NIDEC MOBILITY WK30-ATX-07 Wireless Remote Transmitter User Manual User Manual
OMRON Automotive Electronics Co. Ltd. Wireless Remote Transmitter User Manual
User Manual
2. User’s manual (provisionally)
TRANSMITTER
DOWN
UP LED
POWER
POWER
When you push the POWER, the transmitter start to be active for three seconds.
When you push UP or DOWN button within these three seconds, the transmitter
can transmit signal. (Mode1) If you push UP or DOWN button, it continues being active
for three seconds more. (Mode2)
UP
After you push POWER button, when you continue pushing the UP button,
continue transmitting UP code from the transmitter.
The target to control continues moving up.
DOWN
After you push POWER button, when you continue pushing the DOWN button,
continue transmitting DOWN code from the transmitter.
The target to control continues moving down.
Specification
Mode 1
Mode2
Output
si
g
nal
UP button
(DOWN)
POWER
More than 3s Less than 3s
ON
OFF
ON
OFF
Output
si
g
nal
UP button
(DOWN)
ON
OFF
ON
OFF More than 3s Less than 3s
POWER
