NINGBO CSTAR IMP and EXP 0005 Bluetooth speaker User Manual
NINGBO CSTAR IMP&EXP; CO., LTD Bluetooth speaker
User Manual
Book power bank Bluetooth Speaker
INSTRUCTIONS
BLUETOOTH SPEAKER CHARGE CABLE & AUDIO CABLE
Features:
z Bluetooth Speaker
z Power bank Bluetooth speaker
z Bluetooth Hands-free Microphone
z Auxiliary Line-in Play Function
z With Micro SD card playing music
z Micro USB Charging Cable and 3.5mm Line-in Cable
z Rechargeable Battery
Power on / off
z To turn on, Long press the power button .The blue lights will flash quickly .
z To turn off ,Long press the power button and the lights will go off .
Charging
Charge the speaker and ensure full of charge for the 1st time use .Plug the charging cable
into the micro USB port and then connect the charging cable to the USB port of your
PC .Four step blue lights indicate the power energy . It is just charging a power bank .
On the side the Charging in slot ,there is a charging out slot ,can charge
phone and the devices that need power energy.
Bluetooth Mode
Please check to make sure the device to which you are pairing has Bluetooth
capabilities .This information should be included in your phone or device’s instructions or
packaging .
1.Make sure that the speaker is turned off .
2.Place the speaker and the device in proximity so that both devices are in view.
3.Turn the speaker on .The blue lights will flash quickly until paired.
4.To active the Bluetooth mode and functions on your phone or device .see the
instructions for that device .
5.Set the phone or device to search for Bluetooth devices within and select the
speaker .(MusicBook )
6.Once paired ,a beep sound will be heard and the blue light stop flash .The speaker
is now ready for listening to music or answering calls .
Note :Some mobile phones or other devices will pair automatically when re-started the
speaker.
Bluetooth Description
“” Press and hold to increase volume .Press and release for next song .Not
available in AUX Line-in Mode.
“” Press and hold to decrease volume .Press and release for previous song. Not
available in AUX Line-in Mode .
“” Press and release to pause music .Press and release to answer / end a call .
“” Micro SD card playing music
Play / Pause
In the process of playing music ,press the power button to pause or play
music .
Line-in Mode
Plug one end of the provided 3.5mm AUX cable into the smart phone of music player’s
headphone or speaker jack and plug the other end into the music book .Operate the song
selections and volume from the smart phone or other device .
z Volume and next / previous song function buttons are not available in AUX Line-in
mode .
Specifications
z Power supply DC 5V
z Frequency Response 200HZ-200KHZ
z Speaker Power 3W*2(1 KHZ,THD 10%)
z Battery Output 3.7V~4.2V+0.05V
z Input 5v Li-ion
z Bluetooth version V2.1+EDR
z Bluetooth Voice Calls Yes
Precautions
z Please only use the compute USB or the DC 5V power adapter matching the Micro
USB interface to charge .
z Please keep and use in normal environments .Exposure to extreme elements such as
fire ,water ,or other extreme elements may damage the unit .Do not touch with wet
hands .
z Keep debris or other items from blocking the speakers or from entering any of the
ports .
z Do not attempt to open or take apart this speaker .The speaker will be damaged
during that process .
z If the speaker quality seems lessened ,or a slight pooping noise is heard .It may be
due to low battery .Please recharge the device .
TROUBLESHOOTING
No Sound
z Make sure that the music player is working and that the speaker is charged .
z Make sure the Bluetooth is paired and the AUX 3.5mm cable is plugged in properly
on both ends .
z Make sure the TEK126 is in the proper mode .
Not charging
Check to make sure that you are using the correct cable and that it is fully plugged into
both the device and the USB port that you are charging from. Also check to make sure the
PC or other USB charger is turned on .
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two
conditions: (1) this device may not cause harmful interference, and (2) this device must accept any
interference received, including interference that may cause undesired operation.
Changes or modifications not expressly approved by the party responsible for compliance could
void the user's authority to operate the equipment.
NOTE: This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This equipment generates, uses
instructions, may cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct the interference by one or more of
the following measures:
-- Reorient or relocate the receiving antenna.
-- Increase the separation between the equipment and receiver.
-- Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
-- Consult the dealer or an experienced radio/TV technician for help.
