NINGBO BAI JIA ELECTRIC APPLIANCE YLT-42A-3C Remote control User Manual 110527 RC 017X3 TR 011 3 US 20140411
NINGBO BAI-JIA ELECTRIC APPLIANCE CO.,LTD Remote control 110527 RC 017X3 TR 011 3 US 20140411
User manual
THANK YOU
USE AND CARE GUIDE
3-PACK WIRELESS INDOOR/OUTDOOR
REMOTE CONTROL SWITCH
Product Description
Safety Information
1
2
3
2. Outlet:
The outlet located on the
bottom of the receiver allows
the user to plug an array of
devices into it. Plug the light or
device to be controlled by the
remote into the outlet.
Federal Communications Commission Interference Statement
This equipment has been tested and found to comply with the limits for Class
B digital device, pursuant to part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio or television reception,
which can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the following
measures:
¨ Reorient or relocate the receiving antenna.
¨ Increase the separation between the equipment and the receiver.
¨ Connect the equipment into an outlet on a circuit different from that to
which the receiver is connected.
¨ Consult the dealer or an experienced radio/TV technician for help.
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and
(2) this device must accept any interference received, including interference
that may cause undesired operation of the device.
FCC Caution: Any changes or modifications not expressly approved by the
party responsible for compliance could void the user's authority to operate
this equipment.
This device and its antenna(s) must not be co-located or operating in
conjunction with any other antenna or transmitter.
Store indoors when not in use.
Operating Instructions
¨To activate the receiver, press the “ON” button of the remote control.
The green LED of the remote control will illuminate momentarily and the
LED of the receiver will remain illuminated.
¨To turn the receiver OFF, press the “OFF” button of the remote control.
The LED on the receiver will shut off.
1 Using the remote control
Troubleshooting
Remote control:
¨ Channel :
To control various devices
with three different
channels.
¨ When the “ON” button is
pressed, it will override the
program to on function.
¨ When the “OFF” button is
pressed, it will override the
program to off function.
Maintenance
2 Replacing the battery
¨Remove the battery compartment cover from the back of the remote
control by sliding the cover in the direction that its threads curve.
¨Remove the old battery and place a new DC 3V CR2032 battery into
the battery compartment, correctly observing the polarity indications (+/−)
inside the battery compartment.
¨Replace the battery compartment cover.
¨Dispose or recycle spent/discharged batteries in compliance with all
applicable laws. For detailed information, contact your local solid waste
authority.
RATINGS
125 VAC, 60 Hz
15 A General Purpose
15 A Resistive
1000 W Tungsten
1/3 HP Motor
NOTE: This product is suitable for outdoor use and use in damp
locations.
1. Power indicator light:
The power indicator light
indicates that the receiver is on.
¨To set up the three receivers (outlets) with various devices, locate
channel 1, 2, 3, on the remote control and the 1, 2, 3, on each receiver
and select ON/OFF function with the same channel (1,2,3)
respectively.
¨Mount the receiver on a wall near a grounded electrical outlet. The nail
or screw head must extend at least 3/16 in. out from the wall. Hang the
receiver from the slot on the back of the unit onto a nail or screw. Plug
the power supply cord of the receiver into the outlet.
¨Plug the device cord into the receptacle at the bottom of the
receiver.
¨
Installation Instructions
Installation Instructions
3.
noituloSmelborP
The lights do not turn on and
off via remote control.
Confirm remote operation after replacing
batteries.
The lights do not turn on, even
when the power indicator light
indicates that the receiver is on.
Ensure the lights are functional by
plugging them directly into the outlet.
Be sure that the lights are in the “ON”
position if they have their own switch.
Be sure that the outlet that the receiver
is plugged into is active.
3
WARNING: The device must be mounted in a vertical position
with the receptacle facing downward and with the receptacle at
least 2 ft. above the ground level to prevent water immersion.
WARNING: Do not mutilate or place the battery in a fire. The
battery may burst or release toxic materials. Do not short circuit
or reverse polarity as this may cause burns.
We appreciate the trust and confidence you have placed in
Defiant through the purchase of this outdoor wireless remote control.
Visit us online to see our full line of products available for your home
improvement needs. Thank you for choosing Defiant!
Made in China
SAVE THESE INSTRUCTIONS!
1 2 3
Remove the insulation tab from the battery compartment.
Remote does not turn the
device on or off.
Receiver and transmitter need to be re-synched.
Replug the reciever into a properly gounded outlet
green indicator flash on the reciever, then press the
Model: YLT-42A-3C
and within 15 seconds,
press and hold the OFF(2)
button on the transmitter for 1.5 seconds untill the
ON(2) botton.
Information concernant l'exposition à l'énergie radiofréquence
Votre appareil est con u et fabriqué pour ne pas dépasser les limites
d'émission pour l'exposition à l'énergie RF établie par le gouvernement
du Canada (IC). Les informations sur votre appareil sont en fichier avec
l'IC et peuvent être trouvées sous la section Affichage Grant de
https://sms-sgs.ic.gc.ca/equipmentRechercher après la recherche sur
l'IC pour votre appareil, qui se trouve sur le l'arrière de l'appareil.
This device complies with part 15 of FCC rule and Industry Canada:
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including
license-exempt RSS standard(s).Operation is subject to the following
two conditions
interference that may cause undesired operation.
Avis d'Industrie Canada (IC): Cet appareil est conforme avec Industrie
Son fonctionnement est soumisaux deux conditions suivantes:
(2) cet appareil doit accepter toute interférence, y compris celles
Canada exempts de licence standard RSS (s).
(1) cet appareil ne doit pas provoquer d'interférences et
pouvant causer un mauvais fonctionnement de l'appareil.
