NEC of America AZB9304 Cellular WCDMA/ HSDPA Phone with Bluetooth and WLAN User Manual

NEC Corporation of America Cellular WCDMA/ HSDPA Phone with Bluetooth and WLAN Users Manual

Contents

Users Manual

1
Phone Calls
Making a call/videophone call
Making a call by entering the phone number
1 Enter the phone number starting with the area code,
then (voice call) / Fn with 2 (V.phone)
z Videophone operation
← / → : Adjust zoom
(1 second or longer): Mute your voice
2 After the call ends,
Making a call from Phonebook
Add the phone number of the other party to the phonebook
in advance.
1 MENU＞"TEL function"＞"Phonebook" ＞"Search
phonebook" ＞Select a search condition and search
an entry ＞Use ↑ / ↓ / ← / → to select an entry,
then (voice call)/
Fn with 2 (V.phone)
Making a call from Redial/Received calls
Add the phone number of the other party to the phonebook
in advance.
1 Use → (Redial) or ← (Received calls) to select the
other party, then (voice call)/ Fn with 2 (V.phone)
2
Notifying the other party of your phone number
Set whether to show your phone number (caller ID) on the
other party's phone (display) when making a call.
1 MENU ＞"TEL function" ＞ "
Dial/Receive setting"
＞"Caller ID notification" ＞"Activate/Deactivate"
2 "ON" or "OFF"
Information • If you hear a message requesting your caller
ID, make a call again with Caller ID
notification enabled or with 186 prefix.
Making an international call
Use WORLD CALL to make international calls from Japan.
• You can make calls from overseas. (→ p.10)
1 010＞Country codes＞Area code (City code) ＞Other
party's phone number＞ (voice call)/ Fn with 2
(V.phone)
2 After the call ends,
Information • Dial the other party's phone number
excluding "0" at the beginning of the area
code (city code). However, to make a call to
some countries/areas, such as in Italy, "0" is
required.
3
Receiving a call/videophone call
• When you receive an incoming call, the ring tone sounds.
1 When you receive an incoming call,
2 After the call ends,
Adjusting earpiece volume
1 MENU ＞"TEL function" ＞ "
Dial/Receive setting"
＞"In-call setting" ＞"Volume"＞Adjust with ↑ / ↓
Information • During a call, you can adjust the volume with
/
4
When you cannot answer a call
Setting to record a voice and videophone message
When you cannot answer a voice or videophone call, the
FOMA terminal can record a voice or videophone
message.
1 MENU ＞"TEL function"＞"Rec. msg./Voice memo"
＞" Record message setting" ＞" ON "＞"Phone" or
"Videophone"＞Select an item
2 Set ring time (3-digit number meaning 000-120
seconds)
■If you receive a call with Record message setting ON
Record message activates if the set time ends. Press
to answer a voice call while recording. Press
(Answer with camera image) or Enter (Subst.) (Answer
with substitute image) to answer a videophone call while
recording.
■To play a recorded message
On the standby screen, Enter ＞"" (Record message) or
"" (Record VP message) ＞Select an item
5
Setting Public mode (Driving mode)
When Public mode (Driving mode) is set, a caller hears a
message that you cannot answer the call because you are
driving or in a place where you have to refrain from using a
mobile phone (on a train or bus, in a theater, etc.), then the
call ends.
1 On the standby screen, Fn with
z appears on the standy screen.
■To deactivate
On the standby screen, Fn with
Setting Public mode (Power OFF)
When Public mode (Power OFF) is set, a caller who made
a call while the power is off hears a message that you
cannot answer the call because you are in a place where
you have to turn off the mobile phone (in a hospital, on an
airplane, around a priority seat on a train, etc.), then the
call ends.
1 ＊ ２ ５ ２ ５ １＞
■To deactivate
＊ ２ ５ ２ ５ ０＞
6
Using various Network Services
■ Available network services
Useful DOCOMO network services are available.
・ The network services are not available when you are
outside the service area or in a place where the signal is
weak.
・ For details, refer to "Mobile Phone User's Guide [Network
Services]".
Service name Application Monthly
charge
Voice Mail Service Required Charged
Call Waiting Required Charged
Call Forwarding
Service
Required Free
Nuisance Call
Blocking
Not required Free
Caller ID Notification Not required Free
Caller ID Request Not required Free
Dual Network Service Required Charged
English Guidance Not required Free
Multi Number Required Charged
2in1 Required Charged
Public mode (Driving
mode)
Not required Free
Public mode (Power
OFF)
Not required Free
OFFICEED Required Charged
Melody call Required Charged
7
・ "OFFICEED" requires a subscription and is a fee based
service.
For details, refer to the NTT DOCOMO corporate website
(http://www.docomo.biz/html/service/officeed/
(Japanese)).
Setting Voice Mail Service
1 MENU ＞"TEL function"＞"Voice mail service" ＞
Select an item
Setting Call Waiting
1 MENU ＞"TEL function" ＞" Other network serv."
＞"Call waiting"＞Select an item
Setting Call Waiting
1 MENU ＞"TEL function" ＞" Other network serv."
＞"Call forwarding"＞Select an item
8
Services available for the FOMA terminal
Availabile services Phone number
Directory assistance
(pay: service charge + call charge)
* Unlisted phone numbers cannot be
given.
(No area code) 104
Telegram (pay: telegram charge) (No area code) 115
Time (pay) (No area code) 117
Weather (pay) Area code for
weather forecast
your want +177
Police emergency (No area code) 110
Fire brigade/Ambulance emergency (No area code) 119
Maritime distress call (No area code) 118
Emergency Message Recording
System (pay)
(No area code) 171
Collect call (pay: service charge + call
charge)
(No area code) 106
・ If you are using a "Call Forwarding" service from a
general phone and if a mobile phone is set as the
forwarding number, depending on the settings of the
general phone or mobile phone, the caller may simply
hear the ring tone even when the mobile phone is busy
with another call, out of range, in Self mode or turned off.
9
・ When calling 110, 119 or 118 from the FOMA terminal,
first say you are calling from a mobile phone, give your
number, and state your location clearly, because the
police or fire department may call you back for
confirmation. Also, do not move around when making the
call. Do not turn off the power immediately after ending
the call, but leave it turned on for ten minutes or so, so
that you can receive a call.
・ Depending on the area you are calling from, you may not
be connected with the nearest police or fire department,
etc. In this case, dial from a public or general subscriber
phone.
10
Using overseas
To make calls overseas, use international roaming (WORLD
WING).
■International roaming (WORLD WING) is the service,
which enables you to make calls and perform
communication over networks of affiliated
telecommunications carriers using the FOMA terminal,
phone number and mail address of your own for Japan,
even when you are overseas. Voice calls, SMS and i-mode
mail services are available without any special settings.
■Supported area
This FOMA terminal can be used in the 3G network service
areas. Also can be used in countries/regions compatible with
3G 850 MHz. Check available areas.
■Before overseas use, refer to the following:
- "海外ご利用ガイド" (Overseas use guide) (Japanese) in
"i-mode" folder in "My document" under Data box
- "Mobile Phone User's Guide [International Services]"
- DOCOMO "International services website".
■Information
・
For a country code, international call access code and
international prefix number for the universal number, refer
to "Mobile Phone User's Guide [International Services]" or
DOCOMO "International services website".
・
Overseas usage fees (call charge, packet communications
charge) differ from those in Japan.
11
Available services overseas
Communication services 3G
Voice call*1 ○
Videophone call*1 ○
SMS*2 ○
i-mode*3 ○
i-mode mail ○
i-Channel*3*4 ○
i-concier*5 ○
i-Widget*6 ○
Packet communications via a
PC
○
*1: When 2in1 is active, dialing using Number B is not available. Dialing using
the additional number of Multi number is not available.
*2: When sending an SMS to FOMA terminal user, enter the other party's
phone number as in Japan.
*3: "i-mode overseas use" setting is required.
*4: "i-channel overseas use" setting is required. Packet communications
charges will apply when you automatically update information on "Basic
Channel".
*5: "i-concier overseas use" setting is required. Packet communications
charges will apply for each reception of information. (Included in i-channel
charges in Japan.)
*6: "i-Widget overseas use" setting is required. When you open the i-Widget
screen, multiple Widget Appli may establish communications. In this case,
packet communications charges will apply for each communication.
12
Information • Some services are not available depending
on the operator or network overseas. For
countries and operators, refer to "Mobile
Phone User's Guide [International Services]"
or visit the DOCOMO "International services
website".
Making a call to outside your destination country
1 ０ (1 second or longer) to enter + ＞Country code＞
Area code (City code) ＞The other party's phone
number＞ (voice call)/
Fn with 2 (V.phone)
2 After the call ends,
Information • To make an international call to Japan, dial
"81" as country code.
• Dial the other party's phone number
excluding "0" at the beginning of the area
code (city code). However, to make a call to
some countries/areas, such as in Italy, "0" is
required.
13
Making a call in the country of stay
1 Area code (City code) ＞The other party's phone
number＞ (voice call)/
Fn with 2 (V.phone)
2 After the call ends,
Making a call to "WORLD WING" user overseas
When making a call to "WORLD WING" user overseas,
make a call as an international call to Japan (dial "81"
(Japan) as the country code), irrespective whether the
other party is in or out of the country you stay.
1 ０ (1 second or longer) to enter + ＞８ １＞other
party's mobile phone number excluding the first "0"＞
(voice call)/
Fn with 2 (V.phone)
2 After the call ends,
