NGP Price Book 2016 National Guard Products
User Manual: NGP NGP Price Book Price Book
Open the PDF directly: View PDF
.
Page Count: 50
Phone: 800-647-7874
Fax: 800-255-7874
www.ngp.com
orders@ngp.com
FREIGHT POLICY:
Freight prepaid and allowed (Ground transportation only) in Continental US on orders as follows:
l Thresholds and Gasketing only = $1,000 net or more
l Lites/Louvers/Glass only or combined with
Thresholds/Gasketing = $1,500 net or more
l Non-transportation surcharges (i.e.: construction site delivery,
delivery notication, etc.) will be billed to the customer
l All expedited shipments like “Next Day Air” when requested, will be shipped FedEx, prepaid
and the published rate for the service will be added to the invoice.
l All cartons over 108" in length must be shipped LTL. Minimum freight on these orders is $120.
(Add 4" to material length to determine overall carton length.)
TERMS:
l 1% 10 days - Net 30 days
l Payable in US Dollars
l Credit cards accepted: Visa, Mastercard, Discover and American
Express (Payment terms: NET plus 3% processing)
MINIMUM:
$15.00 net for material
PACKING, HANDLING & INVOICING:
A charge of $15.00 net will be made on orders of $100.00 net or less.
Reinforced Packaging:
A $50 net charge on orders of
Glass only with any size over 35"
Lite Kits with glass any size over 35"
More than 50 Lite Kits with Glass any size
Louvers 64" and larger
Items requiring extra support (ie: welded thresholds, etc.)
RETURNS:
No returns will be accepted without prior approval. After approval and subject to our inspec-
tion, credit will be allowed less a minimum 30% handling charge and all related freight charges.
Material that is not in standard stock sizes and nishes, or is specially fabricated is not returnable.
Self-adhesive products may only be returned within 90 days of the date of sale.
CLAIMS:
Claims for material damage or shortages must be made within 5 days after receipt of material.
NGP is not responsible for any damages or charges beyond replacement of defective material.
(See Warranty)
CANCELLATION:
Orders for non-stock sizes, special nishes, custom fabricated, and glass products are
non-cancelable and non-returnable once in production.
Prices and terms are subject to change without notice.
Price List January 1, 2015
Revised March 15, 2016 to
Include New Products
NATIONAL GUARD PRODUCTS, INC.
THRESHOLDS
GASKETING
LITE KITS &
LOUVERS
EDGES &
ASTRAGALS
GLASS
FINGER
GUARDS
HOSPITALITY
Size Price
Replacement Weatherstrip Screws
Size Price
2 X 1/2" .20 / EA.
4 X 5/8" .20 / EA.
6 X 1/2" .17 / EA.
6 X 3/4" .20 / EA.
6 X 1" .25 / EA.
6 X 1 1/2" .34 / EA.
8-32 x 5/8" MS .95 / EA.
8 X 3/4" .32 / EA.
8 X 1" .34 / EA.
8 X 1 1/4" .36 / EA.
10 X 3/4" .36 / EA.
10 X 1 1/2" .38 / EA.
12 X 1 1/4" .40 / EA.
18 X 7/8" Nails (Wood Jambs) .20 / FT.
18 X 7/8" Nails (Wood Jambs) 37.00 / LB.
#4 Wafer Head (Metal Jambs) .50 / FT.
#4 Wafer Head (Metal Jambs) 77.00 / LB.
Bronze Weatherstrip Fasteners
Threshold Fasteners PER FT. or EA.
Plastic Anchor (PA) .37
Lead Expansion Shield (LES) .60
10-24 Mach. Screw/Lead Anchor (10-24 MS/LA) .85
1/4-20 Mach. Screw/Exp Anchor (1/4-20 MS/EA) 1.10
1/4-20 Combo MS/Anchor (1/4-20-2” Combo) 1.95
Tap-Con Type (1/4 X 1 3/4" Tap-Con) 1.00
Hilti Kwik-Con II TORX (1/4 X 1 3/4") 1.75
10-24 Mach. Screw (10-24 MS) .25
1/4-20 Mach. Screw (1/4-20 MS) .40
10-24 Lead Anchor (10-24 LA) .60
1/4-20 Expansion Anchor (1/4-20 EA) .70
Stainless Steel Fasteners
10-24 Mach. Screw/Lead Anchor (10-24 SS MS/LA) 1.35
1/4-20 Mach. Screw/Exp Anchor (1/4-20 SS MS/EA) 1.70
10 x 1 1/2" Stainless Wood Screw (10 x 1 1/2" SSWS) .95
12 x 1 1/2" Stainless Wood Screw (12 x 1 1/2" SSWS) 1.05
14 x 1 1/2" Stainless Wood Screw (14 x 1 1/2" SSWS) 1.20
Spanner Head Machine Screw & (Spanner 10-24 SSMS/LA) 2.45
Expansion Anchor (Spanner 1/4-20 SSMS/LA) 3.15
Replacement Threshold Screws
Price
10 x 1 1/2" Wood Screw .25 / EA.
Sex Nuts & Bolts for use with Astragals
SNB (for 1-3/4" doors only) 2.20 / FT. or EA. 6 X 3/4" .80
6 X 1" .90
6 X 1 1/2" 1.30
8 X 3/4" 1.15
8 X 1 1/2" 1.25
10 X 3/4" 1.35
10 X 1" 1.40
10 X 1 1/2" 1.45
12 X 1 1/2" 1.55
Size Per Ft. or EA.
Size Per Ft. or EA.
TORX Security Screws
Size Type Per Ft. or EA.
6 X 1/2" .22
6 X 3/4" .28
6 X 1" .35
6 X 1 1/2" .37
8 X 3/4" .38
8 X 1" .42
8 X 1 1/2" .47
10 X 3/4" .52
10 X 1 1/2" .58
12 X 1 1/2" .63
TEK Self-Drilling SS SMS
6 X 3/4" SS SMS 1.30
6 X 1" SMS 1.60
6 X 1 1/2" SMS 1.75
8 X 3/4" SMS 1.70
8 x 1" SMS 1.75
10 X 3/4" SMS 1.80
10 X 1" SMS 1.85
10 X 1 1/2" SMS 1.95
10-24 X 1 1/2" MS 1.70
10-24 X 1 1/2" MS x LA 2.30
12 X 1" SMS 1.85
12 X 1 1/2" SMS 2.15
1/4-20 X 1 1/2" MS 2.45
1/4-20 X 1 1/2" MS x EA 3.15
TORX BITS 20.00 / EA.
TORX DRIVER 24.00 / EA.
TORX DRIVER & set of 7 BITS 85.00 / EA.
2
NATIONAL GUARD PRODUCTS, INC.Phone: 800-647-7874
Fax: 800-255-7874
www.ngp.com
orders@ngp.com
Fasteners
Specialty Fasteners
Stainless Spanner Head SMS
3
Phone: 800-647-7874
Fax: 800-255-7874
www.ngp.com
orders@ngp.com
Phone: 800-647-7874
Fax: 800-255-7874
www.ngp.com
orders@ngp.com
Stainless Steel
Mill Finish Standard
US32 - Polished Stainless Steel - Add 30%
(up to 6" wide, 72" length maximum)
US32D - Brushed Stainless Steel - Add
25%
Bead Blasted - Add 15%
(up to 10” wide only)
“SIA” - “Slick It Ain’t” Abrasive Slip Resistant, Non-Skid Finish
Available on thresholds up to 24" wide, except 818 coverplates up to 10” wide.
All “SIA" products are fabricated to order and may not be returned for credit
Add: Aluminum or Stainless Steel Bronze
Multiply width (inches) x $4.75 per foot $14.25 per foot
Example: SIA on 425HD 5" wide x 6 feet long; multiply $4.75/ft. list x 5 (inches wide) x 6 (ft. long)
Optional Finishes Available on Thresholds & Gasketing
Optional Finishes Powder Coat Finishes
Available on all aluminum, bronze and stainless steel products - Maximum length 144”
Specify clearly on order “Powder Coat” and the color designation
Colors Available:
(DKB) Dark Bronze (T) Tan (BPR) Beige Primer (matches Steelcraft)
(GBL) Gloss Black (GPZ) Gray Primer (CAB) California Bronze (matches Anemostat)
(MBL) Matte Black (W) White (PTY) Putty (matches Anemostat Beige)
(TBL) Textured Black (B) Brass (Gold) (MW) Magnolia White (matches Timely Western White)
(ASL) Aluminum Silver (WB) Walnut Brown (matches Timely Browntone)
Corrosion resistant sealer is applied under all powder coat nishes, which dramatically increases
the corrosion resistance of the nished product. Powder coating is applied to exposed surfaces only.
Quotes available for custom colors, sizes greater than shown, and large quantities.
Powder coat items are nished to order and may not be returned for credit.
Add to cost of product: $15.00 / FT.
Set-up charge (less than 18 FT.): $250
Powder Coat Finishes
Aluminum
Mill Finish Standard
Polished Aluminum - Add 100%
Bead Blasted - Add 25%
(up to 10” wide only)
Architectural Bronze
Satin Finish Standard
Polished Bronze - Add 30%
Dark Oxidized Oil Rubbed
Bronze (US10B) - Add 40%
Bead Blasted - Add 25%
(up to 10” wide only)
4
Threshold Fabrication Charges:
Aluminum Bronze Stainless Steel
Ripping Per Foot Per Rip (List) $5.50 $ 7.50 N/A
Beveling Per Foot Per Side (List) $5.50 $ 7.50 $25.00
*Welding Per Foot Per Weld (List) $9.25 $11.25 $18.50
* Flush underside welding of 1/4" high threshold assemblies requires underside beveling. An inverted “V” is
required for welding; allowing the welded threshold to lay at on the oor. Aluminum thresholds 8143, 8144 and
8145 proles feature underside bevels; add beveling charges to other threshold assembly plates.
Custom Fabrication Charges:
Break Charge (per bend) $60.00 / EA.
Drilling (Non-standard quantity or pattern) $ 3.00 / FT.
Custom Drilling set up $60.00 / EA.
Custom Layout Set-up Charges may apply.
Reinforced Packaging:
An extra charge may be added for reinforced packaging required to support welded components. ($50.00 net min.)
Pre-Notching:
Aluminum or Bronze Stainless Steel
L-Notch (includes both ends) $10.50 / EA. $35.00 / EA.
Set-up charge (less than 100 pcs) $30.00 $125.00
U-Notch (includes both ends) $21.00 / EA. $70.00 / EA.
Set-up charge (less than 100 pcs) $60.00 $250.00
Returned Closed Ends:
R.C.E. (Alum.) $30.00 for Each Returned End
R.C.E. (Bronze) $40.00 for Each Returned End
R.C.E. (Stainless Steel) $60.00 for Each Returned End
Lead Lined Thresholds:
up to 5" wide = $25.00 / FT.
5 1/2" to 10” wide = $37.50 / FT.
Special Threshold Applications
NATIONAL GUARD PRODUCTS, INC.Phone: 800-647-7874
Fax: 800-255-7874
www.ngp.com
orders@ngp.com
Aluminum Stainless Steel Bronze
818 multiply width (inches)* x $ 6.95 / FT. multiply width (inches)* x $20.75 / FT. multiply width (inches)* x $54.50 / FT.
814 multiply width (inches)* x $11.45 / FT. multiply width (inches)** x $37.50 / FT. n/a
828 multiply width (inches)* x $9.25 / FT n/a n/a
838 multiply width (inches)** x $18.15 / FT n/a n/a
* 3" minimum width charge
**4” minimum width
Beveled edges standard
* 3" minimum width
** 4" minimum width
For beveled edges add $25/
ft. per edge.
* 3" minimum width
Beveled edges standard
Example: For an 818 (alum) 8 inches wide by 6 feet long: multiply $6.95/ft. list x 8 (inches wide) x 6 (ft. long).
DKB powder coat nish ONLY offered on cover plates with “SIA” (non-skid) nish – Add 25% plus “SIA” charge on page 3.
Cover Plate Thresholds
Cover Plate Thresholds Threshold Assembly Components
Threshold Assembly Components
882 15.00 / FT.
882DKB 20.00 / FT.
8133 5.75 / FT.
8133DKB 8.20 / FT.
8134 11.30 / FT.
8134DKB 17.80 / FT.
8136 5.20 / FT.
8136BR 49.00 / FT.
8136DKB 7.95 / FT.
8137 5.50 / FT.
8137DKB 7.25 / FT.
8138 5.35 / FT.
8139 7.45 / FT.
8139BR 70.00 / FT.
8139DKB 10.45 / FT.
8140 5.15 / FT.
8140BR 44.50 / FT.
8140DKB 7.65 / FT.
8141 7.75 / FT.
8141DKB 11.25 / FT.
8142 8.50 / FT.
8142BR 74.00 / FT.
8142DKB 11.00 / FT.
8143 11.20 / FT.
8143BR 115.50 / FT.
8143DKB 15.70 / FT.
8144 14.75 / FT.
8144BR 146.00 / FT.
8144DKB 19.25 / FT.
8145 17.75 / FT.
8145BR 194.00 / FT.
8145DKB 23.75 / FT.
8146 20.75 / FT.
8146BR 230.00 / FT.
8146DKB 27.25 / FT.
8147 25.50 / FT.
8147DKB 34.25 / FT.
8148 26.75 / FT.
8148DKB 38.25 / FT.
8149 36.25 / FT.
8149DKB 51.00 / FT.
8150 36.25 / FT.
8150DKB 51.00 / FT.
8152 8.00 / FT.
8152DKB 12.00 / FT.
8163 12.20 / FT.
8163DKB 17.20 / FT.
8164 15.50 / FT.
8164DKB 20.50 / FT.
8167 25.50 / FT.
8167DKB 32.00 / FT.
8168N 8.15 / FT.
8170 39.75 / FT.
8170DKB 52.75 / FT.
Bar Supports
BAR 1 5.85 / FT.
BAR 1BR 40.00 / FT.
BAR 2 6.00 / FT.
BAR 2BR 45.50 / FT.
BAR 4 8.75 / FT.
BAR 6SS 21.00 / FT.
BAR 6SS-2-10 BEV-TAP 43.00 / FT.
5
Phone: 800-647-7874
Fax: 800-255-7874
www.ngp.com
orders@ngp.com
Phone: 800-647-7874
Fax: 800-255-7874
www.ngp.com
orders@ngp.com
6
NATIONAL GUARD PRODUCTS, INC.Phone: 800-647-7874
Fax: 800-255-7874
www.ngp.com
orders@ngp.com
Ramps - Butted Condition
R50 14.85 / FT.
R50DKB 23.85 / FT.
R50SIA 43.35 / FT.
R75 26.00 / FT.
R75DKB 39.30 / FT.
R75SIA 68.75 / FT.
R100 34.65 / FT.
R100DKB 49.00 / FT.
R100SIA 91.65 / FT.
R125 48.70 / FT.
R125DKB 66.75 / FT.
R125SIA 119.95 / FT.
R150 58.80 / FT.
R150DKB 79.45 / FT.
R150SIA 144.30 / FT.
R175 75.50 / FT.
R175DKB 99.95 / FT.
R175SIA 175.25 / FT.
R200 86.00 / FT.
R200DKB 113.00 / FT.
R200SIA 200.00 / FT.
R225 104.00 / FT.
R225DKB 134.00 / FT.
R225SIA 232.25 / FT.
R250 122.50 / FT.
R250DKB 155.50 / FT.
R250SIA 265.00 / FT.
Ramps - Overlap Condition
RO50 41.85 / FT.
RO50DKB 56.85 / FT.
RO50SIA 98.85 / FT.
RO75 53.00 / FT.
RO75DKB 72.30 / FT.
RO75SIA 124.25 / FT.
RO100 61.65 / FT.
RO100DKB 82.00 / FT.
RO100SIA 147.15 / FT.
RO125 75.70 / FT.
RO125DKB 99.75 / FT.
RO125SIA 175.45 / FT.
RO150 85.80 / FT.
RO150DKB 112.45 / FT.
RO150SIA 199.80 / FT.
RO175 102.50 / FT.
RO175DKB 132.95 / FT.
RO175SIA 230.75 / FT.
RO200 113.00 / FT.
RO200DKB 146.00 / FT.
RO200SIA 255.50 / FT.
RO225 131.00 / FT.
RO225DKB 167.00 / FT.
RO225SIA 288.00 / FT.
RO250 149.50 / FT.
RO250DKB 188.50 / FT.
RO250SIA 320.50 / FT.
Returned Closed Ends
For Aluminum Ramps
RCE-9 142.00 / ST.
RCE-9DKB 172.00 / ST.
RCE-9SIA 162.00 / ST.
RCE-9SIA-DKB 192.00 / ST.
RCE-15 232.00 / ST.
RCE-15DKB 262.00 / ST.
RCE-15SIA 252.00 / ST.
RCE-15SIA-DKB 282.00 / ST.
RCE-21 365.00 / ST.
RCE-21DKB 395.00 / ST.
RCE-21SIA 385.00 / ST.
RCE-21SIA-DKB 415.00 / ST.
RCE-30 455.00 / ST.
RCE-30DKB 485.00 / ST.
RCE-30SIA 475.00 / ST.
RCE-30SIA-DKB 505.00 / ST.
Rubber Ramps (Supplied
with Beveled Edges)
RR42 125.00 / FT.
RR952 35.50 / FT.
RR954 88.50 / FT.
Black RTV Silicone
Construction Sealant for
Rubber Ramps
& PVC Carpet Dividers
RR5007BL - 10.1 oz. 21.00 /tube
RR5007BL-12 242.00 /case
(case of 12)
Ramps
Ramps
7
Phone: 800-647-7874
Fax: 800-255-7874
www.ngp.com
orders@ngp.com
Phone: 800-647-7874
Fax: 800-255-7874
www.ngp.com
orders@ngp.com
Thresholds & Gasketing
17BR x 27.00 / FT.
17DKB x 5.15 / FT.
18V 5.70 / FT.
18VDKB 7.80 / FT.
19V 6.70 / FT.
19VB 10.70 / FT.
19VDKB 9.80 / FT.
26NA 8.95 / FT.
26NDKB 11.05 / FT.
35VA 7.68 / FT.
35VB 10.68 / FT.
35VDKB 9.78 / FT.
35ET (*NF) 7.35 / FT.
35ETDKB (*NF) 9.45 / FT.
35ET6 7.60 / FT.
35ET6DKB 9.70 / FT.
35EV 6.10 / FT.
35EVDKB 8.20 / FT.
36ET (*NF) 6.15 / FT.
36ETDKB (*NF) 8.25 / FT.
36ET6 6.40 / FT.
36ET6DKB 8.50 / FT.
36EV 4.90 / FT.
36EVDKB 7.00 / FT.
36VA 6.33 / FT.
36VDKB 8.33 / FT.
43CB (36", 48", 72", 86", 96") x 4.25 / FT.
54CP 5.70 / EA.
57 2.95 / FT.
58 4.20 / FT.
58DKB 5.35 / FT.
80 3.45 / FT.
80B 5.65 / FT.
92NA (*EC) 14.20 / FT.
92NDKB (*EC) 19.70 / FT.
92NWHA (*EC) 18.20 / FT.
92NWHDKB (*EC) 23.70 / FT.
92TA (*EC, *NF) 14.45 / FT.
92TDKB (*EC, *NF) 19.95 / FT.
92T6A (*EC) 14.70 / FT.
92T6DKB (*EC) 20.20 / FT.
5VA 8.10 / FT.
5VB 11.10 / FT.
5VDKB 10.10 / FT.
6VA 6.70 / FT.
6VDKB 8.70 / FT.
7ASL 39.00 / EA.
7DKB 39.00 / EA.
7SP 39.00 / EA.
12T (*NF) 5.20 / FT.
12TDKB (*NF) 7.30 / FT.
12T6 5.45 / FT.
12T6DKB 7.55 / FT.
12V 3.95 / FT.
12VDKB 6.05 / FT.
13TA (*NF) 7.15 / FT.
13TDKB (*NF) 9.25 / FT.
13T6A 7.40 / FT.
13T6DKB 9.50 / FT.
13VA 5.90 / FT.
13VDKB 8.00 / FT.
14RA-1 3/4" 11.85 / FT.
14RA-1 3/4" (SET) 23.70 / FT.
14RA-2 1/4" 15.25 / FT.
14RA-2 1/4" (SET) 30.50 / FT.
14RB-1 3/4" 15.25 / FT.
14RB-1 3/4" (SET) 30.50 / FT.
14RB-2 1/4" 19.00 / FT.
14RB-2 1/4" (SET) 38.00 / FT.
14RDKB-1 3/4" 14.00 / FT.
14RDKB-1 3/4" (SET) 28.00 / FT.
14RDKB-2 1/4" 17.40 / FT.
14RDKB-2 1/4" (SET) 34.80 / FT.
15NA 10.35 / FT.
15NB 13.35 / FT.
15NDKB 12.45 / FT.
16A x 5.15 / FT.
16B x 7.60 / FT.
16DKB x 6.55 / FT.
16SS x 52.00 / FT.
17 x 2.55 / FT.
17B x 5.55 / FT.
Flood Shields
FS10 - 36" 316.00 / EA.
FS10 - 40" 316.00 / EA.
FS10 - 52" 395.00 / EA.
FS10 - 64" 474.00 / EA.
FS10 - 76" 553.00 / EA.
FS10 - 96" 632.00 / EA.
FS22 - 36" 706.00 / EA.
FS22 - 40" 706.00 / EA.
FS22 - 52" 883.00 / EA.
FS22 - 64" 1059.00 / EA.
FS22 - 76" 1235.00 / EA.
FS22 - 96" 1412.00 / EA.
FS34 - 36" 1043.00 / EA.
FS34 - 40" 1043.00 / EA.
FS34 - 52" 1304.00 / EA.
FS34 - 64" 1564.00 / EA.
FS34 - 76" 1825.00 / EA.
FS34 - 96" 2085.00 / EA.
FSSP 75.00 / EA.
Security Door Guards
SDG-3 38.70 / EA.
SDG-4 38.70 / EA.
SDG-10B 38.70 / EA.
SDG-26 36.30 / EA.
SDG-26D 34.00 / EA.
SDG-BRKT-B 22.00 / EA.
SDG-BRKT-OW 11.00 / EA.
SDG-ET 6.50 / EA.
SDG-HO 6.50 / EA.
SDG-DS 6.50 / EA.
SDG-WS 6.50 / EA.
2V (*) 5.45 / FT.
2VDKB (*) 7.15 / FT.
3ASL 39.00 / EA.
3DKB 39.00 / EA.
3SP 39.00 / EA.
4V (*) 5.45 / FT.
4VDKB (*) 7.15 / FT.
Fast Attach Two Way Tape Available -
Specify “FATT” & add 1.20 per Foot
* BUMPER SEAL OPTIONS - Add Per Foot:
NGP-TPV (N) .82 • Pile (P) .16 • Silicone (S) .93
* NF Notched Fins - Add $3.30 Per Foot
*EC End Caps - Add $7.85 Per Set
100VDKB x 4.67 / FT.
101V 3.70 / FT.
101VA 4.35 / FT.
101VB 6.35 / FT.
101VDKB 5.85 / FT.
102VA 5.64 / FT.
102VB 7.24 / FT.
102VDKB 6.84 / FT.
103NA x 15.35 / FT.
103NAFS 17.85 / FT.
103NB x 19.85 / FT.
103NBFS 22.35 / FT.
103NDKB x 18.35 / FT.
103NDKBFS 20.85 / FT.
104NA x 18.78 / FT.
104NB x 23.28 / FT.
104NDKB x 21.78 / FT.
105NA x 19.00 / FT.
105NB x 23.50 / FT.
105NDKB x 22.00 / FT.
106NA x 15.50 / FT.
106NB x 21.00 / FT.
106NDKB x 20.00 / FT.
106SA x 16.00 / FT.
106SB x 21.50 / FT.
106SDKB x 20.50 / FT.
107NA x 11.12 / FT.
107NAFS 13.62 / FT.
107NB x 15.62 / FT.
107NBFS 18.12 / FT.
107NDKB x 14.12 / FT.
107NDKBFS 16.42 / FT.
107SA x 12.57 / FT.
107SB x 17.07 / FT.
107SDKB x 15.57 / FT.
108NA x 7.85 / FT.
108NB x 9.85 / FT.
108NDKB x 9.10 / FT.
109NA 5.88 / FT.
109NB 8.68 / FT.
109NDKB 7.98 / FT.
NATIONAL GUARD PRODUCTS, INC.Phone: 800-647-7874
Fax: 800-255-7874
www.ngp.com
orders@ngp.com
Fast Attach Two Way Tape Available -
Specify “FATT” & add 1.20 per Foot
* NF Notched Fins - Add $3.30 Per Foot
*EC End Caps - Add $7.85 Per Set
Thresholds & Gasketing
8
109NSS 24.75 / FT.
110NA 4.00 / FT.
110NB 5.80 / FT.
110NDKB 5.10 / FT.
110SA 5.45 / FT.
110SB 7.25 / FT.
110SDKB 6.55 / FT.
111 14.20 / FT.
111DKB 19.70 / FT.
112N 11.49 / FT.
112NDKB 13.59 / FT.
113NA 8.09 / FT.
113NDKB 10.19 / FT.
114NA 6.69 / FT.
114NB 8.29 / FT.
114NDKB 7.69 / FT.
114SA 8.29 / FT.
114SB 9.89 / FT.
114SDKB 9.29 / FT.
115NA 5.20 / FT.
115NA (SET) 10.40 / FT.
115NB 7.65 / FT.
115NB (SET) 15.30 / FT.
115NDKB 6.45 / FT.
115NDKB (SET) 12.90 / FT.
116N 6.64 / FT.
116NDKB 8.54 / FT.
118N 8.00 / FT.
118NDKB 11.00 / FT.
119N 9.00 / FT.
119NB 13.00 / FT.
119NDKB 12.00 / FT.
120NA x 5.25 / FT.
120NB x 7.65 / FT.
120NDKB x 6.85 / FT.
120NSS x 22.75 / FT.
120SA x 6.80 / FT.
120SB x 9.20 / FT.
120SDKB x 8.50 / FT.
120SSS x 24.30 / FT.
122NA 5.88 / FT.
92TWHA (*EC) 18.70 / FT.
92TWHDKB (*EC) 24.20 / FT.
92VA (*EC) 13.20 / FT.
92VDKB (*EC) 18.70 / FT.
92WHA (*EC) 16.70 / FT.
92WHDKB (*EC) 22.20 / FT.
95WH 8.65 / FT.
95WHDKB 12.65 / FT.
96V x 3.32 / FT.
96VA x 4.32 / FT.
96VB x 5.52 / FT.
96VDKB x 5.02 / FT.
97V x 2.42 / FT.
97V (SET) x 4.84 / FT.
97VA x 3.18 / FT.
97VA (SET) x 6.36 / FT.
97VB x 4.46 / FT.
97VB (SET) x 8.92 / FT.
97VDKB x 4.07 / FT.
97VDKB (SET) x 8.14 / FT.
98V x 3.70 / FT.
98VA x 4.20 / FT.
98VB x 5.70 / FT.
98VDKB x 5.20 / FT.
99NA (*EC) 15.30 / FT.
99NDKB (*EC) 20.80 / FT.
99NWHA (*EC) 19.30 / FT.
99NWHDKB (*EC) 24.80 / FT.
99TA (*EC, *NF) 15.55 / FT.
99TDKB (*EC, *NF) 21.05 / FT.
99T6A (*EC) 15.80 / FT.
99T6DKB (*EC) 21.30 / FT.
99TWHA (*EC) 19.80 / FT.
99TWHDKB (*EC) 25.30 / FT.
99VA (*EC) 14.30 / FT.
99VDKB (*EC) 19.80 / FT.
99WHA (*EC) 17.80 / FT.
99WHDKB (*EC) 23.30 / FT.
100V x 2.67 / FT.
100VA x 3.47 / FT.
100VB x 5.17 / FT.
Phone: 800-647-7874
Fax: 800-255-7874
www.ngp.com
orders@ngp.com
Phone: 800-647-7874
Fax: 800-255-7874
www.ngp.com
orders@ngp.com
Fast Attach Two Way Tape Available
-Specify “FATT” & add 1.20 per Foot
Thresholds & Gasketing
9
131NB 6.80 / FT.
131NDKB 6.30 / FT.
132NA 5.05 / FT.
132NB 7.15 / FT.
132NDKB 6.65 / FT.
133NA 5.60 / FT.
133NB 7.70 / FT.
133NDKB 7.20 / FT.
134NA 4.45 / FT.
134NB 6.25 / FT.
134NDKB 5.55 / FT.
134SA 6.00 / FT.
134SB 8.00 / FT.
134SDKB 7.50 / FT.
135N x 3.77 / FT.
135NA x 4.88 / FT.
135NB x 5.98 / FT.
135NDKB x 5.43 / FT.
136N 4.84 / FT.
136NDKB 7.98 / FT.
136P 3.94 / FT.
136PDKB 7.09 / FT.
136S 5.44 / FT.
136SDKB 8.59 / FT.
137NA 5.92 / FT.
137NA (SET) 11.84 / FT.
137NB 8.02 / FT.
137NB (SET) 16.04 / FT.
137NDKB 6.95 / FT.
137NDKB (SET) 13.90 / FT.
137SA 7.77 / FT.
137SA (SET) 15.54 / FT.
137SB 9.87 / FT.
137SB (SET) 19.74 / FT.
137SDKB 8.80 / FT.
137SDKB (SET) 17.60 / FT.
139A 6.16 / FT.
139ALD 31.16 / FT.
139BR 89.90 / FT.
139DKB 7.96 / FT.
139DKBLD 32.96 / FT.
139SP 6.25 / FT.
139SPDKB 8.25 / FT.
139SPLD 31.25 / FT.
139SS 26.25 / FT.
139SSLD 51.35 / FT.
140A x 15.60 / FT.
140B x 20.85 / FT.
140DKB x 19.80 / FT.
140PA x 15.60 / FT.
140PA (SET) x 31.20 / FT.
140PB x 20.85 / FT.
140PB (SET) x 41.70 / FT.
140PDKB x 19.80 / FT.
140PDKB (SET) x 39.60 / FT.
140SA x 16.00 / FT.
140SA (SET) x 32.00 / FT.
140SB x 21.25 / FT.
140SB (SET) x 42.50 / FT.
140SDKB x 20.20 / FT.
140SDKB (SET) x 40.40 / FT.
141NA x 15.80 / FT.
141NB x 21.05 / FT.
141NDKB x 20.00 / FT.
141PA x 15.90 / FT.
141PB x 21.15 / FT.
141PDKB x 20.10 / FT.
141SA x 16.30 / FT.
141SB x 21.55 / FT.
141SDKB x 20.50 / FT.
143NA 10.54 / FT.
143NB 14.74 / FT.
143NDKB 13.74 / FT.
143PA 10.04 / FT.
143PB 14.24 / FT.
143PDKB 13.24 / FT.
143SA 10.44 / FT.
143SB 14.64 / FT.
143SDKB 13.64 / FT.
144A 15.70 / FT.
144B 20.95 / FT.
144DKB 19.90 / FT.
122NB 8.68 / FT.
122NDKB 7.98 / FT.
122NSS 24.75 / FT.
123NA 3.79 / FT.
123NAX124A 7.67 / FT.
124A 3.88 / FT.
125NA 5.30 / FT.
125NA (SET) 10.60 / FT.
125NB 7.75 / FT.
125NB (SET) 15.50 / FT.
125NDKB 6.55 / FT.
125NDKB (SET) 13.10 / FT.
125NSS 24.30 / FT.
125NSS (SET) 48.60 / FT.
127NA 3.80 / FT.
127NB 6.20 / FT.
127NDKB 5.40 / FT.
127NSS 21.50 / FT.
127SA 5.35 / FT.
127SB 7.75 / FT.
127SDKB 7.05 / FT.
127SSS 23.05 / FT.
129NA 6.54 / FT.
129NB 8.94 / FT.
129NDKB 8.14 / FT.
129NSS 26.20 / FT.
129UA 8.14 / FT.
129UB 10.54 / FT.
129UDKB 9.74 / FT.
129USS 27.80 / FT.
130NA 4.73 / FT.
130NB 7.13 / FT.
130NBR 21.00 / FT.
130NDKB 6.33 / FT.
130NSS 23.50 / FT.
130SA 6.48 / FT.
130SB 8.88 / FT.
130SBR 22.75 / FT.
130SDKB 8.08 / FT.
130SSS 25.25 / FT.
131NA 4.70 / FT.
10
Fast Attach Two Way Tape Available
-Specify “FATT” & add 1.20 per Foot
144PA 15.70 / FT.
144PA (SET) 31.40 / FT.
144PB 20.95 / FT.
144PB (SET) 41.90 / FT.
144PDKB 19.90 / FT.
144PDKB (SET) 39.80 / FT.
144SA 16.10 / FT.
144SA (SET) 32.20 / FT.
144SB 21.35 / FT.
144SB (SET) 42.70 / FT.
144SDKB 20.30 / FT.
144SDKB (SET) 40.60 / FT.
149MA (SET) x 19.40 / FT.
149MB (SET) x 24.90 / FT.
149MDKB (SET) x 23.90 / FT.
150UA 7.45 / FT.
150UB 9.95 / FT.
150UDKB 9.45 / FT.
151N 4.64 / FT.
151N (SET) 9.28 / FT.
151S 5.44 / FT.
151S (SET) 10.88 / FT.
151V 3.88 / FT.
151V (SET) 7.76 / FT.
152S 2.55 / FT.
152SA 3.55 / FT.
152SB 4.55 / FT.
152SDKB 4.25 / FT.
152V 1.49 / FT.
152VA 2.54 / FT.
152VB 3.59 / FT.
152VDKB 3.19 / FT.
155V x 1.48 / FT.
155VB x 4.18 / FT.
155VDKB x 3.78 / FT.
155S x 3.23 / FT.
155SB x 5.93 / FT.
155SDKB x 5.53 / FT.
156S 2.65 / FT.
156SDKB 4.19 / FT.
156V 1.48 / FT.
156VDKB 3.10 / FT.
157MA x 8.00 / FT.
157MDKB x 10.25 / FT.
158NA x 6.90 / FT.
158NDKB x 8.90 / FT.
158PA x 6.20 / FT.
158PDKB x 8.20 / FT.
158SA x 7.35 / FT.
158SDKB x 9.35 / FT.
158VA x 6.20 / FT.
158VDKB x 8.20 / FT.
159MA x 8.50 / FT.
159MB x 11.25 / FT.
159MDKB x 10.75 / FT.
160S x 2.52 / FT.
160SA x 3.60 / FT.
160SB x 4.53 / FT.
160SDKB x 4.15 / FT.
160U x 3.72 / FT.
160UA x 4.80 / FT.
160UB x 5.63 / FT.
160UDKB x 5.35 / FT.
160V(12 PACK) 3’X7’x 24.14 / SET
160V x 1.42 / FT.
160VA x 2.50 / FT.
160VB x 3.43 / FT.
160VDKB x 3.05 / FT.
161NA x 5.53 / FT.
161NDKB x 6.08 / FT.
161PA x 3.15 / FT.
161PDKB x 3.75 / FT.
161SA x 4.25 / FT.
161SDKB x 4.85 / FT.
161UA x 5.45 / FT.
161UDKB x 6.00 / FT.
161VA x 3.15 / FT.
161VDKB x 3.70 / FT.
162S 4.45 / FT.
162SA 5.45 / FT.
162SB 6.95 / FT.
162SDKB 6.45 / FT.
164V x 1.58 / FT.
164VA x 2.65 / FT.
164VB x 3.58 / FT.
164VDKB x 3.20 / FT.
165NA x 4.74 / FT.
165NDKB x 6.34 / FT.
165SA x 6.99 / FT.
165SDKB x 8.59 / FT.
170NA x 6.55 / FT.
170NB x 9.55 / FT.
170NDKB x 9.05 / FT.
170PA x 6.05 / FT.
170PB x 9.05 / FT.
170PDKB x 8.55 / FT.
170SA x 6.95 / FT.
170SB x 9.95 / FT.
170SDKB x 9.45 / FT.
170VA x 5.71 / FT.
170VB x 8.71 / FT.
170VDKB x 8.21 / FT.
172NA x 4.95 / FT.
172NB x 7.20 / FT.
172NDKB x 6.70 / FT.
172SA x 6.00 / FT.
172SB x 8.25 / FT.
172SDKB x 7.75 / FT.
172VA x 3.85 / FT.
172VB x 6.10 / FT.
172VDKB x 5.60 / FT.
176A x 5.24 / FT.
176DKB x 6.94 / FT.
178SA x 5.41 / FT.
178SDKB x 7.41 / FT.
PF180 1.62 / FT.
(36", 48", 86", 96", 120")
PF183 2.50 / FT.
(36", 48", 86", 96", 120")
184QA 6.26 / FT.
184QB 8.36 / FT.
Thresholds & Gasketing
NATIONAL GUARD PRODUCTS, INC.Phone: 800-647-7874
Fax: 800-255-7874
www.ngp.com
orders@ngp.com
Automatic Door Bottoms:
Other than stock sizes, price at next highest price.
Thresholds & Gasketing
220WHA-60" 109.75 / EA.
220WHB-36" 81.75 / EA.
(24" and under - add $30)
220WHB-48" 105.25 / EA.
220WHB-60" 138.25 / EA.
220WHDKB-36" 75.25 / EA.
(24" and under - add $30)
220WHDKB-48" 96.25 / EA.
220WHDKB-60" 128.25 / EA.
221NBR-36" 144.25 / EA
(24" and under - add $30).
221NBR-48" 189.75 / EA.
221NBR-60" 242.25 / EA.
221NSS-36" 106.75 / EA.
(24" and under - add $30)
221NSS-48" 139.75 / EA.
221NSS-60" 179.75 / EA.
221SBR-36" 157.00 / EA.
(24" and under - add $30)
221SBR-48" 206.75 / EA.
221SBR-60" 263.50 / EA.
221SSS-36" 119.50 / EA.
(24" and under - add $30)
221SSS-48" 156.75 / EA.
221SSS-60" 201.00 / EA.
221WHBR-36" 146.50 / EA.
(24" and under - add $30)
221WHBR-48" 192.75 / EA.
221WHBR-60" 246.00 / EA.
221WHSS-36" 109.00 / EA.
(24" and under - add $30)
221WHSS-48" 142.75 / EA.
221WHSS-60" 183.50 / EA.
222NA-36" 64.75 / EA.
(24" and under - add $30)
222NA-48" 83.75 / EA.
222NA-60" 109.75 / EA.
222NB-36" 81.75 / EA.
(24" and under - add $30)
222NB-48" 105.25 / EA.
222NB-60" 138.28 / EA.
202NA 8.48 / FT.
202NB 11.48 / FT.
202NDKB 10.48 / FT.
203NA 11.88 / FT.
203NB 14.88 / FT.
203NDKB 13.88 / FT.
203NA (MONORAIL) 157.50 / EA.
203NB (MONORAIL) 174.50 / EA.
203NDKB (MONORAIL) 170.50 / EA.
211 7.20 / FT.
211DKB 11.40 / FT.
215 6.03 / FT.
215DKB 8.23 / FT.
215BR 55.00 / FT.
220NA-36" 62.50 / EA.
(24" and under - add $30)
220NA-48" 80.75 / EA.
220NA-60" 106.00 / EA.
220NB-36" 79.50 / EA.
(24" and under - add $30)
220NB-48" 102.25 / EA.
220NB-60" 134.50 / EA.
220NDKB-36" 73.00 / EA.
(24" and under - add $30)
220NDKB-48" 93.25 / EA.
220NDKB-60" 124.50 / EA.
220SA-36" 75.25 / EA.
(24" and under - add $30)
220SA-48" 97.75 / EA.
220SA-60" 127.25 / EA.
220SB-36" 92.25 / EA.
(24" and under - add $30)
220SB-48" 119.25 / EA.
220SB-60" 155.75 / EA.
220SDKB-36" 85.75 / EA.
(24" and under - add $30)
220SDKB-48" 111.00 / EA.
220SDKB-60" 145.75 / EA.
220WHA-36" 64.75 / EA.
(24" and under - add $30)
220WHA-48" 83.75 / EA.
184QDKB 7.76 / FT.
185P x 2.55 / FT.
185PA x 3.50 / FT.
185PB x 4.55 / FT.
185PDKB x 4.05 / FT.
189MA (SET) x 18.40 / FT.
189MDKB (SET) x 22.90 / FT.
190V x 1.59 / FT.
190VA x 2.66 / FT.
190VB x 4.06 / FT.
190VDKB x 3.66 / FT.
197NA 7.70 / FT.
197NB 9.80 / FT.
197NDKB 9.25 / FT.
198NA 5.60 / FT.
198NB 7.70 / FT.
198NDKB 7.10 / FT.
198UA 9.06 / FT.
198UB 11.16 / FT.
198UDKB 10.56 / FT.
199NA 6.98 / FT.
199NB 9.08 / FT.
199NDKB 8.48 / FT.
200NA 4.46 / FT.
200NB 6.56 / FT.
200NBR 21.00 / FT.
200NDKB 5.96 / FT.
200NSS 24.50 / FT.
200SA 6.66 / FT.
200SB 8.76 / FT.
200SBR 23.20 / FT.
200SDKB 8.16 / FT.
200SSS 26.70 / FT.
200UA 8.88 / FT.
200UB 10.98 / FT.
200UBR 25.40 / FT.
200UDKB 10.38 / FT.
200USS 28.90 / FT.
201NA 5.70 / FT.
201NB 7.80 / FT.
201NDKB 7.20 / FT.
11
Phone: 800-647-7874
Fax: 800-255-7874
www.ngp.com
orders@ngp.com
Phone: 800-647-7874
Fax: 800-255-7874
www.ngp.com
orders@ngp.com
Lead Lined where available Up to 36" add $48.00
for Automatic Door Bottoms Up to 48" add $63.00
Up to 60” add $78.00
Automatic Door Bottoms:
Other than stock sizes, price at next highest price.
Fast Attach Two Way Tape Available
-Specify “FATT” & add 1.20 per Foot
223SB-48" 122.25 / EA.
223SDKB-36" 88.00 / EA.
(24" and under - add $30)
223SDKB-48" 114.00 / EA.
225N-36" 55.75 / EA.
(24" and under - add $30)
225N-48" 71.75 / EA.
225N-60" 94.75 / EA.
225S-36" 68.50 / EA.
(24" and under - add $30)
225S-48" 88.75 / EA.
225S-60" 116.00 / EA.
225WH-36" 58.00 / EA.
(24" and under - add $30)
225WH-48" 74.75 / EA.
225WH-60" 98.50 / EA.
229NBR-36" 156.25 / EA.
(24" and under - add $30)
229NBR-48" 205.75 / EA.
229NBR-60" 262.25 / EA.
229NSS-36" 118.75 / EA
(24" and under - add $30)
229NSS-48" 155.75 / EA.
229NSS-60" 199.75 / EA.
229SBR-36" 169.00 / EA.
(24" and under - add $30)
229SBR-48" 222.75 / EA.
229SBR-60" 283.50 / EA.
229SSS-36" 131.50 / EA.
(24" and under - add $30)
229SSS-48" 172.75 / EA.
229SSS-60" 221.00 / EA.
229WHBR-36" 158.50 / EA.
(24" and under - add $30)
229WHBR-48" 208.75 / EA.
229WHBR-60" 266.00 / EA.
229WHSS-36" 121.00 / EA.
(24" and under - add $30)
229WHSS-48" 158.75 / EA.
229WHSS-60" 203.50 / EA.
254P 10.29 / FT.
254PDKB 12.29 / FT.
284Q 2.30 / FT.
303NA x 15.85 / FT.
303NB x 20.35 / FT.
303NDKB x 17.95 / FT.
304NA x 19.38 / FT.
304NB x 23.33 / FT.
304NDKB x 20.98 / FT.
305NA x 19.33 / FT.
305NB x 23.83 / FT.
305NDKB x 21.44 / FT.
310NA-36" 58.75 / EA.
(24" and under - add $30)
310NA-48" 75.75 / EA.
310NA-60" 99.75 / EA.
310NB-36" 75.75 / EA.
(24" and under - add $30)
310NB-48" 97.25 / EA.
310NB-60" 128.25 / EA.
310NDKB-36" 69.25 / EA.
(24" and under - add $30)
310NDKB-48" 88.25 / EA.
310NDKB-60" 118.25 / EA.
310SA-36" 71.50 / EA.
(24" and under - add $30)
310SA-48" 92.75 / EA.
310SA-60" 121.00 / EA.
310SB-36" 88.50 / EA.
(24" and under - add $30)
310SB-48" 114.25 / EA.
310SB-60" 149.50 / EA.
310SDKB-36" 82.00 / EA.
(24" and under - add $30)
310SDKB-48" 106.00 / EA.
310SDKB-60" 139.50 / EA.
310WHA-36" 61.00 / EA.
(24" and under - add $30)
310WHA-48" 78.75 / EA.
310WHA-60" 103.50 / EA.
310WHB-36" 78.00 / EA.
(24" and under - add $30)
Thresholds & Gasketing
222NDKB-36" 75.25 / EA.
(24" and under - add $30)
222NDKB-48" 96.25 / EA.
222NDKB-60" 128.25 / EA.
222SA-36" 77.50 / EA.
(24" and under - add $30)
222SA-48" 100.75 / EA.
222SA-60" 131.00 / EA.
222SB-36" 94.50 / EA.
(24" and under - add $30)
222SB-48" 122.25 / EA.
222SB-60" 159.50 / EA.
222SDKB-36" 88.00 / EA.
(24" and under - add $30)
222SDKB-48" 114.00 / EA.
222SDKB-60" 149.50 / EA.
222WHA-36" 67.00 / EA.
(24" and under - add $30)
222WHA-48" 86.75 / EA.
222WHA-60" 113.50 / EA.
222WHB-36" 84.00 / EA.
(24" and under - add $30)
222WHB-48" 108.25 / EA.
222WHB-60" 142.00 / EA.
222WHDKB-36" 77.50 / EA.
(24" and under - add $30)
222WHDKB-48" 99.25 / EA.
222WHDKB-60" 132.00 / EA.
223NA-36" 64.75 / EA.
(24" and under - add $30)
223NA-48" 83.75 / EA.
223NB-36" 84.00 / EA.
(24" and under - add $30)
223NB-48" 105.25 / EA.
223NDKB-36" 75.25 / EA.
(24" and under - add $30)
223NDKB-48" 96.25 / EA.
223SA-36" 77.50 / EA.
(24" and under - add $30)
223SA-48" 100.75 / EA.
223SB-36" 94.50 / EA.
(24" and under - add $30)
12
NATIONAL GUARD PRODUCTS, INC.Phone: 800-647-7874
Fax: 800-255-7874
www.ngp.com
orders@ngp.com
Lead Lined where available Up to 36" add $48.00
for Automatic Door Bottoms Up to 48" add $63.00
Up to 60” add $78.00
Thresholds & Gasketing
310WHB-48" 100.25 / EA.
310WHB-60" 132.00 / EA.
310WHDKB-36" 71.50 / EA.
(24" and under - add $30)
310WHDKB-48" 91.25 / EA.
310WHDKB-60" 122.00 / EA.
312V 3.50 / FT.
312VDKB 5.75 / FT.
313VA 5.70 / FT.
313VDKB 7.80 / FT.
315 9.06 / FT.
315BR 87.50 / FT.
315DKB 11.46 / FT.
318V 5.35 / FT.
318VDKB 8.35 / FT.
319V 6.45 / FT.
319VB 10.45 / FT.
319VDKB 9.45 / FT.
319ET (*NF) 6.06 / FT.
319ETDKB (*NF) 8.06 / FT.
319ET6 6.31 / FT.
319ET6DKB 8.31 / FT.
319EV 4.81 / FT.
319EVDKB 6.81 / FT.
320N-36" 47.50 / EA.
(24" and under - add $30)
320N-48" 62.00 / EA.
320S-36" 53.00 / EA.
(24" and under - add $30)
320S-48" 69.00 / EA.
320V-36" 46.00 / EA.
(24" and under - add $30)
320V-48" 60.00 / EA.
321 5.88 / FT.
321DKB 7.98 / FT.
322 7.88 / FT.
322BR 82.00 / FT.
322DKB 10.19 / FT.
322X355X327 33.21 / FT.
322DKBX355DKBX
327DKB 43.38 / FT.
323 (**) 9.04 / FT.
323DKB (**) 11.50 / FT.
324 17.88 / FT.
324DKB 25.22 / FT.
325 20.25 / FT.
325BR 210.00 / FT.
325DKB 27.30 / FT.
325HD 31.00 / FT.
325HDDKB 38.00 / FT.
325HDX325HD Welded 71.25 / FT.
325HDDKBX
325HDDKB Welded 85.25 / FT.
327 9.58 / FT.
327BR 116.00 / FT.
327DKB 13.24 / FT.
331-36" 12.30 / EA.
331-48" 16.40 / EA.
335N-36" 48.00 / EA.
(24" and under - add $30)
335N-48" 62.00 / EA.
335S-36" 63.00 / EA.
(24" and under - add $30)
335S-48" 82.00 / EA.
336P 2.25 / FT.
340P 2.12 / FT.
344-36" 23.20 / EA.
344-48" 30.94 / EA.
344NF-36" 27.30 / EA.
344NF-48" 36.40 / EA.
350 12.25 / FT.
350BR 132.00 / FT.
350DKB 16.45 / FT.
355 15.75 / FT.
355DKB 19.95 / FT.
398 12.88 / FT.
399 13.13 / FT.
400 16.75 / FT.
401 12.28 / FT.
402 12.88 / FT.
402X400X402 42.51 / FT.
402X400X400X
402 59.26 / FT.
404 9.72 / FT.
404DKB 13.23 / FT.
407 12.28 / FT.
410 5.49 / FT.
410DKB 7.99 / FT.
411 7.25 / FT.
411BR 78.00 / FT.
411DKB 9.77 / FT.
412 9.45 / FT.
412DKB 13.40 / FT.
412SS 95.00 / FT.
413 6.77 / FT.
413BR 97.50 / FT.
413DKB 11.25 / FT.
413FC 7.31 / FT.
413FCDKB 12.25 / FT.
413SS 95.00 / FT.
414 5.45 / FT.
414DKB 7.45 / FT.
415 12.88 / FT.
415BR 133.00 / FT.
415DKB 15.88 / FT.
416 5.75 / FT.
416DKB 9.45 / FT.
417 8.39 / FT.
417DKB 10.39 / FT.
420NA-36" 96.25 / EA.
(24" and under - add $30)
420NA-48" 125.75 / EA.
420NA-60" 162.25 / EA.
420NB-36" 113.25 / EA.
(24" and under - add $30)
420NB-48" 147.25 / EA.
420NB-60" 190.75 / EA.
420NDKB-36" 106.75 / EA.
(24" and under - add $30)
420NDKB-48" 138.25 / EA.
420NDKB-60" 180.75 / EA.
421NA-36" 120.25 / EA.
(24" and under - add $30)
421NA-48" 157.75 / EA.
421NA-60" 202.25 / EA.
13
Phone: 800-647-7874
Fax: 800-255-7874
www.ngp.com
orders@ngp.com
Phone: 800-647-7874
Fax: 800-255-7874
www.ngp.com
orders@ngp.com
** VINYL FOOT SEAL (V) –
add .44 Per Foot Per Side
* NF Notched Fins - Add $3.30 Per Foot
** VINYL FOOT SEAL (V) –
add .44 Per Foot Per Side
Fast Attach Two Way Tape Available
-Specify “FATT” & add 1.20 per Foot
426HD 35.00 / FT.
426HDDKB 44.00 / FT.
426E (**) 12.60 / FT.
426EDKB (**) 17.60 / FT.
427 19.95 / FT.
427BR 221.00 / FT.
427DKB 24.20 / FT.
427E (**) 17.17 / FT.
427EDKB (**) 22.17 / FT.
427FC 19.80 / FT.
427FCDKB 24.10 / FT.
428BR 263.00 / FT.
428E (**) 21.75 / FT.
428EDKB (**) 29.25 / FT.
428FC 24.08 / FT.
428FCDKB 32.28 / FT.
429BR 280.00 / FT.
429E (**) 24.45 / FT.
429EDKB (**) 32.35 / FT.
430BR 298.00 / FT.
430E (**) 27.79 / FT.
430EDKB (**) 35.19 / FT.
442-5 14.44 / FT.
442BR 115.50 / FT.
457 16.25 / FT.
457DKB 22.85 / FT.
458 22.65 / FT.
458DKB 24.85 / FT.
473BR 88.50 / FT.
483BR 106.50 / FT.
Add for Bronze pan 4.75 per foot
484BR 108.50 / FT.
Add for Bronze pan 4.75 per foot
512 12.60 / FT.
512DKB 16.75 / FT.
512SS 100.00 / FT.
513 10.10 / FT.
513BR 117.00 / FT.
513DKB 15.50 / FT.
513FC 11.34 / FT.
513FCDKB 17.04 / FT.
513HD 26.00 / FT.
513HDDKB 32.95 / FT.
513SS 100.00 / FT.
515 8.97 / FT.
515DKB 11.37 / FT.
520NA-36" 97.75 / EA.
(24" and under - add $30)
520NA-48" 127.75 / EA.
520NA-60" 164.75 / EA.
520NB-36" 114.75 / EA.
(24" and under - add $30)
520NB-48" 149.25 / EA.
520NB-60" 193.25 / EA.
520NDKB-36" 108.25 / EA.
(24" and under - add $30)
520NDKB-48" 140.25 / EA.
520NDKB-60" 183.25 / EA.
522N-36" 93.25 / EA.
(24" and under - add $30)
522N-48" 121.75 / EA.
522N-60" 157.25 / EA.
525 15.44 / FT.
525DKB 18.38 / FT.
600 x 4.50 / FT.
600 (SET) x 9.00 / FT.
600A x 4.75 / FT.
600A (SET) x 9.50 / FT.
600B x 6.75 / FT.
600B (SET) x 13.50 / FT.
600DKB x 6.25 / FT.
600DKB (SET) x 12.50 / FT.
601 x 6.50 FT.
601A x 6.75 / FT.
601B x 8.75 / FT.
601DKB x 8.25 / FT.
602A x 4.65 / FT.
602DKB x 6.15 / FT.
603A x 6.95 / FT.
603DKB x 8.45 / FT.
A605A x 3.48 / FT.
A605A (SET) x 6.96 / FT.
A605B x 5.48 / FT.
A605B (SET) x 10.96 / FT.
A605DKB x 4.96 / FT.
A605DKB (SET) x 9.92 / FT.
Thresholds & Gasketing
421NA-96" 309.25 / EA.
421NA-120" 379.75 / EA.
421NA-144" 450.75 / EA.
421NB-36" 135.25 / EA.
(24" and under - add $30)
421NB-48" 177.75 / EA.
421NB-60" 227.27 / EA.
421NB-96" 349.25 / EA.
421NB-120" 429.75 / EA.
421NB-144" 510.75 / EA.
421NDKB-36" 129.25 / EA.
(24" and under - add $30)
421NDKB-48" 169.75 / EA.
421NDKB-60" 217.25 / EA.
421NDKB-96" 333.25 / EA.
421NDKB-120" 409.75 / EA.
421NDKB-144" 486.75 / EA.
422N-36" 91.75 / EA.
(24" and under - add $30)
422N-48" 119.75 / EA.
422N-60" 154.75 / EA.
423N-36" 91.75 / EA.
(24" and under - add $30)
423N-48" 119.75 / EA.
424 8.00 / FT.
424BR 104.00 / FT.
424DKB 11.65 / FT.
424E 7.70 / FT.
424EDKB 11.35 / FT.
424FC 8.60 / FT.
424FCDKB 12.60 / FT.
425 11.60 / FT.
425BR 132.00 / FT.
425DKB 16.75 / FT.
425E (**) 10.10 / FT.
425EDKB (**) 15.25 / FT.
425FC 10.95 / FT.
425FCDKB 15.85 / FT.
425HD 29.00 / FT.
425HDDKB 37.00 / FT.
426 14.55 / FT.
426BR 157.00 / FT.
426DKB 19.70 / FT.
14
NATIONAL GUARD PRODUCTS, INC.Phone: 800-647-7874
Fax: 800-255-7874
www.ngp.com
orders@ngp.com
Lead Lined where available Up to 36" add $48.00
for Automatic Door Bottoms Up to 48" add $63.00
Up to 60” add $78.00
Automatic Door Bottoms:
Other than stock sizes, price at next highest price.
H623A x 15.25 / FT.
H623DKB x 17.25 / FT.
I-624A x 19.50 / FT.
I-624DKB x 21.75 / FT.
A625A 3.75 / FT.
A625B 6.95 / FT.
A625DKB 6.45 / FT.
F625A 4.65 / FT.
F625B 6.75 / FT.
F625DKB 6.25 / FT.
A626A x 3.65 / FT.
A626B x 5.85 / FT.
A626DKB x 5.35 / FT.
C627A x 5.95 / FT.
C627B x 7.95 / FT.
C627DKB x 7.45 / FT.
OV633A x 6.20 / FT.
OV633B x 8.40 / FT.
OV633DKB x 7.90 FT.
OV634A x 5.40 / FT.
OV634B x 7.60 / FT.
OV634DKB x 7.10 / FT.
A635 4.20 / FT.
D648 x 6.30 / FT.
D648DKB x 8.55 / FT.
653 13.07 / FT.
653DKB 19.07 / FT.
654 9.55 / FT.
654DKB 17.55 / FT.
655 14.07 / FT.
655DKB 21.07 / FT.
656 17.88 / FT.
656DKB 23.88 / FT.
657 12.42 / FT.
657DKB 18.42 / FT.
659 16.67 / FT.
659DKB 22.67 / FT.
672A x 5.75 / FT.
672A (SET) x 11.50 / FT.
672B x 8.00 / FT.
672B (SET) x 16.00 / FT.
672DKB x 7.50 / FT.
672DKB (SET) x 15.00 / ST.
673A x 6.50 / FT.
673B x 8.75 / FT.
673DKB x 8.25 / FT.
674A x 7.75 / FT.
674B x 11.00 / FT.
674DKB x 10.50 / FT.
675A x 6.00 / FT.
675A (SET) x 12.00 / FT.
675B x 9.00 / FT.
675B (SET) x 18.00 / FT.
675DKB x 8.50 / FT.
675DKB (SET) x 17.00 / FT.
678A x 6.75 / FT.
678B x 9.75 / FT.
678DKB x 9.25 / FT.
679A x 7.75 / FT.
679B x 10.75 / FT.
679DKB x 10.25 / FT.
680A-36" 103.75 / EA.
(24" and under - add $30)
680A-48" 135.75 / EA.
680A-60" 174.75 / EA.
680B-36" 120.75 / EA.
(24" and under - add $30)
680B-48" 157.25 / EA.
680B-60" 203.25 / EA.
680DKB-36" 114.25 / EA.
(24" and under - add $30)
680DKB-48" 148.25 / EA.
680DKB-60" 193.25 / EA.
682-36" 100.75 / EA.
(24" and under - add $30)
682-48" 131.75 / EA.
682-60" 169.75 / EA.
683-36" 100.75 / EA.
(24" and under - add $30)
683-48" 131.75 / EA.
700EN 6.60 / FT.
700ENDKB 8.35 / FT.
700ES 7.25 / FT.
700ESDKB 9.00 / FT.
700EU 7.40 / FT.
700EUDKB 9.15 / FT.
B606A x 3.98 / FT.
B606A (SET) x 7.96 / FT.
B606B x 5.98 / FT.
B606B (SET) x 11.96 / FT.
B606DKB x 5.48 / FT.
B606DKB (SET) x 10.96 / FT.
C607A x 4.37 / FT.
C607B x 6.57 / FT.
C607DKB x 6.17 / FT.
D608A x 6.30 / FT.
D608B x 8.50 / FT.
D608DKB x 8.10 / FT.
G610A x 14.40 / FT.
G610B x 16.60 / FT.
G610DKB x 16.10 / FT.
G611A x 19.50 / FT.
G611DKB x 21.75 / FT.
H612A x 14.75 / FT.
H612B x 17.25 / FT.
H612DKB x 16.75 / FT.
612SS 149.90 / FT.
613 12.60 / FT.
613BR 163.00 / FT.
613DKB 17.60 / FT.
613HD 31.00 / FT.
613HDDKB 39.45 / FT.
613SS 149.90 / FT.
H614A x 21.75 / FT.
H614DKB x 24.00 / FT.
I-615A x 19.00 / FT.
I-615B x 22.50 / FT.
I-615DKB x 21.25 / FT.
I-616A x 23.75 / FT.
I-616DKB x 26.00 / FT.
A617A x 3.75 / FT.
A617DKB x 6.00 / FT.
C619A x 5.65 / FT.
C619DKB x 7.90 / FT.
D620A x 6.25 / FT.
D620B x 8.50 / FT.
D620DKB x 8.00 / FT.
G622A x 14.95 / FT.
G622DKB x 16.65 / FT.
15
Phone: 800-647-7874
Fax: 800-255-7874
www.ngp.com
orders@ngp.com
Phone: 800-647-7874
Fax: 800-255-7874
www.ngp.com
orders@ngp.com
Thresholds & Gasketing
Fast Attach Two Way Tape Available
-Specify “FATT” & add 1.20 per Foot
Fast Attach Two Way Tape Available
-Specify “FATT” & add 1.20 per Foot
712SS 171.25 / FT.
713 17.25 / FT.
713BR 186.00 / FT.
713DKB 22.45 / FT.
713FC 18.40 / FT.
713FCDKB 23.60 / FT.
713SS 171.25 / FT.
780SA-36" 53.50 / EA.
(24" and under - add $30)
780SA-48" 68.75 / EA.
780SA-60" 91.00 / EA.
780SA-96" 135.50 / EA.
780SDKB-36" 64.00 / EA.
(24" and under - add $30)
780SDKB-48" 82.00 / EA.
780SDKB-60" 109.50 / EA.
780SDKB-96" 154.00 / EA.
803V (*) 13.55 / FT.
803VDKB (*) 18.55 / FT.
804V (*) 12.90 / FT.
804VDKB (*) 17.90 / FT.
812SS 192.00 / FT.
813 20.50 / FT.
813BR 257.00 / FT.
813DKB 26.50 / FT.
813FC 20.85 / FT.
813FCDKB 27.00 / FT.
813SS 192.00 / FT.
814 See page 5
814SS See page 5
816NA 11.45 / FT.
816NDKB 13.55 / FT.
816TA 10.45 / FT.
816TDKB 12.55 / FT.
816T6A 10.70 / FT.
816T6DKB 12.80 / FT.
816VA 9.20 / FT.
816VDKB 11.30 / FT.
818 See page 5
818BR See page 5
818SS See page 5
819NA 12.55 / FT.
819NDKB 14.65 / FT.
819TA 11.55 / FT.
819TDKB 13.65 / FT.
819T6A 11.80 / FT.
819T6DKB 13.90 / FT.
819VA 10.30 / FT.
819VDKB 12.40 / FT.
828 See page 5
838 See page 5
882 See page 5
883SS (*) 182.00 / FT.
884B/SV (*) 10.00 / FT.
884B/SVDKB (*) 14.00 / FT.
884V (*) 15.92 / FT.
884VDKB (*) 20.22 / FT.
884SS (*) 182.00 / FT.
884-6V (*) 42.15 / FT.
884-6VDKB (*) 51.30 / FT.
884-7V (*) 42.15 / FT.
884-7VDKB (*) 51.30 / FT.
884-8V (*) 42.15 / FT.
884-8VDKB (*) 51.30 / FT.
885V (*) 42.63 / FT.
885VDKB (*) 52.63 / FT.
885-6V(*) 42.63 / FT.
885-6VDKB (*) 52.63 / FT.
885-7V(*) 42.63 / FT.
885-7VDKB (*) 52.63 / FT.
890V (*) 13.65 / FT.
890VB (*) 19.20 / FT.
890VDKB (*) 18.40 / FT.
891V (*) 11.82 / FT.
891VDKB (*) 17.07 / FT.
893V (*,**) 15.02 / FT.
893VDKB (*,**) 19.60 / FT.
895VBR (*) 130.50 / FT.
896HDV (*) 21.80 / FT.
896HDVDKB (*) 28.00 / FT.
896V (*) 10.96 / FT.
896VBR (*) 114.00 / FT.
896VDKB (*) 14.46 / FT.
896SS (*) 182.00 / FT.
897V (*,**) 16.16 / FT.
897VDKB (*,**) 20.66 / FT.
700EV (*) 5.90 / FT.
700EVDKB (*) 7.70 / FT.
700N x 7.65 / FT.
700NA x 8.20 / FT.
700NB x 10.70 / FT.
700NDKB x 9.40 / FT.
700S x 8.30 / FT.
700SA x 8.85 / FT.
700SB x 11.35 / FT.
700SDKB x 10.05 / FT.
700U x 8.45 / FT.
700UA x 9.00 / FT.
700UB x 11.50 / FT.
700UDKB x 10.20 / FT.
701EP 7.40 / FT.
701EPDKB 9.15 / FT.
701P x 8.45 / FT.
701PA x 9.00 / FT.
701PB x 11.50 / FT.
701PDKB x 10.20 / FT.
703EV 5.90 / FT.
703EVDKB 7.70 / FT.
703V x 7.05 / FT.
703VA x 7.60 / FT.
703VB x 10.15 / FT.
703VDKB x 8.85 / FT.
704EV 5.90 / FT.
704EVDKB 7.70 / FT.
704V x 7.05 / FT.
704VA x 7.60 / FT.
704VB x 10.15 / FT.
704VDKB x 8.85 / FT.
705EV 5.90 / FT.
705EVDKB 7.70 / FT.
705V x 7.05 / FT.
705VA x 7.60 / FT.
705VB x 10.15 / FT.
705VDKB x 8.85 / FT.
706A x 8.60 / FT.
706B x 11.15 / FT.
706DKB x 9.85 / FT.
706E 6.90 / FT.
706EDKB 8.70 / FT.
16
NATIONAL GUARD PRODUCTS, INC.Phone: 800-647-7874
Fax: 800-255-7874
www.ngp.com
orders@ngp.com
Thresholds & Gasketing
* BUMPER SEAL OPTIONS - Add Per Foot:
NGP-TPV (N) .82 • Pile (P) .16 • Silicone (S) .93
Automatic Door Bottoms:
Other than stock sizes, price at next highest price.
897NS (**) 19.66 / FT.
897NSDKB (**) 24.16 / FT.
898V (*) 12.54 / FT.
898VDKB (*) 16.74 / FT.
912SS 212.75 / FT.
913 23.60 / FT.
913DKB 29.90 / FT.
913SS 212.75 / FT.
950V (*) 10.92 / FT.
950VDKB (*) 14.42 / FT.
951 16.70 / FT.
951DKB 20.50 / FT.
953 11.15 / FT.
953DKB 15.45 / FT.
954 19.80 / FT.
954DKB 25.15 / FT.
955 14.05 / FT.
955DKB 17.75 / FT.
957 27.00 / FT.
957DKB 33.00 / FT.
959 18.00 / FT.
959DKB 21.00 / FT.
960 36.50 / FT.
960DKB 42.50 / FT.
961 27.20 / FT.
961DKB 33.55 / FT.
962 24.15 / FT.
962DKB 30.45 / FT.
1000RA-5" 11.50 / FT.
1000RA-10" 17.25 / FT.
1000RA-16" 23.00 / FT.
1000RB-5" 14.75 / FT.
1000RB-10" 20.50 / FT.
1000RB-16" 26.25 / FT.
1000RDKB-5" 13.75 / FT.
1000RDKB-10" 19.50 / FT.
1000RDKB-16" 25.25 / FT.
1012SS 233.50 / FT.
1013 28.00 / FT.
1013DKB 34.30 / FT.
1013SS 233.50 / FT.
1015V 2.06 / FT.
1015VDKB 3.61 / FT.
1038NA x 16.68 / FT.
1038NB x 21.18 / FT.
1038NDKB x 19.68 / FT.
1390SP-83-1/8" 107.80 / EA.
1390SP-95-1/8" 123.20 / EA.
1392SP 30.50 / FT.
2014RA 9.88 / FT.
2014RB 11.58 / FT.
2014RDKB 10.88 / FT.
Finger Guards
2248A-38" 262.00 / EA.
2248A-76" 312.00 / EA.
2248A-82" 347.00 / EA.
2248A-86" 377.00 / EA.
2248DKB-38" 282.00 / EA.
2248DKB-76" 332.00 / EA.
2248DKB-82" 367.00 / EA.
2248DKB-86" 397.00 / EA.
2252 B, C, W 158.00 / EA.
2525 B, C, W 1.60 / FT.
(17’, 20’, 21’, 25’, 300')
3038NA x 17.18 / FT.
3038NB x 21.68 / FT.
3038NDKB x 20.18 / FT.
3231 47.50 / FT.
3241 57.00 / FT.
3504 56.00 / FT.
3509 85.00 / FT.
3510 98.00 / FT.
3511 103.00 / FT.
4413-36" 270.00 / EA.
4413-48" 360.00 / EA.
4413-72" 540.00 / EA.
4424-36" 270.00 / EA.
4424-48" 360.00 / EA.
4424-72" 540.00 / EA.
4425-36" 340.00 / EA.
4425-48" 450.00 / EA.
4425-72" 675.00 / EA.
4440SA-36" 111.25 / EA.
(24" and under - add $30)
4440SA-48" 130.25 / EA.
4440SA-60" 149.25 / EA.
4440SA-96" 209.25 / EA.
4440SB-36" 127.25 / EA.
(24" and under - add $30)
4440SB-48" 147.25 / EA.
4440SB-60" 167.25 / EA.
4440SB-96" 227.25 / EA.
4440SDKB-36" 122.50 / EA.
(24" and under - add $30)
4440SDKB-48" 142.50 / EA.
4440SDKB-60" 162.50 / EA.
4440SDKB-96" 222.50 / EA.
4440WHA-36" 105.00 / EA.
(24" and under - add $30)
4440WHA-48" 125.00 / EA.
4440WHA-60" 145.00 / EA.
4440WHA-96" 205.00 / EA.
4440WHB-36" 121.00 / EA.
(24" and under - add $30)
4440WHB-48" 141.00 / EA.
4440WHB-60" 161.00 / EA.
4440WHB-96" 221.00 / EA.
4440WHDKB-36" 116.25 / EA.
(24" and under - add $30)
4440WHDKB-48" 136.25 / EA.
4440WHDKB-60" 156.25 / EA.
4440WHDKB-96" 216.25 / EA.
4441SA-36" 111.25 / EA.
(24" and under - add $30)
4441SA-48" 130.25 / EA.
4441SA-60" 149.25 / EA.
4441SA-96" 209.25 / EA.
4441SB-36" 127.25 / EA.
(24" and under - add $30)
4441SB-48" 147.25 / EA.
4441SB-60" 167.25 / EA.
4441SB-96" 227.25 / EA.
4441SDKB-36" 122.50 / EA.
((24" and under - add $30)
4441SDKB-48" 142.50 / EA.
4441SDKB-60" 162.50 / EA.
4441SDKB-96" 222.50 / EA.
4441WHA-36" 105.00 / EA.
Thresholds & Gasketing
17
Phone: 800-647-7874
Fax: 800-255-7874
www.ngp.com
orders@ngp.com
Phone: 800-647-7874
Fax: 800-255-7874
www.ngp.com
orders@ngp.com
** VINYL FOOT SEAL (V) -
add .44 Per Foot Per Side
Fast Attach Two Way Tape Available
-Specify “FATT” & add 1.20 per Foot
* BUMPER SEAL OPTIONS - Add Per Foot:
NGP-TPV (N) .82 • Pile (P) .16 • Silicone (S) .93
* BUMPER SEAL OPTIONS - Add Per Foot:
NGP-TPV (N) .82 • Pile (P) .16 • Silicone (S) .93
(24" and under - add $30)
4441WHA-48" 125.00 / EA.
4441WHA-60" 145.00 / EA.
4441WHA-96" 205.00 / EA.
4441WHB-36" 121.00 / EA.
(24" and under - add $30)
4441WHB-48" 141.00 / EA.
4441WHB-60" 161.00 / EA.
4441WHB-96" 221.00 / EA.
4441WHDKB-36" 116.25 / EA.
(24" and under - add $30)
4441WHDKB-48" 136.25 / EA.
4441WHDKB-60" 156.25 / EA.
4441WHDKB-96" 216.25 / EA.
4447S-36" 110.00 / EA.
(24" and under - add $30)
4447S-48" 129.00 / EA.
4447S-60" 148.00 / EA.
4447S-96" 208.00 / EA.
4447WH-36" 103.75 / EA.
(24" and under - add $30)
4447WH-48" 123.75 / EA.
4447WH-60" 143.75 / EA.
4447WH-96" 203.75 / EA.
4448S-36" 110.00 / EA
(24" and under - add $30)
4448S-48" 129.00 / EA.
4448S-60" 148.00 / EA.
4448S-96" 208.00 / EA.
4448WH-36" 103.75 / EA.
(24" and under - add $30)
4448WH-48" 123.75 / EA.
4448WH-60" 143.75 / EA.
4448WH-96" 203.75 / EA.
4513-36" 336.00 / EA.
4513-48" 448.00 / EA.
4513-72" 672.00 / EA.
RR5007BL 21.00 / TUBE
RR5007BL-12 Pack 242.00 / CS.
5020 B, C, W 1.88 / FT.
(36", 48", 72", 84", 96", 108")
5020CL 2.28 / FT.
(36", 48", 72", 84", 96", 108")
5021 B, C, W 4.50 / FT.
(36", 48", 84", 96", 108")
5025 B, C, W 2.55 / FT.
(36", 48", 72", 84", 96", 108")
5025CL 2.95 / FT.
(36", 48", 72", 84", 96", 108")
5040 B, 1.34 / FT.
(17’, 20’, 25’, 300’)
ANTI-LIG 5050 B, C, W 1.95 / FT.
ANTI-LIG 5050CL 2.45 / FT.
5050 B, C, T, W 1.45 / FT.
(17’, 20’, 21', 25’, 300’)
5050CL 1.95 / FT.
(17’, 20’, 25’, 300’)
5060B (17’, 21’) 1.95 / FT.
5060CL (17’, 21’) 2.25 / FT.
5070B 2.50 / FT.
(36", 48", 72", 84", 96", 108")
5070CL 2.90 / FT.
(36", 48", 72", 84", 96", 108")
5075B 2.50 / FT.
(36", 48", 72", 84", 96", 108")
5075CL 2.90 / FT.
(36", 48", 72", 84", 96", 108")
5100N-86” 23.00 / RL
5100N-96" 26.50 / RL
5100S-86” 21.00 / RL
5100S-96" 24.25 / RL
8013 25.85 / FT.
8013DKB 33.39 / FT.
8113 27.55 / FT.
8113DKB 35.25 / FT.
8132-96" 83.00 / PC.
8132DKB-96" 123.00 / PC.
8133 thru 8134 See page 5
8135V (*) 10.48 / FT.
8135VDKB (*) 13.68 / FT.
8136 thru 8170 See page 5
8213 30.55 / FT.
8213DKB 39.90 / FT.
8413 12.50 / FT.
8413DKB 16.08 / FT.
8423V (*) 8.96 / FT.
8423VDKB (*) 12.54 / FT.
8424 14.65 / FT.
8424DKB 18.85 / FT.
8425 16.55 / FT.
8425DKB 21.75 / FT.
8426 18.45 / FT.
8426BR 178.00 / FT.
8426DKB 24.20 / FT.
8427 20.75 / FT.
8427BR 222.00 / FT.
8427DKB 27.00 / FT.
8428 23.10 / FT.
8428BR 265.00 / FT.
8428DKB 30.50 / FT.
8429 25.75 / FT.
8429BR 282.00 / FT.
8429DKB 33.00 / FT.
8430 28.75 / FT.
8430BR 299.00 / FT.
8430DKB 36.25 / FT.
8433V (*) 13.80 / FT.
8433VDKB (*) 18.90 / FT.
8434V (*) 15.72 / FT.
8434VDKB (*) 21.52 / FT.
8435V (*) 17.72 / FT.
8435VDKB (*) 23.92 / FT.
8436V (*) 19.97 / FT.
8436VDKB (*) 27.27 / FT.
8437V (*) 22.67 / FT.
8437VDKB (*) 30.07 / FT.
8475 31.37 / FT.
8475DKB 36.67 / FT.
8513 14.53 / FT.
8513DKB 19.10 / FT.
8533V (*) 15.88 / FT.
8533VDKB (*) 21.43 / FT.
8613 17.68 / FT.
8613DKB 22.68 / FT.
8633V (*) 18.12 / FT.
8633VDKB (*) 24.75 / FT.
8713 18.82 / FT.
8713DKB 24.50 / FT.
8813 21.18 / FT.
18
Thresholds & Gasketing
NATIONAL GUARD PRODUCTS, INC.Phone: 800-647-7874
Fax: 800-255-7874
www.ngp.com
orders@ngp.com
Thresholds & Gasketing
8813DKB 27.96 / FT.
8913 24.14 / FT.
8913DKB 31.51 / FT.
9000A x 5.65 / FT.
9000B x 7.75 / FT.
9000DKB x 7.35 / FT.
9001A 9.48 / FT.
9001B 11.88 / FT.
9001DKB 11.08 / FT.
9002 x 5.52 / FT.
9002A x 6.60 / FT.
9002B x 7.53 / FT.
9002DKB x 7.15 / FT.
9115A 9.00 / FT.
9115A (SET) 18.00 / FT.
9115B 11.40 / FT.
9115B (SET) 22.80 / FT.
9115DKB 10.30 / FT.
9115DKB (SET) 20.60 / FT.
9125A 9.10 / FT.
9125A (SET) 18.20 / FT.
9125B 11.50 / FT.
9125B (SET) 23.00 / FT.
9125DKB 10.40 / FT.
9125DKB (SET) 20.80 / FT.
9125SS 28.25 / FT.
9125SS (SET) 56.50 / FT.
9200 9.45 / FT.
9200DKB 9.45 / FT.
9225 12.75 / EA.
9250NA (*EC) 29.20 / FT.
9250NDKB (*EC) 34.70 / FT.
9250NWHA (*EC) 33.20 / FT.
9250NWHDKB (*EC) 38.70 / FT.
9250TA (*EC) 29.45 / FT.
9250TDKB (*EC) 34.95 / FT.
9250TWHA (*EC) 33.70 / FT.
9250TWHDKB (*EC) 39.20 / FT.
9250VA (*EC) 28.20 / FT.
9250VDKB (*EC) 33.70 / FT.
9250WHA (*EC) 31.70 / FT.
9250WHADKB (*EC) 37.20 / FT.
9275 17.00 / EA
9450 B, C 4.35 / FT.
(36", 48", 84", 96", 108")
9500 5.10 / FT.
(36", 48", 84", 96", 108")
9500DKB 5.10 / FT.
(36", 48", 84", 96", 108")
9500 X 2525 B, C, W 7.10 / FT.
(36", 48", 84", 96", 108")
9500 X 5020 B, C, W 7.38 / FT.
(36", 48", 84", 96", 108")
9500DKB X 2525B 7.10 / FT.
(36", 48", 84", 96", 108")
9500DKB X 5020B 7.38 / FT.
(36", 48", 84", 96", 108")
9550 5.30 / FT.
(36", 48", 84", 96", 108")
9550DKB 5.30 / FT.
(36", 48", 84", 96", 108")
9600 x 6.50 / FT.
9600 (SET) x 13.00 / FT.
9600A x 6.75 / FT.
9600A (SET) x 13.50 / FT.
9600B x 8.75 / FT.
9600B (SET) x 17.50 / FT.
9600DKB x 8.25 / FT.
9600DKB (SET) x 16.50 / FT.
9605A x 5.48 / FT.
9605A (SET) x 10.96 / FT.
9605B x 7.48 / FT.
9605B (SET) x 14.96 / FT.
9605DKB x 6.96 / FT.
9605DKB (SET) x 13.92 / FT.
9675A x 8.00 / FT.
9675A (SET) x 16.00 / FT.
9675B x 11.00 / FT.
9675B (SET) x 22.00 / FT.
9675DKB x 10.50 / FT.
9675DKB (SET) x 21.00 / FT.
9700 x 11.30 / FT.
9700A x 11.85 / FT.
9700B x 14.35 / FT.
9700DKB x 13.05 / FT.
9700E 10.25 / FT.
9700EDKB 12.00 / FT.
9706E 9.90 / FT.
9706EDKB 11.70 / FT.
9750 B, C 3.65 / FT.
(36", 48", 72", 84", 96", 108")
9800 B, C, W 1.80 / FT.
(17', 21', 150')
9850 B, C 3.30 / FT.
(36", 48", 72", 84", 96", 108")
81369N 38.50 / FT.
81369NDKB 41.25 / FT.
19
Phone: 800-647-7874
Fax: 800-255-7874
www.ngp.com
orders@ngp.com
Phone: 800-647-7874
Fax: 800-255-7874
www.ngp.com
orders@ngp.com
Fast Attach Two Way Tape Available
-Specify “FATT” & add 1.20 per Foot
* BUMPER SEAL OPTIONS - Add Per Foot:
NGP-TPV (N) .82 • Pile (P) .16 • Silicone (S) .93
Gap Pack 200.55 / SET
Contains in one box:
9200 1 EA. -36" & 84"
9275 1 EA.
9250NWHA 1 EA. -36"
Gap Pack DKB 216.25 / SET
Contains in one box:
9200DKB 1 EA. -36" & 84"
9275 1 EA.
9250NWHDKB 1 EA. -36"
*EC End Caps - Add $7.85 Per Set
Type Threshold Material Single up Pair Add
to 36" up to 72" Per Inch
The following information is required when ordering thresholds for use with oor closers:
• Threshold type x model number.
• Material and Finish
• Door thickness if other than 1 3/4"
• Door opening width
• Handing (Door handing)
• Name of oor closer manufacturer and oor closer model number.
• Abrasive “SIA” nish available - pricing on page 3.
• Polished & dark oxidized oil rubbed nishes are available on Bronze thresholds see page 3.
Note: Item numbers on invoices will read type, threshold number, size. Example: 1 x 427FC x 36".
1 427FC 1/2" x 6-3/4" Alum. 151.40 302.80 1.65
1 427FCDKB 1/2" x 6-3/4" Alum. DKB 164.30 328.60 2.01
1 428FC 1/2" x 7-3/4" Alum. 164.24 328.48 2.01
1 428FCDKB 1/2" x 7-3/4" Alum. DKB 188.84 377.68 2.69
1 429E 1/2" x 9" Alum. 165.35 330.70 2.04
1 429EDKB 1/2" x 9" Alum. DKB 189.05 378.10 2.70
1 430E 1/2" x 10" Alum. 175.37 350.74 2.32
1 430EDKB 1/2" x 10" Alum. DKB 197.57 395.14 2.93
1 713FC 1/4" x 6-3/4" Alum. 147.20 294.40 1.53
1 713FCDKB 1/4" x 6-3/4" Alum. DKB 162.80 325.60 1.97
1 813FC 1/4" x 7-3/4" Alum. 154.55 309.10 1.74
1 813FCDKB 1/4" x 7-3/4" Alum. DKB 173.00 346.00 2.25
1 913 1/4" x 9" Alum. 162.80 310.88 1.97
1 913DKB 1/4" x 9" Alum. DKB 181.70 363.40 2.49
1 1013 1/4" x 10" Alum. 176.00 352.00 2.33
1 1013DKB 1/4" x 10" Alum. DKB 194.90 389.80 2.86
1 427BR 1/2" x 7" Bronze 775.00 1550.00 18.42
1 428BR 1/2" x 8" Bronze 901.00 1802.00 21.92
1 713BR 1/4" x 7" Bronze 670.00 1340.00 15.50
1 813BR 1/4" x 8" Bronze 883.00 1766.00 21.42
3 427FC 1/2" x 6-3/4" Alum. 211.40 362.80 1.65
3 427FCDKB 1/2" x 6-3/4" Alum. DKB 224.30 388.60 2.01
3 428FC 1/2" x 7-3/4" Alum. 224.24 388.48 2.01
3 428FCDKB 1/2" x 7-3/4" Alum. DKB 248.84 437.68 2.69
3 429E 1/2" x 9" Alum. 225.35 390.70 2.04
3 429EDKB 1/2" x 9" Alum. DKB 249.05 438.10 2.70
20
NATIONAL GUARD PRODUCTS, INC.Phone: 800-647-7874
Fax: 800-255-7874
www.ngp.com
orders@ngp.com
Thresholds for Floor Closers
Thresholds for Floor Closers
Type Threshold Materials Single up Pair Add
to 36" up to 72" Per Inch
3 430E 1/2" x 10" Alum. 235.37 410.74 2.32
3 430EDKB 1/2" x 10" Alum. DKB 257.57 455.14 2.93
3 713FC 1/4" x 6-3/4" Alum. 207.20 354.40 1.53
3 713FCDKB 1/4" x 6-3/4" Alum. DKB 222.80 385.60 1.97
3 813FC 1/4" x 7-3/4" Alum. 214.55 369.10 1.74
3 813FCDKB 1/4" x 7-3/4" Alum. DKB 233.00 406.00 2.25
3 913 1/4" x 9" Alum. 222.80 370.88 1.97
3 913DKB 1/4" x 9" Alum. DKB 241.70 423.40 2.49
3 1013 1/4" x 10" Alum. 236.00 412.00 2.33
3 1013DKB 1/4" x 10" Alum. DKB 254.90 449.80 2.86
3 427BR 1/2" x 7" Bronze 855.00 1630.00 18.42
3 428BR 1/2" x 8" Bronze 981.00 1882.00 21.92
3 713BR 1/4" x 7" Bronze 750.00 1420.00 15.50
3 813BR 1/4" x 8" Bronze 963.00 1846.00 21.42
4 427FC 1/2" x 6-3/4" Alum. 211.40 362.80 1.65
4 427FCDKB 1/2" x 6-3/4" Alum. DKB 224.30 388.60 2.01
4 428FC 1/2" x 7-3/4" Alum. 224.24 388.48 2.01
4 428FCDKB 1/2" x 7-3/4" Alum. DKB 248.84 437.68 2.69
4 429E 1/2" x 9" Alum. 225.35 390.70 2.04
4 429EDKB 1/2" x 9" Alum. DKB 249.05 438.10 2.70
4 430E 1/2" x 10" Alum. 235.37 410.74 2.32
4 430EDKB 1/2" x 10" Alum. DKB 257.57 455.14 2.93
4 713FC 1/4" x 6-3/4" Alum. 207.20 354.40 1.53
4 713FCDKB 1/4" x 6-3/4" Alum. DKB 222.80 385.60 1.97
4 813FC 1/4" x 7-3/4" Alum. 214.55 369.10 1.74
4 813FCDKB 1/4" x 7-3/4" Alum. DKB 233.00 406.00 2.25
4 913 1/4" x 9" Alum. 222.80 370.88 1.97
4 913DKB 1/4" x 9" Alum. DKB 241.70 423.40 2.49
4 1013 1/4" x 10" Alum. 236.00 412.00 2.33
4 1013DKB 1/4" x 10" Alum. DKB 254.90 449.80 2.86
4 427BR 1/2" x 7" Bronze 855.00 1630.00 18.42
4 428BR 1/2" x 8" Bronze 981.00 1882.00 21.92
4 713BR 1/4" x 7" Bronze 750.00 1420.00 15.50
4 813BR 1/4" x 8" Bronze 963.00 1846.00 21.42
5 427FC X 424FC 1/2" x 6-3/4" x 3-3/4" Alum. 219.00 378.00 0.72
5 427FCDKB X 424FCDKB 1/2" x 6-3/4" x 3-3/4" Alum.DKB 231.30 402.60 1.05
Thresholds for Floor Closers
21
Phone: 800-647-7874
Fax: 800-255-7874
www.ngp.com
orders@ngp.com
Phone: 800-647-7874
Fax: 800-255-7874
www.ngp.com
orders@ngp.com
Replacement Inserts
NATIONAL GUARD PRODUCTS, INC.Phone: 800-647-7874
Fax: 800-255-7874
www.ngp.com
orders@ngp.com
Replacement Inserts Thresholds for Floor Closers
22
5 428FC X 425FC 1/2" x 7-3/4" x 4-3/4" Alum. 227.98 395.96 0.91
5 428FCDKB X 425FCDKB 1/2" x 7-3/4" x 4-3/4" Alum. DKB 245.98 431.96 1.32
5 713FC X 413FC 1/4" x 6-3/4" x 3-3/4" Alum. 215.02 370.04 0.68
5 713FCDKB X 413FCDKB 1/4" x 6-3/4" x 3-3/4" Alum. DKB 230.10 400.20 1.02
5 813FC X 513FC 1/4" x 7-3/4" x 4-3/4" Alum. 225.53 391.06 0.95
5 813FCDKB X 513FCDKB 1/4" x 7-3/4" x 4-3/4" Alum. DKB 243.08 426.16 1.42
5 427BR X 424BR 1/2" x 7" x 4" Bronze 661.00 1242.00 8.67
5 428BR x 425BR 1/2" x 8" x 5" Bronze 759.00 1438.00 11.00
5 713BR X 413BR 1/4" x 7" x 4" Bronze 613.00 1146.00 8.13
5 813BR X 513BR 1/4" x 8" x 5" Bronze 723.00 1366.00 9.75
Type Threshold Material Single up Pair Add
to 36" up to 72" Per Inch
Floor Closer Preps Only - add to Material Price (For other thresholds not shown above)
Prices are Per Prep (Double for Pairs)
Aluminum Bronze Stainless Steel
Type 1 104.00 204.00 500.00
Type 3 164.00 284.00 620.00
Type 4 164.00 284.00 620.00
Type 5 194.00 324.00 n/a
Pivot Prep for any center hung or offset pivot - $79 each prep.
136P, 140P, 143P, 144P, 158P,
161P, 185P, 701P, 701EP 1.10
254P 3.80
170P, Bumper Pile (threshold) .82
Replacement Polyurethane
Item Price/Ft.
129U, 150U 2.70
160U, 161U, 700EU, 700U 1.90
198U, 200U 4.20
Item Price/Ft.
Replacement Pile
Auto Door Bottom/Door Shoe Parts
Item Price
End Caps - 92, 99, 220, 222, 223, 225,
310, 420, 422, 423, 520, 522, 680,
682, 683, 9250 7.85 /Set
End Caps - 221SS, 229SS 15.75 /Set
Drop Bar Assembly - 220N, 221N,
222N, 225N, 229N, 310N 15.75 / FT.
Drop Bar Assembly - 220S, 221S,
222S, 225S, 229S, 310S 21.00 / FT.
Drop Bar Assembly - 220WH, 221WH,
222WH, 225WH, 229WH, 310WH 16.75 / FT.
Heavy Duty Drop Bar Assemblies:
420N, 422N, 423N, 520N, 522N 24.00 / FT.
680, 682, 683 26.00 / FT.
23
Phone: 800-647-7874
Fax: 800-255-7874
www.ngp.com
orders@ngp.com
Phone: 800-647-7874
Fax: 800-255-7874
www.ngp.com
orders@ngp.com
Replacement Inserts
Replacement Neoprene
Item Price/Ft.
15N, 26N, 92N, 99N, 112N,
113N, 118N, 119N, 816N,
819N, 9250N 2.55
103N, 104N, 105N, 108N,
303N, 304N, 305N, 420N,
421N, 422N, 423N 3.20
106N, 141N 1.92
107N, 165N, 223N, 335N 2.72
109N, 122N 2.29
110N, 120N, 127N, 134N 1.60
115N, 125N 2.10
116N 3.25
123N .99
129N, 137N, 1038N 3.20
130N, 133N 2.15
131N 1.45
132N 1.95
135N, 161N, 700N, 700EN 3.00
158N, 170N 2.35
197N, 199N 3.20
200N, 201N, 114N, 198N 2.20
202N 3.75
203N 6.50
520N, 522N 3.95
81369N 33.30
Flood Shield Bottom 2.75
Flood Shield Side 2.50
Replacement NGP-TPV
Item Price/Ft.
136N .95
151N, 172N 1.35
320N 2.00
Bumper NGP-TPV (threshold) 1.49
Replacement Reinforced
Rubber
Item Price/Ft.
14R-1 3/4" 5.00
14R-2 1/4" 6.50
1000R x 5" 5.75
1000R x 10” 9.75
1000R x 16” 14.50
Replacement Nylon Brush
Item Price/Ft.
Specify Gray or Black.
600, 602, B606 2.36
601, 603 3.40
9000, 9600, 9605 3.06
A Brush, 92WH, 99WH, 220WH,
221WH, 222WH, 225WH, 229WH,
310WH, F625, OV633, OV634,
672, 673, 674, 675, 678, 679,
680, 682, 683, 706, 706E,
4440WH, 4441WH, 4447WH,
4448WH, 9706E 2.15
C Brush 2.75
D Brush 3.30
G Brush 10.60
H Brush 12.80
I Brush 16.20
Replacement Silicone
Item Price/Ft.
107S, 165S, 223S, 335S 3.20
110S, 120S, 127S 2.15
130S 4.10
132S 3.10
136S, 140S, 141S, 144S,
151S, 158S, 170S 1.75
137S 3.40
152S, 155S, 172S, 320S 1.40
156S 1.50
160S, 700S, 700ES 1.40
162S 2.00
200S, 114S 3.65
780S 2.15
4440, 4441, 4447, 4448 7.00
9001S 4.60
9002S, 9700S 2.75
9115S, 9125S 4.25
Bumper Silicone (threshold) 1.60
Replacement Thermoplastic
Item Price/Ft.
12T, 13T, 35ET, 36ET,
92T, 99T, 319ET, 816T,
819T, 9250T 2.00
12T6, 13T6, 35ET6, 36ET6
92T6, 99T6, 319ET6,
816T6, 819T6 2.25
Replacement Vinyl
Item Price/Ft.
5V, 12V, 13V, 18V, 19V, 99V 1.00
25V, 151V, 158V, 170V .67
35V, 35EV, 36V, 36EV, 312V,
313V, 318V, 319V, 319EV 1.18
96V 1.47
97V .92
98V, 101V, 1015V 1.25
100V .85
102V 3.15
149M, 157M, 159M, 189M
(magnet & vinyl) 3.10
152V, 155V, 172V, 320V .55
156V .60
160V, 164V, 190V .60
703, 703E, 704, 704E,
705, 705E .65
Bumper Vinyl (threshold) .67
Foot Seal (threshold) .44
Threshold Splines
Aluminum Spline 2.00
Thermal Break Spline 1/2" 2.00
Thermal Break Spline 1/4" 1.45
24
NATIONAL GUARD PRODUCTS, INC.Phone: 800-647-7874
Fax: 800-255-7874
www.ngp.com
orders@ngp.com
INDEX of Lite Kits, Louvers, Glass
Model Lite Kits Page Page(with Glass)
L-CVFM-SS Stainless Steel 35
L-FRA100 Low Prole 26 27-31
L-FRA100-ALUM Low Prole 26
L-FRA100-RD Round Low Prole 36
L-FRA100-SP Low Prole Special Glass or Door Thickness 32
L-GLF100 Self-Attaching 26
L-GLF100-SP Self-Attaching Special Glass or Door Thickness 32
L-GLF100-SP-TB Thru-Bolted Special Glass or Door Thickness 32
L-GLF100-TB Thru-Bolted 26
L-SG100 Security Grille 34
L-SG100-TB Security Grille Thru-Bolted 34
L-VGLF-MD, MDL Security Grille with Privacy Panel 33
L-VGLF-OG Security Glass with Privacy Panel 33
L-VGLF-PZ Security Glass 33
L-VGLF-SF Security Grille with Privacy Panel 33
L-VGLF-WD Security Glass with Privacy Panel 33
Options: G2-G24 False Mullion Bars 33
Model Louvers Page
L-75-A, B, BF Dark Room 42
L-A700-A, B, BF, C Aluminum 38
L-700-A, B, BF, C Steel - Adjustable 1-3/8" to 2-1/4" doors 37
L-700RX Steel - Self-Attaching Inverted “V” 37
L-1800 Adjustable Blade 39
L-1900 Fire Rated Fusible Link 39
L-VRSG-2 Security Grille 40
L-VRSG-3 Security Grille (Both sides) 41
Lite Kit and Louver Fasteners 36
L-Clips Hollow Metal Door reinforcement
Model Glass Page
Pyran® F Filmed Safety Ceramic 44
Pyran® L Laminated Safety Ceramic 45
SuperLite™ 1-W Safety Wired 43
SuperLite™ 1-20 Safety Tempered 20 Minute 45
SuperLite™ X-90 Safety Rated 90 minute 45
SuperLite™ II-XL Fire Resistive Radiant Heat protection 45
Polycarbonate 48
Tempered Safety Rated 47
Insulated Tempered Safety 48
Wired 46
Model Glazing Tape Page
GT-16 1/16" Thick Butyl Rubber 48
GT-116 1/16" Thick Closed Cell PVC Foam 48
GT-118 1/8" Thick Closed Cell PVC Foam 48
GT-132 1/32" Thick Closed Cell PVC Foam 48
GT-9800 1/16" Thick Intumescent 48
Phone: 800-647-7874
Fax: 800-255-7874
www.ngp.com
orders@ngp.com
Phone: 800-647-7874
Fax: 800-255-7874
www.ngp.com
orders@ngp.com
§ Any mix of items below.
§ Orders must be marked “QUICK SHIP”.
§ Available Finishes: GPZ, DKB, TAN, BPR, CAB: For Galvaneal add 20%.
§ Torx security screws - up to 24" x 24" add $12, over 24" x 24" add $24.
§ Orders mixed with any other products will be subject to standard lead times.
§ Orders must be received by 11 a.m. Central time; after 11 a.m., add one business day.
Order Size List Price with Pyran-F Superlite 1-W Diamond Wired
GT-118 GT-118 GT-118
5 x 35 $80 $325 $222 $144
6 x 27 73 271 189 127
7 x 22 68 266 183 121
8 x 32 80 383 255 159
12 x 12 47 240 158 96
24 x 24 86 861 531 284
24 x 30 94 1062 649 341
24 x 32 99 1135 695 367
24 x 36 103 1264 769 400
24 x 60 193 2129 1286 680
prices reect 10% add to pricing of standard lead time items
TWO DAYS!
L-FRA100 Low Prole
Lite Kit
THREE DAYS!
L-700-RX
Self Attaching,
No Vision Louver
THREE DAYS!
L-FRA100 packed with
GLASS & GLAZING TAPE
QUICK SHIP ITEMS
THREE DAYS!
NON-STOCK SIZES
L-FRA100, L-FRA100-SP, L-GLF100,
L-GLF100-SP, L-GLF100-TB,
L-GLF100-SP-TB
Kits only or packed with
Glass & Glazing Tape GT-118
Pyran F Superlite 1-W Diamond Wired
Glass Only
Pyran F
Superlite 1-W
Diamond Wired
Add 25% to pricing of
standard lead time items
Order Size List Price
12 x 12 $ 75
18 x 12 91
18 x 18 106
24 x 12 105
24 x 18 120
24 x 24 147
prices reect 10% add to pricing of standard
lead time items
25
26
NATIONAL GUARD PRODUCTS, INC.Phone: 800-647-7874
Fax: 800-255-7874
www.ngp.com
orders@ngp.com
L-FRA100, L-GLF100, L-GLF100-TB
Lite Kits for 1-3/4" Doors
HEIGHT
Mullion Bars available for L-GLF-100 and L-GLF100-TB - price of Lite Kit plus $124 per Mullion Bar
Torx Security Screws - up to 24" x 24" add $12, over 24" x 24" add $24
Minimum 3" width or height; maximum 88" width or height
Odd inch and fractional sizes, use next largest even size
Lead lining - $5 per perimeter inch
STC option - $12.80 per square ft.
Gray Primer (GPZ) nish standard and will be provided unless one of the following optional nishes is indicated:
Available at no extra charge: (T) Tan (DKB) Dark Bronze (BPR) Beige Primer (matches Steelcraft)
(CAB) California Bronze (matches Anemostat) (PTY) Putty (matches Anemostat beige)
Add 15% for following nishes:
(B) Brass (Gold) (GBL) Gloss Black (W) White
(MBL) Matte Black (TBL) Textured Black (ASL) Aluminum Silver
(WB) Walnut Brown (matches Timely Browntone)
(MW) Magnolia White (matches Timely Western White)
Galvanneal - Add 20% Zinc EL-Plate - Add $400
W I D T H
6 8 10 12 14 16 18 20 22 24 26 28 30 32 34 36
4 56 56 56 60 63 68 74 74 76 78 82 86 89 91 92 96
6 56 56 56 63 63 71 74 74 78 86 88 90 91 91 92 96
8 56 56 56 68 71 74 74 78 86 88 90 91 91 96 96 98
10 56 56 47 71 74 74 78 86 88 90 91 96 96 96 98 98
12 63 68 71 42 74 78 86 88 90 91 91 96 98 98 98 103
14 52 71 74 74 76 86 88 90 91 91 96 98 98 103 103 113
16 71 74 74 74 86 88 90 91 96 96 96 98 98 103 105 115
18 74 74 79 86 88 90 79 96 96 96 98 98 103 113 113 116
20 74 79 86 88 90 91 96 97 97 98 98 98 113 113 113 116
22 77 61 88 90 91 96 96 97 97 98 98 103 113 113 116 118
24 77 88 90 91 91 96 96 98 98 78 103 116 116 120 120 123
26 71 74 91 91 96 96 98 98 98 91 116 116 120 122 123 124
28 66 91 96 96 98 98 98 98 103 116 116 120 122 123 124 126
30 73 72 96 98 98 98 88 103 113 85 120 122 123 124 126 133
32 91 72 96 98 103 103 89 113 113 90 122 123 124 126 133 135
34 92 85 98 98 103 105 113 113 116 102 123 124 126 133 135 136
36 72 86 98 103 113 115 116 116 118 93 124 126 133 135 136 137
38 94 86 98 109 116 116 120 122 123 125 126 133 135 136 178 184
40 96 97 109 116 116 120 122 123 125 126 133 135 136 178 184 189
42 118 125 133 135 140 146 149 154 159 165 168 176 178 184 189 203
44 122 133 135 140 146 149 154 159 165 168 176 178 184 189 203 208
46 126 135 140 146 149 154 159 165 168 176 178 184 189 203 208 215
48 142 149 154 157 164 168 173 178 187 192 194 200 203 208 215 217
50 146 154 157 164 168 173 178 187 192 194 200 203 208 215 217 220
52 149 157 164 168 173 178 187 192 194 200 203 208 215 217 220 229
54 154 164 168 173 178 187 192 194 200 202 208 215 217 220 229 240
56 159 168 173 178 183 192 194 200 202 208 208 217 220 229 240 246
58 171 178 183 188 192 200 205 208 212 215 222 226 229 240 246 248
60 176 183 188 192 200 205 208 215 218 175 226 229 240 246 248 258
62 180 188 192 200 205 208 215 218 222 210 229 240 246 248 258 263
64 184 192 200 205 208 215 218 222 226 198 240 246 248 258 263 268
66 196 207 214 216 215 226 228 233 239 193 250 252 258 263 268 275
68 202 214 216 220 226 228 233 239 248 250 252 258 263 268 275 281
70 207 216 220 226 228 233 239 248 250 252 258 263 268 275 281 288
72 214 220 226 228 233 239 248 250 252 258 263 268 275 281 288 296
L-FRA100, L-GLF100, L-GLF100-TB Lite Kits for 1-3/4" Doors
Optional Material:
Aluminum = List X 2
27
Phone: 800-647-7874
Fax: 800-255-7874
www.ngp.com
orders@ngp.com
Phone: 800-647-7874
Fax: 800-255-7874
www.ngp.com
orders@ngp.com
W I D T H
6 8 10 12 14 16 18 20 22 24 26 28 30 32 34 36
6 157 157 157 164 164 172 175 175 179 187 201 211 220 228 237 250
8 157 157 157 169 172 175 175 194 213 225 238 250 261 276 287 300
10 157 157 148 172 175 190 207 229 244 260 274 293 310 324 339 353
12 164 169 172 143 195 215 240 258 276 293 313 334 353 369 385 406
14 153 172 175 195 216 245 266 287 310 329 353 374 393 421 440 469
16 172 175 190 211 245 268 292 319 345 367 388 416 437 464 487 519
18 175 175 208 240 266 292 309 351 375 399 429 454 483 517 545 573
20 175 184 229 258 287 319 351 378 409 437 464 491 537 564 591 621
22 178 166 244 276 310 345 375 409 439 470 499 538 578 607 644 676
24 178 209 260 293 329 367 399 437 470 482 543 589 621 661 694 729
26 176 205 274 313 353 388 429 464 499 531 591 630 669 706 746 783
28 171 231 293 334 374 416 454 491 538 589 630 672 712 755 793 833
30 178 221 310 353 393 437 468 527 578 590 669 712 757 799 845 893
32 196 231 324 369 421 464 493 564 607 631 706 755 799 848 898 943
34 197 253 339 385 440 487 545 591 644 676 746 793 845 898 950 997
36 201 264 353 406 469 519 573 621 676 699 783 833 893 943 997 1046
38 230 277 366 432 490 546 601 658 710 767 820 882 935 991 1084 1146
40 239 298 390 455 509 571 627 686 746 801 866 921 980 1076 1140 1199
42 267 335 428 491 556 619 682 744 809 872 936 1004 1063 1129 1191 1266
44 278 352 447 512 581 643 712 780 845 911 979 1044 1113 1177 1255 1319
46 289 364 466 534 603 674 741 813 882 952 1020 1088 1159 1239 1306 1379
48 312 387 493 561 637 709 779 853 930 1000 1071 1145 1213 1287 1362 1429
50 326 402 510 588 660 736 812 889 965 1038 1116 1186 1262 1341 1410 1485
52 336 414 530 608 687 762 846 925 997 1077 1154 1233 1310 1386 1463 1542
54 348 431 548 630 711 793 875 954 1036 1111 1194 1278 1356 1432 1518 1606
56 360 448 566 651 735 824 901 986 1068 1153 1233 1317 1400 1488 1579 1660
58 378 467 594 677 763 853 940 1025 1108 1193 1282 1368 1453 1542 1630 1715
60 387 477 605 689 780 869 955 1046 1132 1169 1303 1390 1484 1574 1659 1749
HEIGHT
Gray Primer (GPZ) nish standard and will be provided unless one of the following optional nishes is indicated:
Available at no extra charge: (T) Tan (DKB) Dark Bronze (BPR) Beige Primer (matches Steelcraft)
(CAB) California Bronze (matches Anemostat) (PTY) Putty (matches Anemostat beige)
Add 15% for following nishes:
(B) Brass (Gold) (GBL) Gloss Black (W) White
(MBL) Matte Black (TBL) Textured Black (ASL) Aluminum Silver
(WB) Walnut Brown (matches Timely Browntone)
(MW) Magnolia White (matches Timely Western White)
Galvanneal - Add 20% Zinc EL-Plate - Add $400
L-FRA100, L-GLF100, L-GLF100-TB with SuperLite™ 1-W
with GT-118 Glazing Tape both sides
Meets CPSC 16CFR 1201 Cat. I & II impact safety requirements
Etched with UL Fire-rating classication on each piece
Mullion bars available for L-GLF100 and L-GLF100-TB - price of lite kit plus $124 per mullion bar
Torx Security Screws - up to 24" x 24" add $12, over 24" x 24" add $24
Minimum 3" width or height; maximum 88”
Under 4" or over 60" - call for quote
Odd inch or fractional sizes, use next largest size
STC option - $12.80 per square ft
L-FRA100, L-GLF100, L-GLF100-TB with SuperLite™ 1-W
28
NATIONAL GUARD PRODUCTS, INC.Phone: 800-647-7874
Fax: 800-255-7874
www.ngp.com
orders@ngp.com
W I D T H
6 8 10 12 14 16 18 20 22 24 26 28 30 32 34 36
6 232 232 232 239 239 247 250 250 254 262 282 299 314 328 344 362
8 232 232 232 244 247 250 250 277 304 325 346 367 386 410 429 450
10 232 232 223 247 250 273 301 333 359 385 410 438 466 490 516 540
12 239 244 247 218 283 315 352 383 413 443 476 509 540 569 597 631
14 228 247 250 283 318 362 397 432 471 504 543 578 612 654 688 731
16 247 250 273 311 362 402 442 485 528 567 605 649 687 731 771 819
18 250 250 302 352 397 442 478 538 581 624 673 716 764 817 864 910
20 250 259 333 383 432 485 538 587 639 687 735 783 850 897 945 996
22 253 241 359 413 471 528 581 639 691 745 797 859 921 974 1033 1088
24 253 297 385 443 504 567 624 687 745 782 868 939 996 1061 1119 1179
26 251 299 410 476 543 605 673 735 797 856 943 1010 1076 1140 1207 1270
28 246 333 438 509 578 649 716 783 859 939 1010 1080 1149 1221 1289 1358
30 253 331 466 540 612 687 749 840 921 965 1076 1149 1226 1299 1376 1455
32 271 348 490 569 654 731 793 897 974 1031 1140 1221 1299 1381 1465 1543
34 272 377 516 597 688 771 864 945 1033 1101 1207 1289 1376 1465 1552 1634
36 295 395 540 631 731 819 910 996 1088 1149 1270 1358 1455 1543 1634 1721
38 329 416 564 670 767 862 957 1054 1146 1242 1334 1436 1529 1624 1757 1858
40 343 443 599 705 801 904 1002 1103 1204 1301 1407 1505 1605 1743 1848 1949
42 377 488 647 753 862 969 1076 1181 1291 1397 1504 1617 1719 1829 1935 2053
44 393 513 677 787 902 1010 1124 1238 1349 1461 1574 1686 1801 1911 2034 2144
46 409 532 705 821 938 1057 1172 1292 1409 1527 1643 1758 1877 2005 2120 2241
48 437 562 743 861 987 1109 1229 1353 1480 1600 1721 1845 1963 2087 2212 2329
50 457 584 770 901 1024 1153 1281 1409 1538 1663 1793 1915 2044 2174 2296 2422
52 472 604 801 933 1067 1196 1333 1466 1592 1727 1858 1991 2122 2253 2384 2517
54 489 628 829 967 1105 1243 1381 1516 1655 1786 1925 2065 2200 2332 2474 2618
56 505 652 858 1001 1143 1290 1426 1570 1710 1853 1991 2134 2275 2421 2570 2710
58 529 679 896 1039 1186 1336 1484 1630 1772 1918 2067 2214 2359 2509 2657 2802
60 546 701 925 1072 1227 1380 1530 1684 1835 1935 2133 2284 2442 2595 2745 2898
62 562 722 953 1113 1270 1421 1580 1735 1891 2031 2202 2366 2520 2674 2836 2993
64 578 743 984 1146 1306 1470 1626 1787 1948 2077 2276 2438 2597 2764 2926 3084
66 602 775 1022 1186 1347 1519 1683 1850 2017 2129 2348 2511 2679 2846 3012 3181
68 620 799 1048 1219 1391 1560 1731 1903 2079 2247 2416 2588 2760 2931 3105 3273
70 637 817 1076 1253 1427 1603 1780 1960 2133 2307 2484 2660 2836 3015 3192 3370
72 656 838 1106 1284 1465 1647 1832 2010 2188 2370 2551 2732 2915 3097 3280 3464
Gray Primer (GPZ) nish standard and will be provided unless one of the following optional nishes is indicated:
Available at no extra charge: (T) Tan (DKB) Dark Bronze (BPR) Beige Primer (matches Steelcraft)
(CAB) California Bronze (matches Anemostat) (PTY) Putty (matches Anemostat beige)
Add 15% for following nishes:
(B) Brass (Gold) (GBL) Gloss Black (W) White
(MBL) Matte Black (TBL) Textured Black (ASL) Aluminum Silver
(WB) Walnut Brown (matches Timely Browntone)
(MW) Magnolia White (matches Timely Western White)
Galvanneal - Add 20% Zinc EL-Plate - Add $400
L-FRA100, L-GLF100, L-GLF100-TB with Pyran® F
with GT-118 Glazing Tape both sides
Meets CPSC 16CFR 1201 Cat. I & II impact safety requirements
Etched with UL Fire-rating classication on each piece
Mullion bars available for L-GLF100 and L-GLF100-TB - price of lite kit plus $124 per mullion bar
Torx Security Screws - up to 24" x 24" add $12, over 24" x 24" add $24
Minimum 3" width or height; maximum 78” height. Under 4" - call for quote
Odd inch or fractional sizes, use next largest size
STC option - $12.80 per square ft
L-FRA100, L-GLF100, L-GLF100-TB with Pyran® F
HEIGHT
29
Phone: 800-647-7874
Fax: 800-255-7874
www.ngp.com
orders@ngp.com
Phone: 800-647-7874
Fax: 800-255-7874
www.ngp.com
orders@ngp.com
HEIGHT
Gray Primer (GPZ) nish standard and will be provided unless one of the following optional nishes is indicated:
Available at no extra charge: (T) Tan (DKB) Dark Bronze (BPR) Beige Primer (matches Steelcraft)
(CAB) California Bronze (matches Anemostat) (PTY) Putty (matches Anemostat beige)
Add 15% for following nishes:
(B) Brass (Gold) (GBL) Gloss Black (W) White
(MBL) Matte Black (TBL) Textured Black (ASL) Aluminum Silver
(WB) Walnut Brown (matches Timely Browntone)
(MW) Magnolia White (matches Timely Western White)
Galvanneal - Add 20% Zinc EL-Plate - Add $400
L-FRA100, L-GLF100, L-GLF100-TB with 1/4" Tempered Glass
with GT-118 Glazing Tape both sides
L-FRA100, L-GLF100, L-GLF100-TB with 1/4" Tempered Glass
Meets CPSC 16CFR 1201 Cat. I & II impact safety requirements
Mullion bars available for L-GLF100 and L-GLF100-TB - price of lite kit plus $124 per mullion bar
Torx Security Screws - up to 24" x 24" add $12, over 24" x 24" add $24
Minimum 3” width, 12” height; maximum 88” width or height
Odd inch or fractional sizes, use next largest size
STC option - $12.80 per square ft
W I D T H
6 8 10 12 14 16 18 20 22 24 26 28 30 32 34 36
12 108 113 116 87 123 127 135 137 139 140 149 154 156 156 156 161
14 97 116 119 123 125 135 137 139 149 149 154 156 156 181 181 191
16 116 119 123 123 135 137 139 149 154 154 154 176 176 181 183 193
18 119 119 128 135 137 139 137 154 154 154 176 176 181 191 210 213
20 119 128 135 137 139 149 154 155 175 176 176 176 210 210 210 213
22 122 110 137 139 149 154 154 175 175 176 176 200 210 210 233 235
24 122 137 139 140 149 154 154 176 176 156 200 213 213 237 237 240
26 120 123 140 149 154 154 176 176 176 188 213 233 237 239 259 260
28 115 140 145 154 156 176 176 176 200 213 233 237 239 259 260 262
30 122 121 154 156 156 176 166 200 210 182 237 239 259 260 282 289
32 140 121 154 156 181 181 167 210 210 207 239 259 260 282 289 291
34 141 134 156 156 181 183 210 210 233 219 259 260 282 289 310 311
36 121 135 156 161 191 193 213 213 235 210 260 262 289 291 311 312
38 143 144 156 187 194 213 217 239 240 261 262 289 291 311 353 379
40 145 155 167 194 194 217 219 240 261 262 289 291 311 353 379 384
42 167 183 191 213 237 243 266 271 295 301 324 351 353 379 384 417
44 171 191 213 218 243 246 271 295 301 324 332 353 379 384 417 422
46 175 193 218 224 246 271 276 301 324 332 353 359 384 417 422 448
48 191 207 232 235 261 285 290 314 343 348 369 395 398 422 448 450
50 204 212 235 261 265 290 314 323 348 369 395 398 422 448 450 473
52 207 215 242 265 290 295 323 348 350 375 398 422 429 450 473 482
54 212 222 246 270 295 304 328 350 375 377 403 429 450 453 482 512
56 217 246 251 275 300 328 330 356 377 403 422 431 453 482 512 518
58 229 256 280 285 309 336 361 383 387 410 436 459 482 493 518 540
60 234 261 285 289 317 341 364 390 413 370 440 462 493 518 540 550
62 238 266 289 317 341 344 371 393 417 424 462 493 499 520 550 574
64 242 270 297 322 344 371 374 397 421 412 473 499 520 550 574 579
66 254 285 311 333 351 382 403 428 453 407 483 505 530 555 579 606
68 260 292 313 337 362 384 408 434 462 483 505 530 555 579 606 612
70 265 294 317 343 364 389 414 443 464 485 511 535 560 586 612 638
72 272 298 323 345 369 395 423 445 466 491 516 540 567 592 619 646
30
NATIONAL GUARD PRODUCTS, INC.Phone: 800-647-7874
Fax: 800-255-7874
www.ngp.com
orders@ngp.com
L-FRA100, L-GLF100, L-GLF100-TB with 1/4" Wired Glass
Diamond & GT-118 Glazing Tape both sides
HEIGHT
Etched with UL re-rating classication on each piece up to 1,296 sq. inches visible area - 54" max. width or height
Mullion bars available for L-GLF100 and L-GLF100-TB - price of lite kit plus $124 per mullion bar
Torx Security Screws - up to 24" x 24" add $12, over 24" x 24" add $24
Under 4" or over 60” - call for quote
Odd inch or fractional sizes, use next largest size
STC option - $12.80 per square ft
W I D T H
6 8 10 12 14 16 18 20 22 24 26 28 30 32 34 36
6 101 101 101 108 108 116 119 119 123 131 140 146 150 154 158 166
8 101 101 101 113 116 119 119 132 144 151 157 163 167 177 181 188
10 101 101 92 116 119 128 137 151 159 166 173 184 193 199 207 213
12 108 113 116 87 130 141 156 164 173 181 192 204 213 219 226 238
14 97 116 119 130 140 158 168 178 191 199 212 222 230 247 255 273
16 116 119 128 137 158 169 180 194 208 217 226 242 251 265 276 295
18 119 119 138 156 168 180 183 211 221 231 247 258 273 293 307 321
20 119 128 151 164 178 194 211 223 238 251 262 273 304 315 327 341
22 122 110 159 173 191 208 221 238 251 264 277 298 321 333 353 368
24 122 144 166 181 199 217 231 251 264 258 301 327 341 363 376 393
26 120 134 173 192 212 226 247 262 277 289 328 347 366 383 403 419
28 115 155 184 204 222 242 258 273 298 327 347 367 385 406 423 441
30 122 140 193 213 230 251 258 294 321 310 366 385 407 425 448 473
32 140 144 199 219 247 265 269 315 333 333 383 406 425 450 475 495
34 141 161 207 226 255 276 307 327 353 358 403 423 448 475 500 521
36 131 166 213 238 273 295 321 341 368 363 419 441 473 495 521 542
38 156 174 218 255 283 309 335 362 385 413 435 468 492 518 582 614
40 161 189 235 269 291 322 347 375 404 427 461 486 514 578 611 639
42 186 221 265 295 327 357 388 417 450 480 511 547 573 607 636 678
44 193 233 276 306 341 369 404 438 469 501 534 565 600 630 673 703
46 199 239 287 319 352 388 419 455 488 522 555 587 622 666 697 735
48 218 257 307 337 375 411 443 479 520 552 585 623 653 689 728 757
50 229 266 315 355 387 425 462 500 537 572 610 642 679 719 749 785
52 235 273 328 366 404 439 482 520 552 591 628 667 703 739 775 814
54 243 284 338 378 417 457 497 534 574 607 648 690 726 760 804 850
56 251 296 348 389 430 475 509 551 589 631 667 707 746 791 838 876
58 266 310 368 406 447 492 534 574 611 651 695 736 776 820 863 903
60 272 317 376 414 459 502 542 587 628 618 707 747 796 840 879 923
Gray Primer (GPZ) nish standard and will be provided unless one of the following optional nishes is indicated:
Available at no extra charge: (T) Tan (DKB) Dark Bronze (BPR) Beige Primer (matches Steelcraft)
(CAB) California Bronze (matches Anemostat) (PTY) Putty (matches Anemostat beige)
Add 15% for following nishes:
(B) Brass (Gold) (GBL) Gloss Black (W) White
(MBL) Matte Black (TBL) Textured Black (ASL) Aluminum Silver
(WB) Walnut Brown (matches Timely Browntone)
(MW) Magnolia White (matches Timely Western White)
Galvanneal - Add 20% Zinc EL-Plate - Add $400
Does NOT comply with IBC 2006 or newer requirements for use in doors
or sidelights. Allowed only in non-hazardous locations dened in IBC
L-FRA100, L-GLF100, L-GLF100-TB with 1/4" Wire Glass
31
Phone: 800-647-7874
Fax: 800-255-7874
www.ngp.com
orders@ngp.com
Phone: 800-647-7874
Fax: 800-255-7874
www.ngp.com
orders@ngp.com
W I D T H
6 8 10 12 14 16 18 20 22 24 26 28 30 32 34 36
6 113 113 113 120 120 128 131 131 135 143 164 170 174 178 182 190
8 113 113 113 125 128 131 131 156 168 175 181 187 191 201 205 212
10 113 113 104 128 131 152 161 175 183 190 197 208 229 235 243 249
12 120 125 128 99 154 165 180 188 197 205 228 240 249 255 262 274
14 109 128 131 154 164 182 192 202 227 235 248 258 266 295 303 321
16 128 131 152 161 182 193 204 230 244 253 262 290 299 313 324 343
18 131 131 162 180 192 204 219 247 257 267 295 306 321 341 367 381
20 131 152 175 188 202 230 247 259 286 299 310 321 364 375 387 401
22 134 134 183 197 227 244 257 286 299 312 325 358 381 393 425 440
24 134 168 190 205 235 253 267 299 312 306 361 387 401 435 448 465
26 144 158 197 228 248 262 295 310 325 349 388 419 438 455 487 503
28 139 179 208 240 258 290 306 321 358 387 419 439 457 490 507 525
30 146 164 229 249 266 299 306 354 381 370 438 457 491 509 544 569
32 164 168 235 255 295 313 317 375 393 405 455 490 509 546 571 591
34 165 185 243 262 303 324 367 387 425 430 487 507 544 571 608 629
36 155 190 249 274 321 343 381 401 440 435 503 525 569 591 629 650
38 180 210 254 303 331 369 395 434 457 497 519 564 588 626 690 734
40 185 225 271 317 339 382 407 447 488 511 557 582 622 686 731 759
42 210 257 301 343 387 417 460 489 534 564 607 655 681 727 756 810
44 217 269 324 354 401 429 476 522 553 597 630 673 720 750 805 835
46 223 275 335 367 412 460 491 539 584 618 663 695 742 798 829 879
48 242 293 355 385 435 483 515 563 616 648 693 743 773 821 872 901
50 265 302 363 415 447 497 546 584 633 680 730 762 811 863 893 941
52 271 309 376 426 476 511 566 616 648 699 748 799 835 883 931 970
54 279 320 386 438 489 529 581 630 682 715 768 822 870 904 960 1018
56 287 344 396 449 502 559 593 647 697 751 799 839 890 947 1006 1044
HEIGHT
Includes U.L. etching up to 1,296 sq. inches visible area - 54" max. width or height
Mullion bars available for L-GLF100 - price of lite kit plus $124 per mullion bar
Torx Security Screws - up to 24" x 24" add $12, over 24" x 24" add $24
Minimum 4" width or height; maximum 56” width or height. Odd inch or fractional sizes, use next largest size
STC option - $12.80 per square ft
Gray Primer (GPZ) nish standard and will be provided unless one of the following optional nishes is indicated:
Available at no extra charge: (T) Tan (DKB) Dark Bronze (BPR) Beige Primer (matches Steelcraft)
(CAB) California Bronze (matches Anemostat) (PTY) Putty (matches Anemostat beige)
Add 15% for following nishes:
(B) Brass (Gold) (GBL) Gloss Black (W) White
(MBL) Matte Black (TBL) Textured Black (ASL) Aluminum Silver
(WB) Walnut Brown (matches Timely Browntone)
(MW) Magnolia White (matches Timely Western White)
Galvanneal - Add 20% Zinc EL-Plate - Add $400
Does NOT comply with IBC 2006 or newer requirements for use in doors
or sidelights. Allowed only in non-hazardous locations dened in IBC
L-FRA100, L-GLF100, L-GLF100-TB with 1/4" Wired Glass
Diamond with GT-9800 Intumescent Glazing Tape both sides
L-FRA100, L-GLF100, L-GLF100-TB with 1/4" Wire Glass
32
NATIONAL GUARD PRODUCTS, INC.Phone: 800-647-7874
Fax: 800-255-7874
www.ngp.com
orders@ngp.com
L-FRA100-SP, L-GLF100-SP, L-GLF100-SP-TB
Lite Kits for Variable Door and Glass Thicknesses
HEIGHT
Gray Primer (GPZ) nish standard and will be provided unless one of the following optional nishes is indicated:
Available at no extra charge: (T) Tan (DKB) Dark Bronze (BPR) Beige Primer (matches Steelcraft)
(CAB) California Bronze (matches Anemostat) (PTY) Putty (matches Anemostat beige)
Add 15% for following nishes:
(B) Brass (Gold) (GBL) Gloss Black (W) White
(MBL) Matte Black (TBL) Textured Black (ASL) Aluminum Silver
(WB) Walnut Brown (matches Timely Browntone)
(MW) Magnolia White (matches Timely Western White)
Galvanneal - Add 20% Zinc EL-Plate - Add $400
W I D T H
6 8 10 12 14 16 18 20 22 24 26 28 30 32 34 36
4 84 84 84 90 95 102 111 111 114 117 123 129 134 137 138 144
6 84 84 84 95 95 107 111 111 117 129 132 135 137 137 138 144
8 84 84 84 102 107 111 111 117 129 132 135 137 137 144 144 147
10 84 84 71 107 111 111 117 129 132 135 137 144 144 144 147 147
12 95 102 107 63 111 117 129 132 135 137 137 144 147 147 147 155
14 78 107 111 111 114 129 132 135 137 137 144 147 147 155 155 170
16 107 111 111 111 129 132 135 137 144 144 144 147 147 155 158 173
18 111 111 119 129 132 135 119 144 144 144 147 147 155 170 170 174
20 111 119 129 132 135 137 144 146 146 147 147 147 170 170 170 174
22 116 92 132 135 137 144 144 146 146 147 147 155 170 170 174 177
24 116 132 135 137 137 144 144 147 147 117 155 174 174 180 180 185
26 107 111 137 137 144 144 147 147 147 137 174 174 180 183 185 186
28 99 137 144 144 147 147 147 147 155 174 174 180 183 185 186 189
30 110 108 144 147 147 147 132 155 170 128 180 183 185 186 189 200
32 137 108 144 147 155 155 134 170 170 135 183 185 186 189 200 203
34 138 128 147 147 155 158 170 170 174 153 185 186 189 200 203 204
36 108 129 147 155 170 173 174 174 177 140 186 189 200 203 204 206
38 141 129 147 164 174 174 180 183 185 188 189 200 203 204 267 276
40 144 146 164 174 174 180 183 185 188 189 200 203 204 267 276 284
42 177 188 200 203 210 219 224 231 239 248 252 264 267 276 284 305
44 183 200 203 210 219 224 231 239 248 252 264 267 276 284 305 312
46 189 203 210 219 224 231 239 248 252 264 267 276 284 305 312 323
48 213 224 231 236 246 252 260 267 281 288 291 300 305 312 323 326
50 219 231 236 246 252 260 267 281 288 291 300 305 312 323 326 330
52 224 236 246 252 260 267 281 288 291 300 305 312 323 326 330 344
54 231 246 252 260 267 281 288 291 300 303 312 323 326 330 344 360
56 239 252 260 267 275 288 291 300 303 312 312 326 330 344 360 369
58 257 267 275 282 288 300 308 312 318 323 333 339 344 360 369 372
60 264 275 282 288 300 308 312 323 327 263 339 344 360 369 372 387
62 270 282 288 300 308 312 323 327 333 315 344 360 369 372 387 395
64 276 288 300 308 312 323 327 333 339 297 360 369 372 387 395 402
66 294 311 321 324 323 339 342 350 359 290 375 378 387 395 402 413
68 303 321 324 330 339 342 350 359 372 375 378 387 395 402 413 422
70 311 324 330 339 342 350 359 372 375 378 387 395 402 413 422 432
72 321 330 339 342 350 359 372 375 378 387 395 402 413 422 432 444
Mullion Bars available for L-GLF100-SP and L-GLF100-SP-TB - price of Lite Kit plus $124 per Mullion Bar
Torx Security Screws - up to 24" x 24" add $12, over 24" x 24" add $24
Minimum: 3" width or height; Maximum 88” width or height
Odd inch and fractional sizes, use next largest even size
Lead lining - $5 per perimeter inch
STC option - $12.80 per square ft
L-FRA100-SP, L-GLF100-SP, L-GLF100-SP-TB
33
Phone: 800-647-7874
Fax: 800-255-7874
www.ngp.com
orders@ngp.com
Phone: 800-647-7874
Fax: 800-255-7874
www.ngp.com
orders@ngp.com
L-VGLF Security Lite Kits
For torx security screws add $6
Zinc EL-Plate - Add $400
Gray Primer (GPZ) nish standard and will be provided unless one of
the following optional nishes is indicated:
Available at no extra charge:
(T) Tan (DKB) Dark Bronze
(BPR) Beige Primer (matches Steelcraft)
(PTY) Putty (matches Anemostat Beige)
(CAB) California Bronze (matches Anemostat)
Add 15% for following nishes:
(B) Brass (Gold) (GBL) Gloss Black
(W) White (MBL) Matte Black
(TBL) Textured Black (ASL) Aluminum Silver
(WB) Walnut Brown (matches Timely Browntone)
(MW) Magnolia White (matches Timely Western White)
Complete Kit shipped including polycarbonate plastic, silicone sealant, fasteners and installation instructions.
L-VGLF- PZ 9x9 $195
(1/2" Polycarbonate
L-VGLF- MD 9x9 $240
(1/2" Polycarbonate)
L-VGLF- MDL 12x12 $320
(1/2" Polycarbonate)
L-VGLF- WD 9x5 $191
(1/2"Polycarbonate)
L-VGLF- OG 9x9 $220
(1/2" Polycarbonate)
L-VGLF- SF 11x11 $295
(1/4" Polycarbonate)
L-VGLF Security Lite Kits
Add $124 per Mullion Bar to
Price of L-GLF100, L-GLF100SP,
L-GLF100-TB, L-GLF100-SP-TB,
L-SG100, L-SG100-TB series Lite Kits
Add:
G2 = 1 Bar $124
G3 = 2 Bars 248
G4 = 2 Bars 248
G6 = 3 Bars 372
G8 = 4 Bars 496
G9 = 4 Bars 496
G10 = 5 Bars 620
G12 = 5 Bars 620
G15 = 6 Bars 744
G18 = 7 Bars 868
G21 = 8 Bars 992
G24 = 9 Bars 1,116
G21
(8 Bars)
G24
(9 Bars)
G18
(7 Bars)
G15
(6 Bars)
G8
(4 Bars)
G9
(4 Bars)
G12
(5 Bars)
G10
(5 Bars)
G6
(3 Bars)
G4
(2 Bars)
G2
(1 Bar)
G3
(2 Bars)
False Mullion Bars
False Mullion Bars
34
NATIONAL GUARD PRODUCTS, INC.Phone: 800-647-7874
Fax: 800-255-7874
www.ngp.com
orders@ngp.com
L-SG100, L-SG100-TB
Lite Kits with Security Grille
W I D T H
6 8 10 12 14 16 18 20 22 24 26 28 30 32 34 36
4 212 212 212 212 212 217 222 226 231 239 246 251 255 269 271 279
6 212 212 212 212 217 220 226 231 239 246 251 255 269 271 279 287
8 212 212 212 212 220 226 231 239 246 251 255 269 271 279 287 294
10 212 212 212 217 226 231 239 246 251 255 269 271 279 287 294 303
12 212 212 217 219 231 239 246 251 255 269 271 279 287 294 303 313
14 217 220 226 231 239 246 251 255 269 271 279 287 294 303 313 413
16 220 226 231 239 246 251 255 269 271 279 287 294 303 313 413 465
18 226 231 239 246 251 255 269 271 279 287 294 303 313 413 465 482
20 231 239 246 251 255 269 271 279 287 294 303 313 413 465 482 511
22 239 246 251 255 269 271 279 287 294 303 313 413 465 482 511 523
24 246 251 255 269 271 279 287 294 303 390 413 465 482 511 523 542
26 251 255 269 271 279 287 294 303 313 413 465 482 511 523 542 607
28 255 269 271 279 287 294 303 313 413 465 482 511 523 542 607 636
30 269 271 279 287 294 303 313 413 465 482 511 523 542 607 636 653
32 271 279 287 294 303 313 413 465 482 511 523 542 607 636 653 684
34 279 287 294 303 313 413 465 482 511 523 542 607 636 653 684 698
36 287 294 303 313 413 465 482 511 523 542 607 636 653 684 698 724
38 294 303 313 413 465 482 511 523 542 607 636 653 684 698 724 765
40 303 313 413 465 482 511 523 542 607 636 653 684 698 724 765 777
42 313 413 465 482 511 523 542 607 636 653 684 698 724 765 777 804
44 413 465 482 511 523 542 607 636 653 684 698 724 765 777 804 827
46 465 482 511 523 542 607 636 653 684 698 724 765 777 804 827 847
48 482 511 523 542 607 636 653 684 698 724 765 777 804 827 847 865
50 511 523 542 607 636 653 684 698 724 765 777 804 827 847 865 898
52 523 542 607 636 653 684 698 724 765 777 804 827 847 865 898 919
54 542 607 636 653 684 698 724 765 777 804 827 847 865 898 919 937
56 607 636 653 684 698 724 765 777 804 827 847 865 898 919 937 966
58 636 653 684 698 724 765 777 804 827 847 865 898 919 937 966 985
60 653 684 698 724 765 777 804 827 847 865 898 919 937 966 985 1014
62 684 698 724 765 777 804 827 847 865 898 919 937 966 985 1014 1070
64 698 724 765 777 804 827 847 865 898 919 937 966 985 1014 1070 1122
66 724 765 777 804 827 847 865 898 919 937 966 985 1014 1070 1122 1178
68 765 777 804 827 847 865 898 919 937 966 985 1014 1070 1122 1178 1236
70 777 804 827 847 865 898 919 937 966 985 1014 1070 1122 1178 1236 1297
72 804 827 847 865 898 919 937 1017 985 1014 1070 1122 1178 1236 1297 1348
HEIGHT
Gray Primer (GPZ) nish standard and will be provided unless one of the following optional nishes is indicated:
Available at no extra charge: (T) Tan (DKB) Dark Bronze (BPR) Beige Primer (matches Steelcraft)
(CAB) California Bronze (matches Anemostat) (PTY) Putty (matches Anemostat beige)
Add 15% for following nishes:
(B) Brass (Gold) (GBL) Gloss Black (W) White
(MBL) Matte Black (TBL) Textured Black (ASL) Aluminum Silver
(WB) Walnut Brown (matches Timely Browntone)
(MW) Magnolia White (matches Timely Western White)
Galvanneal - Add 20% Zinc EL-Plate - Add $400
Mullion Bars available - price of lite kit plus $124 per Mullion Bar
Torx Security Screws - up to 24" x 24" add $12, over 24" x 24" add $24
Minimum 3" width or height; maximum 48" width x 88” height
Odd inch and fractional sizes, use next largest even size
Lead lining - $5 per perimeter inch
STC option - $12.80 per square ft
L-SG100, L-SG100-TB Lite Kits with Security Grille
35
Phone: 800-647-7874
Fax: 800-255-7874
www.ngp.com
orders@ngp.com
Phone: 800-647-7874
Fax: 800-255-7874
www.ngp.com
orders@ngp.com
W I D T H
6 8 10 12 14 16 18 20 22 24 26 28 30 32 34 36
4 239 239 239 257 270 288 315 315 324 333 351 365 378 387 392 410
6 239 239 239 270 270 302 315 315 333 365 374 383 387 387 392 410
8 239 239 239 288 302 315 315 333 365 374 383 387 387 410 410 419
10 239 239 198 302 315 315 333 365 374 383 387 410 410 410 419 419
12 270 288 302 185 315 333 365 374 383 387 387 410 419 419 419 441
14 225 302 315 315 324 365 374 383 387 387 410 419 419 441 441 482
16 302 315 315 315 365 374 383 387 410 410 410 419 419 441 450 491
18 315 293 338 365 374 383 320 410 410 410 419 419 441 482 482 495
20 315 338 365 374 383 387 410 414 414 419 419 419 482 482 482 495
22 329 266 374 383 387 410 410 414 414 419 419 441 482 482 495 504
24 293 374 383 387 387 410 410 419 419 342 441 495 495 513 513 527
26 311 324 387 387 410 410 419 419 419 387 495 495 513 522 527 531
28 288 387 410 410 419 419 419 419 441 495 495 513 522 527 531 540
30 320 315 410 419 419 419 369 441 482 369 513 522 527 531 540 567
32 387 315 410 419 441 441 374 482 482 392 522 527 531 540 567 576
34 392 369 419 419 441 450 482 482 495 446 527 531 540 567 576 581
36 315 374 419 441 482 491 495 495 504 405 531 540 567 576 581 585
38 401 374 419 464 495 495 513 522 527 536 540 567 576 581 761 788
40 410 414 464 495 495 513 522 527 536 540 567 576 581 761 788 810
42 504 536 567 576 599 626 635 657 680 707 720 752 761 788 810 869
44 522 567 576 599 626 635 657 680 707 720 752 761 788 810 869 891
46 540 576 599 626 635 657 680 707 720 752 761 788 810 869 891 918
48 608 635 657 671 702 720 738 761 801 819 828 855 869 891 918 927
50 626 657 671 702 720 738 761 801 819 828 855 869 891 918 927 941
52 635 671 702 720 738 761 801 819 828 855 869 891 918 927 941 981
54 657 702 720 738 761 801 819 828 855 864 891 918 927 941 981 1026
56 680 720 738 761 783 819 828 855 864 734 891 927 941 981 1026 1053
58 729 761 783 806 819 855 878 891 905 918 950 968 981 1026 1053 1062
60 752 783 806 819 855 878 891 918 932 765 968 981 1026 1053 1062 1103
62 770 806 819 855 878 891 918 932 950 900 981 1026 1053 1062 1103 1125
64 788 819 855 878 891 918 932 950 968 860 1026 1053 1062 1103 1125 1148
66 837 887 914 923 918 968 977 995 1022 837 1071 1080 1103 1125 1148 1175
68 864 914 923 941 968 977 995 1022 1062 1071 1080 1103 1125 1148 1175 1202
70 887 923 941 968 977 995 1022 1062 1071 1080 1103 1125 1148 1175 1202 1233
72 914 941 968 977 995 1022 1062 1071 1080 1103 1125 1148 1175 1202 1233 1265
HEIGHT
L-CVFM-SS
Stainless Steel Lite Kits
Torx Security Screws - up to 24" x 24" add $12, over 24" x 24" add $24
Minimum 3" width or height; maximum 88” width or height
Odd inch and fractional sizes, use next largest even size
Lead lining - $5 per perimeter inch
STC option - $12.80 per square ft
Stainless steel material - #4 nish standard and will be provided unless one of the
following optional nishes is indicated:
Add 15% for following nishes:
(T) Tan (DKB) Dark Bronze
(B) Brass (Gold) (GBL) Gloss Black
(W) White (MBL) Matte Black
(TBL) Textured Black (ASL) Aluminum Silver
(PTY) Putty (matches Anemostat Beige) (GPZ) Gray Primer
(BPR) Beige Primer (matches Steelcraft) (MW) Magnolia White (matches Timely Western White)
(CAB) California Bronze (matches Anemostat) (WB) Walnut Brown (matches Timely Browntone)
L-CVFM-SS Stainless Steel Lite Kits
36
NATIONAL GUARD PRODUCTS, INC.Phone: 800-647-7874
Fax: 800-255-7874
www.ngp.com
orders@ngp.com
Size Gray Primer
L-FRA100-RD-12 12" $275
L-FRA100-RD-18 18" $565
L-FRA100-RD-24 24" $595
Add 15% for following nishes: (T) Tan (PTY) Putty (matches Anemostat Beige)
(W) White (DKB) Dark Bronze (CAB) California Bronze (matches Anemostat)
(B) Brass (Gold) (GBL) Gloss Black (BPR) Beige Primer (matches Steelcraft)
(MBL) Matte Black (TBL) Textured Black (WB) Walnut Brown (matches Timely Browntone)
(ASL) Aluminum Silver (MW) Magnolia White (matches Timely Western White)
Zinc - EL plate - Add $400
Galvanneal - Add 20%
Fasteners are nished to match Lite or Louver. Specify color when ordering separately.
Standard Fasteners:
L-GLF100-TB Thru-Bolts (TB) $2.20 / EA.
Torx Thru-Bolts 3.60 / EA.
L-GLF100/L-GLF100-SP #6 x 1-3/4" Truss Head SMS .37 / EA.
#6 x 1-3/4" TORX 1.80 / EA.
L-GLF100-SP #6 x 1" Truss Head SMS .35 / EA.
#6 x 1-1/2" Truss Head SMS .36 / EA.
L-700-RX #8 x 3/4" Oval Phillips head SMS .33 / EA.
L-FRA100 #8 x 1-5/8" Oval Phillips Head SMS .38 / EA.
L-FRA100-SP #8 x 1-1/4" Oval Phillips Head SMS .36 / EA.
#8 x 1-3/4" Oval Phillips Head SMS .40 / EA.
#8 x 1-7/8" Oval Phillips Head SMS .42 / EA.
#8 x 2-1/8" Oval Phillips Head SMS .44 / EA.
#8 x 1-5/8" TORX 1.80 / EA.
#8 x 1-3/4" TORX 1.95 / EA.
L-700, L-A700, L-75 #8 x 3/4" Phillips Head TEK .38 / EA.
L-VGLF series #8 x 1" Phillips Oval TEK .42 / EA.
#8 x 1/2" hex washer TEK .45 / EA.
Round Lite Kits
Replacement Fasteners
Round Lite Kits
Replacement Fasteners
37
Phone: 800-647-7874
Fax: 800-255-7874
www.ngp.com
orders@ngp.com
Phone: 800-647-7874
Fax: 800-255-7874
www.ngp.com
orders@ngp.com
W I D T H
6 8 10 12 14 16 18 20 22 24 26 28 30 32 34 36
4 63 68 72 73 75 76 82 86 91 93 97 105 110 119 122 125
6 68 72 73 75 76 82 86 91 93 97 105 110 119 122 125 136
8 72 73 75 75 82 86 91 93 97 105 110 119 122 125 136 143
10 73 75 76 82 86 91 93 97 105 110 119 122 125 136 143 156
12 75 76 82 68 91 92 82 105 110 95 122 125 136 143 156 168
14 76 82 86 91 93 97 105 110 119 122 125 136 143 156 168 177
16 82 86 91 93 97 104 110 119 122 125 136 143 156 168 177 200
18 86 91 93 95 105 110 96 122 125 109 143 156 168 177 200 208
20 91 93 97 105 110 119 122 125 136 143 156 168 177 200 208 224
22 93 97 105 110 119 122 125 136 143 156 168 177 200 208 224 235
24 97 105 110 119 122 125 134 143 156 133 177 200 208 224 235 252
26 105 110 119 122 125 136 143 156 168 177 200 208 224 235 252 272
28 110 119 122 125 136 143 156 168 177 200 208 224 235 252 272 289
30 119 122 125 136 143 156 168 177 200 208 224 235 252 272 289 305
32 122 125 136 143 156 168 177 200 208 224 235 252 272 289 305 321
34 125 136 143 156 168 177 200 208 224 235 252 272 289 305 321 336
36 136 143 156 168 177 200 208 224 235 252 272 289 305 321 336 354
38 146 158 173 180 205 214 227 240 260 277 293 313 326 343 363 375
40 158 173 180 205 214 227 240 260 277 293 313 326 343 363 375 390
42 173 180 205 214 227 240 260 277 293 313 326 343 363 375 390 403
44 180 205 214 227 240 260 277 293 313 326 343 363 375 390 403 414
46 205 214 227 240 260 277 293 313 326 343 363 375 390 403 414 428
48 214 227 240 260 277 293 313 326 343 363 375 390 403 414 428 439
50 227 240 260 277 293 313 326 343 363 375 390 403 414 428 439 453
52 240 260 277 293 313 326 343 363 375 390 403 414 428 439 453 466
54 260 277 293 313 326 343 363 375 390 403 414 428 439 453 466 478
56 277 293 313 326 343 363 375 390 403 414 428 439 453 466 478 489
58 293 313 326 343 363 375 390 403 414 428 439 453 466 478 489 499
60 313 326 343 363 375 390 403 414 428 379 453 466 478 489 499 513
62 326 343 363 375 390 403 414 428 439 453 466 478 489 499 513 585
64 343 363 375 390 403 414 428 439 453 441 478 489 499 513 585 603
66 363 375 390 403 414 428 439 443 466 453 486 499 513 585 603 629
68 375 390 403 414 428 439 453 466 478 489 499 513 585 603 629 659
70 390 403 414 428 439 453 466 478 489 499 513 585 603 629 659 733
72 403 414 428 439 453 466 478 489 499 513 585 603 629 659 733 770
HEIGHT
L-700-RX, L-700-RX-TB, L-700-A, L-700-B, L-700-BF, L-700-C
Steel Louvers
Non-removable aluminum insect screen - Add $12 per square foot.
Torx Security Screws - up to 24" x 24" add $12, over 24" x 24" add $24
Minimum 6" width x 4" height; maximum 88” width or height
Odd inch and fractional sizes, use next largest even size
Thru Bolts (TB) - no extra charge
Auxiliary inside frame for L-700-BF $40
Gray Primer (GPZ) nish standard and will be provided unless one of the following optional nishes is indicated:
Available at no extra charge: (T) Tan (DKB) Dark Bronze (BPR) Beige Primer (matches Steelcraft)
(CAB) California Bronze (matches Anemostat) (PTY) Putty (matches Anemostat beige)
Add 15% for following nishes:
(B) Brass (Gold) (GBL) Gloss Black (W) White
(MBL) Matte Black (TBL) Textured Black (ASL) Aluminum Silver
(WB) Walnut Brown (matches Timely Browntone)
(MW) Magnolia White (matches Timely Western White)
Galvanneal - Add 20% Zinc EL-Plate - Add $400
L-700-RX, L-700-RX-TB, L-700-A, L-700-B, L-700-BF, L-700-C Steel Louvers
38
NATIONAL GUARD PRODUCTS, INC.Phone: 800-647-7874
Fax: 800-255-7874
www.ngp.com
orders@ngp.com
HEIGHT
L-A700-A, L-A700-B, L-A700-BF, L-A700-C
Aluminum Louvers
W I D T H
6 8 10 12 14 16 18 20 22 24 26 28 30 32 34 36
6 203 203 203 205 211 218 220 232 243 244 255 261 280 290 307 334
8 203 203 205 211 218 220 232 243 244 255 261 280 290 307 334 350
10 203 205 211 218 220 232 243 244 255 261 280 290 307 334 350 382
12 205 211 218 220 232 243 244 255 261 280 290 307 334 350 382 424
14 211 218 220 232 243 244 255 261 280 290 307 334 350 382 424 428
16 218 220 232 243 244 255 261 280 290 307 334 350 382 424 428 484
18 220 232 243 244 255 261 280 290 307 334 350 382 424 428 484 515
20 232 243 244 255 261 280 290 307 334 350 382 424 428 484 515 547
22 243 244 255 261 280 290 307 334 350 382 424 428 484 515 547 576
24 244 255 261 280 290 307 334 350 382 400 428 484 515 547 576 630
26 255 261 280 290 307 334 350 382 424 428 484 515 547 576 630 664
28 261 280 290 307 334 350 382 424 428 484 515 547 576 630 664 709
30 280 290 307 334 350 382 424 428 484 515 547 576 630 664 709 747
32 290 307 334 350 382 424 428 484 515 547 576 630 664 709 747 789
34 307 334 350 382 424 428 484 515 547 576 630 664 709 747 789 839
36 334 350 382 424 428 484 515 547 576 630 664 709 747 789 839 879
38 350 382 424 428 484 515 547 576 630 664 709 747 789 839 879 920
40 382 424 428 484 515 547 576 630 664 709 747 789 839 879 920 952
42 424 428 484 515 547 576 630 664 709 747 789 839 879 920 952 979
44 428 484 515 547 576 630 664 709 747 789 839 879 920 952 979 1014
46 484 515 547 576 630 664 709 747 789 839 879 920 952 979 1014 1045
48 515 547 576 630 664 709 747 789 839 879 920 952 979 1014 1045 1070
50 547 576 630 664 709 747 789 839 879 920 952 979 1014 1045 1070 1100
52 576 630 664 709 747 789 839 879 920 952 979 1014 1045 1070 1100 1141
54 630 664 709 747 789 839 879 920 952 979 1014 1045 1070 1100 1141 1165
56 664 709 747 789 839 879 920 952 979 1014 1045 1070 1100 1141 1165 1194
58 709 747 789 839 879 920 952 979 1014 1045 1070 1100 1141 1165 1194 1223
60 747 789 839 879 920 952 979 1014 1045 1070 1100 1141 1165 1194 1223 1248
62 789 839 879 920 952 979 1014 1045 1070 1100 1141 1165 1194 1223 1248 1427
64 839 879 920 952 979 1014 1045 1070 1100 1141 1165 1194 1223 1248 1427 1477
66 879 920 952 979 1014 1045 1070 1100 1141 1165 1194 1223 1248 1427 1477 1555
68 920 952 979 1014 1045 1070 1100 1141 1165 1194 1223 1248 1427 1477 1555 1630
70 952 979 1014 1045 1070 1100 1141 1165 1194 1223 1248 1427 1477 1555 1630 1818
72 979 1014 1045 1070 1100 1141 1165 1194 1223 1248 1427 1477 1555 1630 1818 1949
Non-removable aluminum insect screen - add $12 per square foot.
Torx Security Screws - up to 24" x 24" add $12, over 24" x 24" add $24
Minimum 6" width or height; maximum 88” width or height
Odd inch and fractional sizes, use next largest even size
Thru-bolts (TB) no extra charge.
Auxiliary inside frame for L-A700-BF $80
Aluminum material - Aluminum Silver (ASL) nish standard and will be provided unless one of the following optional nishes
is indicated:
Available at no extra charge:
(T) Tan (BPR) Beige Primer (matches Steelcraft)
(DKB) Dark Bronze (PTY) Putty (matches Anemostat Beige)
(GPZ) Gray Primer (CAB) California Bronze (matches Anemostat)
Add 15% for following nishes:
(GBL) Gloss Black (MBL) Matte Black
(B) Brass (Gold) (TBL) Textured Black
(W) White
(MW) Magnolia White (matches Timely Western White)
(WB) Walnut Brown (matches Timely Browntone)
L-A700-A, L-A700-B, L-A700-BF, L-A700-C Aluminum Louvers
39
Phone: 800-647-7874
Fax: 800-255-7874
www.ngp.com
orders@ngp.com
Phone: 800-647-7874
Fax: 800-255-7874
www.ngp.com
orders@ngp.com
L-1800 Adjustable Blade Louver
L-1900 Fire-rated Fusible Link Louver
W I D T H
10 12 14 16 18 20 22 24
6 220 225 235 242 250 264 268 275
8 225 235 242 250 264 268 275 287
10 235 242 250 264 268 275 287 290
12 242 201 264 268 219 287 290 238
14 249 276 280 287 292 297 300 305
16 276 287 299 304 308 323 330 337
18 287 299 304 308 252 330 337 342
20 299 304 308 333 335 337 342 345
22 304 308 333 337 342 345 349 352
24 308 333 337 342 349 350 352 281
26 333 342 350 352 363 371 379 388
28 342 352 363 371 379 388 397 406
30 352 371 379 388 397 406 415 425
HEIGHT
Non-removable aluminum insect screen - add $12 per square foot.
Torx Security Screws - up to 24" x 24" add $12.
Minimum size 10" width x 6" height; maximum 24" width x 30” height
Odd inch sizes, use next largest even size. Fractional sizes not available.
L-1900, L-1800 Fire-rated Fusible Link Louver
Gray Primer (GPZ) nish standard and will be provided unless one of the following optional nishes is indicated:
Available at no extra charge: (T) Tan (DKB) Dark Bronze (BPR) Beige Primer (matches Steelcraft)
(CAB) California Bronze (matches Anemostat) (PTY) Putty (matches Anemostat beige)
Add 15% for following nishes:
(B) Brass (Gold) (GBL) Gloss Black (W) White
(MBL) Matte Black (TBL) Textured Black (ASL) Aluminum Silver
(WB) Walnut Brown (matches Timely Browntone)
(MW) Magnolia White (matches Timely Western White)
Galvanneal - Add 20%
Replacement Fusible Links $20
40
NATIONAL GUARD PRODUCTS, INC.Phone: 800-647-7874
Fax: 800-255-7874
www.ngp.com
orders@ngp.com
HEIGHT
L-VRSG-2, L-VRSG-2-TB
Louvers with Security Grille
W I D T H
6 8 10 12 14 16 18 20 22 24 26 28 30 32 34 36
4 121 122 130 134 144 149 155 158 168 175 176 179 186 195 207 219
6 122 130 134 144 149 155 158 166 175 176 179 186 195 207 219 242
8 130 134 144 149 155 158 166 175 176 179 186 195 207 219 242 261
10 134 144 149 155 158 166 175 176 179 186 195 207 219 242 261 270
12 144 149 155 155 166 175 174 179 186 190 207 219 242 261 270 272
14 149 155 158 166 175 176 179 186 195 207 219 242 261 270 272 310
16 155 158 166 175 176 179 186 195 207 219 242 261 270 272 310 340
18 158 166 175 176 179 186 190 207 219 242 261 270 272 310 340 357
20 166 175 176 179 186 195 207 219 242 261 270 272 310 340 357 392
22 175 176 179 186 195 207 219 242 261 270 272 310 340 357 392 415
24 176 179 186 195 207 219 242 261 270 272 310 340 357 392 415 447
26 179 186 195 207 219 242 261 270 272 310 340 357 392 415 447 466
28 186 195 207 219 242 261 270 272 310 340 357 392 415 447 466 490
30 195 207 219 242 261 270 272 310 340 357 392 415 447 466 490 522
32 207 219 242 261 270 272 310 340 357 392 415 447 466 490 522 547
34 219 242 261 270 272 310 340 357 392 415 447 466 490 522 547 576
36 242 261 270 272 310 340 357 392 415 447 466 490 522 547 576 598
38 261 270 272 310 340 357 392 415 447 466 490 522 547 576 598 616
40 270 272 310 340 357 392 415 447 466 490 522 547 576 598 616 636
42 272 310 340 357 392 415 447 466 490 522 547 576 598 616 636 653
44 310 340 357 392 415 447 466 490 522 547 576 598 616 636 653 663
46 340 357 392 415 447 466 490 522 547 576 598 616 636 653 663 693
48 357 392 415 447 466 490 522 547 576 598 616 636 653 663 693 712
50 392 415 447 466 490 522 547 576 598 616 636 653 663 693 712 717
52 415 447 466 490 522 547 576 598 616 636 653 663 693 712 717 726
54 447 466 490 522 547 576 598 616 636 653 663 693 712 717 726 734
56 466 490 522 547 576 598 616 636 653 663 693 712 717 726 734 750
58 490 522 547 576 598 616 636 653 663 693 712 717 726 734 750 814
60 522 547 576 598 616 636 653 663 693 712 717 726 734 750 814 838
62 547 576 598 616 636 653 663 693 712 717 726 734 750 814 838 859
64 576 598 616 636 653 663 693 712 717 726 734 750 814 838 859 891
66 598 616 636 653 663 693 712 717 726 734 750 814 838 859 891 897
68 616 636 653 663 693 712 717 726 734 750 814 838 859 891 897 920
70 636 653 663 693 712 717 726 734 750 814 838 859 891 897 920 938
72 653 663 693 712 717 726 734 750 814 838 859 891 897 920 938 960
Non-removable aluminum insect screen - Add $12 per square foot.
Torx Security Screws - up to 24" x 24" add $12, over 24" x 24" add $24
Minimum 6" width x 4" height; maximum 48" width x 88” height
Odd inch and fractional sizes, use next largest even size
Gray Primer (GPZ) nish standard and will be provided unless one of the following optional nishes is indicated:
Available at no extra charge: (T) Tan (DKB) Dark Bronze (BPR) Beige Primer (matches Steelcraft)
(CAB) California Bronze (matches Anemostat) (PTY) Putty (matches Anemostat beige)
Add 15% for following nishes:
(B) Brass (Gold) (GBL) Gloss Black (W) White
(MBL) Matte Black (TBL) Textured Black (ASL) Aluminum Silver
(WB) Walnut Brown (matches Timely Browntone)
(MW) Magnolia White (matches Timely Western White)
Galvanneal - Add 20%
Zinc EL-Plate -Add $400
L-VRSG-2, L-VRSG-2-TB Louvers with Security Grille
41
Phone: 800-647-7874
Fax: 800-255-7874
www.ngp.com
orders@ngp.com
Phone: 800-647-7874
Fax: 800-255-7874
www.ngp.com
orders@ngp.com
HEIGHT
W I D T H
6 8 10 12 14 16 18 20 22 24 26 28 30 32 34 36
4 133 137 139 143 158 161 171 175 180 198 201 209 223 236 253 263
6 137 139 143 158 161 171 175 180 198 201 209 223 236 253 263 289
8 139 143 157 161 171 175 180 198 201 209 223 236 253 263 289 308
10 143 158 161 171 175 180 198 201 209 223 236 253 263 289 308 321
12 158 161 171 171 180 198 196 209 223 230 253 263 289 308 321 368
14 161 171 175 180 198 201 209 223 236 253 263 289 308 321 368 383
16 171 175 180 198 201 209 223 236 253 263 289 308 321 368 383 412
18 175 180 198 201 209 223 230 253 263 286 308 321 368 383 412 432
20 180 198 201 209 223 236 253 263 289 308 321 368 383 412 432 469
22 198 201 209 223 236 253 263 289 308 321 368 383 412 432 469 500
24 201 209 223 236 253 263 289 308 321 368 383 412 432 469 500 527
26 209 223 236 253 263 289 308 321 368 383 412 432 469 500 527 556
28 223 236 253 263 289 308 321 368 383 412 432 469 500 527 556 608
30 236 253 263 289 308 321 368 383 412 432 469 500 527 556 608 617
32 253 263 289 308 321 368 383 412 432 469 500 527 556 608 617 648
34 263 289 308 321 368 383 412 432 469 500 527 556 608 617 648 677
36 289 308 321 368 383 412 432 469 500 527 556 608 617 648 677 705
38 308 321 368 383 412 432 469 500 527 556 608 617 648 677 705 726
40 321 368 383 412 432 469 500 527 556 608 617 648 677 705 726 750
42 368 383 412 432 469 500 527 556 608 617 648 677 705 726 750 768
44 383 412 432 469 500 527 556 608 617 648 677 705 726 750 768 781
46 412 432 469 500 527 556 608 617 648 677 705 726 750 768 781 813
48 432 469 500 527 556 608 617 648 677 705 726 750 768 781 813 853
50 469 500 527 556 608 617 648 677 705 726 750 768 781 813 853 867
52 500 527 556 608 617 648 677 705 726 750 768 781 813 853 867 876
54 527 556 608 617 648 677 705 726 750 768 781 813 853 867 876 896
56 556 608 617 648 677 705 726 750 768 781 813 853 867 876 896 919
58 608 617 648 677 705 726 750 768 781 813 853 867 876 896 919 1051
60 617 648 677 705 726 750 768 781 813 853 867 876 896 919 1051 1080
62 648 677 705 726 750 768 781 813 853 867 876 896 919 1051 1080 1137
64 677 705 726 750 768 781 813 853 867 876 896 919 1051 1080 1137 1179
66 705 726 750 768 781 813 853 867 876 896 919 1051 1080 1137 1179 1192
68 726 750 768 781 813 853 867 876 896 919 1051 1080 1137 1179 1192 1219
70 750 768 781 813 853 867 876 896 919 1051 1080 1137 1179 1192 1219 1245
72 768 781 813 853 867 876 896 919 1051 1080 1137 1179 1192 1219 1245 1283
L-VRSG-3, L-VRSG-3-TB
Louvers with Security Grille both Sides
Non-removable aluminum insect screen - Add $12 per square foot
Torx Security Screws - up to 24" x 24" add $12, over 24" x 24" add $24
Minimum 6" width x 4" height; maximum 48" width x 88” height
Odd inch and fractional sizes, use next largest even size
Gray Primer (GPZ) nish standard and will be provided unless one of the following optional nishes is indicated:
Available at no extra charge: (T) Tan (DKB) Dark Bronze (BPR) Beige Primer (matches Steelcraft)
(CAB) California Bronze (matches Anemostat) (PTY) Putty (matches Anemostat beige)
Add 15% for following nishes:
(B) Brass (Gold) (GBL) Gloss Black (W) White (MBL)
Matte Black (TBL) Textured Black (ASL) Aluminum Silver
(WB) Walnut Brown (matches Timely Browntone)
(MW) Magnolia White (matches Timely Western White)
Galvanneal - Add 20%
Zinc EL-Plate - Add $400
L-VRSG-3, L-VRSG-3-TB Louvers with Security Grille both Sides
42
NATIONAL GUARD PRODUCTS, INC.Phone: 800-647-7874
Fax: 800-255-7874
www.ngp.com
orders@ngp.com
HEIGHT
W I D T H
6 8 10 12 14 16 18 20 22 24 26 28 30 32 34 36
4 229 229 229 229 235 239 247 251 266 280 333 363 399 408 472 523
6 229 229 229 235 239 247 251 266 280 333 363 399 408 472 523 556
8 229 229 235 239 247 251 266 280 333 363 399 408 472 523 556 655
10 229 235 239 247 251 266 280 333 363 399 408 472 523 556 655 671
12 235 239 247 251 266 280 333 363 399 408 472 523 556 655 671 680
14 239 247 251 266 280 333 363 399 408 472 523 556 655 671 680 750
16 247 251 266 280 333 363 399 408 472 523 556 655 671 680 750 839
18 251 266 280 333 363 399 408 472 523 556 655 671 680 750 839 869
20 266 280 333 363 399 408 472 523 556 655 671 680 750 839 869 955
22 280 333 363 399 408 472 523 556 655 671 680 750 839 869 955 988
24 333 363 399 408 472 523 556 655 671 680 750 839 869 955 988 1044
26 363 399 408 472 523 556 655 671 680 750 839 869 955 988 1044 1102
28 399 408 472 523 556 655 671 680 750 839 869 955 988 1044 1102 1153
30 408 472 523 556 655 671 680 750 839 869 955 988 1044 1102 1153 1188
32 472 523 556 655 671 680 750 839 869 955 988 1044 1102 1153 1188 1244
34 523 556 655 671 680 750 839 869 955 988 1044 1102 1153 1188 1244 1295
36 556 655 671 680 750 839 869 955 988 1044 1102 1153 1188 1244 1295 1364
38 655 671 680 750 839 869 955 988 1044 1102 1153 1188 1244 1295 1364 1398
40 671 680 750 839 869 955 988 1044 1102 1153 1188 1244 1295 1364 1398 1461
42 680 750 839 869 955 988 1044 1102 1153 1188 1244 1295 1364 1398 1461 1525
44 750 839 869 955 988 1044 1102 1153 1188 1244 1295 1364 1398 1461 1525 1577
46 839 869 955 988 1044 1102 1153 1188 1244 1295 1364 1398 1461 1525 1577 1641
48 869 955 988 1044 1102 1153 1188 1244 1295 1364 1398 1461 1525 1577 1641 1685
50 955 988 1044 1102 1153 1188 1244 1295 1364 1398 1461 1525 1577 1641 1685 1757
52 988 1044 1102 1153 1188 1244 1295 1364 1398 1461 1525 1577 1641 1685 1757 1812
54 1044 1102 1153 1188 1244 1295 1364 1398 1461 1525 1577 1641 1685 1757 1812 1878
56 1102 1153 1188 1244 1295 1364 1398 1461 1525 1577 1641 1685 1757 1812 1878 1946
58 1153 1188 1244 1295 1364 1398 1461 1525 1577 1641 1685 1757 1812 1878 1946 2008
60 1188 1244 1295 1364 1398 1461 1525 1577 1641 1685 1757 1812 1878 1946 2008 2082
62 1244 1295 1364 1398 1461 1525 1577 1641 1685 1757 1812 1878 1946 2008 2082 2145
64 1295 1364 1398 1461 1525 1577 1641 1685 1757 1812 1878 1946 2008 2082 2145 2245
66 1364 1398 1461 1525 1577 1641 1685 1757 1812 1878 1946 2008 2082 2145 2245 2342
68 1398 1461 1525 1577 1641 1685 1757 1812 1878 1946 2008 2082 2145 2245 2342 2441
70 1461 1525 1577 1641 1685 1757 1812 1878 1946 2008 2082 2145 2245 2342 2441 2537
72 1525 1577 1641 1685 1757 1812 1878 1946 2008 2082 2145 2245 2342 2441 2537 2636
Textured Black (TBL) nish standard and will be provided unless one of the following optional nishes is indicated:
Available at no extra charge: (T) Tan (DKB) Dark Bronze (BPR) Beige Primer (matches Steelcraft)
(CAB) California Bronze (matches Anemostat) (PTY) Putty (matches Anemostat beige)
Add 15% for following nishes:
(B) Brass (Gold) (GBL) Gloss Black (W) White
(MBL) Matte Black (ASL) Aluminum Silver
(WB) Walnut Brown (matches Timely Browntone)
(MW) Magnolia White (matches Timely Western White)
Zinc EL-Plate - Add $400
L-75-A, L-75-B, L-75-BF
Darkroom Louvers
Non-removable aluminum insect screen - add $12 per square foot
Torx Security Screws - up to 24" x 24" add $12, over 24" x 24" add $24
Minimum 6" width x 4" height; maximum 88" width or height
Odd inch and fractional sizes, use next largest even size
Thru-bolts (TB) no extra charge
L-75-A, L-75-B, L-75-BF Darkroom Louvers
43
Phone: 800-647-7874
Fax: 800-255-7874
www.ngp.com
orders@ngp.com
Phone: 800-647-7874
Fax: 800-255-7874
www.ngp.com
orders@ngp.com
W I D T H
5 6 7 8 10 12 14 16 18 20 22 24 26 28 30 32 34 36
4 97 97 97 97 97 97 97 97 97 97 97 97 97 97 97 97 97 97
6 97 97 97 97 97 97 97 97 97 97 97 97 105 113 121 129 137 146
8 97 97 97 97 97 97 97 97 97 108 119 129 140 151 162 172 183 194
10 97 97 97 97 97 97 97 108 121 135 148 162 175 189 202 216 229 243
12 97 97 97 97 97 97 113 129 146 162 178 194 210 226 243 259 275 291
14 97 97 97 97 97 113 132 151 170 189 207 226 245 264 283 302 321 340
16 97 97 97 97 108 129 151 172 194 216 237 259 280 302 323 345 366 388
18 97 97 97 97 121 146 170 194 218 243 267 291 315 340 364 388 412 437
20 97 97 97 108 135 162 189 216 243 269 296 323 350 377 404 431 458 485
22 97 97 97 119 148 178 207 237 267 296 326 356 385 415 445 474 504 534
24 97 97 113 129 162 194 226 259 291 323 356 388 420 453 485 517 550 582
26 97 105 123 140 175 210 245 280 315 350 385 420 455 490 525 560 595 631
28 97 113 132 151 189 226 264 302 340 377 415 453 490 528 566 604 641 679
30 97 121 141 162 202 243 283 323 364 404 445 485 525 566 606 647 687 728
32 97 129 151 172 216 259 302 345 388 431 474 517 560 604 647 690 733 776
34 97 137 160 183 229 275 321 366 412 458 504 550 595 641 687 733 779 825
36 121 146 170 194 243 291 340 388 437 485 534 582 631 679 728 776 825 873
38 128 154 179 205 256 307 358 410 461 512 563 614 666 717 768 819 870 922
40 135 162 189 216 269 323 377 431 485 539 593 647 701 754 808 862 916 970
42 141 170 198 226 283 340 396 453 509 566 622 679 736 792 849 905 962 1019
44 148 178 207 237 296 356 415 474 534 593 652 711 771 830 889 948 1008 1067
46 155 186 217 248 310 372 434 496 558 620 682 744 806 868 930 992 1054 1116
48 162 194 226 259 323 388 453 517 582 647 711 776 841 905 970 1035 1099 1164
50 168 202 236 269 337 404 472 539 606 674 741 808 876 943 1010 1078 1145 1213
52 175 210 245 280 350 420 490 560 631 701 771 841 911 981 1051 1121 1191 1261
54 182 218 255 291 364 437 509 582 655 728 800 873 946 1019 1091 1164 1237 1310
56 189 226 264 302 377 453 528 604 679 754 830 905 981 1056 1132 1207 1283 1358
58 195 234 273 313 391 469 547 625 703 781 860 938 1016 1094 1172 1250 1328 1407
59 199 238 278 318 397 477 556 636 715 795 874 954 1033 1113 1192 1272 1351 1431
With GT-118 glazing tape supplied (loose) for both sides:
Add $4 per square foot to each piece of glass.
HEIGHT
SuperLite™ I-W
Safety Wired Glass
U.S. Patent No. 7,090,906
Meets CPSC 16CFR 1201 category II impact safety requirements
Etched with UL Fire-rating classication on each piece
Odd inch or fractional sizes, use next largest size
Under 3" or over 59" - call for quote
Full sheet = 57" x 100"
Glass for Round Lite Kits:
to t in kits 12" $ 450
18" $ 875
24" $ 1,100
SuperLite™ I-W Safety Wired Glass
44
NATIONAL GUARD PRODUCTS, INC.Phone: 800-647-7874
Fax: 800-255-7874
www.ngp.com
orders@ngp.com
Pyran® F
Meets CPSC 16CFR 1201 Cat. I & II impact safety requirements
Etched with UL re-rating classication on each piece.
Odd inch or fractional sizes, use next largest size
Under 3" - call for quote
Full sheet = 43” x 77”
W I D T H
5 6 7 8 10 12 14 16 18 20 22 24 26 28 30 32 34 36
4 172 172 172 172 172 172 172 172 172 172 172 172 172 172 172 172 172 172
6 172 172 172 172 172 172 172 172 172 172 172 172 186 201 215 229 244 258
8 172 172 172 172 172 172 172 172 172 191 210 229 248 268 287 306 325 344
10 172 172 172 172 172 172 172 191 215 239 263 287 311 334 358 382 406 430
12 172 172 172 172 172 172 201 229 258 287 315 344 373 401 430 459 487 516
14 172 172 172 172 172 201 234 268 301 334 368 401 435 468 502 535 569 602
16 172 172 172 172 191 229 268 306 344 382 420 459 497 535 573 612 650 688
18 172 172 172 172 215 258 301 344 387 430 473 516 559 602 645 688 731 774
20 172 172 172 191 239 287 334 382 430 478 526 573 621 669 717 764 812 860
22 172 172 172 210 263 315 368 420 473 526 578 631 683 736 788 841 893 946
24 172 172 201 229 287 344 401 459 516 573 631 688 745 803 860 917 975 1032
26 172 186 217 248 311 373 435 497 559 621 683 745 807 870 932 994 1056 1118
28 172 201 234 268 334 401 468 535 602 669 736 803 870 936 1003 1070 1137 1204
30 172 215 251 287 358 430 502 573 645 717 788 860 932 1003 1075 1147 1218 1290
32 172 229 268 306 382 459 535 612 688 764 841 917 994 1070 1147 1223 1300 1376
34 172 244 284 325 406 487 569 650 731 812 893 975 1056 1137 1218 1300 1381 1462
36 215 258 301 344 430 516 602 688 774 860 946 1032 1118 1204 1290 1376 1462 1548
38 227 272 318 363 454 545 635 726 817 908 999 1089 1180 1271 1362 1452 1543 1634
40 239 287 334 382 478 573 669 764 860 956 1051 1147 1242 1338 1433 1529 1624 1720
42 251 301 351 401 502 602 702 803 903 1003 1104 1204 1304 1405 1505 1605 1706 1806
44 263 315 368 420 526 631 736 841 946 1051 1156 1261 1366 1472 1577 1682 1787 1892
46 275 330 385 440 549 659 769 879 989 1099 1209 1319 1429 1538 1648 1758 1868 1978
48 287 344 401 459 573 688 803 917 1032 1147 1261 1376 1491 1605 1720 1835 1949 2064
50 299 358 418 478 597 717 836 956 1075 1194 1314 1433 1553 1672 1792 1911 2031 2150
52 311 373 435 497 621 745 870 994 1118 1242 1366 1491 1615 1739 1863 1988 2112 2236
54 323 387 452 516 645 774 903 1032 1161 1290 1419 1548 1677 1806 1935 2064 2193 2322
56 334 401 468 535 669 803 936 1070 1204 1338 1472 1605 1739 1873 2007 2140 2274 2408
58 346 416 485 554 693 831 970 1108 1247 1386 1524 1663 1801 1940 2078 2217 2355 2494
60 358 430 502 573 717 860 1003 1147 1290 1433 1577 1720 1863 2007 2150 2293 2437 2580
62 370 444 518 592 741 889 1037 1185 1333 1481 1629 1777 1925 2074 2222 2370 2518 2666
64 382 459 535 612 764 917 1070 1223 1376 1529 1682 1835 1988 2140 2293 2446 2599 2752
66 394 473 552 631 788 946 1104 1261 1419 1577 1734 1892 2050 2207 2365 2523 2680 2838
68 406 487 569 650 812 975 1137 1300 1462 1624 1787 1949 2112 2274 2437 2599 2762 2924
70 418 502 585 669 836 1003 1171 1338 1505 1672 1839 2007 2174 2341 2508 2676 2843 3010
72 430 516 602 688 860 1032 1204 1376 1548 1720 1892 2064 2236 2408 2580 2752 2924 3096
74 442 530 619 707 884 1061 1237 1414 1591 1768 1945 2121 2298 2475 2652 2828 3005 3182
76 454 545 635 726 908 1089 1271 1452 1634 1816 1997 2179 2360 2542 2723 2905 3086 3268
77 460 552 644 736 920 1104 1288 1472 1656 1839 2023 2207 2391 2575 2759 2943 3127 3311
Pyran® F
HEIGHT
With GT-118 glazing tape supplied (loose) for both sides: Add $4 per square foot to each piece of glass.
Glass for Round Lite Kits:
to t in kits 12” $ 750
18” 1,450
24” 1,800
45
Phone: 800-647-7874
Fax: 800-255-7874
www.ngp.com
orders@ngp.com
Phone: 800-647-7874
Fax: 800-255-7874
www.ngp.com
orders@ngp.com
Pyran® L, Superlite™ I-20, Superlite™ X-90,
Superlite™ II-XL Glass
Pyran® L, Superlite™ I-20, Superlite™ X-90, Superlite™ II-XL Glass
Pyran® L
3/8" Thick Call for quote
Full sheet = 43" x 77"
GT-118 glazing tape supplied (loose) for both sides:
Add $4 per Sq. FT.
SuperLite™ X-90 L-FRA-100 SP w/Superlite X90 & Glazing Tape
3/4" Thick Available Lite Kit Sizes
12" x 12" $75 Net
$60 ea. Net 6" x 27" $80 Net
7" x 22" $80 Net
Available Sizes
5" x 35" $85 Net
11" x 11"
4" x 34"
5" x 26"
6" x 21"
GT-118 glazing tape supplied (loose) for both sides:
Add $4 per Sq. FT.
SuperLite™ I-20
1/4" Thick Call for quote
GT-118 glazing tape supplied (loose) for both sides:
Add $4 per Sq. FT.
SuperLite™ II-XL
45 Minute 3/4" Thick Call for quote
60 Minute 1 1/8" Thick
90 Minute 1 1/2" Thick
GT-118 glazing tape supplied (loose) for both sides:
Add $4 per Sq. FT.
46
NATIONAL GUARD PRODUCTS, INC.Phone: 800-647-7874
Fax: 800-255-7874
www.ngp.com
orders@ngp.com
W I D T H
5 6 7 8 10 12 14 16 18 20 22 24 26 28 30 32 34 36
4 41 41 41 41 41 41 41 41 41 41 41 41 41 41 41 41 41 41
6 41 41 41 41 41 41 41 41 41 41 41 41 44 48 51 55 58 62
8 41 41 41 41 41 41 41 41 41 46 50 55 59 64 68 73 77 82
10 41 41 41 41 41 41 41 46 51 57 63 68 74 80 85 91 97 103
12 41 41 41 41 41 41 48 55 62 68 75 82 89 96 103 109 116 123
14 41 41 41 41 41 48 56 64 72 80 88 96 104 112 120 128 136 144
16 41 41 41 41 46 55 64 73 82 91 100 109 118 128 137 146 155 164
18 41 41 41 41 51 62 72 82 92 103 113 123 133 144 154 164 174 185
20 41 41 41 46 57 68 80 91 103 114 125 137 148 159 171 182 194 205
22 41 41 41 50 63 75 88 100 113 125 138 150 163 175 188 200 213 226
24 41 41 48 55 68 82 96 109 123 137 150 164 178 191 205 219 232 246
26 41 44 52 59 74 89 104 118 133 148 163 178 192 207 222 237 252 267
28 41 48 56 64 80 96 112 128 144 159 175 191 207 223 239 255 271 287
30 41 51 60 68 85 103 120 137 154 171 188 205 222 239 256 273 290 308
32 41 55 64 73 91 109 128 146 164 182 200 219 237 255 273 292 310 328
34 41 58 68 77 97 116 136 155 174 194 213 232 252 271 290 310 329 349
36 51 62 72 82 103 123 144 164 185 205 226 246 267 287 308 328 349 369
38 54 65 76 87 108 130 151 173 195 216 238 260 281 303 325 346 368 390
40 57 68 80 91 114 137 159 182 205 228 251 273 296 319 342 364 387 410
42 60 72 84 96 120 144 167 191 215 239 263 287 311 335 359 383 407 431
44 63 75 88 100 125 150 175 200 226 251 276 301 326 351 376 401 426 451
46 65 79 92 105 131 157 183 210 236 262 288 314 341 367 393 419 445 472
48 68 82 96 109 137 164 191 219 246 273 301 328 355 383 410 437 465 492
50 71 85 100 114 142 171 199 228 256 285 313 342 370 399 427 456 484 513
52 74 89 104 118 148 178 207 237 267 296 326 355 385 415 444 474 503 533
54 77 92 108 123 154 185 215 246 277 308 338 369 400 431 461 492 523 554
56 80 96 112 128 159 191 223 255 287 319 351 383 415 446 478 510 542 574
58 83 99 116 132 165 198 231 264 297 330 363 396 429 462 495 528 561 595
59 84 101 118 134 168 202 235 269 302 336 370 403 437 470 504 538 571 605
With GT-118 glazing tape supplied (loose) for both sides:
Add $4 per square foot to each piece of glass
With GT-9800 intumescent glazing tape supplied (loose) for both sides:
Add $16 per square foot to each piece of glass
HEIGHT
1/4" Wired Glass - Diamond
Etched with UL Fire-rating classication on each piece up to 1,296 sq. inches visible area - 54" max. width or height
Odd inch or fractional sizes, use next largest size
Under 3" or over 59" - call for quote
Full sheet = 48" x 100"
Glass for Round Lite Kits:
to t in kits 12" $165
18" $315
24" $420
1/4" Wired Glass- Diamond
Does NOT comply with IBC 2006 or newer requirements for use in doors
or sidelights. Allowed only in non-hazardous locations dened in IBC
47
Phone: 800-647-7874
Fax: 800-255-7874
www.ngp.com
orders@ngp.com
Phone: 800-647-7874
Fax: 800-255-7874
www.ngp.com
orders@ngp.com
Tempered Glass - 1/4"
TEMPERED GLASS - 1/4''
Meets CPSC 16CFR 1201 Cat. I & II impact safety requirements
Minimum 11” height. Full sheet = 84" x 144"
Odd inch or fractional sizes, use next largest size
W I D T H
6 8 10 12 14 16 18 20 22 24 26 28 30 32 34 36
12 41 41 41 41 41 41 41 41 41 41 46 46 46 46 46 46
14 41 41 41 41 41 41 41 41 46 46 46 46 46 62 62 62
16 41 41 41 41 41 41 41 46 46 46 46 62 62 62 62 62
18 41 41 41 41 41 41 46 46 46 46 62 62 62 62 77 77
20 41 41 41 41 41 46 46 46 62 62 62 62 77 77 77 77
22 41 41 41 41 46 46 46 62 62 62 62 77 77 77 93 93
24 41 41 41 41 46 46 46 62 62 62 77 77 77 93 93 93
26 41 41 41 46 46 46 62 62 62 77 77 93 93 93 108 108
28 41 41 41 46 46 62 62 62 77 77 93 93 93 108 108 108
30 41 41 46 46 46 62 62 77 77 77 93 93 108 108 124 124
32 41 41 46 46 62 62 62 77 77 93 93 108 108 124 124 124
34 41 41 46 46 62 62 77 77 93 93 108 108 124 124 139 139
36 41 41 46 46 62 62 77 77 93 93 108 108 124 124 139 139
38 41 46 46 62 62 77 77 93 93 108 108 124 124 139 139 155
40 41 46 46 62 62 77 77 93 108 108 124 124 139 139 155 155
42 41 46 46 62 77 77 93 93 108 108 124 139 139 155 155 170
44 41 46 62 62 77 77 93 108 108 124 124 139 155 155 170 170
46 41 46 62 62 77 93 93 108 124 124 139 139 155 170 170 185
48 41 46 62 62 77 93 93 108 124 124 139 155 155 170 185 185
50 46 46 62 77 77 93 108 108 124 139 155 155 170 185 185 201
52 46 46 62 77 93 93 108 124 124 139 155 170 170 185 201 201
54 46 46 62 77 93 93 108 124 139 139 155 170 185 185 201 216
56 46 62 62 77 93 108 108 124 139 155 170 170 185 201 216 216
58 46 62 77 77 93 108 124 139 139 155 170 185 201 201 216 232
60 46 62 77 77 93 108 124 139 155 155 170 185 201 216 232 232
62 46 62 77 93 108 108 124 139 155 170 185 201 201 216 232 247
64 46 62 77 93 108 124 124 139 155 170 185 201 216 232 247 247
66 46 62 77 93 108 124 139 155 170 170 185 201 216 232 247 263
68 46 62 77 93 108 124 139 155 170 185 201 216 232 247 263 263
70 46 62 77 93 108 124 139 155 170 185 201 216 232 247 263 278
72 46 62 77 93 108 124 139 155 170 185 201 216 232 247 263 278
With GT-118 glazing tape supplied (loose) for both sides: Add $4 per square foot to each piece of glass.
Glass for Round Lite Kits:
to t in kits 12” $165
18” 315
24” 420
HEIGHT
48
NATIONAL GUARD PRODUCTS, INC.Phone: 800-647-7874
Fax: 800-255-7874
www.ngp.com
orders@ngp.com
Insulated Tempered, Polycarbonate Glass, Glazing Tape
Insulated Tempered, Polycarbonate Glass,
Glazing Tape & Accessories
Prices per Sq. FT. on this page apply to each piece of glass, rounded up to the next whole foot.
Insulated Tempered Glass - 1" Thick
Each Piece:
1-5 Sq. Feet $155/EA.
6 or more Sq. Ft. $34 per Sq. FT
Minimum height = 11"
Full sheet = 84" x 144"
Polycarbonate - 1/4" Thick
Each Piece:
All Sizes $64 per Sq. FT.
Full sheet = 48" x 96"
For round Lite Kits:
to t in 12" $160
18" 360
24" 640
Polycarbonate - 1/2" Thick
Each Piece:
All Sizes $94 per Sq. FT.
Full Sheet = 48" x 96"
With GT-118 Glazing Tape supplied both sides
Add $4 per Sq. FT.
Packaged with Lite Kit - Use glass pricing with
glazing tape, plus lite kit
With GT-118 Glazing Tape supplied both sides
Add $4 per Sq. FT.
Packaged with Lite Kit - Use glass pricing with
glazing tape, plus lite kit
With GT-118 Glazing Tape supplied both sides
Add $4 per Sq. FT.
Packaged with Lite Kit (L-FRA100-SP or
L-GLF100-SP - for 1-3/4" door with 1/2" glass) -
Use glass pricing with glazing tape, plus lite kit
Butyl Rubber Glazing Tape
GT-16 3/8" wide x 1/16" thick $24 /50’ roll
Accessories
L-Clips $2.75/ EA.
Touch-up spray paint - 12 oz. cans* $36 / EA.
Colors: BPR, CAB, DKB, GPZ, MW, PTY, T, WB
*Ground Shipments to Continental US only.
Closed cell PVC foam Glazing Tape
GT-116 3/8" wide x 1/16" thick $74 /200' roll
GT-118 3/8" wide x 1/8" thick $50 /100' roll
GT-132 3/8" wide x 1/32" thick $73 /200' roll
Intumescent Glazing Tape
GT-9800 1/2" x 1/16" thick $2.00/ FT.
Glazing Tape and Accessories
Door Edges Astragals
540 541 550, 552, 551, 553,
542 543 560, 562, 555, 561,
Door 545 570, 572, 574 563
Height Ea. Set Ea. Set
6'8" 64 90 74 107
7'0" 66 93 76 107
8'0" 76 106 87 123
9'0" 85 120 98 138
10'0" 95 133 109 153
Stainless Steel, #4 Brushed Finish
Door Edges Astragals
540SS 541SS 550SS, 552SS, 551SS, 553SS,
542SS 543SS, 545SS 560SS, 562SS, 555SS, 561SS
570SS, 572SS, 563SS
Door 574SS
Height EA. Set EA. Set
6'8" 161 226 184 268
7'0" 166 231 189 268
8'0" 190 264 216 306
9'0" 214 297 243 344
10'0" 237 330 270 383
Door Aligning Astragals
565, 575 565SS, 575SS
9" Height EA. EA.
Blank 30 75
ASA 49 94
FB 49 94
T 49 94
49
Phone: 800-647-7874
Fax: 800-255-7874
www.ngp.com
orders@ngp.com
Phone: 800-647-7874
Fax: 800-255-7874
www.ngp.com
orders@ngp.com
Insulated Tempered, Polycarbonate Glass,
Glazing Tape & Accessories
Options:
Special door thicknesses - 1-3/8", 2", 2-1/4" Add $20 per set
Hardware Preps: Lock faces, strikes, ush bolts Add $19 per cut out
Zinc Electroplating Add $400
Galvanneal Add 20%
Lead lined Add $25/ Ft.
Torx Security screws #8 x 3/4" Add $1.70/ Ft.
Finishes other than Tan, DKB, GPZ, BPR, CAB, PTY Add 15%
Door Edges and Astragals
Door Edges and Astragals
50
NATIONAL GUARD PRODUCTS, INC.Phone: 800-647-7874
Fax: 800-255-7874
www.ngp.com
orders@ngp.com
TERMS AND CONDITIONS
1. Limited Warranty; Limitation of Remedy and Damages. Subject to the limitations of liability set forth below,
NGP warrants for a period of ve (5) years from date of delivery (the “Warranty Period”), that the products provided
by NGP hereunder (the “Products”) (i) shall conform substantially to the specications provided to NGP, if any, so
long as the Products have been properly installed; and (ii) shall conform substantially to the specications provided
by NGP, and (iii) are free from defects in workmanship and materials.
THIS IS THE SOLE AND EXCLUSIVE WARRANTY GIVEN BY NGP WITH RESPECT TO THE PRODUCTS AND
IS IN LIEU OF ANY AND ALL OTHER WARRANTIES, EXPRESS OR IMPLIED, ARISING BY OPERATION OF
LAW OR OTHERWISE. NGP HEREBY DISCLAIMS AND EXCLUDES ALL IMPLIED WARRANTIES, INCLUDING
BUT NOT LIMITED TO THE WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR
PURPOSE.
This warranty does not cover, and NGP will not be liable for, defects or damage arising from improper installation,
modication, lack of or improper maintenance, improper storage, shipping and handling, ordinary wear and tear,
misuse, abuse, accident, unauthorized service, use with unauthorized products or parts, or improper product selec-
tion or specication.
The sole and exclusive liability of NGP under this warranty or otherwise shall be limited to the repair or replace-
ment of any Product or component part which shall prove defective to the original purchaser from NGP here-
under (the "Purchaser"), and shall not extend to dismantling, installing or reinstalling (or payment for the cost of
the same). NGP will not pay for the costs of repair or replacement performed other than in accordance with this
warranty. NGP SHALL NOT BE LIABLE FOR DAMAGES CAUSED BY DELAY IN PERFORMANCE AND IN
NO EVENT, REGARDLESS OF THE FORM OF THE CLAIM OR CAUSE OF ACTION (WHETHER BASED IN
CONTRACT, INFRINGEMENT, NEGLIGENCE, STRICT LIABILITY, TORT OR OTHERWISE), SHALL NGP'S
LIABILITY TO PURCHASER AND/OR ITS CUSTOMERS EXCEED THE PRICE PAID BY PURCHASER FOR THE
SPECIFIC PRODUCTS GIVING RISE TO THE CLAIM OR CAUSE OF ACTION. PURCHASER AGREES THAT
IN NO EVENT SHALL NGP'S LIABILITY TO PURCHASER AND/OR ITS CUSTOMERS EXTEND TO INCLUDE
INCIDENTAL, CONSEQUENTIAL OR PUNITIVE DAMAGES RESULTING FROM USE OF THE PRODUCTS, OR
ARISING OUT OF ANY BREACH OF THIS WARRANTY. This warranty is governed by the law of the State of
Tennessee without regard to its conicts of law principles.
2. No Set-off. Purchaser acknowledges that its obligations to pay NGP all sums properly invoiced to pur-
chaser by NGP for the products are absolute and unconditional. Purchaser shall make all payments to NGP when
due hereunder and shall not withhold, delay or condition payment for any reason whatsoever. Purchaser shall not
set-off any amounts due NGP against any amounts already due from NGP to Purchaser and expressly waives any
right or claim of set-off.
3. Claims. Any claim by Purchaser with reference to the Products shall be deemed waived by Purchaser
unless submitted in writing in accordance with this Paragraph 3. Purchaser shall inspect the Products immedi-
ately upon receipt and prior to any installation or use of such Products. Unless Purchaser provides written notice
to NGP of any claim for shortages or defects in the Products within fourteen (14) days after Purchaser's receipt
of shipment, such Products shall be deemed nally inspected and accepted by Purchaser. If a defect is of such
nature that reasonable inspection within the time provided herein would not disclose it, then notice of the claimed
defect shall be made in writing and delivered to Purchaser within ten (10) days after Purchaser knew or should
have known of the defect (but in no event later than the expiration of the Warranty Period); provided, however,
that (notwithstanding any provisions hereof to the contrary) NGP shall not be liable for claimed defects in Products
once such Products have been incorporated into a structure. At NGP's request, Purchaser will send any alleged-
ly non-conforming Products to NGP. Any written notice of a claim hereunder shall be sent in writing to National
Guard Products, 4985 East Raines Road, P.O. Box 753430, Memphis, Tennessee 38175.
4. Additional Terms. Acceptance of the Products shall be limited to the terms and conditions contained here-
in. Any terms and conditions contained in Purchaser's purchase order or acceptance that are in addition to, or are
in conict with, the terms and conditions contained herein shall not become a part of the agreement between NGP
and Purchaser unless expressly agreed to in writing by NGP.
