image, changing the front camera to rear
camera, and muting the sound during a
videophone call.→P. 2
■When the other party switches a voice/
videophone call during a call→P. 1 6
■To put the current voice/videophone call
on hold→P. 1 8
3To end the call, press y
Ringing screen/Videophone
ringing screen (P.15)
Call Rejection……Terminate the received call without
answering it.
Call Forwarding……The call is forwarded to the
forwarding number regardless of the Activate/Deactivate
setting of Call Forwarding.
Voice Mail……The call is forwarded to the voice mail
service center regardless of the Activate/Deactivate
setting of Voice Mail.
Change Display……Switch the display from the
additional number 1 or 2 to the number from which the call
is forwarded. This can be selected when receiving a multi
number call (for additional number 1 or 2) and the call is
forwarded at the same time.
zWhen the handsfree device is set to emit the sound
from the handsfree device, the ring tone still sounds
through the handsfree device even when the FOMA
terminal is set to Manner mode or the ring volume is
set to "Silent".
zWhen the Public mode (Driving mode) is set,
operation for incoming calls and messages is as
specified in the "Public mode (Driving mode)" settings.
zWhen Record message is set, operation for incoming
calls is as specified in the "Record message" settings.
zWhen sound is set to be emitted from the FOMA
terminal, operation when rotating the display
counterclockwise during a call is as specified in
"Setting when folded". When sound is set to be
emitted from the handsfree device, rotating the display
counterclockwise does not affect the call status
regardless of the "Setting when folded" setting.
N
Ringing
Function menu
¨
P.15
Videophone ringing
Function menu
¨
P.15
N
zYou can receive a call using a flat-plug earphone/
microphone with switch (optional).→P. 3 8 7
Display while receiving a call
■When the other party's phone number is
notified
The other party's phone number appears on the
screen. When the caller is stored in the
phonebook, the name stored in the phonebook
appears (only the name is displayed while
Keypad lock is set).→P. 9 4
zIf the same phone number is registered in
multiple phonebook entries with different
names, the first name retrieved by the
phonebook search in the order of reading
appears.→P. 9 8
zIf the caller is stored as secret data, the name
and other information does not appear and
only the phone number appears.
zWhen you receive a call for the additional
number of Multi number, the registered name
of the additional number is displayed on the
ringing screen.
■When the other party's phone number is
not notified
The reason for not notifying appears.
Continued on next page
16
Voice/Videophone Calls
When the Other Party
Switches a Voice/Videophone
Call (Caller)
When you receive a voice/videophone call, the other
party can switch the call between a voice call and
videophone call.
zThe receiver cannot switch a call.
zTo switch the call, the receiver needs to set "Ntfy
switch-mode" to notify of the switch beforehand.
→P. 2 4
zYou can use this function with terminals compatible
with voice call/videophone call switch.
<Example: When the other party switched a voice call
to a videophone call>
1In-call screen (P.2)
X
The other party
switches to a videophone call
X
"YES"
During switching, the screen which indicates that
the calls are being switched appears and voice
guidance is played.
When a voice call is switched to a videophone
call, the camera image is sent to the other party.
■To send substitute image to the caller
X"NO"
■When the other party switched a
videophone call to a voice call
XVideophone in-call screen (P.2)XThe other
party switches to a voice call
The videophone call is switched to the voice call.
Using the Dial Keys to
Answer a Call
<Answer setting>
You can use this setting to turn off the ring tone or
answer the phone quickly when you receive a call.
1i
X
"Settings"
X
"Incoming call"
X
"Answer setting"
X
Select any item:
Any key answer……Valid for voice calls and
PushTalk call. You can answer a call by pressing any
of the following keys.
r, d (Answer), 0 to 9, w, t, o,
p, a (マナー ), b (for voice calls only), or @ (for
PushTalk calls only)
* For videophone calls, you can answer the call only by
ordinary key operations (r, d (Subst.) or o
(V.phone)).
Quick silent……Pressing any of the following keys
or opening the FOMA terminal stops the ring tone,
while the caller continues to hear ringing.
0 to 9, w, t, b, p, a (マナー) or o
(for voice calls/PushTalk calls only)
To answer the call, press r, d (Answer/Subst.)
(for unfolded FOMA terminal only), o (V.phone)
(for videophone calls only), or @ (for PushTalk only).
OFF……You can answer the call only with ordinary
key operations.
r, d (Answer/Subst.) or o (V.phone) (for
videophone calls only), @ (for PushTalk only)
zIf you receive a call when using the view style, switch
the display to the standard type to answer the call.
zYou can receive a call using a flat-plug earphone/
microphone with switch (optional).→P. 3 8 7
zIf you have subscribed to the Call waiting, Voice mail
or Call forwarding service and you activate "Set in-call
arrival" and set "Incoming Call Mng" to "Answer", you
will hear a short double beep ("bibip") when you
receive a call during a call.
• If you subscribe to the Voice mail or Call forwarding
service, you can answer a call by ending the current
call.
• If you subscribe to the Call waiting service, you can
answer a voice call by putting the current call on
hold and you can answer a videophone call by
ending the current call.
zYou can set the operation for calls from callers not
stored in the phonebook.→P.148
zYou can set the restriction for each phone number
stored in the phonebook.→P.146
<Videophone>
zYou can also answer the call by pressing o
(V.phone).
zIt may take a few seconds to switch from a camera
image to a substitute image (Chara-den) depending
on the Chara-den.
N
17
Voice/Videophone Calls
Ending/Holding Calls with the
FOMA Terminal rotated
counterclockwise
<Setting when folded>
You can set how your FOMA terminal operates when
the diplay is rotated counterclockwise during a voice
or videophone call.
1i
X
"Settings"
X
"Talk"
X
"Setting
when folded"
X
Select any item:
No tone……Mute the sound. For videophone calls,
Substitute image is sent to the other party. The
other party does not hear the hold tone.
Tone on……Put a call on hold (holding). When the
display is rotated counterclockwise, the other party
hears the hold tone. For videophone calls, the call
hold image is sent to the other party.
Speaker ON……The hold tone is sent to the
other party and also plays through the speaker.
Speaker OFF……Only the other party hears
the hold tone.
End the call……End the call. This is the same
operation as pressing y.
Adjusting the Earpiece
Volume
<Volume>
1On the standby screen
X
c (1 second
or longer)
X
Adjust the volume with c
Pressing c (1 second
or longer) displays the
earpiece volume
screen. If no operation
is performed for 2
seconds or longer while
the earpiece volume
screen is displayed,
earpiece volume adjustment ends.
You can adjust the volume in 6 steps from
"Level 1" (quietest) to "Level 6" (loudest).
■To adjust the earpiece volume during a
call
During a voice call: c (1 second or longer)
During a videophone call: c
• You can also adjust the volume with
a (マナー )/s (L).
Adjusting the Ring Volume
<Ring volume>
You can adjust the volume of the ring tone for each of
an incoming call, mail, chat mail, MessageR/F or
i-Concier information in 6 steps. You can also set the
volume to silent or to gradually get louder.
1i
X
"Settings"
X
"Incoming call"
X
"Ring volume"
X
Select an item to
adjust the volume:
Select "Phone" to adjust the ring tone volume for
voice calls and 64K data communication.
Select "Mail" to adjust the ring tone volume for
i-mode mail, Area Mail, SMS or packet
communication.
2Use c to adjust the ring volume
X
d
(Set)
■To raise the volume gradually
XPress f when "Level 6"
When set to "Step", the ring volume becomes
louder every 3 seconds.
N
zEven when "Quick silent" is set, the "Any key answer"
function is used in Manner mode.
zEven when "Any key answer" and "Quick silent" are
set, if you press 5 (ON/OFF of emergency mode)
or 8 (ON/OFF of privacy angle) for 1 second or
longer, "Any key answer" or "Quick silent" functions do
not operate.
zWhen "Any key answer" is set and you press a (マ
ナー) while the FOMA terminal is folded, the voice call
is put on hold. At this time, the other party hears the
hold tone when "Setting when folded" is set to "Tone
on", but the other party does not hear the hold tone
when "No tone" or "End the call" is set.
N
zWhen Manner mode is set, no sound is played
through the speaker even if "Speaker ON" is set.
zWhen a flat-plug earphone/microphone with switch
(optional) is connected, this function is disabled.
zEven if the "Tone on" setting is selected, rotating
counterclockwise activates the "No tone" setting if
"Call Waiting" is switched on.
zThis setting does has no effect during PushTalk
communication. The operation is in accordance with
"Setting when folded" of the PushTalk settings.
N
zIf you adjust the volume during a call, the setting is
retained after you end the call.
zYou can also adjust the volume during PushTalk call
and a handsfree call.
Continued on next page
18
Voice/Videophone Calls
■To set to silent
XPress g when "Level 1"
An icon appears in the standby screen for you to
confirm that "Silent" is set.
: "Silent" is set for "Phone", "Videophone"
and/or "PushTalk"
: "Silent" is set for "Mail", "Chat mail",
"MessageR", "MessageF" and/or
“i-Concier”
: Both " " and " " are set
Holding the Ringing/Current
Call
<Answer hold/Holding>
<Example: To put a ringing call on hold>
1While ringing
X
y
The FOMA terminal
makes three rapid
beeps and puts the call
on hold.
The caller hears a
message saying that
you cannot answer at
the moment and the call
is held without hanging
up.
■To put the current call on hold
XDuring a callXt
■To end the call during answer hold/call
hold
Xy
2Press r to resume the call
You can also use t to cancel holding when
you have put the current call on hold.
Setting the hold tone
<Set hold tone>
You can set the guidance message to play to the
other party during answer hold.
zYou cannot change the hold tone that is played
during a call.
1i
X
"Settings"
X
"Talk"
X
"Set hold
tone"
X
"On hold tone"
X
Select the hold
tone
Select “Tone 1”, “Tone 2”, “Voice announce 1*” or
“Voice announce 2*".
* : Not available when no voice announcement is
recorded.
Using the Public Mode
The Public mode (Driving mode/Power OFF) is an
automatic answering service provided for public
places and circumstances in which mobile phones
should not be used.
Using the Public Mode
(Driving mode)
<Public mode (Driving mode)>
When Public mode is set, a caller hears a message
notifying that you cannot answer the call because you
are driving or in a place where you have to refrain
from talking on the phone (on the train or bus, in the
theater, etc.), and then the call ends.
zPublic mode can only be set or canceled from the
standby screen (It can also be set or canceled
when the " " icon is displayed.).
zYou can still make calls when Public mode is set.
zThis function is not available during data
communication.
zWhen you receive a call with no caller ID while
Caller ID Request is set to "Activate", the caller ID
request message is announced. (The Public mode
message is not announced.)
1On the standby screen
X
w (1 second
or longer)
Public mode is set and
" " appears.
When you receive a
call, the caller hears the
message "I can't
answer the call because I am driving or I have to
refrain from calling now. Please call back later".
■To cancel the Public mode (Driving mode)
XOn the standby screenXw (1 second or
longer)
Public mode is canceled and " " disappears.
N
zThe ring volume setting specified for "Phone" in this
function is also applied to the "Select ring tone" setting
for a voice call, and the alarm tones for "Schedule"
and "To Do list".
N
zCall charges apply while a ringing call or current call is
put on hold.
N
zThe Public mode setting takes priority when "Record
message" is "ON".
19
Voice/Videophone Calls
●When Public mode (Driving mode) is set
The FOMA terminal does not ring when you receive a
voice call, videophone call or PushTalk call. Calls are
logged in the "Received calls" record as "Missed
calls", and the "Missed call" desktop icon appears on
the standby screen.
zA caller making a voice call hears a message
notifying that you cannot answer the call because
you are driving or in the place where you have to
refrain from using a mobile phone, and then the call
ends.
zA caller making a videophone call sees the Public
mode video message on his or her display, and
then the call ends.
zAn incoming PushTalk call is not answered. The
caller who made the PushTalk call sees the
"Connection failed" message on his or her display.
In the case of a conversation between three or
more people, the participating members are
notified that you are driving.
zIf the FOMA terminal is set to Public mode (Driving
mode) while network services are activated,
received calls are handled as shown in Table 1
(P.20).
zWhen you receive a mail, the ring tone does not
sound and the "New mail" desktop icon appears on
the standby screen.
Using the Public Mode (Power
OFF)
<Public mode (Power OFF)>
When Public mode (Power OFF) is set, a caller who
made a call while the FOMA terminal is turned off
hears a message that you cannot answer the call
because you are in the place where you have to turn
off the mobile phone (in a hospital, on an airplane,
around a priority seat on a train, etc.), and then the
call ends.
1On the standby screen
X
w25
251
X
r
Public mode (Power OFF) is set (Nothing
changes on the standby screen).
When you receive a call after setting Public
mode (Power OFF) and turning off the FOMA
terminal, the caller hears the message "The
person you are calling is in an area where
mobile phones should not be used. Please call
back later".
■To cancel the Public mode (Power OFF)
XOn the standby screenXw252
50Xr
■To check the Public mode (Power OFF)
setting
XOn the standby screenXw252
59Xr
●When Public mode (Power OFF) is set
The setting is valid until "*25250" is dialed to cancel
the Public mode (Power OFF). The setting is not
canceled by just turning on the FOMA terminal.
The Public mode (Power OFF) message is
announced even when you are in an out-of-service
area or where the reception is very poor.
zA caller making a voice call hears a message
notifying that you cannot answer the call because
you are in a place where you have to turn off the
mobile phone, and then the call ends.
zA caller making a videophone call sees the Public
mode (Power OFF) video message on his or her
display, and then the call ends.
zAn incoming PushTalk call is not answered. The
caller who made the PushTalk call sees the
"Connection failed" message on his or her display.
In the case of a conversation between three or
more people, the participating members are
notified that you are not participating.
zIf the FOMA terminal is set to Public mode (Power
OFF) while network services are activated,
zThe Public mode setting takes priority when Manner
mode is set at the same time.
zIf you make a voice call to an emergency number
(110, 119 or 118) while Public mode is set, Public
mode is canceled.
zThe following tones do not sound in Public mode:
• Ring tone for voice call/videophone/PushTalk call
• Ring tones for mail and message
• Various alarm tones
• Wake-up tone
• Charge sound
• Software tone for i-αppli
• Ring tone for packet communication/64k data
communication
• Search request notification tone for GPS function
N
zIf the power is off or " " is displayed, the message
for " " is announced instead of the Public mode
message even when Public mode is set. However, in
the case of PushTalk, "Not participating" is displayed
to the members.
N
Continued on next page
20
Voice/Videophone Calls
received calls are handled as shown in Table 1
(P.20).
When You Cannot Answer a
Received Call
<Missed call>
When you could not answer a received call,
appears on the standby screen. When you select ,
you can check the date, time and caller ID for the call.
z"Icons providing information" →P. 1 2 3
1On the standby screen
X
d
X
Select
""
To check the information with the
FOMA terminal folded
When there is a missed call, new mail (i-mode mail,
Area Mail, or SMS) or new chat mail, the incoming
call lamp keeps on flashing. If you press s, a voice
notifies you of information such as the name of the
caller or sender.
1Press s with the FOMA terminal folded
A voice notifies you of the information in
accordance with the setting of "Info notice
setting".
●Flashing of the Incoming call lamp
When there is a missed call, new mail, new chat mail
or other information, the incoming call lamp keeps on
flashing in the corresponding color set in
"Illumination".
zPhone/Videophone: Color set for "Phone"
zNew mail: Color set for "Mail"
zNew chat mail: Color set for "Chat Mail"
■Flashing color and conditions
zThe lamp does not flash when missed info of
"Illumination" is set to "OFF".
zThe lamp flashes in the default color when
gradation is set in "Illumination".
zYou can set individual illumination settings in the
phonebook.
zThe lamp does not flash in Public mode (Driving
mode).
[Table 1] Handling of received calls when network services and Public mode (Driving mode/
Power OFF) are set
* : If the ring time is set to 0 second, the Public mode message is not announced and the "Voice Mail Service" or "Call
Forwarding Service" applies. In addition, calls are not recorded in the "Received calls" record and the "Missed call"
desktop icon does not appear.
Service
name When a voice call is received When a videophone call is received
Voice Mail
Service
• Connects to the Voice mail service center after
announcing the Public mode message.*
• Connects to the Voice mail service center
without showing the Public mode video
message.
Call
Forwarding
Service
• Transfers the call to the forwarding number
after announcing the Public mode message.*
• Whether or not the Public mode message is
announced depends on the setting of the call
forwarding service.
• Transfers the videophone call to the forwarding
number without showing the Public mode video
message.
• Calls to videophones will not be connected
unless the forwarding party has a videophone
set to comply with 3G-324M.
Nuisance
Call Blocking
• When a call is received from a phone number
registered for nuisance call blocking,
announces a message notifying that a
connection could not be established, and then
ends the call.
• For another phone number, ends the call after
announcing the Public mode message.
• When a call is received from a phone number
registered for nuisance call blocking, shows a
video message notifying that a connection could
not be established, and then ends the call
• For another phone number, ends the call after
showing the Public mode video message.
Caller ID
Request
• When the caller does not notify the caller ID,
ends the call after announcing the caller ID
request message.
• When the caller notifies the caller ID, ends the
call after announcing the Public mode
message.
• When the caller does not notify the caller ID,
ends the call after showing the caller ID request
video message.
• When the caller notifies the caller ID, ends the
call after showing the Public mode video
message.
21
Voice/Videophone Calls
■To turn off the lamp
zSelect the icon for "Missed call", "New mail" or
"Chat mail" on the display to check the information,
or press t (1 second or longer).
Setting the Notification Method for
Missed Calls
<Info notice setting>
You can set the notification method for when s is
pressed with the display at the initial position.
zThe setting items and notification methods by
pressing s are as follows:
■When there is a missed call, new mail, etc.
■When there is no missed call, new mail, etc.
*1: Vibration notifies you of the information when "Phone" of
"Vibration" is set to other than "OFF".
*2: If "Gradation" is set for the flashing color of "Illumination",
the lamp flashes in default colors for missed calls, new
mail, and new chat mail.
1i
X
"Settings"
X
"Incoming call"
X
"Info notice setting"
X
"ON" or "OFF"
■When ボイス (Voice) is selected
If you set “日本語” (Japanese) in the setting of
"Select language", you can select "電子音"
(electronic sound), "ボイス" (voice) and "OFF".
You can set the voice to read out (ON) the name
or not (OFF) when the caller is stored in the
phonebook or when the recording of the
message.
Having the Caller Leave a
Message
<Record message>
When you cannot answer a voice or videophone call,
this function allows you to record a message from the
caller on your FOMA terminal.
zEach message can be up to 20 seconds long, and
5 messages can be recorded for voice calls and 2
messages can be recorded for videophone calls.
Setting Record message
1i
X
"Settings"
X
"Incoming call"
X
"Record message"
X
Select any item:
ON……Select Japanese 1/Japanese 2/English/
Voice announce 1*/Voice announce 2* as a desired
type of answer message, and then set the record
message.
OFF……Cancels the Record message setting.
* : Not available when no voice announcement is
recorded.
2Enter the ringing time (000 to 120
seconds in 3 digits)
The record message is set and " " and " "
appear on the standby screen.
Setting
item Tone and vibration*1 Incoming Call
Lamp
ON The "Bibip, bibip" tone
plays.
The incoming call
lamp lights for
about 6 seconds in
the color set for
"Illumination".
If there are
different types of
information such
as a call and mail,
the lamp changes
to each of the
corresponding
color at 1-second
intervals.*2
Setting
item Tone and vibration*1 Incoming Call
Lamp
ON The "bibibip" tone
plays.
The lamp flashes
in "Color 7" for
about 6 seconds.
N
zThis function alerts you using a "YES" indication when
a desktop icon such as the "Missed call", "New mail",
or "Chat mail" is displayed on the standby screen.
→P. 1 2 3
zYou cannot use s to check for missed calls or new
mail in the following cases:
• When playing music with the Music player/
Music&Video Channel
zThe volume is set to "Level 2" in “Ring volume”.
zOpening the FOMA terminal during the notification
stops the notification.
zIf the reading of caller's name is not stored in the
phonebook or the name stored in the phonebook is
not displayed, the caller's name is not read out even
when "名前通知" (name notification) of "ボイス"
(voice) is set to "ON“ in Japanese language mode.
N
zTo give priority to the "Record message" function
when "Voice Mail" "Mall Forwarding" and "Record
message" are set at the same time, set the ringing
time of Record message shorter than that of Voice
mail and Call forwarding.
Continued on next page
22
Voice/Videophone Calls
When you receive a call with "Record
message" set to "ON"
The record message activates when the set time has
elapsed.
zTo the caller of a voice call, the answer message is
played, and then recording starts.
zTo the caller of a videophone call, the "Preparing"
image is sent and the answer message is played,
and then the "Recording" image is sent and
recording starts.
■When message recording starts
zThe recording screen appears. The caller's voice
can be heard through the FOMA terminal earpiece
during message recording.
■To answer a voice call
during recording
Xr
■To answer a videophone
call during recording
Xr to answer with the
camera image or d (Subst.)
to answer with the substitute
■When message recording ends
zThe original screen
reappears and the "Missed
call" desktop icon and
"Record message" desktop
icon appear on the standby
screen. You can check the
information by selecting one
of the desktop icons.→P. 2 2
zThe number of recordings is
indicated by icons in the
icon display area at the top of the screen.
to : Recorded voice messages (1 to 5)
/ : Recorded videophone messages (1 or 2)
Having Callers Leave a
Message during an Incoming
Call
<Quick message>
Even when the "Record message" function is not set
to "ON", you can record messages while receiving a
call by pressing a key.
1While ringing
X
s (L)
The recording of the message starts.
■To set the FOMA terminal to Manner mode
at the same time recording is started
XWhile ringingXq
Playing/Erasing Recorded
Messages, Voice Memos and
Record VP message
zWhen there is a recorded message which has not
been played, " " (Record message) or " "
(Record VP message) appears on the standby
screen.
<Example: To check a recorded message which has
not been played>
1On the standby screen Select
X
d
X
" " (Record message) or " "
(Record VP message)
"★" appears for the
recorded item.
■To play a message with
a menu operation
XiX"LifeKit"X"Play/
Erase msg." or "Play/Erase
VP msg."
zIf the mute time set for "Ring time (sec.)" is longer than
the ringing time set for the Record message function,
the FOMA terminal switches directly to Record
message without ringing first. To have the FOMA
terminal ring before it records a message, make sure
that the ringing time for Record message is longer
than the mute time.
zYou can use "Ring tone/Image" (for each phonebook
entry) to set an answer message for each phone
number and "Ring tone/Image" (for the phonebook
group) to set an answer message for each group.
N
Ex. Voice call
N
zWhen Manner mode is set, you cannot hear the
caller's voice during message recording.
zYou cannot answer another call during the recording of
a message.
N
zYou cannot set "Record message" to "ON" with this
operation.
zWhen you receive a voice or videophone call when the
messages are full, record message is not activated
and the FOMA terminal keeps on ringing (when q
is pressed, the ringing continues in accordance with
the setting of "Manner mode set").
Play/Erase msg.
Function menu
¨
P. 2 3
23
Voice/Videophone Calls
2Select the item to play
■To make a voice call, videophone call, or
PushTalk call to the phone number
displayed during the playing of a message
Xr (voice call), o (V.phone), @ (PushTalk)
Only one-to-one communication is possible for
PushTalk.
■To erase the playing message
Xu (FUNC)X"Erase"X"YES"
Play/Erase msg. screen (voice/
video) (P.22)
Play, Delete this, Delete rec. msg.*, Delete all……
Select one of the items to perform the operation.
* : Available only with the Play/Erase msg. screen.
Using Chara-den
This function sends a cartoon character instead of
your own image when you make a videophone call.
"Chara-den"→P.315
zYou can display your favorite Chara-den if you set
"Substitute image" of "Select image" to "Chara-
den" beforehand.
You can also use Chara-den by setting Chara-den
in the phonebook or Ring tone/Image function.
zTo switch from the camera image to Chara-den
during a videophone call, select "Substitute image"
from the function menu.
1When you receive a videophone call,
press d (Subst.)
2Control your character by pressing the
dial keys
Pressing a dial key makes the character perform
the action assigned to that key.
"Using Chara-den characters"→P. 3 1 5
Setting Functions for the
Videophone
1i
X
"Settings"
X
"Videophone"
<Record message/Voice memo>
The FOMA terminal beeps and playback
begins. When the playback ends, the FOMA
terminal gives 2 short beeps and the "Play/
Erase msg. screen" reappears.
You can also play the messages by pressing
Ss ( ) on the standby screen.
■To play the next message while playing
a message
XSs ()
Each time you press Ss ( ), the recorded
messages are played from the newest one.
■To stop the playback
XXd (Stop) or Wt
The "Play/Erase msg. screen" reappears.
<Record VP message>
The playback starts. When the playback ends,
the "Play/Erase VP msg. screen" reappears.
■To play another message while playing a
message
Xv
■To adjust the volume while playing a
message
Xc
■To switch the speaker ON/OFF while
playing a message
Xu (FUNC)X"Speaker ON" or "Speaker
OFF"
■To pause the playback
Xd (Stop)
To resume playback, press d (Play).
■To stop the playback
Xt
The "Play/Erase VP msg. screen" reappears.
N
zWhen 2in1 is in A mode or B mode, "★" does not
appear for the recorded message recorded in the
unused phone number. When set to "Dual mode", "★"
appears for recorded messages that are recorded for
both phone numbers.
Chara-den
Videophone settings
24
Voice/Videophone Calls
2Select any item:
Visual preference……Select Normal/Prefer img
qual/Prefer motion spd as an image quality of
videophone calls.
Select image→P. 2 4
Auto redial as voice……Set whether to switch to a
voice call when a videophone call cannot be made
(ON or OFF).
Display setting……Set the image displayed on the
main display or how to display your own camera
image.
Main display……Select Other side/My side for
the image displayed on the main display.
Front camera Reverse……Set whether to
display your camera image as a mirror image
(ON) or normal image (OFF) on your FOMA
terminal.
Ntfy switch-mode→P. 2 4
Hands-free switch……Set whether to switch to
handsfree automatically when starting a videophone
call (ON or OFF).
V-phone while packet→P. 2 4
Setting the image sent during
videophone calls
<Select image>
You can select the image sent instead of the camera
image.
zYou can set a JPEG image whose file size is 100K
bytes or less and not larger than 854 dots wide x
854 dots high, or a GIF image whose file size is
100K bytes or less and not larger than 854 dots
wide x 480 dots high or 480 dots wide x 854 dots
high (except for files with restrictions).
1Videophone settings screen (P.23)
X
"Select image“
X
Select any item:
On hold, Holding, Substitute image, Record
message, Preparing, and Voice memo
2Select the image to be sent:
Pre-installed……Send only a message.
Original……Send an image and a message.
To change the image, select My picture via Change
setting of the function menu.
Chara-den*……Send the image selected for
Substitute image.
Function menu of “Chara-den list screen“ →P. 3 1 6
Priority order for Chara-den setting→ P. 9 6
To change the Chara-den, select a Chara-den from
the Chara-den list via Change setting of the function
menu.
* : Available only when "Substitute image" is selected.
Setting for Switching between Voice
Call and Videophone Call
<Ntfy switch-mode>
You can set whether to notify the other party that your
FOMA terminal supports switching between a voice
call and a videophone call.
zThe other party cannot switch the call when
"Indication OFF" is set.
zYou cannot set this function during a call or while
" " appears.
1Videophone settings screen (P.23)
X
"Ntfy switch-mode"
X
Select any item:
Indication ON, Indication OFF……Activate or
deactivates the Ntfy switch-mode.
Check Indication……Display the “Ntfy switch-
mode” setting.
Setting the answer mode for receiving
a videophone call during i-mode
<V-phone while packet>
zAs the multi access function cannot be used for
videophone, incoming videophone calls during
i-mode communication or while sending or
receiving mails are handled according to this
setting.→P.454
1Videophone settings screen (P.23)
X
"V-phone while packet"
X
Select any
item:
V-phone priority……Switch to the videophone
ringing screen. When you answer the incoming
videophone call, i-mode communication is
disconnected.
Packet downld priority……Reject the incoming
videophone call.
V-phone answerphone……If you have subscribed
to the "Voice Mail Service", the videophone call is
forwarded to the Voice Mail service center
regardless of the Activate/Deactivate setting of Vo ic e
Mail. If you have not subscribed to this service,
Packet downld priority is activated.
25
Voice/Videophone Calls
Call forwarding……If you have subscribed to the
Call Forwarding Service, the videophone call is
forwarded to the forwarding number regardless of
the Activate/Deactivate setting of Call Forwarding. If
you have not set a forwarding number or subscribed
to this service, Packet downld priority is activated.
To enlarge the image to be sent
Enlarge your image and send it to the other party
during a videophone call.
zWhen you are using the rear camera, the zoom can
adjust your image in 16 steps from 1x to
approximately 4x. When you are using the front
camera, the image can be adjusted in the 2 steps
of 1x and approximately 2x.
zEach of the zoom ratios are retained if you switch
between the front camera and rear camera during
a videophone call. If you end the videophone call,
the zoom ratio returns to 1x (standard).
zThe image cannot be enlarged when you are
sending the substitute image.
1During videophone call
X
Press v to
adjust the ratio
Decorating the videophone call screen
<Decorate videophone call>
Decorate your videophone call screen (your camera
image) with a stamp and frame.
1Videophone in-call screen (P.2)
X
u
(FUNC)
X
"Decoration"
X
Select any
item:
Frame……Select a frame from the Frame selection
screen.
Stamp……Select a stamp from the Stamp selection
screen and decide the paste position.
■To erase a frame or stamp
Select “Erase message” or “decoration” from the
function menu of the videophone in-call screen.
Sending a message during a
videophone call (sending camera
image)
<Short message>
1Videophone in-call screen (P.2)
X
u
(FUNC)
X
"Petit message"
X
Enter a
message
The message is displayed. The message
disappears automatically after approximately 15
seconds.
N
<Visual preference>
zIf the signal quality deteriorates during a videophone
call, the image may become grainy or patchy
regardless of the settings in "Visual preference".
<Select image>
zIf you delete the original still image, the "Pre-installed"
image is displayed (sent).
zWhen the Chara-den character set as the substitute
image is deleted and the "Chara-den" substitute
image cannot be displayed, the pre-installed " ビーン
ズ (Beans)" is sent. If you delete the pre-installed
"ビーンズ (Beans)" the "Pre-installed" substitute still
image is sent.
<Auto redial as voice>
zWhen a videophone call is switched and redialed as a
voice call, the call is charged as a voice call and digital
communication charges are not applied.
zWhen a call is redialed, only the voice call record is
logged in the "Redial/Dialed calls" record.
zEven if "Auto redial as voice" is set to "ON", dialing
may not be possible because of conditions of the
network or other party, such as the line being busy.
<Hands-free switch>
zThe FOMA terminal does not switch to handsfree
mode automatically in the following cases even when
"Hands-free switch" is set to "ON":
• While Manner mode is set
• When a flat-plug earphone/microphone with switch
(optional) is connected (the microphone operation is
in accordance with the "Headset mic. setting")
• When holding a call or Record message is activated
for the incoming call
<V-phone while packet>
zEven when "V-phone priority" is set, you cannot
answer the videophone call if you are using multi
access such as i-mode communication during a voice
call.
zWhen "Packet downld priority", "V-phone
answerphone" or "Call forwarding" is set, the received
videophone calls are recorded as "Missed calls" in
"Received calls".
zEven when set to "V-phone priority" or "Packet downld
priority" is set, the "Voice Mail" or "Call Forwarding"
service is activated if the ring time for the "Voice Mail"
or "Call Forwarding" service is set to 0 second.
N
zIf “Front camera Reverse” is set to “OFF” for your
camera image, the decoration is displayed normally,
and a stamp with text can be read correctly.
26
Voice/Videophone Calls
■To canceling entering a message in the
enter text screen
XTo erase all the messageXt
■To erase the message manually after it is
displayed
Xt (1 second or longer)
You can also erase a message by selecting "Off
decoration" from the function menu.
Using the Videophone
Connected to External
Devices
You can make or receive videophone calls from
external devices such as a PC by connecting to the
FOMA terminal with the FOMA USB Cable with
Charge Function 01/02 (Optional).
To use this function, you have to install a videophone
application on the dedicated external device or PC
and prepare commercially available devices such as
an earphone/microphone and USB compatible Web
camera.
zSet the USB mode setting to "Communication
mode". No specific settings are required to connect
external devices.
zFor details on the operating environment, settings,
operating procedure of the videophone application,
refer to the manuals supplied with the external
devices.
z"ドコモテレビ電話ソフト (DOCOMO Videophone
Software)" (Japanese) is compatible with this
function.
You can download the software from the webpage
for DOCOMO Videophone Software (Japanese).
(For information such as details on the PC
operating environment, refer to the support
website.)
N
zIf “Front camera Reverse” is set to "OFF" for your
camera image, the decoration is displayed normally,
and text can be read correctly.
http://videophonesoft.nttdocomo.co.jp/
(Japanese)
N
zYou cannot make a videophone call from the external
device during a voice call.
zWhen you have subscribed to either of Call Waiting,
Voice Mail or Call Forwarding and you receive a
videophone call from an external device during a voice
call, you can answer the call after ending the current
call. When you receive a voice call, videophone call or
64K data communication during a videophone call
from the external device, you can answer the call in
the same way.
FOMA videophone
Connection speed: 64K
Base station
FOMA
network

Navigation menu
