FREIGHT POLICY:
Freight prepaid and allowed (Ground transportation only) in Continental US on orders as follows:
l Thresholds and Gasketing only = $1,000 net or more
l Lites/Louvers/Glass/Continuous Hinges/Sliding Door Hardware only or combined with
Thresholds/Gasketing = $1,500 net or more
l Non-transportation surcharges (i.e.: construction site delivery, delivery notication, etc.)
will be billed to the customer
l All expedited shipments like “Next Day Air” when requested, will be shipped FedEx, prepaid
and the published rate for the service will be added to the invoice.
l Oversized items must be shipped LTL. Minimum freight on these orders is $130 as follows:
All cartons 96” and longer in length (Add 4” to material length to determine overall carton length)
Lite kits with glass or Mullion Bars and all louvers 45” and larger
Lite kits only 60” and larger
OVERSIZE ITEMS ARE NOT ELIGIBLE FOR SHIPMENT ON UPS OR FEDEX
TERMS:
l 1% 10 days - Net 30 days
l Payable in US Dollars
l Credit cards accepted from established accounts: Visa, Mastercard, Discover and American
Express (Payment terms: NET plus 3% processing)
MINIMUM:
$25.00 net for material
PACKING, HANDLING & INVOICING:
A charge of $15.00 net will be made on orders of $100.00 net or less.
Reinforced Packaging:
A $100 net charge on orders with any line item of:
Glass only with any size over 30"
Louvers 64" and larger
Items requiring extra support (ie: welded thresholds, etc.)
Orders requiring reinforced packaging will ship LTL
RETURNS:
No returns will be accepted without prior approval. After approval and subject to our inspec-
tion, credit will be allowed less a minimum 35% handling charge and all related freight charges.
Material that is not in standard stock sizes and nishes, or is specially fabricated is not returnable.
Self-adhesive products may only be returned within 90 days of the date of sale.
CLAIMS:
Claims for material damage or shortages must be made within 5 days after receipt of material.
NGP is not responsible for any damages or charges beyond replacement of defective material.
(See Warranty)
CANCELLATION:
Orders for non-stock sizes, special nishes, custom fabricated, and glass products are
non-cancelable and non-returnable once in production.
Prices and terms are subject to change without notice.
Price List February 1, 2019
NATIONAL GUARD PRODUCTS, INC.
FLOOD SHIELD
CONTINUOUS
HINGES
SLIDING
HARDWARE
GAP
SOLUTIONS
GASKETING
LITE KITS &
LOUVERS
ACOUSTICAL
THRESHOLDS GLASS
HOSPITALITY
FINGER GUARDS
EDGES &
ASTRAGALS
Phone: 800-647-7874
Fax: 800-255-7874
www.ngp.com
orders@ngp.com
2
NATIONAL GUARD PRODUCTS, INC.Phone: 800-647-7874
Fax: 800-255-7874
www.ngp.com
orders@ngp.com
WARRANTY
TERMS AND CONDITIONS
1. Limited Warranty; Limitation of Remedy and Damages. Subject to the limitations of liability set forth below,
NGP warrants products for a period of ve (5) years, except: aluminum geared continuous hinges for lifetime of the
door opening, stainless steel continuous hinges for twenty-ve (25) years, and all hinge electrical modication compo-
nents for ve (5) years from date of delivery (the "Warranty Period"), that the products provided by NGP hereunder
(the "Products") (i) shall conform substantially to the specications provided to NGP, if any, so long as the Products
have been properly installed; and (ii) shall conform substantially to the specications provided by NGP, and (iii) are
free from defects in workmanship and materials.
THIS IS THE SOLE AND EXCLUSIVE WARRANTY GIVEN BY NGP WITH RESPECT TO THE PRODUCTS AND IS
IN LIEU OF ANY AND ALL OTHER WARRANTIES, EXPRESS OR IMPLIED, ARISING BY OPERATION OF LAW OR
OTHERWISE. NGP HEREBY DISCLAIMS AND EXCLUDES ALL IMPLIED WARRANTIES, INCLUDING BUT NOT
LIMITED TO THE WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE.
This warranty does not cover, and NGP will not be liable for, defects or damage arising from improper installation, modi-
cation, lack of or improper maintenance, improper storage, shipping and handling, ordinary wear and tear, misuse, abuse,
accident, unauthorized service, use with unauthorized products or parts, or improper product selection or specication.
The sole and exclusive liability of NGP under this warranty or otherwise shall be limited to the repair or replacement
of any Product or component part which shall prove defective to the original purchaser from NGP hereunder (the
"Purchaser"), and shall not extend to dismantling, installing or reinstalling (or payment for the cost of the same). NGP
will not pay for the costs of repair or replacement performed other than in accordance with this warranty. NGP SHALL
NOT BE LIABLE FOR DAMAGES CAUSED BY DELAY IN PERFORMANCE AND IN NO EVENT, REGARDLESS
OF THE FORM OF THE CLAIM OR CAUSE OF ACTION (WHETHER BASED IN CONTRACT, INFRINGEMENT,
NEGLIGENCE, STRICT LIABILITY, TORT OR OTHERWISE), SHALL NGP'S LIABILITY TO PURCHASER AND/OR
ITS CUSTOMERS EXCEED THE PRICE PAID BY PURCHASER FOR THE SPECIFIC PRODUCTS GIVING RISE
TO THE CLAIM OR CAUSE OF ACTION. PURCHASER AGREES THAT IN NO EVENT SHALL NGP'S LIABILITY TO
PURCHASER AND/OR ITS CUSTOMERS EXTEND TO INCLUDE INCIDENTAL, CONSEQUENTIAL OR PUNITIVE
DAMAGES RESULTING FROM USE OF THE PRODUCTS, OR ARISING OUT OF ANY BREACH OF THIS WARRANTY.
This warranty is governed by the law of the State of Tennessee without regard to its conicts of law principles.
2. No Set-o. Purchaser acknowledges that its obligations to pay NGP all sums properly invoiced to purchaser
by NGP for the products are absolute and unconditional. Purchaser shall make all payments to NGP when due here-
under and shall not withhold, delay or condition payment for any reason whatsoever. Purchaser shall not set-o any
amounts due NGP against any amounts already due from NGP to Purchaser and expressly waives any right or claim
of set-o.
3. Claims. Any claim by Purchaser with reference to the Products shall be deemed waived by Purchaser
unless submitted in writing in accordance with this Paragraph 3. Purchaser shall inspect the Products immediately
upon receipt and prior to any installation or use of such Products. Unless Purchaser provides written notice to NGP
of any claim for shortages or defects in the Products within ve (5) days after Purchaser's receipt of shipment, such
Products shall be deemed nally inspected and accepted by Purchaser. If a defect is of such nature that reasonable
inspection within the time provided herein would not disclose it, then notice of the claimed defect shall be made in writ-
ing and delivered to Purchaser within ten (10) days after Purchaser knew or should have known of the defect (but in no
event later than the expiration of the Warranty Period); provided, however, that (notwithstanding any provisions hereof
to the contrary) NGP shall not be liable for claimed defects in Products once such Products have been incorporated
into a structure. At NGP's request, Purchaser will send any allegedly non-conforming Products to NGP. Any written
notice of a claim hereunder shall be sent in writing to National Guard Products, 4985 East Raines Road, P.O. Box
753430, Memphis, Tennessee 38175.
4. Additional Terms. Acceptance of the Products shall be limited to the terms and conditions contained herein.
Any terms and conditions contained in Purchaser's purchase order or acceptance that are in addition to, or are in conict
with, the terms and conditions contained herein shall not become a part of the agreement between NGP and Purchaser
unless expressly agreed to in writing by NGP.
3
Phone: 800-647-7874
Fax: 800-255-7874
www.ngp.com
orders@ngp.com
Phone: 800-647-7874
Fax: 800-255-7874
www.ngp.com
orders@ngp.com
Price List Index
Model Page
Continuous Geared Hinges ............................... 53-54
Continuous Stainless Steel Hinges ............................55
Cover Plates & Threshold Assembly Components .................7
Door Edges & Astragals.....................................51
False Mullion Bars .........................................33
Fastener Options for Thresholds & Gasketing.....................4
Finger Guards ............................................19
Flood Shields ..............................................9
Glass ............................................. 33, 44-50
Glazing Tape .............................................50
Index of Lite Kits, Louvers & Glass on back of
Lites & Louvers Tab
Lite Kits............................................... 28-37
Replacement Fasteners ...................................46
Louvers............................................... 38-43
Optional Finishes for Thresholds & Gasketing.....................5
“SIA” - “Slick It Ain’t” Abrasive Slip Resistant
Powder Coat Finishes
Quick Ship Lite Kits, Louvers & Glass ..........................27
Ramps ...................................................8
Returned Closed Ends for Aluminum Ramps
Replacement Gasketing Inserts ............................ 25-26
Security Door Guards........................................9
Sliding Door Hardware ......................................56
Threshold Fabrication Charges ................................6
Custom
Lead Lined Thresholds
Pre-Notching
Returned Closed Ends
Thresholds & Gasketing................................... 4-26
Thresholds for Floor Closers .............................. 22-24
Warranty..................................................2
4
NATIONAL GUARD PRODUCTS, INC.Phone: 800-647-7874
Fax: 800-255-7874
www.ngp.com
orders@ngp.com
Fasteners
Specialty Fasteners
Size Price
Replacement Weatherstrip Screws
Size Price
2 X 1/2" .23 / EA.
4 X 5/8" .23 / EA.
6 X 1/2" .20 / EA.
6 X 3/4" .24 / EA.
6 X 1" .29 / EA.
6 X 1 1/2" .37 / EA.
8-32 x 5/8" MS 1.05 / EA.
8 X 3/4" .36 / EA.
8 X 1" .38 / EA.
8 X 1 1/4" .40 / EA.
10 X 3/4" .40 / EA.
10 X 1 1/2" .42 / EA.
12 X 1 1/4" .44 / EA.
18 X 7/8" Nails (Wood Jambs) .25 / FT.
18 X 7/8" Nails (Wood Jambs) 42.00 / LB.
#4 Wafer Head (Metal Jambs) .57 / FT.
#4 Wafer Head (Metal Jambs) 84.00 / LB.
Bronze Weatherstrip Fasteners
Threshold Fasteners PER FT. or EA.
Plastic Anchor (PA) .50
Lead Expansion Shield (LES) .70
10-24 Mach. Screw/Lead Anchor (10-24 MS/LA) 1.00
1/4-20 Mach. Screw/Exp Anchor (1/4-20 MS/EA) 1.25
1/4-20 Combo MS/Anchor (1/4-20-2" Combo) 2.40
Tap-Con Type (1/4 X 1 3/4" Tap-Con) 1.15
Hilti Kwik-Con II TORX (1/4 X 1 3/4") 1.80
10-24 Mach. Screw (10-24 MS) .32
1/4-20 Mach. Screw (1/4-20 MS) .47
10-24 Lead Anchor (10-24 LA) .68
1/4-20 Expansion Anchor (1/4-20 EA) .78
Stainless Steel Fasteners
10-24 Mach. Screw/Lead Anchor (10-24 SS MS/LA) 1.52
1/4-20 Mach. Screw/Exp Anchor (1/4-20 SS MS/EA) 1.88
10 x 1 1/2" Stainless Wood Screw (10 x 1 1/2" SSWS) 1.05
12 x 1 1/2" Stainless Wood Screw (12 x 1 1/2" SSWS) 1.15
14 x 1 1/2" Stainless Wood Screw (14 x 1 1/2" SSWS) 1.30
Spanner Head Machine Screw & (Spanner 10-24 SSMS/LA) 2.60
Expansion Anchor (Spanner 1/4-20 SSMS/LA) 3.40
Replacement Threshold Screws
Price
10 x 1 1/2" Wood Screw .32 / EA.
Sex Nuts & Bolts for use with Astragals
SNB (for 1-3/4" doors only) 2.40 / FT. or EA. 6 X 3/4" .99
6 X 1" 1.09
6 X 1 1/2" 1.51
8 X 3/4" 1.35
8 X 1 1/2" 1.46
10 X 3/4" 1.56
10 X 1" 1.61
10 X 1 1/2" 1.67
12 X 1 1/2" 1.77
Size Per Ft. or EA.
Size Per Ft. or EA.
TORX Security Screws
Size Type Per Ft. or EA.
6 X 1/2" .26
6 X 3/4" .31
6 X 1" .39
6 X 1 1/2" .41
8 X 3/4" .42
8 X 1" .46
8 X 1 1/2" .51
10 X 3/4" .56
10 X 1 1/2" .63
12 X 1 1/2" .68
TEK Self-Drilling SS SMS
6 X 3/4" SS SMS 1.40
6 X 1" SMS 1.72
6 X 1 1/2" SMS 1.88
8 X 3/4" SMS 1.80
8 x 1" SMS 1.88
10 X 3/4" SMS 1.93
10 X 1" SMS 2.00
10 X 1 1/2" SMS 2.10
10-24 X 1 1/2" MS 1.90
10-24 X 1 1/2" MS x LA 2.50
12 X 1" SMS 2.00
12 X 1 1/2" SMS 2.35
1/4-20 X 1 1/2" MS 2.60
1/4-20 X 1 1/2" MS x EA 3.40
TORX BITS 23.00 / EA.
TORX DRIVER 26.00 / EA.
TORX DRIVER & set of 7 BITS 94.00 / EA.
Stainless Spanner Head SMS
5
Phone: 800-647-7874
Fax: 800-255-7874
www.ngp.com
orders@ngp.com
Phone: 800-647-7874
Fax: 800-255-7874
www.ngp.com
orders@ngp.com
Stainless Steel
Mill Finish Standard
US32 - Polished Stainless Steel - Add 30%
(up to 6" wide, 72" length maximum)
US32D - Brushed Stainless Steel - Add 25%
Bead Blasted - Add 25%
(up to 10" wide only)
“SIA” - “Slick It Ain’t” Abrasive Slip Resistant, Non-Skid Finish
Available on thresholds up to 24" wide, except 818 coverplates up to 10" wide.
All “SIA" products are fabricated to order and may not be returned for credit.
Add: Aluminum or Stainless Steel Bronze
Multiply width (inches) x $5.55 per foot $15.85 per foot
Example: SIA on 425HD 5" wide x 6 feet long; multiply $5.55/ft. list x 5 (inches wide) x 6 (ft. long)
Optional Finishes Available on Thresholds & Gasketing
Optional Finishes Powder Coat Finishes
Available on all aluminum, bronze and stainless steel products - Maximum length 144"
Specify clearly on order “Powder Coat” and the color designation
Colors Available:
(DKB) Dark Bronze (T) Tan (BPR) Beige Primer (matches Steelcraft)
(GBL) Gloss Black (GPZ) Gray Primer (CAB) California Bronze (matches Anemostat)
(MBL) Matte Black (W) White (PTY) Putty (matches Anemostat Beige)
(TBL) Textured Black (B) Brass (Gold) (MW) Magnolia White (matches Timely Western White)
(ASL) Aluminum Silver (WB) Walnut Brown (matches Timely Browntone)
Corrosion resistant sealer is applied under all powder coat nishes, which dramatically increases
the corrosion resistance of the nished product. Powder coating is applied to exposed surfaces only.
Quotes available for custom colors, sizes greater than shown, and large quantities.
Powder coat items are nished to order and may not be returned for credit.
Add to cost of product: $15.50 / FT.
Set-up charge (less than 18 FT.): $280
Custom Color Powder Coat
Available on special order: $1,600 Net minimum charge for custom color powder,
plus 15% product surcharge for powder application.
Powder Coat Finishes
Aluminum
Mill Finish Standard
Polished Aluminum - Add 100%
Bead Blasted - Add 25%
(up to 10" wide only)
Architectural Bronze
Satin Finish Standard
Polished Bronze - Add 30%
Dark Oxidized Oil Rubbed
Bronze (US10B) - Add 45%
Bead Blasted - Add 25%
(up to 10" wide only)
6
NATIONAL GUARD PRODUCTS, INC.Phone: 800-647-7874
Fax: 800-255-7874
www.ngp.com
orders@ngp.com
Threshold Fabrication Charges:
Aluminum Bronze Stainless Steel
Ripping Per Foot Per Rip (List) $ 6.20 $ 8.25 N/A
Beveling Per Foot Per Side (List) $ 6.20 $ 8.25 $27.50
*Welding Per Foot Per Weld (List) $10.15 $12.25 $20.30
* Flush underside welding of 1/4" high threshold assemblies requires underside beveling. An inverted “V” is
required for welding; allowing the welded threshold to lay at on the oor. Aluminum thresholds 8143, 8144 and
8145 proles feature underside bevels; add beveling charges to all other threshold assembly plates.
Custom Fabrication Charges:
Break Charge (per bend) $65.00 / EA.
Drilling (Non-standard quantity or pattern) $ 3.25 / FT.
Custom Drilling set up $70.00 / EA.
Custom Layout Set-up Charges may apply.
Reinforced Packaging:
An extra charge may be added for reinforced packaging required to support welded components. ($100.00 net min.)
Pre-Notching:
Aluminum or Bronze Stainless Steel
L-Notch (includes both ends) $11.00 / EA. $36.50 / EA.
Set-up charge (less than 100 pcs) $36.50 $130.00
U-Notch (includes both ends) $22.00 / EA. $73.00 / EA.
Set-up charge (less than 100 pcs) $67.50 $260.00
Returned Closed Ends:
R.C.E. (Alum.) $32.00 for Each Returned End
R.C.E. (Bronze) $42.00 for Each Returned End
R.C.E. (Stainless Steel) $62.50 for Each Returned End
Lead Lined Thresholds:
up to 5" wide = $26.50 / FT.
5 1/2" to 10" wide = $39.50 / FT.
Special Threshold Applications
7
Phone: 800-647-7874
Fax: 800-255-7874
www.ngp.com
orders@ngp.com
Phone: 800-647-7874
Fax: 800-255-7874
www.ngp.com
orders@ngp.com
Aluminum Stainless Steel Bronze
818 multiply width (inches)* x $ 7.85 / FT. multiply width (inches)* x $23.50 / FT. multiply width (inches)* x $67.00 / FT.
814 multiply width (inches)* x $12.75 / FT. multiply width (inches)** x $42.00 / FT. n/a
828 multiply width (inches)* x $10.40 / FT n/a n/a
838 multiply width (inches)** x $20.40 / FT n/a n/a
* 3" minimum width charge
**4" minimum width
Beveled edges standard
* 3" minimum width
** 4" minimum width
For beveled edges add $26/ ft.
per edge.
* 3" minimum width
Beveled edges standard
Example: For an 818 (alum) 8 inches wide by 6 feet long: multiply $7.85/ft. list x 8 (inches wide) x 6 (ft. long).
DKB powder coat nish ONLY oered on cover plates with “SIA” (non-skid) nish – Add 25% plus “SIA” charge on page 5.
Cover Plate Thresholds
Cover Plate Thresholds Threshold Assembly Components
Threshold Assembly Components
882 16.75 / FT.
8133 6.60 / FT.
8133DKB 9.35 / FT.
8134 12.50 / FT.
8134DKB 20.00 / FT.
8136 5.85 / FT.
8136BR 61.00 / FT.
8136DKB 9.00 / FT.
8137 6.25 / FT.
8137DKB 8.25 / FT.
8138 6.00 / FT.
8139 8.40 / FT.
8139BR 87.50 / FT.
8139DKB 12.00 / FT.
8140 5.75 / FT.
8140BR 55.50 / FT.
8140DKB 8.65 / FT.
8141 8.75 / FT.
8141DKB 12.90 / FT.
8142 9.55 / FT.
8142BR 92.00 / FT.
8142DKB 12.50 / FT.
8143 12.70 / FT.
8143BR 144.00 / FT.
8143DKB 17.75 / FT.
8144 16.50 / FT.
8144BR 182.00 / FT.
8144DKB 21.60 / FT.
8145 19.75 / FT.
8145BR 242.00 / FT.
8145DKB 26.75 / FT.
8146 23.00 / FT.
8146BR 275.00 / FT.
8146DKB 30.60 / FT.
8147 28.25 / FT.
8147DKB 38.00 / FT.
8148 29.75 / FT.
8148DKB 42.75 / FT.
8149 40.50 / FT.
8149DKB 57.00 / FT.
8150 40.75 / FT.
8150DKB 58.00 / FT.
8152 9.00 / FT.
8152DKB 13.70 / FT.
8163 13.90 / FT.
8163DKB 19.25 / FT.
8164 17.25 / FT.
8164DKB 23.00 / FT.
8167 28.25 / FT.
8167DKB 36.00 / FT.
8168N 9.15 / FT.
8170 44.25 / FT.
8170DKB 58.75 / FT.
Bar Supports
Item Price / FT.
BAR 1 6.65 / FT.
BAR 1BR 50.00 / FT.
BAR 2 6.75 / FT.
BAR 2BR 57.00 / FT.
BAR 4 9.75 / FT.
BAR 6SS 24.00 / FT.
BAR 6SS-2-10 BEV-TAP 49.00 / FT.
8
NATIONAL GUARD PRODUCTS, INC.Phone: 800-647-7874
Fax: 800-255-7874
www.ngp.com
orders@ngp.com
Ramps
Ramps
Ramps - Butted Condition
R50 19.15 / FT.
R50DKB 30.55 / FT.
R50SIA 52.45 / FT.
R75 32.75 / FT.
R75DKB 50.00 / FT.
R75SIA 82.70 / FT.
R100 44.40 / FT.
R100DKB 64.00 / FT.
R100SIA 111.00 / FT.
R125 62.30 / FT.
R125DKB 86.00 / FT.
R125SIA 145.55 / FT.
R150 74.50 / FT.
R150DKB 100.75 / FT.
R150SIA 174.40 / FT.
R175 96.00 / FT.
R175DKB 127.75 / FT.
R175SIA 212.55 / FT.
R200 107.60 / FT.
R200DKB 143.00 / FT.
R200SIA 240.80 / FT.
R225 132.00 / FT.
R225DKB 170.00 / FT.
R225SIA 281.85 / FT.
R250 155.00 / FT.
R250DKB 198.00 / FT.
R250SIA 321.50 / FT.
Ramps - Overlap Condition
RO50 53.15 / FT.
RO50DKB 72.75 / FT.
RO50SIA 119.75 / FT.
RO75 66.75 / FT.
RO75DKB 92.00 / FT.
RO75SIA 150.00 / FT.
RO100 78.40 / FT.
RO100DKB 105.80 / FT.
RO100SIA 178.30 / FT.
RO125 96.30 / FT.
RO125DKB 128.00 / FT.
RO125SIA 212.85 / FT.
RO150 108.50 / FT.
RO150DKB 142.75 / FT.
RO150SIA 241.70 / FT.
RO175 130.00 / FT.
RO175DKB 170.00 / FT.
RO175SIA 279.85 / FT.
RO200 141.60 / FT.
RO200DKB 185.00 / FT.
RO200SIA 308.10 / FT.
RO225 166.00 / FT.
RO225DKB 212.00 / FT.
RO225SIA 349.15 / FT.
RO250 189.00 / FT.
RO250DKB 240.00 / FT.
RO250SIA 388.80 / FT.
Returned Closed Ends
For Aluminum Ramps
RCE-9 166.00 / ST.
RCE-9DKB 199.00 / ST.
RCE-9SIA 186.00 / ST.
RCE-9SIA-DKB 219.00 / ST.
RCE-15 266.00 / ST.
RCE-15DKB 299.00 / ST.
RCE-15SIA 296.00 / ST.
RCE-15SIA-DKB 329.00 / ST.
RCE-21 439.00 / ST.
RCE-21DKB 479.00 / ST.
RCE-21SIA 489.00 / ST.
RCE-21SIA-DKB 519.00 / ST.
RCE-30 539.00 / ST.
RCE-30DKB 579.00 / ST.
RCE-30SIA 599.00 / ST.
RCE-30SIA-DKB 629.00 / ST.
Rubber Ramps (Supplied
with Beveled Edges)
RR42 154.00 / FT.
RR952 45.00 / FT.
RR954 109.00 / FT.
Black RTV Silicone
Construction Sealant for
Rubber Ramps
& PVC Carpet Dividers
RR5007BL - 10.1 oz. 23.00 /tube
RR5007BL-12 266.00 /case
(case of 12)
9
Phone: 800-647-7874
Fax: 800-255-7874
www.ngp.com
orders@ngp.com
Phone: 800-647-7874
Fax: 800-255-7874
www.ngp.com
orders@ngp.com
Flood Shields, Security Door Guards, Thresholds & Gasketing
* BUMPER SEAL OPTIONS - Add Per Foot:
NGP-TPV (N) .92 • Pile (P) .19 • Silicone (S) 1.04
* NF Notched Fins - Add $3.50 Per Foot
*EC End Caps - Add $9.00 Per Set
*STC-FH Acoustic FH - Add .55 Per Foot
Flood Shields
FS10-36" 360.00 / EA.
FS10-40" 360.00 / EA.
FS10-52" 450.00 / EA.
FS10-64" 540.00 / EA.
FS10-76" 630.00 / EA.
FS10-96" 725.00 / EA.
FS22-36" 805.00 / EA.
FS22-40" 805.00 / EA.
FS22-52" 1005.00 / EA.
FS22-64" 1205.00 / EA.
FS22-76" 1405.00 / EA.
FS22-96" 1606.00 / EA.
FS34-36" 1186.00 / EA.
FS34-40" 1186.00 / EA.
FS34-52" 1485.00 / EA.
FS34-64" 1780.00 / EA.
FS34-76" 2075.00 / EA.
FS34-96" 2370.00 / EA.
FSSP 88.00 / EA.
GAP90
(36", 48", 84", 96")
55.50 / FT.
GAP90DKB
(36", 48", 84", 96")
55.50 / FT.
GAP GAUGE 50.00 / EA.
Security Door Guards
SDG-3 41.75 / EA.
SDG-4 41.75 / EA.
SDG-10B 41.75 / EA.
SDG-26 39.50 / EA.
SDG-26D 35.50 / EA.
SDG-BRKT-MW 12.00 / EA.
SDG-BRKT-WB 24.00 / EA.
SDG-ET 22.00 / EA.
SDG-HO 7.10 / EA.
SDG-DS 7.10 / EA.
SDG-WS 7.10 / EA.
2V (*) 6.00 / FT.
2VDKB (*) 8.00 / FT.
3ASL 43.50 / EA.
3DKB 43.50 / EA.
3SP 43.50 / EA.
4V (*) 6.00 / FT.
4VDKB (*) 8.00 / FT.
5VA 9.10 / FT.
5VB 13.80 / FT.
5VDKB 11.40 / FT.
6VA 7.60 / FT.
6VDKB 9.75 / FT.
7ASL 43.50 / EA.
7DKB 43.50 / EA.
7SP 43.50 / EA.
12T (*NF) 6.00 / FT.
12TDKB (*NF) 8.25 / FT.
12T6 (*STC-FH) 6.20 / FT.
12T6DKB (*STC-FH) 8.50 / FT.
12V 4.40 / FT.
12VDKB 6.75 / FT.
13TA (*NF) 8.05 / FT.
13TDKB (*NF) 10.35 / FT.
13T6A 8.35 / FT.
13T6DKB 10.60 / FT.
13VA 6.70 / FT.
13VDKB 9.00 / FT.
14RA-1 3/4" 13.50 / FT.
14RA-1 3/4" (SET) 27.00 / FT.
14RA-2 1/4" 17.50 / FT.
14RA-2 1/4" (SET) 35.00 / FT.
14RB-1 3/4" 19.00 / FT.
14RB-1 3/4" (SET) 38.00 / FT.
14RB-2 1/4" 23.30 / FT.
14RB-2 1/4" (SET) 46.60 / FT.
14RDKB-1 3/4" 15.90 / FT.
14RDKB-1 3/4" (SET) 31.80 / FT.
14RDKB-2 1/4" 19.90 / FT.
14RDKB-2 1/4" (SET) 39.80 / FT.
15NA 11.55 / FT.
15NB 16.50 / FT.
15NDKB 13.90 / FT.
16A x 5.75 / FT.
16B x 9.50 / FT.
16DKB x 7.50 / FT.
16SS x 58.50 / FT.
17 x 2.90 / FT.
17B x 6.90 / FT.
17DKB x 5.80 / FT.
18V 6.50 / FT.
18VDKB 8.80 / FT.
19V 7.60 / FT.
19VB 13.25 / FT.
19VDKB 10.95 / FT.
26NA 10.00 / FT.
26NDKB 12.35 / FT.
35VA 8.65 / FT.
35VB 13.25 / FT.
35VDKB 10.95 / FT.
35ET (*NF) 8.25 / FT.
35ETDKB (*NF) 10.60 / FT.
35ET6 8.55 / FT.
35ET6DKB 10.90 / FT.
35EV 6.90 / FT.
35EVDKB 9.25 / FT.
36ET (*NF) 7.00 / FT.
36ETDKB (*NF) 9.30 / FT.
36ET6 7.25 / FT.
36ET6DKB 9.60 / FT.
36EV 5.65 / FT.
36EVDKB 7.95 / FT.
36VA 7.25 / FT.
36VDKB 9.55 / FT.
43CB
(36", 48", 72", 84", 96")
x 4.75 / FT.
54CP 6.25 / EA.
58 4.85 / FT.
58DKB 6.35 / FT.
60FP 3.00 / EA.
80B 6.80 / FT.
92NA (*EC) 15.95 / FT.
92NDKB (*EC) 22.15 / FT.
92NWHA (*EC) 20.30 / FT.
92NWHDKB (*EC) 26.45 / FT.
92TA (*EC, *NF) 16.20 / FT.
92TDKB (*EC, *NF) 22.40 / FT.
Fast Attach Two Way Tape Available
-Specify “FATT” & add 1.40 per Foot
10
NATIONAL GUARD PRODUCTS, INC.Phone: 800-647-7874
Fax: 800-255-7874
www.ngp.com
orders@ngp.com
* NF Notched Fins - Add $3.50 Per Foot
* EC End Caps - Add $9.00 Per Set
92TWHA (*EC) 20.80 / FT.
92TWHDKB (*EC) 26.95 / FT.
92T6A (*EC) 16.50 / FT.
92T6DKB (*EC) 22.65 / FT.
92VA (*EC) 14.85 / FT.
92VDKB (*EC) 21.00 / FT.
92WHA (*EC) 18.70 / FT.
92WHDKB (*EC) 24.80 / FT.
95WH 10.25 / FT.
95WHDKB 14.75 / FT.
96V x 3.85 / FT.
96VA x 4.90 / FT.
96VB x 7.00 / FT.
96VDKB x 5.75 / FT.
97V x 2.73 / FT.
97V (SET) x 5.46 / FT.
97VA x 3.60 / FT.
97VA (SET) x 7.20 / FT.
97VB x 5.60 / FT.
97VB (SET) x 11.20 / FT.
97VDKB x 4.65 / FT.
97VDKB (SET) x 9.30 / FT.
98V x 4.20 / FT.
98VA x 4.70 / FT.
98VB x 7.20 / FT.
98VDKB x 5.90 / FT.
99NA (*EC) 17.15 / FT.
99NDKB (*EC) 23.30 / FT.
99NWHA (*EC) 21.50 / FT.
99NWHDKB (*EC) 27.65 / FT.
99TA (*EC, *NF) 17.45 / FT.
99TDKB (*EC, *NF) 23.60 / FT.
99TWHA (*EC) 22.00 / FT.
99TWHDKB (*EC) 28.20 / FT.
99T6A (*EC) 17.75 / FT.
99T6DKB (*EC) 23.85 / FT.
99VA (*EC) 16.00 / FT.
99VDKB (*EC) 22.20 / FT.
99WHA (*EC) 20.00 / FT.
99WHDKB (*EC) 26.00 / FT.
100V x 3.15 / FT.
100VA x 4.00 / FT.
100VB x 6.60 / FT.
101V 4.20 / FT.
101VA 5.00 / FT.
101VB 8.00 / FT.
101VDKB 6.50 / FT.
102VA 6.60 / FT.
102VB 9.50 / FT.
102VDKB 8.10 / FT.
103NA x 17.20 / FT.
103NAFS 19.95 / FT.
103NB x 24.40 / FT.
103NBFS 27.15 / FT.
103NDKB x 20.50 / FT.
103NDKBFS 23.25 / FT.
104NA x 20.95 / FT.
104NB x 28.60 / FT.
104NDKB x 24.35 / FT.
106NA x 17.40 / FT.
106NDKB x 22.85 / FT.
106SA x 18.25 / FT.
106SDKB x 23.70 / FT.
107NA x 12.45 / FT.
107NAFS 15.20 / FT.
107NB x 19.25 / FT.
107NBFS 22.00 / FT.
107NDKB x 15.85 / FT.
107NDKBFS 18.60 / FT.
107SA x 14.00 / FT.
107SB x 21.00 / FT.
107SDKB x 17.50 / FT.
108NA x 8.75 / FT.
108NB x 12.10 / FT.
109NA 6.55 / FT.
109NB 10.80 / FT.
109NDKB 9.25 / FT.
109NSS 28.00 / FT.
110NA 4.44 / FT.
110NB 7.19 / FT.
110NDKB 5.69 / FT.
110SA 6.05 / FT.
110SB 9.10 / FT.
110SDKB 7.45 / FT.
111 16.00 / FT.
111DKB 22.00 / FT.
112N 12.90 / FT.
112NDKB 15.25 / FT.
113NA 9.10 / FT.
113NDKB 11.50 / FT.
114NA 7.50 / FT.
114NB 10.25 / FT.
114NDKB 8.60 / FT.
114SA 9.30 / FT.
114SB 12.20 / FT.
114SDKB 10.35 / FT.
115NA 5.90 / FT.
115NA (SET) 11.80 / FT.
115NB 9.65 / FT.
115NB (SET) 19.30 / FT.
115NDKB 7.35 / FT.
115NDKB (SET) 14.70 / FT.
116N 7.60 / FT.
116NDKB 9.75 / FT.
118N 9.00 / FT.
118NDKB 12.40 / FT.
119N 10.25 / FT.
119NB 16.25 / FT.
119NDKB 13.50 / FT.
120NA x 5.85 / FT.
120NB x 9.50 / FT.
120NDKB x 7.80 / FT.
120NSS x 26.00 / FT.
120SA x 7.58 / FT.
120SB x 11.35 / FT.
120SDKB x 9.53 / FT.
120SSS x 27.70 / FT.
122NA 6.55 / FT.
122NB 10.80 / FT.
122NDKB 9.25 / FT.
122NSS 28.00 / FT.
125NA 5.90 / FT.
125NA (SET) 11.80 / FT.
Fast Attach Two Way Tape Available
-Specify “FATT” & add 1.40 per Foot
Thresholds & Gasketing
11
Phone: 800-647-7874
Fax: 800-255-7874
www.ngp.com
orders@ngp.com
Phone: 800-647-7874
Fax: 800-255-7874
www.ngp.com
orders@ngp.com
125NB 9.65 / FT.
125NB (SET) 19.30 / FT.
125NDKB 7.35 / FT.
125NDKB (SET) 14.70 / FT.
125NSS 27.50 / FT.
125NSS (SET) 55.00 / FT.
127NA 4.30 / FT.
127NB 7.73 / FT.
127NDKB 6.05 / FT.
127NSS 24.50 / FT.
127SA 6.05 / FT.
127SB 9.65 / FT.
127SDKB 7.80 / FT.
127SSS 26.50 / FT.
129NA 7.35 / FT.
129NB 11.10 / FT.
129NDKB 9.15 / FT.
129NSS 29.50 / FT.
129UA 9.25 / FT.
129UB 13.20 / FT.
129UDKB 11.05 / FT.
129USS 32.00 / FT.
130NA 5.40 / FT.
130NB 9.00 / FT.
130NBR 24.50 / FT.
130NDKB 7.15 / FT.
130NSS 26.50 / FT.
130SA 7.30 / FT.
130SB 11.15 / FT.
130SBR 26.50 / FT.
130SDKB 9.10 / FT.
130SSS 28.50 / FT.
131NA 5.25 / FT.
131NB 8.35 / FT.
131NDKB 7.10 / FT.
132NA 5.70 / FT.
132NB 9.00 / FT.
132NDKB 7.50 / FT.
133NA 6.30 / FT.
133NB 9.50 / FT.
133NDKB 8.15 / FT.
134NA 5.00 / FT.
134NB 8.00 / FT.
134NDKB 6.60 / FT.
134SA 6.65 / FT.
134SB 9.75 / FT.
134SDKB 8.25 / FT.
135N x 4.20 / FT.
135NA x 5.50 / FT.
135NB x 7.50 / FT.
135NDKB x 6.15 / FT.
136N 5.35 / FT.
136NDKB 8.90 / FT.
136P 4.45 / FT.
136PDKB 8.00 / FT.
136S 6.00 / FT.
136SDKB 9.60 / FT.
137NA 6.60 / FT.
137NA (SET) 13.20 / FT.
137NB 9.95 / FT.
137NB (SET) 19.90 / FT.
137NDKB 7.80 / FT.
137NDKB (SET) 15.60 / FT.
137SA 8.60 / FT.
137SA (SET) 17.20 / FT.
137SB 12.20 / FT.
137SB (SET) 24.40 / FT.
137SDKB 9.85 / FT.
137SDKB (SET) 19.70 / FT.
139A 6.95 / FT.
139ALD 34.95 / FT.
139BR 106.00 / FT.
139DKB 8.95 / FT.
139DKBLD 36.95 / FT.
139SP 6.95 / FT.
139SPDKB 9.15 / FT.
139SPLD 34.95 / FT.
139SS 29.50 / FT.
139SSLD 57.50 / FT.
140A x 17.15 / FT.
140DKB x 22.35 / FT.
140PA x 17.15 / FT.
140PA (SET) x 34.30 / FT.
140PDKB x 22.00 / FT.
140PDKB (SET) x 44.00 / FT.
140SA x 17.75 / FT.
140SA (SET) x 35.50 / FT.
140SDKB x 22.60 / FT.
140SDKB (SET) x 45.20 / FT.
141NA x 17.70 / FT.
141NDKB x 23.20 / FT.
141PA x 17.50 / FT.
141PDKB x 23.00 / FT.
141SA x 18.50 / FT.
141SDKB x 24.00 / FT.
143NA 11.65 / FT.
143NDKB 15.85 / FT.
143PA 11.15 / FT.
143PDKB 15.35 / FT.
143SA 11.75 / FT.
143SDKB 15.95 / FT.
144A 17.75 / FT.
144DKB 21.95 / FT.
144PA 17.75 / FT.
144PA (SET) 35.50 / FT.
144PDKB 21.95 / FT.
144PDKB (SET) 43.90 / FT.
144SA 18.25 / FT.
144SA (SET) 36.50 / FT.
144SDKB 22.50 / FT.
144SDKB (SET) 45.00 / FT.
149MA (SET) x 21.50 / FT.
149MB (SET) x 30.60 / FT.
149MDKB (SET) x 26.75 / FT.
150UA 8.60 / FT.
150UB 12.30 / FT.
150UDKB 10.80 / FT.
151N 5.25 / FT.
151N (SET) 10.50 / FT.
151S 6.15 / FT.
151S (SET) 12.30 / FT.
151V 4.45 / FT.
151V (SET) 8.90 / FT.
Fast Attach Two Way Tape Available
-Specify “FATT” & add 1.40 per Foot
Thresholds & Gasketing
12
NATIONAL GUARD PRODUCTS, INC.Phone: 800-647-7874
Fax: 800-255-7874
www.ngp.com
orders@ngp.com
Fast Attach Two Way Tape Available
-Specify “FATT” & add 1.40 per Foot
152S 2.88 / FT.
152SA 4.03 / FT.
152SB 5.70 / FT.
152SDKB 4.78 / FT.
152V 1.73 / FT.
152VA 2.88 / FT.
152VB 4.44 / FT.
152VDKB 3.63 / FT.
155V x 1.68 / FT.
155VB x 5.18 / FT.
155VDKB x 4.28 / FT.
155S x 3.55 / FT.
155SB x 7.25 / FT.
155SDKB x 6.15 / FT.
156S 2.95 / FT.
156SDKB 4.70 / FT.
156V 1.65 / FT.
156VDKB 3.50 / FT.
157MA x 8.80 / FT.
157MDKB x 11.40 / FT.
158NA x 7.75 / FT.
158NDKB x 10.05 / FT.
158PA x 7.00 / FT.
158PDKB x 9.30 / FT.
158SA x 8.20 / FT.
158SDKB x 10.50 / FT.
158VA x 6.85 / FT.
158VDKB x 9.15 / FT.
159MA x 9.35 / FT.
159MB x 13.80 / FT.
159MDKB x 11.85 / FT.
160S x 2.80 / FT.
160SA x 4.10 / FT.
160SB x 5.60 / FT.
160SDKB x 4.65 / FT.
160U x 4.20 / FT.
160UA x 5.40 / FT.
160UB x 7.10 / FT.
160UDKB x 6.00 / FT.
160V
(12 PACK) 3'X7'
x 27.54 /
SET
160V x 1.62 / FT.
160VA x 2.79 / FT.
160VB x 4.28 / FT.
160VDKB x 3.55 / FT.
161NA x 6.13 / FT.
161NDKB x 6.78 / FT.
161PA x 3.57 / FT.
161PDKB x 4.25 / FT.
161SA x 4.75 / FT.
161SDKB x 5.40 / FT.
161UA x 6.10 / FT.
161UDKB x 6.75 / FT.
161VA x 3.53 / FT.
161VDKB x 4.18 / FT.
162S 4.96 / FT.
162SA 6.11 / FT.
162SB 8.60 / FT.
162SDKB 7.22 / FT.
164V x 1.75 / FT.
164VA x 2.95 / FT.
164VB x 4.45 / FT.
164VDKB x 3.60 / FT.
165NA x 5.30 / FT.
165NDKB x 7.05 / FT.
165SA x 7.80 / FT.
165SDKB x 9.60 / FT.
170NA x 7.30 / FT.
170NB x 11.80 / FT.
170NDKB x 10.20 / FT.
170PA x 6.70 / FT.
170PB x 11.15 / FT.
170PDKB x 9.60 / FT.
170SA x 7.80 / FT.
170SB x 12.35 / FT.
170SDKB x 10.70 / FT.
170VA x 6.35 / FT.
170VB x 10.70 / FT.
170VDKB x 9.25 / FT.
172NA x 5.50 / FT.
172NB x 8.80 / FT.
172NDKB x 7.50 / FT.
172SA x 6.65 / FT.
172SB x 10.15 / FT.
172SDKB x 8.65 / FT.
172VA x 4.30 / FT.
172VB x 7.50 / FT.
172VDKB x 6.30 / FT.
176A x 5.85 / FT.
176DKB x 8.15 / FT.
178SA x 6.10 / FT.
178SDKB x 8.40 / FT.
PF180
(36", 48", 86", 96", 120")
1.85 / FT.
PF183
(36", 48", 86", 96", 120")
2.85 / FT.
184QA 6.85 / FT.
184QB 10.35 / FT.
184QDKB 8.50 / FT.
185P x 2.90 / FT.
185PA x 3.90 / FT.
185PB x 5.70 / FT.
185PDKB x 4.70 / FT.
189MA (SET) x 20.30 / FT.
189MDKB (SET) x 25.30 / FT.
197NA 8.65 / FT.
197NB 12.28 / FT.
197NDKB 10.45 / FT.
198NA 6.25 / FT.
198NB 9.65 / FT.
198NDKB 8.00 / FT.
198UA 10.20 / FT.
198UB 13.90 / FT.
198UDKB 11.80 / FT.
199NA 7.80 / FT.
199NB 11.25 / FT.
199NDKB 9.40 / FT.
200NA 5.00 / FT.
200NB 8.15 / FT.
200NBR 24.50 / FT.
200NDKB 6.65 / FT.
200NSS 27.50 / FT.
200SA 7.50 / FT.
200SB 11.00 / FT.
200SBR 27.00 / FT.
200SDKB 9.10 / FT.
Thresholds & Gasketing
13
Phone: 800-647-7874
Fax: 800-255-7874
www.ngp.com
orders@ngp.com
Phone: 800-647-7874
Fax: 800-255-7874
www.ngp.com
orders@ngp.com
200SSS 30.00 / FT.
200UA 9.95 / FT.
200UB 13.55 / FT.
200UBR 29.50 / FT.
200UDKB 11.60 / FT.
200USS 33.00 / FT.
201NA 6.55 / FT.
201NB 10.00 / FT.
201NDKB 8.35 / FT.
202NA 9.40 / FT.
202NB 14.40 / FT.
202NDKB 11.90 / FT.
203NA 13.25 / FT.
203NB 18.40 / FT.
203NDKB 15.40 / FT.
203NA (MONORAIL) 175.00 / EA.
203NB (MONORAIL) 217.00 / EA.
203NDKB (MONORAIL) 195.00 / EA.
211 8.00 / FT.
211DKB 12.80 / FT.
215 6.68 / FT.
215DKB 9.18 / FT.
215BR 67.00 / FT.
220NA-36" 69.25 / EA.
(11" - 24" - add $33)
220NA-48" 92.00 / EA.
220NA-60" 118.00 / EA.
220NB-36" 99.00 / EA.
(11" - 24" - add $33)
220NB-48" 128.00 / EA.
220NB-60" 166.00 / EA.
220NDKB-36" 81.50 / EA.
(11" - 24" - add $33)
220NDKB-48" 109.00 / EA.
220NDKB-60" 140.00 / EA.
220SA-36" 82.25 / EA.
(11" - 24" - add $33)
220SA-48" 110.00 / EA.
220SA-60" 141.00 / EA.
220SB-36" 114.00 / EA.
(11" - 24" - add $33)
220SB-48" 147.00 / EA.
220SB-60" 190.00 / EA.
220SDKB-36" 94.00 / EA.
(11" - 24" - add $33)
220SDKB-48" 125.00 / EA.
220SDKB-60" 160.00 / EA.
220WHA-36" 71.50 / EA.
(11" - 24" - add $33)
220WHA-48" 95.00 / EA.
220WHA-60" 121.00 / EA.
220WHB-36" 100.00 / EA.
(11" - 24" - add $33)
220WHB-48" 129.00 / EA.
220WHB-60" 169.00 / EA.
220WHDKB-36" 82.25 / EA.
(11" - 24" - add $33)
220WHDKB-48" 110.00 / EA.
220WHDKB-60" 143.00 / EA.
221NBR-36" 167.00 / EA.
(11" - 24" - add $33)
221NBR-48" 223.00 / EA.
221NBR-60" 278.00 / EA.
221NSS-36" 121.00 / EA.
(11" - 24" - add $33)
221NSS-48" 161.00 / EA.
221NSS-60" 202.00 / EA.
221SBR-36" 184.00 / EA.
(11" - 24" - add $33)
221SBR-48" 245.00 / EA.
221SBR-60" 306.00 / EA.
221SSS-36" 137.00 / EA.
(11" - 24" - add $33)
221SSS-48" 183.00 / EA.
221SSS-60" 229.00 / EA.
221WHBR-36" 174.00 / EA.
(11" - 24" - add $33)
221WHBR-48" 232.00 / EA.
221WHBR-60" 290.00 / EA.
221WHSS-36" 126.00 / EA.
(11" - 24" - add $33)
221WHSS-48" 168.00 / EA.
221WHSS-60" 210.00 / EA.
222NA-36" 73.00 / EA.
(11" - 24" - add $33)
222NA-48" 97.00 / EA.
222NA-60" 123.00 / EA.
222NB-36" 103.00 / EA.
(11" - 24" - add $33)
222NB-48" 132.00 / EA.
222NB-60" 172.00 / EA.
222NDKB-36" 83.25 / EA.
(11" - 24" - add $33)
222NDKB-48" 111.00 / EA.
222NDKB-60" 142.50 / EA.
222SA-36" 84.25 / EA.
(11" - 24" - add $33)
222SA-48" 112.00 / EA.
222SA-60" 143.50 / EA.
222SB-36" 105.00 / EA.
(11" - 24" - add $33)
222SB-48" 140.00 / EA.
222SB-60" 177.00 / EA.
222SDKB-36" 96.25 / EA.
(11" - 24" - add $33)
222SDKB-48" 129.00 / EA.
222SDKB-60" 165.00 / EA.
222WHA-36" 73.75 / EA.
(11" - 24" - add $33)
222WHA-48" 98.00 / EA.
222WHA-60" 125.00 / EA.
222WHB-36" 103.00 / EA.
(11" - 24" - add $33)
222WHB-48" 133.00 / EA.
222WHB-60" 174.00 / EA.
222WHDKB-36" 85.25 / EA.
(11" - 24" - add $33)
222WHDKB-48" 114.00 / EA.
222WHDKB-60" 147.00 / EA.
223NA-36" 72.00 / EA.
(23-1/4" - 24" - add $33)
223NA-48" 96.00 / EA.
223NB-36" 103.50 / EA.
(23-1/4" - 24" - add $33)
223NB-48" 131.50 / EA.
223NDKB-36" 83.75 / EA.
(23-1/4" - 24" - add $33)
223NDKB-48" 112.00 / EA.
223SA-36" 84.75 / EA.
(23-1/4" - 24" - add $33)
223SA-48" 113.00 / EA.
223SB-36" 116.00 / EA.
(23-1/4" - 24" - add $33)
Automatic Door Bottoms:
Other than stock sizes, price at next highest price.
Lead Lined where available Up to 36" add $52.00
for Automatic Door Bottoms Up to 48" add $68.00
Up to 60" add $83.00
Thresholds & Gasketing
14
NATIONAL GUARD PRODUCTS, INC.Phone: 800-647-7874
Fax: 800-255-7874
www.ngp.com
orders@ngp.com
223SB-48" 155.00 / EA.
223SDKB-36" 96.25 / EA.
(23-1/4" - 24" - add $33)
223SDKB-48" 128.00 / EA.
225N-36" 61.75 / EA.
(11" - 24" - add $33)
225N-48" 82.00 / EA.
225N-60" 105.25 / EA.
225S-36" (*STC2) 75.25 / EA.
(11" - 24" - add $33)
225S-48" (*STC2) 100.00 / EA.
225S-60" (*STC2) 128.00 / EA.
225WH-36" 64.00 / EA.
(11" - 24" - add $33)
225WH-48" 85.00 / EA.
225WH-60" 110.00 / EA.
229NBR-36" 181.00 / EA.
(11" - 24" - add $33)
229NBR-48" 241.00 / EA.
229NBR-60" 301.00 / EA.
229NSS-36" 133.00 / EA.
(11" - 24" - add $33)
229NSS-48" 177.00 / EA.
229NSS-60" 222.00 / EA.
229SBR-36" 197.00 / EA.
(11" - 24" - add $33)
229SBR-48" 263.00 / EA.
229SBR-60" 328.00 / EA.
229SSS-36" 156.00 / EA.
(11" - 24" - add $33)
229SSS-48" 208.00 / EA.
229SSS-60" 260.00 / EA.
229WHBR-36" 187.00 / EA.
(11" - 24" - add $33)
229WHBR-48" 249.00 / EA.
229WHBR-60" 312.00 / EA.
229WHSS-36" 145.00 / EA.
(11" - 24" - add $33)
229WHSS-48" 193.00 / EA.
229WHSS-60" 242.00 / EA.
254P 11.55 / FT.
254PDKB 13.85 / FT.
284Q 2.50 / FT.
303NA x 17.75 / FT.
303NB x 25.70 / FT.
303NDKB x 20.95 / FT.
304NA x 21.55 / FT.
304NB x 29.50 / FT.
304NDKB x 24.75 / FT.
310NA-36" 65.75 / EA.
(11" - 24" - add $33)
310NA-48" 88.00 / EA.
310NA-60" 112.00 / EA.
310NB-36" 95.50 / EA.
(11" - 24" - add $33)
310NB-48" 127.00 / EA.
310NB-60" 160.00 / EA.
310NDKB-36" 77.00 / EA.
(11" - 24" - add $33)
310NDKB-48" 103.00 / EA.
310NDKB-60" 132.00 / EA.
310SA-36" 78.00 / EA.
(11" - 24" - add $33)
310SA-48" 104.00 / EA.
310SA-60" 134.00 / EA.
310SB-36" 108.00 / EA.
(11" - 24" - add $33)
310SB-48" 144.00 / EA.
310SB-60" 183.00 / EA.
310SDKB-36" 89.50 / EA.
(11" - 24" - add $33)
310SDKB-48" 119.00 / EA.
310SDKB-60" 154.00 / EA.
310WHA-36" 67.25 / EA.
(11" - 24" - add $33)
310WHA-48" 90.00 / EA.
310WHA-60" 114.00 / EA.
310WHB-36" 96.00 / EA.
(11" - 24" - add $33)
310WHB-48" 128.00 / EA.
310WHB-60" 162.00 / EA.
310WHDKB-36" 79.00 / EA.
(11" - 24" - add $33)
310WHDKB-48" 105.00 / EA.
310WHDKB-60" 135.00 / EA.
312V 3.88 / FT.
312VDKB 6.38 / FT.
312V X 131N 5.50 / FT.
312VDKB X 131N 8.00 / FT.
313VA 6.35 / FT.
313VDKB 8.70 / FT.
315 10.10 / FT.
315BR 108.00 / FT.
315DKB 12.75 / FT.
318V 5.90 / FT.
318VDKB 9.25 / FT.
319V 7.15 / FT.
319VB 12.85 / FT.
319VDKB 10.50 / FT.
319ET (*NF) 6.70 / FT.
319ETDKB (*NF) 8.90 / FT.
319ET6 7.15 / FT.
319ET6DKB 9.30 / FT.
319EV 5.60 / FT.
319EVDKB 7.80 / FT.
320N-36" 54.00 / EA.
(24" available - add $33)
320N-48" 71.00 / EA.
320S-36" 60.00 / EA.
(24" available - add $33)
320S-48" 79.00 / EA.
320V-36" 54.00 / EA.
(24" available - add $33)
320V-48" 71.00 / EA.
321 6.55 / FT.
321DKB 8.88 / FT.
322 8.72 / FT.
322BR 103.00 / FT.
322DKB 11.50 / FT.
322X355X327 36.70 / FT.
322DKBX355DKBX
327DKB 48.25 / FT.
323 (**) 10.05 / FT.
323DKB (**) 12.75 / FT.
324 19.75 / FT.
324DKB 27.80 / FT.
325 22.50 / FT.
325BR 259.00 / FT.
325DKB 30.50 / FT.
325HD 34.70 / FT.
325HDDKB 42.30 / FT.
Automatic Door Bottoms:
Other than stock sizes, price at next highest price.
Fast Attach Two Way Tape Available
-Specify “FATT” & add 1.40 per Foot
* STC2 Acoustic Fins - $19
STC2-PR Acoustic Fins (Pairs) - Add $22
Thresholds & Gasketing
15
Phone: 800-647-7874
Fax: 800-255-7874
www.ngp.com
orders@ngp.com
Phone: 800-647-7874
Fax: 800-255-7874
www.ngp.com
orders@ngp.com
325HDX325HD WELDED 79.55 / FT.
325HDDKBX
325HDDKB WELDED 94.75 / FT.
327 10.65 / FT.
327BR 142.50 / FT.
327DKB 14.80 / FT.
331-36" 13.60 / EA.
331-48" 18.15 / EA.
335N-36" 54.00 / EA.
(23-1/4" - 24" - add $33)
335N-48" 71.00 / EA.
335S-36" (*STC2) 69.00 / EA.
(23-1/4" - 24" - add $33)
335S-48" (*STC2) 91.00 / EA.
336P 2.50 / FT.
340P 2.40 / FT.
344-36" 26.00 / EA.
344-48" 34.65 / EA.
344NF-36" 30.65 / EA.
344NF-48" 40.86 / EA.
350 13.50 / FT.
350BR 164.00 / FT.
350DKB 18.50 / FT.
355 17.50 / FT.
355DKB 22.25 / FT.
398 15.00 / FT.
399 15.30 / FT.
400 18.50 / FT.
401 13.60 / FT.
402 14.10 / FT.
402X400X402 46.70 / FT.
402X400X400X402 65.20 / FT.
404 10.75 / FT.
404DKB 14.65 / FT.
407 13.60 / FT.
410 6.10 / FT.
410DKB 8.80 / FT.
411 8.05 / FT.
411BR 98.00 / FT.
411DKB 10.90 / FT.
412 10.50 / FT.
412DKB 14.90 / FT.
412SS 106.00 / FT.
413 7.45 / FT.
413BR 119.00 / FT.
413DKB 12.50 / FT.
413SS 106.00 / FT.
414 6.00 / FT.
414DKB 8.40 / FT.
415 14.10 / FT.
415BR 160.00 / FT.
415DKB 17.40 / FT.
416 6.35 / FT.
416DKB 10.50 / FT.
417 10.25 / FT.
417DKB 12.50 / FT.
420NA-36" 107.00 / EA.
(11" - 24" - add $33)
420NA-48" 143.00 / EA.
420NA-60" 179.00 / EA.
420NB-36" 141.00 / EA.
(11" - 24" - add $33)
420NB-48" 188.00 / EA.
420NB-60" 235.00 / EA.
420NDKB-36" 119.50 / EA.
(11" - 24" - add $33)
420NDKB-48" 159.00 / EA.
420NDKB-60" 199.00 / EA.
421NA-36" 133.50 / EA.
(11" - 24" - add $33)
421NA-48" 178.00 / EA.
421NA-60" 223.00 / EA.
421NA-96" 355.00 / EA.
421NA-120" 444.00 / EA.
421NA-144" 533.00 / EA.
421NB-36" 166.00 / EA.
(11" - 24" - add $33)
421NB-48" 221.00 / EA.
421NB-60" 277.00 / EA.
421NB-96" 443.00 / EA.
421NB-120" 553.00 / EA.
421NB-144" 664.00 / EA.
421NDKB-36" 143.00 / EA.
(11" - 24" - add $33)
421NDKB-48" 191.00 / EA.
421NDKB-60" 238.00 / EA.
421NDKB-96" 381.00 / EA.
421NDKB-120" 477.00 / EA.
421NDKB-144" 572.00 / EA.
422N-36" 107.00 / EA.
(11" - 24" - add $33)
422N-48" 143.00 / EA.
422N-60" 178.00 / EA.
423N-36" 100.00 / EA.
(11" - 24" - add $33)
423N-48" 133.00 / EA.
424 8.90 / FT.
424BR 130.00 / FT.
424DKB 13.00 / FT.
424E 8.60 / FT.
424EDKB 12.60 / FT.
425 12.75 / FT.
425BR 170.00 / FT.
425DKB 18.45 / FT.
425E (**) 11.10 / FT.
425EDKB (**) 16.85 / FT.
425HD 31.75 / FT.
425HDDKB 40.75 / FT.
426 16.05 / FT.
426BR 203.00 / FT.
426DKB 21.70 / FT.
426E (**) 13.85 / FT.
426EDKB (**) 19.25 / FT.
426HD 38.25 / FT.
426HDDKB 48.25 / FT.
427 22.00 / FT.
427BR 250.00 / FT.
427DKB 26.70 / FT.
427E (**) 18.85 / FT.
427EDKB (**) 24.40 / FT.
428BR 335.00 / FT.
428E (**) 24.00 / FT.
428EDKB (**) 32.50 / FT.
429BR 360.00 / FT.
429E (**) 27.00 / FT.
429EDKB (**) 36.00 / FT.
430BR 380.00 / FT.
Lead Lined where available Up to 36" add $52.00
for Automatic Door Bottoms Up to 48" add $68.00
Up to 60" add $83.00
** VINYL FOOT SEAL (V) –
add .50 Per Foot Per Side
* NF Notched Fins - Add $3.50 Per Foot
* STC2 Acoustic Fins - $19
STC2-PR Acoustic Fins (Pairs) - Add $22
Thresholds & Gasketing
16
NATIONAL GUARD PRODUCTS, INC.Phone: 800-647-7874
Fax: 800-255-7874
www.ngp.com
orders@ngp.com
430E (**) 30.40 / FT.
430EDKB (**) 39.00 / FT.
442BR 145.00 / FT.
457 18.25 / FT.
457DKB 25.85 / FT.
458 25.55 / FT.
458DKB 27.75 / FT.
473BR 114.00 / FT.
483BR 145.00 / FT.
(Add for Bronze Pan 5.15 per foot)
484BR 150.00 / FT.
(Add for Bronze Pan 5.15 per foot)
512 13.95 / FT.
512DKB 19.25 / FT.
512SS 112.00 / FT.
513 11.10 / FT.
513BR 144.00 / FT.
513DKB 17.00 / FT.
513HD 28.40 / FT.
513HDDKB 36.00 / FT.
513SS 112.00 / FT.
515 10.00 / FT.
515DKB 12.50 / FT.
520NA-36" 108.50 / EA.
(11" - 24" - add $33)
520NA-48" 145.00 / EA.
520NA-60" 181.00 / EA.
520NB-36" 143.00 / EA.
(11" - 24" - add $33)
520NB-48" 191.00 / EA.
520NB-60" 238.00 / EA.
520NDKB-36" 121.00 / EA.
(11" - 24" - add $33)
520NDKB-48" 162.00 / EA.
520NDKB-60" 202.00 / EA.
522N-36" 101.00 / EA.
(11" - 24" - add $33)
522N-48" 135.00 / EA.
522N-60" 172.00 / FT.
525 17.00 / FT.
525DKB 20.75 / FT.
600 x 5.00 / FT.
600 (SET) x 10.00 / FT.
600A x 5.35 / FT.
600A (SET) x 10.70 / FT.
600B x 8.40 / FT.
600B (SET) x 16.80 / FT.
600DKB x 7.10 / FT.
600DKB (SET) x 14.20 / FT.
600D-28 35.00 / EA.
601 x 7.20 / FT.
601A x 7.50 / FT.
601B x 10.80 / FT.
601DKB x 9.30 / FT.
602A x 5.20 / FT.
602DKB x 6.95 / FT.
603A x 7.70 / FT.
603DKB x 9.35 / FT.
A605A x 3.90 / FT.
A605A (SET) x 7.80 / FT.
A605B x 6.90 / FT.
A605B (SET) x 13.80 / FT.
A605DKB x 5.75 / FT.
A605DKB (SET) x 11.50 / FT.
B606A x 4.45 / FT.
B606A (SET) x 8.90 / FT.
B606B x 7.50 / FT.
B606B (SET) x 15.00 / FT.
B606DKB x 6.30 / FT.
B606DKB (SET) x 12.60 / FT.
C607A x 4.85 / FT.
C607B x 8.05 / FT.
C607DKB x 6.95 / FT.
D608A x 6.95 / FT.
D608B x 10.50 / FT.
D608DKB x 9.10 / FT.
G610A x 15.80 / FT.
G610B x 20.30 / FT.
G610DKB x 17.80 / FT.
G611A x 21.95 / FT.
G611DKB x 24.65 / FT.
H612A x 16.35 / FT.
H612B x 21.15 / FT.
H612DKB x 18.45 / FT.
612SS 170.00 / FT.
613 13.95 / FT.
613BR 204.00 / FT.
613DKB 19.35 / FT.
613HD 33.90 / FT.
613HDDKB 43.10 / FT.
613SS 170.00 / FT.
H614A x 24.40 / FT.
H614DKB x 27.20 / FT.
I-615A x 21.15 / FT.
I-615B x 27.70 / FT.
I-615DKB x 23.65 / FT.
I-616A x 26.60 / FT.
I-616DKB x 29.20 / FT.
D620A x 6.95 / FT.
D620B x 11.15 / FT.
D620DKB x 9.55 / FT.
G622A x 16.45 / FT.
G622DKB x 19.05 / FT.
H623A x 16.75 / FT.
H623DKB x 19.35 / FT.
I-624A x 21.45 / FT.
I-624DKB x 24.00 / FT.
A625A 4.20 / FT.
A625B 8.70 / FT.
A625DKB 7.35 / FT.
F625A 5.20 / FT.
F625B 9.80 / FT.
F625DKB 7.30 / FT.
A626A x 4.10 / FT.
A626B x 7.25 / FT.
A626DKB x 5.90 / FT.
C627A x 6.75 / FT.
C627B x 9.90 / FT.
C627DKB x 8.45 / FT.
OV633A x 6.90 / FT.
OV633B x 10.50 / FT.
OV633DKB x 9.00 / FT.
OV634A x 6.10 / FT.
OV634B x 9.55 / FT.
OV634DKB x 8.10 / FT.
** VINYL FOOT SEAL (V) –
add .50 Per Foot Per Side
Fast Attach Two Way Tape Available
-Specify “FATT” & add 1.40 per Foot
Thresholds & Gasketing
17
Phone: 800-647-7874
Fax: 800-255-7874
www.ngp.com
orders@ngp.com
Phone: 800-647-7874
Fax: 800-255-7874
www.ngp.com
orders@ngp.com
A635 4.75 / FT.
D648 x 6.95 / FT.
D648DKB x 9.55 / FT.
653 14.50 / FT.
653DKB 21.25 / FT.
654 10.90 / FT.
654DKB 19.60 / FT.
655 15.65 / FT.
655DKB 23.25 / FT.
656 19.85 / FT.
656DKB 26.35 / FT.
657 13.75 / FT.
657DKB 21.35 / FT.
659 18.45 / FT.
659DKB 25.05 / FT.
672A x 6.35 / FT.
672A (SET) x 12.70 / FT.
672B x 10.25 / FT.
672B (SET) x 20.50 / FT.
672DKB x 8.50 / FT.
672DKB (SET) x 17.00 / ST.
673A x 7.15 / FT.
673B x 11.25 / FT.
673DKB x 9.35 / FT.
674A x 9.30 / FT.
674B x 13.40 / FT.
674DKB x 11.50 / FT.
675A x 6.70 / FT.
675A (SET) x 13.40 / FT.
675B x 11.25 / FT.
675B (SET) x 22.50 / FT.
675DKB x 9.50 / FT.
675DKB (SET) x 19.00 / FT.
678A x 7.50 / FT.
678B x 12.10 / FT.
678DKB x 10.35 / FT.
679A x 8.60 / FT.
679B x 13.30 / FT.
679DKB x 11.45 / FT.
680A-36" 112.50 / EA.
(11" - 24" - add $33)
680A-48" 150.00 / EA.
680A-60" 188.00 / EA.
680B-36" 149.50 / EA.
(11" - 24" - add $33)
680B-48" 200.00 / EA.
680B-60" 250.00 / EA.
680DKB-36" 128.00 / EA.
(11" - 24" - add $33)
680DKB-48" 171.00 / EA.
680DKB-60" 213.00 / EA.
682-36" 109.25 / EA.
(11" - 24" - add $33)
682-48" 146.00 / EA.
682-60" 182.00 / EA.
683-36" 109.25 / EA.
(11" - 24" - add $33)
683-48" 146.00 / EA.
D690A 10.35 / FT.
D690B 16.10 / FT.
D690DKB 12.35 / FT.
C697A x 8.05 / FT.
C697B x 11.60 / FT.
C697DKB x 10.20 / FT.
D698A x 10.30 / FT.
D698B x 14.00 / FT.
D698DKB x 12.30 / FT.
C699A x 9.80 / FT.
C699B x 13.25 / FT.
C699DKB x 11.45 / FT.
700EN x 7.25 / FT.
700ENDKB 9.25 / FT.
700ES 8.00 / FT.
700ESDKB 10.00 / FT.
700EU 8.25 / FT.
700EUDKB 10.25 / FT.
700EV (*) 6.50 / FT.
700EVDKB (*) 8.50 / FT.
700N x 8.40 / FT.
700NA x 9.00 / FT.
700NB x 13.25 / FT.
700NDKB x 10.50 / FT.
700S x 9.10 / FT.
700SA x 9.75 / FT.
700SB x 13.85 / FT.
700SDKB x 11.10 / FT.
700U x 9.30 / FT.
700UA x 10.00 / FT.
700UB x 14.00 / FT.
700UDKB x 11.30 / FT.
701EP 8.15 / FT.
701EPDKB 10.15 / FT.
701P x 9.30 / FT.
701PA x 9.95 / FT.
701PB x 14.10 / FT.
701PDKB x 11.30 / FT.
704EV 6.55 / FT.
704EVDKB 8.55 / FT.
704V x 7.75 / FT.
704VA x 8.40 / FT.
704VB x 12.50 / FT.
704VDKB x 9.85 / FT.
705EV 6.55 / FT.
705EVDKB 8.55 / FT.
705V x 7.90 / FT.
705VA x 8.45 / FT.
705VB x 12.45 / FT.
705VDKB x 9.85 / FT.
706A x 9.50 / FT.
706B x 13.70 / FT.
706DKB x 10.90 / FT.
706E 8.11 / FT.
706EDKB 10.11 / FT.
712SS 193.00 / FT.
713 18.90 / FT.
713BR 233.00 / FT.
713DKB 24.55 / FT.
713SS 193.00 / FT.
780SA-36" 60.00 / EA.
(23" - 24" - add $33)
780SA-48" 80.00 / EA.
780SA-60" 100.00 / EA.
780SA-96" 160.00 / EA.
780SDKB-36" 72.00 / EA.
(23" - 24" - add $33)
780SDKB-48" 96.00 / EA.
780SDKB-60" 120.00 / EA.
Automatic Door Bottoms:
Other than stock sizes, price at next highest price.
Fast Attach Two Way Tape Available
-Specify “FATT” & add 1.40 per Foot
Thresholds & Gasketing
18
NATIONAL GUARD PRODUCTS, INC.Phone: 800-647-7874
Fax: 800-255-7874
www.ngp.com
orders@ngp.com
780SDKB-96" 192.00 / EA.
803V (*) 15.05 / FT.
803VDKB (*) 20.50 / FT.
804V (*) 14.40 / FT.
804VDKB (*) 19.80 / FT.
812SS 216.00 / FT.
813 22.75 / FT.
813BR 290.00 / FT.
813DKB 29.35 / FT.
813SS 216.00 / FT.
814 See page 7
814SS See page 7
816NA 12.80 / FT.
816NDKB 15.10 / FT.
816TA 11.70 / FT.
816TDKB 14.00 / FT.
816T6A 12.00 / FT.
816T6DKB 14.40 / FT.
816VA 10.35 / FT.
816VDKB 12.70 / FT.
818 See page 7
818BR See page 7
818SS See page 7
819NA 13.95 / FT.
819NDKB 16.30 / FT.
819TA 12.90 / FT.
819TDKB 15.25 / FT.
819T6A 13.15 / FT.
819T6DKB 15.50 / FT.
819VA 11.60 / FT.
819VDKB 13.85 / FT.
828 See page 7
838 See page 7
882 See page 7
883SS (*) 205.00 / FT.
884B/SV (*) 11.15 / FT.
884B/SVDKB (*) 15.75 / FT.
884V (*) 17.65 / FT.
884VDKB (*) 22.55 / FT.
884SS (*) 205.00 / FT.
884-6V (*) 46.35 / FT.
884-6VDKB (*) 56.45 / FT.
884-7V (*) 46.35 / FT.
884-7VDKB (*) 56.45 / FT.
884-8V (*) 46.35 / FT.
884-8VDKB (*) 56.45 / FT.
885V (*) 47.30 / FT.
885VDKB (*) 58.40 / FT.
885-6V(*) 47.30 / FT.
885-6VDKB (*) 58.40 / FT.
885-7V(*) 47.30 / FT.
885-7VDKB (*) 58.40 / FT.
890V (*) 15.20 / FT.
890VB (*) 23.65 / FT.
890VDKB (*) 20.60 / FT.
895VBR (*) 172.00 / FT.
896V-ADJ (*) 17.20 / FT.
896HDV (*) 23.80 / FT.
896HDVDKB (*) 30.85 / FT.
896V (*) 12.35 / FT.
896VBR (*) 152.00 / FT.
896VDKB (*) 16.00 / FT.
896SS (*) 202.00 / FT.
897V (*,**) 18.00 / FT.
897VDKB (*,**) 23.20 / FT.
897NS (**) 21.75 / FT.
897NSDKB (**) 27.00 / FT.
898V (*) 14.00 / FT.
898VDKB (*) 19.00 / FT.
912SS 240.00 / FT.
913 26.25 / FT.
913DKB 33.50 / FT.
913SS 240.00 / FT.
950V (*) 12.35 / FT.
950VDKB (*) 16.00 / FT.
951 21.25 / FT.
951DKB 26.90 / FT.
953 14.25 / FT.
953DKB 19.85 / FT.
954 25.15 / FT.
954DKB 31.90 / FT.
955 17.90 / FT.
955DKB 23.50 / FT.
957 34.00 / FT.
957DKB 42.00 / FT.
959 22.95 / FT.
959DKB 28.55 / FT.
960 46.45 / FT.
960DKB 53.70 / FT.
961 34.65 / FT.
961DKB 41.95 / FT.
962 30.75 / FT.
962DKB 38.05 / FT.
1000RA-5" 13.00 / FT.
1000RA-10" 19.50 / FT.
1000RA-16" 26.00 / FT.
1000RB-5" 18.50 / FT.
1000RB-10" 25.75 / FT.
1000RB-16" 32.75 / FT.
1000RDKB-5" 15.50 / FT.
1000RDKB-10" 22.00 / FT.
1000RDKB-16" 28.50 / FT.
1012SS 264.00 / FT.
1013 31.25 / FT.
1013DKB 38.50 / FT.
1013SS 264.00 / FT.
1015V 2.50 / FT.
1015VDKB 4.25 / FT.
1038NA x 18.50 / FT.
1038NB x 24.00 / FT.
1038NDKB x 22.00 / FT.
1390SP-83-1/8" 122.00 / EA.
1390SP-95-1/8" 139.00 / EA.
1392SP 34.50 / FT.
2014RA 11.10 / FT.
2014RB 13.30 / FT.
2014RDKB 12.30 / FT.
* BUMPER SEAL OPTIONS - Add Per Foot:
NGP-TPV (N) .92 • Pile (P) .19 • Silicone (S) 1.04
Fast Attach Two Way Tape Available
-Specify “FATT” & add 1.40 per Foot
** VINYL FOOT SEAL (V) -
add .50 Per Foot Per Side
Thresholds & Gasketing
19
Phone: 800-647-7874
Fax: 800-255-7874
www.ngp.com
orders@ngp.com
Phone: 800-647-7874
Fax: 800-255-7874
www.ngp.com
orders@ngp.com
Finger Guards
2248A-38" 320.00 / EA.
2248A-76" 392.00 / EA.
2248A-82" 422.00 / EA.
2248A-86" 459.00 / EA.
2248DKB-38" 344.00 / EA.
2248DKB-76" 414.00 / EA.
2248DKB-82" 445.00 / EA.
2248DKB-86" 482.00 / EA.
2252 B, C, W 177.00 / EA.
2525 B, C, W
(17', 20', 21', 25', 300') 1.75 / FT.
3038NA x 19.00 / FT.
3038NB x 27.00 / FT.
3038NDKB x 22.25 / FT.
3231 54.00 / FT.
3241 66.00 / FT.
3504 65.00 / FT.
3509 99.00 / FT.
3510 112.00 / FT.
3511 119.00 / FT.
4413-36" 305.00 / EA.
4413-48" 405.00 / EA.
4413-72" 605.00 / EA.
4424-36" 305.00 / EA.
4424-48" 405.00 / EA.
4424-72" 605.00 / EA.
4425-36" 390.00 / EA.
4425-48" 515.00 / EA.
4425-72" 770.00 / EA.
4425-96" 1020.00 / EA.
4440SA-36" 123.00 / EA.
4440SA-48" 154.00 / EA.
4440SA-60" 177.00 / EA.
4440SA-96" 250.00 / EA.
4440SB-36" 160.00 / EA.
4440SB-48" 185.00 / EA.
4440SB-60" 210.00 / EA.
4440SB-96" 290.00 / EA.
4440SDKB-36" 136.00 / EA.
4440SDKB-48" 170.00 / EA.
4440SDKB-60" 195.00 / EA.
4440SDKB-96" 265.00 / EA.
4440WHA-36" 117.00 / EA.
4440WHA-48" 150.00 / EA.
4440WHA-60" 175.00 / EA.
4440WHA-96" 250.00 / EA.
4440WHB-36" 150.00 / EA.
4440WHB-48" 175.00 / EA.
4440WHB-60" 200.00 / EA.
4440WHB-96" 275.00 / EA.
4440WHDKB-36" 129.00 / EA.
4440WHDKB-48" 160.00 / EA.
4440WHDKB-60" 185.00 / EA.
4440WHDKB-96" 255.00 / EA.
4441SA-36" 123.00 / EA.
4441SA-48" 154.00 / EA.
4441SA-60" 177.00 / EA.
4441SA-96" 250.00 / EA.
4441SB-36" 160.00 / EA.
4441SB-48" 185.00 / EA.
4441SB-60" 210.00 / EA.
4441SB-96" 290.00 / EA.
4441SDKB-36" 136.00 / EA.
4441SDKB-48" 170.00 / EA.
4441SDKB-60" 195.00 / EA.
4441SDKB-96" 265.00 / EA.
4441WHA-36" 117.00 / EA.
4441WHA-48" 150.00 / EA.
4441WHA-60" 175.00 / EA.
4441WHA-96" 250.00 / EA.
4441WHB-36" 150.00 / EA.
4441WHB-48" 175.00 / EA.
4441WHB-60" 200.00 / EA.
4441WHB-96" 275.00 / EA.
4441WHDKB-36" 129.00 / EA.
4441WHDKB-48" 160.00 / EA.
4441WHDKB-60" 185.00 / EA.
4441WHDKB-96" 255.00 / EA.
4447S-36" 122.00 / EA.
4447S-48" 155.00 / EA.
4447S-60" 180.00 / EA.
4447S-96" 250.00 / EA.
4447WH-36" 115.00 / EA.
4447WH-48" 145.00 / EA.
4447WH-60" 170.00 / EA.
4447WH-96" 240.00 / EA.
4448S-36" 122.00 / EA.
4448S-48" 155.00 / EA.
4448S-60" 180.00 / EA.
4448S-96" 250.00 / EA.
4448WH-36" 115.00 / EA.
4448WH-48" 145.00 / EA.
4448WH-60" 170.00 / EA.
4448WH-96" 240.00 / EA.
4513-36" 390.00 / EA.
4513-48" 520.00 / EA.
4513-72" 780.00 / EA.
RR5007BL 23.00 /
TUBE
RR5007BL-12 Pack 266.00 / CS.
5020 B, C, W 2.17 / FT.
(36", 48", 72", 84", 96", 108")
5020CL 2.67 / FT.
(36", 48", 72", 84", 96", 108")
5021 B, C, W 5.05 / FT.
(36", 48", 84", 96", 108")
5025 B, C, W 2.95 / FT.
(36", 48", 72", 84", 96", 108")
5025CL 3.45 / FT.
(36", 48", 72", 84", 96", 108")
5040 B 1.50 / FT.
(17', 20', 25', 300')
ANTI-LIG 5050 B, C, W 2.20 / FT.
ANTI-LIG 5050CL 2.75 / FT.
5050 B, C, T, W 1.60 / FT.
(17', 20', 21', 25', 300')
5050CL 2.10 / FT.
(17', 20', 21', 25', 300')
5060 B, C (17', 21') 2.25 / FT.
5060CL (17', 21') 2.60 / FT.
5070B 2.88 / FT.
(36", 48", 72", 84", 96", 108")
Fast Attach Two Way Tape Available
-Specify “FATT” & add 1.40 per Foot
Thresholds & Gasketing Finger Guards
Automatic Door Bottoms:
Other than stock sizes, price at next highest price.
20
NATIONAL GUARD PRODUCTS, INC.Phone: 800-647-7874
Fax: 800-255-7874
www.ngp.com
orders@ngp.com
5070CL 3.38 / FT.
(36", 48", 72", 84", 96", 108")
5075 B, C 2.95 / FT.
(36", 48", 72", 84", 96", 108")
5075CL 3.45 / FT.
(36", 48", 72", 84", 96", 108")
5100N-86" 25.50 / RL
5100N-96" 29.50 / RL
5100S-86" 23.50 / RL
5100S-96" 27.50 / RL
8013 29.00 / FT.
8013DKB 37.50 / FT.
8113 30.80 / FT.
8113DKB 39.30 / FT.
8130-96" 271.00 / PC.
8132-96" 90.00 / PC.
8133 thru 8134 See page 7
8135V (*) 11.75 / FT.
8135VDKB (*) 15.30 / FT.
8136 thru 8170 See page 7
8213 35.35 / FT.
8213DKB 45.50 / FT.
8413 14.50 / FT.
8413DKB 19.00 / FT.
8423V (*) 10.50 / FT.
8423VDKB (*) 14.50 / FT.
8424 16.80 / FT.
8424DKB 21.50 / FT.
8425 19.00 / FT.
8425DKB 25.00 / FT.
8426 21.00 / FT.
8426BR 220.00 / FT.
8426DKB 27.50 / FT.
8427 23.50 / FT.
8427BR 275.00 / FT.
8427DKB 30.75 / FT.
8428 26.00 / FT.
8428BR 325.00 / FT.
8428DKB 34.25 / FT.
8429 29.00 / FT.
8429BR 350.00 / FT.
8429DKB 37.00 / FT.
8430 33.00 / FT.
8430BR 365.00 / FT.
8430DKB 41.00 / FT.
8433V (*) 16.00 / FT.
8433VDKB (*) 21.75 / FT.
8434V (*) 18.00 / FT.
8434VDKB (*) 24.50 / FT.
8435V (*) 20.00 / FT.
8435VDKB (*) 27.00 / FT.
8436V (*) 23.00 / FT.
8436VDKB (*) 31.00 / FT.
8437V (*) 26.00 / FT.
8437VDKB (*) 34.00 / FT.
8475 35.00 / FT.
8475DKB 42.00 / FT.
8513 17.00 / FT.
8513DKB 22.00 / FT.
8533V (*) 18.35 / FT.
8533VDKB (*) 24.00 / FT.
8613 20.00 / FT.
8613DKB 26.00 / FT.
8633V(*) 21.00 / FT.
8633VDKB (*) 28.00 / FT.
8713 21.50 / FT.
8713DKB 28.00 / FT.
8813 24.00 / FT.
8813DKB 32.00 / FT.
8913 27.50 / FT.
8913DKB 35.50 / FT.
9000A x 6.35 / FT.
9000B x 9.60 / FT.
9000DKB x 8.25 / FT.
9001A 10.60 / FT.
9001B 14.70 / FT.
9001DKB 12.40 / FT.
9002 x 6.30 / FT.
9002A x 7.30 / FT.
9002B x 9.20 / FT.
9002DKB x 8.00 / FT.
9115A 10.10 / FT.
9115A (SET) 20.20 / FT.
9115B 14.15 / FT.
9115B (SET) 28.30 / FT.
9115DKB 12.80 / FT.
9115DKB (SET) 25.60 / FT.
9125A 10.10 / FT.
9125A (SET) 20.20 / FT.
9125B 14.15 / FT.
9125B (SET) 28.30 / FT.
9125DKB 12.80 / FT.
9125DKB (SET) 25.60 / FT.
9125SS 32.00 / FT.
9125SS (SET) 64.00 / FT.
9200 11.50 / FT.
(36", 48", 84", 96", 108")
9200DKB 11.50 / FT.
(36", 48", 84", 96", 108")
9225 14.25 / EA.
9245NA (*EC) 37.00 / FT.
9245NDKB (*EC) 44.00 / FT.
9245NWHA (*EC) 44.00 / FT.
9245NWHDKB (*EC) 50.90 / FT.
9245TA (*EC, *NF) 37.50 / FT.
9245TDKB (*EC, *NF) 45.00 / FT.
9245TWHA (*EC) 42.15 / FT.
9245TWHDKB (*EC) 49.00 / FT.
9245VA (*EC) 36.00 / FT.
9245VDKB (*EC) 43.00 / FT.
9245WHA (*EC) 40.50 / FT.
9245WHDKB (*EC) 48.00 / FT.
9275 18.50 / EA.
9450 B, C 4.80 / FT.
(36", 48", 84", 96", 108")
9500 5.65 / FT.
(36", 48", 84", 96", 108")
9500DKB 5.65 / FT.
(36", 48", 84", 96", 108")
9500 X 2525 B, C, W 8.00 / FT.
(36", 48", 84", 96", 108")
9500 X 5020 B, C, W 8.42 / FT.
(36", 48", 84", 96", 108")
9500DKB X 2525B 8.00 / FT.
(36", 48", 84", 96", 108")
9500DKB X 5020B 8.42 / FT.
(36", 48", 84", 96", 108")
* BUMPER SEAL OPTIONS - Add Per Foot:
NGP-TPV (N) .92 • Pile (P) .19 • Silicone (S) 1.04
Thresholds & Gasketing
*EC End Caps - Add $9.00 Per Set
*NF Notched Fins - Add $3.50 Per Foot
Fast Attach Two Way Tape Available
-Specify “FATT” & add 1.40 per Foot
21
Phone: 800-647-7874
Fax: 800-255-7874
www.ngp.com
orders@ngp.com
Phone: 800-647-7874
Fax: 800-255-7874
www.ngp.com
orders@ngp.com
9550 5.90 / FT.
(36", 48", 84", 96", 108")
9550DKB 5.90 / FT.
(36", 48", 84", 96", 108")
9600 x 7.30 / FT.
9600 (SET) x 14.60 / FT.
9600A x 7.60 / FT.
9600A (SET) x 15.20 / FT.
9600B x 10.80 / FT.
9600B (SET) x 21.60 / FT.
9600DKB x 9.30 / FT.
9600DKB (SET) x 18.60 / FT.
9605A x 6.15 / FT.
9605A (SET) x 12.30 / FT.
9605B x 9.35 / FT.
9605B (SET) x 18.70 / FT.
9605DKB x 7.95 / FT.
9605DKB (SET) x 15.90 / FT.
9675A x 9.00 / FT.
9675A (SET) x 18.00 / FT.
9675B x 13.80 / FT.
9675B (SET) x 27.60 / FT.
9675DKB x 11.80 / FT.
9675DKB (SET) x 23.60 / FT.
9700 x 12.75 / FT.
9700A x 13.30 / FT.
9700B x 17.90 / FT.
9700DKB x 14.70 / FT.
9700E 11.70 / FT.
9700EDKB 13.60 / FT.
9706E 11.70 / FT.
9706EDKB 13.60 / FT.
9750 B, C 4.30 / FT.
(36", 48", 84", 96", 108")
9800 B, C, W 2.05 / FT.
(17', 21', 150')
9850 B, C 4.00 / FT.
(36", 48", 84", 96", 108")
81369N 42.30 / FT.
81369NDKB 45.60 / FT.
Fast Attach Two Way Tape Available
-Specify “FATT” & add 1.40 per Foot
Thresholds & Gasketing
*EC End Caps - Add $9.00 Per Set
*NF Notched Fins - Add $3.50 Per Foot
22
NATIONAL GUARD PRODUCTS, INC.Phone: 800-647-7874
Fax: 800-255-7874
www.ngp.com
orders@ngp.com
The following information is required when ordering thresholds for use with oor closers:
• Threshold type x model number.
• Material and Finish
• Door thickness if other than 1-3/4"
• Door opening width
• Handing (Door handing)
• Name of oor closer manufacturer and oor closer model number.
• Abrasive “SIA” nish available - pricing on page 5.
• Polished & dark oxidized oil rubbed nishes are available on Bronze thresholds See page 5.
Note: Item numbers on invoices will read type, threshold number, size. Example: 1 x 427E x 36".
1 427E 1/2" x 7" Alum. 163.55 327.10 1.57
1 427EDKB 1/2" x 7" Alum. DKB 180.20 360.40 2.03
1 428E 1/2" x 8" Alum. 179.00 358.00 2.00
1 428EDKB 1/2" x 8" Alum. DKB 204.50 409.00 2.71
1 429E 1/2" x 9" Alum. 188.00 376.00 2.25
1 429EDKB 1/2" x 9" Alum. DKB 215.00 430.00 3.00
1 430E 1/2" x 10" Alum. 198.20 396.40 2.53
1 430EDKB 1/2" x 10" Alum. DKB 224.00 448.00 3.25
1 713 1/4" x 7" Alum. 163.70 327.40 1.58
1 713DKB 1/4" x 7" Alum. DKB 180.65 361.30 2.05
1 813 1/4" x 8" Alum. 175.10 350.20 1.89
1 813DKB 1/4" x 8" Alum. DKB 194.75 389.50 2.44
1 913 1/4" x 9" Alum. 185.45 370.90 2.18
1 913DKB 1/4" x 9" Alum. DKB 207.35 414.70 2.79
1 1013 1/4" x 10" Alum. 200.60 401.20 2.60
1 1013DKB 1/4" x 10" Alum. DKB 222.50 445.00 3.21
1 427BR 1/2" x 7" Bronze 877.00 1754.00 20.83
1 428BR 1/2" x 8" Bronze 1132.00 2264.00 27.92
1 713BR 1/4" x 7" Bronze 826.00 1652.00 19.42
1 813BR 1/4" x 8" Bronze 997.00 1994.00 24.17
3 427E 1/2" x 7" Alum. 227.55 391.10 1.57
3 427EDKB 1/2" x 7" Alum. DKB 244.20 424.40 2.03
3 428E 1/2" x 8" Alum. 243.00 422.00 2.00
3 428EDKB 1/2" x 8" Alum. DKB 268.50 473.00 2.71
3 429E 1/2" x 9" Alum. 252.00 440.00 2.25
3 429EDKB 1/2" x 9" Alum. DKB 279.00 494.00 3.00
Thresholds for Floor Closers
Thresholds for Floor Closers
Type Threshold Materials Single up Pair Add
to 36" up to 72" Per Inch
23
Phone: 800-647-7874
Fax: 800-255-7874
www.ngp.com
orders@ngp.com
Phone: 800-647-7874
Fax: 800-255-7874
www.ngp.com
orders@ngp.com
Type Threshold Materials Single up Pair Add
to 36" up to 72" Per Inch
3 430E 1/2" x 10" Alum. 262.20 460.40 2.53
3 430EDKB 1/2" x 10" Alum. DKB 288.00 512.00 3.25
3 713 1/4" x 7" Alum. 227.70 391.40 1.58
3 713DKB 1/4" x 7" Alum. DKB 244.65 425.30 2.05
3 813 1/4" x 8" Alum. 239.10 414.20 1.89
3 813DKB 1/4" x 8" Alum. DKB 258.75 453.50 2.44
3 913 1/4" x 9" Alum. 249.45 434.90 2.18
3 913DKB 1/4" x 9" Alum. DKB 271.35 478.70 2.79
3 1013 1/4" x 10" Alum. 264.60 465.20 2.60
3 1013DKB 1/4" x 10" Alum. DKB 286.50 509.00 3.21
3 427BR 1/2" x 7" Bronze 961.00 1838.00 20.83
3 428BR 1/2" x 8" Bronze 1216.00 2348.00 27.92
3 713BR 1/4" x 7" Bronze 910.00 1736.00 19.42
3 813BR 1/4" x 8" Bronze 1081.00 2078.00 24.17
4 427E 1/2" x 7" Alum. 227.55 391.10 1.57
4 427EDKB 1/2" x 7" Alum. DKB 244.20 424.40 2.03
4 428E 1/2" x 8" Alum. 243.00 422.00 2.00
4 428EDKB 1/2" x 8" Alum. DKB 268.50 473.00 2.71
4 429E 1/2" x 9" Alum. 252.00 440.00 2.25
4 429EDKB 1/2" x 9" Alum. DKB 279.00 494.00 3.00
4 430E 1/2" x 10" Alum. 262.20 460.40 2.53
4 430EDKB 1/2" x 10" Alum. DKB 288.00 512.00 3.25
4 713 1/4" x 7" Alum. 227.70 391.40 1.58
4 713DKB 1/4" x 7" Alum. DKB 244.65 425.30 2.05
4 813 1/4" x 8" Alum. 239.10 414.20 1.89
4 813DKB 1/4" x 8" Alum. DKB 258.75 453.50 2.44
4 913 1/4" x 9" Alum. 249.45 434.90 2.18
4 913DKB 1/4" x 9" Alum. DKB 271.35 478.70 2.79
4 1013 1/4" x 10" Alum. 264.60 465.20 2.60
4 1013DKB 1/4" x 10" Alum. DKB 286.50 509.00 3.21
4 427BR 1/2" x 7" Bronze 961.00 1838.00 20.83
4 428BR 1/2" x 8" Bronze 1216.00 2348.00 27.92
4 713BR 1/4" x 7" Bronze 910.00 1736.00 19.42
4 813BR 1/4" x 8" Bronze 1081.00 2078.00 24.17
Thresholds for Floor Closers
24
NATIONAL GUARD PRODUCTS, INC.Phone: 800-647-7874
Fax: 800-255-7874
www.ngp.com
orders@ngp.com
Thresholds for Floor Closers
5 427E X 424E 1/2" x 7" x 4" Alum. 244.60 425.20 0.72
5 427EDKB X 424EDKB 1/2" x 7" x 4" Alum.DKB 252.60 441.20 1.05
5 428E X 425E 1/2" x 8" x 5" Alum. 249.20 434.40 0.93
5 428EDKB X 425EDKB 1/2" x 8" x 5" Alum.DKB 269.20 474.40 1.41
5 713 X 413 1/4" x 7" x 4" Alum. 236.80 409.60 0.62
5 713DKB X 413DKB 1/4" x 7" x 4" Alum.DKB 252.55 440.10 1.04
5 813 X 513 1/4" x 8" x 5" Alum. 247.90 431.80 0.93
5 813DKB X 513DKB 1/4" x 8" x 5" Alum.DKB 266.25 468.50 1.42
5 427BR X 424BR 1/2" x 7" x 4" Bronze 763.00 1442.00 10.83
5 428BR x 425BR 1/2" x 8" x 5" Bronze 928.00 1772.00 14.17
5 713BR X 413BR 1/4" x 7" x 4" Bronze 724.00 1364.00 9.92
5 813BR X 513BR 1/4" x 8" x 5" Bronze 831.00 1578.00 12.00
Type Threshold Materials Single up Pair Add
to 36" up to 72" Per Inch
Floor Closer Preps Only - add to Material Price (For other thresholds not shown above)
Prices are Per Prep (Double for Pairs)
Aluminum Bronze Stainless Steel
Type 1 111.00 219.00 535.00
Type 3 176.00 305.00 660.00
Type 4 176.00 305.00 660.00
Type 5 207.00 347.00 n/a
Pivot Prep for any center hung or oset pivot - $85 each prep.
25
Phone: 800-647-7874
Fax: 800-255-7874
www.ngp.com
orders@ngp.com
Phone: 800-647-7874
Fax: 800-255-7874
www.ngp.com
orders@ngp.com
Replacement Inserts
Replacement Neoprene
Item Price/Ft.
15N, 26N, 92N, 99N, 112N,
113N, 118N, 119N, 816N,
819N, 9245N 2.90
103N, 104N, 105N, 108N,
303N, 304N, 305N, 420N,
421N, 422N, 423N 3.65
106N, 141N 2.15
107N, 165N, 223N, 335N 3.05
109N, 122N 2.60
110N, 120N, 127N, 134N 1.85
115N, 125N 2.35
116N 3.70
129N, 137N, 1038N 3.65
130N, 133N 2.45
131N 2.10
132N 2.20
135N, 161N, 700N, 700EN 3.40
148N 5.70
158N, 170N 2.65
197N, 199N 3.65
200N, 201N, 114N, 198N 2.55
202N 4.20
203N 7.35
520N, 522N 4.45
81369N 37.50
Replacement NGP-TPV
Item Price/Ft.
136N, 143N 1.10
151N, 172N 1.50
320N 2.65
Bumper NGP-TPV (threshold) 1.75
Replacement Nylon Brush
Item Price/Ft.
Specify Gray or Black.
600, 602, B606 2.65
601, 603 3.85
9000, 9600, 9605 3.45
A Brush, 92WH, 99WH, 220WH,
221WH, 222WH, 225WH, 229WH,
310WH, F625, OV633, OV634,
A635, 672, 673, 674, 675, 678,
679, 680, 682, 683, 706, 706E,
4440WH, 4441WH, 4447WH,
4448WH, 9245WH, 9706E 2.45
C Brush 3.15
C Brush-EPDM 6.30
D Brush 3.75
D Brush-EPDM 7.15
G Brush 11.90
H Brush 14.40
I Brush 18.20
Replacement Silicone
Item Price/Ft.
107S, 165S, 223S, 335S 3.65
110S, 120S, 127S 2.45
130S 4.65
132S 3.50
136S, 140S, 141S, 143S, 144S,
151S, 158S, 170S 2.00
137S 3.85
152S, 155S, 172S, 320S 1.60
156S 1.70
160S, 700S, 700ES 1.60
162S 2.30
200S, 114S 4.15
780S 2.55
4440, 4441, 4447, 4448 7.80
9001S 5.20
9002S, 9700S 3.15
9115S, 9125S 4.85
Bumper Silicone (threshold) 1.85
Replacement Thermoplastic
Item Price/Ft.
12T, 13T, 35ET, 36ET,
92T, 99T, 319ET, 816T,
819T, 9245T 2.30
12T6, 13T6, 35ET6, 36ET6,
92T6, 99T6, 319ET6,
816T6, 819T6 2.60
Replacement Vinyl
Item Price/Ft.
5V, 6V, 12V, 13V, 18V, 19V,
92V, 99V, 816V, 819V,
9245V 1.35
151V, 158V, 170V 0.80
35V, 35EV, 36V, 36EV, 312V,
313V, 318V, 319V, 319EV, 1.50
96V 1.75
97V 1.15
98V, 101V, 1015V 1.50
100V 1.10
102V 3.70
149M, 157M, 159M, 189M
(magnet & vinyl) 3.55
152V, 155V, 172V, 320V 0.70
156V 0.70
160V, 164V 0.70
704, 704E, 705, 705E 0.70
Bumper Vinyl (threshold) 0.80
Foot Seal (threshold) 0.50
Threshold Splines
Item Price/Ft.
Aluminum Spline 2.35
Thermal Spline 1/2" 2.35
Thermal Spline 1/4" 1.65
Replacement Inserts
26
NATIONAL GUARD PRODUCTS, INC.Phone: 800-647-7874
Fax: 800-255-7874
www.ngp.com
orders@ngp.com
Replacement Inserts
Replacement Inserts
Replacement Pile
Item Price/Ft.
136P, 140P, 143P, 144P, 158P,
161P, 185P, 701P, 701EP 1.25
154P, 254P 4.25
170P, Bumper Pile (threshold) 1.00
Replacement Polyurethane
Item Price/Ft.
129U, 150U 3.20
160U, 161U, 700EU, 700U 2.25
198U, 200U 4.75
Auto Door Bottom/Door Shoe Parts
Item Price
End Caps - 92, 99, 220, 222, 223,
225, 310, 420, 422, 423, 520, 522,
680, 682, 683, 9250 9.00 /Set
End Caps - 221SS, 229SS 18.00 /Set
Drop Bar Assembly - 220N, 221N,
222N, 225N, 229N, 310N 18.00 / FT.
Drop Bar Assembly - 220S, 221S,
222S, 225S, 229S, 310S 24.00 / FT.
Drop Bar Assembly - 220WH, 221WH,
222WH, 225WH, 229WH, 310WH 19.00 / FT.
Heavy Duty Drop Bar Assemblies:
420N, 422N, 423N, 520N, 522N 28.00 / FT.
680, 682, 683 28.50 / FT.
Replacement Reinforced Rubber
Item Price/Ft.
14R-1 3/4" 5.75
14R-2 1/4" 7.40
1000R x 5" 6.55
1000R x 10" 11.00
1000R x 16" 16.40
Flood Shield Replacement Parts
Item Price/Ft.
Flood Shield Bottom, Neoprene 3.15 / FT.
Flood Shield Side, Neoprene 2.90 / FT.
Replacement Mounting Channels
FS10A-MTG CHNL 34.00 /Set
FS10DKB-MTG CHNL 41.00 /Set
FS22A-MTG CHNL 68.00 /Set
FS22DKB-MTG CHNL 81.00 /Set
FS34A-MTG CHNL 102.00 /Set
FS34DKB-MTG CHNL 122.00 /Set
27
Phone: 800-647-7874
Fax: 800-255-7874
www.ngp.com
orders@ngp.com
Phone: 800-647-7874
Fax: 800-255-7874
www.ngp.com
orders@ngp.com
Order Size List Price with Pyran
®
F SuperLite™ 1-W SuperLite™ X-90 Tempered
GT-118 GT-118 GT-116 GT-118
5 x 35 $91 $388 $264 $294 $168
6 x 27 83 324 224 279 160
7 x 22 78 317 217 279 155
8 x 32 91 458 303 NA NA
12 x 12 53 288 188 256 125
24 x 24 99 1035 636 NA NA
24 x 30 109 1280 781 NA NA
24 x 32 115 1368 837 NA NA
24 x 36 118 1523 925 NA NA
24 x 60 247 3024 1827 NA NA
prices reect 15% add to pricing of standard lead time items
TWO DAYS*
L-FRA100 Low Prole
Lite Kit
THREE DAYS*
L-FRA100 packed with
GLASS & GLAZING TAPE
§ *Orders must be received by 11 a.m. Central time; after 11 a.m., add one business day.
§ Orders must be marked “QUICK SHIP”.
§ Any mix of items below.
§ Available Finishes: GPZ, DKB, TAN, BPR, CAB: For Galvaneal add 20%.
§ Torx security screws - up to 24" x 24" add $12, over 24" x 24" add $24.
§ Orders mixed with any other products will be subject to standard lead times.
THREE DAYS*
L-700-RX
Self Attaching,
No Vision Louver
QUICK SHIP ITEMS
THREE DAYS*
NON-STOCK SIZES
L-FRA100, L-FRA100-SP, L-GLF100,
L-GLF100-SP, L-GLF100-TB,
L-GLF100-SP-TB
Kits only or packed with
Glass & Glazing Tape GT-118
Pyran F Superlite 1-W Diamond Wired
Glass Only
Pyran F
Superlite 1-W
Diamond Wired
Order Size List Price
12 x 12 $ 87
18 x 12 104
18 x 18 121
24 x 12 121
24 x 18 138
24 x 24 168
prices reect 15% add to pricing of standard
lead time items
Quick Ship Lites & Louvers & Glass
Tempered - 4 sizes:
11 x 11
6 x 21
4 x 34
5 x 26
Add 25% to pricing of
standard lead time items
28
NATIONAL GUARD PRODUCTS, INC.Phone: 800-647-7874
Fax: 800-255-7874
www.ngp.com
orders@ngp.com
L-FRA100, L-GLF100, L-GLF100-TB Lite Kits for 1-3/4" Doors
L-FRA100, L-GLF100, L-GLF100-TB
Lite Kits for 1-3/4" Doors
HEIGHT
Mullion Bars available for L-GLF-100 and L-GLF100-TB - price of Lite Kit plus $135 per Mullion Bar
Torx Security Screws - up to 24" x 24" add $12.50, over 24" x 24" add $25
Minimum 3" width or height; maximum 88" width or height
Odd inch and fractional sizes, use next largest even size
Lead lining - $6.25 per perimeter inch
STC option - $14 per square ft.
Gray Primer (GPZ) nish standard and will be provided unless one of the following optional nishes is indicated:
Available at no extra charge: (T) Tan (DKB) Dark Bronze (BPR) Beige Primer (matches Steelcraft)
(CAB) California Bronze (matches Anemostat) (PTY) Putty (matches Anemostat beige)
Add 15% for following nishes:
(B) Brass (Gold) (GBL) Gloss Black (W) White
(MBL) Matte Black (TBL) Textured Black (ASL) Aluminum Silver
(WB) Walnut Brown (matches Timely Browntone)
(MW) Magnolia White (matches Timely Western White)
Galvanneal - Add 20% Zinc EL-Plate - Add $420
6 8 10 12 14 16 18 20 22 24 26 28 30 32 34 36
4 63 63 63 67 71 76 83 83 85 87 92 96 100 102 103 107
6 63 63 63 71 71 79 83 83 87 96 99 101 102 102 103 107
8 63 63 63 76 79 83 83 87 96 99 101 102 102 107 107 110
10 63 63 53 79 83 83 87 96 99 101 102 107 107 107 110 110
12 71 76 79 46 83 87 96 99 101 102 102 107 110 110 110 115
14 58 79 83 83 85 96 99 101 102 102 107 110 110 115 115 126
16 79 83 83 83 96 99 101 102 107 107 107 110 110 115 118 129
18 83 83 88 96 99 101 88 107 107 107 110 110 115 126 126 130
20 83 88 96 99 101 102 107 109 109 110 110 110 126 126 126 130
22 86 67 99 101 102 107 107 109 109 110 110 115 126 126 130 132
24 86 99 101 102 102 107 107 110 110 86 115 130 130 134 134 138
26 79 83 102 102 107 107 110 110 110 105 130 130 134 137 138 139
28 72 102 107 107 110 110 110 110 115 130 130 134 137 138 139 141
30 82 81 107 110 110 110 99 115 126 94 134 137 138 139 141 149
32 102 79 107 110 115 115 100 126 126 100 137 138 139 141 149 151
34 103 95 110 110 115 118 126 126 130 114 138 139 141 149 151 152
36 79 96 110 115 126 129 130 130 132 102 139 141 149 151 152 153
38 105 96 110 122 130 130 134 137 138 140 141 149 151 152 199 206
40 109 110 123 131 131 135 138 139 141 142 150 152 153 200 207 213
42 133 141 150 152 158 165 168 173 179 186 189 198 200 207 213 228
44 138 150 152 158 165 168 173 179 186 189 198 200 207 213 228 234
46 142 152 158 165 168 173 179 186 189 198 200 207 213 228 234 242
48 160 168 173 177 185 189 195 200 210 216 218 225 228 234 242 244
50 165 173 177 185 189 195 200 210 216 218 225 228 234 242 244 247
52 168 177 185 189 195 200 210 216 218 225 228 234 242 244 247 257
54 173 185 189 195 200 210 216 218 225 227 234 242 244 247 257 270
56 179 189 195 200 206 216 218 225 227 234 234 244 247 257 270 276
58 193 200 206 212 216 225 231 234 238 242 250 254 257 270 276 279
60 198 206 212 216 225 231 234 242 245 194 254 257 270 276 279 290
62 204 213 217 226 232 235 243 246 251 237 259 271 278 280 291 297
64 208 217 226 232 235 243 246 251 255 224 271 278 280 291 297 302
66 222 234 242 244 243 255 257 263 270 218 282 284 291 297 302 310
68 228 242 244 248 255 257 263 270 280 282 284 291 297 302 310 317
70 234 244 248 255 257 263 270 280 282 284 291 297 302 310 317 325
72 242 248 255 257 263 270 280 282 284 291 297 302 310 317 325 334
Optional Material:
Aluminum = List X 2
W I D T H
29
Phone: 800-647-7874
Fax: 800-255-7874
www.ngp.com
orders@ngp.com
Phone: 800-647-7874
Fax: 800-255-7874
www.ngp.com
orders@ngp.com
L-FRA100, L-GLF100, L-GLF100-TB with SuperLite™ I-W
6 8 10 12 14 16 18 20 22 24 26 28 30 32 34 36
6 180 180 180 187 187 196 200 200 204 213 229 241 251 261 271 285
8 180 180 180 193 196 200 200 221 243 257 272 286 298 316 329 344
10 180 180 170 196 200 217 237 261 279 297 314 335 355 371 389 404
12 187 193 196 163 223 246 274 295 316 336 359 383 404 423 442 466
14 175 196 200 223 247 280 304 328 356 378 405 429 451 483 505 538
16 196 200 217 242 280 307 335 365 396 421 446 477 502 533 560 596
18 200 200 238 274 304 335 355 402 430 458 493 521 555 594 627 658
20 200 210 261 295 328 365 402 434 470 502 534 565 617 649 680 714
22 203 188 279 316 356 396 430 470 504 540 574 619 664 699 741 777
24 203 239 297 336 378 421 458 502 540 553 625 677 714 761 798 839
26 201 234 314 359 405 446 493 534 574 615 680 725 770 813 859 901
28 194 264 335 383 429 477 521 565 619 677 725 773 819 869 913 959
30 203 254 355 404 451 502 538 606 664 679 770 819 872 920 973 1028
32 223 263 371 423 483 533 567 649 699 727 813 869 920 976 1034 1086
34 224 290 389 442 505 560 627 680 741 778 859 913 973 1034 1094 1148
36 229 302 404 466 538 596 658 714 777 804 901 959 1028 1086 1148 1205
38 263 317 420 496 563 627 691 757 817 883 944 1015 1077 1142 1248 1319
40 289 364 480 561 630 707 778 853 928 998 1079 1150 1224 1340 1420 1606
42 323 407 524 603 685 764 844 922 1004 1083 1163 1248 1323 1406 1595 1694
44 336 428 548 629 716 795 880 966 1048 1132 1216 1299 1385 1576 1679 1767
46 349 442 571 656 743 832 917 1007 1094 1182 1268 1353 1443 1657 1748 1847
48 375 470 604 689 784 876 964 1056 1153 1241 1330 1424 1622 1722 1824 1916
50 393 488 624 722 813 909 1005 1100 1196 1289 1386 1585 1688 1794 1890 1992
52 405 503 649 747 847 942 1046 1145 1236 1337 1434 1647 1752 1857 1962 2069
54 419 523 671 774 876 979 1082 1182 1285 1380 1594 1707 1815 1920 2036 2154
56 433 544 694 800 906 1017 1115 1223 1325 1433 1647 1762 1875 1994 2116 2306
58 455 567 726 832 940 1053 1163 1270 1374 1591 1712 1829 1946 2067 2263 2383
60 469 585 749 857 973 1086 1197 1313 1423 1588 1765 1885 2014 2138 2336 2465
62 483 603 772 892 1008 1118 1237 1351 1467 1680 1822 1955 2078 2278 2415 2546
64 496 620 798 918 1036 1158 1271 1390 1619 1712 1883 2014 2141 2357 2492 2622
66 518 649 831 951 1068 1198 1318 1441 1679 1751 1943 2074 2286 2425 2563 2705
68 534 668 850 976 1104 1228 1354 1482 1730 1865 1999 2137 2354 2497 2642 2782
70 548 683 872 1003 1130 1261 1392 1636 1774 1912 2054 2195 2418 2567 2715 2829
72 592 739 952 1094 1239 1385 1534 1676 1817 1963 2108 2332 2485 2637 2789 2912
HEIGHT
Gray Primer (GPZ) nish standard and will be provided unless one of the following optional nishes is indicated:
Available at no extra charge: (T) Tan (DKB) Dark Bronze (BPR) Beige Primer (matches Steelcraft)
(CAB) California Bronze (matches Anemostat) (PTY) Putty (matches Anemostat beige)
Add 15% for following nishes:
(B) Brass (Gold) (GBL) Gloss Black (W) White
(MBL) Matte Black (TBL) Textured Black (ASL) Aluminum Silver
(WB) Walnut Brown (matches Timely Browntone)
(MW) Magnolia White (matches Timely Western White)
Galvanneal - Add 20% Zinc EL-Plate - Add $420
L-FRA100, L-GLF100, L-GLF100-TB with SuperLite™ I-W
with GT-118 Glazing Tape both sides
Meets CPSC 16CFR 1201 Cat. I & II impact safety requirements
Etched with UL Fire-rating classication on each piece
Mullion bars available for L-GLF100 and L-GLF100-TB - price of lite kit plus $135 per mullion bar
Torx Security Screws - up to 24" x 24" add $12.50, over 24" x 24" add $25
Minimum 3" width or height; maximum 88"
Under 4" - call for quote
Odd inch or fractional sizes, use next largest size
STC option - $14 per square ft. W I D T H
30
NATIONAL GUARD PRODUCTS, INC.Phone: 800-647-7874
Fax: 800-255-7874
www.ngp.com
orders@ngp.com
L-FRA100, L-GLF100, L-GLF100-TB with Pyran® F
HEIGHT
6 8 10 12 14 16 18 20 22 24 26 28 30 32 34 36
6 266 266 266 274 274 283 287 287 291 300 323 342 360 376 394 415
8 266 266 266 280 283 287 287 318 349 373 398 421 443 471 493 517
10 266 266 256 283 287 313 345 382 412 442 471 504 536 564 594 621
12 274 280 283 250 324 362 404 440 475 509 547 586 621 654 688 726
14 262 283 287 324 365 415 456 497 541 580 625 665 704 753 792 842
16 283 287 313 357 415 462 508 558 608 652 696 747 792 842 888 944
18 287 287 346 404 456 508 550 619 669 719 775 825 880 941 996 1049
20 287 297 382 440 497 558 619 675 735 792 847 902 979 1034 1090 1148
22 290 275 412 475 541 608 669 735 796 858 919 990 1062 1123 1192 1255
24 290 340 442 509 580 652 719 792 858 900 1001 1082 1148 1224 1290 1360
26 288 344 471 547 625 696 775 847 919 991 1087 1164 1240 1315 1392 1465
28 281 382 504 586 665 747 825 902 990 1082 1164 1246 1326 1409 1487 1567
30 290 380 536 621 704 792 864 968 1062 1113 1240 1326 1414 1498 1588 1679
32 310 398 564 654 753 842 914 1034 1123 1189 1315 1409 1498 1594 1690 1781
34 311 433 594 688 792 888 996 1090 1192 1270 1392 1487 1588 1690 1791 1886
36 337 454 621 726 842 944 1049 1148 1255 1324 1465 1567 1679 1781 1886 1987
38 377 478 649 771 884 993 1103 1215 1321 1433 1539 1657 1764 1875 2027 2143
40 422 549 745 879 1001 1132 1256 1383 1512 1634 1769 1892 2020 2189 2322 2648
42 462 602 803 937 1075 1210 1345 1479 1617 1751 1887 2028 2158 2297 2628 2788
44 481 632 840 979 1124 1262 1406 1550 1690 1832 1975 2116 2261 2595 2761 2913
46 501 656 876 1022 1170 1320 1466 1617 1765 1914 2061 2207 2358 2721 2880 3045
48 534 693 922 1071 1230 1385 1536 1693 1853 2005 2158 2315 2664 2833 3005 3166
50 558 720 956 1120 1277 1439 1601 1764 1926 2085 2248 2597 2773 2952 3120 3294
52 577 744 994 1161 1330 1493 1666 1835 1995 2164 2331 2700 2881 3060 3241 3423
54 598 773 1029 1203 1378 1552 1727 1898 2073 2240 2609 2801 2987 3170 3364 3560
56 619 804 1065 1245 1426 1611 1784 1965 2142 2324 2700 2896 3090 3291 3493 3825
58 647 836 1111 1293 1479 1669 1855 2040 2221 2597 2802 3004 3204 3409 3749 3957
60 668 863 1147 1334 1530 1723 1913 2108 2299 2629 2893 3100 3316 3527 3874 4092
62 689 891 1183 1385 1584 1776 1977 2174 2371 2757 2988 3211 3424 3773 4003 4228
64 709 917 1222 1427 1630 1837 2035 2239 2637 2823 3087 3311 3530 3900 4131 4358
66 737 955 1269 1476 1680 1898 2106 2317 2729 2897 3184 3410 3778 4016 4254 4495
68 759 984 1301 1517 1735 1949 2166 2384 2813 3045 3278 3515 3891 4137 4384 4626
70 780 1008 1336 1560 1780 2003 2227 2649 2888 3127 3371 3613 4001 4255 4508 4700
72 853 1103 1473 1719 1968 2218 2472 2717 2963 3213 3462 3851 4112 4373 4634 4841
Gray Primer (GPZ) nish standard and will be provided unless one of the following optional nishes is indicated:
Available at no extra charge: (T) Tan (DKB) Dark Bronze (BPR) Beige Primer (matches Steelcraft)
(CAB) California Bronze (matches Anemostat) (PTY) Putty (matches Anemostat beige)
Add 15% for following nishes:
(B) Brass (Gold) (GBL) Gloss Black (W) White
(MBL) Matte Black (TBL) Textured Black (ASL) Aluminum Silver
(WB) Walnut Brown (matches Timely Browntone)
(MW) Magnolia White (matches Timely Western White)
Galvanneal - Add 20% Zinc EL-Plate - Add $420
L-FRA100, L-GLF100, L-GLF100-TB with Pyran® F
with GT-118 Glazing Tape both sides
Meets CPSC 16CFR 1201 Cat. I & II impact safety requirements
Etched with UL Fire-rating classication on each piece
Mullion bars available for L-GLF100 and L-GLF100-TB - price of lite kit plus $135 per mullion bar
Torx Security Screws - up to 24" x 24" add $12.50, over 24" x 24" add $25
Minimum 3" width or height; maximum 78" height.
Odd inch or fractional sizes, use next largest size
STC option - $14 per square ft. W I D T H
31
Phone: 800-647-7874
Fax: 800-255-7874
www.ngp.com
orders@ngp.com
Phone: 800-647-7874
Fax: 800-255-7874
www.ngp.com
orders@ngp.com
L-FRA100, L-GLF100, L-GLF100-TB with 1/4" Tempered Glass
HEIGHT
Gray Primer (GPZ) nish standard and will be provided unless one of the following optional nishes is indicated:
Available at no extra charge: (T) Tan (DKB) Dark Bronze (BPR) Beige Primer (matches Steelcraft)
(CAB) California Bronze (matches Anemostat) (PTY) Putty (matches Anemostat beige)
Add 15% for following nishes:
(B) Brass (Gold) (GBL) Gloss Black (W) White
(MBL) Matte Black (TBL) Textured Black (ASL) Aluminum Silver
(WB) Walnut Brown (matches Timely Browntone)
(MW) Magnolia White (matches Timely Western White)
Galvanneal - Add 20% Zinc EL-Plate - Add $420
L-FRA100, L-GLF100, L-GLF100-TB with 1/4" Tempered Glass
with GT-118 Glazing Tape both sides
Meets CPSC 16CFR 1201 Cat. I & II impact safety requirements
Mullion bars available for L-GLF100 and L-GLF100-TB - price of lite kit plus $135 per mullion bar
Torx Security Screws - up to 24" x 24" add $12.50, over 24" x 24" add $25
Minimum 3" width, 12" height; maximum 88" width or height
Odd inch or fractional sizes, use next largest size
STC option - $14 per square ft.
6 8 10 12 14 16 18 20 22 24 26 28 30 32 34 36
12 133 138 141 108 149 154 163 165 167 168 173 179 181 181 181 186
14 120 141 145 149 152 163 165 167 173 173 179 181 181 210 210 221
16 141 145 149 149 163 165 167 173 179 179 179 205 205 210 212 224
18 145 145 155 163 165 167 160 179 179 179 205 205 210 221 245 248
20 145 155 163 165 167 173 179 180 203 205 205 205 245 245 245 248
22 148 134 165 167 173 179 179 203 203 205 205 234 245 245 272 274
24 148 165 167 168 173 179 179 205 205 180 234 248 248 277 277 280
26 146 149 168 173 179 179 205 205 205 224 248 272 277 279 304 305
28 139 168 174 179 181 205 205 205 234 248 272 277 279 304 305 307
30 148 147 179 181 181 205 193 234 245 213 277 279 304 305 331 338
32 168 146 179 181 210 210 194 245 245 242 279 304 305 331 338 341
34 170 162 181 181 210 212 245 245 272 256 304 305 331 338 364 366
36 146 163 181 186 221 224 248 248 274 244 305 307 338 341 366 367
38 172 167 181 217 225 248 253 279 280 306 307 338 341 366 413 443
40 175 181 194 226 226 254 256 281 307 308 340 342 367 414 444 450
42 200 212 221 247 276 283 310 316 345 352 379 411 414 444 450 489
44 204 221 247 253 283 286 316 345 352 379 388 414 444 450 489 495
46 209 223 253 259 286 316 321 352 379 388 414 420 450 489 495 526
48 227 239 268 272 303 331 337 366 400 406 432 462 465 495 526 528
50 236 245 272 303 308 337 366 376 406 432 462 465 495 526 528 555
52 239 248 279 308 337 343 376 406 408 438 465 495 502 528 555 566
54 245 256 284 313 343 353 382 408 438 441 471 502 528 532 566 602
56 250 284 290 319 348 382 384 415 441 471 495 505 532 566 602 608
58 264 295 324 330 358 391 420 447 452 479 510 538 566 578 608 634
60 269 301 330 335 367 396 424 455 482 431 515 542 578 608 634 645
62 275 307 336 368 398 401 432 460 488 498 543 579 586 612 646 676
64 279 312 345 374 401 432 436 464 492 485 555 586 612 646 676 681
66 293 329 360 386 409 445 471 500 530 479 566 592 623 652 681 713
68 299 337 362 391 421 447 476 507 540 566 592 623 652 681 713 720
70 305 339 367 397 423 453 483 517 543 569 599 628 658 689 720 751
72 313 343 374 400 429 459 493 519 545 575 605 634 666 696 727 760
W I D T H
32
NATIONAL GUARD PRODUCTS, INC.Phone: 800-647-7874
Fax: 800-255-7874
www.ngp.com
orders@ngp.com
L-FRA100, L-GLF100, L-GLF100-TB with 1/4" Wired Glass
L-FRA100, L-GLF100, L-GLF100-TB with 1/4" Wired Glass
Diamond & GT-118 Glazing Tape both sides
HEIGHT
Etched with UL re-rating classication on each piece up to 1,296 sq. inches visible area - 54" max. width or height
Mullion bars available for L-GLF100 and L-GLF100-TB - price of lite kit plus $135 per mullion bar
Torx Security Screws - up to 24" x 24" add $12.50, over 24" x 24" add $25
Under 4" - call for quote
Odd inch or fractional sizes, use next largest size
STC option - $14 per square ft.
6 8 10 12 14 16 18 20 22 24 26 28 30 32 34 36
6 119 119 119 127 127 135 139 139 143 152 163 170 175 180 185 194
8 119 119 119 132 135 139 139 154 168 176 184 191 197 208 214 222
10 119 119 109 135 139 149 161 177 186 196 204 217 228 235 245 252
12 127 132 135 102 152 165 183 193 204 214 227 241 252 261 269 283
14 114 135 139 152 164 185 198 210 226 236 251 263 273 294 304 325
16 135 139 149 161 185 199 213 230 247 258 270 288 299 316 330 353
18 139 139 162 183 198 213 218 250 263 275 295 308 326 350 368 384
20 139 149 177 193 210 230 250 265 284 299 314 328 364 378 392 410
22 142 128 186 204 226 247 263 284 300 317 332 358 385 401 424 442
24 142 168 196 214 236 258 275 299 317 310 361 393 410 436 453 474
26 140 157 204 227 251 270 295 314 332 351 394 417 440 461 485 505
28 133 181 217 241 263 288 308 328 358 393 417 442 464 490 511 533
30 142 165 228 252 273 299 310 352 385 374 440 464 491 514 542 571
32 162 168 235 261 294 316 324 378 401 402 461 490 514 543 574 599
34 164 189 245 269 304 330 368 392 424 433 485 511 542 574 605 631
36 152 195 252 283 325 353 384 410 442 438 505 533 571 599 631 657
38 182 205 259 303 338 370 401 435 464 498 526 565 595 628 702 740
40 196 233 294 338 369 410 443 480 519 551 595 629 666 744 787 876
42 225 270 329 368 412 451 492 531 574 614 655 701 736 781 870 927
44 233 285 343 384 429 467 512 557 598 641 684 725 771 862 920 963
46 242 292 357 400 444 490 532 579 623 668 711 754 801 909 955 1006
48 263 314 380 421 472 518 562 609 662 705 750 799 891 943 996 1039
50 276 325 392 443 487 536 586 635 685 731 781 874 927 982 1027 1078
52 284 334 407 457 508 555 610 661 704 756 805 908 961 1012 1065 1119
54 293 347 420 472 525 577 630 679 733 778 881 940 993 1043 1104 1167
56 303 361 433 487 541 600 646 702 752 808 908 966 1022 1085 1150 1241
58 320 378 457 508 562 622 677 731 781 884 946 1005 1063 1125 1221 1279
60 330 389 470 522 582 640 695 754 809 857 973 1032 1101 1163 1258 1323
62 339 401 484 546 605 657 718 774 832 925 1004 1074 1134 1230 1301 1366
64 348 411 500 561 619 682 735 795 904 932 1039 1105 1167 1274 1341 1404
66 365 434 524 583 638 707 765 827 942 947 1072 1136 1239 1308 1377 1449
68 376 447 534 596 661 721 785 850 971 1036 1101 1171 1276 1347 1420 1487
70 385 455 546 613 674 740 806 926 992 1059 1130 1201 1308 1383 1457 1516
72 410 483 587 655 727 800 876 945 1013 1086 1158 1266 1343 1419 1495 1527
Gray Primer (GPZ) nish standard and will be provided unless one of the following optional nishes is indicated:
Available at no extra charge: (T) Tan (DKB) Dark Bronze (BPR) Beige Primer (matches Steelcraft)
(CAB) California Bronze (matches Anemostat) (PTY) Putty (matches Anemostat beige)
Add 15% for following nishes:
(B) Brass (Gold) (GBL) Gloss Black (W) White
(MBL) Matte Black (TBL) Textured Black (ASL) Aluminum Silver
(WB) Walnut Brown (matches Timely Browntone)
(MW) Magnolia White (matches Timely Western White)
Galvanneal - Add 20% Zinc EL-Plate - Add $420
Does NOT comply with IBC 2006 or newer requirements for use in doors or sidelights.
Allowed only in non-hazardous locations dened in IBC
W I D T H
33
Phone: 800-647-7874
Fax: 800-255-7874
www.ngp.com
orders@ngp.com
Phone: 800-647-7874
Fax: 800-255-7874
www.ngp.com
orders@ngp.com
Add $135 per Mullion Bar to
Price of L-GLF100, L-GLF100SP,
L-GLF100-TB, L-GLF100-SP-TB,
L-SG100, L-SG100-TB series Lite Kits
Add:
G2 = 1 Bar $135
G3 = 2 Bars 270
G4 = 2 Bars 270
G6 = 3 Bars 405
G8 = 4 Bars 540
G9 = 4 Bars 540
G10 = 5 Bars 675
G12 = 5 Bars 675
G15 = 6 Bars 810
G18 = 7 Bars 945
G21 = 8 Bars 1,080
G24 = 9 Bars 1,215
G21
(8 Bars)
G24
(9 Bars)
G18
(7 Bars)
G15
(6 Bars)
G8
(4 Bars)
G9
(4 Bars)
G12
(5 Bars)
G10
(5 Bars)
G6
(3 Bars)
G4
(2 Bars)
G2
(1 Bar)
G3
(2 Bars)
False Mullion Bars
L-FRA100 SP with Superlite™ X-90
Available Lite Kit Sizes
12" x 12" $222
5" x 35" $255
6" x 27" $242
7" x 22" $242
3/4" Thick $182 ea.
Available Sizes
11" x 11"
4" x 34"
5" x 26"
6" x 21"
L-FRA-100 SP w/Superlite™ X90 & GT-116 Glazing Tape
Superlite™ X90
GT-116 glazing tape supplied (loose) for both sides:
Add $4.55 per Sq. FT.
Galvanneal – Add 20%
34
NATIONAL GUARD PRODUCTS, INC.Phone: 800-647-7874
Fax: 800-255-7874
www.ngp.com
orders@ngp.com
L-FRA100-SP, L-GLF100-SP, L-GLF100-SP-TB
Lite Kits for Variable Door and Glass Thicknesses
HEIGHT
Gray Primer (GPZ) nish standard and will be provided unless one of the following optional nishes is indicated:
Available at no extra charge: (T) Tan (DKB) Dark Bronze (BPR) Beige Primer (matches Steelcraft)
(CAB) California Bronze (matches Anemostat) (PTY) Putty (matches Anemostat beige)
Add 15% for following nishes:
(B) Brass (Gold) (GBL) Gloss Black (W) White
(MBL) Matte Black (TBL) Textured Black (ASL) Aluminum Silver
(WB) Walnut Brown (matches Timely Browntone)
(MW) Magnolia White (matches Timely Western White)
Galvanneal - Add 20% Zinc EL-Plate - Add $420
6 8 10 12 14 16 18 20 22 24 26 28 30 32 34 36
4 94 94 94 101 106 114 124 124 128 131 138 144 149 153 154 161
6 94 94 94 106 106 119 124 124 131 144 148 151 153 153 154 161
8 94 94 94 114 119 124 124 131 144 148 151 153 153 161 161 165
10 94 94 79 119 124 124 131 144 148 151 153 161 161 161 165 165
12 106 114 119 69 124 131 144 148 151 153 153 161 165 165 165 173
14 87 119 124 124 128 144 148 151 153 153 161 165 165 173 173 190
16 119 124 124 124 144 148 151 153 161 161 161 165 165 173 176 193
18 124 124 133 144 148 151 133 161 161 161 165 165 173 190 190 195
20 124 133 144 148 151 153 161 163 163 165 165 165 190 190 190 195
22 129 100 148 151 153 161 161 163 163 165 165 173 190 190 195 198
24 129 148 151 153 153 161 161 165 165 128 173 195 195 201 201 207
26 119 124 153 153 161 161 165 165 165 158 195 195 201 205 207 208
28 109 153 161 161 165 165 165 165 173 195 195 201 205 207 208 212
30 123 121 161 165 165 165 148 173 190 141 201 205 207 208 212 223
32 153 119 161 165 173 173 149 190 190 150 205 207 208 212 223 227
34 154 143 165 165 173 176 190 190 195 171 207 208 212 223 227 228
36 119 144 165 173 190 193 195 195 198 153 208 212 223 227 228 230
38 158 144 165 183 195 195 201 205 207 210 212 223 227 228 299 309
40 163 165 185 196 196 203 206 208 212 213 225 228 230 301 311 319
42 200 212 225 228 237 247 252 260 269 279 284 297 301 311 319 342
44 206 225 228 237 247 252 260 269 279 284 297 301 311 319 342 351
46 213 228 237 247 252 260 269 279 284 297 301 311 319 342 351 363
48 240 252 260 265 277 284 292 301 316 324 327 337 342 351 363 366
50 247 260 265 277 284 292 301 316 324 327 337 342 351 363 366 371
52 252 265 277 284 292 301 316 324 327 337 342 351 363 366 371 386
54 260 277 284 292 301 316 324 327 337 341 351 363 366 371 386 405
56 269 284 292 301 309 324 327 337 341 351 351 366 371 386 405 415
58 289 301 309 317 324 337 346 351 358 363 374 381 386 405 415 418
60 297 309 317 324 337 346 351 363 368 291 381 386 405 415 418 435
62 305 319 326 339 347 353 364 369 376 356 388 406 416 420 436 445
64 312 326 339 347 353 364 369 376 383 336 406 416 420 436 445 453
66 332 351 363 366 364 383 386 394 405 327 423 426 436 445 453 465
68 342 363 366 373 383 386 394 405 420 423 426 436 445 453 465 475
70 351 366 373 383 386 394 405 420 423 426 436 445 453 465 475 487
72 363 373 383 386 394 405 420 423 426 436 445 453 465 475 487 500
Mullion Bars available for L-GLF100-SP and L-GLF100-SP-TB - price of Lite Kit plus $135 per Mullion Bar
Torx Security Screws - up to 24" x 24" add $12.50, over 24" x 24" add $25
Minimum: 3" width or height; Maximum 88" width or height
Odd inch and fractional sizes, use next largest even size
Lead lining - $6.25 per perimeter inch
STC option - $14 per square ft.
L-FRA100-SP, L-GLF100-SP, L-GLF100-SP-TB
W I D T H
35
Phone: 800-647-7874
Fax: 800-255-7874
www.ngp.com
orders@ngp.com
Phone: 800-647-7874
Fax: 800-255-7874
www.ngp.com
orders@ngp.com
L-SG100, L-SG100-TB
Lite Kits with Security Grille
6 8 10 12 14 16 18 20 22 24 26 28 30 32 34 36
4 244 244 244 244 244 250 256 261 266 275 284 289 294 310 312 322
6 244 244 244 244 250 254 261 266 275 284 289 294 310 312 322 331
8 244 244 244 244 254 261 266 275 284 289 294 310 312 322 331 339
10 244 244 244 250 261 266 275 284 289 294 310 312 322 331 339 349
12 244 244 250 252 266 275 284 289 294 310 312 322 331 339 349 361
14 250 254 261 266 275 284 289 294 310 312 322 331 339 349 361 476
16 254 261 266 275 284 289 294 310 312 322 331 339 349 361 476 536
18 261 266 275 284 289 294 310 312 322 331 339 349 361 476 536 556
20 266 275 284 289 294 310 312 322 331 339 349 361 476 536 556 589
22 275 284 289 294 310 312 322 331 339 349 361 476 536 556 589 603
24 284 289 294 310 312 322 331 339 349 450 476 536 556 589 603 625
26 289 294 310 312 322 331 339 349 361 476 536 556 589 603 625 700
28 294 310 312 322 331 339 349 361 476 536 556 589 603 625 700 733
30 310 312 322 331 339 349 361 476 536 556 589 603 625 700 733 753
32 312 322 331 339 349 361 476 536 556 589 603 625 700 733 753 788
34 322 331 339 349 361 476 536 556 589 603 625 700 733 753 788 805
36 331 339 349 361 476 536 556 589 603 625 700 733 753 788 805 835
38 339 349 361 476 536 556 589 603 625 700 733 753 788 805 835 882
40 350 362 477 537 557 590 604 626 701 734 754 790 806 836 883 897
42 362 477 537 557 590 604 626 701 734 754 790 806 836 883 897 928
44 477 537 557 590 604 626 701 734 754 790 806 836 883 897 928 954
46 537 557 590 604 626 701 734 754 790 806 836 883 897 928 954 977
48 557 590 604 626 701 734 754 790 806 836 883 897 928 954 977 998
50 590 604 626 701 734 754 790 806 836 883 897 928 954 977 998 1036
52 604 626 701 734 754 790 806 836 883 897 928 954 977 998 1036 1060
54 626 701 734 754 790 806 836 883 897 928 954 977 998 1036 1060 1081
56 701 734 754 790 806 836 883 897 928 954 977 998 1036 1060 1081 1115
58 734 754 790 806 836 883 897 928 954 977 998 1036 1060 1081 1115 1137
60 754 790 806 836 883 897 928 954 977 998 1036 1060 1081 1115 1137 1170
62 791 807 837 884 898 929 956 979 999 1037 1062 1082 1116 1138 1171 1236
64 807 837 884 898 929 956 979 999 1037 1062 1082 1116 1138 1171 1236 1296
66 837 884 898 929 956 979 999 1037 1062 1082 1116 1138 1171 1236 1296 1360
68 884 898 929 956 979 999 1037 1062 1082 1116 1138 1171 1236 1296 1360 1427
70 898 929 956 979 999 1037 1062 1082 1116 1138 1171 1236 1296 1360 1427 1497
72 929 956 979 999 1037 1062 1082 1175 1138 1171 1236 1296 1360 1427 1497 1556
HEIGHT
Gray Primer (GPZ) nish standard and will be provided unless one of the following optional nishes is indicated:
Available at no extra charge: (T) Tan (DKB) Dark Bronze (BPR) Beige Primer (matches Steelcraft)
(CAB) California Bronze (matches Anemostat) (PTY) Putty (matches Anemostat beige)
Add 15% for following nishes:
(B) Brass (Gold) (GBL) Gloss Black (W) White
(MBL) Matte Black (TBL) Textured Black (ASL) Aluminum Silver
(WB) Walnut Brown (matches Timely Browntone)
(MW) Magnolia White (matches Timely Western White)
Galvanneal - Add 20% Zinc EL-Plate - Add $420
Mullion Bars available - price of lite kit plus $135 per Mullion Bar
Torx Security Screws - up to 24" x 24" add $12.50, over 24" x 24" add $25
Minimum 3" width or height; maximum 48" width x 88" height
Odd inch and fractional sizes, use next largest even size
Lead lining - $6.25 per perimeter inch
STC option - $14 per square ft.
L-SG100, L-SG100-TB Lite Kits with Security Grille
W I D T H
36
NATIONAL GUARD PRODUCTS, INC.Phone: 800-647-7874
Fax: 800-255-7874
www.ngp.com
orders@ngp.com
6 8 10 12 14 16 18 20 22 24 26 28 30 32 34 36
4 271 271 271 292 307 328 358 358 368 379 399 415 430 440 445 466
6 271 271 271 307 307 343 358 358 379 415 425 435 440 440 445 466
8 271 271 271 328 343 358 358 379 415 425 435 440 440 466 466 476
10 271 271 225 343 358 358 379 415 425 435 440 466 466 466 476 476
12 307 328 343 210 358 379 415 425 435 440 440 466 476 476 476 502
14 256 343 358 358 368 415 425 435 440 440 466 476 476 502 502 548
16 343 358 358 358 415 425 435 440 466 466 466 476 476 502 512 558
18 358 333 384 415 425 435 363 466 466 466 476 476 502 548 548 563
20 358 384 415 425 435 440 466 471 471 476 476 476 548 548 548 563
22 374 302 425 435 440 466 466 471 471 476 476 502 548 548 563 573
24 333 425 435 440 440 466 466 476 476 390 502 563 563 583 583 599
26 353 368 440 440 466 466 476 476 476 440 563 563 583 594 599 604
28 328 440 466 466 476 476 476 476 502 563 563 583 594 599 604 614
30 363 358 466 476 476 476 420 502 548 420 583 594 599 604 614 645
32 440 358 466 476 502 502 425 548 548 445 594 599 604 614 645 655
34 445 420 476 476 502 512 548 548 563 507 599 604 614 645 655 660
36 358 425 476 502 548 558 563 563 573 465 604 614 645 655 660 665
38 455 425 476 527 563 563 583 594 599 609 614 645 655 660 865 896
40 467 472 528 564 564 585 595 600 610 615 646 656 661 866 897 922
42 574 610 646 656 682 712 723 748 774 805 820 856 866 897 922 989
44 595 646 656 682 712 723 748 774 805 820 856 866 897 922 989 1014
46 615 656 682 712 723 748 774 805 820 856 866 897 922 989 1014 1045
48 692 723 748 764 799 820 840 866 912 933 943 973 989 1014 1045 1055
50 712 748 764 799 820 840 866 912 933 943 973 989 1014 1045 1055 1071
52 723 764 799 820 840 866 912 933 943 973 989 1014 1045 1055 1071 1117
54 748 799 820 840 866 912 933 943 973 984 1014 1045 1055 1071 1117 1168
56 774 820 840 866 892 933 943 973 984 835 1014 1055 1071 1117 1168 1199
58 830 866 892 917 933 973 999 1014 1030 1045 1081 1101 1117 1168 1199 1209
60 856 892 917 933 973 999 1014 1045 1060 875 1101 1117 1168 1199 1209 1255
62 877 918 934 975 1000 1016 1046 1062 1082 1026 1118 1169 1200 1210 1256 1282
64 898 934 975 1000 1016 1046 1062 1082 1103 980 1169 1200 1210 1256 1282 1307
66 954 1010 1041 1051 1046 1103 1113 1133 1164 954 1220 1230 1256 1282 1307 1338
68 985 1041 1051 1072 1103 1113 1133 1164 1210 1220 1230 1256 1282 1307 1338 1369
70 1010 1051 1072 1103 1113 1133 1164 1210 1220 1230 1256 1282 1307 1338 1369 1404
72 1041 1072 1103 1113 1133 1164 1210 1220 1230 1256 1282 1307 1338 1369 1404 1440
HEIGHT
L-CVFM-SS
Stainless Steel Lite Kits
Torx Security Screws - up to 24" x 24" add $12.50, over 24" x 24" add $25
Minimum 3" width or height; maximum 88" width or height
Odd inch and fractional sizes, use next largest even size
Lead lining - $6.25 per perimeter inch
STC option - $14 per square ft.
Stainless steel material - #4 nish standard and will be provided unless one of the
following optional nishes is indicated:
Add 15% for following nishes:
(T) Tan (DKB) Dark Bronze
(B) Brass (Gold) (GBL) Gloss Black
(W) White (MBL) Matte Black
(TBL) Textured Black (ASL) Aluminum Silver
(PTY) Putty (matches Anemostat Beige) (GPZ) Gray Primer
(BPR) Beige Primer (matches Steelcraft) (MW) Magnolia White (matches Timely Western White)
(CAB) California Bronze (matches Anemostat) (WB) Walnut Brown (matches Timely Browntone)
L-CVFM-SS Stainless Steel Lite Kits
W I D T H
37
Phone: 800-647-7874
Fax: 800-255-7874
www.ngp.com
orders@ngp.com
Phone: 800-647-7874
Fax: 800-255-7874
www.ngp.com
orders@ngp.com
Complete Kit shipped including polycarbonate plastic, silicone sealant, fasteners and installation instructions.
L-VGLF- PZ 9x9 $222
(1/2" Polycarbonate
L-VGLF- MD 9x9 $268
(1/2" Polycarbonate)
L-VGLF- MDL 12x12 $358
(1/2" Polycarbonate)
L-VGLF- WD 9x5 $214
(1/2"Polycarbonate)
L-VGLF- OG 9x9 $247
(1/2" Polycarbonate)
L-VGLF- SF 11x11 $329
(1/4" Polycarbonate)
Size Gray Primer
L-FRA100-RD-12 12" $295
L-FRA100-RD-18 18" $610
L-FRA100-RD-24 24" $665
Add 15% for following nishes: (T) Tan (PTY) Putty (matches Anemostat Beige)
(W) White (DKB) Dark Bronze (CAB) California Bronze (matches Anemostat)
(B) Brass (Gold) (GBL) Gloss Black (BPR) Beige Primer (matches Steelcraft)
(MBL) Matte Black (TBL) Textured Black (WB) Walnut Brown (matches Timely Browntone)
(ASL) Aluminum Silver (MW) Magnolia White (matches Timely Western White)
Zinc - EL plate - Add $420
Round Lite Kits
Round Lite Kits
L-VGLF Security Lite Kits
L-VGLF Security Lite Kits
For torx security screws add $8
Zinc EL-Plate - Add $420
Gray Primer (GPZ) nish standard and will be provided unless one of
the following optional nishes is indicated:
Available at no extra charge:
(T) Tan (DKB) Dark Bronze
(BPR) Beige Primer (matches Steelcraft)
(PTY) Putty (matches Anemostat Beige)
(CAB) California Bronze (matches Anemostat)
Add 15% for following nishes:
(B) Brass (Gold) (GBL) Gloss Black
(W) White (MBL) Matte Black
(TBL) Textured Black (ASL) Aluminum Silver
(WB) Walnut Brown (matches Timely Browntone)
(MW) Magnolia White (matches Timely Western White)
38
NATIONAL GUARD PRODUCTS, INC.Phone: 800-647-7874
Fax: 800-255-7874
www.ngp.com
orders@ngp.com
6 8 10 12 14 16 18 20 22 24 26 28 30 32 34 36
4 71 76 81 82 84 85 92 96 102 104 109 118 123 133 137 140
6 76 81 82 84 85 92 96 102 104 109 118 123 133 137 140 152
8 81 82 84 84 92 96 102 104 109 118 123 133 137 140 152 160
10 82 84 85 92 96 102 104 109 118 123 133 137 140 152 160 175
12 84 85 92 75 102 103 90 118 123 105 137 140 152 160 175 188
14 85 92 96 102 104 109 118 123 133 137 140 152 160 175 188 198
16 92 96 102 104 109 116 123 133 137 140 152 160 175 188 198 224
18 96 102 104 106 118 123 105 137 140 120 160 175 188 198 224 233
20 102 104 109 118 123 133 137 140 152 160 175 188 198 224 233 251
22 104 109 118 123 133 137 140 152 160 175 188 198 224 233 251 263
24 109 118 123 133 137 140 150 160 175 146 198 224 233 251 263 282
26 118 123 133 137 140 152 160 175 188 198 224 233 251 263 282 304
28 123 133 137 140 152 160 175 188 198 224 233 251 263 282 304 324
30 133 137 140 152 160 175 188 198 224 233 251 263 282 304 324 341
32 137 140 152 160 175 188 198 224 233 251 263 282 304 324 341 359
34 140 152 160 175 188 198 224 233 251 263 282 304 324 341 359 376
36 152 160 175 188 198 224 233 251 263 282 304 324 341 359 376 396
38 163 177 194 201 229 240 254 269 291 310 328 350 365 384 406 420
40 180 197 205 233 243 257 272 294 313 331 354 368 387 410 423 440
42 197 205 233 243 257 272 294 313 331 354 368 387 410 423 440 454
44 205 233 243 257 272 294 313 331 354 368 387 410 423 440 454 467
46 233 243 257 272 294 313 331 354 368 387 410 423 440 454 467 482
48 243 257 272 294 313 331 354 368 387 410 423 440 454 467 482 495
50 257 272 294 313 331 354 368 387 410 423 440 454 467 482 495 510
52 272 294 313 331 354 368 387 410 423 440 454 467 482 495 510 525
54 294 313 331 354 368 387 410 423 440 454 467 482 495 510 525 538
56 313 331 354 368 387 410 423 440 454 467 482 495 510 525 538 551
58 331 354 368 387 410 423 440 454 467 482 495 510 525 538 551 562
60 354 368 387 410 423 440 454 467 482 429 510 525 538 551 562 578
62 373 392 414 427 444 459 471 487 499 515 529 543 555 566 582 662
64 392 414 427 444 459 471 487 499 515 501 543 555 566 582 662 683
66 414 427 444 459 471 487 499 504 529 515 552 566 582 662 683 712
68 427 444 459 471 487 499 515 529 543 555 566 582 662 683 712 745
70 444 459 471 487 499 515 529 543 555 566 582 662 683 712 745 828
72 459 471 487 499 515 529 543 555 566 582 662 683 712 745 828 870
HEIGHT
L-700-RX, L-700-RX-TB, L-700-A, L-700-B, L-700-BF, L-700-C
Steel Louvers
Non-removable aluminum insect screen - Add $13 per square foot.
Torx Security Screws - up to 24" x 24" add $12.50, over 24" x 24" add $25
Minimum 6" width x 4" height; maximum 88" width or height
Odd inch and fractional sizes, use next largest even size
Thru Bolts (TB) - no extra charge
Auxiliary inside frame for L-700-BF $50
L-700-RX, L-700-RX-TB, L-700-A, L-700-B, L-700-BF, L-700-C Steel Louvers
Gray Primer (GPZ) nish standard and will be provided unless one of the following optional nishes is indicated:
Available at no extra charge: (T) Tan (DKB) Dark Bronze (BPR) Beige Primer (matches Steelcraft)
(CAB) California Bronze (matches Anemostat) (PTY) Putty (matches Anemostat beige)
Add 15% for following nishes:
(B) Brass (Gold) (GBL) Gloss Black (W) White
(MBL) Matte Black (TBL) Textured Black (ASL) Aluminum Silver
(WB) Walnut Brown (matches Timely Browntone)
(MW) Magnolia White (matches Timely Western White)
Galvanneal - Add 20% Zinc EL-Plate - Add $420
W I D T H
39
Phone: 800-647-7874
Fax: 800-255-7874
www.ngp.com
orders@ngp.com
Phone: 800-647-7874
Fax: 800-255-7874
www.ngp.com
orders@ngp.com
HEIGHT
L-A700-A, L-A700-B, L-A700-BF, L-A700-C
Aluminum Louvers
6 8 10 12 14 16 18 20 22 24 26 28 30 32 34 36
6 230 230 230 233 240 247 250 263 276 277 289 296 318 329 348 379
8 230 230 233 240 247 250 263 276 277 289 296 318 329 348 379 397
10 230 233 240 247 250 263 276 277 289 296 318 329 348 379 397 434
12 233 240 247 250 263 276 277 289 296 318 329 348 379 397 434 481
14 240 247 250 263 276 277 289 296 318 329 348 379 397 434 481 486
16 247 250 263 276 277 289 296 318 329 348 379 397 434 481 486 549
18 250 263 276 277 289 296 318 329 348 379 397 434 481 486 549 585
20 263 276 277 289 296 318 329 348 379 397 434 481 486 549 585 621
22 276 277 289 296 318 329 348 379 397 434 481 486 549 585 621 654
24 277 289 296 318 329 348 379 397 434 454 486 549 585 621 654 715
26 289 296 318 329 348 379 397 434 481 486 549 585 621 654 715 754
28 296 318 329 348 379 397 434 481 486 549 585 621 654 715 754 805
30 318 329 348 379 397 434 481 486 549 585 621 654 715 754 805 848
32 329 348 379 397 434 481 486 549 585 621 654 715 754 805 848 896
34 348 379 397 434 481 486 549 585 621 654 715 754 805 848 896 952
36 379 397 434 481 486 549 585 621 654 715 754 805 848 896 952 998
38 397 434 481 486 549 585 621 654 715 754 805 848 896 952 998 1044
40 437 485 489 553 588 624 657 718 757 808 851 899 956 1001 1048 1084
42 485 489 553 588 624 657 718 757 808 851 899 956 1001 1048 1084 1115
44 489 553 588 624 657 718 757 808 851 899 956 1001 1048 1084 1115 1154
46 553 588 624 657 718 757 808 851 899 956 1001 1048 1084 1115 1154 1190
48 588 624 657 718 757 808 851 899 956 1001 1048 1084 1115 1154 1190 1218
50 624 657 718 757 808 851 899 956 1001 1048 1084 1115 1154 1190 1218 1252
52 657 718 757 808 851 899 956 1001 1048 1084 1115 1154 1190 1218 1252 1298
54 718 757 808 851 899 956 1001 1048 1084 1115 1154 1190 1218 1252 1298 1326
56 757 808 851 899 956 1001 1048 1084 1115 1154 1190 1218 1252 1298 1326 1359
58 808 851 899 956 1001 1048 1084 1115 1154 1190 1218 1252 1298 1326 1359 1392
60 851 899 956 1001 1048 1084 1115 1154 1190 1218 1252 1298 1326 1359 1392 1420
62 903 960 1005 1052 1088 1119 1159 1194 1222 1256 1303 1330 1363 1396 1424 1628
64 960 1005 1052 1088 1119 1159 1194 1222 1256 1303 1330 1363 1396 1424 1628 1684
66 1005 1052 1088 1119 1159 1194 1222 1256 1303 1330 1363 1396 1424 1628 1684 1773
68 1052 1088 1119 1159 1194 1222 1256 1303 1330 1363 1396 1424 1628 1684 1773 1858
70 1088 1119 1159 1194 1222 1256 1303 1330 1363 1396 1424 1628 1684 1773 1858 2071
72 1119 1159 1194 1222 1256 1303 1330 1363 1396 1424 1628 1684 1773 1858 2071 2220
Non-removable aluminum insect screen - add $13 per square foot.
Torx Security Screws - up to 24" x 24" add $12.50, over 24" x 24" add $25
Minimum 6" width or height; maximum 88" width or height
Odd inch and fractional sizes, use next largest even size
Thru-bolts (TB) no extra charge.
Auxiliary inside frame for L-A700-BF $100
Aluminum material - Aluminum Silver (ASL) nish standard and will be provided unless one of the following optional nishes
is indicated:
Available at no extra charge:
(T) Tan (BPR) Beige Primer (matches Steelcraft)
(DKB) Dark Bronze (PTY) Putty (matches Anemostat Beige)
(GPZ) Gray Primer (CAB) California Bronze (matches Anemostat)
Add 15% for following nishes:
(GBL) Gloss Black (MBL) Matte Black
(B) Brass (Gold) (TBL) Textured Black
(W) White
(MW) Magnolia White (matches Timely Western White)
(WB) Walnut Brown (matches Timely Browntone)
L-A700-A, L-A700-B, L-A700-BF, L-A700-C Aluminum Louvers
W I D T H
40
NATIONAL GUARD PRODUCTS, INC.Phone: 800-647-7874
Fax: 800-255-7874
www.ngp.com
orders@ngp.com
L-1800 Adjustable Blade Louver
L-1900 Fire-rated Fusible Link Louver
10 12 14 16 18 20 22 24
6 245 250 261 269 278 294 298 306
8 250 261 269 278 294 298 306 319
10 261 269 278 294 298 306 319 322
12 269 215 294 298 235 319 322 255
14 277 307 311 319 325 330 334 339
16 307 319 332 338 342 359 367 375
18 319 332 338 342 270 367 375 367
20 332 338 342 370 372 375 380 384
22 338 342 370 375 380 384 388 391
24 342 370 375 380 388 389 391 301
26 375 385 390 395 405 415 425 435
28 385 395 405 415 425 435 445 455
30 395 415 425 435 445 455 465 475
HEIGHT
Non-removable aluminum insect screen - add $13 per square foot.
Torx Security Screws - up to 24" x 24" add $12.50, over 24" x 24" add $25.
Minimum size 10" width x 6" height; maximum 24" width x 30" height.
Odd inch sizes, use next largest even size. Fractional sizes not available.
L-1900, L-1800 Fire-rated Fusible Link Louver
Gray Primer (GPZ) nish standard and will be provided unless one of the following optional nishes is indicated:
Available at no extra charge: (T) Tan (DKB) Dark Bronze (BPR) Beige Primer (matches Steelcraft)
(CAB) California Bronze (matches Anemostat) (PTY) Putty (matches Anemostat beige)
Add 15% for following nishes:
(B) Brass (Gold) (GBL) Gloss Black (W) White
(MBL) Matte Black (TBL) Textured Black (ASL) Aluminum Silver
(WB) Walnut Brown (matches Timely Browntone)
(MW) Magnolia White (matches Timely Western White)
Galvanneal - Add 20%
Replacement Fusible Links $25
W I D T H
41
Phone: 800-647-7874
Fax: 800-255-7874
www.ngp.com
orders@ngp.com
Phone: 800-647-7874
Fax: 800-255-7874
www.ngp.com
orders@ngp.com
HEIGHT
6 8 10 12 14 16 18 20 22 24 26 28 30 32 34 36
4 263 263 263 263 270 274 283 288 305 321 382 417 458 468 542 600
6 263 263 263 270 274 283 288 305 321 382 417 458 468 542 600 638
8 263 263 270 274 283 288 305 321 382 417 458 468 542 600 638 752
10 263 270 274 283 288 305 321 382 417 458 468 542 600 638 752 770
12 270 274 283 288 305 321 382 417 458 468 542 600 638 752 770 780
14 274 283 288 305 321 382 417 458 468 542 600 638 752 770 780 861
16 283 288 305 321 382 417 458 468 542 600 638 752 770 780 861 963
18 288 305 321 382 417 458 468 542 600 638 752 770 780 861 963 997
20 305 321 382 417 458 468 542 600 638 752 770 780 861 963 997 1096
22 321 382 417 458 468 542 600 638 752 770 780 861 963 997 1096 1134
24 382 417 458 468 542 600 638 752 770 780 861 963 997 1096 1134 1198
26 417 458 468 542 600 638 752 770 780 861 963 997 1096 1134 1198 1265
28 458 468 542 600 638 752 770 780 861 963 997 1096 1134 1198 1265 1323
30 468 542 600 638 752 770 780 861 963 997 1096 1134 1198 1265 1323 1363
32 542 600 638 752 770 780 861 963 997 1096 1134 1198 1265 1323 1363 1428
34 600 638 752 770 780 861 963 997 1096 1134 1198 1265 1323 1363 1428 1486
36 638 752 770 780 861 963 997 1096 1134 1198 1265 1323 1363 1428 1486 1565
38 752 770 780 861 963 997 1096 1134 1198 1265 1323 1363 1428 1486 1565 1604
40 770 780 861 963 997 1096 1134 1198 1265 1323 1363 1428 1486 1565 1604 1677
42 780 861 963 997 1096 1134 1198 1265 1323 1363 1428 1486 1565 1604 1677 1750
44 861 963 997 1096 1134 1198 1265 1323 1363 1428 1486 1565 1604 1677 1750 1810
46 963 997 1096 1134 1198 1265 1323 1363 1428 1486 1565 1604 1677 1750 1810 1883
48 997 1096 1134 1198 1265 1323 1363 1428 1486 1565 1604 1677 1750 1810 1883 1934
50 1096 1134 1198 1265 1323 1363 1428 1486 1565 1604 1677 1750 1810 1883 1934 2017
52 1134 1198 1265 1323 1363 1428 1486 1565 1604 1677 1750 1810 1883 1934 2017 2080
54 1198 1265 1323 1363 1428 1486 1565 1604 1677 1750 1810 1883 1934 2017 2080 2155
56 1265 1323 1363 1428 1486 1565 1604 1677 1750 1810 1883 1934 2017 2080 2155 2233
58 1323 1363 1428 1486 1565 1604 1677 1750 1810 1883 1934 2017 2080 2155 2233 2305
60 1363 1428 1486 1565 1604 1677 1750 1810 1883 1934 2017 2080 2155 2233 2305 2390
62 1428 1486 1565 1604 1677 1750 1810 1883 1934 2017 2080 2155 2233 2305 2390 2462
64 1486 1565 1604 1677 1750 1810 1883 1934 2017 2080 2155 2233 2305 2390 2462 2577
66 1565 1604 1677 1750 1810 1883 1934 2017 2080 2155 2233 2305 2390 2462 2577 2688
68 1604 1677 1750 1810 1883 1934 2017 2080 2155 2233 2305 2390 2462 2577 2688 2802
70 1677 1750 1810 1883 1934 2017 2080 2155 2233 2305 2390 2462 2577 2688 2802 2912
72 1750 1810 1883 1934 2017 2080 2155 2233 2305 2390 2462 2577 2688 2802 2912 3025
Textured Black (TBL) nish standard and will be provided unless one of the following optional nishes is indicated:
Available at no extra charge: (T) Tan (DKB) Dark Bronze (BPR) Beige Primer (matches Steelcraft)
(CAB) California Bronze (matches Anemostat) (PTY) Putty (matches Anemostat beige)
Add 15% for following nishes:
(B) Brass (Gold) (GBL) Gloss Black (W) White
(MBL) Matte Black (ASL) Aluminum Silver
(WB) Walnut Brown (matches Timely Browntone)
(MW) Magnolia White (matches Timely Western White)
Zinc EL-Plate - Add $420
L-75-A, L-75-B, L-75-BF
Darkroom Louvers
Non-removable aluminum insect screen - add $13 per square foot
Torx Security Screws - up to 24" x 24" add $12.50, over 24" x 24" add $25
Minimum 6" width x 4" height; maximum 88" width or height
Odd inch and fractional sizes, use next largest even size
Thru-bolts (TB) no extra charge
L-75-A, L-75-B, L-75-BF Darkroom Louvers
W I D T H
42
NATIONAL GUARD PRODUCTS, INC.Phone: 800-647-7874
Fax: 800-255-7874
www.ngp.com
orders@ngp.com
HEIGHT
L-VRSG-2, L-VRSG-2-TB
Louvers with Security Grille
6 8 10 12 14 16 18 20 22 24 26 28 30 32 34 36
4 140 141 150 155 167 172 179 183 194 202 204 207 215 226 239 253
6 141 150 155 167 172 179 183 192 202 204 207 215 226 239 253 280
8 150 155 167 172 179 183 192 202 204 207 215 226 239 253 280 302
10 155 167 172 179 183 192 202 204 207 215 226 239 253 280 302 312
12 167 172 179 179 192 202 201 207 215 220 239 253 280 302 312 315
14 172 179 183 192 202 204 207 215 226 239 253 280 302 312 315 359
16 179 183 192 202 204 207 215 226 239 253 280 302 312 315 359 393
18 183 192 202 204 207 215 220 239 253 280 302 312 315 359 393 413
20 192 202 204 207 215 226 239 253 280 302 312 315 359 393 413 453
22 202 204 207 215 226 239 253 280 302 312 315 359 393 413 453 480
24 204 207 215 226 239 253 280 302 312 315 359 393 413 453 480 517
26 207 215 226 239 253 280 302 312 315 359 393 413 453 480 517 539
28 215 226 239 253 280 302 312 315 359 393 413 453 480 517 539 567
30 226 239 253 280 302 312 315 359 393 413 453 480 517 539 567 604
32 239 253 280 302 312 315 359 393 413 453 480 517 539 567 604 633
34 253 280 302 312 315 359 393 413 453 480 517 539 567 604 633 666
36 280 302 312 315 359 393 413 453 480 517 539 567 604 633 666 692
38 302 312 315 359 393 413 453 480 517 539 567 604 633 666 692 712
40 312 315 359 393 413 453 480 517 539 567 604 633 666 692 712 736
42 315 359 393 413 453 480 517 539 567 604 633 666 692 712 736 755
44 359 393 413 453 480 517 539 567 604 633 666 692 712 736 755 767
46 393 413 453 480 517 539 567 604 633 666 692 712 736 755 767 801
48 413 453 480 517 539 567 604 633 666 692 712 736 755 767 801 823
50 453 480 517 539 567 604 633 666 692 712 736 755 767 801 823 829
52 480 517 539 567 604 633 666 692 712 736 755 767 801 823 829 840
54 517 539 567 604 633 666 692 712 736 755 767 801 823 829 840 849
56 539 567 604 633 666 692 712 736 755 767 801 823 829 840 849 867
58 567 604 633 666 692 712 736 755 767 801 823 829 840 849 867 941
60 604 633 666 692 712 736 755 767 801 823 829 840 849 867 941 969
62 633 666 692 712 736 755 767 801 823 829 840 849 867 941 969 993
64 666 692 712 736 755 767 801 823 829 840 849 867 941 969 993 1030
66 692 712 736 755 767 801 823 829 840 849 867 941 969 993 1030 1037
68 712 736 755 767 801 823 829 840 849 867 941 969 993 1030 1037 1064
70 736 755 767 801 823 829 840 849 867 941 969 993 1030 1037 1064 1085
72 755 767 801 823 829 840 849 867 941 969 993 1030 1037 1064 1085 1110
Non-removable aluminum insect screen - Add $13 per square foot.
Torx Security Screws - up to 24" x 24" add $12.50, over 24" x 24" add $25
Minimum 6" width x 4" height; maximum 48" width x 88" height
Odd inch and fractional sizes, use next largest even size
Gray Primer (GPZ) nish standard and will be provided unless one of the following optional nishes is indicated:
Available at no extra charge: (T) Tan (DKB) Dark Bronze (BPR) Beige Primer (matches Steelcraft)
(CAB) California Bronze (matches Anemostat) (PTY) Putty (matches Anemostat beige)
Add 15% for following nishes:
(B) Brass (Gold) (GBL) Gloss Black (W) White
(MBL) Matte Black (TBL) Textured Black (ASL) Aluminum Silver
(WB) Walnut Brown (matches Timely Browntone)
(MW) Magnolia White (matches Timely Western White)
Galvanneal - Add 20%
Zinc EL-Plate -Add $420
L-VRSG-2, L-VRSG-2-TB Louvers with Security Grille
W I D T H
43
Phone: 800-647-7874
Fax: 800-255-7874
www.ngp.com
orders@ngp.com
Phone: 800-647-7874
Fax: 800-255-7874
www.ngp.com
orders@ngp.com
L-VRSG-3, L-VRSG-3-TB Louvers with Security Grille both Sides
HEIGHT
6 8 10 12 14 16 18 20 22 24 26 28 30 32 34 36
4 154 158 161 165 183 186 198 202 208 229 232 242 258 273 293 304
6 158 161 165 183 186 198 202 208 229 232 242 258 273 293 304 334
8 161 165 182 186 198 202 208 229 232 242 258 273 293 304 334 356
10 165 183 186 198 202 208 229 232 242 258 273 293 304 334 356 371
12 183 186 198 198 208 229 227 242 258 266 293 304 334 356 371 426
14 186 198 202 208 229 232 242 258 273 293 304 334 356 371 426 443
16 198 202 208 229 232 242 258 273 293 304 334 356 371 426 443 476
18 202 208 229 232 242 258 266 293 304 331 356 371 426 443 476 500
20 208 229 232 242 258 273 293 304 334 356 371 426 443 476 500 542
22 229 232 242 258 273 293 304 334 356 371 426 443 476 500 542 578
24 232 242 258 273 293 304 334 356 371 426 443 476 500 542 578 609
26 242 258 273 293 304 334 356 371 426 443 476 500 542 578 609 643
28 258 273 293 304 334 356 371 426 443 476 500 542 578 609 643 703
30 273 293 304 334 356 371 426 443 476 500 542 578 609 643 703 714
32 293 304 334 356 371 426 443 476 500 542 578 609 643 703 714 749
34 304 334 356 371 426 443 476 500 542 578 609 643 703 714 749 783
36 334 356 371 426 443 476 500 542 578 609 643 703 714 749 783 815
38 356 371 426 443 476 500 542 578 609 643 703 714 749 783 815 840
40 371 426 443 476 500 542 578 609 643 703 714 749 783 815 840 867
42 426 443 476 500 542 578 609 643 703 714 749 783 815 840 867 888
44 443 476 500 542 578 609 643 703 714 749 783 815 840 867 888 903
46 476 500 542 578 609 643 703 714 749 783 815 840 867 888 903 940
48 500 542 578 609 643 703 714 749 783 815 840 867 888 903 940 986
50 542 578 609 643 703 714 749 783 815 840 867 888 903 940 986 1003
52 578 609 643 703 714 749 783 815 840 867 888 903 940 986 1003 1013
54 609 643 703 714 749 783 815 840 867 888 903 940 986 1003 1013 1036
56 643 703 714 749 783 815 840 867 888 903 940 986 1003 1013 1036 1063
58 703 714 749 783 815 840 867 888 903 940 986 1003 1013 1036 1063 1215
60 714 749 783 815 840 867 888 903 940 986 1003 1013 1036 1063 1215 1249
62 749 783 815 840 867 888 903 940 986 1003 1013 1036 1063 1215 1249 1315
64 783 815 840 867 888 903 940 986 1003 1013 1036 1063 1215 1249 1315 1364
66 815 840 867 888 903 940 986 1003 1013 1036 1063 1215 1249 1315 1364 1379
68 840 867 888 903 940 986 1003 1013 1036 1063 1215 1249 1315 1364 1379 1410
70 867 888 903 940 986 1003 1013 1036 1063 1215 1249 1315 1364 1379 1410 1440
72 888 903 940 986 1003 1013 1036 1063 1215 1249 1315 1364 1379 1410 1440 1484
L-VRSG-3, L-VRSG-3-TB
Louvers with Security Grille both Sides
Non-removable aluminum insect screen - Add $13 per square foot
Torx Security Screws - up to 24" x 24" add $12.50, over 24" x 24" add $25
Minimum 6" width x 4" height; maximum 48" width x 88" height
Odd inch and fractional sizes, use next largest even size
Gray Primer (GPZ) nish standard and will be provided unless one of the following optional nishes is indicated:
Available at no extra charge: (T) Tan (DKB) Dark Bronze (BPR) Beige Primer (matches Steelcraft)
(CAB) California Bronze (matches Anemostat) (PTY) Putty (matches Anemostat beige)
Add 15% for following nishes:
(B) Brass (Gold) (GBL) Gloss Black (W) White
(MBL) Matte Black (TBL) Textured Black (ASL) Aluminum Silver
(WB) Walnut Brown (matches Timely Browntone)
(MW) Magnolia White (matches Timely Western White)
Galvanneal - Add 20%
Zinc EL-Plate - Add $420
W I D T H
44
NATIONAL GUARD PRODUCTS, INC.Phone: 800-647-7874
Fax: 800-255-7874
www.ngp.com
orders@ngp.com
5 6 7 8 10 12 14 16 18 20 22 24 26 28 30 32 34 36
4 112 112 112 112 112 112 112 112 112 112 112 112 112 112 112 112 112 112
6 112 112 112 112 112 112 112 112 112 112 112 112 122 131 140 150 159 169
8 112 112 112 112 112 112 112 112 112 125 137 150 162 175 187 200 212 225
10 112 112 112 112 112 112 112 125 140 156 172 187 203 218 234 250 265 281
12 112 112 112 112 112 112 131 150 169 187 206 225 243 262 281 300 318 337
14 112 112 112 112 112 131 153 175 197 218 240 262 284 306 328 350 371 393
16 112 112 112 112 125 150 175 200 225 250 275 300 325 350 375 399 424 449
18 112 112 112 112 140 169 197 225 253 281 309 337 365 393 421 449 477 506
20 112 112 112 125 156 187 218 250 281 312 343 375 406 437 468 499 531 562
22 112 112 112 137 172 206 240 275 309 343 378 412 446 481 515 549 584 618
24 112 112 131 150 187 225 262 300 337 375 412 449 487 524 562 599 637 674
26 112 122 142 162 203 243 284 325 365 406 446 487 527 568 609 649 690 730
28 112 131 153 175 218 262 306 350 393 437 481 524 568 612 655 699 743 786
30 112 140 164 187 234 281 328 375 421 468 515 562 609 655 702 749 796 843
32 112 150 175 200 250 300 350 399 449 499 549 599 649 699 749 799 849 899
34 112 159 186 212 265 318 371 424 477 531 584 637 690 743 796 849 902 955
36 140 169 197 225 281 337 393 449 506 562 618 674 730 786 843 899 955 1011
38 148 178 208 237 296 356 415 474 534 593 652 712 771 830 889 949 1008 1067
40 172 206 240 275 343 412 481 549 618 687 755 824 893 961 1030 1099 1167 1348
42 180 216 252 288 360 433 505 577 649 721 793 865 937 1009 1081 1153 1337 1416
44 189 227 264 302 378 453 529 604 680 755 831 906 982 1057 1133 1318 1401 1483
46 197 237 276 316 395 474 553 632 711 790 869 947 1026 1105 1184 1378 1464 1550
48 206 247 288 330 412 494 577 659 742 824 906 989 1071 1153 1348 1438 1528 1618
50 215 257 300 343 429 515 601 687 772 858 944 1030 1116 1311 1404 1498 1592 1685
52 223 268 312 357 446 536 625 714 803 893 982 1071 1160 1363 1461 1558 1655 1753
54 232 278 324 371 463 556 649 742 834 927 1020 1112 1314 1416 1517 1618 1719 1820
56 240 288 336 384 481 577 673 769 865 961 1057 1153 1363 1468 1573 1678 1783 1966
58 249 299 348 398 498 597 697 796 896 996 1095 1303 1412 1520 1629 1738 1923 2036
60 257 309 360 412 515 618 721 824 927 1030 1133 1348 1461 1573 1685 1798 1990 2107
62 266 319 372 426 532 639 745 851 958 1064 1171 1393 1509 1625 1741 1935 2056 2177
64 275 330 384 439 549 659 769 879 989 1099 1318 1438 1558 1678 1798 1997 2122 2247
66 283 340 397 453 566 680 793 906 1020 1133 1359 1483 1607 1730 1931 2060 2188 2317
68 292 350 409 467 584 700 817 934 1050 1167 1401 1528 1655 1783 1990 2122 2255 2387
70 300 360 421 481 601 721 841 961 1081 1311 1442 1573 1704 1835 2048 2185 2321 2422
72 337 404 472 539 674 809 944 1079 1213 1348 1483 1618 1753 1966 2107 2247 2387 2496
With GT-118 glazing tape supplied (loose) for both sides:
Add $4.55 per square foot to each piece of glass.
HEIGHT
SuperLite™ I-W
Safety Wired Glass
U.S. Patent No. 7,090,906
Meets CPSC 16CFR 1201 category II impact safety requirements
Etched with UL Fire-rating classication on each piece
Odd inch or fractional sizes, use next largest size
Under 3" - call for quote
Full sheet = 57" x 100"
Glass for Round Lite Kits:
to t in kits 12" $ 520
18" $ 1,020
24" $ 1,255
SuperLite™ I-W Safety Wired Glass
W I D T H
45
Phone: 800-647-7874
Fax: 800-255-7874
www.ngp.com
orders@ngp.com
Phone: 800-647-7874
Fax: 800-255-7874
www.ngp.com
orders@ngp.com
Pyran® F
Meets CPSC 16CFR 1201 Cat. I & II impact safety requirements
Etched with UL re-rating classication on each piece.
Odd inch or fractional sizes, use next largest size
Full sheet = 43" x 77"
5 6 7 8 10 12 14 16 18 20 22 24 26 28 30 32 34 36
4 199 199 199 199 199 199 199 199 199 199 199 199 199 199 199 199 199 199
6 199 199 199 199 199 199 199 199 199 199 199 199 216 232 249 266 282 299
8 199 199 199 199 199 199 199 199 199 221 243 266 288 310 332 354 376 398
10 199 199 199 199 199 199 199 221 249 277 304 332 360 387 415 443 470 498
12 199 199 199 199 199 199 232 266 299 332 365 398 431 465 498 531 564 597
14 199 199 199 199 199 232 271 310 349 387 426 465 503 542 581 620 658 697
16 199 199 199 199 221 266 310 354 398 443 487 531 575 620 664 708 752 797
18 199 199 199 199 249 299 349 398 448 498 548 597 647 697 747 797 846 896
20 199 199 199 221 277 332 387 443 498 553 609 664 719 774 830 885 940 996
22 199 199 199 243 304 365 426 487 548 609 669 730 791 852 913 974 1034 1095
24 199 199 232 266 332 398 465 531 597 664 730 797 863 929 996 1062 1129 1195
26 199 216 252 288 360 431 503 575 647 719 791 863 935 1007 1079 1151 1223 1294
28 199 232 271 310 387 465 542 620 697 774 852 929 1007 1084 1162 1239 1317 1394
30 199 249 290 332 415 498 581 664 747 830 913 996 1079 1162 1245 1328 1411 1494
32 199 266 310 354 443 531 620 708 797 885 974 1062 1151 1239 1328 1416 1505 1593
34 199 282 329 376 470 564 658 752 846 940 1034 1129 1223 1317 1411 1505 1599 1693
36 249 299 349 398 498 597 697 797 896 996 1095 1195 1294 1394 1494 1593 1693 1792
38 263 315 368 420 526 631 736 841 946 1051 1156 1261 1366 1471 1577 1682 1787 1892
40 304 365 426 487 609 730 852 974 1095 1217 1339 1460 1582 1704 1826 1947 2069 2390
42 319 383 447 511 639 767 895 1022 1150 1278 1406 1533 1661 1789 1917 2045 2370 2509
44 335 402 469 535 669 803 937 1071 1205 1339 1473 1606 1740 1874 2008 2337 2483 2629
46 350 420 490 560 700 840 980 1120 1260 1400 1540 1679 1819 1959 2099 2443 2596 2748
48 365 438 511 584 730 876 1022 1168 1314 1460 1606 1753 1899 2045 2390 2549 2708 2868
50 380 456 532 609 761 913 1065 1217 1369 1521 1673 1826 1978 2323 2489 2655 2821 2987
52 396 475 554 633 791 949 1107 1266 1424 1582 1740 1899 2057 2416 2589 2762 2934 3107
54 411 493 575 657 821 986 1150 1314 1479 1643 1807 1972 2330 2509 2689 2868 3047 3226
56 426 511 596 682 852 1022 1193 1363 1533 1704 1874 2045 2416 2602 2788 2974 3160 3485
58 441 529 618 706 882 1059 1235 1412 1588 1765 1941 2310 2503 2695 2888 3080 3409 3610
60 456 548 639 730 913 1095 1278 1460 1643 1826 2008 2390 2589 2788 2987 3186 3527 3734
62 472 566 660 755 943 1132 1320 1509 1698 1886 2075 2469 2675 2881 3087 3430 3644 3859
64 487 584 682 779 974 1168 1363 1558 1753 1947 2337 2549 2762 2974 3186 3540 3762 3983
66 502 602 703 803 1004 1205 1406 1606 1807 2008 2410 2629 2848 3067 3423 3651 3879 4107
68 517 621 724 828 1034 1241 1448 1655 1862 2069 2483 2708 2934 3160 3527 3762 3997 4232
70 532 639 745 852 1065 1278 1491 1704 1917 2323 2556 2788 3020 3253 3630 3872 4114 4294
72 597 717 836 956 1195 1434 1673 1912 2151 2390 2629 2868 3107 3485 3734 3983 4232 4425
74 613 737 860 982 1229 1474 1719 1966 2211 2456 2702 2947 3192 3583 3838 4093 4349 4578
76 631 757 883 1009 1261 1514 1766 2018 2724 2523 2775 3027 3279 3679 3942 4204 4578 4578
77 639 767 895 1022 1278 1533 1789 2045 2760 2556 2811 3067 3461 3727 3993 4425 4578 4578
Pyran® F
HEIGHT
With GT-118 glazing tape supplied (loose) for both sides: Add $4.55 per square foot to each piece of glass.
Glass for Round Lite Kits:
to t in kits 12" $ 865
18" 1,665
24" 2,065
W I D T H
46
NATIONAL GUARD PRODUCTS, INC.Phone: 800-647-7874
Fax: 800-255-7874
www.ngp.com
orders@ngp.com
Pyran® L, Superlite™ I-20,
Superlite™ II-XL Glass
Pyran® L, Superlite™ I-20, Superlite™ II-XL Glass
Replacement Fasteners
Pyran® L
3/8" Thick Call for quote
Full sheet = 43" x 77"
SuperLite™ I-20
1/4" Thick Call for quote
SuperLite™ II-XL
45 Minute 3/4" Thick Call for quote
60 Minute 1-1/8" Thick
90 Minute 1-1/2" Thick
Fasteners are nished to match Lite or Louver. Specify color when ordering separately.
Standard Fasteners:
L-GLF100-TB Thru-Bolts (TB) $2.40 / EA.
Torx Security Thru-Bolts 3.80 / EA.
L-GLF100/L-GLF100-SP #6 x 1-3/4" Truss Head SMS .41 / EA.
#6 x 1-3/4" TORX 1.95 / EA.
L-GLF100-SP #6 x 1" Truss Head SMS .39 / EA.
L-700-RX, L-1800, L-1900 #8 x 3/4" Oval Phillips head SMS .37 / EA.
#8 x 3/4" Torx Security SMS 1.85 / EA.
L-FRA100 #8 x 1-3/4" Oval Phillips Head SMS .44 / EA.
L-FRA100-SP #8 x 1-1/4" Oval Phillips Head SMS .40 / EA.
#8 x 1-3/4" Oval Phillips Head SMS .44 / EA.
#8 x 1-3/4" Torx Security SMS 2.10 / EA.
L-700, L-A700, L-75 #8 x 3/4" Phillips Head TEK .42 / EA.
L-VGLF series #8 x 1" Phillips Oval TEK .46 / EA.
#8 x 1/2" hex washer TEK .50 / EA.
Replacement Fasteners
47
Phone: 800-647-7874
Fax: 800-255-7874
www.ngp.com
orders@ngp.com
Phone: 800-647-7874
Fax: 800-255-7874
www.ngp.com
orders@ngp.com
5 6 7 8 10 12 14 16 18 20 22 24 26 28 30 32 34 36
4 51 51 51 51 51 51 51 51 51 51 51 51 51 51 51 51 51 51
6 51 51 51 51 51 51 51 51 51 51 51 51 56 60 64 69 73 77
8 51 51 51 51 51 51 51 51 51 57 63 69 74 80 86 91 97 103
10 51 51 51 51 51 51 51 57 64 71 79 86 93 100 107 114 121 129
12 51 51 51 51 51 51 60 69 77 86 94 103 111 120 129 137 146 154
14 51 51 51 51 51 60 70 80 90 100 110 120 130 140 150 160 170 180
16 51 51 51 51 57 69 80 91 103 114 126 137 149 160 172 183 194 206
18 51 51 51 51 64 77 90 103 116 129 141 154 167 180 193 206 219 232
20 51 51 51 57 71 86 100 114 129 143 157 172 186 200 214 229 243 257
22 51 51 51 63 79 94 110 126 141 157 173 189 204 220 236 252 267 283
24 51 51 60 69 86 103 120 137 154 172 189 206 223 240 257 274 292 309
26 51 56 65 74 93 111 130 149 167 186 204 223 242 260 279 297 316 334
28 51 60 70 80 100 120 140 160 180 200 220 240 260 280 300 320 340 360
30 51 64 75 86 107 129 150 172 193 214 236 257 279 300 322 343 364 386
32 51 69 80 91 114 137 160 183 206 229 252 274 297 320 343 366 389 412
34 51 73 85 97 121 146 170 194 219 243 267 292 316 340 364 389 413 437
36 64 77 90 103 129 154 180 206 232 257 283 309 334 360 386 412 437 463
38 68 81 95 109 136 163 190 217 244 272 299 326 353 380 407 434 462 489
40 79 94 110 126 157 189 220 252 283 314 346 377 409 440 472 503 535 617
42 83 99 116 132 165 198 231 264 297 330 363 396 429 462 495 528 612 648
44 86 104 121 138 173 208 242 277 311 346 380 415 450 484 519 604 641 679
46 90 108 127 145 181 217 253 289 325 362 398 434 470 506 542 631 671 710
48 94 113 132 151 189 226 264 302 340 377 415 453 490 528 617 659 700 741
50 98 118 138 157 197 236 275 314 354 393 432 472 511 600 643 686 729 772
52 102 123 143 163 204 245 286 327 368 409 450 490 531 624 669 713 758 803
54 106 127 149 170 212 255 297 340 382 424 467 509 602 648 695 741 787 833
56 110 132 154 176 220 264 308 352 396 440 484 528 624 672 720 768 816 900
58 114 137 160 182 228 274 319 365 410 456 501 597 647 696 746 796 881 933
60 118 141 165 189 236 283 330 377 424 472 519 617 669 720 772 823 911 965
62 122 146 171 195 244 292 341 390 439 487 536 638 691 744 797 886 941 997
64 126 151 176 201 252 302 352 402 453 503 604 659 713 768 823 915 972 1029
66 130 156 182 208 259 311 363 415 467 519 623 679 736 792 884 943 1002 1061
68 134 160 187 214 267 321 374 428 481 535 641 700 758 816 911 972 1033 1093
70 138 165 193 220 275 330 385 440 495 600 660 720 780 840 938 1000 1063 1109
72 154 185 216 247 309 370 432 494 556 617 679 741 803 900 965 1029 1093 1111
With GT-118 glazing tape supplied (loose) for both sides:
Add $4.55 per square foot to each piece of glass
With GT-9800 intumescent glazing tape supplied (loose) for both sides:
Add $16.75 per square foot to each piece of glass
HEIGHT
1/4" Wired Glass - Diamond
Etched with UL Fire-rating classication on each piece up to 1,296 sq. inches visible area - 54" max. width or height
Odd inch or fractional sizes, use next largest size
Under 3" - call for quote
Full sheet = 48" x 100"
Glass for Round Lite Kits:
to t in kits 12" $205
18" $385
24" $500
1/4" Wired Glass- Diamond
Does NOT comply with IBC 2006 or newer requirements for use in doors
or sidelights. Allowed only in non-hazardous locations dened in IBC
W I D T H
48
NATIONAL GUARD PRODUCTS, INC.Phone: 800-647-7874
Fax: 800-255-7874
www.ngp.com
orders@ngp.com
Tempered Glass - 1/4"
TEMPERED GLASS - 1/4''
Meets CPSC 16CFR 1201 Cat. I & II impact safety requirements
Minimum 11" height. Full sheet = 84" x 144"
Odd inch or fractional sizes, use next largest size
6 8 10 12 14 16 18 20 22 24 26 28 30 32 34 36
12 57 57 57 57 57 57 57 57 57 57 57 57 57 57 57 57
14 57 57 57 57 57 57 57 57 57 57 57 57 57 77 77 77
16 57 57 57 57 57 57 57 57 57 57 57 77 77 77 77 77
18 57 57 57 57 57 57 57 57 57 57 77 77 77 77 96 96
20 57 57 57 57 57 57 57 57 77 77 77 77 96 96 96 96
22 57 57 57 57 57 57 57 77 77 77 77 96 96 96 115 115
24 57 57 57 57 57 57 57 77 77 77 96 96 96 115 115 115
26 57 57 57 57 57 57 77 77 77 96 96 115 115 115 134 134
28 57 57 57 57 57 77 77 77 96 96 115 115 115 134 134 134
30 57 57 57 57 57 77 77 96 96 96 115 115 134 134 153 153
32 57 57 57 57 77 77 77 96 96 115 115 134 134 153 153 153
34 57 57 57 57 77 77 96 96 115 115 134 134 153 153 172 172
36 57 57 57 57 77 77 96 96 115 115 134 134 153 153 172 172
38 57 57 57 77 77 96 96 115 115 134 134 153 153 172 172 192
40 57 57 57 77 77 96 96 115 134 134 153 153 172 172 192 192
42 57 57 57 77 96 96 115 115 134 134 153 172 172 192 192 211
44 57 57 77 77 96 96 115 134 134 153 153 172 192 192 211 211
46 57 57 77 77 96 115 115 134 153 153 172 172 192 211 211 230
48 57 57 77 77 96 115 115 134 153 153 172 192 192 211 230 230
50 57 57 77 96 96 115 134 134 153 172 192 192 211 230 230 249
52 57 57 77 96 115 115 134 153 153 172 192 211 211 230 249 249
54 57 57 77 96 115 115 134 153 172 172 192 211 230 230 249 268
56 57 77 77 96 115 134 134 153 172 192 211 211 230 249 268 268
58 57 77 96 96 115 134 153 172 172 192 211 230 249 249 268 287
60 57 77 96 96 115 134 153 172 192 192 211 230 249 268 287 287
62 57 77 96 115 134 134 153 172 192 211 230 249 249 268 287 306
64 57 77 96 115 134 153 153 172 192 211 230 249 268 287 306 306
66 57 77 96 115 134 153 172 192 211 211 230 249 268 287 306 326
68 57 77 96 115 134 153 172 192 211 230 249 268 287 306 326 326
70 57 77 96 115 134 153 172 192 211 230 249 268 287 306 326 345
72 57 77 96 115 134 153 172 192 211 230 249 268 287 306 326 345
With GT-118 glazing tape supplied (loose) for both sides: Add $4.55 per square foot to each piece of glass.
Glass for Round Lite Kits:
to t in kits 12" $200
18" 375
24" 490
HEIGHT
W I D T H
49
Phone: 800-647-7874
Fax: 800-255-7874
www.ngp.com
orders@ngp.com
Phone: 800-647-7874
Fax: 800-255-7874
www.ngp.com
orders@ngp.com
LAMINATED GLASS - 1/4''
Meets CPSC 16CFR 1201 Cat. I & II impact safety requirements
Minimum size 3”. Full sheet sizes 60” x 120”, 72” x 96”
Odd inch or fractional sizes, use next largest size
6 8 10 12 14 16 18 20 22 24 26 28 30 32 34 36
4 132 132 132 132 132 132 132 132 132 132 132 132 132 132 132 132
6 132 132 132 132 132 132 132 132 132 132 132 132 132 132 132 132
8 132 132 132 132 132 132 132 132 132 132 132 132 132 132 132 132
10 132 132 132 132 132 132 132 132 132 132 132 132 132 132 132 132
12 132 132 132 132 132 132 132 132 132 132 132 132 132 132 132 132
14 132 132 132 132 132 132 132 132 132 132 132 132 132 176 176 176
16 132 132 132 132 132 132 132 132 132 132 132 176 176 176 176 176
18 132 132 132 132 132 132 132 132 132 132 176 176 176 176 220 220
20 132 132 132 132 132 132 132 132 176 176 176 176 220 220 220 220
22 132 132 132 132 132 132 132 176 176 176 176 220 220 220 264 264
24 132 132 132 132 132 132 132 176 176 176 220 220 220 264 264 264
26 132 132 132 132 132 132 176 176 176 220 220 264 264 264 308 308
28 132 132 132 132 132 176 176 176 220 220 264 264 264 308 308 308
30 132 132 132 132 132 176 176 220 220 220 264 264 308 308 352 352
32 132 132 132 132 176 176 176 220 220 264 264 308 308 352 352 352
34 132 132 132 132 176 176 220 220 264 264 308 308 352 352 396 396
36 132 132 132 132 176 176 220 220 264 264 308 308 352 352 396 396
38 132 132 132 176 176 220 220 264 264 308 308 352 352 396 396 440
40 132 132 132 176 176 220 220 264 308 308 352 352 396 396 440 440
42 132 132 132 176 220 220 264 264 308 308 352 396 396 440 440 484
44 132 132 176 176 220 220 264 308 308 352 352 396 440 440 484 484
46 132 132 176 176 220 264 264 308 352 352 396 396 440 484 484 528
48 132 132 176 176 220 264 264 308 352 352 396 440 440 484 528 528
50 132 132 176 220 220 264 308 308 352 396 440 440 484 528 528 572
52 132 132 176 220 264 264 308 352 352 396 440 484 484 528 572 572
54 132 132 176 220 264 264 308 352 396 396 440 484 528 528 572 616
56 132 176 176 220 264 308 308 352 396 440 484 484 528 572 616 616
58 132 176 220 220 264 308 352 396 396 440 484 528 572 572 616 660
60 132 176 220 220 264 308 352 396 440 440 484 528 572 616 660 660
62 132 176 220 264 308 308 352 396 440 484 528 572 572 616 660 704
64 132 176 220 264 308 352 352 396 440 484 528 572 616 660 704 704
66 132 176 220 264 308 352 396 440 484 484 528 572 616 660 704 748
68 132 176 220 264 308 352 396 440 484 528 572 616 660 704 748 748
70 132 176 220 264 308 352 396 440 484 528 572 616 660 704 748 792
72 132 176 220 264 308 352 396 440 484 528 572 616 660 704 748 792
With GT-118 glazing tape supplied (loose) for both sides: Add $4.55 per square foot to each piece of glass.
Glass for Round Lite Kits:
to t in kits 12" $450
18" 550
24" 650
HEIGHT
Laminated Glass - 1/4"
W I D T H
50
NATIONAL GUARD PRODUCTS, INC.Phone: 800-647-7874
Fax: 800-255-7874
www.ngp.com
orders@ngp.com
Insulated Tempered, Polycarbonate Glass, Glazing Tape
Insulated Tempered, Polycarbonate Glass,
Glazing Tape & Accessories
Prices per Sq. FT. on this page apply to each piece of glass, rounded up to the next whole foot.
Insulated Tempered Glass - 1" Thick
Each Piece:
1-3 Sq. Feet $225 / EA.
4 or more Sq. Ft. $75 per Sq. FT.
Minimum height = 11"
Full sheet = 84" x 144"
Polycarbonate - 1/4" Thick
Each Piece:
All Sizes $72 per Sq. FT.
Full sheet = 48" x 96"
For round Lite Kits:
to t in 12" $200
18" 425
24" 725
Polycarbonate - 1/2" Thick
Each Piece:
All Sizes $105 per Sq. FT.
Full Sheet = 48" x 96"
With GT-118 Glazing Tape supplied both sides
Add $4.55 per Sq. FT.
Packaged with Lite Kit - Use glass pricing with
glazing tape, plus lite kit
With GT-118 Glazing Tape supplied both sides
Add $4.55 per Sq. FT.
Packaged with Lite Kit - Use glass pricing with
glazing tape, plus lite kit
With GT-118 Glazing Tape supplied both sides
Add $4.55 per Sq. FT.
Packaged with Lite Kit (L-FRA100-SP or
L-GLF100-SP - for 1-3/4" door with 1/2" glass) -
Use glass pricing with glazing tape, plus lite kit
Butyl Rubber Glazing Tape
GT-16 3/8" wide x 1/16" thick $28 /50' roll
Accessories
L-Clips $3.00 / EA.
Touch-up spray paint - 12 oz. cans* $39 / EA.
Colors: ASL, BPR, CAB, DKB, GBL, GPZ, MBL, MW,
PTY, TAN, TBL, W, WB
*Ground Shipments to Continental US only.
Closed cell PVC foam Glazing Tape
GT-116 3/8" wide x 1/16" thick $83 /200' roll
GT-118 3/8" wide x 1/8" thick $57 /100' roll
GT-132 3/8" wide x 1/32" thick $82 /200' roll
Intumescent Glazing Tape
GT-9800 1/2" x 1/16" thick $2.05/ FT.
Glazing Tape and Accessories
51
Phone: 800-647-7874
Fax: 800-255-7874
www.ngp.com
orders@ngp.com
Phone: 800-647-7874
Fax: 800-255-7874
www.ngp.com
orders@ngp.com
Door Edges and Astragals
Door Edges Astragals
540 541 550, 552, 551, 553,
542 543 560, 562, 555, 561,
545 570, 572, 574 563
Door Height
Ea. Set Ea. Set
4'0" 44
6'8" 73 104 84 122
7'0" 75 106 86 124
8'0" 88 122 99 140
9'0" 100 140 115 160
10'0" 110 160 126 182
Stainless Steel, #4 Brushed Finish
Door Edges Astragals
540SS 541SS 550SS, 552SS, 551SS, 553SS,
542SS 543SS, 545SS 560SS, 562SS, 555SS, 561SS
570SS, 572SS, 574SS 563SS
Door Height
EA. Set EA. Set
4'0" 110
6'8" 185 260 210 305
7'0" 190 265 220 310
8'0" 220 305 250 350
9'0" 250 340 290 395
10'0" 270 380 310 435
Options:
Special door thicknesses - 1-3/8", 2", 2-1/4" Add $22
Hardware Preps: Lock faces, strikes, ush bolts Add $20 per cut out
Galvanneal Add 20%
Lead lined Add $27 / FT.
Torx Security screws #8 x 3/4" Add $1.85 / FT.
Finishes other than Tan, DKB, GPZ, BPR, CAB, PTY Add 15%
Door Aligning Astragals
565, 575 565SS, 575SS
9" Height EA. EA.
Blank 35 85
ASA 56 107
FB 56 107
T 56 107
Insulated Tempered, Polycarbonate Glass,
Glazing Tape & Accessories
Door Edges and Astragals
52
NATIONAL GUARD PRODUCTS, INC.Phone: 800-647-7874
Fax: 800-255-7874
www.ngp.com
orders@ngp.com
53
Phone: 800-647-7874
Fax: 800-255-7874
www.ngp.com
orders@ngp.com
Phone: 800-647-7874
Fax: 800-255-7874
www.ngp.com
orders@ngp.com
Options:
1/2 Wood Screws ......no charge
Torx Screws
(TEK & T.B. M.S.) ....... 31.00
Anti-Ligature Hospital Tips:
ALHT (Concealed Models Only) . 94.00
TIPIT® LG (Surface Models) .. 125.00
Cut Hinge to Net Length ... 16.00
Dutch Door Prep ......... 99.00
Electric Options on next page
Continuous Geared Hinges
Bulk pack any order - 5% Discount
• Does not apply to hinge option charges
• Only applies to line items of 2 or more.
Prices are Each
Model 83" 83" Std. Bulk Pack 85" 95" 119"
HD1100A 149 141.55 EA. 6-pack 149 194 303
HD1100A-LL 169 169 214 323
HD1100DKB 193 193 249 395
HD1100DKB-LL 213 213 269 415
HD1400A 159 159 202 303
HD1400A-LL 179 179 222 323
HD1400DKB 199 199 260 395
HD1400DKB-LL 219 219 280 415
HD1800A 159 159 202 303
HD1800A-LL 179 179 222 323
HD1800DKB 199 199 260 395
HD1800DKB-LL 219 219 280 415
HD2100A 222 210.90 EA. 4-pack 222 273 477
HD2100DKB 260 260 335 531
HD2400A 155 147.25 EA. 6-pack 155 202 303
HD2400A-LL 175 175 222 323
HD2400DKB 195 195 254 385
HD2400DKB-LL 215 215 274 405
HD2700A 172 172 218 337
HD2700A-LL 192 192 238 357
HD2700DKB 222 222 280 433
HD2700DKB-LL 242 242 300 453
HD4100A 272 272 363 550
HD4100A-LL 292 292 383 570
HD4100DKB 365 365 463 717
HD4100DKB-LL 385 385 483 737
HD4200A 272 272 363 550
HD4200DKB 365 365 463 717
HD5300A 220 220 275 442
HD5300DKB 290 290 351 599
HD5400A 227 227 280 454
HD5400DKB 290 290 351 599
HD5700A 222 210.90 EA. 4-pack 222 271 478
HD5700DKB 260 260 335 533
Freight prepaid and allowed $1500 net
separately or combined with other
products within continental US.
Continuous Geared Hinges
54
NATIONAL GUARD PRODUCTS, INC.Phone: 800-647-7874
Fax: 800-255-7874
www.ngp.com
orders@ngp.com
Replacement Fastener Covers: Finish 83" 85" 95" 119"
Door Leaf A 37 37 44 51
DKB 46 46 54 62
Frame Leaf A 38 38 45 52
DKB 47 47 55 63
Replacement Fasteners: Finish 83", 85", 95", 119"
Screw Pack Concealed Models A 14.00
HD1100, HD1400, HD1800, HD2400, DKB 14.00
HD2700, HD4100. Specify model and length.
Screw Pack Surface Models A 29.00
HD2100, HD4200, HD5300, HD5400, DKB 29.00
HD5700. Specify model and length.
Screw Pack 1/2 Wood Screws A 11.00
DKB 11.00
Screw Pack Torx (includes TEK & T.B. M.S.) A 31.00
DKB 31.00
Continuous Geared Hinges
Electric Options:
ETW8 . . . . . . . . . . . . . . . . . 468.00
ETW8-MOLEX . . . . . . . . . . . . 505.00
EPT PREP . . . . . . . . . . . . . . 99.00
Replacement Electric Thru Wire Sections:
HD1100A-ETW8 500.00 / EA.
HD1100DKB-ETW8 505.00 / EA.
HD2400A-ETW8 500.00 / EA.
HD2400DKB-ETW8 505.00 / EA.
HD2700A-ETW8 505.00 / EA.
HD2700DKB-ETW8 510.00 / EA.
HD1100A-ETW8-MOLEX 535.00 / EA.
HD1100DKB-ETW8-MOLEX 540.00 / EA.
HD2400A-ETW8-MOLEX 535.00 / EA.
HD2400DKB-ETW8-MOLEX 540.00 / EA.
HD2700A-ETW8-MOLEX 535.00 / EA.
HD2700DKB-ETW8-MOLEX 540.00 / EA.
Accessories:
TIPIT® LG . . . . . . . . . . . . 125.00 / EA.
Continuous Geared Hinges
55
Phone: 800-647-7874
Fax: 800-255-7874
www.ngp.com
orders@ngp.com
Phone: 800-647-7874
Fax: 800-255-7874
www.ngp.com
orders@ngp.com
Stainless Steel Continuous Hinges
Model 83" 85" 95" 119"
SS300 405 435 466 688
SS302 565 656 656 929
SS304 518 595 595 785
SS305 538 569 599 929
SS306 533 630 630 816
SS311 528 605 605 826
SS315 420 451 482 749
Torx Screws . . . . . . . . . . . . . . . . . . . . 58.00
Anti-Ligature Hospital Tip . . . . . . . . . . . . .83.00
Cut Net Length . . . . . . . . . . . . . . . . . . . 52.00
Dutch Door Prep . . . . . . . . . . . . . . . . . 105.00
Polished US32 (629) . . . . . . . . . . . . . . . 475.00
Welded Tips . . . . . . . . . . . . . . . . . . . . 78.00
ETW8 . . . . . . . . . . . . . . . . . . . . . . 575.00
EPT Prep . . . . . . . . . . . . . . . . . . . . . . 95.00
83" 95"
Replacement Fastener Cover - SS Hinge . . . 50 55
Replacement Screw Pack SS300 . . . . . . . 28
Screw Pack Torx - SS Hinge . . . . . . . . .55
Replacement Electric
Thru Wire Section:
ETW8-SS . . . . . . .460.00
Freight prepaid and allowed $1500 net
separately or combined with other
products within continental US.
Stainless Steel Continuous Hinges
56
NATIONAL GUARD PRODUCTS, INC.Phone: 800-647-7874
Fax: 800-255-7874
www.ngp.com
orders@ngp.com
Sliding Door Hardware
Sliding Door Hardware
Stainless Steel Sets:
Part No. Length Price
Top Mount
SLSS1-6 . . . . . . . . . . 78-3/4" . . . . . . . . . . . . . . . . . . 495
SLSS1-6-SC . . . . . . . . 78-3/4" with soft close . . . . . . . . . . 575
SLSS1-8 . . . . . . . . . . 98-7/16" . . . . . . . . . . . . . . . . . 550
SLSS1-8-SC . . . . . . . . 98-7/16" with soft close . . . . . . . . . 630
Side Mount
SLSS2-6 . . . . . . . . . . 78-3/4" . . . . . . . . . . . . . . . . . . 615
SLSS2-6-SC . . . . . . . . 78-3/4" with soft close . . . . . . . . . . 695
SLSS2-8 . . . . . . . . . . 98-7/16" . . . . . . . . . . . . . . . . . 670
SLSS2-8-SC . . . . . . . . 98-7/16" with soft close . . . . . . . . . 750
Option: Cut Track to Net Length — $105
Stainless Steel Components:
Part No. Length Price
SLSS-BS Bracket Spacer . . . . . . . . . . . . 22.50 / EA.
SLSS-DS Door Stop . . . . . . . . . . . . . . . 40.00 / EA.
SLSS-FG Floor Guide . . . . . . . . . . . . . . 17.00 / EA.
SLSS1-H Hanger - Top Mount . . . . . . . . . . 90.00 / EA.
SLSS2-H Hanger - Side Mount. . . . . . . . . 130.00 / EA.
SLSS-6 Track 78-3/4" . . . . . . . . . . . . 198.00 / EA.
SLSS-8 Track 98-7/16" . . . . . . . . . . . . 253.00 / EA.
SLSS-6-SC Track with soft close 78-3/4" . . . . . 303.00 / EA.
SLSS-8-SC Track with soft close 98-7/16" . . . . 358.00 / EA.
