NIDEC MOBILITY J166N Transmitter of Keyless Entry System User Manual 1
OMRON Automotive Electronics Co. Ltd. Transmitter of Keyless Entry System 1
(Short-Term Confidential) User Manual
WARNING
- Changes or modifications not expressly approved by
the party responsible for compliance could void the
user’s authority to operate the equipment.
Your Keyless Operation Key (FOB) operates on a radio
frequency subject to Federal Communications Commission
(FCC) Rules (For vehicle sold in U.S.A.) and Industry Canada
Rules (For vehicles sold in Canada). This device complies with
part 15 of FCC Rules and Industry Canada licence-exempt RSS
standard(s).
Operation is subject to the following two conditions:
- This device may not cause harmful interference, and
- This device must accept any interference, including
interference that may cause undesired operation of this device.
Since this device is always used with vehicle, it is not sold to general end users directly. Therefore there is no user manual of this device.
The following information must be described on the user manual of the vehicle;
AVERTISSEMENT
- Tout changement ou toute modification effectués
par l’utilisateur et dont la conformité n’est pas
expressément approvée par l’organisme responsable
de sa conformité peut entraîner l’annulation de droit
de cet utilisateur de se servir de l’équipment.
Votre clé de fonctionnement sans clé (FOB) fonctionne sur une
fréquence radio relevant de la réglementation établie par la
Commission fédérale des communications (FCC) (pour les
véhicules vendus aux États-Unis) et de la réglementation établie
par Industrie Canada (pour les véhicules vendus au Canada). Cet
appareil est conforme à la section 15 du Réglement de la FCC et
du CNR d'Industrie Canada applicable aux appareils radio
exempts de licence.
Son fonctionnement est soumis aux deux conditions suivantes :
- Ce dispositif ne peut causer d’interférences.
- Ce dispositif doit accepter toute interférences, y compris les
interférences pouvant provoquer un fonctionnment indésirable
de ce dispositif.
CONFIDENTIAL
2. User’s manual
REMOTE TRANSMITTER (installed inside the grip)
You can lock and unlock your vehicle with the remote transmitter.
LOCK
When you push the LOCK button, all the doors are lock.
You cannot lock any of the doors with the module, remote transmitter if any door is open or the key is in the Key
cylinder.
UNLOCK
When you push the UNLOCK button once, only the driver’s door unlocks. The remaining door unlock when you push
the button a second time. If you unlock the doors with the remote transmitter, but do not open any of the doors within
30 seconds, the doors are relocked automatically.
You cannot unlock any of the doors with the transmitter if the key is in the key cylinder.
BOOT RELEASE (Option)
When you press the TRUNK button twice, the boots is open.
The boot is not open if the key is in the key cylinder.
PANIC MODE
When you press the PANIC button, the vehicle starts sounding the horn and flashing the headlight intermittently.
These functions continue for 180 seconds unless any of the buttons on the transmitter are pressed.
TRUNK
LOCK
UNLOCK
PANIC
- 2 -
Copyright 2015 OMRON Automotive Electronics Co. Ltd. All right reserved.
This document and its contents may be used for our application only.
FCC ID, IC Number and Model Number of this transmitter are indicated on the transmitter,
but the transmitter is covered with the keyless entry case under normal conditions.
As this is the transmitter for keyless entry system used in the vehicle, operation instructions for the transmitter and
procedures to open the transmitter’s case are explained in the “procedure for replacing the key battery” section of the
user’s manual for the vehicle.
Consequently, the following note and illustration are shown in the “procedure for replacing the key battery” section of
the user’s manual for the vehicle.
●The Federal Communications Commission (FCC)
ID number, the Industry Canada (IC) number and the
model number (radio certification) are indicated in
the illustrated position.
