NINGBO BAI JIA ELECTRIC APPLIANCE YLT-40-3C Remote control transmitter User Manual 748178 RC 023 TR 009 1B IM 6412 20140411
NINGBO BAI-JIA ELECTRIC APPLIANCE CO.,LTD Remote control transmitter 748178 RC 023 TR 009 1B IM 6412 20140411
User manual
THANK YOU
Visit us online to see our full line of products available for your home
We appreciate the trust and confidence you have placed in
improvement needs. Thank you for choosing Defiant!
Defiant through the purchase of this indoor wireless remote control.
USE AND CARE GUIDE
INDOOR WIRELESS REMOTE CONTROL
WARNING: For indoor use only.
RATINGS
125 VAC, 60 Hz
15 A General Purpose
15 A Resistive
625 W Tungsten
500 VA Electronic Ballast
1/3 HP Motor
Product Description
Safety Information
1
2
3
1. LED power indicator light:
The LED power indicator light
the receiver is on.
2. Outlets:
The outlet located on the
front of the receiver allow the
user to plug an array of devices
into it.
Plug the lights or devices to b
controlled by the remote into
the outlet.
Federal Communications Commission Interference Statement
This equipment has been tested and found to comply with the limits for Class
B digital device, pursuant to part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio or television reception,
which can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the following
measures:
¨ Reorient or relocate the receiving antenna.
¨ Increase the separation between the equipment and the receiver.
¨ Connect the equipment into an outlet on a circuit different from that to
which the receiver is connected.
¨ Consult the dealer or an experienced radio/TV technician for help.
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and
(2) this device must accept any interference received, including interference
that may cause undesired operation of the device.
FCC Caution: Any changes or modifications not expressly approved by the
party responsible for compliance could void the user's authority to operate
this equipment.
This device and its antenna(s) must not be co-located or operating in
conjunction with any other antenna or transmitter.
Store indoors when not in use.
Operating Instructions
¨To activate the receiver, press the “ON” button of the remote control.
The green LED of the remote control will illuminate momentarily and the
LED of the receiver will remain illuminated.
¨To turn the receiver OFF, press the “OFF” button of the remote control.
The LED on the receiver will shut off.
1 Using the remote control
¨Plug the device you wish to be controlled into the receiver (outlet).
noituloSmelborP
The lights do not turn on and
off via remote control.
Troubleshooting
Confirm remote operation after replacing
batteries.
3. Remote control:
¨ ON: When the on button is
pressed, it will override the
receiver´s current program
to on function.
¨ OFF: When the off button is
pressed, it will override the
receiver´s current program
to off function.
¨ Remote indicator light: The
LED light indicates that the
ON or OFF button is being
pressed.
Maintenance
2 Replacing the battery
¨Remove the battery compartment cover from the back of the remote
control by sliding the cover in the direction that its threads curve.
¨Remove the old battery and place a new DC 12V Type A23 battery into
the battery compartment, correctly observing the polarity indications (+/−)
inside the battery compartment.
¨Replace the battery compartment cover.
¨Dispose or recycle spent/discharged batteries in compliance with all
applicable laws. For detailed information, contact your local solid waste
authority.
WARNING: Do not mutilate or place the battery in a fire. The
battery may burst or release toxic materials. Do not short circuit
or reverse polarity as this may cause burns.
Remove the insulation tab from the battery compartment.
¨
Remote does not turn the
device on or off.
Receiver and transmitter need to be re-synched.
Replug the reciever into a properly gounded outlet
press and hold the ON and OFF buttons on the
untill the green indicator
Model: YLT-40C
and within 15 seconds,
transmitter for 2 seconds
flash 3 times on the reciever.
Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils
radio exempts de licence. L'exploitation est autorisée aux deux conditions suivantes:
(1) l'appareil ne doit pas produire de brouillage, et (2) l'utilisateur de l'appareil doit accepter
tout brouillage radioélectrique subi, même si le brouillage est susceptible d'en compromettre
le fonctionnement.
This device complies with Industry Canada’s licence-exempt RSSs. Operation is subject to the following two conditions:
(1) This device may not cause interference; and
(2) This device must accept any interference, including interference that may cause undesired operation of the device.
