User manual
1
8
2
9
3
10
4
11
5
12
6
13
7
14
English - CJB184JALAAA
Quick Start Guide
The mobile phone is in compliance with the requirement of EN
60950-1: 2006 amendment A12: 2011. There will appear a warning
box when the volume level is over 9. If the user selects in the
warning box, the volume can be increased and the phone will repeat
the acknowledgement more than once every 20h of cumulative
listening time.
PROTECT YOUR HEARING
To prevent possible hearing damage, do not listen at
high volume levels for long periods. Exercise caution
when holding your device near your ear while the
loudspeaker is in use.
ONETOUCH 2041 Your mobile
1 ...................
1 Left soft key
2 Call log (Idle screen)
Send call
3 Voicemail (long press)
4 Lock Key (long press
key)
5 Right soft key
6 Power on/Power off
End call
7 Vibration alert
8 Navigation key :
Menu/Confirm an option
1
2 6
3
5
7
4
8
Keys1.1
Navigation key
Confirm an option (press the middle of the key)
Access to call log (idle screen)
Power on/off the handset (long press)
End call
Return to idle
Left soft key
Right soft key
Dial the voicemail number (long press)
From Idle screen
- Short press: enter zero
- Long press: +, "+" are used for dialing an international
call.
- Press longer: Input P/W, "P" and "W" are used for
calling the extension.
In Edit mode:
- Short press: access symbol select.
Input 0 (when the input method is numeric)
From Idle screen
- Short press: Input "*"
- Long press: Lock keypad
In Edit mode:
- Short press: change the input method
From Idle screen
- Short press: Input "#"
- Long press: activate vibrate/general.
In Edit mode:
- Short press: space
Idle screen icons1.2
Battery charge level.
Vibrate mode: your phone vibrates, but neither rings
nor beeps.
Headset connected.
Silence mode: your phone neither rings, beeps nor
vibrates.
Alarm clock programmed.
Voicemail message arrived.
Missed calls.
Roaming.
Level of network reception.
Message unread.
MMS unread.
Call divert.
Message full.
Bluetooth activated.
When you insert SD card will display this icon in sreen.
Getting started
2 ............
Set-up2.1
Removing and installing the back cover
Removing and installing the battery
Inserting and removing TF card
Inserting and removing SIM
Charging the battery
Connect the battery charger to your phone and mains socket
respectively.
The charging may take about 20 minutes to start if the battery •
is flat.
Be careful not to force the plug into the socket. •
Make sure the battery is correctly inserted before connecting •
the charger.
The mains socket must be near to the phone and easily •
accessible (avoid electric extension cables).
When using your telephone for the first time, charge the •
battery fully (approximately 3 hours). You are advised to
fully charge the battery ( ).
To reduce power consumption and energy waste, when •
battery is fully charged, disconnect your charger from the
plug; reduce the backlight time, etc.
The charge is complete when the animation stops.
Power on your phone2.2
Hold down the key until the phone powers on.
Power off your phone2.3
Hold down the key from the idle screen.
Calls
3 ...............................
Making a call3.1
Dial the desired number, press the key to place the call. If you
make a mistake, you can delete the incorrect digits by pressing the
. To hang up the call, press the key.
Making an emergency call
If your phone is covered by the network, dial emergency number
and press the key to make an emergency call. This works even
without a SIM card and without unlocking the keypad.
Calling your voicemail 3.2 (1)
You can see SIM voice mail in this menu.
Receiving a call3.3
When you receive an incoming call, press the key to talk and
then hang up using the key.
Available functions during the call3.4
During a call, you can use your directory, short messages, etc. without
losing your correspondent.
(1) Contact your network operator to check service availability.
Messages
4 .................
Create SMS4.1
From the main menu select “Messages” to create text message.
You can type a message send it to a recipient in the SIM card
directory. You can type a message, and you're also able to insert a
pre-defined message from “Templates”. While writing a message,
select “Options” to access all the messaging options.
Specific letters (accent) will increase the size of the
SMS, this may cause multiple SMS to be sent to your
recipient.
Create MMS4.2
Select Messages-Options-New chat-Options-Add subject, it will
switch to MMS interface automatically.
Contacts
5 ..................
Consulting your contacts5.1
To access the directory from the idle screen, press the key and
select the icon from the menu.
Adding a contact5.2
Select the directory in which you wish to create a file, press the
“Options”, select “New” then save it to "Phone" , "SIM" as you
like.
Call log
6 ......................
You can access your call memory by pressing from the idle screen,
or press the key and select the icon from the menu.
In this menu, you will see Missed call(s), Dialed call(s), Received call(s)
and Rejected call(s), etc.
Camera
7 .....................
This function enables you to take pictures. Press to take the
picture.
Music
8 ........................
Use this function to play audio files. Press to play/pause the audio
player, short press or to last or next audio, in audio player interface,
press and to tune volume.
Videos
9 .......................
Use this funtion to play video files. Press to play/pause the video
player, short press and to tune volume; press or to last or
next video.
FM radio
10 ...............
Your phone is equipped with a radio. You can use the application as a
traditional radio with saved channels. In FM radio interface, press
to play/pause the playing process of the current channel, press and
to tune volume.
Recorder
11 ...............
Use this function to record audio files. The phone support WAV and
AMR. The recording file you stopped will be stored in Audio file list
automatically.
My files
12 ..................
The phone provides a certain space for users to manage files and
support the memory card. The capacity of the memory card is
selectable. You can use the file manager to conveniently manage various
directories and files on the phone and the memory card.
Games
13 ...................
Two games named Sokoban and Snake are embedded in the phone.for
more information please refer to ''help'' in the game.
Profiles
14 ..................
With this menu, you may personalize ringtones for different events
and environments.
Alarm
15 ....................
Your mobile phone has a built-in alarm clock with snooze feature.
Calculator
16 .............
Press the up, down, left, right and OK key to select +, - ×, ÷ and =
respectively.
Press to delete the figure.
Calendar
17 ...............
Once you enter this menu, there is a monthly-view calendar for you to
view the date; you can go to any day you want.
Fake call
18 ................
You can create fake call through this function.
Call filter
19 ...............
You can filter the calls you don’t want to get through this function.
Services
20 ................
STK service is the tool kit of SIM card. This phone supports the service
function .The specific items depend on SIM card and network. Service
menu will be automatically added to the phone menu when supported
by network and SIM card.
Settings
21 .................
From the main menu, select the menu icon and select the
function of your choice in order to customize your telephone: Phone
settings, Call settings, Connections, Security and Restore
factory settings.
Bluetooth
22 .............
You can transfer data, such as music to other device using Bluetooth.
Search the device and accept/transfer data. The received data is
automatically stored in the directory.
Java
23 ........................
Please install Java firstly through press Options key.then you can manage
application as your need.
Opera Mini
24 ..........
After installed it you can view webpage when you connected with
internet.
Dorado
25 .................
You can view webpage when you connected with internet through
this function.
Facebook
26 ..............
Open facebook network can communicate.
To r c h
27 .....................
Long press 5 to open the flashlight function.
Input mode
28 ................
This mode allows you to type a text by choosing a letter or a sequence
of characters associated with a key. Press the key several times until
the desired letter is highlighted. When you release the key the highlight
character is inserted into the text.
© Copyright 2014 TCT Mobile Limited
All rights reserved
TCT Mobile Limited reserves
the right to alter material
or technical specification
without prior notice.
IP4722_2041_QG_Eng_GB_Java_06_140606.indd 1IP4722_2041_QG_Eng_GB_Java_06_140606.indd 1 2014-6-6 4:32:002014-6-6 4:32:00
15
22
16
23
17
24
18
25
19
26
20
27
21
28
Safety and use ......................
We recommend that you read this chapter carefully before using
your phone. The manufacturer disclaims any liability for damage, which
may result as a consequence of improper use or use contrary to the
instructions contained herein.
TRAFFIC SAFETY:•
Given that studies show that using a mobile phone while driving a vehicle
constitutes a real risk, even when the hands-free kit is used (car kit,
headset...), drivers are requested to refrain from using their mobile when
the vehicle is not parked.
When driving, do not use your phone and headphone to listen to music or to
the radio. Using a headphone can be dangerous and forbidden in some areas.
When switched on, your phone emits electromagnetic waves that can
interfere with the vehicle’s electronic systems such as ABS anti-lock
brakes or airbags. To ensure that there is no problem:
- do not place your phone on top of the dashboard or within an airbag
deployment area,
- check with your car dealer or the car manufacturer to make sure that
the dashboard is adequately shielded from mobile phone RF energy.
CONDITIONS OF USE:•
You are advised to switch off the telephone from time to time to
optimise its performance.
Switch the phone off before boarding an aircraft.
Switch the phone off when you are in health care facilities, except in
designated areas. As with many other types of equipment now in regular
use, mobile telephones can interfere with other electrical or electronic
devices, or equipment using radio frequency.
Switch the phone off when you are near gas or flammable liquids. Strictly
obey all signs and instructions posted in a fuel depot, petrol station, or
chemical plant, or in any potentially explosive atmosphere.
When the phone is switched on, it should be kept at least 15 cm from any
medical device such as a pacemaker, a hearing aid or insulin pump, etc. In
particular when using the phone, you should hold it against the ear on
the opposite side to the device, if any.
To avoid hearing impairment, pick up the call before holding your phone
to your ear. Also move the handset away from your ear while using the
“hands-free” mode because the amplified volume might cause hearing
damage.
Do not let children use the phone and/or play with the telephone and
accessories without supervision.
When replacing the cover please note that your phone may contain
substances that could create an allergic reaction.
Always handle your phone with care and keep it in a clean and dust-
free place.
Do not allow your phone to be exposed to adverse weather or
environmental conditions (moisture, humidity, rain, infiltration of liquids,
dust, sea air, etc). The manufacturer’s recommended operating temperature
range is -10°C to +55°C.
At over 55°C the legibility of the phone’s display may be impaired, though
this is temporary and not serious.
Emergency call numbers may not be reachable on all cellular networks. You
should never rely only on your phone for emergency calls.
Do not open, dismantle or attempt to repair your mobile phone yourself.
Do not drop, throw or bend your mobile phone.
Do not use the phone if the glass made screen, is damaged, cracked or
broken to avoid any injury.
Do not paint it.
Use only batteries, battery chargers, and accessories which are recommended
by TCT Mobile Limited and its affiliates and are compatible with your phone
model. TCT Mobile Limited and its affiliates disclaim any liability for damage
caused by the use of other chargers or batteries.
Remember to make back-up copies or keep a written record of all
important information stored in your phone.
Some people may suffer epileptic seizures or blackouts when exposed to
flashing lights, or when playing video games. These seizures or blackouts may
occur even if a person never had a previous seizure or blackout. If you have
experienced seizures or blackouts, or if you have a family history of such
occurrences, please consult your doctor before playing video games on your
phone or enabling a flashing-lights feature on your phone.
Parents should monitor their children’s use of video games or other
features that incorporate flashing lights on the phones. All persons should
discontinue use and consult a doctor if any of the following symptoms
occur: convulsion, eye or muscle twitching, loss of awareness, involuntary
movements, or disorientation. To limit the likelihood of such symptoms,
please take the following safety precautions:
- Do not play or use a flashing-lights feature if you are tired or need sleep.
- Take a minimum of a 15-minute break hourly.
- Play in a room in which all lights are on.
- Play at the farthest distance possible from the screen.
- If your hands, wrists, or arms become tired or sore while playing, stop and
rest for several hours before playing again.
- If you continue to have sore hands, wrists, or arms during or after playing,
stop the game and see a doctor.
When you play games on your phone, you may experience occasional
discomfort in your hands, arms, shoulders, neck, or other parts of your body.
Follow the instructions to avoid problems such as tendinitis, carpal tunnel
syndrome, or other musculoskeletal disorders.
PROTECT YOUR HEARING
To prevent possible hearing damage, do not listen at high
volume levels for long periods. Exercise caution when
holding your device near your ear while the loudspeaker
is in use.
PRIVACY:•
Please note that you must respect the laws and regulations in force in
your jurisdiction or other jurisdiction(s) where you will use your mobile
phone regarding taking photographs and recording sounds with your
mobile telephone. Pursuant to such laws and regulations, it may be strictly
forbidden to take photographs and/or to record the voices of other people
or any of their personal attributes, and duplicate or distribute them, as
this may be considered to be an invasion of privacy. It is the user's sole
responsibility to ensure that prior authorisation be obtained, if necessary, in
order to record private or confidential conversations or take a photograph
of another person; the manufacturer, the seller or vendor of your mobile
phone (including the operator) disclaim any liability which may result from
the improper use of the mobile phone.
BATTERY:•
Before removing the battery from your phone, please make sure that the
phone is switched off.
Observe the following precautions for battery use:
- Do not attempt to open the battery (due to the risk of toxic fumes
and burns).
- Do not puncture, disassemble or cause a short-circuit in a battery.
- Do not burn or dispose of a used battery in household rubbish or store
it at temperatures above 60°C.
Batteries must be disposed of in accordance with locally applicable
environmental regulations. Only use the battery for the purpose for which
it was designed. Never use damaged batteries or those not recommended
by TCT Mobile Limited and/or its affiliates.
This symbol on your telephone, the battery and the accessories
means that these products must be taken to collection points
at the end of their life:
- Municipal waste disposal centres with specific bins for these
items of equipment.
- Collection bins at points of sale.
They will then be recycled, preventing substances being disposed of in the
environment, so that their components can be reused.
In European Union countries:
These collection points are accessible free of charge.
All products with this sign must be brought to these collection points.
In non European Union jurisdictions:
Items of equipment with this symbol are not to be thrown into ordinary bins
if your jurisdiction or your region has suitable recycling and collection facilities;
instead they are to be taken to collection points for them to be recycled.
CAUTION: RISK OF EXPLOSION IF BATTERY IS REPLACED BY AN
INCORRECT TYPE. DISPOSE OF USED BATTERIES ACCORDING TO
THE INSTRUCTIONS.
CHARGERS•
Mains powered chargers will operate within the temperature range of:
0°C to 40°C.
The chargers designed for your mobile phone meet with the standard
for safety of information technology equipment and office equipment use.
They are also compliant to the ecodesign directive 2009/125/EC. Due to
different applicable electrical specifications, a charger you purchased in one
jurisdiction may not work in another jurisdiction. They should be used for
this purpose only.
Due to the used enclosure material, the mobile phone shall only be connected
to a USB Interface of version 2.0 or higher. The connection to so called power
USB is prohibited.The adapter shall be installed near the equipment and shall
be easily accessible. This charger is for indoor use only.
LICENCES •
microSD Logo is a trademark.
ONETOUCH 2041
General information ............
Hot Line Number:• see “TCT Mobile Services” leaflet or go to our
website.
Address: • Room 1910-12A, Tower 3, China HK City, 33 Canton Road,
Tsimshatsui, Kowloon, Hong Kong
On our website, you will find our FAQ (Frequently Asked Questions)
section. You can also contact us by e-mail to ask any questions you may
have.
An electronic version of this user guide is available in English and
other languages according to availability on our server:
www.alcatelonetouch.com
Your telephone is a transceiver that operates on GSM networks with 900
and 1800 MHz bands.
Protection against theft (1)
Your telephone is identified by an IMEI (phone serial number) shown on
the packaging label and in the phone’s memory. We recommend that you
note the number the first time you use your telephone by entering * # 0
6 # and keep it in a safe place. It may be requested by the police or your
operator if your telephone is stolen. This number allows your mobile
telephone to be blocked preventing a third person from using it, even with
a different SIM card.
(1) Contact your network operator to check service availability.
Disclaimer
There may be certain differences between the user manual description
and the phone’s operation, depending on the software release of your
telephone or specific operator services.
TCT Mobile shall not be held legally responsible for such differences, if
any, nor for their potential consequences, which responsibility shall be
borne by the operator exclusively.This handset may contain materials,
including applications and software in executable or source code form,
which is submitted by third parties for inclusion in this handset (“Third
Party Materials”). All third party materials in this handset are provided “as
is”, without warranty of any kind, whether express or implied, including
the implied warranties of merchantability, fitness for a particular purpose
or use/third party application, interoperability with other materials or
applications of the purchaser and non-infringement of copyright. The
purchaser undertakes that TCT Mobile has complied with all quality
obligations incumbent upon it as a manufacturer of mobile devices and
handsets in complying with Intellectual Property rights. TCT Mobile will
at no stage be responsible for the inability or failure of the Third Party
Materials to operate on this handset or in interaction with any other
devices of the purchaser. To the maximum extent permitted by law, TCT
Mobile disclaims all liability for any claims, demands, suits or actions, and
more specifically – but not limited to – tort law actions, under any theory
of liability, arising out of the use, by whatever means, or attempts to use,
such Third Party Materials. Moreover, the present Third Party Materials,
which are provided free of charge by TCT Mobile, may be subject to paid
updates and upgrades in the future; TCT Mobile waives any responsibility
regarding such additional costs, which shall be borne exclusively by the
purchaser. The availability of the applications may vary depending on the
countries and the operators where the handset is used; in no event shall
the list of possible applications and software provided with the handsets
be considered as an undertaking from TCT Mobile; it shall remain merely
as information for the purchaser. Therefore, TCT Mobile shall not be
held responsible for the lack of availability of one or more applications
wished for by the purchaser, as its availability depends on the country
and the operator of the purchaser. TCT mobile reserves the right at any
time to add or remove Third Party Materials from its handsets without
prior notice; in no event shall TCT Mobile be held responsible by the
purchaser for any consequences that such removal may have on the
purchaser regarding the use or attempt to use such applications and
Third Party Materials.
Warranty ..............................
Your phone is warranted against any defect or malfunctioning which
may occur in conditions of normal use during the warranty period of
twelve (12) months (1) from the date of purchase as shown on your
original invoice.
Batteries (2) and accessories sold with your phone are also warranted
against any defect which may occur during the first six (6) months (1) from
the date of purchase as shown on your original invoice.
In case of any defect of your phone which prevents you from normal
use thereof, you must immediately inform your vendor and present your
phone with your proof of purchase.
If the defect is confirmed, your phone or part thereof will be either
replaced or repaired, as appropriate. Repaired phone and accessories
are entitled to a one (1) month warranty for the same defect. Repair
or replacement may be carried out using reconditioned components
offering equivalent functionality.
This warranty covers the cost of parts and labor but excludes any
other costs.
This warranty shall not apply to defects to your phone and/or accessory
due to (without any limitation):
1) Non-compliance with the instructions for use or installation, or with
technical and safety standards applicable in the geographical area where
your phone is used,
2) Connection to any equipment not supplied or not recommended by
TCT Mobile Limited,
3) Modification or repair performed by individuals not authorised by TCT
Mobile Limited or its affiliates or your vendor,
4) Inclement weather, lightning, fire, humidity, infiltration of liquids or foods,
chemical products, download of files, crash, high voltage, corrosion,
oxidation…
Your phone will not be repaired in case labels or serial numbers (IMEI) have
been removed or altered.
There are no express warranties, whether written, oral or implied, other
than this printed limited warranty or the mandatory warranty provided by
your country or jurisdiction.
In no event shall TCT Mobile Limited or any of its affiliates be liable for
indirect, incidental or consequential damages of any nature whatsoever,
including but not limited commercial or financial loss or damage, loss of data
or loss of image to the full extent those damages can be disclaimed by law.
Some countries/states do not allow the exclusion or limitation of indirect,
incidental or consequential damages, or limitation of the duration of
implied warranties, so the preceding limitations or exclusions may not
apply to you.
Troubleshooting....................
Before contacting the service centre, you are advised to follow the
instructions below:
You are advised to fully charge ( • ) the battery for optimal
operation.
Avoid storing large amounts of data in your phone as this may affect •
its performance.
You can use reset by press power key+• . ALL User phone data:
contacts, photos, messages and files, downloaded applications will be
lost permanently.
and carry out the following checks:
My phone is frozen or cannot switch on
Check the battery contacts, remove and reinstall your battery, then •
turn your phone on.
Check the battery power level, charge for at least 20 minutes.•
If it still does not work, please reset the phone using the • power key
and the .
My phone has not responded for several minutes
Remove and re-install the battery, then restart the phone.•
My phone turns off by itself
Check that your screen is locked when you are not using your •
phone, and make sure the Power key is not mis-contacted due to
unlocked screen.
Check the battery charge level.•
If it still does not work, please use User Data Format to reset the •
phone.
My phone cannot charge properly
Make sure you are using an ONE TOUCH battery and the charger •
from the box.
Make sure your battery is inserted properly and clean the battery •
contact if it’s dirty. It must be inserted before plugging in the charger.
Make sure that your battery is not completely discharged; if the •
battery power is empty for a long time, it may take around 20 minutes
to display the battery charger indicator on the screen.
Make sure charging is carried out under normal conditions (0°C •
to +40°C).
When abroad, check that the voltage input is compatible.•
My phone cannot connect to a network or “No service” is
displayed
Try connecting in another location.•
Verify the network coverage with your operator.•
Check with your operator that your SIM card is valid.•
Try selecting the available network(s) manually •
Try connecting at a later time if the network is overloaded.•
My phone cannot connect to the Internet
Check that the IMEI number (press *#06#) is the same as the one •
printed on your warranty card or box.
Make sure that the internet access service of your SIM card is •
available.
Check your phone's Internet connecting settings.•
Make sure you are in a place with network coverage.•
Try connecting at a later time or another location.•
Invalid SIM card
Make sure the SIM card has been correctly inserted (see “Inserting or •
removing the SIM card”).
Make sure the chip on your SIM card is not damaged or scratched.•
Make sure the service of your SIM card is available.•
Unable to make outgoing calls
Make sure you have dialed a valid number and pressed the • key.
For international calls, check the country and area codes.•
Make sure your phone is connected to a network, and the network is •
not overloaded or unavailable.
Check your subscription status with your operator (credit, SIM card •
valid, etc.).
Make sure you have not barred outgoing calls.•
Make sure that your phone is not in flight mode.•
Unable to receive incoming calls
Make sure your phone is switched on and connected to a network •
(check for overloaded or unavailable network).
Check your subscription status with your operator (credit, SIM card •
valid, etc.).
Make sure you have not forwarded incoming calls.•
Make sure that you have not barred certain calls.•
Make sure that your phone is not in flight mode.•
The caller’s name/number does not appear when a call is
received
Check that you have subscribed to this service with your operator.•
Your caller has concealed his/her name or number.•
I cannot find my contacts
Make sure your SIM card is not broken.•
Make sure your SIM card is inserted properly.•
Import all contacts stored in SIM card to phone.•
The sound quality of the calls is poor
You can adjust the volume during a call by pressing the • Up/Down
key.
Check the network strength•
.
Make sure that the receiver, connector or speaker on your phone •
is clean.
I am unable to use the features described in the manual
Check with your operator to make sure that your subscription •
includes this service.
Make sure this feature does not require an ONE TOUCH accessory.•
When I select a number from my contacts, the number cannot
be dialed
Make sure that you have correctly recorded the number in your file.•
Make sure that you have selected the country prefix when calling a •
foreign country.
I am unable to add a contact in my contacts
Make sure that your SIM card contacts are not full; delete some •
files or save the files in the phone contacts (i.e. your professional or
personal directories).
My callers are unable to leave messages on my voicemail
Contact your network operator to check service availability.•
I cannot access my voicemail
Make sure your operator’s voicemail number is correctly entered in •
"Voicemail number".
Try later if the network is busy.•
I am unable to send and receive MMS
Check your phone memory availability as it might be full.•
Contact your network operator to check service availability and •
check MMS parameters.
Verify the server centre number or your MMS profile with your •
operator.
The server centre may be swamped, try again later.•
SIM card PIN locked
Contact your network operator to obtain the PUK code (Personal •
Unblocking Key).
I am unable to download new files
Make sure there is sufficient phone memory for your download.•
Select the microSD card as the location to store downloaded •
files.
Check your subscription status with your operator.•
How to make your battery last longer
Make sure you follow the complete charge time (minimum 4 •
hours).
After a partial charge, the battery level indicator may not be exact. •
Wait for at least 20 minutes after removing the charger to obtain
an exact indication.
Switch on the backlight upon request.•
Exit background-running applications if they are not being used •
for a long time.
The phone will become warm following prolonged calls,
game playing, internet surfing or running other complex
applications.
This heating is a normal consequence of the CPU handling •
excessive data. Ending above actions will make your phone return
to normal temperatures.
(1) The warranty period may vary depending on your country.
(2) The life of a rechargeable mobile phone battery in terms of conversation
time standby time, and total service life, will depend on the conditions of
use and network configuration. Batteries being considered expendable
supplies, the specifications state that you should obtain optimal
performance for your phone during the first six months after purchase
and for approximately 200 more recharges.
IP4722_2041_QG_Eng_GB_Java_06_140606.indd 2IP4722_2041_QG_Eng_GB_Java_06_140606.indd 2 2014-6-6 4:32:012014-6-6 4:32:01
FCC Statement
1. This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions:
(1) This device may not cause harmful interference.
(2) This device must accept any interference received, including interference that
may cause undesired operation.
2. Changes or modifications not expressly approved by the party responsible for
compliance could void the user's authority to operate the equipment.
NOTE:
This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference in a residential
installation.
This equipment generates uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.
SAR Information Statement
Your wireless phone is a radio transmitter and receiver. It is designed and
manufactured not to exceed the emission limits for exposure to radiofrequency (RF)
energy set by the Federal Communications Commission of the U.S. Government.
These limits are part of comprehensive guidelines and establish permitted levels of
RF energy for the general population. The guidelines are based on standards that
were developed by independent scientific organizations through periodic and
thorough evaluation of scientific studies. The standards include a substantial safety
margin designed to assure the safety of all persons, regardless of age and health. The
exposure standard for wireless mobile phones employs a unit of measurement
known as the Specific Absorption Rate, or SAR. The SAR limit set by the FCC is 1.6
W/kg. * Tests for SAR are conducted with the phone transmitting at its highest
certified power level in all tested frequency bands. Although the SAR is determined
at the highest certified power level, the actual SAR level of the phone while
operating can be well below the maximum value. This is because the phone is
designed to operate at multiple power levels so as to use only the power required to
reach the network. In general, the closer you are to a wireless base station antenna,
the lower the power output. Before a phone model is available for sale to the public,
it must be tested and certified to the FCC that it does not exceed the limit
established by the government adopted requirement for safe exposure. The tests are
performed in positions and locations (e.g., at the ear and worn on the body) as
required by the FCC for each model. The highest SAR value for this model phone
when tested for use at the ear is 0.602W/Kg and when worn on the body, as
described in this user guide, is 1.18W/Kg(Body-worn measurements differ among
phone models, depending upon available accessories and FCC requirements).. While
there may be differences between the SAR levels of various phones and at various
positions, they all meet the government requirement for safe exposure. The FCC has
granted an Equipment Authorization for this model phone with all reported SAR
levels evaluated as in compliance with the FCC RF exposure guidelines. SAR
information on this model phone is on file with the FCC and can be found under the
Display Grant section of http://www.fcc.gov/ oet/fccid after searching on
2AAZ8-F1030D Additional information on Specific Absorption Rates (SAR) can be
found on the Cellular Telecommunications Industry Asso-ciation (CTIA) web-site at
http://www.wow-com.com. * In the United States and Canada, the SAR limit for
mobile phones used by the public is 1.6 watts/kg (W/kg) averaged over one gram of
tissue. The standard incorporates a sub-stantial margin of safety to give additional
protection for the public and to account for any variations in measurements.
Body-worn Operation
This device was tested for typical body-worn operations. To comply with RF exposure
requirements, a minimum separation distance of 15mm must be maintained
between the user’s body and the handset, including the antenna. Third-party
belt-clips, holsters, and similar accessories used by this device should not contain any
metallic components. Body-worn accessories that do not meet these requirements
may not comply with RF exposure requirements and should be avoided. Use only the
supplied or an approved antenna.
